Denon Ceol Piccolo DRA-N4 Owner's Manual

Download

Page 1

NETWORK RECEIVER DRA-N4

Owner’s Manual

You can print more than one page of a PDF onto a single sheet of paper.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 2

Accessories

Inserting the batteries

Operating range of the remote control unit

Features

Multiple music formats are supported, all in a compact form factor

Easy operation

Part names and functions

Front/Top panel

Rear panel

Remote control unit

Connections

Speaker connection

Connecting the speaker cables

Connecting the subwoofer

Connecting speakers

Connecting an analog device

Connecting a digital device

Connecting an iPod or USB memory device to the USB port

Connecting to a home network (LAN)

Wired LAN

Wireless LAN

Connecting the power cord

Contents Connections Playback

Settings

Tips Appendix

Contents

Front/Top

panel

Rear panel

Remote control unit

Index

Page 3

Playback

Basic operation

Turning the power on

Selecting the input source

Adjusting the volume

Turning off the sound temporarily

Listening to Internet Radio

Playing the last played Internet Radio station

Using vTuner to add Internet Radio stations to favorites

Playing back files stored on a PC and NAS

Applying media sharing settings

Playing back files stored on a PC and NAS

Favorite function

Registering stations or files to the favorites list

Calling stations or files from the favorites list

To switch between registered stations and files during playback

Deleting stations or files from the favorite list

Playing an iPod

Listening to music on an iPod

Setting operation mode (Browse iPod mode)

Charging the iPod/iPhone

Playing a USB memory device

Playing files stored on USB memory devices

Listening to music on a Bluetooth device

Pairing with a Bluetooth device

Playing a Bluetooth device

Pairing with the Pairing Mode

Connecting a Bluetooth device with the NFC function via NFC

Listening to DIGITAL IN

Listening to ANALOG IN

AirPlay function

Playing songs from your iPhone, iPod touch or iPad

Playing iTunes music with this unit

Selecting multiple speakers (devices)

Spotify Connect function

Playing Spotify music with this unit

Remote play function

Settings required for each device

Web control function

Controlling the unit from a web control

Convenience functions

Adjusting the tone

Sleep timer function

Checking the current time

Switching the display’s brightness

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 4

Settings

Menu map

Menu operation

Inputting characters

Using the number buttons

Using the cursor buttons

General

Alarm

Clock

Volume Limit

Speaker Optimization

Language

Auto-Standby

Usage Data

Firmware

Network

Network Information

Network Control

Friendly Name

Settings

Tips

Troubleshooting

Resetting factory settings

100

Appendix

Playing back USB memory devices

101

Playing back Internet Radio

103

Playing back Bluetooth devices

103

Bluetooth communications

103

Playing back files stored on PC or NAS

104

Last function memory

105

Explanation of terms

106

Trademark information

112

Specifications

113

Index

118

License

120

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 5

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

. . .

Quick Setup Guide CD-ROM

(Owner’s Manual)

Safety Instructions Notes on radio Power cord

Remote control unit

(RC-1198)

R03/AAA batteries

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 6

Inserting the batteries

Remove the rear lid in the direction of the arrow and remove it.

Insert two batteries correctly into the battery compartment as indicated.

R03/AAA batteries

Put the rear cover back on.

NOTE

To prevent damage or leakage of battery fluid:

Do not use a new battery together with an old one.

Do not use two different types of batteries.

If the battery fluid should leak, carefully wipe the fluid off the inside of the battery compartment and insert new batteries.

Operating range of the remote control unit

Point the remote control unit at the remote sensor when operating it.

30°

Approx. 7 m

30°

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 7

Features

Multiple music formats are supported, all in a compact form factor

Supports Internet Radio and music streaming Supports AirPlay® (v

p. 52)

You can enjoy a wide variety of content, including listening to Internet Radio, playing audio files stored on your PC.

This unit also supports Apple AirPlay which lets you stream your music library from an iPhone®, iPad®, iPod touch® or iTunes®.

DLNA (Digital Living Network Alliance) ver. 1.5 support for audio networks

Supports online music, including Spotify

Support for High Quality Audio playback

WAV/FLAC/ALAC (Apple Lossless Audio Codec)/AIFF

Support for Gapless playback

Playback with no gap between music files (for WAV/FLAC/ALAC/AIFF only)

Wi-Fi network capability with built-in diversity antenna, and is certified under WMM (Wi-Fi Multi Media) for efficient wireless connectivity

Easy operation

Easy wireless connection is possible by pressing the Wi-Fi CONNECT button (WPS and Wi-Fi Sharing)

See the separate “Quick Setup Guide”.

Wireless connection with Bluetooth devices can be carried out easily

You can enjoy music simply by connecting wirelessly with your smartphone, tablet, PC, etc.

If the Bluetooth device has NFC function, you can connect easily to touch to N mark

iPod auto detect charges your device even after the unit switches to standby mode

Denon “Hi-Fi Remote” App is application software that allows you to perform basic operations with an iPad, iPhone, Android smartphone or Android tablet such as turning the unit ON/OFF, controlling the volume, and switching the source.

Download the appropriate Denon “Hi-Fi Remote” App for your iOS or Android devices. This unit needs to be connected to your LAN and the iPad, iPhone, Android smartphone, Android tablet or other device needs to be connected to the same network by Wi-Fi (wireless LAN).

OLED (Organic Light Emitting Diode) display that can display 3 lines

Auto Standby mode for energy savings

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 8

Part names and functions

Front/Top panel

VOLUME

ENTER

w t

q ry

oQ0

GTop panelH

GFront panelH

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 9

VOLUME

ENTER

w t

q ry

GTop panelH

Power operation button (X)

Turns power to this unit on and off (standby).

Power indicator

The power indicator changes as shown below according to the status of the unit.

Power on : White

Normal standby : Off

When “Network Control” is set to “On” : Red (v

p. 79)

iPod charge standby : Red (v p. 43)

Alarm standby : Orange (v p. 74)

Display off: White

p. 68)

N mark (Q)

Touch this mark with a Bluetooth device that includes the NFC function when pairing (registering) with it. (v

p. 50)

Volume up/down buttons (VOLUME df)

Adjusts the volume.

Input source select button (q)

Selects the input source.

Cursor buttons (uio p)

These select items.

Playback/Pause/ENTER button (1/3/ENTER)

Plays back and pauses tracks, and enters the selected content.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 10

oQ0

GFront panelH

USB port

Used to connect iPod or USB memory devices. (v

p. 21)

Display

Various information is displayed here.

Remote control sensor

This receives signals from the remote control unit.

(v p. 6)

Headphones jack (R)

Used to connect headphones. When the headphones are plugged into this jack, audio will no longer

be output from the connected speakers.

NOTE

To prevent hearing loss, do not raise the volume level excessively when using headphones.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 11

Rear panel

SPEAKERS

IMPEDANCE : 4~16

NETWORK

ANALOG IN

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

y u

q w e r t

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 12

SPEAKERS

IMPEDANCE : 4~16

NETWORK

ANALOG IN

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

y u

q w e r t

AC inlet (AC IN)

Used to connect the supplied power cord.

(v p. 26)

Speaker terminals (SPEAKERS)

Used to connect speakers. (v p. 17, 19)

ANALOG IN connectors

Used to connect devices equipped with analog audio connectors. (v p. 20)

DIGITAL IN connector

Used to connect devices equipped with digital audio connectors. (v p. 20)

NETWORK connector

Used to connect this unit to the network.

p. 23)

SW OUT connector

Used to connect a subwoofer with a built-in amplifier.

(v p. 18)

Wi-Fi CONNECT buttons (iOS/WPS)

Used to connect to the wireless LAN. (See the separate “Quick Setup Guide”.)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 13

Remote control unit

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

ENTER

Blu

Bluetooth

iPo

iPod/

USB

AUX

Remote control signal transmitter

This transmits signals from the remote control unit. (v p. 6)

CLOCK button

The current time appear on the unit. (v

p. 67)

SLEEP button

This sets the sleep timer.

(v p. 67)

Input source select buttons

These select the input source. (v p. 28)

System buttons

These perform playback related operations.

p. 36, 42, 45)

Reverse-skip / Forward-skip buttons (8, 9)

Play/pause button (1/3)

Channel buttons (CH +, –)

These operate the Favorite function.

p. 38)

SDB/TONE button

Adjusting the tone. (v

p. 66)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 14

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

ENTER

Blu

Bluetooth

iPo

iPod/

USB

AUX

Q0 Q1

Q3 Q4

FAVORITES ADD / CALL buttons

To add radio stations or files to the favorite list, press ADD button. (v p. 39)

To call up a radio station or file registered in the favorite list, press CALL button. (v

p. 39)

TOP MENU button

To back to the top of the menu. (v p. 71)

ENTER button

This determines the selection. (v

p. 71)

Cursor buttons (uio p)

These select items. (v p. 71)

SEARCH button

This displays the search menu.

p. 32, 36, 45)

Number buttons (0 – 9, +10)

These enter letters or numbers into the unit. (v

p. 72)

RANDOM button

Switches the random playback. (v p. 36, 42, 45)

REPEAT button

Switches to the repeat playback.

p. 36, 42, 45)

DIMMER button

Adjust the display brightness of this unit. (v

p. 68)

POWER button (X)

This turns the power on/standby.

p. 28)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 15

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

ENTER

Blu

Bluetooth

iPo

iPod/

USB

AUX

W1 W2

VOLUME buttons (df)

These adjust the volume level.

p. 29)

Information button (INFO)

This switches display items such as the elapsed time, album name and title name in the playback screen.

p. 32, 36, 42, 45)

MUTE button (:)

This mutes the output audio. (v p. 29)

SETUP button

The setting menu is displayed on the display.

(v p. 71)

CLEAR button

This cancels the settings. (v p. 39, 73)

MODE button

This switches the operation mode.

p. 42)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 16

Contents

Speaker connection 17

Connecting an analog device 20

Connecting a digital device 20

Connecting an iPod or USB memory device to the USB port 21

Connecting to a home network (LAN) 23

Connecting the power cord 26

NOTE

Do not plug in the power cord until all connections have been completed.

Do not bundle power cords with connection cables. Doing so can result in noise.

Cables used for connections

Provide necessary cables according to the devices you want to connect.

Speaker cable

Subwoofer cable

Optical cable

Audio cable

LAN cable

Contents Connections Playback

Settings

Tips Appendix

Connections

Front/Top

panel

Rear panel

Remote control unit

Index

Page 17

Speaker connection

Here we connect the speakers in the room to this unit. This section explains how to connect them using typical examples.

NOTE

Disconnect this unit’s power plug from the power outlet before connecting the speakers. Also, turn off the subwoofer.

Connect so that the speaker cable core wires do not protrude from the speaker terminal. The protection circuit may be activated if the core wires touch the rear panel or if the + and - sides touch each other. “Protection circuit” (v

p. 111)

Never touch the speaker terminals while the power cord is connected. Doing so could result in electric shock.

Use speakers with an impedance of 4 – 16

Ω/ohms.

Connecting the speaker cables

Connect the speaker cable with a rubber tube (red) to the + speaker terminal (red), and the other cable to the - speaker terminal (black).

Peel off about 10 mm of sheathing from the tip of the speaker cable, then twist the core wire tightly.

Push the speaker terminal and insert the speaker cable into the cable insertion slot.

Release your finger from the speaker terminal to fix the speaker cable.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 18

NOTE

Ensure that only the core wire part of the speaker cable is inserted. If the covered part is inserted, sound may not be output.

Connecting the subwoofer

Use a subwoofer cable to connect the subwoofer.

SPEAKERS

IMPEDANCE : 4~16

NETWORK

ANALOG IN

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 19

Connecting speakers

SPEAKERS

IMPEDANCE : 4~16

NETWORK

ANALOG IN

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

iOSWPS

SUB WOOFER

OUT

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 20

Connecting an analog device

SPEAKERS

IMPEDANCE : 4~16

NETWORK

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

ANALOG IN

AUDIO

OUT

AUDIO

Analog

device

Connecting a digital device

SPEAKERS

IMPEDANCE : 4~16

NETWORK

ANALOG IN

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

DIGITAL IN

OPTICAL

AUDIO

OPTICAL

OUT

Digital device

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 21

Connecting an iPod or USB memory device to the USB port

To connect an iPod/iPhone to this unit, use the USB adapter cable that was supplied with the iPod/iPhone.

For operating instructions, see

“Playing an iPod” (v

p. 40) or “Playing files stored on USB memory devices” (v p. 45).

USB memory

device

iPod

Denon does not guarantee that all USB memory devices will operate or receive power. When using a portable USB hard disk drive (HDD) which came with an AC adapter, use that device’s supplied AC adapter.

NOTE

USB memory devices will not work via a USB hub.

It is not possible to use this unit by connecting the unit’s USB port to a PC via a USB cable.

Do not use an extension cable when connecting a USB memory device. This may cause radio interference with other devices.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 22

Supported iPod/iPhone models

• iPod classic

• iPod nano

• iPod touch

• iPhone

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 23

Connecting to a home network (LAN)

You can connect this unit to your home network (LAN) to perform various types of playbacks and operations as follows.

Playback of network audio such as Internet Radio and from your music server(s)

Playback of music content from online streaming services

Using the Apple AirPlay function

Operation on this unit via the network

Firmware Update

Wired LAN

SPEAKERS

IMPEDANCE : 4~16

ANALOG IN

DIGITAL IN

OPTICAL

CONNECT

Wi-Fi

SUB WOOFER

OUT

iOSWPS

NETWORK

Internet

Modem

Router

To WAN side

To LAN port

LAN port/

Ethernet

connector

LAN port/

Ethernet

connector

NAS

(Network Attached

Storage)

For connections to the Internet, contact an ISP (Internet Service Provider) or a computer shop.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 24

Wireless LAN

Internet

Modem

To WAN side

Router with access point

With this unit, it is possible to use the DHCP and Auto IP functions to make the network settings automatically.

When using this unit with the broadband router’s DHCP function enabled, this unit automatically performs the IP address setting and other settings. When using this unit connected to a network with no DHCP function, make the settings for the IP address, etc., at “Network”. (v p. 79)

When using this unit, we recommend you use a router equipped with the following functions:

Built-in DHCP server This function automatically assigns IP addresses on the LAN.

Built-in 100BASE-TX switch When connecting multiple devices, we recommend a switching hub with a speed of 100 Mbps or greater.

Use only a shielded STP or ScTP LAN cable which is easily available at electronics stores. (CAT-5 or greater recommended)

The normal shielded-type LAN cable is recommended. If a flat-type cable or unshielded-type cable is used, other devices could be affected by noise.

When using a WPS (Wi-Fi Protected Setup) compatible router, you can connect easily to Wi-Fi by pressing the Wi-Fi CONNECT/WPS button on this unit. (See the separate “Quick Setup Guide”.)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 25

NOTE

The types of routers that can be used depend on the ISP. Contact your ISP or a computer shop for details.

This unit is not compatible with PPPoE. A PPPoE-compatible router is required if you have a contract for a type of line set by PPPoE.

Do not connect a NETWORK connector directly to the LAN port/ Ethernet connector on your computer.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 26

Connecting the power cord

After completing all the connections, insert the power plug into the power outlet.

SPEAKERS

IMPEDANCE : 4~16

To household power outlet (AC 230 V, 50/60 Hz)

Power cord

(supplied)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 27

Contents

Basic operation

Turning the power on 28

Selecting the input source 28

Adjusting the volume 29

Turning off the sound temporarily 29

Playback a device

Playing an iPod 40

Playing a USB memory device 44

Listening to music on a Bluetooth device 46

Listening to DIGITAL IN 51

Listening to ANALOG IN 51

Playback network audio/service

Listening to Internet Radio 30

Playing back files stored on PC or NAS 34

AirPlay function 52

Spotify Connect function 55

Other functions

Favorite function 38

Remote play function 56

Web control function 59

Convenience functions 65

Contents Connections Playback

Settings

Tips Appendix

Playback

Front/Top

panel

Rear panel

Remote control unit

Index

Page 28

Basic operation

ADD

CALL

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

MODE

REP

REPEATAT

RANDO

RANDOM

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

ENTER

MUSIC

SERVER

INTERN

INTERNETET

RADIO

Blu

Bluetooth

iPo

iPod/

USB

AUX

POWER

VOLUME

MUTE

POWER

VOLUME

MUTE

Input source

select buttons

Turning the power on

Press POWER X to turn on power to the unit.

You can also switch the power to standby by pressing X on the main unit.

Selecting the input source

Press the input source select button to be played back.

The desired input source can be selected directly.

Press AUX again to switch between AUX:Digital In/AUX:Analog In.

You can also select the input source by pressing SOURCE on the main unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 29

Adjusting the volume

Use VOLUME df to adjust the volume.

The volume level is displayed.

You can also adjust the volume by turning VOLUME df on the main unit.

Turning off the sound temporarily

Press MUTE :.

“MUTING” appears on the display.

To cancel mute, either adjust the sound volume or press MUTE : again.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 30

Listening to Internet Radio

POWER

CLOCK

DIMMER

SLEEP

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

Blu

Bluetooth

iPo

iPod/

USB

AUX

INTERN

INTERNETET

RADIO

ADD

CALL

FAVORITES

ENTER

INFO

FAVORITES

ADD/CALL

1/3

INTERNET

RADIO

uio p

ENTER

Internet Radio refers to radio broadcasts distributed over the Internet. Internet Radio stations from around the world can be received.

The broad cast station types and specifications supported by this unit for playback are as follows.

WMA

MP3

MPEG-4 AAC

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 31

Listening to Internet Radio

This unit memorizes the last played Internet Radio station. If you press INTERNET RADIO to switch to the Internet Radio function from another input source, the last Internet Radio station you listened to is played.

Prepare for playback.

Check the network environment, then turn on this unit’s power. (v

p. 23)

Press INTERNET RADIO.

Use ui to select the you want to play, then press ENTER.

Country name : Displays typical Internet Radio stations.

Search Stations :

Displays all Internet Radio stations that this unit can tune in to.

Search Podcasts :

Displays Internet Radio stations in the podcasts that this unit can tune in to.

Recommended Stations :

Displays recommended Internet Radio stations.

radiodenon.com:

Displays Internet Radio stations added to favorites in vTuner. For instructions on how to add to favorites in vTuner, see

“Using

vTuner to add Internet Radio stations to favorites” (v

p. 33).

Recently Played :

Displays recently played Internet Radio stations. Up to 20 stations can be stored in “Recently Played”.

Search by Keyword :

Displays Internet Radio stations searched by keyword. For character input, see “Inputting characters” (v p. 72).

Use ui to select the station, then press ENTER.

Playback starts once buffering reaches “100%”.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 32

Operation buttons Function 1/3

Playback/Stop

FAVORITES CALL Call from the Favorite list

FAVORITES ADD Add to the Favorite list

Character search

If the list is not in alphabetical order, you may not be able to perform a character search.

u i o p

Select the item

ENTER Enter the selected item

INFO

Switching the file type/ bit rate and radio station name etc.

Any characters that cannot be displayed are replaced with “.” (period).

NOTE

The radio station database service may be suspended or be otherwise unavailable without notice.

Playing the last played Internet Radio station

Press INTERNET RADIO.

The source switches to “Internet Radio” and the last played radio station plays.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 33

Using vTuner to add Internet Radio stations to favorites

There are many Internet Radio stations in the world, and this unit can tune into these stations. But finding the radio station you want to hear may be difficult, because there are too many stations. If this is the case, then please use vTuner, an Internet Radio station search website specifically designed for this unit. You can use your PC to search Internet Radio stations and add them as your favorites. This unit can play radio stations added to vTuner.

Check the MAC address of this unit. “Network Information” (v

p. 79)

The MAC address is necessary when you create an account for vTuner.

Use your PC to access the vTuner website (http:// www.radiodenon.com).

Enter the MAC address of this unit, then click “Go”.

Enter your E-mail address and a password of your choice.

Select the search criteria (genre, region, language, etc.) of your choice.

You can also enter a keyword to search for a station you want to hear.

Select the radio station of your choice from the list, and then click the Add to Favorites icon.

Enter the name of the favorite group, then click “Go”.

A new favorite group that includes the selected radio station is created.

Internet Radio stations added to favorites in vTuner can be played from “radiodenon.com”

p. 31) with this unit.

Files that can be played back

See “Playing back Internet Radio” (v

p. 103).

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 34

Playing back files stored on a PC and NAS

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

SETUP

VOLUME

MODE

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

Blu

Bluetooth

iPo

iPod/

USB

AUX

MUSIC

SERVER

INFO

ENTER

REP

REPEATAT

RANDO

RANDOM

1/3

8 9

MUSIC

SERVER

INFO

RANDOM

REPEAT

uio p

ENTER

FAVORITES

ADD/CALL

This unit can play back music files and playlists (m3u, wpl) stored on a PC and on Network Attached Storage (NAS) that supports DLNA.

The network audio playback function of this unit connects to the server using technologies shown below.

Windows Media Player Network Sharing Service

This unit can play back the following files.

WMA

MP3

WAV

MPEG-4 AAC

FLAC

ALAC

AIFF

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 35

Applying media sharing settings

Here, we apply the settings to share music files stored on a PC and NAS on the network. If you are using a Media Server, be sure to apply this setting first.

When using Windows Media Player 12 (Windows 7 / Windows 8)

Start up Windows Media Player 12 on the PC.

Select “More streaming options...” in the “Stream”.

Select “Allowed” in the drop-down list for “Denon CEOL piccolo”.

Select “Allowed” in the drop-down list for “Media programs on this PC and remote connections...”.

Follow the instructions on the screen to complete the settings.

When using Windows Media Player 11

Start up Windows Media Player 11 on the PC.

Select “Media Sharing” in the “Library”.

Click the “Share my media” check box, select “Denon CEOL piccolo”, and then click “Allow”.

As you did in step 3, select the icon of the device (other PCs and mobile devices) you want to use as a media controller, and then click “Allow”.

Click “OK” to finish.

Sharing media stored on a NAS device

Change settings on the Network Attached Storage (NAS) device to allow this unit and other devices (PCs and mobile devices) used as media controllers to access the NAS. For details, see the owner’s manual that came with the NAS.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 36

Playing back files stored on a PC and NAS

Use this procedure to play music files or playlists.

Prepare for playback.

Check the network environment, then turn on this unit’s power. “Connecting to a home network (LAN)” (v

p. 23)

Prepare the computer (vComputer’s operating instructions).

Press MUSIC SERVER.

Use ui to select the server including the file to be played, then press ENTER.

Use ui

to select the file, then press ENTER.

Playback starts once buffering reaches “100%”.

Operation buttons Function

1/3

Playback / Pause

(Press and hold) Stop

8 9

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast-forward

FAVORITES CALL Call from the Favorite list

FAVORITES ADD Add to the Favorite list

Character search

If the list is not in alphabetical order, you may not be able to perform a character search.

RANDOM Random playback

REPEAT

Repeat playback

Switching between Single-track repeat and Alltrack repeat.

u i o p

Select the item

ENTER Enter the selected item

INFO

Switching the file type/bit rate, artist name, and album title.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 37

Files that can be played back

See “Playing back files stored on PC or NAS” (v

p. 104).

WMA Lossless files can be played when using a server supporting transcoding, such as Windows Media Player Ver. 11 or later.

NOTE

When playing back music files with your PC or NAS connected through wireless LAN, audio may be interrupted depending on your wireless LAN environment. In this case, play back music files with your PC or NAS connected through wired LAN.

The order in which the tracks/files are displayed depends on the server specifications. If the tracks/files are not displayed in alphabetical order due to the server specifications, searching by the first letter may not work properly.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 38

Favorite function

POWER

CLOCK

DIMMER

SLEEP

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

SDB

TONE

MUTE

ENTER

Blu

Bluetooth

iPo

iPod/

USB

AUX

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

ADD

CALL

FAVORITES

0 – 9, +10

+, –

CLEAR

FAVORITES

ADD/CALL

uio

ENTER

This section provides information on the Favorite function.

The Favorite function allows you to register your favorite broadcast stations and files in the Favorite List in advance so that you can call and listen to the stations or files right away, whenever you want.

The contents that you can register and call are Internet radio station, music server, USB and iPod (only when using Browse iPod mode).

The contents that you can register and call are Internet radio station and music server.

Up to 50 items can be stored in the Favorite List.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 39

Registering stations or files to the favorites list

Press FAVORITES ADD while the Internet radio station or file to register is played back.

Use ui to select a number to register the station or file, and press ENTER.

“Added To Favorites” is displayed and the registration is competed.

Calling stations or files from the favorites list

Press FAVORITES CALL.

Use CH+, CH– or ui to select the station or file that you want to call, and press ENTER.

The respective function starts up and playback starts.

Press 0 – 9, +10 to call files registered to the Favorite list by number.

To switch between registered stations and files during playback

Use CH+, CH– or ui.

Deleting stations or files from the favorite list

Press FAVORITES CALL.

Use ui

to select the station or file that you want to

delete, and press CLEAR.

When the prompt “Delete?” appears, press ENTER.

“Deleted” is displayed and the deletion is completed.

Press o to cancel the operation.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 40

Playing an iPod

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

SETUP

VOLUME

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

Blu

Bluetooth

AUX

iPo

iPod/

USB

INFO

ENTER

MODE

REP

REPEATAT

RANDO

RANDOM

iPod/ USB

INFO

MODE

uio p

ENTER

RANDOM

REPEAT

1/3

8 9

You can use the USB cable provided with the iPod to connect the iPod with the unit’s USB port and enjoy music stored on the iPod.

For information on the iPod models that can be played back with this unit, see “Supported iPod/iPhone models” (v

p. 22).

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 41

Listening to music on an iPod

Connect the iPod to the USB port. (v

p. 21)

When you connect iPod to the USB port, the input source automatically switches to “iPod/USB”.

Press iPod/USB to switch the input source to “iPod/ USB”.

“Remote iPod” is displayed on the display of this unit.

Operate iPod itself directly while seeing the iPod screen to play back music.

The iPod display modes include “Remote iPod” and “Browse iPod”. By default, “Remote iPod”, where you directly operate the iPod itself while looking at the iPod screen, is set.

To change to “Browse iPod” where operations are performed while the iPod information is displayed on this unit, see

“Setting operation mode (Browse iPod

mode)” (v

p. 42).

You can also listen to iPod music using

“AirPlay function” (v

p. 52).

NOTE

Depending on the type of iPod and the software version, some functions may not operate.

Note that Denon will accept no responsibility whatsoever for any problems arising with the data on an iPod when using this unit in conjunction with the iPod.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 42

Setting operation mode (Browse iPod mode)

In this mode, various lists and screens during playback on the iPod are displayed on the body.

This section describes the steps up to playing back tracks on the iPod in “Browse iPod”.

Press MODE and display “Browse iPod”.

Use ui

to select the file to be played, then press

ENTER.

Playback starts.

Display mode Remote iPod

Browse

iPod

Playable files Music file

P P

Video file

Active buttons Remote control

unit (This unit)

P P

iPod

z Only the sound is played.

Operation buttons Function

1/3

Playback / Pause

(Press and hold) Stop

8 9

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast-forward

RANDOM Random playback

REPEAT

Repeat playback

Switching between Single-track repeat and Alltrack repeat.

MODE

Switching between Browse iPod or Remote iPod mode.

u i o p

Select the item

ENTER Enter the selected item

INFO Switching the artist name and album title.

NOTE

Denon will accept no responsibility whatsoever for any loss of iPod data.

Depending on the type of iPod and the software version, some functions may not operate.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 43

Charging the iPod/iPhone

You can charge your iPod/iPhone by connecting it to USB port.

Standby charging

If the unit enters power standby mode while the iPod/iPhone is charging, the unit will switch to standby charging mode, and the iPod/ iPhone will continue to be charged. When in standby charging mode, the power indicator lights turns red.

When the iPod/iPhone is fully charged, the unit automatically stops supplying power for charging and enters normal power standby mode, and the power indicator lights turns off.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 44

Playing a USB memory device

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

SETUP

VOLUME

MUSIC

SERVER

INTERN

INTERNETET

RADIO

CLEAR

SDB

TONE

MUTE

Blu

Bluetooth

AUX

iPo

iPod/

USB

INFO

ENTER

REP

REPEATAT

RANDO

RANDOM

MODE

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

1 2 3

4 5 6

7 8 9

+10 0

0 – 9, +10

iPod/ USB

INFO

uio p

ENTER

RANDOM

REPEAT

1/3

8 9

Playing back music files stored on a USB memory device.

Only USB memory devices conforming to mass storage class and MTP (Media TransferProtocol) standards can be played on this unit.

This unit is compatible with USB memory devices in “FAT16” or “FAT32” format.

This unit can play back the following files.

WMA

MP3

WAV

MPEG-4 AAC

FLAC

ALAC

AIFF

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 45

Playing files stored on USB memory devices

Connect the USB memory device to the USB port. (v

p. 21)

When you connect USB memory device to the USB port, the input source automatically switches to “USB”.

Use ui to select the file to be played, then press ENTER.

Playback starts.

Operation buttons Function

1/3

Playback / Pause

(Press and Hold) Stop

8 9

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast-forward

RANDOM Random playback

REPEAT

Repeat playback

Switching between Single-track repeat and Alltrack repeat.

Character search

If the list is not in alphabetical order, you may not be able to perform a character search.

u i o p

Select the item

ENTER Enter the selected item

INFO Switching the artist name and album title.

NOTE

Note that Denon will accept no responsibility whatsoever for any problems arising with the data on a USB memory device when using this unit in conjunction with the USB memory device.

Files that can be played back

See “Playing back USB memory devices” (v

p. 101).

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 46

Listening to music on a Bluetooth device

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

ENTER

iPo

iPod/

USB

AUX

Blu

Bluetooth

ENTER

Bluetooth

1/3 8 9

Music files stored on Bluetooth devices such as smartphones, digital music players, etc. can be enjoyed on this unit by pairing and connecting this unit with the Bluetooth device.

Communication is possible up to a range of about 10 m.

NOTE

To play back music from a Bluetooth device, the Bluetooth device needs to support the A2DP profile.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 47

Pairing with a Bluetooth device

In order to enjoy music from a Bluetooth device on this unit, the Bluetooth device must first be paired with this unit.

Once the Bluetooth device has been paired, it does not need to be paired again.

Press Bluetooth to switch the input source to “Bluetooth”.

When using for the first time, the unit will go into the pairing mode automatically and “Pairing Mode” will appear on the display of the unit.

Select this unit when its name appears in the list of devices displayed on the screen of the Bluetooth device.

At the end of the pairing, the device name appears on the display of this unit.

Connect to the Bluetooth device while “Pairing Mode” is being displayed on the display of the unit. Perform the connection with the Bluetooth device close to the unit (about 1 m).

When connecting a second Bluetooth device, either press and hold Bluetooth on the remote control unit or SOURCE on this unit for approximately 3 seconds, or press SEARCH when the input source is set to “Bluetooth” in order to pair with the Bluetooth device.

This unit can be paired with a maximum of 8 Bluetooth devices. When a 9th Bluetooth device is paired, it will be registered in place of the oldest registered device.

When a number appears on the display of this unit, check that it is the same number as that shown on the screen of the Bluetooth device and then select “pair” for both the Bluetooth device and the unit. (To select “pair” on this unit, press ENTER on the unit.)

Enter “0000” when the password is requested on the screen of the Bluetooth device.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 48

Playing a Bluetooth device

Check the following before you play back music.

The Bluetooth function of the Bluetooth device must be turned on

Pairing must be completed

Press Bluetooth to switch the input source to “Bluetooth”.

The unit will automatically connect to the most recently used Bluetooth device.

Start playing the Bluetooth device.

The Bluetooth device can also be operated with the remote control of this unit.

Operation buttons Function 1/3

Playback / Pause

8 9

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast-forward

When the power of this unit is turned on, the input source will be automatically switched to “Bluetooth” if a Bluetooth device is connected.

When the “Network Control” setting of this unit is set to “On” and a Bluetooth device is connected with the unit in the standby state, the power of the unit will be turned on automatically.

Press INFO on this unit during playback to switch the display between Title name, Artist name, Album name, etc.

Incompatible characters are displayed as “.” (period).

NOTE

To operate the Bluetooth device with the remote control of this unit, the Bluetooth device needs to support the AVRCP profile.

The remote control of this unit is not guaranteed to work with all Bluetooth devices.

Depending on the type of Bluetooth device, this unit outputs audio that is coupled to the volume setting on the Bluetooth device.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 49

Pairing with the Pairing Mode

Pair a Bluetooth device with this unit.

Press SEARCH when the input source is “Bluetooth”.

The device will go into the pairing mode.

Either press and hold Bluetooth for 3 seconds, or switch the input source to “Bluetooth” and then press and hold SOURCE on this unit for more than 3 seconds to switch to pairing mode.

Select this unit when its name appears in the list of devices displayed on the screen of the Bluetooth device.

At the end of the pairing, the device name appears on the display of this unit.

Enter “0000” when the password is requested on the screen of the Bluetooth device.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 50

Connecting a Bluetooth device with the NFC function via NFC

You can just touch this unit with a Bluetooth device to turn on power to this unit and perform pairing or establish a connection between this unit and the Bluetooth device.

Turn on the NFC function on the Bluetooth device.

For details, see the owner’s manual for your Bluetooth device.

Touch Q on this unit with the NFC antenna part on the Bluetooth device.

If a pairing confirmation screen is displayed, follow the instructions on this unit and the Bluetooth device to complete pairing.

Complete operations as instructed by the Bluetooth device.

Play back music on the Bluetooth device.

This unit outputs music from the Bluetooth device.

When “Network Control” is set to “On”, startup and connection can be performed even when the unit power is off.

When you touch the N mark (Q) on this unit with the Bluetooth device that is playing back music, this unit outputs that music.

Touch the N mark (Q) again during the Bluetooth connection to disconnect the connection.

Touch the N mark (Q) again if pairing or connection with the Bluetooth device fails.

NOTE

Before establishing a NFC connection, cancel the lock function on the Bluetooth device.

When you touch this unit with a Bluetooth device, do so softly.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 51

ADD

CALL

CLOCK

DIMMER

SLEEP

FAVORITES

TOP MENU

INFO

SETUP

MODE

REP

REPEATAT

RANDO

RANDOM

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

ENTER

MUSIC

SERVER

INTERN

INTERNETET

RADIO

Blu

Bluetooth

iPo

iPod/

USB

AUX

POWER

VOLUME

MUTE

AUX

Listening to DIGITAL IN

Prepare for playback.

Check the connection, then turn on this units.

Press AUX to select “AUX:Digital In”.

Play the component connected to this unit.

Only 2-channel linear PCM digital audio signals can be inputted through the DIGITAL IN connector of this unit.

Listening to ANALOG IN

Prepare for playback.

Check the connection, then turn on this units.

Press AUX to select “AUX:Analog In”.

Play the component connected to this unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 52

AirPlay function

Music files stored on your iPhone, iPod touch, iPad or iTunes can be played on this unit via the network.

You can stop AirPlay playback by pressing o or choosing other input source.

To see song and artist names together, press INFO on the remote control unit.

For information about how to use iTunes, also see the Help for iTunes.

The screen may differ depending on the OS and software versions.

Router

This unit

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 53

Playing songs from your iPhone, iPod touch or iPad

If you update your “iPhone/iPod touch/iPad” to iOS 4.2.1 or later, you can stream music stored in your “iPhone/iPod touch/iPad” directly to this unit.

Connect your iPhone, iPod touch or iPad Wi-Fi to the same network as this unit.

For details, see your device’s manual.

Play the song on your iPhone, iPod touch or iPad.

' is displayed on the iPhone, iPod touch or iPad screen.

Tap the AirPlay icon '.

AirPlay

AirDrop

Select this unit.

Playing iTunes music with this unit

Install iTunes 10, or later, on a Mac or Windows PC that is connected to the same network as this unit.

Turn this unit ON.

Set “Network Control” to “On” for this unit. (v

p. 79)

NOTE

When “Network Control” is set to “On”, the unit consumes more standby power.

Start iTunes and click the AirPlay icon ' to select the main unit.

Choose a song and click play in iTunes.

The music will stream to this unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 54

Selecting multiple speakers (devices)

It is possible to play iTunes songs on your home’s AirPlay compatible speakers (devices) other than those of this unit.

Click the AirPlay icon ' and select “Multiple”.

Check the speakers you want to use.

NOTE

In playback using the AirPlay function, the sound is output at the iPhone, iPod touch, iPad or iTunes volume setting level. You should turn down the iPhone, iPod touch, iPad or iTunes volume prior to playback and then adjust it to a suitable level.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 55

Spotify Connect function

Spotify is the world’s most popular streaming service. If you subscribe to Spotify Premium, you can control your new speaker with your phone or tablet. Because Spotify is built-in to your speaker, you can still take calls or use other apps - the music never stops.

To try Spotify Premium free for 30 days, or learn more about Connect, please go to www.spotify.com/connect.

Spotify server

Control

Spotify App

This unit

Audio streaming/control

Playing Spotify music with this unit

Download the “Spotify App” onto your Android or iOS device beforehand. To play a Spotify track in this unit, you need to register in the Spotify premium account first.

Connect the Wi-Fi settings of the iOS or Android device in the same network as this unit.

Launch the Spotify App.

Play back the Spotify track.

Tap the F

icon to select the unit.

4:440:13

The music will stream to this unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 56

Remote play function

You can use your home network to play back with this unit music files stored on PC, NAS, smartphones and portable audio players.

In this case, you use PC, smartphones and portable audio players for operations.

The relevant devices should comply with the DLNA (Digital Living Network Alliance) Ver. 1.5 standard.

A wireless LAN environment is required for playing back music files on smartphones or portable audio players.

For some smartphones, you must install an application for DLNA music playback.

Roles each device plays

The following devices are used for Remote Play. As specified in the DLNA standard, these devices are called DMC, DMS or DMR according to their role.

Name Device example Role

DMC

(Digital Media Controller)

Smartphone

Portable audio player

Denon Hi-Fi Remote App

Performs Remote Play operations. DMC can also play back music files stored on these devices.

DMS

(Digital Media Server)

NAS (Network Attached Storage)

Stores music files. Music files stored on these devices are played back with DMC.

DMR

(Digital Media Renderer)

This unit

Outputs audio of music files played back through Remote Play from speakers. DMR cannot perform playback operations.

Files that can be played back

See “Playing back files stored on PC or NAS” (v

p. 104).

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 57

Settings required for each device

You must make settings on DMC and DMS for Remote Play. Make the following settings. Also see the owner’s manual of each device for settings.

Settings on computer and NAS

Make settings on computer and NAS to exchange data with DMR devices.

For details on the settings, see “Applying media sharing settings” (v

p. 35).

Settings on smartphones

You must install an application for DLNA music playback on your smartphone to perform operations on DMS and this unit (DMR) with your smartphone. The applicable application differs according to your smartphone.

Some smartphones support DLNA music playback with the factory settings. See the owner’s manual of your smartphone.

Settings on portable audio players

Configure the settings so that this unit (DMR) can play back music files stored on your portable audio player. For details on the settings, see the owner’s manual of your portable player.

Settings on this unit

Connect this unit to the DLNA network. You do not need to make other settings.

For the network connection, see the provided “Quick Setup Guide”, “Connecting to a home network (LAN)” (v

p. 23) and

“Settings” (v p. 80).

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 58

Remote Play operations

Operations are different for each device, but the procedures for preparing for Remote Play are the same. The preparation procedures are shown below.

Turn on this unit.

Make sure that this unit is connected to the network.

Display the music file playback screen on DMC.

For PC, open Windows Media Player 12, etc.

For smartphones, switch to the music file playback mode.

Select the friendly name of this unit for the item that sets the playback device on the playback screen.

The default Friendly Name of this unit is “Denon CEOL piccolo”.

Start playing back a music file on DMC.

The function on this unit automatically switches to “Music Server” and the Remote Play mark m appears on the display. Remote

Play starts.

Press o to exit Remote Play mode.

NOTE

During Remote Play, you cannot perform playback operations with this unit. Use the DMC device for these operations.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 59

Web control function

You can control this unit from a web control screen on a web browser.

Router

This unit

This unit and the PC need to be connected to the network properly in order to use the web control function.

“Connecting to a home network (LAN)” (v

p. 23)

Depending on the settings of your security-related software, you may not be able to access this unit from your PC. If this is the case, then change the settings of the security-related software.

Controlling the unit from a web control

Switch the “Network Control” setting to “On”. (v

p. 79)

Check the IP address of this unit with “Network Information”.

p. 79)

IP Address

[Network Information ]

192.168.0.2

Checking the IP address.

Start up the web browser.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 60

Enter the IP address of this unit in browser’s address box.

For example, if the IP address of this unit is “192.168.0.2”, enter “http://192.168.0.2”.

Please select the menu.

news(45)WikipediaYouTubeYahoo! JapanappleBonjour

http://192.168.0.2

NETWORK

FIRMWARE

Entering the IP address.

If you are using the Safari web browser, you can select “Bonjour” and directly access the unit’s web control screen from the overview section.

By adding this unit’s IP address to the browser’s bookmark, you can display the web control screen using the bookmark function the next time you use the browser. If you are using a DHCP server and “Network Control” (v

p. 79)

is set to “Off”, turning the power on/off changes the IP address.

When the top menu is displayed, click on the menu item you want to operate.

Please select the menu.

NETWORK

FIRMWARE

e r

Click when you setup network settings. (vGExample 1H)

Click when you update firmware.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 61

Operate.

GExample 1H Network Setting 1

Friendly Name

Denon CEOL piccolo Set Set Default

Network Connection

Select Connection

Wired

[+]DHCP or Proxy

Test Connection

NETWORK

FIRMWARE

Friendly Name setting

To change the Friendly Name, enter the new name in the text box and click “Set”.

To reset the Friendly Name, click “Set Default”.

Only characters that can be displayed on this unit can be set. (v p. 72)

Network connection settings

Click to change the network connection method. If you select “Wi-Fi”, a new item will appear on-screen. (vGExample 2H)

Click to change DHCP/proxy settings. (vGExample 2H)

Click to connect using the newly applied settings.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 62

Operate.

GExample 2H Network Setting 2

Friendly Name

Denon CEOL piccolo Set Set Default

Network Connection Select Connection Wi-Fi

Save DHCP Proxy Settings

NETWORK

Wi-Fi Setup Manual

Manual

None

Key1

---

S SID Security Security Key Defaullt Key

Address Name

ON OFF

192.168.000.001

255.255.255.000

000.000.000.000

000.000.000.000 00000

Test Connection

[-]DHCP or Proxy DHCP IP Address Subnet Mask Gateway Primary DNS Secondary DNS Proxy Address Or Name Address Port

NETWORK

FIRMWARE

Network connection settings

J GExample 2H - Displayed when “Wi-Fi” is selected in G.

Select or input items as necessary, and then click “Test Connection” to apply the changes.

Items displayed may vary depending on selected items and connection status.

After selecting each item, wait a moment for the display to be updated.

GExample 2H - Displayed when “DHCP” or “Proxy” is selected in H. When changing DHCP/proxy settings, input or select for each item.

To apply network connection settings, click “Test Connection” after making changes.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 63

Update on web screen

“Web control function” (v

p. 59) settings must be completed in advance on a computer belonging to the same network. For information on obtaining update files, please contact our customer service center.

Click D from step 5 for the “Web control function”. (v

p. 59)

The PC will display the following screen. Wait for approximately 1 minute. You can also gain access by entering the IP address shown by the

unit into a web browser.

G The web display H

Please wait...

FIRMWARE

G The unit’s screen display H

When the following screen is displayed by the PC, click the “Choose File” (A) button, select the update file, and click the “Upload” (B) button.

Firmware

Upload new firmware

Upload

Choose File

Click “OK”.

Updating will begin.

Firmware

Warning:

Once started,the upload process cannot be interrupted or adorted, in order to ensure the integrity of the Digital Media Player. Are you sure you want to proceed?

NOTE

Do not operate the unit while updating is in progress.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 64

When the following screen is displayed, updating is complete.

Firmware

New Firmware: xxx.fw

Firmware upload status: 100% completed.

The upload process finished successfully. Please close this.

Button names may vary depending on the OS language used on your computer.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 65

Convenience functions

ADD

CALL

POWER

FAVORITES

TOP MENU

INFO

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

MUTE

Blu

Bluetooth

iPo

iPod/

USB

AUX

CLOCK

DIMMER

SLEEP

SDB

TONE

ENTER

SETUP

DIMMERSLEEP

CLOCK

SDB

TONE

SETUP

uio p

ENTER

Adjusting the tone 66

Sleep timer function 67

Checking the current time 67

Switching the display’s brightness 68

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 66

Adjusting the tone

Press SDB/TONE to select the tone parameter to be adjusted.

Use ui to adjust “Super Dynamic Bass”, “Bass”, “Treble”, “Balance” or “Source Direct”.

Super Dynamic Bass

Emphasizes the bass sound in stages according to the volume (maximum +8 dB).

On / Off (Default: Off)

Bass

Adjusts the bass sound.

–10dB – +10dB(Default : 0dB)

Treble

Adjusts the treble sound.

–10dB – +10dB(Default : 0dB)

Balance

Use op to adjust the left/right volume balance.

Source Direct

The tone is not adjusted.

On / Off (Default: Off)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 67

Sleep timer function

You can have the power automatically switched to standby once a set time has elapsed. This is convenient for listening while going to sleep.

Press SLEEP during playback and select the setting time.

The o indicator on the display lights.

You can set the sleep timer in the range from 10 to 90 minutes in steps of 10 minutes.

To cancel the sleep timer

Press SLEEP to set “Sleep 1Off”. The o indicator on the display turns off.

The sleep timer setting is canceled when the unit switches to standby mode.

To check the time remaining until the sleep timer is activated, press SLEEP.

Checking the current time

Checking the current time when the power is on

Press CLOCK.

Press once more and the display returns to its original condition.

Checking the current time when the power is set to standby

Press CLOCK.

The current time is displayed for 30 seconds.

The time cannot be set when in the standby mode. Turn on the power first.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 68

Switching the display’s brightness

Press DIMMER.

The brightness of the display switches each time the button is pressed (5 levels).

If the buttons are operated when the display is turned off, information is displayed temporarily at a low brightness level.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 69

Menu map

For menu operations, see the following page. By default, this unit has recommended settings defined. You can customize this unit based on your existing system and your preferences.

Quick Setup

Setting items Description Page

Quick Setup Performs the network settings using a Wizard style window.

For details on the operations, see the separate “Quick Setup Guide”.

–

General

Setting items Description Page Alarm Sets the timer playback. 74 Clock Sets the current time.

Volume Limit Make a setting for maximum volume. 75 Speaker Optimization Sets the optimum playback properties of the speakers SC-N4, sold separately. 76 Language Sets the language for display the menu.

Auto-Standby Sets the unit power to standby when the unit is not in use. 76 Usage Data Selects whether or not to send anonymous usage data to Denon. 76 Firmware Set whether or not to check for firmware update, update the firmware, and display update and upgrade

notifications.

Update Update the firmware of this unit. 77 Notifications Set the Update, Upgrade and Alerts notification on/off. 77 Add New Feature Display new features that can be downloaded to this unit and perform an upgrade.

Contents Connections Playback

Settings

Tips Appendix

Settings

Front/Top

panel

Rear panel

Remote control unit

Index

Page 70

Network

Setting items Description Page Network Information Displays various information about the network. 79 Network Control Performs the ON/OFF settings for the network function when in standby mode. 79 Friendly Name Edits a name displayed on the Internet.

Settings Performs the settings for a wired or wireless LAN. 80

Wired Setup Performs the settings for a wired LAN. 80

DHCP (On) or

DHCP

(Off)

Performs the DHCP setting.

IP Address

Performs the IP address setting. 81

Subnet Mask

Performs the subnet mask setting. 81

Gateway

Performs the gateway setting.

Primary DNS

Performs the primary DNS setting. 81

Secondary DNS

Performs the Secondary DNS setting.

Proxy Performs the proxy setting. 81 Test Connection Performs the wired LAN connection. –

Wi-Fi Setup Method Performs the wireless LAN connection setting.

Auto-Scan Selects and sets the wireless connections from the access point list. 82 Share Wi-Fi setting

from an iOS device

Sets the wireless connection using an iOS device. (iOS version 7 or later) 83

WPS (Wi-Fi Protected Setup)

Sets the wireless connection using WPS (Wi-Fi Protected Setup).

Web Browser Setup Sets the wireless connection using web browser. 83 Manual Sets the wireless connection manually. 85

zDisplayed when the “DHCP” setting is “Off”.

p. 80)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 71

ADD

CALL

POWER

CLOCK

DIMMER

SLEEP

FAVORITES

INFO

VOLUME

MODE

REP

REPEATAT

RANDO

RANDOM

MUSIC

SERVER

INTERN

INTERNETET

RADIO

. /

ABC

a/A

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

CLEAR

1 2 3

4 5 6

7 8 9

+10 0

SDB

TONE

MUTE

Blu

Bluetooth

iPo

iPod/

USB

AUX

TOP MENU

SETUP

ENTER

SETUP

uio p

ENTER

TOP MENU

Menu operation

Press SETUP.

The menu is displayed.

Use uiop

to select the menu to be set or operated,

then press ENTER.

Use ui to change to desired setting.

Press ENTER to enter the setting.

To return to the previous item, press o.

Exiting the Menu, press SETUP while the menu is displayed. The menu display disappears.

To back to the top of the menu, during menu operation, press TOP MENU.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 72

Inputting characters

On this unit, you can change the name displayed on the following screens to the names that you prefer.

Text Search (v p. 31, 36, 45)

Character input for the network functions

p. 31)

Using the number buttons

Display the screen for inputting characters.

To change a character, use op to align the cursor with the character that you want to change.

Press +10 to select the character type (upper case, lower case, or numeric characters).

Press 0 – 9, +10 until the desired character is displayed.

The types of characters that can be input are as shown below.

( )

1 . @ - _ / : m n o M N O 6

a b c A B C 2 p q r s P Q R S 7

d e f D E F 3 t u v T U V 8

g h i G H I 4 w x y z W X Y Z 9

j k l J K L 5

z + , ; < =

> ? [ \ ] ^ ` { | }

% & ‘ ( )

! “ # $

Space

Repeat steps 2 and 3 to change the name then press ENTER to register it.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 73

Using the cursor buttons

Display the screen for inputting characters.

To change a character, use op to align the cursor with the character that you want to change.

Use ui

to change the character.

The types of characters that can be input are as shown below.

abcdefghijklmnopqrstuvwxyz

ABCDEFGHIJKLMNOPQRSTUVWXYZ

z + , - . / : ; < = > ? @ ! “ # $ % & ‘ ( )

[ \ ] ^ _ ` { | } ~

0123456789

GLower caseH

GUpper caseH

GSymbolsH

GNumbersH

(Space)

Repeat step 2 to change the name then press ENTER to register it.

Press CLEAR to delete the character.

Press 9 to insert a space.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 74

General

Make various other settings.

Alarm

Set the once alarm and everyday alarm.

Once

Once Alarm Setting: Set the once alarm to on.

Off: The alarm does not operate.

Every Day

Every Day: Set the everyday alarm to on.

Off: The alarm does not operate.

Edit Alarm

Edit the once alarm and everyday alarm.

Use ui to select the alarm mode, then press ENTER.

Use ui to setting for the alarm start time, then press ENTER.

Use ui to select the input source, then press ENTER.

When “Bluetooth” is selected, this unit attempts to connect to the previously connected device.

Use ui to select the volume level “00 – 60”, then press ENTER.

The display shows “Complete!!” and the setting is completed.

The power indicator lights orange when the unit is switched to standby mode in this state.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 75

Clock

Set the current time

You can automatically adjust the clock of this unit using the Internet.

To use this function, the unit must be connected to the Internet.

Use ui to select your time zone, then press ENTER.

Use ui

to select the summer time, then press ENTER.

On: Set the summer time to on.

Off (Default): Set the summer time to off.

Volume Limit

Make a setting for maximum volume

Limits the volume to ensure safe use of this product, and also makes it easier to adjust the volume from AirPlay or an app to an ideal range.

30/45(Default)/60(Full throttle)/Other

When “Other” is selected, the volume upper limit can be set within the range of 16 - 60. Select the value using ui and then press ENTER to enter the setting value.

When the maximum volume is set, if you increase the volume to the setting value and press VOLUMEd again, “Allow max volume?” is displayed. If you press VOLUME d again the maximum volume limit is canceled.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 76

Speaker Optimization

An optimizing filter suited for the properties of the speakers (SC-N4) can be used.

On (Default):

The response is optimized for the speakers (SC-N4, sold separately).

Off: The response is flat.

Language

Set the language for display on the menu.

English / Deutsch / Française / Italiano / Nederlands / Español / Svenska / Русский

/ Polski (Default : English)

Auto-Standby

When “Auto-Standby” is set to “On”, and no operations are made in the stopped state for the set amount of time, this unit automatically enters standby mode.

For the input source “Remote iPod” only, when no operation is performed for eight hours, this unit automatically enters the standby mode.

1min / 5min / 15min (Default)

Other:

When “Other” is selected, the “Auto-Standby” time can be set within the range of 1 - 99 minutes. Select the value using ui and then press ENTER to enter the setting value.

Off: The unit does not go into standby automatically.

Usage Data

For product improvement purposes, please send information on the device settings and operating conditions of the functions to Denon. Information provided by customers will be used as reference material for product development purposes in the future.

Denon will never provide any information we collect to third parties.

Yes: Provide information on the operating status of this unit.

No: Do not provide information on the operating status of this unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 77

Firmware

Set whether or not to check for firmware update, update the firmware, and display update, upgrade and alert notifications.

Update

Update the firmware of this unit.

Check For Update: Check for firmware updates.

Update Start: Execute the update process.

Even if the update fails, this unit will automatically try to update again.

Notifications

Notification messages are displayed in the screen when the power is switched on when new firmware can be used, or when there are other notification messages.

Update

On (Default): Display update message.

Off: Do not display update message.

Upgrade

(Default): Display upgrade message.

Off: Do not display upgrade message.

Notification Alerts

(Default):

Displays notification messages from Denon in the popup menu.

Off:

Does not display notification messages from Denon in the popup menu.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 78

Add New Feature

Display new features that can be downloaded to this unit and perform an upgrade.

Upgrade package:

Display the items to be upgraded.

Upgrade Status:

Display a list of the additional functions provided by the upgrade.

Upgrade Start:

Execute the upgrade process. When the upgrade starts, the menu screen is shut down. During the upgrade, the amount of upgrade time which has elapsed is displayed.

Upgrade ID:

The ID number shown on the display is needed when carrying out the procedure.

See the Denon website for details about upgrades.

When the procedure is complete, “Registered” is displayed in this menu and upgrades can be carried out. If the procedure has not been carried out, “Not Registered” is displayed.

Notes concerning use of “Update” and “Add New Feature”

In order to add new functions, the environment and settings required for connecting to broadband internet are needed.

p. 23)

Perform the add new feature operation after at least 2 minutes has elapsed since turning this unit’s power on.

Do not turn off the power until updating or upgrading is completed.

Even with a broadband connection to the Internet, approximately 20 minutes is required for the updating/upgrading procedure to be completed.

Once updating/upgrade starts, normal operations on this unit cannot be performed until updating/upgrading is completed. Furthermore, updating/upgrading the firmware may reset the backup data for the parameters, etc. set for this unit.

When the update or upgrade failed with a message such as “Update failed” and “Download failed”, remove and re-insert the power cord. “Update Retry” appears on the display and update restarts from the point at which update failed. If the error continues despite this, check the network environment.

Information regarding the “Update” function and “Add New Feature” will be announced on the Denon web site each time related plans are defined.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 79

Network

To use this unit by connecting it to a home network (LAN), you must configure network settings. If you set up your home network via DHCP, set “DHCP” to On (use the default setting). This allows this unit to use your home network.

If you assign an IP address for each device, you must use the “IP Address” setting to assign an IP address to this unit and enter the information about your home network such as the gateway address and subnet mask.

Network Information

Display network information.

Friendly Name / DHCPOn or Off / IP Address / MAC Address / SSID

This is displayed only while a Wi-Fi connection is enabled.

Network Control

Enables network communication in standby power mode.

On:

The network function can be used when in standby power mode. Main unit operable with a network compatible controller.

Off (Default):

The network function cannot be used in standby power mode.

When using the Web control function or a network controller or when you want to use Bluetooth/NFC quickly when the power is off, set “Network Control” to “On”.

NOTE

When “Network Control” is set to “On”, the unit consumes more standby power.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 80

Friendly Name

The Friendly Name is the name of this unit displayed on the network. You can change the Friendly Name according to your preferences.

Select Name

Selects Friendly Name from the list.

Current Friendly Name/Denon DRA-N4 / AV Room / Bedroom / Dining Room / Family Room / Guest Room / Kids Room / Kitchen / Living Room / Office / Denon CEOL piccolo

(Default) /

Other

When you select “Other”, you can change the Friendly Name according to your preferences.

Up to 63 characters can be input.

For character input, see

72).

Settings

You can make detailed settings for the network. To change the network environment, perform “Quick Setup”. (For details

on the operations, see the separate “Quick Setup Guide”.)

If you are using a broadband router (DHCP function), there is no need to make the settings at “IP Address” and “Proxy”, since the DHCP function is set to “On” in this unit’s default settings.

Only set “Settings” when connecting to a network without a DHCP function.

When making wired connection

DHCP

Selects how to connect to the network.

(Default):

Configure the network settings automatically from your router.

Off: Configure the network settings manually.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 81

IP Address

Set the IP address within the ranges shown below.

The Network Audio function cannot be used if other IP addresses are set.

CLASS A: 10.0.0.1 - 10.255.255.254 CLASS B:

172.16.0.1 - 172.31.255.254

CLASS C: 192.168.0.1 - 192.168.255.254

Subnet Mask

When connecting an xDSL modem or connector adapter directly to this unit, input the subnet mask indicated in the documentation supplied by your provider. Normally input 255.255.255.0.

Gateway

When connected to a gateway (router), input its IP address.

Primary DNS, Secondary DNS

If there is only one DNS address indicated in the documentation supplied by your provider, enter it for “Primary DNS”. If two or more DNS are provided by your provider, enter one for “Secondary DNS”.

Proxy

Make this setting when connecting to the Internet via a proxy server. Make the proxy settings only when you connect to the Internet via a

proxy server that is on your internal network or provided by your provider, etc.

Proxy (Off) or Proxy (On): Set the proxy server.

Proxy (Address) or Proxy (Name):

Select when inputting by address or domain name.

Address or Name:

Inputting address or domain name. Up to 38 characters can be input.

Port: Enter port number.

If you cannot connect to the Internet, recheck the connections and settings. (v p. 23)

If you do not understand about Internet connection, contact your ISP (Internet Service Provider) or the store from which you purchased your computer.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 82

When making Wi-Fi connection

In this menu, Wi-Fi settings and connections can be made using any of the five connection methods

Auto-Scan / Share Wi-Fi setting from an iOS device / WPS (Wi-Fi Protected Setup) / Web Browser Setup / Manual

If a LAN cable is connected, remove it.

See the Quick Setup Guide for details on how to connect to Wi-Fi using the Wi-Fi CONNECT button on the rear panel.

Auto-Scan

This automatically searches for networks.

From the list of the networks, select the one you want to connect to.

Select “Rescan” if the network cannot be found.

Make the following settings.

Default Key:

Select the default key.

When connecting to a WEP encrypted network, “Default Key” menu is displayed.

Password: Input the password.

DHCP/Proxy：

Performs the DHCP and proxy setting. (v

p. 80, 81)

Test Connection: Test the connection.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 83

Share Wi-Fi setting from an iOS device

You can use an iOS device such as an iPhone or iPad to configure WiFi settings.

After selecting this item, select Settings/Wi-Fi from the iOS device home screen, select “Denon CEOL piccolo” displayed at the bottom of the screen, and then follow the setting instructions displayed on the iOS device.

For details, see the “Quick Setup Guide”.

The iOS version must be 7 or later.

WPS (Wi-Fi Protected Setup)

Web Browser Setup

Use a web browser to set up Wi-Fi. A Wi-Fi device that can perform web browse operations is required.

Read the precautions on the screen, and press ENTER.

Select “Denon CEOL piccolo” from the Wi-Fi network list of the Wi-Fi device.

The IP address (192.168.1.16) appears on the unit.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 84

Enter the IP address of this unit in browser’s address box.

Please select the menu.

news(45)WikipediaYouTubeYahoo! JapanappleBonjour

http://192.168.1.16

NETWORK

Entering the IP address (192.168.1.16).

If you are using the Safari web browser, you can select “Bonjour” and directly access the unit’s web control screen from the overview section.

When the top menu is displayed, click “NETWORK”.

Please select the menu.

NETWORK

Click “NETWORK”. (vGExample 1H)

Operate.

GExample 1H Network Setting 1

Friendly Name

Denon CEOL piccolo

Network Connection

Select Connection

Test Connection

NETWORK

Network connection settings

Click to change the network connection method. If you select “Wi-Fi”, a new item will appear on-screen. (vGExample 2H)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 85

GExample 2H Network Setting 2

Friendly Name

Denon CEOL piccolo

Network Connection

Select Connection Wi-Fi

NETWORK

Manual

None

Key1

---

SSID Security Security Key Defaullt Key

Test Connection

NETWORK

Network connection settings

E GExample 2H - Displayed when “Wi-Fi” is selected in D. Select or

input items as necessary, and then click “Test Connection” to apply the changes.

Items displayed may vary depending on selected items and connection status.

After selecting each item, wait a moment for the display to be updated.

To apply network connection settings, click “Test Connection” after making changes.

Manual

Sets the wireless connection manually

SSID : Input the name of the wireless network (SSID).

Security:

Select the encryption method according to the encryption setting of the access point you are using.

Default Key:

Select the Default Key.

When connecting to a “WEP” encrypted network, “Default Key” menu is displayed.

Password: Input the password.

DHCP/Proxy：

Performs the DHCP and proxy setting. (v p. 80,

81)

Test Connection: Test the connection.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 86

Contents

Tips

Simple operations in the power off state 87

Simple operations for iPod/USB 87

I only want to recharge my iPod 87

Specifying the iPod track with the alarm function 87

Specifying the desired track with the alarm function 87

Change to summer time 87

Changing or resetting the network environment 88

Volume adjustment is difficult when using AirPlay or app operation, and the sound suddenly becomes too loud 88

Troubleshooting

Power does not turn on / Power is turned off 89

LED is flashing 89

Operations cannot be performed through the remote control unit 90

Display on this unit shows nothing 90

No sound comes out 91

Desired sound does not come out 92

Sound is interrupted or noise occurs 93

iPod cannot be played back 94

USB memory devices cannot be played back 95

Bluetooth cannot be played back 96

File names on the iPod/USB memory device are not displayed properly 96

The Internet radio cannot be played back 97

Music files on PC or NAS cannot be played back 98

Cannot connect by Wi-Fi 99

Contents Connections Playback

Settings

Tips Appendix

Tips

Front/Top

panel

Rear panel

Remote control unit

Index

Page 87

Tips

Simple operations in the power off state

When a input source select buttons, 1/3 button, FAVORITES CALL button or 5

button is pressed, the operation is performed at the same time as the

unit switches on. (v

p. 28, 38)

When the “Network Control” is set to “On”, you can perform playback, or other operations through AirPlay, Denon “Hi-Fi Remote” app. (v p. 79)

Simple operations for iPod/USB

When connected to the USB port, the Input Source automatically changes and playback begins. (v p. 41, 44)

I only want to recharge my iPod

Connect the iPod to this unit when the unit power is on. Then turn the unit power off, and the iPod will continue to charge until fully charged.

p. 43)

Specifying the iPod track with the alarm function

Connect the iPod to this unit by USB and then press the MODE button to register your favorite tracks in the favorites using Browse iPod mode. (v p. 38) Then set a track registered in the favorites as the alarm. (v p. 74)

When using alarm playback on an iPod touch or iPhone, set the iPod touch or iPhone to “Sleep” mode. If the power is switched off using the power off operation, alarm playback cannot be used.

Specifying the desired track with the alarm function

After registering the desired track in NAS, etc., register the track in the favorites and then specify the track in the alarm settings. (v p. 74)

Change to summer time

Select “General” - “Clock” in the setup menu and configure the settings.

p. 75)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 88

Changing or resetting the network environment

Prepare the provided Quick Setup Guide, and run Setup – “Quick Setup”. For detailed settings, run Setup - “Network” - Settings.

p. 80)

Volume adjustment is difficult when using AirPlay or app operation, and the sound suddenly becomes too loud

Reducing the “Volume Limit” setting value (to around 20 to 30) limits the volume setting from AirPlay or an app to an ideal range and makes it easier to adjust the volume. (v p. 75)

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 89

Troubleshooting

1. Are the connections correct?

Is the set being operated as described in the owner’s manual?

3. Are the other devices operating properly?

If this unit does not operate properly, check the items listed in the table below. Should the problem persist, there may be a malfunction. In this case, disconnect the power immediately and contact your store of purchase.

Power does not turn on / Power is turned off

Symptom Cause / Solution Page

Power does not turn on.

Check whether the power plug is correctly inserted into the power outlet.

Power automatically turns off.

The sleep timer is set. Turn on the power again. 67

“Auto-Standby” is set. “Auto-Standby” is triggered when there is no operation for a set amount of time. To disable “Auto-Standby”, set “Auto-Standby” on the menu to “Off”.

LED is flashing

Symptom Cause / Solution Page

Flashing red.

The amplifier circuit in the unit has malfunctioned. Disconnect the power and contact the repair center. －

The clock is incorrect because the AC was temporarily switched off, etc. Check the network connection and adjust the clock.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 90

Operations cannot be performed through the remote control unit

Symptom Cause / Solution Page

Operations cannot be performed through the remote control unit.

Batteries are worn out. Replace with new batteries. 6

Operate the remote control unit within a distance of about 7 m from this unit and at an angle of within 30°. 6

Remove any obstacle between this unit and the remote control unit. －

Insert the batteries in the proper direction, checking the q and w marks.

The set’s remote control sensor is exposed to strong light (direct sunlight, inverter type fluorescent bulb light, etc.). Move the set to a place in which the remote control sensor will not be exposed to strong light.

－

When using a 3D video device, the remote control unit of this unit may not function due to effects of infrared communications between units (such as TV and glasses for 3D viewing). In this case, adjust the direction of units with the 3D communications function and their distance to ensure they do not affect operations from the remote control unit of this unit.

－

Display on this unit shows nothing

Symptom Cause / Solution Page

Display is off.

Press the DIMMER button on the remote control to set any setting other than OFF. 68

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 91

No sound comes out

Symptom Cause / Solution Page

No sound comes out of speakers.

Check the connections for all devices. 17

Insert connection cables all the way in. －

Check that input connectors and output connectors are not reversely connected. －

Check cables for damage. －

Check that speaker cables are properly connected. Check that cable core wires come in contact with the metal part on speaker terminals. Also, securely tighten speaker terminals. Check speaker terminals for looseness.

Check that a proper input source is selected.

Adjust the volume. 29

Cancel the mute mode. 29

Check that the correct input source is selected when audio is being input to this unit from an external device.

Check the digital audio output setting on the connected device. The initial settings may be off depending on the device.

Only 2-channel linear PCM can be input as the digital audio signal to the DIGITAL IN connector of this unit.

No sound is output from the speakers when headphones are connected.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 92

Desired sound does not come out

Symptom Cause / Solution Page

Left/right volume balance is unbalanced.

Press the SDB/TONE button on the remote control to adjust the balance. 66

No sound from the sub woofer.

Check the subwoofer connections. 18

Switch the subwoofer power on. －

Set values are not reflected in “Super Dynamic Bass”, “Bass” and “Treble”.

“Super Dynamic Bass”, “Bass” and “Treble” setting values are not reflected in subwoofer out.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 93

Sound is interrupted or noise occurs

Symptom Cause / Solution Page

During playback from the Internet radio or USB memory device, sound is occasionally interrupted.

When the transfer speed of the USB memory device is slow, sound may occasionally be interrupted. －

The network communication speed is slow or the radio station is busy. －

When making a call on iPhone, noise occurs in audio output on this unit.

When making a call, keep a distance of 20 cm or longer between iPhone and this unit. －

Sound cuts out when using Wi-Fi connection.

If nearby devices cause playback to cut out due to electronic interference, switch to a wired LAN connection.

Particularly when you play back large music files, depending on your wireless LAN environment, the playback sound may be interrupted. In this case, make the wired LAN connection.

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 94

iPod cannot be played back

Symptom Cause / Solution Page

iPod cannot be connected.0When using iPod by connecting it to the USB port, some iPod variations are not supported. 22

When iPod is connected by using a USB cable other than the genuine cable, iPod may not be recognized. Use a genuine USB cable.

－

The AirPlay icon ' is not displayed on iTunes / iPhone / iPod touch / iPad.

This unit and PC / iPhone / iPod touch / iPad are not connected to the same network (LAN). Connect it to the same LAN as this unit.

The firmware on iTunes / iPhone / iPod touch / iPad is not compatible with AirPlay. Update the firmware to the latest version.

－

No sound is produced.

The volume on iTunes / iPhone / iPod touch / iPad is set to the minimum level. The volume on iTunes / iPhone / iPod touch / iPad is linked with the volume on this unit. Set a proper volume level.

－

The AirPlay playback is not performed, or this unit is not selected. Click the AirPlay icon ' on the iTunes / iPhone / iPod touch / iPad screen and select this unit.

Audio is interrupted during the AirPlay playback on iPhone / iPod touch / iPad.

Quit the application running in the background of the iPhone/iPod touch/iPad, and then play using AirPlay.

－

Some external factors may be affecting the wireless connection. Modify the network environment by taking measures such as shortening the distance from the wireless LAN access point.

－

iTunes cannot be played back through the remote control unit.

Enable the “Allow iTunes audio control from remote speakers” setting on iTunes. Then, you can perform playback, pause, and skip operations through the remote control unit.

－

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 95

USB memory devices cannot be played back

Symptom Cause / Solution Page

“No Connection” is displayed.

The set cannot recognize a USB memory device. Disconnect and reconnect the USB memory device. 21

USB memory devices of a mass storage class or those compatible with MTP are supported. －

This unit does not support a connection through a USB hub. Connect the USB memory device directly to the USB port.

－

The USB memory device must be formatted to FAT16 or FAT32. －

Not all USB memory devices are guaranteed to work. Some USB memory devices are not recognized. When using a type of portable hard disc drive compatible with the USB connection that requires power from an AC adapter, use the AC adapter that came with the drive.

－

Files on the USB memory device are not displayed.

Files of a type not supported by this unit are not displayed.

This unit can display a file structure with up to 8 levels and up to 5000 subfolders and files in total. Modify the folder structure of the USB memory device.

－

When multiple partitions exist on the USB memory device, only files on the first partition are displayed. －

Files on a USB memory device cannot be played.

Files are created in a format that is not supported by this unit. Check the formats supported by this unit.

You are attempting to play a file that is copyright protected. Files that are copyright protected cannot be played on this unit.

－

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 96

Bluetooth cannot be played back

Symptom Cause / Solution Page

Bluetooth devices cannot be connected to this unit.

The Bluetooth function in the Bluetooth device has not been enabled. See the Owner’s Manual of the Bluetooth device to enable the Bluetooth function.

－

Bring the Bluetooth device near to this unit. －

The Bluetooth device cannot connect with this unit if it is not compatible with the A2DP profile. －

Turn the power of the Bluetooth device off and on again, and then try again. －

Set “Network Control” to “On” and connect again.

NFC connection fails

Check the NFC settings on each Bluetooth device. －

Cancel the Lock function on each Bluetooth device. －

Check the NFC position on each Bluetooth device, and then move the NFC close to Q on this unit.

Set “Network Control” to “On” and connect again. 79

The sound is cut off.

Bring the Bluetooth device near to this unit. －

Remove obstructions between the Bluetooth device and this unit. －

To prevent electromagnetic interference, locate this unit away from microwave ovens, wireless LAN devices and other Bluetooth devices.

－

Reconnect the Bluetooth device. －

File names on the iPod/USB memory device are not displayed properly

Symptom Cause / Solution Page

The file names are not displayed properly (“…”, etc.).

Characters that cannot be displayed are used. This is not a malfunction. On this unit, characters that cannot be displayed are replaced with a “.” (period).

－

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 97

The Internet radio cannot be played back

Symptom Cause / Solution Page

The radio station list is not displayed.

The LAN cable is not properly connected, or the network is disconnected. Check the connection status. 23

Internet Radio cannot be played.

The selected radio station is broadcasting in a format that is not supported by this unit. Formats that can be played back in this unit are MP3, WMA and AAC.

103

The firewall function is enabled on the router. Check the firewall setting. －

The IP address is not properly set.

Check the power of the router is on. －

To obtain the IP address automatically, enable the DHCP server function on the router. Also, set the DHCP setting to “On” on this unit.

To obtain the IP address manually, set the IP address and proxy on this unit. 80

Some radio stations broadcast silently during some time period. In this case, no audio is output. Wait for a while and select the same radio station, or select another radio station.

Cannot connect to favorite radio stations.

Radio station is not currently in service. Register radio stations in service. －

For some radio stations, “Connection Down” is displayed and station cannot be connected to.

The selected radio station is not in service. Select a radio station in service. －

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 98

Music files on PC or NAS cannot be played back

Symptom Cause / Solution Page

Files stored on a computer cannot be played.

Files are stored in a non-compatible format. Record in a compatible format. 104

You are attempting to play a file that is copyright protected. Files that are copyright protected cannot be played on this unit.

－

The set’s USB port cannot be used for connection to a computer. －

Media sharing settings are not correct. Change media sharing settings so that the unit can access the folders on your computer.

Server is not found, or it is not possible to connect to the server.

The computer’s or router’s firewall is activated. Check the computer’s or router’s firewall settings. －

Computer’s power is not turned on. Turn on the power. －

Server is not running. Launch the server. －

Set’s IP address is wrong. Check the set’s IP address.

Music files on PC cannot be played back.

Even if PC is connected to the USB port on this unit, music files on it cannot be played back. Connect PC to this unit through the network.

Files on PC or NAS are not displayed.

Files of a type not supported by this unit are not displayed. 104

Music stored on a NAS cannot be played.

If you use a NAS in conformity with the DLNA standard, enable the DLNA server function in the NAS setting.

－

If you use a NAS that does not conform with the DLNA standard, play the music via a PC. Set Windows Media Player’s media sharing function and add NAS to the selected play folder.

If connection is restricted, set audio equipment as the connection target. －

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 99

Cannot connect by Wi-Fi

Symptom Cause / Solution Page

Cannot connect to the network.

The network name and password (WEP, etc.) settings are wrong. Configure the network settings according to the setting details of this unit.

Reduce the distance between the wireless LAN access point and this unit, remove any obstructions and make sure the view to the access point is unobstructed before trying to connect again. Also, install microwave ovens and other network access points as far away as possible.

－

Check the router power supply. －

This unit supports IEEE802.11.b/g/n. －

Configure the access point channel settings away from channels that are being used by other networks. －

This unit is not compatible with WEP (TSN). －

Cannot connect to WPS.

Check that the WPS mode of the router is operating. －

Press and hold the Wi-Fi CONNECT/WPS button on this unit for approx. 3 seconds within 2 minutes of operating the router.

－

A router/settings that are compatible with WPS 2.0 standards are required. Set the encryption time to “None”, “WPA-PSK (AES)” or “WPA2-PSK (AES)”.

If the router encryption method is WEP/WPA-TKIP/WPA2-TKIP, you cannot connect by using the Wi-Fi CONNECT/WPS button. In this case, use the “Auto-Scan” or “Manual” method to connect.

Cannot connect to the network using iPhone/iPod touch/iPad.

Update the iPhone/iPod touch/iPad firmware to the latest version. －

When using a USB cable to configure the settings, the iOS device firmware version needs to support iOS 5 or later. When configuring the settings via a wireless connection, iOS 7 or later needs to be supported.

－

Contents Connections Playback

Settings

Tips Appendix

Front/Top

panel

Rear panel

Remote control unit

Index

Page 100

Resetting factory settings

Perform this procedure if the display is abnormal or if operations cannot be performed. Various settings are reset to the factory default values. Make settings again.

VOLUME

ENTER

VOLUME

When power is switched to standby.

Press the power button (X) while pressing VOLUMEdf together on this unit.

When the power indicator lights, release the all buttons.

“Initialized” appears on the display.

If “Initialized” does not display in step 3, start over from step 1.

Contents Connections Playback

Settings

Tips Appendix

100

Front/Top

panel

Rear panel

Remote control unit

Index
