Page 1
Dell PowerEdge Express Flash NVMe PCIe SSD
Adapter
User’s Guide
Page 2
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2017 - 04
Rev. A03
Page 3
Contents
1 Overview........................................................................................................................................................5
PCIe interface.....................................................................................................................................................................5
NVMe PCIe SSD adapter features.................................................................................................................................. 5
Device health................................................................................................................................................................5
Self-Monitoring Analysis and Reporting Technology............................................................................................... 5
Remaining rated write endurance.............................................................................................................................. 6
Device write status...................................................................................................................................................... 6
Supported operating systems for NVMe PCIe SSD .....................................................................................................6
2 Technical specications................................................................................................................................. 7
3 Getting started with NVMe PCIe SSD........................................................................................................... 9
Conguring NVMe PCIe SSD adapter in dierent operating systems........................................................................ 9
4 Replacing and conguring hardware for NVMe PCIe SSD adapter............................................................... 10
Removing NVMe PCIe SSD adapter from system.......................................................................................................10
Installing NVMe PCIe SSD adapter in system................................................................................................................11
5 Driver installation......................................................................................................................................... 12
Downloading NVMe PCIe SSD drivers...........................................................................................................................12
Installing or upgrading NVMe PCIe SSD driver for Microsoft Windows Server 2008 R2 SP1, 2012, 2012
R2, and 2016......................................................................................................................................................................12
Installing or upgrading NVMe PCIe SSD driver for Red Hat Enterprise Linux or SUSE Linux Enterprise
Server.................................................................................................................................................................................13
Installing or upgrading NVMe PCIe SSD driver for VMware.......................................................................................14
6 Conguring and managing your NVMe PCIe SSD adapter............................................................................16
OpenManage Server Administrator................................................................................................................................16
Storage information....................................................................................................................................................16
Congure and manage NVMe PCIe SSD adapter.................................................................................................. 16
Running physical device tasks...................................................................................................................................17
NVMe PCIe SSD adapter available tasks.................................................................................................................17
Performing cryptographic erase task for NVMe PCIe SSD.................................................................................. 18
Exporting the log........................................................................................................................................................ 18
Human Interface Infrastructure conguration utility.................................................................................................... 18
Entering the HII conguration utility.........................................................................................................................19
Viewing physical device properties...........................................................................................................................19
Erasing physical devices............................................................................................................................................ 19
Exporting the log........................................................................................................................................................ 19
Exiting the HII conguration utility...........................................................................................................................20
7 Troubleshooting............................................................................................................................................ 21
Contents
3
Page 4
Self-Monitoring Analysis and Reporting Technology errors.........................................................................................21
Ungraceful system shutdown or power loss................................................................................................................. 21
General errors....................................................................................................................................................................21
NVMe PCIe SSD description is truncated...............................................................................................................21
Software RAID array created by using PCIe SSDs is not detected after SLES 11 is rebooted.........................22
NVMe PCIe SSD is not displayed in device management in operating system................................................. 22
Cannot update rmware by using Dell Update Package (DUP).......................................................................... 22
Linux fails to boot and prompts for the root password......................................................................................... 22
I/O device error on write to NVMe PCIe SSD....................................................................................................... 22
NVMe PCIe SSD performance measurement not optimal................................................................................... 23
In Windows Server, OpenManage Server Administrator does not detect PCIe NVMe devices......................23
Windows event ID 11 error reported in Windows event log.................................................................................. 24
System is unable to inventory or manage NVMe PCIe SSDs from HII utility..................................................... 24
8 Getting help.................................................................................................................................................25
Contacting Dell.................................................................................................................................................................25
Documentation matrix.....................................................................................................................................................25
Documentation feedback................................................................................................................................................26
Locating your system Service Tag.................................................................................................................................26
4 Contents
Page 5
Overview
The PowerEdge Express Flash Non-Volatile Memory Express (NVMe) Peripheral Component Interconnect Express (PCIe) Solid State
Device (SSD) Adapter is a high-performance storage device designed for solutions requiring low latency, high I/O operations per second
(IOPS), and enterprise class storage reliability and serviceability. The NVMe PCIe SSDs oer a Multi-Level Cell (MLC) or Triple-Level Cell
(TLC) NAND ash technology with a high-speed PCIe 3.0 compliant interface. The high-speed PCIe 3.0 compliant interface helps improve
performance for I/O bound solutions.
NVMe is the standardized, high-performance host controller interface that uses SSD on a PCI Express bus (PCIe SSDs).
NVMe PCIe SSD adapters are available on selected PowerEdge systems from SM1715, PM1725, and PM1725a in varying capacities.
Topics:
• PCIe interface
• NVMe PCIe SSD adapter features
• Supported operating systems for NVMe PCIe SSD
PCIe interface
1
The SSD controller used on the NVMe PCIe SSD has a PCIe Generation 3 (8 GT/s) interface. The interface is a PCIe x4 lane width for a 16channel ash memory controller, and is used to transmit or receive storage interface commands between the host and the NVMe PCIe
SSD.
NVMe PCIe SSD adapter features
The following sections describe the dierent features of the NVMe PCIe SSD Adapter.
Device health
The NVMe PCIe SSD design is based on NAND ash technology. NAND SSDs have a nite number of program or erase cycles and a nite
number of spare blocks (replacements for other worn or faulty NAND blocks).
The program erase cycles and spare blocks are continuously monitored for each NVMe PCIe SSD through various software management
applications. For more information, see Conguring and managing your NVMe PCIe SSD adapter.
Self-Monitoring Analysis and Reporting Technology
The Self-Monitoring Analysis and Reporting Technology (SMART) feature set minimizes unscheduled system downtime by providing a
method of early detection of device degradation or fault conditions. By monitoring and storing critical performance and calibration
parameters, the SMART feature set attempts to predict degradation or fault conditions. Awareness of a negative reliability condition allows
the host system to warn you of an impending risk of device failure and advise on appropriate action.
Overview 5
Page 6
Remaining rated write endurance
NAND SSDs have a nite number of program erase cycles. The NVMe PCIe SSD is warranted to a maximum amount of data written to the
device in total bytes written. The NVMe PCIe SSD self monitors for these limits, and software management applications notify you when
you reach these limits.
NOTE: If you continue to write to the device after it reaches the threshold of total bytes written, the amount of time the NVMe
PCIe SSD retains data while powered o decreases below device specications. For more information, see Technical
specications.
Device write status
NAND SSDs have a nite number of spare sectors. If the device exhausts the available spare sectors, the NVMe PCIe SSD enters Write
Protect (Read-Only) mode. In Write Protect mode, you can only perform read operations to the device. The NVMe PCIe SSD self-
monitors for these limits, and software management applications notify you when you reach these limits.
Supported operating systems for NVMe PCIe SSD
NOTE: For all operating system documents, see Dell.com/operatingsystemmanuals.
Only the following operating systems support the NVMe PCIe SSD devices:
• Microsoft Windows Server 2008 R2 SP1 (x64/EM64T) or later
• Microsoft Windows Server 2012 (x64/EM64T)
• Microsoft Windows Server 2012 R2
• Microsoft Windows Server 2016
• Red Hat Enterprise Linux 6.4 (x64/EM64T) or later
• Red Hat Enterprise Linux 7.0 or later
• SUSE Linux Enterprise Server 11 SP3 or later
• SUSE Linux Enterprise Server 12 or later
• VMware ESXi 5.5
• VMware ESXi 6.0 or later
6
Overview
Page 7
Technical specications
NOTE: The specications provided are for information purposes only and do not constitute an extension of Dell's warranty for
this product.
Table 1. Technical specications
Features Description
NAND type Multi-Level Cell (SM1715)
Triple-Level Cell (PM1725/PM1725a)
Hot swappable No
Embedded data protection enabled Yes
Device write cache Yes
Bootable device No
Self-monitoring enabled Yes
Oine data retention Up to three months after total bytes written reaches 100%
2
General
Model SM1715 adapter
PM1725 adapter
PM1725a adapter
Device protocol NVMe
NVMe standard 1.0 (SM1715)
1.1 (PM1725)
1.2 (PM1725a)
Bus protocol PCIe
Bus protocol version 3.0
Bus Link Width
Physical Dimensions
Height Max. 18.71 mm
Width Max. 69.85 mm
Length Max. 167.65 mm
x4 (SM1715)
x8 (PM1725/PM1725a)
Device Capacity
Technical specications 7
Page 8
Un-formatted capacity
1.6 TB, 3.2 TB, and 6.4 TB
User-addressable sectors
Bytes per sector 512 Bytes
Rated Write Endurance (TBW) for SM1715 family 1.6 TB: 29.2 PB (10 DWPD)
Rated Write Endurance (TBW) for PM1725 and
PM1725a families
Environment
Operating temperature 0°C to 55°C
Shock 1500 G/0.5 ms
Vibration 10 HZ – 2000 Hz at 20 G
Power Requirements
Active power 25 W (FW Limit)
1.6 TB: 3,125,627,568 LBAs
3.2 TB: 6,251,233,968 LBAs
6.4 TB: 12,502,446,768 LBAs
3.2 TB: 58.4 PB (10 DWPD)
1.6 GB: 14.6 PB (5 DWPD)
3.2 TB: 29.2 PB (5 DWPD)
6.4 TB: 58.4 PB (5 DWPD)
Electrical characteristics
Voltage input 3.3 V and 12 V
8
Technical specications
Page 9
3
Getting started with NVMe PCIe SSD
The NVMe PCIe SSD adapters you ordered with your system are ready for use. For more information, see Conguring NVMe PCIe SSD
adapter in dierent operating systems, or see Conguring and managing your NVMe PCIe SSD adapter.
Conguring NVMe PCIe SSD adapter in dierent
operating systems
In Windows-based systems, the NVMe PCIe SSDs have a controller entity and a device entity. The controller entity is displayed under the
Storage controller menu in the Device Manager.
Use the controller entity when installing or updating the NVMe PCIe SSD driver. You can congure the NVMe PCIe SSD for use on
Windows from Computer Management > Storage > Disk Management Tool.
On Linux-based systems, you can congure the NVMe PCIe SSD from the partitioning tool by specifying or selecting the device name. The
device name for NVMe PCIe SSDs is /dev/nvmeXn1, where X is the number corresponding to each NVMe PCIe SSD in the system (For
example: /dev/nvme0n1; /dev/nvme1n1; /dev/nvme2n1 and so on).
Use OpenManage Server Administrator for managing and performing NVMe PCIe SSD-related tasks. For more information, see Conguring
and managing your NVMe PCIe SSD adapter.
In VMware systems, you can congure the NVMe PCIe SSD as datastore or for a passthrough operation. You can use vSphere Client to
congure the NVMe PCIe SSD. Conguring PCIe devices as passthrough is not recommended due to the following limitations:
• You cannot take snapshots of the Virtual Machine (VM).
• Your VM cannot use failover features such as VMotion and Distributed Resources Scheduler (DRS).
• You cannot hot-add any other device to the VM such as a USB key. To add an additional device, rst shut down the VM.
Conguring NVMe PCIe SSD as passthrough is not recommended outside of Dell-specic solutions. See the solution-specic
documentation at Dell.com/support/manuals.
Getting started with NVMe PCIe SSD 9
Page 10
Replacing and conguring hardware for NVMe
PCIe SSD adapter
CAUTION: All work must be performed at an electrostatic discharge (ESD)-safe workstation to meet the EIA-625-requirements
for handling electrostatic discharge sensitive devices. All actions must be performed following the latest revisions of the IPCA-610 ESD recommended practices.
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage
due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came
with the product.
NOTE: For complete information on U.S. Terms and Conditions of Sale, Limited Warranties and Returns, Export Regulations,
Software License Agreement, Safety, Environmental and Ergonomic Instructions, Regulatory Notices, and Recycling Information,
see the Safety, Environmental and Regulatory Information, End User License Agreement, and Warranty and Support Information
that shipped with your system.
The NVMe PCIe SSD adapter is directly connected to the system board.
NOTE
: For information on removing and installing system components, see the system specic Owner's Manual at Dell.com/
support/manuals.
4
Topics:
• Removing NVMe PCIe SSD adapter from system
• Installing NVMe PCIe SSD adapter in system
Removing NVMe PCIe SSD adapter from system
CAUTION
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage
due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came
with the product.
1 Turn o the system, including any attached peripherals, and disconnect the system from the electrical outlet and peripherals.
2 Open the system.
3 Locate the adapter on the system board.
4 Lift the adapter to remove it from the system board.
5 Close the system.
6 Reconnect the system to its electrical outlet and peripherals, and turn on the system.
: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
NOTE
: Dell recommends that you always use a static mat and static strap while working on components in the interior
of the system.
CAUTION
: To prevent damage to the adapter, hold the adapter by its edges only.
10 Replacing and conguring hardware for NVMe PCIe SSD adapter
Page 11
Installing NVMe PCIe SSD adapter in system
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage
due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came
with the product.
NOTE: To determine which PCIe slot and which size of bracket to use, consult the slot priority matrix in your server Owner’s
Manual. Following the slot priority matrix ensures that the optimal PCIe slot is selected to maximize performance.
1 Turn o the system, including any attached peripherals, and disconnect the system from the electrical outlet.
NOTE: Dell recommends that you always use a static mat and static strap while working on components in the interior
of the system.
2 Open the system.
CAUTION: To prevent damage to the adapter, you must hold the adapter by its edges only.
3 Determine which bracket, half height or full height, is required, and install the appropriate bracket.
4 Align the card-edge connector with the connector on the system board.
5 Press the card edge down until the adapter is fully seated.
6 Close the system.
7 Reconnect the system to its electrical outlet and attached peripherals, and turn on the system.
Replacing and
conguring hardware for NVMe PCIe SSD adapter 11
Page 12
Driver installation
For the current list of operating systems supported by NVMe PCIe SSD, see Supported operating systems for NVMe PCIe SSD .
Topics:
• Downloading NVMe PCIe SSD drivers
• Installing or upgrading NVMe PCIe SSD driver for Microsoft Windows Server 2008 R2 SP1, 2012, 2012 R2, and 2016
• Installing or upgrading NVMe PCIe SSD driver for Red Hat Enterprise Linux or SUSE Linux Enterprise Server
• Installing or upgrading NVMe PCIe SSD driver for VMware
Downloading NVMe PCIe SSD drivers
To download NVMe PCIe SSD drivers:
1 Go to Dell.com/support.
2 Specify a Service Tag or express service code in the Enter a Service Tag or Express Service Code eld or in the Browse for a
product option click the View products drop-down.
3 Select Servers, Storage, & Networking.
4 Select PowerEdge.
5 Select your system.
The drivers that are applicable to your selection are displayed.
6 Select Drivers and Downloads.
7 Select Solid State Storage.
The NVMe PCIe SSD drivers that are applicable to your system are displayed.
From the available list, download the latest NVMe PCIe SSD drivers to a USB drive, CD, or DVD.
5
Installing or upgrading NVMe PCIe SSD driver for Microsoft Windows Server 2008 R2 SP1, 2012, 2012 R2, and 2016
: For a complete list of supported operating systems, see Supported operating systems for NVMe PCIe SSD .
NOTE
NOTE: Use the procedures in this section to install or upgrade the driver for Windows. The driver is updated frequently. To
ensure that you have the current version of the driver, download the latest Windows driver from Dell.com/support. For more
information, see Downloading NVMe PCIe SSD drivers.
NOTE: Close all applications on your system before you update the driver.
NOTE: Windows Server 2012 R2 contains an in-box NVMe driver; however Dell requires updating to the latest driver to ensure
full Express Flash NVMe PCIe SSD support.
NOTE: Windows Server 2016 contains an in-box NVMe driver fully supported by Dell. However, we still recommend you to check
Dell.com/support for the latest driver updates.
To install or upgrade the NVMe PCIe SSD driver for Windows Server using Dell Update Package (DUP):
12 Driver installation
Page 13
1 Insert the media containing the latest driver that you downloaded from Dell.com/support/drivers.
2 Double-click the executable and follow the on-screen instructions to install the NVMe PCIe SSD driver using DUP.
NOTE: Dell provides the DUP to update drivers on systems running 2008 R2 SP1, Windows Server 2012, Windows Server 2012
R2, and Windows Server 2016 operating systems. DUP is an executable application that updates drivers for specic devices.
DUP supports command line interface and silent execution. For more information, see the driver release notes at Dell.com/
support/drivers .
When DUPs are not used to upgrade the driver, follow the instructions below:
1 Insert the media containing the latest driver that you downloaded in Downloading NVMe PCIe SSD drivers.
Click Start > Control Panel > System and Security.
2
3 Select Device Manager under the System option.
The Device Manager screen is displayed.
4 Double-click the entry to expand the Storage controllers. Alternatively, you can click the plus symbol next to the Storage controllers.
For example, a 3.2 TB NVMe PCIe SSD device is displayed as Dell Express Flash NVMe PM1725 3.2TB.
NOTE: If there is no NVMe PCIe SSD driver installed, the NVMe PCIe device is listed under the Other devices option. In
this case, the NVMe PCIe device is displayed as PCIe device.
5 Double-click the NVMe PCIe device for which you want to install or update the driver.
6 Click the Driver tab, and click Update Driver.
The Update Device Driver screen is displayed.
7 Select Browse my computer for driver software.
8 Select Let me pick from a list of device drivers on my computer.
9 Select Have Disk.
10 Follow the steps in the wizard, and browse to the location of the driver les.
11 Select the INF le from the driver media.
12 Click OK to exit the wizard.
13 Click Next.
NOTE
: If there is more than one NVMe PCIe SSD in the system, repeat steps 4–13 for all remaining devices in the
system.
14 Restart the system for the changes to take eect.
NOTE
: Dell does not recommend loading the drivers from Windows Server 2012 R2 or other older Windows versions in
Windows Server 2016.
Installing or upgrading NVMe PCIe SSD driver for Red Hat Enterprise Linux or SUSE Linux Enterprise Server
: For a complete list of supported operating systems, see Supported operating systems for NVMe PCIe SSD .
NOTE
NOTE: Use the procedures in this section to install or upgrade the driver for Linux. The driver is updated frequently. To ensure
that you have the current version of the driver, download the latest Linux driver from Dell.com/support. For more information,
see Downloading NVMe PCIe SSD drivers.
NOTE: Starting with RHEL 7.2 and SLES 12 SP1, there is a fully supported in-box driver. Earlier operating systems that may have
an in-box driver are not supported. Dell recommends that you download the latest drivers from Dell.com/support. For more
information, see Downloading NVMe PCIe SSD drivers.
Driver installation 13
Page 14
SUSE Linux Enterprise Server 11 and 12 drivers are provided in the Kernel Module Package (KMP) format while Red Hat Enterprise Linux 6
drivers are provided in the Kernel Module Loader (KMOD) format. KMODs are Red Hat Packet Manager (RPM)s and are driver packaging
methods that contain kernel modules, instituted to better handle kernel update situations. To install or update the NVMe PCIe SSD driver:
1 For SLES, download the SUSE GPG Public key from the SUSE website and import by using the command #rpm –import <GPG
public key>.
2 Uncompress the zipped tarball driver release package.
3 Install the driver package using the command: rpm -ihv < driver rpm package name >.rpm
NOTE: Use rpm -Uvh <package name> when updating an existing package.
4 Restart the system for the driver update to take eect.
5 After the system restarts, verify that the driver has been installed with the system command: # modinfo nvme
The version shown in the output must match with the version of the package.
6 Verify that the driver has been loaded with the system command:# lsmod | grep nvme or # cat /proc/modules | grep
nvme
These commands return nvme if the driver is loaded.
The NVMe PCIe SSDs are ready for use. See Conguring NVMe PCIe SSD adapter in dierent operating systems.
Installing or upgrading NVMe PCIe SSD driver for VMware
: For a complete list of supported operating systems, see Supported operating systems for NVMe PCIe SSD .
NOTE
NOTE: Use the procedures in this section to install or upgrade the driver for VMware ESXi 5.5. To ensure that you have the
current version of the driver, download the latest VMware ESXi 5.5 driver from Dell.com/support. For more information, see
Downloading NVMe PCIe SSD drivers.
NOTE: VMware ESXi 5.5 U3 and later contains an in-box driver. Dell recommends that you to go to VMware’s download site for
the latest NVMe driver and follow the documentation provided there for installation instructions.
1 Transfer the NVMe PCIe SSD driver to the ESXi host using either vSphere Client Browse Datastore or an SFTP/FTP/SCP client.
Using the vSphere Client:
a Navigate to the conguration.
b Select Storage from the hardware section.
c Right-click Datastore, and then select Browse.
d Upload the PCIe SSD driver to the datastore.
Using an SFTP/FTP/SCP client:
a Launch the SFTP/FTP/SCP program.
b Extract the driver les from the *.zip le.
c Copy the PCIe SSD driver le to a local folder on the host.
2 Power o all VMs running inside the ESXi host operating system.
3 Enable the ESXi shell service.
Using the vSphere client:
a Navigate to the Conguration tab of the host IP.
b Click Software > Security Prole.
c Click Services > ESXi Shell > Properties.
d Start the ESXi shell service.
Directly from the host settings:
a Press <F2> to customize system settings.
14
Driver installation
Page 15
b Enter your user name and password.
c Navigate to the troubleshooting options.
d Enable the ESXi shell.
e Enable SSH.
4 Install the NVMe PCIe SSD driver on the ESXi host.
a Navigate to the datastore volume or le directory that contains the NVMe PCIe SSD driver, and run the following command:
esxcli software vib install /<complete_path_to_offline_driver>.
b Reboot the ESXi host.
5 Ensure that the driver has been correctly installed by running the following command: esxcli software vib list | grep
nvme.
6 Using vSphere, place the ESXi host in maintenance mode and reboot the host.
7 Once the host reboots and is running, take the host out of maintenance mode.
Driver installation 15
Page 16
6
Conguring and managing your NVMe PCIe SSD
adapter
The storage management applications discussed in the following topics enable you to manage and congure the NVMe PCIe SSD Adapter.
These applications also allow you to control and monitor multiple NVMe PCIe SSDs, and provide online maintenance.
The NVMe PCIe SSD solution supports Unied Extensible Firmware Interface (UEFI) and Human Interface Infrastructure (HII) for preoperating system device management, OpenManage Server Administrator (OMSA) application for operating system device management,
and Integrated Dell Remote Access Controller (iDRAC) with Lifecycle Controller for local or remote device management. The NVMe PCIe
SSD solution supports UEFI, HII and iDRAC with Lifecycle Controller management on select PowerEdge systems only. OMSA for NVMe
PCIe SSD device management is available on all supported PowerEdge systems.
NOTE: For more information about iDRAC/LC remote management, check your platform Owner’s Manual.
Topics:
• OpenManage Server Administrator
• Human Interface Infrastructure conguration utility
OpenManage Server Administrator
The OpenManage Server Administrator is a storage management application that provides features for managing components of the
NVMe PCIe SSD solution on supported operating systems. The OpenManage Server Administrator application enables you to perform the
NVMe PCIe SSD functions from a single graphical or command-line interface. For more information, see the OpenManage Server
Administrator online help accessible from the application.
All storage management features for the NVMe PCIe SSD solution are accessible by selecting the Storage object, and then the PCIe SSD
Subsystem in the Server Administrator tree view.
Storage information
To access Storage Information:
1 Expand the Storage tree object to display the storage component objects.
2 Expand the PCIe SSD Subsystem tree object.
The Storage Information window is displayed under Information/Conguration.
3 To make changes to the Storage Information properties, click Properties.
Congure and manage NVMe PCIe SSD adapter
Use the Physical Device Properties screen to view information about NVMe PCIe SSD Adapter and to run NVMe PCIe SSD Adapter
tasks.
To view the complete set of NVMe PCIe SSD properties, select Full View from the Options taskbar. Physical device properties are
described below:
16 Conguring and managing your NVMe PCIe SSD adapter
Page 17
Name Displays the name of the NVMe PCIe SSD. The name includes the slot ID in which the NVMe PCIe SSD Adapter is
installed.
State Displays the current state of the NVMe PCIe SSD Adapter.
Bus Protocol Displays the technology that the NVMe PCIe SSD Adapter is using.
Device Name In Windows: \\.\PhysicalDriveX.
In Linux: /dev/nvmeXn1.
Media Displays the media type of the physical SSD.
Remaining Rated
Write Endurance
Firmware Revision Displays the currently running rmware version on the NVMe PCIe SSD.
Driver Version Displays the currently running driver version of the NVMe PCIe SSD.
Model Number Displays the Piece Part Identication (PPID) of the NVMe PCIe SSD.
Capacity Displays the full capacity of the device.
Form Factor Displays the form factor of the NVMe PCIe SSD installed in the system.
Vendor ID Displays the hardware vendor of the device.
Product ID Displays the product ID of the device.
Serial No. Displays the serial number of the device.
PCIe Negotiated
Link Speed
PCIe Maximum Link
Speed
PCIe Maximum Link
Width
Form Factor Displays the form factor of the NVMe PCIe SSD installed in the system.
Displays the warranted wear out level of the NVMe PCIe SSD (in percentage).
Displays the speed of data transfer that the device negotiated upon initial communication. This speed depends the
speed of the device.
Displays the highest possible speed at which the device can transfer data.
Displays the link width of the device.
Running physical device tasks
1 Expand the Storage tree object to display the storage component objects.
2 Expand the PCIe SSD Subsystem object.
3 Select PCIe SSD in slot X.
4 Select a task from the Available Tasks drop-down menu.
5 Click Execute.
NVMe PCIe SSD adapter available tasks
The following are in the NVMe PCIe SSD adapter drop-down menu:
• Cryptographic Erase
• Export Log
Conguring
and managing your NVMe PCIe SSD adapter 17
Page 18
Performing cryptographic erase task for NVMe PCIe SSD
CAUTION: Performing a cryptographic erase on an NVMe PCIe SSD results in permanent loss of all data on the NVMe PCIe SSD.
NOTE: During cryptographic erase, the host is not able to access the NVMe PCIe SSD.
1 Expand the Storage tree object to display the storage component objects.
a On Linux platforms, unmount any le systems mounted on the device.
2 Expand the PCIe SSD Subsystem object.
3 Select the PCIe SSD in slot X.
4 Select the Cryptographic Erase task from the Available Tasks drop-down menu.
5 Click Execute.
The following caution message is displayed: "When you perform the Cryptographic Erase operation, any data
on the disk will be lost permanently. Are you sure you want to continue?"
6 Select Cryptographic Erase to proceed.
A pop-up message is displayed: Are you sure you want to perform ‘Cryptographic Erase’ on this physical device?
7 Click OK to proceed, or select Go Back to previous page to cancel the operation.
Exporting the log
1 Expand the Storage tree object to display the storage components.
2 Expand the PCIe SSD Subsystem object.
3 Select PCIe SSD in slot X.
4 Select the Export Log task from the Available Tasks drop-down menu.
5 Click Execute.
6 Note where the log le will be exported.
7 Click Export Log and follow the instructions to complete.
Human Interface Infrastructure conguration utility
The Human Interface Infrastructure (HII) conguration utility is a standardized way of viewing and setting a device conguration. The HII
conguration utility provides pre-operating system functionality and management for NVMe PCIe SSDs including:
• Viewing physical device properties
• Running physical device operations
• Retrieving debug information
NOTE
: HII is only available starting on select Dell 13th generation PowerEdge systems.
NOTE: Do not insert or remove an NVMe PCIe SSD from the HII conguration
utility.
18 Conguring and managing your NVMe PCIe SSD adapter
Page 19
Entering the HII conguration utility
To enter the HII conguration utility:
1 Turn on the system.
2 Press F2 during system startup to enter the system setup.
3 Navigate to the Device Settings option.
Select the desired NVMe PCIe SSD to view its HII conguration page. Each device includes an entry such as: PCIe SSD in Slot
4
X: Dell NVMe PCIe SSD Configuration Data.
Viewing physical device properties
Follow the steps to view physical device properties:
1 Select View Physical Device Properties in the HII conguration utility.
2 Press Esc to return to the previous screen.
3 To exit the PCIe SSD HII conguration utility, click Exit in the top-right corner of the System Setup menu.
Erasing physical devices
CAUTION
NOTE: During a cryptographic erase, the host cannot access the NVMe PCIe SSD.
NOTE: If the system reboots or experiences a power loss during a cryptographic erase, the operation aborts. Reboot the system
and restart the process.
NOTE: The cryptographic erase operation takes a few seconds to complete. While this operation is in progress, you cannot
navigate away from this page.
To perform a cryptographic erase on an NVMe PCIe SSD from the HII conguration utility, do the following:
1 Navigate to the Select Physical Device Operations menu of the HII conguration utility.
2 Select Cryptographic Erase.
The following warning message displays: Performing a cryptographic erase results in permanent loss of all
data on the device. Do you want to continue?
You can select Yes or No.
3 Press Esc to return to the previous screen.
4 To exit the HII conguration utility, click Exit in the top-right corner of the System Setup menu.
: Performing a cryptographic erase on an NVMe PCIe SSD results in permanent loss of all data on the NVMe PCIe SSD.
.
Exporting the log
The Export Log option exports the NVMe PCIe SSD log to a text le. The log contains debug information of the NVMe PCIe SSD which
can be useful while troubleshooting.
NOTE
: To save the log, you need a writable media with a UEFI-compatible le system attached to the
system.
NOTE: If there are no application devices inserted into the system when entering the Export Log HII screen, then the only option
is to return to the previous page.
Conguring and managing your NVMe PCIe SSD adapter 19
Page 20
To export the NVMe PCIe SSD log from the HII conguration utility, do the following:
1 Navigate to the Export Log menu of the HII conguration utility.
2 Select the le system device to which the log will be exported.
3 Select the directory into which you want to save the log.
4 Enter the le name under which you want to save the log in the File Name text box.
For example, NVMe.log.
5 Click Export and follow the instructions to complete.
6 To exit the HII conguration utility, click Exit in the top-right corner of the System Setup menu.
Exiting the HII conguration utility
NOTE: Clicking Exit in any HII page takes you back to the System Setup main menu.
NOTE: Press Esc from any HII page to return to the previous page.
To exit the HII conguration utility, click Exit in the top-right corner of the System Setup menu.
20 Conguring and managing your NVMe PCIe SSD adapter
Page 21
7
Troubleshooting
NOTE: To get help for your NVMe PCIe SSD, see Contacting Dell.
Topics:
• Self-Monitoring Analysis and Reporting Technology errors
• Ungraceful system shutdown or power loss
• General errors
Self-Monitoring Analysis and Reporting Technology errors
The NVMe PCIe SSD solution is always monitored for errors by its internal software. If an error occurs, it is detected and recorded in an
internal log. Based on the criticality of the error, the software may inform the host server that further action is needed. It signies that the
error condition occurred a specic number of times and that the device health needs attention.
Ungraceful system shutdown or power loss
If the host system experiences a power loss, the NVMe PCIe SSD may not have time to perform its internal shut down procedure. In such
an event, the device may enter a recovery mode.
This recovery process is also known as rebuilding. During rebuilding, there is very limited access from the host operating system. After the
recovery procedure is complete, the device is fully accessible from the host operating system.
NOTE
: Dell recommends that you use power backup solutions for all Dell systems.
General errors
The following section describes general errors related to NVMe PCIe SSD.
NVMe PCIe SSD description is truncated
Description
Cause In Windows 2012 R2 , there is a new ag STOR_FEATURE_DEVICE_NAME_NO_SUFFIX that removes the
In Windows 2012 R2 , the device description is truncated from the Device Manager > Disk Drives view. For
example, you see NVMe Dell Express Flash or NVMe Dell Express Fla SCSI Disk Device instead of NVMe Dell
Express Flash SCSI Disk Device.
suffix in the device friendly name. This is only seen in Windows 2012 R2 and this ag is enabled by design of the
Windows
name truncated intermittently.
2012 R2 in-box driver. The Dell-provided NVMe driver uses the correct ag, but you may see the device
Solution This is a known issue and the message can be ignored.
Troubleshooting 21
Page 22
Software RAID array created by using PCIe SSDs is not detected after SLES 11 is rebooted
Cause The boot.md service is not started during RAID creation. The boot.md service must be enabled for the init process
to start the MD-RAID device.
Solution Run the command # chkconfig boot.md to verify if the boot.md service is on or o. This command should
start the boot.md service. If it does not, run the command# chkconfig boot.md on to enable it.
NVMe PCIe SSD is not displayed in device management in operating system
Cause The device driver is not installed.
Solution For more information, see Driver Installation section in this manual.
Cannot update rmware by using Dell Update Package (DUP)
Cause
Solution Before you update the device rmware using DUP, ensure that the required device driver for the operating system
The supported device driver for the operating system available on your system, is not installed or loaded.
available on your system is installed. For more information, see the Driver Installation section.
Linux fails to boot and prompts for the root password
Cause
Solution Perform the following steps to recover from this situation:
A stale volume mount point is still present after a device removal or cryptographic erase.
1 Enter the root password to enter maintenance mode.
2 Remount the root lesystem as read-write using the following command: mount -orw,remount/.
3 Manually edit /etc/fstab to remove the nonexistent device entry.
I/O device error on write to NVMe PCIe SSD
Description
Windows event log may report the following entries on the rst write attempt to an NVMe PCIe SSD: Event ID
7: The device, \Device\Harddisk\DRX, has a bad block.
When attempting to initialize the device using Computer Management > Storage > Disk Management, the
following message is displayed: Virtual Disk Manager, Data Error (cyclic redundancy
check).
22 Troubleshooting
Page 23
Linux messages log may report the following entries on a write attempt to an NVMe PCIe SSD:
• Buffer I/O error on device nvmeXn1, logical block Y (where X is the number
corresponding to the device and Y is the logical block)
• nvmeXn1: unable to read partition table (where X is the number corresponding
to the device)
Cause NVMe PCIe SSDs have a nite number of write cycles. When an NVMe PCIe SSD exhausts the number of writes,
it goes into Write Protect (Read Only) mode.
Solution By using system management applications, you may check the NVMe PCIe SSD state to conrm if the NVMe PCIe
SSD is in Read-Only Mode. For further instructions, contact a Dell Technical Service representative.
NVMe PCIe SSD performance measurement not optimal
Description There are a number of factors that may alter the performance of an NVMe PCIe SSD. Dell recommends to take
basic setup measures to ensure performance optimization of these devices.
Cause NVMe PCIe SSD has not been preconditioned and/or BIOS settings are not optimal.
Solution
• Without preconditioning the NVMe PCIe SSD, performance measurements can be misleading as they may not
reect long-term performance of the device. Preconditioning enables ash management, which stabilizes data
throughput over a period. For the Solid-State Storage Performance Test Specication, see snia.org.
• Congure the server for low latency performance. To achieve maximum performance with NVMe PCIe SSDs,
change the server performance prole in the BIOS settings to Performance.
In Windows Server, OpenManage Server Administrator does not detect PCIe NVMe devices
In Windows Server 2012 R2
Description
Cause The operating system is using the in-box NVMe driver.
Solution Install the latest NVMe driver available on Dell.com/support.
In Windows Server 2016
Windows Server 2012 R2 contains an in-box NVMe driver that is not supported by OpenManage Server
Administrator.
Description
Cause The operating system is not using the in-box or required NVMe driver.
Solution Remove any NVMe drivers that is not specically released for the Windows Server 2016.
Windows Server 2016 contains an in-box NVMe driver that is supported by OpenManage Server Administrator.
Troubleshooting 23
Page 24
Windows event ID 11 error reported in Windows event log
Description Event ID 11 Error is reported in the Windows event log during each system boot.
Cause This issue exists in the in-box Windows NVMe driver.
Solution Install the latest NVMe driver available on Dell.com/support.
System is unable to inventory or manage NVMe PCIe SSDs from HII utility
Description NVMe PCIe SSDs are not discovered in the HII utility.
Cause HII support for NVMe PCIe SSDs was added on select 13th generation PowerEdge systems. There is no pre-OS
management for NVMe PCIe SSDs in previous PowerEdge servers.
Solution Use Dell's OpenManage Server Administrator to manage your NVMe PCIe SSD.
24 Troubleshooting
Page 25
Getting help
Contacting Dell
Dell provides several online and telephone based support and service options. If you do not have an active internet connection, you can nd
contact information about your purchase invoice, packing slip, bill, or Dell product catalog. Availability varies by country and product, and
some services may not be available in your area. To contact Dell for sales, technical assistance, or customer service issues:
1 Go to Dell.com/support.
2 Select your country from the drop-down menu on the lower right corner of the page.
3 For customized support:
a Enter your system Service Tag in the Enter your Service Tag eld.
b Click Submit.
The support page that lists the various support categories is displayed.
4 For general support:
a Select your product category.
b Select your product segment.
c Select your product.
The support page that lists the various support categories is displayed.
5 For contact details of Dell Global Technical Support:
a Click Global Technical Support.
b The Contact Technical Support page is displayed with details to call, chat, or e-mail the Dell Global Technical Support team.
8
Documentation matrix
The documentation matrix provides information on documents that you can refer to for setting up and managing your system.
Table 2. Documentation matrix
To... See the...
Install your system into a rack Rack documentation included with your rack solution
Set up your system and know the system technical specications Getting Started With Your System that shipped with your system or
see Dell.com/poweredgemanuals
Install the operating system Operating system documentation at Dell.com/
operatingsystemmanuals
Get an overview of the Dell Systems Management oerings Dell OpenManage Systems Management Overview Guide at
Dell.com/openmanagemanuals > OpenManage software
Congure and log in to iDRAC, set up managed and management
system, know the iDRAC features, and troubleshoot by using iDRAC
Know about the RACADM subcommands and supported RACADM
interfaces
Launch, enable, and disable Dell Lifecycle Controller, know the
features, use and troubleshoot Dell Lifecycle Controller
Integrated Dell Remote Access Controller User's Guide at Dell.com/
idracmanuals
RACADM Command Line Reference Guide for iDRAC at Dell.com/
idracmanuals
Dell Lifecycle Controller User’s Guide at Dell.com/idracmanuals
Getting help 25
Page 26
To... See the...
Use Dell Lifecycle Controller Remote Services Dell Lifecycle Controller Remote Services Quick Start Guide at
Dell.com/idracmanuals
Set up, use, and troubleshoot OpenManage Server Administrator Dell OpenManage Server Administrator User’s Guide at Dell.com/
openmanagemanuals > OpenManage Server Administrator
Install, use, and troubleshoot OpenManage Essentials Dell OpenManage Essentials User’s Guide at Dell.com/
openmanagemanuals > OpenManage Essentials
Know the features of the storage controller cards, deploy the cards,
and manage the storage subsystem
Check the event and error messages generated by the system
rmware and agents that monitor system components
Storage controller documentation at Dell.com/
storagecontrollermanuals
Dell Event and Error Messages Reference Guide at Dell.com/
openmanagemanuals > OpenManage software
Documentation feedback
Click the Feedback link in any of the Dell documentation pages, ll out the form, and click Submit to send your feedback.
Locating your system Service Tag
Your system is identied by a unique Express Service Code and Service Tag number. The Express Service Code and Service Tag are found
on the front of a physical DR Series system by pulling out the information tag. The service tag can also be found on the Support page in
the GUI. This information is used to route support calls to the appropriate personnel for resolution.
26
Getting help
Loading...
