Digital Juice LED-KIT1 User manual
PORTABLE LED VIDEO LIGHT SYSTEM
USER’S GUIDE
TABLE OF CONTENTS
About The MiniBurst 128/256 LED Lighting System 2
Package Contents 2
MiniBurst Controllers & Connectors 4
Charging the Battery 5
Operating Your MiniBurst Lighting System 6
Technical Data/Specications 7
Cleaning Instructions 7
Troubleshooting 7
Safety Precautions & Warnings 8
Replacement Parts & Accessories 9
Limited Warranty 10
USER’S GUIDE
About the
MiniBurst
128/256 LED
Lighting System
Package
Contents
7
Congratulations on your purchase of this Digital Juice Gear
MiniBurst portable light-emitting diode (LED) lighting instrument.
Please read these instructions carefully before using the unit. Follow
the procedures described, in order to optimize the lifespan and
functionality of the components of this Digital Juice Gear product.
Check to see that the following components are included in the
packaging:
a. 12v AC Power Supply Adapter (1):
MiniBurst lights can be plugged directly into a standard AC outlet
to power the unit for longer shoots.
b. Battery Pack:
1
2
3
4
5
This unit contains a 7.4v
rechargeable Lithium Ion
battery — 6000mAh pack
for the MiniBurst 256 (2)
or a 2100mAh pack for the
MiniBurst 128 (3)
c. Battery Charger Unit:
Battery Dock (4), A/C power
cord (5), 12V DC adapter (6)
When the charger is plugged
into both the electrical outlet
and the battery pack, a light
(7) located on top of the
battery dock will indicate the
charging state of the battery.
6
2
USER’S GUIDE
d. Hotshoe Swivel Mount:
The hotshoe swivel mount (8) allows
for easy mounting of the Digital Juice
MiniBurst LED Light to the shoe mount
on most still and video cameras.
e. Diffusion/Warming Filters:
The diffusion and warming filters mount easily to the front of the
light by sliding into the provided channel built into the aluminum
frame. The warming filter (9) is used to match the daylight balanced LED to warmer tungsten fixtures, while the diffusion filter
(10) helps to soften and spread the light.
9
f. Digital Juice Gear MiniBurst Light Fixture:
Available in two sizes — the MiniBurst 128 (11) and the
MiniBurst 256 (12). Both MiniBurst lights have identical controls
and connectors as described on the next page.
8
Package
Contents
(continued)
10
12
g. Deluxe Carry Bag:
Each MiniBurst light unit comes in an attractive deluxe carry bag
(13) with integrated padded grip handle, detachable shoulder
strap, padded velcro-attached dividers and
a zippered mesh accessory pocket.
The professional styling and lightweight protection this bag offers
your new MiniBurst light is
indispensable when shooting
on location.
11
13
3
