DE6241
IFU 104.5
ADDITIONAL EQUIPMENT REQUIRED:
• ELECTRIC HAND ROUTER
• 30mm ROUTER GUIDE BUSH
• TUNGSTEN CARBIDE ROUTER CUTTER - 12.7mm DIA X 50mm (1/2” DIA X 2”)
• MINIMUM OF 2 QUICK ACTION OR ‘G’ CLAMPS
Page 2
Left & Right Hand
90° Joints
Left & Right Hand
45° Joints
For 420, 500, 600, 616, 620 ,
650 & 720mm Wide Worktops
Location holes for flush fitting
location pegs
Rout recesses for Worktop
Connecting Bolts
Rout recesses for
100mm x 50mm
desk top cable tidy
inserts. & carrying
handle
Worktop pegs
storage facility
Rout recesses for
80mm circular desk
top cable tidy
inserts.
Denotes Female Denotes Male
Location slot for
screw clamp
DE6289
