Page 1
APEX Series
Analytical and Toploading Balances
Page 2
APEX Series Economical Balances
The performance you need at the price you want
Features Include:
• Large, easy to read LCD
• Automatic external calibration
• Multiple weigh units: grams, ounces, troy ounces, pennyweight,
carats, grains, pounds and taels
• Parts counting
• Percentage weighing
• Level indicator
• Leveling feet
• Simple, menu operation
• Stainless-steel weighing pan
• Overload protection
• RS232C interface
Value priced. Ideal for those who demand quality even on a limited budget. The APEX-Series balance is the
economical solution to your weighing needs.
Newest technology. APEX-Series balances incorporate the latest in single-block weighing technology, for
quicker response times and accurate, repeatable results.
Easy operation. Large “Zero” key provides quick taring. Basic weighing is effortless. Use menu-driven
operation for more advanced weighing features.
Multiple weighing modes.With the press of a single key, toggle between four weigh units: grams, pennyweight,
ounces and one-user selected unit including grains, carats, pounds, troy ounces, or taels.
The APEX-Series balances from Denver
Instrument offer simplicity, accuracy and
reliability at economical prices. Comprehensive
features make these instruments ideal for
laboratory, industrial and educational
environments.
Page 3
Parts counting. APEX-Series balances are ideal for inventory and process control. Simply place the reference
quantity (10, 20, 50 or 100 pieces) on the pan and the balance will do the rest. Add or subtract pieces for an
accurate piece count.
Percent weighing.The versatile features of these balances allow measurement of a percent proportional to a
reference weight. Eliminate human errors by seeing the weight increase or decrease in percentage points instead
of typical weighing units.
Calibration is a snap. Use a precision external weight to assure that every reading is accurate. Enter the calibration
menu, add the calibration weight and instantly the balance completes the calibration.
RS232 interface. Connect the APEX-Series balance to a computer or printer for a permanent record of results.
Press the “Print” key and the results are transferred automatically. Easy to integrate into a GLP or ISO program.
Built to last. These balances are constructed to withstand the rigors of diverse environments from educational to
industrial use. The solid construction and simplistic operation makes this the balance of choice.
Page 4
Analytical Models:
APX-60, APX-100, APX-200
Model APX-60 APX-100 APX-200 APX-153 APX-203 APX-323
Capacity 60g 100g 200g 150g 200g 320g
Readability 0.1mg 0.1mg 0.1mg 0.001g 0.001g 0.001g
Taring Range 0 to 60g 0 to 100g 0 to 200g 0 to 150g 0 to 200g 0 to 320g
Repeatability 0.1mg 0.1mg 0.1mg 0.001g 0.001g 0.001g
Linearity ±0.2mg ±0.2mg ±0.2mg ±0.002g ±0.002g ±0.002g
Pan Size 3.1” dia. 3.1” dia. 3.1” dia. 4.5”dia. 4.5”dia. 4.5”dia.
(79mm) (79mm) (79mm) (114mm) (114mm) (114mm)
Model APX-402 APX-602 APX-1502 APX-3202 APX-2001 APX-4001 APX-6001
Capacity 400g 600g 1500g 3200g 2000g 4000g 6000g
Readability 0.01g 0.01g 0.01g 0.01g 0.1g 0.1g 0.1g
Taring Range 0 to 400g 0 to 600g 0 to 1500g 0 to 3200g 0 to 2000g 0 to 4000g 0 to 600 0g
Repeatability 0.01g 0.01g 0.01g 0.01g 0.1g 0.1g 0.1g
Linearity ±0.02g ±0.02g ±0.02g ±0.02g ±0.2g ±0.2g ±0.2g
Pan Size 4.5”dia. 4.5”dia. 4.5”dia. 5.9” dia. 5” x 7” 5” x 7” 5” x 7”
(114mm) (114mm) (114mm) (150mm) (127 x 178mm) (127 x 178mm) (127 x 178mm)
Common Specifications:
Analytical Unit Dimensions (LxWxH): 12.6 x 8.7 x 12.8” (320 x 221 x 325mm)
Analytical Chamber Dimensions (LxWxH): 6.25 x 7.5 x 9.25 (159 x 191 x235mm)
Height Above Pan: 8.8” (224mm)
Analytical Net Weight: 9.0 lbs. (4.1kg)
Toploader Unit Dimensions (LxWxH): 12.7 x 8.8 x 3.0” (322 x 224 x 76mm)
Toploader Net Weight: 4.9 lbs. (1.8kg)
Stabilization Time (average): 5 seconds (Analytical Models)
3 seconds (Toploading Models)
Operating Temperature: 10°-30°C (50°-86° F)
Electrical Requirements: 115VDC at100mA, Center Pin (-),
Adapter Included
Toploading Models:
APX-20 01, APX- 4001, APX-6001
Toploading Models:
APX-153, APX-203 , APX-323 (also
available with analytical draft shield)
APX-402, APX-602, APX-1502
