Introduction

This introduction is divided into two sections. The first section, "Introduction to the SNMP Reference Guide," explains the SNMP Reference Guide design. All essential Simple Network Management Protocol (SNMP) terms are defined in this section. Some of the vocabulary may seem complex and unfamiliar to system administrators who are using SNMP for the first time. SNMP experts can skim this section, and beginners can read the section more carefully.

The second section, "Introduction to the Server Administrator SNMP Subagent," is a more technical introduction to the management information base (MIB) that underlies Server Administrator services.

Audience

This guide is intended for system administrators, network administrators, and anyone who wants to write SNMP MIB applications to monitor systems.

What’s New in this Release

This section lists changes to the Server Administrator MIBs in this release of Server Administrator.

What's New in the Instrumentation MIB

• Updated the Processor Device Family with the new value.

• Increased the size of the following MIB string attributes:

–

systemManagementSoftwareURLName

–

operatingSystemOperatingSystemName

–

operatingSystemOperatingSystemVersionName

deviceFamilyIsIntelCore2(190)

What's New in the Remote Access MIB

No changes.

What's New in the Field Replaceable Unit MIB

No changes.

Introduction 13

What's New in the Storage Management Group MIB

• Added the new

• Changed the syntax of the following objects from octet strings to display strings:

controllerPCISlot

–

enclosureSCSIRate

–

arrayDiskSASAddress

enclosureSASAddress

attribute to the Enclosure Table.

What's New in the Change Management MIB

No changes.

Introduction to the SNMP Reference Guide

This reference guide provides a formatted version of the Server Administrator Instrumentation MIB (filename 10892.mib), the Server Administrator Remote Access MIB (filename dcs3rmt.mib), the Server Administrator Field Replaceable Unit MIB (filename dcs3fru.mib), the Server Administrator Storage Management MIB (filename dcstorag.mib), and the Server Administrator Change Management MIB (filename dellcm.mib) that are released with the current version of Dell™ OpenManage™ Server Administrator.

Sections in this guide follow MIB groups and provide explanations and definitions for the terms used to define MIB objects. Content in this reference guide is organized as documented in the following subsections.

General Content

Table 1-1 describes the sections that provide general information about the MIBs documented in this guide.

Table 1-1. General Content Sections in This Guide

Section Topics MIB Group

Number

1 Introduction to SNMP basics and to the MIBs that support Server Administrator services NA

25 Traps — describes in-band traps defined in the Server Administrator Instrumentation

MIB and out-of-band traps sent by the Remote Access Controller (RAC) and Baseboard Management Controller (BMC).

Appendix A Standard Data Type Definitions — defines standard data types used in this

reference guide.

Appendix B SNMP Sample Output — provides a sample SNMP output. NA

Glossary Defines acronyms, abbreviations, and technical terms used in this reference guide. NA

5000

14 Introduction

Server Administrator Instrumentation MIB

The Server Administrator Instrumentation MIB (filename 10892.mib) provides instrumentation data that allows you to monitor the health of a system with SNMP management applications. It provides:

• Information about the status of temperatures, power supplies, voltages, currents, fans, and memory at key points in the system

• Rapid access to detailed fault and performance information gathered by industry standard systems management agents

• Version information for Basic Input/Output System (BIOS), firmware, and operating system

• A detailed account of every cost of ownership (COO) detail about your system

In addition, traps are sent to report a change in status of the health of critical components.

The Server Administrator Instrumentation MIB structures its MIB objects into groups of scalar objects or MIB tables that provide related information. Table 1-2 describes each Server Administrator Instrumentation MIB group and lists the MIB group number assigned to the MIB group. The Server Administrator Instrumentation MIB groups are identified by the SNMP OID

1.3.6.1.4.1.674.10892.1.<MIB group number>, where <MIB group number> is the MIB group number assigned to the MIB group. See the relevant section for more information about the MIB objects defined in a MIB group.

Table 1-2. Server Administrator Instrumentation MIB Sections in This Guide

Section Topics MIB Group

Numbers

2 Instrumentation MIB Version Group — defines version numbers of the Instrumentation MIB 1

3 Systems Management Software Group — defines information about the systems

management software and the supported systems management standards

4 System State Group — defines status, state, and redundancy for a system and its components 200

5 Chassis Information Group — defines chassis types, events, and indicators 300

6 Operating System Group — defines variables for name, version, service pack, and other

information about a system’s operating system

7 System Resource Group — defines variables for input/output ports, memory, interrupts, and

direct memory access

8 Power Group — defines variables for power units, power supplies, and their current and

voltage probes

9 Thermal Group — defines variables for temperature probes and cooling devices 700

10 User Security Group — defines variables for creating and modifying user accounts 800

11 Remote Flash BIOS Group — defines variables for updating the system’s BIOS remotely 900

12 Port Group — defines variables for major port types such as keyboard, monitor, small computer

system interface (SCSI), Universal Serial Bus (USB), and parallel and serial ports

100

400

500

600

1000

Introduction 15

Table 1-2. Server Administrator Instrumentation MIB Sections in This Guide (continued)

Section Topics MIB Group

Numbers

13 Device Group — defines variables for pointing, keyboard, processor, cache, memory,

and personal computer interface devices

14 Slot Group — defines variables for the system’s slots 1200

15 Memory Group — defines variables for the system’s physical memory 1300

16 BIOS Setup Control Group — defines variables for BIOS functions such as boot sequence,

speakers, Wake on the local area network (LAN), diskettes, ports, and network interface controllers (NIC)

17 Local Response Agent Group — defines variables for global settings and actions. These variables

allow users to predetermine how the system responds to a particular type of event

18 Cost of Ownership Group — defines variables for tracking data on the system’s service

contract, lease, repair records, trouble tickets, and so on

20 Cluster Group — defines variables for systems that operate as a cluster 1800

21 Baseboard Management Controller Group — provides information about the Baseboard

Management Controller (BMC) that may be present in your system. In addition to providing general information about the BMC, this group provides information about the serial and local area network (LAN) interfaces of the BMC

25 Traps — defines the types of alerts that can be sent to report the status of critical components 5000

1100

1400

1500

1600

1900

Server Administrator Remote Access MIB

The Server Administrator Remote Access MIB (filename dcs3rmt.mib) provides in-band information about remote access hardware that may be present in your system.

The Server Administrator Remote Access MIB structures its MIB objects into groups of scalar objects or MIB tables that provide related information. Table 1-3 describes each Server Administrator Remote Access MIB group and lists the MIB group number assigned to the MIB group. The Server Administrator Remote Access MIB groups are identified by the SNMP OID 1.3.6.1.4.1.674.10892.1.<MIB group number> where <MIB group number> is the MIB group number assigned to the MIB group. See the relevant section for more information about the MIB objects defined in a MIB group.

Table 1-3. Server Administrator Remote Access MIB Sections in This Guide

Section Topic MIB Group

Numbers

19 Remote Access Group — provides information about remote access hardware that may be

present in your system and defines variables for administrative users, SNMP trap destinations, modem configuration for dial-up networking, dial-in configuration, and dial-out destinations

1700

16 Introduction

Server Administrator Baseboard Management Controller, ASF MIB

The Server Administrator BMC MIB (filename DcAsfSrv.mib) provides information about the traps sent by BMC. The Server Administrator BMC MIB structures its MIB objects that provide related information. The BMC MIB groups are identified by the SNMP OID 1.3.6.1.4.1.3183.1.1.<MIB group number> The BMC MIB is adheres to ASF 2.0 standard and hence the enterprise ID is wired for management (3183).

Server Administrator Field Replaceable Unit MIB

The Server Administrator Field Replaceable Unit MIB (filename dcs3fru.mib) provides information about field replaceable unit (FRU) hardware that may be present in your system.

The Server Administrator Field Replaceable Unit MIB structures its MIB objects into groups of scalar objects or MIB tables that provide related information. Table 1-4 describes each Server Administrator Field Replaceable Unit MIB group and lists the MIB group number assigned to the MIB group. The Server Administrator Field Replaceable Unit MIB groups are identified by the SNMP OID

1.3.6.1.4.1.674.10892.1.<MIB group number> where <MIB group number> is the MIB group number assigned to the MIB group. See the relevant section for more information about the MIB objects defined in a MIB group.

Table 1-4. Server Administrator Field Replaceable Unit MIB Sections in This Guide

Section Topic MIB Group

Numbers

22 Field Replaceable Unit Group — provides information about field replaceable units that

may be present in your system

2000

Server Administrator Storage Management MIB

The Server Administrator Storage Management MIB (filename dcstorag.mib) provides storage management data that allows you to monitor the health of storage resources with SNMP management applications.

Table 1-5 describes each Server Administrator Storage Management MIB group and lists the MIB group number assigned to the MIB group. The Server Administrator Storage Management MIB groups are identified by the SNMP OID 1.3.6.1.4.1.674.<MIB group number> where <MIB group number> is the MIB group number assigned to the MIB group. See the relevant section for more information about the MIB objects defined in a MIB group.

Introduction 17

Table 1-5. Server Administrator Storage Management MIB Sections in This Guide

Section Topics MIB Group

Numbers

23 Storage Management Group — consists of definitions for the following MIB groups:

• Storage Management Group

• Storage Management Information Group

• Global Data Group

• Physical Devices Group

• Logical Devices Group

• Storage Management Event Group

26 Storage Management Alert Reference — lets you monitor the health of storage

resources such as controllers, connectors, array disks, and virtual disks

10893

Server Administrator Change Management MIB

The Server Administrator Change Management MIB (filename dellcm.mib) provides management data that allows you to monitor the inventory of devices and applications with SNMP management applications.

Table 1-6 describes each Server Administrator Change Management MIB group and lists the MIB group number assigned to the MIB group. The Server Administrator Change Management MIB groups are identified by the SNMP OID 1.3.6.1.4.1.674.<MIB group number> where <MIB group number> is the MIB group number assigned to the MIB group. See the relevant section for more information about the MIB objects defined in a MIB group.

Table 1-6. Server Administrator Change Management MIB Sections in This Guide

Section Topics MIB Group

Number

24 Change Management Group - describes the inventory data provided by the

Change Management MIB that allows users to monitor devices and software present on a particular managed computer chassis

10899

How This Guide Defines Technical Terms

The following table provides information about where to find definitions for technical terms in this reference guide.

18 Introduction

Table 1-7. Where to Find Definitions for Technical Terms

Type of Definition See

Basic SNMP vocabulary. Introduction

MIB-group-specific variable values. MIB-group-specific MIB variables contain links to the tables that define these values in the last section of the section in which these variables are used.

Systems management terms, acronyms, and commonly managed components referred to in this reference guide.

Server Administrator-standard data types that specify variable values in this reference guide.

Sections 3, 5, 7, 8, 9, and 11 through 18.

Glossary

Appendix A, "Standard Data Type Definitions."

SNMP Basic Terminology

It is important to have a good understanding of the key technical terms used in this guide. This guide provides definitions for all essential terms used in describing the Server Administrator MIBs. The Glossary contains definitions for all essential terms and acronyms.

SNMP Master Agent

Typically, the SNMP agent on a managed system consists of one SNMP master agent and zero or more SNMP extension agents. This SNMP agent extendable structure facilitates the addition of new MIB modules without having to rebuild the entire SNMP agent and is invisible to SNMP management applications.

The SNMP master agent is responsible for receiving SNMP request protocol messages from SNMP management applications and sending SNMP response protocol messages. As part of processing SNMP request protocol messages, the SNMP master agent typically communicates with one or more SNMP extension agents. This communication does not involve standard SNMP protocol messages. The SNMP master agent uses an extension protocol that shields the SNMP extension agent from the standard SNMP protocol messages. The extension protocol also provides a way for SNMP extension agents to send SNMP event notifications (called traps in SNMPv1). The SNMP master agent is also responsible for sending SNMP event notification protocol messages to SNMP management applications.

On supported operating systems, the SNMP master agent is provided with the operating system. For example, on supported Microsoft SNMP master agent. For information on the versions of the SNMP protocol supported by the SNMP master agent, see the operating system documentation.

Windows® operating systems, the Windows SNMP service is the

SNMP Extension Agent

The SNMP extension agent is responsible for registering the MIB objects that it supports with the SNMP master agent and then processing requests from the SNMP master agent for those MIB objects. The SNMP extension agent also initiates event notifications to the SNMP master agent. The SNMP extension agent does not receive or send standard SNMP protocol messages. The SNMP extension agent communicates with the SNMP master agent using an extension protocol defined by the SNMP master agent.

The Server Administrator SNMP subagent is an SNMP extension agent.

Introduction 19

Managed Object

A managed object is any item in a computer system that can be singled out for discovery, monitoring, or user intervention and correction.

NOTE: Not all managed objects described in this guide are supported by all systems.

MIB

A MIB acts as a structured road map for managed objects. As an Application Programming Interface (API), a MIB allows systems management tools to retrieve data maintained by an agent. The server administrator MIB is divided into several major groups of managed objects.

Variable

A variable is a component of a managed object. A temperature probe, for example, has a variable to describe its capabilities, its health or status, and certain indexes that you can use to locate specific temperature probes. One index for the probe would be the probe’s chassis number. Some systems may have multiple chassis—one chassis for the central processing unit and another chassis for storage. A chassis within a system can also have more than one temperature probe. Variables for a temperature probe include its capabilities, status, chassis index, and index.

One-Based Index

When an index is one-based, counting starts at 1. One-based indexing counts the first instance as 1, the second index as 2, and so on.

Zero-Based Index

When an index is zero-based, counting starts at 0. Zero-based indexing counts the first instance as 0, the second index as 1, and so on.

Fields

Managed object variables contain fields. In this reference guide, managed object variables have the following fields defined:

Name is the exact string by which the variable is known in the MIB. MIB variables are named according to the following conventions:

• Variable names start with a lowercase letter.

• Spaces are not allowed between words in the variable name.

• Acronyms are in uppercase letters, except when an acronym is the first word in the variable name.

• With the exception of the first letter of the variable name and acronyms, all other words in the variable name start with capital letters.

20 Introduction

The following variable names illustrate these conventions:

temperatureProbeLowerCriticalThreshold coolingUnitIndex pCIDeviceSpeed

Object Identifier (OID) is the unique number assigned to an object defined in a MIB. An OID is written as a sequence of subidentifiers in decimal notation. Each OID in this reference guide has a prefix that identifies the managed objects as belonging to Dell™: 1.3.6.1.4.1.674. The additional numbers identify the MIB group and subgroup as well as the table entry number of any variables.

For example, the OID for the temperature probe managed object table is 700.20 and the variable for the location of the temperature probe (temperatureProbeLocationName) has an OID of 700.20.1.8. The full OIDs for these items are 1.3.6.1.4.1.674.10892.1.700.20 for the temperatureProbeTable and

1.3.6.1.4.1.674.10892.1.700.20.1.8 for the temperatureProbeLocation. For more information about the structure of OIDs, see "SNMP MIB OIDs."

Description is a brief explanation of what a particular managed object does.

Syntax defines the data type in which the values of the variable must be expressed. Most variables in this

reference guide use standard data types such as string or boolean. All data types that are unique to server administrator variables are defined at the end of the section in which they occur. Standard data types are defined in "Standard Data Type Definitions."

Access specifies whether persons with administrative privileges can read but not modify the value of a variable (read only) or can both read and modify the value of a variable (read-write).

Frequently Used Terms in Variable Names

The following terms are frequently used in the name of a MIB variable:

Capability refers to the actions an object can perform, or to actions that can be taken by the object. Hot-pluggable is an example of a capability. If a card is hot-pluggable, it can be replaced while a system is running. Capability settings refer to the capabilities of the object that the user can select from and activate if desired. Capability settings allow users of the server administrator to predetermine how an object will behave under specific conditions.

Settings are the conditions of a manageable object that determine what happens when a certain value is detected in a component. For example, a user can set the upper critical threshold of a temperature probe to 75 degrees Celsius. If the probe reaches that temperature, the setting causes an alert to be sent to the management console. Some settings, when reached, can trigger a system shutdown or other response to prevent damage to the system.

State refers to the condition of an object that has more than one condition. For example, an object may be in a "not ready" or in an "enabled" state.

Status refers to the health of an object or how the object is functioning. For example, the status of a temperature probe that is measuring acceptable temperatures would be reported as normal. When the probe begins reading temperatures that exceed limits set by the user, it reports a critical status.

Introduction 21

Tabl es

This reference guide contains two types of tables: tables that are used to organize and define variable values and tables that define MIB objects. Readers must understand the differences between these two types of tables.

SNMP Tables

Most of the MIB objects defined in this reference guide are organized into SNMP tables. SNMP tables organize data into two-dimensional structural arrays. In SNMP, objects that have a relationship to other objects are called columnar objects. Columnar objects are the type of object used to form lists and tables. When a MIB group is divided into one or more discrete tables, the word "table" has a technical meaning. An example is the section of this reference guide entitled Universal Unique Identifier (UUID). The UUID object has a type and a value that uniquely identify an object such as a chassis. The table defines all of the variables that comprise the managed object UUID.

The following table is an example of an SNMP table. The table contains variables that must occur in a definite sequence. In the example table the defined variables are UUID Chassis Index, UUID Index, UUID Type, and UUID Value.

Example SNMP Table

UUID Table

These objects comprise the Server Administrator definitions for the UUID.

Name uUIDTable

Object ID 1.3.6.1.4.1.674.10892.1.300.20

Description Defines the UUID table.

Syntax SEQUENCE OF UUIDTableEntry

Access Not accessible

UUID Table Entry

Name uUIDTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1

Description Defines the UUID table entry.

Syntax UUIDTableEntry

Access Not accessible

Index uUIDIndex, uUIDchassisIndex

22 Introduction

UUID Chassis Index

Name uUIDchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

UUID Index

Name uUIDIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.2

Description Defines the index of the UUID in a specified chassis.

Syntax DellObjectRange

Access Read-only

UUID Type

Name uUIDType

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.3

Description Defines the type of the UUID for this chassis.

Syntax DellUUIDType

Access Read-only

UUID Value

Name uUIDValue

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.4

Description Defines the value of the UUID for this chassis.

Syntax OCTET STRING (SIZE[16])

Access Read-only

Introduction 23

Reference Guide Content Tables

NOTE: Variable values are defined for any variable that is Server Administrator-specific. Industry-standard

variable definitions are documented in "Standard Data Type Definitions."

Some of the tables in this guide have no technical significance in SNMP. These tables are designed to show information in a readable form. The following table, for example, defines the Server Administrator-specific variable, DellFanControlCapabilities. The table provides the name of the variable, its data type, the values that are valid for the variable, and the meaning of each value.

Table 1-8. Example Variable Type Definition Table

Variable Name: DellFanControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(1) The fan’s capabilities are unknown. lowSpeedCapable(2) The fan can be set to low speed. highSpeedCapable(4) The fan can be set to high speed. lowOrHighSpeedCapable(6) The fan can be set to low or high speed.

This type of table is used throughout the reference guide to list and define variable values. Tables that explain Server Administrator-specific variable values are located in the final section of sections that define Server Administrator-specific variables. In the preceding example, the variable name is DellFanControlCapabilities. This variable must be expressed as an integer and has four possible values: unknown, lowSpeedCapable, highSpeedCapable, and lowOrHighSpeed Capable.

Section Organization

Sections in this reference guide are based on the Server Administrator MIBs, so the complexity of each section depends on the complexity of each MIB group. The first section provides a high-level introduction to the MIB group. If the group is defined by one or more tables, the second section lists these tables. The third section documents the variables that comprise the group, and if applicable, the variables that comprise the tables. The fourth section contains definitions for any Server Administrator-specific variables that are used in the section. The following example shows the typical content of these four sections.

BIOS Setup Control Group

This section explains the purpose of the MIB group and summarizes the major features of the component groups.

BIOS Group Tables

If there is more than one SNMP table for a group, this section lists all of the tables. For this BIOS group example, there are eight tables listed. In each section, double-clicking any table on the list takes you to that table.

24 Introduction

• BIOS Setup Control Table

• SCSI Control Table

• Parallel Port Control Table

• Serial Port Control Table

• USB Control Table

• IDE Control Table

• Diskette Control Table

• Network Interface Control Table

Variables that make up each table in the group

This section documents the variables for the eight tables that comprise the BIOS group.

BIOS Variable Values

This section explains any Server Administrator-specific variables and data types that are used in this section. In the BIOS group example, there are 17 unique, Server Administrator-specific variable meanings. Information on each Server Administrator-specific variable is presented in a formatted table.

Introduction to the Server Administrator SNMP Subagent

This guide provides formatted information drawn primarily from the MIB files written for the Server Administrator services that support the SNMP protocol.

For each of the variables defined in the MIBs, the following fields are specified:

• Variable name

• OID or unique identifying number

•Description

• Data type of the variable (for example: integer, string, octet string)

• Whether the variable is accessible, not accessible, read-only, or read-write

• Index or indexes, if applicable

Introduction 25

For each MIB group that has unique variable definitions, tables are included in the last section of the section to explain the meaning of the terms.

Standards for writing MIBs are defined by the Internet Engineering Task Force (IETF). Structure of Management Information (SMI) is a standard that specifies the rules for defining the structure and type of managed objects and events in a MIB. SMIv1 is specified in Request For Comments (RFC) 1155. The Server Administrator MIB conforms to the SMIv1 standard.

SNMP is a systems management standard originally designed for network management. SNMP manages much more than networks. Information Technology (IT) professionals use SNMP for monitoring and managing computer systems and the various components and peripherals supported by their systems.

SNMP standards are defined by the Internet Engineering Task Force (IETF). SNMP version 1 was published in August 1988 and is the most commonly supported version of SNMP. SNMP version 2 was first published in May 1993, but has not gained widespread market acceptance. SNMP version 3 was recently completed and has addressed security issues that exist in version 1.

All SNMP systems consist of one or more managed systems that provide data through an SNMP agent to a management system. The management system provides a user interface to view data from the managed systems. The management system and managed systems communicate over a network (typically through User Datagram Protocol/Internet Protocol [UDP/IP]).

The management system and a managed system communicate by means of a common data schema. SNMP MIB files define the structure, type, and values of the SNMP data. While MIBs can be standardized or enterprise specific, most operating systems supply SNMP agents for the standard MIB-I and MIB-II schemas. MIB-I defines a base set of standard management information for systems implementing the Internet Protocol (IP) suite. MIB-II defines characteristics of the system, characteristics of network interfaces, and characteristics of components of the IP on the system. In addition to the standard MIBs, many hardware vendors have defined MIBs that provide management data specific to their systems and peripheral devices.

Monitored data can be retrieved through SNMP using the Get command. Typically, this command requires the host name or IP address of the target machine as well as the OID of the data to retrieve. Exact details are dependent on the operating system and the development tools being used to create the management application. The Get command has a variant known as GetNext.

SNMP MIB OIDs

Each data class within an MIB is defined by an OID. OIDs are unique across all MIBs. An OID consists of a series of digits separated by periods. The OID functions in a similar fashion to a phone number. The phone number 011-512-471-0000 uniquely identifies a single phone. The phone number can be broken down into a number of components to uniquely identify a phone. The first component, 011, is the country code for the United States. The second component, 512, identifies the area code for central Texas. The third component, 471, is the phone exchange for a large state university in the city of Austin. The final component, 0000, is the main switchboard.

26 Introduction

There are two main differences between the phone number example and an actual OID. The first difference is that there are many more components in an OID, up to 128. The combination of these components is called an OID prefix. The second difference is that OIDs support the concept of indexes or keys. The OID prefix specifies the data class but does not specify an instance of the data within the class. Indexes can be used to identify the instances of a data class. These indexes are referred to as the OID suffix.

The assignment of values for each OID prefix component can be illustrated by using a tree structure. The following is an example of an OID assignment:

ROOT

CCITT(0)

ISO(1)

ORG(3)

DOD(6)

INTERNET(1)

MGMT(2)

MIB(1)

EXPERIMENTAL(3)

PRIVATE(4)

ENTERPRISES(1)

DELL(674)

SNMPv2(6)

In the preceding example, the OID prefix for the Dell enterprise would be 1.3.6.1.4.1.674.

The numbers in boldface type show the categories and numbers that apply to Server Administrator. All Server Administrator-defined OIDs consist of 1.3.6.1.4.1.674 followed by additional component values.

SNMP Security

SNMP version 1 has a very limited security mechanism. SNMP agents support the use of a community string, which is configured at each SNMP agent and is passed as a part of all SNMP request messages. There is no verification that the requester is actually a member of the specified community.

Because most system and network management data is not confidential, this limited security is acceptable for Get types of requests. On the other hand, this security is not acceptable for Set types of operations where an SNMP request could power off a system, reconfigure a redundant array of independent disks (RAID) card, and so on. Some vendors have chosen not to support SNMP Set operations for this reason. Server Administrator is able to support SNMP Set operations because its

Introduction 27

SNMP agents implement a hash/digest mechanism to prevent unauthorized SNMP Set operations. One limitation of this practice is that only server administrator-developed SNMP management applications have the capability to support the hash/digest mechanism.

NOTE: The default SNMP agent configuration usually includes a SNMP community name such as public. For

security reasons, change the SNMP community names from their default values. For information about changing SNMP community names, see the Dell OpenManage Server Administrator User’s Guide. This guide is available on the Dell Support website at support.dell.com and on the Dell PowerEdge Installation and Server Management and Dell PowerEdge Documentation CDs. For additional guidelines, see the Securing an SNMP Environment article, dated May 2003, in the Dell Power Solutions magazine. This magazine is also available at www.dell.com/powersolutions.

NOTE: In Dell OpenManage Server Administrator version 5.2, SNMP Set operations are disabled by default. Server

Administrator provides support to enable or disable SNMP Set operations. For more information on enabling or disabling SNMP Set operations in Server Administrator, see the Dell OpenManage Server Administrator User’s Guide or the Dell OpenManage Server Administrator Command Line Interface User's Guide.

Management Actions

Management actions can be performed using the SNMP Set command. These actions can consist of configuring a phone number for the system’s owner, rebooting a system, or changing the asset tag of the system. See the previous section, "SNMP Security," for limitations on Set operations.

SNMP Traps

SNMP is frequently used to monitor systems for fault conditions such as temperature violations, hard drive failures, and so on. Management applications can monitor for these conditions by polling the appropriate OIDs with the Get command and analyzing the returned data. This method has its drawbacks. If it is done frequently, significant amounts of network bandwidth can be consumed. If it is done infrequently, the response to the fault condition may not occur in a timely fashion. SNMP traps avoid these limitations of the polling method.

An SNMP trap is an asynchronous event indicating that something significant has occurred. This is analogous to a pager receiving an important message, except that the SNMP trap frequently contains all the information needed to diagnose a fault.

Two drawbacks to SNMP traps are that they are sent using UDP, which is not a guaranteed delivery mechanism, and that they are not acknowledged by the receiver.

An SNMP trap message contains the trap’s enterprise OID, the agent IP address, a generic trap ID, the specific trap ID, a time stamp, and zero or more variable bindings (varbinds). The combination of an enterprise OID and a specific trap ID uniquely identifies each Server Administrator-defined trap. A varbind consists of an OID and its value and provides additional information about the trap.

In order for a management system to receive SNMP traps from a managed system, the node must be configured to send traps to the management system. Trap destination configuration is dependent on the operating system. When this configuration is done, a management application on the management system can wait for traps and act on them when received.

For a list of traps supported by the server administrator SNMP subagent, see "Traps."

28 Introduction

Instrumentation MIB Version Group

The Instrumentation Management Information Base (MIB) Version Group defines the attributes that identify the version of the Instrumentation MIB supported by the systems management software.

The mIBMajorVersionNumber, mIBMinorVersionNumber, and mIBMaintenanceVersionNumber attributes are scalar objects, meaning that they are not related to other MIB objects and are thus not placed in a table.

MIB Major Version Number

Name mIBMajorVersionNumber

Object ID 1.3.6.1.4.1.674.10892.1.1.1.0

Description Defines the major version number of the version of this MIB

supported by the systems management software. For example, if the MIB version is 1.2.3, the major version number is 1.

A major version number change indicates a major change in object functionality.

Syntax DellUnsigned8BitRange

Access Read-only

MIB Minor Version Number

Name mIBMinorVersionNumber

Object ID 1.3.6.1.4.1.674.10892.1.1.2.0

Description Defines the minor version number of the version of this MIB

supported by the systems management software. For example, if the MIB version is 1.2.3, the minor version number is 2.

A minor revision provides additional support for new objects as well as problem fixes.

Syntax DellUnsigned8BitRange

Access Read-only

Instrumentation MIB Version Group 29

MIB Maintenance Version Number

Name mIBMaintenanceVersionNumber

Object ID 1.3.6.1.4.1.674.10892.1.1.3.0

Description Defines the maintenance version number for the version of this MIB

supported by the systems management software. For example, if the MIB version is 1.2.3, the maintenance version number is 3.

Syntax DellUnsigned8BitRange

Access Read-only

30 Instrumentation MIB Version Group

Systems Management Software Group

The Systems Management Software Group allows users to see information about the standards and software that are supported by the agent of a particular managed computer chassis. The Systems Management Software Group classifies each computer chassis according to the systems management standard that the agent supports.

Additional objects define the universal resource locator (URL) of the systems management software and the language in which systems management information displays. Defining these objects enables users to manage a system using an internet browser. You can access Server Administrator using the secure hypertext transfer protocol (https) and a pre-assigned port number of 1311, or you can specify a port number of your own choosing.

NOTE: Using the Software → Server Preferences menu of Server Administrator, you can bind to either one

IP address or to all IP addresses.

NOTE: To manage a system remotely using Server Administrator, type one of the following in the address field

of your browser:

https://<systemname>:<1311

https://<IP address>:<1311

To manage a system locally using Server Administrator, type the following in the address field of your browser:

https://localhost:<1311

or user specified port number

or user-specified port number

Systems Management Software

The following objects describe the fields for server administrator systems management information. The systems management software variables are scalar objects, meaning that they are not related to other management information base (MIB) objects and are thus not placed in a table.

Systems Management Software Group 31

Systems Management Software Name

Name systemManagementSoftwareName

Object ID 1.3.6.1.4.1.674.10892.1.100.1

Description Defines the systems management software product name.

Syntax DellString

Access Read-only

Systems Management Software Version Number Name

Name systemManagementSoftwareVersionNumberName

Object ID 1.3.6.1.4.1.674.10892.1.100.2

Description Defines the version number of the systems management software.

Syntax DellString

Access Read-only

Systems Management Software Build Number

Name systemManagementSoftwareBuildNumber

Object ID 1.3.6.1.4.1.674.10892.1.100.3

Description Defines the build number of the systems management software.

Syntax DellUnsigned16BitRange

Access Read-only

Systems Management Software Description Name

Name systemManagementSoftwareDescriptionName

Object ID 1.3.6.1.4.1.674.10892.1.100.4

Description Defines the description of the systems management software.

Syntax DellString

Access Read-only

32 Systems Management Software Group

Systems Management Software Supported Protocol

Name systemManagementSoftwareSupportedProtocol

Object ID 1.3.6.1.4.1.674.10892.1.100.5

Description Defines the systems management standards (SNMP or CIM)

supported by the systems management software.

Syntax SMSSupportedTypes (See Table 3-1.)

Access Read-only

Systems Management Software Preferred Protocol

Name systemManagementSoftwarePreferredProtocol

Object ID 1.3.6.1.4.1.674.10892.1.100.6

Description Defines the preferred systems management standard for the systems

management software.

Syntax SMSSupportedTypes (See Table 3-1.)

Access Read-only

Systems Management Software Update Level Name

Name systemManagementSoftwareUpdateLevelName

Object ID 1.3.6.1.4.1.674.10892.1.100.7

Description Defines the update level of the system management software.

Syntax DellString

Access Read-only

Systems Management Software URL Name

Name systemManagementSoftwareURLName

Object ID 1.3.6.1.4.1.674.10892.1.100.8

Description Defines the universal resource locator (URL) of the systems

management software.

Syntax DisplayString (SIZE (0..1024))

Access Read-only

Systems Management Software Group 33

Systems Management Software Language Name

Name systemManagementSoftwareLanguageName

Object ID 1.3.6.1.4.1.674.10892.1.100.9

Description Defines the language of the systems management software.

Syntax DisplayString (SIZE (0..255))

Access Read-only

Systems Management Software Global Version Name

Name systemManagementSoftwareGlobalVersionName

Object ID 1.3.6.1.4.1.674.10892.1.100.10

Description Defines the global version of the systems management software.

Syntax DellString

Access Read-only

Systems Management Software Feature Flags

Name systemManagementSoftwareFeatureFlags

Object ID 1.3.6.1.4.1.674.10892.1.100.11

Description Defines the features of the systems management software.

Syntax SMSFeatureFlags (See Table 3-2)

Access Read-only

Systems Management Software SNMP Agent Feature Flags

Name systemManagementSoftwareSNMPAgentFeatureFlags

Object ID 1.3.6.1.4.1.674.10892.1.100.12

Description Defines the features of the SNMP agent software provided by the

operating system.

Syntax SMSSNMPAgentFeatureFlags (See Table 3-3)

Access Read-only

34 Systems Management Software Group

Systems Management Software Manufacturer Name

Name systemManagementSoftwareManufacturerName

Object ID 1.3.6.1.4.1.674.10892.1.100.13

Description Defines the manufacturer of the systems management software.

Syntax DellString

Access Read-only

Systems Management Software Variable Values

This section includes definitions of server administrator-specific variable values used in this section.

Table 3-1. Systems Management Software Supported Standards

Variable Name: SMSSupportedTypes Data Type: Integer

Possible Data Values Meaning of Data Value

supportsSNMP(1) This system supports SNMP. supportsDMI(2) This system supports DMI. supportsSNMPandDMI(3) This system supports SNMP and DMI. supportsCIMOM(4) This system supports CIM. supportsSNMPandCIMOM(5) This system supports SNMP and CIM.

Table 3-2. Systems Management Software Feature Flags

Variable Name: SMSFeatureFlags Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The Systems Management Software features are

not enabled.

webOneToOneManagementPreferred(1) The web 1:1 management preferred feature is

enabled.

Systems Management Software Group 35

Table 3-3. Systems Management Software SNMP Agent Feature Flags

Variable Name: SMSSNMPAgentFeatureFlags Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The Systems Management Software SNMP agent

features are not enabled.

supportsSparseTables(1) The SNMP agent supports sparse tables.

36 Systems Management Software Group

System State Group

The Management Information Base (MIB) variables presented in this section enable you to track various attributes that describe the state of the critical components supported by your system. Components monitored under the System State Group include power supplies, AC power cords, AC power switches, and cooling devices, as well as temperature, fan, amperage, and voltage probes.

System State Group Table

The System State Group defines objects in the System State MIB table.

System State Table

The following object sets up the System State Table:

Name systemStateTable

Object ID 1.3.6.1.4.1.674.10892.1.200.10

Description Defines the System State Table.

Syntax SEQUENCE OF SystemStateTableEntry

Access Not accessible

System State Table Entry

Name systemStateTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1

Description Defines the System State Table entry.

Syntax SystemStateTableEntry

Access Not accessible

Index systemStatechassisIndex

System State Group 37

System State Chassis Index

Name systemStatechassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

System State Global System Status

Name systemStateGlobalSystemStatus

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.2

Description Defines the global system status of all chassis being monitored by this

instrumentation instance.

Syntax DellStatus

Access Read-only

System State Chassis State

Name systemStateChassisState

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.3

Description Defines the system state of this chassis.

Syntax DellStateSettings

Access Read-only

System State Chassis Status

Name systemStateChassisStatus

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.4

Description Defines the system status of this chassis.

Syntax DellStatus

Access Read-only

38 System State Group

System State Power Unit State Details

Name systemStatePowerUnitStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.5

Description Defines the state of all power units in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the state of a specific power unit. The first byte returned represents the state of the first power unit, the second byte returned represents the state of the second power unit, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Power Unit Status Redundancy

Name systemStatePowerUnitStatusRedundancy

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.6

Description Defines the system status of the power unit(s) in this chassis.

Syntax DellStatus

Access Read-only

System State Power Unit Status Details

Name systemStatePowerUnitStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.7

Description Defines the status of all power units in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the status of a specific power unit. The first byte returned represents the status of the first power unit, the second byte returned represents the status of the second power unit, and so on. The bytes have the same definition type as DellStatusRedundancy.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 39

System State Power Supply State Details

Name systemStatePowerSupplyStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.8

Description Defines the state of all power supplies in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the state of a specific power supply. The first byte returned represents the state of the first power supply, the second byte returned represents the state of the second power supply, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Power Supply Status Combined

Name systemStatePowerSupplyStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.9

Description Defines the status of all power supplies in this chassis.

Syntax DellStatus

Access Read-only

System State Power Supply Status Details

Name systemStatePowerSupplyStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.10

Description Defines the status of all power supplies in this chassis. The results are returned as a binary

octet string, Each byte of the octet string represents the status of a specific power supply. The first byte returned represents the status of the first power supply, the second byte returned represents the status of the second power supply, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

40 System State Group

System State Voltage State Details

Name systemStateVoltageStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.11

Description Defines the state of all voltage probes in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the status of a specific voltage probe. The first byte returned represents the status of the first voltage probe, the second byte returned represents the status of the second voltage probe, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Voltage Status Combined

Name systemStateVoltageStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.12

Description Defines the status of all voltage probes in this chassis.

Syntax DellStatus

Access Read-only

System State Voltage Status Details

Name systemStateVoltageStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.13

Description Defines the status of all voltage probes in this chassis.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 41

System State Amperage State Details

Name systemStateAmperageStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.14

Description Defines the state of all current probes in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the status of a specific current probe. The first byte returned represents the state of the first current probe, the second byte returned represents the state of the second current probe, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Amperage Status Combined

Name systemStateAmperageStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.15

Description Defines the status of all amperage probes in this chassis. The result is returned as a combined

status value. The value has the same definition type as DellStatus.

Syntax DellStatus

Access Read-only

System State Amperage Status Details

Name systemStateAmperageStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.16

Description Defines the status of all amperage probes in this chassis. The results are returned as a binary

octet string. Each byte of the octet string represents the status of a specific amperage probe. The first byte returned represents the status of the first amperage probe, the second byte returned represents the status of the second amperage probe, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

42 System State Group

System State Cooling Unit State Details

Name statesystemStateCoolingUnitStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.17

Description Defines the state of all cooling units in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the state of a specific cooling unit. The first byte returned represents the state of the first cooling unit, the second byte returned represents the state of the second cooling unit, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Cooling Unit Status Redundancy

Name systemStateCoolingUnitStatusRedundancy

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.18

Description Defines the state of all cooling units in this chassis.

Syntax DellStatusRedundancy

Access Read-only

System State Cooling Unit State Details

Name systemStateCoolingUnitstateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.19

Description Defines the state of all cooling units in this chassis. The results are returned as a binary octet

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 43

System State Cooling Device State Details

Name systemStateCoolingDeviceStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.20

Description Defines the state of all cooling devices in this chassis. The results are returned as a binary octet

string. Each byte of the octet string represents the state of a specific cooling device. The first byte returned represents the state of the first cooling device, the second byte returned represents the state of the second cooling device, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Cooling Device Status Combined

Name systemStateCoolingDeviceStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.21

Description This attribute defines the cooling device status of all cooling devices in this chassis.

The results is returned as a combined status value. The value has the same definition type as DellStatus.

Syntax DellStatus

Access Read-only

System State Cooling Device Status Details

Name systemStateCoolingDeviceStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.22

Description Defines the status of all cooling devices in this chassis. The results are returned as a binary

octet string. Each byte of the octet string represents the status of a specific cooling device. The first byte returned represents the status of the first cooling device, the second byte returned represents the status of the second cooling device, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

44 System State Group

System State Temperature State Details

Name systemStateTemperatureStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.23

Description Defines the state of all temperature probes in this chassis. The results are returned as a binary

octet string. Each byte of the octet string represents the state of a specific temperature probe. The first byte returned represents the state of the first temperature probe, the second byte returned represents the status of the second temperature probe, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Temperature Status Combined

Name systemStateTemperatureStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.24

Description Defines the status of all temperature probes in this chassis. The result is returned as a

combined status value. The value has the same definition type as DellStatus.

Syntax DellStatus

Access Read-only

System State Temperature Status Details

Name systemStateTemperatureStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.25

Description Defines the status of all temperature probes in this chassis. The first byte returned represents

the status of the first temperature probe, the second byte returned represents the status of the second temperature probe, and so on.

Syntax OCTET STRING (SIZE(1..128)

Access Read-only

System State Group 45

System State Memory Device State Details

Name systemStateMemoryDeviceStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.26

Description Defines the state of all memory devices in this chassis. The results are returned as a binary

octet string. Each byte of the octet string represents the state of the specific memory device. The first byte returned represents the state of the first memory device, the second byte returned represents the status of the second memory device, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128)

Access Read-only

System State Memory Device Status Combined

Name systemStateMemoryDeviceStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.27

Description Defines the status of all memory devices in this chassis.

Syntax DellStatus

Access Read-only

System State Memory Device Status Details

Name systemStateMemoryDeviceStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.28

Description Defines the status of all memory devices in this chassis. The results are returned as a binary

octet string. Each byte of the octet string represents the status of a specific memory device. The first byte returned represents the status of the first memory device, the second byte returned represents the status of the second memory device, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128)

Access Read-only

46 System State Group

System State Chassis Intrusion State Details

Name systemStateChassisIntrusionStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.29

Description Defines the intrusion state of all intrusion detection devices in this chassis. The results are

returned as a binary octet string. Each byte of the octet string represents the status of a specific intrusion detection device. The first byte returned represents the status of the first intrusion detection device, the second byte returned represents the status of the second intrusion detection device, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128)

Access Read-only

System State Chassis Intrusion Status Combined

Name systemStateChassisIntrusionStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.30

Description Defines the intrusion status of all intrusion detection devices in this chassis. The result is

returned as a combined status value. The value has the same definition type as DellStatus.

Syntax DellStatus

Access Read-only

System State Chassis Intrusion Status Details

Name systemStateChassisIntrusionStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.31

Description Defines the intrusion status of all intrusion detection devices in this chassis. The first byte

returned represents the status of the first intrusion detection device, the second byte returned represents the status of the second intrusion detection device, and so on.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 47

System State AC Power Switch State Details

Name systemStateACPowerSwitchStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.32

Description Defines the individual state of all AC power switches in this chassis. The first byte returned

represents the state of the first AC power switch, the second byte returned represents the state of the second AC power switch, and so on.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State AC Power Switch Status Redundancy

Name systemStateACPowerSwitchStatusRedundancy

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.33

Description Defines the overall redundancy status of the AC power switches in this chassis.

Syntax DellStatusRedundancy

Access Read-only

System State AC Power Switch Status Details

Name systemStateACPowerSwitchStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.34

Description Defines the individual status of all AC power switches in this chassis. The first byte returned

represents the status of the first AC power switch, the second byte returned represents the status of the second AC power switch, and so on.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State AC Power Cord State Details

Name systemStateACPowerCordStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.35

Description Defines the individual state of all AC power cords for any AC power switches in this chassis.

The first byte returned represents the state of the first AC power cord, the second byte returned represents the state of the second AC power cord, and so on.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

48 System State Group

System State AC Power Cord Status Combined

Name systemStateACPowerCordStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.36

Description Defines the overall status of all AC power cords for any AC power switches in this chassis.

Syntax DellStatus

Access Read-only

System State AC Power Cord Status Details

Name systemStateACPowerCordStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.37

Description Defines the individual status of all AC power cords for any AC power switches in this chassis.

The first byte returned represents the status of the first AC power cord, the second byte returned represents the status of the second AC power cord, and so on.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Redundant Memory Unit State Details

Name systemStateRedundantMemoryUnitStateDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.38

Description Defines the state of all redundant memory units in this chassis. The results are returned as a

binary octet string, each byte of the octet string represents the state of the specific object. The first byte returned represents the state of the first object, and so on. The bytes have the same definition type as DellStateSettings.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Redundant Memory Unit Status Redundancy

Name systemStateRedundantMemoryUnitStatusRedundancy

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.39

Description Defines the overall redundancy status for redundant memory.

Syntax DellStatusRedundancy

Access Read-only

System State Group 49

System State Redundant Memory Unit Status Details

Name systemStateRedundantMemoryUnitStatusDetails

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.40

Description Defines the status of all redundant memory units in this chassis. The results are returned as a

binary octet string, each byte of the octet string represents the status of the specific object. The first byte returned represents the status of the first object, and so on. The bytes have the same definition type as DellStatusRedundancy.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Event Log Status

Name systemStateEventLogStatus

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.41

Description Defines the overall status of this chassis (ESM) event log.

Syntax DellStatus

Access Read-only

System State Power Unit Status Combined

Name systemStatePowerUnitStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.42

Description Defines the combined status of all power units of this chassis.

Syntax DellStatus

Access Read-only

System State Power Unit Status List

Name systemStatePowerUnitStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.43

Description Lists the status of each power unit of this chassis. The results are returned as a binary octet

string where each byte of the octet string represents the status of a power unit. The first byte returned represents the status of the first power unit, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

50 System State Group

System State Cooling Unit Status Combined

Name systemStateCoolingUnitStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.44

Description Defines the combined status of all cooling units of this chassis.

Syntax DellStatus

Access Read-only

System State Cooling Unit Status List

Name systemStateCoolingUnitStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.45

Description Lists the status of each cooling unit of this chassis. The results are returned as a binary octet

string where each byte of the octet string represents the status of a cooling unit. The first byte returned represents the status of the first cooling unit, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State AC Power Switch Status Combined

Name systemStateACPowerSwitchStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.46

Description Defines the combined status of all AC power switches of this chassis.

Syntax DellStatus

Access Read-only

System State AC Power Switch Status List

Name systemStateACPowerSwitchStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.47

Description Lists the status of each AC power switch of this chassis. The results are returned as a binary

octet string where each byte of the octet string represents the status of an AC power switch. The first byte returned represents the status of the first AC power switch, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 51

System State Redundant Memory Unit Status Combined

Name systemStateRedundantMemoryUnitStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.48

Description Defines the combined status of all redundant memory units of this chassis.

Syntax DellStatus

Access Read-only

System State Redundant Memory Unit Status List

Name systemStateRedundantMemoryUnitStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.49

Description Lists the status of each redundant memory unit of this chassis. The results are returned as a

binary octet string where each byte of the octet string represents the status of a redundant memory unit. The first byte returned represents the status of the first redundant memory unit, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Processor Device Status Combined

Name systemStateProcessorDeviceStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.50

Description Defines the combined status of all processor devices of this chassis.

Syntax DellStatus

Access Read-only

System State Processor Device Status List

Name systemStateProcessorDeviceStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.51

Description Lists the status of each processor device of this chassis. The results are returned as a binary

octet string where each byte of the octet string represents the status of a processor device. The first byte returned represents the status of the first processor device, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

52 System State Group

System State Battery Status Combined

Name systemStateBatteryStatusCombined

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.52

Description Defines the combined status of all batteries of this chassis.

Syntax DellStatus

Access Read-only

System State Battery Status List

Name systemStateBatteryStatusList

Object ID 1.3.6.1.4.1.674.10892.1.200.10.1.53

Description Lists the status of each battery of this chassis. The results are returned as a binary octet string

where each byte of the octet string represents the status of a battery. The first byte returned represents the status of the first battery, and so on. The bytes have the same definition type as DellStatus.

Syntax OCTET STRING (SIZE(1..128))

Access Read-only

System State Group 53

54 System State Group

Chassis Information Group

The Chassis Information Group provides information about the type or types of chassis in your system, as well as information about the light-emitting diode (LED) indicators and settings for devices on each chassis. Information is also available about the current date and time displayed on the chassis, intrusion warnings, watchdog timer, systems management basic input/output system (SMBIOS), and so on.

Chassis Information Group Tables

The following management information base (MIB) tables define the objects in the Chassis Information Group:

• Chassis Information Table

• UUID Table

• POST Log Table

• Event Log Table

• System BIOS Table

• Firmware Table

• Intrusion Table

•Baseboard Table

Chassis Information Table

The following object sets up the Chassis Information Table.

Name chassisInformationTable

Object ID 1.3.6.1.4.1.674.10892.1.300.10

Description Defines the chassis information table.

Syntax SEQUENCE OF ChassisInformationTableEntry

Access Not accessible

Chassis Information Group 55

Chassis Information Table Entry

Name chassisInformationTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1

Description Defines the chassis information table entry.

Syntax ChassisInformationTableEntry

Access Not accessible

Index chassisIndexChassisInformation

Chassis Index Chassis Information

Name chassisIndexChassisInformation

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.1

Description Defines the index (one-based) of this chassis. The first chassis will be

numbered one.

Syntax DellObjectRange

Access Read-only

Chassis State Capabilities

Name chassisStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.2

Description Defines the capabilities of the chassis.

Syntax DellStateCapabilities

Access Read-only

Chassis State Settings

Name chassisStateSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.3

Description Defines the state settings for the chassis.

Syntax DellStateSettings

Access Read-write

56 Chassis Information Group

Chassis Status

Name chassisStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.4

Description Defines the status of the chassis.

Syntax DellStatus

Access Read-only

Chassis Parent Index Reference

Name chassisparentIndexReference

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.4

Description Defines the index (one-based) of the parent chassis of this chassis,

if any. A zero (0) means that this chassis is the parent of all other chassis managed by the Server Administrator.

Syntax DellObjectRange

Access Read-only

Chassis Type

Name chassisType

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.6

Description Defines the chassis type.

Syntax DellChassisType (See Table 5-2.)

Access Read-only

Chassis Name

Name chassisName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.7

Description Defines the user-assigned chassis name of the chassis.

Syntax DellString

Access Read-write

Chassis Information Group 57

Chassis Manufacturer Name

Name chassisManufacturerName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.8

Description Defines the manufacturer’s name for this chassis.

Syntax DellString

Access Read-only

Chassis Model Name

Name chassisModelName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.9

Description Defines the system model type for this chassis.

Syntax DellString

Access Read-only

Chassis Asset Tag Name

Name chassisAssetTagName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.10

Description Defines the user-assigned asset tag name for this chassis.

Syntax DisplayString (SIZE (0..10))

Access Read-write

Chassis Service Tag Name

Name chassisServiceTagName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.11

Description Defines the service tag name for this chassis.

Syntax DisplayString (SIZE (0..7))

Access Read-only

58 Chassis Information Group

Chassis ID

Name chassisID

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.12

Description Defines the asset tag name for this chassis.

Syntax DellUnsigned8BitRange

Access Read-only

Chassis ID Extension

Name chassisIDExtension

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.13

Description Defines the SMBIOS machine ID of this chassis.

Syntax DellUnsigned16BitRange

Access Read-only

Chassis System Class

Name chassisSystemClass

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.14

Description Defines the chassis class of this chassis.

Syntax DellChassisSystemClass (See Table 5-20.)

Access Read-only

Chassis System Name

Name chassisSystemName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.15

Description Defines the system name of this chassis.

Syntax DellString

Access Read-only

Chassis Information Group 59

Chassis System Boot Date Name

Name chassisSystemBootDateName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.16

Description Defines the boot time of this system.

Syntax DellDateName

Access Read-only

Chassis System Date Name

Name chassisSystemDateName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.17

Description Defines the current time on this system.

Syntax DellDateName

Access Read-only

Chassis System Location Name

Name chassisSystemLocationName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.18

Description Defines the user-assigned location for this chassis.

Syntax DellString

Access Read-write

Chassis System Primary User Name

Name chassisSystemPrimaryUserName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.19

Description Defines the user-assigned primary user name for this chassis.

Syntax DellString

Access Read-write

60 Chassis Information Group

Chassis System User Phone Number Name

Name chassisSystemUserPhoneNumberName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.20

Description Defines the user-assigned phone number of the primary user of the

system.

Syntax DellString

Access Read-write

Chassis Connection Status Unique

Name chassisConnectionStatusUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.21

Description Defines the status of the connection from the system chassis to an

expansion chassis.

Syntax DellConnectionStatus (See Table 5-3.)

Access Read-only

Chassis Fan Control Capabilities Unique

Name chassisFanControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.22

Description Defines the capabilities of the fan control function in this chassis.

Syntax DellFanControlCapabilities (See Table 5-4.)

Access Read-only

Chassis Fan Control Settings Unique

Name chassisFanControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.23

Description Defines the readings and settings of the fan control hardware in

the chassis.

Syntax DellFanControlSettings

Access Read-write

Chassis Information Group 61

Chassis LED Control Capabilities Unique

Name chassisLEDControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.24

Description Defines the capabilities of the LED control function in the chassis.

Syntax

Access Read-only

DellLEDControlCapabilities (See Table 5-5.)

Chassis LED Control Settings Unique

Name chassisLEDControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.25

Description Defines the readings and settings of the LED control hardware in the

chassis.

Syntax DellLEDControlSettings (See Table 5-6.)

Access Read-write

Chassis Hard-Drive (HD) Fault Clear Control Capabilities

Name chassisHDFaultClearControlCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.26

Description Specifies whether the chassis allows reset of the chassis hard-drive

fault LED.

Syntax DellHDFaultLEDControlCapabilities (See Table 5-7.)

Access Read-only

Chassis HD Fault Clear Control Settings

Name chassisHDFaultClearControlSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.27

Description Allows reset of the chassis hard-drive fault LED.

Syntax DellHDFaultLEDControlSettings (See Table 5-8.)

Access Read-write

62 Chassis Information Group

Chassis Identify Flash Control Capabilities

Name chassisIdentifyFlashControlCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.28

Description Specifies whether the chassis front-panel LED can be set to flash.

Syntax DellChassisIdentifyControlCapabilities (See Table 5-9.)

Access Read-only

Chassis Identify Flash Control Settings

Name chassisIdentifyFlashControlSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.29

Description Causes the chassis front-panel LED to flash.

Syntax DellChassisIdentifyControlSettings (See Table 5-10.)

Access Read-write

Chassis Lock Present

Name chassisLockPresent

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.30

Description Specifies whether a chassis lock is present on the chassis.

Syntax DellBoolean

Access Read-only

Chassis Host Control Capabilities Unique

Name chassishostControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.31

Description Defines the capabilities of the host control object.

Syntax DellHostControlCapabilities (See Table 5-11.)

Access Read-only

Chassis Information Group 63

Chassis Host Control Settings Unique

Name chassishostControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.32

Description Defines the current settings of the host control object.

Syntax DellHostControlSettings (See Table 5-12.)

Access Read-write

Chassis Watchdog Control Capabilities Unique

Name chassiswatchDogControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.33

Description Defines the capabilities of the watchdog timer object.

Syntax DellWatchDogControlCapabilities (See Table 5-13.)

Access Read-only

Chassis Watchdog Control Settings Unique

Name chassiswatchDogControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.34

Description Defines the current settings and the values allowed to be set for the

watchdog timer object.

Syntax DellWatchDogControlCapabilities (See Table 5-13.)

Access Read-write

Chassis Watchdog Control Expiry Time Capabilities Unique

Name chassiswatchDogControlExpiryTimeCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.35

Description Defines the capabilities of the watchdog expiry timer object.

Syntax DellWatchDogTimerCapabilities (See Table 5-13.)

Access Read-only

64 Chassis Information Group

Chassis Watchdog Control Expiry Time

Name chassiswatchDogControlExpiryTime

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.36

Description Defines the current reading and allows setting of the nonrecoverable

watchdog expiry timer object.

Syntax DellUnsigned16BitRange

Access Read-write

Chassis Allow Set Commands From SNMP

Name chassisallowSETCommandsfromSNMP

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.37

Description Specifies whether Simple Network Management Protocol (SNMP) Set type

commands are allowed by Server Administrator.

This attribute does not reflect whether SNMP Set type commands are allowed by the SNMP master agent.

Syntax DellBoolean

Access Read-only

Chassis Power Button Control Capabilities Unique

Name chassisPowerButtonControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.38

Description Defines the capabilities of the power button control function.

Syntax DellPowerButtonControlCapabilities (See Table 5-16)

Access Read-only

Chassis Power Button Control Settings Unique

Name chassisPowerButtonControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.39

Description Defines the current reading and allows setting of the power button

control hardware.

Syntax DellPowerButtonControlSettings (See Table 5-17)

Access Read-write

Chassis Information Group 65

Chassis Reseller Name

Name chassisResellerName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.40

Description Defines the name of the chassis reseller.

Syntax DisplayString (SIZE (0..128))

Access Read-only

Chassis Reseller Contact Information Name

Name chassisResellerContactInformationName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.41

Description Defines the chassis reseller contact information name.

Syntax DisplayString (SIZE (0..128))

Access Read-only

Chassis Reseller Product Name

Name chassisResellerProductName

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.42

Description Defines the chassis reseller product name.

Syntax DisplayString (SIZE (0..128))

Access Read-only

Chassis Reseller System ID

Name chassisResellerSystemID

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.43

Description Defines the chassis reseller system ID.

Syntax DellUnsigned16BitRange

Access Read-only

66 Chassis Information Group

Chassis NMI Button Control Capabilities Unique

Name chassisNMIButtonControlCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.44

Description Defines the capabilities of the NMI button control function.

Syntax DellNMIButtonControlCapabilities (See Table 5-18)

Access Read-only

Chassis NMI Button Control Settings Unique

Name chassisNMIButtonControlSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.10.1.45

Description Defines the current reading and allows setting of the NMI button

control hardware.

Syntax DellNMIButtonControlSettings (See Table 5-19)

Access Read-write

UUID Table

These objects comprise the server administrator definitions for the Universal Unique Identifier (UUID).

Name uUIDTable

Object ID 1.3.6.1.4.1.674.10892.1.300.20

Description Defines the UUID table.

Syntax SEQUENCE OF UUIDTableEntry

Access Not accessible

UUID Table Entry

Name uUIDTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1

Description Defines the UUID table entry.

Syntax UUIDTableEntry

Access Not accessible

Index uUIDIndex, uUIDchassisIndex

Chassis Information Group 67

UUID Chassis Index

Name uUIDchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

UUID Index

Name uUIDIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.2

Description Defines the index of the UUID in a specified chassis.

Syntax DellObjectRange

Access Read-only

UUID Type

Name uUIDType

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.3

Description Defines the type of the UUID for this chassis.

Syntax DellUUIDType

Access Read-only

UUID Value

Name uUIDValue

Object ID 1.3.6.1.4.1.674.10892.1.300.20.1.4

Description Defines the value of the UUID for this chassis.

Syntax OCTET STRING (SIZE(16))

Access Read-only

68 Chassis Information Group

POST Log Table

This section defines attributes for the power-on self-test (POST) log. When you turn on your computer, the POST checks various system components before the operating system loads. The POST tests the random-access memory (RAM), the hard drives, and the keyboard, for example. While the POST is running, it makes a log file that system administrators can view. The variables in this section also contribute to managing the POST log.

Name postLogTable

Object ID 1.3.6.1.4.1.674.10892.1.300.30

Description Defines the POST Log Table.

Syntax SEQUENCE OF PostLogTableEntry

Access Not accessible

POST Log Table Entry

Name postLogTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1

Description Defines the POST Log Table entry.

Syntax PostLogTableEntry

Access Not accessible

Index postLogchassisIndex, postLogRecordIndex

POST Log Chassis Index

Name postLogchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

POST Log Record Index

Name postLogRecordIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.2

Description Defines the record number (one-based) of the POST log.

Syntax DellUnsigned32BitRange

Access Read-only

Chassis Information Group 69

POST Log State Capabilities Unique

Name postLogStateCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.3

Description Defines the capabilities of the object that is writing the POST log.

Syntax DellStateCapabilitiesLogUnique

Access Read-only

POST Log State Settings Unique

Name postLogStateSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.4

Description Defines the state of the object that is writing the POST log.

Syntax DellStateSettingsLogUnique

Access Read-write

POST Log Record

Name postLogRecord

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.5

Description Defines the data for the specified chassis and record index in the POST log

being returned.

Syntax DisplayString (SIZE (0..1024))

Access Read-only

POST Log Format

Name postLogFormat

Object ID 1.3.6.1.4.1.674.10892.1.300.30.1.5

Description Defines format of the POST log.

Syntax DellLogFormat (See Table 5-1.)

Access Read-only

70 Chassis Information Group

Event Log Table

Name eventLogTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.40

Description Defines the Event Log Table.

Syntax SEQUENCE OF EventLogTableEntry

Access Not accessible

Event Log Table Entry

Name eventLogTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1

Description Defines the event Log Table Entry.

Syntax EventLogTableEntry

Access Not accessible

Index eventLogchassisIndex,eventLogRecordIndex

Event Log Chassis Index

Name eventLogchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

Event Log Record Index

Name eventLogRecordIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.2

Description Defines the record index of the event log.

Syntax DellUnsigned32BitRange

Access Read-only

Chassis Information Group 71

Event Log State Capabilities Unique

Name eventLogStateCapabilitiesUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.3

Description Defines the capabilities of the object that is writing the event log.

Syntax DellStateCapabilitiesLogUnique

Access Read-only

Event Log State Settings Unique

Name eventLogStateSettingsUnique

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.4

Description Defines the state settings for the object that is writing the event log.

Syntax DellStateSettingsLogUnique

Access Read-write

Event Log Record

Name eventLogRecord

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.5

Description Defines the data for the specified chassis and log record index in the

event log being returned.

Syntax DisplayString (SIZE (0..1024))

Access Read-only

Event Log Format

Name eventLogFormat

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.6

Description Defines the format of the event log.

Syntax DellLogFormat (See Table 5-1.)

Access Read-only

72 Chassis Information Group

Event Log Severity Status

Name eventLogSeverityStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.7

Description Defines the severity of the event log record.

Syntax DellStatus

Access Read-only

Status Mandatory

Event Log Date Name

Name eventLogDateName

Object ID 1.3.6.1.4.1.674.10892.1.300.40.1.8

Description Defines the date and time of the event log record.

Syntax DellDateName

Access Read-only

Status Mandatory

System BIOS Table

This table lists objects that define the system’s basic input/output system (BIOS).

Name systemBIOSTable

Object ID 1.3.6.1.4.1.674.10892.1.300.50

Description Defines the System BIOS Table.

Syntax SEQUENCE OF SystemBIOSTableEntry

Access Not accessible

System BIOS Table Entry

Name systemBIOSTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1

Description Defines the System BIOS Table entry.

Syntax SystemBIOSTableEntry

Access Not accessible

Index systemBIOSchassisIndex,systemBIOSIndex

Chassis Information Group 73

System BIOS Chassis Index

Name systemBIOSchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

System BIOS Index

Name systemBIOSIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.2

Description Defines the index (one-based) of the system BIOS of this object.

Syntax DellObjectRange

Access Read-only

System BIOS State Capabilities

Name systemBIOSStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.3

Description Defines the capabilities of the system BIOS of this object.

Syntax DellStateCapabilities

Access Read-only

System BIOS State Settings

Name systemBIOSStateSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.4

Description Defines the state of the system BIOS of this object.

Syntax DellStateSettings

Access Read-write

74 Chassis Information Group

System BIOS Status

Name systemBIOSStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.5

Description Defines the status of the system BIOS of this object.

Syntax DellStatus

Access Read-only

System BIOS Size

Name systemBIOSSize

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.6

Description Defines the image size of the system BIOS in kilobytes (KB). A zero (0)

indicates that the image size of the BIOS is unknown.

Syntax DellUnsigned32BitRange

Access Read-only

System BIOS Release Date Name

Name systemBIOSReleaseDateName

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.7

Description Defines the release date of the system BIOS.

Syntax DellDateName

Access Read-only

System BIOS Version Name

Name systemBIOSVersionName

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.8

Description Defines the version name of the system BIOS.

Syntax DellString

Access Read-only

Chassis Information Group 75

System BIOS Starting Address

Name systemBIOSStartingAddress

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.9

Description Defines the starting address of the system BIOS. A zero (0) indicates that

the address is unknown.

Syntax DellUnsigned64BitRange

Access Read-only

System BIOS Ending Address

Name systemBIOSEndingAddress

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.10

Description Defines the ending address of the system BIOS. A zero (0) indicates that

the address is unknown.

Syntax DellUnsigned64BitRange

Access Read-only

System BIOS Manufacturer Name

Name systemBIOSManufacturerName

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.11

Description Defines the system BIOS manufacturer’s name.

Syntax DellString

Access Read-only

76 Chassis Information Group

System BIOS Characteristics

Name systemBIOSCharacteristics

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.12

Description Defines characteristics of the system BIOS. This attribute is a bit field

where a bit has the meaning defined below when set to 1 (one). Bit 63 is the first bit in the value, and bit 0 is the last bit in the value. See the description of DellUnsigned64BitRange at the beginning of this file for more information on the format of the value.

Bits 48-63 need to be examined in the context of the system ID. The system ID is available in the attribute chassisID. If the value for chassisID is non-zero, bits 48-63 have the meaning defined below: Bit Position Meaning if Set

-------------- -----------------Bit 0 Reserved Bit 1 Reserved Bit 2 Unknown Bit 3 BIOS Characteristics Not Supported Bit 4 ISA is supported Bit 5 MCA is supported Bit 6 EISA is supported Bit 7 PCI is supported Bit 8 PC Card (PCMCIA) is supported Bit 9 Plug and Play is supported Bit 10 APM is supported Bit 11 BIOS is Upgradeable (Flash) Bit 12 BIOS shadowing is allowed Bit 13 VL-VESA is supported Bit 14 ESCD support is available Bit 15 Boot from CD is supported Bit 16 Selectable Boot is supported Bit 17 BIOS ROM is socketed Bit 18 Boot From PC Card (PCMCIA) is supported Bit 19 EDD (Enhanced Disk Drive) Specification is supported Bit 20 Int 13h - Japanese Floppy for NEC 9800 1.2mb (3.5 in,

1k Bytes/Sector, 360 RPM) is supported

Bit 21 Int 13h - Japanese Floppy for Toshiba 1.2mb (3.5 in,

360 RPM) is supported Bit 22 Int 13h - 5.25 in / 360 KB Floppy Services are supported Bit 23 Int 13h - 5.25 in /1.2MB Floppy Services are supported Bit 24 Int 13h - 3.5 in / 720 KB Floppy Services are supported Bit 25 Int 13h - 3.5 in / 2.88 MB Floppy Services are supported Bit 26 Int 5h, Print Screen Service is supported Bit 27 Int 9h, 8042 Keyboard services are supported Bit 28 Int 14h, Serial Services are supported

Chassis Information Group 77

Name systemBIOSCharacteristics

Description Bit Position Meaning if Set

-------------- ------------------

Bit 29 Int 17h, Printer Services are supported Bit 30 Int 10h, CGA/Mono Video Services are supported Bit 31 NEC PC-98 Bit 32-47 Reserved Bit 48 Built-in NIC supports Magic Packet Bit 49 System supports Wake-on-LAN Bit 50 System supports chassis intrusion Bit 51 Built-in NIC supports pattern-matching Bit 52 System BIOS supports a 7-character service tag Bit 53-63 Reserved

Syntax DellUnsigned64BitRange

System BIOS Characteristics Ext 1

Name systemBIOSCharacteristicsExt1

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.13

Description Defines additional characteristics of the system basic input/output system

(BIOS). This attribute is a bit field where a bit has the meaning defined below when set to 1 (one).

Bit Position Meaning if Set

-------------- -----------------Bit 0 ACPI supported Bit 1 USB Legacy is supported Bit 2 AGP is supported Bit 3 I2O boot is supported Bit 4 LS-120 boot is supported Bit 5 ATAPI ZIP Drive boot is supported Bit 6 1394 boot is supported Bit 7 Smart Battery supported

Syntax DellUnsigned8BitRange

Access Read-only

78 Chassis Information Group

System BIOS Characteristics Ext 2

Name systemBIOSCharacteristicsExt2

Object ID 1.3.6.1.4.1.674.10892.1.300.50.1.14

Description Defines additional characteristics of the system BIOS. This attribute is a bit

field where a bit has the meaning defined below when set to 1 (one).

Bit Position Meaning if Set

--------------- -------------------Bit 0 BIOS Boot Specification supported Bit 1 Function key-initiated Network Service boot supported Bit 2 Targeted Content Distribution supported Bit 3-7 Reserved

Syntax DellUnsigned8BitRange

Access Read-only

Firmware Table

Name firmwareTable

Object ID 1.3.6.1.4.1.674.10892.1.300.60

Description Defines the Firmware Table.

Syntax SEQUENCE OF FirmwareTableEntry

Access Not accessible

Firmware Table Entry

Name firmwareTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1

Description Defines the Firmware Table entry.

Syntax FirmwareTableEntry

Access Not accessible

Index firmwarechassisIndex, firmwareIndex

Chassis Information Group 79

Firmware Chassis Index

Name firmwarechassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

Firmware Index

Name firmwareIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.2

Description Defines the index (one-based) of the firmware in this chassis.

Syntax DellObjectRange

Access Read-only

Firmware State Capabilities

Name firmwareStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.3

Description Defines the capabilities of the firmware states.

Syntax DellStateCapabilities

Access Read-only

Firmware State Capabilities

Name firmwareStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.4

Description Defines the state of the firmware and allows for the setting of the firmware.

Syntax DellStateSettings

Access Read-write

80 Chassis Information Group

Firmware Status

Name firmwareStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.5

Description Defines the status of the firmware.

Syntax DellStateSettings

Access Read-only

Firmware Size

Name firmwareSize

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.6

Description Defines the image size of the firmware in KB. A zero (0) indicates that the

size is unknown.

Syntax DellUnsigned16BitRange

Access Read-only

Firmware Type

Name firmwareType

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.7

Description Defines the type of the firmware.

Syntax DellFirmwareType

Access Read-only

Firmware Type Name

Name firmwareTypeName

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.8

Description Defines the name of firmware type.

Syntax DellString

Access Read-only

Chassis Information Group 81

Firmware Update Capabilities

Name firmwareUpdateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.9

Description Defines the bitmap of supported methods for firmware update.

Syntax DellUnsigned16BitRange

Access Read-only

Firmware Date Name

Name firmwareDateName

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.10

Description Defines the date of the firmware.

Syntax DellDateName

Access Read-only

Firmware Version Name

Name firmwareVersionName

Object ID 1.3.6.1.4.1.674.10892.1.300.60.1.11

Description Defines the version name of the firmware.

Syntax DellString

Access Read-only

Intrusion Table

The following objects and attributes describe the different forms of chassis intrusion, a situation that occurs when the cover of a computer is removed.

Name intrusionTable

Object ID 1.3.6.1.4.1.674.10892.1.300.70

Description Defines the Intrusion Table.

Syntax SEQUENCE OF IntrusionTableEntry

Access Not accessible

82 Chassis Information Group

Intrusion Table Entry

Name intrusionTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1

Description Defines the Intrusion Table entry.

Syntax IntrusionTableEntry

Access Not accessible

Index intrusionchassisIndex, intrusionIndex

Intrusion Chassis Index

Name intrusionchassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.1

Description Defines the index (one-based) of this chassis.

Syntax DellObjectRange

Access Read-only

Intrusion Index

Name intrusionIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.2

Description Defines the index of the intrusion objects in this subgroup.

Syntax DellObjectRange

Access Read-only

Intrusion State Capabilities

Name intrusionStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.3

Description Defines the capabilities of the intrusion object.

Syntax DellStateCapabilities

Access Read-only

Chassis Information Group 83

Intrusion State Settings

Name intrusionStateSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.4

Description Defines the settings of the intrusion object.

Syntax DellStateSettings

Access Read-write

Intrusion Status

Name intrusionStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.5

Description Defines the status of the intrusion object.

Syntax DellStatus

Access Read-only

Intrusion Reading

Name intrusionReading

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.6

Description Defines the reading of the intrusion object.

Syntax DellIntrusionReading

Access Read-only

Intrusion Type

Name intrusionType

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.7

Description Defines the type of the intrusion object.

Syntax DellIntrusionType

Access Read-only

84 Chassis Information Group

Intrusion Location Name

Name intrusionLocationName

Object ID 1.3.6.1.4.1.674.10892.1.300.70.1.8

Description Defines the location name of the intrusion object in this subgroup.

Syntax DellString

Access Read-only

Baseboard Table

This table lists objects that define the baseboard of a system.

Name baseBoardTable

Object ID 1.3.6.1.4.1.674.10892.1.300.80

Description Defines the Baseboard Table.

Syntax SEQUENCE OF BaseBoardTableEntry

Access Not accessible

Baseboard Table Entry

Name baseBoardTableEntry

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1

Description Defines the Baseboard Table entry.

Syntax BaseBoardTableEntry

Access Not accessible

Index baseBoardChassisIndex, baseBoardIndex

Baseboard Chassis Index

Name baseBoardChassisIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.1

Description Defines the index (one-based) of the associated chassis.

Syntax DellObjectRange

Access Read-only

Chassis Information Group 85

Baseboard Index

Name baseBoardIndex

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.2

Description Defines the index (one-based) of the base board.

Syntax DellObjectRange

Access Read-only

Baseboard State Capabilities

Name baseBoardStateCapabilities

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.3

Description Defines the state capabilities of the baseboard.

Syntax DellStateCapabilities

Access Read-only

Baseboard State Settings

Name baseBoardStateSettings

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.4

Description Defines the state settings of the baseboard.

Syntax DellStateSettings

Access Read-write

Baseboard Status

Name baseBoardStatus

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.5

Description Defines the status of the baseboard.

Syntax DellStatus

Access Read-only

86 Chassis Information Group

Baseboard Feature Flags

Name baseBoardFeatureFlags

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.6

Description Defines the features of the baseboard.

Syntax DellBaseBoardFeatureFlags

Access Read-only

Baseboard Type

Name baseBoardType

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.7

Description Defines the type of the baseboard.

Syntax DellBaseBoardType

Access Read-only

Baseboard Type Name

Name baseBoardTypeName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.8

Description Defines the name of the type of baseboard.

Syntax DellString

Access Read-only

Baseboard Location Name

Name baseBoardLocationName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.9

Description Defines the location name of the baseboard.

Syntax DellString

Access Read-only

Chassis Information Group 87

Baseboard Manufacturer Name

Name baseBoardManufacturerName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.10

Description Defines the baseboard manufacturer’s name.

Syntax DellString

Access Read-only

Baseboard Product Name

Name baseBoardProductName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.11

Description Defines the baseboard product’s name.

Syntax DellString

Access Read-only

Baseboard Version Name

Name baseBoardVersionName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.12

Description Defines the baseboard version name.

Syntax DellString

Access Read-only

Baseboard Service Tag Name

Name baseBoardServiceTagName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.13

Description Defines the baseboard service tag name.

Syntax DellString

Access Read-only

88 Chassis Information Group

Baseboard Piece Part ID (PPID) Name

Name baseBoardPiecePartIDName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.14

Description Defines the baseboard PPID.

Syntax DellString

Access Read-only

Baseboard Asset Tag Name

Name baseBoardAssetTagName

Object ID 1.3.6.1.4.1.674.10892.1.300.80.1.15

Description Defines the baseboard asset tag name.

Syntax DellString

Access Read-only

Chassis Information Group Variable Values

This section includes definitions for server administrator-specific variable values used in this section.

Table 5-1. Log Format

Variable Name: DellLogFormat Data Type: Integer

Possible Data Values Meaning of Data Value

raw(1) The log is in the format received from the firmware. ascii(2) The log is in ASCII format. uniCode(3) The log is in Unicode format.

Chassis Information Group 89

Table 5-2. Chassis Type

Variable Name: DellChassisType Data Type: Integer

Possible Data Values Meaning of Data Value

other(1) The chassis type is not one of the following: unknown(2) The chassis type is unknown. desktop(3) The chassis type is a desktop. lowProfileDesktop(4) The chassis type is a low-profile desktop. pizzaBox(5) The chassis type is a pizza box. miniTower(6) The chassis type is a minitower. tower(7) The chassis type is a tower. portable(8) The chassis type is a portable. lapTop(9) The chassis type is a laptop. noteBook(10) The chassis type is a notebook. handHeld(11) The chassis type is a handheld. dockingStation(12) The chassis type is a docking station. allInOne(13) The chassis type is an all-in-one. subNoteBook(14) The chassis type is a subnotebook. spaceSaving(15) The chassis type is a spacesaver. lunchBox(16) The chassis type is a lunch box. mainSystemChassis(17) The chassis type is the main system chassis. expansionChassis(18) The chassis type is an expansion chassis. subChassis(19) The chassis type is a subchassis. busExpansionChassis(20) The chassis type is a bus-expansion chassis. peripheralChassis(21) The chassis type is a peripheral chassis. raidChassis(22) The chassis type is a disk RAID chassis. rackMountChassis(23) The chassis type is a rack-mounted chassis. sealedCasePC(24) The chassis type is a sealed-case chassis. multiSystemChassis(25) The chassis type is a multisystem chassis.

90 Chassis Information Group

Table 5-3. Connection Status

Variable Name: DellConnectionStatus Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(2) The status of the chassis connection is unknown. ok(3) The status of the chassis connection is OK. failure(4) The status of the chassis connection is failure.

Table 5-4. Fan Control Capabilities

Variable Name: DellFanControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

Table 5-5. Front-Panel LED Control Capabilities

Variable Name: DellLEDControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(1) The LED control capabilities are unknown. alertOnErrorCapable(2) The LED control can be set to alert on an error condition. alertOnWarningAndErrorCapable(4) The LED control can be set to alert on an error and a

warning condition.

alertOnWarningOrErrorCapable(6) The LED control can be set to alert on an error or a

warning condition.

Chassis Information Group 91

Table 5-6. Front-Panel LED Control Settings

Variable Name: DellLEDControlSettings Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(1) The LED control setting is unknown. alertOnError(2) The LED control is set to alert on an error condition. alertOnWarningAndError(4) The LED control is set to alert on an error or a

warning condition.

Table 5-7. Hard-Drive Fault LED Control Capabilities

Variable Name: DellHDFaultLEDControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The hard drive has no fault LED capabilities. unknownCapabilities(1) The hard-drive fault LED capabilities are unknown. enableCapable(2) The hard-drive fault LED can be disabled (offline, a binary 0

value) or enabled (online, a binary 1 value).

notReadyCapable(4) The hard-drive fault LED can indicate not ready. resetCapable(8) The hard-drive fault LED can be reset.

Table 5-8. Hard-Drive Fault LED Control Settings

Variable Name: DellHDFaultLEDControlSettings Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The LEDs do not have any fault settings capabilities. unknown(1) The hard-drive fault LEDs’ state is unknown. enabled(2) The hard-drive fault LEDs’ state is disabled (offline, a binary 0

value) or enabled (online, a binary 1 value).

notReady(4) The hard-drive fault LEDs’ state is not ready. reset(8) The hard-drive fault LEDs have been reset. resetAndEnable(10) The hard-drive fault LEDs have been reset and enabled.

92 Chassis Information Group

Table 5-9. Chassis Identification Control Capabilities

Variable Name: DellChassisIdentifyControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The LEDs do not have any chassis identification capabilities. unknownCapabilities(1) The chassis identification control’s capabilities are unknown. enableCapable(2) The chassis identification controls can be disabled (offline, a

binary 0 value) or enabled (online, a binary 1 value).

notReadyCapable(4) The chassis identification control’s capabilities are not ready. identifyCapable(8) The chassis identification control’s LEDs can be made to

identify the chassis.

NOTE: Chassis identification capabilities allow system administrators to set front panel light-emitting diodes (LEDs)

to blink when the chassis has malfunctioning components. When enabled, the blinking lights help administrators locate the problem chassis.

Table 5-10. Chassis Identification Control Settings

Variable Name: DellChassisIdentifyControlSettings Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(1) The chassis identification control’s state is unknown. enabled(2) The chassis identification control’s state is disabled (offline,

a binary 0 value) or enabled (online, a binary 1 value).

notReady(4) identifyChassis(8)

The chassis identification control’s state is not ready.

The chassis identification control’s LEDs may be returned to (normal) 0, or (identify chassis) 1.

identifyChassisAndEnable(10)

The chassis identification control’s LEDs may be returned to normal (a binary 0 value), or identify chassis and enabled (a binary 1 value).

Chassis Information Group 93

Table 5-11. Host Control Capabilities

Variable Name: DellHostControlCapabilities

NOTE: An operator can manually cause these actions using SNMP.

Data Type: Integer

Possible Data Values Meaning of Data Value

manualRebootCapable(1) The operator can reboot capable host. manualPowerOFFCapable(2) The operator can power off capable host. manualPowerCycleCapable(4) The operator can power-cycle capable host. manualAllExceptOperatingSystemShutdown

Capable(7) manualOperatingSystemShutdownCapable(8) The operator can shut down the operating-

manualFullyCapable(15) The operator can reboot, power on and off the power-cycle

Table 5-12. Host Control Settings

Variable Name: DellHostControlSettings

The operator can reboot and power off capable host.

system–shutdown capable host.

capable host, and shut down the operating-system–shutdown capable host.

NOTE: An operator can manually cause these actions using SNMP.

Data Type: Integer

Possible Data Values Meaning of Data Value

manualReboot(1) The operator can reboot the host. manualPowerOFF(2) The operator can power off the host. manualPowerCycle(4) Power cycle the host. manualOperatingSystemShutdown(8) The operator can shut down the operating system on the

host.

manualOperatingSystemShutdownThenReboot (9)

manualOperatingSystemShutdownThenPowerOFF (10)

manualOperatingSystemShutdownThenPower Cycle(12)

The operator can shut down the operating system on the host then reboot.

The operator can shut down the operating system on the host then power off machine.

The operator can shut down the operating system on the host then power cycle machine.

94 Chassis Information Group

Table 5-13. Watchdog Control Capabilities

Variable Name: DellWatchDogControlCapabilities

NOTE: When the system determines that the operating system is not responding, it will automatically perform the

selected action without operator intervention.

Data Type: Integer

Possible Data Values Meaning of Data Value

automaticRebootCapable(1) Watchdog controls can be set to reboot capable host. automaticPowerCycleCapable(2) Watchdog controls can be set to power cycleable

capable host.

automaticNotificationCapable(4) Watchdog controls can be set to notify capable host. automaticWatchDogTimerCapable(8) Watchdog controls can be set to function

automatically.

automaticPowerOffCapable(16) Watchdog controls can be set to automatically power

off host.

automaticAllExceptNotificationCapable(27) Watchdog controls can be set to automatically

perform all functions except notification capable.

automaticFullyCapable(31) Watchdog controls can be set to automatically

perform all functions.

Table 5-14. Watchdog Control Settings

Variable Name: DellWatchControlSettings

NOTE: The watchdog timer is the mechanism used by a chassis to determine if the operating system has

stopped responding.

Data Type: Integer

Possible Data Values Meaning of Data Value

automaticRebootEnabled(1) Automatic reboot is enabled for this host. automaticPowerCycleEnabled(2) Automatic power cycleable is enabled for this host. automaticNotificationEnabled(4) Automatic notification is enabled for this host. automaticPowerOffEnabled(8) Automatic power off is enabled for this host.

Chassis Information Group 95

Table 5-15. Watchdog Timer Capabilities

Variable Name: DellWatchDogTimerCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

type1Capable(1) Watchdog timer can time in intervals from 20–480 seconds. type2Capable(2) Watchdog timer can time in 30-, 60-, 120-, and 480-second intervals. type3Capable(4) Watchdog timer can time in 60-second intervals.

Table 5-16. Power Button Control Capabilities

Variable Name: DellPowerButtonControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The power button has no capabilities. unknownCapabilities(1) The power button capabilities are unknown. enableCapable(2) The power button can be enabled (online) or disabled (offline).

Table 5-17. Power Button Control Settings

Variable Name: DellPowerButtonControlSettings Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The power button has no settings capabilities. unknown(1) The power button settings are unknown. enabled(2) The power button state is enabled. disabled(4) The power button state is disabled.

96 Chassis Information Group

Table 5-18. NMI Button Control Capabilities

Variable Name: DellNMIButtonControlCapabilities Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The NMI button has no capabilities. unknownCapabilities(1) The NMI button capabilities are unknown. enableCapable(2) The NMI button can be enabled (online) or disabled (offline).

Table 5-19. NMI Button Control Settings

Variable Name: DellNMIButtonControlSettings Data Type: Integer

Possible Data Values Meaning of Data Value

none(0) The NMI button has no settings capabilities. unknown(1) The NMI button settings are unknown. enabled(2) The NMI button state is enabled. disabled(4) The NMI button state is disabled.

Table 5-20. Chassis System Class

Variable Name: DellChassisSystemClass Data Type: Integer

Possible Data Values Meaning of Data Value

other(1) The chassis system class is not one of the following: unknown(2) The chassis system class is unknown. workstationClass(3) The chassis system class is a workstation. serverClass(4) The chassis system class is a server. desktopClass(5) The chassis system class is a desktop. portableClass(6) The chassis system class is a portable. netPCClass(7) The chassis system class is a "Net PC." storageClass(8) The chassis system class is storage.

Chassis Information Group 97

Table 5-21. Firmware Type

Variable Name: DellFirmwareType Data Type: Integer

Possible Data Values Meaning of Data Value

other(1) The firmware type is other than following values. unknown(2) The firmware type is unknown. systemBIOS(3) The firmware type is System BIOS embeddedSystemManagementController(4) The firmware type is Embedded System Management

Controller.

powerSupplyParallelingBoard(5) The firmware type is Power Supply Paralleling Board. systemBackPlane(6) The firmware type is System (Primary) Backplane. powerVault2XXSKernel(7) The firmware type is Dell™ PowerVault™ 2XXS Kernel. powerVault2XXSApplication(8) The firmware type is PowerVault 2XXS Application. frontPanel(9) The firmware type is Front Panel Controller. baseboardManagementController(10) The firmware type is Baseboard Management Controller. hotPlugPCI(11) The firmware type is Hot Plug Peripheral Component

Interconnect (PCI) Controller.

sensorData(12) The firmware type is Sensor Data Records. peripheralBay(13) The firmware type is Peripheral Bay Backplane. secondaryBackPlane(14) The firmware type is Secondary Backplane for

ESM 2 systems.

secondaryBackPlaneESM3And4(15) The firmware type is Secondary Backplane for ESM 3 and 4

systems.

rac(16) The firmware type is Remote Access Controller.

98 Chassis Information Group

Table 5-22. Baseboard Type

Variable Name: DellBaseBoardType Data Type: Integer

Possible Data Values Meaning of Data Value

unknown(1) The baseboard type is unknown. other(2) The baseboard type is not one of the following types. serverBlade(3) The baseboard type is a server blade. connectivitySwitch(4) The baseboard type is a connectivity switch. systemManagementModule(5) The baseboard type is a system management module. processorModule(6) The baseboard type is a processor module. ioModule(7) The baseboard type is an I/O module. memoryModule(8) The baseboard type is a memory module daughterBoard(9) The baseboard type is a daughter board. motherboard(10) The baseboard type is a mother board. processorMemoryModule(11) The baseboard type is a processor or memory module processorIOModule(12) The baseboard type is a processor or I/O module interconnectBoard(13) The baseboard type is an interconnect board.

Table 5-23. Baseboard Feature Flags

Variable Name: DellBaseBoardFeatureFlags Data Type: Integer

Possible Data Values Meaning of Data Value

NOTE: These values are bit fields, so combination values are possible.

no features(0) This baseboard has no feature flags. boardIsHostingBoard(1) This baseboard is a hosting board. boardRequiresDaughterBoard(2) This baseboard requires at least one daughter board or

auxiliary card.

boardIsRemovable(4) This baseboard is removable. boardIsReplaceable(8) This baseboard is replaceable. boardIsHotSwappable(16) This baseboard is hot swappable.

Chassis Information Group 99

100 Chassis Information Group

Dell OpenManage Server Administrator Version 5.2 SNMP Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

SNMP Reference Guide

Contents

Introduction

Audience

What’s New in this Release

What's New in the Instrumentation MIB

What's New in the Remote Access MIB

What's New in the Field Replaceable Unit MIB

What's New in the Storage Management Group MIB

What's New in the Change Management MIB

Introduction to the SNMP Reference Guide

General Content

Server Administrator Instrumentation MIB

Server Administrator Remote Access MIB

Server Administrator Baseboard Management Controller, ASF MIB

Server Administrator Field Replaceable Unit MIB

Server Administrator Storage Management MIB

Server Administrator Change Management MIB

How This Guide Defines Technical Terms

SNMP Basic Terminology

Frequently Used Terms in Variable Names

Tabl es

Reference Guide Content Tables

Section Organization

Other Documents You May Need

Introduction to the Server Administrator SNMP Subagent

SNMP MIB OIDs

SNMP Security

Management Actions

SNMP Traps

Instrumentation MIB Version Group

MIB Major Version Number

MIB Minor Version Number

MIB Maintenance Version Number

Systems Management Software Group

Systems Management Software

Systems Management Software Name

Systems Management Software Version Number Name

Systems Management Software Build Number

Systems Management Software Description Name

Systems Management Software Supported Protocol

Systems Management Software Preferred Protocol

Systems Management Software Update Level Name

Systems Management Software URL Name

Systems Management Software Language Name

Systems Management Software Global Version Name

Systems Management Software Feature Flags

Systems Management Software SNMP Agent Feature Flags

Systems Management Software Manufacturer Name

Systems Management Software Variable Values

System State Group

System State Group Table

System State Table

Chassis Information Group

Chassis Information Group Tables

Chassis Information Table

UUID Table

POST Log Table

Event Log Table

System BIOS Table

Firmware Table

Intrusion Table

Baseboard Table

Chassis Information Group Variable Values
