Dell OpenManage
Server Administrator
Version 6.5
Messages Reference
Guide
Notes and Cautions
NOTE:
your computer.
CAUTION:
instructions are not followed.
____________________
Information in this document is subject to change without notice. © 2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, PowerEdge™, PowerVault™, and OpenManage™ are trademarks of Dell Inc. Microsoft trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat Enterprise Linux Inc. in the United States and/or other countries. Novell trademark of Novell Inc. in the United States and other countries. Oracle of Oracle Corporation and/or its affiliates. Citrix trademarks or trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware is registered trademarks or trademarks of VMWare, Inc. in the United States or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
A CAUTION indicates potential damage to hardware or loss of data if
®
, Windows®, and Windows Server® are either
®
and Enterprise Linux® are registered trademarks of Red Hat,
®
is a registered trademark and SUSE ™ is a
®
, Xen®, and XenServer® are either registered
®
is a registered trademark
®
January 2011

Contents

1 Introduction
What’s New in this Release
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
Messages Not Described in This Guide
Understanding Event Messages
Sample Event Message Text
Viewing Alerts and Event Messages
. . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . .
Logging Messages to a Unicode Text File
Viewing Events in Windows Server 2003 and Windows Server 2008
. . . . . . . . . . . . . . .
Viewing Events in Red Hat Enterprise Linux and SUSE Linux Enterprise Server
Viewing Events in VMware ESX/ESXi
Viewing the Event Information
. . . . . . . . . . .
Understanding the Event Description
2 Server Management Messages
Server Administrator General Messages
. . . . . . . . .
. . . . .
. . . . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . . .
7
8
8
8
10
10
11
12
12
13
13
14
19
19
Temperature Sensor Messages
Cooling Device Messages
Voltage Sensor Messages
Current Sensor Messages
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
Contents
22
26
29
32
3
Chassis Intrusion Messages
. . . . . . . . . . . . . .
35
Redundancy Unit Messages
Power Supply Messages
Memory Device Messages
Fan Enclosure Messages
AC Power Cord Messages
Hardware Log Sensor Messages
Processor Sensor Messages
Pluggable Device Messages
Battery Sensor Messages
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
Secure Digital (SD) Card Device Messages
Chassis Management Controller Messages
3 Storage Management Message
Reference
. . . . . .
. . . . . .
38
42
46
47
49
50
52
55
57
59
63
65
Alert Monitoring and Logging
Alert Message Format with Substitution Variables
Alert Message Change History
Alert Descriptions and Corrective Actions
. . . . . . . . . . . . . .
. .
. . . . . . . . . . . . .
. . . . . . .
65
66
69
70
4 System Event Log Messages for
IPMI Systems
Temperature Sensor Events
4
Contents
. . . . . . . . . . . . . . .
221
221
Voltage Sensor Events
. . . . . . . . . . . . . . . . .
222
Fan Sensor Events
Processor Status Events
Power Supply Events
Memory ECC Events
BMC Watchdog Events
Memory Events
Hardware Log Sensor Events
Drive Events
Intrusion Events
BIOS Generated System Events
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
Operating System Generated System Events
Cable Interconnect Events
Battery Events
. . . . . . . . . . . . . . . . . . . . . .
Power And Performance Events
. . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . .
223
225
226
229
229
230
231
232
233
234
240
241
241
242
Index
Entity Presence Events
Miscellaneous
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
Contents
244
244
247
5
6
Contents
1

Introduction

Dell OpenManage Server Administrator generates event messages stored primarily in the operating system or Server Administrator event logs and sometimes in Simple Network Management Protocol (SNMP) traps. This document describes the event messages that are created by Server Administrator version 6.5 and displayed in the Server Administrator alert log.
Server Administrator creates events in response to sensor status changes and other monitored parameters. The Server Administrator event monitor uses these status change events to add descriptive messages to the operating system event log or the Server Administrator alert log.
Each event message that Server Administrator adds to the alert log consists of a unique identifier called the event ID for a specific event source category and a descriptive message. The event message includes the severity, cause of the event, and other relevant information, such as the event location and the previous state of the monitored item.
The tables in this guide list all Server Administrator event IDs in numeric order. Each entry includes the description, severity level, and cause of the event ID. The message text in angle brackets (for example, <State>) describes the event-specific information provided by the Server Administrator.
Introduction
7

What’s New in this Release

No new alerts have been added. The existing alerts 2081, 2347, and 2388 are modified to include additional information.

Messages Not Described in This Guide

This guide describes only event messages logged by Server Administrator and Storage Management that are displayed in the Server Administrator alert log. For information on other messages generated by your system, see one of the following sources:
•The
Installation and Troubleshooting Guide or Hardware Owner's Manual
shipped with your system
Operating system documentation
Application program documentation

Understanding Event Messages

This section describes the various types of event messages generated by the Server Administrator. When an event occurs on your system, Server Administrator sends information about one of the following event types to the systems management console:
Table 1-1. Understanding Event Messages
Icon Alert Severity Component Status
OK /Normal / Informational
War n in g / Non-critical
Critical / Failure / Error
8
Introduction
An event that describes the successful operation of a unit. The alert is provided for informational purposes and does not indicate an error condition. For example, the alert may indicate the normal start or stop of an operation, such as power supply or a
An event that is not necessarily significant, but may indicate a possible future problem. alert may indicate that a component (such as a temperature probe in an enclosure) has crossed a warning threshold.
A significant event that indicates actual or imminent loss of data or loss of function. threshold or a hardware failure such as
sensor reading returning to normal.
For example, a Warning/Non-critical
For ex a mple,
crossing a failure
an array disk.
Server Administrator generates events based on status changes in the following sensors:
Temperature Sensor
— Helps protect critical components by alerting the systems management console when temperatures become too high inside a chassis; also monitors the temperature in a variety of locations in the chassis and in attached system(s).
Fan Sensor
— Monitors fans in various locations in the chassis and in
attached system(s).
Volt ag e Se nso r
— Monitors voltages across critical components in various
chassis locations and in attached system(s).
Current Sensor
— Monitors the current (or amperage) output from the
power supply (or supplies) in the chassis and in attached system(s).
Chassis Intrusion Sensor
— Monitors intrusion into the chassis and
attached system(s).
Redundancy Unit Sensor
— Monitors redundant units (critical units such as fans, AC power cords, or power supplies) within the chassis; also monitors the chassis and attached system(s). For example, redundancy allows a second or
n
th fan to keep the chassis components at a safe temperature when another fan has failed. Redundancy is normal when the intended number of critical components are operating. Redundancy is degraded when a component fails, but others are still operating. Redundancy is lost when there is one less critical redundancy device than required.
Power Supply Sensor
— Monitors power supplies in the chassis and in
attached system(s).
Memory Prefailure Sensor
— Monitors memory modules by counting the
number of Error Correction Code (ECC) memory corrections.
Fan Enclosure Sensor
— Monitors protective fan enclosures by detecting their removal from and insertion into the system, and by measuring how long a fan enclosure is absent from the chassis. This sensor monitors the chassis and in attached system(s).
AC Power Cord Sensor
— Monitors the presence of AC power for an
AC power cord.
Hardware Log Sensor
Processor Sensor
— Monitors the size of a hardware log.
— Monitors the processor status in the system.
Introduction
9
Pluggable Device Sensor
or configuration errors for some pluggable devices, such as memory cards.
Battery Sensor
the system.
SD Card Device Sensor
card devices in the system.
— Monitors the status of one or more batteries in
— Monitors the addition, removal,
— Monitors instrumented Secure Digital (SD)
Sample Event Message Text
The following example shows the format of the event messages logged by Server Administrator.
EventID: 1000
Source: Server Administrator
Category: Instrumentation Service
Type: Information
Date and Time: Mon Oct 21 10:38:00 2002
Computer: <computer name>
Description:
Server Administrator starting
Data: Bytes in Hex

Viewing Alerts and Event Messages

An event log is used to record information about important events.
Server Administrator generates alerts that are added to the operating system event log and to the Server Administrator alert log. To view these alerts in Server Administrator:
1
Select the
2
Select the
3
Select the
You can also view the event log using your operating system’s event viewer. Each operating system’s event viewer accesses the applicable operating system event log.
10
System
Logs
Alert
Introduction
object in the tree view.
tab.
tab.
The location of the event log file depends on the operating system you are using.
On systems running the Microsoft Windows operating systems, event messages are logged in the operating system event log and the Server Administrator event log. The Server Administrator event log file is named
dcsys32.xml
The default
On systems running the Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Citrix XenServer, VMware ESX, and VMware ESXi operating systems, the event messages are logged in the operating system log file and the Server Administrator event log. The default name of the operating system log file is operating system log file using a text editor such as Administrator event log file is named or
64
Linux, SUSE Linux Enterprise Server, Citrix XenServer and VMware ESX operating systems, the Server Administrator event log file is located in the
/opt/dell/srvadmin/var/log/openmanage
operating system, the Server Administrator event log file is located in the
/etc/cim/dell/srvadmin/log/openmanage
and is located in the
install_path
bit depending on the operating system. In the Red Hat Enterprise
is
<install_path>\omsa\log
C:\Program Files\Dell\SysMgt
/var/log/messages
, and you can view the
vi
or
emacs
dcsys<xx>.xml
directory. In the VMware ESXi
directory.
, where xx is either 32
directory.
.
. The Server
Logging Messages to a Unicode Text File
Logging messages to a Unicode text file is optional. By default, the feature is disabled in the Server Administrator. To enable this feature, modify the
Event Manager section of the dcemdy<xx>.ini configuration file where xx is 32 or 64 bit depending on the operating system, as follows:
On systems running Microsoft Windows operating systems, you can locate the configuration file in the the property
C:\Program Files\Dell\SysMgt
service to enable the setting. The Server Administrator Unicode text event log file is named <
install_path>\omsa\log directory
On systems running the Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Citrix XenServer and VMware ESX operating systems, you can locate the configuration file in the
srvadmin-deng/ini
UnitextLog.enabled=true
UnitextLog.enabled=true
dcsys32.log
directory and set the property
<install_path>\dataeng\ini
. The default
. Restart the
and is located in the
.
. Run the
DSM SA Event Manager
/opt/dell/srvadmin/etc/
/etc/init.d/dataeng
directory and set
install_path
is
Introduction
11
restart
command to restart the Server Administrator Event Manager service and enable the setting. This also restarts the Server Administrator Data Manager and SNMP services. The Server Administrator Unicode text event log file is named on the operating system and is located in the
openmanage
directory.
dcsys<xx>.log
where xx is 32 or 64 bit depending
/opt/dell/srvadmin/var/log/
The following sub-sections explain how to launch the Windows Server 2003, Windows Server 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESX, and VMware ESXi event viewers.
Viewing Events in Windows Server 2003 and Windows Server 2008
1
Click the
2
Double-click
3
In the
The
4
To view the details of an event, double-click one of the event items.
Start
button, point to
Administrative Tools
Event Viewer
System Log
NOTE:
You can also look up the dcsys<xx>.xml file, in the <install_path>\omsa\log directory, to view the separate event log file, where the default install_path is C:\Program Files\Dell\SysMgt and xx is 32 or 64 depending on the operating system that is installed.
window, click the
window displays a list of recently logged events.
Settings
, and click
Control Panel
, and then double-click
Tr ee
tab and then click
.
Event Viewer
System Log
.
Viewing Events in Red Hat Enterprise Linux and SUSE Linux Enterprise Server
1
Log in as
2
Use a text editor such as vi or
/var/log/messages
The following example shows the Red Hat Enterprise Linux and SUSE Linux Enterprise Server message log, /var/log/messages. The text in boldface type indicates the message text.
root
.
emacs
to view the file named
.
.
NOTE:
These messages are typically displayed as one long line. In the following example, the message is displayed using line breaks to help you see the message text more clearly.
...
12
Introduction
Feb 6 14:20:51 server01 Server Administrator: Instrumentation Service EventID: 1000
Server Administrator starting
Feb 6 14:20:51 server01 Server Administrator: Instrumentation Service EventID: 1001
Server Administrator startup complete
Feb 6 14:21:21 server01 Server Administrator: Instrumentation Service EventID: 1254 Chassis
intrusion detected Sensor location: Main chassis intrusion Chassis location: Main System Chassis Previous state was: OK (Normal) Chassis intrusion state: Open
Feb 6 14:21:51 server01 Server Administrator: Instrumentation Service EventID: 1252 Chassis
intrusion returned to normal Sensor location: Main chassis intrusion Chassis location: Main System Chassis Previous state was: Critical (Failed) Chassis intrusion state: Closed
Viewing Events in VMware ESX/ESXi
1
Log in to the system running VMware ESX/ESXi with VMware vSphere Client.
2
Click
3
ViewAdministrationSystem Logs
Select
Server Log
/var/log/messages
.
entry from the drop-down list.
Viewing the Event Information
The event log for each operating system contains some or all of the following information:
Date
— The date the event occurred.
Time
— The local time the event occurred.
Ty p e
— A classification of the event severity: Information, Warning,
or Error.
User
— The name of the user on whose behalf the event occurred.
Computer
— The name of the system where the event occurred.
Introduction
13
Source
— The software that logged the event.
Category
Event ID
Description
— The classification of the event by the event source.
— The number identifying the particular event type.
— A description of the event. The format and contents of
the event description vary, depending on the event type.
Understanding the Event Description
Table 1-2 lists in alphabetical order each line item that may appear in the event description.
Table 1-2. Event Description Reference
Description Line Item Explanation
Action performed was: <Action>
Action requested was: <Action>
Additional Details:
<Additional details for the event>
<Additional power supply status information>
Chassis intrusion state: <Intrusion
state>
Chassis location:
<Name of chassis>
Specifies the action that was performed, for example:
Action performed was: Power cycle
Specifies the action that was requested, for example:
Action requested was: Reboot, shutdown OS first
Specifies additional details available for the hot plug event, for example:
Memory device: DIMM1_A Serial number: FFFF30B1
Specifies information pertaining to the event, for example:
Power supply input AC is off, Power supply POK (power OK) signal is not normal, Power supply is turned off
Specifies whether the chassis intrusion state is Open or Closed. For example:
Chassis intrusion state: Open
Specifies name of the chassis that generated the message, for example:
Chassis location: Main System Chassis
14
Introduction
Table 1-2. Event Description Reference
Description Line Item Explanation
Configuration error type:
<type of configuration error>
Current sensor value (in Amps):
<Reading>
Date and time of action: <Date and
time>
Device location: <Location in chassis>
Discrete current state: <State>
Discrete temperature state:
<State>
Discrete voltage state: <State>
Fan sensor value:
<Reading>
Log type: <Log type>
Memory device bank location: <Bank
name in chassis>
Specifies the type of configuration error that occurred, for example:
Configuration error type: Revision mismatch
Specifies the current sensor value in amps, for example:
Current sensor value (in Amps): 7.853
Specifies the date and time the action was performed, for example:
Date and time of action: Sat Jun 12 16:20:33 2004
Specifies the location of the device in the specified chassis, for example:
Device location: Memory Card A
Specifies the state of the current sensor, for example:
Discrete current state: Good
Specifies the state of the temperature sensor, for example:
Discrete temperature state: Good
Specifies the state of the voltage sensor, for example:
Discrete voltage state: Good
Specifies the fan speed in revolutions per minute (RPM) or On/Off, for example:
Fan sensor value (in RPM): 2600
Fan sensor value: Off
Specifies the type of hardware log, for example:
Log type: ESM
Specifies the name of the memory bank in the system that generated the message, for example:
Memory device bank location: Bank_1
(continued)
Introduction
15
Table 1-2. Event Description Reference
Description Line Item Explanation
Memory device location:
<Device name in chassis>
Number of devices required for full redundancy:
<Number>
Peak value (in Watts): <Reading>
Possible memory module event cause:
<list of causes>
Power Supply type:
<type of power supply>
Previous redundancy state was: <State>
Previous state was:
<State>
Processor sensor status: <status>
Redundancy unit:
<Redundancy location in chassis>
SD card device type: <Type of SD card device>
Specifies the location of the memory module in the chassis, for example:
Memory device location: DIMM_A
Specifies the number of power supply or cooling devices required to achieve full redundancy, for example:
Number of devices required for full redundancy: 4
Specifies the peak value in Watts, for example:
Peak value (in Watts): 1.693
Specifies a list of possible causes for the memory module event, for example:
Possible memory module event cause: Single bit warning error rate exceeded
Single bit error logging disabled
Specifies the type of power supply, for example:
Power Supply type: VRM
Specifies the status of the previous redundancy message, for example:
Previous redundancy state was: Lost
Specifies the previous state of the sensor, for example:
Previous state was: OK (Normal)
Specifies the status of the processor sensor, for example:
Processor sensor status: Configuration error
Specifies the location of the redundant power supply or cooling unit in the chassis, for example:
Redundancy unit: Fan Enclosure
Specifies the type of SD card device, for example:
SD card device type: Hypervisor
(continued)
16
Introduction
Table 1-2. Event Description Reference
Description Line Item Explanation
SD card state:
<State of SD card>
Sensor location:
<Location in chassis>
Temperature sensor value: <Reading>
Voltage sensor value (in Volts):
<Reading>
Specifies the state of the SD card, for example:
SD card state: Present, Active
Specifies the location of the sensor in the specified chassis, for example:
Sensor location: CPU1
Specifies the temperature in degrees Celsius, for example:
Temperature sensor value (in degrees Celsius): 30
Specifies the voltage sensor value in volts, for example:
Voltage sensor value (in Volts): 1.693
(continued)
Introduction
17
18
Introduction
2

Server Management Messages

The following tables lists in numerical order each event ID and its corresponding description, along with its severity and cause.
NOTE:
For corrective actions, see the appropriate documentation.

Server Administrator General Messages

The messages in Table 2-1 indicate that certain alert systems are up and working.
Table 2-1. Server Administrator General Messages
Event IDDescription Severity Cause
0000 Log was cleared Information User cleared the log from
Server Administrator.
A user can clear the OpenManage Server Administrator log. This operation does not clear the operating system event log. Therefore, this event is not logged in the operating system event log. This is logged in the OpenManage System Administrator alert log.
0001 Log backup created Information The log was full, copied to
backup, and cleared.
1000 Server Administrator
starting
1001 Server Administrator
startup complete
Information Server Administrator is
beginning to initialize.
Information Server Administrator
completed its initialization.
Server Management Messages
19
Table 2-1. Server Administrator General Messages
Event IDDescription Severity Cause
(continued)
1002 A system BIOS update
has been scheduled for the next reboot
1003 A previously scheduled
system BIOS update has been canceled
1004 Thermal shutdown
protection has been initiated
1005 SMBIOS data is absent Error The system does not contain
1006 Automatic System
Recovery (ASR) action was performed Action performed was: <Action> Date and time of action: <Date and time>
Information The user has chosen to update
the flash basic input/output system (BIOS).
Information The user decides to cancel the
flash BIOS update, or an error occurs during the flash.
Error This message is generated
when a system is configured for thermal shutdown due to an error event. If a temperature sensor reading exceeds the error threshold for which the system is configured, the operating system shuts down and the system powers off. This event may also be initiated on certain systems when a fan enclosure is removed from the system for an extended period of time.
the required systems management BIOS version 2.2 or higher, or the BIOS is corrupted.
Error This message is generated
when an automatic system recovery action is performed due to a hung operating system. The action performed and the time of action is provided.
20
Server Management Messages
Table 2-1. Server Administrator General Messages
Event IDDescription Severity Cause
(continued)
1007 User initiated host
system control action Action requested was: <Action>
1008 Systems Management
Data Manager Started
1009 Systems Management
Data Manager Stopped
1011 RCI table is corrupt Error This message is generated
1012 IPMI Status
Interface: <the IPMI interface being used>, <additional information if available and applicable>
Information User requested a host system
control action to reboot, power off, or power cycle the system. Alternatively, the user had indicated protective measures to be initiated in the event of a thermal shutdown.
Information Systems Management
Data Manager services were started.
Information Systems Management
Data Manager services were stopped.
when the BIOS Remote Configuration Interface (RCI) table is corrupted or cannot be read by the systems management software.
Information This message is generated
to indicate the Intelligent Platform Management Interface (IPMI)) status of the system.
Additional information, when available, includes Baseboard Management Controller (BMC) not present, BMC not responding, System Event Log (SEL) not present, and SEL Data Record (SDR) not present.
Server Management Messages
21
Table 2-1. Server Administrator General Messages
Event IDDescription Severity Cause
(continued)
1013 System Peak Power
detected new peak value Peak value (in Watts):<Reading>
1014 System software
event:<Description> Date and time of action:<Date and time>
Information The system peak power sensor
detected a new peak value in power consumption. The new peak value in Watts is provided.
Warning This event is generated when
the systems management agent detects a critical system software generated event in the system event log which could have been resolved.

Temperature Sensor Messages

The temperature sensors listed in Table 2-2 help protect critical components by alerting the systems management console when temperatures become too high inside a chassis. The temperature sensor messages use additional variables: sensor location, chassis location, previous state, and temperature sensor value or state.
22
Server Management Messages
Table 2-2. Temperature Sensor Messages
Event IDDescription Severity Cause
1050 Temperature sensor has failed
Sensor location: <Location in chassis> Chassis location: <Name of chassis> Previous state was: <State>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
1051 Temperature sensor value
unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
Error A temperature
sensor on the backplane board, system board, or the carrier in the specified system failed. The sensor location, chassis location, previous state, and temperature sensor value are provided.
Information A temperature
sensor on the backplane board, system board, or drive carrier in the specified system could not obtain a reading. The sensor location, chassis location, previous state, and anominal temperature sensor value information is provided.
Server Management Messages
23
Table 2-2. Temperature Sensor Messages
Event IDDescription Severity Cause
(continued)
1052 Temperature sensor returned
to a normal value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
1053 Temperature sensor detected
a warning value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
Information A temperature
sensor on the backplane board, system board, or drive carrier in the specified system returned to a valid range after crossing a failure threshold. The sensor location, chassis location, previous state, and temperature sensor value are provided.
Warning A temperature
sensor on the backplane board, system board, CPU, or drive carrier in the specified system exceeded its warning threshold. The sensor location, chassis location, previous state, and temperature sensor value are provided.
24
Server Management Messages
Table 2-2. Temperature Sensor Messages
Event IDDescription Severity Cause
(continued)
1054 Temperature sensor detected
a failure value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
1055 Temperature sensor detected
a non-recoverable value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Temperature sensor value (in degrees Celsius): <Reading>
If sensor type is discrete:
Discrete temperature state:
<State>
Error A temperature
sensor on the backplane board, system board, or drive carrier in the specified system exceeded its failure threshold. The sensor location, chassis location, previous state, and temperature sensor value are provided.
Error A temperature
sensor on the backplane board, system board, or drive carrier in the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, and temperature sensor value information is provided.
Server Management Messages
25

Cooling Device Messages

The cooling device sensors listed in Table 2-3 monitor how well a fan is functioning. Cooling device messages provide status and warning information for fans in a particular chassis.
Table 2-3. Cooling Device Messages
Event IDDescription Severity Cause
1100 Fan sensor has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
1101 Fan sensor value unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
Error A fan sensor in the
specified system is not functioning. The sensor location, chassis location, previous state, and fan sensor value information is provided.
Error A fan sensor in the
specified system could not obtain a reading. The sensor location, chassis location, previous state, and a nominal fan sensor value information is provided.
26
Server Management Messages
Table 2-3. Cooling Device Messages
Event IDDescription Severity Cause
(continued)
1102 Fan sensor returned to a
normal value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
1103 Fan sensor detected a warning
value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
1104 Fan sensor detected a failure
value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
Information A fan sensor
reading on the specified system returned to a valid range after crossing a warning threshold. The sensor location, chassis location, previous state, and fan sensor value information is provided.
Warning A fan sensor
reading in the specified system exceeded a warning threshold. The sensor location, chassis location, previous state, and fan sensor value information is provided.
Error A fan sensor in the
specified system detected the failure of one or more fans. The sensor location, chassis location, previous state, and fan sensor value information is provided.
Server Management Messages
27
Table 2-3. Cooling Device Messages
Event IDDescription Severity Cause
(continued)
1105 Fan sensor detected a
non-recoverable value
Sensor location: <Location in
chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Fan sensor value: <Reading>
Error A fan sensor
detected an error from which it cannot recover. The sensor location, chassis location, previous state, and fan sensor value information is provided.
28
Server Management Messages

Voltage Sensor Messages

The voltage sensors listed in Table 2-4 monitor the number of volts across critical components. Voltage sensor messages provide status and warning information for voltage sensors in a particular chassis.
Table 2-4. Voltage Sensor Messages
Event IDDescription Severity Cause
1150 Voltage sensor has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
1151 Voltage sensor value unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
Error A voltage sensor in
the specified system failed. The sensor location, chassis location, previous state, and voltage sensor value information is provided.
Information A voltage sensor in
the specified system could not obtain a reading. The sensor location, chassis location, previous state, and a nominal voltage sensor value are provided.
Server Management Messages
29
Table 2-4. Voltage Sensor Messages
Event IDDescription Severity Cause
(continued)
1152 Voltage sensor returned to
a normal value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
1153 Voltage sensor detected a
warning value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
Information A voltage sensor in
the specified system returned to a valid range after crossing a failure threshold. The sensor location, chassis location, previous state, and voltage sensor value information is provided.
Warning A voltage sensor in
the specified system exceeded its warning threshold. The sensor location, chassis location, previous state, and voltage sensor value information is provided.
30
Server Management Messages
Table 2-4. Voltage Sensor Messages
Event IDDescription Severity Cause
(continued)
1154 Voltage sensor detected
a failure value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
1155 Voltage sensor detected a
non-recoverable value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Voltage sensor value (in Volts): <Reading>
If sensor type is discrete:
Discrete voltage state:
<State>
Error A voltage sensor in
the specified system exceeded its failure threshold. The sensor location, chassis location, previous state, and voltage sensor value information is provided.
Error A voltage sensor in
the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, and voltage sensor value information is provided.
Server Management Messages
31

Current Sensor Messages

The current sensors listed in Table 2-5 measure the amount of current (in amperes) that is traversing critical components. Current sensor messages provide status and warning information for current sensors in a particular chassis.
Table 2-5. Current Sensor Messages
Event IDDescription Severity Cause
1200 Current sensor has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
Error A current sensor
in the specified system failed. The sensor location, chassis location, previous state, and current sensor value are provided.
32
Server Management Messages
Table 2-5. Current Sensor Messages
Event IDDescription Severity Cause
(continued)
1201 Current sensor value unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
1202 Current sensor returned to
a normal value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
Error A current sensor
in the specified system could not obtain a reading. The sensor location, chassis location, previous state, and a nominal current sensor value information is provided.
Information A current sensor
in the specified system returned to a valid range after crossing a failure threshold. The sensor location, chassis location, previous state, and current sensor value information is provided.
Server Management Messages
33
Table 2-5. Current Sensor Messages
Event IDDescription Severity Cause
(continued)
1203 Current sensor detected a
warning value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
1204 Current sensor detected a
failure value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
Warning A current sensor
in the specified system exceeded its warning threshold. The sensor location, chassis location, previous state, and current sensor value are provided.
Error A current sensor
in the specified system exceeded its failure threshold. The sensor location, chassis location, previous state, and current sensor value are provided.
34
Server Management Messages
Table 2-5. Current Sensor Messages
Event IDDescription Severity Cause
(continued)
1205 Current sensor detected a
non-recoverable value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
If sensor type is not discrete:
Current sensor value (in Amps): <Reading> OR
Current sensor value (in Watts): <Reading>
If sensor type is discrete:
Discrete current state: <State>
Error A current sensor
in the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, and current sensor value are provided.

Chassis Intrusion Messages

The chassis intrusion messages listed in Table 2-6 are a security measure. Chassis intrusion means that someone is opening the cover to a system’s chassis. Alerts are sent to prevent unauthorized removal of parts from a chassis.
Server Management Messages
35
Table 2-6. Chassis Intrusion Messages
Event IDDescription Severity Cause
1250 Chassis intrusion
sensor has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
1251 Chassis intrusion
sensor value unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
1252 Chassis intrusion
returned to normal
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
Error A chassis intrusion sensor
in the specified system failed. The sensor location, chassis location, previous state, and chassis intrusion state are provided.
Error A chassis intrusion sensor
in the specified system could not obtain a reading. The sensor location, chassis location, previous state, and chassis intrusion state are provided.
Information A chassis intrusion sensor
in the specified system detected that a cover was opened while the system was operating but has since been replaced. The sensor location, chassis location, previous state, and chassis intrusion state information is provided.
36
Server Management Messages
Table 2-6. Chassis Intrusion Messages
Event IDDescription Severity Cause
(continued)
1253 Chassis intrusion in
progress
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
1254 Chassis intrusion
detected
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
1255 Chassis intrusion
sensor detected a non-recoverable value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Chassis intrusion state:
<Intrusion state>
Warning A chassis intrusion sensor
in the specified system detected that a system cover is currently being opened and the system is operating. The sensor location, chassis location, previous state, and chassis intrusion state information is provided.
Critical A chassis intrusion sensor
in the specified system detected that the system cover was opened while the system was operating. The sensor location, chassis location, previous state, and chassis intrusion state information is provided.
Error A chassis intrusion sensor
in the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, and chassis intrusion state information is provided.
Server Management Messages
37

Redundancy Unit Messages

Redundancy means that a system chassis has more than one of certain critical components. Fans and power supplies, for example, are so important for preventing damage or disruption of a computer system that a chassis may have “extra” fans or power supplies installed. Redundancy allows a second or nth fan to keep the chassis components at a safe temperature when the primary fan has failed. Redundancy is normal when the intended number of critical components are operating. Redundancy is degraded when a component fails but others are still operating. Redundancy is lost when the number of components functioning falls below the redundancy threshold. Table 2-7 lists the redundancy unit messages.
The number of devices required for full redundancy is provided as part of the message, when applicable, for the redundancy unit and the platform. For details on redundancy computation, see the respective platform documentation.
Table 2-7. Redundancy Unit Messages
EventIDDescription Severity Cause
1300 Redundancy sensor has
failed
Redundancy unit: <Redundancy
location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
1301 Redundancy sensor value
unknown
Redundancy unit: <Redundancy
location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
38
Server Management Messages
Warning A redundancy sensor in
the specified system failed. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy are provided.
Warning A redundancy sensor in
the specified system could not obtain a reading. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy are provided.
Table 2-7. Redundancy Unit Messages
EventIDDescription Severity Cause
(continued)
1302 Redundancy not applicable
Redundancy unit:
<Redundancy location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
1303 Redundancy is offline
Redundancy unit:
<Redundancy location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
Information A redundancy sensor in
the specified system detected that a unit was not redundant. The redundancy location, chassis location, previous redundancy state, and the number of devices required for full redundancy information is provided.
Information A redundancy sensor in
the specified system detected that a redundant unit is offline. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy information is provided.
Server Management Messages
39
Table 2-7. Redundancy Unit Messages
EventIDDescription Severity Cause
(continued)
1304 Redundancy regained
Redundancy unit:
<Redundancy location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
1305 Redundancy degraded
Redundancy unit:
<Redundancy location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
Information A redundancy sensor in
the specified system detected that a “lost” redundancy device has been reconnected or replaced; full redundancy is in effect. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy information is provided.
Warning A redundancy sensor in
the specified system detected that one of the components of the redundancy unit has failed but the unit is still redundant. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy information is provided.
40
Server Management Messages
Table 2-7. Redundancy Unit Messages
EventIDDescription Severity Cause
(continued)
1306 Redundancy lost
Redundancy unit:
<Redundancy location in chassis>
Chassis location: <Name of chassis>
Previous redundancy state was: <State>
Error A redundancy sensor in
the specified system detected that one of the components in the redundant unit has been disconnected, has failed, or is not present. The redundancy unit location, chassis location, previous redundancy state, and the number of devices required for full redundancy are provided.
Server Management Messages
41

Power Supply Messages

The power supply sensors monitor how well a power supply is functioning. The power supply messages listed in Table 2-8 provide status and warning information for power supplies present in a particular chassis.
Table 2-8. Power Supply Messages
Event IDDescription Severity Cause
1350 Power supply sensor has
failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of
power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
Error A power supply sensor
in the specified system failed. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information are provided.
42
Server Management Messages
Table 2-8. Power Supply Messages
Event IDDescription Severity Cause
(continued)
1351 Power supply sensor value
unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
1352 Power supply returned to
normal Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
Information A power supply sensor
in the specified system could not obtain a reading. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information are provided.
Information A power supply has
been reconnected or replaced. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information are provided.
Server Management Messages
43
Table 2-8. Power Supply Messages
Event IDDescription Severity Cause
(continued)
1353 Power supply detected a
warning Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
1354 Power supply detected a
failure
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
Warning A power supply sensor
reading in the specified system exceeded a user-definable warning threshold. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information are provided.
Error A power supply has
been disconnected or has failed. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information are provided.
44
Server Management Messages
Table 2-8. Power Supply Messages
Event IDDescription Severity Cause
(continued)
1355 Power supply sensor detected
a non-recoverable value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Power Supply type: <type of power supply>
<Additional power supply status information>
If in configuration error state:
Configuration error type: <type of configuration error>
Error A power supply sensor
in the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, power supply type, additional power supply status, and configuration error type information is provided.
Server Management Messages
45

Memory Device Messages

The memory device messages listed in Table 2-9 provide status and warning information for memory modules present in a particular system. Memory devices determine health status by monitoring the ECC memory correction rate and the type of memory events that have occurred.
NOTE:
A critical status does not always indicate a system failure or loss of data. In some instances, the system has exceeded the ECC correction rate. Although the system continues to function, you should perform system maintenance as described in Table 2-9.
NOTE:
Table 2-9. Memory Device Messages
Event IDDescription Severity Cause
In Table 2-9, <status> can be either
critical
or
non-critical
.
1403 Memory device status is
<status>
Memory device location:
<location in chassis>
Possible memory module event cause: <list of
causes>
1404 Memory device status is
<status>
Memory device location:
<location in chassis>
Possible memory module event cause: <list of causes>
Warning A memory device correction
rate exceeded an acceptable value. The memory device status and possible memory module event cause information is provided.
Error A memory device correction
rate exceeded an acceptable value, a memory spare bank was activated, or a multibit ECC error occurred. The system continues to function normally (except for a multibit error). Replace the memory module identified in the message during the system’s next scheduled maintenance. Clear the memory error on multibit ECC error. The memory device status and possible memory module event cause information is provided.
46
Server Management Messages

Fan Enclosure Messages

Some systems are equipped with a protective enclosure for fans. Fan enclosure messages listed in Table 2-10 monitor whether foreign objects are present in an enclosure and how long a fan enclosure is missing from a chassis.
Table 2-10. Fan Enclosure Messages
Event IDDescription Severity Cause
1450 Fan enclosure sensor
has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1451 Fan enclosure sensor
value unknown
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1452 Fan enclosure inserted
into system
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1453 Fan enclosure removed
from system
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Critical/ Failure / Error
Warning The fan enclosure sensor in
Information A fan enclosure has been
Warning A fan enclosure has been
The fan enclosure sensor in the specified system failed. The sensor and chassis location information is provided.
the specified system could not obtain a reading. The sensor and chassis location information is provided.
inserted into the specified system. The sensor and chassis location information is provided.
removed from the specified system. The sensor and chassis location information is provided.
Server Management Messages
47
Table 2-10. Fan Enclosure Messages
Event IDDescription Severity Cause
(continued)
1454 Fan enclosure removed
from system for an extended amount of time
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1455 Fan enclosure sensor
detected a non­recoverable value
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Error A fan enclosure has been
removed from the specified system for a user-definable length of time. The sensor and chassis location information is provided.
Error A fan enclosure sensor in the
specified system detected an error from which it cannot recover. The sensor and chassis location are provided.
48
Server Management Messages

AC Power Cord Messages

The AC power cord messages listed in Table 2-11 provide status and warning information for power cords that are part of an AC power switch, if your system supports AC switching.
Table 2-11. AC Power Cord Messages
Event IDDescription Severity Cause
1500 AC power cord sensor
has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1501 AC power cord is not
being monitored
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1502 AC power has been
restored
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Critical/ Failure/ Error
Information The AC power cord status is
Information Power is restored in an AC
An AC power cord sensor in the specified system failed. The AC power cord status cannot be monitored. The sensor and chassis location information is provided.
not being monitored. This occurs when a system’s expected AC power configuration is set to nonredundant. The sensor and chassis location information is provided.
power cord that did not have AC power. The sensor and chassis location information is provided.
Server Management Messages
49
Table 2-11. AC Power Cord Messages
Event IDDescription Severity Cause
(continued)
1503 AC power has been lost
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1504 AC power has been lost
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
1505 AC power has been lost
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Critical/ Failure/ Error
Error Power supply is disrupted to
Error An AC power cord sensor in

Hardware Log Sensor Messages

Power supply is disrupted to the AC power cord or an AC power cord is not transmitting power, but there is sufficient redundancy to classify this as a warning. The sensor and chassis location information is provided.
the AC power cord or an AC power cord is not transmitting power, and lack of redundancy requires this to be classified as an error. The sensor and chassis location information is provided.
the specified system failed. The AC power cord status cannot be monitored. The sensor and chassis location information is provided.
The hardware logs provide hardware status messages to systems management software. On certain systems, the hardware log is implemented as a circular queue. When the log becomes full, the oldest status messages are overwritten when new status messages are logged. On some systems, the log is not circular. On these systems, when the log becomes full, subsequent hardware status messages are lost. Hardware log sensor messages listed in Table 2-12 provide status and warning information about the noncircular logs that may fill up, resulting in lost status messages.
50
Server Management Messages
Table 2-12. Hardware Log Sensor Messages
Event IDDescription Severity Cause
1550 Log monitoring has
been disabled
Log type: <Log type>
1551 Log status is unknown
Log type: <Log type>
1552 Log size is no longer
near or at capacity
Log type: <Log type>
1553 Log size is near
capacity
Log type: <Log type>
1554 Log size is full
Log type: <Log type>
1555 Log sensor has failed
Log type: <Log type>
Warning A hardware log sensor in the
specified system is disabled. The log type information is provided.
Information A hardware log sensor in the
specified system could not obtain a reading. The log type information is provided.
Information The hardware log on the
specified system is no longer near or at its capacity, usually as the result of clearing the log. The log type information is provided.
Warning The size of a hardware log on the
specified system is near or at the capacity of the hardware log. The log type information is provided.
Error The size of a hardware log on
the specified system is full. The log type information is provided.
Error A hardware log sensor in the
specified system failed. The hardware log status cannot be monitored. The log type information is provided.
Server Management Messages
51

Processor Sensor Messages

The processor sensors monitor how well a processor is functioning. Processor messages listed in Table 2-13 provide status and warning information for processors in a particular chassis.
Table 2-13. Processor Sensor Messages
Event IDDescription Severity Cause
1600 Processor sensor has
failed
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
1601 Processor sensor value
unknown
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
Critical/ Failure/ Error
Critical/ Failure/ Error
A processor sensor in the specified system is not functioning. The sensor location, chassis location, previous state and processor sensor status information is provided.
A processor sensor in the specified system could not obtain a reading. The sensor location, chassis location, previous state and processor sensor status information is provided.
52
Server Management Messages
Table 2-13. Processor Sensor Messages
Event IDDescription Severity Cause
(continued)
1602 Processor sensor
returned to a normal value
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
1603 Processor sensor
detected a warning value
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
Information A processor sensor in the
specified system transitioned back to a normal state. The sensor location, chassis location, previous state and processor sensor status are provided.
Warning A processor sensor in the
specified system is in a throttled state. The sensor location, chassis location, previous state and processor sensor status information is provided.
Server Management Messages
53
Table 2-13. Processor Sensor Messages
Event IDDescription Severity Cause
(continued)
1604 Processor sensor
detected a failure value
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
1605 Processor sensor
detected a non­recoverable value
Sensor Location:
<Location in chassis>
Chassis Location:
<Name of chassis>
Previous state was:
<State>
Processor sensor status: <status>
Error A processor sensor in the
specified system is disabled, has a configuration error, or experienced a thermal trip. The sensor location, chassis location, previous state and processor sensor status are provided.
Error A processor sensor in the
specified system has failed. The sensor location, chassis location, previous state and processor sensor status are provided.
54
Server Management Messages

Pluggable Device Messages

The pluggable device messages listed in Table 2-14 provide status and error information when some devices, such as memory cards, are added or removed.
Table 2-14. Pluggable Device Messages
Event IDDescription Severity Cause
1650 <Device plug event
type unknown>
Device location:
<Location in chassis, if available>
Chassis location:
<Name of chassis, if available>
Additional details:
<Additional details for the events, if available>
1651 Device added to
system
Device location:
<Location in chassis>
Chassis location:
<Name of chassis>
Additional details:
<Additional details for the events>
Information A pluggable device event message
of unknown type was received. The device location, chassis location, and additional event details, if available, are provided.
Information A device was added in the
specified system. The device location, chassis location, and additional event details, if available, are provided.
Server Management Messages
55
Table 2-14. Pluggable Device Messages
Event IDDescription Severity Cause
(continued)
1652 Device removed from
system
Device location:
<Location in chassis>
Chassis location:
<Name of chassis>
Additional details:
<Additional details for the events>
1653 Device configuration
error detected
Device location:
<Location in chassis>
Chassis location:
<Name of chassis>
Additional details:
<Additional details for the events>
Information A device was removed from the
specified system. The device location, chassis location, and additional event details, if available, are provided.
Error A configuration error was
detected for a pluggable device in the specified system. The device may have been added to the system incorrectly.
56
Server Management Messages

Battery Sensor Messages

The battery sensors monitor how well a battery is functioning. The battery messages listed in Table 2-15 provide status and warning information for batteries in a particular chassis.
Table 2-15. Battery Sensor Messages
Event IDDescription Severity Cause
1700 Battery sensor has failed
Sensor location: <Location in chassis>
Chassis location: <Name of chassis>
Previous state was: <State>
Battery sensor status: <status>
1701 Battery sensor value unknown
Sensor Location: <Location in
chassis>
Chassis Location: <Name of chassis>
Previous state was: <State>
Battery sensor status:
<status>
Critical/ Failure/ Error
Warning A battery sensor in
A battery sensor in the specified system is not functioning. The sensor location, chassis location, previous state, and battery sensor status information is provided.
the specified system could not retrieve a reading. The sensor location, chassis location, previous state, and battery sensor status information is provided.
Server Management Messages
57
Table 2-15. Battery Sensor Messages
Event IDDescription Severity Cause
(continued)
1702 Battery sensor returned to a
normal value
Sensor Location: <Location in
chassis>
Chassis Location: <Name of chassis>
Previous state was: <State>
Battery sensor status:
<status>
1703 Battery sensor detected a
warning value
Sensor Location: <Location in
chassis>
Chassis Location: <Name of chassis>
Previous state was: <State>
Battery sensor status:
<status>
1704 Battery sensor detected a
failure value
Sensor Location: <Location in
chassis>
Chassis Location: <Name of chassis>
Previous state was: <State>
Battery sensor status:
<status>
Information A battery sensor in
the specified system detected that a battery transitioned back to a normal state. The sensor location, chassis location, previous state, and battery sensor status information is provided.
Warning A battery sensor in
the specified system detected that a battery is in a predictive failure state. The sensor location, chassis location, previous state, and battery sensor status information is provided.
Error A battery sensor in
the specified system detected that a battery has failed. The sensor location, chassis location, previous state, and battery sensor status information is provided.
58
Server Management Messages
Table 2-15. Battery Sensor Messages
Event IDDescription Severity Cause
(continued)
1705 Battery sensor detected a
non-recoverable value
Sensor Location: <Location in
chassis>
Chassis Location: <Name of chassis>
Previous state was:
Battery sensor status:
<status>
<State>
Error A battery sensor in
the specified system could not retrieve a value. The sensor location, chassis location, previous state, and battery sensor status information is provided.

Secure Digital (SD) Card Device Messages

The SD card device sensors monitor instrumented SD card devices in the system. Table 2-16 lists the messages that provide status and error information for SD card devices present in a chassis.
Table 2-16. SD Card Device Messages
Event IDDescription Severity Cause
1750 SD card device sensor has
failed
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
Error An SD card device
sensor in the specified system failed. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
Server Management Messages
59
Table 2-16. SD Card Device Messages
Event IDDescription Severity Cause
1751 SD card device sensor
value unknown
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
1752 SD card device returned to
normal
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
Information An SD card device
sensor in the specified system could not obtain a reading. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
Information An SD card device
sensor in the specified system detected that an SD card transitioned back to a normal state. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
60
Server Management Messages
Table 2-16. SD Card Device Messages
Event IDDescription Severity Cause
1753 SD card device detected a
warning
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
1754 SD card device detected a
failure
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
Warning An SD card device
sensor in the specified system detected a warning condition. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
Error An SD card device
sensor in the specified system detected an error. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
Server Management Messages
61
Table 2-16. SD Card Device Messages
Event IDDescription Severity Cause
1755 SD card device sensor
detected a non-recoverable value
Sensor location: <Location
in chassis>
Chassis location: <Name of chassis>
Previous state was:
<State>
SD card device type: <Type of SD card device>
SD card state: <State of SD card>
Error An SD card device
sensor in the specified system detected an error from which it cannot recover. The sensor location, chassis location, previous state, and SD card device type information is provided. The SD card state is provided if an SD card is present in the SD card device.
62
Server Management Messages

Chassis Management Controller Messages

The Alerts sent by Dell M1000e Chassis Management Controller (CMC) are organized by severity. That is, the event ID of the CMC trap indicates the severity (informational, warning, critical, or non-recoverable) of the alert. Each CMC alert includes the originating system name, location, and event message text. The alert message text matches the corresponding Chassis Event Log message text that is logged by the sending CMC for that event.
Table 2-17. Chassis Management Controller Messages
EventID Description Severity Cause
2000 CMC generated a
test trap
2002 CMC reported a
return-to-normal or informational event
2003 CMC reported a
warning
2004 CMC reported a
critical event
2005 CMC reported a
non-recoverable event
Informational A user-initiated test trap
was issued, through the CMC GUI or RACADM CLI.
Informational CMC informational
event, as described in the drsCAMessage variable binding supplied with the alert.
Warning CMC warning event, as
described in the drsCAMessage variable supplied with the alert.
Critical CMC critical event, as
described in the drsCAMessage variable binding supplied with the alert.
Non-Recoverable CMC non-recoverable
event, as described in the drsCAMessage variable binding supplied with the alert.
Server Management Messages
63
64
Server Management Messages
3

Storage Management Message Reference

The Dell OpenManage Server Administrator Storage Management’s alert or event management features let you monitor the health of storage resources such as controllers, enclosures, physical disks, and virtual disks.

Alert Monitoring and Logging

The Storage Management Service performs alert monitoring and logging. By default, the Storage Management service starts when the managed system starts up. If you stop the Storage Management Service, then alert monitoring and logging stops. Alert monitoring does the following:
Updates the status of the storage object that generated the alert.
Propagates the storage object’s status to all the related higher objects in the storage hierarchy. For example, the status of a lower-level object is propagated up to the status displayed on the
Storage
Logs an alert in the alert log and the operating system application log.
Sends an SNMP trap if the operating system’s SNMP service is installed and enabled.
object.
Health
tab for the top-level
NOTE:
Dell OpenManage Server Administrator Storage Management does not log alerts regarding the data I/O path. These alerts are logged by the respective RAID drivers in the system alert log.
See the Dell OpenManage Server Administrator Storage Management Online Help for updated information.
Storage Management Message Reference
65

Alert Message Format with Substitution Variables

When you view an alert in the Server Administrator alert log, the alert identifies the specific components such as the controller name or the virtual disk name to which the alert applies. In an actual operating environment, a storage system can have many combinations of controllers and disks as well as user-defined names for virtual disks and other components. Each environment is unique in its storage configuration and user-defined names. To receive an accurate alert message, that the Storage Management service must be able to insert the environment-specific names of storage components into an alert message.
This environment-specific information is inserted after the alert message text as shown for alert 2127 in Table 3-1.
For other alerts, the alert message text is constructed from information passed directly from the controller (or another storage component) to the alert log. In these cases, the variable information is represented with a percent symbol in the Storage Management documentation. An example of such an alert is shown for alert 2334 in Table 3-1.
Table 3-1. Alert Message Format
Alert ID Message Text Displayed in the
Storage Management Service Documentation
2127 Background Initialization
started
2334 Controller event log% Controller event log: Current capacity of the
Message Text Displayed in the Alert Log with Variable Information Supplied
Background Initialization started: Virtual Disk 3 (Virtual Disk 3) Controller 1 (PERC 5/E Adapter)
battery is above threshold.: Controller 1 (PERC 5/E Adapter)
The variables required to complete the message vary depending on the type of storage object and whether the storage object is in a SCSI or SAS configuration. The following table identifies the possible variables used to identify each storage object.
NOTE:
Some alert messages relating to an enclosure or an enclosure component, such as a fan or EMM, are generated by the controller when the enclosure or enclosure component ID cannot be determined.
66
Storage Management Message Reference
NOTE:
A, B, C and X, Y, Z in the following examples are variables representing the
storage object name or number.
Table 3-2. Message Format with Variables for Each Storage Object
Storage Object Message Variables
Controller Message Format: Controller A (Name)
Message Format: Controller A
For example, 2326 A foreign configuration has been detected: Controller 1 (PERC 5/E Adapter)
NOTE:
The controller name is not always displayed.
Battery Message Format: Battery X Controller A
For example, 2174 The controller battery has been removed: Battery 0 Controller 1
SCSI Physical Disk
SAS Physical Disk
Virtual Disk Message Format: Virtual Disk X (Name) Controller A (Name)
Enclosure: Message Format: Enclosure X:Y Controller A, Connector B
SCSI Power Supply
Message Format: Physical Disk X:Y Controller A, Connector B
For example, 2049 Physical disk removed: Physical Disk 0:14 Controller 1, Connector 0
Message Format: Physical Disk X:Y:Z Controller A, Connector B
For example, 2049 Physical disk removed: Physical Disk 0:0:14 Controller 1, Connector 0
Message Format: Virtual Disk X Controller A
For example, 2057 Virtual disk degraded: Virtual Disk 11 (Virtual Disk 11) Controller 1 (PERC 5/E Adapter)
NOTE:
The virtual disk and controller names are not always displayed.
For example, 2112 Enclosure shutdown: Enclosure 0:2 Controller 1, Connector 0
Message Format: Power Supply X Controller A, Connector B, Tar ge t I D C
where "C" is the SCSI ID number of the enclosure management module (EMM) managing the power supply.
For example, 2122 Redundancy degraded: Power Supply 1, Controller 1, Connector 0, Target ID 6
Storage Management Message Reference
67
Table 3-2. Message Format with Variables for Each Storage Object
Storage Object Message Variables
SAS Power Supply
SCSI Temperature Probe
SAS Temperature Probe
SCSI Fan Message Format: Fan X Controller A, Connector B, Target ID C
SAS Fan Message Format: Fan X Controller A, Connector B, Enclosure C
SCSI EMM Message Format: EMM X Controller A, Connector B, Target ID C
SAS EMM Message Format: EMM X Controller A, Connector B, Enclosure C
Message Format: Power Supply X Controller A, Connector B, Enclosure C
For example, 2312 A power supply in the enclosure has an AC failure: Power Supply 1, Controller 1, Connector 0, Enclosure 2
Message Format: Temperature Probe X Controller A, Connector B, Tar g et ID C
where C is the SCSI ID number of the EMM managing the temperature probe.
For example, 2101 Temperature dropped below the minimum warning threshold: Temperature Probe 1, Controller 1, Connector 0, Tar g et ID 6
Message Format: Temperature Probe X Controller A, Connector B, Enclosure C
For example, 2101 Temperature dropped below the minimum warning threshold: Temperature Probe 1, Controller 1, Connector 0, Enclosure 2
where C is the SCSI ID number of the EMM managing the fan.
For example, 2121 Device returned to normal: Fan 1, Controller 1, Connector 0, Target ID 6
For example, 2121 Device returned to normal: Fan 1, Controller 1, Connector 0, Enclosure 2
where C is the SCSI ID number of the EMM.
For example, 2121 Device returned to normal: EMM 1, Controller 1, Connector 0, Target ID 6
For example, 2121 Device returned to normal: EMM 1, Controller 1, Connector 0, Enclosure 2
(continued)
68
Storage Management Message Reference

Alert Message Change History

The following table describes the changes made to the Storage Management alerts from the previous release of Storage Management to the current release.
Table 3-3. Alert Message Change History
Storage Management 3.5
Product Versions to which changes apply
New Alerts None
Deleted Alerts None
Modified Alerts 2388, 2347, 2081
Storage Management 3.4
Product Versions to which changes apply
New Alerts 2405, 2406, 2407, 2408, 2409, 2410, 2411,
NOTE:
The Dell Key Manager (DKM) and CacheCade features are available from
calendar year 2011.
Deleted Alerts None
Modified Alerts None
Storage Management 3.3
Product Versions to which changes apply
New Alerts 2394, 2395, 2396, 2397, 2398, 2399, 2400,
Deleted Alerts None
Modified Alerts Alert severity changed for 1151 and 1351
Storage Management 3.5.0
Server Administrator 4.5.0
Dell OpenManage 6.5.0
Storage Management 3.4.0
Server Administrator 4.4.0
Dell OpenManage 6.4.0
2412, 2413, 2414, 2415, 2416, 2417, 2418
Storage Management 3.3.0
Server Administrator 4.3.0
Dell OpenManage 6.3.0
2401, 2402, 2403, 2404
Storage Management Message Reference
69
Table 3-3. Alert Message Change History
Storage Management 3.2
Product Versions to which changes apply
New Alerts 2387, 2388, 2389, 2390, 2392, 2393
Deleted Alerts None
Modified Alerts None
(continued)
Storage Management 3.2.0
Server Administrator 4.2.0
Dell OpenManage 6.2.0

Alert Descriptions and Corrective Actions

The following sections describe alerts generated by the RAID or SCSI controllers supported by Storage Management. The alerts are displayed in the Server Administrator Alert tab or through Windows Event Viewer. These alerts can also be forwarded as SNMP traps to other applications.
SNMP traps are generated for the alerts listed in the following sections. These traps are included in the Dell OpenManage Server Administrator Storage Management management information base (MIB). The SNMP traps for these alerts use all of the SNMP trap variables. For more information on SNMP support and the MIB, see the Dell OpenManage SNMP Reference Guide.
To locate an alert, scroll through the following table to find the alert number displayed on the Server Administrator Alert tab or search this file for the alert message text or number. See “Understanding Event Messages” on page 8 for more information on severity levels.
For more information regarding alert descriptions and the appropriate corrective actions, see the online help.
70
Storage Management Message Reference
Table 3-4. Storage Management Messages
EventIDDescription Severity Cause and Action Related Alert
Information
2048 Device failed Critical /
Failure / Error
Cause: A storage component such as a physical disk or an enclosure has failed. The failed component may have been identified by the controller while performing a task such as a rescan or a check consistency.
Action: Replace the failed component. You can identify which disk has failed by locating the disk that has a red “X” for its status. Perform a rescan after replacing the failed component.
Clear Alert Number:
2121.
Related Alert Number:
2095, 2201, 2203
Local Response Agent (LRA) Number:
2051, 2061, 2071, 2081, 2091, 2101
SNMP Trap Numbers
754 804 854 904 954 1004 1054 1104 1154 1204
Storage Management Message Reference
71
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2049 Physical disk
removed
War n in g / Non-critical
Cause: A physical disk has been removed from the disk group. This alert can also be caused by loose or defective cables or by problems with the enclosure.
Action: If a physical disk was removed from the disk group, either replace the disk or restore the original disk. On some controllers, a removed disk has a red X for its status. On other controllers, a removed disk may have an Offline status or is not displayed on the user interface. Perform a rescan after replacing or restoring the disk. If a disk has not been removed from the disk group, then check for problems with the cables. See the
online help more information on checking Ensure that the enclosure is powered on. If the problem persists, check the enclosure documentation for further diagnostic information.
the cables.
for
Clear Alert Number:
2052.
Related Alert Number:
2054, 2057, 2056, 2076, 2079, 2081, 2083, 2129, 2202, 2204, 2270, 2292, 2299, 2369
LRA Number: 2070
SNMP Tra p Numbers
903
72
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2050 Physical disk
offline
2051 Physical disk
degraded
War n in g / Non-critical
War n in g / Non-critical
Cause: A physical disk in the disk group is offline. The user may have manually put the physical disk offline.
Action: Perform a rescan. You can also select the offline disk and perform a Make
Online operation.
Cause: A physical disk
has reported an error condition and may be degraded. The physical disk may have reported the error condition in response to a consistency check or other operation.
Action: Replace the degraded physical disk. You can identify which disk is degraded by locating the disk that has a red X for its status. Perform a rescan after replacing the disk.
Clear Alert Number:
2158.
Related Alert Number:
2099, 2196
LRA Number: 2070
Clear Alert:
None
Related Alert Number: 2070
LRA Number:
None
SNMP Trap Numbers
903
903
Storage Management Message Reference
73
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2052 Physical disk
inserted
2053 Virtual disk
created
2054 Virtual disk
deleted
2055 Virtual disk
configuration changed
OK / Normal / Informational
OK / Normal / Informational
War n in g / Non-critical
OK / Normal / Informational
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Cause: A virtual disk
has been deleted. Perfor ming a Reset Configuration may detect that a virtual disk has been deleted.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert:
None
Related Alert Number:
2065, 2305, 2367
LRA Number:
None
Clear Alert:
None
Related Alert:
None
LRA Number:
None
Clear Alert:
None
Related Alert:
None
LRA Number: 2080
Clear Alert:
None
Related Alert:
None
LRA Number:
None
SNMP Tra p Numbers
901
1201
1203
1201
74
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2056 Virtual disk
failed
Critical / Failure / Error
Cause: One or more physical disks included in the virtual disk have failed. If the virtual disk is non-redundant (does not use mirrored or parity data), then the failure of a single physical disk can cause the virtual disk to fail. If the virtual disk is redundant, then more physical disks have failed than can be rebuilt using mirrored or parity information.
Create a new
Action: virtual disk and restore from a backup.
The disk controller rebuilds the virtual disk by first configuring a hot spare for the disk, and then initiating a write operation to the disk. The write operation initiates a rebuild of the disk.
Clear Alert:
None
Related Alert Number:
2048, 2049, 2050, 2076, 2079, 2081, 2129, 2346
LRA Number: 2081
SNMP Trap Numbers
1204
Storage Management Message Reference
75
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2057 Virtual disk
degraded
War n in g / Non-critical
Cause 1: This alert message occurs when a physical disk included in a redundant virtual disk fails. Because the virtual disk is redundant (uses mirrored or parity information) and only one physical disk has failed, the virtual disk can be rebuilt.
Action 1: Configure a hot spare for the virtual disk, if one is not already configured. Rebuild the virtual disk. If you are using an Expandable RAID Controller (PERC) PERC 3/SC, 3/DCL, 3/DC, 3/QC, 4/SC, 4/DC, 4e/DC, 4/Di, CERC ATA100/4ch, PERC 5/E, PERC 5/i or a Serial Attached SCSI (SAS) 5/iR controller, rebuild the virtual disk by first configuring a hot spare for the disk, and then initiating a write operation to the disk. The write operation initiates a rebuild of the disk.
Clear Alert Number:
None
Related Alert Number:
2048, 2049, 2050, 2076, 2079, 2081, 2123, 2129, 2346
LRA Number: 2080
SNMP Tra p Numbers
1203
76
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2057 contd.
2058 Virtual disk
check consistency started
2059 Virtual disk
format started
OK / Normal / Informational
OK / Normal / Informational
Cause 2: A physical disk in the disk group has been removed.
Action 2: If a physical disk was removed from the disk group, either replace the disk or restore the original disk. You can identify which disk has been removed by locating the disk that has a red “X” for its status. Perform a rescan after replacing the disk.
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert Number:
2085.
Related Alert Number:
None
LRA Number:
None
Clear Alert Number:
2086.
Related Alert Number:
None
LRA Number:
None
SNMP Trap Numbers
1201
1201
Storage Management Message Reference
77
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2060 Copy of data
started on physical disk 1 from physical disk 2.
2061 Virtual disk
initialization started
2062 Physical disk
initialization started
OK / Normal /Informationa l
OK / Normal / Informational
OK / Normal / Informational
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert Number:
None
Related Alert Number: 2075
LRA Number:
None
Clear Alert Number:
2088.
Related Alert Number:
None
LRA Number:
None
Clear Alert Number:
2089.
Related Alert Number:
None
LRA Number:
None
SNMP Tra p Numbers
901
1201
901
78
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2063 Virtual disk
reconfiguratio n started
2064 Virtual disk
rebuild started
2065 Physical disk
rebuild started
OK / Normal / Informational
OK / Normal / Informational
OK / Normal / Informational
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert Number:
2090.
Related Alert Number:
None
LRA Number:
None
Clear Alert Number:
2091.
Related Alert Number:
None
LRA Number:
None
Clear Alert Number:
2092.
Related Alert Number:
2099, 2121, 2196
LRA Number:
None
SNMP Trap Numbers
1201
1201
901
Storage Management Message Reference
79
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2067 Virtual disk
check consistency cancelled
OK / Normal / Informational
Cause: The check consistency operation was cancelled because a physical disk in the array has failed or because a user cancelled the check consistency operation.
Action: If the physical disk failed, then replace the physical disk. You can identify which disk failed by locating the disk that has a red “X” for its status. Perform arescan after replacing the disk. When performing a consistency check, be aware that the consistency check can take a long time. The time it takes depends on the size of the physical disk or the virtual disk.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
None
SNMP Tra p Numbers
1201
80
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2070 Virtual disk
initialization cancelled
2074 Physical disk
rebuild cancelled
OK / Normal / Informational
OK / Normal / Informational
Cause: The virtual disk initialization cancelled because a physical disk included in the virtual disk has failed or because a user cancelled the virtual disk initialization.
Action: If a physical disk failed, then replace the physical disk. You can identify which disk has failed by locating the disk that has a red “X” for its status. Perform a rescan after replacing the disk. Restart the format physical disk operation. Restart the virtual disk initialization.
Cause: The user has cancelled the rebuild operation.
Action: Restart the rebuild operation.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
None
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
None
SNMP Trap Numbers
1201
901
Storage Management Message Reference
81
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2075 Copy of data
completed on physical disk %2 from physical disk %1
2076 Virtual disk
Check Consistency failed
OK / Normal / Informational
Critical / Failure / Error
Cause: This alert is provided for informational purposes.
Action: None
Cause: A physical disk
included in the virtual disk failed or there is an error in the parity information. A failed physical disk can cause errors in parity information.
Action: Replace the failed physical disk. You can identify which disk has failed by locating the disk that has a red “X” for its status. Rebuild the physical disk. When finished, restart the check consistency operation.
Clear Alert Number:
None
Related Alert Number:
2060.
LRA Number:
None
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2081
SNMP Tra p Numbers
901
1204
82
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2077 Virtual disk
format failed
2079 Virtual disk
initialization failed
2080 Physical disk
initialization failed
Critical / Failure / Error
Critical / Failure / Error
Critical / Failure / Error
Cause: A physical disk included in the virtual disk failed.
Action: Replace the failed physical disk. You can identify which physical disk has failed by locating the disk that has a red X for its status. Rebuild the physical disk. When finished, restart the virtual disk format operation.
Cause: A physical disk included in the virtual disk has failed or a user has cancelled the initialization.
Action: If a physical disk has failed, then replace the physical disk.
Cause: The physical disk has failed or is corrupt.
Action: Replace the failed or corrupt disk. You can identify a disk that has failed by locating the disk that has a red “X” for its status. Restart the initialization.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2081
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2081
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2071
SNMP Trap Numbers
1204
1204
904
Storage Management Message Reference
83
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2081 Virtual disk
reconfiguratio n failed
Critical / Failure / Error
Hardware RAID:
Cause: A physical disk
included in the virtual disk has failed or is corrupt. A user may also have cancelled the reconfiguration.
Action: Replace the failed or corrupt disk. You can identify a disk that has failed by locating the disk that dispalys a red X in the status field.
If the physical disk is part of a redundant array, then rebuild the physical disk. When finished, restart the reconfiguration.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2081
SNMP Tra p Numbers
1204
84
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2081
Virtual disk
contd.
reconfiguratio n failed
2082 Virtual disk
rebuild failed
Critical / Failure / Error
Critical / Failure / Error
Software RAID:
•Perform a backup with the Verify option.
• If the file backup fails, try to restore the failed file from a previous backup.
• When the backup with the Verify option is complete without any errors, delete the Virtual Disk.
• Recreate a new Virtual Disk with new drives.
• Restore the data from backup.
Cause: A physical disk included in the virtual disk has failed or is corrupt. A user may also have cancelled the rebuild.
Action: Replace the failed or corrupt disk. You can identify a disk that has failed by locating the disk that has a red “X” for its status. Restart the virtual disk rebuild.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2081
Clear Alert Number:
None
Related Alert Number: 2048
LRA Number:
2081
SNMP Trap Numbers
1204
1204
Storage Management Message Reference
85
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2083 Physical disk
rebuild failed
2085 Virtual disk
check consistency completed
2086 Virtual disk
format completed
Critical / Failure / Error
OK / Normal / Informational
OK / Normal / Informational
Cause: A physical disk included in the virtual disk has failed or is corrupt. A user may also have cancelled the rebuild.
Action: Replace the failed or corrupt disk. You can identify a disk that has failed by locating the disk that has a red “X” for its status. Rebuild the virtual disk rebuild.
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert Number:
None
Related Alert Number:
None
LRA Number: 2071
Clear Alert Status: Alert
2085 is a clear alert for alert
2058.
Related Alert Number:
None
LRA Number:
None
Clear Alert Status: Alert
2086 is a clear alert for alert
2059.
Related Alert Number:
None
LRA Number:
None
SNMP Tra p Numbers
904
1201
1201
86
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2087 Copy of data
resumed from physical disk %2 to physical disk %1
2088 Virtual disk
initialization completed
2089 Physical disk
initialization completed
OK / Normal / Informational
OK / Normal / Informational
OK / Normal / Informational
Cause: This alert is for informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Cause: This alert is for
informational purposes.
Action: None
Clear Alert Status: None
Related Alert Number: 260.
LRA Number:
None
Clear Alert Status: Alert
2088 is a clear alert for alerts 2061 and
2136.
Related Alert Number:
None
LRA Number:
None
Clear Alert Status: Alert
2089 is a clear alert for alert
2062.
Related Alert Number:
None
LRA Number:
None
SNMP Trap Numbers
901
1201
901
Storage Management Message Reference
87
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2090
Virtual disk reconfiguration completed
2091 Virtual disk
rebuild completed
2092 Physical disk
rebuild completed
OK / Normal / Informational
OK / Normal / Informational
OK / Normal / Informational
Cause:
This alert is for
informational purposes.
Action:
None
Cause:
This alert is for
informational purposes.
Action:
None
Cause:
This alert is for
informational purposes.
Action:
None
Clear Alert
Alert
Status:
2090 is a clear alert for alert
2063.
Related Alert Number:
None
LRA Number:
None
Clear Alert
Alert
Status:
2091 is a clear alert for alert
2064.
Related Alert Number:
None
LRA Number:
None
Clear Alert Status:
Alert 2092 is a clear alert for alert
2065.
Related Alert Number:
None
LRA Number:
None
SNMP Tra p Numbers
1201
1201
901
88
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2094 Predictive
Failure reported.
War n in g / Non-critical
Cause:
The physical disk is predicted to fail. Many physical disks contain Self Monitoring Analysis and Reporting Technology (SMART). When enabled, SMART monitors the health of the disk based on indications such as the number of write operations that have been performed on the disk.
Action:
Replace the physical disk. Even though the disk may not have failed yet, it is strongly recommended that you replace the disk.
If this disk is part of a redundant virtual disk,
Offline
perform the task on the disk; replace the disk; and then assign a hot spare and the rebuild starts automatically.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
SNMP Trap Numbers
903
Storage Management Message Reference
89
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2094 cond.
2095 SCSI sense
data.
2098 Global hot
spare assigned
OK / Normal / Informational
OK / Normal / Informational
If this disk is a hot spare, then unassign the hot spare; perform the
Prepare to Remove
on the disk; replace the disk; and assign the new disk as a hot spare.
CAUTION:
disk is part of a nonredundant disk, back up your data immediately. If the disk fails, you cannot recover the data.
Cause:
A SCSI device experienced an error, but may have recovered.
Action:
None
Cause:
A user has assigned a physical disk as a global hot spare. This alert is for informational purposes.
Action:
None
task
If this
Clear Alert Number:
None
Related Alert Number:
LRA Number:
None
Clear Alert Number:
None
Related Alert Number:
LRA Number:
None
2273
2277
SNMP Tra p Numbers
751, 851, 901
901
90
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2099 Global hot
spare unassigned
2100 Temperature
exceeded the maximum warning threshold
OK / Normal / Informational
War n in g / Non-critical
Cause:
A user has unassigned a physical disk as a global hot spare. This alert is for informational purposes.
Action:
None
Cause:
The physical disk enclosure is too hot. A variety of factors can cause the excessive temperature. For example, a fan may have failed, the thermostat may be set too high, or the room temperature may be too hot.
Action:
Check for factors that may cause overheating. For example, verify that the enclosure fan is working. You should also check the thermostat settings and examine whether the enclosure is located near a heat source. Make sure the enclosure has enough ventilation and that the room temperature is not too hot. See the physical disk enclosure documentation for more diagnostic information.
Clear Alert Number:
None
Related Alert Number:
LRA Number:
None
Clear Alert Number:
2353.
Related Alert Number:
LRA Number:
2090
None
2112
SNMP Trap Numbers
901
1053
Storage Management Message Reference
91
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2101 Temperature
dropped below the minimum warning threshold
2102 Temperature
exceeded the maximum failure threshold
War n in g / Non-critical
Critical / Failure / Error
Cause:
The physical disk enclosure is too cool.
Action:
Check if the thermostat setting is too low and if the room temperature is too cool.
Cause:
The physical disk enclosure is too hot. A variety of factors can cause the excessive temperature. For example, a fan may have failed, the thermostat may be set too high, or the room temperature may be too hot.
Action:
Check for factors that may cause overheating. For example, verify that the enclosure fan is working. You should also check the thermostat settings and examine whether the enclosure is located near a heat source. Make sure the enclosure has enough ventilation and that the room temperature is not too hot. See the physical disk enclosure documentation for more diagnostic information.
Clear Alert Number:
2353.
Related Alert Number:
None
LRA Number:
2090
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2091
SNMP Tra p Numbers
1053
1054
92
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2103 Temperature
dropped below the minimum failure threshold
2104 Controller bat-
tery is recondi­tioning
2105 Controller
battery recondition is completed
Critical / Failure / Error
OK / Normal / Informational
OK / Normal / Informational
Cause:
The physical disk enclosure is too cool.
Action:
Check if the thermostat setting is too low and if the room temperature is too cool.
Cause:
This alert is for
informational purposes.
Action:
None
Cause:
This alert is for
informational purposes.
Action:
None
Clear Alert Number:
None
Related Alert Number:
LRA Number:
2091
Clear Alert Number:
2105.
Related Alert Number:
None
LRA Number:
None
Clear Alert Status:
2105 is a clear alert for alert
2104.
Related Alert Number:
None
LRA Number:
None
2112
Alert
SNMP Trap Numbers
1054
1151
1151
Storage Management Message Reference
93
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2106 SMART FPT
exceeded
War n in g / Non-critical
Cause:
A disk on the specified controller has received a SMART alert (predictive failure) indicating that the disk is likely to fail in the near future.
Action:
Replace the disk that has received the SMART alert. If the physical disk is a member of a non-redundant virtual disk, then back up the data before replacing the disk.
CAUTION:
Removing a physical disk that is included in a non-redundant virtual disk causes the virtual disk to fail and may cause data loss.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
SNMP Tra p Numbers
903
94
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2107 SMART
configuration change
Critical / Failure / Error
Cause:
A disk has received a SMART alert (predictive failure) after a configuration change. The disk is likely to fail in the near future.
Action:
Replace the disk that has received the SMART alert. If the physical disk is a member of a non­redundant virtual disk, then back up the data before replacing the disk.
CAUTION:
Removing a physical disk that is included in a non-redundant virtual disk causes the virtual disk to fail and may cause data loss.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2071
SNMP Trap Numbers
904
Storage Management Message Reference
95
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2108 SMART
warning
War n in g / Non-critical
Cause:
A disk has received a SMART alert (predictive failure). The disk is likely to fail in the near future.
Action:
Replace the disk that has received the SMART alert. If the physical disk is a member of a non-redundant virtual disk, then back up the data before replacing the disk.
CAUTION:
Removing a physical disk that is included in a non-redundant virtual disk causes the virtual disk to fail and may cause data loss.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
SNMP Tra p Numbers
903
96
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2109 SMART
warning temperature
War n in g / Non-critical
Cause:
A disk has reached an unacceptable temperature and received a SMART alert (predictive failure). The disk is likely to fail in the near future.
Action 1:
why the physical disk has reached an unacceptable temperature. A variety of factors can cause the excessive temperature. For e x a m ple, a fan may have failed, the thermostat may be set too high, or the room temperature may be too hot or cold. Verify that the fans in the server or enclosure are working. If the physical disk is in an enclosure, you should check the thermostat settings and examine whether the enclosure is located near a heat source.
Determine
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
SNMP Trap Numbers
903
Storage Management Message Reference
97
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2109 contd
Make sure the enclosure has enough ventilation and that the room temperature is not too hot. See the physical disk enclosure documentation for more diagnostic information.
Action 2:
identify why the disk has reached an unacceptable temperature, then replace the disk. If the physical disk is a member of a non-redundant virtual disk, then back up the data before replacing the disk.
Removing a physical disk that is included in a non-redundant virtual disk causes the virtual disk to fail and may cause data loss.
If you cannot
CAUTION:
SNMP Tra p Numbers
98
Storage Management Message Reference
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2110 SMART
warning degraded
2111 Failure
prediction threshold exceeded due to test
War n in g / Non-critical
War n in g / Non-critical
Cause:
A disk is degraded and has received a SMART alert (predictive failure). The disk is likely to fail in the near future.
Action:
Replace the disk that has received the SMART alert. If the physical disk is a member of a non­redundant virtual disk, then back up the data before replacing the disk.
CAUTION:
Removing a physical disk that is included in a non-redundant virtual disk causes the virtual disk to fail and may cause data loss.
Cause:
A disk has received a SMART alert (predictive failure) due to test conditions.
Action:
None
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2070
SNMP Trap Numbers
903
903
Storage Management Message Reference
99
Table 3-4. Storage Management Messages
(continued)
EventIDDescription Severity Cause and Action Related Alert
Information
2112 Enclosure was
shut down
Critical / Failure / Error
Cause:
The physical disk enclosure is either hotter or cooler than the maximum or minimum allowable temperature range.
Action:
Check for factors that may cause overheating or excessive cooling. For example, verify that the enclosure fan is working. You should also check the thermostat settings and examine whether the enclosure is located near a heat source. Make sure the enclosure has enough ventilation and that the room temperature is not too hot or too cold. See the enclosure documentation for more diagnostic information.
Clear Alert Number:
None
Related Alert Number:
None
LRA Number:
2091
SNMP Tra p Numbers
854
100
Storage Management Message Reference
Loading...
