PRESSURE WASHER

OWNERS MANUAL for

Model 2225CWH

Read Owner's Manual. Do not operate equipment until you have read Owners Manual for Safety, Assembly, Operation, Maintenance and Storage Instructions.

This product is not equipped with a spark arresting muffler. If the product will be used around flammable materials, or on land covered with materials such as agricultural crops, forest, brush, grass, or other similar items, then an approved spark arrester must be installed and is legally required in the state of California. It is a violation of California statutes section 130050 and/or sections 4442 and 4443 of the California Public Resources Code, unless the engine is equipped with a spark arrestor, as defined in section 4442, and maintained in effective working order. Spark arresters are also required on some U. S. Forest service land and may also be legally required under other statutes and ordinances.

This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm. This warning is given in compliance with California Proposition 65, as detectable amounts of chemicals subject to proposition 65 may be contained in this product.

CAUTION

ENGINE OIL MUST BE ADDED TO THE ENGINE BEFORE USE.

MGP-2225CWH 1/7/00

TABLE OF CONTENTS

Table of Contents ...................................................

2

Assembly ................................................................

7

Owner's Responsibilities .........................................

2

Operation ................................................................

8

Pressure Washer Return Policy .............................

2

Maintenance .........................................................

14

Warranty ..................................................................

3

Storage .................................................................

15

Safety Rules ............................................................

4

Troubleshooting ....................................................

16

Contents of Carton .................................................

6

Repair Parts ..........................................................

17

Unpacking ...............................................................

7

Quick Facts ..............................................

back page

OWNER'S RESPONSIBILITIES

Congratulations! You have purchased a high quality product from America’s leading manufacturer of pressure washers. This pressure washer, when properly used and maintained, will provide trouble free service. Please read and follow these instructions for proper use and maintenance.

Read and understand all safety warnings.

Read this Owner’s Manual. Save these instructions. Owner's manual should remain with unit at all times.

Do not operate this unit until you have read this Owners Manual for Safety, Operation, and Maintenance Instructions.

Read the Engine Owner's Manual supplied with this unit.

Do not operate this unit until you have read the Engine Owners Manual for Safety, Operation, and Maintenance Instructions.

Check for visible shipping damage. Shipping damage will cause problems in operation of this unit.

If you experience any problems and need assistance, please call us at our toll free number

1-800-888-2468, Ext 2, 2. 8:00 a.m. to 8:00 p.m. E.S.T.

If you need warranty repair or service part purchase, you can locate an Authorized Warranty Service Center nearest you by calling us at

1-800-888-2468, Ext 2, 1 24 hours a day, 7 days a week.

NOTE: Photos and illustrations in this manual are for reference only and may not represent a specific model.

PRESSURE WASHER RETURN POLICY

Within 15 days of your purchase, Sam's will gladly exchange your pressure washer or refund your money. Sales receipt is required.

After 15 days manufacturer's warranty applies.

Refer to this Owners Manual for manufacturer's warranty.

If you need warranty repair or service part purchase, you can locate an Authorized Warranty Service Center nearest you by calling us at 1-800-888-2468, Ext 2, 1 24 hours a day, 7 days a week.

SAFETY GUIDELINES - DEFINITIONS

This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections.

DANGER indicates an imminently hazardous situation

CAUTION indicates a potentially hazardous situation which, if

which, if not avoided, will result in death or serious injury.

not avoided, may result in minor or moderate injury.





WARNING indicates a potentially hazardous situation

CAUTION used without the safety alert symbol indicates a

which, if not avoided, could result in death or serious

potentially hazardous situation which, if not avoided, may

injury.

result in property damage.



10/2/97

2 — ENG

WARRANTY

LIMITED WARRANTY

ONE YEAR FROM DATE OF PURCHASE

All merchandise manufactured by DeVilbiss Air Power Company Manufacturing is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only).

Air compressors, *air tools, accessories, service parts, pressure washers, and generators used in commercial applications (income producing) are covered by a 90 day warranty.

DeVilbiss Air Power Manufacturing will repair or replace, at DeVilbiss’ option, products or components which have failed within the warranty period. Repair or replacement, and service calls on 60 and 80 gallon air compressors, will be handled by Authorized Warranty Service Centers and will be scheduled and serviced according to the normal work flow and business hours at the service center location, and depending on the availability of replacement parts.

All decisions of DeVilbiss Air Power Company Manufacturing with regard to this policy shall be final.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

RESPONSIBILITY OF ORIGINAL PURCHASER (Initial User):

Retain original cash register sales receipt as proof of purchase for warranty work.

Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s).

Deliver or ship the product to the nearest DeVilbiss Air PowerManufacturing Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.

Air compressors with 60 and 80 gallon tanks only will be inspected at the site of installation. Contact the nearest Authorized Warranty Service Center, that provides on-site service calls, for service call arrangement.

If the purchaser does not receive satisfactory results from the Authorized Warranty Service Center, the purchaser should contact DeVilbiss Air Power Company Manufacturing.

THIS WARRANTY DOES NOT COVER:

Merchandise sold as reconditioned, floor models and/or display models. Any damaged or incomplete equipment sold "as is".

Merchandise used as "rental" equipment.

Merchandise that has become inoperative because of ordinary wear, misuse, freeze damage, use of improper chemicals, negligence, accident, improper and/or unauthorized repair or alterations including failure to operate the product in accordance with the instructions provided in the Owners Manual (s) supplied with the product.

*Air Tools: O-Rings and driver blades are considered ordinary wear parts, therefore, they are warranted for a period of 45 days from the date of purchase.

An air compressor that pumps air more than 50% during a one hour period is considered misuse because the air compressor is undersized for the required air demand. Maximum compressor pumping time per hour is 30 minutes.

Merchandise sold by DeVilbiss Air Power Manufacturing which has been manufactured by and identified as the product of another company. The product manufacturer's warranty will apply.

Repair and transportation costs of merchandise determined not to be defective.

Cost associated with assembly, required oil, adjustments or other installation and start-up cost.

ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you.

213Industrial Drive • Jackson, TN 38301-9615 Telephone: 1-800-888-2468 , Ext. 2

FAX: 1-800-888-9036

Form: SP-100-G - 9/29/99

3 — ENG

IMPORTANT SAFETY INSTRUCTIONS

IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING.









HAZARD



WHAT CAN HAPPEN



HOW TO PREVENT IT





















Spilled gasoline and it’s vapors can become

Shut off engine and allow it to cool before











DANGER

















ignited from cigarette sparks, electrical



adding fuel to the tank.





RISK OF EXPLOSION



arcing, exhaust gases, and hot engine

Use care in filling tank to avoid spilling fuel.







components such as the muffler.











OR FIRE





Move pressure washer away from fueling





































Heat will expand fuel in the tank which could



area before starting engine.





















Keep maximum fuel level ½” below top of























result in spillage and possible fire explosion.





















Operating the pressure washer in an



tank to allow for expansion.























explosive environment could result in a fire.

Operate and fuel equipment in well



















































ventilated areas free from obstructions.



























Equip areas with fire extinguishers suitable



























for gasoline fires.





















Materials placed against or near the

Never operate pressure washer in an area























containing dry brush or weeds.























pressure washer can interfere with its proper

























Always keep pressure washer a minimum of























ventilation features causing overheating and























possible ignition of the materials.



four feet away from surfaces (such as





















Muffler exhaust heat can damage painted



houses, automobiles, or live plants) that























could be damaged from muffler exhaust























surfaces, melt any material sensitive to heat



heat.























(such as siding, plastic, rubber, or vinyl), and



























damage live plants.

Store fuel in an OSHA approved container,





















Improperly stored fuel could lead to























accidental ignition. Fuel improperly secured



in a secure location away from work area.























could get into the hands of children or



























other unqualified persons.

























Use of acids, toxic or corrosive chemicals,

Do not spray flammable liquids























poisons, insecticides, or any kind of



























flammable solvent with this product could



























result in serious injury or death.





















































Breathing exhaust fumes will cause serious

Operate pressure washer in a well ventilated











DANGER





















area. Avoid enclosed areas such as















injury or death.









RISK TO BREATHING







garages, basements ,etc.











Never operate unit in a location occupied by



















































humans or animals.





















Some cleaning fluids contain substances

Use only cleaning fluids specifically























which could cause injury to skin, eyes, or



recommended for high pressure washers.























lungs.



Follow manufacturers recommendations.









































































Unsafe operation of your pressure washer

Become familiar with the operation and























could lead to serious injury or death to you



controls of the pressure washer.











WARNING

























or others.

Keep operating area clear of all persons,







RISK OF UNSAFE

















pets, and obstacles.









OPERATION





Do not operate the product when fatigued



























or under the influenceof alcohol or drugs.



























Stay alert at all times.

























Never defeat the safety features of this



























product.

























Do not operate machine with missing,



























broken, or unauthorized parts.

























Never leave wand unattended while unit is



























running.





















The spray gun/wand is a powerful cleaning

Keep children away from the pressure























tool that could look like a toy to a child.



washer at all times.





















Reactive force of spray will cause gun/wand

Do not overreach or stand on an unstable























to move, and could cause the operator to



support. Grip gun/wand firmly with both























slip or fall, or misdirect the spray. Improper



hands. Expect the gun to kick when























control of gun/wand can result in injuries to



triggered.























self and others.



































4 — ENG

IMPORTANT SAFETY INSTRUCTIONS













HAZARD

WHAT CAN HAPPEN



HOW TO PREVENT IT



























• Spray directed at electrical outlets or

Unplug any electrically operated product











WARNING



















switches, or objects connected to an



before attempting to clean it. Direct spray



























electrical circuit, could result in a fatal



away from electric outlets and switches.



































RISK OF









electrical shock.









ELECTRICAL





















SHOCK









































































































• Your washer operates at fluid pressures

Never place hands in front of nozzle.











WARNING



















and velocities high enough to penetrate

Direct spray away from self and others.









RISK TO FLUID

human and animal flesh, which could

Make sure hose and fittings are tightened









result in amputation or other serious



and in good condition. Never hold onto











INJECTION













injury. Leaks caused by loose fittings or



the hose or fittings during operation.



























worn or damaged hoses can result in

Do not allow hose to contact muffler.



























injection injuries. DO NOT TREAT FLUID

• Never attach or remove wand or hose



























INJECTION AS A SIMPLE CUT! See a



fittings while system is pressurized.



























physician immediately!

• Use only hose and high pressure























































• Relieve system pressure before attempt-



accessories rated for pressure higher than























































ing maintenance or disassembly of



your pressure washer's p.s.i.



























equipment.

To relieve system pressure, shut off engine,































turn off water supply, and pull gun trigger































until water stops flowing.



























































• Use of acids, toxic or corrosive chemi-

Do not use acids, gasoline, kerosene, or











WARNING



















cals, poisons, insecticides, or any kind of



any other flammable materials in this





RISK OF CHEMICAL BURN

flammable solvent with this product



product. Use only household detergents,





could result in serious injury or death.



cleaners and degreasers recommended



























































for use in pressure washers.





























Wear protective clothing to protect































eyes and skin from contact with sprayed































materials.



























































• Contact with hot surfaces, such as

During operation, touch only the control











WARNING



















engines exhaust components, could



surfaces of the pressure washer. Keep





RISK OF HOT SURFACES

result in serious burn.



children away from the pressure washer































at all times. They may not be able to































recognize the hazards of this product.













































• Fuel or oil can leak or spill and could

• If pressure washer is equipped with a fuel







DANGER











result in fire or breathing hazard, serious

shut-off valve, turn the valve to the off



RISK OF INJURY AND



injury or death can result. Fuel or oil leaks

position before transporting to avoid fuel

PROPERTY DAMAGE

will damage carpet, paint or other

leaks. If pressure washer is not equipped

surfaces in vehicles or trailers.

with a fuel shut-off valve, drain the fuel from







WHEN









tank before transporting. Only transport fuel



TRANSPORTING OR







in an OSHA approved container. Always







STORING



















place pressure washer on a protective mat















when transporting to protect against damage















to vehicle from leaks. Remove pressure















washer from vehicle immediately upon arrival















at your destination.

















The powerful spray from your pressure washer is capable of causing damage to surfaces such as wood, glass, automobile paint, auto striping and trim, and delicate objects such as flowers and shrubs. Before spraying, check the item to be cleaned to assure yourself that it is strong enough to resist damage from the force of the spray. Avoid the use of the concentrated spray stream except for very strong surfaces like concrete and steel.

Operating unit with water supply shutoff without flow of water will result in equipment damage. Operating the pressure washer with water supply shutoff will void your warranty. You should never run this pressure washer for more than 2 minutes without pulling the trigger to allow cool water to enter the pump and the heated (recirculated) water to exit.

5 — ENG

CONTENTS OF CARTON





English

Spanish



Instructional





Owner's

Owner's



Video





Manual

Manual







Engine











Manual













Nozzle Cleaning Kit



Handle Knobs

















Bagged Parts





Bagged Handle









Spray Gun



Multi-Reg Wand











30 Weight

Engine Frame and

High Pressure Hose

Chemical Hose

Engine Oil







Wheel Assembly









6 — ENG

Loading...
+ 14 hidden pages
