Devolo Magic 1 User Manual
M anual
devolo M agic 1 WiFi
2-1
devolo Magic 1 WiFi
2-1
© 2018 devolo AG Aachen (Deutschland)
While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics. devolo shall
be liable only to the degree specified in the terms of sale and delivery.
The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from devolo. We reserve the right to make any alterations that arise as the result of technical development.
Trademarks
TM
Android
Linux
Ubuntu
Mac
iPhone
is a registered trademark of Open Handset Alliance.
®
is a registered trademark of Linus Torvalds.
®
is a registered trademark of Canonical Ltd.
®
and Mac OS X® are registered trademarks of Apple Computer, Inc.
®
,iPad® and iPod® are registered trademarks of Apple Computer, Inc.
Windows® and Microsoft® are registered trademarks of Microsoft, Corp.
®
devolo, dLAN
and the devolo logo are registered trademarks of devolo AG.
All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for
technical errors or omissions.
devolo AG
Charlottenburger Allee 67
52068 Aachen
Deutschland
www.devolo.com
Aachen, September 2018
Version 1.0
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1.3 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1.4 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1.5 devolo on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 devolo Magic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 The devolo Magic 1 WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Pairing – Establishing a PLC connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.1 Reading the PLC indicator light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.2 WiFi button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3.3 Reading the WiFi indicator light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.3.4 Reset button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3.5 Network jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.3.6 WiFi antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.3.7 Integrated electrical socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.1 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3 Connecting the devolo Magic 1 WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.3.1 Starter Kit – Automatic set-up for a new devolo Magic PLC network . . . . . . . . . . . . . . . . . . . . . . . . 22
3.3.2 Addition – Expanding an existing PLC network by adding another devolo Magic 1 WiFi . . . . . . . 23
3.3.3 Changing the network password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3.4 Integrating the devolo Magic 1 WiFi into an existing WiFi network . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4 Installation of devolo software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.5 Removing the devolo Magic adapter from a PLC network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
devolo Magic 1 WiFi
4 Network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.1 Calling up the built-in web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.2 General information about the menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.4 WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.4.1 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.4.2 WiFi networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.4.3 Guest network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.4.4 Mesh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.4.5 Schedule control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.4.6 WiFi Protected Setup (WPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.4.7 Neighbour networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.5 Powerline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.6 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.6.1 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.6.2 IPv4/IPv6 configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.7 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.7.1 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.7.2 Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.7.3 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.7.4 Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.7.5 Config Sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.1 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2 Frequency range and transmitting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.3 Channels and carrier frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.4 Bandwidth optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.5 Disposal of old devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.6 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
devolo Magic 1 WiFi
Preface 6
1 Preface
Welcome to the fantastic world of devolo Magic!
In no time at all, devolo Magic transforms your house into
a multimedia home that is ready for the future today.
devolo Magic gives you noticeably higher speeds, more
stability and greater range, providing the perfect Internet
experience as a result!
1.1 About this manual
Carefully read all instructions before setting up the device
and store the manual and/or installation guide for later reference.
After a brief introduction to „devolo Magic“ and to the
devolo Magic 1 WiFi in Chapter 2, Chapter 3 tells you how
to successfully start using the adapter in your network.
Chapter 4 describes in detail the setting options of the
built-in devolo Magic configuration interface.
Tips for bandwidth optimisation, information about environmental compatibility of the device, as well as our warranty terms, can be found in Chapter 5 at the end of the
manual.
Description of the icons
This section contains a brief description of the icons used in
this manual and/or on the rating plate, the device connector, as well as the icons used on the package:
Icon Description
Very important safety symbol that warns
you of imminent electrical voltage which
if not observed can result in serious injury
or death.
An important safety symbol that warns
you of a potentially dangerous situation
involving a burn hazard which can result
in minor injuries or damage to property.
An important note that should be observed which can potentially lead to material damages.
The device may only be used indoors in
dry conditions.
devolo Magic 1 WiFi
7 Preface
Icon Description
The manufacturer/distributing company
uses the CE marking to declare that the
product meets all applicable European
regulations and has been subjected to
the prescribed conformity assessment
procedures.
It is used to prevent the occurrence of waste electrical and electronic equipment
and to reduce this type of waste through
reuse, recycling and other forms of utilisation. The European Community WEEE
Directive establishes minimum standards for handling
waste electrical and electronic equipment in the EU.
Additional information, background material and configuration tips for your device.
Indicates a completed course of action
1.2 Intended use
Use devolo products, devolo software and the provided accessories as described to prevent damage and injury.
Products
devolo products are communication devices designed for
indoors.* Depending on the product, they are equipped
with a PLC- (PowerLine Communication) and/or a Wi-Fi
module. Computers, laptops, smartphones, tablets, smart
TVs and other devices connected this way are integrated
into a home network over the existing electrical wiring
and/or Wi-Fi without any complicated wiring. devolo devices must never be used outdoors because the high temperature fluctuations and moisture can damage both the
product and the power line. devolo products may not be installed at a height above two metres unless an additional
fas-tening mechanism is available. The products are intended for operation in the EU, Switzerland and Norway.
* The only exceptions are devolo outdoor products, which
are suited for the outdoor use thanks to their IP certification.
Software
devolo devices can be used only with the free, downloadable programs approved and available on devolo AG's website (www.devolo.com)
Play). Any modifications to the product-specific firmware
and in app stores (iOS and Google
devolo Magic 1 WiFi
Preface 8
or software could damage the products and, in the worstcase scenario, render them unusable and negatively affect
conformity.
Always use the most up-to-date software version to make
sure you have the latest security functions and device updates. The installed devolo software notifies you automatically if a new software version is available.
Accessories
Use only the provided accessories:
Network cable: RJ45-RJ45 Cat-5e UTP
1.3 CE Conformity
This product complies with the technical requirements of the directives 2014/35/EU, 2014/30/
EU, 2011/65/EU und 2009/125/EC.
This product is designed for use in the EU, Switzerland and Norway.
A printout of the simplified CE declaration of this product is
separately included and can also be found under
www.devolo.com/support/ce
.
1.4 Safety notes
It is essential to have read and understood all safety and
operating instructions before the devolo device is used for
the first time; keep them safe for future reference.
DANGER! Electrical shock caused by electricity
Do not reach into the electrical socket, do not
open the device and do not insert any objects
into the electrical socket or into the ventilation
openings
Users do not need to carry out any maintenance on devolo
devices. In the event of damage, disconnect the devolo device from the mains supply by pulling it or its plug out of
the electrical socket. Then contact qualified specialist personnel (after-sales service) exclusively. Damage is deemed to have occurred, for example,
if the power plug is damaged.
if the devolo device has been showered with liquid
(such as rain or other water).
if the devolo device is inoperable.
if the housing of the devolo device is damaged.
Do not plug devolo devices directly into each other.
Devices that are plugged into each other can experience a decrease in transmission rate.
devolo Magic 1 WiFi
9 Preface
DANGER! Electric shock caused by electricity
Device must be plugged into a power socket
with a connected earth wire
devolo devices may be operated only on a mains power
supply as described on the rating plate.
To disconnect devolo devices from the mains supply, unplug the device from the electrical socket.
The power socket and all connected network devices
should be easily accessible so that you can pull the power plug quickly if needed.
CAUTION! Heat development during operation
Certain housing components can become very
hot in certain situations. Attach device so that
it is touch-proof, observing optimal positioning
devolo devices should only be installed at locations that
guarantee adequate ventilation. Slots and openings on the
housing are used for ventilation:
Do not cover devolo devices during operation.
Do not place any objects on devolo devices.
Do not insert any objects into the openings of devolo
devices.
devolo devices must not be placed directly next to a
naked flame (such as fire or candles).
devolo devices must not be exposed to direct heat
radiation (e.g. radiator, direct sunlight).
CAUTION! Damage to housing from cleaning
agents containing solvents
Clean only electroless and with dry cloth
1.5 devolo on the Internet
For detailed information on our products and
devolo Magic, visit www.devolo.com
There you will find product descriptions and documentation, and also updates of devolo software and your device's
firmware.
If you have any further ideas or suggestions related to our
products, please don't hesitate to contact us at
support@devolo.com
!
.
devolo Magic 1 WiFi
Introduction 10
Fig. 1 devolo Magic throughout the home
2 Introduction
2.1 devolo Magic
Home is where devolo Magic is – in no time at all,
devolo Magic transforms your house or flat into a multimedia home of the future with noticeably higher speed, more
stability and greater range, providing the perfect Internet
experience as a result!
Be inspired by products that are astonishingly easy to install, with impressive, innovative technology and unbeatable performance.
devolo Magic 1 WiFi
11 Introduction
The product name concept
The devolo Magic name concept has the following
structure:
Product family devolo Magic
Performance catego-ry1
Transmission type WiFi
Number of sockets 2
Integrated electrical
socket
Be ready for the technology of the future today
devolo Magic embodies the new generation of the triedand-tested Powerline technology (PLC) based on the cutting-edge G.hn architecture. G.hn was developed by the International Telecommunication Union (ITU) with ongoing
development provided primarily by the HomeGrid Forum
industry association. devolo Magic products are certified
according to HomeGrid standards and are compatible with
other HomeGrid-certified products.
Like the HomePlug AV technology used in established devolo dLAN devices, devolo Magic uses the household
mains supply for data transmission and secures ideal performance and stability in locations where network cables
1 (= yes)
are not viable or desired and/or the WiFi frequently falls
short due to ceilings and walls.
To set up a devolo Magic network, you need at least
two devolo Magic devices. For technical reasons, devices from the devolo Magic series are not compatible with dLAN devices.
2.2 The devolo Magic 1 WiFi
A brief introduction to the devolo Magic adapter:
Unpack– plug in – get started and be prepared for the
new generation of the tried-and-tested Powerline
technology and innovative mesh WiFi with swiftness
and stability:
Powerline
At speeds up to 1200 Mbps
Over distances up to 400 metres
Security – with 128-bit AES Powerline encryption
Mesh WiFi
At speeds up to 1200 Mbps
Four antennas cover the 2.4 and 5 GHz WiFi frequen-
cies at the same time and use the full extent of the
entire 5 GHz frequency band (Dynamic Frequency
Selection, DFS).
devolo Magic 1 WiFi
Introduction 12
Air-time fairness – Quicker WiFi devices take priority
in the network.
Band steering – Use of the optimum frequency band
(2.4 and 5 GHz frequency band)
Roaming – Quickly and seamlessly connect to the
strongest WiFi access point
Security – with WPA2 for wireless ac ("IEEE 802.11a/
b/g/n/ac" WiFi high-speed standards)
Convenient additional functions such as parental
controls, guest WiFi, time control and Config Sync are
integrated in the devolo Magic 1 WiFi.
Efficiency– The integrated PowerSave mode reduces
energy consumption automatically at low data traf-
fic.
The 2 network connectors on the
devolo Magic 1 WiFi let you connect stationary network devices—such as a game console, TV or media
receiver—to your Internet access point over the
Powerline network (e.g. Internet router).
Its integrated electrical socket can be used like a
normal wall socket to supply power to an additional
network device or a power strip.
The devolo Magic 1 WiFi features
An integrated electrical socket,
A PLC button with LED status display,
A WiFi button with LED status display,
Four internal WiFi antennas,
Two network connectors,
A reset button (next to the network connectors).
The LED status displays can be disabled. You can find
more information about this in Chapter 4 Network
configuration or in the product manual for the
devolo Cockpit software available online at
www.devolo.com/cockpit
.
devolo Magic 1 WiFi
13 Introduction
Fig. 2: devolo Magic 1 WiFi with country-specific
connector and power socket
Fig. 3 Network connectors
2.3 Pairing – Establishing a PLC connection
devolo Magic adapters that are in the factory default condition, i.e. have been recently purchased or successfully reset (see Chapter 3.5 Removing the devolo Magic
adapter from a PLC network), automatically start to attempt to pair (establish a PLC connection) with
anotherdevolo Magic adapter when reconnected to the
mains supply.
devolo Magic 1 WiFi
Starting up a new devolo Magic PLC network
After plugging the devolo Magic adapters into available
power sockets, a new devolo Magic network is established
automatically within 3 minutes.
Introduction 14
Expanding an existing devolo Magic PLC network by
adding another devolo Magic adapter
In order to use a new devolo Magic 1 WiFi in your
devolo Magic- network, first you have to connect it to your
existing devolo Magic adapters devices as a network. This
is accomplished by using a shared PLC password, which
can be assigned in various ways:
Using devolo Cockpit or the devolo app (see Chapter
3.4 Installation of devolo software)
Using the web interface (see Chapter 4.5 Powerline)
Using the PLC button as described below.
To do so, plug the new devolo Magic adapter into an
available power socket and, for approximately
1 second, press the PLC button on a devolo Magic
adapter in your existing devolo Magic network.
For each pairing operation, only one additional
devolo Magic adapter can be added at a time.
LED Flashing be-
haviour
1 Red LED Lights up for up
to 2 sec.
Meaning LED status display
Start-up process Cannot be disabled
Within 3 minutes, press the PLC button on the
devolo Magic adapter that you want to add to your
existing devolo Magic network. The LED of this adapter now also flashes white.
After a short time, the flashing LED becomes a
steady white light. The devolo Magic adapter has
been successfully integrated into your existing
devolo Magic network.
You can find detailed information about installing
devolo Magic adapters in Chapter 3.3 Connecting
the devolo Magic 1 WiFi.
2.3.1 Reading the PLC indicator light
The integrated PLC indicator light (LED) shows the status
for the devolo Magic 1 WiFi by illuminating and/or flashing:
(web interface*)
devolo Magic 1 WiFi
15 Introduction
LED Flashing be-
haviour
2 Red LED Flashes at inter-
vals of 0.5 sec.
(on/off)
3 Red LED Lights up steady Status 1: The other network nodes are in standby
Meaning LED status display
Status 1: The reset of the devolo Magic adapter
was successful. The PLC/reset button has been
pressed and held for 10 seconds.
Status 2: The devolo Magic adapter (once again)
has the factory default settings. Since the last reset,
no pairing with another devolo Magic adapter has
taken place.
Connect the adapter with another devolo Magic adapter to create a full-fledged PLC network as described in Chapter 2.3 Pairing – Establishing a PLC
connection.
mode and cannot currently be accessed over the
mains supply. The PLC LEDs of the other
devolo Magic adapters flash white only for a short
time.
Status 2: The connection to the other network nodes has been interrupted. There may be electromagnetic or radio frequency interference on the power
line. In this case, put the devolo Magic adapters closer to each other or try to shut off the source of interference.
(web interface*)
Cannot be disabled
Can be disabled
devolo Magic 1 WiFi
Introduction 16
LED Flashing be-
haviour
4Red and
white LED
5 White LED Status 1: Flas-
6 White LED Lights up steady The devolo Magic connection does not have any is-
7 White LED Flashes at inter-
8Red and
white LED
Flashes at intervals of 0.1 sec.
red/2 sec. white
hes at intervals
of 0.5 sec.
Status 2: Flashes at intervals
of
1 sec.
vals of
0.1 sec. on /
5sec.off
Flashes at intervals of 0.5 sec.
red/0.5 sec.
white
Meaning LED status display
Data transmission rate not in optimum range ** Can be disabled
Status 1: This devolo Magic adapter is in pairing
mode and the system is searching for new
devolo Magic adapters.
Status 2: Someone has triggered the "Identify device" function on the web interface or in the devolo
app. This function identifies the devolo Magic adapter being sought.
sues and the devolo Magic adapter is ready to operate.
The devolo Magic adapter is in standby mode.*** Can be disabled
The devolo Magic adapter is carrying out a firmware update.
(web interface*)
Cannot be disabled
Can be disabled
Cannot be disabled
devolo Magic 1 WiFi
