Digital Watchdog DW-V960H1616T User Manual

1 | H.264 Digital Video Recorder

CAUTION

RISK OF EXPLOSION IF AN INCORRECT TYPE REPLACES BATTERY. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTION. THIS EQUIPMENT IS FOR INDOOR USE, AND ALL THE COMMUNICATION WIRING IS LIMITED TO INSIDE OF THE BUILDING, OR ANY SIMILAR WORD.

Note : Keep this manual handy every time you operate this equipment. Also, check with your dealer

for further assistance and for the latest revision of this manual. Your dealer might provide you with a digital version of this manual. We also ask to keep the original box and packing materials in case of return and for long-term storage of the DVR unit.

Safety Information

The safety information is provided for the wellness of the equipment and for the safety of the operator. Please review and observe all instructions and warnings in this manual.

Preparations before installation

To protect your DVR from damage and to optimize performance, be sure to keep the DVR away from dust, humidity, and area with high voltage equipment such as refrigerator.

Do not install or place equipment in areas where the air vents can be obstructed, such as in tight enclosures or small utility closet. Keeping the unit in a temperature-controlled room with ample regulated power is highly recommended. Do not overload the wall outlet, as this can result in the risk of fire or electric shock.

Uninterruptible power devices such as UPS power surge protectors are recommended, and the DVR units must at least be connected with UL, CUL, or CSA approved power surge protector. Avoid direct sun light and avoid heat.

FCC Information

This equipment has been tested and found to comply with the limits of Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and radiates radio frequency energy, and if not installed and used in

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment under FCC rules.

accordance with the instruction manual, may cause harmful interference to radio communications.

UL Information

- for pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible

- if the battery is placed elsewhere in the equipment, there shall be a marking close to the battery or statement in the servicing instructions.

User’s Manual | 2

Contents

CHAPTER 1 : DVR USER MANUAL

1 GETTING STARTED 8

1.1 Checking Supplied Items 8

1.2 Connecting Peripheral Device 9

1.3 System Startup and Shutdown 10

2 EXPLANATION FOR EACH FUNCTION 12

2.1 Front Panel 12

2.2 Rear Panel 13

2.3 IR Remote Controller 14

3 OPERATION 15

3.1 User Log-in 15

3.2 Quick Startup Wizard 16

3.3 Live Display Mode 17

3.4 PTZ Operation 22

3.5 Freeze Mode 23

3.6 Call Monitor Operation 24

3.7 Playback of Recorded Video 24

3.8 Single Channel Playback in Live Mode (Cameo) 26

3.9 Quick Backup during Playback 27

3.10 Search Recording Image 28

3.11 DST Setting 33

3.12 Screen Saver 34

4 SETTING 35

4.1 System 36

4.2 Device 44

4.3 Record 49

4.4 Network 52

4.5 Backup 56

4.6 Quick Setup 58

5 WEB SURVEILLANCE 59

5.1 Web Login 59

5.2 Web Configuration 60

5.3 Web monitoring 62

5.4 Web Playback 65

3 | H.264 Digital Video Recorder

CHAPTER 2 : CMS CLIENT SOFTWARE USER MANUAL

6 CMS USER GUIDE 68

6.1 PC REQUIREMENT 68

6.2 INSTALL 68

6.3 UNINSTALL 71

6.4 BASIC OPERATION 72

6.5 CMS FUNCTIONS 81

6.6 CMS SETUP 88

CHAPTER 3 : ACS CLIENT SOFTWARE USER MANUAL

7 ACS USER GUIDE 97

7.1 System Requirement 97

7.2 Install 97

7.3 Uninstall 99

7.4 Basic Operation 99

7.5 Advanced Operation 105

7.6 ACS Setup 108

CHAPTER 4 : MAC ACS CLIENT SOFTWARE USER MANUAL

8 MAC ACS USER GUIDE 115

8.1 System Requirement 115

8.2 Install 115

8.3 Basic Operation 116

CHAPTER 5 : FACESTAMP SOFTWARE USER MANUAL

9 FACE STAMP SOFTWARE 126

9.1 Face Stamp Software Set-up 126

User’s Manual | 4

CHAPTER 6 : MOBILE PHONE SOFTWARE USER MANUAL

10 MOBILE PHONE SOFTWARE USER GUIDE 134

10.1 iPhone application software 134

10.2 Android application software 144

10.3 Using WAP+3G Connection 154

APPENDIX : DYNDNS SITE REGISTRATION 156

APPENDIX : NETWORK SETUP FOR EXTERNAL USAGE 158

APPENDIX : SPECIFICATION 160

5 | H.264 Digital Video Recorder

User’s Manual | 6

Chapter 1

DVR USER MANUAL

7 | Chapter 1 : DVR User Manual

User’s Manual | 8

Items


Quantity

User Manual (DVR & Software)

Quick Start Guide

1 Set 1 Set

CD (Manual & Software) Rubber Mount

1 Set 1 Set (4 Pieces)

12V DC Adaptor Power Cable

1 Set

IR Remote Controller

1 Set

USB Mouse

1 Set

Ground Screw

1 Sst (1piece PVS Rear /

1piece )

1 GETTING STARTED

1.1 Checking Supplied Items

Make sure that you have the following items supplied with your DVR. If any of these items are missing or damaged, notify your vendor immediately. Keep the packing utilities for moving or storage purposes afterwards.

9 | Chapter 1 : DVR User Manual

NOTE

Install the system in a location with good ventilation to prevent overheating.

WARNING !

※When connecting power cord to the system, it is strongly recommended first to plug the power cord to the system and then plug the other side of power cord into the wall AC socket.

1.2 Connecting Peripheral Device

This section describes how to connect peripheral devices efficiently to the DVR.

Install the DVR on flat surface. If required, attach a rubber mount for installation. If a 19-inch rack is used with 1.5U Height case, it is recommend to install the system on a shelf and use 2.5~3U (1U=1.75 inch or 4.45 cm) space for proper ventilation.

[8CH (W)428x(H)93x(D)446mm]

[16CH (W)428x(H)93x(D)446mm]

User’s Manual | 10

NOTE

Do not forget the administrator’s password that was set for the first time. In case the password is lost, contact your vendor.

NOTE

The mouse is included. In case you need to replace it, it is highly recommended to choose well-known major brands such as DELL, MICROSOFT, LOGITECH, or SAMSUNG.

1.3 System Startup and Shutdown

1.3.1 System Startup

After connecting peripheral devices such as cameras, monitors and a mouse to the DVR, power up the DVR by connecting DC12V 9A adaptor to the power jack on the rear panel. The boot log will display as shown below. Please wait until the boot process completes.

There is only one Administrator Account configurable in the DVR system. It is assigned with an unchangeable User ID marked as ‘admin’. The default password is empty (No Password). Administrator account has full access to the DVR and its configurable parameters. The Administrator Account also has the ability to create new users and to assign rights to the new user accounts. Those new users created by ‘admin’ account can also login with a specific password set by ‘admin’ account.

11 | Chapter 1 : DVR User Manual

NOTE

It is not recommended to disconnect the power cable abruptly from the back of the DVR because it may affect the DVR and Hard Drive.

NOTE

User can type in the password using the virtual keyboard or the numeric buttons on the IR remote controller.

1.3.2 System Shutdown and change password

Option 1. Click the Shutdown button and input password on pop-up to power off the DVR

Option 2. Click the right button on the mouse and select the Shut Down to power off the DVR.

The default password for ‘admin’ account is none. Therefore, just click ‘Enter’ button on the dial pad. If you changed the password for ‘admin’ account, please type in the changed password to login.

No.

Buttons

Functions

Menu / Exit

Menu / Exit toggled button

Mode

Change screen display mode

Freeze

Freeze display screen on/off

PTZ

PTZ control on/off

Instant Record Button

Emergency Recording

Go to search mode

Instant Play

Full screen Reverse Playback

B-Mark

Bookmark set-up in playback, Bookmark search in Live

Call Monitor

Enable to select the camera channel to set it for spot output in full screen model

I-Backup

Instant Backup

11 Fast rewind

12 Playback, Reverse Playback togged button

13 Pause in playback

14 Stop Playback

Fast forward

Enter button (execute selected menu and designated value)

Direction button to control the menu

Open

Toggle to open and close DVD±RW

DVD±RW Bay

Bay for optional DVD±RW

1~16

Channel selection button from CH1 to CH16

Jog / Shuttle

Jog & Shuttle to manipulate playback speed

2 x 2.0 USB ports (mouse, backup, F/W update)

LED Indicators

Indicate status of Power(green) Record(red) Network(orange)

NOTE

I- Backup (Instant Backup)

In playback mode, the user can press the “I-backup” button on the frontal keypad to configure both “start” and “End” time. Once the “Start” and “End” time is set, click the “Start” button to start the backup process.

2 EXPLANATION FOR EACH FUNCTION

2.1 Front Panel

[8/16CH (W)428x(H)93x(D)446mm]

User’s Manual | 12

13 | Chapter 1 : DVR User Manual

No.

I/O

Functions

VIDEO-IN

Camera Input from CH1 upto CH16 (Auto-detect NTSC/PAL)

LOOP OUT

Loops through output from CH1 upto CH16

VIDEO OUT

Main output in composite

SPOT OUT

Programmable digital spot outputu

e-SATA

e-SATA for external storage device

NAS

Network port for network attached storage (10/100)

VGA

Main output in D-sub 25pin

RS-232C

Serial port for external devices

HDMI

Main output in HDMI

Ethernet

Gigabit Network prot (10/100/1000)

PTZ / KEYBOARD

2 x RS-485 for PTZ cameras and keyboard controller

ALARM IN

Alarm Input

Alarm Output

Alarm output (2 relay output and 2 TTL output)

MIC IN

Microphone input

AUDIO IN

Audio input (amplifiered)

AUDIO OUT

Audio out 1 (green) : Main audio output (amplifiered) Audio out 2 (blue) : Audio output for is used for head set.

Power On / Off Switch

Power On/Off Switch

POWER

Main power supply connection (Default : 12 V, 9A)

Ground to protect DVR (Installed in rackmount kit)

NOTE

Carefully check whether the specification of the peripheral devices matches the DVR’s specification.

2.2 Rear Panel

[8CH (W)428x(H)93x(D)446mm]

[16CH (W)428x(H)93x(D)446mm]

User’s Manual | 14

No.

Functions

Instant (Emergency) Recording Button

Numeric Button

Auto-Sequence Button on Live Display Mode

Freeze Button

Call Monitor Button

Channel Selection Button

Instant Playback Button

Search Button

OK (Select) Button

Audio Mute Button

Playback Button on Search Mode (Fast Backward/Playback/Stop/Fast Forward)

Exit Button

Display Mode Button

Zoom Button

Bookmark Button

Zoom In & Out Button

Backup Button

PTZ Button

Direction Button (Up/Down/Right/Left)

Menu Button

ID Select Button (DVR1 ~ DVR8)

2.3 IR Remote Controller

In order to use IR Remote Controller, the ID of the IR Remote Controller must be same as the ID of the DVR.

(Default ID # for DVR and IR Remote Controller is “1”.)

If you have more than two DVRs, you are able to control them individually with just one remote controller by setting up ‘Remote ID’. (The Remote ID is adjustable from ‘1’ up to ‘8’.)

The function buttons of the IR Remote Controller are as below.

15 | Chapter 1 : DVR User Manual

NOTE

1) <LOGIN> window will be permanently displayed in monitor as above picture until user logs in with the right ID and password.

2) If it is set as Auto Log-In, DVR does not require LOG-IN. (Please refer to 4.1.2 User.)

3 OPERATION

3.1 User Log-in

Check the power connection. The system can be used after power-on.

The DVR has various setting categories. The administrator can set the system password and <User> to prevent unauthorized changes to setting values and alteration of recorded file.

Enter the <Admin> or <User> password which had been set by using the virtual keyboard.

User’s Manual | 16

3.2 Quick Startup Wizard

Quick Startup Wizard is specially designed to make it much easier for the major DVR settings such as Time/Date setup, Record setup, Network setup and Quick setup. When the DVR boots up, the Quick Startup Wizard operates automatically. It can be disabled by setting in the main menu.

17 | Chapter 1 : DVR User Manual

NOTE

In playback mode, the maximum resolution is 960x480 / 960x576(NTSC/PAL).

3.3 Live Display Mode

3.3.1 Full HD(1080p) Live Display

Full HD Live Display can is available in live quad (4) mode by using its HDMI and VGA output.

3.3.2 5x Signal Extender (Built-in 4CH)

The adjustable 4CH built-in Image Enhancer enables to extend the distance coverage upto 900m (2950ft) between the cameras and DVR. tO enable, go to ‘Camera Setup’ in the DVR’s main menu and chekk the ‘5x Signal Extender’ check box. This feature is available for channels 1~4 only.

User’s Manual | 18

3.3.3 Channel Selection

Channel selction can be done by following one of the steps below:

1. CH1~CH16 buttons loicatd on the top of the front panel.

2. 1~16 buttons on the IR Remote Control.

The display mode can be changed by pressing the ‘MODE’ button on the DVR’s front panel.

The live images can be displayed in real-time in 1, 4, 9, 16 screen splits. Whenever the left/right arrow button on the front panel or IR remote controller is pressed, the screen will be sequentially changed.

[1 Ch] [4 Ch]

[9 Ch] [16 Ch]

To select channel by mouse, click target channel single time to display in full screen. To return to previous display mode, click the screen again.

To view the pop-up menu, right click anywhere on the display screen.

19 | Chapter 1 : DVR User Manual

Icon to be shown

at right-upper corner on each channel screen

Icon to be shown

at right-bottom corner on full screen.

Continuous Recording

Audio Channel

Motion Recording

PTZ Control

Sensor Recording

No HDD, Smart Alarm & HDD Failure

Continuous+ Motion Recording

Sequence display on

Continuous + Sensor Recording

Digital zoom on

Motion + Sensor Activating Recording

Continuous + Motion Recording + Sensor Activating Recording

Emergency Recording

FaceStamp Recording

3.3.4 Icons

The live mode display’s icons or messages will be indicated on the screen to indicate the system mode or status.

Below are the icon categories that are indicated on the monitor.

The sliding menu for display will be appeared when mouse cursor move into bottom and right click of mouse enale to access pop-up-menu.

To show the menu bar, move the mouse’s cursor to the bottom of the screen. The menu bar will be displayed.

Menu button. When pressed the following options will appear: System Setup, Search, Playback, Logout.

Screen split options- each button represent a different display option. Select from single channel, 4

channel, 9 channel, or 16 channel display.

User’s Manual | 20

NOTE

If you cannot find any colored-mark in the top right corner of the live screen mode, that means that no recording mode has been set for the specific channel. Check the recording schedule for that camera in the main menu options.

Sequence- if pressed, the system will start displaying all the channels in sequence mode. To stop, press the button

again, or right click on the screen and select ‘SEQUENCE’ (See section 3.3.5 Po-Up Window).

CH. Buttons- use these buttons to view a specifc channel in full screen mode. Simply

press the channel number of the desired camera to view it in single channel mode.

“instant (emergency) recording”- In emergency recording, the system will record video based on the panic record settings. Default settings for panic record are: 30FPS @ 960x480. If you want to change the panic record settings, go to RECORD  Panic Record.

Enable/ Disable “PTZ” mode- In PTZ mode, user can move pan/tilt and zoom-in/out in supported PTZ cameras by

moving the mouse pointer, like a virtual joystick.

Go to Instant playback.

shows 60%, then 60% of HDD space has been used up for recording.

To hide the menu bar, move the mouse’s cursor away from the menu bar.

HDD usage indicator- This button will indicate the percentage of your HDD being used for video recording. If it

3.3.5 Pop-up Menu

Right-clicking anywhere on the screen will open up the pop up sub-menu as shown below:

21 | Chapter 1 : DVR User Manual

DISPLAY- Select the display split from the available options:

- 1 Screen- Single channel. Automatically displays CH1. If you select 1 Screen again, the next chronological channel will be displayed.

- 4 Screen- Quad mode. Automatically displays channels 1~4. If 4 Screen is selected again, the next chronological 4 channels (5~8) will be displayed.

- 9 Screen- Automatically displayes channels 1~9. If 9 Screen is selected again, the next cohoronological channels (10~16+1~2) will be displayed.

- 16 Screen- Displays all 16 channels (available only in 16 channel models)

SEQUENCE- when selected, icon will appear on the bottom right corner of the screen, and the display screen will be sequentially changed (Please note, option will be disabled if display area is in 16 channel mode).

ZOOM- Enables/ disables digital zoom function. When enabled, icon will appear and zoomed area will be displayed on the bottom right corne. The Zoom will automatical y focus on the center of the camera’s display. To adjust ot, go to the small zoom display at the bottom of the camera display and move the yellow frame to the desired are you would like to view in zoom. To move the yellow frame, use your mouse to drag the lines of the yellow frame to the desired location. To go back to live display mode, right-click on the screen and select “ZOOM” again.

When a camera is disconnected, a warning sound, or a pop-up window will appear on the screen, depending on the system settings.

FREEZE- Freezes the current image. See section 3.5 Freeze for more information. CALL MONITOR- Enter Call Monitor Control Mode. See section 3.6 Call Monitor for more information. PTZ CONTROL- Open the DVR’s PTZ control. See section 3.4 PTZ for more information. INSTANT REC- Start Panic Recording. PLAYBACK- Select playback option:

- 10, 15, 30, 60 seconds- start playback from the selected number of seconds ago.

- 2, 3, 5, minutes- start playback from the selected number of minutes ago.

- Open Playback Mode- automatically go to instant playback.

SEARCH- Select video search options:

- Date/ Time- open calendar search.

- First/ Last Data- Go to the first or last recorded data.

- System/ Event Log- open log search window.

- Bookmarks- open bookmark search.

- Cameo- change selected channel to single channel playback in live mode.

SETUP- open the DVR’s main menu. LOGOUT- User logout.

As the Admin user, you can seup up multiple users with different levels of authorization. If a certain user is not allowed to view a certain camera in live or playback, then no image will appear on the display screen. To create, delete, or modify users, go to the main menu and select system settings. See section

User’s Manual | 22

NOTE

Full PTZ functions are available by using USB mouse, IR remote control, or keyboard controller and are available only on supported PTZ cameras.

NOTE

User will see numeric pad to select “Preset” number. The preset is defined by setting a PTZ protocol in the setting menu. The maximum number of preset is 255, but the number of available presets may vary by camera make and model.

3.4 PTZ Operation

Before starting PTZ control, please make sure the camera you wish to control is a supported PTZ camera and is installed and configured properly. See section 4.2.6 PTZ for setup information. To enter PTZ mode, follow one of the options below:

1. Right-click on the screen and select PTZ Control.

2. Click on the joystick button in the menu bar located on the bottom of the main screen.

3. Press the PTZ button on the DVR’s front panel, or

4. Press the PTZ button on the IR remote control.

In PTZ mode, user can control PTZ operation with the USB mouse.

While pressing the left button of the mouse, drag the mouse pointer up/down, left/right to move pan/tilt position of the camera accordingly. The further away from the center of the screen you move the mouse, faster will the camera move. The user can also zoom-in/out by rolling the wheel of mouse up or down.

For focus control in PTZ mode, right-click to get the pop-up menu as shown below. Default mode is to “ZOOM”. Select “FOCUS” to switch the mouse’s wheel function from zoom-in/out to focus near/ far.

The user can also select the preset button to start/ stop a preset, or exit PTZ screen model.

23 | Chapter 1 : DVR User Manual

CAUTION

Depending on PTZ camera, some preset positions might be skipped if, for example, the PTZ camera cannot mechanically move or control focus within the interval time required by the DVR. In this case, it is recommended to increase the interval settings to a value that allows for the cameras to finish its Pan & Tilt.

User can automatically switch PTZ camera positions according to defined presets by using the GUARD TOUR function. The connected PTZ camera must support touring functions. “GUARD TOUR” on the pop-up menu can be enabled only in full screen mode. See 4.2.6 PTZ for instructions on how to setup the GUARD TOUR.

3.5 Freeze Mode

Press FREEZE button on the front panel, or click the right button on the mouse and select the Freeze mode while viewing a live image. In the Freeze mode, the image from the cameras will freeze, but the the date/ time information at the bottom of the screen will not. To resume the live view, press FREEZE again, or click the right button on the mouse and select the FREEZE.

User’s Manual | 24

NOTE

- A spotout monitor displays another spotout monitor’s video in full screen through the function

- In spot sequence, if Call monitor is selected, spot sequence stops and selected channel pops up.

- While call monitor runs, if a channel event happens, Call monitor stops and the event pops up.

3.6 Call Monitor Operation

Press the CALL MON button on the front panel, or click the right button on the mouse and select the CALL MONITOR to enter call monitor control mode. The numeric panel will pop up at the center of the screen.

Enter the channel number on the numeric panel to display full screen mode out of assigned spot out channels.

▪ Press the close button on the bottom of the numeric panel to go back to the previously programmed spot monitor mode.

3.7 Playback of Recorded Video

To play a recorded video, press the Play button from the menu bar, or the Instant Play in the DVR’s front panel or on the IR remote controller.

The recorded files can be seen in rewind or fast forward modes. Press the rewind and fast-forward buttons to control the playback’s speed ( 2, 4, 8, 16, 32 times real time when playing backwards or forwards).

User can click playback button to automatically play the latest video clip in rewind mode.

25 | Chapter 1 : DVR User Manual

Button

Function

Jump to first data. If recording is set to motion, system will jump to previous recorded motion video.

Fast rewind

Frame-by-Frame Rewind

Play video in rewind

Pause video

Stop Playabck. When selected, the Playabck menu window will appear.

Playback video

Frame-by Frame playback

Fast playback

Jump to last data. If recording is set to motion, system will jump to the next recorded motion video.

Go to calendar search

Bookmark Video

Export/ Instant Bakup

Exit Playback to Live mode.

In playback screen, user can make various playback modes, make an instant manual backup (archive), go to calendar search mode, change channel, and change screen modes. By clicking the left mouse button in the colored-time bar, the user can jump to a different time in the recording. In addition, user can move the vertical search bar and release by dragging it back and forth to search the desired time in detail.

User’s Manual | 26

3.8 Single Channel Playback in Live Mode (Cameo)

Single channel playback can be displayed while other channels are still in live mode. In live view mode, right-click on the channel that you want to view in playback and select Search Single Channel Search.

Hover the mouse’s cursor over the selected channel to display the playback control bar. Use the playback control bar to playback, fast rewind, pause and play the video. The channel in playback mode will be indicated by a blue frame around it. To return to live mode, press the x button on the top right-hand corner of the playback control bar.

27 | Chapter 1 : DVR User Manual

NOTE

The “HELP” button oofers interactive help, recommended settings and step-by-step instructions on how to correctly setup main functions in the DVR. For example, if you need help on how to set “BACKUP”, click “HELP” button at the right bottom of the BACKUP menu.

3.9 Quick Backup during Playback

User can easily archive video while viewing the video during live or playback mode.

1. In playback mode, press and hold the “I.BACKUP” button on the front panel to set start time for the backup video. “INSTANT BACKUP START” will appear at the bottom right hand corner of the display.

2. Press the “I.BACKUP”button again to set the backup’s end time. The backup menu window will pop-up.

3. If necessary, adjust the following options:

a. Select the channels to be included in the backup file.

b. Adjust the start and end time of the

backup file.

c. Select to include the Backup Viewer with

the archived file.

d. Calculate the expected size of the

backup file

e. Device- CD/DVD or USB thumb drive.

f. Complete the backup.

3.10 Search Recording Image

3.10.1 Date/Time Search

To search your recorded data by date/ time, follow one of the options below:

1. Click the quick Menu button at the left side of the menu bar, select Search Date/ Time

2. Right-click anywhere on the screen, select Search Date/ Time

The calendar window will appear, Days with recorded data available will be indicated in RED.

User’s Manual | 28

1. Select from the calendar the date. If necessary, use the manual year and month options on the left side to adjust the calendar view.

2. The ‘Intelli-Search Bar’ at the bottom of the window will display hours when recorde data is availablein color code. Once the recorded video data of the selected date is shown, user can adjust the vertical search line to the time that user wants to search by dragging a mouse. As the vertical line is moving back and forth, user can see “the Search time” clock is also changing. When user decides the Search time, click Play to see the selected video data.

3. The colors of the time bar are different, depending on the recording mode.

29 | Chapter 1 : DVR User Manual

CAUTION

Dark Blue Color- The data recorded during DST (Daylight Saving Time) will be indicated in Dark Blue

color in the Intelli-Search Bar on playback mode.

No color - NONE- Camera has no recorded data for the selected time. Red- Panic recording- recording triggered by the user when pressing the Instant/ Panic Recoreding. Yellow- Continuous recording. Green- Motion recording- The system records only when motion is detected. Orange- Sensor recording- The system records when a sensor is triggered and only during the dwell time as set in

“SENSOR” of the “DEVICE” menu. If “SENSOR” is disabled under the “DEVICE” menu, and recording schedule is set to “SENSOR”, the system will not record even though a sensor is triggered.

Blue- “Continuous” + “Motion”-The system records continuously and will switch to the motion recording configuration if

motion is detected in the motion area. The system will also send a “motion event” message to the Pivot Client Software over the network. If “MOTION ALARM” is disabled in the “DEVICE” menu, and recording is set to “CONT + MOT”, the system will record with continuous recording even when motion is detected in motion area.

Orange- “Continuous” + “Sensor”- The system records continuously and will switch sensor recording if a sensor is

triggered during dwell time. The system will also send a “sensor event” message to the Pivot Client Software over the network. If “SENSOR” is disabled in the “DEVICE” menu, and recording mdoe is set to “CONT + SENS”, the system will record with continuous recording even when a sensor is triggered.

Pink - “Motion” + “Sensor”-The system records only when motion is detected AND when a sensor is triggered at

the same time. If ‘MOTION’ and ‘SENSOR’ are both disabled in the “DEVICE” menu, the system will not record nor notify the Pivot Client Software when motion occurs or a sensor is activated.

Purple- “Continuous” + “Motion” + “Sensor”- The system records continuously and will switch to ‘MOTION’ or

‘SENSOR’ recording mode if motion is detected in the motion area, or if a sensor is triggered during dwell time.

4. To view video from the selected time, follow one of the options below:

a. Use the manual hour option to view specific hours of the day.

b. Using the table, click on the hour you would like to view in playback.

5. Press the ‘Play’ button at the bottom fo the window. The system will display all channels in playback mode, corresponding to the selected date and time.

User’s Manual | 30

NOTE

If an alarm or event do not appear in the envent log, check the alarm settings, and connection port at the DVR’s rear panel.

3.10.2 Event Log

The Event log search allows you to search for a particular event, quickly and easily, displaying the search results in a detailed table format.

1. To open Event Log Search, perform one of the following options:

a. Click quick menu button, select Search Event Log

b. Right-click anywhere on the screen ans select Search Event Log.

2. Select the date you would like to search.

3. Select which events should be included in the log report. Select from: Sensor, Motion, Video Loss, Panic Recording, HDD Full, or All.

4. Press ‘Search’. The system will display all search results in the table, starting with the latest events.

5. Use the buttons on the bottom of the window to move between the log report’s pages.

6. If necessary, export this log report to a USB memory device in text file format.

a. Attach a USB memory stick to the USB port

b. Press “SCAN” to detect the USB stick

c. Press “EXPORT” to copy the log information to the media.

To see video associated with a particular event, press the play icon next to the event you would like to view.

31 | Chapter 1 : DVR User Manual

3.10.3 System Log

The system log search allows you to search for any changes made to the system, quickly and easily, displaying the search results in a detailed table format.

7. To open System Log Search, perform one of the following options:

a. Click quick menu button, select Search System Log

b. Right-click anywhere on the screen ans select Search System Log.

8. Select the date you would like to search.

9. Select which events should be included in the log report. Select from: System, Setup, Network, or All

10. Press ‘Search’. The system will display all search results in the table, starting with the latest events.

11. Use the buttons on the bottom of the window to move between the log report’s pages.

12. If necessary, export this log report to a USB memory device in text file format.

a. Attach a USB memory stick to the USB port

b. Press “SCAN” to detect the USB stick

c. Press “EXPORT” to copy the log information to the media.

Once export is completed, the user can find a date folder created in USB thumb drive.

There is “system.log” file stored in the date folder.

User’s Manual | 32

NOTE

20 numbers of log record will be shown on one page of the <System Log> and <Event Log> window. User can click the arrow icon to search the log records on another page.

NOTE

Press “SEARCH” on the front panel to get the SEARCH pop-up menu as shown above. In this menu, full search functionality is controlled using the front panel key buttons.

3.10.4 First Data

If selected the system will go to the first screen of the recorded video. This is the oldest video recorded.

3.10.5 Last Data

If selected, the syste, will go to the last screen of the recorded video. This is the latest video recorded.

3.10.6 Bookmark

If selected, the syste, will go to the bookmark list to search the recorded video data in the bookmark list. You can create your

own bookmark list by clicking the button during playback. When you perform a bookmark search, all bookmarked

videos will appear in a table format, allowing you to easily playback the bookmarked video data by clicking the button, right next to each bookmark.

33 | Chapter 1 : DVR User Manual

3.11 DST Setting

DST starts at 2:00 local time on 2nd Sunday of March, and ends at 2:00 DST on 1st Sunday of November in most of North America.

During DST (Daylight Saving Time) period, DVR time clock has to be adjusted according to regional time zone. That is, the DVR time clock will be shifted by one hour after the DST settings start, and the DVR will restore the time clock back to normal after DST ends.

To make DST setting on the DVR, go to the menu: SYSTEM > SYSTEM INFO and click “DATE/TIME” to get the DST setting window as shown below. Setup DST “Begin & End” time after checking the “USE DST” box.

Since the clock jumps forward when DST begins, from 2:00 to 3:00, no data will be displayed on the search mode for all channels for one hour due to DST.

When DST ends, the clock will jump backwards, from at 2:00 to 1:00. In this case, there will be an hour of overlapped video. The overlapped video will be indicated in a blue color in the Intelli-Search Bar during playback mode.

User’s Manual | 34

NOTE

The SCREEN SAVER will not work when WAITING TIME is set to “NONE” or both SPOT and VGA checkbox are unchecked. SCREEN SAVER may not work during system upgrade, HDD formatting, or data backup process. The system will continue recording while the monitor is turned off. See 4.1.2USER for more information on “AUTO LOGOFF” settings.

When the overlapped video is selected in playback mode, a message titled “Recorded video Selection” will pop up. The user can then select to play DST data or Non-DST data.

Click OK to play DST image. Click CANCEL to play Non-DST image.

[“DST” image is displayed on screen] [“Non-DST” image is displayed on screen]

3.12 Screen Saver

To setup a screen saver for your DVR, go to the menu setup: SYSTEM > SYSTEM INFO and click “SCREEN SAVER” to get the SCREEN SAVER setting window as shown below.

Select CRT and/or VGA, and set the WAITING TIME for when the monitor will automatically turn off. Select the waiting time from: NONE, 1,2,3,4,5,6,7,8,9,10,20,30,40,50, and up to 60 MIN

To turn on the selected monitor, click with your mouse, press any frontal key buttons, or press any buttons on the remote controller.

35 | Chapter 1 : DVR User Manual

Main Classification

Sub Classification

SYSTEM

SYSTEM INFO

USER

EXPORT/IMPORT

HDD

FACTORY DEFAULT

FACE STAMP

DEVICE

CAMERA

AUDIO

SENSOR

MOTION ALARM

EXTRA ALARM

PTZ

RECORD

RECORD SETUP

PANIC RECORD

LIVE STREAM SETTING

SCHEDULE

HOLIDAY

NETWORK

DDNS

NOTIFICATION

BACKUP

NAS BACKUP

NAS SERVER

Q.SETUP

QUICK SETUP

4 SETTING

General setting structure consists of “System”, “Device”, “Record”, “Network”, “Backup,” and ‘Quick Setup” as shown

To move between the menu options, move the mouse pointer from “System” through “Quick Setup” to instantly display the sub-menus. Click on any sub-menu to acces it.

User’s Manual | 36

4.1 System

4.1.1 System Info

The System Info sub-menu includes the following setup options: Date/ Time, HDMI Resolution, Language, Remote ID, Version & System Upgrade, Video Signal, IP & MAC Addresses, Keyboard Setup, NTP Setup, Display Setup, and Screen Saver Setup.

37 | Chapter 1 : DVR User Manual

CAUTION

It is recommended to format the HDD after finishing the firmware upgrade because the data recorded by previous firmware may cause malfunction of DVR due to different format. It is highly recommended to check all functions and menus after a firmware upgrade for proper layout and performance. If necessary, you can return system to its default settings.

- Date/ Time- manually enter the DVR’s date and time, time zone, and enable/ disabled DST.

Using the available options, manually adjust the date and time from the calendar, select the display mode for the time, and the date, and select the appropriate time zone. If applicable, check the ‘USE DST’ box. See section 3.12 DST Setting for more information.

- HDMI Resolution- Select the DVR’s output resolution. DVRs support the following video resolutions: 800x600, 1024x768, 1280x1024, 1920x1080. User must set the proper resolution according to the monitor resolution

- Language- Select the DVR’s display language from the availanle in the drop-down menu.

- Remote ID- Set the DVR’s remote ID. This ID should be the same as the IR Remote Control.

- Firmware Version & system upgrade- when a new version is available, use the easy upgrade menu to upgrade your DVR to the latest version. To upgrade your system, follow one of the options below:

Upgrading system using USB memory stick:

1. Insert the USB thumb-drive formatted by FAT32 in any USB port of DVR (compatible with USB 2.0)

2. Once the system detects the thumb-drive, user can see its brand or model name in the “DEVICE” field after pressing the “SCAN” button.

3. Click “OK” to confirm.

Upgrading system using Digital Watchdog’s FTP server:

1. Select FTP in the drop-down list and type a given IP address in the Host Address (Digital Watchdog’s FTP Server IP Address: 208.179.32.42). Username and password is “none” (Default). *The FTP server address is subject to change without a prior notice.

2. Click ‘Check’ button then DVR will detect the latest Firmware version from the FTP server. If there is a new firmware, DVR will ask you whether you want to upgrade it or not.

3. Click ‘OK’ to confirm it and then click ‘START’ to start upgrading.

- Video Signal- Displays the video out signal from the DVR.

- DVR’s IP & MAC Addersses- This information is necessary when connecting to the DVR via its web viewer or the Pivot Client Software. See section 4.4 Network for more information and configuration options.

- Keyboard setup- Setup the DVR’s ID, baudrate and model to match the information of the keyboard you would like to use. The Keyboard’s ID must match the ID set in the DVR.

User’s Manual | 38

- NTP Setup- Setup the DVR to automatically sync with a Network Time Protocol. There are two types of TIME SYNC MODE:

o Server Mode- The DVR is set as a Time Sync

Server, which can synchronize its own time with another DVR(s) connected over the same network environment.

o Client Mode- The operating DVR is set as the

client DVR. Enter the IP address or URL of another DVR, Advanced Client Software (ACS), or Central Management System (CMS), as a Time Sync Server in “SYNC SERVER”. This will cause your DVR to sync its time with a Time Sync Server in the set interval time.

- Display Options- Set sequence dwell time, spot-out dwell time, spot-out channel, pop-up camera, and OSD as indicated below:

o OSD:

 Select which information will be displayed in the OSD visible on each channel in Live.

 Select which information will be displayed in the OSD visible on each channel in Playback.

 Set the OSD’s transparency level, the higher the percentage, the more transparent the OSD text

will appear.

 Setup a dwell time for the OSD text, after which, the OSD will automatically disappear.

 Setup a dwell time for the Setup Menu, after which, the Setup Menu will automatically disappear.

o Set sequence dwell time- Setup how long the system will display each channel in Sequence mode, before

switching to the next channel.

o Spot-out Monitor Spot monitor operation

1. Spot out display mode - It supports programmable multi display mode(Full,4,9,16) on digital spot output.

2. Spot out channel select- Spot out monitor displays selected channels only or spot sequence displays.

** Non-selected channels are not displayed as black screen in covert

3. Spot out cam popup- If cam popup is set in Sensor, Motion notify, Spot monitor also pops up the event.

4. Spot Monitor interval- Spot Sequence time setting

o You may select On/Off for Live or Playback status display by checking a check box.

- Screen Saver Setup- See section 3.13 Screen Saver for more information.

39 | Chapter 1 : DVR User Manual

NOTE

Total number of users including administrator is 9 users.

4.1.2 User

Master user of this system is always Admin with factory default of No password. This user cannot be deleted.

It is recommended that the Admin change the password for extra security.

Admin can designate a new user with different permission levels by: functions, menu access, and live & playback.

“Function” options restrict a user’s access to functions such as search, PTZ control, backup, and playback.

“Menu Access” options restric a user’s access certain menu settings, like system, device, record, network, backup, and quick setup.

“Live & Playback” options restrict a user’s viewing of the deselected channels. If a channel is deselected, user will not be able to view live or playback for thet certain camera channel.

Admin user can also select whether the DVR will repuire login for every main function.

If user selects “On Boot”, the DVR will not ask for an ID and Password input again even though the system reboots.

On the contrary, if user selects Auto Log-off and sets the time, the DVR will automatically go to the live display mode that occurs after the set time. Then, the DVR will ask for an ID and Password input when user wants to control the DVR.

User’s Manual | 40

NOTE

1) Formatting may take around 40 sec for 320GB, 1 minutes for 500GB, or 7 minutes for 2TB.

2) The system always reserves a maximum of 20GB of space in each built-in HDD to utilize the memory for archiving effectively.

4.1.3 Export/Import

If you have multiple DVRs, you can copy the settings from one DVR and apply it to others, saving you time and guaranteeing proper installation on all devices.

“Export” allows you to copy the settings set for current DVR to a USB memory device.

“Import” allows you to apply the settings from another DVR using USB memory device. During the import process, make sure that the firmware version of source DVR is the same as the destination DVR.

4.1.4 HDD

HDD information sub-menu displays all relevant information regarding all HDDs connected to the DVR. The system will display internal HDDs and externl HDDs (eSATA) separately.

Press the ‘Check’ button next to the HDD’s name to view that HDD’s health status. When pressed, the system will display the HDD’s model, size, current temperature, Live Time (how long the HDD has been operating), and any Bad Sectors.

User can select “Overwrite” or “Rec Stop” when the HDD is full. If ‘Overwrite’ is selected, when the HDD is full, new video will be recorded OVER older data. If ‘Rec Stop’ is selected, the HDD will stop recording any data once it’s full.

To formay a new HDD or an existing HDD, check the checkbox next to the HDD you would like to format, and click “HDD Clear”.

If system resources are occupied with task, such as making a network connection or performing video playback during the format process, the format may fail. If the format fails, reboot the system resources and then try to format again.

41 | Chapter 1 : DVR User Manual

NOTE

Upon clicking “Start” and entering the admin password, all the configuration values made by the user will be deleted. The system setting will be sent to factory defaults. The recorded video data will not be erased.

4.1.5 Factory Default

With an authorized password, users can get the system back to factory default configuration.

4.1.6 Face Stamp Set-up

The Facestamp is an exclusive Digital Watchdog feature used for employee and time amangement. It is compatible only with Digital Watchdog’s VMAX960H series.

If you have purchased the Facestamp hardware, follow the instructions below on setting up the Facestamp on the DVR. Consult the Facestamp’s QSG for additional installation information.

o Connect the FACESTAMP hardware to the DVR using an RS-485 cable. Connect the cable to the DVR’s KEYBOARD

RS-485 port. See 2.2 Rear Panel for more information.

o Go to System Setup System Info sub-menu

o Select ‘FACESTAMP’ in the Keyboard options from the drop-down menu.

o Adjust the Baudrate to 115200

o Adjust the Keyboard ID to 252 or 250.

User’s Manual | 42

4.1.7 Face Stamp User Registration

Listed users can be monitored as Faces Stamp events through VMAX960H & VMAX960H Flex when listed users check in and out Face Stamp.

To add, delete, or modifty Facestamp users, go to the DVR’s System Settings, Facestamp sub-menu.

1. Select the channel to which the Facestamp access panel is connected.

2. To add a user, press the add button.

3. Enter a USER ID. This will be the ID e ach user will have to enter in the Face Stamp Access Panel to identify themselves.

4. Enter USER NAME. This name will appear as the access panel recognizes the user’s ID when entered correctly.

5. To modify or delete a user, check the box next to the user’s name and press ‘modify’ to adjust the user’s name, or ‘delete’ to remove the user all together.

4.1.8 Face Stamp Schedule

Go to the Schedule Setup menu to assign the Facestamp channel a recording schedule. After selecting the Face Stamp channel, user schedule this with Face Stamp profile. See section 4.3 Record for more information on setting up a recording schedule.

43 | Chapter 1 : DVR User Manual

4.1.9 Face Stamp Search

Whenever users check in our out using the Face Stamp access panel, the check in or out will be recorded as an event, and a

picture of the user will be stored in the DVR. Managers then can search and review their employee’s time and attendance.

To perform a local search on the DVR for all Facestamp events follow these steps:

1. In live mode, right-click anywhere on the sreecn and select Search Face Stamp.

2. Facestamp search window will appear. Select the day you want to search from the calendar. Days with recorded data will

be highlighted in the calendar.

3. Select to view all events markeed as Check-in, check out, or both.

4. Press the ‘Search’ button.

5. Press the button next to an event to view three (3) seconds of video associated with the selected event.

6. Press ‘Check Test’ to check a user out. Enter the user’s ID number and press OK. They will appear as checked in the

system.

7. you can export the event search result for your records. Connect a USB to the DVR, press scan and allow the system to

find the USB device. Select Export to save the data in table format.

For more advance searching and playback options see the Facestamp software.

User’s Manual | 44

4.2 Device

There are Seven sub menus in the Device menu, such as Camera, Audio, Sensor, Motion Alarm, Extra Alarm, PTZ and

POS. Users can easily move to the “Device” menu by selecting the icon on the top right of the menu screen.

4.2.1 Camera

Users can setup camera title, covert, brightness, contrast, motion sensitivity, and audio mapping for each camera.

“Covert,” also called “hidden camera” feature, hides camera display and playback as if there were no camera recording.

Users can apply this covert function not only to Live view, but also to Playback view.

The default motion area setup is the entire camera area.

See section 3.3.2 Image Enhancer (Long Reach) in page 14 for more information on the purpose and setup of the Long Reach features.

45 | Chapter 1 : DVR User Manual

CAUTION

Relay contact can handle up to 24VDC/1A(or 125VAC/0.5A) of other devices. If connected to a circuit that is over 24VDC/1A(or 125VAC/0.5A), the system may experience problems.

4.2.2 Audio

Users can select the audio input and output during live display and match the audio input to a designated channel. (Please refer to Section 4.3.1 Camera Record). Adjust the audio volume using the volume control panel, enable or disable audio recording for each channel, and enable or disable audio during live video.

In addition, users can listen to the audio for both live display and playback mode through the network using Advanced Client Software (ACS), Central Management System (CMS), and/or Internet Explorer web browser.

4.2.3 Sensor

 Type- OFF, N/O (Normal Open) , N/C (Normal Close) The Sensor.

 Cam- Select the associated camera.

 Notify- Users can select how to be alerted when a sensor is activated or motion is triggered by pressing the

“NOTIFY” button. The system can generate a buzzer sound and/or make a pop-up screen for the camera in alarm.

User’s Manual | 46

NOTE

“Sensor” here means the alarm connected to the DVR, which is triggered by physical sensor input.

NOTE

If the sensor does not operate properly check the setting of the sensor type (N/O or N/C). The alarm might not function if the actual connecting sensor type and the sensor type in the system setting are inconsistent.

NOTE

“Camera pop-up” means that multi-screen live video mode will be switched automatically to single channel mode, when an alarm is triggered. This single channel video will be the channel triggered by alarm.

 Preset- User can select the camera to move to a preset position, once the sensor is triggered. (User should

setup preset position in PTZ menu 4.2.6 in advance) In addition, users can set multi-preset with a single PTZ camera. Therefore, users can cover a multi-preset zone with a single PTZ camera.

 Relay- 1~4/Off Relay Output.

 Dwell Time- Set the recording period from the start of sensor input activation. During this period, the

corresponding camera video will record according to the frame and alarm (relay) output set. The recording stops and alarm output is turned off when the dwell time has elapsed.

 Copy Setting- Upon pressing Copy Settings button, Copy Settings popup will appear. In this popup, choose the

sensor the user wants to copy from at the “From” field. Choose the parameters such as Type, Cam, Notify, Preset, Relay, and Dwell Time on the check box. Check on the checkbox next to the sensor numbers to apply the copy setting(s) to another channel on the “To” box.

47 | Chapter 1 : DVR User Manual

NOTE

“Motion Alarm” here means alarm triggered by motion detection set by motion menu of DVR.

4.2.4 Motion Alarm

Select Motion alarm to record only when motion detection is triggered by DVR S/W upon user’s defined motion area.

An alarm signal is sent via the selected sensor-out channel.

 COPY SETTINGS- Upon pressing Copy Settings button, Copy Settings popup will appear. In this popup, choose the

camera the user wants to copy from at the “From” field. Choose the parameters such as Use, Notify, Relay, and Dwell Time on the check box. Check on the checkbox next to the sensor numbers to apply the copy setting(s) to another channel on the “To” box.

4.2.5 Extra Alarm

S.M.A.R.T. alarm is an alarm signal triggered when the HDD is about to be out of operation.

This alarm is created by the HDD and captured by DVR. If the HDD does not create this alarm, then the DVR also cannot capture and output this signal.

Users also set the percentage for HDD Usage. For example, when Usage is 50%, DVR will notify by a camera popup or a beep sound when HDD is 50% full.

User’s Manual | 48

PROCEDURE

How to setup PTZ camera with Pelco-D protocol (example)

1) Make sure the serial communication with the PTZ camera is through RS-485 port.

2) Select “Pelco-D” at the protocol list, and set the address.

3) Select Baud Rate to be the same as the PTZ camera

4) Click the “Save” button to confirm this configuration.

4.2.6 PTZ

Full control of PTZ camera is available in this menu. For details, please refer to Section 3.4 PTZ Operation.

 Protocol- Select the proper protocol of the connected PTZ camera.

 Address- Set the PTZ driver address of the connected camera.

 Check the below items for proper P/T/Z operation.

1. Check if the protocol of the connected PTZ camera is correct.

2. Check if the communication settings, including the baud rate, of the connected PTZ camera are in accordance with the assigned value for that P/T/Z protocol.

3. Check if the address of the connected PTZ camera is correct.

4. Check if the wiring to the P/T/Z controllers are correct.

 Preset- The system supports the number of preset from 1 to 255.

 Baudrate- User can select the baud rate level from 1,200bps up to 115,200bps.

 Tour- once the PTZ camera is properly setup, you can set it to run a tour, moving between a set of predefined presets:

1. Make sure you have at least 2 presets set in the DVR. To do so:

a. Enter a preset number in the preset box.

b. Move the camera to a desired location

c. Press the’Set’ button.

2. Press the ‘Set’ button next to the Guard Tour.

3. Select the channel in which you have a PTZ camera connected and press ‘edit’

4. Select the presets you want to use from the preset column and oress the >> button to add them to the Guard Tour sequence. Please note that the presets will run in the order in which they appear on the right column.

5. If necessary, adjust the time interval between each preset fro 5~30 seconds.

6. To start the Guard Tour, Press the ‘Tour’ button.

49 | Chapter 1 : DVR User Manual

NOTE

COPY SETTINGS

Copy Settings popup allows you to choose the camera you want to copy from in the “FROM” field. Choose which settings you want to copy, such as Resolution, FPS, Quality, Event Resolution, Event FPS, Event Quality, PreAlarm and PostAlarm. Check the checkbox next to the cameras to apply the copy setting(s) to another channel on the “To” box.

4.3 Record

Users can configure various record settings such as Continuous, Event, and Panic for each individual camera in the Record Setup Menu. Network Stream settings are independently configured from the Record settings in this menu as well. Use this setup option to ptimize the bandwidth used by the DVR by configuring the resolution, FPS, and image quality separately.

4.3.1 Record Setup

Under the Record Setup tab, set the desired resolution, frame rate, quality and recording for each camera, and for each recording mode. Use the copy setting button to apply the recording settings from one channel to multiple cameras.

User’s Manual | 50

Users can also configure the Network Stream settings independently from the Record settings under the “Live Stream” tab as shown below.

The Live Stream menu enables users to optimize data transmitted over the network by configuring the Resolution, FPS, and Quality without affecting the Record settings.

For example, users can configure 960H (960x480) resolution, 15 FPS with Normal quality for Live Stream (over the Network) and configure 960H (960x480), 30 FPS with Highest quality for recording video.

Users also have the option to configure different settings for Panic Recording. The Panic Record setting will be applied wen you select to start panic recording for any of the channels. It is highly recommended to use the maximum resolution, FPS, and quality for this record type.

51 | Chapter 1 : DVR User Manual

4.3.2 Schedule

You can set up the record schedule by applying a various record modes to each date and time. Simply select a record mode by mouse and drag it to the desired date and time.

4.3.3 Holiday

Users can setup a specific day of a month or day of week as a holiday as shown below. Once holiday is selected, the recording setup for those holidays will be affected by the schedule setting in the schedule.

User’s Manual | 52

4.4 Network

4.4.1 Network

The system has built-in web server.

 ETHERNET

- DVR network system

- ETHERNET LAN port

 Network Type

Select network connect type. Select either LAN for fixed (Static) IP or DHCP for dynamic IP. If DHCP is selected, click ‘IP DETECT’ button to automatically detect IP address and network information.

 Subnet Mask

Subnet Mask address classifies the subnet that the system belongs to. Standard address is 255.255.255.0. For more information, please consult your network administrator or your internet service provider

 Gateway

This is the IP address of the network router or gateway server. It is required when the user wants to connect through the external router from the remote. For more information, please consult your network administrator or your internet provider

 DNS Server

Enter the IP address of the Domain Name Server. There are two DNS settings. (The preferred DNS and the alternative DNS) *You should enter the DNS Server information in order to use internet. (Provided by your ISP)

 TCP/IP Port

Enter the port number to use when connecting locally or remotely.

 Mobile Port

Enter the mobile port number to use when connecting to mobile phones.

 Web Port

Enter the port number to use when connecting from the Web Browser.

53 | Chapter 1 : DVR User Manual

NOTE

TCP/IP Port, Mobile Port, and Web Port should be a different number from each other.

NOTE

The system transfers video images at real-time over the network even during no record. For example, user can monitor live video even when motion has not occurred during motion detection mode.

NOTE

If there is no physical network connection, it may take a few minutes for the system to start working, since the network configuration in DHCP mode and the DHCP connection cannot be made.

 UPnP (Universal Plug and Play) and Auto Private IP Setup (NAT Traversal)

UPnP stands for Universal Plug and Play, which indicates a universal protocol for widespread plug-and-play devices to ease the network implementation. When a PC and a DVR both installed the UPnP function, the PC can automatically recognize the DVR in the same local area network. The advantage of this function is that a PC can connect to the DVR directly by clicking on the icon representing the DVR in <My Network Places> folder as shown below. The first five characters of the file name of a detected DVR is subject to a firmware version

Simply double click on the desired icon. Then, it will open an internet browser that connects to the DVR via the remote control software as shown below. Please type in your User ID and Password to login and click ‘Connect’ button to connect.

 Auto Private IP Setup (NAT Traversal)

The UPnP NAT Traversal function will help to automatically setup a router if the DVR connects to the internet via a router.

When a PC connects to a DVR, which is not in the same local area network, a real IPO address and corresponding port number is required. However if the DVR is behind a router, the communication between the PC and the DVR will be transmitted back and forth by the router. The router will need to setup port mapping (Port Forwarding) before images from the DVR is remotely viewed on the PC. For each individual DVR, the setting needs to be done individually.

If the DVR has UPnP NAT traversal function, the setting of the router will be done automatically when it is enabled.

Just check ‘Auto IP (NAT Traversal)’ check box in the UPnP setup menu. Then it will take care of Auto IP detect by itself.

User’s Manual | 54

NOTE

The standard DDNS domain name is dwddns2.net, and users can use dwddns.net or dyndns.com by drop-down list.

4.4.2 DDNS

The User has to mark the “Use DDNS” check box to use it.

 DDNS Server

dwddns.net or dwddns2.net is the fixed domain name of DDNS server.

Enter a desired DVR name. If you would like, add a user and password protection when users will connect to the DVR using the DDNS.

Press the ‘Start’ button. If the DVR name you have entered is available, press the ‘Save’ button.

To access your DVR using the DDNS address, open an internet explorer page, and enter in the address bar “DVRName.dwddns2.net”

55 | Chapter 1 : DVR User Manual

NOTE

Configuration’s first priority is always given to “Schedule Setup ” of the “RECORD” menu. Thus, the system will not send alarm message or email notification upon motion alarm or sensor even though user marks the checkbox of above event selection, unless user sets the “Schedule Setup” in the “RECORD” menu. For example, if user sets “Continuous” only for “Schedule Setup ” of the “RECORD” menu and marks the “All” checkbox in “REMOTE NOTIFY”, then the system will not send alarm messages. In this case, user has to set “C + M”, “MOTION”, “SENSOR”, “C+ S” or “C+M+ S” for REMOTE NOTIFY or E-Mail NOTIFY to function properly.

4.4.3 Notification

 Remote Notify

The system can notify an alarm message to the IP address of Advanced Client Software over the network.

User can choose from a selection of different kinds of alarms by pressing “ADD.” Alarms can be generated by Sensor, Motion Detection, Disk Full, Admin PW Changed, Video Loss, and Power On/Off. If you click box of Face Stamp to get notification.

 E-Mail Notify

The system can send notification to an Email address or Advanced Client Software and the Central Management System over the network. User can choose from a selection of different kinds of alarms by pressing “ADD.” Alarms can be generated by Sensor, Motion Detection, Disk Full, Admin PW Changed, Video Loss, Power On/Off and FaceStamp. By clicking “Use TLS”, users can use a public email address such as Yahoo, Google, Hotmail accounts. Type DVR name in the “DVR Name” box. The DVR name will appear in the email so that users can recognize which DVR sent an email.

User’s Manual | 56

NOTE

Backup device shall be a well-known major brand of USB thumb drives formatted by FAT/FAT32 for proper backup.

NOTE

User can easily backup video in “Quick Backup” during video playback. Refer to section 3.5 for quick backup details.

NOTE

User can click the “Calculate” button to learn the backup file size before executing backup.

NOTE

User can rename the backup file name before starting backup process and also put a password in the backup file for security purpose. In order to playback the file, user should input the password.

4.5 Backup

4.5.1 Backup

Users can archive a video clip recorded for a certain period on a selected channel or channels as shown below.

Connect an appropriate USB memory device, like USB thumb drive, USB HDD, or a built-in CD or DVD burner and press “SCAN” button to get the system to recognize it before archiving. Necessary file size will be shown before burning.

57 | Chapter 1 : DVR User Manual

NOTE

User also can play the backup-video clips by Advanced Client Software and Central Management System.

4.5.2 Backup Video Retrieve

There will be a single file after archiving, if “Auto Player” was selected.

User can double click “BackupPlayer.exe” file to open the video data file (PSF format) in the folder.

User can print out, capture a still image, zoom out, or make an ASF file format, by using the icons located on top of the player window.

User’s Manual | 58

NOTE

Quick setup must be deactivated if the user requires configuration from the other menus.

NOTE

After the user marks “Use Quick Setup” to define settings, the system will ignore all other configurations set by full menus.

4.6 Quick Setup

Quick Setup helps user make simple configuration for recording resolution, entire recording speed by frame, recording mode, and recording periods.

The system will put the first priority for configuration on this quick setup and will follow this rule regardless of configurations set in other menus. Users should not fill in the checkbox of Use Quick Setup if he/she wants to utilize full system configuration defined in the other menus.

59 | Chapter 1 : DVR User Manual

5 WEB SURVEILLANCE

The VMAX960H DVR has a built-in web server. Using an ordinary web-browser over a network, users can always stay connected to the system for live monitoring, playback, or remote configuration without installing any remote client software.

5.1 Web Login

The user is required to input the correct IP address in the web browser after making the web port available in the router. Please note, if you are connecting to the DVR from a remote network (via the internet), you must port-forward the corresponding ports in your reouter before you can access your DVR.

For more information, see the Appendix section, and consult your Installer or Internet Service Provider.

After allowing the download of the Active-X file (see page 58 for more information), users can find the login page view seen below. Default USER ID is “admin” and No password.

It is recommended to use an Internet Explorer web page. To open the DVR’s web viewer on a Google Chrome web viewer, please install the IE Tab add on option.

Then, simply enter the DVR’s IP address or DDNS address in the address bar and click on the on the tool bar of the web viewer.

User’s Manual | 60

Main Classification

Sub Classification

SYSTEM

SYSTEM INFO

USER

HDD

DEFAULT

DEVICE

CAMERA

AUDIO

SENSOR

MOTION ALARM

EXTRA ALARM

RECORD

RECORD SETUP

LIVE STREAM

PANIC RECORD

SCHEDULE

NETWORK

DDNS

NOTIFICATION

QUICK SETUP

[System]

[Device]

5.2 Web Configuration

Menu of Web Configuration

After logging in with the right ID and password, users can make various configuration changes in the Web Configuration window seen below. This Web Configuration menu is only available to the “admin” account.

61 | Chapter 1 : DVR User Manual

[Record]

[Network]

[Quick Setup]

NOTE

This web CGI screen is directly supported from the built-in web server in the DVR, regardless of Internet connection.

NOTE

<System Reboot> enables user to reboot the system without any changes to the setup. When the network is disconnected due to abnormal operation of the system, user can use this function and try to reconnect. However, the IP number assigned to the system may be changed due to the DHCP mode.

User’s Manual | 62

5.3 Web monitoring

The first time you access your DVR via the Web viewer, you will be asked to install Active-X file before monitoring live video. Please follow the installation process to complete the Active-X installation. Without it, you will not be able to view video from any of the DVR’s channels.

[Web Active X Install ]

User can get into web monitoring after log in as shown below. In order to connect to DVR, select the vewieing mode (Live/ Playback) and click “ Connect ” located at the top left corner.

63 | Chapter 1 : DVR User Manual

No.

Title

Function

Connection Mode

Select to view the DVR in Live or Playback Mode.

Connection Option

Select to Connect or Disconnect from the DVR.

PTZ

PTZ control options, including: virtual direction arrows, zoom and focus, and preset.

Calendar

Date & Time search.

Playback Controllers

First data, fast rewind speed, play rewind, pause, play, fast forward speed, last data.

Audio

Enable/ Disable audio.

Export Options

Export a still image, export a video, or print a still image with notes of a selected channel.

Display Options

Select single, 4-channel mode, 9- channel mode, or 16-channel mode (16-channel display will not be available on 8-channel models).

Channel Selection

Select manually a specific channel to go to single channel mode.

Time bar

In playback mode, indicates available recorded video for each channel for the 24 hours of the selected day.

Time indicator

Use the time indicator line to update playback video from a selected channel or multi-channels.

Main Display Area

View live or playback from the selected cameras.

Remote Setup

Will open remote setup option (See 5.2 Web Configuration). Available for admin users only.

Logout

Exit connection from the DVR.

①

②

③

④

⑤

⑥

⑦

⑧

⑨

⑩

⑪

⑫

⑬

⑭

User’s Manual | 64

NOTE

The image resolution in “Live monitoring” in this web browser can be adjusted from the DVR’s ‘Live Stream’ sub-menu under the ‘Record’ Setup Menu.

NOTE

If live image is not properly shown on IE web browser due to network capabilities or low bandwidth, it is recommended to close and re-open the IE web browser.

User can monitor live video in 1, 4, 9 or 16 screen modes. If user wants to see single channel in full screen, double-click on the live video screen. User can change to single mode by clicking the mode icon located at the bottom left.

65 | Chapter 1 : DVR User Manual

5.4 Web Playback

Users can remotely playback the DVR images by clicking “SEARCH” button in the middle of bottom window. In order to connect to DVR, the user has to click “ Connect ” button which is located at the top left corner.

 Playback Time

Select the date and time on Time Search, located at the middle of left side of window, and click button.

 Playback Icon

Play/Pause is toggled and playback speed is shown on the left box.

 Play DST

Check this box to play overlapped images during DST (Daylight Saving Time) period.

For further details, please refer to Section 3.7 (DST Setting and Image Playback)

 Intelli-Search Bar

User can move the blue vertical line to the time that user wants to search.

The colors of the time bar are different by each recording mode. Please, refer to Section 4.3.2 for details on color

User’s Manual | 66

Chapter 2

CMS CLIENT SOFTWARE USER MANUAL

67 | Chapter 2 : CMS Client Software User Manual

Windows XP, Vista, 7

CPU

Pentium Dual core 1.8Ghz or higher

VGA

1024X768, 256MB supporting DirectX

RAM

1GB

HDD

20MB for installation, 10GB for Remote Backup

Windows XP, Vista

CPU

Pentium 4, 2Ghz

VGA

1024X768, 64MB 24bit color graphic card

RAM

1GB

HDD

20MB Free Space

6 CMS USER GUIDE

6.1 PC REQUIREMENT

User’s Manual | 68

Recommended PC Requirement

Minimum PC Requirement

6.2 INSTALL

Run Central Management Software Setup.exe saved on the included CD.

When clicked, the Setup Menu will appear.

Follow the setup instructions to complete the installation.

69 | Chapter 2 : CMS Client Software User Manual

Press if you want to install the program in a different directory.

Press to move to the next screen.

Select what Icons and shortcuts you wish to install on your desktop.

Press to move to the next screen.

User’s Manual | 70

Select to begin installation. When the installation is complete, the below message will appear.

Select whether you want to launch the software and select “finish”.

71 | Chapter 2 : CMS Client Software User Manual

6.3 UNINSTALL

To uninstall CMS, press UNINSTALL CMS from the Start Menu of your PC.

A window will appear in Windows7 or Windows Vista. Press YES to begin the process.

When the process is complete, the below message will appear.

User’s Manual | 72

6.4 BASIC OPERATION

Click on the CMS icon on the Desktop or click START on Windows PC and go to the CMS Folder.

73 | Chapter 2 : CMS Client Software User Manual

6.4.1 LOG IN

The default ID is Administrator, and there is no default password. The administrator account has the highest level of authority on the CMS.

6.4.2 SCREEN LAYOUT

User’s Manual | 74

Item

Description

Main Toolbar

(Setup Tab)

The Main Toolbar has three (3) selectable tabs named "Main", "Export" and "Setup". In the Setup tab, there are CMS setup and Remote setup.

Main Toolbar

(Export Tab)

In the Export tab, users can save JPEG, AVI and Print images of selected video.

Main Toolbar

(Main Tab)

In the Main tab, users can connect to Live and Search views, disconnect, change display mode and sequence, Panorama Search and Thumbnail Search.

Site List Panel

All of the registered sites in the setup tab are shown in the site list. Simply drag and drop the desired site to the display screen to connect to the site.

PTZ Panel

Enables users to control a PTZ camera, in Live mode.

Search Panel

In the Search mode, the recording information for each channel will be displayed, based on a selection of a specific date in the calendar.

Display Panel

This is the area where live view and search view are displayed.

Event Search Panel

CMS can display all the events setup on each individual DEVICE. These events will be listed in this panel. An event data can be searched by double-clicking on an event.

Information Panel

Shows the current time and site information of the selected channel.

Favorite Panel

Create favorite site for quick access to the sites frequently viewed.

Item

Description

CMS Setup

Remote Setup

Access the setup menu of the DEVICE remotely and change the settings.

Windows Exit

Minimize/Maximize the CMS Window or close the CMS program.

6.4.3 MAIN TOOLBAR (SETUP)

75 | Chapter 2 : CMS Client Software User Manual

Item

Description


Capture an image of the selected (focused) channel.

Movie

Save the selected channel in ASF format movie file.

Print the selected channel.

Item

Description

Live

Connect to the selected site in Live mode.

Connect to the selected site in Search mode.

Disconnect

Disconnect the single channel selected.

Disconnect All

Disconnect all of the connected sites and channels.

Display Mode

Choose the display mode from single, 4 split, 9 split, 16 split, 20 split, 36 split, 64 split.

Full

Shows Full screen display.

Sequence

Sequences the different channel displays.

Dual Monitor

Create an additional display window.

Panorama

Show frame by frame display for a selected single channel in Search mode.

Thumbnails

Thumbnail search for a selected single channel in Search mode.

6.4.4 MAIN TOOLBAR (EXPORT)

6.4.5 MAIN TOOLBAR (MAIN)

User’s Manual | 76

①

②

③

④

⑤

⑥

⑦

⑧

6.4.6 SITE LIST

The Site List displays all of the DEVICES that are currently setup for remote connection with the CMS application.

To select and view a desired camera or device, simply drag it from the site list panel onto the viewing area. Then, select the

options Live or Search ( ).

If a DEVICE site is dragged onto the viewable area, then the selected DEVICE or all cameras from the DEVICE will be displayed.

6.4.7 PTZ CONTROL

PTZ camera control is only available in Live mode.

77 | Chapter 2 : CMS Client Software User Manual

No.

Button

Description

Navigation

Key

8 directional arrows allow the user to move the PTZ camera. The PTZ Camera is moved when one of these arrows are pressed to the direction desired, and stops the movement if the mouse button is released.

Zoom

Zoom In and Zoom Out.

Focus

Adjust the focus of the PTZ camera.

Virtual PTZ

If Virtual PTZ is activated, it enables users to control the PTZ camera’s movement, Zoom and Focus. PTZ can be controlled with the mouse on the channel screen directly.

PTZ Speed

Adjust the PTZ camera response speed. Getting Faster as moves to the right.

Preset

Set PTZ presets on current view.

7 Go to the preset location.

8 Save the preset location..

6.4.8 SEARCH

The Search panel is activated only in Search Mode.

When you connect to a site in Search Mode, dates with recorded data will be highlighted in red. Select a specific date in the calendar and then the recording information will be shown in the table.

Press (Go button) to start playback from a selected time.

If DST is enabled, the earlier one-hour overlapped video will be shown first.

No.

Button

Description

Go to First.

Forward Playback : Decrease the speed / Reverse Playback : Increase the speed.

Step Forward.

Reverse Playback.

Pause.

Forward Playback.

Step Backward.

Forward Playback : Increase the speed / Reverse Playback : Decrease the speed.

Go to Last.

Recording Modes

No Record White

Continuous (Yellow Color)

Panic (Red Color)

Alarm (Orange Color)

Motion (Green Color)

Click the time or move the time bar to the time you want to playback in the search panel.

For a more detailed search as seen below, double-click the time that you want to jump.

Detailed search is available on a 6 minute basis as shown below.

User’s Manual | 78

Playback Control Panel

79 | Chapter 2 : CMS Client Software User Manual

Audio control

(Audio On/Off): Turn On or Off the Audio channel.

Two-way Audio: Two-Audio between the CMS and DEVICE.

Bookmark: Add the selected channel to your bookmark list.

6.4.9 DISPLAY

In live mode, the text LIVE will be displayed in white, and the channel will be bordered in blue.

In search mode, the text SEARCH will be displayed in red, and the channel will be bordered in red.

A selected channel will be bordered in yellow. The site name will be shown at the lower left hand corner of the screen.

6.4.10 EVENT SEARCH

CMS can receive any event data from the DEVICE as shown below.

You can select a desired date to view the event list for the selected date. You can choose either event log or system log. Start the playback by double-clicking the Index number of each even list. The system log will show CMS start/end, live/search, option, remote setup, image/movie export etc.

6.4.11 INFORMATION

User’s Manual | 80

The current date/time, site name, IP address, ID, channel and Live/Search status will be shown for a selected channel.

6.4.12 FAVORITE

Cameras currently displayed on the screen can be added, deleted and edited as a favorite site group.

Place cameras of DEVICE site into a desired channel

location of the screen and then click to create a new favorite site group. Then, you can simply place those cameras on the same channel location by drag & drop as

shown below. In order to delete a favorite site, click .

81 | Chapter 2 : CMS Client Software User Manual

6.5 CMS FUNCTIONS

6.5.1 EVENT SEARCH

When you right click on a site in the site list, a quick access menu will appear.

Select EVENT SEARCH to run Event Search.

Item

Description

System Connection Info

The information of the DEVICE you are connected to will be filled out automatically.

Event Download Status

Right after connecting to the DEVICE, event information will be downloaded automatically. The download progress bar will be shown.

Calendar Search

If there is an event in the selected date, the date will be highlighted. Select a specific date to start event search.

Interval Setup

Set the start time and the end time to Search events.

Event List

When a desired date is chosen, the event list of the desired date will be shown on the list.

Channel/Event Filter

Event information can be sorted by a channel or event type.

Start/Stop Search

Start/Stop Search button.

6.5.2 REMOTE BACKUP

User’s Manual | 82

When you right click on a site in the site list, the quick access menu will appear.

Select REMOTE BACKUP to run Remote Backup.

83 | Chapter 2 : CMS Client Software User Manual

Item

Description

System Connection Info

The information of the DEVICE you are connected to will be filled out automatically.

Recording Directory

Decide the recording directory to backup.

System Recording Info

Displays the start and end time of the recorded data in the system.

Backup Setting

Setup the start and end time of the data to backup.

Channel

Select the channels to backup.

Backup Progress

Backup Progress bar indicates the backup process status.

Backup Status Window

Displays the backup status in text message.

When the backup process is completed, “Backup Completed” message will appear.

6.5.3 FIRMWARE UPGRADE

When you right click on a site in the site list, the quick access menu will appear.

Select FIRMWARE UPGRADE to run Firmware Upgrade.

User’s Manual | 84

Item

Description

DEVICE Connection Info

Input the information of DEVICE you are connected to.

Firmware File Directory

Select the firmware file directory to upgrade.

DEVICE Name/ Current Version

Displays the current DEVICE Name and Firmware Version.

New Version to upgrade

Displays the new DEVICE Name and Firmware Version.

Upgrade Progress

Start Upgrade and upgrade progress bar shows the upgrade progress status.

Upgrade Status Window

Displays the upgrade status in text message.

When the backup process is completed, “Backup Completed” message will appear.

6.5.4 MULTI MONITOR

Click MULTI MONITOR in the Main Toolbar to run the Multi Monitor function.

When you select MULTI MONITOR, you will see an additional window with the same split display as the main window. This setup is useful if your monitor center has more than one monitor screen.

85 | Chapter 2 : CMS Client Software User Manual

6.5.5 PANORAMA

Click PANORAMA in the main tool bar to run the Panorama View.

In Live mode or Search mode, the panorama view will show frame by frame display of the selected channel.

The Panorama view is available for one selected channel at a time.

To return to normal view, click PANORAMA again.

6.5.6 THUMBNAIL SEARCH

Click THUMBNAIL in the main toolbar to run the Thumbnail Search. This feature is available only in Search mode.

First, select a channel and click THUMBNAIL. The Thumbnail Search Pop-up window will come up.

Item

Description

Date

Use the Calendar to select a desired date.

Time Interval

Select the (time interval) to display still shots by a specified time. You may choose 1min, 3min, 5min, 10min, 30min, and 1hour (ex. 1min. means 1 still shot per 1 minute of recorded video data.)

Image Size

Adjust the Thumbnail Image size by using the slide bar. Moving the slide bar to the right will increase the image size, and moving it to the left will decrease image size.

Time Range

Select the (start time and end time) by using the slide bar.

Thumbnail

images

Thumbnail images will be shown.

Search button.

If you click each thumbnail image, you can search the selected data directly.

6.5.7 BOOKMARK

User’s Manual | 86

Click icon in the bottom right corner under the video display screen to bookmark a selected one channel search data.

Once the selected search data is bookmarked, the bookmark data is listed with an image in the bookmark list as shown below.

Select a bookmark list and click search or double click it to search the bookmarked data.

Click REMOVE to remove a selected bookmark from the list and click DELETE ALL to delete the entire bookmark list.

Click RENAME to change the name of a selected bookmark.

87 | Chapter 2 : CMS Client Software User Manual

6.5.8 VIRTUAL PTZ

If a PTZ camera is selected, click ‘Virtual PTZ’ to activate ‘Virtual PTZ’ function.

This allows users to control a PTZ camera by using the mouse controls. For example, place the mouse cursor over the PTZ channel and left-click the left, right, top or bottom of the screen to move camera left, right, up or down, respectively.

6.5.9 DIGITAL ZOOM IN/OUT

In Live/Search mode, digital zoom can be activated in a single full screen mode by using the mouse wheel.

Scroll up the mouse wheel, to zoom in. Scroll down the mouse wheel to zoom out on selected channel.

①

②

③

④

⑤

⑥

⑦

⑧

⑨

⑩

6.6 CMS SETUP

Options for DEVICE Registration, Network, User, Display, Event and other options.

6.6.1 REGISTRATION

Add, Modify, Import, Export or Remove DEVICE site information.

User’s Manual | 88

To modify and / or remove DEVICE information, click ADD or REMOVE to amend DEVICE site information.

Click Export to save the current site list and as a file. Click Import to import the file to the site list.

Ex) Adding a new DEVICE site

89 | Chapter 2 : CMS Client Software User Manual

Item

Description

Name

The name of the site.

The site’s IP Address.

Search all DEVICE sites in the same local network. (UPnP function)

Port

Port of the site. (Default: 9010)

Web port

Web Port of the site. (Default: 80)

User ID to access the site.

Password

Password to access the site.

Channel

Number of channel of the site. (for example: 16ch DEVICE: 1-16 or specifically: 1,3,5,7,9)

Model

Select a DEVICE or DEVICE’s model name.

Aspect Ratio

Select the displayed Aspect Ratio. (Custom, 1:1, 4:3, 16:9)

Once a new DEVICE site is added, the new DEVICE information will be displayed on the site list panel as shown below.

User’s Manual | 90

6.6.2 NETWORK

Enables users to setup RECONNECT and AUTO CONNECT to the network.

Enable Reconnect: When the network is unstable or disconnected, it will try to reconnect periodically. When the network gets stable again, it’s reconnected.

Enable Auto Connect: When you restart the CMS program again, it will reconnect to the last sites seen before logging off.

6.6.3 USER

User authority can be changed by Administrator. “admin” is the built-in account for administrating the DEVICE and CMS program.

91 | Chapter 2 : CMS Client Software User Manual

Add and change User authorities.

User authority can be changed by Administrator. Click Add button to create a new user ID and edit the user authority.

6.6.4 DISPLAY

Options for OSD setting. Users can modify what information will be displayed on the video screens.

①

②

③

Title: Turn on/off the DEVICE title and channel number.

Date/Time: Turn on/off the Date/Time of the site.

DEVICE Name: Turn on/off the name of the site.

Time Format Sync: Synchronize the DEVICE time format to CMS.

Record Status: Able to turn on/off the Record Status of the site.

Live/Search: Able to turn on/off the Live/Search of the site.

Sequence: Able to set Sequence interval.

User’s Manual | 92

6.6.5 EVENT

Setup the event port, event type, and popup settings for an event.

93 | Chapter 2 : CMS Client Software User Manual

Item

Description

Port

Input the same event port number from the DEVICE setting to receive event notification from the DEVICE.

Filter

Select the type of event to receive.

Action

Setup the popup duration and enable beep sound.

Item

Description

Recording Directory

Decide the recording directory to save images.

Language

Select a desired language.

FTP Information

In order to have Auto Upgrade, input FTP information. Once the FTP setup is done, CMS will detect the latest firmware is in the FTP and start upgrading automatically.

Auto Login

If you enable the auto login after inputting ID and Password, next time you login, you don’t need to type in the ID and Password again.

①

②

③

④

6.6.6 MISC.

Setup the Recording Directory, Language, Auto Upgrade, and Auto Login.

User’s Manual | 94

95 | Chapter 2 : CMS Client Software User Manual

Chapter 3

ACS CLIENT SOFTWARE USER MANUAL

User’s Manual | 96

97 | Chapter 3 : ACS Client Software User Manual

WindowXP, Vista

CPU

Pentium 4, 2Ghz

VGA

1024*768, 64MB 24bit color graphic card

RAM

1GB

HDD

20MB Free space

WindowXP, Vista

CPU

Intel Core i5 cpu 2.80GHz

VGA

ATI Radeon HD 512

RAM

4GB

HDD

20MB Free space

7 ACS USER GUIDE

7.1 System Requirement

Recommended System Requirement

Minimum System Requirement.

7.2 Install

a. Run Advanced Client SoftwareSetup.exe on the included CD. Follow the setup wizard to complete the

installation.

b. Press to install the program in a different directory. Press to continue.

User’s Manual | 98

c. Select what Icons and shortcuts you wish to install on your desktop. Press to move to the next

screen

d. Select to begin installation. When the installation is complete, the below message will appear.

Select whether you want to launch the software and select “finish”.

Digital Watchdog DW-V960H1616T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
