Digital Watchdog DWC-C261T User Manual

Starlight MPA Box Camera
DWC-C261T
ABOUT MANUAL
Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference.
06252014
PRECAUTIONS
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of he FCC rules. These limits are designed to provide reasonable protection against harmful interference. when the equipment is operated in a residential environment. This equipment generates, uses, and radiates radio frequency energy; and if it is not installed and used in accordance wi h the instruction manual, it may cause harmful interference to radio communications.
WARNING: Changes or modifications are not expressly approved by he manufacturer.
2
TABLE OF CONTENTS
Introduction
Installation
Module OSD Menu
Troubleshooting
Warranty Information
Specifications
Features Parts and Descriptions Dimensions
Inside the Box Mount Installation Instructions Adjustment of Focus
4 5 6
7
8-9
10
11-23
24
25-26
27-28
3
FEATURES*
1/3" Sony 1.3M CMOS 820 TV Lines [B/W], 800 TV Lines [Color] Compatible with C/ CS Mount Lenses True Day & Night with IR Cut Filter 3D DNR (3D Digital Noise Reduction) WDR (Wide Dynamic Range) Star-Light (Super Low Light Technology) HME (Highlight Masking Exposure) Defog (Extreme Weather Image Copmensation) Digital Quick Zoom & 8x Digital Zoom 16:9 and 4:3 Viewing Modes 1 Alarm Output AGC / BLC / AWB Privacy Zones (16) & 4 Motion Detection Zones Camera Control via RS-485/ UTC RS485 Built-In
4
PARTS & DESCRIPTION*
Lens Connector Box Camera Moun ing Bracket Connectors A-Iris Socket Back Focus Alarm +/­RS485 Connector OSD Control Arrows and Enter Buttons Power LED BNC Video Output AC / DC Power Input Terminal Block
1
1
5
DIMENSIONS IN MILLIMETERS (IN)*
47.6
(1.87”)
14.5(0.57”)
62.0(2.44”)
55.0(2.17”)
58.8(2.31”)
6
119.7(4.71”)
119.7(4.71”)
131.8(5.19”)
58.8(2.31”)
55.0(2.17”)
62.0(2.44”)
INSIDE THE BOX*
Included with C2 Box Camera
Color Box User Manual Mini-DIN Connector (For Video or DC Auto Iris Lens) Adapter Ring for “C” Type Lenses Two-Port Terminal Block (for AC or DC Power Connection) Cable Extension for Alarm In / Out and RS-485
5
6
7
INSTALLATION*
8
Using an appropriate mounting bracket, mark and drill the necessary holes to mount the bracket to a wall or ceiling.
Attach the mounting bracket to the surface using machine screws.
Attach the box camera to the moun ing bracket.
Adjust the camera’s position. Consult the manual of he mounting bracket for addi ional information.
INSTALLATION*
Connect an appropriate lens to he camera lens connector by twisting he lens clockwise. The camera is compatible with any C or CS mount lens. For “C” lenses, please use the provided Adapter Ring. See page 10 for details. *Lens is not included.
Connect the lens’ cable to the box’s A-Iris Socket.
Adjust the lens’ zoom and focus accordingly. Consult the manual of the lens for additional information.
9
