Dell™ PowerEdge™ R720 t
Carrier Grade
As a telecommunications Original Equipment Manufacturer (OEM), you’ve told us you need aordable performance,
improved energy eciency, and accelerated time-to-market to maximize ROI. With the Carrier Grade Dell PowerEdge
R720t, you get all that plus peace of mind with our Tier 1 quality and reliability.
Telecom server solution
NEBS compliance is an important requirement in your
environment. As a recognized global leader in enterprise
platforms, Dell OEM Solutions oers NEBS Level-3 and
ETSI-certified PowerEdge
®
on Intel
global availability. Our rack mount systems are designed
to deliver high performance, maximum scalability,
and safe and reliable service. Dell’s 12th Generation
PowerEdge Carrier Grade servers for OEM oer:
• Open standard systems
• Industry standards solutions
• Global regulatory support and availability
Xeon® processors at tier 1 levels of stability and
› Improved compatibility based on
industry-leading Dell products
› Rapidly scalable and easily expandable
› NEBS Level 3 and ETSI certified
› Fresh-air cooling systems enable servers to operate in
warmer environments than traditional data centers
› Designed for extreme conditions such as
high humidity, earthquakes and dust
™
Carrier Grade servers running
Additional features
• Accelerated performance enables you
to operate fast and eciently.
• Increased productivity helps you to maintain
focus on your intellectual property (IP).
• Industry-leading support gives you the agility
to manage your clients more eciently.
• Identity Module simplies the distribution and maintenance
of customized BIOS, helping OEMs get updates to
market quickly and keep their focus on innovation.
• LCD Access Control Panel has a chassis-front interaction
giving your customers full control of the platform.
• Dell’s latest XL program oers enhanced predictability around
your hardware configurations, so that you can better control
your resources and manage your product lifecycles.
PowerEdge R720t
Carrier Grade
Service and support
Bring your game-changing innovations to market fast with
our services, including design, manufacture, fulfillment and
global support. We’ll help you refine a product or design
new products with the right services, so you can focus
on your IP. Choose from services that can help you:
• Rebrand or custom-design Dell hardware, from the BIOS to
the branding of product, packaging and support documents.
• Conduct applications testing on our hardware.
• Integrate hardware, image, applications, peripheral
and documents as your systems are built.
• Consolidate, stage, deliver and support your orders globally.
• Provide your customers with the support they need, anything,
anywhere with more than 30,000 Dell employees in tech
support, parts and field services in more than 100 countries.
• NEBS Level 3 and ETSI certied
• Tier 1 class hardware with
OEM-specic features
• Comprehensive, global
service and support
Page 2
Feature PowerEdge R720 t Compliant Components
Form Factor 2U rack
Chassis for up to sixteen 2.5” hard drives
Processors 95W Intel® Xeon®
E5-2600 series processors:
• Intel® Xeon® E5-2650 processor
• Intel® Xeon® E5-2640 processor
• Intel® Xeon® E5-2620 processor
• Intel® Xeon® E5-2603 processor
• Intel® Xeon® E5-2650 v2 processor
• Intel® Xeon® E5-2640 v2 processor
• Intel® Xeon® E5-2620 v2 processor
• Intel® Xeon® E5-2609 v2 processor
Processor Sockets 2
Internal Interconnect 2 x Intel® QuickPath Interconnect (QPI) links: 6.4GT/s; 7.2GT/s; 8.0GT/s
Cache 2.5MB per core; core options: 4, 6, 8
Chipset Intel® C600
Memory
*
Up to 384GB (24 DIMM slots); 4GB/8GB/16GB DDR3 RDIMM LV up to 1600MT/s
I/O Slots 7 PCIe slots:
• One x16 full-length, full-height
• Three x8 full-length, full-height
• Three x8 half-length, half-height
Communication Options NICs:
Broadcom 5719 QP 1Gb
Broadcom 5720 DP 1Gb
Intel Ethernet I350 QP 1Gb
Intel Ethernet X540 DP 10GBASE-T
Intel X520 DP 10Gb DA/SFP+
Qlogic 10GB Dual Port SFP
CNAs:
Broadcom 57810 DP 10Gb DA/SFP+
Brocade 1020 Dual-Port 10 Gbps FCoE
HBAs:
Brocade 815/825 SP/DP 8 Gbps FC
Emulex LPE 12000/12002 Single/Dual Channel 8Gb, Optical, PCIe
Qlogic 2560/2562 Single/Dual Channel 8Gb Optical FC PCIe
QLogic QLE2462, Dual Channel, 4 Gbps, Optical, FC, PCIe
RAID Controller Internal:
PERC H310
External HBAs (RAID):
PERC H810
PERC H710
PERC H710p
Drive Bays Up to sixteen 2.5” drives
Peripheral bay option: Slim optical drive bay with choice of DVD + RW
Maximum Internal Storage
Hard Drive Options
*
19.2TB
*
15,000 RPM SAS drives (146GB, 300GB)
10,000 RPM SAS drives (300GB, 600GB, 900GB, 1.2TB)
7,200 RPM Near-line SAS drives (500GB, 1TB)
SAS SSD (200GB, 400GB)
SATA SSD (200GB, 400GB, 800GB)
Self-Encrypting Drives available
Embedded NIC Broadcom 57800S Dual Port 10GbE SFP+
with 2 x 1GbE (TOE and iSCSI ooad available on 10GbE ports)
Power Supply Ecient redundant hot swap 1100W DC or 1100W AC power supplies
Remote Management iDRAC7 with Lifecycle Controller
iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option)
8GB vFlash media (upgrade option), 16GB vFlash media (upgrade option)
Rack Support ReadyRails™ Sliding Rails or 2/4-Post Static Rails
Learn more at Dell.com/OEM
