CONCRETE SAW
PARTS LIST
MODEL
CC8000
April 2014
Part #1800451
Page 2
Table of Contents
Description Page No.
Saw Controls Legend…………………………………………………………... 3
Drawing 1. Frame Group………….…………………………………………... 4 - 5
Drawing 2. Arm Assembly…………………………………………….....l….. 6 - 7
Drawing 3. Hydraulics Group A………..………………………….….......... 8 - 9
Drawing 4. Hydraulics Group B…..…………………………………………. 10 - 11
Drawing 5. Power Steering Group…………………………….…..………… 12 - 13
Drawing 6. Engine Group……………………………………………………. 14 – 15
Air Cleaner Assembly…………………………………………………………. 16
Muffler Assembly………………………………………………………………. 17
Drawing 7. Light, Pointer, Water Pump Group………….…………………. 18 - 19
Drawing 8. Blade Guard Assembly……….………………….……..………. 20 - 21
Drawing 9. Plunge Cut Assembly………….……………………..….......... 22 - 23
Drawing 10. Pressure Limiter Assembly………………………….…………. 24 - 25
Drawing 11. Slot Cutter Attachment……………………………….…………. 26 - 27
Drawing 12. Hydraulic Circuit Schematic….……….…………....………….. 28 - 29
Drawing 13. Wiring Diagram…….……..……….………….…………………. 30 - 31
Angle Arm Option….…….……..……….………….…………………. 32
Dust Collector Option…….……………………………………………………. 34 – 39
Strobe Light Option……………………………………………………………. 40
Tiller Steering Option……..……….…..…..…….……………………..………. 41
Decal Sheet……….…..…..…….……………………..… ………… ……… …… 42
Blade Speed (RPM) Chart……….…..…..…….……………………..………. 43
Warranty……………………………………………………………………….…..Rear Cover
Quick Reference Service Filters
Part No. Description Manufacturer’s Part N o .
2701775 Engine Oil Filter (Deutz #1174416)
2701339 Engine Fuel Filter (Deutz #1174482)
2500474 In-line Fuel Tank Filter (Fram #G2)
2505020 Primary Air Filter Element (Donaldson #P608533)
2503681 Secondary Air Filter Element (Donaldson #P 600975)
2702208 Hydraulic Oil Filter, Pump (Sauer Danfoss #9700810)
3200486 Hydraulic Oil Filter, Remote (Arlon Parker #FA35-CC10)
Page 3
Saw Controls Legend
1. Travel Speed Control Lever 12. Blade Tachometer / Hour Meter
2. Blade Raise Pushbutton 13. Blade Raising Speed Control
3. Blade Lower Pushbutton 14. Blade Lowering Speed Control
4. Blade Speed Control Lever 15. Air Cleaner Restriction Indicator
5. Emergency Stop Button 16. Fuel Tank Cap / Gauge
6. Engine Temperature Gauge 17. Blade Shaft Wrench
7. Engine Alternator Light 18. Blade Depth Stop Bolt
8. Engine Oil Temperature Light 19. Hydraulic Oil Temperature Gauge
9. Engine Oil Pressure Light 20. Blade Angle Adjustment Nut
10. Ignition Switch 21. Water Control Valve
11. Vernier Throttle Control 22. Seat Adjustment Lever
23. Water Supply Hose Hook
Page 4
4
Page 5
_________________________________
5
CC8000 Parts List
Drawing 1
Frame Group
_________________________________
Diagram
Number
1 6040000 1 Frame Base 48 2500880 1 Control Cable, 72" Travel
2 6040011 1 Frame Upright 49 2900144 4 Capscrew, Hex Hd., 1/4"-20 x 3/4"
3 2900025 4 Capscrew, Hex Hd., 1/2"-13 x 1-1/4" 50 2900010 6 Lock Nut, 1/4"-20 Nylon
4 2900084 1 Lock Washer, 1/2" Split 51 6040166 1 Speed Control Lever Assembly
5 2900058 4 Flat Washer, 1/2" SAE (Includes #50 - #62)
6 2900026 3 Lock Nut, 1/2"-13 Nylon 52 6040149 1 Speed Control Lever Only
7 2900180 19 Capscrew, Hex Washer Hd., 1/4"-20 x 1" 53 2501280 1 Control Grip Body
8 2900024 23 Lock Washer, 1/4" Split 54 2501281 1 Control Grip Cover
9 2900009 27 Flat Washer, 1/4" SAE 55 2500644 1 Plug. Rectangular
10 6040030 1 Frame Side Panel 56 2900452 1 Screw, Oval Head, #4 x 5/8"
11 2500892 2 Panel Pull 57 2800372 1 Pushbutton Switch, Raise
12 2900371 2 J-Bolt, 3/8"-16 58 2800373 1 Pushbutton Switch, Lower
13 2900033 4 Hex Nut, 3/8"-16 59 2500694 2 Plug, 5/8" Hole
14 2900006 10 Lock Washer, 3/8" Split 60 2900453 1 Setscrew, Soc. Hd., M5 x 12mm
15 2900014 10 Flat Washer, 3/8" SAE 61 6040167 1 Wiring Harness, Raise/Lower
16 6040031 1 Frame Rear Panel 62 2900048 2 Capscrew, Hex Hd., 1/4"-20 x 1-1/2"
17 6040029 1 Frame Top Panel 63 2500761 1 Seat
18 2900538 8 Capscrew, Hex Hd., 5/16"-18 x 1-3/4" 64 6040037 1 Seat Platform
19 2900031 20 Lock Washer, 5/16" Split 65 2900137 2 Capscrew, Hex Hd., 5/8"-11 x 3-1/4"
20 2900022 20 Flat Washer, 5/16" SAE 66 2900002 8 Flat Washer, 5/8" SAE
21 2900019 8 Capscrew, Hex Hd., 5/16"-18 x 3/4" 67 2900135 3 Lock Nut, 5/8"-11 Nylon
22 2800461 1 Emergency Stop Button 68 6040014 1 Foot Rest
23 2800462 1 Contact Block N.C. 6040133 1 Foot Rest (Reverse Mount)
24 2800388 1 Fuse Panel, 6 Circuit 69 2900146 1 Capscrew, Hex Hd., 5/8"-11 x 4"
25 2900451 2 Machine Screw, Soc. Hd., #10-24 x 1-1/4" 70 3200013 1 Street Elbow, 1/2" NPT
26 2900016 2 Flat Washer, #10 USS 71 3200022 1 Fitting, 1/2" Female Pipe to 3/4" Female
27 2900017 2 Lock Nut, 10-24 Nylon Garden Hose
28 6013093 1 Gauge Panel 72 3200025 1 Filter Hose Washer
29 2900021 6 Tapscrew, Pan Hd., #10-24 x 3/8" 73 3200027 1 Water Valve
30 2700785 1 Alternator Light 74 3200155 1 Fitting, 1/2" Male Pipe to 3/4" Male
31 2700787 1 Oil Temperature Light 75 6010021 1 Water Hose Assembly, 42" Long
32 2700786 1 Oil Pressure Light (Includes #14, #15, #66, #77 - #84)
33 2702333 1 Engine Temperature Gauge 78 6040001 2 Axle Mount
34 2700783 1 Ignition Switch 79 2900147 4 Capscrew, Hex Hd., 5/8"-11 x 1-3/4"
35 2500228 1 Vernier Throttle Cable 60" 80 2900113 4 Lock Washer, 5/8" Split
36 6010416 1 Blade Shaft Tach/Hour Meter 81 2900079 2 Capscrew, Hex Hd., 3/8"-16 x 2-1/4"
37 6040038 1 Controls Frame 82 2502115 2 Wheel, 10" Dia. x 4" Wide
38 2900138 4 Capscrew, Hex Hd., 5/16"-18 x 1" 83 2500748 4 Bearing, Wheel
39 6040070 1 Controls Rear Panel 84 2500782 2 Set Collar, 1-1/4" with Setscrew
40 6040071 1 Controls Side Panel 85 2800267 1 Light, Wedge Base
41 2900082 4 Capscrew, Hex Hd., 1/4"-20 x 1/2"
42 6040072 1 Controls Front Panel 87 2701261 1 Ignition Key
43 6040032 1 Gate Plate 88 6010013 2 Wheel Well Brace
44 2900542 2 Tap Bolt, Hex Hd., 1/2"-13 x 3-1/2" 89 2900013 4 Capscrew, Hex Hd., 3/8"-16 x 1-1/4"
45 2900037 2 Hex Nut, 1/2"-13 90 6040236 1 Edge Trim, 16" Long
46 2500881 1 Quadco Speed Controller 91 6040306 1 Access Panel
47 2501358 1 Control Cable, 54" Blade
Part
No.
2700923 1 (Bulb Only) Garden Hose
2700923 1 (Bulb Only) 76 6040077 1 Front Axle Assembly
2700923 1 (Bulb Only) 77 6040010 1 Front Axle
Qty.
Reg.
Description
Diagram
Number
86 2800389 6 Fuse, 10 Amp Red ATO/ATC
Part
No.
Qty.
Reg.
Description
Page 6
6
Page 7
__________________________________
7
CC8000 Parts List
Drawing 2
Arm Assembly
__________________________________
Diagram
Number
1 6040008 1 Arm Weldment 24 2900113 2 Lock Washer, 5/8" Split
2 6040243 1 Pillow Block Assembly with Splined Input Shaft 25 2900002 1 Flat Washer, 5/8" SAE
3 6040007 1 Pillow Block 32 6040025 1 Blade Guard Brace for 30" - 36" Blade Guards
4 2900062 1 Grease Fitting, 1/8" NPT 33 2900005 2 Capscrew, Hex Hd., 3/8"-16 x 1"
5 2900139 6 Capscrew, Hex Hd., 1/2"-13 x 1-3/4" 34 2900006 2 Lock Washer, 3/8" Split
6 2900084 6 Lock Washer, 1/2" Split 35 2900014 2 Flat Washer, 3/8" SAE
7 2900058 10 Flat Washer, 1/2" SAE 36 6040069 1 Blade Guard Brace for 42" - 54" Blade Guards
8 6040240 1 Blade Shaft with Splined Input 37 2500211 1 Wrench, 15/16"
Part
Qty.
No.
Reg.
& 6" Dia. Flanges (Includes #3 - #27) 26 6040333 1 Blade Guard Mount
6040244 1 Pillow Block Assembly with Splined Input Shaft 27 2800169 1 Magnetic Sensor with Wire Connector & Nut
& 8" Dia. Flanges (Includes #3 - #18, #21 - #29) 28 6013017 1 Inner Flange, 8" for 42" - 54" Blade Guards
6040079 1 Pillow Block Assembly with Keyed Input Shaft 29 6013018 1 Outer Flange, 8" with Drive Pin for
& 6" Dia. Flanges (Includes #3 - #27) 42" - 54" Blade Guards (Includes #21)
6040080 1 Pillow Block Assembly with Keyed Input Shaft 30 6040036 1 Blade Guard Support Bar
& 8" Dia. Flanges (Includes #3 - #18, #21 - #29) 31 2900511 2 Capscrew, Soc. Hd., 1/2"-13 x 1-1/4"
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
6040003 1 Blade Shaft with Keyed Input 38 2900307 1 Wing Screw, M6 x 16mm
9 6010040 1 Key, 1/4" Sq. x 13/16" 39 6040078 1 Depth Stop Bolt, 3/4"-10 x 12"
(2 req'd for 8" Flanges) 40 2900041 1 Hex Nut, 3/4"-10
10 2500686 2 Bearing, 50mm x 90mm x 20mm 41 2900476 1 Swivel Pad Nut, 3/4"-10
11 6040006 1 Motor Adapter 42 6040009 1 Pivot Shaft
12 2900175 6 Capscrew, Soc. Hd., 3/8"-16 x 1" 43 2900376 2 Capscrew, Hex Hd., 1/2"-13 x 7"
13 6040005 1 Seal Plate 44 2900026 2 Lock Nut, 1/2"-13 Nylon
14 2900235 4 Capscrew, Flat Hd., 3/8"-16 x 1" 45 6040002 1 Arm Clevis
(10 req'd for 8" Flanges) 46 2500746 2 Bearing, 2" Insert
15 2500808 1 Seal, 1-3/4" x 2-3/8" x 5/16" 47 6040023 1 Arm Mount Weldment
16 2500751 1 Seal, 1-3/4" V-Ring 48 2900350 1 Lock Washer, 2-1/2" Split
17 6010230 1 Shaft Tach Gear, 1-3/4" I.D. 49 2900546 1 Hex Nut, 2-1/2"-4
18 2900089 2 Capscrew, Soc. Hd., 1/4"-28 x 1" 50 2900370 4 Capscrew, Hex Hd., 1"-8 x 3"
19 6010038 1 Inner Flange, 6" for 14" - 36" Blade Guards 51 2900365 4 Lock Washer, 1" Split
20 6010039 1 Outer Flange, 6" with Drive Pin for 52 2900366 2 Tap Bolt, Hex Hd., 3/8"-16 x 2"
14" - 36" Blade Guards (Includes #21) 53 2900033 2 Hex Nut, 3/8"-16
21 2900197 1 Drive Pin Only, 3/8" Dia. x 2" 54 1802199 1 RPM Label
22 2900418 1 Setscrew, Soc Hd., 5/16"-18 x 5/8" 55 6010529 1 Tapered Mount Adapter
(2 req'd for 8" Flanges) 56 2900471 1 Capscrew, Soc. Hd., 1/4"-20 x 2-1/2"
23 2900130 1 Capscrew, Hex Hd., 5/8"-11 x 4" Left Hand
Page 8
8
Page 9
________________________________
9
CC8000 Parts List
Drawing 3
Hydraulics Group A
_________________________________
Diagram
Number
1 2600295 1 Sauer Pump 40 3200298 1 Elbow, 3/4" O-Ring to 1/2" Male JIC
1A 2702208 1 Pump Filter Element, Spin-On 41 6040238 1 Hose Assembly, 1/2" x 30" PL
1B 2702329 1 Neutral Start Switch 42 6040054 1 Hose Assembly, 1/2" x 26" PL
2 2900499 8 Capscrew, Hex Hd., 1/2"-13 x 1-1/2" 43 3200304 2 Elbow, 1/2" Male JIC to 1/2" Female JIC
3 2900084 12 Lock Washer, 1/2" Split 44 3200286 2 Adapter, 1/2" O-Ring to 1/2" Male JIC
4 2900058 8 Flat Washer, 1/2" SAE 45 3200259 1 Heat Exchanger
5 3200249 2 Flange Kit, 1" Split (Includes #6 - #9) 46 6040287 1 Hose Assembly, 1" x 40"
6 3200336 4 Flange Half, 1" Split 47 3200300 1 Manifold, Case Drain
7 2900149 8 Capscrew, Hex Hd., 7/16"-14 x 1-3/4" 48 2900380 2 Capscrew, Hex Hd., 1/4"-20 x 2-3/4"
8 2900238 8 Lock Washer, 7/16" Split 49 3201242 1 Bushing, 1" MNPT to 1/4" FNPT
9 3200337 2 O-Ring, 1" Split Flange 50 3200418 1 Adapter, 1/4" Male Pipe to 1/4" Male JIC
10 3200244 1 Hose Assembly, 3/4" x 70" HP 51 3200283 4 Adapter, 1/2" Male Pipe to 1/2" Male JIC
11 3200245 1 Hose Assembly, 3/4" x 65" HP 52 3200134 1 Cap, 1/2" JIC
12 2600315 1 VOAC Motor with Splined Shaft 53 6040248 1 Hose Assembly, 1/2" x 68" PL
13 2900139 4 Capscrew, Hex Hd., 1/2"-13 x 1-3/4" 55 6040057 1 Hose Assembly, 1" x 34" LP
14 3200248 2 Flange Kit, 3/4" Split (Includes #15 - #17) 56 3200505 1 Filter Head
15 3200338 4 Flange Half, 3/4" Split 57 3201175 1 Filter Element, Spin-On
16 3200339 2 O-Ring, 3/4" Split Flange 58 6040239 1 Filter Mount Bracket
17 2900006 14 Lock Washer, 3/8" Split 59 2900144 2 Capscrew, Hex Hd., 1/4"-20 x 3/4"
18 2900375 8 Capscrew, Hex Hd., 3/8"-16 x 4-1/2" 60 2900019 4 Capscrew, Hex Hd., 5/16"-18 x 3/4"
19 3200287 1 Adapter, 5/8" O-Ring to 1/2" Male JIC 61 2900022 4 Flat Washer, 5/16" SAE
20 6040249 1 Hose Assembly, 1/2" x 22" PL 62 2900039 4 Lock Nut, 5/16"-18 Nylon
21 2600212 1 Oilgear Pump 63 3200502 1 Filter Pressure Gauge
22 2900013 6 Capscrew, Hex Hd., 3/8"-16 x 1-1/4" 64 3200099 1 Street Elbow, 1/8" NPT 45°
23 2900014 6 Flat Washer, 3/8" SAE 65 3200066 1 Hex Pipe Coupling, 1/8" NPT
24 6040022 1 Shift Lever 66 3200179 1 Pipe Nipple, 1/8" NPT x 3"
25 2900451 1 Capscrew, Socket Hd., #10-24 x 1-1/4" 67 3200156 1 Street Elbow, 1/8" NPT 90°
26 2900017 1 Lock Nut, #10-24 Nylon 68 6040058 1 Hose Assembly, 1" x 22" LP
27 2501358 1 Control Cable, 54" Blade 69 6040021 1 Hydraulic Reservoir Tank
28 2500880 1 Control Cable, 72" Travel 70 2501429 1 Filler/Breather Cap (6 Bolt)
29 2900186 2 Hex Nut, 1/4"-28 2500760 1 Filler/Breather Cap (7 Bolt)
30 2500409 2 Rod End, 1/4"-28 Female 71 2500762 1 Level/Temperature Sight Gauge
31 2900008 1 Capscrew, Hex Hd., 1/4"-20 x 1" 72 3200261 1 Suction Strainer, 2" NPT
32 2900010 4 Lock Nut, 1/4"-20 Nylon 73 3200282 2 Elbow, 1-1/4" Male Pipe to 1" Male JIC
33 2900052 1 Capscrew, Hex Hd., 1/4"-20 x 1-1/4" 74 3200487 1 Tee, 1" Male JIC to 1" Female JIC
34 6040233 1 Cable Cable Bracket 75 3200488 1 Reducer, 1" Female JIC to 1/2" Male JIC
35 2900493 2 Capscrew, Socket Hd., M6 x 50mm 76 6040062 1 Hose Assembly, 1/2" x 18" HP
36 2900024 6 Lock Washer, 1/4" Split 77 6040235 1 Hose Assembly, 1" x 28" LP
37 6040232 1 Control Cable Guide Bar 78 3200297 1 Elbow, 1" O-Ring to 1" Male JIC
38 2900294 2 Capscrew, Hex Hd., 1/4"-20 x 2" 79 3200160 1 Plug, 1/2" NPT Hex Head
39 2900009 8 Flat Washer, 1/4" SAE 80 3200006 1 Cap, 1/4" JIC
Part
No.
2600203 1 VOAC Motor with Keyed Shaft 54 3200289 5 Elbow, 1" Male Pipe to 1" Male JIC
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
Page 10
10
Page 11
________________________________
11
CC8000 Parts List
Drawing 4
Hydraulics Group B
_________________________________
Diagram
Number
1 6040091 1 Oil Cooler Assembly (Includes #2 - #11) 23 3200295 2 Adapter, 1/2" O-Ring to 3/8" Female Pipe
2 3200262 1 Oil Cooler 24 3200296 2 Adapter, 3/8" Male Pipe to 1/4" Male Pipe
3 2900196 4 Capscrew, Hex Hd., 3/8"-16 x 3/4" 25 3200056 2 Flow Control Valve, 1/4" NPT
4 2900006 4 Lock Washer, 3/8" Split 26 3200057 4 Elbow, 1/4" Male Pipe to 1/4" Male JIC
5 2900014 4 Flat Washer, 3/8" SAE 27 6040114 3 Hose Assembly, 1/4" x 30" HP
6 3200364 2 Reducer, 3/4" Male Pipe to 1/2" Female Pipe 28 3200314 2 Nipple, 1/8" QD
7 3200155 2 Fitting, 1/2" Male Pipe to 3/4" Male Garden Hose 29 3200315 2 Coupler, 1/8" QD
8 3200038 2 Reducer, 1" Male Pipe to 3/4" Female Pipe 30 6040115 1 Hose Assembly, 1/4" x 22" HP
9 3200430 2 Street Elbow, 3/4" NPT Steel 31 2500896 1 Cylinder
10 3200162 2 Fitting, 3/4" Male Pipe to 1/2" Push Lock 2500278 1 (Seal Kit)
11 6011055 1 Water Hose Assembly, 30" Long 32 2500738 1 Rod End, 3/4"-16 Female
Part
No.
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
12 3200257 1 Valve, 4 Way Solenoid 33 2900362 1 Clevis Pin, 3/4" Dia. x 2-3/4"
2701964 2 (Valve Coil Only) 34 2900363 1 Clevis Pin, 3/4" Dia. x 3-3/4"
13 6040043 1 Valve Bracket 35 2900004 2 Cotter Pin, 1/8" x 1"
14 2900294 4 Capscrew, Hex Hd., 1/4"-20 x 2" 36 2900003 4 Flat Washer, 3/4" SAE
15 2900009 6 Flat Washer, 1/4" SAE 37 6040008 1 Arm Weldment
16 2900010 4 Lock Nut, 1/4"-20 Nylon 38 6010021 1 Water Hose Assembly, 42" Long
17 2900008 2 Capscrew, Hex Hd., 1/4"-20 x 1" 39 3200300 1 Manifold, Case Drain
18 2900024 2 Lock Washer, 1/4" Split 40 3200283 1 Adapter, 1/2" Male Pipe to 1/2" Male JIC
19 3200286 4 Adapter, 1/2" O-Ring to 1/2" Male JIC 41 6040248 1 Hose Assembly, 1/2" x 68" PL
20 6040063 2 Hose Assembly, 1/2" x 30" HP 42 6040249 1 Hose Assembly, 1/2" x 22" PL
21 3200304 2 Elbow, 1/2" Male JIC to 1/2" Female JIC 43 3200287 1 Adapter, 5/8" O-Ring to 1/2" Male JIC
22 3200258 1 Valve, Cylinder Lock 44 2600315 1 VOAC Motor with Splined Shaft
2600203 1 VOAC Motor with Keyed Shaft
Page 12
12
Page 13
__________________________________
13
CC8000 Parts List
Drawing 5
Power Steering Group
________________________________
Part # 6040132 Power Steering Upgrade Kit (Includes #1 - #30)
Diagram
Number
1 6040131 1 Steering Support Brace 22 2701901 1 Woodruff Key, 1/4" Wide x 1" Dia.
2 2900494 3 Capscrew, Hex Hd., 5/16"-18 x 2" 23 3200422 4 Adapter, 5/8" O-Ring to 1/2" Male JIC 45°
3 2900031 3 Lock Washer, 5/16" Split 24 2900029 4 Capscrew, Hex Hd., 3/8-16 x 1-1/2"
4 2900022 3 Flat Washer, 5/16" SAE 25 2900006 4 Lock Washer, 3/8" Split
5 2600222 1 Steering Control Unit 26 2900014 4 Flat Washer, 3/8" SAE
6 2600221 1 Steering Column 27 2900062 1 Grease Fitting, 1/8" NPT
7 2900311 4 Capscrew, Hex Hd., M6 x 25mm 28 N/A
8 2900024 4 Lock Washer, 1/4" Split 29 6040066 2 Hose Assembly, 1/2" x 46" HP
9 2501170 1 Steering Wheel 30 3200332 1 Tee, 1/2" Male JIC to 1/2" Female JIC
10 2900435 1 Hex Nut, M16x1.5 31 2600213 1 Wheel Drive Motor (Includes #32 and #33)
Part
No.
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
11 2501176 1 Steering Wheel Cap 32 2701902 1 Key, 5/16" Square x 1"
12 3200263 5 Adapter, 3/8" O-Ring to 3/8" Male JIC 33 2701903 1 Hex Nut, 1"-20 Slotted
13 6040123 5 Hose Assembly, 3/8" x 78" HP 34 2900374 1 Cotter Pin, 5/32" x 1-1/2"
14 6011492 1 Includes 6010997 & 6011347 35 2900105 4 Capscrew, Hex Hd., 1/2"-13 x 2-3/4"
14A 6010997 1 Drive Wheel Support Arm 36 2900026 4 Lock Nut, 1/2"-13 Nylon
15 2900370 3 Capscrew, Hex Hd., 1"-8 x 3" 37 6040012 1 Drive Wheel with Hub
16 2900365 3 Lock Washer, 1" Split 38 2600212 1 Oilgear Pump
17 6011343 1 Drive Wheel Bracket 39 3200285 3 Elbow, 1/2" O-Ring to 1/2" Male JIC
18 2504000 1 Bearing, 1-3/4" Thrust 40 3200286 3 Adapter, 1/2" O-Ring to 1/2" Male JIC
19 6011347 1 Bearing, 1-3/4" x 2" x 3" 41 3200257 1 Valve, 4 Way Solenoid
20 2501376 1 Retaining Ring, 1-3/4" 42 6040237 1 Hose Assembly, 1/2" x 16" HP
21 2600223 1 Steering Motor (Includes #22)
Page 14
14
Page 15
__________________________________
15
CC8000 Parts List
Drawing 6
Engine Group
__________________________________
Diagram
Number
1 2600328 1 Engine, Deutz Diesel Model BF4L2011 26 2900138 6 Capscrew, Hex Hd., 5/16"-18 x 1"
1A 2701775 1 Oil Filter 28 2800144 2 Capscrew, Hex Hd., 1/4"-20 x 3/4"
1B 2701339 1 Fuel Filter 29 2500940 1 Throttle Cable Clamp
2 2900347 4 Capscrew, Hex Hd., M12 x 100mm 30 2900015 2 Capscrew, Hex Hd., #10-24 x 3/4"
3 2900058 8 Flat Washer, 1/2" SAE 31 2900017 2 Lock Nut, #10-24 Nylon
4 2900327 4 Lock Nut, M12 Nylon 32 6013029 1 Throttle Arm
5 6040084 1 Muffler Assembly 33 6048212 1 Pivot Pin
6 2900333 2 Capscrew, Hex Hd., M10 x 25mm 34 2900034 1 Cotter Pin, 3/32" x 3/4"
7 2900321 2 Lock Washer, M10 Split 35 2900059 1 Setscrew, Soc. Hd., #10-32 x 1/4"
8 2900014 2 Flat Washer, 3/8" SAE 36 2501784 1 Fuel Tank, Plastic
9 2900031 11 Lock Washer, 5/16" Split 37 2500649 1 Fuel Tank Cap with Gauge
10 6040013 1 Air Cleaner Platform 38 6040028 1 Fuel Tank Mount
11 2900310 3 Capscrew, Hex Hd., M6 x 20mm 6040027 1 Fuel Tank Mount (For Slot Cutter Option)
12 2900024 5 Lock Washer, 1/4" Split 39 3200012 1 Street Elbow, 1/4" NPT
13 2900009 3 Flat Washer, 1/4" SAE 40 3200202 1 Fitting, 1/4" Male Pipe to 5/16" Push Lock
14 2900329 1 Capscrew, Hex Hd., M8 x 20mm 41 6013096 1 Fuel Line Hose, 5/16" I.D. x 28" Long
15 2900022 11 Flat Washer, 5/16" SAE 42 2500474 1 Fuel Filter, 5/16" with Clamps
16 6011496 1 Air Cleaner Assembly 43 6013095 1 Fuel Line Hose, 5/16" I.D. x 4" Long
17 2700208 1 Battery, 12 Volt 44 3200062 2 Hose Clamp #4
18 6010016 1 Battery Pad 45 3200057 1 Elbow, 1/4" Male Pipe to 1/4" Male JIC
19 2800073 1 Battery Cable, Positive (Red) 46 3200091 1 Fitting, 1/4" Female JIC to 1/4" Push Lock
20 2800256 1 Battery Boot (Red) 47 6048096 1 Fuel Line Hose, Return, 1/4" I.D. x 12"
21 2800072 1 Battery Cable, Negative (Black) 48 2900019 4 Capscrew, Hex Hd., 5/16"-18 x 3/4"
22 2800257 1 Battery Boot (Black) 49 6010451 1 Oil Drain Hose Assembly
23 2800182 1 Negative Ground Cable (Black)
24 6040026 1 Battery Strap
25 6048077 2 Rubber Strip
Part
No.
2600232 1 Engine, Deutz Diesel Model BF4L1011F 27 6040073 1 Throttle Brace
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
Page 16
2
16
1
6011496 AIR CLEANER ASSEMBLY
18
4
13
12
11
15
14
16
17
3
4
DETAIL B
SCALE 2 : 5
14
5
4
6
4
7
9
10
DETAIL A
SCALE 2 : 5
MOUNTS OVER ENGINE
ON AIR CLEANER PLATFORM
PRIMARY REPLACEMENT
ELEMENT: 2505020
SECONDARY REPLACEMENT
ELEMENT: 2503681
QTY.PART NO.ITEM
1 6011493 1 Bracket, Air FIlter
2 2504349 1 Air Filter Assembly
3 2503689 1 Hose, Union, 3-1/2", Rubber
4 3200198 5 Hose Clamp #64
5 6011396 1 Tube, 3-1/2" O.D. x 8"
6 2500427 1 Hose Elbow, 3-1/2" I.D.
7 6011397 1 Tube, 3-1/2" O.D. x 13"
8 2500458 1 Hose Elbow, 3" to 3-1/2" I.D.
9
6013118
1 Connector Tube, 2-3/4" O.D.
DESCRIPTION
TO ENGINE
AIR INTAKE
ITEM PART NO. QTY. DESCRIPTION
10 3200197 1 Hose Clamp #52
11 2901359 4 Fender Washer, M6
12 2900765 4 Lock Washer, M6 Split
13 2900310 4
14 2900022 8 Flat Washer, 5/16" SAE
15 2900031 4 Lock Washer, 5/16" Split
16 2900138 4 Cap Screw, Hex Hd., 5/16-18 x 1"
17 2900039 4 Lock Nut, 5/16-18 Nylon
18 2500423 1 Restriction Indicator
Cap Screw, Hex Hd., M6-1.0 x
20mm
8
Page 17
6040084 CC8000 MUFFLER ASSEMBLY
17
5
2
MOUNTS TO FLYWHEEL
END OF ENGINE
1
7
8
7
ITEM PART NO. CC7874/QTY. DESCRIPTION
1 6013102 1 Exhaust Support Plate
2 2700746 1 Muffler
3 6013110 1 Exhaust Pipe
4 2700748 2 Muffler Clamp 2"
5 2700747 1 Rain Cap 2"
6 2900014 4 Flat Washer, 3/8" SAE
7 2900321 2 Lock Washer, M10 Split
8 2900333 2 Cap Screw, Hex Hd., M10-1.5 x 25mm
9 2900031 3 Lock Washer, 5/16" Split
10 2900343 3 Hex Nut, M8-1.25
3
TO ENGINE
EXHAUST PORT
6
10
9
Page 18
18
Page 19
__________________________________
19
CC8000 Parts List
Drawing 7
Light, Pointer, Water Pump Group
__________________________________
Diagram
Number
1 6010112 1 Spot Light Kit (Includes #2 - #12) 23 6011201 1 Front Pointer Frame
2 2500194 2 Spot Light, 12 Volt (Includes #3) 24 6011152 2 Front Pointer Arm
3 2900033 4 Hex Nut, 3/8"-16 25 2900105 2 Capscrew, Hex Hd., 1/2"-13 x 2-3/4"
4 2900006 6 Lock Washer, 3/8" Split 26 2900026 4 Lock Nut, 1/2"-13 Nylon
5 2900014 6 Flat Washer, 3/8" SAE 27 2900005 2 Capscrew, Hex Hd., 3/8"-16 x 1"
6 6010106 1 Light Bar 28 2501379 1 Caster, Threaded Stem
7 6010107 1 Light Bar Mount Bracket 29 2900058 1 Flat Washer, 1/2" SAE
8 2400157 3 Hand Lock Knob, 5/16"-18 30 2900543 1 Jam Lock Nut, 1/2"-13 Nylon
9 2900144 2 Capscrew, Hex Hd., 1/4"-20 x 3/4" 31 6040024 1 Front Pointer Rod
10 2900010 10 Lock Nut, 1/4"-20 Nylon 32 2500740 1 Pointer Cap
11 2800062 2 Toggle Switch 33 2900234 2 Hand Lock Knob, 3/8"-16
Part
No.
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
12 2800063 2 Switch Boot 34 6011054 1 Pointer Cable
13 (REF) 1 Seat Platform 35 3200221 3 Cable Clamp
14 (REF) 1 Controls Side Panel 36 6040093 1 Pointer Mount
15 6041000 1 Light Support Stand 37 2900139 2 Capscrew, Hex Hd., 1/2"-13 x 1-3/4"
16 2900013 4 Capscrew, Hex Hd., 3/8"-16 x 1-1/4" 38 6040117 1 Optional Water Pump Kit (Includes
17 2900379 1 U-Bolt, 1/4"-20 #10 - #12, #18, #39 - #44)
18 2900009 14 Flat Washer, 1/4" SAE 39 2600200 1 Water Pump, 12 Volt Diaphragm
19 6040232 1 Cable Guide Bar 40 2701694 1 Port Fitting 90° with O-Ring (Set of 2)
20 2900294 2 Capscrew, Hex Hd., 1/4"-20 x 2" 41 3200016 2 Hose Clamp #8
21 6040138 1 Light Extension Bar 42 6040129 1 Inlet Hose Assembly, 24" Long
22 6040083 1 Front Pointer Assembly 43 6010302 1 Outlet Hose Assembly, 48" Long
(Includes #3, #23 - #35) 44 2900008 4 Capscrew, Hex Hd., 1/4"-20 x 1"
Page 20
20
Page 21
__________________________________
21
CC8000 Parts List
Drawing 8
Blade Guard Assembly
__________________________________
Diagram
Number
1 6010070 1 14" Blade Guard Assembly 11 2900294 2 Capscrew, Hex Hd., 1/4"-20 x 2"
2 6010071 1 14" Blade Guard Front & Rear Only 6010087 2 Water Tube for 30" Blade Guard
3 6010304 1 14" Blade Guard Front Only 20 6048150 1 Hinge Assembly for 14" Blade Guard
4 6010081 1 Splash Flap 25 6010560 1 Hinge Assembly for 26" - 54" Blade Guards
5 2900008 2 Capscrew, Hex Hd., 1/4"-20 x 1" (Includes #26 - #31)
6 2900009 4 Flat Washer, 1/4" SAE 26 6010549 1 Hinge Only
7 2900083 2 Fender Washer, 1/4" x 1-1/4" 27 2900479 1 Capscrew, Hex Hd., 3/4"-10 x 4"
8 2900010 15 Lock Nut, 1/4"-20 Nylon 28 2900467 1 Lock Nut, 3/4"-10 Nylon
9 6010261 1 Manifold for 14" - 30" Blade Guards 29 2900005 4 Capscrew, Hex Hd., 3/8"-16 x 1"
10 2500830 1 Manifold Gasket for 14" - 36" 32 2900291 1 Capscrew, Hex Hd., 5/8"-18 x 4"
Part
No.
6010072 1 20" Blade Guard Assembly 13 3200002 1 Fitting, 3/4" Male Garden Hose to
6010074 1 26" Blade Guard Assembly 14 2900278 1 Lanyard with Lock Pin for
6010076 1 30" Blade Guard Assembly 2900279 1 Lanyard with Lock Pin for
6010260 1 36" Blade Guard Assembly 2900280 1 Lanyard with Lock Pin for
6010143 1 42" Blade Guard Assembly 2900281 1 Lanyard with Lock Pin for
6010145 1 48" Blade Guard Assembly 15 2900156 1 Lock Pin Only
6010183 1 54" Blade Guard Assembly 6010085 2 Water Tube for 20" Blade Guard
6010073 1 20" Blade Guard Front & Rear Only 6010088 2 Water Tube for 36" Blade Guard
6010075 1 26" Blade Guard Front & Rear Only 6010114 2 Water Tube for 42" Blade Guard
6010077 1 30" Blade Guard Front & Rear Only 6010115 2 Water Tube for 48" Blade Guard
6010259 1 36" Blade Guard Front & Rear Only 6013023 2 Water Tube for 54" Blade Guard
6010144 1 42" Blade Guard Front & Rear Only 17 6048155 2 Water Tube Clamp
6010146 1 48" Blade Guard Front & Rear Only 18 2900020 4 Capscrew, Flat Hd., 1/4"-20 x 3/4"
6010184 1 54" Blade Guard Front & Rear Only 19 1800001 1 Warning Label
6010305 1 20" Blade Guard Front Only (Includes #8, #21 - #23)
6010306 1 26" Blade Guard Front Only 6010251 1 Hinge Assembly for 20" Blade Guard
6010307 1 30" Blade Guard Front Only (Includes #8, #21, #22)
6010308 1 36" Blade Guard Front Only 21 2500270 1 Hinge Only
6010311 1 42" Blade Guard Front Only 22 2900144 6 Capscrew, Hex Hd., 1/4"-20 x 3/4"
6010312 1 48" Blade Guard Front Only 23 2900052 1 Capscrew, Hex Hd., 1/4"-20 x 1-1/4"
6010313 1 54" Blade Guard Front Only 24 2900024 2 Lock Washer, 1/4" Split
6010264 1 Manifold for 36" Blade Guard 30 2900006 4 Lock Washer, 3/8" Split
6010273 1 Manifold for 42" - 54" Blade Guards 31 2900014 4 Flat Washer, 3/8" SAE
2500859 1 Manifold Gasket for 42" - 54" 34 2900002 1 Flat Washer, 5/8" SAE
Qty.
Reg.
(Includes #2 - #23) 12 3200001 3 Pipe Plug, 1/8" NPT
(Includes #2 - #22) 3/8" Male Pipe
(Includes #2 - #19, #24, #25) 14" & 20" Blade Guards
(Includes #2 - #19, #24, #25) 26" & 30" Blade Guards
(Includes #2 - #19, #24 - #34) 36" & 42" Blade Guards
(Includes #2 - #19, #24 - #34) 48" & 54" Blade Guards
(Includes #2 - #19, #24 - #34) 16 6048283 2 Water Tube for 14" Blade Guard
(Includes #2 - #19, #24 - #34) 6010086 2 Water Tube for 26" Blade Guard
Blade Guards 33 2900113 1 Lock Washer, 5/8" Split
Blade Guards
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
Page 22
22
Page 23
__________________________________
23
CC8000 Parts List
Drawing 9
Plunge Cut Assembly
__________________________________
Part # 6040334 Plunge Cut Assembly for Splined Shaft Motor (Includes #1 - #48)
Diagram
Number
1 6040329 1 Pillow Block Assembly with Splined Input 25 2900471 1 Cap Screw, Soc. Hd., 1/4-28 x 2-1/2"
2 6040330 1 Pillow Block 27 2800169 1 Magnetic Sensor with Wire Connector & Hex Nut
3 2900062 1 Grease Fitting, 1/8" NPT 28 6010624 1 20" Plunge Guard Assembly (Includes #29 - #48)
4 2900106 6 Capscrew, Hex Hd., 1/2"-13 x 2" 29 6010625 1 20" Plunge Guard Front & Rear Only
5 2900084 6 Lock Washer, 1/2" Split 30 6010251 2 Hinge Assembly (Includes #31 - #33)
6 2900058 6 Flat Washer, 1/2" SAE 31 2500270 2 Hinge Only
7 6040331 1 Blade Shaft with Splined Input 32 2900144 16 Capscrew, Hex Hd., 1/4"-20 x 3/4"
8 2500804 2 Tapered Roller Bearing, Cone and Cup 33 2900010 19 Lock Nut, 1/4"-20 Nylon
9 6010138 1 Key, 3/8" Sq. x 7/8" 34 6010219 1 Splash Flap
10 2900203 1 Dowel Pin, 3/8" Dia. x 3" 35 2900008 3 Capscrew, Hex Hd., 1/4"-20 x 1"
11 2502048 1 Bearing Lock Nut 36 2900009 3 Flat Washer, 1/4" SAE
Part
No.
Qty.
Reg.
Shaft (Includes #2 - #27) 26 2900113 1 Lock Washer, 5/8" Split
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
12 6040006 1 Motor Adapter 37 2900083 3 Fender Washer, 1/4" x 1-1/4"
13 2900175 6 Capscrew, Soc. Hd., 3/8"-16 x 1" 38 2500067 2 Spring, 3/8" Dia. x 4"
14 6040332 1 Seal Plate 39 2900015 4 Machine Screw, Hex Hd., #10-24 x 3/4"
15 2900235 4 Capscrew, Flat Hd., 3/8"-16 x 1" 40 2900017 8 Lock Nut, #10-24 Nylon
16 2501372 1 Seal, 2-1/4" x 3" x 3/8" 41 6010190 2 Manifold Bar
17 2502047 1 Seal, 2-1/4" V-Ring 42 2900241 2 U-Bolt with 1/4"-20 Hex Nuts
18 6013091 1 Shaft Tach Gear, 1-3/4" I.D. 43 3200153 1 Pipe Plug, 3/8" NPT
19 6010136 1 Inner Flange, 8" 44 6010189 1 Water Manifold
20 6010139 2 Drive Pin, 3/8" Dia. x 7-1/8" 45 3200208 4 Spray Nozzle, 1/4" NPT
21 6010137 1 Outer Flange, 8" 46 3200209 1 Pipe Elbow, 1/2" Female
22 6048346 1 Shaft Nut, 1-1/2"-12 Left Hand 47 3200155 1 Fitting, 1/2" Male Pipe to 3/4" Male Garden Hose
23 6040333 1 Blade Guard Mount 48 1800001 1 Warning Label
24 6010529 1 Tapered Mount Adapter
Page 24
24
Page 25
__________________________________
25
CC8000 Parts List
Drawing 10
Pressure Limiter Assembly
__________________________________
Part #6040256 Pressure Limiter Kit for 30 GPM at 2500 PSI maximum (Includes #1 - #35)
Diagram
Number
1 3200350 1 Flushing Valve Block Assembly 22 3200349 1 Restrictor, 3/8" O-Ring to 3/8" Male JIC
2 2500678 2 Vibration Isolator, 3/8"-16 23 6040255 1 Hose Assembly, 3/8" HP
3 6040253 1 Valve Block Platform 24 3200271 1 Elbow, 3/8" O-Ring to 3/8" Male JIC
4 2900014 2 Flat Washer, 3/8" SAE 25 3200328 1 Flow Meter
5 2900006 2 Lock Washer, 3/8" Split 26 3200228 1 Pressue Gauge
6 2900033 2 Hex Nut, 3/8"-16 27 3200036 1 Elbow, 3/4" Male Pipe
7 2900019 1 Capscrew, Hex Hd., 5/16"-18 x 3/4" 28 3200112 1 Elbow, 1" O-Ring to 3/4" Male JIC
8 2900031 3 Lock Washer, 5/16" Split 29 3200417 1 Elbow, 3/4" Female to 3/4" Male JIC
9 2900022 3 Flat Washer, 5/16" SAE 30 3200424 1 Adapter, 3/4" O-Ring to 3/4" Female JIC
10 2900289 2 Capscrew, Hex Hd., 5/16"-18 x 2-1/4" 31 3200351 1 Filter, High Pressure
Part
No.
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
11 3200298 1 Elbow, 3/4" O-Ring to 1/2" Male JIC 3200352 1 (Replacement Element)
12 6040254 1 Hose Assembly, 1/2" PL 32 3200510 1 Elbow, 3/4" O-Ring to 3/4" Female Pipe
13 3200138 3 Adapter, 1" O-Ring to 3/4" Female Pipe 33 3200329 1 Check Valve, 3/4" NPT
14 3200137 5 Hex Nipple, 3/4" NPT 34 3200324 3 Coupler, 3/4" QD (FFM) 5,000 PSI
15 3200512 2 Dust Cap 35 3200325 3 Nipple, 3/4" QD (FF)
16 3200100 1 Coupler, 3/4" QD (NS) 2,500 PSI 36 3200345 2 Hose Assembly, 3/4" x 48" HP
17 3200101 1 Nipple, 3/4" QD (NS) 37 3200346 2 Hose Assembly, 3/4" x 16" HP
18 3200310 1 Tee, 3/4" Female to 3/4" Male Pipe Run 38 (REF) 1 Sauer Pump
19 3200071 1 Reducer, 3/4" Male to 3/8" Female Pipe 39 (REF) 1 VOAC Motor
20 3200109 1 Adapter, 3/8" O-Ring to 3/8" Male Pipe 40 (REF) 1 Steering Support Brace
21 3200435 1 Pressure Relief Valve 2,500 PSI 41 (REF) 1 Manifold, Case Drain
Page 26
26
Page 27
__________________________________
27
CC8000 Parts List
Drawing 11
Slot Cutter Attachment
__________________________________
Part #6040294 Slot Cutter Attachment with Splined Shaft Motor
Diagram
Number
1 2600315 1 VOAC Motor with Splined Shaft 33 6040124 1 Inner Flange, 7"
2 2900139 4 Capscrew, Hex Hd., 1/2"-13 x 1-3/4" 34 6040125 1 Outer Flange, 7"
3 2900084 17 Lock Washer, 1/2" Split 35 2900406 1 Flat Washer, 1-3/4" USS
4 3200248 2 Flange Kit, 3/4" Split (Includes #5 - #7) 36 2900402 1 Lock Washer, 1-3/4" Split
5 3200338 4 Flange Half, 3/4" Split 37 2900401 1 Jam Nut, 1-3/4"-12
6 3200339 2 O-Ring, 3/4" Split Flange 38 6040116 2 Drive Pin, 3/8" Dia. X 28" Long
7 2900006 16 Lock Washer, 3/8" Split 39 6040293 1 Blade Guard, 24" Capacity
8 2900375 8 Capscrew, Hex Hd., 3/8"-16 x 4-1/2" 40 2900196 4 Capscrew, Hex Hd., 3/8"-16 x 3/4"
9 3200520 1 Hose Assembly, 3/4" x 75" HP 41 2900014 12 Flat Washer, 3/8" SAE
10 3200519 1 Hose Assembly, 3/4" x 80" HP 42 6040099 1 Splash Flap
11 2900025 4 Capscrew, Hex Hd., 1/2"-13 x 1-1/4" 43 2900144 7 Capscrew, Hex Hd., 1/4"-20 x 3/4"
12 2900009 6 Flat Washer, 1/4" SAE 44 6040111 1 Cylinder Attachment
13 2900013 8 Capscrew, Hex Hd., 3/8"-16 x 1-1/4" 45 2900010 7 Lock Nut, 1/4"-20 Nylon
14 3200287 1 Adapter, 5/8" O-Ring to 1/2" Male JIC 46 2500177 1 Cylinder, 2"
15 6040399 1 Hose Assembly, 1/2" x 130" PL 47 6010031 1 Cylinder Pin, 3"
16 6040289 1 Pivot Frame Weldment, 24" Blades 48 2900064 4 Hair Pin Cotter, 3/4"
17 2500787 3 Pillow Block Bearing, 1-5/8" 49 6010119 1 Cylinder Pin, 3-1/2"
18 6040097 1 Bearing Spacer, 5/8" 50 2900184 1 Grease Fitting, 1/4"-28 x 45°
19 2501500 1 Motor Coupling, 14 Tooth Spline Bore 51 3200057 2 Elbow, 1/4" Male Pipe to 1/4" Male JIC
20 2500960 1 Coupling Spider Insert 52 6040109 2 Hose Assembly, 1/4" x 14" HP
21 2500959 1 Shaft Coupling, 1-3/4" 53 3200314 1 Nipple, 1/8" QD
22 6040095 1 Motor Adapter 54 3200315 1 Coupler, 1/8" QD
23 2900105 3 Capscrew, Hex Hd., 1/2"-13 x 2-3/4" 55 6040106 1 Water Manifold Pipe
24 2400150 1 Handle 56 6040107 2 Manifold Bar
25 2900088 2 Capscrew, Soc. Hd., 1/4"-20 x 1" 57 2900024 4 Lock Washer, 1/4" Split
26 2500658 1 Flange Cartridge Bearing, 1-3/4" 58 2900241 2 U-Bolt, 1/4"-20
27 2900106 4 Capscrew, Hex Hd., 1/2"-13 x 2" 59 3200153 1 Pipe Plug, 3/8" NPT
28 2900058 4 Flat Washer, 1/2" SAE 60 3200050 9 Spray Nozzle, 1/8" NPT
29 6040288 1 Blade Shaft, 1-3/4" 61 3200209 1 Elbow, 1/2" Female Pipe
30 6048097 1 Key, 3/8" Sq. x 1-3/4" 62 3200155 1 Fitting, 1/2" Male Pipe to 3/4" Male Garden Hose
31 2900203 1 Dowel Pin, 3/8" x 3" 63 6010021 1 Water Hose Assembly, 42" Long
32 6010138 1 Key, 3/8" Sq. x 7/8" 64 2900080 2 Capscrew, Hex Hd., 1/2"-13 x 3-1/2"
Part
No.
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
Page 28
28
Page 29
__________________________________
29
CC8000 Parts List
Drawing 12
Hydraulic Circuit Schematic
__________________________________
Diagram
Number
1 6040021 1 Hydraulic Reservoir Tank 13 3200259 1 Oil Cooler (Air)
2 2600295 1 Sauer Pump 14 3200505 1 Return Filter Head
3 2600315 1 VOAC Motor with Splined Shaft 3200502 1 Filter Pressure Gauge
4 3200262 1 Oil Cooler (Water) 16 3200350 1 Optional Flushing Valve Block Assembly
5 2600212 1 Oilgear Pump 17 3200100 1 Coupler, 3/4" QD (NS) 2,500 PSI
6 2600213 1 Wheel Drive Motor 18 3200101 1 Nipple, 3/4" QD (NS)
7 3200257 1 Valve, 4 Way Solenoid 19 3200435 1 Pressure Relief Valve 2,500 PSI
Part
No.
2702208 1 (Pump Filter Element, Spin-On) 3200486 1 Filter Element, Spin-On
2600203 1 VOAC Motor with Keyed Shaft 15 3200261 1 Suction Strainer
2701964 2 (Valve Coil Only) 20 3200349 1 Restrictor, 3/8" O-Ring to 3/8" Male JIC
Qty.
Reg.
Description
Diagram
Number
Part
No.
Qty.
Reg.
Description
8 3200258 1 Valve, Cylinder Lock 21 3200328 1 Flow Meter
9 3200056 2 Flow Control Valve 22 3200228 1 Pressure Gauge
10 2500896 1 Cylinder 23 3200351 1 Filter, High Pressure
2500278 1 (Seal Kit) 3200352 1 (Replacement Element)
11 2600222 1 Steering Control Unit 24 3200329 1 Check Valve, 3/4" NPT
12 2600223 1 Steering Motor 25 3200324 1 Coupler, 3/4" QD (FFM) 5,000 PSI
26 3200325 1 Nipple, 3/4" QD (FF)
Page 30
30
Page 31
________________________
31
CC8000 Parts List
Drawing 13
Wiring Diagram
________________________
Diagram
Number
1 2700783 1 Ignition Switch 15 2800146 2 Connector, 2 Wire Tower
2 2700208 1 Battery, 12 Volt 2800174 4 Cable Seal, Gray
3 2800073 1 Battery Cable, Positive (Red) 16 2800144 3 Relay
4 2800072 1 Battery Cable, Negative (Black) 2800263 3 Relay Connector
5 2702274 1 Starting Motor (Includes #6) 17 2800461 1 Emergency Stop Button
6 2701823 1 Solenoid Switch 2800462 1 Contact Block N.C.
7 2800387 1 Circuit Breaker, 25 Amp 18 2800388 1 Fuse Panel, 6 Circuit
Part
No.
2701261 1 Ignition Key 2800115 4 Female Terminal, 14/16 Gage Wire
2800182 1 Ground Cable, Negative (Black) 2800264 12 Wire Terminal, 1/4" Push-on
2800364 1 Circuit Breaker Boot, Red 2800389 6 Fuse, 10 Amp Red ATO/ATC
Qty.
Req.
Description
Diagram
Number
Part
No.
Qty.
Req.
Description
8 2800376 1 Connector Housing 19 2701745 1 Oil Cooler Fan Motor Assembly
2800377 6 Terminal, 14/16 Gage Wire 20 2702329 1 Pump Neutral Start Switch (NC)
9 2702333 1 Engine Temperature Gauge 21 2800372 1 Pushbutton Switch, Raise
10 2700785 1 Alternator Light 22 2800373 1 Pushbutton Switch, Lower
2700923 1 (Bulb Only) 23 3200257 1 Valve, 4 Way Solenoid
11 2700786 1 Oil Pressure Light 2701964 2 (Valve Coil Only)
2700923 1 (Bulb Only) 24 6010416 1 Tach/Hour Meter
12 2700787 1 Oil Temperature Light 2800267 1 Light Bulb, Wedge Base
2700923 1 (Bulb Only) 25 2800169 1 Magnetic Sensor (Includes #14)
13 2500761 1 Seat 26 2500194 2 Spot Light, 12 Volt
14 2800145 2 Connector, 2 Wire Shroud 27 2800062 2 Toggle Switch
2800114 4 Male Terminal, 14/16 Gage Wire 2800063 2 Switch Boot
2800174 4 Cable Seal, Gray 28 2600200 1 Optional Water Pump, Diaphragm
Page 32
10
32
11
Optional Angle Cutting Arm Assembly #6040159
2
1
3
5
6
4
9
8
5
7
27
26
25
23
24
3
15
22
12
13
14
15
21
17
20
19
17
16
18
Page 33
Optional Angle Cutting Arm Assembly #6040159
33
ITEM PART NO. QTY. DESCRIPTION
1 3200314 1 Nipple, 1/8" Quick Disconnect
2 3200315 1 Coupler, 1/8" Quick Disconnect
3 6040115 2 Hose Assembly 1/4" x 22" HP
4 3201663 2 Elbow, 1/4" M. Pipe to 1/4" M. JIC (45 deg)
5 2900064 2 Hair Pin Cotter, 3/4"
6 6010031 1 Cylinder Pin, 1" Dia. x 3" Long
7 2900002 3 Flat Washer, 5/8" SAE
8 2900113 1 Lock Washer, 5/8" Split
9 2900164 1 Cap Screw, Flange Hd., 5/8-11 x 1-1/2"
10 2900546 1 2 1/2" - 4 Hex Nut
11 2900350 1 2 1/2" Lock Washer Split
12 6040161 1 Angle Arm Mount Weldment
13 2900365 4 Lock Washer, 1" Split
14 2900370 4 1" - 8 x 3" Hex HD Capscrew
15 2500746 2 Bearing, 2" Innsert
16 2900026 2 1/2"-13 Jam Nut
17 2900058 4 1/2 FLAT WASHER
18 6040162 1 Angle Arm Weldment
19 2900307 1 Wing Screw, M6 x 16mm
20 2500211 1 Wrench, 15/16" Open End
21 2900433 1 Clevis Pin, 1" x 4"
22 2900440 1 Cotter Pin, 3/16" x 1-1/2"
23 6040009 1 Pivot Shaft
24 2900376 2 Cap Screw, Hex Head., 1/2-13 x 7"
25 6040160 1 Angle Arm Clevis
26 2501145 1 Hydraulic Cylinder
27 2900184 1 Grease Fitting, 1/4" NPT x 45 degree
Page 34
34
Page 35
RIDER SAW DUST COLLECTOR
35
PART NO. 6040135
ITEM
PART #.
1 6040134 1 FRAME EXTENSION
2 6040271 1 RUBBER 1/8” THK. x 6” WIDE x 8-1/2” LG.
3 2900008 7 ¼-20 x 1” LG. HEX HD. CAP SCREW
4 2900005 7 3/8-16 X 1” HEX HD. CAP SCREW
5 2900014 10 3/8” FLATWASHER, SAE
6 2900018 2 3/8-16 LOCK NUT, NYLON
7 2501201 1 DUST KOP CYCLONE COLLECTOR
8 6040145 1 BLADE GUARD
9 6040146 1 6” ELBOW, 90 DEGREE, 11 GA. ST’L.
10 2900083 3 ¼” FENDER WASHER
11 6040205 1 HOSE. 6” I.D. X 48” LONG
12 2501239 2 CLAMP, HOSE, 3-5/8-6-1/2” DIA.
13 3200422 1 1/2” MJIC TO 5/8”M. O-RING ELBOW, 45°
14 3200285 1 ½” M. O-RING TO ½” MJIC ELBOW, 90°
15 6040148 1 MOUNTING BRKT. FOR HYD. SEL. VALVE
16 3200434 1 HYDRAULIC SELECTOR VALVE, 3-WAY
17 2600291 1 HYDRAULIC MOTOR, .37 C.I.
18 2500686 2 BEARING, 50mm X 90mm X 20mm
19 6048018 1 KEY, 3/16 X ¾” LONG
20 6040136 1 SHAFT FOR HYD. MOTOR TO FAN
21 6040139 2 SPACER, 3.539 OD x 3.270 ID x .250 W
22 2900459 1 1.875 O.D. X 1.156 I.D. X .125 THK., WASH
23 2501276 1 1-1/8” RETAINING RING, EXTERNAL
24 6040153 1 HOSE ASSEMBLY, ½” x 133” HP
25 6040154 1 HOSE ASSEMBLY, ½” x 102” HP
26 6040137 1 PILLOW BLOCK
27 6010169 1 KEY, ¼” x 1-1/4” LONG
28 6040140
29 3200435 1 PRESSURE RELIEF VALVE, 2600 PSI
30 6040155 1 HOSE ASSEMBLY, ½” X 67” HP
31 6040156 2 HOSE ASSEMBLY, ½” X 47” HP
32 6040157 1 HOSE ASSEMBLY, ½” X 40” HP
33 6040158 1 HOSE ASSEMBLY, 3/8” X 21” HP
34 3200266 1 3/8” M. O-RING TO ½” MJIC ADAPTER
35 2600365 1 HYD. PUMP
36 2501270 1 V BELT GUARD
37 3200367 2 ½” M. O-RING TO ½” M. JIC ELBOW, 45°
38 2900009 9 ¼” FLAT WASHER, SAE
39 3200332 3 ½” MJIC x ½” FJIC SWIVEL NUT RUN TEE
QTY DESCRIPTION
PILLOW BLOCK ASSEMBLY,
1
INCLUDES 18, 20-23,26
ITEMS 4, 5, 51, 56 & 58-77 ARE IN
AUXILIARY PUMP ASSEMBLY 6010337
ITEM
PART #. QTY DESCRIPTION
40 3200304 4 ½” MJIC x ½” FJIC ELBOW, 90°
41 6040172 1 HOSE ASSEMBLY, ¾” X 24” LP
42 2900010 7 ¼-20 LOCK NUT, NYLON
43 2900289 2 5/16-18 x 2-1/4” HEX HD. CAP SCREW
44 2900039 8 5/16-18 LOCKNUT, NYLON
45 2900217 2 5/16-18 x 1-1/4” HEX HD. CAPSCREW
46 2900139 4 ½-13 x 1-3/4” HEX HD. CAP SCREW
47 2900127 4 ½” FLAT WASHER, USS
48 2900026 4 ½” LOCKNUT, NYLON
49 6040025 1 BLADE GUARD BRACE
50 2703093 1 O-RING, 3-3/8 x .062”
51 2900006 7 3/8” LOCKWASHER, SPLIT
52 2900279 1 LANYARD WITH LOCKPIN
53 3200298 2 ½” MJIC TO ¾”M. O-RING ELBOW, 90°
54 3200400 1 3/4” M O-RING TO 3/4”MJIC ELBOW, 90°
55 3200495 1 1” FJIC TO 3/4” MJIC REDUCER
56 3200116 1 1/4” M. O-RING TO 3/8” MJIC ELBOW
57 3200487 1 1” JIC SWIVEL NUT RUN T
58 3200271 1 3/8” M. O-RING TO 3/8” MJIC ELBOW
59 2600070 1 HYD. PUMP (INCLUDES #60 - #63)
60 2700321 1 BREATHER CAP, 3/8 NPT
61 2701815 1 DIPSTICK
62 2700169 1 SOLENOID, MOTOR
63 2700243 1 VALVE COIL
2700244 1 VALVE STEM
64 6010398 1 WIRE COVER, 3/8” ID X 70”
65 6040276 1 HOSE ASSEMBLY, 3/8” X 63” HP
66 6040275 1 HOSE ASSEMBLY, 3/8” X 54” HP
67 2800068 10 WIRE TIE, 7-1/2”, WHITE
68 6010394 1 WIRE ASSY., 14 GAGE, RED, 12”
69 2800513 1 RED BATTERY CABLE 90”
70 2800514 1 BLACK BATTERY CABLE 90”
71 6010397 2 WIRE COVER, 3/8” ID X 10”
72 6010396 1 WIRE ASSY., 14 GAGE, GREEN, 72”
73 2800368 1 RECTIFIER/DIODE
74 2900211 1 #10-32 x 1-1/4 RD HD SCREW
75 2900038 1 #10 LOCK WASHER
76 2900188 1 #10-32 HEX. NUT
77 6010395 1 WIRE ASSY., 14 GAGE,WHITE, 72”
HOSES 24, 25, 30-33, & 41
ARE IN KIT 6040277
Page 36
36
Page 37
RIDER SAW DUST COLLECTOR
37
PART NO. 6040135
ITEM
PART #.
1 6040134 1 FRAME EXTENSION
2 6040271 1 RUBBER 1/8” THK. x 6” WIDE x 8-1/2” LG.
3 2900008 7 ¼-20 x 1” LG. HEX HD. CAP SCREW
4 2900005 7 3/8-16 X 1” HEX HD. CAP SCREW
5 2900014 10 3/8” FLATWASHER, SAE
6 2900018 2 3/8-16 LOCK NUT, NYLON
7 2501201 1 DUST KOP CYCLONE COLLECTOR
8 6040145 1 BLADE GUARD
9 6040146 1 6” ELBOW, 90 DEGREE, 11 GA. ST’L.
10 2900083 3 ¼” FENDER WASHER
11 6040205 1 HOSE. 6” I.D. X 48” LONG
12 2501239 2 CLAMP, HOSE, 3-5/8-6-1/2” DIA.
13 3200422 1 1/2” MJIC TO 5/8”M. O-RING ELBOW, 45°
14 3200285 1 ½” M. O-RING TO ½” MJIC ELBOW, 90°
15 6040148 1 MOUNTING BRKT. FOR HYD. SEL. VALVE
16 3200434 1 HYDRAULIC SELECTOR VALVE, 3-WAY
17 2600291 1 HYDRAULIC MOTOR, .37 C.I.
18 2500686 2 BEARING, 50mm X 90mm X 20mm
19 6048018 1 KEY, 3/16 X ¾” LONG
20 6040136 1 SHAFT FOR HYD. MOTOR TO FAN
21 6040139 2 SPACER, 3.539 OD x 3.270 ID x .250 W
22 2900459 1 1.875 O.D. X 1.156 I.D. X .125 THK., WASH
23 2501276 1 1-1/8” RETAINING RING, EXTERNAL
24 6040153 1 HOSE ASSEMBLY, ½” x 133” HP
25 6040154 1 HOSE ASSEMBLY, ½” x 102” HP
26 6040137 1 PILLOW BLOCK
27 6010169 1 KEY, ¼” x 1-1/4” LONG
28 6040140
29 3200435 1 PRESSURE RELIEF VALVE, 2600 PSI
30 6040155 1 HOSE ASSEMBLY, ½” X 67” HP
31 6040156 2 HOSE ASSEMBLY, ½” X 47” HP
32 6040157 1 HOSE ASSEMBLY, ½” X 40” HP
33 6040158 1 HOSE ASSEMBLY, 3/8” X 21” HP
34 3200266 1 3/8” M. O-RING TO ½” MJIC ADAPTER
35 2600365 1 HYD. PUMP
36 2501270 1 V BELT GUARD
37 3200367 2 ½” M. O-RING TO ½” M. JIC ELBOW, 45°
38 2900009 9 ¼” FLAT WASHER, SAE
39 3200332 3 ½” MJIC x ½” FJIC SWIVEL NUT RUN TEE
QTY DESCRIPTION
PILLOW BLOCK ASSEMBLY,
1
INCLUDES 18, 20-23,26
ITEMS 4, 5, 51, 56 & 58-77 ARE IN
AUXILIARY PUMP ASSEMBLY 6010337
ITEM
PART #. QTY DESCRIPTION
40 3200304 4 ½” MJIC x ½” FJIC ELBOW, 90°
41 6040172 1 HOSE ASSEMBLY, ¾” X 24” LP
42 2900010 7 ¼-20 LOCK NUT, NYLON
43 2900289 2 5/16-18 x 2-1/4” HEX HD. CAP SCREW
44 2900039 8 5/16-18 LOCKNUT, NYLON
45 2900217 2 5/16-18 x 1-1/4” HEX HD. CAPSCREW
46 2900139 4 ½-13 x 1-3/4” HEX HD. CAP SCREW
47 2900127 4 ½” FLAT WASHER, USS
48 2900026 4 ½” LOCKNUT, NYLON
49 6040025 1 BLADE GUARD BRACE
50 2703093 1 O-RING, 3-3/8 x .062”
51 2900006 7 3/8” LOCKWASHER, SPLIT
52 2900279 1 LANYARD WITH LOCKPIN
53 3200298 2 ½” MJIC TO ¾”M. O-RING ELBOW, 90°
54 3200400 1 3/4” M O-RING TO 3/4”MJIC ELBOW, 90°
55 3200495 1 1” FJIC TO 3/4” MJIC REDUCER
56 3200116 1 1/4” M. O-RING TO 3/8” MJIC ELBOW
57 3200487 1 1” JIC SWIVEL NUT RUN T
58 3200271 1 3/8” M. O-RING TO 3/8” MJIC ELBOW
59 2600070 1 HYD. PUMP (INCLUDES #60 - #63)
60 2700321 1 BREATHER CAP, 3/8 NPT
61 2701815 1 DIPSTICK
62 2700169 1 SOLENOID, MOTOR
63 2700243 1 VALVE COIL
2700244 1 VALVE STEM
64 6010398 1 WIRE COVER, 3/8” ID X 70”
65 6040276 1 HOSE ASSEMBLY, 3/8” X 63” HP
66 6040275 1 HOSE ASSEMBLY, 3/8” X 54” HP
67 2800068 10 WIRE TIE, 7-1/2”, WHITE
68 6010394 1 WIRE ASSY., 14 GAGE, RED, 12”
69 2800513 1 RED BATTERY CABLE 90”
70 2800514 1 BLACK BATTERY CABLE 90”
71 6010397 2 WIRE COVER, 3/8” ID X 10”
72 6010396 1 WIRE ASSY., 14 GAGE, GREEN, 72”
73 2800368 1 RECTIFIER/DIODE
74 2900211 1 #10-32 x 1-1/4 RD HD SCREW
75 2900038 1 #10 LOCK WASHER
76 2900188 1 #10-32 HEX. NUT
77 6010395 1 WIRE ASSY., 14 GAGE,WHITE, 72”
HOSES 24, 25, 30-33, & 41
ARE IN KIT 6040277
Page 38
38
Page 39
RIDER SAW DUST COLLECTOR
39
PART NO. 6040135
ITEM
PART #.
1 6040134 1 FRAME EXTENSION
2 6040271 1 RUBBER 1/8” THK. x 6” WIDE x 8-1/2” LG.
3 2900008 7 ¼-20 x 1” LG. HEX HD. CAP SCREW
4 2900005 7 3/8-16 X 1” HEX HD. CAP SCREW
5 2900014 10 3/8” FLATWASHER, SAE
6 2900018 2 3/8-16 LOCK NUT, NYLON
7 2501201 1 DUST KOP CYCLONE COLLECTOR
8 6040145 1 BLADE GUARD
9 6040146 1 6” ELBOW, 90 DEGREE, 11 GA. ST’L.
10 2900083 3 ¼” FENDER WASHER
11 6040205 1 HOSE. 6” I.D. X 48” LONG
12 2501239 2 CLAMP, HOSE, 3-5/8-6-1/2” DIA.
13 3200422 1 1/2” MJIC TO 5/8”M. O-RING ELBOW, 45°
14 3200285 1 ½” M. O-RING TO ½” MJIC ELBOW, 90°
15 6040148 1 MOUNTING BRKT. FOR HYD. SEL. VALVE
16 3200434 1 HYDRAULIC SELECTOR VALVE, 3-WAY
17 2600291 1 HYDRAULIC MOTOR, .37 C.I.
18 2500686 2 BEARING, 50mm X 90mm X 20mm
19 6048018 1 KEY, 3/16 X ¾” LONG
20 6040136 1 SHAFT FOR HYD. MOTOR TO FAN
21 6040139 2 SPACER, 3.539 OD x 3.270 ID x .250 W
22 2900459 1 1.875 O.D. X 1.156 I.D. X .125 THK., WASH
23 2501276 1 1-1/8” RETAINING RING, EXTERNAL
24 6040153 1 HOSE ASSEMBLY, ½” x 133” HP
25 6040154 1 HOSE ASSEMBLY, ½” x 102” HP
26 6040137 1 PILLOW BLOCK
27 6010169 1 KEY, ¼” x 1-1/4” LONG
28 6040140
29 3200435 1 PRESSURE RELIEF VALVE, 2600 PSI
30 6040155 1 HOSE ASSEMBLY, ½” X 67” HP
31 6040156 2 HOSE ASSEMBLY, ½” X 47” HP
32 6040157 1 HOSE ASSEMBLY, ½” X 40” HP
33 6040158 1 HOSE ASSEMBLY, 3/8” X 21” HP
34 3200266 1 3/8” M. O-RING TO ½” MJIC ADAPTER
35 2600365 1 HYD. PUMP
36 2501270 1 V BELT GUARD
37 3200367 2 ½” M. O-RING TO ½” M. JIC ELBOW, 45°
38 2900009 9 ¼” FLAT WASHER, SAE
39 3200332 3 ½” MJIC x ½” FJIC SWIVEL NUT RUN TEE
QTY DESCRIPTION
PILLOW BLOCK ASSEMBLY,
1
INCLUDES 18, 20-23,26
ITEMS 4, 5, 51, 56 & 58-77 ARE IN
AUXILIARY PUMP ASSEMBLY 6010337
ITEM
PART #. QTY DESCRIPTION
40 3200304 4 ½” MJIC x ½” FJIC ELBOW, 90°
41 6040172 1 HOSE ASSEMBLY, ¾” X 24” LP
42 2900010 7 ¼-20 LOCK NUT, NYLON
43 2900289 2 5/16-18 x 2-1/4” HEX HD. CAP SCREW
44 2900039 8 5/16-18 LOCKNUT, NYLON
45 2900217 2 5/16-18 x 1-1/4” HEX HD. CAPSCREW
46 2900139 4 ½-13 x 1-3/4” HEX HD. CAP SCREW
47 2900127 4 ½” FLAT WASHER, USS
48 2900026 4 ½” LOCKNUT, NYLON
49 6040025 1 BLADE GUARD BRACE
50 2703093 1 O-RING, 3-3/8 x .062”
51 2900006 7 3/8” LOCKWASHER, SPLIT
52 2900279 1 LANYARD WITH LOCKPIN
53 3200298 2 ½” MJIC TO ¾”M. O-RING ELBOW, 90°
54 3200400 1 3/4” M O-RING TO 3/4”MJIC ELBOW, 90°
55 3200495 1 1” FJIC TO 3/4” MJIC REDUCER
56 3200116 1 1/4” M. O-RING TO 3/8” MJIC ELBOW
57 3200487 1 1” JIC SWIVEL NUT RUN T
58 3200271 1 3/8” M. O-RING TO 3/8” MJIC ELBOW
59 2600070 1 HYD. PUMP (INCLUDES #60 - #63)
60 2700321 1 BREATHER CAP, 3/8 NPT
61 2701815 1 DIPSTICK
62 2700169 1 SOLENOID, MOTOR
63 2700243 1 VALVE COIL
2700244 1 VALVE STEM
64 6010398 1 WIRE COVER, 3/8” ID X 70”
65 6040276 1 HOSE ASSEMBLY, 3/8” X 63” HP
66 6040275 1 HOSE ASSEMBLY, 3/8” X 54” HP
67 2800068 10 WIRE TIE, 7-1/2”, WHITE
68 6010394 1 WIRE ASSY., 14 GAGE, RED, 12”
69 2800513 1 RED BATTERY CABLE 90”
70 2800514 1 BLACK BATTERY CABLE 90”
71 6010397 2 WIRE COVER, 3/8” ID X 10”
72 6010396 1 WIRE ASSY., 14 GAGE, GREEN, 72”
73 2800368 1 RECTIFIER/DIODE
74 2900211 1 #10-32 x 1-1/4 RD HD SCREW
75 2900038 1 #10 LOCK WASHER
76 2900188 1 #10-32 HEX. NUT
77 6010395 1 WIRE ASSY., 14 GAGE,WHITE, 72”
HOSES 24, 25, 30-33, & 41
ARE IN KIT 6040277
Page 40
6040338 STROBE LIGHT ASSEMBLY
40
8
10
11
10
9
MAST 1 REPLACES CURRENT
LIGHT EXTENSION BAR, 6040138.
12
CUT WIRES AT STROBE TO ~4" . STRIP
AND ATTACH ITEMS 8, 10, & 11.
4
1
3
STRIP CORD 3 AND ATTACH ITEMS 9, 10, &12.
CRIMP ITEM 14 TO WHITE WIRE OF CORD.
CRIMP ITEM 13 TO BLACK WIRE OF CORD.
SECURE CORD 3 TO BRACKET WITH ITEM 4.
MOUNT ITEM 5 TO HOLE IN GAUGE PANEL.
ATTACH CORD TO SWITCH (14)
AND GROUND (13).
ATTACH WIRE 7 TO SWITCH AND
FUSE PANEL (NOT SHOWN).
13
14
SPOTLIGHT 2500194 CAN NOW BE
5
RELOCATED DIRECTLY TO THE MAST.
6
7
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 6040147
2 2800398
3 6010933 Cord, 18 Ga., x 2 Wire, 2' Coiled 1
4 2800068
5 2800062
6 2800063 Switch Boot 1
7 6041165
8 2800145 Connector, 2 Wire Shroud 1
9 2800146 Connector, Tower 2 Wire 1
10 2800440 Cable Seal 4
11 2800441
12 2800442
13 2800597
14 2800598
Wire Assy., 16 Ga., x 24"
20-18 Gage Male Terminal
20-18 Gage Female Terminal
22-18 Gage Terminal Ring, 1/4"
22-18 Gage Push On, Female
Light Mast
Strobe Light
Tie Wrap, 7-1/2"
Toggle Switch On/Off
1
1
2
1
1
2
2
1
1
Page 41
6010447 CC8000 TILLER STEERING OPTION
41
17
1614
15
4
14
9
513
3
A
8
7
14
18
DETAIL A
SCALE 1 : 2
MOUNTS OVER DRIVE
WHEEL,REPLACES
HYDRAULIC STEER MOTOR.
ITEM NO. PART NUMBER QTY. DESCRIPTION
1 6010453 1 Tiller Steer Weldment
2 2501638 1 Bearing, 1" Flanged, 2-Bolt
3 6010454 1 Tiller Steering Weldment
4 6010455 1 Bar, 3/4 x1 x 22-1/2"
5 2900234 1 Hand Lock Knob, 3/8"-16
6 2701901 1 Key, Woodruff, 1/4 x 1.0 Dia.
7 2900022 2 Flat Washer, 5/16" SAE
8 2900031 2 Lock Washer, 5/16" Split
9 2900138 2 Cap Screw, Hex Hd., 5/16-18 x 1"
10 2900014 4 Flat Washer, 3/8" SAE
11 2900006 4 Lock Washer, 3/8" Split
12 2900013 4 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
13 2505085 1 Machine Handle, Revolving
14 2900058 6 Flat Washer, 1/2" SAE
15 6010463 2 Spacer Tube, 3/4 OD x 13 Gage
16 2900084 2 Lock Washer, 1/2" Split
17 2900395 2 Cap Screw, Hex Hd., 1/2-13 x 5"
18 2900037 2 Hex Nut, 1/2-13
11
10
2
12
THIS SURFACE
TO REAR.
6
DETAIL B
SCALE 1 : 2
1
B
Page 42
__________________________________
42
CC8000 Parts List
Drawing 14
Decal Group
__________________________________
CORE CUT DECAL
#1800443 (Qty 3)
INSTRUMENT PANEL DECAL WARNING DECAL
#1800348 #1800001 (Qty 3)
SAW LABELS SHEET
#1800351
Page 43
___________________________________________________________________________________
43
Blade Speed (RPM) Chart
Model CC8000 Rider Concrete Saw
____________________________________________________________________
WARNING: Do not exceed blade shaft speed (RPM) shown for each blade size.
Excessive blade speed control could result in blade breakage and serious
personal injury.
Blade Size No Load RPM Max. Depth of Cut
14" 3000 3-3/4"
20" 2450 6-3/4"
26" 1950 9-3/4"
30" 1650 11-3/4"
36" 1400 14-3/4"
42" 1050 16-3/4"
48" 850 19-3/4"
54" 775 22-3/4"
WARNING: When changing blade size, use chart shown below for selecting items
that must be changed.
Blade Size Blade Guard Assembly Inner Flange (Flange Size) Outer Flange (Flange Size)
14" 6010070 6010038 (6") 6010039 (6")
20" 6010072 6010038 (6") 6010039 (6")
26" 6010074 6010038 (6") 6010039 (6")
30" 6010076 6010038 (6") 6010039 (6")
36" 6010260 6010038 (6") 6010039 (6")
42" 6010143 6013017 (8") 6013018 (8")
48" 6010145 6013017 (8") 6013018 (8")
54" 6010183 6013017 (8") 6013018 (8")
Page 44
EQUIPMENT AND PARTS
WARRANTY
Diamond Products warrants all equipment manufactured by it against defects
in workmanship or materials for a period of one (1) year from the date of
shipment to Customer.
The responsibility of Diamond Products under this Warranty is limited to
replacement or repair of defective parts at Diamond Products’ Elyria, Ohio
factory, or at a point designated by it, of such parts as shall appear to us upon
inspection at such parts, to have been defective in material or workmanship,
with expense for transportation and labor borne by Customer.
In no event shall Diamond Products be liable for consequential or
incidental damages arising out of the failure of any Product to operate properly.
Integral units such as engines, electric motors, batteries, transmissions,
etc., are excluded from this Warranty and are subject to the prime
manufacturer’s warranty.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, AND ALL SUCH OTHER WARRANTIES ARE HEREBY
DISCLAIMED.
333 Prospect Street, Elyria, Ohio 44035
(440) 323-4616 (800) 321-5336 Fax (440) 323-8689
www.diamondproducts.com
Printed in U.S.A. #1800451
Loading...
