8410/8411 V-LINE LAUNDRY
`
Overview
The V-LINE dispenses from one to six laundry chemicals into any small capacity laundry machine. The
operator may select between nine formulas. The dispenser may be triggered with a front panel button,
remote button, or three automatic triggering options.
Warnings
Installation of DEMA products must meet all applicable electrical codes and regulations
established by national, city, county, parish, provincial or other agencies. It is possible
that electrical codes and regulations require that a certified electrical contractor or
engineer perform the electrical installation. For questions, contact a certified electrician.
ALL ELECTRICAL POWER MUST BE TURNED OFF TO THE DISPENSER
AND TO THE APPLIED MACHINE.
All installations must conform to local plumbing codes and use approved backflow
prevention devices. A pressure indicating tee is to be installed with existing faucets
according to local plumbing codes in the state of Wisconsin and any other state that
requires the use of a pressure indicating tee.
ALWAYS WEAR PROTECTIVE CLOTHING AND EYEWEAR WHEN WORKING
WITH CHEMICAL PRODUCTS.
I-1040 Page 1 of 14
Rev. A-39489 1/21/14
Specifications
Ordering Nomenclature
8410J-51-FR
Remote
Packing List
V-Line Dispensing system (84xx) which contains pumps, power supply, electronic control board
(IQ-50)
Hook up kit which includes Velcro, zip ties, chemical label sheet. (V-Line Remote and cable are
optional)
Quick connect pump fittings
Specifications:
Main Power: 115V/230V 50/60Hz 2A
o Units are shipped with a power cord that uses a U.S. 115VAC grounded plug
Trigger Signal Connection: 10-250VAC 50/60Hz
o System can be set to ignore signals less than 70VAC
Pumps
o 24VDC, 105RPM motors
o Small Blue Pump Rate 16 ounces/min (460 ml/min) water
o Large Blue Pump Rate 50 ounces/min (1480 ml/min) water
Add a “R”
Flush Valve
Add a “F”
Squeeze Tube Material
0 = EPDM
1 = Supertube
2 = Silicone
4 = Viton
Number of Pumps
2 through 6
*If flush valve is req’d, max number of pumps is 5.
Ex: 8410J-51-F. This will give you 5 pump module + 1
flush valve.
Pump Size w/ Squeeze tube fitting
8410J = Small Blue QC Pump, JG ¼ x 3/8, 105RPM
8410J60 = Small Blue QC Pump, JG ¼ x 3/8, 60RPM
8410B = Small Blue QC Pump, Barb 3/8, 105RPM
8410C = C2 Pump, no fittings, 105RPM
8410T – Small Blue QC Pump, JG ¼ x ¼ , 60RPM
8411J = Large Blue QC Pump, JG 3/8 x 3/8, 105RPM
8411B = Large Blue QC Pump, Barb 3/8, 105RPM
I-1040 Page 2 of 14
Rev. A-39489 1/21/14
8410 Series
(larger pumps are not shown)
FEATURES
Five Modes of operation
o Formula Select Mode – Each pump receives a trigger from the machine supply valves
and then performs the delay and dispensing as programmed. A trigger qualifying time
may be programmed to ignore short valve cycles.
o Push Button Mode – When the button on the front of the dispenser or the “start” button
on the VLR (V-Line Remote, formula selector) is pressed, all pumps delay for a
programmed time and then dispense the programmed amount of chemical.
o Flex Trigger – This allows any pump to operated using any trigger. A pump can be
programmed to operate with multiple triggers.
o Sequence Mode – This allows the pumps to be triggered using the drain valve on the
laundry machine. It is possible to us the hot and cold fill valves as well.
o Relay Mode – This will cause the pumps to directly respond to trigger inputs.
9 Formula Capability
Programming is performed on board at the control face of the system
Load counter for each formula
Total load count for all formulas
Password protected programming
Prewired for minimum installation time
Quick-change squeeze tubes which require no tools
Out of product alarms available
I-1040 Page 3 of 14
Rev. A-39489 1/21/14
Installation
Electrical Installation – Main Power and Trigger Signal Wiring
All installations must be in accordance with city, county, parish, state or provincial electrical codes and
should be performed by a certified electrician. A ½” nonmetallic conduit system must be used to install the
power cord. For questions, please contact local licensed electrical contractor.
Caution: Before electrical installation is started all electrical power must be turned off to the laundry machine
at the appropriate service panel. Lockout and tag out procedures must be used. There is a potential for
exposure to high voltage conditions when the V-Line enclosure is opened.
A complete survey of the laundry room or site installation should be completed in advance of starting the V-Line
installation.
1. The V-Line is prewired with a power cord that includes a 115VAC grounded plug. Simply plug the power
cord in grounded 115VAC wall outlet for main power.
a. Wall plug/socket adapters may be used to plug the power cord into various country plug
configurations. The adapter must be rated to accept 115/230VAC 10A.
b. Alternative Main Power Hardwire– The molded plug can be cut off and connected directly to the
laundry machine or alternate power source. The operating voltage 100-250VAC 50/60HZ. The
system will automatically adjust to the incoming voltage. Laundry machine ratings and instructions
must be observed. Consult with laundry machine or equipment manufacturer for connection
information.
2. Select a location to mount the V-Line on a wall that will allow access to the chemical product containers and
the chemical product feeds points on the laundry machine. Direct spray or high steam areas must be avoided.
3. If using the 951 series flush manifold or any other flush manifold , select a location that will allow all the
electrical (power for solenoid valve and/or pressure switch) and tubing connections to be accessible. It should
be noted that the flush output on the electronic control board is a 24VDC signal. The solenoid coil for the
flush valve will need to match this output signal.
Trigger Signal Wiring
It is possible to cutout supply signals from the machine that fall below 70VAC by using the voltage cutout switch.
When the V-Line enclosure is opened the voltage cutout switch can be accessed.
When this switch is set to the 12V-100V setting the system can accept supply signals from the machine
that range from 12-250VAC. This is the factory default setting for any product.
When this switch is set to 100V-240V, the system can accept signals that range from approximately 70-
250VAC.
Note: When combining 2 or more trigger signal inputs from one supply signal from the laundry machine, it
is recommended to have the voltage cutout switches set to 12V-100V settings. The system will accept 12250VAC trigger signals.
See the wiring configuration table on the next page for definition of the various wires.
I-1040 Page 4 of 14
Rev. A-39489 1/21/14
V-Line Wiring Configuration (For Sequence Mode) (For Formula Select Mode or Relay Mode)
Trigger
Input
1 Black White Event Trigger Signal Pump 1
2 Brown White Event Trigger Signal Pump 2
3 Red White Reset (opt’l) ex.
4 Orange White
5 Green White Signal Pump 5
6 Blue White Auto Formula Select (see AFS note)
Sequence Mode Trigger Wiring
There are two methods to wire for sequence mode
1. Use the normally open solenoid drain valve. Connect the “black” and “white” wires parallel to the solenoid
drain valve. See laundry machine wiring diagram for appropriate connection points.
2. Use hot and cold fill solenoid valves. Connect the “black” to one valve, the “brown” to other valve, and the
“white” to a common. See laundry machine wiring diagram for appropriate connection points.
Auto Formula Select
Auto Formula select allows the formulas to be selected based on a trigger signal that is received from the
laundry machine. The following list outlines the setup of this feature:
o The 6
o A trigger source that can be programmed at the laundry machine will be required. The timing of this
trigger source is what determines which formula is selected by the V-Line control board (IQ-50).
o To determine the amount of signal time for any formula simply calculate as follows: Multiply the
formula number by 2 - Example: Formula 7 needs a trigger signal equal to 14 seconds. (7 X 2 = 14).
A 14 second trigger signal to V-Line input number 6 (Blue and white wires) will change the V-Line
to formula 7.
Line (signal) Common Function of Trigger Input
Sequence Mode Formula Select/Relay Mode
door switch
Not Used
th
trigger input (blue wire) on the V-Line is used for this purpose.
Signal Pump 3
Signal Pump 4
End User Remote
The V-Line can be ordered with V-Line Formula Selection Remote. The remote is used for two reasons;
To select wash formulas manually
To start a formula program when the system is setup in “push button” mode (see operation mode
in programming section for more information).
1. Turn power off to the V-Line using the power switch on the bottom of the V-Line control module.
2. Remove the (4) screws on face plate and loosen the face plate to access the control board.
3. Remove the one of the white plugs on the bottom of the V-Line control module.
4. Phish the remote cable thru the hole and up to the control board and plug into the black RJ jack
(similar to phone jack).
5. Use the supplied strain relief piece that will surround the remote cable and plug into the hole at the
bottom of the V-Line control module.
6. Reassemble the face plate and reinstall the (4) face plate screws.
I-1040 Page 5 of 14
Rev. A-39489 1/21/14
Programming
Programming Menu
1. To ENTER the programming menu, hold the right arrow for 4 seconds until the
Language menu appears.
2. Press ENTER to select a different language. A cursor will appear next the displayed
language.
3. Use the UP and DOWN to select a different language. English, French, Spanish and
Portuguese are the 4 choices.
4. Press ENTER when the desired language is displayed.
5. Press the DOWN to access programming and the Enter Code screen will be displayed.
6. Press ENTER.
a. If it is a brand new unit or has never had an access code programmed the system
will go immediately into programming.
b. If the system has been programmed previously with an access code, the system
will display 4 zeros. The appropriate access code will need to be entered by
using the LEFT and RIGTH and UP and DOWN. When the correct access code
is displayed, press ENTER.
Clear Load Counts
1. Use the UP and DOWN to scroll through the programming menu until you find Clear
Load Counts.
2. Press the ENTER to access the menu.
3. Press ENTER to clear all load counts and then press the LEFT arrow to confirm the
clearing of all load counts.
4. Press the LEFT to move back to the Programming Menu.
Language
English
Enter Code
Clear Loads
Operation Mode
Configuration
Formula Lockout
Clear Load
Counts
Left to Reset
I-1040 Page 6 of 14
Rev. A-39489 1/21/14
Operation Mode
1. Using the UP and DOWN buttons scroll down through the programming menu until you
find Operation Mode. Operation mode will dictate how the system will operate as well
as allow certain programming menu’s to unlock depending on which mode is selected.
2. Press the ENTER key to start the selection.
3. Use the UP and DOWN arrows to move cursor to desired operation mode.
4. Press ENTER to save the selection.
5. Press LEFT button to return to Programming Menu.
Operation Mode Descriptions
Formula Select – This mode causes each pump to run its delay and run time for the
selected formula in response to the respective trigger input. Trigger 1 will run pump 1,
trigger 2 will run pump 2, etc. The Trigger Time setting allows a qualifying time to be
set to avoid false triggers because of stray signals. Trigger signals for this mode are
typically found on supply valves on the laundry machine.
Push Button – Selecting this mode causes all pumps to run when the ENTER key on the
front of the V-Line or the START button on the VLR remote is pressed on one of the
formula screens. All delays will start immediately with the key press and the pumps will
run when the delays expire. Lockout will also be active. This prevents accidental retriggering.
Flex Trigger – Flex Trigger mode is similar to Formula Select mode, but each pump can
be programmed to operate from any trigger. Any pump can be programmed to operate
with multiple triggers as well.
Sequence – Sequence mode allows automatic triggering of pumps when conventional
supply signals are not available. Each pump delay and run time occurs in response to a
sequential event from the laundry machine. The most typical way to use Sequence
mode is to hook up the trigger signal number 1 input (black wire) and the common
(white wire) to the drain valve, which is a normally open valve on most laundry
machines. Each time the machine fills the drain valve is energized to the closed
position. The trigger signal input number 1 will register the signal and count it as a fill.
The system can be programmed to run pumps at any fill along with programming a final
fill thus resetting the sequence count for a new wash cycle. As an alternative, the hot
and cold fill valves can be used. In this case connect the trigger 1 to the hot valve and
the trigger 2 wire to the cold valve. The common wire (white) may need to be split
using a wire nut and a couple of short pieces of wire to complete the trigger circuit so
that each valve will have the common wire connected.
Relay – This mode causes the inputs to directly drive the outputs. No pump
programming is required. If six pumps are used, pump six must be assigned to one of the
first five trigger inputs. If a flush is used, the flush time may be programmed for each
formula.
Configuration
This function will define how many pumps will be used on the dispenser and set flush
manifold operation settings.
1. Use the UP and DOWN to scroll through the Programming Menu until you find the
menu Configuration.
2. Press the ENTER key to start the selection.
3. Use the UP and DOWN to select the pump configuration.
4. Press ENTER to save the selection.
5. To program flush, use the DOWN to move the asterisk (*) to the flush.
6. Press the ENTER button and the cursor will appear next to the flush setting.
7. Use the UP and DOWN to adjust from “no” to a flush time in seconds.
Clear Loads
Operation Mode
Configuration
Formula Lockout
Operation Mode
Formula Select
Press Enter
Operation Mode
Push Button
Press Enter
Operation Mode
Flex Trigger
Press Enter
Operation Mode
Sequence
Press Enter
Operation Mode
Relay
Press Enter
Clear Loads
Operation Mode
Configuration
Formula Lockout
Configuration
Pumps – 5
Flush -No
I-1040 Page 7 of 14
Rev. A-39489 1/21/14
Note: This is the post flush time. The flush will automatically run with the pump if the flush
s
time is set to 1 or more seconds.
8. Press the ENTER button to save the flush setting.
9. Press LEFT button to return to Programming Menu.
Notes:
If 6 pumps are configured, the flush option is not available & the number 6 pump will
need to be operated triggers 1-5, as there is no number 6 trigger input available.
Flush time has a range of 1-999 seconds.
When the six pump option is selected in Formula Select or Relay modes one of the first
five triggers must be selected to operate pump six.
Formula Lockout
This feature allows the system to only operate pumps once from a given trigger signal input.
Any subsequent trigger signals will be ignored during the active Formula Lockout clock.
The Formula Lockout clock starts on the first trigger signal received to any of the 5 trigger
signal inputs. At that point the active Formula Lockout clock will apply to all trigger signal
inputs.
1. Use the UP and Down to scroll through the Programming Menu until you find the menu
Formula Lockout and press ENTER.
2. Use the UP and DOWN to select the formula.
3. Press the ENTER to change the lockout time for the selected formula.
4. Use the UP and DOWN to set the lockout time for the length of the wash cycle for each
formula. The time measurement is in minutes.
5. Press the ENTER key to save setting.
6. Press the LEFT arrow button to return to the Programming Menu.
Program Formula (9 Formulas Max, will not display in Relay mode)
This will program pump run times for Level 1, Level 2, and Delay times for each pump.
1. Use the UP and DOWN to scroll through the Programming Menu and find Program
Formula and press ENTER. An asterisk (*) will appear as a cursor.
2. With the asterisk next to the “Form” number. Press ENTER to change the formula to be
programmed.
3. When desired formula number is displayed, press ENTER to program pumps.
a. Use the LEFT and RIGHT to move from Level 1, Level 2 and Delay
programming.
b. Use the UP and DOWN to select a pump or move back to the FORM selection.
c. Press the ENTER when at the desired pump to program a pump run time or
delay.
d. Use the UP and DOWN to adjust the pump run or delay time. The range is 0-
999. The units are as follows:
i. Seconds for Formula Select and Sequence Modes
ii. Minutes for Push Button Mode
e. Press ENTER to save the setting.
f.
Repeat step 3 process for all pump runs and delay times.
4. Repeat steps 2 & 3 to program additional formulas.
5. Press the LEFT to return Program Formula screen.
Note: Only the number of pumps that were set in the configuration setup will be displayed
in the program formula screens. Also, all pump run times are in seconds.
Configuration
Pumps – 5
Flush –001
Operation Mode
Configuration
Formula Lockout
Program Formula
Formula Lockout
Formula 1
Time in Min = 00
Operation Mode
Configuration
Formula Lockout
Program Formula
Form 1 Level 1
P1 020s P4 020s
P2 020s P5 020s
P3 020s
Form 1 Level 2
P1 020s P4 020s
P2 020s P5 020s
P3 020s
Form 1 Delay
P1 020s P4 020s
P2 020s P5 020s
P3 020s
I-1040 Page 8 of 14
Rev. A-39489 1/21/14
Default Formula
This feature allows the system to be setup so that when the load count pump is operated on
any given formula the system will then change to the default formula setting.
1. Use the UP and DOWN button to scroll through the Programming Menu to find Default
Formula and press ENTER. The display then should show either “NO DEFUALT
FORM” or FORMULA = x.
2. This can be changed by pressing ENTER and adjust to the desired setting of “no default
formula” or a default formula.
3. Press ENTER to accept the new setting.
Assign Triggers (only displayed in Formula Select Mode)
This feature allows any pump to be assigned to any trigger signal input.
1. Use the UP and DOWN to scroll through the Programming Menu to find Assign
Triggers. Press ENTER and the Assign Triggers screen will be displayed.
2. Use the UP and DOWN to move the asterisk (*) to the desired pump. Press ENTER and
cursor will flash.
3. Use the UP and DOWN to change the desired trigger signal input number.
4. Press ENTER to save the new setting.
5. Repeat steps 2 – 4 for any additional pumps.
6. Press LEFT to move back to the main Program Menu.
Enter Sequence –Drain Mode (only displayed in Sequence mode)
1. Use the UP and DOWN scroll through the Programming Menu to find Enter Sequence
and press ENTER. The Sequence screen will be displayed.
2. Use the UP and DOWN to move the asterisk (*) on the right side next to the Formula
number. Press the ENTER to change the formula. A cursor will flash next to the
formula number.
3. Use the UP and DOWN to change to the desired formula number. When the desired
formula number is displayed, press the ENTER button.
4. Use the DOWN to move the asterisk (*) from Formula to Sequence. Press the ENTER
to change the sequence number. A cursor will flash next to the sequence number.
a. Use the UP and DOWN to change to the desired sequence number. When the
desired sequence number is displayed, press the ENTER.
b. Use the DOWN to move the asterisk (*) to the row of pump numbers along the
bottom edge of display.
c. Press the ENTER to program pumps to run at the displayed Sequence number.
d. A cursor will flash over the number 1 in the pump row. Use the RIGHT and
LEFT buttons to move the cursor and the UP and DOWN to add to run a pump
or remove a pump operation that had been previously programmed. When UP
is pressed an asterisk (*) will appear indicating that this pump will run. When
DOWN is pressed the asterisk (*) will be removed, indicating that the pump will
not run.
Note: The “F” in the pump row represents the final sequence event (final fill on the
laundry machine). Program an asterisk (*) above the “F” when the final sequence
event (final fill on the laundry machine). This will reset the sequence count for a
new wash cycle. Pumps can be programmed to run on the final event.
5. Repeat step 4 for all sequence events in the displayed formula.
6. Repeat all steps for additional formulas.
Note: Each formula will require complete sequence mode programming.
Program Formula
Default Formula
Assign Triggers
Load Count Pump
Program Formula
Default Formula
Assign Triggers
Load Count Pump
Assign Triggers
P1 1 P4 4
*P2 2 P5 5
P3 3
Configuration
Formula Lockout
Program Formula
Enter Sequence
Formula 1
Sequence = 01
* - - - - -
1 2 3 4 5 F
I-1040 Page 9 of 14
Rev. A-39489 1/21/14
Load Count Pump (not displayed in Relay mode)
Select a pump for each formula that will be counted each time it is operated (does not count
when pump is primed).
1. Scroll through the Programming Menu to find Load Count Pump and press ENTER.
2. Use the UP and DOWN to select the formula. Press ENTER to change the displayed
load count pump for the displayed formula. A cursor will flash next to the setting.
3. Use UP and DOWN to select a desired load count pump.
4. Press the ENTER to save the results.
5. Press LEFT to return to the Program Menu.
Trigger Time (only displayed in Formula Select, Flex Trigger or Sequence modes)
Programs a qaulification time for triggers received. The trigger time defines how long an
uninterupted trigger signal from the laundry machine is required to start a pump operation.
The range is 2 to 90 seconds. The factory default is 5 seconds.
1. Use the UP and DOWN to scroll through the Programming Menu to find Trigger Time
and press ENTER. The Trigger Time program menu will be displayed.
2. Press ENTER to modify the trigger time. A cursor will flash next to the trigger time.
3. Use the UP and DOWN to adjust the time.
4. Press the ENTER key to save the displayed trigger time.
5. Press LEFT to return to the Program Menu.
Test Formulas
Tests the output of the programmed pump by allowing a button to activate the operation in
any formula and pump run time. See procedure below:
1. Scroll through the Programming Menu to find Test Formulas and press ENTER.
2. To Select the Formula:
a. Use UP and DOWN to move the asterisk to the Formula Setting and press
ENTER. A cursor will flash next to the formula number.
b. Use UP and DOWN to find the desired formula and press ENTER when the
desired formula number is displayed.
3. To Select the pump to be tested;
a. Use UP and DOWN to move the asterisk (*) to the Pump Setting and press
ENTER. A cursor will begin to flash on the far right of the Pump Setting.
b. Use UP and DOWN button to select a Pump and RT (Level 1 or Level 2 run
time). When the desired Pump and RT are displayed press ENTER.
4. To Test the Pump Output or Time;
a. Use UP and DOWN to move the asterisk to the Start selection.
b. Press ENTER to start the pump and allow the pump to operate an either time or
collect the output in a graduated cylinder to check for accuracy.
Note: When the pump is running the “Start” function will become a “Stop” function.
The pump can be stopped if necessary.
Enter Code
Allows a unique passcode to be setup for accessing programming. Passcode is 4 numeric
characters.
1. Using the UP and DOWN scroll through the Program Menu and find Enter New Code.
Press ENTER and the Enter New Code screen will be displayed.
2. Press ENTER to modify the access code. 4 zeros and a flashing cursor will be displayed.
3. Use the LEFT and RIGHT and UP and DOWN to change the 4 zeros to the desired
access code.
4. Press ENTER when the desired access code is displayed. The change will be complete.
5. Press the LEFT to return to the Program Menu.
Note: If you forget the password, call DEMA Technical Service for directions on how to
reset the password.
Formula Lockout
Program Formula
Enter Sequence
Load Count Pump
Load Count
Formula 1
Pump = 1
Program Formula
Enter Sequence
Load Count Pump
Trigger Time
Trigger Time
05s 2-90s
Press Enter
Enter Sequence
Load Count Pump
Trigger Time
Test Formulas
Test Formula
Formula 1
Pump = 1 RT 1
Start
Load Count Pump
Trigger Time
Test Formula
Enter New Code
Enter Code
Press Enter
I-1040 Page 10 of 14
Rev. A-39489 1/21/14
Set Defaults (and Copy Program)
CAUTION – Using this feature will erase all programming and restore the dispenser to
factory settings.
1. Using the UP and DOWN scroll through the Program Menu and find Set Defaults.
Press Enter and the Set Factory Default screen will be displayed.
2. Press ENTER to clear and restore the system to the factory defaults. A screen will
appear that has a flashing cursor next to the word “no”.
3. Use the UP or DOWN change to “yes” or back to “no”.
a. Press ENTER with “yes” displayed to clear the programs and restore the factory
defaults. The display will show the system restoring and eventually display
“memory cleared”.
b. Press ENTER with “no” displayed to move back to previous screen without
clearing and restoring factory defaults.
4. Press the LEFT to return to the Program Menu.
Copy a program (use Set Defaults)
Using the Copy Cable (DEMA P/N 84.254.1) programming from another V-Line can be
imported to the V-Line.
1. Turn main power off to each V-line using the power switch at the bottom of the V-Line
control module.
2. Turn power off to all laundry machines or equipment that the trigger cable of each V-
Line may be connected.
Caution - Before going any further assure that no power is being supplied to the
trigger cables to each V-Line.
3. Remove the 4 screws from the front face of both V-Lines and loosen the front face to
access the control board.
4. Using the Copy Cable, connect the cable to the Data Port on each V-Line control board.
5. Turn the main power to each V-Line on using the main power switch at the bottom of
the V-Line control module.
6. Enter programming on the V-Line that will receive the programming (not the V-Line
that has been programmed).
7. Use the UP and DOWN to scroll through the Program Menu and find Set Defaults.
Press ENTER and the Set Factory Defaults screen will be displayed.
8. Press ENTER to clear any programming and import new programming. A screen will
appear that has a flashing cursor next to the word “no”.
9. Use the UP or DOWN and change to “yes”.
10. Press ENTER and the display will show the system restoring and eventually display
“memory cleared, import program, no”.
11. Press ENTER and a cursor will flash next to the word “no”.
12. Use the UP or DOWN to change to “yes”.
13. Press ENTER and “copying” will be displayed. Eventually this will change to
“finished”. At this point the program has successfully been copied to the V-Line.
14. Turn the main power off to the V-Lines.
15. Remove the data cable and reassemble the front face to the V-Lines using the (4)
screws.
Trigger Time
Test Formula
Enter New Code
Set Defaults
Set Factory
Default
Press Enter
Set Factory
Default - Yes
Trigger Time
Test Formula
Enter New Code
Set Defaults
Set Factory
Default
Press Enter
Memory Cleared
Import Program
Yes
Memory Cleared
Import Program
Copying
Memory Cleared
Import Program
Finished
I-1040 Page 11 of 14
Rev. A-39489 1/21/14
Exit Programming
Press the ENTER key to return to the Formula screens. Pressing the LEFT arrow from any
of the menu screens will display this screen.
User Functions and Operation
Changing Formulas at the User Screen
When powered and sitting idle, the V-Line will display the formula, the formula load count
and the total load counts for all formulas. Changing Formulas at the Front of the V-Line;
There are three ways to select a formula in all operating modes:
1. The formula may be selected using the UP and DOWN arrows on the dispenser.
2. The V-Line Formula Selector remote may be used to select a formula.
3. Auto Formula Select - see the Auto Formula Select in the Trigger Wiring Section.
Run a Formula
A formula will be started according to Operating Mode that was set through the
programming screens.
For Push Button mode press the ENTER on the front of V-Line or the START on
the Formula Selector Remote and all pumps will start with their delay time
followed by their run time.
For Formula Select mode each pump will respond to its individual trigger.
For Sequence mode each pump will operate at the input sequence that was
programmed.
For Relay mode each pump will respond to its respective trigger.
When a formula is running the load count will be replaced with a status indicator for each
pump. The indicator will show the pump number. The pump number will be above a “D”
for delay, an “R” for run, a “-“ for finished, an “H” for hold, or an “L” for locked out. A “-“
indicates that the pump has not yet been triggered. When a flush is used a “+” indicates the
flush is running. When the lockout time has expired the display will return to the load
counts for the formula.
Prime Pump
1. From the formula select screen press and hold the Left arrow for at least 10 seconds. The
Prime Pump screen will be displayed.
2. Use the UP and DOWN to select the desired pump.
3. Press ENTER to start priming.
4. Press ENTER again to stop the pump.
5. To exit the Prime Pump screen, hit the RIGHT arrow and that will take you back to the
Formula select screen
Note : If the pump is left running it will automatically stop after 2 minutes.
Test Formulas
Enter New Code
Set Defaults
Exit Program
Exit Programming
Press Enter
Formula 1
Load 0000
Total Loads 0000
Prime Pump 1
Enter to Stop
Prime Pump 1
Enter to Start
I-1040 Page 12 of 14
Rev. A-39489 1/21/14
Parts list
NO. PART NO. DESCRIPTION
81.173.9 DETERGENT J-PUMP , 105 RPM, EPDM TUBING, JG FITTING
1*
2 80.59.105MK 105 RPM GEAR MOTOR
3
4
5
6 84.260.1 CONTROL COVER
7 81.147.1 KEY PAD
8 84.250.1 IQ-50 CONTROL BOARD
9 84.261.1 HIGH VOLTAGE SHIELD
10 84.206.3 P-PUMP ENCLOSURE
11 84.265.1 POWER SUPPLY SHIELD
12
13 84.195.3 P-PUMP ENCLOSURE BACK
81.173.10 DETERGENT J-PUMP, 105 RPM, EPDM TUBING, BARB FITTING
84.205.1 DETERGENT P-PUMP , 105 RPM, EPDM TUBING, JG FITTING
84.205.2 DETERGENT P-PUMP , 105 RPM, EPDM TUBING, BARB FITTING
81.197.1 J-PUMP ENCLOSURE
84.206.3 P-PUMP ENCLOSURE
81.143.1 J-PUMP ENCLOSURE BACK
84.195.3 P-PUMP ENCLOSURE BACK
81.324.1 J-PUMP WALL BRACKET
81.24 P-PUMP WALL BRACKET
81.350.1 60W POWER SUPPLY (USE WITH J-PUMPS)
81.361.1 96W POWER SUPPLY (USE WITH P-PUMPS)
I-1040 Page 13 of 14
Rev. A-39489 1/21/14
14 81.144.1 DOVE TAIL JOINT
81.198.14
81.198.15
81.198.4 J-PUMP MODULE COMPLETE, EPDM TUBES W/ JG FITTINGS
81.198.6 J-PUMP MODULE COMPLETE, EPDM TUBES W/ BARB FITTINGS
15*
16 44.116.2 #8 X 3/8” LONG HI/LO SCREW
17 81.47.1 ½” HOLE PLUG
18 81.148.3 CONDUIT FITTING
19 81.163.1 POWER SWITCH
20 84.176.3 STRAIN RELIEF
21 41.40.2 #6 X 32 SCREW
22 81.20.2 #4 X 3/8 HI/LO SCREW
23 81.20.3 #4 X 1/2 HI/LO SCREW
24 81.183.5 STRAIN RELIEF
25 84.254.1 CABLE, PROGRAM COPY (OPTIONAL)
26 84.255.1 CABLE, EXTENTION PROGRAM COPY (OPTIONAL)
27 84.65.53 V-LINE FORMULA SELECTION REMOTE KIT
84.203.14
84.203.15
84.203.4 P-PUMP MODULE COMPLETE, EPDM TUBES W/ JG FITTINGS
84.203.5 P-PUMP MODULE COMPLETE, EPDM TUBES W/ BARB FITTINGS
81.198.7 VALVE MODULE (NO MOUNTING BRACKET)
J-PUMP MODULE COMPLETE W/WALL BRACKET, & EPDM TUBES
WITH JG FITTINGS
J-PUMP MODULE COMPLETE W/WALL BRACKET, & EPDM TUBES W/
BARB FITTINGS
P-PUMP MODULE COMPLETE W/WALL BRACKET, & EPDM TUBES
WITH JG FITTINGS
P-PUMP MODULE COMPLETE W/WALL BRACKET, & EPDM TUBES W/
BARB FITTINGS
*There are more options available that have different squeeze tube materials. Call for more options.
Warranty
Merchandise Returns
No Merchandise will be returned for credit without DEMA’S written permission. Returned merchandise authorization
number is required in advance of return.
Product Warranty
DEMA products are warranted against defective material and workmanship under normal use and service for one year from
the date of manufacture. This limited warranty does not apply to any products that have a normal life shorter than one year or
failure and damage caused by chemicals, corrosion, physical abuse, or misapplication. Rubber and synthetic rubber parts
such as “O”-rings, diaphragms, PVC tubing, and gaskets are considered expendable and are not covered under warranty.
This warranty is extended only to the original buyer of DEMA products. If products are altered or repaired without prior
approval of DEMA, this warranty is void.
Defective units or parts should be returned to the factory with transportation prepaid. If inspection shows them to be
defective, they will be repaired or replaced without charge, F.O.B. factory. DEMA assumes no liability for damages. Return
merchandise authorization number must be granted in advance of returned units for repair or replacement (See “Merchandise
Returns” above).
I-1040 Page 14 of 14
Rev. A-39489 1/21/14
Loading...
