Denali M1 Thermoelectric Chiller
Manual
(from Solid State Cooling Systems built exclusively for Cole-Parmer)
167 Myers Corners Road, Wappingers Falls NY, 12569
(845)296-1300
email: info1@sscooling.com
www.sscooling.com
DENALI M1 52-13382-1
2
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1
T
AABBLLEE OOFF
T
SAFETY PRECAUTIONS AND SYMBOLS _____________________________________________ 2
SECTION 1 _________________________________________________________________________ 3
INTRODUCTION ______________________________________________________________________ 3
SECTION 2 _________________________________________________________________________ 4
SPECIFICATIONS _____________________________________________________________________ 4
SECTION 3 _________________________________________________________________________ 6
HOOK UP __________________________________________________________________________ 6
3.1 ELECTRICAL CONNECTIONS (SEE FIGURE 3B) ____________________________________________ 7
3.2 PLUMBING CONNECTIONS (SEE FIGURE 3B) _____________________________________________ 7
3.3 AIR CONSIDERATIONS _____________________________________________________________ 8
3.4 COOLANT FILL ___________________________________________________________________ 8
SECTION 4 _________________________________________________________________________ 8
START UP __________________________________________________________________________ 8
SECTION 5 _________________________________________________________________________ 9
C
OONNTTEENNTTS
C
S
OPERATION ________________________________________________________________________ 9
5.1 SIMPLE OPERATION _______________________________________________________________ 9
5.2 ADVANCED OPERATION ____________________________________________________________ 9
5.3 ALARM SIGNAL _________________________________________________________________ 11
SECTION 6 ________________________________________________________________________ 12
SYSTEM ALARMS/TROUBLESHOOTING ___________________________________________________ 12
SECTION 7 ________________________________________________________________________ 13
DENALI M1 RS-232 COMMUNICATION __________________________________________________ 13
7.1 COMMUNICATION SPECIFICATION ___________________________________________________ 13
7.2 COMMUNICATION PROTOCOL _______________________________________________________ 14
7.3 RS232 COMMUNICATION EXAMPLES _________________________________________________ 15
SECTION 8 ________________________________________________________________________ 15
TECHNICAL SUPPORT ________________________________________________________________ 15
SECTION 9 ________________________________________________________________________ 16
MSDS FOR COOLANTS _______________________________________________________________ 16
WARRANTY POLICY ______________________________________________________________ 28
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1300 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
1
Date
October 22, 2013
CE Declaration of Conformity
We: Solid State Cooling Systems
167 Myers Corners Road
Wappingers Falls, NY 12590
USA
declare under our sole responsibility that the
Denali M1
meets the provisions of the directives:
2004/108/EC EMC Directive
2006/95/EC Low Voltage Directive
EN 61326-1: 2006 Emissions and Immunity
EN 61000-3-2: 2006 Harmonics Emissions
EN 61000-3-3: 2008 Voltage Fluctuations and Flicker
EN 61010-1: 3rd Edition Safety Low Voltage Directive Safety requirements for
electrical equipment for measurement, control, and
laboratory use.
Lloyd F Wright
Chief Technology Officer
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
2
CAUTION
WARNING
SAFETY PRECAUTIONS AND SYMBOLS _________________________
Read the MSDS for the coolant used and follow all safety precautions listed in the MSDS
prior to removing coolant tubes or opening the fill cap as this could result in contact with the
coolant inside.
CCAAUUTTIIOONN
Never disassemble the chiller as irreparable damage may occur.
Any attempt to open or repair the unit will void the warranty
Never store the chiller over 60 °C.
Never operate the chiller in ambient temperatures of 40 ºC or greater.
Never operate the chiller within 2 ºC of the coolant’s freezing point.
Always use only proper coolants as specified in manual. SSCS recommends Koolance
LIQ-702CL-B (27% Propylene Glycol and water)
Never ship the chiller with coolant inside the liquid cold plate as freezing temperatures may be
encountered which would damage the unit. Always pump all coolant out of the chiller prior to
shipping.
Symbols Used in this Manual
The red CAUTION equilateral triangle symbol appears throughout
the manual. Please follow the important instructions accompanying
this symbol to avoid significant damage to the chiller.
The red WARNING equilateral triangle symbol appears throughout
the manual accompanying certain maintenance and repair activities.
Please follow the important instructions accompanying this symbol
to avoid situations that could cause injury to the operator or other
personnel.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
3
Manual
D
EENNAALLII
D
T
HHEERRMMOOEELLEECCTTRRIICC CCHHIILLLLEER
T
MM11
R
PRODUCT
SECTION 1
I
NTRODUCTION _________________________________________________
The Denali M1 mini recirculating chiller utilizes thermoelectric
technology to deliver 180 Watts of cooling capacity without the use
of compressors or refrigerants. With fewer moving parts, the system
is highly reliable and energy efficient. As the world’s smallest, air
cooled recirculating chiller, the Denali M1 is ideal for laboratory
use. It is the perfect bench-top solution to precisely control the
temperature of analytical equipment, lasers, low-light CCD
cameras, microtiter cold plates, sample stages or any process
requiring point of use temperature control. The system is versatile
and simple to operate. It also has a cycling feature where two
different temperature s et points may be entered with a soak t ime at
each temperature and the number of cycles desired.
The chiller ships with the items listed below. Please locate them
prior to discarding the shipping box.
(1) Denali M1 Recirculating Liquid Chiller
(1) 200 watt 13.5 VDC Table Top Power Supply
(1) AC Line Cord
(1) 250 ml Squirt Bottle
(2) Valve quick disconnect fittings, 1/8th inch hose barb
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
4
SECTION 2
S
PECIFICATIONS _______________________________________________
Operating (Set Point) Range: 0°C to 45 °C
Ambient Temperature: 10°C to 40 °C (non-condensing)
Stability / Repeatability: + 0.1 °C with constant load (even near ambient)
Cooling Capacity: 180 watts @ 20°C in a 20°C ambient
(See figure 1 for cooling curve)
Heating Capacity: >240 watts @ 20°C in a 20°C ambient
Noise (at 1 meter): < 55 dBA
Coolant Type: 27% Propylene Glycol and Water recommended preventing
bacterial growth and minimizing noise and extending pump
life. (Note: propylene glycol is non-toxic). SSCS
Recommends Koolance LIQ-702CL-B coolant.
Ethylene Glycol and Water mixtures are also acceptable.
Note: Methanol, Ethanol, or Isopropyl Alcohol may not
be used as coolants, either by themselves or in water
mixtures; use of these coolants voids the chiller
warranty.
Process Fluid Fittings: 1/8” CPC quick disconnect with shut-off valves
Coolant Pump: 500ml/min brushless DC magnetically driven gear
(See Figure 2 for pump curve)
Coolant Outlet Pressure: Nominal 10psi @ 500ml/min, Maximum 35 psig
Tank Volume: 75 ml
Wetted Materials: Copper, polymers and stainless steel
Size (L x W x H): 7.5” x 5” x 7” (19 x 13 x 18 cm)
Weight: 9 lbs (4.1 kg)
Operating Voltage: 13.5VDC, 15 amps max
AC/DC Power Supply Output: 200 watt, 13.5 VDC; 100-240 VAC input
AC/DC Power Supply Input: Universal 100-240 VAC, 50/60 Hz, 2.8 amps max
Communications: Keypad or RS232 interface
Alarms: Temperature, fluid level, system or component failure
Safety Certifications: (with power supply) CE/ UL (TUV)
EN 61010-1: 3rd Edition
UL 61010-1: 3rd Edition
CAN/CSA 61010-1: 3rd Edition
RoHS RoHS Compliant
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
5
Figure 1
Denali M1 Capacity in 20°C Ambient
Figure 2
Denali M1 Pump Performance @ 20°C Fluid Temperature
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
Note: Pump to pump variation is +/- 10%.
DENALI M1 52-13382-1
6
Tank
9-pin Dsub
Coolant
Keypad
Airflow Outlet
Display
Airflow Inlet
DC Power
ON/OFF
SECTION 3
H
OOK UP ______________________________________________________
Figure 3A: Top View
Screen
(Under Magnet Cover)
For RS-232 &
Dry Contact Alarms
Figure 3B: Back View
Switch
Connector
Return
Coolant
Supply
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
7
Country / Region
Part Number
USA/Canada
22-22333-1
Europe
22-22333-2
Japan
22-22333-3
UK
22-22333-4
Israel
22-22800-1
Australia
22-23213-1
Korean
22-23526-1
China (3 prong)
22-23661-1
NEMA 6-15 208 US Straight
16-23918-1
NEMA L6-15 208 US Twist
16-23918-2
9 Pin D-Sub Pin#
RS-232 Signal Description
2
Transmit Data (TXD)
3
Receive Data (RXD)
5
Ground
WARNING
Electrical Shock
3.1 ELECTRICAL CONNECTIONS (SEE FIGURE 3B)
Power: The Denali M1 comes with a 200w 13.5VDC bench top
power supply. Plug the DC output connector into the Denali M1 as
shown in figure 3B.
A wide variety of power cords are available to support universal
power operation:
Hazard: Never Plug
in a Line Cord with
Wet Hands
Alarms: The Denali M1 has one 250 VAC 1 amp dry contact relay
to indicate a system alarm or temperature out of range. Connect to
this dry contact on the 9-pin dsub connector as follows:
System/Temp Alarm: Pin 1
Alarm Signal Return: Pin 6
RS 232: The Denali M1 comes with a RS-232 communication link.
Connections are made via a 9-pin dsub connector as follows:
3.2
PLUMBING CONNECTIONS (SEE FIGURE 3B)
The Denali M1 has two Colder Products compatible 1/8” valved
quick disconnect coolant fittings. Two mating valved quick
disconnect inserts are included with 1/8” ID hose barb fittings for
convenience.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
8
WARNING
Electrical Shock Hazard:
Read the Coolant MSDS
Use only recommended
coolants
WARNING
CAUTION
3.3 AIR CONSIDERATIONS
Restricting airflow into or out of the Denali M1 will impair
performance. Maintain at least 3” of clearance around the air inlet
and outlet to ensure no restriction of airflow.
3.4 COOLANT FILL
The coolant fill cap is located at the top of the unit. Twist and
remove the plug then use the 250 ml bottle (shipped with the chiller)
to fill reservoir prior to starting unit.
Prior to filling the chiller
S
ECTION 4
S
TART UP _____________________________________________________
Start-up the chiller using the following steps:
1) Connect 1/8” ID hose to fluid connections located on the back
side, labeled Coolant Supply and Coolant Return.
2) Open the reservoir cap on top. Using the 250 ml bottle provided,
fill the reservoir to just below the bottom of its neck with
coolant.
3) Plug the table top power supply output into DC power connector
Never Plug in a Line Cord
with Wet Hands
on back of chiller. (see Figure 3B)
4) Plug table top power supply power cord into an AC power outlet.
5) Optional: connect the alarm signal to the 9-pin dsub connector as
per section 3.1.
6) Turn on switch located to the left of the display. The front
display should read the current coolant temperature. If the front
display reads “TANK LOW”, add coolant to the reservoir until
the display changes to read the coolant temperature.
Important Notes:
1) The Denali M1 p erforms a self-diagnostic check for 10 seconds
after turn-on. If the tank level low alarm persists, or if another
alarm is displayed, consult section 6.0 of this manual.
2) If the chiller tank is filled above the bottom of its neck, coolant
can leak out the top when the cap is closed.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
9
Key
Action
UP
Pressing the UP key raises the parameter value displayed.
DOWN
Pressing the DOWN key lowers the parameter value displayed
ENTER
Pressing the ENTER key momentarily enters the parameter changed.
ENTER
Pressing and holding the ENTER key for 3 seconds changes the LCD display menu.
SECTION 5
O
PERATION ____________________________________________________
The chiller is operated via the control panel located on the top of the
unit. The control panel has an 8-character LCD display and three
input keys: UP, DOWN, and ENTER. These keys work as follows:
5.1 SIMPLE OPERATION
The Denali M1 comes with preset operating parameters that will
work well for most applications. If temperature control at one
temperature is desired, follow the steps below.
1) Turn on chiller and wait for display to read TEMP: XX.X°C
2) Press the UP or DOWN keys to change SETTEMP1 to the
desired set point.
3) Press the ENTER key.
The chiller will now control to the set point temperature. To
change the set point temperature just press the UP or DOWN
keys again to change SETTEMP1 to the new set point, followed
by the ENTER key.
5.2 ADVANCED OPERATION
The Denali M1 has two menus: the Status Menu and the Paramet er
Input Menu. The Status Menu shows the current temperature of
coolant leaving the chiller (see Figure 4). The Status Menu also
allows input of new coolant temperature set points when the cycling
feature is off. The Parameter Input Menu allows input of set point
temperatures, soak times, number of cycles if cycling between two
temperatures, an alarm temperature, a temperature offset, and a
password to enter the Parameter Input Menu. (The default password
is 0000 until changed by the user.) Press and hold the enter key for 3
seconds to enter the parameter menu.
Note: While in the Parameter Input Menu, if no keys are pressed for
30 seconds the display will revert to the status menu.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
10
SIMPLE OPERATION
ADVANCED OPERATION
(STATUS MENU)
press and hold enter key
(PARAMETER INPUT MENU)
TEMP: XX.X°C (current temp)
PASSWORD XXXX
P
(change set point)
↵
SETTEMP1 XX.X°C
SETTEMP1 XX.X°C
↵
↵
TEMP: XX.X°C (current temp)
SETTIME1 XXXX (in minutes)
↵
SETTEMP2 XX.X°C
↵
SETTIME2 XXX (in minutes)
↵
# CYC XXX
↵
ALRM TMP +/-X.X°C
↵
OFFSET +/-X.X°C
↵
CHNG PWD Y/N (change
password)
Figure 4: MENU STRUCTURE:
NOMENCLATURE:
UP or Increase Value
Down or Decrease Value
↵ Press Enter Momentarily
Press & Hold Enter Key 3 Sec
RESS OR
Allowable Value Ranges:
SETTEMP1 2 TO 45 °C
SETTIME1 0 TO 999 minutes
SETTEMP2 2 TO 45 °C
SETTIME2 0 TO 999 minutes
# OF CYC 0 TO 999
ALRM TMP 1 TO 9 OC in 0.1°C increments
OFFSET -5 °C TO 5 °C in 0.1°C increments
CHNG PWD Y OR N
NOTE: If continuous control at one set-point temperature is desired, set # OF CYCLES to zero.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
11
Status Menu: The status menu displays the current coolant
temperature in °C or will display an alarm type should an alarm
occur.
Pressing the UP or DOWN keys with # of cycles set to zero will
change the set point temperature upon pressing the START key.
Parameter Input Menu: The parameter input menu allows input of
operating temperatures, soak times, number of cycles desired,
temperature units desired, time units desired, the alarm temperature
range and an offset temperature to change the displayed temperature.
SETTEMP1 = Set point of first control temperature.
If # OF CYCLES is set to zero, this is the control temperature.
SETTIME1 = Soak time at temperature 1.
Not used if # OF CYCLES is set to zero.
SETTEMP2= Set point of second control temperature.
Not used if # OF CYCLES is set to zero.
SETTIME2 = Soak time at temperature 2.
Not used if # OF CYCLES is set to zero.
# OF CYC = Number of cycles between temperature1 and
temperature2. If set to zero, the chiller will control at
temperature SETTEMP1.
ALRM TMP = +/- Alarm temperature set point.
If the current temperature is out sid e of the s et point +/- t he dry
contact alarm will open.
OFFSET = Used to adjust the current temperature displayed.
Entering 5 ºC will increase the displayed temperature by 5 ºC.
Typically used to match temperatures with an external sensor.
Also adjusts RS-232 temperature reported.
CHG PWD = Y/N Entering Y allows user to change the password
allowing entry into the parameter input menu.
5.3 ALARM SIGNAL
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
The Denali M1 has one normally closed dry contact alarm for
temperature out of range or s ystem failure, located on pins 1 & 6 of
the 9-pin dsub connector.
A list of system failures caus ing the d ry contact alarm to open can be
found in Section 6. In the event of a failure, the alarm type will be
shown on the front display.
DENALI M1 52-13382-1
12
Do not remove cover or
WARNING
SECTION 6
S
YSTEM ALARMS/TROUBLESHOOTING ______________________________
The Denali M1 has two system alarms that when triggered will
show on the display. When an alarm is displayed the system will
not attempt to heat or cool the coolant.
TANK LOW: Liquid reservoir level is too low. Unless filling for
the first time, check all outside plumbing lines for leaks. Once all
leaks are sealed, remove the cap and add more process fluid until
the alarm disappears.
attempt to repair unit,
as electrical shock
hazards exist inside.
RTD OPEN or RTD SHO RT: The temperature sen sor has failed or
its connector has come loose. Turn off the chiller and disconnect
the AC power cord. Contact SSCS for an RMA number to return
the unit for RTD replacement.
Important: The tank level low alarm will automatically reset when
the tank is filled. The RTD failure alarm will not reset until the
system power is turned off.
OTHER ISSUES:
COOLING CAPACITY INSUFFICIENT: If the chiller is not
providing sufficient cooling, check that the air inlet and outlet are
not restricted and that the fan is running. If airflow is not restricted,
contact SSCS technical support.
RS-232 COMMUNICATION NOT WORKING: If the RS-232
communications does not seem to be working try cycling the power
to reset the communications. If the problem persists, call SSCS
technical support 845-296-1300.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
13
Host / Master
9-Pin D-sub Pin #
Chiller / Slave
9-Pin Female D-sub Pin#
2 (Receive – Rx)
2 (Transmit – Tx)
3 (Transmit – Tx)
3 (Receive – Rx)
5 (Ground)
5 (Ground)
SECTION 7
D
ENALI M1 RS-232 COMMUNICATION ______________________________
The Denali M1 comes with a modified (pin-out) RS232
communication port. The chiller uses this port to communicate a
comprehensive set of control parameters with a Host PC - these
parameters are outlined in Section 7.2. This port is a 9-pin female dsub connector and is found on the front of the chiller
(see Figure 3A).
Note also that pins 1 and 6 on this port are connected to a dry contact
relay and thus the RS-232 connecting cable must be customized.
This relay is "closed" when the unit is functioning properly and the
RTD temperature is within the Alarm Range. The relay is “open”
when the RTD temperature is outside the Alarm Range or any other
fault exists.
7.1 COMMUNICATION SPECIFICATION
Table 1: Signal definition and wiring
Specification
Speed: 9600 baud
Data Flow Control: Manually set RTS (no “hardware handshaking”)
Data Format: 8-bit serial
Number of Stop bits: 1
Parity: None
Transmission Breakdown: One command byte followed by zero, one, or two data
Master/Slave: The chiller is always the SLAVE
Interrupts Reported: None, must be polled for status
Transmission Length: < 15 meters
Minimum Time Required Between
Host Command Transmissions 0.500 sec
bytes depending on data type.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
14
Bit Position
Description
Bit =1
Bit = 0
Command Byte
Bit 7 (MSB)
Set Remote Control
remote control
local control (chiller)
Bit 6
Remote On/Off
chiller On
chiller in standby
Bit 5
Communication
Direction
remote to chiller
(command from master)
chiller to remote
(status from chiller)
Bits 4 – 0
Parameters being communicated (see table 2)
Data Bytes
1 or 2 bytes depending on parameter (see tables 3 and 4)
Bits 4 – 0
Parameter
No of Data Bytes
00001
Chiller set point temperature
2
01001
Current temperature at chiller coolant output
2
01000
Faults from chiller (fan, RTD failure, etc.)
1
Temperature (examples)
High Byte
Low Byte
Hexadecimal
0.1 °C
00000000
00000001
0001
1.0 °C
00000000
00001010
000A
10.0 °C
00000000
01100100
0064
20.0 °C
00000000
11001000
00C8
30.0 °C
00000001
00101100
012C
40.0 °C
00000001
10010000
0190
Bit Position
Fault Assigned
Hex value when fault is present
7 (MSB)
Temperature below alarm range
80 6 unassigned
N/A 5 unassigned
N/A 4 RTD fault
10 3 unassigned
N/A
2
Temperature above alarm range
04 1 unassigned
N/A
0
Tank Level Low
01
7.2 COMMUNICATION PROTOCOL
Table 2: Command and Data Bytes
Table 3: Control Parameter
Table 4: Temperature Data Bytes (2 bytes)
The 2 data bytes for the temperature set point and transmission of the current temperature represent the
value of the temperature in 0.1o C increments.
For example:
Table 5: Faults Data Byte (1 byte)
0 = OK, 1 = Fault
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
15
Example
Communications Sequence
1) Send set point of 25°C to chiller
Host sends command byte = E1 (hex)
Host sends LOW data byte = FA (hex)
Host sends HIGH data byte = 00 (hex)
Chiller sends command byte = E1 (hex)
2) Read chiller set point
Host sends command byte = C1 (hex)
Chiller sends command byte = C1 (hex)
Chiller sends LOW data byte = set point value in hex (LB)
Chiller sends HIGH data byte = set point value in hex (HB)
3) Read the actual temperature
Host sends command byte = C9
Chiller sends command byte = C9
Chiller sends LOW data byte = actual temp in hex (LB)
Chiller sends HIGH data byte = actual temp in hex (HB)
4) Read the faults table
Host sends command byte = C8
Chiller sends command byte = C8
Chiller sends faults data byte = fault data in hex
Notes
1) The Oasis can store 8 bytes of transmission. It is recommended that the transmissions be limited to
1 data exchange of one, two, or three bytes (depending upon the data being communicated), until
the master has received the acknowledgement from the Oasis.
2) An acknowledgement of the transmission will be sent back to the master when the Oasis reads the
data. In the case of data transmitted to the Oasis Controller only, the acknowledgement will be the
command byte. In the case of data requested by the master, the acknowledgement will be the
command byte plus the data byte(s) requested.
3) For software that requires data types to be specified:
- Format of command bytes: number, “word”, unsigned, MSB first
- Format of sent data bytes: number, “word”, unsigned, LSB first
- Format of received data bytes: variable length string
4) If RS-232 communications does not seem to be functioning, cycle the main power to reset.
7.3 RS232 COMMUNICATION EXAMPLES
SECTION 8
T
ECHNICAL SUPPORT ___________________________________________
Delighting our customers is our highest priority. Please contact us
immediately for technical assistance whenever you have questions
or concerns.
Hours: 8 a.m. to 5 p.m. Eastern Time, weekdays
Telephone: (845) 296-1300
Fax: (845) 296-1303
E-mail: info1@sscooling.com
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
16
SECTION 9
MSDS
FOR COOLANTS
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
17
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
18
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
19
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
20
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
21
Ingredient CAS No Percent Hazardous
100% Yes
MSDS for Ethylene Glycol
ETHYLENE GLYCOL
MSDS Number: E5125 --- Effective Date: 02/25/99
1. PRODUCT IDENTIFICATION
Synonyms: 1,2-Ethanediol; glycol; 1,2-Dihydroxyethane; Ethylene Alcohol; Ethylene Dihydrate
CAS No.: 107-21-1
Molecular Weight: 62.07
Chemical Formula: CH2OHCH2OH
Product Codes:
J.T. Baker: 5387, 5845, 9140, 9298, 9300, 9346, 9349, 9356, L715
Mallinckrodt: 5001, 5037
2. COMPOSITION/INFORMATION ON INGREDIENTS
--------------------------------------- ------------ ------- ---------
Ethylene Glycol 107-21-1 99 -
3. HAZARDS IDENTIFICATION
Emergency Overview
------------------------------------------------------------------------! HARMFUL OR FATAL IF
SWALLOWED. HARMFUL IF INHALED OR ABSORBED THROUGH SKIN. MAY
CAUSE ALLERGIC SKIN REACTION. MAY CAUSE IRRITATION TO SKIN, EYES,
AND RESPIRATORY TRACT. AFFECTS CENTRAL NERVOUS SYSTEM.
J.T. Baker SAF-T-DATA
(tm)
Ratings (Provided here for your convenience)
------------------------------------------------------------------------Health Rating: 2 - Moderate
Flammability Rating: 1 - Slight
Reactivity Rating: 1 - Slight
Contact Rating: 2 - Moderate
Lab Protective Equip: GOGGLES; LAB COAT; VENT HOOD; PROPER GLOVES
Storage Color Code: Orange (General Storage)
POTENTIAL HEALTH EFFECTS ---------------------------------------
Inhalation:
Vapor inhalation is generally not a problem unless heated or misted. Exposure to vapors over an extended
time period has caused throat irritation and headache. May cause nausea, vomiting, dizziness and
drowsiness. Pulmonary edema and central nervous system depression may also develop. When heated or
misted, has produced rapid, involuntary eye movement and coma.
Ingestion:
Initial symptoms in massive dosage parallel alcohol intoxication, progressing to CNS depression,
vomiting, headache, rapid respiratory and heart rate, lowered blood pressure, stupor, collapse, and
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
22
unconsciousness with convulsions. Death from respiratory arrest or cardiovascular collapse may follow.
Lethal dose in humans: 100 ml (3-4 ounces).
Skin Contact:
Minor skin irritation and penetration may occur.
Eye Contact:
Splashes may cause irritation, pain, and eye damage.
Chronic Exposure:
Repeated small ex posures by any route can cause severe kidney problems. Brain damage may also occur.
Skin allergy can develop. May damage the developing fetus.
Aggravation of Pre-existing Conditions:
Persons with pre-existing skin disorders, eye problems, or impaired liver, kidney, or respiratory function
may be more susceptible to the effects of this substance.
4. FIRST AID MEASURES
Inhalation:
Remove to fresh air. If not breathing, give artificial respiration. If breathing is difficult, give oxygen. Call a
physician.
Ingestion:
Induce vomiting immediately as directed by medical personnel. Never give anything by mouth to an
unconscious person. Get medical attention.
Skin Contact:
Remove any contaminated clothing. Wash skin with soap and water for at least 15 minutes. Get medical
attention if irritation develops or persists.
Eye Contact:
Immediately flush eyes with plenty of water for at least 15 minutes, lifting lower and upper eyelids
occasionally. Get medical attention immediately.
Note to Physician:
Give sodium bicarbonate intravenously to treat acidosis. Urinalysis may show low specific gravity,
proteinuria, pyuria, cylindruria, hematuria, calcium oxide, and hippuric acid crystals. Ethanol can be used
in antidotal treatment but monitor blood glucose when administering ethanol because it can cause
hypoglycemia. Consider infusion of a diuretic such as mannitol to help prevent or control brain edema and
hemodialysis to remove ethylene glycol from circulation.
5. FIRE FIGHTING MEASURES
Fire:
Flash point: 111C (232F) CC
Autoignition temperature: 398C (748F)
Flammable limits in air % by volume:
lel: 3.2; uel: 15.3
Slight to moderate fire hazard when exposed to heat or flame.
Explosion:
Above flash point, vapor-air mixtures are explosive within flammable limits noted above. Containers may
explode when involved in a fire.
Fire Extinguishing Media:
Dry chemical, foam or carbon dioxide. Water or foam may cause frothing. Water spray may be used to
extinguish surrounding fire and cool exposed containers. Water spray will also reduce fume and irritant
gases.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
23
Special Information:
In the event of a fire, wear full protective clothing and NIOSH-approved self-contained breathing
apparatus with full-face piece operated in the pressure demand or other positive pressure mode. Toxic
gases and vapors may be released if involved in a fire.
6. ACCIDENTAL RELEASE MEASURES
Ventilate area of leak or spill. Remove all sources of ignition. Wear appropriate personal protective
equipment as specified in Section 8. Isolate hazard area. Keep unnecessary and unprotected personnel
from entering. Contain and recover liquid when possible. Use non-sparking tools and equipment. Collect
liquid in an appropriate container or absorb with an inert material (e. g., vermiculite, dry sand, earth), and
place in a chemical waste container. Do not use combustible materials, such as sawdust. Do not flush to
sewer! US Regulations (CERCLA) require reporting spills and releases to soil, water and air in excess of
reportable quantities. The toll free number for the US Coast Guard National Response Center is (800) 424-
8802.
7. HANDLING AND STORAGE
Keep in a tightly closed container, stored in a cool, dry, ventilated area. Protect against physical damage.
Separate from acids and oxidizing materials. Containers of this material may be hazardous when empty
since they retain product residues (vapors, liquid); observe all warnings and precautions listed for the
product.
8. EXPOSURE CONTROLS/PERSONAL PROTECTION
Airborne Exposure Limits:
-OSHA Permissible Exposure Limit (PEL):
50 ppm Ceiling
-ACGIH Threshold Limit Value (TLV):
50 ppm Ceiling (vapor)
Ventilation System:
A system of local and/or general ex haus t is recom men ded to keep em pl oyee exposures below the Airborne
Exposure Limits. Local exhaust ventilation is generally preferred because it can control the emissions of
the contaminant at its source, preventing dispersion of it into the general work area. Please refer to the
ACGIH document, Industrial Ventilation, A Manual of Recommended Practices, most recent edition, for
details.
Personal Respirators (NIOSH Approved):
If the exposure limit is exceeded, a half-face respirator with an organic vapor cartridge and particulate
filter (NIOSH type P95 or R95 filter) may be worn for up to ten times the exposure limit or the maximum
use concentration specified by the appropriate regulatory agency or respirator supplier, whichever is
lowest. A full-face piece respirator w ith an organic vapor cartr idge and particulate filter (NIOSH P100 or
R100 filter) may be worn up to 50 times the exposure limit, or the maximum use concentration specified
by the appropriate regulatory agency or respirator supplier, whichever is lowest. Please note that N series
filters are not recommended for thi s material. For emergenci es or instances where t he exposure lev els are
not known, use a full-face piece positive-pressure, air-supplied respirator. WARNING: Air-purifying
respirators do not protect workers in oxygen-deficient atmospheres.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
24
Skin Protection:
Wear protective gloves and clean body-covering clothing.
Eye Protection:
Use chemical safety goggles. Maintain eye wash fountain and quick-drench facilities in work area.
9. PHYSICAL AND CHEMICAL PROPERTIES
Appearance:
Clear oily liquid.
Odor:
Odorless.
Solubility:
Miscible in water.
Specific Gravity:
1.1 @20C/4C
pH:
No information found.
% Volatiles by volume @ 21C (70F):
100
Boiling Point:
197.6C (388F)
Melting Point:
-13C (9F)
Vapor Density (Air=1):
2.14
Vapor Pressure (mm Hg):
0.06 @ 20C (68F)
Evaporation Rate (BuAc=1):
No information found.
10. STABILITY AND REACTIVITY
Stability:
Stable under ordinary conditions of use and storage.
Hazardous Decomposition Products:
Carbon dioxide and carbon monoxide may form when heated to decomposition. May produce acrid smoke
and irritating fumes when heated to decomposition.
Hazardous Polymerization:
Will not occur.
Incompatibilities:
Strong oxidizing agents. Reacts violently with chlorosulfonic acid, oleum, sulfuric acid, perchloric acid.
Causes ignition at room temperature with chromium trioxide, potassium permanganate and sodium
peroxide; causes ignition at 212F(100C) with ammonium dichromate, silver chlorate, sodium chloride and
uranyl nitrate.
Conditions to Avoid:
Heat, flames, ignition sources, water (absorbs readily) and incompatibles.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
25
11. TOXICOLOGICAL INFORMATION
Toxicological Data:
Oral rat LD50: 4700 mg/kg; skin rabbit LD50: 9530 mg/kg.
Irritation - skin rabbit: 555mg(open), mild; eye rabbit: 500mg/24H, mild.
Investigated as a tumorigen, mutagen, reproductive effector.
Reproductive Toxicity:
Has shown teratogenic effects in laboratory animals.
--------\Cancer Lists\------------------------------------------------------
---NTP Carcinogen-- Ingredient Known Anticipated IARC Category
------------------------------------ ----- ----------- ------------ Ethylene Glycol (107-21-1) No No None
12. ECOLOGICAL INFORMATION
Environmental Fate:
When released into the soil, this material is expected to readily biodegrade. When released into the soil,
this material is expected to leach into groundwater. When released into the soil, this material is not
expected to evaporate significantly. When released into water, this material is expected to readily
biodegrade. When released i nto the water, this material is ex pected to have a half-life between 1 and 10
days. This material is not expected to significantly bioaccumulate. This material has a log octanol-water
partition coefficient of less than 3.0. When released into water, this material is not expected to evaporate
significantly. When released into the air, this material is expected to be readily degraded by reaction with
photochemically produced hydroxyl radicals. When released into the air, this material is expected to have
a half-life between 1 and 10 days.
Environmental Toxicity:
The LC50/96-hour values for fish are over 100 mg/l.
13. DISPOSAL CONSIDERATIONS
Whatever cannot be saved for recovery or recycling should be managed in an appropriate and approved
waste disposal facility. Processing, use or contamination of this product may change the waste
management options. State and local disposal regulations may differ from federal disposal regulations.
Dispose of container and unused contents in accordance with federal, state and local requirements.
14. TRANSPORT INFORMATION
Not regulated.
15. REGULATORY INFORMATION
--------\Chemical Inventory Status - Part 1\-------------------------------- Ingredient TSCA EC Japan Australia
----------------------------------------------- ---- --- ----- -------- Ethylene Glycol (107-21-1) Yes Yes Yes Yes
--------\Chemical Inventory Stat us - Part 2\---------------------------------
--Canada- Ingredient Kore a DSL NDSL Phil.
----------------------------------------------- ----- --- ---- ---- Ethylene Glycol (107-21-1) Yes Yes No Yes
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
26
--------\Federal, State & International Regulations - Part 1\----------------
-SARA 302- ------SAR A 313----- Ingredient RQ TPQ List Chemical Catg.
----------------------------------------- --- ----- ---- ------------- Ethylene Glycol (107-21-1) No No Yes No
--------\Federal, State & International Regulations - Part 2\----------------
-RCRA- -TSCA Ingredient CERCLA 261.33 8(d)
----------------------------------------- ------ ------ ----- Ethylene Glycol (107-21-1) 5000 No No
Chemical Weapons Convention: No TSCA 12(b): No CDTA: No
SARA 311/312: Acute: Yes Chronic: Yes Fire: No Pressure: No
Reactivity: No (Pure / Liquid)
Australian Hazchem Code: No information found.
Poison Schedule: No information found.
WHMIS:
This MSDS has been prepared according to the hazard criteria of the Controlled Products Regulations
(CPR) and the MSDS contains all of the information required by the CPR.
16. OTHER INFORMATION
NFPA Ratings: Health: 1 Flammability: 1 Reactivity: 0
Label Hazard Warning:
WARNING! HARMFUL OR FATAL IF SWALLOWED. HARMFUL IF INHALED OR
ABSORBED THROUGH SKIN. MAY CAUSE ALLERGIC SKIN REACTION. MAY CAUSE
IRRITATION TO SKIN, EYES, AND RESPIRATORY TRACT. AFFECTS CENTRAL
NERVOUS SYSTEM.
Label Precautions:
Do not breathe vapor or mist.
Use only with adequate ventilation.
Keep container closed.
Avoid contact with eyes, skin and clothing.
Wash thoroughly after handling.
Label First Aid:
If inhaled, remove to fresh air. If not breathing, give artificial respiration. If breathing is difficult,
give oxygen. In case of contact, immediately flush skin or eyes with plenty of water for at least 15
minutes. Call a physician if irritation develops or persists. If swallowed, give water or milk to drink
and induce vomiting. Never give anything by mouth to an unconscious person. In all cases call a
physician.
Product Use:
Laboratory Reagent.
Revision Information:
MSDS Section(s) changed since last revision of document includes: 8.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
27
Disclaimer:
Mallinckrodt Baker, Inc. provides the information contained herein in good faith but makes
no representation as to its comprehensiveness or accuracy. This document is intended only as
a guide to the appropriate precautionary handling of the material by a properly trained
person using this product. Individuals receiving the information must exercise their
independent judgment in determining its appropriateness for a particular purpose.
MALLINCKRODT BAKER, INC. MAKES NO REPRESENTATIONS OR
WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE WITH RESPECT TO THE INFORMATION SET FORTH
HEREIN OR THE PRODUCT TO WHICH THE INFORMATION REFERS.
ACCORDINGLY, MALLINCKRODT BAKER, INC. WILL NOT BE RESPONSIBLE FOR
DAMAGES RESULTING FROM USE OF OR RELIANCE UPON THIS NFORMATION.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
DENALI M1 52-13382-1
28
WARRANTY POLICY
The Denali M1 Chiller is covered under a one-year parts and labor warranty from the date of shipment,
assuming proper use and maintenance of the unit. Al l warranty work shall be performed at Solid State
Cooling Systems’ facility, currently located in Wappingers Falls, NY, USA and requires pre-authorization
by SSCS. Malfunctioning products should be returned to Solid State Cooling Systems by the method
described below. Solid State Cooling Systems will provide a Failure Analysis Report to the customer and
will determine if the problem is covered under the warranty.
Warranty Coverage:
Products with defects in components or manufacturing which are reported to Solid State Cooling
Systems before the end of the warranty period will be repaired or replaced at no cost (see below for
reporting requirements). The warranty period begins on the date the product was initially shipped from
Solid State Cooling Systems’ factory.
Excluded from Warranty:
Excluded from warranty is any damage caused to the product occurring during, but not limited to, such
events as shipment, installation, storage, or usage occurring during a situation specifically cautioned
against or noted in the product manual.
Specific situations, which invalidate the warranty, include (but are not limited to):
Removing the serial number label.
Any disassembly (partial or complete) of the product.
Changing any components of the product.
Subjecting the product to temperatures below the freezing point of the coolant used.
Subjecting any product to temperature, voltage, current, or pressure (internal or external) greater than
that specified in the product manual.
Any actions prohibited in the "Caution" section of the product manual.
Returned Goods Procedure and Reporting Requirements
Before a failed product is returned to the factory, a Returned Materials Authorization (RMA) number must
be obtained from Customer Service at (845) 296-1300. The date the RMA is requested will be the
reporting date noted and relevant to the warranty. Products, which have received an RMA, must be
received at SSCS’s factory, within 30 days or the reporting date will be moved ahead 30 days and a new
30-day waiting period will begin. Customers shall pay shipping cost of returning any unit to SSCS and
SSCS shall pay shipping cost of returning any unit repaired under warranty to the customer.
All out of warranty returned goods will require an evaluation purchase order prior to receipt at Solid State
Cooling Systems. The evaluation costs will depend on product model and will be deducted from the cost
of any repairs required.
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590
TELEPHONE: (845) 296-1303 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM REVISION E1
Loading...
