INSTRUCTION MANUAL
Portable Single-Stage
Dust Collector
(Model 50-770)
PART NO. 902117 (015)
Copyright © 2001 Delta Machinery
ESPAÑOL: PÁGINA 15
To learn more about DELTA MACHINERY
visit our website at: www.deltamachinery.com.
For Parts, Service, Warranty or other Assistance,
please call
1-800-223-7278 (In Canada call 1-800-463-3582).
Page 2
2
GENERAL SAFETY RULES
Woodworking can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there
are certain hazards involved with the operation of the product. Using the machine with respect and caution will
considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored,
personal injury to the operator may result. Safety equipment such as guards, push sticks, hold-downs, featherboards,
goggles, dust masks and hearing protection can reduce your potential for injury. But even the best guard won’t make
up for poor judgment, carelessness or inattention. Always use common sense
and exercise caution
in the workshop.
If a procedure feels dangerous, don’t try it. Figure out an alternative procedure that feels safer. REMEMBER: Your
personal safety is your responsibility.
This machine was designed for certain applications only. Delta Machinery strongly recommends that this machine not
be modified and/or used for any application other than that for which it was designed. If you have any questions relative
to a particular application, DO NOT use the machine until you have first contacted Delta to determine if it can or should
be performed on the product.
Technical Service Manager
Delta Machinery
4825 Highway 45 North
Jackson, TN 38305
(IN CANADA: 505 SOUTHGATE DRIVE, GUELPH, ONTARIO N1H 6M7)
WARNING: FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS PERSONAL INJURY
1. FOR YOUR OWN SAFETY, READ INSTRUCTION
MANUAL BEFORE OPERATING THE TOOL. Learn the
tool’s application and limitations as well as the specific
hazards peculiar to it.
2. KEEP GUARDS IN PLACE and in working order.
3. ALWAYS WEAR EYE PROTECTION.
Wear safety
glasses. Everyday eyeglasses only have impact resistant
lenses; they are not safety glasses. Also use face or dust
mask if cutting operation is dusty. These safety glasses
must conform to ANSI Z87.1 requirements. Note:
Approved glasses have Z87 printed or stamped on them.
4. REMOVE ADJUSTING KEYS AND WRENCHES. Form
habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it “on”.
5. KEEP WORK AREA CLEAN. Cluttered areas and
benches invite accidents.
6. DON’T USE IN DANGEROUS ENVIRONMENT. Don’t
use power tools in damp or wet locations, or expose them
to rain. Keep work area well-lighted.
7. KEEP CHILDREN AND VISITORS AWAY. All children
and visitors should be kept a safe distance from work area.
8. MAKE WORKSHOP CHILDPROOF – with padlocks,
master switches, or by removing starter keys.
9. DON’T FORCE TOOL. It will do the job better and be
safer at the rate for which it was designed.
10. USE RIGHT TOOL. Don’t force tool or attachment to
do a job for which it was not designed.
11. WEAR PROPER APPAREL. No loose clothing, gloves,
neckties, rings, bracelets, or other jewelry to get caught in
moving parts. Nonslip footwear is recommended. Wear
protective hair covering to contain long hair.
12. SECURE WORK. Use clamps or a vise to hold work
when practical. It’s safer than using your hand and frees
both hands to operate tool.
13. DON’T OVERREACH. Keep proper footing and
balance at all times.
14. MAINTAIN TOOLS IN TOP CONDITION. Keep tools
sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
15. DISCONNECT TOOLS before servicing and when
changing accessories such as blades, bits, cutters, etc.
16. USE RECOMMENDED ACCESSORIES. The use of
accessories and attachments not recommended by Delta
may cause hazards or risk of injury to persons.
17. REDUCE THE RISK OF UNINTENTIONAL STARTING.
Make sure switch is in “OFF” position before plugging in
power cord.
In the event of a power failure, move switch
to the “OFF” position.
18. NEVER STAND ON TOOL. Serious injury could occur if
the tool is tipped or if the cutting tool is accidentally
contacted.
19. CHECK DAMAGED PARTS. Before further use of the
tool, a guard or other part that is damaged should be
carefully checked to ensure that it will operate properly and
perform its intended function – check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its
operation. A guard or other part that is damaged should be
properly repaired or replaced.
20. DIRECTION OF FEED. Feed work into a blade or
cutter against the direction of rotation of the blade or cutter
only.
21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool until it comes to a
complete stop.
22.
STAY ALERT, WATCH WHAT YOU ARE DOING, AND
USE COMMON SENSE WHEN OPERATING A POWER
TOOL. DO NOT USE TOOL WHILE TIRED OR UNDER
THE INFLUENCE OF DRUGS, ALCOHOL, OR
MEDICATION. A moment of inattention while operating
power tools may result in serious personal injury.
23. MAKE SURE TOOL IS DISCONNECTED FROM
POWER SUPPLY while motor is being mounted,
connected or reconnected.
24. THE DUST GENERATED by certain woods and wood
products can be injurious to your health. Always operate
machinery in well ventilated areas and provide for proper
dust removal. Use wood dust collection systems whenever
possible.
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
Page 3
3
IMPORTANT SAFETY RULES FOR
DUST COLLECTORS
WARNING:
Basic precautions
should always be followed when using your dust
collector. To reduce the risk of injury, electrical
shock or fire, comply with the safety rules listed
below:
1. DO NOT leave the dust collector plugged into the
electrical outlet. Unplug dust collector from the outlet
when not in use and before servicing, changing bags,
unclogging and cleaning.
2. ALWAYS turn all controls “OFF” before unplugging
the dust collector.
3. WARNING: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, do not use on wet surfaces. Do
not expose to rain. Store indoors.
4. FOLLOW all electrical and safety codes, including
the National Electric Code (NEC) and the Occupational
Safety and Health Regulations (OSHA). All electrical
connections and wiring should be made by qualified
personnel only.
5. DO NOT use the dust collector to pick up
flammable or combustible liquids, such as gasoline.
NEVER use the dust collector near any flammable or
combustible liquids.
6. USE the dust collector to pick up wood materials
only. DO NOT use the dust collector to pick up metal
shavings, metal dust, or metal parts.
7. NEVER use the dust collector to dissipate fumes
or smoke. NEVER pick up anything that is burning or
smoking, such as cigarettes, matches or hot ashes.
8. DO NOT pull the dust collector by the power cord.
NEVER allow the power cord to come in contact with
sharp edges, hot surfaces, oil or grease. Do not place
anything over the top of the power cord.
9. DO NOT unplug the dust collector by pulling on the
power cord. ALWAYS grasp the plug, not the cord.
10. DO NOT handle the plug or dust collector with wet
hands.
11. REPLACE a damaged cord immediately. DO NOT
use a damaged cord or plug. If the dust collector is not
operating properly, or has been damaged, left outdoors
or has been in contact with water, take it to an
Authorized Service Center for service.
12. DO NOT use the dust collector as a toy. DO NOT
use near or around children.
13. DO NOT insert fingers or foreign objects into the
dust intake port. Keep hair, loose clothing, fingers, and
all body parts away from openings and moving parts of
the dust collector.
14. DO NOT use with any opening blocked; keep
openings free of dust, lint, hair, and anything that may
reduce air flow.
15. NEVER use the dust collector without the dust
collection bag in place and properly secured.
16. ALWAYS use intake cover to cover dust port when
the dust collector is not in use or mounted to a
supporting surface for storage.
17. PERIODICALLY INSPECT dust bag for any cuts,
rips or tears. NEVER operate the dust collector with a
damaged bag or vacuum hose.
18. The dust collector is designed for home use or light
commercial duty ONLY!
19. CONNECT dust collector to a properly grounded
outlet only. See grounding instructions.
20. USE EXTRA CARE when cleaning on stairs.
Page 4
4
UNPACKING AND CLEANING
Carefully unpack the tool and all loose items from the shipping container(s). Remove the protective coating from all
unpainted surfaces. This coating may be removed with a soft cloth moistened with kerosene (do not use acetone, gasoline
or lacquer thinner for this purpose). After cleaning, cover the unpainted surfaces with a good quality household floor paste
wax.
Fig. 2
1. Dust collector
2. Hose
3. Dust bag
4. Outtake flange
5. Outtake flange gasket
6. Intake funnel
7. Intake support angle brace
8. Upper support bracket
9. Lower tube support
10. Wheel casters (4)
11. Lower tube support clamps (2)
12. Adjustable locking lever
13. Hose clamps (2)
14. 5/16-18x5/8" Button head carriage bolt (2)
15. 5/16" lockwasher (3)
16. 5/16" Hex nut (6)
17. 5/16-18x5/8" Hex head screw (4)
18. Intake cap
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Page 5
5
ASSEMBLY
ASSEMBLING WHEEL
CASTERS
1. Remove the hex nut and lockwasher from each of
the four wheel casters.
2. Place the dust collector on its side.
2. Insert bolt from wheel caster through the four holes
(A) Fig. 3 in the base of the dust collector.
3. Place a lockwasher (A) Fig. 4 onto each bolt.
4. Thread hex nut (B) Fig. 4 onto each of the four bolt
heads and tighten securely.
ASSEMBLING OUTTAKE
FLANGE
1. Align the holes in the outtake flange (A) Fig. 5 with
the holes in the outtake flange gasket (B).
2. Insert a 5/16-18x5/8" hex head bolt thru the outtake
flange, outtake flange gasket and the base unit as
shown in Fig. 6.
3. Thread a 5/16” hex nut (B) onto the 5/16-18x5/8"
hex head bolt (A) Fig. 6 and tighten securely.
4. Repeat this process for the three remaining bolts.
Fig. 3
A
Fig. 4
A
B
Fig. 5
A
B
Fig. 6
A
B
Page 6
6
ASSEMBLING DUSTPORT
TUBE AND CONNECTOR TO
DUST COLLECTOR BODY
1. Place tube clamp (A) Fig. 7 on the lower support
tube holder (B).
2. Insert the tube support bracket (A) into the tube
support holder (B) as shown in Fig. 8.
3. Place a tube clamp (A) onto the lower tube support
as shown in Fig. 9.
Fig. 7
A
B
Fig. 8
A
B
Fig. 9
A
Page 7
7
4. Align the two holes in the intake support angle brace
(A) Fig. 10 with the two holes in the intake funnel (B).
5. Fasten the intake support angle brace to the intake
funnel by inserting the two 5/16-18x5/8" button head
carriage bolts (C) thru the intake funnel (B) and the intake
support angle brace (A) as shown in Fig. 11.
6. Place a 5/16" lockwasher (A) Fig. 12,onto the bolt
(B), and thread a 5/16" hex nut (C) onto the bolt (B) and
tighten securely.
7. Attach the upper support bracket (B) Fig. 13 to the
intake support angle brace (C) with the adjustable
locking lever (D). NOTE: PLACE A 5/16”
LOCKWASHER (E) FIG. 13, ONTO LOCKING LEVER
SCREW BEFORE ATTACHING TO THE INTAKE
SUPPORT ANGLE BRACE.
Fig. 10
A
B
Fig. 11
B
A
C
Fig. 12
A
B
C
Fig. 13
B
C
D
E
Page 8
8
ASSEMBLING
VACUUM HOSE TO
DUST COLLECTOR
1. Place the intake cap holder (D) on the dust collector
as shown in Fig. 15. NOTE: DO NOT COVER THE
INTAKE PORT WITH THE INTAKE CAP WHEN
ATTACHING THE HOSE TO THE INTAKE PORT.
2. Place hose clamp (A) Fig. 15, onto one end of
vacuum hose (B) and slide hose around intake port (C)
as shown in Fig. 16. Tighten hose clamp (A).
8. Place lower support tube (B) Fig. 14, onto intake
funnel assembly (A) and secure with tube clamp (C).
Fig. 14
A
B
C
Fig. 15
Fig. 16
D
A
C
B
A
C
Page 9
9
Fig. 17 Fig. 18
Fig. 19
Fig. 20
3. Place the remaining hose clamp (A) Fig. 17, around the other end of vacuum hose (B) and slide hose (B) onto intake
funnel (C) and tighten hose clamp (A). NOTE: If desired, intake funnel (C) can be rotated to the vertical position, as
shown in Fig. 18.
ASSEMBLING DUST BAG TO DUST COLLECTOR
Loosely thread end of dust bag strap (A) through clamp (B) as shown in Fig. 19. Place open end of dust bag (C) Fig.
19, over outlet flange (D) Fig. 20 and firmly pull strap (A) to fasten dust collection bag to outlet flange.
A
B
C
C
A
B
C
D
A
CONNECTING TOOL TO POWER SOURCE
POWER CONNECTIONS
A separate electrical circuit should be used for your tools. This circuit should not be less than #12 wire and should be
protected with a 20 Amp time lag fuse. Have a qualified electrician repair or replace damaged or worn cord
immediately. Before connecting the motor to the power line, make certain the switch is in the “OFF” position and be
sure that the electric current is of the same characteristics as stamped on the motor nameplate. All line connections
should make good contact. Running on low voltage will damage the motor.
MOTOR SPECIFICATIONS
Your tool is wired for 120 volt, 60 HZ alternating current. Before connecting the tool to the power source, make sure
the switch is in the “OFF” position.
GROUNDING INSTRUCTIONS
WARNING: THIS TOOL MUST BE GROUNDED WHILE IN USE TO PROTECT THE OPERATOR FROM
ELECTRIC SHOCK.
This dust collector must be grounded. If it should malfunction or break down, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This dust collector is equipped with a cord having
an equipment-grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the dust collector. If it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
Page 10
10
Fig. 19
Fig. 20
GROUNDED OUTLET BOX
CURRENT
CARRYING
PRONGS
GROUNDING BLADE
IS LONGEST OF THE 3 BLADES
GROUNDED OUTLET BOX
GROUNDING MEANS
ADAPTER
Fig. 21
120 VOLT,
SINGLE PHASE OPERATION
This tool must be grounded while in use to protect the
operator from electric shock. The motor recommended
for use with your dust collector is shipped wired for 120
Volt, Single Phase, and is equipped with an approved
3-conductor cord and 3-prong grounding type plug to
fit the proper grounding type receptacle, as shown in
Fig. 19. The green conductor in the cord is the
grounding wire. Never connect the green wire to a live
terminal.
A temporary adapter, shown in Fig. 20, is available for
connecting 3-prong grounding type plugs to 2-prong
receptacles if a properly grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet can be installed by a qualified
electrician. THIS ADAPTER IS NOT APPLICABLE IN
CANADA. The green-colored rigid ear, lug, etc.,
extending from the adapter, is the grounding means and
must be connected to a permanent ground such as to a
properly grounded outlet box, as shown in Fig. 20.
Whenever the adapter is used, it must be held in place
with a metal screw.
240 VOLT,
SINGLE PHASE OPERATION
The motor supplied with your dust collector is a dual
voltage 120/240 volt motor. The dust collector motor is
shipped ready-to-run for 120 volt operation; however, it
may be converted for 240 volt operation.
The conversion of your dust collector for 240 volt
operation must be done by qualified electrical personnel.
Should you desire to have your dust collector converted
for 240 volts, take your dust collector to your local
Authorized Delta Service Center. Call 1-800-223-7278 for
the location of the nearest Authorized Service Center. The
Service Center will be able to convert your dust collector
for 240 volts by (a) re-wiring the motor for 240 volts; (b)
installing a 240 volt attachment plug to the power supply
cord; and (c) replacing the single pole on/off switch
shipped with your dust collector with a double pole switch.
The dust collector with a 240 volt plug should only be
connected to an outlet having the same configuration as
the plug illustrated in Fig. 21. No adapter is available or
should be used with the 240 volt plug.
CURRENT CARRYING PRONGS
GROUND PRONG
240 VOLT
AS A PRECAUTION IN ALL CASES, MAKE CERTAIN
THE RECEPTACLE IN QUESTION IS PROPERLY
GROUNDED. IF YOU ARE NOT SURE, HAVE A
CERTIFIED ELECTRICIAN CHECK THE RECEPTACLE.
Use proper extension cords. Make sure your extension cord is in good condition and is a 3-wire extension cord which
has a 3-prong grounding type plug and a 3-hole receptacle which will accept the tool’s plug. When using an extension
cord, be sure to use one heavy enough to carry the current of the tool. An undersized cord will cause a drop in line
voltage, resulting in loss of power and overheating. Fig. 22 & 23, shows the correct gauge to use depending on the
cord length. If in doubt, use the next heavier gauge. The smaller the gauge number, the heavier the cord.
EXTENSION CORDS
GROUNDED OUTLET BOX
Page 11
11
OPERATING CONTROLS & ADJUSTMENTS
WARNING: FOR OPERATOR SAFETY, MAKE
CERTAIN THE DUST INTAKE PORT IS COVERED
WITH THE VACUUM HOSE BEFORE OPERATING
THE MACHINE. THE ROTATING FAN INSIDE THE
BLOWER HOUSING IS ACCESSIBLE THROUGH THE
DUST INTAKE PORT AND IS HAZARDOUS. MAKE
SURE INTAKE CAP COVERS THE INTAKE PORT
WHEN HOSE IS REMOVED. ALWAYS WEAR PROPER
APPAREL.DO NOT WEAR JEWELRY, AND KEEP
FINGERS AND ALL FOREIGN OBJECTS OUT OF
THE DUST INTAKE PORT.ALWAYS FOLLOW THE
SAFETY RULES OF THIS MANUAL.
STARTING AND STOPPING
DUST COLLECTOR
The ON/OFF power switch (A) Fig. 24, is located on the
side of the motor. To turn the machine “ON”, move the
toggle switch (B) towards the “ON” position. To turn the
switch “OFF”, move the toggle switch (B) towards the
“OFF” position.
LOCKING SWITCH IN
THE “OFF” POSITION
When the tool is not in use, the switch should be locked
in the “OFF” position to prevent unauthorized use. This
can be done by grasping the switch toggle (B) Fig. 25,
and pulling it out of the switch (A) as shown. With the
switch toggle removed, the switch will not operate.
However, should the switch toggle be removed while the
machine is running, the switch can be turned “OFF”
once, but cannot be restarted without inserting switch
toggle (B).
Fig. 24
Fig. 25
A
B
A
B
Fig. 22
MINIMUM GAUGE EXTENSION CORD
RECOMMENDED SIZES FOR USE WITH STATIONARY ELECTRIC TOOLS
Ampere Volts Total Length of Gauge of
Rating Cord in Feet Extension Cord
0-6 120 up to 25 18 AWG
0-6 120 25-50 16 AWG
0-6 120 50-100 16 AWG
0-6 120 100-150 14 AWG
6-10 120 up to 25 18 AWG
6-10 120 25-50 16 AWG
6-10 120 50-100 14 AWG
6-10 120 100-150 12 AWG
10-12 120 up to 25 16 AWG
10-12 120 25-50 16 AWG
10-12 120 50-100 14 AWG
10-12 120 100-150 12 AWG
12-16 120 up to 25 14 AWG
12-16 120 25-50 12 AWG
12-16 120
GREATER THAN 50 FEET NOT RECOMMENDED
MINIMUM GAUGE EXTENSION CORD
RECOMMENDED SIZES FOR USE WITH STATIONARY ELECTRIC TOOLS
Ampere Volts Total Length of Gauge of
Rating Cord in Feet Extension Cord
0-6 240 up to 50 18 AWG
0-6 240 50-100 16 AWG
0-6 240 100-200 16 AWG
0-6 240 200-300 14 AWG
6-10 240 up to 50 18 AWG
6-10 240 50-100 16 AWG
6-10 240 100-200 14 AWG
6-10 240 200-300 12 AWG
10-12 240 up to 50 16 AWG
10-12 240 50-100 16 AWG
10-12 240 100-200 14 AWG
10-12 240 200-300 12 AWG
12-16 240 up to 50 14 AWG
12-16 240 50-100 12 AWG
12-16 240
GREATER THAN 100 FEET NOT RECOMMENDED
Fig. 23
Page 12
12
OPERATIONS
This versatile dust collector is light, compact and can
easily be transported to a variety of locations for use in
and out of the workshop. This dust collector can be
used with many different types of woodworking
machinery as shown in Figs. 26, 27, and 28. This dust
collector shows its versatility in the way that the intake
port can be positioned to accommodate different types
of wood working machinery.
Fig. 26 illustrates the dust collector used in conjunction
with a router. Note that the intake port is adjusted so that
it will be able to collect the dust created by using the
router.
Fig. 27 illustrates the dust collector used in conjunction
with a table saw. Note that the intake port is removed
from the lower tube support. The intake funnel can be
clamped to a tool to provide dust collection as shown.
Fig. 28 illustrates the dust collector used in conjunction
with a drum sander that is equipped with a dust removal
port. The intake funnel can be removed and the 4" dust
tube can be connected directly to the dust removal port.
Fig. 26
Fig. 27
Fig. 28
Page 13
13
TRANSPORTATION AND
STORAGE
1. The dust collector features a convenient carrying
handle with rubber grip (A) Fig. 29, which allows the unit
to be carried easily from one job area to another.
IMPORTANT: THE DUST COLLECTOR WEIGHS
APPROXIMATELY 46 LBS. CARE SHOULD BE TAKEN
WHEN LIFTING AND TRANSPORTING THE MACHINE.
2. In addition to the carrying handle, the machine
features a storage mounting bracket (B) Fig. 30, with a
hole for mounting the dust collector to a wall or wooden
support (when not in use).
Fig. 29
Fig. 30
MAINTENANCE
WARNING: Before any maintenance or service is performed, be sure the dust collector is discon-
nected from the power source to prevent accidental starting. All maintenance other than the items recommended in
this manual should be performed by an authorized Delta Service Center.
1. WARNING: Always disconnect the machine from the power source before performing any maintenance
procedures.
2. The condition of the dust bag should be checked periodically for damage and emptied on a regular basis. Do not
transport the machine with a full dust bag.
3. Clean and apply a dry silicone lubricant monthly to the impeller to remove any dirt or build-up of pitch, gum and
wood shavings.
4. WARNING: Always make sure that the intake cap (A) Fig. 31, covers the intake port when the hose is not
connected to the machine.
Fig. 31
A
B
A
Page 14
14
Printed in U.S.A.
PARTS, SERVICE OR WARRANTY ASSISTANCE
All Delta Machines and accessories are manufactured to high quality standards and are serviced by a
network of Porter-Cable • Delta Factory Service Centers and Delta Authorized Service Stations. To obtain
additional information regarding your Delta quality product or to obtain parts, service, warranty assistance, or
the location of the nearest service outlet, please call 1-800-223-7278 (In Canada call 1-800-463-3582).
ACCESSORIES
A complete line of accessories is available from your Delta Supplier, Porter-Cable • Delta Factory Service Centers,
and Delta Authorized Service Stations. Please visit our Web Site
www.deltamachinery
.com
for a catalog or
for the name of your nearest supplier.
WARNING: Since accessories, other than those offered by Delta, have not been tested
with this product, use of such accessories could be hazardous. For
safest operation, only
Delta recommended accessories should be used with this product.
Two Year Limited Warranty
Delta will repair or replace, at its expense and at its option, any Delta machine, machine part, or machine accessory which
in normal use has proven to be defective in workmanship or material, provided that the customer returns the product
prepaid to a Delta factory service center or authorized service station with proof of purchase of the product within two
years and provides Delta with reasonable opportunity to verify the alleged defect by inspection. Delta may require that
electric motors be returned prepaid to a motor manufacturer’s authorized station for inspection and repair or replacement.
Delta will not be responsible for any asserted defect which has resulted from normal wear, misuse, abuse or repair or
alteration made or specifically authorized by anyone other than an authorized Delta service facility or representative. Under
no circumstances will Delta be liable for incidental or consequential damages resulting from defective products. This
warranty is Delta’s sole warranty and sets forth the customer’s exclusive remedy, with respect to defective products; all
other warranties, express or implied, whether of merchantability, fitness for purpose, or otherwise, are expressly
disclaimed by Delta.
Loading...
