DeWalt D25002, D25003 Operator's Manual

1

®

D25002
D25003

19

ENGLISH

HEAVY DUTY ROTARY HAMMER DRILL
D25002/D25003

Congratulations!

You have chosen a DEWALT Power Tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional Power Tool users.

Technical data

D25002 D25003

Voltage V 230 230
(U.K. & Ireland only) V 230/115 230/115
Power input W 600 650
No load speed min-10 - 1,150 0 - 1,150
Load speed min-10 - 820 0 - 820
Impact energy J 2.4 2.4
Maximum drilling range in
steel/wood/concrete mm 13/30/22 13/30/24
Chiselling no yes
Core drilling capacity in
soft brick mm - 65
Tool holder SDS-plus®SDS-plus

®

Collar diameter mm 43 43
Weight kg 2.3 2.3

Fuses:

Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs

The following symbols are used throughout this
manual:

Denotes risk of personal injury, loss of life
or damage to the tool in case of non­observance of the instructions in this
manual.

Denotes risk of electric shock.

EC-Declaration of conformity

D25002/D25003

DEWALT declares that these Power Tools have been
designed in compliance with: 89/392/EEC,
89/336/EEC, 73/23/EEC, EN 50144, EN 55104,
EN 55014, EN 61000-3-2 & EN 61000-3-3.

For more information, please contact DEWALT at the
address below or refer to the back of the manual.

Level of sound pressure according to 86/188/EEC &
89/392/EEC, measured according to EN 50144:

D25002 D25003

LpA(sound pressure) dB(A)* 97 97
LWA(acoustic power) dB(A) 105 105
* at the operator’s ear

Take appropriate measures for the
protection of hearing if the sound
pressure of 85 dB(A) is exceeded.

Weighted root mean square acceleration value
according to EN 50144:

D25002 D25003

10 m/s

2

10 m/s

2

Powerful high frequent interference may cause
speed oscillations up to 20%. These, however,
disappear as soon as the interference is
suppressed.

Director Engineering & Product Development
Horst Großmann

DEWALT, Richard-Klinger-Straße 40,
D-65510, Idstein, Germany

20

ENGLISH

Safety instructions

When using Power Tools, always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and
personal injury. Read the following safety
instructions before attempting to operate this
product.
Keep these instructions in a safe place!

General

1 Keep work area clean

Cluttered areas and benches can cause accidents.

2 Consider work area environment

Do not expose Power Tools to humidity. Keep
work area well lit. Do not use Power Tools in the
presence of inflammable liquids or gases.

3 Guard against electric shock

Prevent body contact with earthed surfaces (e.g.
pipes, radiators, cookers and refrigerators).
For use under extreme conditions (e.g. high
humidity, when metal swarf is being produced,
etc.) electric safety can be improved by inserting
an isolating transformer or a (FI) earth-leakage
circuit-breaker.

4 Keep children away

Do not let children come into contact with the
tool or extension cord. Keep all people away
from the work area.

5 Extension cords for outdoor use

When the tool is used outdoors, always use
extension cords intended for outdoor use and
marked accordingly.

6 Store idle tools

When not in use, Power Tools must be stored in
a dry place and locked up securely, out of reach
of children.

7 Dress properly

Do not wear loose clothing or jewellery. They can
be caught in moving parts. Preferably wear
rubber gloves and non-slip footwear when
working outdoors. Wear protective hair covering
to keep long hair out of the way.

8 Wear safety goggles

Also use a face or dust mask in case the
operations produce dust or flying particles.

9 Beware of maximum sound pressure

Take appropriate measures for the protection of
hearing if the sound pressure of 85 dB(A) is
exceeded.

10 Secure workpiece

Use clamps or a vice to hold the workpiece. It is
safer and it frees both hands to operate the tool.

11 Do not overreach

Keep proper footing and balance at all times.

12 Avoid unintentional starting

Do not carry the plugged-in tool with a finger on
the switch. Be sure that the switch is released
when plugging in.

13 Stay alert

Watch what you are doing. Use common sense.
Do not operate the tool when you are tired.

14 Disconnect tool

Shut off power and wait for the tool to come to a
complete standstill before leaving it unattended.
Unplug the tool when not in use, before servicing
or changing accessories.

15 Remove adjusting keys and wrenches

Always check that adjusting keys and wrenches
are removed from the tool before operating the
tool.

16 Use appropriate tool

The intended use is laid down in this instruction
manual. Do not force small tools or attachments
to do the job of a heavy-duty tool. The tool will
do the job better and safer at the rate for which it
was intended.
Warning! The use of any accessory or
attachment or performance of any operation with
this tool, other than those recommended in this
instruction manual may present a risk of personal
injury.

17 Do not abuse cord

Never carry the tool by its cord or pull it to
disconnect from the socket. Keep the cord away
from heat, oil and sharp edges.

18 Maintain tools with care

Keep the tools in good condition and clean for better
and safer performance. Follow the instructions for
maintenance and changing accessories. Inspect the
tool cords at regular intervals and, if damaged, have
them repaired by an authorized DEWALT repair
agent. Inspect the extension cords periodically and
replace them if damaged. Keep all controls dry,
clean and free from oil and grease.

19 Check for damaged parts

Before using the tool, carefully check it for
damage to ensure that it will operate properly
and perform its intended function.
