Delphi SKYFi3 User Manual
SKYFi3® Kit for Bose® System
VERSION 1.0
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
The SKYFi3 Satellite Radio Receiver incorporates an FM transmitter
and is therefore classified as an intentional transmitter. Changes or
modifications to the unit not expressly approved by Delphi can void
your authority to operate this equipment.
Warning: The FCC and FAA have not certified the Delphi SKYFi3
Satellite Radio Receiver for use in any aircraft (neither portable nor
permanent installation). Therefore, Delphi cannot support this type
of application or installation.
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
Need help?
Call us at 1.877.GO.DELPHI
Monday through Friday from 8:00 a.m. - 8:00 p.m. Eastern Time
Saturday and Sunday from 10:00 a.m. - 4 :00 p.m Eastern Time
Note: Extended seasonal hours may be available.
Thank you for purchasing a Delphi SKYFi3® Kit for your Bose® System.
We’ve designed many thoughtful features into this system to ensure that
your level of listening enjoyment is the very best it can be.
In the event that you have questions or trouble getting started with your
new system, please do not return to the store. Call us first! We can help.
Please install the latest software update. You may also refer to the “Software
Update” insert and the “Troubleshooting” section of the enclosed SKYFi3
user guide for more information.
Technical Support is also available at www.shopdelphi.com/skyfi3 support.
All features and functions are subject to change without notice.
To ensure you have the latest features and satellite service compatibility,
please visit http://fwupdt.xmradio.com/ to check for any updates for the
product. Delphi recommends that you check for any updates before using
the SKYFi3. You will need the Radio ID of your SKYFi3. You can find this
number on the bottom of the receiver and on the box.
Go to http://fwupdt.xmradio.ca
1
Table of Contents
Contents
Welcome ............................................................................................. 3
About Delphi ...................................................................................... 4
About XM ........................................................................................... 4
Some Important Reminders ............................................................. 5
Controls .............................................................................................. 6
Connecting the Parts ......................................................................... 7
When Using Bose Wave Radio/CD ................................................
When Using Bose System With Multi-CD Changer .....................
Receiving the XM Signal ................................................................. 10
Activating Your SKYFi3 ................................................................... 12
Using the Remote Control .............................................................. 13
Using the Remote Control to Turn on Your System ..................
When There’s No Signal on the SKYFi3 Screen ........................
To Get Out of XM Mode ..............................................................
Bose System Universal Remote Control Buttons ......................
Delphi SKYFi3 Universal Remote Control Buttons .................... 18
Other Things to Know About the Remote Control ....................
Troubleshooting ............................................................................... 20
Care ...................................................................................................
Warranty ...........................................................................................
8
9
14
14
15
17
19
21
22
2
Welcome
Welcome
Thank you for purchasing the new Delphi SKYFi3® Kit for your
Bose® System. You are just minutes away from adding more than
170 channels of live XM® satellite radio to your existing system.
To transform your Bose System into a satellite radio receiver, just
follow the instructions found in this manual.
3
About Delphi
Delphi is a world leader in mobile electronics, vehicle components,
and audio technology. Delphi created the first in-dash car radio in
1936 and continues its strong tradition of innovation in the audio
industry. Now Delphi technology has helped make satellite radio a
reality, and Delphi continues to expand its in-vehicle and consumer
electronics technologies. With its exciting line of satellite radio products, Delphi offers a broad portfolio of products to answer a wide
variety of information and entertainment needs—in the vehicle,
home, office, or virtually anywhere.
About XM
XM Satellite Radio is the nation’s leading provider of satellite
radio*. XM broadcasts over 170 digital channels of totally new
music, news, sports, and children’s programming direct to cars
and homes via satellite and its extensive repeater network, which
supplements the satellite signal to ensure seamless transmission. Subscribers pay a monthly fee for the XM service. Exclusive
programming on XM includes Major League Baseball® games for
every team, all season long. XM is broadcast via satellite from
coast to coast, so you can listen to XM continuously as you travel
across the country.
*To receive the XM service, you must subscribe to XM. Available in the continental United States and Canada
only. Satellite radio reception depends on the ability of the antenna to receive a signal. The signal may not be
available in buildings or if obstructed (e.g., by mountains, trees, bridges, etc.).
4
Some Important Reminders
Some Important Reminders
We know you are eager to begin using your SKYFi3 Kit for Bose
System. Please take a moment to review the following:
Warning: This manual and the SKYFi3
user guide contain important safety and operating information. Please read, understand,
and follow the instructions in these manuals.
Failure to do so could result in personal injury,
death, and/or damage to your SKYFi3, accessories, and/or property.
Caution: Refrain from using food or
drinks near your SKYFi3. Spilling food or drinks
on the unit can damage it.
Caution: Use your SKYFi3 only with the
enclosed components or approved accessories.
Do not modify wires or other connectors in any
way; you could cause a malfunction, which
could damage your SKYFi3 and will void your
warranty.
This product’s software can be updated and all features and functions are subject to change without notice. Please check for online
updates for your SKYFi3. See page 1 for more information.
SKYFi3 uses a microSD™ card (sold separately) to store digital audio files. Delphi recommends using SanDisk brand microSD cards
for the best performance. SKYFi3 accepts microSD cards up to 2 GB
in capacity.
Please make sure your battery is fully charged (three hours) before
using your SKYFi3 on battery power.
5
Controls
Controls
See the enclosed SKYFi3 user guide for more information on
how to enjoy all of the features of your SKYFi3.
microSD
Slot
Earbud
Jack
Display
Arrow Keys
Select menu entries,
change channels, skip
through songs, change
categories, and more...
Play/Pause
Mode/Power
Press to change modes:
Live XM, My Music, Aux.
Press and hold to power
on and off.
Menu
Display the main
menu of functions:
Record, Favorites,
Bookmarks, Settings, My Music.
6
Display
Press to change the
display appearance.
Press and hold to
change from vertical
to horizontal
orientation.
Power
Volume
Hold
Slide the switch down
to lock controls.
USB Connector
Connect SKYFi3 to
your PC.
Main Connector
For connecting SKYFi3 to car, home
cradles, and additional accessories.
Connecting the Parts
Connecting the Parts
Connect the parts for the Delphi SKYFi3 Kit for Bose System as
shown in the picture below.
AUX IN
Bose System setup—
see page 8 & 9 if using a Bose Wave
Radio/CD or Multi-CD changer
7
Connecting the Parts
When Using Bose Wave Radio/CD
If you are using a Bose Wave Radio/CD, please use the included
RCA adapter to plug in as shown in the figure below.
1
AUX IN
2
8
When Using Bose System With Multi-CD Changer
If you are using the Bose System with Multi-CD Changer, please
use the included RCA adapter to plug in as shown in the figure
below.
Note: If you are unsure which
Bose System you own, the model
number can be found on the bottom of your Bose System. Also,
be sure to change the switch
inside the battery cover on the
remote control to the Bose/CD
position.
2
1
AUX IN
9
