PARTS AND SERVICE INSTRUCTIONS
FOR THE
ELECTRIC FIREPLACE
MODEL NUMBERS:
BF33STP/DXP
BF39STP/DXP
Valued Customer,
We are pleased that you have chosen to purchase an electric fireplace manufactured by Dimplex North America Ltd.
Over the years, valuable memories will occur around the warmth and comfort of your hearth. Thank you for allowing our product to be the backdrop for those special moments.
70000000REV01
1
TABLE OF CONTENTS
OPERATION |
PAGE 3 |
PARTS DRAWING |
PAGE 6 |
PARTS LIST |
PAGE 7 |
WIRING DIAGRAM |
PAGE 8 |
MAIN ON/OFF SWITCH REPLACEMENT |
PAGE 9 |
PURIFIRE SWITCH REPLACEMENT |
PAGE 10 |
HEATER ON/OFF SWITCH REPLACEMENT |
PAGE 11 |
FLAME MOTOR/FLAME ROD REPLACEMENT |
PAGE 12 |
VOLTAGE SELECTOR SWITCH REPLACEMENT |
PAGE 14 |
HEATER ELEMENT REPLACEMENT |
PAGE 17 |
BLOWER MOTOR REPLACEMENT |
PAGE 19 |
TEMPERATURE LIMIT SWITCH REPLACEMENT |
PAGE 23 |
REMOTE CONTROL KIT |
PAGE 27 |
2
PURIFIRE SWITCH
OPERATION
MANUAL CONTROLS (WITHOUT REMOTE OPTION)
The fireplace can be controlled by the manual switches located on the fireplace (FIGURE 1).
Main Power Switch
Main ON/OFF switch, activates the flame effect.
Heater Control Switch
Heater ON/OFF switch, activates heater to the high level.
MAIN POWER HEATER CONTROL SWITCH
SWITCH
FIGURE 1
BFRC
KIT OFF
SWITCH
PURIFIRE
SWITCH
ON
SWITCH
LEVEL 1 |
MAIN POWER |
SWITCH |
|
INDICATOR |
LEVEL 3 |
LEVEL 2 |
|
INDICATOR |
INDICATOR |
FIGURE 2
MANUAL CONTROLS (WITH REMOTE OPTION)
The fireplace can also be controlled in a similar manner to the remote control with the manual switches located on the fireplace (FIGURE 2). (refer to initialization instructions on page 2)
Main Power Switch
Main ON/OFF switch supplies power to the circuit board. When the Main ON/OFF switch is switched to the ON position the Level 1 indicator light will flash.
On Switch
1.Pressing once on the remote control board “ON
SWITCH” activates the Level 1 function.
Level 1: The flame effect is turned on and the first red indicator light is activated.
2.Pressing twice on the remote control board “ON SWITCH” activates the Level 2 function.
Level 2: The flame effect remains on, the Purifire is activated if Purifire switch is in the “-“ position.
Heater remains off.
3.Pressing three times on the remote control board “ON SWITCH” activates the Level 3 function.
Level 3: The flame effect remains on, the Purifire is activated if Purifire switch is in the “-“ position. the heater is set to the high heat setting.
Off Switch
Pressing this button ONCE will turn the unit OFF.
3
BF33STP, BF33DXP, BF39STP, BF39DXP
REMOTE CONTROL
The remote control has a range of approximately 50ft. (15.25m). It does not have to be pointed at the fireplace and can pass through most obstacles (including walls). It is supplied with one of 243 independent frequencies to prevent interference with other units. The frequency designation is indicated on the back of the transmitter (FIGURE 3).
Remote Control Initialization
This procedure is required every time there is a loss of power to the remote control in the fireplace (i.e. power failure, breaker tripped, main power switch is turned off)
1.Ensure that power is supplied through main service panel.
2.Access the manual controls, (remove glass doors if applicable) pull the right hand steel curtain to the side of the unit.
(FIGURE 4)
3.Locate manual controls refer to FIGURE 5.
4.Activate main power switch, (“ ” position is “ON”, “
” position is “OFF”) red Level 1 indicator light will flash.
5. Press and hold the ON switch marked “ ” for five seconds. The red Level 2 indicator light will flash.
6. Press the ON button located on the remote control transmitter
(FIGURE 3). This will synchronize the remote control transmitter and receiver.
Remote Control Usage
The remote control operates the fireplace levels sequentially. The level is increased every time the ON button on the transmitter is pressed. The fireplace can be turned off at any point by pressing the OFF button on the remote control transmitter.
Level 1: The flame effect is turned on and the first red indicator light is activated. Level 2: The flame effect remains on, the Purifire is activated if Purifire switch is in the “-“ position. Heater remains off.
Level 3: The flame effect remains on, the Purifire is activated if Purifire switch is in the “-“ position. the heater is set to the high heat setting.
MANUAL OVERHEAT
CONTROLS INDICATOR
Off Switch
On Switch
Main Power
Switch
|
|
|
|
|
|
|
|
FIGURE 4 |
Level 1 Indicator |
|
|
Level 3 Indicator |
|
||
|
|
|
|
FIGURE |
5 |
||
|
|
|
|
|
|||
|
4 |
Level 2 Indicator |
|
|
|||
|
|
|
|
|
|
|
|
BF33STP, BF33DXP, BF39STP, BF39DXP
RESETTING THE TEMPERTURE CUTOUT SWITCH
The heater on this fireplace is protected with a safety device to prevent overheating.
Should the heater overheat, a red light (Fig. 4) will be activated and an automatic cut out will turn the heater off. The heater will re-activate once the heater has cooled. The overheat cutout will be triggered if the filter is dirty.
WALL MOUNTED CONTROLS
The fireplace can be installed with wall mounted controls. These controls include wall switches and thermostats. (see installation guide for details)
A. Wall Mounted Switches
This model may be installed such that a wall mounted switch activates the flame effect and a wall mounted heater switch activates the heater. A wall mounted switch can also be installed to operate the heater independent of the flame.
B. Wall Mounted Thermostat
This unit may be installed such that a wall mounted thermostat can adjust the heat temperature to your individual requirements. Turn the thermostat control clockwise all the way to turn on the heater. When the room reaches the desired temperature, turn the thermostat knob counter clockwise until you hear a click. Leave in this position to maintain the room temperature at this setting. For additional heat, turn the thermostat clockwise until you hear the click again and the heater will turn on. To turn the heater off, turn the thermostat counter clockwise all the way, and/or turn the manual heater switch on the unit to the OFF position.
VOLTAGE SELECTOR SWITCH LOCATION
IMPORTANT:
Ensure that the incoming power supply voltage matches the setting of the voltage selector switch.
NOTE:
The voltage selector switch is located inside the exhaust panel on the top right hand corner (FIGURE 6).
CAUTION:
When changing the voltage selector switch from 240 volts to 120 volts ensure that the power supply is turned off.
NOTE:
Carefully insert a flat headed screwdriver inside the exhaust panel to change the switch from 240 volts (230 position) to 120 volts (115 position).
5
BF33STP, BF33DXP, BF39STP, BF39DXP |
|
|
|
8 |
7 |
5 |
6 |
12 |
|
|
|
17 |
|
|
9 |
|
|
|
|
13 |
|
|
11 |
|
|
|
|
|
|
|
10 |
|
|
|
15 |
3 |
|
|
|
|
|
|
14 |
1 |
|
|
|
|
|
|
2 |
|
|
|
4 |
18 |
|
|
16 |
|
|
|
|
19 |
|
|
|
6 |
|
|
|
BF33STP, BF33DXP, BF39STP, BF39DXP
REPLACEMENT PARTS
|
DIMPLEX BUILT IN FIREPLACE |
|
|
REPLACEMENT PART |
BF33ST |
BF33DX |
|
1. |
LOG SET |
0438200300RP |
0439230100RP |
2. |
REFLECTOR ROD |
5900081000RP |
5900081000RP |
3. |
GROMMET |
8500000400RP |
8500000400RP |
4. |
FLICKER ASSEMBLY |
6901811200RP |
6901811200RP |
5. |
BLOWER ASSEMBLY |
5300110300RP |
5300110300RP |
6. |
BLOWER MOTOR |
5300110400RP |
5300110400RP |
7. |
HEATER ELEMENT |
2200510100RP |
2200510100RP |
8. |
CUTOUT |
2300260300RP |
2300260300RP |
9. |
VOLTAGE SELECTOR |
2500320200RP |
2500320200RP |
10.MAIN ON/OFF SWITCH |
2800070400RP |
2800070400RP |
|
11.HEATER SWITCH |
2800070700RP |
2800070700RP |
|
12.MIRROR SEMI-SILVERED |
5900161000RP |
5900161100RP |
|
13.EXTRUSION |
0438650200RP |
0438650200RP |
|
14.STEEL CURTAIN |
8800240403RP |
8800240403RP |
|
15.STEEL CURTAIN ROD |
8800250300RP |
8800250300RP |
|
16.LOWER LIGHT HARNESS |
2500370200RP |
2500370200RP |
|
17.FILTER, PURIFIRE |
0439060100RP |
0439060100RP |
|
REPLACEMENT PART |
BF39ST |
BF39DX |
|
1. |
LOG SET |
0438550200RP |
0439070100RP |
2. |
REFLECTOR ROD |
5900080900RP |
5900080900RP |
3. |
GROMMET |
8500000400RP |
8500000400RP |
4. |
FLICKER ASSEMBLY |
6901811200RP |
6901811200RP |
5. |
BLOWER ASSEMBLY |
5300110300RP |
5300110300RP |
6. |
BLOWER MOTOR |
5300110400RP |
5300110400RP |
7. |
HEATER ELEMENT |
2200510100RP |
2200510100RP |
8. |
CUTOUT |
2300260200RP |
2300260200RP |
9. |
VOLTAGE SELECTOR |
2500320200RP |
2500320200RP |
10.MAIN ON/OFF SWITCH |
2800070400RP |
2800070400RP |
|
11.HEATER SWITCH |
2800070700RP |
2800070700RP |
|
12.MIRROR SEMI-SILVERED |
5900160600RP |
5900160700RP |
|
13.EXTRUSION |
0438650100RP |
0438650100RP |
|
14.STEEL CURTAIN |
8800240103RP |
8800240103RP |
|
15.STEEL CURTAIN ROD |
8800250100RP |
8800250100RP |
|
16.LOWER LIGHT HARNESS |
2500370200RP |
2500370200RP |
|
17.FILTER, PURIFIRE |
0439060100RP |
0439060100RP |
|
OPTIONAL ACCESSORIES |
|
|
|
18. REMOTE CONTROL KIT |
BFRC-KIT |
|
|
19. WALL THERMOSTAT |
TS521W |
|
|
7
BF33STP, BF33DXP, BF39STP, BF39DXP |
WIRING DIAGRAM |
8 |
BF33STP, BF33DXP, BF39STP, BF39DXP
If the fireplace was operating prior to servicing allow at least 10 minutes for light bulbs and heating elements to cool off to avoid accidental burning of skin.
Disconnect circuit power before attempting any maintenance or cleaning to reduce the risk of electric shock or damage to persons.
TO REPLACE MAIN ON/OFF SWITCH
1.Open the steel curtains (remove glass doors if applicable).
2.Remove the log grate retaining screws and remove the log grate.
3.Pull the rear edge of the log set forward by grasping the ember bed by the sides (handle the log set only by the ember bed and not the logs) and pulling firmly until the rear tab pops out from under the back ledge, then lift out.
4.Disconnect the log set LED wire harness from unit. (DX MODELS ONLY)
5.Remove the light bulb closest to the main on/off switch for easier access.
6.Locate the switch cover plate and remove the mounting screws.
7.Remove the switch cover plate by releasing assembly from the quick connect connection.
8.Reach hand into the opening and locate the main on/off switch.
9.Depress the retainer clips on the rear of the switch and push the switch out of the bottom cover.
10.Disconnect the wiring connections noting their original locations.
11.Properly orientate the new switch and connect all of the wiring connections.
12.Reassemble in the reverse order as above.
NOTE: To replace the log set re-connect the logset LED wire harness to the unit, insert the front edge, pushing back down until the rear tab snaps under the back ledge and the logs are resting against the mirror.
9
