Dell OpenManage™

Server Administrator

Version 5.0

Command Line Interface

User's Guide

www.dell.com | support.dell.com

Notes and Notices

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

____________________

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell, the DELL logo, PowerEdge, and Dell OpenManage are trademarks of Dell Inc.; Microsoft, Windows,

MS-DOS, and Windows NT are registered trademarks and Windows Server is a trademark of Microsoft Corporation; SUSE is a registered trademark of Novell, Inc. in the United States and other countries; Red Hat is a registered trademarks of Red Hat, Inc.; Intel, Pentium, and Xeon are registered trademarks and Itanium and Intel386 are trademarks of Intel Corporation; VESA is a registered trademark of V ideo Electronic Standards Association; UNIX is a registered trademark of The Open Group in the United States and other countries; OS/2 is a registered trademark of International Business Machines Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

February 2006

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

What's New for Version 5.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Using CLI Commands from Windows Command Prompts

Primary CLI Commands

CLI Error Checking and Error Messages

Success Messages Failure Messages

Scripting and Comparing With the CLI

Command Syntax Overview

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

. . . . . . . . . . . . . . . . . . . . . 15

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

. . . . . . . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . 13

2 omhelp: Getting Help With CLI Commands . . . . . . . . . . . . 19

Example Help Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3 omdiag: Using the Diagnostic Service . . . . . . . . . . . . . . . 23

omdiag about. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

omdiag about details=true

omdiag chassis

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

omdiag chassis -? omdiag chassis cmos omdiag chassis memory omdiag chassis modem omdiag chassis network omdiag chassis parallelport omdiag chassis pci omdiag chassis rac omdiag chassis serialport omdiag chassis usbctrl

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

. . . . . . . . . . . . . . . . . . . . . . . . . . 27

. . . . . . . . . . . . . . . . . . . . . . . . . . . 27

. . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Contents 3

omdiag storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

omdiag storage -? omdiag storage cddvd omdiag storage floppy omdiag storage idedevdiag omdiag storage raidctrl omdiag storage sasdevdiag omdiag storage scsidevdiag

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . . . . 35

. . . . . . . . . . . . . . . . . . . . . . . . . 35

. . . . . . . . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . . . . . . . . . . . . . . . . . 37

. . . . . . . . . . . . . . . . . . . . . . . . 38

omdiag system

omdiag system -?

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4 omreport: Viewing System Status Using the

Instrumentation Service

Conventions for Parameter Tables. . . . . . . . . . . . . . . . . . . . . . . . 41

omreport Command Summary

Help With the omreport Command

omreport about

omreport chassis Commands

omreport chassis omreport chassis acswitch omreport chassis batteries omreport chassis bios omreport chassis biossetup omreport chassis bmc omreport chassis currents omreport chassis fans omreport chassis fancontrol omreport chassis firmware omreport chassis frontpanel omreport chassis fru omreport chassis info omreport chassis intrusion omreport chassis leds omreport chassis memory omreport chassis nics omreport chassis ports

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . 45

. . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . 47

. . . . . . . . . . . . . . . . . . . . . . . . . . . 47

. . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . . . . . 52

. . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . . . . 54

4 Contents

omreport chassis processors. . . . . . . . . . . . . . . . . . . . . . . . 55

omreport chassis pwrsupplies omreport chassis remoteaccess omreport chassis slots omreport chassis temps omreport chassis volts

. . . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . . . . 58

omreport system Commands

omreport system Commands for Viewing Logs omreport system alertaction omreport system assetinfo omreport system events omreport system operatingsystem omreport system pedestinations omreport system platformevents omreport system recovery omreport system shutdown omreport system summary omreport system thrmshutdown omreport system version

. . . . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . . . . . 60

. . . . . . . . . . . . . . . . . . . . . . . . . 61

. . . . . . . . . . . . . . . . . . . . . . . . . . 61

. . . . . . . . . . . . . . . . . . . . . 62

. . . . . . . . . . . . . . . . . . . . . . 62

. . . . . . . . . . . . . . . . . . . . . . 64

. . . . . . . . . . . . . . . . . . . . . . . . . 64

. . . . . . . . . . . . . . . . . . . . . . 67

. . . . . . . . . . . . . . . . . . . . . . . . . . 68

5 omconfig: Managing Components Using the

Instrumentation Service

Conventions for Parameter Tables. . . . . . . . . . . . . . . . . . . . . . . . 69

omconfig Command Summary

Help With the omconfig Command

. . . . . . . . . . . . . . . . . . . . . . . . . 69

. . . . . . . . . . . . . . . . . . . . . . . . . . 70

. . . . . . . . . . . . . . . . . . . . . . . 72

omconfig about

omconfig chassis

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

omconfig chassis biossetup omconfig chassis bmc omconfig chassis currents omconfig chassis fans omconfig chassis fancontrol omconfig chassis frontpanel omconfig chassis info omconfig chassis leds

. . . . . . . . . . . . . . . . . . . . . . . . 74

. . . . . . . . . . . . . . . . . . . . . . . . . . . 80

. . . . . . . . . . . . . . . . . . . . . . . . . 90

. . . . . . . . . . . . . . . . . . . . . . . . . . . 91

. . . . . . . . . . . . . . . . . . . . . . . . 92

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

. . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Contents 5

omconfig chassis memorymode . . . . . . . . . . . . . . . . . . . . . . 94

omconfig chassis remoteaccess omconfig chassis temps omconfig chassis volts

. . . . . . . . . . . . . . . . . . . . . . . . . . 105

. . . . . . . . . . . . . . . . . . . . . . 95

. . . . . . . . . . . . . . . . . . . . . . . . . 104

omconfig preferences

omconfig preferences cdvformat omconfig preferences dirservice omconfig preferences snmp omconfig preferences useraccess

omconfig system

omconfig system alertaction Commands for Clearing Logs omconfig system pedestinations omconfig system platformevents omconfig system events omconfig system webserver omconfig system recovery omconfig system shutdown omconfig system thrmshutdown

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

. . . . . . . . . . . . . . . . . . . . . 106

. . . . . . . . . . . . . . . . . . . . . . . 107

. . . . . . . . . . . . . . . . . . . . 108

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

. . . . . . . . . . . . . . . . . . . . . . . 109

. . . . . . . . . . . . . . . . . . . . . . . 111

. . . . . . . . . . . . . . . . . . . . . 112

. . . . . . . . . . . . . . . . . . . . . . . . . 115

. . . . . . . . . . . . . . . . . . . . . . . 117

. . . . . . . . . . . . . . . . . . . . . . . . 117

. . . . . . . . . . . . . . . . . . . . . . . . 118

. . . . . . . . . . . . . . . . . . . . . 119

6 omconfig system assetinfo: Editing Cost of

Ownership Values

omconfig System Asset Info Overview . . . . . . . . . . . . . . . . . . . . 121

User Level Required for Adding Asset Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

. . . . . . . . . . . . 121

6 Contents

Adding Acquisition Information

. . . . . . . . . . . . . . . . . . . . . . . . 121

Example Commands for Adding Acquisition Information

Adding Depreciation Information

. . . . . . . . . . . . . . . . . . . . . . . 123

Example Commands for Adding Depreciation Information

Adding Extended Warranty Information

. . . . . . . . . . . . . . . . . . . . 124

Example Command for Adding Extended Warranty Information

Adding Lease Information

Example Command for Adding Lease Information

Adding Maintenance Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . 125

. . . . . . . . . . . . 125

. . . . . . . . . . . . . . . . . . . . . . . 126

Example Command for Adding Maintenance Information

. . . . . . . . 122

. . . . . . . . 123

. . . . . 124

. . . . . . . . 126

Adding Outsource Information. . . . . . . . . . . . . . . . . . . . . . . . . 127

Example Command for Adding Outsource Information

. . . . . . . . . . 127

Adding Owner Information

Example Command for Adding Owner Information

Adding Service Contract Information

Example Command for Adding Service Information

Adding Support Information

Example Command for Adding Support Information

Adding System Information

Example Command for Adding System Information

Adding Warranty Information

Example Command for Adding Warranty Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . 128

. . . . . . . . . . . . 128

. . . . . . . . . . . . . . . . . . . . . 129

. . . . . . . . . . . 129

. . . . . . . . . . . . . . . . . . . . . . . . . . 130

. . . . . . . . . . . 130

. . . . . . . . . . . . . . . . . . . . . . . . . . 131

. . . . . . . . . . . 131

. . . . . . . . . . . . . . . . . . . . . . . . . 132

. . . . . . . . . . 132

7 omreport rac: Viewing Remote Access

Controller Components

Conventions for Parameter Tables. . . . . . . . . . . . . . . . . . . . . . . 133

omreport rac Command Summary

Help With the omreport rac Command

omreport rac authentication

Example Command for omreport rac authentication

. . . . . . . . . . . . . . . . . . . . . . . . 133

. . . . . . . . . . . . . . . . . . . . . . . 133

. . . . . . . . . . . . . . . . . . . . 134

. . . . . . . . . . . . . . . . . . . . . . . . . . 134

. . . . . . . . . . . 135

omreport rac dialinusers

omreport rac dialoutusers

omreport rac network

omreport rac modem

omreport rac remote

omreport rac snmptraps

omreport rac users

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

. . . . . . . . . . . . . . . . . . . . . . . . . . . 135

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

omreport rac viewcertificate

. . . . . . . . . . . . . . . . . . . . . . . . . 137

Contents 7

8 omconfig rac: Managing the Remote

Access Controller

Conventions for Parameter Tables. . . . . . . . . . . . . . . . . . . . . . . 139

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

omconfig rac Command Summary

Help With the omconfig rac Command

omconfig rac authentication

. . . . . . . . . . . . . . . . . . . . . . . 139

. . . . . . . . . . . . . . . . . . . . 141

. . . . . . . . . . . . . . . . . . . . . . . . . . 141

Local Operating System Authentication Example Command for omconfig rac authentication

omconfig rac dialinusers

Example Commands

omconfig rac dialoutusers

Example Commands

omconfig rac generatecert

omconfig rac modem

omconfig rac network

Example Command

omconfig rac snmptraps

Example Commands

omconfig rac remote

Example Command

omconfig rac rmdialinuser

Example Command

. . . . . . . . . . . . . . . . . . . . . . . . . . . 142

. . . . . . . . . . . . . . . . . . . . . . . . . . . 143

. . . . . . . . . . . . . . . . . . . . . . . . . . . 144

. . . . . . . . . . . . . . . . . . . . . . . . . . 144

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

. . . . . . . . . . . . . . . . . . . . . . . . . . . 148

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

. . . . . . . . . . . . . . . . . . . . . . . . . . . 149

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

. . . . . . . . . . . . . . . . . 141

. . . . . . . . . . . 142

8 Contents

omconfig rac rmdialoutuser

Example Command

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

omconfig rac rmsnmptrap

Example Command

omconfig rac rmuser

Example Command

omconfig rac reset

omconfig rac uploadcert

omconfig rac users

Example Command

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

. . . . . . . . . . . . . . . . . . . . . . . . . . 150

. . . . . . . . . . . . . . . . . . . . . . . . . . . 150

9 Using the Storage Management Service . . . . . . . . . . . . 155

CLI Command Syntax. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Syntax for Required, Optional, and Variable Command Elements

User Privileges for omreport storage and omconfig storage

omreport Command

omreport Storage Help

omreport Controller Status

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

. . . . . . . . . . . . . . . . . . . . . . . . 159

. . . . . . . . . 158

omreport Global Information (Smart Thermal Shutdown Status) omreport Battery Status omreport Connector Status omreport Enclosure Status omreport Temperature Probe Status omreport Fan Status omreport Power Supply Status omreport EMM Status omreport Array Disk Status omreport Virtual Disk Status

omconfig Global Commands

omconfig Global Enable Smart Thermal Shutdown omconfig Global Disable Smart Thermal Shutdown omconfig Global Rescan Controller

omconfig Controller Commands

omconfig Rescan Controller omconfig Global Rescan Controller omconfig Enable Controller Alarm omconfig Disable Controller Alarm omconfig Quiet Controller Alarm omconfig Test Controller Alarm omconfig Reset Controller Configuration omconfig Create Virtual Disk omconfig Set Controller Rebuild Rate omconfig Set Background Initialization Rate omconfig Set Reconstruct Rate omconfig Set Check Consistency Rate omconfig Export the Controller Log omconfig Import Foreign Configuration

. . . . . . . . . . . . . . . . . . . . . . . . . 159

. . . . . . . . . . . . . . . . . . . . . . . . 160

. . . . . . . . . . . . . . . . . . . 161

. . . . . . . . . . . . . . . . . . . . . . . . . . . 161

. . . . . . . . . . . . . . . . . . . . . . 162

. . . . . . . . . . . . . . . . . . . . . . . . . . 163

. . . . . . . . . . . . . . . . . . . . . . . . 163

. . . . . . . . . . . . . . . . . . . . . . . 164

. . . . . . . . . . . . . . . . . . . . . . . . . . 165

. . . . . . . . . . . 165

. . . . . . . . . . . 166

. . . . . . . . . . . . . . . . . . . . 166

. . . . . . . . . . . . . . . . . . . . . . . . 167

. . . . . . . . . . . . . . . . . . . . . . . 168

. . . . . . . . . . . . . . . . . . . . 168

. . . . . . . . . . . . . . . . . . . . 169

. . . . . . . . . . . . . . . . . . . . . 169

. . . . . . . . . . . . . . . . . . . . . . 169

. . . . . . . . . . . . . . . . . 170

. . . . . . . . . . . . . . . . . . . . . . . 170

. . . . . . . . . . . . . . . . . . 174

. . . . . . . . . . . . . . . 175

. . . . . . . . . . . . . . . . . . . . . 175

. . . . . . . . . . . . . . . . . . 175

. . . . . . . . . . . . . . . . . . . . 176

. . . . . . . . . . . . . . . . . 176

. . . . . . 156

. . . . 159

Contents 9

omconfig Clear Foreign Configuration . . . . . . . . . . . . . . . . . . 177

omconfig Set Patrol Read Mode omconfig Start Patrol Read omconfig Stop Patrol Read

. . . . . . . . . . . . . . . . . . . . . 177

. . . . . . . . . . . . . . . . . . . . . . . . 177

. . . . . . . . . . . . . . . . . . . . . . . . 178

omconfig Virtual Disk Commands

omconfig Blink Virtual Disk

. . . . . . . . . . . . . . . . . . . . . . . . 179

omconfig Unblink Virtual Disk omconfig Initialize Virtual Disk omconfig Cancel Initialize Virtual Disk omconfig Fast Initialize Virtual Disk omconfig Slow Initialize Virtualize Disk omconfig Cancel Background Initialize omconfig Restore Dead Segments omconfig Split Mirror omconfig Unmirror

. . . . . . . . . . . . . . . . . . . . . . . . . . . 182

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

omconfig Assign Dedicated Hot Spare omconfig Unassign Dedicated Hot Spare omconfig Check Consistency omconfig Cancel Check Consistency omconfig Pause Check Consistency omconfig Resume Check Consistency omconfig Delete Virtual Disk

. . . . . . . . . . . . . . . . . . . . . . . 186

omconfig Format Virtual Disk omconfig Reconfiguring Virtual Disks omconfig Change Virtual Disk Policy omconfig Rename Virtual Disk

. . . . . . . . . . . . . . . . . . . . . . . 178

. . . . . . . . . . . . . . . . . . . . . . 179

. . . . . . . . . . . . . . . . . . . . . . 180

. . . . . . . . . . . . . . . . . . 180

. . . . . . . . . . . . . . . . . . . 180

. . . . . . . . . . . . . . . . . 181

. . . . . . . . . . . . . . . . . . . . 181

. . . . . . . . . . . . . . . . . . 183

. . . . . . . . . . . . . . . . 183

. . . . . . . . . . . . . . . . . . . . . . . 184

. . . . . . . . . . . . . . . . . . . 185

. . . . . . . . . . . . . . . . . . 185

. . . . . . . . . . . . . . . . . . . . . . . 186

. . . . . . . . . . . . . . . . . . 187

. . . . . . . . . . . . . . . . . . . 187

. . . . . . . . . . . . . . . . . . . . . . 188

10 Contents

omconfig Array Disk Commands

omconfig Blink Array Disk

. . . . . . . . . . . . . . . . . . . . . . . . 188

. . . . . . . . . . . . . . . . . . . . . . . . 189

omconfig Unblink Array Disk omconfig Prepare to Remove Array Disk omconfig Initialize Array Disk omconfig Offline Array Disk omconfig Offline Array Disk omconfig Online Array Disk

. . . . . . . . . . . . . . . . . . . . . . . . 191

. . . . . . . . . . . . . . . . . . . . . . . . 192

omconfig Assign Global Hot Spare omconfig Unassign Global Hot Spare omconfig Rebuild Array Disk omconfig Cancel Rebuild Array Disk omconfig Remove Dead Segments

. . . . . . . . . . . . . . . . . . . . . . . 189

. . . . . . . . . . . . . . . . . 190

. . . . . . . . . . . . . . . . . . . . . . . 190

. . . . . . . . . . . . . . . . . . . . 193

. . . . . . . . . . . . . . . . . . 193

. . . . . . . . . . . . . . . . . . . . . . . 194

. . . . . . . . . . . . . . . . . . . 195

. . . . . . . . . . . . . . . . . . . . 195

omconfig Clear Array Disk . . . . . . . . . . . . . . . . . . . . . . . . 196

omconfig Cancel Clear Array Disk

. . . . . . . . . . . . . . . . . . . . 196

omconfig Battery Commands

omconfig Recondition Battery omconfig Start Battery Learn Cycle omconfig Delay Battery Learn Cycle

omconfig Connector Commands

omconfig Rescan Connector

omconfig Enclosure Commands

omconfig Enable Enclosure Alarm omconfig Disable Enclosure Alarm omconfig Enable Smart Thermal Shutdown omconfig Disable Smart Thermal Shutdown omconfig Set Enclosure Asset Tag omconfig Set Enclosure Asset Name omconfig Set Temperature Probe Thresholds omconfig Reset Temperature Probe Thresholds omconfig Set All Temperature Probe Thresholds omconfig Reset All Temperature Probe Thresholds omconfig Blink

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

. . . . . . . . . . . . . . . . . . . . . . . . . 197

. . . . . . . . . . . . . . . . . . . . . . 197

. . . . . . . . . . . . . . . . . . . 198

. . . . . . . . . . . . . . . . . . . . . . . . 199

. . . . . . . . . . . . . . . . . . . . . . . 199

. . . . . . . . . . . . . . . . . . . . . . . . 199

. . . . . . . . . . . . . . . . . . . . 200

. . . . . . . . . . . . . . . . . . . . 201

. . . . . . . . . . . . . . . 201

. . . . . . . . . . . . . . . . . . . . 202

. . . . . . . . . . . . . . . . . . . 202

. . . . . . . . . . . . . . 203

. . . . . . . . . . . . . 203

. . . . . . . . . . . . 204

. . . . . . . . . . . 204

10 Working With CLI Command Results . . . . . . . . . . . . . . . 207

Output Options for Command Results . . . . . . . . . . . . . . . . . . . . . 207

Controlling Command Output Display Writing Command Output to a File Selecting a Format for Your CLI Command Output

. . . . . . . . . . . . . . . . . . . 207

. . . . . . . . . . . . . . . . . . . . 207

. . . . . . . . . . . . 209

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Index

Contents 11

12 Contents

Introduction

Whether you are using the graphical user interface (GUI) or the command line interface (CLI), Server Administrator performs essential systems management tasks.

The reporting and viewing features allow retrieval of overall health status for systems on your network. At the component level, you can view information about the voltages, temperatures, current, fan RPM, memory functioning, and many other critical component details. You see a detailed account of many relevant cost of ownership (COO) facts about your system in summary view. Version information for BIOS, firmware, operating system, and all installed software is easy to retrieve. You can also run diagnostic tests on system components.

Configuration features allow the Server Administrator to perform essential tasks described in detail in the following sections.

NOTE: You can use the CLI instead of the Server Administrator home page, and turn the Server Administrator

Web server off if you have security concerns. The CLI does not use the Web server. Use the omconfig system webserver action=stop command to turn off the Web server. The Web server starts automatically after a reboot, so this command must be issued every time a system starts up. See "omconfig system webserver" for more information.

What's New for Version 5.0

• Added support for SUSE® LINUX Enterprise Server (version 9), SP3 for Intel® Extended Memory 64 Technology (Intel EM64T)

• Added support for the following RAID controllers: PERC 5/i Adapter, PERC 5/i Integrated, and SAS 5/iR Integrated

• Added support for the following Dell™ PowerEdge™ systems: 1900, 1950, 1955, 2900, and 2950

• Added support for the following new commands:

chassis remoteaccess

• Phasing out the following commands:

and

chassis rac,

omconfig chassis rac

omreport chassis bmc, omconfig chassis bmc, omreport

omreport chassis remoteaccess

and

omconfig

Using CLI Commands from Windows Command Prompts

If you are running the Windows® operating system, use the 32-bit command prompt to issue a Server Administrator CLI command. You can access the 32–bit command prompt by clicking the

Start button and pointing to Programs→ Accessories→ Command Prompt shortcut, or by clicking the Start button and selecting Run, then typing cmd.exe in the Run dialog box.

Introduction 13

Do not type command into the Run dialog box to launch a command line window; this activates the MS-DOS

emulator command.com, which has environment variable limitations that can cause subtle

problems with the CLI.

Primary CLI Commands

The commands that carry out the functions of Server Administrator are:

•

omconfig

•

omdiag

•

omhelp

•

omreport

The omconfig command writes values that you assign to an object's properties. You can specify values for warning thresholds on components or prescribe what action your system is to take when a certain warning or failure event occurs. You can also use the omconfig command to assign specific values to your system's asset information parameters, such as the purchase price of the system, the system's asset tag, or the system's location.

The omdiag command runs diagnostic tests against system hardware to isolate problems.

The omhelp command displays short text help for CLI commands. The shorthand equivalent of omhelp is the command for which you want help followed by -?. For example, to display help for the omreport command, type one of the following commands:

omhelp omreport omreport -?

The omreport command produces reports of your system’s management information.

NOTE: For an overall summary of CLI commands, type omhelp.

Table 1-1 lists the primary CLI commands used by Server Administrator. This guide contains a section for each primary command.

Table 1-1. CLI Commands and Sections in This Guide

Primary CLI Command

omconfig omconfig: Managing Components

omdiag omdiag: Using the Diagnostic Service

omhelp omhelp: Getting Help With CLI

omreport omreport: Viewing System Status

Section Title Related Sections

omconfig system assetinfo: Editing

Using the Instrumentation Service

Commands

Using the Instrumentation Service

Cost of Ownership Values

omreport rac: Viewing Remote Access Controller Components

14 Introduction

NOTE: Omupdate commands are no longer supported in Server Administrator and are replaced by Dell Update

Package or Server Update Utility commands. To update the different components, download the Dell Update Package and run <package name> /s [/f]. See the Dell Update Packages for Microsoft

Systems User’s Guide, the Dell Update Packages for Red Hat Utility User’s Guide for more information on corresponding CLI syntax.

Enterprise Linux User’s Guide, or the Server Update

Windows Operating

Additional useful topics about the CLI include:

• Working With CLI Command Results

• Glossary

CLI Error Checking and Error Messages

The CLI checks your commands for correct syntax when you enter them. If you enter a command and the command is executed successfully, a message displays, stating that your command has been successful.

Success Messages

For a successful omreport command, data about the component displays. When data for the component displays, your command is successful.

The following omconfig command examples show valid CLI commands and their success messages:

Command:

omconfig chassis temps index=0 warnthresh=default

Message:

Temperature probe warning threshold value(s) set successfully.

Command:

omconfig chassis biossetup attribute=speaker setting=on

Message:

BIOS setup configured successfully.

Command:

omconfig system assetinfo info=depreciation duration=6

Message:

Asset information set successfully.

Introduction 15

Failure Messages

CLI failure messages provide reasons why some commands do not succeed. Some common reasons why commands fail include syntax errors and components that are not present. Many error messages provide syntax information that you can use to execute the command successfully.

If you try to execute a command for a component or feature that is not present in your system configuration, the error message states that the component is not present.

Command:

omreport chassis currents

Example message:

Error! No current probes found on this system.

Command:

omconfig chassis volts index=3 minwarnthresh=3.3000

Example message:

Error! Number with up to 3 digits after decimal point expected, read

3.3000 The value given by the command specifies more than 3 digits after the

decimal point. A valid minimum warning threshold value for volts contains up to 3 digits after the decimal point.

Ty p e :

omconfig chassis volts index=3 minwarnthresh=3.300

When you enter the revised command with three decimal points, you receive another error message:

Error! This voltage probe min warning threshold must be between

11.400 and 12.480.

Revised command:

omconfig chassis volts index=3 minwarnthresh=11.500

Message:

Voltage probe warning threshold(s) set successfully.

16 Introduction

Scripting and Comparing With the CLI

The Server Administrator CLI allows administrators to write batch programs or scripts to be executed by the operating system. For an enterprise with many systems, an administrator could write a configuration script that specified the warning thresholds for each major component of a system and also specified a set of actions that the administrator wants each system to take in case of a warning or failure event. In the most critical cases, the administrator could write a script so that the system shuts down to prevent damage. The administrator could then distribute and execute the script to many managed systems at the same time. Such a scenario facilitates configuring any number of new systems acquired by a company and makes implementation of new system administration policies easier across many existing systems that require reconfiguration.

A similar scenario could be used to populate a large number of newly acquired systems with detailed asset information. Much of the information would be the same, such as the manufacturer or lessor of the system, whether support for the system is outsourced, name of the system's insurance company, method of depreciation, and so on. Any variable that is common to all systems could be scripted, sent to all managed systems, and executed. Asset information that is unique to a system could be scripted as a group and sent to that managed node for execution. For example, a script could specify values for all unique variables such as owner, primary user phone number, asset tag, and so on. Scripts to populate unique values would set all unique variables at once rather than one by one through the system's command line.

In many cases, the CLI allows a user with a very well-defined task in mind to retrieve information about the system rapidly. If a user wants to review a comprehensive summary of all system components and save that summary information to a file for comparison with later system states, the CLI is ideal.

Using CLI commands, administrators can write batch programs or scripts to execute at specific times. When these programs execute, they can capture reports on components of interest, such as fan RPMs during periods of high system usage compared with the same measurements at times of lowest system usage. Command results can be routed to a file for later analysis. Reports can help administrators gain information that can be used to adjust usage patterns, to justify purchasing new system resources, or to focus on the health of a problem component.

Command Syntax Overview

Commands vary in complexity. The simplest command has only command level 1. The omhelp command is a simple command. When you type

The next level of complexity includes commands that contain command levels 1 and 2. All of the about commands are examples of command level 2 complexity. The omconfig about, omdiag about, and omreport about commands all cause a very brief summary to display. The summary shows version information for the systems management software installed on your system; for example, Server Administrator 1.x.

omhelp, a list of the main CLI commands is displayed.

Introduction 17

Some commands have command level 1 and command level 2 and one name=value pair. Consider the following example command that instructs Server Administrator for more details about the environment for Server Administrator:

omreport about details=true

Command level 1 is omreport, command level 2 is about, and the name=value pair is details=true.

Many commands use command level 1, command level 2, and command level 3, but do not require any parameters (name=value pairs). Most omreport commands are of this type. For example:

omreport system alertaction

causes a list of alert actions that are configured for components on your system to be displayed.

The most complex commands have all three command levels and can have multiple name=value pairs. An example of two name=value pairs:

omconfig system assetinfo info=depreciation duration=3

An example of nine name=value pairs:

omconfig system assetinfo info=acquisition purchasecost= <

mmddyy

> ponum=<n> signauth=<

expensed=<

<n> waybill=<n> installdate=<

text

yes | no

> costcenter=<

text

mmddyy

> purchasedate=

In each section, command syntax and other information about commands is formatted with any of the following fields that apply:

command level 1 command level 2 command level 3 name=value pair 1 name=value pair 2

18 Introduction

omhelp: Getting Help With CLI Commands

The omhelp command and its equivalent, <command> -?, accesses the CLI's detailed help text interface. You can get help at several levels of detail.

Each fully qualified CLI command may have a variable number of distinct parts: the command (command level 1), one or more subcommands (command level 2 and command level 3, if present), and one or more name=value pair(s).

By appending -? (space-dash-question mark) to any command, you can get help on the command.

Example Help Commands

When you type omconfig -?, you get general help about the omconfig command. The help at this level lists the available subcommands for omconfig:

•about

•preferences

• chassis

• system

When you type omconfig system -?, CLI help lists all of the subcommands that are available for omconfig system:

• alertaction

• alertlog

• assetinfo

• cmdlog

• esmlog

•events

• recovery

• shutdown

• thrmshutdown

• webserver

omhelp: Getting Help With CLI Commands 19

Figure 2-1 shows the levels of help for a command.

Figure 2-1. Different Levels of Help for a Command

You can also parse the omconfig system assetinfo command as follows:

<command level 1 command level 2 command level 3> <name=value pair 1> [name=value pair 2]

where command levels 1, 2, and 3 are represented by omconfig system assetinfo, name=value pair 1 is represented by info=depreciation, and name=value pair 2 is represented by method=straightline.

To set your depreciation method to straight line, type:

omconfig system assetinfo info=depreciation method=straightline

The CLI responds with the following message:

Asset information set successfully.

When you type

omconfig system assetinfo -?, the help that displays provides information about

assigning values for the name and option fields. Partial results for the request omconfig system assetinfo

-? are as follows:

assetinfo Set asset information.

For one info value, specify one or more optional parameter(s). Table 2-1 displays the optional parameters for info=acquisition:

20 omhelp: Getting Help With CLI Commands

Table 2-1. Optional Parameters

Info Value Optional parameters

Info=acquisition purchasecost=<num>

waybill=<num> installdate=<mmddyy> purchasedate=<mmddyy> ponum=<num> signauth=<text> expensed=<yes|no> costcenter=<text> info=depreciation method=<text> duration=<num> percent=<percent> unit=<months|years|unknown>

omhelp: Getting Help With CLI Commands 21

22 omhelp: Getting Help With CLI Commands

omdiag: Using the Diagnostic Service

The omdiag command allows you to test chassis and storage components such as hard drives, physical memory, communications and printer ports, Network Interface Controllers (NICs), CMOS, and more.

Most tests described in this section take less than one minute. Some tests can take longer depending on the device being tested. You cannot abort tests you start through the command line interface.

NOTICE: If you run omdiag commands from more than one console when the DSM SA Connection Service

(for systems running Microsoft Enterprise Server and Red Hat® Enterprise Linux) is not running, then the test in the first console will run to completion, but the test(s) in the subsequent console(s) may exit with a "Test was interrupted" message.

NOTE: You can abort a Diagnostic Service test run through the CLI by using the Diagnostic Status window in

the Server Administrator GUI. Click the Diagnostics tab, click Status, and click Abort to stop the currently running test or click Abort All to stop the currently running test and all queued tests.

NOTE: You cannot use <Ctrl-C> to cancel a CLI session from the console. However, tests started from the CLI

can be aborted using the "Abort" link in the "Diagnostic Status" page in the GUI.

NOTE: If the secure port server is not running when you type an omdiag command, there will be a noticeable

delay before the command executes because the system must check the hardware to determine the diagnostic information to display.

NOTE: On systems running the Microsoft Windows operating system, the enumeration process requires that

the Windows Management Instrumentation (WMI) services be running.

Windows®) or dsm_om_connsvc (for systems running

SUSE® LINUX

Table 3-1 is a high-level summary of the omdiag command. The columns titled "Command level 2" and "Command level 3" list the major arguments that can be used with omdiag. The "Use" column provides a very general statement about the actions that can be performed using omdiag. More details about syntax and use of the command appear later in this section.

Table 3-1. omdiag Command Level 1, Level 2, and Level 3

Command level 1

omdiag

Command level 2

about Displays version number and properties for the

Command level 3

details= true

name=value pair

Use

Server Administrator program.

Displays information for all of the Server Administrator programs that are installed.

omdiag: Using the Diagnostic Service 23

Table 3-1. omdiag Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

system any level 3

chassis cmos

Command level 3

command for chassis or storage

memory

modem

network

parallelport

pci

serialport

rac

usbctrl

name=value pair

passes=<n> Runs a test n time(s).

time= <minutes>

quicktest=

haltonerror=

Device=

passes=<n> Runs a test n time(s).

time= <minutes>

quicktest=

haltonerror=

Device=

Use

Runs the test for specified chassis or storage component.

Runs a test for the specified number of minutes <minutes>.

Uses a faster algorithm to conduct a specific test if one is available.

Stops the tests if an error is encountered.

Specifies the device on which to run test.

Runs the CMOS test.

Runs the memory test.

Runs the modem test.

Runs the NIC test.

Runs the parallel port test.

Runs the PCI test.

Runs the serial port test.

Runs the RAC test.

Tests the Universal Serial Bus (USB) controller(s).

Runs a test for no more than the specified number of minutes <minutes>.

Uses a faster algorithm to conduct a specific test if one is available.

Stops the tests if an error is encountered.

Specifies the device on which to run the test.

24 omdiag: Using the Diagnostic Service

Table 3-1. omdiag Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

storage cddvd

omdiag about

Command level 3

floppy

raidctrl

idedevdiag

sasdevdiag

scsidevdiag

name=value pair

passes=<n> Runs a test n time(s).

time= <minutes>

quicktest=

haltonerror=

Device=

Use

Runs the CD/DVD drive test.

Runs the diskette drive test.

Runs the RAID control and attached device test.

Runs the IDE disk tests.

Runs Serial Attached SCSI (SAS), SAS RAID controller, and attached device tests.

Runs the SCSI controller and attached tape and hard drive tests.

Runs a test for no more than the specified number of minutes <minutes>.

Uses a faster algorithm to conduct a specific test if one is available.

Stops the tests if an error is encountered.

Specifies the device on which to run the test.

Use the omdiag about command to learn the product name and version number of the systems management application installed on your system. The following is an example output from the omdiag about command:

Product name : Dell OpenManage Server Administrator Version : 5.

x.x

Company : Dell Inc.

omdiag: Using the Diagnostic Service 25

omdiag about details=true

Use the omdiag about details=true command to see information about all of the Server Administrator programs that are installed. The following is an example output from the omdiag about details=true command:

Product name : Dell OpenManage Server Administrator Version : 5. Copyright : Copyright (C) Dell Inc.

Company : Dell Inc. Contains : Instrumentation Service 5.

x.x

Storage Management Service 3.x. Diagnostic Service 3.x. Sun JRE - OEM Installed Version 1.x. Secure Port Server 1.x. Core Service 1.x. Instrumentation Service Integration Layer 1.x. Storage Management Service Integration Layer 1.x. Server Administrator 5.x.

omdiag chassis

Use the omdiag chassis commands to perform tests on nonstorage components of a system, such as the memory, NICs, PCI, and ports.

NOTE: When you issue CLI commands to a server module in a modular system, chassis refers only to the

server module.

omdiag chassis -?

Use the omdiag chassis -? command to see a list of all chassis components on the system.

26 omdiag: Using the Diagnostic Service

omdiag chassis cmos

Use the omdiag chassis cmos command to test the system configuration information in the CMOS settings. The following test is performed:

• Checksum Test — Performs a checksum test on the CMOS memory to determine if any bytes are corrupt. This test scans the CMOS memory and calculates the checksum of the bytes read from the checksum range. The calculated result is compared with the results stored in the CMOS memory. If they match, the test succeeds; otherwise, the test logs errors.

omdiag chassis memory

Use the omdiag chassis memory command to test the system's RAM. The following test is performed:

NOTE: Shut down all other programs before running this test.

NOTE: Sufficient swap-space (temporary storage space used during a move or reconfiguration) is needed to

support the demands of the memory test.

NOTE: This test checks only memory seen by the operating system on systems that have redundant memory

support (spare bank or mirroring).

• Pattern Test — Checks your system’s memory by using a data patterns test. These patterns test the memory's storage integrity and its ability to store data accurately. This test writes a pattern to each byte in the memory and reads the pattern back. This verifies that the data paths, error-correction circuits, and the memory devices themselves are working correctly.

omdiag chassis modem

Use the omdiag chassis modem command to run tests on all modems.

NOTE: This test runs on analog communication lines (regular telephone lines) and will not test a cable or Digital

Subscriber Link (DSL) modem. Currently, a test is not provided for testing cable or DSL modems; you can, however, test cable or DSL Internet connections. To test an Internet connection that uses a cable or DSL modem, you must use the network test.

NOTE: Shut down all other programs before running this test. If other programs use the modem, the test does not

run and you see "Cannot Run" in the Results window.

omdiag: Using the Diagnostic Service 27

• Modem Test — Sends a series of AT command set commands to your modem to see if it is working. The AT command set is a series of industry-standard instructions for the modem to perform.

NOTE: The correct modem drivers, when required, should be installed for the modem diagnostic tests to run

and provide the best results. For systems running Red Hat Enterprise Linux, in some cases, the "setserial" command can be used to configure the modems without drivers.

The modem test performs the following tests:

– Hayes Basic Command Test— Uses the Hayes basic command set to exercise and diagnose the

functionality of the modem. The Hayes basic commands are written to the modem and the result codes are verified and displayed either textually or numerically. Only important commands that are common across different modems are used during this test.

– Hayes Extended Command Test — Uses the extended command group of the Hayes command

set to exercise and diagnose the functionality of the modem. The Hayes extended commands are written to the modem and the result codes are verified and displayed either textually or numerically. Only important commands that are common across different modems are used during this test.

– S-Registers Test — Uses the selected range of S-Registers to exercise and diagnose the

functionality of the modem. The test saves the current S-register values, sets a new value, verifies that the new value can be read and is correct, and restores the original value. The result codes are verified and displayed either textually or numerically.

NOTE: In cases where the Windows registry with modem drivers is corrupted due to bad installs/uninstalls,

the modem diagnostic might give unexpected results.

• Broadcom Modem Test — Used for both external (for example, connected to a serial port) and internal modems (for example, connected to a PCI slot).

The Broadcom Modem test performs the following tests:

NOTE: The following tests are not supported on systems running a Red Hat Enterprise Linux operating system.

– Broadcom Modem Dialtone Detection Test — Verifies the correct operation of the codec, DAA,

and control logic on the Broadcom V.92 56K modem. This is accomplished by detecting the presence of a dial tone on the telephone line. A telephone line must be attached to the modem for this test to pass. If a dialtone is not detected, a warning is reported.

– Broadcom Modem Loopback Test — Instructs the Broadcom V.92 56K modem to perform a

standard local analog loopback test. A test pattern is looped back and checked by the modem. The test fails if the modem reports any errors during the test.

– Broadcom Modem AT Command Test — Verifies the correct operation of the AT command

microprocessor and associated control functions on the Broadcom V.92 56K modem. A series of ATcommands are issued and the responses are checked for correctness. Each command must correctly return "OK" or an error is reported.

28 omdiag: Using the Diagnostic Service

omdiag chassis network

Use the omdiag chassis network command to test the NIC. Three main categories of diagnostic tests available are:

•

Generic Network Diagnostic Tests

•

Broadcom NIC Diagnostic Tests

•

Intel® NIC Diagnostic Tests

Generic Network Diagnostic Tests

The following two tests are available on all Dell™ supported NICs:

– NIC Communication Test — Checks whether the NIC under test is physically connected (wired)

to the network. It also checks whether the NIC has a valid IP address.

NOTE: The network team test is only available on systems running a supported Microsoft Windows

operating system.

– NIC Team Test — Checks whether the NIC under test is in team mode. NIC teaming is one

method for providing high availability and fault tolerance in systems.

Broadcom NIC Diagnostic Tests

The following tests are available on Dell supported Broadcom NICs:

– BRCMNetwork Control Registers Test — Tests most of the internal registers on the chip. Each

chip contains many internal registers. Each register can contain some read-only bits and some read/write bits. This diagnostic tests read-only bits that cannot be overwritten, and tests if read/write bits can be written properly.

– BRCMNetwork MII Registers Test — Tests most MII registers on the chip. Each chip contains

many MII registers. Each MII register may contain some read-only bits and some read/write bits. This diagnostic tests read-only bits that cannot be overwritten, and tests if read/write bits can be written properly.

– BRCMNetwork EEPROM Test — Tests the EEPROM checksum of the bootstrap record and the

configuration block on the chip.

– BRCMNetwork Internal Memory Test — Tests most of the internal memory of the chip. Each chip

contains a certain amount of on-chip memory to support on-chip processor operations.

– BRCMNetwork Interrupt Test — Tests the interrupt capability of the chip by verifying that the

NDIS driver is able to receive interrupts from the NIC.

– BRCMNetwork MAC Loop–back Test — Verifies that the NDIS driver is able to send and receive

packets from the NIC. It issues IOCTL (Input Output Controls) to request driver setup (MAC layer loop back) in hardware.

– BRCMNetwork PHY Loop–back Test — Verifies that the NDIS driver is able to send and receive

packets from the NIC. It issues IOCTL (Input Output Controls) to request driver setup (PHY layer loop back) in hardware.

omdiag: Using the Diagnostic Service 29

– BRCMNetwork On Chip CPU Test — Tests the internal processor(s) on the chip. The test will

halt all on-chip processors, download an executable binary to the processor memory, and execute the program.

– BRCMNetwork LED Test — Blinks the LEDs on the NIC.

– BRCMNetwork ASF Test — Tests various processor event registers and SMBus control registers.

Exercises ASF related hardware on the chip.

Intel NIC Diagnostic Tests

The following tests are available on Dell supported Intel NICs:

NOTE: For systems that have a PCI-E Intel Network Interface Controller (NIC), Intel PROSet Utility for

Microsoft Device Manager is required for the Intel network adapter diagnostics on systems running a Microsoft Windows operating system. If you have a PCI-X Intel NIC, you may install either the Intel PROSet for Microsoft Device Manager or the Intel PROSet management agent to enable Intel network adapter diagnostics. If you have any other Dell-supported Intel NIC, you should install the Intel PROSet management agent. If these requirements are not met, the Intel vendor tests will not be available (only the default network diagnostics are available). You can access the Intel PROSet for Microsoft Device Manager from either the Dell PowerEdge™ Service and Diagnostic Utilities CD or from the Dell Support website at support.dell.com.

NOTE: The following tests are only available on systems running a supported Microsoft Windows

operating system.

– Intel FIFO Registers Test — Tests FIFO memory on the adapter by writing and reading patterns

to and from the FIFO memory.

– Intel Control Registers Test — Checks for any conflicts in the I/O address and tests the

accessibility of the registers. This test includes all General Registers, Receive Registers, and Transmit Registers. It does not test the EEPROM Control/Data Register.

– Intel EEPROM Test — Verifies the integrity of data read from the EEPROM. This test completes a

write and read from the EEPROM and then compares the results for consistency.

– Intel Interrupt Test — Uses the Interrupt registers to confirm that all NIC Interrupts work.

– Intel MAC Loopback Test — Tests the NIC’s ability to send and receive packets by sending packets to

itself. This test uses the MAC Loopback mode.

NOTE: The Intel MAC Loopback Test is not supported on the Intel PRO/1000 MF and the Intel PRO/1000 MT

DP network cards.

– Intel PHY Loopback Test — Tests the NIC’s ability to send and receive packets by sending packets

to itself. This test uses the PHY Loopback mode. Not all NICs support PHY Loopback.

– Intel Link Test — Checks the network connection, and the NICs send and receive functionality by

sending 1000 proprietary packets out on the network and retrieving those same packets.

30 omdiag: Using the Diagnostic Service

The Intel Online Diagnostics tests and the Intel Offline Diagnostics tests are only available on systems running a supported Red Hat Enterprise Linux operating system.

– Intel Online Diagnostics Tests — Performs a limited set of tests without interrupting normal

NIC operation during the tests.

– Intel Offline Diagnostics Tests — Performs a full set of tests. This test might disrupt the normal

operation of the NIC.

omdiag chassis parallelport

Use the omdiag chassis parallelport command to test the parallel port, which is a high-speed communications port for attaching certain devices to your system.

The parallel port test writes a series of characters to the port and then reads it back again. If this test detects differences between the written and read character series, it logs an error message and the test fails. The parallel port test performs the following tests:

• Mode Test — Tests the different modes of the Extended Capabilities Port (ECP). The following modes are tested:

– Standard Mode (unidirectional)

– Byte Mode (a bi-directional mode, also called Reverse Mode)

– Parallel Port FIFO Mode (SPP hardware-handshake)

– EPP Mode (may not be available depending on chipset)

– ECP FIFO Mode (ECP hardware-handshake)

– FIFO Test Mode (test mode to determine FIFO depth)

– Configuration Mode (cnfgX registers are available)

NOTE: The Mode test may disrupt normal operation of a device connected to the parallel port, for example, a

printer that is printing.

• Parallel Port Register Test — Tests the parallel port registers using a write-read strategy, for example, writing some data into the register, reading the data of the same registry and verifying it against the data written (data-pattern, walking-bit). The following registers are tested:

– Standard Parallel Port (SPP) Registers: Control, Data, and Status Port registers

– Extended Parallel Port (EPP) Registers: Address and EPP Data Port registers

– Extended Capabilities Port (ECP) Register: Extended Control Register (ECR)

– ECP Configuration Registers A and B (cnfgA, cnfgB)

omdiag: Using the Diagnostic Service 31

• FIFO Test — Configures the parallel port to the FIFO Test Mode. It detects the FIFO's depth, writes different data patterns to the FIFO, and reads the patterns back from the FIFO. If the data written and read are different, the test sends out an appropriate result.

• ECP Protocol Test — ECP protocol includes a simple compression scheme (maximum compression of 64:1) called Run-Length Encoding (consecutive repeated bytes are sent as a single byte with a repeatHcount). This test configures the parallel port to FIFO Test Mode, tests if the compression is supported, and sends out an appropriate result.

NOTE: Turn off all connected external devices before running this diagnostic.

omdiag chassis pci

Use the omdiag chassis pci command to test the PCI bus and check all PCI devices.

The PCI test includes the boards configuration test, which checks for the presence of PCI capability and then scans all PCI devices for proper communication. PCI diagnostics enumerate the various kinds of buses on the system board. In addition to the PCI bus, the package enumerates SCSI, IDE, and USB buses. On systems running Microsoft Windows, the enumeration process requires that the WMI (Windows Management Instrumentation) services is running. The following tests are performed by the PCI test:

• PCI Device Configuration Test — Scans through the PCI bus, enumerating all the PCI devices. This test examines the interrupt requests (IRQs) for each PCI device in use and issues a warning for those devices that share the same ones. This test also checks if the driver for the device is loaded and functioning correctly.

omdiag chassis rac

Use the omdiag chassis rac command to run the tests on the remote access controller (RAC).

The RAC test provides IT administrators with continuous access to their systems, enabling a full range of systems management functions including monitoring, controlling, updating, and recovering. The RAC can be connected to a PCI expansion slot or embedded on the system board. DRAC III and above are enumerated and tested, whereas DRAC II is only enumerated, but not tested.

NOTE: In order to run the diagnostics, all the RAC drivers are required to be installed on the system, and the

RAC-specific services are required to be running on the system.

NOTE: In cases where the Windows registry is corrupted due to bad installs/uninstalls of RAC drivers, the

RAC diagnostic might give unexpected results.

The following tests are performed by the RAC test:

• POST Result Test — Runs the power–on self–test (post) on the RAC hardware and firmware, gets the result of the POST operation, and reports any errors.

• In–Band Access Test — Checks the status of the RAC–specific service running on the system that is used for the in–band access of the RAC (through the operating system).

• Out–of–Band Test — Verifies the connectivity to the out–of–band interface of the RAC (the NIC on the RAC). It first checks if the NIC is enabled on the RAC and if a valid IP address is assigned to it. It then checks if it can connect to the HTTPS service running at this IP address.

32 omdiag: Using the Diagnostic Service

omdiag chassis serialport

Use the omdiag chassis serialport command to test all 9-pin (AT) and 25-pin (PC, XT, and PS/2) serial ports. The following tests are performed:

• Serial Port Register Test — Writes different data-patterns to the read-write registers of the serial port, reads them back, and verifies the data against the written data. If this test detects differences between the written and read data, it logs an error message and the test fails.

• Internal Loopback Test — Tests serial ports that have an internal loop-back mode, specifically for testing. This test uses the internal loop-back mode to transmit and receive data and compare that the data received is the same as the data transmitted. The write-only and read-only buffers are tested. Error conditions such as buffer overrun are also detected.

• Baud Rate Test — Verifies the speed of the port against the system clock to ensure that the baud rate is within an acceptable range. The baud rate is controlled by writing appropriate values to the Divisor Latch bytes. The port transmits and receives (in internal loop-back mode) for 2 seconds, and checks whether the number of characters transmitted and received is two times the baud rate divided by 10 (10 bits are used to transfer 1 byte).

• Interrupt Test — Verifies that the serial port is generating or receiving interrupt requests (IRQs) correctly when key events occur. Otherwise error events are generated and the test fails.

NOTICE: This test may disrupt normal operation of a device connected to the serial port, for example, a modem. It

is recommended that any connected external device is turned off when this test is running.

omdiag chassis usbctrl

Use the omdiag chassis usbctrl command to test the USB controller(s).

The USB test performs the following test:

NOTE: The following test is available on systems running supported Microsoft Windows and Red Hat Enterprise

Linux (version 3) and later operating systems.

NOTE: On systems running supported Red Hat Enterprise Linux operating systems, connecting or removing a

USB device from the server while the diagnostics enumeration is in progress, may cause the system to hang.

• USB Node Detection Test — Scans the USB bus, enumerating all the USB devices connected to the USB controller being tested. USB diagnostics enumerate the various kinds of USB controllers on the system board. In addition to the on-board USB controllers, the package enumerates USB controller cards inserted in the PCI slot and any other USB devices connected to the ports of these USB controllers. This test examines hot plugged and unplugged devices from the tested USB controller.

omdiag: Using the Diagnostic Service 33

omdiag storage

Use the omdiag storage commands to perform tests on your system’s storage components, such as the CD drive, DVD drive, diskette drive, hard drive, tape drive, and SCSI or RAID controller.

omdiag storage -?

Use the omdiag storage -? command to see a list of all storage components on the system.

omdiag storage cddvd

Use the omdiag storage cddvd command to test CD and DVD drives.

The CD or DVD drive test runs several tests on a CD or DVD drive to make sure the drive is working properly. This test determines how many CD or DVD drives are in your system and tests only those drives that support the appropriate CD or DVD media. To run this test, you must have a data CD or DVD (such as a program CD or DVD or your system's recovery CD or DVD) in the drive to be tested. Standard music CDs are not suitable for testing.

NOTE: USB CD and DVD drives present at enumeration should not be disconnected at the time of testing if the USB

CD or DVD drive is being tested. A CD must be present in the CD drive being tested.

If there is no data CD or DVD present in the drive to be tested, you will see the following error message:

Media not present in the drive, or the device may have become disconnected, or the cable may be bad. Make sure that the cable is properly connected. Insert media in the drive and run the test again.

The CD/DVD drive test performs the following tests:

• Extremity Test — Conducts negative testing on the drive. The drive is requested to execute illegal commands to access particular extreme sectors or play illegal lists. The test is expected to fail.

• Driver Mechanism Test — Performs the eject, close, and stop actions to determine if the drive servo mechanism, the door motor, and the spindle motor are operating correctly. Slim CD/DVD drives like those generally available in portable and rack-optimized systems do not allow retracting of the eject tray. This kind of CD/DVD drive cannot be tested for drive mechanism test eject and close functionality.

• Read Exerciser Test — Accesses and reads the actual contents of the media. If the data is in the format of files, the data is read sector by sector into a temporary memory buffer during the first attempt. During subsequent reads, the read pattern will follow a random set of sectors for the quick test and a sequential set of sectors for the complete test. This data is then compared with data that was previously stored in the memory to ensure the correctness of the read operation.

NOTICE: Allow sufficient time for the operating system to detect the presence of media in the drive before running

the CD/DVD diagnostics.

34 omdiag: Using the Diagnostic Service

NOTE: This is the longest test in the CD/DVD diagnostics.

NOTE: Multi-session CDs are not supported by this test on supported Red Hat Enterprise Linux operating systems.

If the test fails, insert a different CD without multiple sessions and run the test again.

NOTE: Defective CDs may cause CD drive test failures. If an error occurs, insert a different CD and run the

test again.

omdiag storage floppy

Use the omdiag storage floppy command to test the diskette drive.

The diskette drive test examines your diskette drive using a series of seek and read tests to see if your drive is working correctly. You must insert a diskette into the diskette drive in order to run this test. The diskette test performs the following tests:

• Linear seek Test— Tests the integrity of the diskette drive mechanics. Moves the diskette drive heads continuously, starting from the center of the diskette and moving outward to the maximum track, one track at a time, until the entire disk is tested.

• Random seek Test — Tests the integrity of the diskette drive mechanics. Moves the diskette drive heads to several hundred random locations on the diskette, one track at a time.

• Funnel seek Test — Tests the integrity of the diskette drive mechanics. Moves the diskette drive heads continuously in a funnel fashion. For example, the test moves the heads from the first track on the disk to the last, then to the second track, and from the second to the last track, and then to the third track, and so on.

• Extremity Test — Attempts to access sectors beyond the range and confirms the error received.

• Read-Write Test — Targets an appropriate number of sectors. The data on each of these sectors is read into a buffer where it is stored until it is restored. The algorithm then writes a stream of roving data onto each sector. It then returns to the first designated sector and reads back the data to confirm the data integrity. After this, the original data is restored.

NOTICE: On systems running a supported Red Hat Enterprise Linux operating system, disconnecting the USB cable

of a USB diskette drive while the test is running might cause unpredictable results.

NOTE: Defective diskettes may cause the diskette drive test to fail. If an error occurs, insert a different diskette

and run the test again.

NOTE: Read-only diskettes will cause diskette drive test failures. If the test fails, ensure that the read-only switch

on the diskette is in the read-write (or unlocked) position and run the test again.

omdiag storage idedevdiag

Use the omdiag storage idedevdiag to test IDE hard drives to verify that they are functional. The storage controller test performs the following tests:

IDE Hard Disk Test — Tests the hard drives on your system. This test verifies a drive's ability to respond to commands, return diagnostic information, and ensure data integrity across the entire hard-drive surface.

omdiag: Using the Diagnostic Service 35

omdiag storage raidctrl

Use the omdiag storage raidctrl command to validate normal operations of Adaptec and LSI RAID controllers and connected hard drives. This command allows a user to test all RAID controllers and attached drives. With more command options, a specific controller and its connected hard drives may be tested.

• Adaptec RAID Controller Hardware Test — Performs various tests to validate normal operations of Adaptec RAID controllers. It allows a user to selectively test a specific controller. The test retrieves and verifies the status information of the main components of the controller. It performs basic and advanced operations to verify the working status of the controller. The Adaptec Controller Hardware test performs the following tests:

– Pause-resume I/O Test — Verifies the Pause I/O and Resume I/O functions of the controller on all

of the buses.

– Device scan Test — Verifies the status of devices attached to the controller. This test takes a

snapshot of the status of current attached devices, rescans for all devices, and then compares the status with the first snapshot, reporting any changes.

– NVRAM and battery test Test — Checks for the existence of a nonvolatile random access memory

(NVRAM) and a battery module. If an NVRAM and a battery are present, the test verifies the normal operation of these modules.

– Global cache Test — Retrieves the global cache parameters and verifies the normal operation of

this function.

You must stop an application that reserves the RAID controller before you attempt to run the Adaptec RAID controller diagnostic test or the hard disk diagnostic test. If you do not, the diagnostic reports a failure with the following message:

An application or service that manipulates RAID such as FAST or PERC Console has reserved the controller and must be stopped before running this test. See the Server Administrator online context-sensitive help or the "Server Administrator CLI User's Guide" for more information.

NOTE: To stop FAST or the PERC Console, exit the application.

• LSI RAID Controller Hardware Test — Consists of two parts:

– Configuration Test — Tests and verifies the format and content of the configuration data and

compares it to the actual configuration for any discrepancies. Any format violations and configuration mismatches are reported. Failing this test does not imply that the controller is defective. Instead, failing this test means that the controller's configuration is not the same as the data from NVRAM.

– Timer Test — Tests the timer sequence of the RAID controller. Any nonsupported timer sequence

verifications result in a timer test failure. Timer test failures cause the controller to be marked as failed.

• LSI RAID Controller Battery Test — Tests the voltage and temperature on the battery, if one is present. If this test fails and a battery is installed on your RAID controller, replace the battery. The test is nondestructive; it does not write data to the storage devices managed by the controller.

36 omdiag: Using the Diagnostic Service

• Adaptec and LSI Array Disk Test — Tests the hard drives on your system. You can test hard drives attached to a system through a qualified Adaptec or LSI RAID controller and determine if the drives have failed. This test verifies a drive's ability to respond to commands, return diagnostic information, and ensure data integrity across the entire hard-drive surface.

• Identify Connected Disks —Ensures that the SCSI subsystem between the controller and the connected device is intact. The Identify Connected Disk test is only available if the Adaptec and/or LSI controller have devices connected to them.

NOTE: The hard disk diagnostics are designed to run as a low-priority background task to limit the effect on I/O.

Because of their low priority, it is recommended that you limit hard disk activity while running the diagnostics. The diagnostics may run slowly or even stop while hard disk I/O activity is running simultaneously.

The diagnostics resume when the hard drive I/O activity has decreased. If the following message appears:

Device Inquiry command failed

it is likely that the hard drive is not connected properly. Check the cables to ensure that the hard drive is properly connected to the controller. The hard drive may also fail and display the following message:

Device failed a send diagnostic command: Check cable connections and termination and run this test again. If this error still occurs, it may indicate a hardware problem.

To avoid this message, run the diagnostic when the system is experiencing light hard-drive I/O activity.

• Adaptec and LSI Blink Disk Light — Blinks the lights of a hard drive for 30 seconds to assist in locating the hard drive.

omdiag storage sasdevdiag

Use the omdiag storage sasdevdiag command to test SAS, SAS RAID controllers, and connected devices. This test performs the following tests:

• Physical Integrity Test — Verifies the integrity of the physical layer of the SAS enclosure and its connected hard drives. When a failure is identified, an error message will be displayed indicating that an error has occurred. The detailed Phy error report log (Comma Separated Value, CSV file) is available for Dell technical support personnel for further analysis. Prior knowledge of Phy is required to interpret this log file. CSV files can be opened with common applications such as Microsoft Excel, Open Office, and so on. Contact Dell technical support in case of repeated failures.

• Controller Log Test — SAS RAID controllers store all historical events in their memory. This test exports the logs to a readable text file and Comma Separated Value (CSV) files. Entries in the exported log file are intended for Dell technical support personnel. The messages in the log are informational at the user level. Quick test will only retrieve entries since the last system boot. Using the text or CSV files, Dell support personnel can analyze the logs to identify any potential failure of the system. By default, the test runs for approximately 5 minutes. But in quick mode, it runs for 90 seconds.

omdiag: Using the Diagnostic Service 37

• Enclosure Log Test — Enclosures store all historical events in their memory. This test exports the logs to a readable text file and Comma Separated Value (CSV) files. Entries in the exported log file are intended for Dell technical support personnel. The messages in the log are informational at the user level. Using the text or CSV files, Dell support personnel can analyze the logs to identify any potential failure of the system.

• Disk Self Test — Verifies the hard disks attached to a system through a qualified SAS or RAID controller to determine if the hard disk has failed.

NOTE: The hard disk diagnostics are designed to run as a low-priority background task to limit the effect on I/O.

omdiag storage scsidevdiag

Use the omdiag storage scsidevdiag command to test the SCSI controller, connected hard drives, and tape devices. This test performs the following tests:

• SCSI Channel Communication Test — Ensures that the SCSI subsystem between the controller and connected device is intact. This test is only available if the controller has devices connected to it.

• SCSI Disk Test — Moves the hard drive heads continuously, starting from the center of the disk and moving outward to the maximum track, one track at a time, until the entire disk is tested. For a quick test, this test moves the drive heads to several hundred random locations on the disk, one track at a time.

• Blink Disk Light — Blinks the lights of a hard drive for 30 seconds to assist in locating the drive.

• SCSI Tape Drive Tests — Performs several tests on the SCSI tape drive, which is connected to a SCSI controller channel using a SCSI cable. The appropriate tape drive and SCSI controller drivers must be installed to enumerate the tape drive. The following tests are performed on SCSI tape drives:

– Tape Device Self-Test — Ensures that any media in the drive is writable. For autoloaders/changers,

this test does not require a tape cartridge. For tape drives, a tape cartridge is required as this test writes data to the media installed in the drive. This test initially verifies the communication path from the host to the tape drive. If communication can be established, the test performs a quick test of the drive's RAM and then performs the built-in RAM diagnostic. This diagnostic can vary depending on the type of the drive. For autoloaders/changers, no other tests are performed. For tape drives, the diagnostic writes several blocks of data and filemarks on the drive and tests the drive’s ability to space along the filemarks.

– Tape Drive Media Test — Writes data to media present in the drive. Ensure that any media in the

drive is writable. The quick test will attempt to write 30 percent of the media's capacity and then space back to the beginning of the media. The data is then read to confirm the written data's integrity. The data is erased when the test is complete. The full test will attempt to write 80 percent of the media's capacity.

NOTE: Tape tests can take several hours to complete because the tests are proportional to the tape

capacities. Regular tests can take more than ten hours to complete, while the quick test can take up to ten hours to complete.

38 omdiag: Using the Diagnostic Service

– Tape Drive Insert Test — Verifies the tape drive's ability to load a tape cartridge. This test is not

available for autoloader/changer tape drives. This test also writes a small amount of data, verifies the data written, and then ejects the media.

NOTE: When the media is ejected from the tape drive, run the Tape Drive Insert Test as an individual test. Do

not group this test with any other tests on this device.

– Tape Drive Eject Test — Verifies the tape drive's ability to eject a tape cartridge. It will issue a

Prevent Allow Medium Removal SCSI

This test is not available for autoloader/changer tape drives.

NOTE: When the media is ejected from the tape drive, run the Tape Drive Eject Test as an individual test. Do

not group this test with any other tests on this device.

– Check Tape Drive Firmware (optional) — Checks the tape drive firmware revision number to see

if any updates exist.

• SCSI Tape Library/Changer Tests — Performs several tests on a SCSI tape library or changer, which is connected to a SCSI controller channel using a SCSI cable. Appropriate SCSI controller and tape changer or library drives must be installed for the tape changer or library to be enumerated. The following tests are performed on a SCSI tape library or changer:

– Tape Device Self Test — Initially verifies the communication path from the host to the tape drive.

If communication can be established, the test performs a quick test of the drive's RAM and then performs the built-in RAM diagnostic. This test does not require a tape cartridge. This diagnostic can vary based on the type of the drive.

– Tape Changer Automation Test — Tests the functionality of the robotic components in the

autoloader or library. The test consists of two individual tests: a slot-to-slot test and a slot-to-drive test. The complete tape changer automation test repeats both tests twice.

The slot-to-slot test is not supported on all devices. For devices that support this type of functionality, the test randomly moves tape cartridges from one storage slot to another, and back again.

command and then attempt to unload the tape cartridge.

The slot-to-drive test randomly loads and unloads tape cartridges to and from one or more drives.

– Check Tape Changer/Library Firmware (optional) — Checks the tape changer/library firmware

revision and verifies if an update is required.

omdiag system

You can use the omdiag system command to test any of the components for the system, regardless of whether they are part of the chassis. For example, omdiag system memory tests the memory just the same as if you run omdiag chassis memory.

omdiag system -?

Use the omdiag system -? command to see a list of all components on the system.

omdiag: Using the Diagnostic Service 39

40 omdiag: Using the Diagnostic Service

omreport: Viewing System Status Using the Instrumentation Service

The omreport command allows you to see detailed information about your system components. You can retrieve summaries for many system components at one time, or you can get details about a specific component. This chapter shows you how to get reports with the level of detail that you want.

Commands documented in this chapter vary in whether they define the fields that appear in the results of a particular omreport command. Fields are defined only if they have a special or less familiar use.

As with all other components, you can use omreport to view component status, and omconfig to manage a component. For information on how to configure components for management, see "omconfig: Managing Components Using the Instrumentation Service."

Often you can use omreport commands to get information you need to execute an omconfig command. For example, if you want to edit the minimum temperature for a warning event on a temperature probe, you need to know the index of the probe you want to configure. You can use omreport chassis temps to display a list of probes and their indexes.

Conventions for Parameter Tables

When listing the parameters that a command can take, the parameters are listed in alphabetical order instead of the order in which they appear in the command line interface.

The symbol |, often called pipe, is the logical exclusive or operator. For example, enable | disable means that you can enable or disable the component or feature, but you cannot simultaneously enable and disable the component or feature.

omreport Command Summary

NOTE: Although this chapter lists all possible omreport commands, the commands available on your system

depend on your system configuration. The results that display for the omreport command vary from one system to another. Data displays for installed components only.

NOTE: When a system includes an external chassis, the displayed results vary by operating system.

SUSE

On external chassis information in a separate section after the main chassis information. On Microsoft Windows

LINUX

systems, data about the external chassis does not appear in omreport output.

Enterprise Server and Red Hat® Enterprise Linux systems, omreport commands display

omreport: Viewing System Status Using the Instrumentation Service 41

Table 4-1 is a high-level summary of the omreport command. The column titled "Command level 1" shows the omreport command at its most general. "Command level 2" shows the major objects or components that you can view using omreport (about, chassis, storage, system, and rac). "Command level 3" lists the specific objects and components for which you can view reports. "User privilege required" refers to the type of privilege you need to perform the command, where U=User, P=Power User, and A= Administrator. "Use" is a very general statement about the actions that can be performed using omreport. More details about syntax and use of the command appear later in this section.

Table 4-1 shows the omreport commands available for about, system, and main system chassis. For information about viewing storage components, see "omreport: Viewing System Status Using the Instrumentation Service."

Table 4-1. omreport Command Level 1, Level 2, and Level 3

Command level 1

omreport

Command level 2

about U, P, A Shows version number and properties for the

chassis U, P, A Shows a general status for all main components.

Command level 3

details=true U, P, A Displays information for all of the Server

acswitch U, P, A Shows failover settings where redundant AC

batteries U, P, A Shows properties set for batteries.

bios U, P, A Shows BIOS facts such as manufacturer, version,

biossetup U, P, A Shows BIOS setup properties configured during

bmc U, P, A Shows general information on remoteaccess.

User privilege required

Use

Server Administrator program.

Administrator programs that are installed.

power lines are supported in a system.

and date last updated.

system boot.

NOTE: This subcommand will be phased-out in

future releases. It will be replaced by the subcommand remoteaccess.

currents U, P, A Shows the status and thresholds for the system

current sensors.

fancontrol U, P, A Shows properties set for fan speed.

fans U, P, A Shows status and thresholds for system fans.

firmware U, P, A Shows firmware properties such as version, date

of last update, and whether the firmware is updatable.

42 omreport: Viewing System Status Using the Instrumentation Service

Table 4-1. omreport Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

storage A See "Using the Storage Management Service."

system U, P, A Shows a high-level summary of system

Command level 3

frontpanel U, P, A Shows whether the front panel button settings,

fru U, P, A Shows the Field Replaceable Unit (FRU)

info U, P, A Shows a status summary for main system chassis

intrusion U, P, A Shows the status of the system’s intrusion

leds U, P, A Shows the properties you have set for LEDs to

memory U, P, A Shows properties of your system's memory arrays.

nics U, P, A Shows number of NICs installed in your system,

ports U, P, A Shows properties for your system’s parallel and

processors U, P, A Shows properties of your system’s processors,

pwrsupplies U, P, A Shows properties of power supplies.

remoteaccess U, P, A Shows general information on remote access.

slots U, P, A Shows properties of your system’s expansion slots

temps U, P, A Shows the status and thresholds for the system

volts U, P, A Shows the status and thresholds for the system

User privilege required

Use

such as for the Power button and/or Nonmasking Interrupt (NMI) button (if present on the system), are enabled or disabled.

information.

components.

sensor(s).

flash under various alert conditions.

NIC vendor, NIC description, IP address, and connection status.

serial ports, such as I/O address, IRQ level, connector type, and maximum speed.

including speed, manufacturer, and processor family.

and other slot types.

temperature sensors.

voltage sensors.

components.

omreport: Viewing System Status Using the Instrumentation Service 43

Table 4-1. omreport Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

rac U, P, A See "omreport rac: Viewing Remote Access

Command level 3

alertaction U, P, A Shows warning and failure threshold values, as

alertlog U, P, A Allows the administrator to show the alert log.

assetinfo U, P, A Shows cost of ownership information for

cmdlog U, P, A Allows the administrator to show the

esmlog U, P, A Allows the administrator to show the

events U, P, A Shows the system’s SNMP event settings.

operatingsystem U, P, A Shows the name and version of your

pedestinations U, P, A Shows destinations where alerts for platform

platformevents U, P, A Shows the system’s response for each listed

postlog U, P, A Shows your system’s POST log.

recovery U, P, A Shows how your system is configured to respond

shutdown U, P, A Shows how the shutdown action is to be

summary U, P, A Shows key facts for all system components,

thrmshutdown U, P, A Shows what shutdown action, if any, is to be

version U, P, A Shows a summary for all updatable components

User privilege required

Use

well as actions that have been configured when an essential component detects a warning or failure state.

your system.

command log.

hardware log.

operating system.

events are configured to be sent.

platform event.

to a hung operating system.

performed.

including main system chassis, software, and storage.

taken when a temperature warning or failure condition is detected.

on your system.

Controller Components."

44 omreport: Viewing System Status Using the Instrumentation Service

Help With the omreport Command

Use the omreport -? command to get a list of the available commands for omreport.

Use omreport <command level 2> -? to get help on the level 2 commands about, chassis, and system. The following information on omreport system -? applies equally to getting help for the omreport chassis command.

To see a list of valid commands for omreport system, type:

omreport system -? | more

omreport about

Use the omreport about command to learn the product name and version number of the systems management application installed on your system. The following is an example output from the omreport about command:

Product name Version Copyright Company

For even more details about the environment for Server Administrator, type:

omreport about details=true

Server Administrator includes a number of services, each of which has a version number of its own. The Contains field reports version numbers for the services as well as other useful details. The output below is an example, and can change depending on your configuration and the version of Server Administrator that is installed on your system:

Contains: Instrumentation Service 5.

x.x

Storage Management Service 3.x. Diagnostic Service 3.x. Sun JRE - OEM Installed Version 3.x. Secure Port Server 1.x. Core Service 1.x. Instrumentation Service Integration Layer 1.x. Storage Management Service Integration Layer 1.x. Server Administrator 5.x.

omreport: Viewing System Status Using the Instrumentation Service 45

omreport chassis Commands

Use omreport chassis commands to view details for the entire chassis or for a particular component.

omreport chassis

When you type:

omreport chassis

Server Administrator displays a general status for your main system chassis components.

NOTE: The omreport chassis command does not list the health status of the Diagnostics Service. To view the

health of the Diagnostics Service, see the Properties page for the Main System Chassis object on the Server Administrator home page.

NOTE: When you issue CLI commands to a server module in a modular system, chassis refers only to the

server module.

NOTE: As with all output shown in this guide, the following output is an example and may vary depending on your

system configuration.

SEVERITY : COMPONENT Ok : Fans Critical : Intrusion Ok : Memory Ok : Power Supplies Ok : Temperatures Ok : Voltages

omreport chassis acswitch

Use the omreport chassis acswitch command if your system has redundant AC power lines that are configured in a failover arrangement. When you type:

omreport chassis acswitch

46 omreport: Viewing System Status Using the Instrumentation Service

Server Administrator displays the following output:

AC Failover Switch AC Switch Redundancy

Redundancy Status : Full Number of devices required for full

redundancy Redundancy Mode : Redundancy Configuration : Input Source Line 1, upon redundancy restoration, return to Line 1

AC Power Lines Status : Ok Location : AC Power Line 1 AC Present : Power Present Active Source : Active Status : Ok Location : AC Power Line 2 AC Present : Power Present Active Source : Not Active

Server Administrator reports values for the Redundancy Status and Redundancy Mode fields.

omreport chassis batteries

Use the omreport chassis batteries command to view battery properties.

omreport chassis bios

Use the omreport chassis bios command to view current BIOS information. When you type:

omreport chassis bios

Server Administrator displays a summary of your system’s BIOS information.

omreport: Viewing System Status Using the Instrumentation Service 47

omreport chassis biossetup

Use the omreport chassis biossetup command to view BIOS setup parameters that are normally available only during system boot.

Ty p e :

omreport chassis biossetup

Table 4-2 displays the BIOS setup parameters that are available:

NOTE: Not all the parameters are displayed. Only those BIOS setup properties that are configured during system

boot are displayed.

Table 4-2. BIOS Setup Parameters

Parameters Description

Bezel Displays whether the bezel removal intrusion check during system

reboot is enabled or disabled.

Bootsequence Displays the device that is used to boot the system.

Console Redirection Displays if the BIOS screen is redirected over a particular serial port

or if it is turned off.

Console Redirection After Boot Displays whether console redirection after system reboot is enabled

or disabled.

Diskette Displays whether the diskette is disabled, auto enabled, or read only.

Demand Based Power Management (DBS)

Dual NIC Displays whether NIC 1 and NIC 2 with PXE is enabled or disabled.

External Serial Connector Displays whether the external serial connector is mapped to COM

Console Redirection Failsafe Baud Rate

IDE Displays whether the drive is enabled or disabled.

IDE Primary Drive 0 Displays whether the device is automatically detected and enabled

IDE Primary Drive 1 Displays whether the device is automatically detected and enabled

Intrusion Displays whether the intrusion check is enabled or disabled during

Mouse Displays whether the mouse is enabled or disabled.

NIC and NIC 2 Displays whether the first and second NICs are enabled (with or

Displays whether DBS is enabled or disabled on the system.

port 1 or COM port 2 or a Remote Access Device.

Displays the setting for console redirection failsafe baud rate.

or if the device is disabled.

system boot.

without PXE) or disabled during system boot.

48 omreport: Viewing System Status Using the Instrumentation Service

Table 4-2. BIOS Setup Parameters (continued)

Parameters Description

Numlock Displays whether the keypad can be used as number keys.

Parallel port address Displays whether the address is located on LPT1, LPT2, and LPT3,

or if it is disabled.

Parallel port mode Displays the setting associated with the parallel port.

Primary SCSI Displays whether the device is on or off.

RAID on motherboard Displays whether RAID-on-motherboard is detected as a RAID

device, a SCSI device, or if the device is disabled during system boot.

RAID Channel A Displays whether RAID-on-motherboard Channel A is detected as a

RAID device or a SCSI device.

RAID Channel B Displays whether RAID-on-motherboard Channel B is detected as a

RAID device or a SCSI device.

SATA Displays whether the onboard SATA controller is set to ATA mode,

RAID mode, or is disabled.

SATA port Displays if the SATA port is enabled or disabled.

Secondary SCSI Displays whether the device is enabled or disabled.

Serial Communications Displays whether COM port 1 and COM port 2 are enabled or

disabled with or without console redirection.

Serial Port 1 Displays whether serial port 1 is mapped to a COM port, a

COM port 1, a COM port 3, a COM1 BMC, a BMC Serial, a BMC NIC, a BMC RAC, or is disabled.

Serial Port 2 Displays whether serial port 2 is mapped to a COM port, a

COM port 2, a COM port 4, or is disabled.

Speaker Displays whether the speaker is on or off.

USB or USBB Displays whether the USB port is enabled or disabled.

User accessible USB Displays whether the user-accessible USB port is enabled or disabled.

omreport chassis bmc

NOTE: This command will be phased-out in future releases. It will be replaced by the command omreport chassis

remoteaccess.

Use the omreport chassis bmc command to view baseboard management controller (BMC) general information.

Ty p e :

omreport chassis bmc

omreport: Viewing System Status Using the Instrumentation Service 49

The output from the omreport chassis bmc command lists each of the valid parameters. Table 4-3 shows the available settings.

Table 4-3. omreport chassis bmc

name=value pair Description

config=advsol Reports advanced BMC information on a serial over local area network

(LAN) connection.

config=nic Reports BMC information for the LAN.

config=serial Reports serial port information for BMC.

config=serialoverlan Reports BMC information on a serial over LAN connection.

config=terminalmode Reports terminal mode settings for the serial port.

config=user Reports information on BMC users.

omreport chassis currents

Use the omreport chassis currents command to view current (amperage) probe status and settings. When you type:

omreport chassis currents index=

the index parameter is optional. If you do not specify the index, Server Administrator displays a summary of status, readings, and thresholds set for all current probes present on your system. If you specify the index, Server Administrator displays a summary for a specific current probe.

omreport chassis fans

Use the omreport chassis fans command to view fan probe status and settings. When you type:

omreport chassis fans index=

the index parameter is optional. If you do not specify the index, Server Administrator displays a summary of status, readings, and thresholds set for any fan probes that might be present on your system. If you specify the index, Server Administrator displays a summary for a specific fan probe.

omreport chassis fancontrol

Use the omreport chassis fancontrol command to see how fan speed is set on your system. Fan speed can be set to optimize speed for cooling or for quiet operation. Table 4-4 shows the available settings.

Table 4-4. Fan Control Settings

name=value pair Description

speed=quiet Set fan speed for quiet operation.

speed=maxcool Set fan speed for maximum cooling.

50 omreport: Viewing System Status Using the Instrumentation Service

omreport chassis firmware

Use the omreport chassis firmware command to view current firmware properties. When you type:

omreport chassis firmware

Server Administrator displays a summary of your system’s firmware properties.

omreport chassis frontpanel

Use the omreport chassis frontpanel command to view whether the front panel button control settings, such as for the Power button and/or Nonmasking Interrupt (NMI) button (if present on the system), are enabled or disabled.

If the Power button override is present on your system, you can see whether the Power button override is enabled or not. If enabled, the Power button turns the power to the system On and Off.

If the NMI button is present on your system, you can see whether the NMI button is enabled or not. The NMI button can be used to troubleshoot software and device errors when using certain operating systems.

omreport chassis fru

Use the omreport chassis fru command to view the Field Replaceable Unit (FRU) information. When you type:

omreport chassis fru

Server Administrator displays a summary of your system’s FRU information. This information is available through the Dell OpenManage™ Server Administrator GUI, Simple Network Management Protocol, and Common Information Model and is primarily used to support troubleshooting activities.

omreport chassis info

Use the omreport chassis info command to see a summary of installed component versions. When you type:

omreport chassis info index=

the index parameter specifies a chassis number and is optional. If you do not specify the index, Server Administrator displays summary chassis information for each chassis. If you specify the index, Server Administrator displays summary information for a specific chassis.

omreport: Viewing System Status Using the Instrumentation Service 51

Depending on your configuration, output may resemble the following example:

Index Chassis Name Host Name Baseboard Management Controller Version Primary Backplane Version Sensor Data Record Version Chassis Model Chassis Lock Chassis Service Tag Chassis Asset Tag Flash chassis indentify LED state Flash chassis indentify LED timeout value

If you run this command on a PowerEdge 1655MC system, the following additional information displays:

•

Server Module Service Tag

(The Chassis Service Tag field indicates the service tag of your PowerEdge 1655MC system chassis.)

Server Module Asset Tag

•

Server Module Location

PowerEdge 1655MC system chassis.

— The service tag of the server module that you are currently logged into.

— The asset tag of the server module that you are currently logged into.

— A number assigned to the server module that indicates its position in the

: 0 : Main System Chassis : everglades : 1.80 : 1.01 : SDR Version 0.33 : PowerEdge 1750 : Present : 8RLNB1S : : Off : 300

omreport chassis intrusion

Use the omreport chassis intrusion command to find out whether the cover of your system is open or not. Server Administrator tracks chassis intrusion events because intrusions may indicate an attempt to steal a system component, or to perform unauthorized maintenance on the system. Type:

omreport chassis intrusion

A message that resembles the following may display:

Status Probe Name State

52 omreport: Viewing System Status Using the Instrumentation Service

: Ok : Main chassis intrusion : Chassis is closed

omreport chassis leds

Use the omreport chassis leds command to find out whether clear hard drive fault is supported and what severity level lights up the LED. Type:

omreport chassis leds index=

The index parameter is optional. If you do not specify the index, Server Administrator displays a summary of LED information for chassis 0. If you specify the index, Server Administrator displays a summary for a specific chassis.

The following is an example output:

Flash chassis indentify LED state Flash chassis indentify LED

timeout value

: Off : 300

omreport chassis memory

Use omreport chassis memory to see details for each memory module slot in your system. If your system supports redundant memory, this command also displays the status, state, and type of memory redundancy implemented on your system. Type:

omreport chassis memory index=

The index parameter is optional. If you do not specify the index, Server Administrator displays information for all memory on your system. If you specify the index, Server Administrator displays a summary for a specific memory module.

Output for an occupied memory slot may resemble the following:

Index Status Connector Name Type Size

An unoccupied memory slot still has a connector name. Output for an unoccupied memory slot may resemble the following:

: 1 : OK : DIMM_B : SDRAM-SYNCHRONOUS : 256 MB

Index Status Connector Name Type Size

: 2 : Unknown : DIMM_D : Not Occupied : Unknown

omreport: Viewing System Status Using the Instrumentation Service 53

If your system supports redundant memory, the redundancy output may resemble the following:

Memory Redundancy Redundancy Status Fail Over State Redundancy Configuration Attributes Memory Array 1 Attributes Memory Array 1 Attributes Memory Array 1 Attributes Memory Array 1 Attributes Memory Array 1

: Full : Inactive : SpareBank : Location : Proprietary Add-on Card : Use : Unknown : Installed Capacity : 1536 MB : Maximum Capacity : 12288 MB : Slots Available : 12

omreport chassis nics

Use the omreport chassis nics command to view NIC properties. Type:

omreport chassis nics index=

The index parameter is optional. If you do not specify the index, Server Administrator displays properties about all NICS on your system. If you specify the index, Server Administrator displays properties for a specific NIC.

Values display for the following fields: Index (number of the NIC card), IP address, Ve nd or, Description, and Connection Status.

omreport chassis ports

Use the omreport chassis ports command to view properties of your system’s parallel and serial ports.

Values display for the following fields: Port Type, External Name, Base I/O Address, IRQ Level,

Connector Type, and Maximum Speed.

Port Type is the detailed type of each system port, from the more general serial, parallel, and USB ports to

the names of ports by device type connected to it, for example, pointing device or keyboard.

External Name is the name of the port, such as serial or parallel, USB, mouse, keyboard, and so on.

Base I/O Address is the starting I/O address expressed in hexidecimal.

IRQ Level is a hardware interrupt on a system. The hardware interrupt signals the system's CPU that an

event has started or ended in a peripheral component such as a modem or printer. When communicated over a peripheral component interconnect card, the IRQ level is a standard way to identify the type of device that is sending the interrupt request.

54 omreport: Viewing System Status Using the Instrumentation Service

Connector Type refers to the type of plug or cable and plug that connects two devices together, in this case, the type of connector that attaches an external device to a system. There are many connector types, each designed to connect a different device type to a system. Examples include DB-9 Male, AT, Access Bus, PS/2, and so on.

Maximum Speed is the port speed. Port speed refers to the data transmission rate of an input/output channel, measured in numbers of bits per second. Serial ports usually have a maximum speed of 115 Kbps and USB version 1.x ports have a maximum speed of 12 Kbps.

omreport chassis processors

Use the omreport chassis processors command to view properties of your system’s processors.

Values display for the following fields: Connector Name, Manufacturer, Processor Family, Processor

Ver si on , Current Speed, External Clock Speed, and State.

Connector Name refers to the name or number of the device that occupies the processor slot in

the system.

Manufacturer is the business entity that sells the processor.

Processor Family refers to the type of processor made by a manufacturer such as Intel

Pentium

III.

Processor Version refers to the model and stepping number of the processor.

Current Speed is the actual processor speed in MHz at system boot time.

External Clock Speed is the speed of the processor's external clock in MHz.

State refers to whether the processor slot is enabled or disabled.

Core Count refers to the number of processors integrated onto one chip.

Itanium™ or

Cache Properties for a Specific Processor

To learn the cache properties for a processor on a given connector, type:

omreport chassis processors index=

The index parameter is optional. If you do not specify the index, Server Administrator displays properties for all processors. If you specify the index, Server Administrator displays properties for a specific processor.

The following fields are defined for a cache present on a particular microprocessor. If the cache is internal to the processor, the fields do not appear in the cache report:

• Speed

• Cache Device Supported Type

• Cache Device Current Type

• External Socket Name

omreport: Viewing System Status Using the Instrumentation Service 55

Fields Reported for Each Cache on a Particular Processor

Status reports whether a specific cache on the processor is enabled or disabled.

Level refers to primary or secondary cache. Primary-level cache is a memory bank built into the processor.

Secondary-level cache is a staging area that feeds the primary cache. A secondary-level cache may be built into the processor or reside in a memory chip set outside the processor. The internal processor cache is referred to as a Level 1 (or L1). L2 cache is the external cache in a system with an Intel Pentium processor, and it is the second level of cache that is accessed. The names L1 and L2 are not indicative of where the cache is physically located (internal or external), but describe which cache is accessed first (L1, therefore internal).

Speed refers to the rate that the cache can forward data from main memory to the processor.

Max Size is the maximum amount of memory that the cache can hold in KB.

Installed Size is the actual size of the cache.

Ty p e indicates whether the cache is primary or secondary.

Location is the location of the cache on the processor or on a chip set outside the processor.

A Write Policy describes how the cache deals with a write cycle. In a write-back policy, the cache acts like a buffer. When the processor starts a write cycle the cache receives the data and stops the cycle. The cache then writes the data back to main memory when the system bus is available.

In a write-through policy, the processor writes through the cache to main memory. The write cycle does not complete until the data is stored into main memory.

Associativity refers to the way main memory content is stored on the cache.

• A fully associative cache allows any line in main memory to be stored at any location in the cache.

• A 4-way set-associative cache directly maps four specific lines of memory to the same four lines of cache.

• A 3-way set-associative cache directly maps three specific lines of memory to the same three lines of cache.

• A 2-way set-associative cache directly maps two specific lines of memory to the same two lines of cache.

• A 1-way set-associative cache directly maps a specific line of memory in the same line of cache.

For example, line 0 of any page in memory must be stored in line 0 of cache memory.

Cache Device Supported Type is the type of static random access memory (SRAM) that the device can support.

Cache Device Current Type is the type of the currently installed SRAM that the cache is supporting.

External Socket Name Silk Screen Name is the name printed on the system board next to the socket.

Error Correction Type identifies the type of error checking and correction (ECC) that this memory can

perform. Examples are correctable ECC or uncorrectable ECC.

This report shows cache information for each cache present on the microprocessor.

56 omreport: Viewing System Status Using the Instrumentation Service

omreport chassis pwrsupplies

Use the omreport chassis pwrsupplies command to view properties of your system’s power supplies. Ty p e :

omreport chassis pwrsupplies index=

The index parameter is optional. If you do not specify the index, Server Administrator displays properties for all power supplies in your system. If you specify the index, Server Administrator displays properties for a specific processor.

For each power supply in the system, values display for the following fields: Status, Location, Ty p e , Max Wattage, and Online Status.

omreport chassis remoteaccess

NOTE: This command is applicable to Dell™ PowerEdge x8xx and x9xx systems only.

Use the omreport chassis remoteaccess command to view general information on baseboard management controller (BMC) and remote access control (RAC) if DRAC is installed.

Ty p e :

omreport chassis remoteaccess

The output from the omreport chassis remoteaccess command lists each of the valid parameters. Table 4-5 shows the available settings.

Table 4-5. omreport chassis remoteaccess

name=value pair Description

config=advsol Reports advanced BMC or RAC information on a serial over local area

network (LAN) connection.

config=nic Reports BMC or RAC information for the LAN.

config=serial Reports serial port information for BMC or RAC.

config=serialoverlan Reports BMC or RAC information on a serial over LAN connection.

config=terminalmode Reports terminal mode settings for the serial port.

config=user Reports information on BMC or RAC users.

omreport chassis slots

Use the omreport chassis slots command to view properties of your system’s slots. Type:

omreport chassis slots index=

The index parameter is optional. If you do not specify the index, Server Administrator displays properties for all of the slots in your system. If you specify the index, Server Administrator displays properties for a specific slot.

omreport: Viewing System Status Using the Instrumentation Service 57

For each slot in the system, values display for the following fields: Index, Slot ID, Adapter, and Data Bus Width.

Index is the number of the slot in the system.

Slot ID is the silk screen name printed on your system's motherboard next to the slot. Alphanumeric text

uniquely identifies each slot in the system.

Adapter refers to the name and or type of the card that fits into the slot, for example, a storage array controller, SCSI adapter, or HBA.

Data bus width is the width, in bits, of the information pathway between the components of a system. Data bus width range is 16 to 64 bits.

omreport chassis temps

Use the omreport chassis temps command to view properties of your system’s temperature probes. When you type:

omreport chassis temps index=

The index parameter is optional. If you do not specify the index, Server Administrator displays a summary of status, readings, and thresholds set for any temperature probes that might be present on your system. If you specify the index, Server Administrator displays a summary for a specific temperature probe.

omreport chassis volts

Use the omreport chassis volts command to view properties of your system’s voltage probes. When you type:

omreport chassis volts index=

The index parameter is optional. If you do not specify the index, Server Administrator displays a summary of status, readings, and thresholds set for any voltage probes that might be present on your system. If you specify the index, Server Administrator displays a summary for a specific voltage probe.

omreport system Commands

Use the omreport system commands to view logs, to see how shutdown actions are configured, and to view threshold values, cost of ownership information, and information about how recovery actions are configured.

omreport system

Use the omreport system command to see a general status for your system components. When you specify a level 3 command, such as omreport system shutdown, you can get detailed information for one system component rather than the high level status that you get with omreport system. Type:

omreport system

58 omreport: Viewing System Status Using the Instrumentation Service

If your system has both a main system chassis and at least one direct attached storage device, Server Administrator may display a summary that resembles the following example.

NOTE: As with all output shown in this guide, the following output is an example and may vary depending on your

system configuration.

SEVERITY : COMPONENT Ok : Main System Chassis Critical : Storage

Commands for Viewing Logs

You can use the omreport system command to view logs: the alert log, the command log, the hardware or ESM log, and the POST log.

NOTE: If the Alert log or Command log displays invalid XML data (such as when XML data generated for the

selection is not well-formed), clearing the log by typing "omconfig system alertlog action=clear" or "omconfig system cmdlog action=clear" resolves the issue. If you need to retain the log information for future reference, you should save a copy of the log before clearing the log. See "Commands for Clearing Logs" for more information about clearing logs.

To view the contents of the alert log, type:

omreport system alertlog

To view the contents of the command log, type:

omreport system cmdlog

To view the contents of the ESM log, type:

omreport system esmlog

To view the contents of the POST log, type:

omreport system postlog

ESM Log Overall Health Status

When you type omreport system esmlog, the Embedded Systems Management (ESM) report displays. The first line of the report reflects the overall health of the system hardware. For example, Health: OK means that less than 80 percent of the space allotted for the esmlog is occupied with messages. If 80 percent or more of the allotted space for the esmlog is occupied, the following caution appears:

Health: Non-Critical

If a caution appears, resolve all warning and critical severity conditions, and then clear the log.

omreport: Viewing System Status Using the Instrumentation Service 59

omreport system alertaction

Use the omreport system alertaction command to see a summary of alert actions that have been configured for warning and failure events on your system components. Alert actions determine how Server Administrator responds when a component has a warning or failure event.

The omreport system alertaction command is useful for viewing which alert actions have been specified for components. To set an alert action for a component, you must use the omconfig system alertaction command. See "omconfig: Managing Components Using the Instrumentation Service."

Components and Events for Which You Can View Alert Actions

You can view alert action properties for the following components and events, if the components/events are present on the system:

• battery warning

• battery failure

• chassis intrusion

• current probe warning

• current probe failure

•fan warning

• fan failure

• memory pre-failure

• memory failure

• power supply warning

• power supply failure

• degraded redundancy

• lost redundancy

• temperature warning

• temperature failure

• voltage warning

• voltage failure

• processor warning

• processor failure

• hardware log warning

• hardware log full

• watchdog ASR

60 omreport: Viewing System Status Using the Instrumentation Service

omreport system assetinfo

Use the omreport system assetinfo command to see cost of ownership data for the system, such as acquisition, depreciation, and warranty information. To set any of these fields, you must use the omconfig system assetinfo command. See "omconfig: Managing Components Using the Instrumentation Service."

omreport system events

Use the omreport system events command to view the current enabled or disabled SNMP traps. This command displays a summary of each component in your system for which events can be generated. For each component, the report shows which severities are set to be reported and which severities are set not to be reported. The following is an example output for a few components:

omreport system events Current SNMP Trap Configuration

----------System

----------Settings Enable: Informational, Warning and Critical Disable: None

--------------Power Supplies

---------------Settings Enable: Informational, Warning and Critical Disable: None

----------Fans

----------Settings Enable: Critical Disable: Informational and Warning

The full report lists the settings for all components in your system for which events can be generated.

To view the status for components of a specific type, use the omreport system events type= <component name> command. This command displays a summary of each component in your system for which events can be generated. Table 4-6 shows the events displayed for various component types.

NOTE: Some component types may be unavailable on your system.

omreport: Viewing System Status Using the Instrumentation Service 61

Table 4-6. System Events by Component Type

name=value pair Description

type=accords Reports events for AC power cords.

type=battery Reports events for batteries

type=currents Reports events for fan amperage probes.

type=fanenclosures

type=fans Reports events for fans.

type=intrusion Reports events for chassis intrusion.

type=log Reports events for logs.

type=memory Reports events for memory.

type=powersupplies Reports events for power supplies.

type=redundancy Reports events for redundancy.

type=temps Reports events for temperatures.

type=volts Reports events for voltages.

Example Command for Event Type

Reports events for fan enclosures.

When you type:

omreport system events type=fans

The following is an example output:

----------Fans

----------Settings Enable: Critical Disable: Informational and Warning

omreport system operatingsystem

Use the omreport system operatingsystem command to display operating system information.

omreport system pedestinations

Use the omreport system pedestinations command to view destinations where alerts for platform events are configured to be sent. Depending on the number of destinations displayed, you can configure a separate IP address for each destination address.

Ty p e :

omreport system pedestinations

62 omreport: Viewing System Status Using the Instrumentation Service

The output from the omreport system pedestinations command lists each of the valid parameters.

NOTE: The actual number of destinations that can be configured on your system may differ.

Table 4-7 shows the available settings.

Table 4-7. omreport system pedestinations

Output Attributes Description

Destination List

Destination Number: Destination1

Destination IP Address: 101.102.103.104

Destination Number: Destination 2

Destination IP Address: 110.120.130.140

Destination Number: Destination 3

Destination IP Address: 201.202.203.204

Destination Number: Destination 4

Destination IP Address: 210.211.212.213

Destination Configuration Settings

attribute=communitystring communitystring: Displays the text

destination 1: Displays the first destination.

101.102.103.104: IP address of the first destination.

destination 2: Displays the second destination.

110.120.130.140: IP address of the second destination.

destination 3: Displays the third destination.

201:202:203:204: IP address of the third destination.

destination 4: Displays the fourth destination.

210.211.212.213: IP address of the fourth destination.

string that acts as a password and is used to authenticate SNMP messages sent between the baseboard management controller (BMC) and the destination management station.

omreport: Viewing System Status Using the Instrumentation Service 63

omreport system platformevents

Use the omreport system platformevents command to view how the system responds for each listed platform event.

omreport system recovery

Use the omreport system recovery command to see whether there is an action configured for a hung operating system. You can also view the number of seconds that must elapse before an operating system is considered to be hung.

omreport system shutdown

Use the omreport system shutdown command to view any pending shutdown actions for your system. If properties for shutdown are configured, executing this command displays them.

omreport system summary

Use the omreport system summary command to view a comprehensive summary of software and hardware components currently installed on your system.

Example Command Output

When you type:

omreport system summary

the output that appears in your CLI window depends on the systems management software, operating system, and hardware components and options that are installed on your system. The following partial command results are unique and may not resemble the results for your system’s hardware and software configuration:

System Summary

-----------------Software Profile

-----------------System Management

Name : Dell OpenManage Server Administrator Version : 5. Description : Systems Management Software

64 omreport: Viewing System Status Using the Instrumentation Service

x.x

Contains: : Instrumentation Service 5.x.

: Storage Management Service 3.x. : Diagnostic Service 3.x.

: Sun JRE - OEM Installed Version 3.x. : Secure Port Server 1.x.

: Dell OpenManage Core Service 1.x.

: Instrumentation Service Integration Layer 1.x.

: Storage Management Service Integration Layer 1.x. Operating System Name : Microsoft Windows 2000 Server Version : Service Pack 3 (Build 2 System Time : Fri Sep 20 18:02:52 2 System Bootup Time : Wed Sep 18 18:37:58 2

XXX

)

The system summary hardware information includes data values for installed components of the following types that are present in your system:

System Attributes

• Host name

• System location

Main System Chassis

Chassis

• Chassis model

• Chassis service tag

• Chassis lock

• Chassis asset tag

If you run this command on a PowerEdge 1655MC system, the following additional information displays:

•

Server Module Service Tag

— The service tag of the server module that you are currently logged into.

(The Chassis Service Tag field indicates the service tag of your PowerEdge 1655MC system chassis.)

•

Server Module Asset Tag

•

Server Module Location

— The asset tag of the server module that you are currently logged into.

— A number assigned to the server module that indicates its position in the

PowerEdge 1655MC system chassis.

omreport: Viewing System Status Using the Instrumentation Service 65

Processor

The following are listed for each processor in the system:

• Processor manufacturer

• Processor family

• Processor version

• Current speed

• Maximum speed

• External clock speed

•Voltage

Memory

• Total installed capacity

• Memory available to the operating system

• Total maximum capacity

• Memory array count

Memory Array

The following details are listed for each memory board or module in the system (for example, the system board or the memory module in a given slot number):

• Location

•Use

• Installed capacity

• Maximum capacity

• Slots available

• Slots used

• ECC type

BIOS

• Manufacturer

• BIOS version

• Release date

• BIOS firmware information

•Name

• BIOS firmware version

66 omreport: Viewing System Status Using the Instrumentation Service

Firmware

•Name

•Version

Network Interface Card

The following details are listed for each NIC in the system:

• IP address

• Subnet mask

• Default gateway

• MAC address

Storage Enclosures

The following details are listed for each storage enclosure attached to the system:

•Name

• Product ID

omreport system thrmshutdown

Use the omreport system thrmshutdown command to view which properties, if any, have been configured for a thermal shutdown action.

The three properties that display for thermal shutdown are disabled, warning, or failure. If the CLI displays the following message, the thermal shutdown feature has been disabled:

Thermal protect shutdown severity: disabled

If the system is configured to shutdown when a temperature probe detects a warning or failure event, one of the following messages displays:

Thermal protect shutdown severity: warning Thermal protect shutdown severity: failure

omreport: Viewing System Status Using the Instrumentation Service 67

omreport system version

Use the omreport system version command to list the version numbers of the BIOS, firmware, systems management software, and operating system that are installed on your system.

Example Command Output

When you type:

omreport system version

the output that appears in your CLI window depends on the version of the BIOS, RAID controllers, and firmware installed on your system. The following partial command results are unique and may not resemble the results for your system’s configuration:

Version Report

--------------------Main System Chassis

--------------------Name : BIOS

Version : A12 Updateable : N/A

Name : Baseboard Management Controller Version : 2.00 Updateable : N/A

Name : Primary Backplane Version : 1.01 Updateable : N/A

--------------Software

--------------Name : Microsoft Windows 2000 Advanced Server

Version : 5.0 Service Pack 4 (Build 2195) on x86 Updateable : N/A

Name : Dell Server Administrator Version : 5.0.0 Updateable : N/A

68 omreport: Viewing System Status Using the Instrumentation Service

omconfig: Managing Components Using the Instrumentation Service

The omconfig command allows you to provide values that define warning events, configure alert actions, clear logs, and configure system shutdown, as well as allowing you to perform other systems management tasks.

Examples of omconfig capabilities include the administrator's privilege to clear command, alert, and hardware logs; the administrator's privilege to configure and execute system shutdown; power user and administrator's privilege to default or specify values for warning events on current probes, fans, voltage probes, and temperature probes; power user and administrator's privilege to set alert actions in the event of a warning or failure event from intrusion, current probes, fans, voltage probes, and temperature probes.

For information on how to use the omconfig system command to view and to manage cost of ownership information (assetinfo), see "omconfig system assetinfo: Editing Cost of Ownership Values."

Often you must use the omreport commands to get the information you need to execute an omconfig command. For example, if you want to edit the minimum temperature for a warning event on a temperature probe, you need to know the index of the probe you want to configure. You can use the omreport chassis temps command to display a list of probes and their indexes. For more information on using the omreport command, see "omreport: Viewing System Status Using the Instrumentation Service."

Conventions for Parameter Tables

When listing the parameters that a command can take, the parameters are listed in alphabetical order instead of the order in which they appear in the command line interface.

omconfig: Managing Components Using the Instrumentation Service 69

omconfig Command Summary

NOTE: Although this section lists all possible omconfig commands, the commands available on your system depend

on your system configuration. If you try to get help or execute a command for a component that is not installed on your system, Server Administrator issues a message that the component or feature is not found on the system.

Table 5-1 is a high-level summary of the omconfig command. The columns titled "Command level 2" and "Command level 3" list the major arguments that can be used with omconfig. "User privilege required" refers to the type of privilege you need to perform the command, where U=User, P=Power User, and A=Administrator. "Use" is a very general statement about the actions that can be performed using omconfig. More details about syntax and use of the command appear later in this section.

Table 5-1. omconfig Command Level 1, Level 2, and Level 3

Command level 1

omconfig

Command level 2

about U, P, A Shows version number and properties for the

preferences

system

Command level 3

details=true U, P, A Displays information for all of the Server

cdvformat A Specifies the delimiter for separating data fields

dirservice A Configures the Active Directory service.

snmp A Sets the SNMP root password.

useraccess A Determines whether users below the

alertaction P, A Determines in advance what actions are to be

alertlog P, A Allows the administrator to clear the log.

assetinfo P, A Enters and edits cost of ownership information

cmdlog P, A Allows the administrator to clear the log.

esmlog P, A Allows the administrator to clear the log.

User privilege required

Use

Server Administrator program.

Administrator programs that are installed.

reported in custom delimited format (cdv).

administrator level are allowed to use Server Administrator or not.

taken for warning or failure events on intrusion, fans, temperatures, voltages, power supplies, memory, and redundancy.

for your system, including values for depreciation, lease, maintenance, service, and support.

70 omconfig: Managing Components Using the Instrumentation Service

Table 5-1. omconfig Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

chassis

Command level 3

events P, A Enables and disables SNMP traps.

pedestinations P, A Sets IP addresses for alert destinations.

platformevents A Determines the shutdown action, if any, to be

recovery P, A Determines in advance how your system

shutdown A Allows the administrator to select from several

thrmshutdown A Sets the severity level at which a thermal event

webserver A Starts or stops the Web server.

biossetup A Configures behavior of specific system

bmc P, A Configures remote access information.

User privilege required

Use

taken for a specific platform event. Also, enables and disables platform events filter alert generation.

responds to a hung operating system.

options when shutting down the system.

triggers a system shutdown.

components that are controlled by the BIOS.

NOTE: This subcommand will be phased-out in

future releases and replaced by the subcommand remoteaccess.

currents P, A Configures current probe warning thresholds

by default or by value.

fans P, A Configures fan probe warning thresholds by

default or by value.

NOTE: You cannot change threshold values on

embedded server management (ESM3) and Dell™ PowerEdge™ x8xx systems.

fancontrol P, A Allows you to optimize fan speed for

maximum cooling or quiet operation.

frontpanel A Configures the Power button and Nonmasking

Interrupt (NMI) button if present on the system.

info P, A Allows you to set an initial value for, or to edit

the value for, asset tag or chassis name.

leds P, A Specifies when to flash a chassis fault LED or

chassis identification LED, and allows you to clear the LED for the system's hard drive.

omconfig: Managing Components Using the Instrumentation Service 71

Table 5-1. omconfig Command Level 1, Level 2, and Level 3 (continued)

Command level 1

Command level 2

Command level 3

memorymode A Enables or disables the spare bank and

remoteaccess P, A Configures remote access information.

temps P, A Sets warning threshold values by default or value.

User privilege required

Use

mirroring memory modes, and also specify which mode to use.

NOTE: You cannot change threshold values on

ESM3 and PowerEdge x8xx systems.

volts P, A Sets warning threshold values by default or value.

NOTE: You cannot change threshold values on

ESM3 and PowerEdge x8xx systems.

storage See "Using the Storage Management Service."

Help With the omconfig Command

Use the omconfig -? command to get a list of the available commands for omconfig.

Use omconfig <command level 2> -? to get help on the level 2 commands about, chassis, preferences, and system. The following information on omconfig system -? applies equally to getting help for the omconfig chassis command.

Use the omconfig system -? command to get a list of the available commands for omconfig system.

Use the omconfig preferences -? command to get a list of the available commands for omconfig preferences, such as cdvformat, which is the custom delimiter format (cdv). Type the following command to display the list of delimiter values for the cdv:

omconfig preferences cdvformat -?

Use a command of the form omconfig system <command level 3> -? to get a list of the parameters you must use to execute a particular omconfig system command. For example, the following commands produce a list of valid parameters for omconfig system alertaction and omconfig system shutdown:

omconfig system alertaction -? omconfig system shutdown -?

In the case of the omconfig system alertaction command, you can use various options to prevent all of the CLI help from scrolling by before you can read it.

To scroll command output one screen at a time, type:

omconfig system alertaction -? | more

where | more allows you to press the spacebar to see the next screen of CLI help output.

72 omconfig: Managing Components Using the Instrumentation Service

To make a file that contains all of the help for the omconfig system alertaction -? command, type:

omconfig system alertaction -? -outa alert.txt

where -outa directs the output of the command to a file called alert.txt.

To read the help for the alertaction command on a Microsoft or SUSE

LINUX Enterprise Server operating system, type:

more alert.txt

Windows®, Red Hat® Enterprise Linux,

omconfig about

Use the omconfig about command to learn the product name and version number of the systems management application installed on your system. The following is an example output from the omconfig about command:

For more details about the environment for Server Administrator, type:

omconfig about details=true

Server Administrator includes a number of services, each of which has a version number of its own. The Contains field reports version numbers for the services and provides other useful details. The output that follows is an example, and it can change depending on your configuration and the version of Server Administrator that is available:

x.x

Contains: Instrumentation Service 5.

Layer 1. Server Administrator 5.x.

x.x

omconfig: Managing Components Using the Instrumentation Service 73

x.x

omconfig chassis

Use the omconfig chassis commands to default or to set values for current, fan, voltage, and temperature probes, to configure BIOS behavior during system start up, to clear memory error counts, and to enable or disable power button control features where system configuration permits.

Use the omconfig chassis -? command to see a list of all omconfig chassis commands.

NOTE: When you issue CLI commands to a server module in a modular system, chassis refers only to the

server module.

omconfig chassis biossetup

Use the omconfig chassis biossetup command to configure system BIOS settings that are normally available only in your system's BIOS setup boot time settings.

NOTICE: Changing certain BIOS setup options might disable your system or require you to reinstall the

operating system.

NOTE: You must reboot your system before any changes to the BIOS setup options take effect.

NOTE: Not all BIOS setup options are available on every system.

Table 5-2 shows the name=value pairs you can use with this command.

Table 5-2. BIOS Setup

name=value pair 1 attribute=

attribute=acpwrrecovery setting=off | last | on off: System is turned off.

attribute=bezel setting=enable | disable enable: Enable the bezel removal

attribute=bootsequence setting=diskettefirst | hdonly

attribute=conredirect setting=enable | disable enable: Redirects the BIOS screen over

name=value pair 2 setting=

| devicelist |cdromfirst

Description

last: System returns to previous state.

on: System is turned on.

intrusion check during system boot.

disable: Disable the bezel removal intrusion check during system boot.

Tells the BIOS which device is used to boot the system, and the order in which the boot routine is to check each device.

Serial Port 1. Keyboard and text output are redirected over Serial Port 2.

disable: Turns off the BIOS console redirection.

74 omconfig: Managing Components Using the Instrumentation Service

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=crab setting=enable | disable enable: Enable BIOS console redirection

name=value pair 2 setting=

Description

after system reboot.

disable: Disable BIOS console redirection.

NOTE: The command crab is valid for Dell

PowerEdge 2900, 2950, 1950, and 1955 systems only.

attribute=cpuht setting=enable | disable enable: Enable logical processor hyper

threading.

disable: Disable logical processor hyper threading.

attribute=cpuvt setting=enable | disable enable: Enable virtualization.

disable: Disable virtualization.

attribute=dbs setting=enable | disable enable: Enables Demand Based Power

Management (DBS) on the system.

disable: Disables DBS on the system.

attribute=diskette setting=off | auto | writeprotect off: Disable the diskette drive.

auto: Auto enable the diskette drive.

writeprotect

the diskette drive read only.

attribute=dualnic setting=off | onpxeboth |

onpxenone | onpxenic1 | onpxenic2

attribute=extserial setting=com1 | com2 | rad com1: Maps external serial connector to

off: The NICs are disabled.

onpxeboth: Both the NICs are PXE

enabled.

onpxenone: PXE is not enabled on either of the NICs.

onpxenic1: PXE is enabled on NIC 1.

onpxenic2: PXE is enabled on NIC 2.

COM 1.

com2: Maps external serial connector to COM 2.

rad: Maps external serial connector to remote access device.

: Do not allow writes. Make

omconfig: Managing Components Using the Instrumentation Service 75

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=fbr setting=9600 | 19200 | 57600 |

attribute=ide setting=on | off

attribute=idepridrv setting=off | auto off: Disables the device.

attribute=intrusion setting=enable | disable enable: Enables the intrusion check

attribute=mouse setting=on | off on: Enable the mouse.

attribute=nic setting=enabled | disabled

name=value pair 2 setting=

115200

force=true

| enablednonepxe

Description

9600: Sets the console redirection failsafe baud rate to 9600 bits per second.

19200: Sets the console redirection failsafe baud rate to 19200 bits per second.

57600: Sets the console redirection failsafe baud rate to 57600 bits per second.

115200: Sets the console redirection failsafe baud rate to 115200 bits per second.

on: Enables this device.

off: Disables this device.

force=true: Verification of setting change.

auto: Automatically detect and enable

the device.

during system boot. If the system also has bezel intrusion checking, then the intrusion option checks for removal of the bezel of the system.

disable: Disables the intrusion check during system boot.

off: Disable the mouse.

enabled: Enable the NIC during system

boot (with PXE on if the system has PXE).

disabled: Disable the NIC during system boot.

enablednonepxe: Enable the NIC during system boot (with PXE off if the system has PXE).

76 omconfig: Managing Components Using the Instrumentation Service

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=nic2 setting=enabled | disabled

attribute=numlock setting=on | off on: Use the keypad as number keys.

attribute=ppaddress setting=off | lpt1 | lpt2 | lpt3 off: Disable the parallel port address.

attribute=ppmode setting=at | ps2 | ecp | epp at: Set the parallel port mode to type AT.

attribute=primaryscsi setting=on | off

name=value pair 2 setting=

| enablednonepxe

force=true

Description

enabled: Enable the second NIC during system boot (with PXE on if the system has PXE).

disabled: Disable the second NIC during system boot.

enablednonepxe: Enable the second NIC during system boot (with PXE off if the system has PXE).

off: Use the keypad as arrow keys.

lpt1: Locate the device on LPT1.

lpt2: Locate the device onLPT2.

lpt3: Locate the device on LPT3.

ps2: Set the parallel port mode to

type PS/2.

ecp: Set the parallel port mode to type ECP (extended capabilities port).

epp: Set the parallel port mode to type EPP (enhanced parallel port).

NOTICE: If you modify the setting for

primary scsi, romb, romba, or rombb, your system becomes inoperable until you reinstall the operating system.

on: Enable this device.

off: Disable this device.

force=true: Verification of

setting change.

omconfig: Managing Components Using the Instrumentation Service 77

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=romb setting=raid | off | scsi

attribute=romba setting=raid | scsi

attribute=rombb setting=raid | scsi

attribute=sata setting=off | ata | raid off: Disables SATA controller.

attribute=sataport (0...7) or (A...H)

attribute=secondaryscsi setting=on | off on: Enables this device.

name=value pair 2 setting=

force=true

setting=off | auto off: Disables the SATA port.

Description

raid: Instructs the BIOS to detect RAID-on-motherboard as a RAID device.

off: Disable the device during system boot.

scsi: Instructs the BIOS to detect this device as a SCSI device.

force=true: Verification of setting change.

raid: Instructs the BIOS to detect RAID-on-motherboard channel A as a RAID device.

scsi: Instructs the BIOS to detect this device as a SCSI device.

force=true: Verification of setting change.

raid: Instructs the BIOS to detect RAID-on-motherboard channel B as a RAID device.

scsi: Instructs the BIOS to detect this device as a SCSI device.

force=true: Verification of setting change.

ata: Sets the onboard SATA controller to ATA mode.

raid: Sets the onboard SATA controller to RAID mode.

auto: Automatically enable the SATA port.

off: Disables this device.

78 omconfig: Managing Components Using the Instrumentation Service

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=serialcom setting=off | on |com1 |com2 off: Disables serial communication

attribute=serialport1 setting=off | auto | com1 | com3

name=value pair 2 setting=

| bmcserial | bmcnic | rac | com1bmc

Description

setting.

on: Enables serial communication setting without console redirection.

com1: Enables serial communication setting with console redirection via COM 1.

com2: Enables serial communication setting with console redirection via COM 2.

off: Disables serial port 1.

auto: Maps serial port 1 to a COM port.

com1: Maps serial port 1 to COM port 1.

com3: Maps serial port 1 to COM port 3.

bmcserial: Maps serial port 1 to

BMC Serial.

bmcnic: Maps serial port 1 to the Baseboard Management Controller (BMC) Network Interface Controller (NIC).

rac: Maps serial port 1 to the Remote Access Controller (RAC).

com1bmc: Maps serial port 1 to COM port 1 bmc.

NOTE: This command is valid on

PowerEdge 1850, 2800, and 2850 systems only.

attribute=serialport2 setting=off | auto | com2 | com4 off: Disables serial port 2.

auto: Maps serial port 2 to a COM port.

com2: Maps serial port 2 to COM port 2.

com4: Maps serial port 2 to COM port 4.

attribute=speaker setting=on | off on: Enables the speaker.

off: Disables the speaker.

omconfig: Managing Components Using the Instrumentation Service 79

Table 5-2. BIOS Setup (continued)

name=value pair 1 attribute=

attribute=uausb setting=on | backonly | off on: Enables the user-accessible

attribute=usb setting=enabled | disabled enabled: Enables the USB port(s).

name=value pair 2 setting=

Description

USB port(s)

backonly: Enables only the user accessible USB port(s) at the back of the system.

off: Disables the user-accessible USB port(s).

disabled: Disables the USB port(s).

NOTE: Depending on your system’s

hardware, only one of the two attributes usb and usbb is available for configuring the USB port(s).

attribute=usbb setting=enabled |

enabledwithbios| disabled

enabled: Enables the USB port(s) during system boot, without BIOS support.

enabledwithbios: Enables the USB port(s) during the system boot, with BIOS support.

disabled: Disables the USB port(s) during system boot.

NOTE: Depending on your system’s

hardware, only one of the two attributes usb and usbb is available for configuring the USB port(s).

omconfig chassis bmc

NOTE: This command will be phased-out in future releases. It will be replaced by the command omconfig chassis

remoteaccess.

Use the omconfig chassis bmc command to configure:

• The BMC on a local area network (LAN)

• The serial port for BMC

• The BMC on a serial over LAN connection

• Terminal settings for the serial port

• Advanced settings for a serial over LAN connection

• Information on a BMC user

NOTE: You have to enter the user ID to configure user information.

80 omconfig: Managing Components Using the Instrumentation Service

Ty p e :

omconfig chassis bmc

The output from the omconfig chassis bmc command lists each of the available configurations. Table 5-3 shows the valid parameters:

Table 5-3. omconfig chassis bmc

name=value pair 1 config=

config=advsol characcuminterval=number number: Sets the character

config=nic enable=true | false true: Enables IPMI over LAN.

name=value pair 2 Description

accumulate interval in 5 millisecond intervals.

charsendthreshold=number number: Sets the number of

characters. BMC automatically sends a serial over LAN data packet that contains this number of characters as soon as this number of characters (or greater) has been accepted from the baseboard serial controller into the BMC.

false: Disables IPMI over LAN.

encryptkey=text text: Text to encrypt IPMI sessions.

NOTE: The option text is supported

only on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems.

gateway=gateway Gateway: Sets a gateway address if you

have selected static as the IP address source for the BMC LAN interface.

enablenic=true | false true: Enables the DRAC NIC.

false: Disables the DRAC NIC

NOTE: The option enablenic is

supported only on PowerEdge 1900,1950, 1955, 2900, and 2950 systems that have DRAC installed.

IP address=IP IP: Sets the IP address if you have

selected static as the IP address source for the BMC LAN interface.

omconfig: Managing Components Using the Instrumentation Service 81

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

name=value pair 2 Description

ipsource=static | dhcp | systemsoftware

static: Static if the IP address of the BMC LAN interface is a fixed, assigned IP address.

dhcp: DHCP if the source of the IP address of the BMC LAN interface is the dynamic host configuration protocol.

systemsoftware: System software if the source of the IP address of the BMC LAN interface is from the system software.

NOTE: Not all commands may be

supported on the system.

nicselection=nic1 | teamednic1nic2 | dracnic

nic1: Enables NIC 1.

teamednic1nic2: Enables NIC

teaming functionality.

dracnic: Enables DRAC NIC if DRAC 5 is installed.

NOTE: The option nicselection is

supported only on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems.

NOTE: If there are multiple embedded

NICs on your system, you can select the NIC teaming option to share the BMC management traffic between them.

privilegelevel=administrator | operator | user

subnet=Subnet subnet: Sets a subnet mask if you have

administrator: Sets the maximum privilege level that can be accepted on a LAN channel to Administrator.

operator: Sets the maximum privilege level that can be accepted on a LAN channel to Operator.

user: Sets the maximum privilege level that can be accepted on a LAN channel to User.

selected static as the IP address source for the BMC LAN interface.

82 omconfig: Managing Components Using the Instrumentation Service

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=serial baudrate=9600 | 19200 | 38400 |57600

name=value pair 2 Description

vlanenable=true | false true: Enables the virtual

vlanid=number number: Virtual LAN identification in

vlanpriority=number number: Priority of virtual LAN

| 115200

flowcontrol=none | rtscts none: No control over the flow of

LAN identification.

false: Disables the virtual LAN identification.

the range of 1 to 4094.

identification in the range of 0 to 7.

9600: Sets connection speed to 9600 bits per second.

19200:Sets connection speed to 19200 bits per second.

38400: Sets connection speed to 38400 bits per second.

57600: Sets connection speed to 57600 bits per second.

115200: Sets connection speed to 115200 bits per second.

NOTE: Baud rates of 9600, 19200, 38400,

and 57600 are supported on PowerEdge 1800,1850, 2800, and 2850 systems. Baud rates of 9600, 19200, and 57600 are supported on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems. Baud rate of 115200 is supported on certain systems that have a DRAC 5 installed.

communication through the serial port.

rtscts: RTS is ready to send and CTS is clear to send.

omconfig: Managing Components Using the Instrumentation Service 83

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=serial

(continued)

name=value pair 2 Description

directbasic: Type of messaging used for IPMI messaging over a serial connection.

directterminal: Type of messaging that uses printable ASCII characters and allows a limited number of text commands over a serial connection.

directbasicterminal: Both basic and terminal mode messaging over a serial connection.

modembasic: Type of messaging used for IPMI messaging over a modem.

modemterminal: Type of messaging that uses printable ASCII characters and that allows a limited number of text commands over a modem.

modembasicterminal: Both basic and terminal messaging over a modem.

NOTE: Not all commands may be

supported on the system.

privilegelevel=administrator | operator | user

config=serialoverlan enable=true | false true: Enables serial over LAN for

administrator: Sets the maximum privilege level that can be accepted on a serial connection, to Administrator.

operator: Sets the maximum privilege level that can be accepted on a serial connection, to Operator.

user: Sets the maximum privilege level that can be accepted on a serial connection, to User.

the BMC.

false: Disables serial over LAN for the BMC.

84 omconfig: Managing Components Using the Instrumentation Service

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=serialoverlan

(continued)

name=value pair 2 Description

baudrate=9600 | 19200 | 38400 | 57600 | 115200

9600: Sets the volatile and nonvolatile connection speed to 9600 bits per second.

19200: Sets the volatile and nonvolatile connection speed to 19200 bits per second.

38400: Sets the volatile and nonvolatile connection speed to 38400 bits per second.

57600: Sets the volatile and nonvolatile connection speed to 57600 bits per second.

115200: Sets the volatile and nonvolatile connection speed to 115200 bits per second.

NOTE: Baud rates of 9600 and 19200

are supported on PowerEdge 1800, 1850, 2800, and 2850 systems. Baud rates of 9600, 19200, and 57600 are supported on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems. Baud rate of 115200 is supported on certain systems that have a DRAC 5 installed.

privilegelevel=administrator | operator | user

config=settodefault Takes the default configuration

administrator: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to Administrator.

operator: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to Operator.

user: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to User.

settings.

omconfig: Managing Components Using the Instrumentation Service 85

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=terminalmode deletecontrol=outputdel |

name=value pair 2 Description

outputbkspspbksp

echocontrol=enabled | disabled enabled: Enables characters to be sent

handshakingcontrol=enabled | disabled enabled: Directs the BMC to output a

outputdel: BMC outputs a <del> character when <bksp> or <del> is received.

outputbkspspbksp: BMC outputs a <bksp><sp><bksp> character when <bksp> or <del> is received.

to the screen.

disabled: Disables characters to be sent to the screen.

character sequence that indicates when its input buffer is ready to accept another command.

disabled: Does not direct the BMC to output a character sequence that indicates when its input buffer is ready to accept another command.

86 omconfig: Managing Components Using the Instrumentation Service

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=terminalmode

(continued)

name=value pair 2 Description

inputlinesequence=cr | null cr: The console uses <CR> as a new

line sequence.

null: The console uses <NULL> as a new line sequence.

lineediting=enabled | disabled enabled: Enables line editing as a line

is typed.

disable: Disables line editing as a line is typed.

none: BMC does not use a termination sequence.

crlf: BMC uses <CR-LF> as a new line sequence when the BMC writes a new line to the console.

null: BMC uses <Null> as a new line sequence when the BMC writes a new line to the console.

cr: BMC uses <CR> as a new line sequence when the BMC writes a new line to the console.

lfcr: BMC uses <LF-CR> as a new line sequence when the BMC writes a new line to the console.

lf: BMC uses <LF> as a new line sequence when the BMC writes a new line to the console.

omconfig: Managing Components Using the Instrumentation Service 87

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=user id=number enable=true | false id=number: ID number of the user

name=value pair 2 Description

being configured.

enable=true: Enables user.

enable=false: Disables user.

id=number enableserialoverlan=true | false

id=number: ID number of the user being configured.

enableserialoverlan=true: Enables serialoverlan.

enableserialoverlan=false: Disables serialoverlan.

NOTE: The option enableserialoverlan

is supported only on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems.

config=user

(continued)

id=number name=text number: ID number of the user being

configured.

name=text: Name of the user.

id=number newpw=text

confirmnewpw=text

id=number serialaccesslevel= administrator | operator | user | none

number: ID number of the user being configured.

newpw=text: New password of the user.

confirmnewpw=text: Confirm new password of the user.

id=number: ID number of the user being configured.

serialaccesslevel=administrator: User with an ID has access privileges of an Administrator for the Serial Port channel.

serialaccesslevel=operator: User with an ID has access privileges of an Operator for the Serial Port channel.

serialaccesslevel=user: User with an ID has access privileges of a User for the Serial Port Channel.

serialaccesslevel=none: User with an ID does not have access privileges for the Serial Port Channel.

88 omconfig: Managing Components Using the Instrumentation Service

Table 5-3. omconfig chassis bmc (continued)

name=value pair 1 config=

config=user

(continued)

name=value pair 2 Description

id=user id

id=user id: User ID of the user being configured.

NOTE: Only RAC groups can be

configured. The option dracusergroup is available only if DRAC 5 is present on the system.

dracusergroup=admin: Enables the Administrator User privileges.

dracusergroup=poweruser: Enables the Power User privileges.

dracusergroup=guest: Enables the Guest User privileges.

dracusergroup=testalert: Enables the Test Alert User privileges.

dracusergroup=custom: Enables the Custom User privileges.

NOTE: See Table 5-4 for more

information on the name=value pair.

dracusergroup=custom.

dracusergroup=none: Does not

enable User privileges.

id=number lanaccesslevel= administrator | operator | user| none

id=number: ID number of the user being configured.

lanaccesslevel=administrator: User with an ID has access privileges of an Administrator for the LAN channel.

lanaccesslevel=operator: User with an ID has access privileges of an Operator for the LAN channel.

lanaccesslevel=user: User with an ID has access privileges of a User for the LAN channel.

lanaccesslevel=none: User with an ID does not have access privileges for the LAN channel.

omconfig: Managing Components Using the Instrumentation Service 89

Table 5-4. omconfig chassis bmc config=user id=<user id> dracusergroup=custom

name=value pair 1 config=

config=user id=user id

name=value pair 2 Description

logindrac= true | false

dracusergroup=custom

configuredrac= true | false

configure users= true | false

clearlogs= true | false

executeservercommands= true | false

accessconsoleredir= true | false

accessvirtualmedia= true | false

testalerts= true | false

executediagcommands= true | false

omconfig chassis currents

Use the omconfig chassis currents command to set amperage probe warning thresholds. As with other components, you can view both warning and failure threshold values, but you cannot set failure thresholds. Your system's manufacturer sets the minimum and maximum failure thresholds.

NOTE: Settable thresholds vary from one system configuration to another.

NOTE: Systems that contain embedded systems management 3 (ESM3) capabilities do not allow you to set

warning threshold values to default values.

Valid Parameters for Current Warning Thresholds

Table 5-5 shows the valid parameters for setting current warning thresholds:

NOTE: The index parameter is optional. If you do not specify the index, Server Administrator displays a summary of

status, readings, and thresholds set for all current probes present on your system. "Current probes are not present in all systems". If you specify the index, Server Administrator displays a summary for a specific current probe.

Table 5-5. omconfig chassis currents

name=value pair Description

index=<n> Number of the probe or probe index (must be specified).

warnthresh=default Sets minimum and maximum warning thresholds to default.

90 omconfig: Managing Components Using the Instrumentation Service

Table 5-5. omconfig chassis currents (continued)

name=value pair Description

minwarnthresh=<n> Minimum warning threshold (3 decimal places).

maxwarnthresh=<n> Maximum warning threshold (3 decimal places).

Default Minimum and Maximum Warning Thresholds

If you want to set both the upper and lower current warning threshold values to the recommended default value, type:

omconfig chassis currents index=0 warnthresh=default

You cannot default one value and set another. In other words, if you default the minimum warning threshold value, you are also selecting the default value for the maximum warning threshold value.

Specify a Value for Minimum and Maximum Warning Thresholds

If you prefer to specify values for the current probe warning thresholds, you must specify the number of the probe you are configuring and the minimum and/or maximum warning threshold values. In the following example, the probe that is being configured is probe 0:

omconfig chassis currents index=0 minwarnthresh=3.310 maxwarnthresh=

3.381

When you issue the command and the system sets the values you specify, the following message appears:

Current probe warning threshold(s) set successfully.

omconfig chassis fans

Use the omconfig chassis fans command to set fan probe warning thresholds. As with other components, you can view both warning and failure threshold values, but you cannot set failure thresholds. Your system's manufacturer sets the minimum and maximum failure thresholds.

Valid Parameters for Fan Warning Thresholds

Table 5-6 shows the valid parameters for setting fan warning thresholds:

Table 5-6. omconfig chassis fans

name=value pair Description

index=<n> Number of the probe or probe index (must be specified).

warnthresh=default Sets minimum and maximum warning thresholds to default.

minwarnthresh=<n> Minimum warning threshold.

maxwarnthresh=<n> Maximum warning threshold.

omconfig: Managing Components Using the Instrumentation Service 91

Default Minimum and Maximum Warning Thresholds

NOTE: Systems that contain ESM3, ESM4, and BMC capabilities do not allow you to set warning threshold values

to default values.

If you want to set both the upper and lower fan warning threshold values to the recommended default value, type:

omconfig chassis fans index=0 warnthresh=default

You cannot default one value and set another. In other words, if you default the minimum warning threshold value, you are also selecting the default value for the maximum warning threshold value.

Specify a Value for Minimum and Maximum Warning Thresholds

NOTE: Minimum and maximum warning thresholds for the fan probe cannot be set on PowerEdge

x9xx systems.

8xx and

If you prefer to specify values for the fan probe warning thresholds, you must specify the number of the probe you are configuring and the minimum and/or maximum warning threshold values. In the following example, the probe that is being configured is probe 0. The first command sets only the minimum threshold; the second sets minimum and maximum thresholds:

omconfig chassis fans index=0 minwarnthresh=4580 omconfig chassis fans index=0 minwarnthresh=4580 maxwarnthresh=9160

When you issue the command and the system sets the values you specify, the following message appears:

Fan probe warning threshold(s) set successfully.

omconfig chassis fancontrol

Use the omconfig chassis fancontrol command to set fan speed. You can optimize speed for cooling or for quiet operation. Table 5-7 shows the valid parameters for the command.

Table 5-7. omconfig chassis fancontrol

name=value pair Description

speed=quiet Sets fan speed for quiet operation.

speed=maxcool Sets fan speed for maximum cooling.

omconfig chassis frontpanel

Use the omconfig chassis frontpanel command to configure the Power button and the Nonmasking Interrupt (NMI) button and to specify and configure the LCD line number.

NOTE: The Power and NMI buttons can be configured only if present on the system.

Table 5-8 shows the valid parameters for the command.

92 omconfig: Managing Components Using the Instrumentation Service

Table 5-8. omconfig chassis frontpanel

name=value pair 1 name=value pair 2 Description

lcdindex=<index> NA Specify the LCD line number.

config=none | default | custom

text=<custom text> NA Set the custom text for LCD when config=custom.

nmibutton enable=true | false true: Enables the NMI button on the system.

powerbutton enable=true | false true: Enables the Power button on the system.

NA none: Set the LCD text to none.

default: Set the LCD text to default.

custom: Set the LCD text to custom.

false: Disables the NMI button on the system.

false: Disables the Power button on the system.

omconfig chassis info

Use the omconfig chassis info command to enter an asset tag name for your system and a chassis name for your system. If your system is a modular one, you can enter asset tag names for modular components as well. Table 5-9 shows the valid parameters for the command.

Table 5-9. omconfig chassis info

name=value pair Description

index=<n> Number of the chassis whose asset tag or name you are setting.

tag=<text> Asset tag in the form of alphanumeric text. Letters or numbers

cannot exceed 10 characters.

name=<text> Name of the chassis.

In the following example, the asset tag for the main system chassis is being set to buildsys:

omconfig chassis info index=0 tag=buildsys

Index 0 always defaults to main system chassis. The following command omits index=n, but accomplishes the same thing:

omconfig chassis info tag=buildsys

An acceptable command, when executed, results in the following message:

Chassis info set successfully.

For some chassis, you can assign a different name. You cannot rename the main system chassis. In the example below, the command renames chassis 2 from storscsi1 to storscsia:

omconfig chassis info index=2 name=storscsia

omconfig: Managing Components Using the Instrumentation Service 93

As with other commands, the CLI issues an error message if you do not have a chassis 2 (the main chassis=0). The CLI allows you to issue commands only for the system configuration you have.

omconfig chassis leds

Use the omconfig chassis leds command to specify when to flash a chassis fault LED or chassis identification LED and allow you to clear the LED for the system's hard drive. Table 5-10 shows the valid parameters for the command.

Table 5-10. omconfig chassis leds

name=value pair 1 name=value pair 2 Description

index=<n> NA Number of the chassis where the LED

resides (defaults to chassis 0, main system chassis).

led=fault severity=warning | critical Select to flash the LED either when a

warning event occurs or when a critical event occurs.

led=hdfault action=clear Sets the number of faults for the hard drive

back to zero (0).

led=identify flash=off | on

time-out=<n>

Sets the chassis identification LED to off or on. Set the time-out value for the LED to flash to a number of seconds.

omconfig chassis memorymode

Use the omconfig chassis memorymode command to specify the redundancy mode you want to use for your system’s memory in case of memory errors.

Redundant memory enables a system to switch to other available memory modules if unacceptable errors are detected in the modules it is currently using. The omconfig chassis memorymode command allows you to disable redundancy; when you disable redundancy, you instruct the system not to switch to other available memory modules when the module the system is using begins to encounter errors. If you want to enable redundancy, you must choose among spare, mirror, and RAID.

Spare mode disables a bank of system memory in which a correctable memory event is detected, enables the spare bank, and copies all the data from the original bank to the spare bank. Spare bank requires at least three banks of identical memory; the operating system does not recognize the spare bank.

Mirror mode switches to a redundant copy of memory when an uncorrectable memory event is detected. After switching to the mirrored memory, the system does not switch back to the original system memory until the next reboot. The operating system does not recognize half of the installed system memory in this mode.

RAID mode provides an extra level of memory checking and error recovery at the expense of some memory capacity.

94 omconfig: Managing Components Using the Instrumentation Service

Table 5-11 shows the valid parameters for the command.

Table 5-11. omconfig chassis memorymode

name=value pair 1 Description

index=<n> Number of the chassis where the memory module resides (the default is

chassis 0, the main system chassis).

redundancy=spare | mirror | disabled | raid5

Spare disables the memory module that has a correctable memory event and copies the failing module’s data to a spare bank. Disabled indicates that the system is not to use other available memory modules if uncorrectable memory events are detected. Mirror switches the systems to a mirrored copy of the memory if the failing module has an uncorrectable memory event. In mirror mode, the operating system does not switch back to the original module until the system reboots. RAID5 is a method of system memory configuration. This is logically similar to the RAID 5 mode used in hard drive storage systems. This memory mode gives you an extra level of memory checking and error recovery at the expense of some memory capacity. The RAID mode supported is RAID level 5 striping with rotational parity.

omconfig chassis remoteaccess

NOTE: This command is applicable to PowerEdge x8xx and x9xx systems only.

Use the omconfig chassis remoteaccess command to configure:

• Remote access on a local area network (LAN).

• The serial port for BMC or RAC, whichever is installed.

• The BMC or RAC on a serial over LAN connection.

• Terminal settings for the serial port.

• Advanced settings for a serial over LAN connection.

• Information on a BMC or RAC user.

NOTE: You have to enter the user ID to configure user information.

Ty p e :

omconfig chassis remoteaccess

omconfig: Managing Components Using the Instrumentation Service 95

The output from the omconfig chassis remoteaccess command lists each of the available configurations. Table 5-3 shows the valid parameters:

Table 5-12. omconfig chassis remoteaccess

name=value pair 1 config=

config=advsol characcuminterval=number number: Sets the character accumulate

config=nic enable=true | false true: Enables IPMI over LAN.

name=value pair 2 Description

interval in 5 millisecond intervals.

charsendthreshold=number number: Sets the number of characters. BMC

automatically sends a serial over LAN data packet that contains this number of characters as soon as this number of characters (or greater) has been accepted from the baseboard serial controller into the BMC.

false: Disables IPMI over LAN.

encryptkey=text

confirmencryptkey=text

text: Text used for encryption and confirmation of encryption.

NOTE: The option text is supported only on

PowerEdge 1900, 1950, 1955, 2900, and 2950 systems.

gateway=Gateway Gateway: Sets a gateway address if you have

selected static as the IP address source for the BMC LAN interface.

enablenic=true | false true: Enables DRAC NIC.

false: Disables DRAC NIC

NOTE: The option enablenic is supported on

PowerEdge 1900, 1950, 1955, 2900, and 2950 systems that have DRAC installed.

IP address=IP ip: Sets the IP address if you have selected

static as the IP address source for the BMC LAN interface.

96 omconfig: Managing Components Using the Instrumentation Service

Table 5-12. omconfig chassis remoteaccess (continued)

name=value pair 1 config=

config=nic (continued) ipsource=static | dhcp | systemsoftware static: Static if the IP address of the BMC

name=value pair 2 Description

LAN interface is a fixed, assigned IP address.

dhcp: DHCP if the source of the IP address of the BMC LAN interface is the dynamic host configuration protocol.

systemsoftware: System software if the source of the IP address of the BMC LAN interface is from the system software.

NOTE: Not all commands may be supported on

the system.

nicselection=nic1 | teamednic1nic2 | dracnic

nic1: Enables NIC 1.

teamednic1nic2: Enables NIC teaming

functionality.

dracnic: Enables DRAC NIC if DRAC 5 is installed.

NOTE: The option nicselection is supported

only on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems.

privilegelevel=administrator | operator | user

subnet=Subnet subnet: Sets a subnet mask if you have

administrator: Sets the maximum privilege level that can be accepted on a LAN channel to Administrator.

operator: Sets the maximum privilege level that can be accepted on a LAN channel to Operator.

user: Sets the maximum privilege level that can be accepted on a LAN channel to User.

selected static as the IP address source for the BMC LAN interface.

omconfig: Managing Components Using the Instrumentation Service 97

Table 5-12. omconfig chassis remoteaccess (continued)

name=value pair 1 config=

config=nic (continued) vlanenable=true | false true: Enables the virtual LAN identification.

config=serial baudrate=9600 | 19200 | 38400 | 57600

name=value pair 2 Description

false: Disables the virtual LAN identification.

vlanid=number number: Virtual LAN identification in the

range of 1 to 4094.

vlanpriority=number number: Priority of virtual LAN identification

in the range of 0 to 7.

9600: Sets connection speed to 9600 bits

| 115200

per second.

19200:Sets connection speed to 19200 bits per second.

38400: Sets the volatile and nonvolatile connection speed to 38400 bits per second.

57600: Sets the volatile and nonvolatile connection speed to 57600 bits per second.

115200: Sets the volatile and nonvolatile connection speed to 115200 bits per second.

NOTE: Baud rates of 9600 and 19200 are

supported on PowerEdge 1800, 1850, 2800, and 2850 systems. Baud rates of 9600, 19200, 38400, and 57600 are supported on PowerEdge 1900, 1950, 1955, 2900, and 2950 systems. Baud rate of 115200 is supported on certain systems that have a DRAC 5 installed.

flowcontrol=none | rtscts none: No control over the flow of

communication through the serial port.

rtscts: RTS is ready to send and CTS is clear to send.

98 omconfig: Managing Components Using the Instrumentation Service

Table 5-12. omconfig chassis remoteaccess (continued)

name=value pair 1 config=

config=serial (continued) mode=directbasic | directterminal |

name=value pair 2 Description

directbasicterminal | modembasic | modemterminal | modembasicterminal

privilegelevel=administrator | operator | user

directbasic: Type of messaging used for IPMI messaging over a serial connection.

directterminal: Type of messaging that uses printable ASCII characters and that allows a limited number of text commands over a serial connection.

directbasicterminal: Both basic and terminal mode messaging over a serial connection.

modembasic: Type of messaging used for IPMI messaging over a modem.

modemterminal: Type of messaging that uses printable ASCII characters and that allows a limited number of text commands over amodem.

modembasicterminal: Both basic and terminal messaging over a modem.

NOTE: Not all commands may be supported on

the system.

administrator: Sets the maximum privilege level that can be accepted on a serial connection, to Administrator.

operator: Sets the maximum privilege level that can be accepted on a serial connection, to Operator.

user: Sets the maximum privilege level that can be accepted on a serial connection, to User.

omconfig: Managing Components Using the Instrumentation Service 99

Table 5-12. omconfig chassis remoteaccess (continued)

name=value pair 1 config=

config=serialoverlan enable=true | false true: Enables serial over LAN for the BMC.

name=value pair 2 Description

false: Disables serial over LAN for the BMC.

baudrate=9600 | 19200 | 38400 | 57600 | 115200

9600: Sets the volatile and nonvolatile connection speed to 9600 bits per second.

19200: Sets the volatile and nonvolatile connection speed to 19200 bits per second.

38400: Sets the volatile and nonvolatile connection speed to 38400 bits per second.

57600: Sets the volatile and nonvolatile connection speed to 57600 bits per second.

115200: Sets the volatile and nonvolatile connection speed to 115200 bits per second.

NOTE: Baud rates of 9600 and 19200 are

privilegelevel=administrator | operator | user

config=settodefault Takes the default configuration settings.

config=terminalmode deletecontrol=outputdel |

outputbkspspbksp

administrator: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to Administrator.

operator: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to Operator.

user: Sets the maximum privilege level that can be accepted on a serial over LAN channel, to User.

outputdel: BMC outputs a <del> character when <bksp> or <del> is received.

outputbkspspbksp: BMC outputs a <bksp><sp><bksp> character when <bksp> or <del> is received.

100 omconfig: Managing Components Using the Instrumentation Service
