Preface 5
devolo dLAN pro 1200+ triple
1Preface
Thank you for placing your trust in this product.
devolo dLAN business solutions are a favourably
priced option for using the power grid infrastructure
in a building to establish a broadband IP network.
The advantage this brings is obvious: no new cables
have to be laid – expenditure and costs remain low.
dLAN can be used as an easily scalable, primary network as well as to supplement an existing infrastructure.
The dLAN pro 1200+ triple allows you to set up your
own home network with almost no effort. Because
the clever dLAN technology transmits the data over
the electrical wiring, you do not have to lay any new
cables.
1.1 About this manual
Carefully read all instructions before setting up the device and store the manual and/or installation guide for
later reference.
After a brief introduction to "dLAN" and "Green IT" basics and a presentation of the dLAN pro 1200+ triple
in Chapter 2, Chapter 3 will cover successfully setting up your dLAN pro 1200+ triple. Chapter 4 explains how to configure your dLAN pro network. Tips for
bandwidth optimization, information of environmental
compatibility of the device and our warranty conditions
can be found in Chapter 5 and conclude the manual.
You can find the technical data for the
dLAN pro 1200+ triple in the product information
sheet on the enclosed product CD.
Description of the symbols
Here we briefly describe the meaning of the symbols
used in this manual, on the label and/or packaging.
Very important note. Failure to observe this note may result in damage.
Important note that should be observed.
Additional information, background mate-
rial and configuration tips for your device.
The device is designed for indoor use
only.
With the CE marking the manufacturer declares that the product complies with all valid
European directives and that it has been the
subject of the applicable conformity assessment procedures.
Page 7
6 Preface
devolo dLAN pro 1200+ triple
The WEEE Directive 2012/19/EU is used to
prevent the occurrence of waste electrical
and electronic equipment and to reduce
this type of waste through reuse, recycling
and other forms of utilisation. It establishes
minimum standards for handling waste
electrical and electronic equipment in the
EU.
1.1.1 Intended use
Use the device as described in these instructions to prevent damage and injuries.
1.1.2 CE conformity
This product complies with the technical requirements
of the EMC directive 2014/30/EC and the other relevant provisions of the FTEG.
This product is designed for use in
the EU, Switzerland and Norway.
The product is class B equipment.
You can find the CE declaration of this product under
www.devolo.com
.
1.1.3 Safety notes
It is essential to have read and understood all safety
and operating instructions before the devolo device is
used for the first time; keep them safe for future reference.
DANGER due to electricity
Users should never open devolo devices. Opening
the device poses a risk of electric shock!
Users do not need to carry out any maintenance on devolo devices. In the event of damage, disconnect the
devolo device from the mains supply by pulling it or its
plug out of the power outlet. Then contact qualified
specialist personnel (after-sales service) exclusively.
Damage is deemed to have occurred, for example,
쎲 if the power plug is damaged
쎲 if the devolo device has been showered with
liquid (e.g. rain or water).
쎲 if the devolo device is inoperable.
쎲 if the housing of the devolo device is damaged.
devolo devices may only be operated using a mains
power supply, as described on the nameplate.
Page 8
Preface 7
devolo dLAN pro 1200+ triple
DANGER due to electricity
devolo devices must be connected to an electrical power outlet with a protective ground.
To disconnect devolo devices from the mains supply,
pull the device itself or its mains plug from the power
outlet. The power outlet and all connected net-
work devices should be easily accessible so that
you can pull the mains plug quickly if needed.
devolo devices are designed for indoor use
only.
Only use devolo devices at a dry location.
Disconnect devolo devices from the mains supply to clean! Avoid solvent cleaning agents since they
can cause damage to the housing. Only use a dry towel
for cleaning.
DANGER due to overheating
Multiple devolo devices must not be interlocked.
devolo devices should only be installed at locations
that guarantee adequate ventilation. Slots and
openings on the housing are used for ventilation:
쎲 Do not cover devolo devices when operating.
쎲 Do not place any objects on devolo devices.
쎲 Do not insert any objects into the openings of
devolo devices.
쎲 devolo devices must not be placed directly next
to an open flame (such as fire or candles).
devolo devices must not be exposed to direct heat
radiation (e.g. radiator, direct sunlight).
1.2 devolo on the Internet
For detailed information on our products, visit
www.devolo.com/en/business-solutions
.
The devolo business area not only contains product
descriptions and documentation, but also updates of
devolo software and your device's firmware. We
especially recommend the descriptions of the "dLAN
pro network," which are arranged according to
Application, Sectors and Integration, where you
can find lots of interesting background information.
If you have any further ideas or suggestions related to
our products, please don't hesitate to contact us at
support@devolo.com
!
Page 9
8 devolo dLAN pro
devolo dLAN pro 1200+ triple
2 devolo dLAN pro
devolo dLAN business solutions are a favourably
priced option to establish a broadband IP network in a
building—using the power grid or according to the
dLAN pro product also coax lines or two-wire lines.
Fig. 1
Page 10
devolo dLAN pro 9
devolo dLAN pro 1200+ triple
Positioning anywhere in a building is possible due to
the flexibility of dLAN pro networking over an existing
power line: even areas without a network connection
are perfectly integrated this way. dLAN can be used as
an easily scalable, primary network as well as to supplement an existing infrastructure. The advantage this
brings is obvious: no new cables have to be laid—expenditure and costs remain low.
2.1 devolo—Up to speed on green
IT
Developers at devolo, have for a long time kept a close
eye on how much power dLAN devices may consume.
After all, a devolo network via electrical sockets should
not only be convenient, but also require as little energy
as possible—particularly during times when it is not
being used.
That devolo can satisfy the demand for energy efficiency is evidenced by the patented energy-saving mode
in the devices. It automatically reduces the energy
consumption when the computers in the dLAN pro
network or connected equipment are switched off.
The energy-saving mode is disabled
for the dLAN pro 1200+ triple in the
factory defaults.
If you would like to ensure that a
dLAN device switches to energy-saving mode, this function can be activated in the dLAN AVpro manager
software.
The energy-saving mode in the devices is not only a
tribute to environmental protection but also a real
service to the customer. Most people tend to forget to
regularly press the standby button on the hardware.
The patented technology in devolo devices
allows you to save energy without having to do
anything. And if less energy is consumed, your elec-
tric meter will turn more slowly. In other words, every
minute the device is in power saving mode, you will
save money.
Page 11
10 devolo dLAN pro
devolo dLAN pro 1200+ triple
A dLAN device connected to a computer can only go into energy saving
mode if the network card of the
switched-off computer is also inactive. If you are using a network card
that remains active even when the
computer is switched off, we recommend connecting the computer to an
on/off switch using a multiple socket
so that both the computer and the integrated network card are de-energised.
2.2 The dLAN pro 1200+ triple
쎲 Developed for professional use in small networks
with high demands on reliability and performance
쎲 dLAN technology from the world's market leader,
developed for professional use
쎲 Professional remote management using the
devolo AVpro manager software with comprehensive configuration options
쎲 Reliable security in public areas: PowerSave func-
tions, LED status display and encryption button
can be switched off by remote management
쎲 The fast transfer rate and dLAN speeds up to
1200 Mbps allow you to experience entertain-
ment at the highest level. The range+ technology provides an even more stable Internet
connection with significantly longer range.
쎲 3 Gigabit Ethernet ports
쎲 Optimal dLAN security with a 128-bit AES key
쎲 Supports Quality of Service (QoS) for automatic
data prioritisation
쎲 Long range of up to 400 meters with a connection
over the power line
쎲 Patented energy-saving technology for cost-effi-
cient operation
쎲 The dLAN pro 1200+ triple is provided with the
dLAN AVpro manager configuration tool, which
enables reliable, fast and convenient integration
of the dLAN pro 1200+ triple into dLAN pro networks with different architecture ('Peer-to-Peer' or
'MDU').
Page 12
devolo dLAN pro 11
devolo dLAN pro 1200+ triple
2.3 All about the network
2.3.1 Internet standalone solution
Fig. 2
Page 13
12 devolo dLAN pro
devolo dLAN pro 1200+ triple
2.3.2 dLAN Peer-to-Peer
If the network is configured as a 'Peer-to-Peer' network
('P2P'), all dLAN pro devices within it are equal to each
other. The connected network nodes can communicate
with one another freely and directly. The dLAN pro device which is most easily accessible from all dLAN pro
devices in the network is automatically designated by
these as the Central Coordinator ('CCo') and from then
on coordinates the communication between the
nodes. By default, dLAN pro devices are configured as
a Peer-to-Peer network.
Fig. 3
Fig. 4
Page 14
devolo dLAN pro 13
devolo dLAN pro 1200+ triple
2.3.3 dLAN MDU
If the network is configured as an 'MDU' network
(MDU: 'Multiple Dwelling Unit'), the connected network nodes are linked as 'slaves' to a 'master' and
form a logical dLAN pro network segment along with
their 'master'. Each slave sends data only to its master.
At the technical level, communication between the
slaves of the MDU dLANs is not possible. The masters
of the MDU dLANs are interconnected via Ethernet
switches. Thus MDU dLANs are ideally suited for floorby-floor networking (such as in hotels). MDU dLANs
can be configured only in the expert mode of the dLAN
AVpro manager.
Fig. 5 Room 1 Room 2 Room 3 Room 4
Page 15
14 Installation
devolo dLAN pro 1200+ triple
3 Installation
This chapter covers everything you need to know to set
up your dLAN pro 1200+ triple. It will explain connecting the dLAN pro 1200+ triple and its functions. We
will also briefly introduce the devolo software.
3.1 Package contents
Please ensure that the delivery is complete before beginning with the installation of your
dLAN pro 1200+ triple:
쎲 Single Kit:
쑗 dLAN pro 1200+ triple
쑗 Network cable
쑗 Hard copy of installation guide
쑗 Hard copy of declaration of conformity
or
쎲 Starter Kit:
쑗 dLAN pro 1200+ triple
쑗 dLAN pro 1200+
쑗 Two network cables
쑗 Hard copy of installation guide
쑗 Hard copy of declaration of conformity
devolo AG reserves the right to change the package
contents without prior notice.
3.2 System requirements
쎲 Operating systems: Windows 7 Professional
SP1 (x86/x64), Windows 8.1 Pro (x86/x64),
Windows 10 (x86/x64), Ubuntu 12.04 LTS „Pre-
Fig. 6 is country-specific
Page 16
Installation 15
devolo dLAN pro 1200+ triple
cise Pangolin“ (x86/x64), Ubuntu 13.04 „Raring
Ringtail“ (x86/x64), Ubuntu 14.04, OpenSuse
12.3 (x86/x64)
쎲 Network connection
Please note that your computer or other device must feature a network device with a
network port.
To set up a dLAN pro network, you need
two dLAN pro devices 200 Mbps,
500 Mbps and 1200 Mbps).
3.3 Functions
The dLAN pro 1200+ triple has a monitoring light
(LED), three network jacks and an encryption button.
3.3.1 Monitoring light
The monitoring light (LED) shows all of the statuses for
the dLAN pro 1200+ triple by illuminating and/or flashing in different ways:
쎲 The LED flashes quickly in red at uniform inter-
vals if the dLAN pro 1200+ triple is connected to
the mains supply but there is no dLAN
connection.
쎲 The LED lights up in white if the
dLAN pro 1200+ triple is ready to operate and
there is a dLAN connection.
쎲 The LED flashes quickly in white at uniform
intervals if the encryption process (pairing) is
being performed in the dLAN pro network.
쎲 The LED flashes in white at irregular intervals if
the dLAN pro 1200+ triple is in energy-saving
mode.
쎲 The LED flashes in red at uniform intervals if the
data transmission rate of the
dLAN pro 1200+ triple is not optimal. For information to improve the data transmission rate,
please see the chapter 5.1 Bandwidth optimi-
zation.
The function of the LED status display
can be deactivated in the
dLAN AVpro manager software.
3.3.2 Network connection
These are the connection points on the
dLAN pro 1200+ triple for connecting it to computers
or other network devices with network cables.
3.3.3 Encryption button
Data encryption at the touch of a button; For more information on the functions of the encryption button,
Page 17
16 Installation
devolo dLAN pro 1200+ triple
please see the chapter 4.2 dLAN pro network encryption at the touch of a button.
For safety reasons, you can deactivate the encryption button in the
dLAN AVpro manager software.
3.3.4 Integrated electrical socket
If you connect additional network devices using a multiple socket, plug this multiple socket into the electrical
socket of the dLAN pro 1200+ triple. The integrated
mains filter eliminates any noise of connected devices
and significantly improves data transmission in the
home network.
3.3.5 Standby mode
A dLAN pro device switches to Standby mode after a
short while if no active network device such as a computer is connected to the network port. In Standby
mode, the dLAN pro device cannot be accessed
via the power supply grid. As soon as the network
device (e.g. computer) connected to the network interface is switched on again, your dLAN pro device can
also be reached again via the electrical wiring.
The energy-saving mode is disabled for the
dLAN pro 1200+ triple in the factory defaults.
If you would like to ensure that a dLAN device switches
to energy saving mode, this function can be activated
in the dLAN AVpro manager software. More information concerning "energy-saving mode" can be found in
the chapter 2.1 devolo—Up to speed on green IT.
3.4 Connecting the
dLAN pro 1200+ triple
This section describes how to connect your
dLAN pro 1200+ triple to computers or other network
devices.
For the permitted voltage range for
operating the device and the power
consumption, refer to the label on
the rear side of the device.
Additional technical information is
available in the download area at
www.devolo.com
.
The device is designed for indoor use
only.
햲 Use network cables to connect the
dLAN pro 1200+ triple to the network ports of
your running computers or other network devices.
Page 18
Installation 17
devolo dLAN pro 1200+ triple
Prevent tripping hazards when cabling.
DANGER due to electricity! The
dLAN pro 1200+ triple must be
connected to an electrical power outlet with a protective ground.
햳 Plug the dLAN pro 1200+ triple into a free electri-
cal outlet.
The power outlet and all connected
network devices should be easily accessible so that you can pull the
mains plug quickly if needed.
To disconnect the device from the
mains supply, pull the device itself or
its mains plug from the power outlet.
Additional network devices that are
connected via a multiple socket are
connected to the mains power supply by
plugging the multiple socket into the integrated electrical socket of the
dLAN pro 1200+ triple.
햴 Once you have connected at least two dLAN pro
devices as described above, your dLAN
pro network has been set up. To secure your dLAN
pro network, continue with the configuration as
described in chapter 4 dLAN network.
For detailed information about connecting
other devolo dLAN devices, visit our website: www.devolo.com
3.5 dLAN AVpro manager
The dLAN AVpro manager provides advanced dLAN
functions, such as:
쎲 Management software to support the user during
configuration and monitoring
쎲 Central administration interface
쎲 Real time monitoring of all the dLAN pro devices
in the network
쎲 Global or individual assignment of security set-
tings for databases and devices
쎲 MDU mode for master/slave networks and peer-
to-peer networks
쎲 VLAN configuration for subnet management
For detailed descriptions and information on
configuration of your dLAN pro network, please
consult the devolo dLAN AVpro manager manual at
www.devolo.com/en/business-solutions.
Page 19
18 Installation
devolo dLAN pro 1200+ triple
3.5.1 Software for Windows
The dLAN AVpro manager software is available at
www.devolo.com/en/business-solutions
. After you
have downloaded the installation file to your PC, start
it by double-clicking on it.
Then you will find the link to the configuration interface as well as the installed dLAN AVpro manager in
the program group Start All Programs devolo.
3.5.2 Software for Linux
The dLAN AVpro manager software is available at
www.devolo.com/en/business-solutions
. OpenSuse
and Linux are currently supported.
Page 20
dLAN pro network 19
devolo dLAN pro 1200+ triple
4 dLAN pro network
4.1 Security in the dLAN
Before you can use the dLAN pro 1200+ triple in your
dLAN pro network, first you have to connect it to other
dLAN pro devices as a network. Two specific pieces of
information are especially important for this:
쎲 Shared use of a dLAN password results in a delim-
ited dLAN network.
쎲 Shared use of the dLAN password serves as access
control to the dLAN pro network as well as the
encryption, and thereby the interception protection, of the transmitted data.
The dLAN password can be specified automatically via
the encryption button or manually using the
dLAN AVpro manager program. Please note the following basic principle when choosing your encryption
method:
쎲 In dLAN pro networks, data encryption is as
simple as touching a button, since all corresponding dLAN pro devices are equipped
with an encryption button.
쎲 For dLAN pro networks that include devices with
and without encryption buttons, data encryp-
tion must be set up using the dLAN AVpro
manager.
4.2 dLAN pro network encryption
at the touch of a button
To encrypt a dLAN pro network, in which all associated
devices are equipped with an encryption button, simply
press the encryption button that is located on the device. Pressing this button will encrypt your dLAN pro
network with a randomly generated password.
For security reasons, you can deactivate encryption button in the dLAN
AVpro manager software.
Page 21
20 dLAN pro network
devolo dLAN pro 1200+ triple
The following section contains exact instructions of encryption on the basis of possible network scenarios:
dLAN devices cannot be configured
while in Standby mode.
Encrypting a new dLAN pro network with a
dLAN pro 1200+ triple and an additional dLAN
pro device
Once both dLAN pro devices have been successfully
connected, press each encryption button for >one sec-
ond within two minutes of one another.
That's it! Your dLAN pro network is now protected
against unauthorised access.
Fig. 7
Page 22
dLAN pro network 21
devolo dLAN pro 1200+ triple
Expanding an existing dLAN pro network by
adding another dLAN pro device
If you have already secured your existing dLAN pro
network using the encryption button, use the same
method to integrate further devices. Once you have
successfully connected the new dLAN pro device, first
press the encryption button (> one second) of one of
your network’s existing devices, then press the
encryption button (> one second) of your new dLAN
pro device within two minutes.
That's it! The new dLAN pro device is now integrated
in your network. To integrate additional dLAN pro devices in your network, repeat the above steps.
Removing a dLAN pro device from a network
To remove a dLAN pro 1200+ triple or another dLAN
pro device from an existing network, press its encryption button for at least ten seconds. The device will be
assigned a new randomly generated password and will
thus no longer be able to access the network. To integrate the device into a different dLAN pro network, follow the steps described above, depending on whether
you are setting up a new network or adding the device
to an existing one.
Page 23
22 Appendix
devolo dLAN pro 1200+ triple
5 Appendix
5.1 Bandwidth optimization
To significantly improve the transmission capacity of
the network, we recommend that you comply with the
following "connection rules":
쎲 Plug the device directly into a wall socket. Avoid
multiple sockets.
쎲 You should connect all additional network devices
that are connected to a multiple socket to the
mains power supply via the electrical socket integrated into the dLAN pro 1200+ triple.
쎲 To take full advantage of the filter function of the
dLAN pro 1200+ triple and to improve data transmission in the network, always plug the multiple
socket into the electrical socket of the
dLAN pro 1200+ triple.
5.2 Disposal of old devices
To be used in the countries of the European Union and
other European countries with a separate collecting system:
The icon with crossed-out wastebasket on
the device means that this product is an
electrical or electronic device that falls
within the scope of application of the
European Community WEEE Directive.
These types of devices may no longer be
disposed of with household waste. Rather
they can be given to a municipal collection
point free of charge. Contact your
municipal government to find out the
address and hours of the nearest collection
point.
Fig. 11
Page 24
Appendix 23
devolo dLAN pro 1200+ triple
5.3 Warranty conditions
The devolo AG warranty is given to purchasers of devolo products in
addition to the warranty conditions provided by law and in accordance with the following conditions:
1 Warranty coverage
a) The warranty covers the equipment delivered and all its parts.
Parts will, at devolo's sole discretion, be replaced or repaired
free of charge if, despite proven proper handling and adherence to the operating instructions, these parts became defective due to fabrication and/or material defects. Alternatively,
devolo reserves the right to replace the defective product with
a comparable product with the same specifications and features. Operating manuals and possibly supplied software are
excluded from the warranty.
b) Material and service charges shall be covered by devolo, but
not shipping and handling costs involved in transport from the
buyer to the service station and/or to devolo.
c) Replaced parts become property of devolo.
d) devolo is authorized to carry out technical changes (e.g. firm-
ware updates) beyond repair and replacement of defective
parts in order to bring the equipment up to the current technical state. This does not result in any additional charge for the
customer. A legal claim to this service does not exist.
2 Warranty period
The warranty period for this devolo product is three years. This
period begins at the day of delivery from the devolo dealer. Warranty services carried out by devolo do not result in an extension of
the warranty period nor do they initiate a new warranty period. The
warranty period for installed replacement parts ends with the warranty period of the device as a whole.
3Warranty procedure
a) If defects appear during the warranty period, the warranty
claims must be made immediately, at the latest within a period
of 7 days.
b) In the case of any externally visible damage arising from trans-
port (e.g. damage to the housing), the person carrying out the
transportation and the sender should be informed immediately. On discovery of damage which is not externally visible,
the transport company and the sender are to be immediately
informed in writing, at the latest within 3 days of delivery.
c) Transport to and from the location where the warranty claim is
accepted and/or the repaired device is exchanged, is at the
purchaser's own risk and cost.
d) Warranty claims are only valid if a copy of the original
purchase receipt is returned with the device. devolo reserves
the right to require the submission of the original purchase
receipt.
4 Suspension of the warranty
All warranty claims will be deemed invalid
a) if the label with the serial number has been removed from the
device,
b) if the device is damaged or destroyed as a result of acts of
nature or by environmental influences (moisture, electric
shock, dust, etc.),
c) if the device was stored or operated under conditions not in
compliance with the technical specifications,
d) if the damage occurred due to incorrect handling, especially to
non-observance of the system description and the operating
instructions,
e) if the device was opened, repaired or modified by persons not
contracted by devolo,
f) if the device shows any kind of mechanical damage, or
g) if the warranty claim has not been reported in accordance with
3a) or 3b).
Page 25
24 Appendix
devolo dLAN pro 1200+ triple
5Operating mistakes
If it becomes apparent that the reported malfunction of the device
has been caused by unsuitable hardware, software, installation or
operation, devolo reserves the right to charge the purchaser for the
resulting testing costs.
6 Additional regulations
The above conditions define the complete scope of devolo's legal
liability.
a) The warranty gives no entitlement to additional claims, such as
any refund in full or in part. Compensation claims, regardless
of the legal basis, are excluded. This does not apply if e.g.
injury to persons or damage to private property are specifically
covered by the product liability law, or in cases of intentional
act or culpable negligence.
b) Claims for compensation of lost profits, indirect or consequen-
tial detriments, are excluded.
c) devolo is not liable for lost data or retrieval of lost data in
cases of slight and ordinary negligence.
d) In the case that the intentional or culpable negligence of
devolo employees has caused a loss of data, devolo will be
liable for those costs typical to the recovery of data where periodic security data back-ups have been made.
e) The warranty is valid only for the first purchaser and is not
transferable.
f) The court of jurisdiction is located in Aachen, Germany in the
case that the purchaser is a merchant. If the purchaser does
not have a court of jurisdiction in the Federal Republic of Germany or if he moves his domicile out of Germany after conclusion of the contract, devolo's court of jurisdiction applies. This
is also applicable if the purchaser's domicile is not known at
the time of institution of proceedings.
g) The law of the Federal Republic of Germany is applicable. The
UN commercial law does not apply to dealings between devolo
and the purchaser.
Page 26
devolo dLAN pro 1200+ triple
Index
C
CCo 12
CE declaration 6
Central Coordinator 12
D
Disposal of old devices 22
dLAN pro device 12
dLAN pro network 19
E
Encryption button 15, 19
energy saving mode 9
Expert mode 13
I
Integrated electrical socket 16
M
Master 13
MDU 13
Monitoring light (LED) 15
Multiple Dwelling Unit 13
N
Network connections 15
Network segment 13
P
P2P 12
Package contents 15
Peer-to-peer 12
S
Safety notes 6
Slave 13
W
Warranty 23
Loading...
