DFI KS211, KS212 User Manual

www.d.com
1
Chapter 1 Introduction
KS211/212
7” Touch Panel PC
User’s Manual
A27010427
www.d.com
3
Chapter 1 Introduction
Table of Contents
Copyright ����������������������������������������������������������������������������������������������������������� 2
Trademarks ������������������������������������������������������������������������������������������������������� 2
FCC and DOC Statement on Class B ���������������������������������������������������2
About this Manual �����������������������������������������������������������������������������������������4
Warranty ������������������������������������������������������������������������������������������������������������4
Static Electricity Precautions ��������������������������������������������������������������������4
Safety Measures ��������������������������������������������������������������������������������������������4
About the Package ���������������������������������������������������������������������������������������5
Chapter 1 - Introduction ���������������������������������������������������������������������������6
Overview ������������������������������������������������������������������������������������������������������� 6 Key Features ������������������������������������������������������������������������������������������������6 Specifications ����������������������������������������������������������������������������������������������� 7 Getting the Know the KS211/212 ����������������������������������������������������������9 Mechanical Dimensions ��������������������������������������������������������������������������� 10
Chapter 2 - Installation �������������������������������������������������������������� 11
Connecting Cables to Terminal Blocks ����������������������������������������������� 11 Removing the Chassis Cover ������������������������������������������������������������������12
Chapter 3 - Hardware Installation �������������������������������������������� 13
Board Layout ���������������������������������������������������������������������������������������������13 System Memory ���������������������������������������������������������������������������������������� 13 Jumper Settings ���������������������������������������������������������������������������������������� 13 Top Panel I/O Port ����������������������������������������������������������������������������������� 16
Side Panel I/O Port ���������������������������������������������������������������������������������� 16 Bottom Panel I/O Ports ��������������������������������������������������������������������������17
Chapter 4 - Mounting Options �������������������������������������������������������������� 22
Wall Mount ������������������������������������������������������������������������������������������������� 22 Panel Mount �����������������������������������������������������������������������������������������������23
Appendix A - BSP User Guide ��������������������������������������������������������������� 22
Appendix B – Android BSP Known Issue ����������������������������������������35
www.d.com
11
Chapter 2 Installation
Chapter 2 - Installation
Chapter 2
Connecting Cables to Terminal Blocks
Important:
When installing the touch panel PC, make sure the power is off. Failure to turn off, may cause severe damage to the system.
1. Insert the cable end of the power adaptor to the terminal block. To firmly fix the cable into
the terminal block, use a screwdriver to clamp down the wires to the screw that is in the terminal block.
2. Plug the terminal block into the DC-in connector and then tighten the screws to secure the terminal block in place.
Terminal block
Wire
Power adapter cable
DC-in connector
Screws
White Wire
Black Wire
+ -
