9XTend-PKG-R

RS-232/422/485 RF Modem

User Guide

Revision history—90000813

Revision Date Description

A March 2007 Baseline release.

B February 2016 Added support for XTend vB devices. Miscellaneous editorial changes.

C May 2018 Added explanation of range estimates.

Product documentation

To find up-to-date documentation for all Digi products, visit www.digi.com/documentation.

To provide feedback on this documentation, send your comments to techcomm@digi.com.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States and other countries worldwide. All other trademarks mentioned in this document are the property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a commitment on the part of Digi International. Digi provides this document “as is,” without warranty of any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Digi may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time.

Range figure estimates within this guide are based on free-air terrain with limited sources of interference. Actual range will vary based on transmitting power, orientation of transmitter and receiver, height of transmitting antenna, height of receiving antenna, weather conditions, interference sources in the area, and terrain between receiver and transmitter, including indoor and outdoor structures such as walls, trees, buildings, hills, and mountains.

Warranty

To view product warranties online, visit www.digi.com/howtobuy/terms.

Send comments

Documentation feedback: To provide feedback on this document, send your comments to techcomm@digi.com.

Customer support

Digi Technical Support: Digi offers multiple technical support plans and service packages to help our customers get

the most out of their Digi product. For information on Technical Support plans and pricing, contact us at +1

952.912.3456 or visit www.digi.com/support.

9XTend-PKG-R RS-232/485 RF Modem User Guide 2

Contents

About the RF Modems

Interfacing protocol

Applicable hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Key features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Worldwide acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Performance specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cyclic sleep current (mA, average) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Networking and security specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

User-selected TX Power Output specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

External interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

RS-232 operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

RS-485 (2-wire) operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DIP switch settings and pin signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

RS-485 (4-wire) and RS-422 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

DIP switch settings and pin signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Operation

Serial communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

RS-232 and RS-485/422 data flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Host and RF Modem settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Transparent operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

API operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Modes of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Idle mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Transmit mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Receive mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Command mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

AT Command mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Binary Command mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Configure the RF Modem

Automatic DIP switch configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Use XCTU to configure the RF Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Load default firmware settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Binary commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Command reference table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Command descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

%V (Board Voltage) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

AM (Auto-set MY) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

9XTend-PKG-R RS-232/485 RF Modem User Guide 3

AP (API Enable) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

AT (Guard Time After) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

BD (Interface Data Rate) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

BR (RF Data Rate) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

BT (Guard Time Before) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

CC (Command Sequence Character) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

CD (GPO2 Configuration) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

CF (Number Base) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

CN (Exit AT Command Mode) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

CS (GPO1 Configuration) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

CT (Command Mode Timeout) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

DB (Received Signal Strength) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

DT (Destination Address) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

E0 (Echo Off) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

E1 (Echo On) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

ER (Receive Error Count) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

FH (Force Wake-up Initializer) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

FL (Software Flow Control) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

FS (Forced Sync Time) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

FT (Flow Control Threshold) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

GD (Receive Good Count) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

HP (Hopping Channel) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

HT (Time before Wake-up Initializer) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

HV (Hardware Version) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

ID (Modem VID) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

KY (AES Encryption Key) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

LH (Wake-up Initializer Timer) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

MD (RF Mode) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

MK (Address Mask) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

MT (Multi-transmit) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

MY (Source Address) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

NB (Parity) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

PB (Polling Begin Address) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

PD (Minimum Polling Delay) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

PE (Polling End Address) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

PK (Maximum RF Packet Size) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

PL (TX Power Level) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

PW (Pin Wake-up) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

RB (Packetization Threshold) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

RC (Ambient Power - Single Channel) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

RE (Restore Defaults) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

RM (Ambient Power - All Channels) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

RN (Delay Slots) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

RO (Packetization Timeout) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

RP (RSSI PWM Timer) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

RR (Retries) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

RT (GPI1 Configuration) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

SB (Stop Bits) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

SH (Serial Number High) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

SL (Serial Number Low) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

SM (Sleep Mode) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

ST (Time before Sleep) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

TP (Board Temperature) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

TR (Transmit Error Count) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

9XTend-PKG-R RS-232/485 RF Modem User Guide 4

TT (Streaming Limit) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

TX (Transmit Only) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

VL (Firmware Version - Verbose) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

VR (Firmware Version - Short) Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

WA (Active Warning Numbers) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

WN (Warning Data) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

WR (Write) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

WS (Sticky Warning Numbers) command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

API operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

API frame specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

API Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

RF Modem Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

RF communication modes

Network topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Point-to-point networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Sample network profile (Broadcast communications) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Sample network profile (Acknowledged communications) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Point-to-multipoint networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Sample network profile (Broadcast communications) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Basic RF modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Acknowledged RF mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Peer to peer networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Sample network profile (Broadcast communications) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Sample network profile (Acknowledged communications) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Basic RF modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Acknowledged RF mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Address recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Basic communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Streaming mode (default) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Streaming mode connection sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Multi-transmit mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Multi-transmit mode connection sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Repeater mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Repeater mode theory of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Configure a repeater network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Repeater network: configure communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Repeater network algorithm details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Repeat delay based on RSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Response packet delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Bandwidth considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Polling mode (basic) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Polling mode theory of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configure a Polling Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Configure a Polling Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Acknowledged communications: Acknowledged mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Acknowledged mode connection sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Polling mode (acknowledged) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

9XTend-PKG-R RS-232/485 RF Modem User Guide 5

Agency certifications

FCC (United States) Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

FCC Part 15 Class B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

IC (Industry Canada) Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

RF Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

ACMA (Australia) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Legacy XTend Modem approved antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

XTend vB Modem approved antennas (30 dBm Maximum RF power) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Development guide

RS-232 Accessories Kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

9XTend-PKG-R RS-232/485 RF Modem User Guide 6

About the RF Modems

The 9XTend RF Modem affords OEMs and integrators an easy-to-use RF solution that sustains reliable delivery of data between remote devices.

Out-of-box, the modem is configured to immediately sustain long range wireless links between devices. Simply feed serial data into one modem, then the data will surface on the other end of the wireless link. The modem transfers a standard asynchronous serial data stream between devices.

Applicable hardware

This manual covers both the 9XTend-PKG-R RS-232/422/485 RF Modem, and the XTend vB Modem. Throughout the manual, you will see references to the “Legacy Modem” and the “XTend vB Modem.” Legacy modems have part numbers with the format XT09-PK.-... and contain radio model XT09. XTend vB modems have part numbers with the format XTP9B-PK.-... and contain radio model XBP9X.

Key features

Long Range Data Integrity

1 Watt Power Output

Range (@9,600 b/s throughput data rate):

• Indoor: up to 1000’ (300 m)

• Outdoor RF line-of-sight: up to 14 miles (22 km) w/dipole antenna

• Outdoor RF line-of-sight: up to 40 miles (64 km) w/high-gain antenna

Range (@115,200 b/s throughput data rate):

• Indoor: up to 500’ (150 m)

• Outdoor RF line-of-sight: up to 7 miles (11 km) w/dipole antenna

• Outdoor RF line-of-sight: up to 20 miles (32 km) w/high-gain antenna

Continuous RF data stream up to 115,200 b/s

Receiver Sensitivity: -110 dBm (@ 9600 baud), –100 dBm (@ 115200 baud)

Advanced Networking and Security

True Peer-to-Peer (no Master device required), Point-to-Point, Point-to-Multipoint and Multidrop

Retries and Acknowledgments

9XTend-PKG-R RS-232/485 RF Modem User Guide 7

FHSS (Frequency Hopping Spread Spectrum)

10 hopping channels, each with over 65,000 unique network addresses available

256-bit AES Encryption (AES algorithm is FIPS-197 certified)

Low Power

7 - 28 V Supply Voltage

Pin, Serial Port and Cyclic software sleep modes supported

Easy-to-Use

No configuration necessary for out-of box RF communications

External DIP Switch configuration

Free XCTU Software (Testing and configuration software)

RF Modems easily configured using standard AT and binary commands

Transparent Operation (Wireless links replace serial wires)

Portable (small form-factor easily fits into a wide range of data systems)

Software-selectable I/O interfacing rates

MODBUS, CTS

Multiple data formats supported (parity, start and stop bits, etc.)

, RTS, DCD, DTR (and more) I/O Support

Specifications

XII™ Interference Immunity

Worldwide acceptance

FCC Approved (USA) Refer to Agency certifications on page 84 for FCC Requirements. Systems that

include XTend RF Modems inherit Digi’s Certifications.

ISM (Industrial, Scientific and Medical) license-free 902-928 MHz frequency band

Manufactured under ISO 9001:2000 registered standards

9XTend RF Modems are optimized for use in the US, Canada, Australia and Israel

Specifications

Out-of-box, the 9XTend RF Modem is configured to provide immediate long range wireless links between devices. The modem can be configured to support additional functionality through the use of standard AT and binary commands. Refer to Command mode on page 30 and Configure the RF Modem on page 33 for more information. The following table provides the specifications.

9XTend-PKG-R RS-232/485 RF Modem User Guide 8

Specifications

Performance specifications

Note Range figure estimates are based on free-air terrain with limited sources of interference. Actual range will vary

based on transmitting power, orientation of transmitter and receiver, height of transmitting antenna, height of receiving antenna, weather conditions, interference sources in the area, and terrain between receiver and transmitter, including indoor and outdoor structures such as walls, trees, buildings, hills, and mountains.

This document describes how Digi RF products are designed to have good out-of-band interference rejection from other sources of RF emissions 1 MHz or more away from the frequency in which the Digi RF product is designed to operate. An out-of-band interfering radio is one that is intended to broadcast in one frequency but has RF energy that bleeds-over to affect a second radio operating on a different frequency. Final performance can still vary at any particular installation site, dependent on both the physical environment in which the radio is installed and the amount of in-band and out-of-band interference sources broadcasting in that same localized area.

Specification @9600 b/s Throughput Data Rate @115200 b/s Throughput Data Rate

Transmit Power Output (software selectable using PL command)

Indoor Range Up to 1000’ (300 m) Up to 500’ (150 m)

Outdoor RF line-of-sight Range

Interface Data Rate (software selectable using BD command)

Throughput Data Rate (software selectable using BR command)

RF Data Rate 10,000 b/s 125,000 b/s

Receiver Sensitivity -110 dBm -100 dBm

Legacy RF Modem: 1mW - 1 Watt Legacy RF Modem: 1mW - 1 Watt

XTend vB Modem: 100 mW - 1 Watt XTend vB Modem: 100 mW - 1 Watt

Up to 14 miles (22 km) w/ dipole antenna

Up to 40 miles (64 km) w/ high-gain antenna

1200 – 230400 b/s 1200 – 230400 b/s

9,600 b/s 115,200 b/s

Up to 7 miles (11 km) w/ dipole antenna

Up to 20 miles (32 km) w/ high-gain antenna

Power requirements

Specification Legacy Modem XTend vB Modem

Supply voltage 7 - 28 V 7 - 28 V

Receive current 100 mA 60 mA

Pin sleep current 16 mA 16 mA

Serial port sleep current (SM = 2) 42 mA 37 mA

9XTend-PKG-R RS-232/485 RF Modem User Guide 9

Cyclic sleep current (mA, average)

Sleep mode Cycle time RF data rate Legacy Modem XTend vB Modem

(SM = 8) 16 seconds BR = 0 18 mA 17 mA

BR = 1 16 mA 16 mA

(SM = 7) 8 seconds BR = 0 19 mA 17 mA

BR = 1 17 mA 16 mA

(SM = 6) 4 seconds BR = 0 22 mA 18 mA

BR = 1 17 mA 16 mA

(SM = 5) 2 seconds BR = 0 28 mA 20 mA

BR = 1 18 mA 17 mA

(SM = 4) 1 second BR = 0 37 mA 24 mA

BR = 1 20 mA 17 mA

Specifications

Networking and security specifications

Specification Value

Frequency 902-928 MHz

Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)

Modulation FSK (Frequency Shift Keying)

Network Topologies Supported Peer-to-Peer (“Master/Slave” relationship not required), Point-to-Point, Point-to-Multipoint

and Multidrop

Channel Capacity 10 hop sequences share 50 frequencies

Encryption 256-bit AES Encryption – To implement, refer to the KY (AES Encryption Key) Command on

page 50

Physical specifications

Specification Value

RF Modem Board Size 2.750” x 5.500” x 1.125” (6.99cm x 13.97” x 2.86cm)

Weight 7.1 oz. (200g)

Serial Connector DB-9

Power Connector 2.1 mm barrel

Operating Temperature -40 to 85º C (industrial)

9XTend-PKG-R RS-232/485 RF Modem User Guide 10

Specifications

Specification Value

Antenna

Connector RPSMA (Reverse-polarity SMA)

Impedance 50 ohms unbalanced

Regulatory approvals FCC Part 15B. See Agency certifications on page 84 for important

information.

User-selected TX Power Output specifications

Transmit power output 1 mW 10 mW 100 mW 500 mW 1 W

Legacy Modem

Typical transmit current (9 VDC supply voltage) 135 mA 250 mA 245 mA 475 mA 800 mA

XTend vB Modem

Typical transmit current (9 VDC supply voltage) N/A N/A 210 mA 400 mA 580 mA

9XTend-PKG-R RS-232/485 RF Modem User Guide 11

Specifications

1‐01a. ConfigSwitch

1‐01b. I/O&PowerLEDs

1‐01c. DB‐9SerialPort

1‐01d RSSILEDs

1‐01e. PowerConnector

* Note: The XTend RF modem can accept voltages as low as 5V.

Contact Digi Technical Support to implement this option.

1‐02a. DIPSwitch

1‐02b. AntennaConector

External interface

1-01a. Config (Configuration) Switch

Front View The Config Switch provides an alternate method for entering into

Command Mode. To enter Command Mode at the default RF data rate of the modem, hold the Config Switch down for two seconds.

1-01b. I/O and Power LEDs

LEDs indicate modem activity as follows:

Yellow (top LED)= Serial Data Out (to host)

Green (middle) = Serial Data In (from host)

Red (bottom) = Power/TX Indicator (Red light is on when powered; it pulses on/off briefly during RF transmission.)

1-01c. DB-9 Serial Port

Standard female DB-9 (RS-232) connector. This connector can be also used for RS-485 and RS-422 connections.

1-01d. RSSI LEDs

RSSI LEDs indicate the amount of fade margin present in an active wireless link. Fade margin is defined as the difference between the incoming signal strength and the modem's receiver sensitivity.

3 LEDs ON=Very Strong Signal (> 30 dB fade margin)

2 LEDs ON=Strong Signal (> 20 dB fade margin)

1 LED ON=Moderate Signal (> 10 dB fade margin)

0 LED ON=Weak Signal (< 10 dB fade margin)

1-01e. Power Connector

7-28 VDC* power connector (Center positive, 5.5/2.1mm)

1-02a. DIP Switch

Back View During each power-on sequence (reset or boot), the modem is

automatically configured according to the positions of the DIP Switch. The DIP Switch provides integrators with a limited number of external programming options. [Refer to Figure for configuration options]

1-02b. Antenna Port

The antenna port is a 50 RF signal connector for connecting to an external antenna. The connector type is RPSMA (Reverse Polarity SMA) female. The connector has threads on the outside of a barrel

9XTend-PKG-R RS-232/485 RF Modem User Guide 12

and a male center conductor.

DIP Switch Settings of the XTIB-R (RS-232/485) Interface Board

Refer to the tables in Automatic

DIP switch configurations on

page 33 regarding configurations triggered by the positions of the DIP Switch (during power-up).

Specifications

9XTend-PKG-R RS-232/485 RF Modem User Guide 13

Interfacing protocol

The 9XTend RS-232/422/485 RF Modem supports the following interfacing protocols:

• RS-232

• RS-485 (2-wire) Half-duplex

• RS-485 (4-wire) and RS-422

RS-232 operation

DIP switch settings and pin signals

RS-232 DIP Switch Settings Pins used on the female RS-232 (DB-9) Serial Connector

DIP Switch settings are read and applied only while powering-on.

9XTend-PKG-R RS-232/485 RF Modem User Guide 14

RS-232 operation

The following table shows the RS-232 Signals and their implementations on the XTend RF Modem (Low-asserted signals are distinguished by horizontal line over pin name).

Pin Reference

Name

Description Implementation

DB-9 Pin

RS-232 Name

1 DCD GPO2 Data-Carrier-Detect Connected to DSR (pin6)

2 RXD DO Received Data Serial data exiting the RF modem (to host)

3 TXD DI Transmitted Data Serial data entering into the RF modem (from host)

4 DTR GPI2 Data-Terminal-Ready Can enable Power-Down on the RF modemy

5GND- Ground SignalGround

6 DSR GPO2 Data-Set-Ready Connected to DCD (pin1)

7 RTS

/ CMD GPI1 Request-to-Send /

Provides RTS flow control or enables Command Mode

Command Mode

8CTSGPO1Clear-to-Send Provides CTS

flow control

9 RI - Ring Indicator Optional power input that is connected internally to the

positive lead of the front power connector

1. The ‘Pin Reference Name’ provides an associative tag that references commands used to define pin behaviors. GPI stands for "General Purpose Input" and GPO stands for "General Purpose Output". As an example, the CD command is used to define the behavior of GPO2 (DB-9 pin number 1). The ‘Pin Reference Name’ is the name used when referring to XTend commands and parameters.

Wiring diagrams

The following diagram shows the RS-232 DTE Device (male DB-9 connector) wired to a DCE RF modem (female DB-9).

9XTend-PKG-R RS-232/485 RF Modem User Guide 15

RS-485 (2-wire) operation

The following diagram shows the DCE RF modem (female DB-9 connector) wired to an RS-232 DCE Device (male DB-9).

Sample wireless connection: DTE <--> DCE DCE <--> DCE

RS-485 (2-wire) operation

DIP switch settings and pin signals

RS-485 (2-wire) Half-duplex DIP Switch Settings Pins used on the female RS-232 (DB-9) Serial Connector

RS-485 (2-wire) w/ Termination (optional)

9XTend-PKG-R RS-232/485 RF Modem User Guide 16

Terminationisthe120resistorbetweenT+ andT‐. DIPSwitchsettingsarereadandappliedonly whilepowering‐on.

Note Refer to Figure 3-15 and Figure 3-16 for the RJ-45 connector pin designations used in RS-485/422

environments.

The following table shows RS-485 (2-wire half-duplex) signals and their implementations on the XTend RF Modem.

DB-9 Pin RS-485 Name Description Implementation

RS-485 (2-wire) operation

2 T/R- (TRA) Negative Data

Transmit serial data to and from the RF modem

Line

5 GND Ground Signal Ground

8 T/R+ (TRB) Positive Data Line Transmit serial data to and from the RF modem

9 PWR Power Optional power input that is connected internally

to the front power connector

1, 3, 4, 6, 7 not used

Wiring diagram

The following diagram shows the XTend RF Modem in an RS-485 (2-wire) half-duplex environment.

9XTend-PKG-R RS-232/485 RF Modem User Guide 17

RS-485 (4-wire) and RS-422 Operation

DIP switch settings and pin signals

RS-485 (2-wire) Half-duplex DIP Switch Settings Pins used on the female RS-232 (DB-9) Serial Connector

RS-485 (2-wire) w/ Termination (optional)

Terminationisthe120resistorbetweenT+ andT‐. DIPSwitchsettingsarereadandappliedonly whilepowering‐on.

The following table shows the RS-485/422 (4-wire) Signals and their implementations on the XTend RF Modem.

DB-9 Pin RS-485/422 Name Description Implementation

2 T- (TA) Transmit Negative Data

Line

3R- (RA) Receive Negative Data

Line

5 GND Signal Ground Ground

7R+ (RB) Receive Positive Data

Line

8 T+ (TB) Transmit Positive Data

Line

9 PWR Power Optional power input that is connected internally to the front power

Serial data sent from the RF modem

Serial data received by the RF modem

Serial data sent from the RF modem

connector

1, 4, 6 not used

9XTend-PKG-R RS-232/485 RF Modem User Guide 18

RS-485 (4-wire) and RS-422 Operation

Wiring diagrams

The following diagram shows the XTend RF Modem in an RS-485 (4-wire) environment.

The following diagram shows the XTend RF Modem in an RS-422 environment.

RS-485/422 connection guidelines

The RS-485/422 protocol provides a solution for wired communications that can tolerate high noise and push signals over long cable lengths. RS-485/422 signals can communicate as far as 4000 feet (1200 m). RS-232 signals are suitable for cable distances up to 100 feet (30.5 m).

RS-485 offers multi-drop capability in which up to 32 nodes can be connected. The RS-422 protocol is used for pointto-point communications.

Suggestions for integrating the XTend RF Modem with the RS-485/422 protocol

1. When using Ethernet twisted pair cabling: Select wires so that T+ and T- are connected to each wire in a twisted pair. Likewise, select wires so that R+ and R- are connected to a twisted pair. (For example, tie the green and white/green wires to T+ and T-.)

2. For straight-through Ethernet cable (not cross-over cable) - The following wiring pattern works well: Pin3 to T+, Pin4 to R+, Pin5 to R-, Pin6 to T-

3. Note that the connecting cable only requires 4 wires (even though there are 8 wires).

4. When using phone cabling (RJ-11) - Pin2 in the cable maps to Pin3 on opposite end of cable and Pin1 maps to Pin4 respectively.

9XTend-PKG-R RS-232/485 RF Modem User Guide 19

Male DB-9 to RJ-45 Adapter (yellow)

Female DB-9 to RJ-45 Adapter (green)

RS-485 (4-wire) and RS-422 Operation

An XTend RS-232/422/485 RF Modem ‘Accessories Kit’ is available that includes connectors that facilitate RS-485/422 and other serial communications. Refer to Development guide on page 95 for information regarding the connectors and tools included in the kit.

9XTend-PKG-R RS-232/485 RF Modem User Guide 20

Operation

WARNING! When operating at 1 Watt power output, observe a minimum separation distance of 2 m (6 ft) between

modems. Transmitting in close proximity of other modems can damage modem front ends.

Serial communications

RS-232 and RS-485/422 data flow

The XTend RS-232/422/485 RF Modem interfaces to a host device through a standard DB-9 connector. Devices that have a standard DB-9 (RS-232) serial port can connect directly through the pins of the modem as shown in the figure below. The following figure shows the System Data Flow in an RS-232 environment.

Host and RF Modem settings

Serial communications between a host and an XTend RF Modem are dependent upon having matching baud rate, parity, stop bit and number of data bits settings. Failure to enter the modem into AT Command Mode is most commonly due to baud rate mismatch. Refer to the table below to ensure host serial port settings match those of the modem. The following table provides the Parameter Values Critical to serial communications between RF Modem and host.

Parameter Setting XTend RF Modem Default Parameter Value

Baud (Serial Data Rate) 9600 b/s (BD parameter = 3)

Number of Data Bits 8 (NB parameter = 0)

9XTend-PKG-R RS-232/485 RF Modem User Guide 21

Serial communications

Parameter Setting XTend RF Modem Default Parameter Value

Parity None (NB parameter = 0)

Number of Stop Bits 1 (NB parameter = 0)

Both the RF modem and host (PC) settings can be viewed and adjusted using Digi's proprietary XCTU Software.

Flow Control

The following diagram shows the Internal Data Flow Diagram (The five most commonly-used pin signals shown).

DI (Data In) buffer and Flow Control

When serial data enters the modem through the DI pin (Data In), the data is stored in the DI Buffer until it can be processed.

When the RB and RO parameter thresholds are satisfied (refer to ‘Transmit Mode’ section for more information), the modem attempts to initialize an RF connection. If the modem is already receiving RF data, the serial data is stored in the modem's DI Buffer. The DI buffer stores at least 2.1 KB. If the DI buffer becomes full, hardware or software flow control must be implemented in order to prevent overflow (loss of data between the host and RF modem).

To eliminate the need for flow control:

1. Send messages that are smaller than the DI buffer size. The size of the DI buffer varies according to the packet size (PK parameter) and the parity setting (NB parameter) used.

2. Interface at a lower baud rate (BD parameter) than the RF data rate (BR parameter).

Two cases in which the DI Buffer may become full and possibly overflow:

1. If the serial interface data rate is set higher than the RF data rate of the modem, the modem will receive data from the host faster than it can transmit the data over-the-air.

2. If the modem is receiving a continuous stream of RF data or if the modem is monitoring data on a network, any serial data that arrives on the DI pin (Data In) is placed in the DI Buffer. The data in the DI buffer will be transmitted over-the-air when the modem no longer detects RF data in the network.

Hardware Flow Control (CTS

CTS

(high) to signal to the host device to stop sending data [refer to FT (Flow Control Threshold) and CS (GPO1

Configuration) Commands]. CTS

). When the DI buffer is 17 bytes away from being full; by default, the modem de-asserts

is re-asserted after the DI Buffer has 34 bytes of memory available.

Software Flow Control (XON). XON/XOFF software flow control can be enabled using the FL (Software Flow Control) Command. This option only works with ASCII data.

DO (Data Out) buffer

When RF data is received, the data enters the DO buffer and is sent out the serial port to a host device. Once the DO Buffer reaches capacity, any additional incoming RF data is lost. The DO buffer stores at least 2.1 KB.

9XTend-PKG-R RS-232/485 RF Modem User Guide 22

Serial communications

Two cases in which the DO Buffer may become full and possibly overflow:

1. If the RF data rate is set higher than the interface data rate of the modem, the modem will receive data from the transmitting modem faster than it can send the data to the host.

2. If the host does not allow the modem to transmit data out from the DO buffer because of being held off by hardware or software flow control.

Hardware Flow Control (RTS

Buffer as long as RTS

Software Flow Control (XOFF). XON/XOFF software flow control can be enabled using the FL (Software Flow Control) Command. This option only works with ASCII data.

(GPI1) is de-asserted.

). If RTS is enabled for flow control (RT Parameter = 2), data will not be sent out the DO

Transparent operation

By default, XTend RF Modems operate in Transparent Mode. The modems act as a serial line replacement - all UART data received through the DI pin is queued up for RF transmission. When RF data is received, the data is sent out the DO pin.

When the RO (Packetization Timeout) parameter threshold is satisfied, the modem attempts to initialize an RF transmission. If the modem cannot immediately transmit (for instance, if it is already receiving RF data), the serial data continues to be stored in the DI Buffer. Data is packetized and sent at any RO timeout or when the maximum packet size is received.

The modem operates as described above unless the Command Mode Sequence is detected. The Command Mode Sequence consists of three copies of the command sequence character [CC parameter] surrounded by the before and after guard times [BT and AT parameters].

If the DI buffer becomes full, hardware or software flow control must be implemented in order to prevent overflow (loss of data between the host and modem).

API operation

API (Application Programming Interface) Operation is an alternative to the default Transparent Operation. The API is frame-based and extends the level to which a host application can interact with the networking capabilities of the module. When in API mode, all data entering and leaving the RF modem is contained in frames that define operations or events within the modem.

Transmit Data Frames (received through the DI (Data In) pin) include:

• 16-bit address

Receive Data Frames (sent out the DO (Data Out) pin) include:

• Showing a received RF packet (16 bits only)

• Response to a TX (Transmit) packet

• Showing events such as hardware reset, watchdog reset, asynchronous events, etc.

The modem will send data frames to the application containing status packets; as well as source, RSSI and payload information from received data packets.

API operation option facilitates many operations such as the examples cited below:

• Change destination addresses without having to enter command mode

• Receive success/failure status of each RF packet

9XTend-PKG-R RS-232/485 RF Modem User Guide 23

• Identify the source address of each received packet

To implement API operations, see API operation on page 66.

Serial communications

9XTend-PKG-R RS-232/485 RF Modem User Guide 24

Modes of operation

XTend RF Modems operate in five modes.

Idle mode

When not receiving or transmitting data, the RF modem is in Idle Mode. The modem shifts into the other modes of operation under the following conditions:

• Transmit Mode (Serial data is received in the DI Buffer)

• Receive Mode (Valid RF data is received through the antenna)

• Sleep Mode (Sleep Mode condition is met)

• Command Mode (Command Mode Sequence is issued)

Transmit mode

When the first byte of serial data is received from the UART in the DI buffer, the modem attempts to shift to Transmit Mode and initiate an RF connection with other modems. After transmission is complete, the modem returns to Idle Mode.

RF transmission begins after either of the following criteria is met:

1. RB bytes have been received by the UART and are pending for RF transmission. Refer to the RB (Packetization Threshold) Command.

2. At least one character has been received by the UART and is pending for RF transmission; and RO character times of silence been observed on the UART. Refer to the RO (Packetization Timeout) Command.

9XTend-PKG-R RS-232/485 RF Modem User Guide 25

Modes of operation

The following diagram shows the Transmit Mode Data Flow.

The character timeout trigger can be disabled by setting RO to zero. In this case, transmission will not begin until RB bytes have been received and are pending for RF transmission. The RB parameter may be set to any value between 1 and the RF packet size [refer to PK (Max RF Packet Size) parameter], inclusive. Note that transition to Transmit Mode cannot take place during RF reception; the RF reception must complete before the radio can transition into Transmit Mode.

If RB or RO conditions are met, the modem initializes a communications channel. Serial data in the DI buffer is grouped into RF packets (up to 2048 bytes in each packet, refer to PK Command), converted to RF data and is transmitted over-the-air until the DI buffer is empty.

Channel initialization is the process of sending an RF initializer that synchronizes receiving modems with the transmitting modem. During channel initialization, incoming serial data accumulates in the DI buffer.

RF data, which includes the payload data, follows the RF initializer. The payload includes up to the maximum packet size (PK Command) bytes. As the TX modem nears the end of the transmission, it inspects the DI buffer to see if more data exists to be transmitted. This could be the case if more than PK bytes were originally pending in the DI buffer or if more bytes arrived from the UART after the transmission began. If more data is pending, the transmitting modem assembles a subsequent packet for transmission.

Refer to the ‘RF Communication Modes’ section to view state diagrams that illustrate channel initialization and the sequence of events that follow.

RF packet

* When streaming multiple RF packets, the RF Initializer is only sent in front of the first packet.

9XTend-PKG-R RS-232/485 RF Modem User Guide 26

Modes of operation

RF initializer

An RF initializer is sent each time a new connection sequence begins. The RF initializer contains channel information that notifies receiving modems of information such as the hopping pattern used by the transmitting modem. The first transmission always sends an RF initializer.

An RF initializer can be of various lengths depending on the amount of time determined to be required to prepare a receiving modem. For example, a wake-up initializer is a type of RF initializer used to wake remote modems from Sleep Mode (Refer to the FH, LH, HT and SM Commands for more information). The length of the wake-up initializer should be longer than the length of time remote modems are in cyclic sleep.

Header

The header contains network addressing information that filters incoming RF data. The receiving modem checks for matching a Hopping Channel, VID and Destination Address. Data that does not pass through all three network filter layers is discarded.

Refer to the ‘Addressing’ section of the “RF Communication Modes” chapter for more information.

CRC (Cyclic Redundancy Check)

To verify data integrity and provide built-in error checking, a 16-bit CRC (Cyclic Redundancy Check) is computed for the transmitted data and attached to the end of each RF packet. On the receiving end, the receiving modem computes the CRC on all incoming RF data. Received data that has an invalid CRC is discarded [refer to the ‘Receive Mode’ section].

Receive mode

If a modem detects RF data while operating in Idle Mode, the modem transitions to Receive Mode to start receiving RF packets. Once a packet is received, the modem checks the CRC (cyclic redundancy check) to ensure that the data was transmitted without error. If the CRC data bits on the incoming packet are invalid, the packet is discarded. If the CRC is valid, the packet proceeds to the DO Buffer.

The following figure shows the Receive Mode Data Flow.

* Refer to the ‘Address Recognition’ section for more information regarding address recognition.

9XTend-PKG-R RS-232/485 RF Modem User Guide 27

Modes of operation

The modem returns to Idle Mode when valid RF data is no longer detected or after an error is detected in the received RF data. If serial data is stored in the DI buffer while the modem is in Receive Mode, the serial data will be transmitted after the modem is finished receiving data and returns to Idle Mode.

Sleep mode

Software sleep

Sleep Modes enable the modem to enter states of low-power consumption when not in use. Three software Sleep Modes are supported:

• Pin Sleep (Host Controlled)

• Serial Port Sleep (Wake on Serial Port activity)

• Cyclic Sleep (Wake on RF activity)

In order to enter Sleep Mode, one of the following conditions must be met (in addition to the modem having a nonzero SM parameter value):

1. The modem is idle (no data transmission or reception) for the amount of time defined by the ST (Time before Sleep) parameter.

Note ST is only active when SM = 4-5.

2. GPI2 (SLEEP) is asserted (only for the ‘Pin Sleep’ option).

When in Sleep Mode, the modem will not transmit or receive data until the modem first transitions to Idle Mode. All Sleep Modes are enabled and disabled using SM Command. Transitions into and out of Sleep Modes are triggered by various mechanisms as shown in the table below.

Sleep Mode (Setting)

Pin Sleep (SM = 1)

Serial Port Sleep (SM = 2)

Transition into Sleep Mode

Assert GPI2 pin - A micro controller can shut down and wake modems via the GPI2 pin.

Note: The modem will complete a transmission or reception before activating Pin Sleep.

Automatic transition to Sleep Mode occurs after a user-defined period of inactivity (no transmitting or receiving of data).

Period of inactivity is defined by the ST (Time before Sleep) Command.

Transition out of Sleep Mode (wake)

De-assert GPI2 pin (SM) See Power

When a serial byte is received on the DI pin

Related Commands

(SM), ST See Power

Power Consumption

requirements on

page 9

requirements on

page 9

Cyclic Sleep (SM = 4 - 8)

9XTend-PKG-R RS-232/485 RF Modem User Guide 28

RF modem transitions in and out of Sleep Mode in cycles (user-selectable wake-up interval of time is set using the SM command). The cyclic sleep in ter val o f time mus t be short er tha n th e inte rval o f time tha t is def ined b y the LH (Wake-up Initializer Timer) command.

Note: The modem can be forced into Idle Mode using the GPI2 pin if the PW (Pin Wake-up) command is issued.

(SM), ST, HT, LH, PW

See Power

requirements on

page 9

Modes of operation

The SM (Sleep Mode) command is central to setting all Sleep Mode configurations. By default, Sleep Modes are disabled (SM = 0) and the modem remains in Idle/Receive Mode. When in this state, the modem remains constantly ready to respond to serial or RF activity.

Pin Sleep (SM = 1)

• Pin/Host-controlled

This mode is voltage level activated. When the GPI2 pin is asserted, the modem will finish any transmitting or receiving activity; enter Idle Mode; then enter a state of sleep. When in Pin Sleep Mode, the modem will not respond to serial or RF activity.

After enabling Pin Sleep, the GPI2 pin controls whether the modem is active or sleeping. When GPI2 is de-asserted, the modem is fully operational. When GPI2 is asserted, the modem transitions to Sleep Mode and remains in its lowest power-consuming state until the pin is de-asserted. This pin is only active if the modem is setup to operate in this mode; otherwise the pin is ignored.

Once in Pin Sleep, CTS pin is also de-asserted (low) when the modem is in Pin Sleep Mode.

Note: The modem will complete a transmission or reception before activating Pin Sleep.

(GPO1) is de-asserted (high), indicating that data should not be sent to the modem. The PWR

Serial Port Sleep (SM = 2)

• Wake on serial port activity

Serial Port Sleep is a Sleep Mode in which the modem runs in a low power state until serial data is detected on the DI pin.

The period of time the modem sleeps is determined by ST (Time before Sleep) Command. Once a character is received through the DI pin, the modem returns to Idle Mode and is fully operational.

Cyclic Sleep (SM = 4-8)

Cyclic Sleep Modes allow modems to periodically wake and check for RF data. The modem wakes according to the times designated by the Cyclic sleep settings. If the modem detects a wake-up initializer during the time it is awake, the modem synchronizes with the transmitting modem and receives data after the wake-up initializer runs its duration. Otherwise, the modem returns to Sleep Mode and continues to cycle in and out of activity until a wake-up initializer is detected.

While the modem is in Cyclic Sleep Mode, CTS the modem. When the modem awakens to listen for data, GPO1 is asserted and any data received on the DI Pin is transmitted. The PWR pin is also de-asserted (low) when the modem is in Cyclic Sleep Mode.

(GPO1) is de-asserted (high) to indicate that data should not be sent to

The modem remains in Sleep Mode for a user-defined period of time ranging from 0.5 seconds to 16 seconds (SM parameters 4 through 8). After this interval of time, the modem returns to Idle Mode and listens for a valid data packet for 100 ms. If the modem does not detect valid data (on any frequency), the modem returns to Sleep Mode. If valid data is detected, the modem transitions into Receive Mode and receives the incoming RF packets. The modem then returns to Sleep Mode after a period of inactivity determined by the ST "Time before Sleep" parameter.

The modem can also be configured to wake from cyclic sleep when the GPI2 pin is de-asserted. To configure a modem to operate in this manner, PW (Pin Wake-up) Command must be issued. Once the GPI2 pin is de-asserted, the modem is forced into Idle Mode and can begin transmitting or receiving data. It remains active until data is no longer detected for the period of time specified by the ST Command, at which point it resumes its low-power cyclic state.

Cyclic scanning

9XTend-PKG-R RS-232/485 RF Modem User Guide 29

Modes of operation

Each RF transmission consists of an RF Initializer and payload. The RF initializer contains initialization information and all receiving modems must wake during the wake-up initializer portion of data transmission in order to be synchronized with the transmitting modem and receive the data.

The cyclic interval time defined by the SM (Sleep Mode) command must be shorter than the interval time defined by LH (Wake-up Initializer Timer) command.

The following figure shows the Correct Configuration (LH > SM): The length of the wake-up initializer exceeds the time interval of Cyclic Sleep. The receiver is guaranteed to detect the wake-up initializer and receive the accompanying payload data.

Command mode

To modify or read modem parameters, the modem must first enter into Command Mode (state in which incoming characters are interpreted as commands). Two command types are supported:

• AT Commands

• Binary Commands

For modified parameter values to persist in the modem registry, changes must be saved to non-volatile memory using the WR (Write) command. Otherwise, parameters are restored to previously saved values when the modem is powered off and then on again.

AT Command mode

To Enter AT Command mode:

1. Send the 3-character command sequence "+++" and observe guard times before and after the command characters. [refer to ‘Default AT Command Mode Sequence’ below.] The ‘Terminal’ tab (or other serial communications software) of the XCTU Software can be used to enter the sequence. [OR]

2. Assert (low) the CONFIG

[If the modem is mounted to a Digi RS-232/485 Interface Board, the result can be achieved by pressing the configuration switch down for 2 seconds.]

Default AT Command Mode Sequence (for transition to Command Mode):

pin and turn the power going to the modem off and back on (or pulse the SHDN pin).

• No characters sent for one second [refer to the BT (Guard Time Before) Command]

• Input three plus characters (“+++”) within one second

[refer to the CC (Command Sequence Character) Command.]

• No characters sent for one second [refer to the AT (Guard Time After) Command.]

All of the parameter values in the sequence can be modified to reflect user preferences.

9XTend-PKG-R RS-232/485 RF Modem User Guide 30

Modes of operation

Send AT commands

Send AT commands and parameters using the syntax shown below.

To read a parameter value stored in the modem register, leave the parameter field blank.

The preceding example would change the modem’s Destination Address to "0x1F". To store the new value to nonvolatile (long term) memory, the Write (ATWR) command must subsequently be sent before powering off the modem.

When a command is sent to the modem, the modem will parse and execute the command. Upon successful execution of a command, the modem returns an “OK” message. If execution of a command results in an error, the modem returns an “ERROR” message.

To Exit AT Command Mode:

1. If no valid AT Commands are received within the time specified by CT (Command Mode Timeout) Command, the modem automatically returns to Idle Mode. [OR]

2. Send ATCN (Exit Command Mode) Command.

For an example of programming the RF modem using AT Commands and descriptions of each configurable parameter, see Use XCTU to configure the RF Modem on page 34.

Binary Command mode

Sending and receiving parameter values using binary commands is the fastest way to change operating parameters of the modem. Binary commands are used most often to sample signal strength [refer to DB (Received Signal Strength) parameter] and/or error counts; or to change modem addresses and channels for polling systems when a quick response is necessary. Since the sending and receiving of parameter values takes place through the same serial data path as 'live' data (received RF payload), interference between the two types of data can be a concern.

Common questions about using binary commands:

• What are the implications of asserting CMD while live data is being sent or received?

• After sending serial data, is there a minimum time delay before CMD can be asserted?

• Is a time delay required after CMD is de-asserted before payload data can be sent?

• How does one discern between live data and data received in response to a command?

The CMD pin (GPI1) must be asserted in order to send binary commands to the modem. The CMD pin can be asserted to recognize binary commands anytime during the transmission or reception of data. The status of the CMD signal is only checked at the end of the stop bit as the byte is shifted into the serial port. The application does not allow control over when data is received, except by waiting for dead time between bursts of communication.

If the command is sent in the middle of a stream of payload data to be transmitted, the command will essentially be executed in the order it is received. If the modem is continuously receiving data, the radio will wait for a break in the received data before executing the command. The CTS command request [refer to figure below].

A minimum time delay of 100 µs (after the stop bit of the command byte has been sent) must be observed before the CMD pin can be de-asserted. The command executes after all parameters associated with the command have been sent. If all parameters are not received within 0.5 seconds, the modem returns to Idle Mode.

9XTend-PKG-R RS-232/485 RF Modem User Guide 31

signal will frame the response coming from the binary

Modes of operation

Note: When parameters are sent, they are two bytes long with the least significant byte sent first. Binary commands that return one parameter byte must be written with two parameter bytes.

Commands can be queried for their current value by sending the command logically ORed (bit-wise) with the value 0x80 (hexadecimal) with CMD asserted. When the binary value is sent (with no parameters), the current value of the command parameter is sent back through the DO pin.

Binary Command Write then Read

Signal #4 is CMD

Signal #1 is the DI signal

Signal #2 is the DO signal from the radio

Signal #3 is CTS

In this graph, a value was written to a register and then read out to verify it. While not in the middle of other received data, note that the CTS

IMPORTANT: In order for the modem to recognize a binary command, the RT (GPI1 Configuration) parameter must be set to one. If binary programming is not enabled (RT parameter value is not equal to ‘1’), the modem will not recognize that the CMD pin is asserted and therefore will not recognize the data as binary commands.

For a binary programming example, see Binary commands on page 36 (DT command example returns two bytes).

signal outlines the data response out of the modem.

9XTend-PKG-R RS-232/485 RF Modem User Guide 32

Configure the RF Modem

Automatic DIP switch configurations

Each time the RF modem is powered-on, AT commands are sent to the on-board module as dictated by the positions of the DIP switches. DIP switch configurations are sent automatically during the power-on sequence and affect modem parameter values as shown in the table below.

RF Modem DIP Switches

The following table shows the Power-up Options - Commands sent as result of DIP Switch Settings (SW = DIP Switch).

Switches Condition Behavior Commands Sent During Power-up

Switches 1 and 2 (Restore Defaults / Serial Interfacing)

9XTend-PKG-R RS-232/485 RF Modem User Guide 33

If SW1 and SW2 are ON (up)

If SW1 is ON (up) RS-232 Operation ATCS 0 (RS-232, CTS flow control)

If SW1 is OFF (down) RS-485 or RS-422

Restore Defaults ATRE

ATWR

ATCS 3 (RS-485 or RS-422 Operation)

Operation

(Restore Defaults)

(Write defaults to non-volatile memory)

Automatic DIP switch configurations

Switches Condition Behavior Commands Sent During Power-up

Switches 5 and 6 (TX/RX Modes)

IMPORTANT: To avoid overwriting previously stored custom configurations (due to the automatic configurations that take place each time the RF modem is powered-on), it is necessary to disable a processor located inside the modem.

To disable the processor, turn switches 5 and 6 ON (up). When switches 5 and 6 are ON, only the CS command is sent [refer to table below]. The following table shows the User Defined Mode (Switches 5 and 6 are ON (up)).

If SW5 and SW6 are OFF (down)

If SW5 is OFF (down) and SW6 is ON (up)

If SW5 is ON (up) and

SW6 is OFF (down)

If SW5 is ON (up) and

SW6 is ON (up)

Multipoint Base ATMY 0

ATDT FFFF

ATMT 3

Multipoint Remote

Point-to-Point ATAM

User Defined Processor is disabled and AT Commands are not sent to

ATAM

ATDT 0

ATMT 0

ATRR A

ATDT FFFF

ATMT 3

the modem (except for CS command as shown below.)

(Source Address)

(Destination Address)

(Multi-Transmit option)

(Auto-set MY, MY = unique)

(Destination Address)

(Multi-Transmit option)

(Retries)

(Auto-set MY, MY = unique)

(Destination Address)

(Multi-Transmit option)

Only DIP Switches ON (up) Condition Command Sent During Power-up

SW1, SW5 and SW6 If CS = 0, 1, 2 or 4 CS parameter remains the same

If CS = 3 ATCS 0 (RS-232 operation, CTS flow control)

SW2, SW5 and SW6 If CS = 2 ATCS 2 (GPO1 high)

If CS = 0, 1, 3 or 4 ATCS 3 (RS-485/422 Operation)

SW5 and SW6 only If CS = 2 ATCS 2 (GPO1 high)

If CS = 0, 1, 3 or 4 ATCS 3 (RS-485/422 Operation)

Note The results of SW 2, 5 and 6 ON and SW 5 and 6 ON are the same

Use XCTU to configure the RF Modem

XBee Configuration and Test Utility (XCTU) is a multi-platform program that enables developers to interact with Digi radio frequency (RF) devices through a graphical interface. The application includes built-in tools that make it easy to set up, configure, and test Digi RF devices.

For instructions on downloading and using XCTU, go to:

http://www.digi.com/products/xbee-rf-solutions/xctu-software/xctu

Refer to the online help for XCTU for more information on the program and how to use it. The help information is available at:

https://docs.digi.com/display/XCTU/XCTU+Overview

9XTend-PKG-R RS-232/485 RF Modem User Guide 34

Automatic DIP switch configurations

Refer to Command mode on page 30 for information regarding entrance into Command Mode, sending AT commands and exiting Command Mode.

PC setup

1. Set the DIP Switch to RS-232 mode. [Switches 1 and 5 are ON (up) and the remaining 4 switches are OFF (down).]

2. Connect the male DB-9 connector of the PC with the female DB-9 connector of the RF modem using an RS-232 cable.

3. Power the RF modem through the power connector.

Setup for RF Modem Configurations through XCTU:

To send AT commands, refer to Send AT commands on page 31.

Load default firmware settings

In XCTU, you can load default module firmware settings onto a module in your device list. To load default firmware settings:

1. Switch to Configuration working mode.

2. Select a module from the device list. XCTU displays the current firmware settings for that module.

3. From the Configuration toolbar, click the Load default firmware settings button to load the default values established by the firmware.

4. Firmware settings are loaded but not written to the module. In order to write them in the module, click the Write

module settings button on the toolbar.

Note You can also load default firmware settings with the Firmware explorer tool, but the tool does not have write

functionality.

CAUTION! Do not send commands to the modem during flash programming (when parameters are being written

to the modem registry).

9XTend-PKG-R RS-232/485 RF Modem User Guide 35

Binary commands

To Send Binary commands:

Example: Use binary commands to change the RF modem's destination address to 0x1A0D and save the new address to non-volatile memory.

1. RT Command must be set to '1' in AT Command Mode to enable binary programming.

2. Assert CMD (Pin 10 is driven high). (Enter Binary Command Mode)

3. Send Bytes [parameter bytes must be 2 bytes long]:

00 (Send DT (Destination Address) Command) 0D (Least significant byte of parameter bytes) 1A (Most significant byte of parameter bytes) 08 (Send WR (Write) Command)

4. De-assert CMD (GPI1 is driven low). (Exit Binary Command Mode)

Note CTS (GPO1) is high when a command is being executed. Hardware flow control must be disabled as CTS will

hold off parameter bytes.

Command reference table

This AT command information is provided for reference. For additional details, refer to the XTend and XTend vB RF module user's guides.

XTend Commands (The RF modems expect numerical values in hexadecimal. Hexadecimal values are designated by a “0x” prefix. Decimal equivalents are designated by a “d” suffix.)

AT Command

%V 0x3B (59d) Board Voltage 0x2CCCA - 0x5BFFA [read-

AM 0x40 (64d) Auto-set MY -- Networking and

AP v2.x20* -- API Enable 0 - 2 Serial Interfacing 1 0

AT 0x05 (5d) Guard Time After 2 - (ATST-3) [x 100 msec] Command Mode

BD 0x15 (21d) Interface Data Rate 0 - 8 (standard rates)

Binary Command

AT Command Name Parameter Range

only]

0x39 - 0x1C9C38 (Legacy Modem non-standard rates)

0x4B0 - 0x2580 and 0x4B00 0x1C9468 (XTend vB Modem non-standard rates)

Command Category

Diagnostics 4 --

Security

Options

Serial Interfacing 4 3

# Bytes Returned

-- --

2 0x0A (10d)

Factory Default

BR 0x39 (57d) RF Data Rate 0 - 1 RF Interfacing 1 2

BT 0x04 (4d) Guard Time Before 0 - 0xFFFF [x 100 msec] Command Mode

Options

9XTend-PKG-R RS-232/485 RF Modem User Guide 36

2 0x0A (10d)

Command reference table

AT Command

CC 0x13 (19d) Command Sequence

CD 0x28 (40d) GPO2 Configuration 0 - 4 Serial Interfacing 1 2

CF -- Number Base 0 - 2 Command Mode

CN 0x09 (9d) Exit Command Mode -- Command Mode

CS 0x1F (31d) GPO1 Configuration 0 - 4 Serial Interfacing 1 0

CT 0x06 (6d) Command Mode Timeout 2 - 0xFFFF [x 100 ms] Command Mode

DB 0x36 (54d) Received Signal Strength 0x6E - 0x28 [read-only] Diagnostics 2 --

DT 0x00 (0d) Destination Address 0 - 0xFFFF Networking and

E0 0x0A (10d) Echo Off -- Command Mode

Binary Command

AT Command Name Parameter Range

0x20 - 0x7F Command Mode

Character

Command Category

Options

Security

Options

# Bytes Returned

10x2B ["+"]

-- --

20xC8

-- --

Factory Default

(43d)

(200d)

E1 0x0B (11d) Echo On -- Command Mode

Options

ER 0x0F (15d) Receive Error Count 0 - 0xFFFF Diagnostics 2 0

FH 0x0D (13d) Force Wake-up Initializer -- Sleep (Low

Power)

FL 0x07 (7d) Software Flow Control 0 - 1 Serial Interfacing 1 0

FS 0x3E (62d) Forced Sync Time 0 - 0xFFFF [x 10 msec] RF Interfacing 2 0

FT 0x24 (36d) Flow Control Threshold 0 - (DI buffer size - 0x11)

[Bytes]

GD 0x10 (16d) Receive Good Count 0 - 0xFFFF Diagnostics 2 0

HP 0x11 (17d) Hopping Channel 0 - 9 Networking and

HT 0x03 (3d) Time before Wake-up

Initializer

HV -- Hardware Version 0 - 0xFFFF [read-only] Diagnostics 2 --

ID 0x27 (39d) Modem VID 0x11 - 0x7FFF (user-settable)

0 - 0xFFFF [x 100 msec] Sleep (Low

0x8000 - 0xFFFF (factory-set, read-only)

Serial Interfacing 2 DI buffer

Security

Power)

Networking and Security

-- --

2 0xFFFF

2 0x3332

size minus 0x11

(65535d)

(13106d)

9XTend-PKG-R RS-232/485 RF Modem User Guide 37

Command reference table

AT Command

KY 0x3C (60d) AES Encryption Key 0 - (Any other 64-digit hex

LH 0x0C (12d) Wake-up Initializer Timer 0 - 0xFF [x 100 msec] Sleep (Low

MD v2.x20* 0x31 (49d) RF Mode 0 - 6 Networking and

MK 0x12 (18d) Address Mask 0 - 0xFFFF Networking and

MT 0x3D (61d) Multi-Transmit 0 - 0xFF Networking and

MY 0x2A (42d) Source Address 0 - 0xFFFF Networking and

NB 0x23 (35d) Parity 0 - 4 Serial Interfacing 1 0

PB v2.x20* 0x45 (69d) Polling Begin Address 0 - 0xFFFF Networking and

PD v2.x20* 0x47 (71d) Minimum Polling Delay 0 - 0xFFFF

Binary Command

AT Command Name Parameter Range

valid key)

(Base: (x 1 ms), Remote: [x 10 ms])

Command Category

Networking and Security

Power)

Security

Networking and Security

# Bytes Returned

2 0xFFFF

Factory Default

(65535d)

PE v2.x20* 0x46 (70d) Polling End Address 0 - 0xFFFF Networking and

Security

PK 0x29 (41d) Maximum RF Packet Size 1 - 0x800 [Bytes] RF Interfacing 2 varies

PL 0x3A (58d) TX Power Level 0 - 4 RF Interfacing 1 4 (1 Watt)

PW 0x1D (29d) Pin Wake-up 0 - 1 Sleep (Low

Power)

RB 0x20 (32d) Packetization Threshold 1 - Current value of PK Serial Interfacing 2 0x800

RC -- Ambient Power - Single

Channel

RE 0x0E (14d) Restore Defaults -- (Special) -- --

RM -- Ambient Power - All

Channels

RN 0x19 (25d) Delay Slots 0 - 0xFF [slots] Networking and

RO 0x21 (33d) Packetization Timeout 0 - 0xFFFF [x UART character

0 - 0x31 [dBm, read-only] Diagnostics 1 --

No parameter - 0x7D0 Diagnostics 2 --

Security

Serial Interfacing 2 3

time]

(2048d)

RP 0x22 (34d) RSSI PWM Timer 0 - 0xFF [x 100 msec] Diagnostics 1 0x20 (32d)

9XTend-PKG-R RS-232/485 RF Modem User Guide 38

Command descriptions

AT Command

RR 0x18 (24d) Retries 0 - 0xFF Networking and

RT 0x16 (22d) GPI1 Configuration 0 - 2 Serial Interfacing 1 0

SB 0x37 (55d) Stop Bits 0 - 1 Serial Interfacing 1 0

SH 0x25 (37d) Serial Number High 0 - 0xFFFF [read-only] Diagnostics 2 varies

SL 0x26 (38d) Serial Number Low 0 - 0xFFFF [read-only] Diagnostics 2 varies

SM 0x01 (1d) Sleep Mode 0 - 8 (3 is reserved) Sleep (Low

ST 0x02 (2d) Time before Sleep (ATAT+3) - 0x7FFF [x 100

TP 0x38 (56d) Board Temperature 0 - 0x7F [read-only] Diagnostics 1 --

TR 0x1B (27d) Delivery Failure Count 0 - 0xFFFF [read-only] Diagnostics 2 0

TT 0x1A (26d) Streaming Limit 0 - 0xFFFF [0 = disabled] Networking and

Binary Command

AT Command Name Parameter Range

msec]

Command Category

Security

Power)

Sleep (Low Power)

Security

# Bytes Returned

1 0x0A (10d)

2 0x64

Factory Default

(100d)

TX 0x3F (63d) Transmit Only 0 - 1 RF Interfacing 1 0

VL -- Firmware Version -

verbose

VR 0x14 (20d) Firmware Version 0 - 0xFFFF [read-only] Diagnostics 2 --

WA -- Active Warning Numbers Returns string Diagnostics -- --

WN -- Warning Data Returns string Diagnostics -- --

WR 0x08 (8d) Write -- (Special) -- --

WS -- Sticky Warning Numbers Returns string Diagnostics -- --

* Firmware version in which command and parameter options were first supported.

Returns string Diagnostics -- --

Command descriptions

Commands in this section are listed alphabetically. Command categories are designated between the "< >" symbols that follow each command title. By default, XTend RF Modems expect numerical values in hexadecimal since the default value of the CF (Number Base) Parameter is '1'. Hexadecimal values are designated by the "0x" prefix and decimal values by the "d" suffix.

%V (Board Voltage) Command

<Diagnostics> %V Command is used to read the current voltage of the modem circuit board.

Sample Output:

9XTend-PKG-R RS-232/485 RF Modem User Guide 39

Command descriptions

5.02 V (when ATCF = 0) 5051F (when ATCF = 1) *

5.02 (when ATCF = 2)

* When CF = 1 (default), a hex integer is shown that is equal to (voltage * 65536d).

AT Command: AT%V

Binary Command: 0x3B (59 decimal)

Parameter Range (read-only): 0x2CCCA - 0x5BFFA (2.80 - 5.75 decimal)

Number of bytes returned: 4

AM (Auto-set MY) Command

AT Command: ATAM

Binary Command: 0x40 (64 decimal)

<Networking and Security> AM Command is used to automatically set the MY (Source Address) parameter from the factory-set serial number of the modem. The address is formed with bits 29, 28 and 13-0 of the serial number (in that order). The resulting value is displayed as a result of this command.

AP (API Enable) command

<Serial Interfacing> The AP command is used to enable the modem to operate using the frame-based API operation.

AT Command: ATAP

Parameter Range:0 - 2

Parameter Configuration

0 API Disabled (Transparent Operation)

1 API enabled (w/out escaped characters)

2 API enabled (with escaped characters)

Default Parameter Value:0

Number of Bytes Returned:1

Legacy Modem Minimum Firmware Version Required: 2.x20

AT (Guard Time After) command

<Command Mode Options> AT Command is used to set/read the time-of-silence that follows the command sequence character (CC Command) of the AT Command Mode Sequence (BT + CC + AT). By default, 1 second must elapse before and after the command sequence character.

The times-of-silence surrounding the command sequence character are used to prevent inadvertent entrance into AT Command Mode.

9XTend-PKG-R RS-232/485 RF Modem User Guide 40

Command descriptions

AT Command: ATAT

Binary Command: 0x05 (5 decimal)

Parameter Range:2 - (ATST-3), up to 0x7FFC

[x 100 milliseconds]

Default Parameter Value: 0x0A (10 decimal)

Number of bytes returned: 2

Related Commands: BT (Guard Time Before), CC (Command Sequence Character)

BD (Interface Data Rate) command

<Serial Interfacing> The BD command is used to set and read the serial interface data rate (baud rate) used between the RF modem and host. This parameter determines the rate at which serial data is sent to the modem from the host. Modified interface data rates do not take effect until the CN (Exit AT Command Mode) command is issued and the system returns the 'OK' response.

When parameters 0-8 are sent to the modem, the respective interface data rates are used (as shown in the table on the right).

The RF data rate is not affected by the BD parameter. If the interface data rate is set higher than the RF data rate, a flow control configuration may need to be implemented.

The range between standard and non-standard baud rates is invalid.

AT Command: ATBD

Binary Command: 0x15 (21 decimal)

Parameter Ranges: 0 - 8 (standard rates) 0x39 - 0x1C9C38 (Legacy Modem non-standard rates)

0x4B0 - 0x2580 and 0x4B00 - 0x1C9468 (XTend vB Modem non-standard rates)

Parameter Configuration (b/s)

0 1200

1 2400

2 4800

3 9600

4 19200

5 38400

6 57600

7 115200

8 230400

Default Parameter Value: 3

9XTend-PKG-R RS-232/485 RF Modem User Guide 41

Command descriptions

AT Command: ATBD

Legacy Modem Non-standard baud rates supported as of firmware v2.x20

Number of bytes returned: 4

Non-standard Interface Data Rates

BD values above 0x38 (Legacy) or 0x4AF (XTend vB) are interpreted as an actual baud rate. When a non-standard value is sent, the closest interface data rate represented by the number is stored in the BD register. For example, a rate of 19200 b/s can be set by sending the following command line "ATBD4B00".

Note on Legacy only: when the BD command is sent with a non-standard interface data rate, the UART will adjust to accommodate the requested interface rate. In most cases, the clock resolution will cause the stored BD parameter to vary from the parameter that was sent. Reading the BD command (send the "ATBD" command without an associated parameter value) will return the value actually stored in the modem’s BD register.

BR (RF Data Rate) command

<RF Interfacing> The BR command is used to set and read the RF data rate (rate that RF data is transmitted over-theair) of the modem.

AT Command: ATBR

Binary Command: 0x39 (57 decimal)

Parameter Range:0 - 1

Parameter RF data rate

010 kb/s

1 125 kb/s

Default Parameter Value:1

Number of bytes returned: 1

BT (Guard Time Before) command

<AT Command Mode Options> The CC command is used to set/read the ASCII character used between guard times of the AT Command Mode Sequence (BT + CC + AT). This sequence enters the modem into AT Command Mode so that data entering the modem (from the host) is recognized as commands instead of payload.

AT Command: ATCC

Binary Command: 0x13 (19 decimal)

Parameter Range: 0x20 - 0x7F

Default Parameter Value: 0x2B (ASCII “+”)

Number of bytes returned: 1

Related Commands: AT (Guard Time After), BT (Guard Time Before)

9XTend-PKG-R RS-232/485 RF Modem User Guide 42

Command descriptions

CC (Command Sequence Character) command

AT Command: ATCC

Binary Command: 0x13 (19 decimal)

Parameter Range: 0x20 - 0x7F

Default Parameter Value: 0x2B (ASCII “+”)

Number of bytes returned: 1

Related Commands: AT (Guard Time After), BT (Guard Time Before)

CD (GPO2 Configuration) Command

<Serial Interfacing> CD Command is used to select/read the behavior of the GPO2 line (pin 3).

AT Command: ATCD

Binary Command: 0x28 (40 decimal)

Parameter Range: 0 - 8 (standard rates)

Parameter Configuration

0RX LED

1 Default High

2 Default Low

3(reserved)

4 RX LED (valid address only)

Default Parameter Value: 2

Number of bytes returned: 1

9XTend-PKG-R RS-232/485 RF Modem User Guide 43

Command descriptions

CF (Number Base) Command

<Command Mode Options> CF command is used to set/read the command formatting setting.

The following commands are always entered and read in hex, no matter the CF setting:

VR (Firmware Version) HV (Hardware Version) KY (AES Encryption Key)

AT Command: ATCF

Parameter Range: 0 – 2

Para meter Con figu ration

0 Commands utilize default number base; decimal commands may output units

1 All commands forced to unsigned, unit-less hex

2 Commands utilize their default number base; no units are output

Default Parameter Value: 1

Number of bytes returned: 1

CN (Exit AT Command Mode) Command

<Command Mode Options> The CN command is used to explicitly exit the modem from AT Command Mode.

AT Command: ATCN

Binary Command: 0x09 (9 decimal)

CS (GPO1 Configuration) Command

<Serial Interfacing> CS Command is used to select the behavior of the GP01 pin (pin 9). This output can provide RS232 flow control, control the TX enable signal (for RS-485 or RS-422 operations).

By default, GP01 provides RS-232 CTS

AT Command: ATCS

Binary Command: 0x1F (31 decimal)

Parameter Range: 0 - 4

Parameter Configuration

(Clear-to-Send) flow control.

0 RS-232 CTS

1 RS-485 TX enable low

2High

3 RS-485 TX enable high

9XTend-PKG-R RS-232/485 RF Modem User Guide 44

flow control

Command descriptions

AT Command: ATCS

4Low

Default Parameter Value: 0

Number of bytes returned: 1

Related Commands: RT (GPI1 Configuration), TO (GP01 Timeout)

CT (Command Mode Timeout) Command

<Command Mode Options> The CT command is used to set and read the amount of inactive time that elapses before the modem automatically exits from AT Command Mode and returns to Idle Mode.

Use the CN (Exit AT Command Mode) command to exit AT Command Mode manually.

AT Command: ATCT

Binary Command: 0x06 (6 decimal)

Parameter Range:2 - 0xFFFF

[x 100 milliseconds]

Default Parameter Value: 0xC8 (200d)

Number of bytes returned: 2

Related Command: CN (Exit AT Command Mode)

DB (Received Signal Strength) Command

<Diagnostics> DB Command is used to read the receive signal strength (in decibels relative to milliwatts) of the last received packet. This parameter is useful in determining range characteristics of the RF modems under various conditions.

In default mode, this command shows the power level in signed decimal format with the units (dBm). If CF = 1, the magnitude of the value is presented in unsigned hex. If CF = 2, the value is presented in decimal, but without the units.

Sample Output:

-88 dBm (when ATCF = 0) 58 (when ATCF = 1)

-88 (when ATCF = 2)

Note If the DB register is read before the modem has received an RF packet, the modem will return a value of

0x8000 (which means an RF packet has not yet been received).

AT Command: ATDB

Binary Command: 0x36 (54 decimal)

Parameter Range (read-only): 0x6E - 0x28 (-110 to -40 Decimal)

Number of bytes returned: 2

9XTend-PKG-R RS-232/485 RF Modem User Guide 45

Command descriptions

DT (Destination Address) Command

<Networking and Security> DT Command is used to set/read the networking address of an RF modem. The modems utilize three filtration layers: Vendor ID Number (ATID), Channel (ATHP), and Destination Address (ATDT). The DT command assigns an address to a modem that enables it to communicate only with other modems having the same address. All modems that share the same DT parameter can communicate with each other.

RF modems in the same network with a different destination address (than that of the transmitter) will listen to all transmissions to stay synchronized, but will not send any of the data out their serial ports.

AT Command: ATDT

Binary Command: 0x00

Parameter Range:0 - 0xFFFF

Default Parameter Value: 0

Number of bytes returned: 2

Related Commands: HP (Hopping Channel), ID (Modem VID), MK (Address Mask), MY (Source Address)

E0 (Echo Off) Command

<Command Mode Options> E0 Command turns off character echo in AT Command Mode.

By default, echo is off.

AT Command: ATE0

Binary Command: 0x0A (10 decimal)

E1 (Echo On) Command

<Command Mode Options> E1 Command enables character echo in AT Command Mode. Each typed character will be echoed back to the terminal when ATE1 is active. E0 (Echo Off) is the default.

AT Command: ATE1

Binary Command: 0x0B (11 decimal)

ER (Receive Error Count) Command

<Diagnostics> The ER command is used to set/read the number of receive-errors. The error count records the number of packets partially received then aborted on a reception error. This value returns to 0 after a reset and is not nonvolatile (Value does not persist in the modem's memory after a power-up sequence). Once the Receive Error Count reaches its maximum value (up to 0xFFFF), it remains at its maximum count value until the maximum count value is explicitly changed or the modem is reset.

The ER parameter is not reset by pin, serial port or cyclic sleep modes.

9XTend-PKG-R RS-232/485 RF Modem User Guide 46

Command descriptions

AT Command: ATER

Binary Command: 0x0F (15 decimal)

Parameter Range: 0 - 0xFFFF

Default Parameter Value: 0

Number of bytes returned: 2

Related Commands: GD (Receive Good Count)

FH (Force Wake-up Initializer) Command

<Sleep (Low Power)> The FH command is used to force a Wake-up Initializer to be sent on the next transmission. Use only with cyclic sleep modes active on remote modems.

ATFH will not send a long header if ATHT = 0xFFFF. WR (Write) Command does not need to be issued with FH Command.

AT Command: ATFH

Binary Command: 0x0D (13 decimal)

FL (Software Flow Control) Command

<Serial Interfacing> The FL command is used to configure software flow control. Hardware flow control is implemented with the modem as the GP01 pin (CTS be transferred to the modem.

FL Command can be used to allow software flow control to also be enabled. The XON character used is 0x11 (17 decimal). The XOFF character used is 0x13 (19 decimal)

AT Command: ATFL

Binary Command: 0x07 (7 decimal)

Parameter Range: 0 - 1

Parameter Configuration

0 Disable software flow control

1 Enable software flow control

Default Parameter Value: 0

Number of bytes returned: 1

pin of the OEM RF module), which regulates when serial data can

FS (Forced Sync Time) Command

<RF Interfacing> The FS command only applies to streaming data. Normally, only the first packet of a continuous stream contains the full RF initializer. The RF modems then remain synchronized for subsequent packets of the stream. This parameter can be used to periodically force an RF initializer during such streaming. Any break in UART

9XTend-PKG-R RS-232/485 RF Modem User Guide 47

Command descriptions

character reception long enough to drain the DI Buffer (UART receive buffer) and cause a pause in RF data transmission will also cause an RF initializer to be inserted on the next transmission.

AT Command: ATFS

Binary Command: 0x3E (62 decimal)

Parameter Range:0 - 0xFFFF [x 10 milliseconds]

Default Parameter Value: 0

Number of bytes returned: 2

FT (Flow Control Threshold) Command

<Serial Interfacing> The FT command is used to set/read the flow control threshold. When FT bytes have accumulated in the DI buffer (UART Receive), CTS

AT Command: ATFT

Binary Command: 0x24 (36 decimal)

is de-asserted or the XOFF software flow control character is transmitted.

Parameter Range: 0 - (DI buffer size minus 0x11) [Bytes]

Default Parameter Value: DI Buffer size minus 0x11 (17 decimal)

Number of bytes returned: 2

GD (Receive Good Count) Command

<Diagnostics> The GD command is used to set/read the count of good received RF packets. Its parameter value is reset to 0 after every reset and is not non-volatile (The parameter value does not persist in the RF modem's memory after a power-up sequence). Once the "Receive Good Count" reaches its maximum value (up to 0xFFFF), it remains at its maximum count value until the maximum count value is manually changed or the modem is reset.

The GD parameter is not reset by pin, serial port or cyclic sleep modes.

AT Command: ATGD

Binary Command: 0x10 (16 decimal)

Parameter Range: 0 - 0xFFFF

Default Parameter Value: 0

Number of bytes returned: 2

Related Commands: ER (Receive Error Count)

HP (Hopping Channel) Command

<Networking and Security> The HP command is used to set/read the RF modem's hopping channel number. A channel is one of three layers of filtration available to the modem.

9XTend-PKG-R RS-232/485 RF Modem User Guide 48

Command descriptions

In order for modems to communicate with each other, the modems must have the same channel number since each channel uses a different hopping sequence. Different channels can be used to prevent modems in one network from listening to transmissions of another.

AT Command: ATHP

Binary Command: 0x11 (17 decimal)

Parameter Range: 0 - 9

Default Parameter Value: 0

Number of bytes returned: 1

Related Commands: ID (Modem VID), DT (Destination Address), MK (Address Mask)

HT (Time before Wake-up Initializer) Command

<Sleep (Low Power)> The HT command is used to set/read the time of inactivity (no serial or RF data is sent or received) before a wake-up initializer is sent by a TX (transmitting) RF modem. The HT parameter should be set shorter than inactivity timeout [ST Command] time of any RX (receiving) modems operating in Cyclic Sleep (SM=4-8). The wake-up initializer sent by the TX modem instructs all RX modems to remain awake to receive RF data.

From the RX modem perspective: After HT time elapses and the inactivity timeout [ST Command] is met, the RX modem goes into cyclic sleep. In cyclic sleep, the RX modem wakes once per sleep interval [SM Command] to check for a wake-up initializer. When a wake-up initializer is detected, the modem stays awake to receive data. The wake-up initializer must be longer than the cyclic sleep interval to ensure that sleeping modems detect incoming data.

When HT time elapses, the TX modem knows it needs to send a wake-up Initializer for all RX modems to remain awake and receive the next transmission.

AT Command: ATHT

Binary Command: 0x03 (3 decimal)

Parameter Range:0 - 0xFFFF [x 100 milliseconds]

Default Parameter Value: 0xFFFF (wake-up initializer will not be sent)

Number of bytes returned: 2

Related Commands: LH (Wake-up Initializer Timer), SM (Sleep Mode), ST (Time before Sleep)

HV (Hardware Version) Command

<Diagnostics> The HV command is used to read the hardware version of the RF modem.

AT Command: ATHV

Parameter Range:0 - 0xFFFF [Read-only]

Legacy Modem Minimum Firmware Version Required: v1.x80

9XTend-PKG-R RS-232/485 RF Modem User Guide 49

Command descriptions

ID (Modem VID) Command

<Networking and Security> The ID command is used to set/read the VID (Vendor Identification Number) of the RF modem. RF modems must have matching VIDs in order to communicate.

AT Command: ATID

Binary Command: 0x27 (39 decimal)

Parameter Range:

0x11 - 0x7FFF (user-settable)

0 - 0x10 and 0x8000 - 0xFFFF (factory-set)

Default Parameter Value: 0x3332 (13106d)

Number of bytes returned: 2

KY (AES Encryption Key) Command

<Networking and Security> The KY command is used to set the 256-bit AES (Advanced Encryption Standard) key for encrypting/decrypting data. Once set, the key cannot be read out of the modem by any means. The entire payload of the packet is encrypted using the key and the CRC is computed across the ciphertext. When encryption is enabled, each packet carries an additional 16 bytes to convey the random CBC Initialization Vector (IV) to the receiver(s). The KY value may be “0” or any 256-bit value (= 64 hex digits = 32 bytes). Any other value, including entering ATKY by itself with no parameters, causes an error.

A modem with the wrong key (or no key) will receive encrypted data, but the data driven out the serial port will be meaningless. Likewise, a modem with a key will receive unencrypted data sent from a modem without a key, but the output will be meaningless. Because CBC mode is utilized, repetitive data appears differently in different transmissions due to the randomly-generated IV.

AT Command: ATKY

Binary Command: 0x3C (60 decimal)

Parameter Range: 0 - (any other 64-digit hex valid key)

Default Parameter Value: 0 (disabled)

Number of bytes returned: 2

Number Base: Always Hexadecimal

LH (Wake-up Initializer Timer) Command

<Sleep (Low Power)> The LH Command is used to set/read the duration of time during which the wake-up initializer is sent. When receiving modems are in Cyclic Sleep Mode, they power-down after a period of inactivity (as specified by the ST parameter) and will periodically wake and listen for transmitted data. In order for the receiving modems to remain awake, they must detect ~35ms of the wake-up initializer.

LH Command must be used whenever a receiving modem is operating in Cyclic Sleep Mode. The Wake-up Initializer Time must be longer than the cyclic sleep time that [as determined by SM (Sleep Mode) parameter]. If the wake-up initializer time were less than the Cyclic Sleep interval, the connection would be at risk of missing the wake-up initializer transmission.

9XTend-PKG-R RS-232/485 RF Modem User Guide 50

Command descriptions

Refer to figures located under the SM command description to view diagrams of correct and incorrect configurations. The images emphasize that the LH value must be greater than the SM value.

AT Command: ATLH

Binary Command: 0x0C (12 decimal)

Parameter Range:0 - 0xFF

[x 100 milliseconds]

Default Parameter Value: 1

Number of bytes returned: 1

Related Commands: HT (Time before Wake-up Initializer), SM (Sleep Mode), ST (Time before Sleep)

MD (RF Mode) Command

<Networking and Security> The MD command is used to select/read the settings that enable the Polling and Repeater Modes on the modem.

Polling Mode - A ‘Polling Base’ is responsible for polling remotes. A ‘Polling Remote’ requires a poll in order to transmit.

Repeater Mode - A ‘Repeater’ re-sends RF data unless the transmission is addressed to it or if the transmission has already been detected. A ‘Repeater End Node’ handles repeated messages, but will not repeat the message over-theair.

Refer to the Polling and Repeater Mode sections of the ‘RF Communication Modes’ chapter for more information.

AT Command: ATMD

Binary Command: 0x31 (49 decimal)

Parameter Range: 0 - 6

Parameter Configuration

0 Transparent Operation (Repeater Base)

1 [reserved - not used]

2 [reserved - not used]

3Polling Base

4Polling Remote

5Repeater

6Repeater End Node

Default Parameter Value: 0

Number of bytes returned: 1

Legacy Modem Minimum Firmware Version Required: 2.x20

9XTend-PKG-R RS-232/485 RF Modem User Guide 51

Command descriptions

MK (Address Mask) Command

<Networking and Security> The MK command is used to set/read the Address Mask of a modem.

All RF data packets contain the Destination Address of the TX (transmitting) modem. When a packet is received, the TX modem Destination Address is logically "ANDed" (bitwise) with the Address Mask of the RX (receiving) modem. The resulting value must match the Destination Address or Address Mask of the RX modem for the packet to be received and sent out the RX modem's DO (Data Out) pin. If the "ANDed" value does not match the Destination Address or Address Mask of the RX modem, the packet is discarded.

Sniffer Mode (when MK = 0): ACK requests are ignored and every RX (receive) frame is sent to the UART, without regard for repeated frames.

All “0” values are treated as irrelevant values and ignored.

AT Command: ATMK

Binary Command: 0x12 (18 decimal)

Parameter Range:0 - 0xFFFF

Default Parameter Value: 0xFFFF (65535d)

Number of bytes returned: 2

Related Commands: DT (Destination Address), HP (Hopping Channel), ID (Modem VID), MY (Source Address)

MT (Multi-transmit) Command

<Networking and Security> The MT command is used to enabled multiple transmissions of RF data packets. When Multi-transmit Mode is enabled (MT > 0), packets do not request an ACK (acknowledgment) from the receiving RF modem(s). MT takes precedence over RR, so if both MT and RR are non-zero, then MT+1 packets will be sent (with no ACK requests).

When a receiving modem receives a packet with remaining forced retransmissions, it calculates the length of the packet and inhibits transmission for the amount of time required for all retransmissions. Thereafter, a random number of delay slots are inserted between 0 and RN before transmission is allowed from the receiving modem(s). This prevents all listening modems from transmitting at once upon conclusion of a multiple transmission event (when RN > 0).

NOTE: The actual number of forced transmissions is the parameter value plus one. For example, if MT = 1, two transmissions of each packet will be sent.

AT Command: ATMT

Binary Command: 0x3D (61 decimal)

Parameter Range: 0 - 0xFF

Default Parameter Value:0 (no forced retransmissions)

Number of bytes returned: 1

Related Commands: Networking (DT, MK, MY, RN, TT), Serial Interfacing (BR, PK, RB, RO), RF Interfacing (FS)

9XTend-PKG-R RS-232/485 RF Modem User Guide 52

Command descriptions

MY (Source Address) Command

<Networking and Security> The MY command is used to set/read the Source Address of the RF modem.

AT Command: ATMY

Binary Command: 0x2A (42 decimal)

Parameter Range: 0 - 0xFFFF

Default Parameter Value: 0xFFFF (Disabled - DT (Destination Address) parameter serves as both source and destination address.)

Number of bytes returned: 2

Related Commands: DT (Destination Address), HP (Hopping Channel), ID (Modem VID), MK (Address Mask)

NB (Parity) Command

<Serial Interfacing> The NB command is used to select/read the parity settings of the RF modem for UART communications.

AT Command: ATNB

Binary Command: 0x23 (35 decimal)

Parameter Range: 0 - 4

Parameter Configuration

0 8-bit (no parity or

7-bit (any parity)

1 8-bit even

28-bit odd

38-bit mark

4 8-bit space

Default Parameter Value: 0

Number of bytes returned: 1

PB (Polling Begin Address) Command

<Networking and Security> PB command is used to set/read the modem’s Polling Begin Address - the first address polled Polling Mode is enabled.

Polling Operations: The ‘Polling Base’ (MD = 3) cycles through a sequential range of addresses, polling each ‘Polling Remote’ (MD = 4). The base then waits for a response and proceeds to the next ‘Polling Remote’. Each ‘Polling Remote’ responds by sending the data from the Data In buffer following the RB and RO parameters. When there is no eligible data to send, the ‘Polling Remote’ will not respond. The ‘Polling Base’ will move to the next address in the polling sequence after a short delay.

9XTend-PKG-R RS-232/485 RF Modem User Guide 53

Command descriptions

AT Command: ATPB

Binary Command: 0x45 (69 decimal)

Parameter Range: 0 - 0xFFFF

Default Parameter Value: 0

Number of bytes returned: 2

Legacy Modem Minimum Firmware Version Required: 2.x20

Related Commands: MD (RF Mode), PE (Polling End Address), PD (Minimum Polling Delay)

PD (Minimum Polling Delay) Command

<Networking and Security> The PD command is used to set/read Polling Delay (Base, MD=3) or Polling Timeout (Remote, MD=4).

Polling Delay (Base) is the time between polling cycles. The Polling Base will start the polling cycle after sending the first poll. After the polling cycle has completed, the timer is restarted.

Polling Timeout (Remote) is the amount of time the remote unit will hold data from the serial port before discarding it. Data entered within the PD time of the poll is transmitted and not discarded.

AT Command: ATPD

Binary Command: 0x47 (71 decimal)

Parameter Range: 0 - 0xFFFF (Base: [x 1ms], Remote: [x 10ms])

Default Parameter Value: 0

Number of bytes returned: 2

Legacy Modem Minimum Firmware Version Required: 2.x20

Related Commands: MD (RF Mode), PB (Polling Begin Address), PE (Polling End Address)

PE (Polling End Address) Command

<Networking and Security> PE command is used to set/read the modem’s Polling End Address - the last address polled when Polling Mode is enabled.

Polling Operations: The ‘Polling Base’ (MD = 3) cycles through a sequential range of addresses, polling each ‘Polling Remote’ (MD = 4). The base then waits for a response and proceeds to the next ‘Polling Remote’. Each ‘Polling Remote’ responds by sending data from the DI buffer following the RB and RO parameters. When there is no eligible data to send, the ‘Polling Remote’ will not respond. The ‘Polling Base’ will move to the next address in the polling sequence after a short delay.

AT Command: ATPE

Binary Command: 0x46 (70 decimal)

Parameter Range: 0 - 0xFFFF

9XTend-PKG-R RS-232/485 RF Modem User Guide 54

Command descriptions

AT Command: ATPE

Default Parameter Value: 0

Number of bytes returned: 2

Legacy Modem Minimum Firmware Version Required: 2.x20

Related Commands: MD (RF Mode), PB (Polling Begin Address), PD (Minimum Polling Delay)

PK (Maximum RF Packet Size) Command

<RF Interfacing> The PK command is used to set/read the maximum size of RF packets transmitted from an RF modem. The maximum packet size can be used along with the RB and RO parameters to implicitly set the channel dwell time.

If PK is set above 256 and BR is subsequently changed to 0, PK will automatically be lowered to 256 and a warning will be raised (refer to the BR (RF Data Rate) and WN (Warning Data) commands for details).

Changes to the PK parameter may have a secondary effect on the RB (Packetization Threshold) parameter. RB must always be less than or equal to PK. If PK is changed to a value that is less than the current value of RB, the RB value is automatically lowered to be equal to PK.

* When BR = 0 (9600 baud), the maximum PK value is 0x100 (256d). When BR = 1 (115,200 baud), the maximum PK value is 0x800 (2048d).

AT Command: ATPK

Binary Command: 0x29 (41 decimal)

Parameter Range:1 - 0x800 [Bytes]

Default Parameter Value:0x100* or 0x800* (256 or 2048 decimal)

Number of bytes returned: 2

Related Commands: BR (RF Data Rate) RB (Packetization Threshold), RO (Packetization Timeout), WN (Warning Data)

PL (TX Power Level) Command

<RF Interfacing> The PL command is used to set/read the power level at which the RF modem transmits data. The XTend vB modem does not support the 1 mW and 10 mW power levels. If PL is set to 0 or 1, the device transmits at 100 mW.

AT Command: ATPL

Binary Command: 0x3A (58 decimal)

Parameter Range: 0 - 4

Default Parameter Value: 4

Number of bytes returned: 1

9XTend-PKG-R RS-232/485 RF Modem User Guide 55

Command descriptions

PW (Pin Wake-up) Command

<Sleep (Low Power)> Under normal operation, an RF modem in Cyclic Sleep Mode cycles from an active state to a lowpower state at regular intervals until data is ready to be received. If the PW parameter is set to 1, the GPI2 pin (SLEEP) can be used to awaken the modem from Cyclic Sleep. When the GPI2 Pin is de-asserted (low), the modem will be fully operational and will not go into Cyclic Sleep.

Once the GPI2 pin is asserted, the modem will remain active for the period of time specified by the ST (Time before Sleep) parameter and will return to Cyclic Sleep Mode (if no data is ready to be transmitted). PW Command is only valid if Cyclic Sleep has been enabled.

AT Command: ATPW

Binary Command: 0x1D (29 decimal)

Parameter Range: 0 - 1

Parameter Configuration

0Disabled

1Enabled

Default Parameter Value: 0

Number of bytes returned: 1

Related Commands: SM (Sleep Mode), ST (Time before Sleep)

RB (Packetization Threshold) Command

<Serial Interfacing> The RB command is used to set/read the character threshold value.

RF transmission begins after data is received in the DI Buffer and either of the following criteria is met:

• RB characters received by the UART

• RO character times of silence detected on the UART receive lines (after receiving at least 1 Byte of data)

If PK (Max. RF Packet Size) is lowered below the value of RB, RB is automatically lowered to match the PK value. If (RO = 0), RB bytes must be received before beginning transmission.

Note: RB and RO criteria only apply to the first packet of a multi-packet transmission. If data remains in the DI Buffer after the first packet, transmissions will continue in a streaming manner until there is no data left in the DI Buffer (UART receive buffer).

AT Command: ATRB

Binary Command: 0x20 (32 decimal)

Parameter Range:0 - PK parameter value (up to 0x800 Bytes)

Default Parameter Value: 0x800 Bytes

Number of bytes returned: 2

Related Commands: BR (RF Data Rate), PK (RF Packet Size), RO (Packetization Timeout)

9XTend-PKG-R RS-232/485 RF Modem User Guide 56

Command descriptions

RC (Ambient Power - Single Channel) Command

<Diagnostics> The RC command is used to examine and report the power level on a given channel.

Sample output:

-78 dBm [when CF = 0] 4e [when CF = 1]

-78 [when CF = 2]

AT Command: ATRC

Parameter Range (read-only): 0 - 0x31 [dBm]

Number of bytes returned: 1

Related Commands: RM (Ambient Power - All Channels)

RE (Restore Defaults) Command

<Diagnostics> The RE command is used to restore all configurable parameters to their factory default settings.

The RE Command does not cause default values to be stored to non-volatile (persistent) memory. For the restored default settings to persist in the modem’s non-volatile memory and be saved in the event of RF modem reset or power-down, the WR (Write) command must be issued prior to power-down or reset.

AT Command: ATRE

Binary Command: 0x0E (14 decimal)

RM (Ambient Power - All Channels) Command

<Diagnostics> The RM command is used to examine and report power levels on all channels. If no parameter is given, the channels are scanned one time. If a parameter is given, the channels are repeatedly scanned for that number of seconds. The maximum power level seen for each channel is reported (i.e. peak hold).

A graphical spectrum analyzer can be implemented by repeatedly sending the RM command (with no arguments) and reading the resultant 50 power levels (this is easiest to do when CF = 1 or 2).

Sample output [when CF = 0]: Ch 0: -100 dBm

Ch 1: -103 dBm ... Ch 49: -99 dBm

Sample output [when CF = 1]: 64

67 ... 63

Sample output [when CF = 2]: 100

-103 …

-99

9XTend-PKG-R RS-232/485 RF Modem User Guide 57

Command descriptions

AT Command: ATRM

Parameter Range: no parameter - 0x7D0)

Number of bytes returned: 2

Related Commands: RC (Ambient Power - Single channel)

RN (Delay Slots) Command

<Networking and Security> The RN command is used to set/read the time delay that the transmitting RF modem inserts before attempting to resend a packet. If the transmitting modem fails to receive an acknowledgment after sending a packet, it inserts a random number of delay slots (ranging from 0 to (RN minus 1)) before attempting to resend the packet. Each delay slot is 5 msec (when BR=1) and 54 msec (when BR=0).

If two modems attempt to transmit at the same time, the random time delay after packet failure allows only one modem to transmit the packet successfully; while the other modem waits until the channel available for RF transmission.

RN Command is only applicable if retries have been enabled [RR (Retries) Command] or if forced delays will be inserted into a transmission [TT (Streaming Limit) Command].

AT Command: ATRN

Binary Command: 0x19 (25 decimal)

Parameter Range:0 - 0xFF [38 ms slots]

Default Parameter Value: 0 (no delay slots inserted)

Number of bytes returned: 1

Related Commands: RR (Retries), TT (Streaming Limit)

RO (Packetization Timeout) Command

<Serial Interfacing> The RO command is used to set/read the Packetization Timeout setting. RF transmission begins when data is in the DI buffer and either of the following criteria are met:

• RO character times of silence on the UART receive lines (after receiving at least 1 byte)

• RB characters have been received by the UART

RB and RO criteria only apply to the first packet of a multi-packet transmission. If data remains in the DI Buffer (UART receive) after the first packet, transmissions will continue in a streaming manner until there is no data left in the DI Buffer.

When RO is the transmission-beginning criteria: The actual time between the reception of the last character from the UART and the beginning of RF transmission will be at least 800 µsec longer than the actual RO time to allow for transmission setup. Additionally, it is subject to 100-200 µsec of additional uncertainty, which could be significant for small values of RO at high UART bit rates.

The correct UART character time (10, 11, or 12 bits) is calculated based on the following criteria:

• 1 start bit

• 8 data bits

• 0 or 1 parity bit [as determined by the NB (Parity) Command)

9XTend-PKG-R RS-232/485 RF Modem User Guide 58

Command descriptions

• 1 or 2 stop bits [as determined by SB (Stop Bits) Command]

AT Command: ATRO

Binary Command: 0x21 (33 decimal)

Parameter Range:0 - 0xFFFF [ x UART character times ]

Default Parameter Value: 3

Number of bytes returned: 2

Related Commands: RB (Packetization Threshold)

RP (RSSI PWM Timer) Command

<Diagnostics> RP Command is used to enable a PWM ("Pulse Width Modulation") output on the Config/RSSI pin (pin 11 of the OEM RF Module). The pin is calibrated to show the difference between received signal strength and the sensitivity level of the RF modem. PWM pulses vary from zero to 95 percent. Zero percent means the received RF signal is at or below the published sensitivity level of the modem.

AT Command: ATRP

Binary Command: 0x22 (34 decimal)

Parameter Range:0 - 0xFF [x 100 milliseconds]

Default Parameter Value: 0x20 (32d)

Number of bytes returned: 1

The following table shows dB levels above sensitivity and PWM values (The total time period of the PWM output is 8.32 ms. PWM output consists of 40 steps and therefore the minimum step size is 0.208 ms.):

dBm above sensitivity PWM percentage (high period / total period)

10 20%

20 35%

30 50%

A non-zero value defines the time that PWM output is active with the RSSI value of the last received RF packet. After the set time when no RF packets are received, PWM output is set low (0 percent PWM) until another RF packet is received. PWM output is also set low at power-up. A parameter value of 0xFF permanently enables PWM output and always reflects the value of the last received RF packet.

The Config/RSSI pin is shared between PWM output and Config input. When the modem is powered, the Config pin is an input. During the power-up sequence, if RP parameter is a non-zero value, the Config pin is configured as an output and set low until the first RF packet is received. With a non-zero RP parameter, the Config pin is an input for RP ms after power up.

RR (Retries) Command

<Networking and Security> The RR command is used to set/read the maximum number of retries sent for a given RF packet. When RR Command is enabled (RR>0), RF packet retries and ACKs (acknowledgments) are enabled.

9XTend-PKG-R RS-232/485 RF Modem User Guide 59

Command descriptions

Exceptions: If the MT command in enabled (MT>0) or if a broadcast Destination Address is used (DT = 0xFFFF); RF packet retries and ACKs are disabled.

After transmitting a packet, the transmitting RF modem waits to receive an acknowledgment from a receiving modem. If the acknowledgment is not received in the period of time specified by RN (Delay Slots) Command, the original packet is transmitted again. The RF packet is transmitted repeatedly until an acknowledgment is received or until the packet is sent RR times.

AT Command: ATRR

Binary Command: 0x18 (24 decimal)

Parameter Range:0 - 0xFF

Default Parameter Value: 0x0A (10 decimal)

Number of bytes returned: 1

RT (GPI1 Configuration) Command

<Serial Interfacing> The RT command is used to set/read the behavior of the GPI1 pin (GPI1) of the OEM RF Module. The pin can be configured to enable binary programming or RTS

flow control.

AT Command: ATRT

Binary Command: 0x16 (22 decimal)

Parameter Range: 0 - 2

Parameter Configuration

0 Disabled

1 Enable Binary Programming

2Enable RTS

Default Parameter Value: 0

Number of bytes returned: 1

Related Commands: SM (Sleep Mode), ST (Time before Sleep)

Flow Control

SB (Stop Bits) Command

<Serial Interfacing> The SB Command is used to set/read the number of stop bits in the data packet.

AT Command: ATSB

Binary Command: 0x37 (55 decimal)

Parameter Range: 0 - 1

Parameter Configuration

01 stop bit

9XTend-PKG-R RS-232/485 RF Modem User Guide 60

Command descriptions

AT Command: ATSB

12 stop bits

Default Parameter Value: 0

Number of bytes returned: 1

SH (Serial Number High) Command

<Diagnostics> SH Command is used to set/read the serial number high word of the RF modem.

AT Command: ATSH

Binary Command: 0x25 (37 decimal)

Parameter Range (read-only): 0 - 0xFFFF

Default Parameter Value: varies

Number of bytes returned: 2

Related Commands: SL (Serial Number Low)

SL (Serial Number Low) Command

<Diagnostics> SL Command is used to set/read the serial number low word of the RF modem.

AT Command: ATSL

Binary Command: 0x26 (38 decimal)

Parameter Range (read-only): 0 - 0xFFFF

Default Parameter Value: varies

Number of bytes returned: 2

Related Commands: SH (Serial Number High)

SM (Sleep Mode) Command

<Sleep Mode (Low Power)> The SM Command is used to set/read the RF modem's Sleep Mode settings that configure the modem to run in states that require minimal power consumption.

AT Command: ATSM

Binary Command: 0x01

Parameter Range: 0 - 8 (3 is reserved)

Parameter Configuration

0Disabled

9XTend-PKG-R RS-232/485 RF Modem User Guide 61

AT Command: ATSM

1Pin Sleep

2 Serial Port Sleep

3[reserved]

4 Cyclic 1.0 second sleep

(RF modem wakes every 1.0 seconds)

5 Cyclic 2.0 second sleep

6 Cyclic 4.0 second sleep

7 Cyclic 8.0 second sleep

8 Cyclic 16.0 second sleep

Default Parameter Value: 0

Number of bytes returned: 1

Related Commands:

Pin Sleep - PC (Power-up Mode), PW (Pin Wake-up)

Command descriptions

Serial Port Sleep - ST (Time before Sleep)

Cyclic Sleep - ST (Time before Sleep), LH (Wake-up Initializer Timer), HT (Time Before Wake-up Initializer), PW (Pin Wake-up)

ST (Time before Sleep) Command

<Sleep Mode (Low Power)> The ST Command is used to set/read the period of time (in milliseconds) in which the RF modem remains inactive before entering Sleep Mode.

For example, if the ST Parameter is set to 0x64 (100 decimal), the modem will enter into Sleep mode after 10 seconds of inactivity (no transmitting or receiving).

This command can only be used if Cyclic Sleep or Serial Port Sleep Mode settings have been selected using SM (Sleep Mode) Command.

AT Command: ATST

Binary Command: 0x02 (2 decimal)

Parameter Range:(ATAT+3) - 0x7FFF [x 100 milliseconds]

Default Parameter Value: 0x64 (100 decimal)

Number of bytes returned: 2

Related Commands: SM (Sleep Mode), LH (Wake-up Initializer Timer), HT (Time before Wake-up Initializer)

TP (Board Temperature) Command

<Diagnostics> TP Command is used to read the current temperature of the board.

9XTend-PKG-R RS-232/485 RF Modem User Guide 62

Command descriptions

AT Command: ATTP

Binary Command: 0x38 (56 decimal)

Parameter Range (read-only): 0- 0x7F

Number of bytes returned: 1

Related Command: WN (Warning Data)

Sample Output:

26 C [when ATCF = 0] 1A [when ATCF = 1] 26 [when ATCF = 2].

TR (Transmit Error Count) command

<Diagnostics> The TR command is used to report the number of retransmit failures. This number is incremented each time a packet is not acknowledged within the number of retransmits specified by the RR (Retries) parameter. The number of packets therefore are counted that were not successfully received and subsequently discarded.

The TR parameter is not non-volatile and is reset to zero when the RF modem is reset.

AT Command: ATTR

Binary Command: 0x1B (27 decimal)

Parameter Range: 0 - 0xFFFF

Default Parameter Value: 0

Number of bytes returned: 2

Related Commands: RR (Retries)

TT (Streaming Limit) command

<Networking and Security> The TT command is used to set/read the limit on the number of bytes that can be sent out before a random delay is issued.

If an RF modem is sending a continuous stream of RF data, a delay is inserted which stops its transmission and allows other modems time to transmit (once it sends TT bytes of data). Inserted random delay lasts between 1 and 'RN + 1' delay slots, where each delay slot lasts 38 ms.

The TT command can be used to simulate full-duplex behavior.

AT Command: ATTT

Binary Command: 0x1A (26 decimal)

Parameter Range:0 - 0xFFFF

Default Parameter Value: 0 (disabled)

9XTend-PKG-R RS-232/485 RF Modem User Guide 63

Command descriptions

AT Command: ATTT

Number of bytes returned: 2

Related Commands: RN (Delay Slots)

TX (Transmit Only) command

<RF Interfacing> The TX command is used to set/read the transmit/receive behaviors of the RF modem. Setting a modem to TX-only (TX = 1) may reduce latency because the transmitting modem will never be confined to receiving data from other modems.

AT Command: ATTX

Binary Command: 0x3F (63 decimal)

Parameter Range: 0 - 1

Parameter Configuration

0TX and RX

1TX-only

Default Parameter Value: 0

Number of bytes returned: 1

VL (Firmware Version - Verbose)

<Diagnostics> The VL command is used to read the verbose firmware version of the RF modem.

AT Command: ATVL

Parameter Range: returns string

Default Parameter Value: 0

Number of bytes returned: 2

VR (Firmware Version - Short) Command

<Diagnostics> The VR command is used to read the firmware version of the RF modem.

Note: Firmware versions contain four significant digits - “A.B.C.D”. If B=2, the modem is programmed for operation in Australia only.

AT Command: ATVR

Binary Command: 0x14 (20 decimal)

Parameter Range (read-only): 0 - 0xFFFF

Number of bytes returned: 2

9XTend-PKG-R RS-232/485 RF Modem User Guide 64

Command descriptions

WA (Active Warning Numbers) command

<Diagnostics> The WA command reports the warning numbers of all active warnings - one warning number per line. No further information is shown and warning counts are not reset.

AT Command: ATWA

Parameter Range:Returns string - one warning number per line.

Sample Output (indicates warnings 1 and 3 are currently active):

1 3 OK

WN (Warning Data) command

<Diagnostics> WN command is used to report the following data for all active and sticky warnings:

• Warning number and description

• Number of occurrences since the last WN or WS command

• Whether the warning is currently active

Warnings, which are not currently active and have not been active since the last issuance of the WN or WS commands, are not displayed. The WN command also resets all non-zero warning counts; except for warnings that are presently active, which are set to 1.

AT Command: ATWN

Parameter Range: returns string

Sample output:

Warning 4: Over-temperature 5 occurrences; presently inactive.

Warning # Description

1 Under-voltage. This is caused if the supply voltage falls below the minimum threshold for the lowest power level

(2.8 V). If/when the voltage rises above the threshold, the warning is deactivated. The module will not transmit below this voltage threshold.

2 Over-voltage. This is caused if the supply voltage exceeds 5.75 V. Transmission is not allowed while this warning is

active.

3 Under-temperature. This is caused if the temperature sensed by the module is less than -40 C. The module does

not artificially limit operation while this warning is active, but module functionality is not guaranteed.

4 Over-temperature. This is caused if the temperature sensed by the module is greater than 105 C. The module does

not allow transmission nor reception while this warning is active. The warning is deactivated when the temperature falls to 100 C.

5 Power reduced. This is caused if the transmit power has to be reduced from the level programmed by PL Command

due to insufficient supply voltage. The 1 W power level requires 4.75 V or higher; 500 mW requires 3.0 V or higher; 100 mW, 10 mW and 1 mW require 2.8 V or higher.

9XTend-PKG-R RS-232/485 RF Modem User Guide 65

API operation

Warning # Description

6 Default calibration data in flash. This is caused if the module-specific power calibration data is either not present

or is invalid, or if none of the parameters have been modified from their default values. Power levels may be incorrect.

7 Default configuration parameters in flash. This is caused if user-modifiable parameters (i.e. those stored by a 'WR'

command) in flash are all the compiled-in default values. This is caused if the user configuration is found to be not present or invalid at power-up and there is no custom configuration, or if no user-modifiable parameters have been modified from the compiled-in defaults. Modification of one or more parameters without the subsequent WR to commit the changes to flash will not deactivate this warning, since it reflects the status of the parameters in flash. Note that this warning does not reflect usage of the custom configuration defaults, only usage of the compiled-in defaults.

8 Default factory configuration parameters in flash. This is caused if the factory parameters in flash are all the default

values. This is caused if the factory configuration is found to be not present or invalid at power-up, or if no factory parameters have been modified.

WR (Write) command

<(Special)> The WR command is used to write configurable parameters to non-volatile memory (Values remain in the modem's memory until overwritten by another use of WR Command).

If changes are made without writing them to non-volatile memory, the modem will revert back to previously saved parameters the next time the modem is powered-on.

If the non-volatile user configuration is not correct, WR will re-attempt (up to 3x). If all three attempts fail, the command will return an ERROR alert.

AT Command: ATWR

Binary Command: 0x08

WS (Sticky Warning Numbers) command

<Diagnostics> The WS command reports warning numbers of all warnings active since the last use of the WS or WN command (including any warnings which are currently active). This command also resets all non-zero warning counts, except for warnings that are presently active, which are set to 1.

AT Command: ATWS

Parameter Range (read-only): 1 - 8

Number of bytes returned: 1

API operation

By default, XTend RF Modems act as a serial line replacement (Transparent Operation) - all UART data received through the DI pin is queued up for RF transmission. When the modem receives an RF packet, the data is sent out the DO pin with no additional information.

Inherent to Transparent Operation are the following behaviors:

• If modem parameter registers are to be set or queried, a special operation is required for transitioning the modem

into Command Mode; see Command mode on page 30.

9XTend-PKG-R RS-232/485 RF Modem User Guide 66

API operation

Start Delimiter

(Byte 1)

Length

(Bytes 2-3)

Frame Data

(Bytes 4-n)

Checksum

(Byte n + 1)

0x7E MSB LSB API-specific Structure 1 Byte

Start Delimiter

(Byte 1)

Length

(Bytes 2-3)

Frame Data

(Byt es 4- n)

Checksum

(Byte n + 1)

0x7E MSB LSB API-specific Structure 1 Byte

Characters E scaped If Needed

• In point-to-multipoint systems, the application must send extra information so that the receiving modem(s) can

distinguish between data coming from different remotes.

As an alternative to the default Transparent Operation, API (Application Programming Interface) Operations are available. API operation requires that communication with the modem be done through a structured interface (data is communicated in frames in a defined order). The API specifies how commands, command responses and modem status messages are sent and received from the modem using a UART Data Frame.

API frame specifications

Two API modes are supported and both can be enabled using the AP (API Enable) command. Use the following AP parameter values to configure the modem to operate in a particular mode:

• AP = 0 (default): Transparent Operation (UART Serial line replacement)

API modes are disabled.

• AP = 1: API Operation

• AP = 2: API Operation (with escaped characters)

Any data received prior to the start delimiter is silently discarded. If the frame is not received correctly or if the checksum fails, the data is silently discarded.

API Operation (AP parameter = 1)

When this API mode is enabled (AP = 1), the UART data frame structure is defined as follows:

MSB = Most Significant Byte, LSB = Least Significant Byte

API Operation - with Escape Characters (AP parameter = 2)

When this API mode is enabled (AP = 2), the UART data frame structure is defined as follows::

MSB = Most Significant Byte, LSB = Least Significant Byte

Escape characters

When sending or receiving a UART data frame, specific data values must be escaped (flagged) so they do not interfere with the UART or UART data frame operation. To escape an interfering data byte, insert 0x7D and follow it with the byte to be escaped XOR’d with 0x20.

Data bytes that need to be escaped:

• 0x7E – Frame Delimiter

• 0x7D – Escape

9XTend-PKG-R RS-232/485 RF Modem User Guide 67

API operation

Length

(Bytes 2- 3)

Checksum

(Byte n + 1)

MSB LSB 1 Byte

Start Delimit er

(Byte 1)

0x7E

Frame Data (Bytes 4- n)

API-specific Structure

Identifier-specific Data

cmdData

API Identifier

cmdID

• 0x11 – XON

• 0x13 – XOFF

Example - Raw UART Data Frame (before escaping interfering bytes):

0x7E 0x00 0x02 0x23 0x11 0xCB

0x11 needs to be escaped which results in the following frame:

0x7E 0x00 0x02 0x23 0x7D 0x31 0xCB

Note In the above example, the length of the raw data (excluding the checksum) is 0x0002 and the checksum of the

non-escaped data (excluding frame delimiter and length) is calculated as: 0xFF - (0x23 + 0x11) = (0xFF - 0x34) = 0xCB.

Checksum

To test data integrity, a checksum is calculated and verified on non-escaped data.

To calculate: Not including frame delimiters and length, add all bytes keeping only the lowest 8 bits of the result and subtract from 0xFF.

To verify: Add all bytes (include checksum, but not the delimiter and length). If the checksum is correct, the sum will equal 0xFF.

API Types

Frame data of the UART data frame forms an API-specific structure as follows:

The cmdID frame (API-identifier) indicates which API messages will be contained in the cmdData frame (Identifierspecific data). Refer to the sections that follow for more information regarding the supported API types. Note that multi-byte values are sent big endian.

RF Modem Status

API Identifier: 0x8A RF modem status messages are sent from the modem in response to specific conditions.

9XTend-PKG-R RS-232/485 RF Modem User Guide 68

RF Modem Status Frames

cmdData0x8A

Length Che cks umStart Delimiter Frame Data

Identi fier -specifi c DataAPI Identifier

MSB LSB0x7E 1 ByteAP I-specific Stru cture

St atus (Byte 5)

0 = Hardware reset 1 = Watchdog timer reset

cmdData0x01

Length ChecksumStart Delimiter Fr ame Data

Identifi er-spe cific DataAPI Identifi er

MSB LS B0x7E 1 ByteAPI-specific Structure

Frame ID (Byte 5)

Ident ifies t he UA RT data f rame for the host to corr elate with a subsequent A CK (acknowl edgement). Set ting F rame I D t o ‘0' wil l dis able respons e fr ame.

Destination Address (Bytes 6-7)

MSB first, LSB last. Br oadcast = 0xFFF F

Options (Byte 8)

0 = S tandard 1 = Disable AC K

RF Data (Byte(s) 9-n)

Up to 2048 Bytes per packet

*Length [By tes]=APIIdentifier+FrameID+Option+RFData

**“R”valuewasarbitrarilyselect ed

Checksum

0x18

Byte 12

Desti nati on Addres s

Bytes 6-7

0xFFFF

Option

0x00

Byte 8

Frame ID**

R (0x52)

Byte 5

Length*

Bytes 2-3

0x00 0x08

AP I Identi fi er

0x01

Byte 4

Star t Del imiter

Byte 1

0x7E

RF Data

1 (0x31) 2 (0x32) 3 (0x33)

Bytes 9-11

TX (Transmit) Request: 16-bit address

API Identifier Value: 0x01 A TX Request message will cause the modem to send RF Data as an RF Packet.

TX Packet (16-bit address) Frames

API operation

Example: TX Packet API Frames

TX (Transmit) Status

API Identifier Value: 0x89 When a TX Request is completed, the modem sends a TX Status message. This message will indicate if the packet was transmitted successfully or if there was a failure.

9XTend-PKG-R RS-232/485 RF Modem User Guide 69

TX Status Frames

cmdData0x89

Length ChecksumStart Delimiter Frame Data

Identifi er-spe cific DataAPI Identifier

MSB LSB0x7E 1 ByteAPI-specific Structure

Frame ID (Byte 5) Status (Byte 6)

0 = Success 1 = No ACK (A cknowl edgement) receiv ed

Ident ifies UART data frame being report ed. Note: If Frame ID = 0 in the TX Request, no AT Command Response w ill be given.

cmdData0x81

Length Check sumS tart De limiter Fra me Data

Identifier-specific DataAPI Identifier

MSB LSB0x7E 1 ByteAPI-specific Structure

bit 0 = ACK bit 1 = Indicate broadcast bits 2-7 [reserved]

Up to 2048 Bytes per packet

Recei ved S ignal S trengt h I ndicator Hexadec imal equivalent of (-dBm) value. (For example: If RX signal strength = -40 dBm, “0x 28” (40 decimal) is retur ned)

Source Address (Bytes 5-6) RSSI (Byte 7)

MSB (most significant byte) first, LSB (least si gnific ant) last

Options (Byte 8) RF Da ta (Byte(s) 9-n)

Note “STATUS = 1” occurs when all retries are expired and no ACK is received.

“STATUS = 3” occurs when a packet is purged due to a ‘Polled Remote’ not receiving a poll.

RX (Receive) Packet: 16-bit address

API Identifier Value: 0x81 When the modem receives an RF packet, it is sent out the UART using this message type.

RX Packet (16-bit address) Frames

API operation

9XTend-PKG-R RS-232/485 RF Modem User Guide 70

RF communication modes

Network topologies

The XTend RF Module supports three different network topologies: point-to-point, point-to-multipoint and peer-topeer.

Point-to-point networks

This following section provides the RF communication type and RF mode for XTend RF Module point-to-point networks.

Definition

Point-to-point means an RF data link between two devices.

Sample network profile (Broadcast communications)

Use the default values for all devices.

Sample network profile (Acknowledged communications)

Assume the default value for all parameters that are not in this list. These profiles do not reflect addressing implementations.

1. Use XCTU or another terminal program to send the AM command. See the AM command for details.

2. Set the destination address to 0xFFFF, send: ATDT FFFF

Basic RF modes

Streaming, Multi-Transmit, Repeater.

Acknowledged RF mode

9XTend-PKG-R RS-232/485 RF Modem User Guide 71

Point-to-multipoint networks

Acknowledged mode.

Point-to-multipoint networks

This following section provides the RF communication type and RF mode for XTend RF Module point-to-multipoint networks.

Definition

Point-to-multipoint means a network with RF data links between one base and multiple remotes.

Sample network profile (Broadcast communications)

Assume the default value for all parameters that are not in this list. These profiles do not reflect addressing implementations.

Base:

1. Send ATMY 0 to set the source address to 0x00.

2. Send ATDT FFFF to set the destination address to 0xFFFF.

Remotes:

1. Use XCTU or another terminal program to send the AM command. See the AM command for details.

2. Send ATDT 0 to set the destination address to 0x00.

Sample network profile (Acknowledged communications)

Assume the default value for all parameters that are not in this list. These profiles do not reflect addressing implementations.

Base:

1. Send ATMY 0 to set the source address to 0x00.

2. Send ATDT FFFF to set the destination address to 0xFFFF.

3. Send ATRR 3 to set the number of retries to 3.

Remotes:

1. Use XCTU or another terminal program to send the AM command.

2. Send ATDT FFFF to set the destination address to 0xFFFF.

9XTend-PKG-R RS-232/485 RF Modem User Guide 72

Peer to peer networks

3. Send ATRR 3 to set the number of retries to 3.

Basic RF modes

Streaming, Multi-Transmit, Repeater, and Polling.

Acknowledged RF mode

Acknowledged and Polling.

Peer to peer networks

This following section provides the RF communication type and RF mode for XTend RF Module peer-to-peer networks.

Definition

In Peer-to-peer networks, RF devices remain synchronized without the use of master/server dependencies. Each device shares the roles of master and slave. Digi's peer-to-peer architecture features fast synch times (35 ms to synchronize devices) and fast cold start times (50 ms before transmission).

Sample network profile (Broadcast communications)

Assume the default value for all parameters that are not in this list. These profiles do not reflect addressing implementations.

Use the default values for all devices.

Sample network profile (Acknowledged communications)

Assume the default value for all parameters that are not in this list. These profiles do not reflect addressing implementations.

All devices:

1. Send ATMY 0 to set the source address to 0x00.

2. Send ATDT FFFF to set the destination address to 0xFFFF.

3. Send ATRR 3 to set the number of retries to 3.

Basic RF modes

Streaming.

9XTend-PKG-R RS-232/485 RF Modem User Guide 73

Addressing

Acknowledged RF mode

Acknowledged.

Addressing

Each RF packet contains addressing information that the receiving devices use to filter incoming RF data. Receiving devices inspect the Preamble ID (HP parameter), Vendor Identification Number (ID parameter) and Destination Address (DT parameter) in each RF packet. A receiving device discards all data that does not pass through all three network security layers.

The following image illustrates the addressing layers in the RF packet header.

Address recognition

The transmitting device can address transmissions to a specific device or group of devices using the DT and MK commands. A receiving device only accepts a packet if it determines that the packet is addressed to it, either as a global or local packet. The receiving device makes this determination by inspecting the destination address of the packet and comparing it to its own address and address mask.

The transmitting device determines whether the packet is for a specific node (local address) or multiple nodes (global address) by comparing the packet's destination address (DT) and its own address mask (MK). This assumes you program the address masks on the transmitting device and receiving device to the same value for proper operation in each RF communication mode.

For more information, see the DT (Destination Address and MK (Address Mask) commands.

Basic communications

Basic communications includes two sub-types:

• Broadcast. By default, the XTend RF Module communicates through Broadcast communications and within a peer-

to-peer network topology. When any device transmits, all other devices within range receive the data and pass it directly to their host device.

• Addressed. If addressing parameters match, the device forwards the RF data it receives to the DOUT buffer;

otherwise, it discards the RF data.

When using Basic communications, the integrator handles any functions, such as acknowledgments, at the application layer. The Broadcast modes provide transparent communications, meaning that the RF link replaces a wired link.

9XTend-PKG-R RS-232/485 RF Modem User Guide 74

Streaming mode (default)

Streaming mode is most appropriate for data systems that are more sensitive to latency and/or jitter than to occasional packet loss; for example: streaming audio or video.

Characteristics Highest data throughput

Lowest latency and jitter

Reduced immunity to interference

Transmissions never acknowledged (ACK) by receiving device(s)

Required parameter values (TX device) RR = 0

Related commands Networking (DT, MK, MY), Serial interfacing (PK, RB, RO, TT)

Streaming mode connection sequence

Events and processes in this mode are common to all of the other RF modes.

When streaming data, the firmware only observes the RB and RO parameters on the first packet.

After transmission begins, the transmission event continues without interruption until the DIN buffer is empty or the device reaches the streaming limit (TT parameter). As with the first packet, the payload of each subsequent packet includes up to the maximum packet size (PK parameter).

The TX (transmitting) device specifies the TT parameter as the maximum number of bytes the TX device can send in one transmission event. After the device reaches the TT parameter threshold, the TX device forces a random delay of 1 to RN delay slots; exactly 1 delay slot if RN = 0.

The TX device sends subsequent packets without an RF initializer since RX (receiving) devices remain synchronized with the TX device for the duration of the transmission (from preceding packet information). However, due to interference, some RX devices may lose data (and synchronization to the TX device), particularly during long transmission events.

Once the TX device has sent all pending data or has reached the TT limit, the transmission event ends. The TX device does not transmit again for exactly RN delay slots if the local (for example the TX device's) RN parameter is set to a nonzero value. The RX device(s) do not transmit for a random number of delay slots between 0 and (RN-1) if the local (for example the RX device's) RN parameter is set to a non-zero value. These delays lessen congestion following long bursts of packets from a single TX device, during which several RX devices may have become ready to transmit.

Multi-transmit mode

Use Multi-transmit mode for applications that require reliable delivery without using retries and acknowledgments.

Characteristics Reliable delivery through forcing the transmission of every RF packet.

Every RF packet is sent exactly MT + 1 times, with no delays between packets.

Diminished throughput and increased latency.

Required parameter values (TX device)

MT ≥ 1.

Related commands Networking (DT, MK, MY, RN, TT), Serial interfacing (BR, PK, RB, RO), RF

interfacing (FS).

9XTend-PKG-R RS-232/485 RF Modem User Guide 75

Repeater mode

Multi-transmit mode connection sequence

In Multi-transmit mode, the device re-transmits each packet MT times, for a total of (MT+1) transmissions. There is no delay between retransmissions, and the TX (transmitting) device never receives RF data between retransmissions. Each retransmission includes an RF initializer. A transmission event may include follow-on packets, each of which retransmit MT times. Devices ignore the Forced Sync (FS) parameter in Multi-Transmit Mode.

The firmware does not apply the RB and RO parameters to follow-on packets, meaning that once transmission has begun, it continues without interruption until the DIN buffer is empty or the device reaches the streaming limit (TT parameter). As with the first packet, the payload of each follow-on packet includes up to the maximum packet size (PK parameter) bytes, and the TX device checks for more pending data near the end of each packet. The device does not send follow-on packets until it finishes all retransmissions of the previous packet.

The TX device specifies the streaming limit (TT) as the maximum number of bytes that the TX device can send in one transmission event, which may consist of many packets. If the device reaches the TT parameter limit, the TX device forces a random delay of 1 to RN delay slots (exactly 1 delay slot if RN is zero). In Multi-transmit mode, the firmware counts each packet only once when tracking the streaming limit (TT), no matter how many times it is retransmitted.

When an RX (receiving) device receives a Multi-transmit packet, it calculates the amount of time remaining in the Multi-transmit event, and inhibits its own transmissions for the duration of the Multi-transmit event, plus a random number of delay slots between 0 and (RN-1). If the local RN parameter is zero, the delay is only for the calculated duration of the event. An RX device only needs to receive one of the transmissions, and it keep the channel off until the TX device is complete. If follow-on packets are coming, the RX devices move to the new frequency and listen for the follow-on packet for a specific period of time.

Repeater mode

Use Repeater mode in networks where you need intermediary devices to relay data to devices beyond the transmission range of the base device.

Characteristics Low power consumption.

Minimizes interference

Tags each RF packet with a unique Packet ID (PID).

Each repeater only repeats a packet once (the PID tracks the packet).

Increases latency and decreases throughput. The number of hops determine latency and throughput, not the number of repeaters. Multiple repeaters within range of a source node count as one hop.

All RF packets propagate to every device in the network (filtering rules apply).

Packet destination addresses (DT) determine which packets the device sends out the serial port and/or retransmits.

Broadcast communications: each packet comes out every node exactly once.

Addressed communications: all devices see every packet. Only the devices with a matching address forward it to the DOUT buffer.

Constraints Requires that each device have a unique MY parameter.

System must introduce only one packet at a time to the network for transmission. The PK parameter determines the maximum number of bytes.

Each hop (H) decreases network throughput by a factor of 1/(H+1). Additional repeaters add network redundancy without decreasing throughput.

9XTend-PKG-R RS-232/485 RF Modem User Guide 76

Configure a repeater network

Suggestions Insert a variable delay before repeating packets to avoid collisions (based on RSSI).

Bu ffe r an y in com ing ser ial d ata and del ay re spo nse packet transmissions until the previous packet clears out of the network.

For best results, use the RO and RB commands to ensure that the RF packets align with the underlying protocol packets as the network can only accept one RF packet at a time.

Required parameter values (TX device)

Related commands Networking (MD, DT, MY, AM), Serial interfacing (RN, PK, RO, RB)

MD = 5 or 6.

MY = unique value. You can accomplish this by issuing the AM and WR commands to all devices in the network.

Repeater mode theory of operation

You can extend the effective range and reliability of your data system by forwarding traffic through one or more repeaters. Instead of using routing tables and path discovery to establish dynamic paths through a network, the repeater system uses a sophisticated algorithm to propagate each RF packet through the entire network.

The network supports RF packets up to 2048 bytes when the RF data rate is set at 9600 bps (BR = 0). The repeater network can operate using broadcast or addressed communications for multi-drop networks, and it works well in many systems with no special configuration.

When in Repeater mode, the network repeats each message among all available devices exactly one time. This mechanism eliminates the need for configuring specific routes. The following figure illustrates the Repeater network topology.

Configure a repeater network

If an RF link is weak, a device is out-of-range or a difficult RF environment is present; you can use repeaters to extend the effective range and reliability of the network.

A network may consist of End Nodes (EN), End/Repeater Nodes (ERN) and a Base Node (BN). The base node initiates all communications. Both Repeater Nodes and End Nodes can source data, allowing connection to host devices. Repeater Nodes however, are able to repeat information in a simple store and forward fashion. As an example, one End Node (which can be a base or remote) must send a message to another End Node. Because the End Node is out of range of the base device, you can use a repeater to forward information from the Base to the End Node.

You can configure a repeater network to operate using Basic Broadcast or Basic Addressed communications. The addressing capabilities of the device allow integrators to send a packet as a global packet (DT = 0xFFFF) and shift out of every device in the network (Basic Broadcast). Alternately, you can send the packet with a specific DT parameter so that only a specific remote node accepts it (Basic Addressed).

9XTend-PKG-R RS-232/485 RF Modem User Guide 77

Configure a repeater network

Repeater network: configure communications

To configure a Repeater network for Basic broadcast communications:

1. Assign each device a unique MY (source) address. Use the AM command to configure a unique source address based on the device serial number. This is essential because a unique packet ID on each RF packet is based on the originator’s MY value.

2. Set DT = 0xFFFF to enable Basic Broadcast communications OR Basic Addressed communications (DT specifies a specific destination).

3. Configure PK, RO and RB to ensure that the RF packet aligns with the protocol packet. For example: PK=0x100 RB=0x100 RO depends on baud rate

4. Set MD = 5 to configure one or more devices that you do not intend to be repeaters as repeater End Nodes in the system.

5. Set MD = 6 to configure remote nodes as destinations. This ensures that the remote node waits for the repeater traffic to subside before it transmits a response.

To configure a Repeater network for Basic addressed communications, use DT to assign unique addresses to each device in the network.

Repeater network algorithm details

The firmware uses an algorithm to propagate each RF packet through the entire repeater network. Within a repeater network, the firmware only defines Repeater Nodes and repeater End Nodes. Repeater Nodes forward messages on to other devices within range; End Nodes do not.

The algorithm maintains a list of messages previously received in a buffer. The firmware discards messages already in the buffer. This eliminates End Nodes receiving multiple copies of a packet from more than one source, and also eliminates multiple repeaters within range of each other from continually passing messages in an infinite loop.

Packet ID (PID) is composed of the TX (transmitting) device MY address and the packet sequence number.

The firmware ignores incoming packets with a PID already in the buffer.

Each device maintains a PID buffer 4-deep of previously received packets (managed as FIFO).

The firmware may shift packets out the serial port and/or repeat them depending on the DT parameter in the RF packet. The following table shows the basis for these decisions.

Address Match Send out serial port? Repeat?

Global Yes Yes

Local Yes No

None No Yes

Repeat delay based on RSSI

A transmitted packet may be received by more that one repeater at the same time. In order to reduce the probability that the repeaters will transmit at the same instant, resulting in a collision and possible data loss; the firmware uses an algorithm that allows a variable back-off prior to a repeater retransmitting the packet. The algorithm allows devices that receive the packet with a stronger RF signal (RSSI) to have the first opportunity to retransmit the packet.

9XTend-PKG-R RS-232/485 RF Modem User Guide 78

Configure a repeater network

Use the RN (Delay Slots) parameter to configure this delay. Set RN = 0 (no delays) for small networks with few repeaters or repeaters that are not within range of each other. Set RN = 1 for systems with two to five repeaters that may be within range of each other.

The actual length of the delay is computed by the formula:

Delay (ms) = L * DS

DS = (-41-RSSI)/10*RN)+RandomInt(0,RN)

Where L is the length of the transmitted packet in milliseconds, DS is the number of delay slots to wait, RSSI is the received signal strength in dBm, RN is the value of the RN register and RandomInt (A,B) is a function that returns a random integer from A to B-0

Response packet delay

As a packet propagates through the repeater network, if any node receives the data and generates a quick response, the network needs to delay the response so as not to collide with subsequent retransmissions of the original packet. To reduce collisions, both repeater and end node devices in a repeater network delay transmission of data shifted in the serial port to allow any repeaters within range to complete their retransmissions.

The time for this delay is computed by the formula:

Maximum Delay (ms) = L * DS

DS = ((-41-(-100))/10)*RN)+RN+1

Where L is the length of the transmitted packet in milliseconds, DS is the number of delay slots to wait, RSSI is the received signal strength in dBm, and RN is the value of the RN register.

Use case - Broadcast Repeater network

Consider modems R1 through R10 each communicating to a PLC using the ModBus protocol and spaced evenly in a line. All ten modems are configured as 'destinations and repeaters' within the scope of Basic Broadcast Communications (MD=5, AM, DT=0xFFFF, PK=0x100, RO=0x03, RB=0x100, RN=1). The Base Host (BH) shifts payload that is destined for R10 to R1. R1 initializes RF communication and transmits payload to nodes R2 through R5 which are all within range of R1. The modems R2 through R5 receive the RF packet and retransmit the packet simultaneously. They also send the data out the serial ports, to the PLCs. The following table shows commands used to configure repeater functions.

AT Command

AM 0x3A (58d) Auto-set MY - - -

DT 0x00 (0d) Destination Address 0 - 0xFFFF 2 0

MD 0x3C (60d) RF Mode 0 - 6 1 0

MY 0x2A (42d) Source Address 0 - 0xFFFF 2 0xFFFF

Binary Command

AT Command Name

Range

# Bytes Returned

Factory Default

RN 0x19 (25d) Delay Slots 0 - 0xFF [slots] 1 0

WR 0x08 (8d) Write - - -

9XTend-PKG-R RS-232/485 RF Modem User Guide 79

Polling mode (basic)

Bandwidth considerations

Using broadcast repeaters in a network reduces the overall network data throughput as each repeater must buffer an entire packet before retransmitting it. For example: if the destination is within range of the transmitter and the packet is 32-bytes long, the transmission takes 12 ms on a device operating at 115,200 baud. If the same packet must propagate through two repeaters, it takes 12 ms to arrive at the first repeater, 12 ms to get to the second and a final 12 ms to reach the destination for a total of 36 ms. Accounting for UART transfer times (~1ms/byte at 9600 baud), the time for a server to send a 32-byte query and receive a 32-byte response is about 200 ms, allowing for 5 polls per second. With the two repeaters in the path, the same query/response sequence would take about 500 ms for two polls per second.

Generally, network throughput decreases by a factor of 1/(R+1), with R representing the number of repeaters between the source and destination.

Polling mode (basic)

Polling mode (basic) and Polling mode (acknowledged) operate in the same way. The only difference between the two modes is in their means of achieving reliable delivery of data. Polling mode (basic) uses multiple transmissions to achieve reliable delivery.

Characteristics Uses a high percentage of available network bandwidth.

Eliminates collisions.

Works with reliable delivery (RR or MT parameters).

Supports binary data transfers.

Base device requests packets from remote device by polling a sequential range of addresses.

Base device is configured to specify the range of addresses being polled.

Uses inter-character delay to create RF packet lengths aligned with protocol packet lengths up to 2048 bytes long.

Constraints The minimum time interval between polling cycles is configurable. However, if the

remote devices cannot all be processed within that time interval, the polling cycle is ineffective (i.e. it will impose no additional delay). In order to ensure a pause between polling cycles, you must set PD to a value that is large enough to accommodate the pause.

Recommended use Use for point-to-multipoint applications that require Reliable Delivery of data. Use this

mode when it is critical that a base device be able to discern data coming from multiple devices.

Required parameter values (Base)

Required parameter values (Remote)

Related commands Networking: MT, PD, DT, MY, and AM

MD (RF Mode) = 3

PB (Polling Begin Address)

PE (Polling End Address)

MD (RF Mode) = 4

9XTend-PKG-R RS-232/485 RF Modem User Guide 80

Acknowledged communications: Acknowledged mode

Polling mode theory of operation

A Polling Base device cycles through a sequential range of addresses. The Polling Base polls each Polling Remote device, waits for a response, then poll the next remote address in the sequence. Each Polling Remote responds by sending the data from its DIN buffer following the RB and RO parameters. When there is no eligible data to send, the Polling Remote does not respond. The Polling Base polls the next address in the polling sequence after a short delay.

Configure a Polling Base

To configure a device as a Polling Base:

1. Set MD = 3.

2. Set MY = 0.

3. Set the sequential range of polling addresses using PB and PE.

4. (Optional) Enable Basic Reliable Delivery (MT ≥ 0). The firmware also supports Acknowledged Reliable Delivery. For more information, see

5. (Optional) Use PD to configure a delay between polls to slow down the system, if needed.

6. (Optional) Enable API Mode to address remote devices within polling range on a packet-by-packet basis.

Polling mode (acknowledged) on page 83.

Configure a Polling Remote

To configure a device as a Polling Remote:

1. Set MD = 4.

2. Configure sequential source addresses for all remote devices using MY.

3. Set DT to point to the Polling Base (DT = 0x0000).

4. (Optional) Enable Basic Reliable Delivery (MT >= 0). The firmware also supports Acknowledged Reliable Delivery. For more information, see

Polling mode (acknowledged) on page 83.

Acknowledged communications: Acknowledged mode

Use Acknowledged mode for applications that need reliable delivery. If messages are smaller than 256 bytes, use the RB and RO commands to align RF packets to application packets.

Characteristics Reliable delivery through positive acknowledgments for each

packet.

Throughput, latency and jitter vary depending on the quality of the channel and the strength of the signal.

Required parameter values (TX device)

Related commands Networking (DT, MK, RR), Serial Interfacing (PK, RN, RO, RB, TT)

RR (Retries) >= 1

9XTend-PKG-R RS-232/485 RF Modem User Guide 81

Acknowledged communications: Acknowledged mode

Acknowledged mode connection sequence

After sending a packet while in Acknowledged mode, the TX (transmitting) device listens for an acknowledgment (ACK). If it receives the ACK, it either moves on to sending a subsequent packet if more transmit data is pending or waits for exactly RN random delay slots before allowing another transmission if no more data is pending transmit.

If the TX device does not receive the ACK within the allotted time, it retransmits the packet with a new RF initializer following the ACK slot. There is no delay between the first ACK slot and the first retransmission. Subsequent retransmissions incur a delay of a random number of delay slots, between 0 and RN. If RN is set to 0 on the TX device, there are never any back-off delays between retransmissions. During back-off delays, the TX device goes into Idle Mode and may receive RF data. This can have the effect of increasing the back-off delay, as the device cannot return to Transmit (or retransmit) mode as long as it is receiving RF data.

After receiving and acknowledging a packet, the RX (receiving) device moves to the next frequency and listens for either a retransmission or new data for a specific period of time. Even if the TX device indicates that it has no more pending transmit data, it may not have received the previous ACK, and so may retransmit the packet, possibly with no delay after the ACK slot. In this case, the RX device always detects the immediate retransmission, which holds off the communications channel and reduces collisions. RX devices acknowledge each retransmission they receive, but they only pass the first copy of a packet they receive out the UART.

The device does not apply the RB and RO parameters to subsequent packets, meaning that once transmission begins, it continues uninterrupted until the DIN buffer is empty or it reaches the streaming limit (TT parameter. As with the first packet, the payload of each subsequent packet includes up to the maximum packet size (PK parameter), and the TX device checks for more pending data near the end of each packet.

The TT parameter specifies the maximum number of bytes that the TX device sends in one transmission event, which may consist of many packets and retries. If a device reaches the TT parameter limit, the TX device forces a random delay of 1 to RN delay slots (exactly 1 delay slot if RN is zero). Each packet counts only once toward TT, no matter how many times the packet is retransmitted.

Subsequent packets in Acknowledged mode are similar to those in Streaming mode, with the addition of an ACK between each packet, and the possibility of retransmissions. The device sends subsequent packets without an RF initializer, as the RX devices are already synchronized to the TX device from the preceding packet(s) and they remain synchronized for the duration of the transmission event. Each packet retransmission includes an RF initializer.

Once the TX device sends all pending data or reaches the TT limit, the acknowledged transmission event is complete. The TX device does not transmit again for exactly RN delay slots, if the local RN parameter is set to a non-zero value. The RX device does not transmit for a random number of delay slots between 0 and (RN-1), if the local RN parameter is set to a non-zero value. The intent of these delays is to lessen congestion following long bursts of packets from a single TX device, during which several RX devices may have themselves become ready to transmit.

9XTend-PKG-R RS-232/485 RF Modem User Guide 82

Polling mode (acknowledged)

Polling mode (acknowledged) and Polling mode (basic) operate in the same way. The difference between the two modes is in their means of achieving the reliable delivery of data. In Polling mode (acknowledged), the firmware achieves reliable delivery using retries and acknowledgments.

Characteristics Uses a high percentage of available network bandwidth.

Eliminates collisions.

Works with reliable delivery (RR or MT parameters).

Supports binary data transfers.

Base device requests packets from remote device by polling a sequential range of addresses.

Base device is configured to specify the range of addresses being polled.

Uses inter-character delay to create RF packet lengths aligned with protocol packet lengths up to 2048 bytes long.

Constraints The minimum time interval between polling cycles is configurable. However, if the

remote devices cannot all be processed within that time interval, the polling cycle is ineffective (i.e. it will impose no additional delay). In order to ensure a pause between polling cycles, PD must be set to a value which is large enough to accommodate the pause.

Recommended use Use for point-to-multipoint applications that require Reliable Delivery of data. Use

this mode when it is critical that a base device be able to discern data coming from multiple devices.

Required parameter values (Base)

Required parameter values (Remote)

Related commands Networking (RR, PD, DT, MY, AM)

For configuration and theory of operation information, see

Polling Base on page 81

MD (RF Mode) = 3,

PB (Polling Begin Address)

PE (Polling End Address)

MD (RF Mode) = 4

Polling mode theory of operation on page 81, Configure a

and Configure a Polling Remote on page 81.

9XTend-PKG-R RS-232/485 RF Modem User Guide 83

Agency certifications

Before installing and powering on the RF modem, read all instructions and keep these instructions in a safe place for future reference.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

FCC (United States) Certification

FCC Part 15 Class B

Radio Frequency Interface (RFI) (FCC 15.105)

This device has been tested and found to comply with the limits for Class B digital devices pursuant to Part 15 Subpart B of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Labeling requirements (FCC 15.19)

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Modifications (FCC 15.21)

9XTend-PKG-R RS-232/485 RF Modem User Guide 84

IC (Industry Canada) Certification

Changes or modifications to this equipment not expressly approved by Digi may void the user’s authority to operate this equipment.

IC (Industry Canada) Certification

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

RF Exposure

CAUTION! This equipment is approved for mobile and base station transmitting devices only. Antenna(s) used for

this transmitter must be installed to provide a separation distance of at least 34 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

ATTENTION Cet équipement est approuvé pour la mobile et la station base dispositifs d'émission seulement.

Antenne(s) utilisé pour cet émetteur doit être installé pour fournir une distance de séparation d'au moins 34 cm à partir de toutes les personnes et ne doit pas être situé ou fonctionner en conjonction avec tout autre antenne ou émetteur.

ACMA (Australia)

Power requirements

Regulations in Australia stipulate a maximum of 30 dBm EIRP (Effective Isotropic Radiated Power). The EIRP equals the sum (in dBm) of power output, antenna gain and cable loss and cannot not exceed 30 dBm.

The EIRP formula for Australia is:

Note The maximum EIRP for the FCC (United States) and IC (Canada) is 36 dBm.

9XTend-PKG-R RS-232/485 RF Modem User Guide 85

Legacy XTend Modem approved antennas

(1-watt transmit power output or lower)

Part Number Type Connector Gain Application

A09-HSM-7 Straight half-wave RPSMA 3.0 dBi Fixed / Mobile

A09-HASM-675 Articulated half-wave RPSMA 2.1 dBi Fixed / Mobile

A09-HABMM-P6I Articulated half-wave w/ 6" pigtail MMCX 2.1 dBi Fixed / Mobile

A09-HABMM-6-P6I Articulated half-wave w/ 6" pigtail MMCX 2.1 dBi Fixed / Mobile

A09-HBMM-P6I Straight half-wave w/ 6" pigtail MMCX 2.1 dBi Fixed / Mobile

A09-HRSM Right angle half-wave RPSMA 2.1 dBi Fixed

A09-HASM-7 Articulated half-wave RPSMA 2.1 dBi Fixed

A09-HG Glass mounted half-wave RPSMA 2.1 dBi Fixed

A09-HATM Articulated half-wave RPTNC 2.1 dBi Fixed

A09-H Half-wave dipole RPSMA 2.1 dBi Fixed

Yagi antennas (approved when operating at 1-watt power output or lower)

Part Number Type Connector Gain Required Antenna Cable Loss Application

A09-Y6 2 Element Yagi RPN 6.1 dBi 0.1 dB* Fixed / Mobile

A09-Y7 3 Element Yagi RPN 7.1 dBi 1.1 dB* Fixed / Mobile

A09-Y8 4 Element Yagi RPN 8.1 dBi 2.1 dB* Fixed / Mobile

A09-Y6TM 2 Element Yagi RPTNC 6.1 dBi 0.1 dB* Fixed / Mobile

A09-Y7TM 3 Element Yagi RPTNC 7.1 dBi 1.1 dB* Fixed / Mobile

A09-Y8TM 4 Element Yagi RPTNC 8.1 dBi 2.1 dB* Fixed / Mobile

Omni-directional base station antennas (approved when operating at 1-watt power output or lower)

Part Number Type Connector Gain Required Antenna Cable Loss Application

A09-F0 Fiberglass Base Station RPN 0 dBi - Fixed

A09-F1 Fiberglass Base Station RPN 1.0 dBi - Fixed

A09-F2 Fiberglass Base Station RPN 2.1 dBi - Fixed

A09-F3 Fiberglass Base Station RPN 3.1 dBi - Fixed

A09-F4 Fiberglass Base Station RPN 4.1 dBi - Fixed

A09-F5 Fiberglass Base Station RPN 5.1 dBi - Fixed

A09-F6 Fiberglass Base Station RPN 6.1 dBi 0.1 dB* Fixed

9XTend-PKG-R RS-232/485 RF Modem User Guide 86

Legacy XTend Modem approved antennas

Part Number Type Connector Gain Required Antenna Cable Loss Application

A09-F7 Fiberglass Base Station RPN 7.1 dBi 1.1 dB* Fixed

A09-F8 Fiberglass Base Station RPN 8.1 dBi 2.1 dB* Fixed

A09-W7 Wire Base Station RPN 7.1 dBi 1.1 dB* Fixed

A09-F0 Fiberglass Base Station RPSMA 0 dBi - Fixed

A09-F1 Fiberglass Base Station RPSMA 1.0 dBi - Fixed

A09-F2 Fiberglass Base Station RPSMA 2.1 dBi - Fixed

A09-F3 Fiberglass Base Station RPSMA 3.1 dBi - Fixed

A09-F4 Fiberglass Base Station RPSMA 4.1 dBi - Fixed

A09-F5 Fiberglass Base Station RPSMA 5.1 dBi - Fixed

A09-F6 Fiberglass Base Station RPSMA 6.1 dBi 0.1 dB* Fixed

A09-F7 Fiberglass Base Station RPSMA 7.1 dBi 1.1 dB* Fixed

A09-F8 Fiberglass Base Station RPSMA 8.1 dBi 2.1 dB* Fixed

A09-W7SM Wire Base Station RPSMA 7.1 dBi 1.1 dB* Fixed

A09-F0TM Fiberglass Base Station RPTNC 0 dBi - Fixed

A09-F1TM Fiberglass Base Station RPTNC 1.0 dBi - Fixed

A09-F2TM Fiberglass Base Station RPTNC 2.1 dBi - Fixed

A09-F3TM Fiberglass Base Station RPTNC 3.1 dBi - Fixed

A09-F4TM Fiberglass Base Station RPTNC 4.1 dBi - Fixed

A09-F5TM Fiberglass Base Station RPTNC 5.1 dBi - Fixed

A09-F6TM Fiberglass Base Station RPTNC 6.1 dBi 0.1 dB* Fixed

A09-F7TM Fiberglass Base Station RPTNC 7.1 dBi 1.1 dB* Fixed

A09-F8TM Fiberglass Base Station RPTNC 8.1 dBi 2.1 dB* Fixed

A09-W7TM Wire Base Station RPTNC 7.1 dBi 1.1 dB* Fixed

* FCC regulations stipulate a 36 dBm EIRP power requirement. Users implementing antenna gain greater than 6.0 dB must compensate for the added gain with cable loss. When operating at 1 W power output, the sum (in dB) of cable loss and antenna gain shall not exceed 6.0 dB.

Mag Mount antennas (approved when operating at 1-watt power output or lower)

Part Number Type Connector Gain Required Antenna Cable Loss Application

A09-M0SM Mag Mount RPSMA 0 dBi - Fixed

A09-M2SM Mag Mount RPSMA 2.1 dBi - Fixed

9XTend-PKG-R RS-232/485 RF Modem User Guide 87

Legacy XTend Modem approved antennas

Part Number Type Connector Gain Required Antenna Cable Loss Application

A09-M3SM Mag Mount RPSMA 3.1 dBi - Fixed

A09-M5SM Mag Mount RPSMA 5.1 dBi - Fixed

A09-M7SM Mag Mount RPSMA 7.1 dBi -1.1 dB* Fixed

A09-M8SM Mag Mount RPSMA 8.1 dBi -2.1 dB* Fixed

A09-M0TM Mag Mount RPTNC 0 dBi - Fixed

A09-M2TM Mag Mount RPTNC 2.1 dBi - Fixed

A09-M3TM Mag Mount RPTNC 3.1 dBi - Fixed

A09-M5TM Mag Mount RPTNC 5.1 dBi - Fixed

A09-M7TM Mag Mount RPTNC 7.1 dBi -1.1 dB* Fixed

A09-M8TM Mag Mount RPTNC 8.1 dBi -2.1 dB* Fixed

Multi-path antennas (approved when operating at 1-watt power output or lower)

Part Number Type Connector Gain Application

A09-DPSM-P12F omni directional permanent mount w/ 12ft pigtail RPSMA 3.0 dBi Fixed

A09-D3NF-P12F omni directional magnetic mount w/ 12ft pigtail RPN 3.0 dBi Fixed

A09-D3SM-P12F omni directional w/ 12ft pigtail RPSMA 3.0 dBi Fixed

A09-D3PNF omni directional permanent mount RPN 3.0 dBi Fixed

A09-D3TM-P12F omni directional w/ 12ft pigtail RPTNC 3.0 dBi Fixed

A09-D3PTM omni directional permanent mount RPTNC 3.0 dBi Fixed

A92-D4PNF 900 MHz / 2.4GHz permanent mount RPN 2.1 dBi Fixed

A92-D4P 900 MHz / 2.4GHz permanent mount RPSMA 2.1 dBi Fixed

A92-D4PTM 900 MHz / 2.4GHz permanent mount RPTNC 2.1 dBi Fixed

Half-wave antennas (approved when operating at 100 mW power output or lower)

Part Number Type Connector Gain Application

A09-QW Quarter-wave wire Permanent 1.9 dBi Fixed / Mobile

A09-QRAMM 3 " Quarter-wave wire MMCX 2.1 dBi Fixed / Mobile

A09-QSM-3 Quarter-wave straight RPSMA 1.9 dBi Fixed / Mobile

A09-QSM-3H Heavy duty quarter-wave straight RPSMA 1.9 dBi Fixed / Mobile

9XTend-PKG-R RS-232/485 RF Modem User Guide 88

Legacy XTend Modem approved antennas

Part Number Type Connector Gain Application

A09-QBMM-P6I Quarter-wave w/ 6" pigtail MMCX 1.9 dBi Fixed / Mobile

A09-QHRN Miniature Helical Right Angle solder Permanent -1 dBi Fixed / Mobile

A09-QHSN Miniature Helical Right Angle solder Permanent -1 dBi Fixed / Mobile

A09-QHSM-2 2" Straight RPSMA 1.9 dBi Fixed / Mobile

A09-QHRSM-2 2" Right angle RPSMA 1.9 dBi Fixed / Mobile

A09-QHRSM-170 1.7" Right angle RPSMA 1.9 dBi Fixed / Mobile

A09-QRSM-380 3.8" Right angle RPSMA 1.9 dBi Fixed / Mobile

A09-QAPM-520 5.2" Articulated Screw mount Permanent 1.9 dBi Fixed / Mobile

A09-QSPM-3 3" Straight screw mount Permanent 1.9 dBi Fixed / Mobile

A09-QAPM-3 3" Articulated screw mount Permanent 1.9 dBi Fixed / Mobile

A09-QAPM-3H 3" Articulated screw mount Permanent 1.9 dBi Fixed / Mobile

Yagi antennas (approved when operating at 100 mW power output or lower)

Part Number Type Connector Gain Application

A09-Y6 2 Element Yagi RPN 6.1 dBi Fixed / Mobile

A09-Y7 3 Element Yagi RPN 7.1 dBi Fixed / Mobile

A09-Y8 4 Element Yagi RPN 8.1 dBi Fixed / Mobile

A09-Y9 4 Element Yagi RPN 9.1 dBi Fixed / Mobile

A09-Y10 5 Element Yagi RPN 10.1 dBi Fixed / Mobile

A09-Y11 6 Element Yagi RPN 11.1 dBi Fixed / Mobile

A09-Y12 7 Element Yagi RPN 12.1 dBi Fixed / Mobile

A09-Y13 9 Element Yagi RPN 13.1 dBi Fixed / Mobile

A09-Y14 10 Element Yagi RPN 14.1 dBi Fixed / Mobile

A09-Y14 12 Element Yagi RPN 14.1 dBi Fixed / Mobile

A09-Y15 13 Element Yagi RPN 15.1 dBi Fixed / Mobile

A09-Y15 15 Element Yagi RPN 15.1 dBi Fixed / Mobile

A09-Y6TM 2 Element Yagi RPTNC 6.1 dBi Fixed / Mobile

A09-Y7TM 3 Element Yagi RPTNC 7.1 dBi Fixed / Mobile

A09-Y8TM 4 Element Yagi RPTNC 8.1 dBi Fixed / Mobile

A09-Y9TM 4 Element Yagi RPTNC 9.1 dBi Fixed / Mobile

9XTend-PKG-R RS-232/485 RF Modem User Guide 89

Legacy XTend Modem approved antennas

Part Number Type Connector Gain Application

A09-Y10TM 5 Element Yagi RPTNC 10.1 dBi Fixed / Mobile

A09-Y11TM 6 Element Yagi RPTNC 11.1 dBi Fixed / Mobile

A09-Y12TM 7 Element Yagi RPTNC 12.1 dBi Fixed / Mobile

A09-Y13TM 9 Element Yagi RPTNC 13.1 dBi Fixed / Mobile

A09-Y14TM 10 Element Yagi RPTNC 14.1 dBi Fixed / Mobile

A09-Y14TM 12 Element Yagi RPTNC 14.1 dBi Fixed / Mobile

A09-Y15TM 13 Element Yagi RPTNC 15.1 dBi Fixed / Mobile

A09-Y15TM 15 Element Yagi RPTNC 15.1 dBi Fixed / Mobile

9XTend-PKG-R RS-232/485 RF Modem User Guide 90

Legacy XTend Modem approved antennas

XTend vB Modem approved antennas (30 dBm Maximum RF power)

The following tables cover the antennas that are approved for use with the XBee-PRO XTC RF modules. If applicable, the tables show the required cable loss between the device and the antenna.

Digi does not carry all of these antenna variants. Contact Digi Sales for available antennas.

Dipole antennas

All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.

Part Number Type Connector Gain Application

A09-HSM-7 Straight half-wave RPSMA 2.1 dBi Fixed / Mobile

A09-HASM-675 Articulated half-wave RPSMA 2.1 dBi Fixed / Mobile

A09-HABMM-P5I Swivel half wave with 5" pigtail MMCX 2.1 dBi Fixed / Mobile

A09-HBMM-P5I Straight half-wave with 6" pigtail MMCX 2.1 dBi Fixed / Mobile

A09-HASM-7 Articulated half-wave RPSMA 2.1 dBi Fixed

A09-HRSM* Right angle half-wave RPSMA 2.1 dBi Fixed

A09-HG* Glass mounted half-wave RPSMA 2.1 dBi Fixed

A09-HATM* Articulated half-wave RPTNC 2.1 dBi Fixed

A09-H* Half-wave dipole RPSMA 2.1 dBi Fixed

Yagi antennas

All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.

Required Antenna Cable

Part Number Type Gain Connector

A09-Y6NF* 2 element Yagi 6.1 dBi N 2.0 dB Fixed/Mobile

A09-Y7NF* 3 element Yagi 7.1 dBi N 3.0 dB Fixed/Mobile

A09-Y8NF 4 element Yagi 8.1 dBi N 4.0 dB Fixed/Mobile

A09-Y9NF* 4 element Yagi 9.1 dBi N 5.0 dB Fixed/Mobile

A09-Y10NF* 5 element Yagi 10.1 dBi N 6.0 dB Fixed/Mobile

A09-Y11NF 6 element Yagi 11.1 dBi N 7.0 dB Fixed/Mobile

Loss

Application

A09-Y12NF* 7 element Yagi 12.1 dBi N 8.0 dB Fixed/Mobile

A09-Y13NF* 9 element Yagi 13.1 dBi N 9.0 dB Fixed/Mobile

A09-Y14NF* 14 element Yagi 14.0 dBi N 9.9 dB Fixed/Mobile

9XTend-PKG-R RS-232/485 RF Modem User Guide 91

Legacy XTend Modem approved antennas

Required Antenna Cable

Part Number Type Gain Connector

A09-Y6TM* 2 element Yagi 6.1 dBi RPTNC 2.0 dB Fixed/Mobile

A09-Y7TM* 3 element Yagi 7.1 dBi RPTNC 3.0 dB Fixed/Mobile

A09-Y8TM* 4 element Yagi 8.1 dBi RPTNC 4.0 dB Fixed/Mobile

A09-Y9TM* 4 element Yagi 9.1 dBi RPTNC 5.0 dB Fixed/Mobile

A09-Y10TM-P10I 5 element Yagi 10.1 dBi RPTNC 6.0 dB Fixed/Mobile

A09-Y11TM* 6 element Yagi 11.1 dBi RPTNC 7.0 dB Fixed/Mobile

A09-Y12TM* 7 element Yagi 12.1 dBi RPTNC 8.0 dB Fixed/Mobile

A09-Y13TM* 9 element Yagi 13.1 dBi RPTNC 9.0 dB Fixed/Mobile

A09-Y14TM* 14 element Yagi 14.0 dBi RPTNC 9.9 dB Fixed/Mobile

Loss

Application

Omni-directional base station antennas

All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.

Required Antenna

Part Number Type Gain Connector

A09-F0NF* Fiberglass Base Station 0 dBi N - Fixed

A09-F1NF* Fiberglass Base Station 1.0 dBi N - Fixed

A09-F2NF-M Fiberglass Base Station 2.1 dBi N - Fixed

A09-F3NF* Fiberglass Base Station 3.1 dBi N - Fixed

A09-F4NF* Fiberglass Base Station 4.1 dBi N - Fixed

A09-F5NF-M Fiberglass Base Station 5.1 dBi N - Fixed

A09-F6NF* Fiberglass Base Station 6.1 dBi N 0.9 dB Fixed

A09-F7NF* Fiberglass Base Station 7.1 dBi N 1.9 dB Fixed

A09-F8NF-M Fiberglass Base Station 8.1 dBi N 2.9 dB Fixed

A09-F0SM* Fiberglass Base Station 0 dBi RPSMA - Fixed

A09-F1SM* Fiberglass Base Station 1.0 dBi RPSMA - Fixed

Cable Loss

Application

A09-F2SM* Fiberglass Base Station 2.1 dBi RPSMA - Fixed

A09-F3SM* Fiberglass Base Station 3.1 dBi RPSMA - Fixed

A09-F4SM* Fiberglass Base Station 4.1 dBi RPSMA - Fixed

A09-F5SM* Fiberglass Base Station 5.1 dBi RPSMA - Fixed

9XTend-PKG-R RS-232/485 RF Modem User Guide 92

Legacy XTend Modem approved antennas

Required Antenna

Part Number Type Gain Connector

A09-F6SM* Fiberglass Base Station 6.1 dBi RPSMA 0.9 dB Fixed

A09-F7SM* Fiberglass Base Station 7.1 dBi RPSMA 1.9 dB Fixed

A09-F8SM* Fiberglass Base Station 8.1 dBi RPSMA 2.9 dB Fixed

A09-F0TM* Fiberglass Base Station 0 dBi RPTNC - Fixed

A09-F1TM* Fiberglass Base Station 1.0 dBi RPTNC - Fixed

A09-F2TM* Fiberglass Base Station 2.1 dBi RPTNC - Fixed

A09-F3TM* Fiberglass Base Station 3.1 dBi RPTNC - Fixed

A09-F4TM* Fiberglass Base Station 4.1 dBi RPTNC - Fixed

A09-F5TM* Fiberglass Base Station 5.1 dBi RPTNC - Fixed

A09-F6TM* Fiberglass Base Station 6.1 dBi RPTNC 0.9 dB Fixed

A09-F7TM* Fiberglass Base Station 7.1 dBi RPTNC 1.9 dB Fixed

Cable Loss

Application

A09-F8TM* Fiberglass Base Station 8.1 dBi RPTNC 2.9 dB Fixed

A09-W7* Wire Base Station 7.1 dBi RPN 1.9 dB Fixed

A09-W7SM* Wire Base Station 7.1 dBi RPSMA 1.9 dB Fixed

A09-W7TM* Wire Base Station 7.1 dBi RPTNC 1.9 dB Fixed

Dome antennas

All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.

Required Antenna Cable

Part Number Type Gain Connector

A09-D3PNF* Omnidirectional permanent mount 3.0 dBi N 0.4 dB Fixed/Mobile

A09-D3NF* Omnidirectional magnetic mount 3.0 dBi N 0.4 dB Fixed/Mobile

A09-D3PTM* Omnidirectional permanent mount 3.0 dBi RPTNC 0.4 dB Fixed/Mobile

A09-D3PSM* Omnidirectional permanent mount 3.0 dBi RPSMA 0.4 dB Fixed/Mobile

Loss

Application

9XTend-PKG-R RS-232/485 RF Modem User Guide 93

Legacy XTend Modem approved antennas

Monopole antennas

All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.

Required Antenna Cable

Part Number Type Gain Connector

A09-QRAMM 3" Quarter wave wire 2.1 dBi MMCX - Fixed/Mobile

A09-QRSM-2.1* Quarter wave 2.1" right angle 3.3 dBi RPSMA 0.4 dB Fixed/Mobile

A09-QW* Quarter wave wire 1.9 dBi Permanent - Fixed/Mobile

A09-QSM-3* Quarter wave straight 1.9 dBi RPSMA - Fixed/Mobile

Loss

Application

A09-QSM-3H* Heavy duty quarter wave

straight

A09-QBMM-P6I* Quarter wave w/ 6" pigtail 1.9 dBi MMCX - Fixed/Mobile

A09-QHSM-2* 2" straight 1.9 dBi RPSMA - Fixed/Mobile

A09-QHRSM-2* 2" right angle 1.9 dBi RPSMA - Fixed/Mobile

A09-QHRSM-170* 1.7" right angle 1.9 dBi RPSMA - Fixed/Mobile

A09-QRSM-380* 3.8" right angle 1.9 dBi RPSMA - Fixed/Mobile

A09-QAPM-520* 5.2" articulated screw mount 1.9 dBi Permanent - Fixed/Mobile

A09-QSPM-3* 3" straight screw mount 1.9 dBi Permanent - Fixed/Mobile

A09-QAPM-3* 3" articulated screw mount 1.9 dBi Permanent - Fixed/Mobile

A09-QAPM-3H* 3" articulated screw mount 1.9 dBi Permanent - Fixed/Mobile

1.9 dBi RPSMA - Fixed/Mobile

9XTend-PKG-R RS-232/485 RF Modem User Guide 94

Development guide

RS-232 Accessories Kit contents

The accessories listed below are included with XTend RF Modems that carry the "-RA" suffix on the product number. For example: Part number "XT09-PKC-RA" includes the listed accessories and part number "XT09-PKC-R" does not. The accessories kit includes hardware and software needed for developing long range wireless links. For testing the modem's range, Digi recommends the purchase of one RF Modem with the accessories and one without.

Item Qty. Description Part Number

Quick Start Guide 1 Familiarizes users with some of the modem’s most important functions. 90000812-88

XTend-PKG-R™ RS-232/485 RF Modem

Antenna 1 900 MHz RPSMA, 6" Half-Wave, dipole, articulating A09-HASM-675

Serial Loopback Adapter

NULL Modem Adapter (male-to-male)

Male DB-9 to RJ-45 Adapter

Female DB-9 to RJ-45 Adapter

Power Adapter 1 Allows Interface Board to be powered by a 110 Volt AC power supply JP5P2-9V11-6F

RS-232 Cable (6’) 1 Connects interface board to devices having an RS-232 serial port JD2D3-CDS-6F

1 Long Range 900 MHz RF Modem with RPSMA Connector XT09-PK.-... or

XTP9B-PK.-...

1 Connects to the female RS-232 (DB-9) serial connector of the Digi Interface

Board and can be used to configure the modem to function as a repeater (for range testing)

1 Connects to the female RS-232 (DB-9) serial connector of the Digi Interface

Board and can be used to connect the modem to another DCE (female DB9) device

1 Facilitates adapting the DB-9 Connector of the Digi Interface Board to a CAT5

cable (male DB9 to female RJ45)

1 Facilitates adapting the DB-9 Connector of the Digi Interface Board to a CAT5

cable (female DB9 to female RJ45)

JD2D3-CDL-A

JD2D2-CDN-A

JE1D2-CDA-A

JE1D3-CDA-A

9XTend-PKG-R RS-232/485 RF Modem User Guide 95

RS-232 Accessories Kit contents

Adapters

The development kit includes several adapters that facilitate the following functions:

• Performing Range Tests

• Testing Cables

• Connecting to other RS-232 DCE and DTE devices

• Connecting to terminal blocks or RJ-45 (for RS-485/422 devices)

NULL modem adapter (male-to-male)

Part Number: JD2D2-CDN-A (Black, DB-9 M-M) The male-to-male NULL modem adapter is used to connect two DCE

devices. A DCE device connects with a straight-through cable to the male serial port of a computer (DTE).

The following figure shows the Male NULL modem adapter and pinouts.

The following figure shows an example of a Digi Radio Modem (DCE Device) connecting to another DCE device).

Serial loopback adapter

Part Number: JD2D3-CDL-A (Red, DB-9 M-F) The serial loopback adapter is used for range testing. During a range

test, the serial loopback adapter configures the modem to function as a repeater by looping serial data back into the radio for retransmission.

The following figure shows a Serial loopback adapter and pinouts.

9XTend-PKG-R RS-232/485 RF Modem User Guide 96

RS-232 Accessories Kit contents

Male DB-9 to RJ-45 adapter

Part Number: JE1D2-CDA-A (Yellow) This adapter facilitates adapting the DB-9 Connector of the Digi Interface

Board to a CAT5 cable (male DB9 to female RJ45).

Refer to the ‘RS-485 (4-wire) and RS-422 Operation’ sections for RS-485/422 connection guidelines.

The following figure shows a Male DB-9 to RJ-45 Adapter and pinouts.

Female DB-9 to RJ-45 adapter

Part Number: JE1D3-CDA-A (Green) This adapter Facilitates adapting the DB-9 Connector of the Digi Interface Board

to a CAT5 cable (female DB9 to female RJ45).

Refer to the ‘RS-485 (4-wire) and RS-422 Operation’ sections for RS-485/422 connection guidelines.

The following figure show a Female DB-9 to RJ-45 Adapter and pinouts.

9XTend-PKG-R RS-232/485 RF Modem User Guide 97

RS-232 Accessories Kit contents

9XTend-PKG-R RS-232/485 RF Modem User Guide 98
