DeWalt DCH213, DCH214 User Manual

DCH213

www .

.eu

DCH214

Figure 1

m

l

c

k

j

i

d

e

b

a

h

g

f

Figure 2

b

1

Figure 3

Figure 5

Figure 4

f

g

f

2

l

m

Figure 6

Figure 7

DCH214

n

o

o

p

3

ENGLISH

HEAVY-DUTY CORDLESS ROTARY HAMMERDRILL
DCH213, DCH214

The vibration emission level given in this information

Congratulations!

You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional power tool users.

Technical Data

DCH213 DCH214

Voltage VDC 18 18
Type 1 1
No-load speed min-1 0–1100 0–1100
Impact rate min-1 0–4200 0–4200
Impact energy (EPTA 05/2009) J 2 2
Maximum drilling range

in steel/wood/concrete mm 13/26/20 13/26/20
Chuck SDS Plus® SDS Plus
Collar diameter mm 54 54
Battery Type Li-Ion Li-Ion
Weight (without battery pack) kg 2.3 2.5

LPA (sound pressure) dB(A)
KPA (sound pressure uncertainty) dB(A)
LWA (sound power) dB(A)
KWA (sound power uncertainty) dB(A)

Vibration total values (triax vector sum) determined according to
EN 60745:

h

h

h

h

Vibration emission value a
Drilling into concrete
a

Vibration emission value a
Chiselling
a

Vibration emission value a
Drilling into metal
a

Vibration emission value a
Screwdriving
ah =

=

h,HD

Uncertainty K = m/s²

=

h,Cheq

Uncertainty K = m/s²

=

h,D

Uncertainty K = m/s²

Uncertainty K = m/s²

86 86

3 3

97 97

2.9 2.9

m/s² 6.9 6.9

1.5 1.5

m/s²

5.3 5.3

1.5 1.5

m/s²

≤ 2.5 ≤ 2.5

1.5 1.5

m/s²

≤ 2.5 ≤ 2.5

1.5 1.5

sheet has been measured in accordance with a
standardised test given in EN 60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.

An estimation of the level of exposure to

®

Identify additional safety measures to

Battery pack DCB180 DCB181

Battery type Li-Ion Li-Ion
Voltage VDC 18 18
Capacity Ah 3.0 1.5
Weight kg 0.64 0.35

Charger DCB105

Mains voltage VAC 230 V
Battery type Li-Ion
Approx. charging time min 30 60

(1.5 Ah (3.0 Ah
battery packs) battery packs)

Weight kg 0.49

Fuses:

Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 3 Amperes, in plugs

WARNING: The declared vibration

emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase the
exposure level over the total working
period.

vibration should also take into account
the times when the tool is switched off
or when it is running but not actually
doing the job. This may significantly
reduce the exposure level over the total
working period.

protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.

32

ENGLISH

Defi nitions: Safety Guidelines

The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.

DANGER: Indicates an imminently

NOTICE: Indicates a practice not

Denotes risk of electric shock.

Denotes risk of fire.

hazardous situation which, if not avoided,
will result in death or serious injury.

WARNING: Indicates a potentially

hazardous situation which, if not
avoided, could result in death or
serious injury.

CAUTION: Indicates a potentially

hazardous situation which, if not
avoided, may result in minor or

moderate injury.

related to personal injury which, if
not avoided, may result in property
damage.

EC-Declaration of Conformity

MACHINERY DIRECTIVE

DCH213, DCH214

DEWALT declares that these products described
under Technical Data are in compliance with:
2006/42/EC, EN 60745-1, EN60745-2-6.

These products also comply with Directive
2004/108/EC. For more information, please contact
D

EWALT at the following address or refer to the

back of the manual.
The undersigned is responsible for compilation of the

technical file and makes this declaration on behalf of

EWALT.

D

Horst Grossmann
Vice President Engineering and Product
Development
DEWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany

02.02.2011

WARNING: To reduce the risk of injury,

read the instruction manual.

General Power Tool Safety Warnings

WARNING! Read all safety warnings

The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery­operated (cordless) power tool.

1) WORK AREA SAFETY

a) Keep work area clean and well lit.

b) Do not operate power tools in explosive

c) Keep children and bystanders away while

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet.

b) Avoid body contact with earthed or

c) Do not expose power tools to rain or wet

d) Do not abuse the cord. Never use the

e) When operating a power tool outdoors,

f) If operating a power tool in a damp

and all instructions. Failure to follow
the warnings and instructions may result
in electric shock, fire and/or serious
injury.

SAVE ALL WARNINGS AND INSTRUCTIONS

FOR FUTURE REFERENCE

Cluttered or dark areas invite accidents.

atmospheres, such as in the presence of
flammable liquids, gases or dust. Power

tools create sparks which may ignite the dust
or fumes.

operating a power tool. Distractions can
cause you to lose control.

Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs

and matching outlets will reduce risk of
electric shock.

grounded surfaces such as pipes,
radiators, ranges and refrigerators. There

is an increased risk of electric shock if your
body is earthed or grounded.

conditions. Water entering a power tool will
increase the risk of electric shock.

cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase the
risk of electric shock.

use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use

reduces the risk of electric shock.

location is unavoidable, use a residual
current device (RCD) protected supply.

Use of an RCD reduces the risk of electric
shock.

33

ENGLISH

3) PERSONAL SAFETY

a) Stay alert, watch what you are doing and

use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of

inattention while operating power tools may
result in serious personal injury.

b) Use personal protective equipment.

Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.

c) Prevent unintentional starting. Ensure

the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger

on the switch or energising power tools that
have the switch on invites accidents.

d) Remove any adjusting key or wrench

before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in personal
injury.

e) Do not overreach. Keep proper

footing and balance at all times. This
enables better control of the power tool in
unexpected situations.

f) Dress properly. Do not wear loose

clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair

can be caught in moving parts.

g) If devices are provided for the connection

of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce

dust-related hazards.

4) POWER TOOL USE AND CARE

a) Do not force the power tool. Use the

correct power tool for your application.

The correct power tool will do the job
better and safer at the rate for which it
was designed.

b) Do not use the power tool if the switch

does not turn it on and off. Any power
tool that cannot be controlled with the switch
is dangerous and must be repaired.

c) Disconnect the plug from the power

source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive safety

measures reduce the risk of starting the
power tool accidentally.

d) Store idle power tools out of the reach

of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.

Power tools are dangerous in the hands of
untrained users.

e) Maintain power tools. Check for

misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by

poorly maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.

g) Use the power tool, accessories and

tool bits etc., in accordance with these
instructions taking into account the
working conditions and the work to
be performed. Use of the power tool for

operations different from those intended
could result in a hazardous situation.

5) BATTERY TOOL USE AND CARE

a) Recharge only with the charger specified

by the manufacturer. A charger that is

suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.

b) Use power tools only with specifically

designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.

c) When battery pack is not in use, keep it

away from other metal objects like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.

Shorting the battery terminals together may
cause burns or a fire.

d) Under abusive conditions, liquid may be

ejected from the battery, avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the

battery may cause irritation or burns.

6) SERVICE

a) Have your power tool serviced by a

qualified repair person using only identical
replacement parts. This will ensure that the

safety of the power tool is maintained.

34

ENGLISH

Additional Safety Instructions for
Rotary Hammers

• Wear ear protectors. Exposure to noise can
cause hearing loss.

• Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.

• Hold power tools by insulated gripping

surfaces when performing an operation
where the cutting tool may contact hidden
wiring. Contact with a “live” wire will make

exposed metal parts of the tool “live” and shock
the operator.

• Use clamps or other practical way to secure

and support the workpiece to a stable
platform. Holding the work by hand or against

your body is unstable and may lead to loss of
control.

• Wear safety goggles or other eye protection.
Hammering operations cause chips to fly. Flying
particles can cause permanent eye damage.
Wear a dust mask or respirator for applications
that generate dust. Ear protection may be
required for most applications.

• Keep a firm grip on the tool at all times.

Do not attempt to operate this tool
without holding it with both hands. It is

recommended that the side handle be used at
all times. Operating this tool with one hand will
result in loss of control. Breaking through or
encountering hard materials such as re-bar may
be hazardous as well. Tighten the side handle
securely before use.

• Do not operate this tool for long periods of
time. Vibration caused by hammer action may
be harmful to your hands and arms. Use gloves
to provide extra cushion and limit exposure by
taking frequent rest periods.

• Do not recondition bits yourself. Chisel
reconditioning should be done by an authorized
specialist. Improperly reconditioned chisels
could cause injury.

• Wear gloves when operating tool or
changing bits. Accessible metal parts on the
tool and bits may get extremely hot during
operation. Small bits of broken material may
damage bare hands.

• Never lay the tool down until the bit has
come to a complete stop. Moving bits could
cause injury.

• Do not strike jammed bits with a hammer to
dislodge them. Fragments of metal or material
chips could dislodge and cause injury.

• Slightly worn chisels can be resharpened by

grinding.

• Keep the power cord away from the rotating
bit. Do not wrap the cord around any part of

your body. An electric cord wrapped around a
spinning bit may cause personal injury and loss
of control.

Residual Risks

The following risks are inherent to the use of rotary
hammers:

– Injuries caused by touching the rotating parts or

hot parts of the tool.

In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:

– Impairment of hearing.
– Risk of squeezing fingers when changing the

accessory.

– Health hazards caused by breathing dust

developed when working in concrete and/or
masonry.

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual before use.

Wear ear protection.

Wear eye protection.

DATE CODE POSITION

The date code, which also includes the year of
manufacture, is printed into the housing surface that
forms the mounting joint between tool and battery.

Example:

2011 XX XX

Year of Manufacture

Important Safety Instructions for All
Battery Chargers

SAVE THESE INSTRUCTIONS: This manual
contains important safety and operating instruc tions
for the DCB105 battery charger.

• Before using the charger, read all instructions
and cautionary markings on charger, battery
pack and product using the battery pack.

35

ENGLISH

WARNING: Shock hazard. Do not allow

CAUTION: Burn hazard. To reduce

NOTICE: Under certain conditions, with

• DO NOT attempt to charge the battery pack

• These chargers are not intended for

• Do not expose charger to rain or snow.

• Pull by plug rather than cord when

• Make sure that cord is located so that it will

• Do not use an extension cord unless it

• When operating a charger outdoors, always

• Do not block the ventilation slots on the

any liquid to get inside charger. Electric
shock may result.

the risk of injury, charge only DEWALT
rechargeable battery packs. Other types
of batteries may overheat and burst
resulting in personal injury and property
damage.

CAUTION: Children should be

supervised to ensure that they do not
play with the appliance.

the charger plugged in to the power
supply, the exposed charging contacts
inside the charger can be shorted by
foreign material. Foreign materials of
a conductive nature such as, but not
limited to, steel wool, aluminum foil or
any buildup of metallic particles should
be kept away from charger cavities.
Always unplug the charger from the
power supply when there is no battery
pack in the cavity. Unplug charger
before attempting to clean.

with any chargers other than the ones in
this manual. The charger and battery pack are

specifically designed to work together.

any uses other than charging DEWALT
rechargeable batteries. Any other uses

may result in risk of fire, electric shock or
electrocution.

disconnecting charger. This will reduce risk
of damage to electric plug and cord.

not be stepped on, tripped over or otherwise
subjected to damage or stress.

is absolutely necessary. Use of improper

extension cord could result in risk of fire,
electric shock or electrocution.

provide a dry location and use an extension
cord suitable for outdoor use. Use of a cord

suitable for outdoor use reduces the risk of
electric shock.

charger. The ventilation slots are located

on the top and sides of the charger. Place

the charger in a position away from any heat
source.

• Do not operate charger with damaged cord
or plug — have them replaced immediately.

• Do not operate charger if it has received
a sharp blow, been dropped or otherwise
damaged in any way. Take it to an authorised

service centre.

• Do not disassemble the charger; take it to
an authorised service centre when service or
repair is required. Incorrect reassembly may

result in a risk of electric shock, electrocution or
fire.

• In case of damaged power supply cord the
supply cord must be replaced immediately by
the manufacturer, its service agent or similar
qualified person to prevent any hazard.

• Disconnect the charger from the outlet
before attempting any cleaning. This will
reduce the risk of electric shock. Removing

the battery pack will not reduce this risk.

• NEVER attempt to connect 2 chargers together.

• The charger is designed to operate on
standard 230 V household electrical power.
Do not attempt to use it on any other
voltage. This does not apply to the vehicular

charger.

SAVE THESE INSTRUCTIONS

Chargers

The DCB105 charger accepts 10.8 V, 14.4 V and
18V Li-Ion (DCB121, DCB140, DCB141, DCB180
and DCB181) battery packs.

This charger requires no adjustment and is designed
to be as easy as possible to operate.

Charging Procedure (fi g. 4)

1. Plug the charger into an appropriate 230 V
outlet before inserting the battery pack.

2. Insert the battery pack (f) into the charger,
making sure the pack is fully seated in the
charger. The red (charging) light will blink
continuously indicating that the charging
process has started.

3. The completion of charge will be indicated by
the red light remaining ON continuously. The
pack is fully charged and may be used at this
time or left in the charger.

NOTE: To ensure maximum performance and life of
Li-Ion batteries, charge the battery pack fully before
first use.

36

ENGLISH

Charging Process

Refer to the table below for the state of charge of
the battery pack.

State of charge

charging –– –– –– ––

fully charged –––––––––––––––––

hot/cold pack delay –– • –– • –– • –– •

x problem pack or charger • • • • • • • • • • • •

problem powerline •• •• •• •• •• ••

This charger will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing to
light or by displaying problem pack or charger blink
pattern.

NOTE: This could also mean a problem with a
charger.

If the charger indicates a problem, take the charger
and battery pack to be tested at an authorised
service centre.

Hot/Cold Pack Delay

When the charger detects a battery that is too hot
or too cold, it automatically starts a hot/cold pack
delay, suspending charging until the battery has
reached an appropriate temperature. The charger
then automatically switches to the pack charging
mode. This feature ensures maximum battery life.

XR Li-Ion tools are designed with an Electronic
Protection System that will protect the battery
against overloading, overheating or deep discharge.

The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place the
Li-Ion battery on the charger until it is fully charged.

A cold battery pack will charge at about half the rate
of a warm battery pack. The battery pack will charge
at that slower rate throughout the entire charging
cycle and will not return to maximum charge rate
even if the battery warms.

Important Safety Instructions for All
Battery Packs

When ordering replacement battery packs, be sure
to include the catalog number and voltage.

The battery pack is not fully charged out of the
carton. Before using the battery pack and charger,
read the safety instructions below and then follow
the charging procedures outlined.

READ ALL INSTRUCTIONS

• Do not charge or use the battery pack
in explosive atmospheres, such as in the
presence of flammable liquids, gases or
dust. Inserting or removing the battery pack

from the charger may ignite the dust or fumes.

• Never force the battery pack into charger.

Do not modify the battery pack in any way
to fit into a non-compatible charger as
battery pack may rupture causing serious
personal injury.

• Charge the battery packs only in designated

EWALT chargers.

D

• DO NOT splash or immerse in water or other
liquids.

• Do not store or use the tool and battery
pack in locations where the temperature
may reach or exceed 40˚ C (105° F) (such as
outside sheds or metal buildings in summer).

• For best results, make sure the battery pack is
fully charged before use.

WARNING: Never attempt to open

CAUTION: When not in use, place

SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION
(Li-Ion)

• Do not incinerate the battery pack even if it

• If battery contents come into contact with

the battery pack for any reason. If
the battery pack case is cracked or
damaged, do not insert it into the
charger. Do not crush, drop or damage
battery pack. Do not use a battery
pack or charger that has received a
sharp blow, been dropped, run over
or damaged in any way (e.g., pierced
with a nail, hit with a hammer, stepped
on). Electric shock or electrocution may
result. Damaged battery packs should
be returned to the service centre for
recycling.

tool on its side on a stable surface
where it will not cause a tripping or
falling hazard. Some tools with large

battery packs will stand upright on the
battery pack but may be easily knocked
over.

is severely damaged or is completely worn
out. The battery pack can explode in a fire.

Toxic fumes and materials are created when
lithium ion battery packs are burned.

the skin, immediately wash the area with
mild soap and water. If the battery liquid gets

into the eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical

37

ENGLISH

attention is needed, the battery electrolyte
is composed of a mixture of liquid organic
carbonates and lithium salts.

• Contents of opened battery cells may cause

respiratory irritation. Provide fresh air. If

symptoms persists, seek medical attention.

WARNING: Burn hazard. Battery liquid

may be flammable if exposed to spark
or flame.

Battery Pack

BATTERY TYPE

The DCH213 and DCH214 operate on 18 volt
battery packs.

The DCB180 or DCB181 battery packs may be
used. Refer to Technical Data for more information.

Storage Recommendations

1. The best storage place is one that is cool and
dry away from direct sunlight and excess heat
or cold. For optimum battery performance and
life, store battery packs at room temperature
when not in use.

2. For long storage, it is recommended to store a
fully charged battery pack in a cool, dry place
out of the charger for optimal results.

NOTE: Battery packs should not be stored
completely depleted of charge. The battery pack will
need to be recharged before use.

Labels on Charger and Battery Pack

In addition to the pictographs used in this manual,
the labels on the charger and the battery pack show
the following pictographs:

Read instruction manual before use.

Charging.

Fully charged.

Hot/cold pack delay.

Problem pack or charger.

x

Problem powerline.

Do not probe with conductive objects.

Do not charge damaged battery packs.

Use only with DEWALT battery packs.

Others may burst, causing personal injury
and damage.

Do not expose to water.

Have defective cords replaced

immediately.

Charge only between 4° C and 40° C.

Discard the battery pack with due care for

the environment.

Do not incinerate the battery pack.

Charges Li-Ion battery packs.

See Technical Data for charging time.

Only for indoor use.

Package Contents

The package contains:
1 Cordless rotary hammerdrill
1 Side handle
1 Charger
2 Battery packs
1 Kitbox
1 Instruction manual
1 Exploded drawing

NOTE: Battery packs and chargers are not included
with N-models.

• Check for damage to the tool, parts or
accessories which may have occurred during
transport.

• Take the time to thoroughly read and
understand this manual prior to operation.

Description (fi g. 1)

WARNING: Never modify the power

tool or any part of it. Damage or
personal injury could result.

38

ENGLISH

a. Variable speed switch
b. Forward/reverse button
c. Mode selector
d. Worklight
e. Side handle
f. Battery pack
g. Release button
h. Main handle
i. Drill bit symbol (rotary drilling mode)
j. Hammerdrilling symbol (rotary hammering

mode)
k. Hammer symbol (hammering only mode)
l. Chuck
m. Sleeve

INTENDED USE

Your DCH213 and DCH214 cordless rotary
hammerdrills have been designed for professional
drilling and hammerdrilling applications, as well as
screwdriving and chipping applications.

DO NOT use under wet conditions or in presence of
flammable liquids or gases.

These hammerdrills are professional power tools.
DO NOT let children come into contact with the

tool. Supervision is required when inexperienced
operators use this tool.

• This product is not intended for use by persons

(including children) suffering from diminished

physical, sensory or mental abilities; lack of

experience, knowledge or skills unless they are

supervised by a person responsible for their

safety. Children should never be left alone with

this product.

Electrical Safety

The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.

Your DEWALT charger is double insulated

in accordance with EN 60335; therefore
no earth wire is required.

If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DEWALT service organization.

Mains Plug Replacement
(U.K. & Ireland Only)

If a new mains plug needs to be fitted:

• Safely dispose of the old plug.

• Connect the brown lead to the live terminal in
the plug.

• Connect the blue lead to the neutral terminal.

Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.

WARNING: No connection is to be

made to the earth terminal.

Using an Extension Cable

An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm2; the maximum length is 30 m.

When using a cable reel, always unwind the cable
completely.

ASSEMBLY AND ADJUSTMENTS

WARNING: Prior to assembly and

WARNING: Use only DEWALT battery

adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.

packs and chargers.

Inserting and Removing the
Battery Pack from the Tool (fi g. 3)

WARNING: To reduce the risk of injury,

NOTE: For best results, make sure your battery
pack is fully charged.

TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE

1. Align the battery pack (f) with the rails inside the

2. Slide it into the handle until the battery pack is

TO REMOVE THE BATTERY PACK FROM THE TOOL

1. Press the battery release button (g) and firmly

never depress the battery release button
without removing the battery pack.
Depressing the battery release button
without removing the battery pack can
result in the battery pack falling out
unexpectedly.

tool’s handle (fig. 3).

firmly seated in the tool and ensure that it does
not disengage.

pull the battery pack out of the tool handle.

39

ENGLISH

2. Insert battery pack into the charger as
described in the charger section of this manual.

Variable Speed Switch (fi g. 1)

To turn the tool on, squeeze the trigger switch (a).
To turn the tool off, release the trigger switch. Your
tool is equipped with a brake. The chuck will stop as
soon as the trigger switch is fully released.

The variable speed trigger switch enables you to
select the best speed for a particular application.
The farther you squeeze the trigger switch, the faster
the tool will operate. For maximum tool life, use
variable speed only for starting holes or fasteners.

NOTE: Continuous use in variable speed range is
not recommended. It may damage the switch and
should be avoided.

Side Handle (fi g. 1)

WARNING: To reduce the risk of

personal injury, ALWAYS operate
the tool with the side handle properly
installed. Failure to do so may result
in the side handle slipping during tool
operation and subsequent loss of
control. Hold tool with both hands to
maximize control.

The side handle (e) clamps to the front of the gear
case and may be rotated 360˚ to permit right- or
left-hand use. Side handle must be tightened
sufficiently to resist the twisting action of the tool if
the accessory binds or stalls. Be sure to grip the
side handle at the far end to control the tool
during a stall.

To loosen side handle, rotate counterclockwise.

Forward/Reverse Control Button
(fi g. 1, 2)

WARNING: Always wait until the motor

has come to a complete standstill
before changing the direction of rotation.

A forward/reverse control button (b) determines the
direction of the tool and also serves as a lock off
button.

To select forward rotation, release the trigger switch
and depress the for ward/re verse control button on
the right side of the tool.

To select reverse, release the trigger switch and
depress the forward/reverse control button on the
left side of the tool.

The center position of the control button locks the
tool in the off position. When changing the position
of the control button, be sure the trigger is released.

NOTE: The first time the tool is run after changing
the direction of rotation, you may hear a click on
start up. This is normal and does not indicate a
problem.

Worklight (fi g. 1)

There is a worklight (d) located on the front of the
tool. The worklight will be activated when the trigger
switch is squeezed. The worklight is activated
when the trigger switch is depressed, and will
automatically turn off 20 seconds after the trigger
switch is released. If the trigger switch remains
depressed, the worklight will remain on.

NOTE: The worklight is for lighting the immediate
work surface and is not intended to be used as a
flashlight.

Selecting the Operating Mode (fi g. 1)

WARNING: Do not select the operating

mode when the tool is running.

Your tool is equipped with a separate mode
selector (c) to switch between rotary drilling, rotary
hammering and hammering only mode.

Rotary drilling: for screwdriving and for drilling

into steel, wood and plastics.

Rotary hammering: for concrete and

masonry drilling.

Hammering only: for light chipping.

For rotary drilling, rotate the mode selector (c)
until the arrow points to the drill bit symbol (i). For
rotary hammering mode, align the arrow with the
hammerdrilling symbol (j). For hammering only mode,
align arrow with the hammer symbol (k).

NOTE: The mode selector (c) must be in rotary
drilling, rotary hammering or hammering only mode
at all times. There are no operable positions in
between.

Active Vibration Control (fi g. 1)

The active vibration control neutralises rebound
vibration from the hammer mechanism. Lowering
hand and arm vibration, it allows more comfortable
use for longer periods of time and extends the life of
the unit.

For best vibration control, hold the tool with one
hand on the main handle (h) and the other hand
on the side handle (e). Apply just enough pressure
so the hammer is approximately mid-stroke. The
hammer only needs enough pressure to engage the

40

ENGLISH

internal active vibration control. Applying too much
pressure will not make the tool drill faster and active
vibration control will not engage.

SDS Chuck (fi g. 5)

To insert bit, insert shank of bit about 19 mm (3/4")
into chuck (l). Push and rotate bit until it locks in
place. The bit will be securely held.

To release bit, pull the sleeve (m) back and remove
the bit.

Replacing the Tool Holder with the
Chuck (fi g. 7)

DCH214

1. Turn the locking collar (o) into the unlocking
position and pull the tool holder (n) off.

2. Push the chuck (p) onto the spindle and turn
the locking collar into the locking position.

3. To replace the chuck with the tool holder, first
remove the chuck the same way as the tool
holder was removed. Then place the tool holder
the same way as the chuck was placed.

WARNING: Never use standard chucks

in the rotary hammering mode.

Overload Clutch

In case of jamming of a drill bit, the drive to the
drill spindle is interrupted. Because of the resulting
forces, always hold the tool with both hands and
take a firm stance.

OPERATION
Instructions for Use

WARNING:

• Always observe the safety instructions

and applicable regulations.

• Be aware of the location of pipework

and wiring.

• Apply only a gentle pressure to

the tool (approx. 5 kg). Excessive
force does not speed up drilling but
decreases tool performance and may
shorten tool life.

• Do not drill or drive too deep to

prevent damage to the dust cover.

• Always hold the tool firmly with both

hands and ensure a secure stance.
Always operate the tool with the side
handle properly mounted.

WARNING: To reduce the risk of

serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories.

Proper Hand Position (fi g. 1, 6)

WARNING: To reduce the risk of

WARNING: To reduce the risk of

Proper hand position requires one hand on the main
handle (h), with the other hand on the side handle
(e).

serious personal injury, ALWAYS
use proper hand position as shown
in figure 6.

serious personal injury, ALWAYS hold
securely in anticipation of a sudden
reaction.

Drill Operation (fi g. 1)

WARNING: To reduce the risk of

HAMMERDRILLING (FIG. 1)

1. Set the mode selector switch (c) to the "rotary

2. Insert the appropriate drill bit. For best results

3. Adjust the side handle (e) as required.

4. Mark the spot where the hole is to be drilled.

5. Place the drill bit on the spot and switch on the

ROTARY DRILLING (FIG. 1)

1. Set the mode selector switch (c) to the "rotary

2. Depending on your tool, follow either of the

- Fit a chuck adaptor/chuck assembly

serious personal injury, turn tool off and
disconnect tool from power source
before making any adjustments or
removing/installing attachments or
accessories.

WARNING: To reduce the risk of

personal injury, ALWAYS ensure
workpiece is anchored or clamped
firmly. If drilling thin material, use a wood
“back-up” block to prevent damage to
the material.

hammering" position.

use high quality carbide-tipped bits.

tool.

drilling" position.

following instructions:

(DCH213). Special SDS Plus adaptors with
threaded sections are available for use with
standard 10 or 13 mm chucks to enable
straight shank bits to be used.

41

ENGLISH

– Replace the tool holder with the chuck

(DCH214).

3. Proceed as described for rotary hammering.

CAUTION: Never use standard chucks

SCREWDRIVING (FIG. 1)

1. Set the mode selector switch (c) to the "rotary

2. Select the direction of rotation.

3. Depending on your tool, follow either of the

– Insert the special SDS Plus

– Replace the tool holder with the chuck

4. Insert the appropriate screwdriver bit. When

5. Gently press the variable speed switch (a) to

6. When the screw is flush with the workpiece,

CHIPPING (FIG. 1)

1. Set the mode selector switch (c) to the

2. Insert the appropriate chisel and check if it is

3 Adjust the side handle (e) as required.

4. Switch on the tool and start working.

It may be necessary to briefly run the motor after
having changed from chiselling to rotary modes in
order to align the gears.

WARNING:

• Do not use this tool to mix or pump

• Do not mix or stir inflammable liquids

in the rotary hammering mode.

drilling" position.

following instructions:

adaptor for use with hexagonal screwdriver
bits (DCH213).

(DCH214).

driving slotted head screws always use bits with
a finder sleeve.

prevent damage to the screw head. In reverse
(LH) rotation the tool speed is automatically
reduced for easy screw removal.

release the variable speed switch to prevent
the screw head from penetrating into the
workpiece.

"hammering only" position.

properly locked.

easily combustible or explosive fluids
(benzine, alcohol, etc.).

labelled accordingly.

®

screwdriving

This machine is not user-serviceable. Take the
tool to an authorised D
approximately 40 hours of use. If problems occur
before this time contact an authorised D
repair agent.

The charger and battery pack are not serviceable.
There are no serviceable parts inside.

WARNING: To reduce the risk of

serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up

can cause injury.

EWALT repair agent after

EWALT

Lubrication

Your power tool requires no additional lubrication.

Cleaning

WARNING: Blow dirt and dust out of

WARNING: Never use solvents or

CHARGER CLEANING INSTRUCTIONS

WARNING: Shock hazard. Disconnect

the main housing with dry air as often as
dirt is seen collecting in and around the
air vents. Wear approved eye protection
and approved dust mask when
performing this procedure.

other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.

the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the charger
using a cloth or soft non-metallic brush.
Do not use water or any cleaning
solutions.

MAINTENANCE

Your DEWALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.

42

Optional Accessories

WARNING: Since accessories, other

than those offered by DEWALT, have
not been tested with this product, use
of such accessories with this tool could

ENGLISH

be hazardous. To reduce the risk of
injury, only DEWALT recommended
accessories should be used with this
product.

Various types of SDS Plus® drill bits and chisels are
available as an option.

Accessories and attachments used must be
regularly lubricated around the SDS Plus

Consult your dealer for further information on the
appropriate accessories.

®

fitment.

Protecting the Environment

Separate collection. This product must

not be disposed of with normal
household waste.

product needs replacement, or if it is of no further

Should you find one day that your D

use to you, do not dispose of it with household
waste. Make this product available for separate
collection.

Separate collection of used products

and packaging allows materials to be
recycled and used again. Re-use of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw materials.

Local regulations may provide for separate collection
of electrical products from the household, at
municipal waste sites or by the retailer when you
purchase a new product.

DEWALT provides a facility for the collection and
recycling of DEWALT products once they have
reached the end of their working life. To take
advantage of this service please return your product
to any authorised repair agent who will collect them
on our behalf.

You can check the location of your nearest
authorised repair agent by contacting your local
DEWALT office at the address indicated in this
manual. Alternatively, a list of authorised DEWALT
repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com.

EWALT

• Run the battery pack down completely, then
remove it from the tool.

• Li-Ion cells are recyclable. Take them to your
dealer or a local recycling station. The collected
battery packs will be recycled or disposed of
properly.

Rechargeable Battery Pack

This long life battery pack must be recharged when
it fails to produce sufficient power on jobs which
were easily done before. At the end of its technical
life, discard it with due care for our environment:

43

ENGLISH

GUARANTEE

DEWALT is confident of the quality of its
products and offers an outstanding guarantee
for professional users of the product. This
guarantee statement is in addition to and in
no way prejudices your contractual rights as a
professional user or your statutory rights as a
private non-professional user. The guarantee
is valid within the territories of the Member
States of the European Union and the
European Free Trade Area.

• 30 DAY NO RISK SATISFACTION GUARANTEE •

If you are not completely satisfied with the
performance of your D
return it within 30 days, complete with all
original components, as purchased, to
the point of purchase, for a full refund or
exchange. The product must have been
subject to fair wear and tear and proof of
purchase must be produced.

• ONE YEAR FREE SERVICE CONTRACT •

If you need maintenance or service for your
DEWALT tool, in the 12 months following
purchase, you are entitled to one service free
of charge. It will be undertaken free of charge
at an authorised DEWALT repair agent. Proof
of purchase must be produced. Includes
labour. Excludes accessories and spare parts
unless failed under warranty.

• ONE YEAR FULL WARRANTY •

EWALT product becomes defective

If your D
due to faulty materials or workmanship
within 12 months from the date of purchase,
DEWALT guarantees to replace all defective
parts free of charge or – at our discretion –
replace the unit free of charge provided that:

• The product has not been misused;

• The product has been subject to fair
wear and tear;

• Repairs have not been attempted by
unauthorised persons;

• Proof of purchase is produced;

• The product is returned complete with all
original components.

If you wish to make a claim, contact your
seller or check the location of your nearest
authorised DEWALT repair agent in the
DEWALT catalogue or contact your DEWALT
office at the address indicated in this manual.
A list of authorised DEWALT repair agents and
full details of our after-sales service is available
on the Internet at: www.2helpU.com.

EWALT tool, simply

44
