DIAMOND
P R O D U C T S
CONCRETE SAW
PARTS LIST
MODEL
CC6560XLS
July 2011
Part #1800821
2
Table of Contents
.
.
.
…
…
…
.
.
…
…
…
…
…
.
3
Pictorial Index…………….….……………
Controls Legend…….…….….……………
4,5 Engine Assembly……………………………..40,41
6 Muffler Assembly…………………………….42
Quick Reference Service Filters / Belts……7 Pointer Stop Assembly………………………. 43
Frame Upright Assembly……….…………
8,9 4” PTO Assembly……………………..……. 44
Instrument Panel Assembly……………….. 10 Rotary Tensioner Assembly…….…………… 45
Control Grip Assembly…………………….11 Transmission Jackshaft Assembly……………46
Control Lever Assembly (Eaton)…………..12 Throttle Cable Assembly……………………. 47
Control Lever Assembly (Sundstrand)……. 13 Belt Guard Assembly………………………
48
Fuel Supply Assembly….………...………..14 Front Pointer Assembly………………………49
Fuel Tank Assembly………………………. 15 14” Blade Guard Assembly……………….…. 50,51
Battery Assembly…………………………. 16 20” Blade Guard Assembly…….…………….52,53
Hydraulic Pump Assembly……...………… 17 26” Blade Guard Assembly……….…………. 54,55
Depth Indicator Assembly………………… 18 30” Blade Guard Assembly……….………….56,57
Depth Stop Assembly…………………….. 19 36” Blade Guard Assembly……….………….58,59
Water Supply Assembly………………….. 20 Optional Water Pump Assembly………….….60
Air Cleaner Assembly…………………….. 21 Optional Water Safety Switch Assembly…….61
Air Intake Assembly………………………. 22 Optional Spot Light Assembly………………. 62
Frame Lift Assembly……………………… 23 Optional Magnetic Spot Light Assembly…….63
Frame Base Assembly……………………. 24 Optional Glow Plug Assembly……………….64
Hydraulic Cylinder Assembly……………
Rear Drive Assembly (Eaton)…………….. 26,27 Optional Free Wheeling Clutch Assembly…
Eaton Transmission Assembly…………….
Linkage Assembly………………………… 29 Optional Blade Stacking Assembly………….
Rear Drive Assembly (Sundstrand)……….. 30,31 Optional Blade Spacing Assembly…………
Rear Axle Assembly (Eaton / Gear)………. 32 Optional Blade Spacing Assembly…………
Rear Axle Assembly (Sundstrand / Chain)
25 Optional Speed Metering Valve Assembly……65
66,67
28 Optional Parking Brake Assembly……..……. 68,69
70,71
72,73
74,75
33 Optional Side Plunge Assembly………………76,77
Front Axle Assembly………………………34 Optional Oil Bath Blade Shaft Assembly…… 78-81
Front Wheel Assembly……………………. 35 Optional Oil Expansion Tank Assembly……. 82
Blade Shaft Assembly (Blades 14” – 26”)
Blade Shaft Assembly (Blades 30” – 36”)
36 Decal Group……………………………….… 83
37 Wiring Diagram………………………………84,85
Shaft Tach Gear Assembly……….……….. 38 Options Wiring Diagram…………………….. 86
Belt Drive Assembly………………………
39 Blade Speed Conversion Charts………….….. 87
Warranty…………………………….….…….88
Pictorial Page Index
4
49
42
43
47
44
50
52
54
56
58
40
23
20
2122
10
19
18
11
13
15
8
16
3736
39
24
45
34
Shown with Sundstrand Transmission
46
25
33
30
Pictorial Page Index
5
49
43
48
42
40 23
20
21
10
8
15
12
17
16
26
28
24
39
38
36 37
34
Shown with Eaton Transmission
35
32
50 52 54 56 58
Controls Legend
6
1 Engine Temperature Gauge 14 Handle Lock Knobs
1 Engine Temperature Gauge 14 Handle Lock Knobs
2 Ignition Switch 15 Speed Control Lever
2 Ignition Switch 15 Speed Control Lever
3 Alternator Light 16 Lower Pushbutton
3 Alternator Light 16 Lower Pushbutton
4 Oil Temperature Light 17 Raise Pushbutton
4 Oil Temperature Light 17 Raise Pushbutton
5 Oil Pressure Light 18 Fuel Tank Cap
5 Oil Pressure Light 18 Fuel Tank Cap
6 Vernier Throttle Control 19 Transmission Engagement Lever *
6 Vernier Throttle Control 19 Transmission Engagement Lever *
7 Blade Tachometer / Hour Meter 20 Transmission Engagement Lever **
7 Blade Tachometer / Hour Meter 20 Transmission Engagement Lever **
8 Pre-Cleaner 21 Water Safety Switch (Optional)
8 Pre-Cleaner 21 Water Safety Switch (Optional)
9 Air Cleaner Restriction Indicator 22 Spotlight Switch (Optional)
9 Air Cleaner Restriction Indicator 22 Spotlight Switch (Optional)
10 Depth Stop Knob 23 Water Pump Switch (Optional)
10 Depth Stop Knob 23 Water Pump Switch (Optional)
11 Cutting Depth Indicator 24 Lowering Speed Metering Valve (Optional)
11 Cutting Depth Indicator 24 Lowering Speed Metering Valve (Optional)
* For Eaton Transmission Only
12 Water Valve
12 Water Valve
13 Emergency Stop Button
13 Emergency Stop Button
6
8
* For Eaton Transmission Only
** Optional for Sundstrand Transmission Only
** Optional for Sundstrand Transmission Only
9
10
12
2
1
3
14
4
18
5
7
19
17
15
11
23
16
24
21
22
12
13
14
20
Quick Reference Service Filters / Belts
7
DP Part No. Description Manufacturer's Part No.
2701775 Engine Oil Filter (Deutz #1174416)
2701339 Engine Fuel Filter (Deutz #1174482)
2501785 In-Line Fuel Tank Filter (Wix #33007)
2501386 Outer Primary Air Filter (Donaldson #P827653)
2501387 Inner Safety Air Filter (Donaldson #P829332)
2502041 Blade Shaft Belt Set (Gates #5/3VX530)
2502042 Blade Shaft Belt Set (Gates #5/3VX560)
2501779 Sundstrand Transmission Belt (Gates #AX29)
2501946 Eaton Transmission Belt (Gates #AX39)
2501781 Engine to Jackshaft Belt (Gates #AX42)
Frame Upright Assembly #6010715A
8
29
22
18
22
12
13
24
16
22
22
19
11
21
22
26
25
9
8
10
28
23
24
27
11
23
17
14
9
8
10
17
15
5
2
5
6
7
1
3
24
4
7
22
22
20
4
15
Frame Upright Assembly #6010715A
9
ITEM PART NO. QTY. DESCRIPTION
1 6010687 1 Frame Upright Weldment
2 2900013 2 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
3 2900014 2 Flat Washer, 3/8" SAE
4 2900018 2 Lock Nut, 3/8-16 Nylon
5 2900499 4 Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
6 2900058 4 Flat Washer, 1/2" SAE
7 2900026 4 Lock Nut, 1/2-13 Nylon
8 6010014 2 Handle Bar, 36" Long
9 2500636 2 Handle Grip
10 2501955 2 Handle Stop Grip
11 2900430 2 Hand Lock Knob, 1/2-13 x 1-1/2"
12 2501427 1 Rope Cleat
13 2900483 2 Tap Screw, Flat Hd., #10-24 x 1"
14 6010015 1 Rear Cover Screen
15 2900180 4 Cap Screw, Hex Flange Hd., 1/4-20 x 1"
16 6010166 1 Gate Cover Bar
17 2900144 2 Cap Screw, Hex Hd., 1/4-20 x 3/4"
18 2900010 2 Lock Nut, 1/4-20 Nylon
19 2500203 2 Grommet, 3/4" I.D.
20 2501146 1 Plug, 1-1/4" Hole
21 2500549 1 Plug, 7/8" Hole
22 2501287 12 Plug, 7/16" Hole
23 2500462 2 Plug, 3/8" Hole
24 2503749 9 Plug, 5/16" Hole (Tapered)
25 1800169 1 Serial Number Plate, US
26 2900096 2 Rivet, 3/32" Dia.
27 1800377 1 Serial Number Plate, CE
28 2900287 2 Rivet, 1/8" Dia.
29 2503704 1 Wrench, 15/16" Combination
Instrument Panel Assembly #6010716
10
(Includes Items #1, #8 - #21)
19
20
18
10
11
12
13
14
11
89
15
7
2
1
3
4
ITEM PART NO. Q TY. DESCRIPTION
1 6013093 1 Gauge Panel
2 2703192 1 Temperature Gauge, Pricol
3 2703194 1 Ignition Switch & Key
2703195 1 Ignition Key Only, Double Cut
4 2700785 1 Alternator Light
5 2700787 1 Oil Temperature Light
6 2700786 1 Oil Pressure Light
7 2500376 1 Vernier Throttle Cable
8 6010416 1 Tach/Hour Meter (VDO) Calibrated
2800611 2 Light Socket
2800612 2 Light Bulb, Wedge Base
9 2400628 1 O-Ring #152
10 6010019 1 Hydraulic Pump Cover Plate
11 2801367 1 E-Stop Switch
12 2900021 8 Tap Screw, Pan Hd., #10-24 x 3/8"
13 6010098 1 Switch Plate
14 2500204 3 Plug, 1/2" Hole
15 2900445 6 Tap Screw, Flat Hd., #10-24 x 1/2"
16 2500463 1 Plug, 3/4" Hole
17 6010101 2 Edge Trim 8-1/2"
18 2800388 1 Fuse Panel, 6 Circuit
19 2800389 6 Fuse, 10 Amp Red ATO/ATC
20 2900913 2 Cap Screw, Soc. Hd., #10-24 x 1"
21 2900017 2 Lock Nut, #10-24 Nylon
12
6
5
21
15
11
16
17
Control Grip Assembly #6010319
11
1
3
4
6
8
5
9
2
4
7
ITEM PART NO. QTY. DESCRIPTION
1
2
3
4 2500694 2 Plug, 5/8" Hole
5
6
7
8
9 2800393 1 Harness, Hydraulic Pump
2501280 1 Control Grip Body
2501281 1 Control Grip Cover
2500644 1 Plug, Rectangular
2800372 1 Pushbutton Switch, Raise
2800373 1
2900453 1
2900452 1 Machine Screw, Oval Hd., #4 x 5/8"
Pushbutton Switch, Lower
Set Screw, Soc. Hd., M5 x 12mm
Control Lever Assembly #6010719 (Eaton)
12
15
17
5
4
14
16
13
9
4
9
3
2
1
4
18
7
8
9
10
11
5
ITEM PART NO. QTY. DESCRIPTION
1 6010056 1 Lever Support Weldment
2 2501339 1 Rubber Support Mount
3 2900008 2 Cap Screw, Hex Hd., 1/4-20 x 1"
4 2900010 6 Lock Nut, 1/4-20 Nylon
5 2900144 4 Cap Screw, Hex Hd., 1/4-20 x 3/4"
6 6010055 1 Friction Spacer
7 2900018 2 Lock Nut, 3/8-16 Nylon
8 6010314 1 Speed Control Lever
9 2900153 3 Friction Washer, 3/8"
10 2900473 1 Flat Washer, 3/8" USS
11 2900474 4 Belleville Washer, 3/8"
12 2900472 1 Cap Screw, Hex Flange Hd., 3/8-16 x 2"
13 6010057 1 Engagement Lever Weldment
14 2900014 1 Flat Washer, 3/8" SAE
15 2900029 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
16 6010058 1 Gate Plate
17 2500002 1 Lever Grip
18 6010319 1 Control Grip Assembly
7
6
12
5
13
18
Control Lever Assembly #6010720 (Sundstrand)
3
2
4
16
1
7
14
8
15
14
17
6
4
6
4
15
5
6
7
13
19
9
10
11
12
16
6
14
9
ITEM PART NO. QTY. DESCRIPTION
1 6010122 1 Lever Support Weldment
2 2501339 1 Rubber Support Mount
3 2900008 2 Cap Screw, Hex Hd., 1/4-20 x 1"
4 2900010 6 Lock Nut, 1/4-20 Nylon
5 2900144 4 Cap Screw, Hex Hd., 1/4-20 x 3/4"
6 2900018 4 Lock Nut, 3/8-16 Nylon
7 6010055 2 Friction Spacer
8 6010315 1 Speed Control Lever
9 2900153 2 Friction Washer, 3/8"
10 2900473 1 Flat Washer, 3/8" USS
11 2900474 4 Belleville Washer, 3/8"
12 2900472 1 Cap Screw, Hex Flange Hd., 3/8-16 x 2"
13 6010123 1 Linkage Lever
14 2900014 3 Flat Washer, 3/8" SAE
15 2900047 3 Cap Screw, Hex Hd., 3/8-16 x 1-3/4"
16 2500007 2 Set Collar, 1/2" with Set Screw
17
18
19
6010702 1
6010166 1 Gate Cover Bar
6010319 1 Control Grip Assembly
Linkage Assembly 4-1/4"
15
Fuel Supply Assembly #6010699
14
1
6
2
4
3
6
6
7
5
6
ITEM PART NO. QTY. DESCRIPTION
1 2501777 1 Fuel Valve w/Pick-Up
2 2501215 1 Bushing, Rubber, Tank
3 6010693 1 Fuel Supply Hose, 5/16" I.D. x 30"
4 2501785 1
5 6013095 1 Fuel Line Hose, 5/16" I.D. x 4"
6 3200062 4 Hose Clamp #4
7 2501434 1 Hose Clamp, 1/2" x 3/4" Wide
Filter, Diesel Fuel
Fuel Tank Assembly #6010700
15
8
9
7
1
14
14
13
12
10
11
3
2
4
33
6
3
4
6
5
4
4
ITEM PART NO. QTY. DESCRIPTION
1 2501784 1 Fuel Tank
2 6010257 2 Fuel Tank Mount Bar
3 2900022 8 Flat Washer, 5/16" SAE
4 2900031 8 Lock Washer, 5/16" Split
5 2900019 4 Cap Screw, Hex Hd., 5/16-18 x 3/4"
6 2900138 4 Cap Screw, Hex Hd., 5/16-18 x 1"
7 3200206 1 Pipe Plug, 1/4" NPT
8 2504786 1 Fuel Tank Cap & Gauge
9 2500205 1 Fuel Tank Grommet
10 3200057 1 Elbow, 1/4" M. Pipe to 1/4" M. JIC
11 3200091 1 Fitting, 1/4" F. JIC to 1/4" Push Lock
12 6010103 1 Fuel Return Hose, 1/4" I.D. x 32"
13 3200062 1 Hose Clamp #4
14 6010699 1 Fuel Supply Assembly
5
18
16
Battery Assembl y #6010721
19
13
4
3
18
14
5
12
3
4
2
ITEM PART NO. QTY.
1 6010670 1
2 6010554 1
3
4
5 2900039 5
6 2900031 1
7 6010017 1
8 6010344 2
9 2900010 4
10 6010016 1
11 2800465 1
12
13
14
15
16 2800256 1
17 2800257 1
18 2800197 2
19 2800198 2
20 2900014 1
21 2900006 1
22
2900019 6
2900022 6
2800073 1
2800072 1
2800095 1
2800182 1
2900196
1
19202122
9
17
7
3
Battery Platform
Battery Support Brace
Cap Screw, Hex Hd., 5/16-18 x 3/4"
Flat Washer, 5/16" SAE
Lock Nut, 5/16-18 Nylon
Lock Washer, 5/16" Split
Battery Top Brace
Rod, 1/4-20 x 9-1/2"
Lock Nut, 1/4-20 Nylon
Battery Pad
Battery, 12 Volt Group Size 24
Battery Cable, Positive (Red)
Battery Cable, Negative (Black)
Battery Cable, 14" Positive (Red)
Battery Cable, 14" Negative (Black)
Battery Boot, Large (Red)
Battery Boot, Large (Black)
Battery Boot, Small (Red)
Battery Boot, Small (Black)
Flat Washer, 3/8" SAE
Lock Washer, 3/8" Split
Cap Screw, Hex Hd., 3/8-16 x 3/4"
5
6
4
DESCRIPTION
1
15
16
11
8
10
3
4
5
9
Hydraulic Pump Assembly #6010213
17
(Includes Items #1 - #11)
2
3
11
10
4
1
8
9
11
10
7
6
14
5
13
ITEM
1 2600070 1
2 2700321 1
3 3200120 1
4 3200123 1
5 3200115 1
6 3200060 1
7 3200056 1
8 3200057 1
9 2900014 2
10 2900006 2
11 2900047 2
12 3200116 1 Elbow, 1/4" O-Ring to 3/8" M. JIC
13 3200046 1 Fitting, 3/8" F. JIC to 3/8" Push Lock
14 6010059 1 Clear Hose, 3/8" I.D. x 19"
PART NO. QTY.
12
DESCRIPTION
Hydraulic Pump Unit
Breather Cap
Pipe Coupling, 3/8" NPT
Pipe Nipple, 3/8" NPT x 2"
Elbow, 3/8" O-Ring to 1/4" F. Pipe
Hex Nipple, 1/4" NPT
Flow Control Valve, 1/4" NPT
Elbow, 1/4" M. Pipe to 1/4" M. JIC
Flat Washer, 3/8" SAE
Lock Washer, 3/8" Split
Cap Screw, Hex Hd., 3/8-16 x 1-3/4"
9
Depth Indicator Assembly #6010214
18
11
10
5
1
3
4
7
4
2
12
7
6
9
8
14
13
15
ITEM PART NO. QTY. DESCRIPTION
1 6010092 1 Depth Indicator Mount Bracket
2 2500155 2 Cable Pulley, 1-1/4"
3 2900008 2 Cap Screw, Hex Hd., 1/4-20 x 1"
4 2900010 4 Lock Nut, 1/4-20 Nylon
5 2900144 2 Cap Screw, Hex Hd., 1/4-20 x 3/4"
6 2500145 1 Flange Bearing, 3/8"
7 2900014 3 Flat Washer, 3/8" SAE
8 6010091 1 Depth Indicator Pointer
9 2900079 1 Cap Screw, Hex Hd., 3/8-16 x 2-1/4"
10 6010093 1 Cable Pulley, 2"
11 2900018 1 Lock Nut, 3/8-16 Nylon
12 6010094 1
13 2500196 1 Spring, 3/8" x 15"
14 2900055 1 Cotter Pin, 3/16" x 1"
15 2500214 1 Cable Clamp
Depth Indicator Cable with Crimp, 48"
5
19
6
2
Depth Stop Assembly #6010215
4
3
10
1
ITEM PART NO. QTY. DESCRIPTION
9
11
8
7
1 6010097 1 Depth Stop Weldment
2 2900665 4 Belleville Washer, 1/2"
3 2900058 1 Flat Washer, 1/2" SAE
4 2900239 1 Friction Washer, 1/2"
5 6010095 1 Depth Stop Knob
6 2900132 1 Roll Pin, 3/16" x 1-1/4"
7 2900158 1 Yoke, 1/2-13
8 2900084 1 Lock Washer, 1/2" Split
9 2900037 1 Hex Nut, 1/2-13
10 2900007 1 Clevis Pin, 1/2" Dia. x 1-3/8"
11 2900004 1 Cotter Pin, 1/8" x 1"
Water Supply Assembly #6010718
20
6
10
7
5
11
3
8
13
9
12
1
3
7
8
4
2
6
ITEM PART NO. QTY. DESCRIPTION
1 6090069 1 Water Supply Tube
2 3200045 1 Pipe Tee, 1/2" NPT
3 3200008 2 Close Nipple, 1/2" NPT
4 3200022 1 Fitting, 1/2" F. Pipe to 3/4" F. Garden
5 3200025 1 Hose Filter Washer
6 3200013 2 Street Elbow, 1/2" NPT
7 3200027 2 Water Valve
8 3200155 2 Fitting, 1/2" M. Pipe to 3/4" M. Garden
9 6010021 1 Water Hose Assembly, 42" Long
10 3200001 1 Plug, 1/8" NPT
11 2900241 2 U-Bolt, 1/2" Pipe
12 2900009 4 Flat Washer, 1/4" SAE
13 2900010 4 Lock Nut, 1/4-20 Nylon
3
21
Air Cleaner Assembly #6010717
2
4
11
6
7
8
1
5
12
ITEM PART NO. QTY. DESCRIPTION
1 2501384 1 Air Cleaner Complete
2501386 1 Outer Primary Filter
2501387 1 Inner Safety Filter
2500239 1 Rubber Dust Ejector Boot
2 2501388 1 Pre-Cleaner with Clamp
3 2500423 1 Restriction Indicator
4 3200117 1 Close Nipple, 1/8" NPT
5 2501385 1 Mounting Band, Polymer
6 6010325 1 Air Cleaner Mount Spacer
7 2900022 5 Flat Washer, 5/16" SAE
8 2900039 4 Lock Nut, 5/16-18 Nylon
9 2900138 1 Cap Screw, Hex Hd., 5/16-18 x 1"
10 2900217 1 Cap Screw, Hex Hd., 5/16-18 x 1-1/4"
11 2900508 1 Cap Screw, Hex Hd., 5/16-18 x 1-1/2"
12 2900538 1 Cap Screw, Hex Hd., 5/16-18 x 1-3/4"
7
7
9
8
8
7
10
7
Air Intake Assembly #6010730
22
(Includes Items #1 - #14)
7
9
10
3
5
2
5
6
2
1
5
8
5
5
15
11
13
1
4
5
12
14
ITEM PART NO. QTY. DESCRIPTION
1 2500669 2 Hose Elbow, 3" I.D.
2 6010559 2 Connector Tube, 3" O.D.
3 6010692 1 Air Cleaner Hose, 3" I.D. x 18"
4 6013118 1 Connector Tube, 2-3/4" O.D.
5 3200197 6 Hose Clamp #52
6 2501753 1 Hose Mount Support
7 2900592 1 Eyebolt, M10 x 50mm
8 2900013 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
9 2900018 1 Lock Nut, 3/8-16 Nylon
10 2900325 1 Hex Nut, M10-1.5
11 6010409 1 Connector Tube, 1-7/8" O.D.
12 2500229 1 Hose Reducer, 2-1/2" to 2" I.D.
13 3200096 1 Hose Clamp #40
14 3200095 1 Hose Clamp #32
15 2702207 1 Hose Elbow, Turbo Inlet
Frame Lift Assembly #6010784
23
8
1
10
8
9
3
9
10
4
5
6
2
6
7
5
2
ITEM PART NO. QTY. DESCRIPTION
1 6013051 1 Frame Lift
2 6013053 2 Frame Lift Spacer
3 6010776A 1 Frame Lift Stop Brace
4 6010776B 1 Frame Lift Stop Brace
5 2900465 2 Cap Screw, Hex Hd., 3/4-10 x 2-1/4"
6 2900003 2 Flat Washer, 3/4" SAE
7 2900467 2 Lock Nut, 3/4-10 Nylon
8 2900013 2 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
9 2900005 2 Cap Screw, Hex Hd., 3/8-16 x 1"
10 2900018 4 Lock Nut, 3/8-16 Nylon
7
Frame Base Assembly #6010722
24
23
22
11
24
9
2
4
5
6
17
7
4
5
8
11
2
3
12
21
15
14
13
10
1
19
16
20
18
ITEM PART NO. QTY. DESCRIPTION
1 6010662A 1 Frame Base
2 6010681 2 Skid Plate
3 6010680 1 Guard Attachment Plate (25 degree)
4 2900058 4 Flat Washer, 1/2" SAE
5 2900084 4 Lock Washer, 1/2" Split
6 2900086 1 Cap Screw, Hex Hd., 1/2-13 x 1"
7 2900499 1 Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
8 2900139 2 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
9 6010660 2 Forward Engine Mount
10 6010661 2 Rear Engine Mount
11 2900147 4 Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
12 2900135 4 Lock Nut, 5/8-11 Nylon
13 2900002 4 Flat Washer, 5/8" SAE
14 2900113 4 Lock Washer, 5/8" Split
15 2900136 4 Cap Screw, Hex Hd., 5/8-11 x 2"
16 6010645 1 Shaft/Flange Guard (Wide)
17 2900156 1 Lock Pin with Ring
18 6010683 1 Rear Pointer Rod
19 2900033 1 Hex Nut, 3/8-16
20 2900013 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
21 6010022 1 Rear Pointer
22 2900006 1 Lock Washer, 3/8" Split
23 2900047 1 Cap Screw, Hex Hd., 3/8-16 x 1-3/4"
24 2502038 1 Plug, 2-1/2" Hole
Hydraulic Cylinder Assembly #6010714
25
4
7
4
6
4
3
5
1
2
ITEM PART NO. QTY. DESCRIPTION
1
2 6010031 1 Cylinder Pin, 3"
3 6010119 1 Cylinder Pin, 3-1/2"
4 2900064 4
5 3200067 1
6 3200057 1 Elbow, 1/4" M. Pipe to 1/4" M. JIC
7 3200054 1 Hose Assembly, 32" Long
2500177 1 Hydraulic Cylinder
Hair Pin Cotter, 3/4"
Cylinder Breather, 1/4" NPT
4
Rear Drive Assembly #6010723 (Eato n)
26
5
6
12
32
34
33
34
13
23
22
2
34
13
1
16
26
14
15
24
25
14
15
24
11
10
29
13
3
13
30
26
25
25
28
8
31
27
9
18
7
4
17
21
19
20
18
19
20
Rear Drive Assembly #6010723 (Eato n)
27
ITEM PART NO.
1 6010068 1
2 6010027 1
3 6010028 1
4 2500159 2
5
6
7
8
9
10
11
12
13
14
15
16
17 6010674 1
18
19 2900022 6
20
21
22
23
24
25
26 2900026 3
27 2900542
28 6010673 1
29
30
31
32 2501946 1 V-Belt, AX39
33
34
2900005 4
2900006 4
6010664 1
6048229 1
2500148 1
2500149 1
6010069 1
6010671 1
2900009 9
2900024 5
2900023 5
6010679 1
2900668 6
2900039 6
6010678 1
2900140 1
2900141
2900106 2
2900058
6010735 1 Spacer, Fan Guard
2900052 2 Cap Screw, Hex Hd., 1/4-20 x 1-1/4"
2900010
6010724
6010725 1
QTY.
1
4
1
2
1
Transmission Platform Weldment
Mount Foot, Right Hand
Mount Foot, Left Hand
Pillow Block Bearing, 3/4"
Cap Screw, Hex Hd., 3/8-16 x 1"
Lock Washer, 3/8" Split
Transmission Jackshaft, 18 Tooth
Key, 3/16" Sq. x 1-1/4"
Sprocket, #40 x 45 Tooth
QD Bushing, SDS x 3/4" w/Fasteners
Chain, #40 x 56 Pitch
Chain Guard
Flat Washer, 1/4" SAE
Lock Washer, 1/4" Split
Cap Screw, Hex Hd., 1/4-20 x 5/8"
Gear Guard
Sprocket Guard
Cap Screw, Hex Hd., 5/16-18 x 7/8"
Flat Washer, 5/16" SAE
Lock Nut, 5/16-18 Nylon
Cover Plate (Wide)
Set Screw, Sq. Hd., 5/16-18 x 1-1/2"
Hex Nut, 5/16-18
Cap Screw, Hex Hd., 1/2-13 x 2"
Flat Washer, 1/2" SAE
Lock Nut, 1/2-13 Nylon
Tap Bolt, Hex Hd., 1/2-13 x 3-1/2"
Fan Guard
Lock Nut, 1/4-20 Nylon
Eaton Transmission Assembly
Linkage Assembly
DESCRIPTION
Eaton Transmission Assembly #6010724
28
9
8
23
6
5
2522
24
21
7
3
2
23
22
1
21
10
ITEM PART NO. QTY. DESCRIPTION
1 2600068 1 Eaton Hydrostatic Transmission
2 3200046 2 Fitting, 3/8" F. JIC to 3/8" Push Lock
3 6010060 1 Oil Recirculation Hose, 3/8" I.D. x 9"
4 2900143 1 Woodruff Key #61, 3/16" x 5/8"
5 2900063 1 Woodruff Key #405, 1/8" x 5/8"
6 2500150 1 Sprocket, #40 x 11 Tooth w/Setscrews
7 2900083 1 Fender Washer, 1/4" x 1-1/4"
8 2900024 1 Lock Washer, 1/4" Split
9 2900082 1 Cap Screw, Hex Hd., 1/4-20 x 1/2"
10 6010064 1 Shift Lever
11 2900058 1 Flat Washer, 1/2" SAE
12 2900026 1 Lock Nut, 1/2-13 Nylon
13 6010682 1 Transmission Pulley 5.5"
14 2900142 2 Set Screw, Soc. Hd., 5/16-18 x 3/8"
15 2500519 1 Cooling Fan, 7"
16 2900038 4 Lock Washer, #10 Split
17 2900448 4 Machine Screw, Hex Hd., #10-32 x 1/2"
18 2900567 1 Flat Washer, 5/16" USS
19 2900031 1 Lock Washer, 5/16" Split
20 2900019 1 Cap Screw, Hex Hd., 5/16-18 x 3/4"
21 2900035 4 Cap Screw, Hex Hd., 3/8-16 x 3"
22 2900014 4 Flat Washer, 3/8" SAE
23 2900018 4 Lock Nut, 3/8-16 Nylon
24 3200062 1 Hose Clamp #4
25 6010059 1 Clear Hose, 3/8" I.D. x 19"
14
11
12
4
14
15
13
16
17
18
19
20
Linkage Assembly #6010725
29
4
4
3
4
3
6
3
4
4
4
10
5
5
5
4
3
4
2
3
4
9
4
7
8
5
ITEM PART NO. QTY. DESCRIPTION
1 6010067 1 Bell Crank
2 2900153 2 Friction Washer, 3/8"
3 2900029 6
4 2900014 14 Flat Washer, 3/8" SAE
5 2900018 7
6 2900047 1
7 2900006 1
8 2900033 1 Hex Nut, 3/8-16
9 6010704 1
10 6010705 1
11 6010706 1
Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
Lock Nut, 3/8-16 Nylon
Cap Screw, Hex Hd., 3/8-16 x 1-3/4"
Lock Washer, 3/8" Split
Linkage Assembly 5-1/8"
Linkage Assembly 6-1/4"
Linkage Assembly 8"
11
5
4
5
2
3
4
4
1
5
Rear Drive Assembly #6010726 (Sundstrand)
30
31
38
4
35
36
34
7
36
10
20
24
21
32
16
33
23
7
37
18
15
17
15
15
16
19
16
15
9
2
8
22
12
3
13
11
5
6
14
15
1
27
15
14
29
25
27
28
16
26
31
32
30
33
Rear Drive Assembly #6010726 (Sundstrand)
31
ITEM PART NO. QTY.
1 6010118 1
2 2600021 1
3 6011037 1
4 2500519 1
5 2900038 4
6 2900448 4
7 2900142 4
8 6010170 1
9 6010129 1
10 2900429 1
11 6010120 1
12
13
14
15
16
17 6010703 1
18 2900029 1
19 2900596 1
20 6030126 1
21
22
23
24
25
26
27
28
29
30
31
32
33
34 6010673 1
35
36
37 2900010 2
38 2501779 1
2900140 1
2900141 1 Hex Nut, 5/16-18
2900160 4
2900014 6
2900018 6
6010672A 1
6010130 1
6010127 1
6010169 1
2900499 1
2900127 1
2900026 2
2900542 1
2900058 2
6010677 1
2900668
2900022
2900039
2900144 2
2900009 4
6
6
6
DESCRIPTION
Transmission Platform
Hydrostatic Transaxle Assembly
Transmission Pulley 3.5"
Cooling Fan, 7"
Lock Washer, #10 Split
Machine Screw, Hex Hd., #10-32 x 1/2"
Set Screw, Soc. Hd., 5/16-18 x 3/8"
Key, 3/16" Sq. x 1"
Shift Lever
Set Screw, Soc. Hd., 5/16-24 x 1/2"
Chain Tensioning Bracket
Set Screw, Sq. Hd., 5/16-18 x 1-1/2"
Cap Screw, Hex Hd., 3/8-16 x 4"
Flat Washer, 3/8" SAE
Lock Nut, 3/8-16 Nylon
Linkage Assembly 11-1/2"
Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
Cap Screw, Hex Hd., 3/8-16 x 2-1/2"
Spacer, 1"
Chain Guard
Chain, #50 x 50 pitch
Transmission Sprocket, #50 x 19 Tooth
Key, 1/4" Sq. x 1-1/4"
Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
Flat Washer, 1/2" USS
Lock Nut, 1/2-13 Nylon
Tap Bolt, Hex Hd., 1/2-13 x 3-1/2"
Flat Washer, 1/2" SAE
Cover Plate (Narrow)
Cap Screw, Hex Hd., 5/16-18 x 7/8"
Flat Washer, 5/16" SAE
Lock Nut, 5/16-18 Nylon
Fan Guard
Cap Screw, Hex Hd., 1/4-20 x 3/4"
Flat Washer, 1/4" SAE
Lock Nut, 1/4-20 Nylon
V-Belt, AX29
Rear Axle Assembly #6010743 (Eato n / Gear)
32
8
7
6
5
ITEM
1
2
3
4
5
6
7
8
1
4
2
PART NO. QTY. DESCRIPTION
6010686 1 Rear Axle Weldment w/60 Tooth Gear
2500873 2 Wheel, 10" Rear with 2" Bore
2500874 2 Trantorque Bushing, 1-1/4"
2500158 2 Pillow Block Bearing 1-1/4"
6010024 2
2900058 4
2900084 4 Lock Washer, 1/2" Split
2900139 4 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
Rear Axle Bearing Spacer, 1/8"
Flat Washer, 1/2" SAE
3
Rear Axle Assembly #6010744 (Sundstrand / Chain)
33
3
2
4
1
8
7
6
5
9
ITEM PART NO. QTY. DESCRIPTION
1 6010281 1 Rear Axle Weldment w/35 Tooth Sprocket
2
3
4
5 6010024 2 Rear Axle Bearing Spacer, 1/8"
6
7
8
9
2500873 2 Wheel, 10" Rear with 2" Bore
2500874 2 Trantorque Bushing, 1-1/4"
2500158 2 Pillow Block Bearing 1-1/4"
2900058 4 Flat Washer, 1/2" SAE
2900084 4 Lock Washer, 1/2" Split
2900025 2 Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
2900139 2 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
Front Axle Assembly #6010562
34
16
1
12
13
14
17
9
8
10
11
3
4
5
6
15
2
ITEM PART NO. QTY. DESCRIPTION
1 6010535 1 Front Axle Weldment
2 6010581 2 Wheel Assembly, 8" Front
3 2501393 2 Wheel Cover Gasket
4 6010536 2 Wheel Cover
5 2900038 8 Lock Washer, #10 Split
6 2900159 8 Machine Screw, Rd. Hd., #10-24 x 5/8"
7 2900127 2 Flat Washer, 1/2" USS
8 2900084 6 Lock Washer, 1/2" Split
9
10 2900058 4 Flat Washer, 1/2" SAE
11
12 2900002 1 Flat Washer, 5/8" SAE
13 2900113 1 Lock Washer, 5/8" Split
14 2900112 1 Hex Nut, 5/8-11
15 2900492 1 Tap Bolt, Hex Hd., 5/8-11 x 4"
16
17 2900184 1
2900025 6 Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
2500158 2 Pillow Block Bearing 1-1/4"
2900446 1 Swivel Pad Nut, 5/8-11
Grease Fitting, 1/8" NPT x 45 degree
7
8
9
Front Wheel Assembly #6010581
35
2
1
3
4
5
ITEM PART NO. QTY. DESCRIPTION
1 2501390 1 Wheel, 8" Front
2 2501428 1 Seal, 1-1/2" V-Ring
3 2501391 1 Seal, 1-1/4" x 1-3/4" x 1/4"
4 2501418 4 Ball Bearing, 1" x 2" x 1/2"
5 2501392 1 Retaining Ring, 2" Internal
Blade Shaft Assembly #6010713A (Blades 14" - 26")
36
11
8
13
7
12
3
6
2
9
8
7
5
3
4
5
1
14
9
8
7
6
7
8
2
ITEM PART NO. QTY. DESCRIPTION
1 6010543 1 Blade Shaft
2 2500151 2 Blade Shaft Bearing, 1-3/4"
3 2900264 2 Grease Fitting, 1/8" NPT x 1-3/4"
4 4645006 1 Key, 3/8" Sq. x 4"
5 6010040 2 Key, 1/4" Sq. x 15/16"
6 2900418 2 Set Screw, Soc. Hd., 5/16-18 x 5/8"
7 2900002 6 Flat Washer, 5/8" SAE
8 2900113 6 Lock Washer, 5/8" Split
9 2900136 4 Cap Screw, Hex Hd., 5/8-11 x 2"
10 2900146 1 Cap Screw, Hex Hd., 5/8-11 x 4"
11 2900130 1 Cap Screw, Hex Hd., 5/8-11 x 4" LH
12 6010036 2 Inner Flange 4-1/2"
13 6010037 2 Outer Flange 4-1/2" with Pin
14 6010697 1 Shaft Tach Gear Assembly
12
13
10
Blade Shaft Assembly #6010713B (Blades 30" - 36")
37
11
13
3
8
7
12
6
2
9
8
7
5
3
4
5
1
14
9
8
7
6
7
8
2
ITEM PART NO. QTY. DESCRIPTION
1 6010543 1 Blade Shaft
2 2500151 2 Blade Shaft Bearing, 1-3/4"
3 2900264 2 Grease Fitting, 1/8" NPT x 1-3/4"
4 4645006 1 Key, 3/8" Sq. x 4"
5 6010040 2 Key, 1/4" Sq. x 15/16"
6 2900418 2 Set Screw, Soc. Hd., 5/16-18 x 5/8"
7 2900002 6 Flat Washer, 5/8" SAE
8 2900113 6 Lock Washer, 5/8" Split
9 2900136 4 Cap Screw, Hex Hd., 5/8-11 x 2"
10 2900146 1 Cap Screw, Hex Hd., 5/8-11 x 4"
11 2900130 1 Cap Screw, Hex Hd., 5/8-11 x 4" LH
12 6010038 2 Inner Flange 6"
13 6010039 2 Outer Flange 6" with Pin
14 6010697 1 Shaft Tach Gear Assembly
12
13
10
Shaft Tach Gear Assembly #6010697
38
4
11
10
9
9
7
6
5
7
7
3
2
7
8
2
1
6
ITEM PART NO. QTY. DESCRIPTION
1 6010230 1 Shaft Tach Gear, Split
2 6010669 2 Shaft Tach Gear Guard
3 6010668 1 Shaft Tach Guard Spacer 5/8"
4 2800169 1 Magnetic Sensor w/Jam Nut
5 2900113 1 Lock Washer, 5/8" Split
6 2501752 2 Seal, 1-3/4" V-Ring
7 2900022 8 Flat Washer, 5/16" SAE
8 2900039 2 Lock Nut, 5/16-18 Nylon
9 2900726 2 Cap Screw, Hex Hd., 5/16-18 x 2-1/2"
10 2900031 4 Lock Washer, 5/16" Split
11 2900508 4 Cap Screw, Hex Hd., 5/16-18 x 1-1/2"
7
8
Belt Drive Assembly #6010733
39
14" BLADE DRIVE
ITEM PART NO. QTY. DESCRIPTION
1 6010658 1 Sheave, 4" x 10 Groove w/Bushing
2501380 1 Sheave, 4" x 10 Groove Taper Style
2501410 1 Taper Bushing, 1-3/4" w/Setscrews
2 2502041 1 Belt Set, 5/3VX530 - 5 Strand
3 2501781 1 V-Belt, AX42
20" & 26" BLADE DRIVE
ITEM PART NO. QTY. DESCRIPTION
1 6010545 1 Sheave, 4.5" x 10 Groove w/Bushing
2501381 1 Sheave, 4.5" x 10 Groove Taper Style
2501410 1 Taper Bushing, 1-3/4" w/Setscrews
2 2502041 1 Belt Set, 5/3VX530 - 5 Strand
3 2501781 1 V-Belt, AX42
30" & 36" BLADE DRIVE
ITEM PART NO. QTY. DESCRIPTION
1 6013046 1 Sheave, 6" x 10 Groove w/Bushing
2500439 1 Sheave, 6" x 10 Groove QD Style
2500176 1 Q D Bushing, SK x 1-3/4" w/Fasteners
2 2502042 1 Belt Set, 5/3VX560 - 5 Strand
3 2501781 1 V-Belt, AX42
3
1
2
36
40
Engine Assembly #6010727
35
33
32
34
24
23
22
31
32
37
5
4
3
2
1
9
29
28
30
25
26
21
27
10
8
9
8
16
15
18
11
9
12
8
17
6
19
20
14
7
13
7
Engine Assembly #6010727
41
ITEM PART NO. QTY. DESCRIPTION
1 2600326 1 Engine, Deutz Model BF3L2011
2 6090417 1 Spacer, 2-1/4" Long
3 2900084 1 Lock Washer, 1/2" Split
4 2900482 1 Hex Nut, M12
5 2900481 1 Eyebolt , M12 x 6"
6 6010659 2 Engine Support Leg
7 2900347 2 Cap Screw, Hex Hd., M12 x 100mm
8 2900058 4 Flat Washer, 1/2" SAE
9 2900327 4 Loc k Nut, M12 Nylon
10 2900346 2 Cap Screw, Hex Hd., M12 x 80mm
11 2900137 2 Cap Screw, Hex Hd., 5/8-11 x 3-1/4"
12 2900721 2 Flat Washer, 5/8" USS Hardened
13 2900135 2 Lock Nut, 5/8-11 Nylon
14 2900502 2 Cap Screw, Hex Hd., 5/8-11 x 5"
15 2900113 2 Lock Washer, 5/8" Split
16 2900002 2 Flat Washer, 5/8" SAE
17 2900491 2 Lock Nut, 5/8-11 Flanged
18 2900480 2 Tap Bolt, Hex Hd., 3/4-10 x 6"
19 2900041 2 Hex Nut, 3/4-10
20 2900476 2 Swivel Pad Nut, 3/4-10
21 6010698 1 Oil Drain Valve Assembly
22 6010712 1 Crankcase Breather Assembly
ITEM PART NO. QTY. DESCRIPTION
23 3200814 1 Oil Drain Valve, M18x1.5
24 3200062 1 Hose Clamp #4
25 6010364 1 Oil Drain Hose, 3/8" I.D. x 14"
26 3200741 1 Hose Plug
27 2501434 1 Hose Clamp, 5/8" x 3/4" Wide
28 2900014 1 Flat Washer, 3/8" SAE
29 2900006 1 Lock Washer, 3/8" Split
30 2900005 1 Cap Screw, Hex Hd., 3/8-16 x 1"
ITEM PART NO. QTY. DESCRIPTION
31 6010710 1 Breather Block
32 3200475 2 Elbow, 1/4" M. Pipe to 3/8" Hose Barb
33 6010711 1 Breather Hose, 3/8" I.D. x 5"
34 3200031 1 Fitting, 1/4" F. Pipe to 3/8" Hose Barb
35 3200016 1 Hose Clamp #8
36 2900342 2 Cap Screw, Hex Hd., M6 x 30mm
37 2702620 1 Gasket, Crankcase Breather
Muffler Assembly #6010728
42
7
6
3
4
1
5
ITEM PART NO. QTY. DESCRIPTION
1 2702785 1 Muffler
2 2702786 1 Exhaust Pipe
3 2701618 1 Gasket, Turbo Outlet
4 2702549 3 Stud, M8 x 30mm
5 2900343 3 Hex Nut, M8-1.25
6 2700609 2 Muffler Clamp 2-1/2"
7 2501775 1 Tail Pipe, 2-1/2" I.D. x 12"
8 2900321 1 Lock Washer, M10 Split
9 2900333 1 Cap Screw, Hex Hd., M10-1.5 x 25mm
10 6010696 1 Pointer Stop Assembly
2
6
10
8
9
Pointer Stop Assembly #6010696
43
10
11
15
14
5
1
4
3
15
6
7
13
12
ITEM PART NO. QTY. DESCRIPTION
1
2 6010583 1 Pointer Stop
3
4 2900321 2 Lock Washer, M10 Split
5
6 2900083 2 Fender Washer, 1/4" x 1-1/4"
7
8 2900048 1 Cap Screw, Hex Hd., 1/4-20 x 1-1/2"
9
10 2900009 1 Flat Washer, 1/4" SAE
11
12 2501093 1 Bumper, 1"
13 2900172 1 Machine Screw, Rd. Hd., #10-24 x 1-1/4"
14 2900017 1 Lock Nut, #10-24 Nylon
15 2500573 3 Plug, 1" Square Tube
2
6
15
6010688 1 Adapter Plate
2900223 2 Cap Screw, Hex Hd., M10 x 30mm
2900014 3 Flat Washer, 3/8" SAE
2900024 1 Lock Washer, 1/4" Split
2900392 1 Cap Screw, Hex Hd., 1/4-20 x 1-3/4"
2900010 1 Lock Nut, 1/4-20 Nylon
8
9
26
44
24
23
PTO Assembly #6010770
(Includes Items #1 - #24)
1
5
3
2
21
25
22
4
Hub Unit #6010772
(Includes Items #21 - #24)
7
8
ITEM PART NO. QTY. DESCRIPTION
1 6010352 1 Inner Ring Support
2 2900223 11 Cap Screw, Hex Hd., M10-1.5 x 30mm
3 2900321 11 Lock Washer, M10 Split
4 2501983 1 Seal, 2" x 2-5/8" x 5/16"
5 2900621 8 Cap Screw, Hex Hd., 3/8-16 x 7/8"
6 2501717 1 Shaft Support Sleeve
7 2501984 1 Seal, 1" x 1-1/4" x 1/8"
8 2500751 1 Seal, 1-3/4" V-Ring
9 2501722 1 Sheave, 4" x 11 Groove
10 2501719 1 Bearing Retainer Plate
11 2501998 1 Grease Slinger Disc
6
12
11
PTO Unit #6010771
(Includes Items #5 - #20)
10
14
13 15
9
16
18
17
19
20
12 2900624 6 Machine Screw, Hex Hd., #6-32 x 3/8"
13 2501986 4 Ball Bearing, 40mm x 68mm x 15mm
14 6046020 1 PTO Bearing Spacer
15 2501747 4 Shim, 40mm x 50mm x 0.1mm
16 2900654 1 Bearing Lock Nut, 1-9/16"-18
17 2501720 1 Splined Drive Shaft
18 2501985 1 Grease Disc
19 2900954 6 Cap Screw, Hex Hd., 3/8-24 x 7/8"
20 2900062 1 Grease Fitting, 1/8" NPT
21 2501721 1 Coupling Hub
22 2900633 6 Cap Screw, Hex Hd., M10-1.0 x 50mm
23 2501714 1 Seal, 1" x 1-1/2" x 1/4"
24 2501670 1 Hubbard Plug, 1-1/8"
25 2701276 1 Flywheel, Deutz Engine
26 2702756 2 Cap Screw, Hex Hd., M10-1.0 x 40mm
Rotary Tensioner Assembly #6010694
45
5
3
7
6
4
8
2
9
1
7
6
ITEM PART NO.
1 2501750
2 6010684
3 2501751
4 2501754
5 2900192
6 2900026
7 2900127
8 2900414
9
2900477 1
QTY.
1
1
1
1
1
2
2 Flat Washer, 1/2" USS
1
DESCRIPTION
Rotary Tensioner
Rotary Tensioner Spacer 1/2"
Idler Pulley 4"
Knob, 1/2-13 Tapered
Cap Screw, Hex Hd., 1/2-13 x 2-1/4"
Lock Nut, 1/2-13 Nylon
Cap Screw, Hex Hd., 1/2-13 x 4-1/4"
Shoulder Screw, 5/8" x 1" (1/2-13)
Transmission Jackshaft Assembly #6010695
46
6
4
1
10
9
3
8
4
3
5
2
5
3
4
4
8
7
ITEM PART NO. QTY. DESCRIPTION
1 6010667 1 Jackshaft Pivot Housing
2 6010666 1
3 2501743 5 Ball Bearing, 20mm x 42mm x 12mm
4 2501748 4 Retaining Ring, 42mm Internal
5 6048229 2 Key, 3/16" Sq. x 1-1/4"
6 2500455 2 Pulley, 4" Single Groove w/Setscrews
7
8
9
10
2900669 1 Shoulder Bolt, 20mm x 90mm (M16)
6010685 2 Bearing Spacer, 1/4"
2900002 1 Flat Washer, 5/8" SAE
2900670 1
Transmission Jackshaft
Lock Nut, M16 Nylon
6
13
47
Throttle Cable Assembly #6010729
14
15
12
16
4
6
2
3
10
ITEM PART NO. QTY.
1 6010523 1
2 2500940 1
3 2900015 2
4 2900017 2
5 2900310 4
6 2900302 2
7 6013029 1
8 2900024 2
9 6048212 1
10 2900059 1
11 2900034 1
12 2501434 1
13 2900022 1
14 2900031 1
15 2900360 1
16 2500376 1
9
Throttle Bracket
Throttle Cable Clamp
Machine Screw, Hex Hd., #10-24 x 3/4"
Lock Nut, #10-24 Nylon
Cap Screw, Hex Hd., M6 x 20mm
Lock Nut, M6 Nylon
Throttle Arm
Lock Washer, 1/4" Split
Pivot Pin
Set Screw, Soc. Hd., #10-32 x 1/4"
Cotter Pin, 3/32" x 3/4"
Hose Clamp, 1/2" x 3/4" Wide
Flat Washer, 5/16" SAE
Lock Washer, 5/16" Split
Cap Screw, Hex Hd., M8 x 25mm
Vernier Throttle Cable
5
1
8
7
11
DESCRIPTION
6
48
7
Belt Guard Assembly #6010732
8
9
13
8
7
6
14
5
2
3
2
3
12
4
4
11
4
3
2
2
10
3
1
ITEM PART NO.
1 6010690 1 Belt Guard
2 2900473 5 Flat Washer, 3/8" USS
3 2900006 5 Lock Washer, 3/8" Split
4 2900005 5 Cap Screw, Hex Hd., 3/8-16 x 1"
5 6010558 1 Guard Mounting Tab, 3/8-16
6 2900022 5 Flat Washer, 5/16" SAE
7 2900031 5 Lock Washer, 5/16" Split
8 2900019 5 Cap Screw, Hex Hd., 5/16-18 x 3/4"
9 6010556 1 Belt Guard Mount Bracket
10 6010768 1 Swing Cover Plate with Label
11 2900246 1 Shoulder Screw, 5/16" x 1/4" (1/4-20)
12 2900252 1 Belleville Washer, 5/16"
13 2900010 1 Lock Nut, 1/4-20 Nylon
14
2500489 1 Plug, 1" Hole
QTY.
DESCRIPTION
4
Front Pointer Assembly #6010540
49
12
11
3
4
1
13
5
6
7
14
3
11
2
8
9
ITEM PART NO. QTY. DESCRIPTION
1 6010541 1 Front Pointer Frame
2 6011152 2 Front Pointer Arm
3 6013025 1 Front Pointer Rod
4 2500740 1 Pointer Cap
5 2501409 1 Wheel, 6"
6 2900127 2 Flat Washer, 1/2" USS
7 2500007 2 Set Collar, 1/2" with Set Screw
8 2900105 2 Cap Screw, Hex Hd., 1/2-13 x 2-3/4"
9 2900026 2 Lock Nut, 1/2-13 Nylon
10 2900005 2 Cap Screw, Hex Hd., 3/8-16 x 1"
11 2900033 4 Hex Nut, 3/8-16
12 2900013 2 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
13 6017241 1 Pointer Rope 11 Foot
14 3200221 2 Pinch Clamp, Two Ear
10
2
8
14" Blade Guard Assembly #6010950
50
20
24
23
22
19
23
21
22
10
9
4
7
8
13
9
4
6
11
12
18
17
16
3
4
2
13
1
6
14
10
6 5
15
14" Blade Guard Assembly #6010950
51
ITEM PART NO. QTY. DESCRIPTION
1 6010601 1 14" Blade Guard Front & Rear Only
2 6010081 1 Splash Flap
3 2900310 2 Cap Screw, Hex Hd., M6-1.0 x 20mm
4 2901494 4 Flat Washer, M6
5 2900083 2 Fender Washer, 1/4" x 1-1/4"
6 2900302 8 Lock Nut, M6-1.0 Nylon Insert
7 6010261 1 Water Manifold
8 2500830 1 Water Manifold Gasket
9 2901355 2 Cap Screw, Hex Hd., M6-1.0 x 50mm
10 3200001 3 Plug, 1/8" NPT
11 3200002 1 Fitting, 3/8" M. Pipe to 3/4" M. Garden
12 2900278 1 Lanyard with Lock Pin
13 6048283 2 Water Tube for 14" Guard
14
15 2900308 4 Cap Screw, Flat Hd., M6-1.0 x 16mm
16 1800001 1 Warning Label
17 1801369A 1 Blade Guard Size Tag
18 2900287 2 Rivet, 1/8" Dia.
19 6048026
6048155 2 Water Tube Clamp
Hinge Assembly1
ITEM PART NO. QTY. DESCRIPTION
20 2500270 1 Blade Guard Hinge
21 2900310 5 Cap Screw, Hex Hd., M6-1.0 x 20mm
22 2901494 6 Flat Washer, M6
23 2900302 7 Lock Nut, M6-1.0 Nylon Insert
24 2900312 1 Cap Screw, Hex Hd., M6-1.0 x 35mm
20
52
21
20" Blade Guard Assembly #6010952
9
9
19
16
22
23
10
4
7
8
13
4
12
6
11
18
17
1
3
4
6
14
13
10
15
2
6
5
20" Blade Guard Assembly #6010952
53
ITEM PART NO. QTY. DESCRIPTION
1 6010603 1 20" Blade Guard Front & Rear Only
2 6010081 1 Splash Flap
3 2900310 2 Cap Screw, Hex Hd., M6-1.0 x 20mm
4 2901494 4 Flat Washer, M6
5 2900083 2 Fender Washer, 1/4" x 1-1/4"
6 2900302 8 Lock Nut, M6-1.0 Nylon Insert
7 6010261 1 Water Manifold
8 2500830 1 Water Manifold Gasket
9 2901355 2 Cap Screw, Hex Hd., M6-1.0 x 50mm
10 3200001 3 Plug, 1/8" NPT
11 3200002 1 Fitting, 3/8" M. Pipe to 3/4" M. Garden
12 2900278 1 Lanyard with Lock Pin
13 6010085 2 Water Tube for 20" Guard
14 6048155 2 Water Tube Clamp
Cap Screw, Flat Hd., M6-1.0 x 16mm4290030815
Warning Label1180000116
11801369D17
18
1604802719
Blade Guard Size Tag
Rivet, 1/8" Dia.22900287
Hinge Assembly
ITEM PART NO. QTY. DESCRIPTION
20 2500270 1 Blade Guard Hinge
21 2900310 6 Cap Screw, Hex Hd., M6-1.0 x 20mm
22 2901494 6 Flat Washer, M6
23 2900302 6 Lock Nut, M6-1.0 Nylon Insert
22
54
25
26" Blade Guard Assembly #6010954
21
24
23
20
26
21
18
19
27
11
7
8
14
10
9
4
12
13
17
1
3
4
14
6
15
6
5
2
11
16
26" Blade Guard Assembly #6010954
55
ITEM PART NO. QTY. DESCRIPTION
1 6010955 1 26" Blade Guard Front & Rear Only
2 6010081 1 Splash Flap
3 2900310 2 Cap Screw, Hex Hd., M6-1.0 x 20mm
4 2901494 4 Flat Washer, M6
5 2900083 2 Fender Washer, 1/4" x 1-1/4"
6 2900302 6 Lock Nut, M6-1.0 Nylon Insert
7 6010261 1 Water Manifold
8 2500830 1 Water Manifold Gasket
9 2900765 2 Lock Washer, M6 Split
10 2901355 2 Cap Screw, Hex Hd., M6-1.0 x 50mm
11 3200001 3 Plug, 1/8" NPT
12 3200002 1 Fitting, 3/8" M. Pipe to 3/4" M. Garden
13
14 6010086 2 Water Tube for 26" Guard
15 6048155 2 Wat er Tube Clamp
16 2900308 4 Cap Screw, Flat Hd., M6-1.0 x 16mm
17 1800001 1 Warning Label
18 1801369F 1 Blade Guard Size Tag
19 2900287 2 Rivet, 1/8" Dia.
20 6010873
2900279 1 Lanyard with Lock Pin
Universal Hinge Assembly1
ITEM PART NO. QTY DESCRIPTION
21 6010871 2 Hinge Weldment, Universal
22 2900479 1 Cap Screw, Hex Hd., 3/4-10 x 4"
23 2900467 1 Lock Nut, 3/4-10 Nylon
24 2901356 4 Flat Washer, M10
25 2900321 4 Lock Washer, M10 Split
26 2900333 4 Cap Screw, Hex Hd., M10-1.5 x 25mm
27 2503824 1 Detent Pin, 3/4" x 3" Grip
26
56
29
30" Blade Guard Assembly #6010956
(Includes Items #1 - #20)
25
28
20
27
30
19
18
25
31
10
11
7
9
8
4
14
13
12
1
17
22
23
24
5
14
15
6
21
6
4
3
2
11
16
30" Blade Guard Assembly #6010956
57
(Includes Items #1 - #20)
ITEM PART NO. QTY. DESCRIPTION
1 6010957 1 30" Blade Guard Front & Rear Only
2 6010081 1 Splash Flap
3 2900310 2 Cap Screw, Hex Hd., M6-1.0 x 20mm
4 2901494 4 Flat Washer, M6
5 2900083 2 Fender Washer, 1/4" x 1-1/4"
6 2900302 6 Lock Nut, M6-1.0 Nylon Insert
7 6010261 1 Water Manifold
8 2500830 1 Water Manifold Gasket
9 2900765 2 Lock Washer, M6 Split
10 2901355 2 Cap Screw, Hex Hd., M6-1.0 x 50mm
11 3200001 3 Plug, 1/8" NPT
12 3200002 1 Fitting, 3/8" M. Pipe to 3/4" M. Garden
13 2900279 1 Lanyard with Lock Pin
14 6010087 2 Water Tube for 30" Guard
15 6048155 2 W ater Tube Clamp
16 2900308 4 Cap Screw, Flat Hd., M6-1.0 x 16mm
17
18 1801369G 1 Blade Guard Size Tag
19 2900287 2 Rivet, 1/8" Dia.
20 6010873 1 Universal Hinge Assembly
21 6010511 1 Blade Guard Brace
22 2901356 1 Flat Washer, M10
23 2900321 1 Lock Washer, M10 Split
24 2900333
1800001 1 Warning Label
Cap Screw, Hex Hd., M10-1.5 x 25mm1
ITEM PART NO. QTY DESCRIPTION
25 6010871 2 Hinge Weldment, Universal
26 2900479 1 Cap Screw, Hex Hd., 3/4-10 x 4"
27 2900467 1 Lock Nut, 3/4-10 Nylon
28 2901356 4 Flat Washer, M10
29 2900321 4 Lock Washer, M10 Split
30 2900333 4 Cap Screw, Hex Hd., M10-1.5 x 25mm
31 2503824 1 Detent Pin, 3/4" x 3" Grip
29
58
28
31
32
30
23
33
36" Blade Guard Assembly #6010958
(Includes Items #1 - #23)
28
34
10
9
11
19
18
4
7
14
8
22
21
20
12
13
17
1
25
26
3
2
15
14
24
27
6
4
5
6
11
16
36" Blade Guard Assembly #6010958
59
(Includes Items #1 - #23)
ITEM PART NO. QTY. DESCRIPTION
1 6010959 1 36" Blade Guard Front & Rear Only
2 6010081 1 Splash Flap
3 2900310 2 Cap Screw, Hex Hd., M6-1.0 x 20mm
4 2901494 4 Flat Washer, M6
5 2900083 2 Fender Washer, 1/4" x 1-1/4"
6 2900302 6 Lock Nut, M6-1.0 Nylon Insert
7 6010261 1 Water Manifold
8 2500830 1 Water Manifold Gasket
9 2900765 2 Lock Washer, M6 Split
10 2901355 2 Cap Screw, Hex Hd., M6-1.0 x 50mm
11 3200001 3 Plug, 1/8" NPT
12 3200002 1 Fitting, 3/8" M. Pipe to 3/4" M. Garden
13 2900280 1 Lanyard with Lock Pin
14 6010088 2 Water Tube for 36" Guard
15 6048155 2 W ater Tube Clamp
16 2900308 4 Cap Screw, Flat Hd., M6-1.0 x 16mm
17 1800001 1 Warning Label
18 1801369H 1 Blade Guard Size Tag
19 2900639 2 Rivet, 1/8" Dia.
20
21 2900716 1 Lock Washer, M16 Split
22 2901349 1 Cap Screw, Hex Hd., M16-2.0 x 110mm
23 6010873 1 Universal Hinge Assembly
24 6010511 1 Blade Guard Brace
25 2901356 1 Flat Washer, M10
26 2900321 1 Lock Washer, M10 Split
27 2900333
2901358 1 Flat Washer, M16
Cap Screw, Hex Hd., M10-1.5 x 25mm1
ITEM PART NO. QTY DESCRIPTION
28 6010871 2 Hinge Weldment, Universal
29 2900479 1 Cap Screw, Hex Hd., 3/4-10 x 4"
30 2900467 1 Lock Nut, 3/4-10 Nylon
31 2901356 4 Flat Washer, M10
32 2900321 4 Lock Washer, M10 Split
33 2900333 4 Cap Screw, Hex Hd., M10-1.5 x 25mm
34 2503824 1 Detent Pin, 3/4" x 3" Grip
Optional Water Pump Assembly #6011032
60
9
10
5
6
2
1
3
5
6
7
4
3
8
7
8
ITEM PART NO. QTY.
1 2600200 1 Water Pump, 12V Diaphragm
2 2900008 4
3 2900009 8 Flat Washer, 1/4" SAE
4 2900010 4
5 2701694 2
6 3200016 2
7 6010302 1 Hose Assembly, 4 Foot
8 6010303 1
9 2800062 1 Toggle Switch
10 2800063 1
Cap Screw, Hex Hd., 1/4-20 x 1"
Lock Nut, 1/4-20 Nylon
Port Fitting, 1/2" Barb x 90 Degree
Hose Clamp #8
Hose Assembly, 5 Foot
Switch Boot
DESCRIPTION
Optional Water Safety Switch Assembly #6010522
61
2
1
4
3
5
ITEM PART NO. QTY. DESCRIPTION
1 2800060 1 Water Pressure Safety Switch
2 2800062 1 Toggle Switch
3 2800063 1 Switch Boot
4 2800144 1 Relay
5 2800263 1 Relay Connector
Optional Spot Light Assembly #6010112
62
8
7
6
5
1
2
ITEM PART NO. QTY.
1 2500194 1
2 6010106 1
3 6010107 1
4 2400157 2
5 2900144 2
6 2900010 2
7 2800062 1
8 2800063 1
3
DESCRIPTION
Spot Light, 12 Volt
Light Bar
Light Bar Mount Bracket
Hand Lock Knob, 5/16-18 x 1"
Cap Screw, Hex Hd., 1/4-20 x 3/4"
Lock Nut, 1/4-20 Nylon
Toggle Switch
Switch Boot
4
5
4
Optional Magnetic Spot Light Assembly #6011170
63
1
5
2
4
1
2
3
ITEM PART NO. QTY. DESCRIPTION
1 2501087 1 Light, 12V Magnetic Base
2 2800374 1 Outlet, 12 Volt Power
3 2800375 1 Cap, 12 Volt Power Outlet
4 2800062 1 Toggle Switch On/Off
5 2800063 1 Switch Boot
Optional Glow Plug Assembly #6010596
64
1
2
3
ITEM PART NO. QTY. DESCRIPTION
1 2701698 1 Glow Plug
2 2900301 1 Lock Nut, M5 Nylon
3 2501792 1 Bumper, Recessed Rubber
Optional Loweri ng Sp eed Metering Valve Assembly #6010227
65
9
5
7
6
5
1
2
3
4
ITEM PART NO. QTY.
1 3200211 1
2 3200212 1
3 3200057 2
4 3200115 1
5 3200213 2
6 3200219 1
7 3200218 1
8 6010247 1
9 6010248 1
8
3
DESCRIPTION
Valve, 1/4" Metering
Panel Mounting Kit
Elbow, 1/4" M. Pipe to 1/4" M. JIC
Elbow, 3/8" O-Ring to 1/4" F. Pipe
Tee, 1/4" M. JIC to 1/4" M. Pipe
Adapter, 1/4" M. Pipe to 1/4" F. JIC
Check Valve
Hose Assembly, 8" Long
Hose Assembly, 20" Long
1
Optional Free Wheeling Clutch Assembly #6010179 (Sundstrand)
66
29
28
26
27
30
31
24
9
28
17
25
16
15
27
29
18
20
12
4
5
6
3
8
7
10
2
9
1
21
11
18
18
17
23
13
14
22
16
19
18
19
Optional Free Wheeling Clutch Assembly #6010179 (Sundstrand)
67
ITEM PART NO. QTY.
1 6011043 1
2
3 6011044 1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 2900014 4
19
20
21 2500152 1
22 6011050 1
23 2900063 1
24 6011051 1
25 2400007 1
26 2900125 1
27 6011099 2
28 2900008 4
29 2900010 4
30 2500375 1
31 2500007 1
2900233 1
2900508 1
2900031 1
6011089 1
2900383 1
2900024 1
2900023 2
6012055 1
6011088 1
2900061 1
6011041 1
2500374 1
6011042 1
2900117 2
2900029 2
2900018 2
2500886 1
DESCRIPTION
Clutch Clamp
Cap Screw, Soc. Hd., 5/16-18 x 1-1/2"
Clutch Brace
Cap Screw, Hex Hd., 5/16-18 x 1-1/2"
Lock Washer, 5/16" Split
Key, 1/4" Sq. x 1" Long
Fender Washer, M8
Lock Washer, 1/4" Split
Cap Screw, Hex Hd., 1/4-20 x 5/8"
Clutch Sprocket Assembly, 19 Tooth
Clutch Hub
Grease Fitting, 1/4-28 x 90 Degree
Clutch Ring with Bearing
Retaining Ring, 2" External
Clutch Yoke
Cap Screw, Soc. Hd., #10-24 x 3/8"
Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
Flat Washer, 3/8" SAE
Lock Nut, 3/8-16 Nylon
Rod End, 3/8-24 Male
Rod End, 3/8-24 Female
Engagement Lever
Woodruff Key #405, 1/8" x 5/8"
Engagement Handle
Knob, 1/2-20 x 1-3/8" Dia.
Hex Nut, 1/4-20
Lever Guide
Cap Screw, Hex Hd., 1/4-20 x 1"
Lock Nut, 1/4-20 Nylon
Compression Spring
Set Collar, 1/2" with Set Screw
20
68
Optional Parking Brake Assembly #6011228
8
23
9
23
19
7
6
22
22
21
21
12
11
10
1
4
16
13
3
17
18
2
14
15
5
Optional Parking Brake Assembly #6011228
69
ITEM PART NO. QTY.
1 6011229 1
2 2501664 1
3 6011230 1
4 6048229 1
5 6011231 1
6 2900083 1
7 2900024 1
8 2900082 1
9 6011232 1
10 2900473 1
11 2900474 1
12 2900005 1
13 6011234 1
14 2900632 1
15 2900037 1
16 2900014 2
17 2900006 2
18 2900196 2
19 6011233 1
20 2500002 1
21 2900022 2
22 2900019 2
23 2900039 2
DESCRIPTION
Bearing Housing Bar
Ball Bearing, 3/4" x 1-5/8" x 7/16"
Pivot Pin
Key, 3/16" Sq. x 1-1/4"
Pivot Arm
Fender Washer, 1/4" x 1-1/4"
Lock Washer, 1/4" Split
Cap Screw, Hex Hd., 1/4-20 x 1/2"
Brake Lever
Flat Washer, 3/8" USS
Belleville Washer, 3/8"
Cap Screw, Hex Hd., 3/8-16 x 1"
Friction Washer, 3/4" x 2-1/2" x 3/8"
T-Bolt, 1/2-13
Hex Nut, 1/2-13
Flat Washer, 3/8" SAE
Lock Washer, 3/8" Split
Cap Screw, Hex Hd., 3/8-16 x 3/4"
Lever Gate
Lever Grip
Flat Washer, 5/16" SAE
Cap Screw, Hex Hd., 5/16-18 x 3/4"
Lock Nut, 5/16-18 Nylon
Optional Blade Stacking Assembly #6010630
70
(Up to 1-1/2" width)
5
23
12
13
15
18
9
14
21
18
16
17
4
3
2
6
1
22
20
19
15
11
11
15
19
11
8
9
20
7
10
Optional Blade Stacking Assembly #6010630
71
(Up to 1-1/2" width)
ITEM PART NO. QTY. DESCRIPTION
1 6010159 1 Outer Flange 4-1/2" with Pin
2 2900002 1 Flat Washer, 5/8" SAE
3 2900113 1 Lock Washer, 5/8" Split
4 2900210 1 Cap Screw, Hex Hd., 5/8"-11 x 5" LH
5 6010620 1 20" Wide Blade Guard Assembly
ITEM PART NO. QTY.
6 6010621 1
7 6010296 1
8 2900008 2
9 2900009 4
10 2900083 2
11 2900010 8
12 6010288 1
13 2500988 1
14 2900294 2
15 3200001 3
16 3200002 1
17 2900278 1
18 6010085 2
19 6048155 2
20 2900020 4
21 3200208 1
22 1800001 1
23 6010251 1
DESCRIPTION
20" Wide Blade Guard Front & Rear Only
Splash Flap
Cap Screw, Hex Hd., 1/4-20 x 1"
Flat Washer, 1/4" SAE
Fender Washer, 1/4" x 1-1/4"
Lock Nut, 1/4-20 Nylon
Water Manifold
Water Manifold Gasket
Cap Screw, Hex Hd., 1/4-20 x 2"
Plug, 1/8" NPT
Fitting, 3/8" M. Pipe to 3/4" M. Garden
Lanyard with Lock Pin
Water Tube for 20" Guard
Water Tube Clamp
Cap Screw, Flat Hd., 1/4-20 x 3/4"
Nozzle, 1/4" NPT
Warning Label
Hinge Assembly for 20" Guard
Optional Blade Spacing Assembly #6010631
72
(Up to 2" width)
5
4
14
9
15
12
16
13
2
1
22
23
18
21
18
11
3
17
6
8
9
20
20
19
15
11
15
19
11
7
10
Optional Blade Spacing Assembly #6010631
73
(Up to 2" width)
ITEM PART NO. QTY. DESCRIPTION
1
2
3
4
5
6010186 1 Blade Shaft Extension, Left Hand Thread
6010187 1 Outer Flange 4-1/2"
2900218 1 Dowel Pin, 3/8" Dia. x 3-1/2"
2900212 1 Hex Nut, 1"-14 Left Hand
6010620 1 20" Wide Blade Guard Assembly
ITEM PART NO. QTY.
6 6010621 1
7 6010296 1
8 2900008 2
9 2900009 4
10 2900083 2
11 2900010 8
12 6010288 1
13 2500988 1
14 2900294 2
15 3200001 3
16 3200002 1
17 2900278 1
18 6010085 2
19 6048155 2
20 2900020 4
21 3200208 1
22 1800001 1
23 6010251 1
DESCRIPTION
20" Wide Blade Guard Front & Rear Only
Splash Flap
Cap Screw, Hex Hd., 1/4-20 x 1"
Flat Washer, 1/4" SAE
Fender Washer, 1/4" x 1-1/4"
Lock Nut, 1/4-20 Nylon
Water Manifold
Water Manifold Gasket
Cap Screw, Hex Hd., 1/4-20 x 2"
Plug, 1/8" NPT
Fitting, 3/8" M. Pipe to 3/4" M. Garden
Lanyard with Lock Pin
Water Tube for 20" Guard
Water Tube Clamp
Cap Screw, Flat Hd., 1/4-20 x 3/4"
Nozzle, 1/4" NPT
Warning Label
Hinge Assembly for 20" Guard
Optional Blade Spacing Assembly #6010632
74
(Up to 4" width)
5
4
24
14
16
2
1
23
22
15
12
13
9
21
3
17
6
8
9
18
11
15
11
18
11
7
10
19
20
Optional Blade Spacing Assembly #6010632
75
(Up to 4" width)
ITEM PART NO. QTY. DESCRIPTION
1
2
3
4
5 6010622 1 20" Wide Blade Guard Assembly
6010309 1 Blade Shaft Extension, Left Hand Thread
6010187 1 Outer Flange 4-1/2"
6010359 1 Drive Pin, 3/8" Dia. x 5"
2900212 1 Hex Nut, 1"-14 Left Hand
ITEM PART NO. QTY.
6 6010623 1
7 6010366 1 Splash Flap
8
9
10
11
12 6048123 2 Water Manifold
13 2500829 2 Water Manifold Gasket
14
15
16
17
18
19
20 2900020 4
21
22
23
24 6010588 1 Hose Assembly, Dual Inlet
2900008
2900009
2900083
2900010
2900294
3200001
3200002
2900278 1 Lanyard with Lock Pin
6010085 2
6048155 2
3200208
1800001 1
6010251
3
7
3
11
4
4
2
2
2
20" Wide Blade Guard Front & Rear Only
Cap Screw, Hex Hd., 1/4-20 x 1"
Flat Washer, 1/4" SAE
Fender Washer, 1/4" x 1-1/4"
Lock Nut, 1/4-20 Nylon
Cap Screw, Hex Hd., 1/4-20 x 2"
Plug, 1/8" NPT
Fitting, 3/8" M. Pipe to 3/4" M. Garden
Water Tube for 20" Guard
Water Tube Clamp
Cap Screw, Flat Hd., 1/4-20 x 3/4"
Nozzle, 1/4" NPT
Warning Label
Hinge Assembly for 20" Guard
DESCRIPTION
Optional Side Plunge Assembly #6010633
76
(Up to 6" width)
8
23
24
27
25
7
6
5
4
3
1
9
2
24
22
21
15
25
14
14
26
17
18
16
25
25
20
24
14
11
12
23
10
13
19
Optional Side Plunge Assembly #6010633
77
(Up to 6" width)
ITEM PART NO. QTY. DESCRIPTION
1
2
3
4
5
6
7
8
6010587 1
2900203 1 Dowel Pin, 3/8" Dia. x 3"
6010138 1
6010136 1 Inner Flange 8"
6010139 2 Drive Pin, 3/8" Dia. x 7-1/8"
6010137 1 Outer Flange 8"
6048346 1 Jam Nut, 1-1/2-12 Left Hand
6010624 1 20" Plunge Guard Assembly
Blade Shaft
Key, 3/8" Sq. x 7/8"
ITEM PART NO. QTY.
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
6010625 1 20" Plunge Guard Front & Rear Only
6010219 1 Splash Flap
2900008
2900009
2900083
2900010
6010190 2 Manifold Bar
2900144 4 Cap Screw, Hex Hd., 1/4-20 x 3/4"
2900241 2 U-Bolt, 1/2" Pipe
6010365 1 Water Manifold
3200153 1 Pipe Plug, 3/8" NPT
3200050 4 Nozzle, 1/8" NPT
3200209 1 Pipe Elbow, 1/2" Female
3200155 1 Fitting, 1/2" M. Pipe to 3/4" M. Garden
2500067 2 Spring, 3/8" x 4"
2900015 4 Machine Screw, Hex Hd., #10-24 x 3/4"
2900017 8 Lock Nut, #10-24 Nylon
1800001 1
6010251
3
3
3
11
2
DESCRIPTION
Cap Screw, Hex Hd., 1/4-20 x 1"
Flat Washer, 1/4" SAE
Fender Washer, 1/4" x 1-1/4"
Lock Nut, 1/4-20 Nylon
Warning Label
Hinge Assembly for 20" Guard
Optional Oil Bath Blade Shaft Assembly #6010795A (Blades 14" - 26")
78
19
18
3
17
1
20
22
21
8
4
19
18
17
9
10
11
12
13
14
15
16
25
26
24
18
17
26
16
25
15
14
13
12
11
17
18
2
5
4
7
3
10
9
6
23
Optional Oil Bath Blade Shaft Assembly #6010795A (Blades 14" - 26")
79
ITEM PART NO. QTY. DESCRIPTION
1 6010796 1 Blade Shaft Housing
2 6010797 1 Blade Shaft
3 2502197 4 Ball Bearing, 45mm x 85mm x 19mm
4 6010040 2 Key, 1/4" Sq. x 15/16"
5 4645006 1 Key, 3/8" Sq. x 4"
6 6010798 1 Shaft Tach Gear, 60 Tooth
7 2900142 2 Set Screw, Soc. Hd., 5/16-18 x 3/8"
8 2502199 1 Retaining Ring, 85mm Internal
9 2703093 2 O-Ring #042
10 6010799 2 Isolater Seal Housing
11 2503878 2 Cassette Seal
12 2503848 2 O-Ring #234
13 6010851 2 Seal Cover Plate
14 2501752 2 Seal, 1-3/4" V-Ring
15 2900020 8 Cap Screw, Flat Hd., 1/4-20 x 3/4"
16 2900418 2 Set Screw, Soc. Hd., 5/16-18 x 5/8"
17 2900002 6 Flat Washer, 5/8" SAE
18 2900113 6 Lock Washer, 5/8" Split
19 2900136 4 Cap Screw, Hex Hd., 5/8-11 x 2"
20 2800169 1 Magnetic Sensor w/Jam Nut
21 2900805 1 Sealing Washer, 5/8"
22 2502037 1 Magnetic Oil Drain Plug
23 2900146 1 Cap Screw, Hex Hd., 5/8-11 x 4"
24 2900130 1 Cap Screw, Hex Hd., 5/8-11 x 4" LH
25 6010036 2 Inner Flange 4-1/2"
26 6010037 2 Outer Flange 4-1/2" with Pin
2900197 1 Dowel Pin, 3/8" Dia. x 2"
19
80
Optional Oil Bath Blade Shaft Assembly #6010795B (Blades 30" - 36")
18
20
17
21
22
1
3
8
4
19
18
17
9
10
11
12
13
16
14 15
25
26
24
18
17
26
16
25
15
14
13
12
17
18
2
5
4
7
3
10
9
11
6
23
Optional Oil Bath Blade Shaft Assembly #6010795B (Blades 30" - 36")
81
ITEM PART NO. QTY. DESCRIPTION
1 6010796 1 Blade Shaft Housing
2 6010797 1 Blade Shaft
3 2502197 4 Ball Bearing, 45mm x 85mm x 19mm
4 6010040 2 Key, 1/4" Sq. x 15/16"
5 4645006 1 Key, 3/8" Sq. x 4"
6 6010798 1 Shaft Tach Gear, 60 Tooth
7 2900142 2 Set Screw, Soc. Hd., 5/16-18 x 3/8"
8 2502199 1 Retaining Ring, 85mm Internal
9 2703093 2 O-Ring #042
10 6010799 2 Isolater Seal Housing
11 2503878 2 Cassette Seal
12 2503848 2 O-Ring #234
13 6010851 2 Seal Cover Plate
14 2501752 2 Seal, 1-3/4" V-Ring
15 2900020 8 Cap Screw, Flat Hd., 1/4-20 x 3/4"
16 2900418 2 Set Screw, Soc. Hd., 5/16-18 x 5/8"
17 2900002 6 Flat Washer, 5/8" SAE
18 2900113 6 Lock Washer, 5/8" Split
19 2900136 4 Cap Screw, Hex Hd., 5/8-11 x 2"
20 2800169 1 Magnetic Sensor w/Jam Nut
21 2900805 1 Sealing Washer, 5/8"
22 2502037 1 Magnetic Oil Drain Plug
23 2900146 1 Cap Screw, Hex Hd., 5/8-11 x 4"
24 2900130 1 Cap Screw, Hex Hd., 5/8-11 x 4" LH
25 6010038 2 Inner Flange 6"
26 6010039 2 Outer Flange 6" with Pin
2900197 1 Dowel Pin, 3/8" Dia. x 2"
Optional Oil Expansion Tank Assembly #6010793
82
7
6
6
6
5
1
6
5
3
2
ITEM PART NO. QTY. DESCRIPTION
1 2502039 1 Expansion Tank & Cap
2 6010794 1 Hose, 1/2" ID x 60"
3 3200016 2 Hose Clamp #8
4 3200935 1 Fitting, 3/8" M. Pipe to 1/2" Hose Barb
5 2900144 2 Cap Screw, Hex Hd., 1/4-20 x 3/4"
6 2900009 4 Flat Washer, 1/4" SAE
7 2900010 2 Lock Nut, 1/4-20 Nylon
2
3
4
83
Decal Group
CORE CUT DECAL INSTRUMENT PANEL DECAL
#1800787 (Qty. 3) #1800348
RPM CHART DECAL WARNING DECAL
#1800583B #1800001
SAW LABELS SHEET GREASE DECAL
#1800351 #1800897
84
Wiring Diagram
85
Item Part No. Qty. Description Item Part No. Qty. Description
1 2800396 1 Control Panel Harness 23 2800387 1 Circuit Breaker, 25 Amp
2 2800429 1 Engine Harness (Includes #31 & #32) 2800364 1 Circuit Breaker Boot, Red
3 2800397 1 Tach Sensor Harness (Includes #29 & #30) 24 2800144 1 Relay
4 2800392 1 Relay Harness 2800263 1 Relay Connector
5 2800393 1 Hydraulic Pump Harness 2800264 4 Wire Terminal, 1/4" Push-on
6 2800073 1 Battery Cable, Positive (Red) 25 2801367 1 Emergency Stop Button
7 2800072 1 Battery Cable, Negative (Black) 26 2800388 1 Fuse Panel, 6 Circuit
8 2800095 1 Solenoid Cable, Positive (Red) 2800389 6 Fuse, 10 Amp Red ATO/ATC
9 2800182 1 Ground Cable, Negative (Black) 27 6010416 1 Tach/Hour Meter (VDO) Calibrated
10 2800465 1 Battery, 12 Volt Group Size 24 2800611 2 (Light Socket)
11 2600070 1 Hydraulic Pump Unit (Includes #12 & #13) 2800612 2 (Light Bulb, Wedge Base)
12 2700169 1 Solenoid, Motor 28 2800170 1 Magnetic Sensor (Includes #29)
13 2700243 1 Valve Coil 29 2800145 2 Connector, 2 Wire Shroud
2700244 1 Valve Stem 2800114 4 Male Terminal, 14/16 Gage Wire
14 2800372 1 Pushbutton Switch, Raise 2800174 4 Cable Seal, Gray
15 2800373 1 Pushbutton Switch, Lower 30 2800146 2 Connector, 2 Wire Tower
16 2702274 1 Starting Motor (Includes #17) 2800115 4 Female Terminal, 14/16 Gage Wire
17 2701823 1 Solenoid Switch 2800174 4 Cable Seal, Gray
18 2703192 1 Temperature Gauge, Pricol 31 2800145 1 Connector, 2 Wire Shroud
19 2700785 1 Alternator Light 2800114 1 Male Terminal, 14/16 Gage Wire
2700923 1 (Bulb Only) 2800112 1 Male Terminal, 12 Gage Wire
20 2700786 1 Oil Pressure Light 2800174 1 Cable Seal, Gray
2700923 1 (Bulb Only) 2800175 1 Cable Seal, Blue
21 2700787 1 Oil Temperature Light 32 2800146 1 Connector, 2 Wire Tower
2700923 1 (Bulb Only) 2800115 1 Female Terminal, 14/16 Gage Wire
22 2703194 1 Ignition Switch & Key 2800113 1 Female Terminal, 12 Gage Wire
2703195 1 (Ignition Key Only) 2800174 1 Cable Seal, Gray
2800175 1 Cable Seal, Blue
Options Wiring Diagram
86
Item Part No. Qty. Description Item Part No. Qty. Description
1 2800062 3 Toggle Switch 5 2600200 1 Water Pump, 12V Diaphragm
2800063 3 Switch Boot 6 2800060 1 Water Pressure Safety Switch
2 2500194 1 Spot Light, 12 Volt 7 2800144 1 Relay
3 2501087 1 Magnetic Base Light, 12 Volt 2800263 1 Relay Connector
4 2800374 1 Power Outlet, 12 Volt 2800264 4 Wire Terminal, 1/4" Push-on
2800375 1 Outlet Cap 8 2701698 1 Glow Plug
Blade Speed Conversion Charts
87
WARNING:
Blade Size
14" 3,000 4" 3,000 4" 4-1/2"
20" 2,500 4.5" 2,800 4" 7-1/2"
26" 2,100 4.5" 2,350 4" 10-1/2"
30" 1,800 6" 2,700 4" 11-3/4"
36" 1,500 6" 2,250 4" 14-3/4"
Do not exceed blade speed (RPM) shown for each blade size.
Excessive blade speed could result in blade breakage and serious personal injury!
Blade Shaft Engine
No Load RPM Sheave Size No Load RPM Sheave Size
Max. Depth
of Cut
WARNING:
Model CC6560XLS
Blade Guard Assembly
Blade Shaft Sheave
(Sheave Size)
Drive Belts (2)
(Belt Size)
Inner Flanges (2)
(Flange Size)
Outer Flanges (2)
(Flange Size)
Skid Plate
Mounting Holes
When changing blade size, use chart shown below for selecting items that must be changed.
14" 20" 26" 30" 36"
6010950 6010952 6010954 6010956 6010958
6010658
(4")
2501009
(5/3VX530)
6010036
(4.5")
6010037
(4.5")
Bottom Set Bottom Set Bottom Set Top Set Top Set
6010545
(4.5")
2501009
(5/3VX530)
6010036
(4.5")
6010037
(4.5")
6010545
(4.5")
2501009
(5/3VX530)
6010036
(4.5")
6010037
(4.5")
6013046
(6")
2500262
(5/3VX560)
6010038
(6")
6010039
(6")
6013046
(6")
2500262
(5/3VX560)
6010038
(6")
6010039
(6")
EQUIPMENT AND PARTS
WARRANTY
Diamond Products warrants all equipment manufactured by it against defects
in workmanship or materials for a period of one (1) year from the date of
shipment to Customer.
The responsibility of Diamond Products under this Warranty is limited to
replacement or repair of defective parts at Diamond Products’ Elyria, Ohio
factory, or at a point designated by it, of such parts as shall appear to us upon
inspection at such parts, to have been defective in material or workmanship,
with expense for transportation and labor borne by Customer.
In no event shall Diamond Products be liable for consequential or
incidental damages arising out of the failure of any Product to operate properly.
Integral units such as engines, electric motors, batteries, transmissions,
etc., are excluded from this Warranty and are subject to the prime
manufacturer’s warranty.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, AND ALL SUCH OTHER WARRANTIES ARE HEREBY
DISCLAIMED.
333 Prospect Street, Elyria, Ohio 44035
(440) 323-4616 • (800) 321-5336 • Fax (440) 323-8689
www.diamondproducts.com
Printed in U.S.A. #1800821
Loading...
