You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make
DeWALT one of the most reliable partners for professional power toolusers.
Technical Data
DCH143DCH243DCH253DCH254DCH273DCH274
VoltageV
Type112211
Max power outputW400400400400400400
No-load speedmin-10–11000–11500–12000–12000–11000–1100
Impact ratebpm0–43500–44000–45000–45000–46000–4600
Single impact energy (EPTA 05/2009)J2.02.12.12.12.12.1
Maximum drilling range in
steel/wood/concretemm10/20/2013/26/2013/26/2413/26/2413/26/2413/26/24
ChuckSDS Plus
Noise and vibration total values (triax vector sum) according to EN60745-2-6:
LPA (emission sound pressure level)
LWA (sound power level)
K
(uncertainty for the given sound level)
14.41818181818
DC
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
dB(A)868686868686
dB(A)979797979797
dB(A)333333
®
Drilling into concrete
Vibration emission value a
=m/s²6.67.46.66.66.66.6
h, HD
Uncertainty K =m/s²1.51.51.51.51.51.5
Chiselling
Vibration emission value a
=m/s²5.46.05.45.45.45.4
,
Cheq
h
Uncertainty K =m/s²1.51.51.51.51.51.5
Drilling into metal
Vibration emission value ah,D =m/s²≤ 2.5≤ 2.5≤ 2.5≤ 2.5≤ 2.5≤ 2.5
Uncertainty K =m/s²1.51.51.51.51.51.5
Screwdriving
Vibration emission value ah =m/s²≤ 2.5≤ 2.5≤ 2.5≤ 2.5≤ 2.5≤ 2.5
Uncertainty K =m/s²1.51.51.51.51.51.5
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment ofexposure.
WARNING: The declared vibration
emission level represents the main
4
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase
the exposure level over the total
workingperiod.
English
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
workingperiod.
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of workpatterns.
declares that these products described
under Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010,
EN60745-2-6:2010.
These products also comply with Directive
2004/108/EC (until 19.04.2016), 2014/30/EU (from
20.04.2016) and 2011/65/EU. For more information,
please contact
refer to the back of the manual.
The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf of
Markus Rompel
Director Engineering
D-65510, Idstein, Germany
06.11.2015
WARNING: To reduce the risk of injury,
.
, Richard-Klinger-Straße 11,
read the instructionmanual.
at the following address or
General Power Tool Safety Warnings
WARNING! Read all safety warnings
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) powertool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
b) Do not operate power tools in explosive
and all instructions. Failure to follow
the warnings and instructions may
result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
Cluttered or dark areas inviteaccidents.
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
orfumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to losecontrol.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electricshock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed orgrounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electricshock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electricshock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electricshock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of
electricshock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personalinjury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personalinjuries.
c) Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invitesaccidents.
6
English
d) Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personalinjury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpectedsituations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair
can be caught in movingparts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce
dust-relatedhazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
wasdesigned.
b) Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the switch
is dangerous and must berepaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive safety
measures reduce the risk of starting the
power toolaccidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrainedusers.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained powertools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier tocontrol.
g) Use the power tool, accessories and
tool bits etc., in accordance with these
instructions taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardoussituation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
batterypack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury andfire.
c) When battery pack is not in use, keep it
away from other metal objects like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or afire.
d) Under abusive conditions, liquid may be
ejected from the battery, avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation orburns.
6) SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool ismaintained.
Additional Safety Instructions for
Rotary Hammers
• Wear ear protectors. Exposure to noise can
cause hearingloss.
• Use auxiliary handles supplied with the tool.
Loss of control can cause personalinjury.
• Hold power tools by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring. Contact with a “live” wire will make
exposed metal parts of the tool “live” and could
give the operator an electricalshock.
• Use clamps or other practical way to secure
and support the workpiece to a stable
platform. Holding the work by hand or against
your body is unstable and may lead to loss
ofcontrol.
• Wear safety goggles or other eye protection.
Hammering operations cause chips to fly. Flying
particles can cause permanent eye damage.
Wear a dust mask or respirator for applications
that generate dust. Ear protection may be
required for mostapplications.
7
English
DeWALT
• Keep a firm grip on the tool at all times.
Do not attempt to operate this tool
without holding it with both hands. It is
recommended that the side handle be used at
all times. Operating this tool with one hand will
result in loss of control. Breaking through or
encountering hard materials such as re-bar may
be hazardous as well. Tighten the side handle
securely beforeuse.
• Do not operate this tool for long periods of
time. Vibration caused by hammer action may
be harmful to your hands and arms. Use gloves
to provide extra cushion and limit exposure by
taking frequent restperiods.
• Do not recondition bits yourself. Chisel
reconditioning should be done by an authorized
specialist. Improperly reconditioned chisels
could causeinjury.
• Wear gloves when operating tool or
changing bits. Accessible metal parts on the
tool and bits may get extremely hot during
operation. Small bits of broken material may
damage barehands.
• Never lay the tool down until the bit has
come to a complete stop. Moving bits could
causeinjury.
• Do not strike jammed bits with a hammer to
dislodge them. Fragments of metal or material
chips could dislodge and causeinjury.
• Slightly worn chisels can be resharpened
bygrinding.
• Keep the power cord away from the rotating
bit. Do not wrap the cord around any part of
your body. An electric cord wrapped around a
spinning bit may cause personal injury and loss
ofcontrol.
Residual Risks
The following risks are inherent to the use of rotary
hammers:
– Injuries caused by touching the rotating parts or
hot parts of thetool.
In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:
– Impairment ofhearing.
– Risk of squeezing fingers when changing
theaccessory.
– Health hazards caused by breathing dust
developed when working in concrete and/
ormasonry.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
DATE CODE POSITION
The date code, which also includes the year of
manufacture, is printed into the housing surface that
forms the mounting joint between tool andbattery.
Example:
2016 XX XX
Year of Manufacture
Important Safety Instructions for All
Battery Chargers
SAVE THESE INSTRUCTIONS: This manual
contains important safety and operating instruc tions
for compatible batterychargers.
• Before using charger, read all instructions and
cautionary markings on charger, battery pack,
and product using batterypack.
WARNING: Shock hazard. Do not allow
WARNING: We recommend the use of
CAUTION: Burn hazard. To reduce
CAUTION: Children should be
NOTICE: Under certain conditions, with
any liquid to get inside charger. Electric
shock mayresult.
a residual current device with a residual
current rating of 30mA or less.
the risk of injury, charge only
rechargeable batteries. Other types of
batteries may burst causing personal
injury anddamage.
supervised to ensure that they do not
play with theappliance.
the charger plugged in to the power
supply, the charger can be shorted by
foreign material. Foreign materials of
a conductive nature such as, but not
limited to, grinding dust, metal chips,
steel wool, aluminum foil, or any buildup
of metallic particles should be kept away
from charger cavities. Always unplug the
charger from the power supply when
8
English
DeWALT
DeWALT
there is no battery pack in the cavity.
Unplug charger before attempting
toclean.
• DO NOT attempt to charge the battery pack
with any chargers other than the ones in
this manual. The charger and battery pack are
specifically designed to worktogether.
• These chargers are not intended for
any uses other than charging
rechargeable batteries. Any other uses
may result in risk of fire, electric shock
orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when
disconnecting charger. This will reduce risk
of damage to electric plug andcord.
• Make sure that cord is located so that it
will not be stepped on, tripped over, or
otherwise subjected to damage orstress.
• Do not use an extension cord unless it
is absolutely necessary. Use of improper
extension cord could result in risk of fire,
electric shock, orelectrocution.
• Do not place any object on top of charger
or place the charger on a soft surface that
might block the ventilation slots and result
in excessive internal heat. Place the charger
in a position away from any heat source. The
charger is ventilated through slots in the top and
the bottom of thehousing.
• Do not operate charger with damaged cord
or plug — have them replacedimmediately.
• Do not operate charger if it has received
a sharp blow, been dropped, or otherwise
damaged in any way. Take it to an authorised
servicecentre.
• Do not disassemble charger; take it to an
authorised service centre when service or
repair is required. Incorrect reassembly may
result in a risk of electric shock, electrocution
orfire.
• In case of damaged power supply cord the
supply cord must be replaced immediately by
the manufacturer, its service agent or similar
qualified person to prevent anyhazard.
• Disconnect the charger from the outlet
before attempting any cleaning. This will
reduce the risk of electric shock. Removing
the battery pack will not reduce thisrisk.
• NEVER attempt to connect 2 chargerstogether.
• The charger is designed to operate on
standard 230V household electrical
power. Do not attempt to use it on any
other voltage. This does not apply to the
vehicularcharger.
SAVE THESE INSTRUCTIONS
Chargers
The DCB105, DCB107, DCB112, DCB113 and
DCB115 chargers accept 10.8V, 14.4V and 18V
Li-Ion XR (DCB123, DCB127, DCB140, DCB141,
DCB142, DCB143, DCB144, DCB145, DCB180,
DCB181, DCB182, DCB183, DCB183B, DCB184,
DCB184B and DCB185) battery packs.
chargers require no adjustment and are
designed to be as easy as possible tooperate.
Charging Procedure (Fig.3)
1. Plug the charger into an appropriate outlet
before inserting batterypack.
2. Insert the battery pack(F) into the charger.
The red (charging) light will blink continuously
indicating that the charging process hasstarted.
3. The completion of charge will be indicated by
the red light remaining ON continuously. The
pack is fully charged and may be used at this
time or left in thecharger.
NOTE: To ensure maximum performance and life of
Li-Ion batteries, charge the battery pack fully before
firstuse.
Charging Process
Refer to the table below for the charge status of the
battery pack.
Charge indicators: DCB105
charging
fully charged
hot/cold pack delay
replace battery pack
Charge indicators: DCB107, DCB112, DCB113, DCB115
charging
fully charged
hot/cold pack delay*
* DCB107, DCB112, DCB113, DCB115: The red
light will continue to blink, but a yellow indicator
light will be illuminated during this operation.
Once the battery has reached an appropriate
temperature, the yellow light will turn off and the
charger will resume the charging procedure.
9
English
DeWALT
DeWALT
The compatible charger(s) will not charge a faulty
battery pack. The charger will indicate faulty battery
by refusing to light or by displaying problem pack or
charger blink pattern.
NOTE: This could also mean a problem with a
charger.
If the charger indicates a problem, take the charger
and battery pack to be tested at an authorised
service centre.
HOT/COLD PACK DELAY
When the charger detects a battery that is too hot
or too cold, it automatically starts a Hot/Cold Pack
Delay, suspending charging until the battery has
reached an appropriate temperature. The charger
then automatically switches to the pack charging
mode. This feature ensures maximum battery life.
A cold battery pack will charge at about half the rate
of a warm battery pack. The battery pack will charge
at that slower rate throughout the entire charging
cycle and will not return to maximum charge rate
even if the battery warms.
LITHIUM-ION BATTERY PACKS ONLY
XR Li-Ion tools are designed with an Electronic
Protection System that will protect the battery
against overloading, overheating or deep discharge.
The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place
the lithium-ion battery on the charger until it is fully
charged.
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure
to include catalogue number andvoltage.
The battery pack is not fully charged out of the
carton. Before using the battery pack and charger,
read the safety instructions below. Then follow
charging proceduresoutlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting
or removing the battery from the charger may
ignite the dust orfumes.
• Never force battery pack into charger. Do
not modify battery pack in any way to fit into
a non-compatible charger as battery pack
may rupture causing serious personalinjury.
• Charge the battery packs only in
chargers.
• DO NOT splash or immerse in water or
otherliquids.
• Do not store or use the tool and battery
pack in locations where the temperature
may reach or exceed 40 ˚C (105 ˚F) (such as
outside sheds or metal buildings in summer).
WARNING: Never attempt to open the
CAUTION: When not in use, place
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION
(Li-Ion)
• Do not incinerate the battery pack even if it
• If battery contents come into contact with
• Contents of opened battery cells may cause
WARNING: Burn hazard. Battery liquid
battery pack for any reason. If battery
pack case is cracked or damaged,
do not insert into charger. Do not
crush, drop or damage battery pack.
Do not use a battery pack or charger
that has received a sharp blow, been
dropped, run over or damaged in any
way (i.e., pierced with a nail, hit with a
hammer, stepped on). Electric shock
or electrocution may result. Damaged
battery packs should be returned to
service centre forrecycling.
tool on its side on a stable surface
where it will not cause a tripping
or falling hazard. Some tools with
large battery packs will stand upright
on the battery pack but may be easily
knockedover.
is severely damaged or is completely worn
out. The battery pack can explode in a fire.
Toxic fumes and materials are created when
lithium ion battery packs areburned.
the skin, immediately wash area with mild
soap and water. If battery liquid gets into the
eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte
is composed of a mixture of liquid organic
carbonates and lithiumsalts.
respiratory irritation. Provide fresh air. If
symptoms persists, seek medicalattention.
may be flammable if exposed to spark
orflame.
Transportation
batteries comply with all applicable
shipping regulations as prescribed by industry and
legal standards which include UN Recommendations
on the Transport of Dangerous Goods; International
Air Transport Association (IATA) Dangerous Goods
10
English
DeWALT
DeWALT
DeWALT
DeWALT
DeWALT
DeWALT
Regulations, International Maritime Dangerous
Goods (IMDG) Regulations, and the European
Agreement Concerning The International Carriage
of Dangerous Goods by Road (ADR). Lithium-ion
cells and batteries have been tested to section 38.3
of the UN Recommendations on the Transport of
Dangerous Goods Manual of Tests andCriteria.
In most instances, shipping a
will be excepted from being classified as a fully
regulated Class 9 Hazardous material. In general, the
two instances that require shipping Class 9 are:
1. Air shipping more than two
battery packs when the package contains only
battery packs (no tools), and
2. Any shipment containing a lithium-ion battery
with an energy rating greater than 100 watt
hours (Wh). All lithium-ion batteries have the
watt hour rating marked on thepack.
Regardless of whether a shipment is
considered excepted or fully regulated, it is the
shipper's responsibility to consult the latest
regulations for packaging, labeling/marking and
documentationrequirements.
Transporting batteries can possibly cause fire if the
battery terminals inadvertently come in contact with
conductive materials. When transporting batteries,
make sure that the battery terminals are protected
and well insulated from materials that could contact
them and cause a shortcircuit.
The information provided in this section of the
manual is provided in good faith and believed to be
accurate at the time the document was created.
However, no warranty, expressed or implied, is
given. It is the buyer’s responsibility to ensure that its
activities comply with the applicableregulations.
battery pack
lithium-ion
Battery Pack
BATTERY TYPE
The DCH143 operates on 14.4 V battery packs. The
DCH243, DCH253, DCH254, DCH273 and DCH274
operate on 18 V batterypacks.
The DCB140, DCB141, DCB142, DCB143,
DCB144 or DCB145 battery packs (14.4 V) may be
used on theDCH143.
The DCB180, DCB181, DCB182, DCB183,
DCB183B, DCB184, DCB184B or DCB185
battery packs (18 V) may be used on the DCH243,
DCH253, DCH254, DCH273 andDCH274.
Storage Recommendations
1. The best storage place is one that is cool and
dry away from direct sunlight and excess heat
or cold. For optimum battery performance and
life, store battery packs at room temperature
when not inuse.
2. For long storage, it is recommended to store a
fully charged battery pack in a cool, dry place
out of the charger for optimalresults.
NOTE: Battery packs should not be stored
completely depleted of charge. The battery pack will
need to be recharged beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual,
the labels on the charger and the battery pack may
show the following pictographs:
Read instruction manual before use.
See Technical Data for charging time.
Battery charging.
Battery charged.
Battery defective.
Hot/cold pack delay.
Do not probe with conductive objects.
Do not charge damaged battery packs.
Do not expose to water.
Have defective cords replaced
immediately.
Charge only between 4 ˚C and 40 ˚C.
Only for indoor use.
Discard the battery pack with due care
for the environment.
Charge
designated
battery packs other than the designated
charger may make them burst or lead to
other dangerous situations.
battery packs only with
batteries with a
chargers. Charging
11
English
Do not incinerate the battery pack.
Package Contents
The package contains:
1 Cordless rotary hammerdrill
1 Side handle and depth rod
1 Charger
1 Battery pack (D1, L1, M1, P1)
2 Battery packs (D2, L2, M2, P2)
3 Battery packs (D3, L3, M3, P3)
NOTE: Battery packs and chargers are not included
with N-models.
• Check for damage to the tool, parts or
accessories which may have occurred
duringtransport.
• Take the time to thoroughly read and
understand this manual prior tooperation.
Description (Fig.1, 3, 7)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury couldresult.
A. Variable speed switch
B. Forward/reverse button
C. Mode selector
D. Worklight (DCH143, DCH253, DCH254,
DCH273, DCH274)
E. Side handle
F. Battery pack
G. Release button
H. Main handle
I. Drill bit symbol (rotary drilling mode)
J. Hammerdrilling symbol (rotary hammering
mode)
K. Hammer symbol (hammering only mode)
L. SDS Plus® tool holder
M. Sleeve
N. Fuel gauge button
O. Dust cover
P. Locking collar
Q. Keyless chuck (DCH254, DCH274)
R. Belt hook (DCH273, DCH274)
S. Mode selector button
T. Dust extraction system electrical connection
INTENDED USE
Your DCH143, DCH243, DCH253, DCH254,
DCH273 and DCH274 cordless rotary hammerdrills
have been designed for professional drilling and
hammerdrilling applications, as well as screwdriving
and chippingapplications.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
These hammerdrills are professional powertools.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use thistool.
• Young children and the infirm. This appliance
is not intended for use by young children or
infirm persons without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
thisproduct.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of yourmains.
Your DeWALT charger is double insulated
in accordance with EN60335; therefore
no earth wire isrequired.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DeWALT serviceorganization.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in
theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be
made to the earthterminal.
12
English
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm2; the maximum length is 30m.
When using a cable reel, always unwind the
cablecompletely.
ASSEMBLY AND ADJUSTMENTS
WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the batterypack.
WARNING: Use only DeWALT battery
packs andchargers.
Inserting and Removing the
Battery Pack from the Tool (Fig.3)
WARNING: To reduce the risk of injury,
never depress the battery release button
without removing the battery pack.
Depressing the battery release button
without removing the battery pack
can result in the battery pack falling
outunexpectedly.
NOTE: For best results, make sure your battery
pack is fullycharged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack(F) with the rails inside the
tool’s handle (Fig.3).
2. Slide it into the handle until the battery pack is
firmly seated in the tool and ensure that it does
notdisengage.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the battery release button(G) and firmly
pull the battery pack out of the toolhandle.
2. Insert battery pack into the charger as
described in the charger section of thismanual.
FUEL GAUGE BATTERY PACKS (FIG.3)
Some DeWALT battery packs include a fuel gauge
which consists of three green LED lights that indicate
the level of charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel
gauge button(N). A combination of the three green
LED lights will illuminate designating the level of
charge left. When the level of charge in the battery
is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the
charge left on the battery pack. It does not indicate
tool functionality and is subject to variation based
on product components, temperature and enduserapplication.
Variable Speed Switch (Fig.1)
To turn the tool on, squeeze the trigger switch(A). To
turn the tool off, release the trigger switch. Your tool
is equipped with a brake. The tool holder will stop as
soon as the trigger switch is fullyreleased.
The variable speed trigger switch enables you to
select the best speed for a particular application.
The farther you squeeze the trigger switch, the faster
the tool will operate. For maximum tool life, use
variable speed only for starting holes orfasteners.
NOTE: Continuous use in variable speed range is
not recommended. It may damage the switch and
should beavoided.
Side Handle (Fig.1)
WARNING: To reduce the risk of
personal injury, ALWAYS operate
the tool with the side handle properly
installed. Failure to do so may result
in the side handle slipping during tool
operation and subsequent loss of
control. Hold tool with both hands to
maximizecontrol.
The side handle(E) clamps to the front of the gear
case and may be rotated 360˚ to permit right- or
left-hand use. The side handle must be tightened
sufficiently to resist the twisting action of the tool if
the accessory binds or stalls. Be sure to grip the
side handle at the far end to control the tool
during astall.
To loosen side handle, rotatecounterclockwise.
Forward/Reverse Control Button
(Fig.1, 2)
WARNING: Always wait until the motor
has come to a complete standstill
before changing the direction ofrotation.
A forward/reverse control button(B) determines
the direction of the tool and also serves as a lock
offbutton.
To select forward rotation, release the trigger switch
and depress the for ward/re verse control button on
the right side of thetool.
To select reverse, release the trigger switch and
depress the forward/reverse control button on the
left side of thetool.
13
English
The center position of the control button locks the
tool in the off position. When changing the position
of the control button, be sure the trigger isreleased.
NOTE: The first time the tool is run after changing
the direction of rotation, you may hear a click on
start up. This is normal and does not indicate
aproblem.
Worklight (Fig.1)
DCH143, DCH253, DCH254, DCH273, DCH274
There is a worklight(D) located on the front of the
tool. The worklight will be activated when the trigger
switch is squeezed. The worklight is activated
when the trigger switch is depressed, and will
automatically turn off 20 seconds after the trigger
switch is released. If the trigger switch remains
depressed, the worklight will remainon.
NOTE: The worklight is for lighting the immediate
work surface and is not intended to be used as
aflashlight.
Selecting the Operating Mode (Fig.1)
WARNING: Do not select the operating
mode when the tool isrunning.
Your tool is equipped with a separate mode
selector(C) to switch between rotary drilling, rotary
hammering and hammering onlymode.
Rotary drilling: for screwdriving and for drilling
into steel, wood andplastics.
Rotary hammering: for concrete and
masonrydrilling.
Hammering only: for lightchipping.
Before attempting to rotate the mode selector
depress the mode selector button(S). For rotary
drilling, rotate the mode selector(C) until the arrow
points to the drill bit symbol(I). For rotary hammering
mode, align the arrow with the hammerdrilling
symbol(J). For hammering only mode, align arrow
with the hammer symbol(K).
NOTE: The mode selector(C) must be in rotary
drilling, rotary hammering or hammering only
mode at all times. There are no operable positions
inbetween.
Active Vibration Control
The active vibration control neutralises rebound
vibration from the hammer mechanism. Lowering
hand and arm vibration, it allows more comfortable
use for longer periods of time and extends the life of
the unit. In operation, a spring loaded mechanism
counterbalances the vibration forces. This can be
sensed by the cushioning effect when pressure is
applied to the tool. Make sure the spring is engaged
but not too firmly. The mechanism should be
allowed to "float."
Belt Hook (Fig.1, 4)
DCH273, DCH274
A belt hook(R) is fitted below the main handle(H) on
the left side of the tool. To extend the belt hook pull
it out from the side of the tool. To store the belt hook
push it back flush with the side of thetool. The belt
hook(R) can be positioned to the left or right of the
tool to accommodate left or right-handed users.
1. Position the belt hook into the extended position
and remove the hex head screw located on the
underside of the main handle.
2. Pull out the belt hook until it is free from the unit.
3. Reinsert the belt hook into the desired side and
push it into the slot.
NOTE: On some models the slot may be
covered with a sticker. Either remove the
sticker or pierce the sticker to expose the slot
underneath.
4. Re-insert the hex screw and tighten securely.
If use of the hook is not desired at all, it can be
removedcompletely.
SDS Plus® Tool Holder (Fig.5)
To insert a drill or chisel bit, insert the shank of
the bit about 19 mm (3/4") into SDS Plus® tool
holder(L). Push and rotate bit until it locks in place.
The bit will be securelyheld.
To release bit, pull the sleeve(M) back and remove
thebit.
Replacing the SDS Plus® Tool Holder
with the Keyless Chuck (Fig.7)
DCH254, DCH274
1. Turn the locking collar(P) into the unlocked
position and pull the SDS Plus® tool
holder(L)off.
2. Push the keyless chuck(Q) onto the spindle and
turn the locking collar into the lockingposition.
3. To replace the keyless chuck with the
SDS Plus® tool holder, first remove the keyless
chuck the same way as the SDS Plus® tool
holder was removed. Then replace the
SDS Plus® tool holder the same way as the
keyless chuck wasreplaced.
14
English
WARNING: Never use standard chucks
in the rotary hammeringmode.
Overload Clutch
There are two different types of overload clutch
fitted. The DCH143, DCH243, DCH253 and
DCH254 have a mechanical overload clutch, the
DCH273 and DCH274 have an electronic overload
clutch fitted.
In case of jamming of a drill bit, the drive to the
drill spindle is interrupted. On units fitted with a
mechanical clutch the indication that the clutch has
activated will be an audible ratcheting together with
increased vibration. If the electronic clutch activates
the motor is repeatedly switched on and off for a few
seconds to replicate the feedback associated with a
mechanical clutch. Release and depress the trigger
to re-engage drive.
Because of the resulting forces, always hold the tool
with both hands and take a firmstance.
Dust Extraction System (Fig.1)
A dedicated integrated dust extraction
system (D25303DH) is available and can be
purchasedseparately.
To operate the D25303DH uses an electrical
connection(T) to the rotary hammer.
The DCH253, DCH254 (TYPE 2 Only), DCH273,
and DCH274 rotary hammer models are equipped
with the electrical connection(T).
NOTE: The D25303DH is not compatible with
the DCH143, DCH243 or TYPE 1 versions of the
DCH253 and DCH254.
The DCH274 is available supplied complete with a
D25303DH and extended kit box as the DCH275.
OPERATION
Instructions for Use
WARNING:
• Always observe the safety instructions
and applicableregulations.
• Be aware of the location of pipework
andwiring.
• Apply only a gentle pressure to
the tool (approx. 5 kg). Excessive
force does not speed up drilling but
decreases tool performance and may
shorten toollife.
• Do not drill or drive too deep to
prevent damage to the dust cover(O).
• Always hold the tool firmly with both
hands and ensure a secure stance.
Always operate the tool with the side
handle properlymounted.
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments
oraccessories.
Proper Hand Position (Fig.1, 6)
WARNING: To reduce the risk of
serious personal injury, ALWAYS
use proper hand position as shown
in figure6.
WARNING: To reduce the risk of
serious personal injury, ALWAYS
hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the
main handle(H), with the other hand on the side
handle(E).
Drill Operation (Fig.1)
WARNING: To reduce the risk of
serious personal injury, turn tool off
and disconnect tool from power
source before making any adjustments
or removing/installing attachments
oraccessories.
WARNING: To reduce the risk of
personal injury, ALWAYS ensure
workpiece is anchored or clamped
firmly. If drilling thin material, use a wood
“back-up” block to prevent damage to
thematerial.
HAMMERDRILLING (FIG.1)
1. Set the mode selector switch(C) to the "rotary
hammering"position.
2. Insert the appropriate drill bit. For best results
use high quality carbide-tippedbits.
3. Adjust the side handle(E) asrequired.
4. Mark the spot where the hole is to bedrilled.
5. Place the drill bit on the spot and switch on
thetool.
ROTARY DRILLING (FIG.1)
1. Set the mode selector switch(C) to the "rotary
drilling"position.
2. Depending on your tool, follow either of the
following instructions:
15
English
DeWALT
DeWALT
– Fit a chuck adaptor/chuck assembly
(DCH143, DCH243, DCH253, DCH273).
Special SDS Plus® adaptors with threaded
sections are available for use with standard
10 or 13 mm chucks to enable straight shank
bits to beused.
– Replace the SDS Plus® tool holder with the
keyless chuck (DCH254, DCH274).
3. Proceed as described for rotaryhammering.
WARNING: Never use standard chucks
in the rotary hammeringmode.
SCREWDRIVING (FIG.1)
1. Set the mode selector switch(C) to the "rotary
drilling"position.
2. Select the direction ofrotation.
3. Depending on your tool, follow either of the
following instructions:
– Insert the special SDS Plus® screwdriving
adaptor for use with hexagonal screwdriver
bits (DCH143, DCH243, DCH253, DCH273).
– Replace the SDS Plus® tool holder with the
keyless chuck (DCH254, DCH274).
4. Insert the appropriate screwdriver bit. When
driving slotted head screws always use bits with
a findersleeve.
5. Gently press the variable speed switch(A) to
prevent damage to the screw head. In reverse
(LH) rotation the tool speed is automatically
reduced for easy screwremoval.
6. When the screw is flush with the workpiece,
release the variable speed switch to prevent
the screw head from penetrating into
theworkpiece.
CHIPPING (FIG.1)
1. Set the mode selector switch(C) to the
"hammering only"position.
2. Insert the appropriate chisel and check if it is
properlylocked.
3 Adjust the side handle(E) asrequired.
4. Switch on the tool and startworking.
It may be necessary to briefly run the motor after
having changed from chiselling to rotary modes in
order to align thegears.
WARNING:
• Do not use this tool to mix or pump
easily combustible or explosive fluids
(benzine, alcohol, etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.
MAINTENANCE
Your DeWALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regularcleaning.
WARNING: To reduce the risk of
This machine is not user-serviceable. Take the
tool to an authorised
approximately 40 hours of use. If problems occur
before this time contact an authorised
repairagent.
The charger and battery pack are not serviceable.
There are no serviceable partsinside.
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up
can causeinjury.
repair agent after
Lubrication
Your power tool requires no additionallubrication.
Cleaning
WARNING: Blow dirt and dust out of
WARNING: Never use solvents or
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect
the main housing with dry air as often as
dirt is seen collecting in and around the
air vents. Wear approved eye protection
and approved dust mask when
performing thisprocedure.
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into aliquid.
the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the
charger using a cloth or soft nonmetallic brush. Do not use water or any
cleaningsolutions.
16
Optional Accessories
WARNING: Since accessories, other
than those offered by DeWALT, have
not been tested with this product, use
of such accessories with this tool could
be hazardous. To reduce the risk of
injury, only DeWA LT recommended
accessories should be used with
thisproduct.
Various types of SDS Plus® drill bits and chisels are
available as anoption.
Accessories and attachments used must be
regularly lubricated around the SDS Plus®fitment.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries
marked with this symbol must not be
disposed of with normal household waste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
English
Rechargeable Battery Pack
This long life battery pack must be recharged when
it fails to produce sufficient power on jobs which
were easily done before. At the end of its technical
life, discard it with due care for our environment:
• Run the battery pack down completely, then
remove it from thetool.
• Li-Ion cells are recyclable. Take them to your
dealer or a local recycling station. The collected
battery packs will be recycled or disposed of
properly.
