AA-0477
AA-0479
DESCRIPTION REAR PANEL:
1/ CH A Volume
2/ Power Switch
3/ CH B Volume Knob
4/ CH A distortion Led
5/ CH A protection Led
6/ Power Led
7/ CH B protection Led
8/ CH B distortion Led
AA-0477 44-0479
1 8Ω Stereo Output Power 75Wx2 150Wx2
2 4Ω Stereo Output Power 100Wx2 200Wx2
4 8Ω Bridge Output Power 250W 450W
6 Frequency Response 20Hz-20KHz 20Hz-20KHz
7 THD+N(20Hz-20KHz) <0.1% <0.1%
8 Slew Rate 20V/μs 30V/μs
9 Damping Factor >300 >300
10 Voltage Gain (8Ω rated power@ 0.775V)36dB 39.8dB
11 Output Circuitry Class AB Class AB
12 Signal to Noise Ratio > 80dB >90dB
13 Cross Talk > 70dB >75dB
14 Input Sensitivity(8?) 0.775V, 1.0V, 1.4V 0.775V, 1.0V, 1.4V
15 Input Impedance 20K? balance/10K?unbalance 20K? balance/10K?unbalance
15 Cooling fan Three fans, front -to- rear air flow Three fans, front -to- rear air flow
17 Input Connectors Input XLR Input XLR
18 Output Connectors Speakon Speakon
19 Front Controls AC switch, Ch1 and Ch2 gain knobs AC switch, Ch1 and Ch2 gain knobs
20 Rear Controls Sensitivity, GND, Stereo/Parallel/Bridge Switches Sensitivity, GND, Stereo/Parallel/Bridge Switches
21 Front Panel Indicators (LED) Power On (Blue), Clip (Red), Protect (Red) Power On (Blue), Clip (Red), Protect (Red)
20 Amplifier Protection
Short Circuit, Thermal Overload, Clip Limiter, DC Voltage,
Soft Start,
Short Circuit, Thermal Overload, Clip Limiter, DC
Voltage, Soft Start,
Soft Start, Ultrasonic and RF Protection Soft Start, Ultrasonic and RF Protection
21 Net Weight/Gross Weight 6.7Kg/7.4Kg 7.4Kg/8.1Kg
22 Machine size 483*280*90 483*280*90
Packing Dimensions 510*360*160 510*360*160
23 Power Requirements AC240V-50-60HZ (280Watt) AC240V-50-60HZ (400Watt)
