Delta 50-775 User Manual

INSTRUCTION MANUAL

One H.P. Single-Stage

Dust Collector

(Model 50-775)

PART NO. 902116 (015)

Copyright © 2001 Delta Machinery

To learn more about DELTA MACHINERY
visit our website at: www.deltamachinery.com.

For Parts, Service, Warranty or other Assistance,

please call

1-800-223-7278 (In Canada call 1-800-463-3582).

SPANISH: PAGE 13

2

GENERAL SAFETY RULES

Woodworking can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there
are certain hazards involved with the operation of the product. Using the machine with respect and caution will
considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored,
personal injury to the operator may result. Safety equipment such as guards, push sticks, hold-downs, featherboards,
goggles, dust masks and hearing protection can reduce your potential for injury. But even the best guard won’t make
up for poor judgment, carelessness or inattention. Always use common sense and exercise caution in the workshop.
If a procedure feels dangerous, don’t try it. Figure out an alternative procedure that feels safer. REMEMBER: Your
personal safety is your responsibility.

This machine was designed for certain applications only. Delta Machinery strongly recommends that this machine not
be modified and/or used for any application other than that for which it was designed. If you have any questions relative
to a particular application, DO NOT use the machine until you have first contacted Delta to determine if it can or should
be performed on the product.

Technical Service Manager
Delta Machinery
4825 Highway 45 North
Jackson, TN 38305

(IN CANADA: 505 SOUTHGATE DRIVE, GUELPH, ONTARIO N1H 6M7)

WARNING: FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS PERSONAL INJURY

1. FOR YOUR OWN SAFETY, READ INSTRUCTION

MANUAL BEFORE OPERATING THE TOOL. Learn the

tool’s application and limitations as well as the specific
hazards peculiar to it.

2. KEEP GUARDS IN PLACE and in working order.

3. ALWAYS WEAR EYE PROTECTION.

Wear safety
glasses. Everyday eyeglasses only have impact resistant
lenses; they are not safety glasses. Also use face or dust
mask if cutting operation is dusty. These safety glasses
must conform to ANSI Z87.1 requirements. Note:
Approved glasses have Z87 printed or stamped on them.

4. REMOVE ADJUSTING KEYS AND WRENCHES. Form
habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it “on”.

5. KEEP WORK AREA CLEAN. Cluttered areas and benches

invite accidents.

6. DON’T USE IN DANGEROUS ENVIRONMENT. Don’t
use power tools in damp or wet locations, or expose them
to rain. Keep work area well-lighted.

7. KEEP CHILDREN AND VISITORS AWAY. All children
and visitors should be kept a safe distance from work area.

8. MAKE WORKSHOP CHILDPROOF – with padlocks,
master switches, or by removing starter keys.

9. DON’T FORCE TOOL. It will do the job better and be
safer at the rate for which it was designed.

10. USE RIGHT TOOL. Don’t force tool or attachment to
do a job for which it was not designed.

11. WEAR PROPER APPAREL. No loose clothing, gloves,
neckties, rings, bracelets, or other jewelry to get caught in
moving parts. Nonslip footwear is recommended. Wear
protective hair covering to contain long hair.

12. SECURE WORK. Use clamps or a vise to hold work
when practical. It’s safer than using your hand and frees
both hands to operate tool.

13. DON’T OVERREACH. Keep proper footing and
balance at all times.

14. MAINTAIN TOOLS IN TOP CONDITION. Keep tools
sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.

15. DISCONNECT TOOLS before servicing and when
changing accessories such as blades, bits, cutters, etc.

16. USE RECOMMENDED ACCESSORIES. The use of
accessories and attachments not recommended by Delta
may cause hazards or risk of injury to persons.

17. REDUCE THE RISK OF UNINTENTIONAL STARTING.
Make sure switch is in “OFF” position before plugging in
power cord.

In the event of a power failure, move switch

to the “OFF” position.

18. NEVER STAND ON TOOL. Serious injury could occur if
the tool is tipped or if the cutting tool is accidentally
contacted.

19. CHECK DAMAGED PARTS. Before further use of the
tool, a guard or other part that is damaged should be
carefully checked to ensure that it will operate properly and
perform its intended function – check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its
operation. A guard or other part that is damaged should be
properly repaired or replaced.

20. DIRECTION OF FEED. Feed work into a blade or cutter
against the direction of rotation of the blade or cutter only.

21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool until it comes to a
complete stop.

22.

STAY ALERT, WATCH WHAT YOU ARE DOING, AND
USE COMMON SENSE WHEN OPERATING A POWER
TOOL. DO NOT USE TOOL WHILE TIRED OR UNDER
THE INFLUENCE OF DRUGS, ALCOHOL, OR
MEDICATION. A moment of inattention while operating

power tools may result in serious personal injury.

23. MAKE SURE TOOL IS DISCONNECTED FROM
POWER SUPPLY while motor is being mounted,
connected or reconnected.

24. THE DUST GENERATED by certain woods and wood
products can be injurious to your health. Always operate
machinery in well ventilated areas and provide for proper
dust removal. Use wood dust collection systems whenever
possible.

25.

WARNING: SOME DUST CREATED BY POWER
SANDING, SAWING, GRINDING, DRILLING, AND OTHER
CONSTRUCTION ACTIVITIES contains chemicals known

to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:

· lead from lead-based paints,

· crystalline silica from bricks and cement and other

masonry products, and

· arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure
to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those
dust masks that are specially designed to filter out
microscopic particles.

SAVE THESE INSTRUCTIONS.

Refer to them often and use them to instruct others.

3

IMPORTANT SAFETY RULES FOR

DUST COLLECTORS

WARNING:

Basic precautions
should always be followed when using your dust
collector. To reduce the risk of injury, electrical
shock or fire, comply with the safety rules listed
below:

1. DO NOT leave the dust collector plugged into the
electrical outlet. Unplug dust collector from the outlet
when not in use and before servicing, changing bags,
unclogging and cleaning.

2. ALWAYS turn all controls “OFF” before unplugging the
dust collector.

3. WARNING: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, do not use on wet surfaces. Do
not expose to rain. Store indoors.

4. FOLLOW all electrical and safety codes, including
the National Electric Code (NEC) and the Occupational
Safety and Health Regulations (OSHA). All electrical
connections and wiring should be made by qualified
personnel only.

5. DO NOT use the dust collector to pick up
flammable or combustible liquids, such as gasoline.
NEVER use the dust collector near any flammable or
combustible liquids.

6. DO NOT use the dust collector to pick up metal
shavings, metal dust, or metal parts.

7. NEVER use the dust collector to dissipate fumes
or smoke. NEVER pick up anything that is burning or
smoking, such as cigarettes, matches or hot ashes.

8. DO NOT pull the dust collector by the power cord.
NEVER allow the power cord to come in contact with
sharp edges, hot surfaces, oil or grease. Do not place
anything over the top of the power cord.

9. DO NOT unplug the dust collector by pulling on the
power cord. DO NOT place anything over the top of the
cord. DO NOT run appliance over the cord. ALWAYS
grasp the plug, not the cord.

10. DO NOT handle the plug or dust collector with wet
hands.

11. REPLACE a damaged cord immediately. DO NOT
use a damaged cord or plug. If the dust collector is not
operating properly, or has been damaged, left outdoors
or has been in contact with water, take it to an
Authorized Service Center for service.

12. DO NOT use the dust collector as a toy. DO NOT
use near or around children.

13. DO NOT insert fingers or foreign objects into the
dust intake port. Keep hair, loose clothing, fingers, and
all body parts away from openings and moving parts of
the dust collector.

14. DO NOT use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.

15. NEVER use the dust collector without the dust
collection bag in place and properly secured.

16. ALWAYS use intake cover to cover inlet port when
the dust collector is not in use or mounted to a
supporting surface for storage.

17. PERIODICALLY INSPECT dust bag for any cuts,
rips or tears. NEVER operate the dust collector with a
damaged bag or vacuum hose.

18. The dust collector is designed for home use or light
commercial duty ONLY!

19. CONNECT dust collector to a properly grounded
outlet only. See grounding instructions.

20. USE EXTRA CARE when cleaning on stairs.

4

Fig. 2

UNPACKING AND CLEANING

Carefully unpack the tool and all loose items from the shipping container(s). Remove the protective coating from all
unpainted surfaces. This coating may be removed with a soft cloth moistened with kerosene (do not use acetone, gasoline
or lacquer thinner for this purpose). After cleaning, cover the unpainted surfaces with a good quality household floor paste
wax.

1. Motor and blower assembly

2. Base

3. Wheel casters (4)

4. Side support (2)

5. Upper bag (bag with loop see Fig. 14)

6. Lower bag

7. Filter bag clamp (2)

8. Firm board

9. Filter bag hanger

10. Hose

11. Hose clamp (2)

12. 5/16 Hex nut (9)

13. 5/16 Lockwasher (12)

14. 5/16-18x3/4" Hex head screw (12)

15. Intake cap

1

2

3

4

5 6

7

8

9

10

11

12

13

14

15
