DENSITRON TFT-K-Kit-007 User Guide

TFT Evaluation Kit

User manual

CUSTOMER

PRODUCT

NUMBER

CUSTOMER

APPROVAL

TFT-K-Kit-007

INTERNAL APPROVALS

Product Mgr Doc. Control Electr. Eng

Elijah

Ebo

Date: 04/09/07 Date: 04/09/07 Date: 04/09/07

Anthony

Perkins

Bazile

Peter

Date

FORM No. DT-029

TABLE OF CONTENTS

1 INTRODUCTION ........................................................................................................ 4

2 SETTING UP THE KIT ............................................................................................. 5

3 TFT PANEL .................................................................................................................... 6

3.1 TFT

3.2 E

MECHANICAL PARAMETERS

LECTRICAL PARAMETERS

................................................................................ 6

......................................................................................... 7

4 DRIVER CARD........................................................................................................... 10

4.1 E

4.2 M

LECTRICAL PARAMETERS

ECHANICAL PARAMETERS

....................................................................................... 10

..................................................................................... 22

5 TECHNICAL SUPPORT ......................................................................................... 23

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 2 / 23

REVISION RECORD

Rev.

A 04/09/07

Date Page Chapt.

First revision

Comment ECR no.

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 3 / 23

1 Introduction

This user manual contains the instructions on setting up and using the Densitron Kyocera TFT evaluation kit.

The evaluation kit contains:

- 1 x Kyocera TCG057QVGLAC 5.7” TFT panel

o Anti glare treatment o (320 x R.G.B) x 240 dots o COG LCD with LED Backlight. o Dimensions: 144.0 x 104.8 x 13.0 mm o Effective Viewing Area: 117.2 x 88.4 mm o Dot Pitch: 0.12 x 0.36 mm o 3.3V supply

(Please refer to datasheet for full specifications).

- 1 x Driver Card with VGA and DVI inputs

- 24V Power supply

- 33 way FFC Cable

- 24V to 12V DC-DC Converter

- Documentation CD.

The documentation CD contains the manual for the parts that make up the kit.

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 4 / 23

2 Setting up the kit

The kit should be unpacked in a static-free environment, with adequate anti-static precautions being observed.

The cables are all keyed and only one cable from the kit will fit each of the connection steps described below:

1) Connect the display to the driver card, using the 33 way FFC cable. You will notice that one end is only 32 ways wide; this end plugs into CN400 on the driver card.

2) Connect the OSD board to CN500 on the driver card.

3) Check the jumper settings on the driver card and confirm that they are correctly set according to the display requirements.

4) Connect the 12V output of the DC-DC converter to connector CN300 of the driver card.

5) Connect the DC plug on LED backlighting cable protruding from the display panel to the socket attached to the thinner set of cables from the 24V input of the DC-DC converter.

6) Plug the 24V power supply to the thicker set of cables attached to the 24V input on the DC-DC converter.

7) Supply a VGA source via CN2 (Analogue RGB) or CN1 (DVI).

8) The system will power up automatically, however the correct input will have to be selected from the OSD menu. Refer to the driver card specifications for the OSD menu functionality.

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 5 / 23

3 TFT PANEL

3.1 TFT mechanical parameters

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 6 / 23

3.2 Electrical parameters

3.2.1 Absolute Maximum Ratings

Item Symbol Min Max Unit

Power input voltage VDD 0 4.0 V

Input signal voltage Vin -0.3 6.0 V

Forward Current IF - (27) mA

Reversed Voltage VR - (5) V

3.2.2 Electrical Characteristics

Item Symbol Min Typ Max Unit

Power input

voltage

Current

consumption

Permissive input ripple voltage

(VDD = 3.3V)

Input signal voltage (Low) V

Input signal voltage (High) V

VDD = 3.3V

VDD 3.0 3.3 3.6 V

IDD - 130 160 mA

V

RP

IL

IH

- - 100 mVp-p

0 - 0.3VDD

0.7VDD

- +5.5V V

V

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 7 / 23

3.2.3 Interface Signals

Product No.

TFT-K-Kit-007 REV. A

PD064VT4

Page 8 / 23

Pin No.

Symbol

Description

1 AN1

Anode 1

2 AN2

Anode 2

3 AN3

Anode 3

4 CA1

Cathode 1

5 CA2

Catho

de 2

6 CA3

Cathode 3

Forward Current *1

IF -

(25)

- mA

Ta =

-

10~70

- (24.2)

(27.0)

V

IF = 25mA *1,

- (23.1)

(25.9)

V

IF = 25mA *1,

- (22.1)

(24.9)

V

IF = 25mA *1,

Operating life *2

T -

(50,000

- V IF = 25mA *1

3.2.4

LED Backlight pin descriptions

3.2.5 Backlight Characteristics

Item Symbol Min.

Typ. Max. Unit

Note

°C

Forward Voltage

VF

) *3

Ta = -10 °C

Ta = 25 °C

Ta = 70 °C

*1 For each “AN1-CA1”, “AN2-CN2” and “AN3-CN3”

*2 When brightness decreases to 50% of initial brightness

*3 Life Time is estimated data.

*An input current below 8.0mA may reduce the brightness uniformity of the LED backlight. This is because the amount of light from each LED chip is different. Therefore, please evaluate carefully before finalizing the input current.
