DEA600 Radio System
Introduction
The information and figures in this manual describe features that may or may not be on your specific vehicle either because they are options that you did not
purchase or due to changes subsequent to the printing of this owner manual.
The DEA600 System consists of a 7" Smart Display connected to a Radio. The Smart Display functions as a main display managing the entire user interface. The
Smart Display with resistive touch-screen has a rear USB for playback or USB modem connection, and manages the Applications, Phone interface, Audio, Internet
and Bluetooth / Wi-Fi connections. The Radio is a module capable of managing the audio output of the system to the speakers, containing the tuner (AM, FM,
WX), Sirius XM, Front Aux, Rear Aux, USB, CD. It also transmits the audio output from the Smart Display and manages the hard buttons.
IMPORTANT!: The operation of this equipment is subject to the following two conditions: (1) It is possible that this equipment or device may not cause
harmful interference, and (2) the equipment or device must accept any interference, including interference that may cause undesired operation.
System Features and Functions
The DEA600 System implements the following features and functions:
7" display with resistive touch-screen.
Bluetooth & Wi-Fi connectivity.
4 Integrated Analog Camera Inputs.
Microphone Input (Mono).
GPS/Navigation Application Compatibility.
Audio Outputs.
Voice Recognition.
Text to Speech.
1 knob with center push.
Front Aux Input / Rear Aux Input.
USB compatibility for Apple devices.
CD Playback.
Front USB Connectivity (USB Playback).
Tuner (AM/FM/WX).
SiriusXM.
4/2 Speakers Output.
Steering Wheel Control Compatibility.
Rear Seat Audio Compatibility.
Smart
Display
Radio
Owner´s Manual DEA600 Radio
5 | P a g e
Radio
Radio Button Operation
Volume Knob/Power
Rotate to Increase/decrease Volume. Press Knob to turn ON/OFF the Radio.
One-Hour Timer
With key off, pressing the PWR button on Radio or PWR button on RSA will
turn ON the receiver and activate the receiver’s one-hour timer. The receiver
will turn OFF after one hour or by pressing the PWR button.
Eject
It removes any disc from the CD slot.
Phone
The Phone button is used to open the Phone App; and during a Phone Call it
can be used to hang up the call.
Dim Day / Dim Night
The Dimming Day button is used to increment the brightness level of the
Smart Display and the backlight level of the Radio bezel.
The Dimming Night button is used to decrease the brightness level of the
Smart Display and the backlight level of the Radio bezel.
Back / Home / Menu
The Back button is used to exit the current screen and open the previous
screen.
The Home button is used to go directly to the main home screen.
The Menu button is used to open the menu related to the current screen.
When the System is on the Home screen, the Menu button opens the
"System Settings" menu.
Owner´s Manual DEA600 Radio
6 | P a g e
Smart Display
Getting Started
Using the touch screen
A “Touch” over a soft key activates or selects the corresponding function, or
it opens the selected item; please see Figure 1, as reference.
Figure 1: Touch action over Navigation App
A “Swipe” action is the case when the System registers a touch and a linear
streak movement over the screen. The movement can be performed to the
right, left, up and down. Due to this, the System is able to discern among 4
swipes:
Swipe Right.
Swipe Left.
Swipe Up.
Swipe Down
The next right screen is presented once the system senses a Swipe Left
action; please see Figure 2, as reference.
Figure 2: Swipe to the Left action
The next left screen is presented once the System senses a Swipe Right
action; please see Figure 3, as reference.
Figure 3: Swipe to the Right action
Owner´s Manual DEA600 Radio
7 | P a g e
The next top screen is presented once the System senses a Swipe Down
action; please see Figure 4, as reference.
Figure 4: Swipe down action
The next bottom screen is presented once the System senses a Swipe Up
action; please see Figure 5, as reference.
Figure 5: Swipe up action
Home screen & Navigation buttons
The installed application icons are presented at the home screen. The home
screen is distributed in a home main screen and subsequent home screens.
Each of the home screens present a maximum of 6 application icons, plus
the Audio widget. The number of the subsequent home screens is relative to
the number of installed applications. Each subsequent home screen is
added to the right of the main home screen or next to the right of the last
subsequent home screen. An indicator identifies which home screen is
displayed. The screen indicator is placed below the top bar of the home
screen.
The following Applications are presented at the Home Screen as default
(Figure 6):
Gauges
Navigation
Audio
Phone
Camera Views
Clock
Owner´s Manual DEA600 Radio
8 | P a g e
Figure 6: The Main home screen
Each application icon works as the application activation soft key.
The System has the capability to rearrange the application icons according
to the user needs. The basic sequence is (see Figure 7 as reference):
Select the desired application.
Press, and hold, the application icon to "grab" it.
"Drag" the icon to the desired location by moving the application to
this one.
"Drop" the icon by releasing it.
Figure 7: Drag and Drop Function
At the top bar of each screen are the Notification and Status bars. The
Notification bar presents the following information, if available:
Icon
Meaning
Notification
Downloading Data
CD Warning
CD Source available
New SMS/text message
Software update available
CoPilot Truck navigation running
WiFi network available
More icons available
The Notification Bar accepts the swipe down action in order to present more
information related to the displayed icons.
Also, the Status bar presents the following information, if available:
Owner´s Manual DEA600 Radio
9 | P a g e
Status
Mute
Bluetooth ON, not connected
Bluetooth ON/Connected to a Bluetooth Device
Connected to a Wi-Fi network
USB Source available
DDA active
Alarm Indicator
78°F
Temperature
Table 1: Notification & Status Icons meaning.
The System presents four soft key navigation buttons at the bottom of the
screen:
Back
Home
Menu
Voice Recognition
The Back soft key is used to exit the current screen and open the previous
screen. The Back soft key button doesn’t have any effect on the home
screen.
The Home soft key is used to go directly to the home screen.
The Menu soft key is used to open the menu related to the current screen
(for example, Figure 8); when it is used in the Launcher the Menu soft key
will open the System Settings menu (Figure 9 and Figure 10).
The Voice Recognition soft key starts the Voice Recognition application.
Figure 8: Settings menu related to SiriusXM audio source
Figure 9: The settings screen – Page I
Owner´s Manual DEA600 Radio
10 | P a g e
Figure 10: The settings screen – Page II
When the System is turned OFF, the clock view illustrated on will be shown
(Figure 11).
Figure 11: Clock view in OFF power mode
When the Driver Distraction Avoidance (DDA) mode is active, some
application icons from the home screen are grayed out and cannot be
selected by the user, see Figure 12 as reference.
Figure 12: DDA mode active
Dim Day / Dim Night
The Dimming level is indicated each time the Dim Day, or Dim Night, button
is pushed (Figure 13).
Figure 13: The Dimming level indicator pop-up
Owner´s Manual DEA600 Radio
11 | P a g e
Volume
Volume level is indicated each time the volume knob is turned (Figure 14).
Figure 14: The Volume level indicator pop-up
Volume mute condition is also reported at the Status bar (Figure 15).
Figure 15: The Mute activation indicator icon
Mute
This feature is used to mute the radio due to an external event in the vehicle.
The radio remains MUTE while event is active.
If this event occurs, the Media sources are paused. Once it ends, the
System continues playing the media.
There are some actions that can cancel this mute like: Alarm notification,
volume changes, media insertion, a Bluetooth call, among others.
Reverse Mute
The radio is muted if the reverse gear is selected. This interruption is ignored
if the radio is on a Bluetooth phone call.
Selecting any transmission gear different than reverse cancels the mute
(starts the media).
Audio Application
The Audio application is located on the home screen of the Smart Display
(Figure 16). All Music source are accessed and managed via the Audio app.
Figure 16: Open Audio App to access Music Sources
Owner´s Manual DEA600 Radio
12 | P a g e
The Audio sources are presented to the user in a tab-bar at the top of the
application screen, with each Audio source working as a soft key selector;
the selected Audio source icon is highlighted.
The System does not allow the selection of more than one Audio Source
option at a time. If the System senses the selection of the current Audio
source option no change will take place.
The System supports 9 different Audio sources: 5 Media sources and 4
Radio sources.
Media Sources
The System displays 5 Media sources at the main Audio sources tab-bar:
USB
CD
Aux
Bluetooth
Rear Aux
If media audio source are not available, the corresponding icons are
displayed in gray.
Media Audio Control Soft keys
The System presents the next control soft keys as part of the Media sources
interface:
Play/Pause
Next
Previous
Repeat
Shuffle
Views
In the case the CD media, USB or the Bluetooth media source are selected,
the user interface is illustrated in Figure 17.
Figure 17: Audio App Media Sources
The System displays the song name, artist name and the album image
artwork, if available.
The System displays the track time bar located under the album artwork of
the file that is being played, please see Figure 18, as reference.
Figure 18: Track Time Bar
Owner´s Manual DEA600 Radio
13 | P a g e
Fast forward function is activated by long pressing the next soft key for 2
seconds. Fast reverse function is activates by long pressing the previous
soft key for 2 seconds.
Views
The System presents the view soft key, when it is selected (Figure 19), the
following options are displayed:
Artists
Albums
All Songs
Playlists
Search
Figure 19: Views Soft key
For Apple devices the System supports the following additional views:
Genre
Composer
Audio Books
Artist
The System presents the albums allocated by artist, illustrated on Figure 20.
Figure 20: The Artists view
All the artists in this mode work as a soft key. Once an artist is selected, the
System starts to play all the media files related.
For Apple devices the artist view screen follows the distribution and styling
Figure 21 illustrates.
Figure 21: Apple Artist View
Owner´s Manual DEA600 Radio
14 | P a g e
Once an artist is selected the System displays the list of the contained
albums, as shown in the Figure 22.
Figure 22: Apple Artist’s Albums View
The System displays up to 5 items per screen. In the case there are more
than 5 albums, the remaining albums are shown in subsequent screens
below. All items in the list work as a soft key button selector.
Albums
The albums view screen follows the distribution and styling as the Figure 23
illustrates.
Figure 23: The Albums view
The System displays the albums contained in the media source selected.
The albums are displayed in a grid manner. Up to 10 album icons are
displayed per screen. In the case there are more than 10 albums, the
remaining album are distributed in subsequent screens available by scrolling
right.
Each album icon works as a soft key selector. The albums are distributed by
5 columns of two albums per screen. Each Album grid displays the Album
image (if available), Album name and Artist name. If the Album name is not
available the label "Unknown" is displayed. If the Artist name is not available
the label "Unknown" as the artist name is displayed.
If one album is selected, the System starts to play all the media files related.
In the case the album artwork is not available the System displays a
standard album icon as Figure 24 illustrates.
Owner´s Manual DEA600 Radio
15 | P a g e
Figure 24: Standard Album Artwork icon
For Apple devices the album view screen follows the distribution and styling
illustrated on previous Figure 22.
Once an album is selected the System displays the list of the contained
songs. The System displays up to 5 items per screen. In the case there are
more than 5 items the remaining items can be viewed by scrolling down.
All Songs
Once the All Songs view is selected the System displays the list of the
contained songs. Up to 5 songs are displayed per screen. In the case there
are more than 5 songs, the remaining songs are distributed in subsequent
screens. All songs in the list work as a soft key button selector. Once a song
is selected, the System plays the selection.
Playlists
The System presents the playlists contained in the connected device
following the distribution and styling Figure 25 illustrates.
Figure 25: The Playlists view
Search
If the Search tab is selected, the search screen is displayed with the
following elements:
White Box
Keyboard
The Keyboard works as the user-system interface to acquire the
alpha/numeric search. The white box displays the acquired information. The
System continue playing audio while performing the search. The Figure 26
illustrates the search screen.
Owner´s Manual DEA600 Radio
16 | P a g e
Figure 26: The Search screen
The Views soft key button is not available for the next Media sources:
CD
Aux
Bluetooth
Rear Aux
In the case the Rear Aux media source is selected, the user interface shall
follow the distribution and styling Figure 27 illustrates.
Figure 27: The Rear Aux Media source screen
In the case the Aux media source is selected, the user interface shall follow
the distribution and styling of the Figure 28.
Figure 28: The Aux Media source screen
Owner´s Manual DEA600 Radio
17 | P a g e
USB
Playing from a USB
The USB port is in the front of the Radio. Five volts DC power is limited to
one amp from this port. Devices such as iPod that require greater current will
not charge from this port.
1. Connect the USB.
2. The USB Source media is automatically selected and plays the
media content of the USB device if no other app of higher priority is
in use (I.E. phone call, video, reverse mute…).
3. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Soft key for further
information.
Drives
The USB MP3 players and USB drives connected must comply with the USB
Mass Storage specification:
MS-Dos partition only
Class specification (USB MSC) and supports formats of FAT32,
FAT16, NTFS, and HFS+
Hard disk drives may be played, but they are not supported.
The radio will not be able to play back write-protected music.
MTP players are not supported.
For MP3 Files
MP3 files must meet the following guidelines for proper playback:
Bit rates: 32, 40, 48, 56, 64, 80, 96, 112, 124, 160, 192, 224, 256,
320 kbps for MPEG-1 Audio Layer 3
Sampling frequencies: 32, 44.1 and 48 kHz for MPEG-1 Audio
Layer 3
Maximum number of folders: Eight folders with 255 files per folder
Maximum of 1,000 files on a disc
M3u and pls playlist versions supported
Recorded on a CD-R or CD-RW with a maximum capacity of 700
MB
Error Messages
If an “UNSUPPORTED” message is displayed, it could be for one of the
following reasons:
When a MTP Player or a USB device with unsupported format or
partition is connected.
When the device is damaged.
When the connected device was not connected as mass storage
device.
If “NO MUSIC” message is displayed, it could be because there are no
playable MP3 files.
iPod
This Radio supports the following iPod models:
iPod classic
®
(6G)
iPod nano
®
( 6G, and 7G)
iPod touch
®
(4G, and 5G)
iPhone
®
(4S, 5, 5C, and 5S)
Other iPods may be played, but functionality is not guaranteed.
The radio provides up to 1A of charge, so any device connected to the USB
that requires less than 1 A will be charged.
There may be problems with the operation and function in the following
situations:
When connecting an iPod on which a more recent version of the
firmware is installed than is supported by the Radio.
When connecting an iPod with firmware from other providers is
installed.
Playing from an iPod
To connect an iPod:
1. Connect one end of the standard iPod USB cable to the iPod's dock
connector.
2. Connect the other end to the USB port in the front of Radio.
Owner´s Manual DEA600 Radio
18 | P a g e
3. Radio will start playing the USB and shows the track number, Song,
Artist, elapsed time, and album information when available.
4. If the iPod is an unsupported model, it can still be listened to in the
vehicle by connecting to the auxiliary input jack using a standard
3.5 mm (1/8 in) stereo cable.
5. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Soft key for further
information.
Expected behavior when iPod is connected:
The iPod battery recharges automatically while the vehicle is on.
The iPod shuts off and stops charging when the vehicle is shut off.
Error Messages
If an “UNSUPPORTED” message is displayed, it could be for one of the
following reasons:
When the iPod connected is not supported.
The iPod does not respond to the radio commands, in this case
reset the iPod and try again the connection.
If a “NO MUSIC” message is displayed, it could be because there are no
playable files in the iPod.
CD Player
The player can be used for CD and MP3 audio.
With the vehicle on, insert a disc into the slot, label side up, the player pulls it
in and begins playing.
The system is capable of playing:
Most audio CDs
CD-R or CD-RW with MP3 files
When playing any compatible recordable disc, the sound quality can be
reduced due to disc quality, the method of recording, the quality of the music
that has been recorded, or the way the disc has been handled.
There can be increased skipping, difficulty in recording tracks, difficulty in
finding tracks, and/or difficulty in loading and ejecting.
If these problems occur, check the disc for damage or try a known good
disc.
To avoid damage to the CD player:
Do not use scratched or damaged discs.
Do not apply labels to discs. (The labels could get caught in the
player).
Insert only one disc at a time.
Keep the loading slot free of foreign materials, liquids, and debris.
Use a marking pen to label the top of the disc.
To load a disc:
1. Turn the vehicle on.
2. Insert a disc into the slot, label side up. The player pulls it in the
rest of the way. If the disc is damaged or improperly loaded, there
is an error on the screen and the disc ejects.
3. Press “Eject” to eject a disc from the CD player. If the disc is n ot
removed within a short period of time, it is automatically pulled back
into the player.
Playing an Audio CD:
1. After the CD is inserted, the mode is changed to CD mode, unless
any mode with a higher priority is active (I.E. phone call, video,
reverse mute….).
2. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Soft key for further
information.
Error Messages
If a “Disc Error” message is displayed and/or the disc comes out, it could be
for one of the following reasons:
The disc has an invalid or unknown format.
The disc is very hot. Try the disc again when the temperature
returns to normal.
The road is very rough. Try the disc again when the road is
smoother.
The disc is bent.
The disc is dirty, scratched, wet, or upside down.
The air is very humid. Try the disc again later.
Owner´s Manual DEA600 Radio
19 | P a g e
There was a problem while burning the disc.
The label is caught in the CD player.
If the disc is not playing correctly, for any other reason, try a known
good CD.
If any error continues, contact your dealer.
For MP3 Files:
MP3 files must meet the following guidelines for proper playback:
Bit rates: 32, 40, 48, 56, 64, 80, 96, 112, 124, 160, 192, 224, 256,
320 kbps for MPEG-1 Audio Layer 3
Sampling frequencies: 32, 44.1 and 48 kHz for MPEG-1 Audio
Layer 3
Maximum number of folders: Eight folders with 255 files per folder
Maximum of 1,000 files on a disc
M3U and PLS playlist versions supported
Recorded on a CD-R or CD-RW with a maximum capacity of 700
MB
Special Considerations
Root Directory:
The root directory is treated as a folder. All files contained directly under the
root directory are accessed prior to any root directory folders.
Empty Folders:
If a root directory or folder is empty or contains only folders, the player
advances to the next folder in the file structure that contains a compressed
audio file. The empty folder(s) are not displayed or numbered.
Front Auxiliary
Front auxiliary input is active when a jack connector is inserted.
After the connector is inserted, the mode is changed to Front Aux mode,
unless any mode with a higher priority is active (I.E. phone call, video,
reverse mute….).
This operation is not available while the System is in standby power mode.
In front auxiliary mode, you can play an external device such as an iPod
®
or
MP3 player via the auxiliary input jack on the front of the receiver.
To use an external device simply connect the device via the auxiliary input
jack.
Front auxiliary mode will not be available if no device is connected to the
auxiliary input jack on the front of the receiver.
Bluetooth Player
If your connected device supports this feature, it can be used as an audio
source input to the radio, allowing you to enjoy the music files stored on your
phone.
This feature is recommended for use with the default device player.
Functionality cannot be warranted, when a third party player is used in the
connected device. The radio can be out of synchrony if the user alters or
command the player within the phone.
Playing Bluetooth Audio:
1. Pair device to Smart display. Refer to Bluetooth Settings for further
information.
2. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Soft key for further information.
Notes:
Repeat and random functions will only be shown if the cell phone
supports these features.
The contacts shown on the radio display will depend on the
information received by the radio from the phone device used.
Functions may differ depending on the phone. Please consult your
cell phone user guide regarding how to enable it.
Some phones will make the radio display BT AUDIO PAUSE while
audio is available. This is normal on phones that do not have full
compatibility with this radio Bluetooth remote control commands.
Some devices will disconnect Bluetooth when a transfer is
performed.
Rear Auxiliary
The DEA600 is not safety product.
The cameras and the rear auxiliary inputs are provided for driver
conveniences only.
The purpose of this stereo input is to connect the audio output of an external
source or a sound channel from a safety system. When the source is an
external Navigation audio input the system detects activation of the
Loading...
