DeWalt DC013-XE Instruction Manual

DC013-XE

HEAVY-DUTY WORK SITE CHARGER/RADIO

INSTRUCTION MANUAL

1

IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY DEWALT TOOL,
CALL US AT: 1800 654 155 (Aust) or 0800 339258 (NZ).

DC013 Heavy-Duty Work Site Charger/Radio

The DC013 Heavy-Duty Work Site Charger/Radio is a combination AM/FM radio and
DEWALT charger. The DC013 will charge most DEWALT 7.2 to 18.0 volt NiCd, NiMH,
Li-Ion batteries except for Univolt batteries. Batteries sold separately.

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or
other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the grounding-type plug. A grounding type
plug has three blades, the third is the grounding prong. The third prong is provided
for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the
manufacturer.

12. Only place radio on a level, stable surface.

13. Unplug this apparatus during lightning storms or when
unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

15. Apparatus shall not be exposed to dripping or splashing and no objects filled with

liquids, such as vases, shall be placed on the apparatus

The lightning flash with arrow head within a triangle is intended to tell the user

that parts inside the product are a risk of electric shock to persons.

The exclamation point within a triangle is intended to tell the user that

important operating and servicing instructions are in the papers with the

appliance.
This Class B digital apparatus complies with Canadian ICES-003.
NOTE: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to ratio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the

Definitions: Safety Guidelines

The definitions below describe the level of severity for each signal
word. Please read the manual and pay attention to these symbols.

DANGER: Indicates an imminently hazardous situation which, if

not avoided, will result in death or serious injury.

WARNING: Indicates a potentially hazardous situation which, if

not avoided, could result in death or serious injury.

CAUTION: Indicates a potentially hazardous situation which, if

not avoided, may result in minor or moderate injury.
NOTICE: Used without the safety alert symbol indicates a

potentially hazardous situation which, if not avoided, may result in

property damage.

2

equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help.

NOTICE: Per FCC Part 15, changes or modifications to this equipment not expressly
approved by DEWALT could void your authority to operate this equipment.

WARNING: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture. Use only in dry locations.

CAUTION: To prevent electric shock, ensure mains supply is earthed and only a 3

pin plug is used .

Electrical Safety

The electric motor has been designed for one voltage only. Always check that the
power supply corresponds to the voltage on the rating plate. 240 V AC means your
tool will operate on alternating current. As little as 10% lower voltage can cause loss
of power and can result in overheating. All DEWALT tools are factor y tested; if this
tool does not operate, check the power supply. Your DEWALT tool is double insulated,
therefore no earth wire is required.

• Young children and the infirm. This appliance is not intended for use by

young children or infirm persons without supervision. Young children should be
supervised to ensure that they do not play with this appliance.

• Replacement of the supply cord. If the supply cord is damaged, it must be

replaced by the manufacturer or an authorised DEWALT Ser vice Centre in order
to avoid a hazard.

Extension Cords

CAUTION: Use only extension cords that are approved by the country’s Electrical
Authority. Before using extension cords, inspect them for loose or exposed wires,
damaged insulation and defective fittings. Replace the cord if necessary.

MINIMUM GAUGE FOR CORD SETS
For Cable length (m): 7.5 15 25 30 45 60
Use Cable with minimum rating (Amperes)
Tool Amperes

0 - 3.4 7.5 7.5 7.5 7.5 7.5 7.5

3.5 - 5.0 7.5 7.5 7.5 7.5 10 15

5.1 - 7.0 10 10 10 10 15 15

7.1 - 12.0 15 15 15 15 20 20

12.1 - 20.0 20 20 20 20 25 –

• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:

V ..................volts A .............amperes

Hz ................hertz W ............watts

min ..............minutes

.........alternating cur rent

.........direct current .........alternating or direct current

...............Class I Construction

n

o ...........no load speed

....................(grounded) ...........earthing terminal

...............Class II Constr uction ..........safety aler t symbol

....................(double insulated) BPM ........beats per minute

…/min ...........per minute RPM ........revolutions per minute

................shock hazard symbol

Important Safety Instructions for All Battery Packs

When ordering replacement battery packs, be sure to include catalog number and
voltage. Consult the chart at the end of this manual for compatibility of chargers and
battery packs.

The battery pack is not fully charged out of the carton. Before using the battery pack
and charger, read the safety instructions below. Then follow charging procedures
outlined.

READ ALL INSTRUCTIONS

3

• Do not charge or use battery in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Inserting or removing the battery
from the charger may ignite the dust or fumes.

• NEVER force battery pack into charger. DO NOT modify battery pack in
any way to fit into a non-compatible charger as battery pack may rupture
causing serious personal injury. Consult the chart at the end of this manual for

compatibility of batteries and chargers.

• Charge the battery packs only in DEWALT chargers.

• DO NOT splash or immerse in water or other liquids.

• Do not store or use the tool and battery pack in locations where the
temperature may reach or exceed 105°F (40˚C) (such as outside sheds or
metal buildings in summer).

DANGER: Electrocution hazard. Never attempt to open the battery pack for any

reason. If battery pack case is cracked or damaged, do not inser t into charger. Do not
crush, drop or damage battery pack. Do not use a battery pack or charger that has
received a sharp blow, been dropped, run over or damaged in any way (i.e., pierced
with a nail, hit with a hammer, stepped on). Electric shock or electrocution may result.
Damaged battery packs should be returned to service center for recycling.
NOTE: Battery storage and carrying caps are provided for use whenever the batter y is out
of the tool or charger. Remove cap before placing battery in charger or tool.

WARNING: Fire hazard. Do not store or carry battery so that

metal objects can contact exposed battery terminals. For

example, do not place battery in aprons, pockets, tool boxes,
product kit boxes, drawers, etc., with loose nails, screws, keys,
etc. without battery cap. Transporting batteries can possibly

cause fires if the battery terminals inadvertently come in contact with conductive
materials such as keys, coins, hand tools and the like. The US Department of

Transportation Hazardous Material Regulations (HMR) actually prohibit transporting
batteries in commerce or on airplanes (i.e., packed in suitcases and carry-on
luggage) UNLESS they are properly protected from short circuits. So when
transporting individual batteries, make sure that the battery terminals are protected
and well insulated from materials that could contact them and cause a short circuit.

SPECIFIC SAFETY INSTRUCTIONS FOR NICKEL CADMIUM (NiCd) OR NICKEL
METAL HYDRIDE (NiMH)

• Do not incinerate the battery pack even if it is severely damaged or is
completely worn out. The battery pack can explode in a fire.

• A small leakage of liquid from the battery pack cells may occur under extreme
usage or temperature conditions. This does not indicate a failure.

However, if the outer seal is broken:

a. and the batter y liquid gets on your skin, immediately wash with soap and

water for several minutes.

b. and the battery liquid gets into your eyes, flush them with clean water for

a minimum of 10 minutes and seek immediate medical attention. (Medical

note: The liquid is 25-35% solution of potassium hydroxide.)

SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (LI-ION)

• Do not incinerate the battery pack even if it is severely damaged or is
completely worn out. The battery pack can explode in a fire. Toxic fumes and

materials are created when lithium ion battery packs are burned.

• If battery contents come into contact with the skin, immediately wash area
with mild soap and water. If battery liquid gets into the eye, rinse water over the
open eye for
15 minutes or until irritation ceases. If medical attention is needed, the battery
electrolyte is composed of a mixture of liquid organic carbonates and lithium
salts.

• Contents of opened battery cells may cause respiratory irritation. Provide fresh
air. If symptoms persists, seek medical attention.

WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or

flame.
