Dell OpenManage Integration for VMware vCenter 2.1 User Manual

OpenManage Integration for VMware vCenter for Web Client

User's Guide Version 2.1

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. mentioned herein may be trademarks of their respective companies.

2014 - 04

Rev. A00

™

and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks and names

Dell

Contents

1 Introduction............................................................................................................................................. 11

OpenManage Integration for VMware vCenter Features.......................................................................................................11

2 Understanding How to Configure or Edit the OpenManage Integration for VMware

vCenter........................................................................................................................................................ 13

Configuration Wizard Welcome Page.....................................................................................................................................13

vCenter Selection....................................................................................................................................................................13

Creating A New Connection Profile using the Initial Configuration Wizard........................................................................... 14

Scheduling Inventory Jobs [Wizard].......................................................................................................................................16

Running A Warranty Retrieval Job [Wizard]...........................................................................................................................17

Configuring Events And Alarms [Wizard]................................................................................................................................17

3 About VMware vCenter Web Client Navigation................................................................................19

Navigating to the OpenManage Integration for VMware vCenter Inside the VMware vCenter............................................ 19

Understanding Icon Buttons...................................................................................................................................................19

Locating the Software Version............................................................................................................................................... 20

Refreshing the Screen Content...............................................................................................................................................20

Viewing the OpenManage Integration for VMware vCenter Licensing Tab.......................................................................... 20

Opening Online Help............................................................................................................................................................... 21

Finding Help and Support........................................................................................................................................................21

Downloading a Troubleshooting Bundle..........................................................................................................................22

Soft iDRAC Reset.............................................................................................................................................................. 22

Launching the Administration Console.............................................................................................................................23

4 Profiles......................................................................................................................................................25

Viewing Connection Profiles...................................................................................................................................................25

Creating A Connection Profile................................................................................................................................................ 26

Editing a Connection Profile....................................................................................................................................................28

Refreshing A Connection Profile.............................................................................................................................................30

Deleting A Connection Profile.................................................................................................................................................30

Testing a Connection Profile...................................................................................................................................................30

Viewing Chassis Profiles.........................................................................................................................................................30

Editing a Chassis Profile...................................................................................................................................................31

Creating A Chassis Profile................................................................................................................................................31

Deleting Chassis Profiles..................................................................................................................................................32

Testing a Chassis Profile.................................................................................................................................................. 32

5 Job Queue................................................................................................................................................33

Inventory History.....................................................................................................................................................................33

Viewing Hosts Inventory ..................................................................................................................................................33

Changing Inventory Job Schedules................................................................................................................................. 34

Running an Inventory Job Now........................................................................................................................................35

Running a Chassis Inventory job now.............................................................................................................................. 35

Warranty History.....................................................................................................................................................................35

Viewing Warranty History................................................................................................................................................ 35

Modifying a Warranty Job Schedule............................................................................................................................... 36

Running a Hosts Warranty Job Now................................................................................................................................36

Running a Chassis Warranty Job Now.............................................................................................................................37

About Logs.............................................................................................................................................................................. 37

Viewing the Logs.............................................................................................................................................................. 38

Exporting Log Files............................................................................................................................................................38

6 Console Administration..........................................................................................................................39

Using the Administration Console...........................................................................................................................................39

Registering a vCenter Server........................................................................................................................................... 39

Modifying The vCenter Administrator Login.....................................................................................................................40

Updating The SSL Certificates For Registered vCenter Servers......................................................................................40

Uninstalling the OpenManage Integration for VMware vCenter From VMware vCenter................................................40

Uploading a OpenManage Integration for VMware vCenter License to the Administration Console.............................40

Virtual Appliance Management..............................................................................................................................................41

Restarting the Virtual Appliance...................................................................................................................................... 41

Updating a Repository Location and Virtual Appliance....................................................................................................41

Updating the Virtual Appliance Software Version........................................................................................................... 42

Downloading the Troubleshooting Bundle.......................................................................................................................42

Setting Up The HTTP Proxy.............................................................................................................................................. 42

Setting Up the NTP Servers..............................................................................................................................................42

Generating a Certificate Signing Request........................................................................................................................43

Setting up Global Alerts.......................................................................................................................................................... 44

Managing Backup And Restore..............................................................................................................................................44

Configuring Backup And Restore..................................................................................................................................... 44

Scheduling Automatic Backups....................................................................................................................................... 45

Performing An Immediate Backup................................................................................................................................... 45

Restoring the Database from a Backup........................................................................................................................... 45

Understanding the vSphere Client Console ........................................................................................................................... 46

Configuring Network Settings.......................................................................................................................................... 46

Changing the Virtual Appliance Password.......................................................................................................................46

Setting The Local Time Zone............................................................................................................................................ 47

Rebooting Virtual Appliance.............................................................................................................................................47

Resetting The Virtual Appliance To Factory Settings.......................................................................................................47

Refreshing the Console View........................................................................................................................................... 48

Read-only User Role.........................................................................................................................................................48

Migration Path to migrate from 1.6/1.7 to 2.1....................................................................................................................48

7 Settings.....................................................................................................................................................51

Editing the OMSA Link............................................................................................................................................................ 51

Understanding Using OMSA with 11th Generation Servers.............................................................................................51

Viewing Warranty Expiration Notification Settings................................................................................................................ 53

Configuring Warranty Expiration Notification.................................................................................................................. 53

About Firmware Updates........................................................................................................................................................ 53

Setting Up the Firmware Update Repository....................................................................................................................54

Running The Firmware Update Wizard for a Single Host.................................................................................................54

Running the Update Firmware Wizard for a Cluster.........................................................................................................55

Viewing Firmware Update Status for Clusters and Datacenters..................................................................................... 56

Understanding Events And Alarms for Hosts..........................................................................................................................57

Understanding Events And Alarms for Chassis................................................................................................................58

Configuring Events And Alarms .......................................................................................................................................59

Viewing the Data Retrieval Schedules for Inventory and Warranty.......................................................................................60

Understanding Using OMSA with 11th Generation Servers...................................................................................................60

Deploying The OMSA Agent Onto An ESXi System................................................................................................................ 61

Deploying the OMSA Agent onto an ESX System...................................................................................................................61

Setting Up An OMSA Trap Destination...................................................................................................................................61

8 Viewing Warranty Expiration Notification Settings.......................................................................... 63

Configuring Warranty Expiration Notification.........................................................................................................................63

9 About Firmware Updates.......................................................................................................................65

Setting Up the Firmware Update Repository.......................................................................................................................... 66

Running The Firmware Update Wizard for a Single Host....................................................................................................... 66

Running the Update Firmware Wizard for a Cluster............................................................................................................... 67

10 Understanding Events And Alarms for Hosts...................................................................................69

Understanding Events And Alarms for Chassis...................................................................................................................... 70

Configuring Events And Alarms ............................................................................................................................................. 70

Viewing Events................................................................................................................................................................. 71

Viewing the Alarm and Event Settings............................................................................................................................. 71

Viewing the Data Retrieval Schedules for Inventory and Warranty.......................................................................................72

11 Viewing Associated Host for a Chassis............................................................................................ 73

12 Chassis Management.......................................................................................................................... 75

Viewing Chassis Summary Details..........................................................................................................................................75

Viewing Hardware Inventory: Fans.........................................................................................................................................76

Viewing Hardware Inventory: I/O Modules............................................................................................................................ 76

Viewing Hardware Inventory: iKVM....................................................................................................................................... 77

Viewing Hardware Inventory: PCIe.........................................................................................................................................78

Viewing Hardware Inventory: Power Supplies.......................................................................................................................79

Viewing Hardware Inventory: Temperature Sensors............................................................................................................. 80

Viewing Warranty Details....................................................................................................................................................... 80

Viewing Storage......................................................................................................................................................................81

Viewing Firmware Details for a Chassis................................................................................................................................. 82

Viewing Management Controller Details for a Chassis..........................................................................................................82

Viewing Associated Host for a Chassis.................................................................................................................................. 83

13 Monitoring a Single Host.....................................................................................................................85

Viewing Host Summary Details...............................................................................................................................................85

Launching Management Consoles......................................................................................................................................... 88

Launching the Remote Access Console (iDRAC)............................................................................................................. 88

Launching the OMSA Console..........................................................................................................................................89

Launching the Remote Access Console (iDRAC)....................................................................................................................89

Setting Up Physical Server Blink Indicator Light....................................................................................................................89

14 Buying and Uploading a Software License...................................................................................... 91

About OpenManage Integration for VMware vCenter Licensing...........................................................................................91

15 Viewing Hardware: FRU Details for a Single Host.......................................................................... 93

16 Viewing Hardware: Processor Details for a Single Host............................................................... 95

17 Viewing Hardware: Power Supply Details for a Single Host.........................................................97

18 Viewing Hardware: Memory Details for a Single Host...................................................................99

19 View Hardware: NICs Details for a Single Host............................................................................ 101

20 Viewing Hardware: PCI Slots for a Single Host.............................................................................103

21 Viewing Hardware: Remote Access Card Details for a Single Host..........................................105

22 Viewing Storage Details for a Single Host..................................................................................... 107

Viewing Storage: Virtual Disk Details for a Single Host........................................................................................................108

Viewing Storage: Physical Disk Details for a Single Host.................................................................................................... 109

Viewing Storage: Controller Details for a Single Host..........................................................................................................111

Viewing Storage: Enclosure Details for a Single Host..........................................................................................................111

23 Viewing Firmware Details for a Single Host...................................................................................113

24 Viewing Power Monitoring for a Single Host.................................................................................115

25 Viewing Warranty Status for a Single Host....................................................................................117

Renewing Host Warranty......................................................................................................................................................117

26 Quickly Viewing Only Dell Hosts...................................................................................................... 119

27 Monitoring Hosts on Clusters and Datacenters............................................................................ 121

28 Viewing Overview Details for Datacenters and Clusters.............................................................123

29 Viewing Hardware: FRUs for Datacenters or Clusters.................................................................127

30 Viewing Hardware: Processor Details for Datacenters or Clusters.......................................... 129

31 Viewing Hardware: Power Supply Details for Datacenters and Clusters.................................131

32 Viewing Hardware: Memory Details for Datacenters and Clusters...........................................133

33 Viewing Hardware: NICs Details for Datacenters and Clusters.................................................135

34 Viewing Hardware: PCI Slot Details for Datacenters and Clusters........................................... 137

35 Viewing Hardware: Remote Access Card Details.........................................................................139

36 Viewing Storage: Physical Disks for Datacenters and Clusters.................................................141

37 Viewing Storage: Virtual Disk Details for Datacenters and Clusters.........................................145

38 Viewing Firmware Details for Datacenters and Clusters.............................................................149

39 Viewing Warranty Summary Details for Datacenters and Clusters...........................................151

40 Viewing Power Monitoring for Datacenters and Clusters...........................................................153

41 Console Administration......................................................................................................................155

Registering a vCenter Server................................................................................................................................................155

Modifying The vCenter Administrator Login......................................................................................................................... 156

Updating The SSL Certificates For Registered vCenter Servers.......................................................................................... 156

Uninstalling the OpenManage Integration for VMware vCenter From VMware vCenter.................................................... 156

Uploading a OpenManage Integration for VMware vCenter License to the Administration Console..................................157

Restarting the Virtual Appliance...........................................................................................................................................157

Updating a Repository Location and Virtual Appliance........................................................................................................157

Updating the Virtual Appliance Software Version................................................................................................................158

Setting Up The HTTP Proxy...................................................................................................................................................158

Setting Up the NTP Servers.................................................................................................................................................. 158

Generating a Certificate Signing Request............................................................................................................................ 159

Uploading an HTTPS Certificate........................................................................................................................................... 159

Restoring the Default HTTPS Certificate...............................................................................................................................159

Setting up Global Alerts........................................................................................................................................................ 160

Managing Backup And Restore............................................................................................................................................160

Configuring Backup And Restore................................................................................................................................... 160

Scheduling Automatic Backups..................................................................................................................................... 161

Performing An Immediate Backup................................................................................................................................. 161

Understanding the vSphere Client Console ......................................................................................................................... 162

Configuring Network Settings........................................................................................................................................ 162

Changing the Virtual Appliance Password.....................................................................................................................162

Setting The Local Time Zone.......................................................................................................................................... 163

Rebooting Virtual Appliance...........................................................................................................................................163

Resetting The Virtual Appliance To Factory Settings.....................................................................................................163

Refreshing the Console View......................................................................................................................................... 164

Read-only User Role.......................................................................................................................................................164

42 Troubleshooting.................................................................................................................................. 165

Frequently Asked Questions (FAQ)....................................................................................................................................... 165

'Settings' page fails to load, if we navigate away and go back to ‘Settings’ page........................................................ 165

Why is the DNS configuration settings restored to original settings after appliance reboot if using DHCP for

appliance IP and DNS settings overwritten................................................................................................................... 165

Using OpenManage Integration for VMware vCenter to update an Intel Network card with the firmware version

of 13.5.2 is not supported................................................................................................................................................165

On trying a firmware update with an invalid DUP, the hardware update job status on the vCenter console

neither fails nor times-out for hours, though the job status in LC says ‘FAILED’. Why is this happening?................... 166

Administration Portal is still showing the unreachable Update Repository location.....................................................166

Why do I see “Task cannot be scheduled for the time in the past” error in inventory schedule/Warranty

schedule page of Initial Configuration Wizard?............................................................................................................. 166

Why did my system not enter maintenance mode when I performed a one-to-many firmware update?..................... 166

Warranty and Inventory schedule for all vCenters is not applying when selected under "Dell Home > Monitor >

Job Queue > Warranty/Inventory History >Schedule"................................................................................................... 166

Why is the Installation date showing up as 12/31/1969 for some of the firmware on the firmware page?....................167

Why is successive Global refresh cause exception to be thrown in Recent Task window?.........................................167

Why is the Web client UI distorted for few of the Dell screens in IE 10?.......................................................................167

Using OpenManage Integration for VMware vCenter to update an Intel Network card with the firmware version

of 13.5.2 is not supported................................................................................................................................................167

Even if my repository has bundles for selected 11G system, why is firmware update showing that I have no

bundles for Firmware Update?....................................................................................................................................... 167

Why am I not seeing the OpenManage Integration Icon on the Web Client even if the registration of the plug-in

to the vCenter was successful?..................................................................................................................................... 168

I get an exception whenever I click finish after editing a connection profile through Web Client. Why?.....................168

I am unable to see the connection profiles to which a host belongs to when I create\edit a connection profile in

web GUI. Why?...............................................................................................................................................................168

On editing a Connection profile the select host window in the Web UI is blank. Why?................................................ 168

How Come I See An Error Message Displayed After Clicking The Firmware Link?.......................................................168

What generation of Dell servers does the OpenManage Integration for VMware vCenter configure and support

for SNMP traps?.............................................................................................................................................................169

What vCenters in linked mode are managed by OpenManage Integration for VMware vCenter?............................... 169

Does OpenManage Integration for VMware vCenter support vCenter in linked mode?............................................... 169

What are the Required Port Settings for the OpenManage Integration for VMware vCenter?.....................................170

What are the Minimum requirements for successful installation and operation of the virtual appliance?.................. 171

How Do I Find the Expected Translations for Renewing Warranty?..............................................................................171

How come I do not see my new iDRAC version details listed on the vCenter Hosts & Clusters page?.........................172

How Do I Test Event Settings by Using OMSA to Simulate a Temperature Hardware Fault?....................................... 172

I Have the OMSA Agent Installed on a Dell Host System, But I Still Get an Error Message That OMSA is Not

Installed. What Should I Do?.......................................................................................................................................... 173

Can the OpenManage Integration for VMware vCenter Support ESX/ESXI with Lockdown Mode Enabled?...............173

Inventory is Failing on Hosts ESXi 4.0 Update2 and ESXi Update 3 in Lockdown Mode after a Reboot........................ 173

When I tried to use lockdown mode, it failed.................................................................................................................174

What Setting Should I Use For UserVars.CIMoeMProviderEnable With ESXi 4.1 U1?.................................................. 174

I Am Using A Reference Server to Create a Hardware Profile But it Failed. What Should I Do?.................................. 174

I Am Attempting to Deploy ESX/ESXi on a Blade Server and it Failed. What Should I Do?........................................... 174

Why are My Hypervisor Deployments Failing on my Dell PowerEdge R210 II Machines?............................................ 174

Why Do I See Auto-discovered Systems Without Model Information in the Deployment Wizard................................ 174

The NFS Share is Set Up With the ESX/ESXI ISO, but Deployment Fails with Errors Mounting the Share Location.....174

How Do I Force Removal of the Virtual Appliance?....................................................................................................... 175

Entering a Password in the Backup Now Screen Receives an Error Message............................................................ 175

In the vSphere Web Client, Clicking the Dell Server Management Portlet Or the Dell Icon Returns A 404 Error..........175

My Firmware Update Failed. What Do I Do?.................................................................................................................. 175

My vCenter Registration Failed. What Can I Do?........................................................................................................... 175

Performance during Connection Profile Test Credentials is extremely slow or unresponsive..................................... 175

Does the OpenManage Integration for VMware vCenter support the VMware vCenter Server appliance?................176

Does the OpenManage Integration for VMware vCenter support the vSphere Web Client?........................................176

Why is my firmware level still not updated when I have performed firmware update with Apply on Next reboot

option and the system was rebooted?

Why is the host still shown under the chassis even after removing the host from the vCenter tree?...........................176

Bare Metal Deployment Issues............................................................................................................................................ 176

Contacting Dell......................................................................................................................................................................177

........................................................................................................................... 176

Where To Get Additional Help For This Software.................................................................................................................177

Dell Management Plug-in For VMware vCenter Related Information..................................................................................177

43 Virtualization—Related Events.........................................................................................................179

A Security Roles and Permissions........................................................................................................184

A Data Integrity........................................................................................................................................ 185

A Access Control Authentication, Authorization, and Roles............................................................186

A Dell Operation Role..............................................................................................................................187

A Dell Infrastructure Deployment Role................................................................................................ 188

A Understanding Privileges................................................................................................................... 189

B Understanding Auto-Discovery......................................................................................................... 191

Auto-Discovery Prerequisites...............................................................................................................................................191

Enabling or Disabling Administrative Accounts on iDRAC Servers......................................................................................192

Manually Configuring a PowerEdge 11th Generation Server for Auto-Discovery ...............................................................192

Manually Configuring a PowerEdge 12th Generation Server for Auto-Discovery............................................................... 194

Introduction

VMware vCenter is the primary console used by IT administrators to manage and monitor VMware vSphere ESX/ESXi hosts. In a standard virtualized environment, VMware alerts and monitoring are used to prompt you to launch a separate console to resolve hardware issues. OpenManage Integration for VMware vCenter is a product that lets you manage VMware vCenter servers from within the VMware Web client and free you from being tied to a Windows system. Using OpenManage Integration for VMware vCenter, you have capabilities to manage and monitor Dell hardware within the virtualized environment, such as:

• Alerts and environmental monitoring: Detect key hardware faults and perform virtualization-aware actions (for example, migrate workloads or place host in maintenance mode).

• Single server monitoring and reporting: Monitoring and reporting capabilities of servers.

• Firmware updates: Update Dell hardware to the most recent version of BIOS and firmware.

• Enhanced deployment options: Create hardware profiles, hypervisor profiles, and deploy any combination of the two on bare-metal Dell PowerEdge servers, remotely and without PXE—using vCenter

OpenManage Integration for VMware vCenter Features

You can use the OpenManage Integration for VMware vCenter to perform:

Inventory Inventory key assets, perform configuration tasks, and provide cluster and datacenter views of

Dell platforms.

Monitoring and Alerting

Firmware Updates

Deployment and Provisioning

Service Information

Security Role and Permissions

Detect key hardware faults and perform virtualization-aware actions (for example, migrate workloads or place host in maintenance mode). Provide additional intelligence (inventory, events, alarms) to diagnose server problems. Report at the datacenter and cluster view and export to CSV file.

Update Dell hardware to the most recent version of BIOS and firmware.

Create hardware profiles, hypervisor profiles, and remotely deploy any combination of the two on bare-metal Dell PowerEdge servers using VMware vCenter, without using PXE.

Retrieve warranty information from Dell online.

Integrate with standard vCenter authentication, rules, and permissions.

Understanding How to Configure or Edit the OpenManage Integration for VMware vCenter

After you complete the basic installation of the OpenManage Integration for VMware vCenter, the Initial Configuration Wizard is displayed when you click on the Dell OpenManage Integration icon. Use the Initial Configuration Wizard to configure the Settings on first launch. For subsequent instances use the Settings page. Also, from the Initial Configuration Wizard you can edit the settings of warranty, inventory, events and alarms. Although using the Initial Configuration Wizard is the most common method used, you can also accomplish this task through the appliance's OpenManage Integration → Manage → Settings page in the OpenManage Integration for VMware vCenter. For more information on the Initial Configuration Wizard, see, OpenManage Integration for VMWare vCenter User Guide.

Configuration Tasks Using the Configuration Wizard

The Initial Configuration Wizard can be used to configure the following for one vCenter or for all registered vCenters:

1. vCenter Selection

2. Creating A New Connection Profile

3. Scheduling Inventory Jobs

4. Running A Warranty Retrieval Job

5. Configuring Events And Alarms

NOTE: You can also launch the Initial Configuration Wizard using the link Start Initial Configuration Wizard under Basic Tasks in the Getting Started page.

Configuration Wizard Welcome Page

After you install the OpenManage Integration for VMware vCenter, it must be configured.

1. In the vSphere Web Client, click on Home, and then OpenManage Integration Icon

2. The first time you click on the OpenManage Integration icon, it opens the Configuration Wizard. You can also

access this wizard on the OpenManage Integration → Getting Started → Start Initial Configuration Wizard page.

vCenter Selection

The vCenter selection page allows you to select a specific vCenter to configure settings for, or allows you to select all vCenters to configure them.

1. In the Initial Configuration Wizard, click on Next in the Welcome screen.

2. Select one vCenter or all vCenters from the vCenters drop-down list. Select an individual vCenter for those not

configured yet or if you have added a new vCenter to your environment. The vCenter selection page allows you to select one or more vCenters to configure settings

3. Click Next to proceed to the Connection Profile description page.

Creating A New Connection Profile using the Initial Configuration Wizard

A connection profile stores the iDRAC and host credentials that the virtual appliance uses to communicate with Dell servers. Each Dell server must be associated with a connection profile to be managed by the OpenManage Integration for VMware vCenter. You may assign multiple servers to a single connection profile. Creating the Connection Profile is similar between the Configuration Wizard and from the OpenManage Integration for VMware vCenter → Settings option.

Prior to using the Active Directory credentials with a connection profile, the Active Directory user account must exist in Active Directory and this account must already be enabled in iDRAC. This wizard is not for creating Active Directory accounts or enabling Active Directory on iDRAC.

NOTE: You are not allowed to create a connection profile if the number of hosts added exceeds the license limit for Creating a Connection Profile

To create a new connection profile using the wizard:

1. From the Connection Profile Description page, click Next to proceed.

2. In the Name and Credentials page, enter the Connection Profile Name and an optional Connection Profile

Description.

3. In the Name and Credentials page, under iDRAC Credentials, do one of the following:

NOTE: The iDRAC account requires administrative privileges for updating firmware, applying hardware profiles, and deploying hypervisor.

• For iDRACs already configured and enabled for Active Directory on which you want to use Active Directory, select the Use Active Directory check box; otherwise skip down to configure the iDRAC credentials.

– In the Active Directory User Name text box, type the user name. Type the username in one of these formats:

domain\username or username@domain. The user name is limited to 256 characters. Refer to Microsoft Active Directory documentation for user name restrictions.

– In the Active Directory Password text box, type the password. The password is limited to 127 characters.

– In the Verify Password text box, type the password again.

– Perform one of the following actions:

* To download and store the iDRAC certificate and validate it during all future connections, select the

Enable Certificate Check check box.

* To not store and perform the iDRAC certificate check during all future connections, clear the Enable

Certificate Check .

• To configure iDRAC credentials without Active Directory, do the following:

– In the User Name text box, type the user name. The user name is limited to 16 characters. Refer to the

iDRAC documentation for information about user name restrictions for your version of iDRAC.

NOTE: The local iDRAC account requires administrative privileges for updating firmware, applying hardware profiles, and deploying hypervisor.

– In the Password text box type the password. The password is limited to 20 characters.

– In the Verify Password text box, type the password again.

– Perform one of the following actions:

* To download and store the iDRAC certificate and validate it during all future connections, select Enable

Certificate Check check box.

* To not store and perform the iDRAC certificate check during all future connections, clear Enable

Certificate Check check box.

4. In the Host Root area, do one of the following:

• For hosts already configured and enabled for Active Directory on which you want to use Active Directory, select the Use Active Directory check box; otherwise skip down to configure your Host Credentials.

– In the Active Directory User Name text box, type the user name. Type the username in one of these formats:

domain\username or username@domain. The user name is limited to 256 characters. Refer to Microsoft Active Directory documentation for user name restrictions.

– In the Active Directory Password text box, type the password. The password is limited to 127 characters.

– In the Verify Password text box, type the password again.

– Perform one of the following actions:

* To download and store the Host certificate and validate it during all future connections, select the

Enable Certificate Check check box .

* To not store and perform the Host certificate check during all future connections, clear the Enable

Certificate Check check box.

• To configure Host Credentials without Active Directory, do the following:

– In the User Name text box, the user name is root. This is the default username and you cannot change the

username. However, if the Activate directory is set, you can choose any Active directory user not just root.

– In the Password text box type the password. The password is limited to 127 characters.

NOTE: The OMSA credentials are the same credentials used for ESX and ESXi hosts.

– In the Verify Password text box, type the password again.

– Perform one of the following actions:

* To download and store the Host certificate and validate it during all future connections, select the

Enable Certificate Check check box.

* To not store and perform the Host certificate check during all future connections, clear the Enable

Certificate Check check box

5. Click Next.

6. In the Associated Hosts page, select the hosts for the connection profile and click OK.

7. To test the connection profile, select one or more hosts and select the Test Connection button. This step is optional. This is used to check whether the Host and iDRAC credentials are correct or not.

8. To complete the profile, click Next. For servers that do not have either an iDRAC Express or Enterprise card, the iDRAC test connection result states Not Applicable for this system.

Scheduling Inventory Jobs [Wizard]

The inventory schedule configuration is similar between the Configuration Wizard and from the OpenManage Integration under Manage section, Settings option.

NOTE: To make sure that the OpenManage Integration for VMware vCenter continues to display updated information, it is recommended that you schedule a periodic inventory job. The inventory job consumes minimal resources and will not degrade host performance.

NOTE: Chassis gets discovered automatically once the inventory for all hosts is run. If the chassis is added to a chassis profile, then the chassis inventory automatically runs. In a SSO environment having multiple vCenters, the chassis inventory runs automatically with every vCenter when the inventory for any vCenter is run at a scheduled time.

To schedule an inventory job:

1. In the Configuration Wizard, in the Inventory Schedule window, do one of the following:

• The Enable Inventory Data Retrieval check box is selected by default to enable you to schedule the inventory.

2. Under Inventory Data Retrieval Schedule, do the following:

a. Select the check box next to each day of the week that you want to run the inventory. By default, all the days

are selected.

b. In the text box, enter the time in HH:MM format.

The time you enter is your local time. Therefore, if you want to run the inventory at the virtual appliance time zone, calculate the time difference between your local and virtual appliance time zone, and then enter the time appropriately.

3. To apply the changes and continue, click Next to proceed with the warranty schedule settings.

Running A Warranty Retrieval Job [Wizard]

The warranty retrieval job configuration is similar between the wizard and from the OpenManage Integration for VMware vCenter, Settings option. In addition, you can run the Warranty Retrieval Job now, from Job Queue. Scheduled jobs would be listed in the Job queue. Chassis gets discovered automatically once the warranty for all hosts is run. If the chassis is added to a chassis profile, then the chassis warranty automatically runs. In a SSO environment having multiple vCenters, the chassis warranty runs automatically with every vCenter when the warranty for any vCenter is run.

To run a warranty retrieval job:

1. In the Configuration Wizard, in the Warranty Schedule window, do one of the following:

• Select the Enable Warranty Data Retrieval check box to enable you to schedule the warranty.

2. Under Warranty Data Retrieval Schedule, do the following:

a. Select the check box next to each day of the week that you want to run the warranty. b. In the text box, enter the time in HH:MM format.

3. To apply the changes and continue, click Next to proceed with the warranty schedule settings.

Configuring Events And Alarms [Wizard]

Configure events and alarms using the Configuration Wizard or from the OpenManage Integration for VMware vCenter, Settings option for Events and Alarms.

NOTE: On hosts prior to Dell PowerEdge 12th generation servers, this feature requires that the virtual appliance IP address is configured in the trap destination list in OMSA to display host events in vCenter.

To configure events and alarms:

1. In the Initial Configuration Wizard, under Event Posting Levels, select one of the following:

• Do not post any events - Block hardware events.

• Post All Events - Post all hardware events.

• Post only Critical and Warning Events - Post only critical or warning level hardware events.

• Post only Virtualization-Related Critical and Warning Events - Post only virtualization-related critical and

warning events; this is the default event posting level.

2. To enable all hardware alarms and events, select the Enable Alarms for Dell Hosts check box.

NOTE: Dell hosts that have alarms enabled respond to critical events by entering maintenance mode.

3. A dialog box Enabling Dell Alarm Warning is displayed, click Continue to accept the change, or click Cancel. You should click on Continue for the clusters displayed when the DRS is not enabled.

NOTE: This step is only seen if Enable Alarms For Dell Hosts is selected.

4. To continue the wizard, click Apply.

About VMware vCenter Web Client Navigation

Navigating around VMware vCenter is easy. When you log in to VMware vCenter and land on the home page and Home Tab, the OpenManage Integration icon is located in the main content area under the Administration group. Use the OpenManage Integration icon to locate the OpenManage Integration for VMware vCenter tab and to locate the Dell group in the Navigator area.

VMware vCenter layout has the following three main sections:

Navigator The Navigator area is the primary menu used to access the different views in the console.

OpenManage Integration for VMware vCenter has a special group under the vCenter menu that serves as the primary access point for OpenManage Integration for VMware vCenter.

Main Content area

Notifications Displays vCenter alarms, task and work in progress. OpenManage Integration for VMware

Displays the views selected in the Navigator. The main content area is the area where most of the content displays.

vCenter integrates with the alarm, event and task systems in vCenter to display its own information in the Notification area.

Navigating to the OpenManage Integration for VMware vCenter Inside the VMware vCenter

The OpenManage Integration for VMware vCenter is located in a special Dell group within VMware vCenter.

1. Log in to VMware vCenter.

2. In VMware vCenter home page, click the OpenManage Integration icon.

From here you can manage OpenManage Integration for VMware vCenter connection profiles, product settings, monitor inventory and warranty jobs, view the summary page and much more from the tabs in the main content area.

3. To monitor hosts, datacenters, and clusters, in the left-side Navigator, under Inventory Lists, select the host, datacenter or cluster you want to investigate and then on the Object tab, click the object you want.

4. Use the Summary or Monitor tab to help you monitor activities or tasks from other Dell hosts.

Understanding Icon Buttons

The product user interface uses many icon-based action buttons for the actions you take.

Table 1. Icon buttons defined.

Icon Button Definition

Use this plus-sign icon to add or create something new.

Use this add server icon to add a server to a connection profile, datacenter, and cluster,

Icon Button Definition

Use this icon to abort a job.

Use this icon to collapse a list.

Use this icon to expand a list.

Use this icon to delete an object.

Use this icon to change a schedule.

Use this pencil icon to edit.

Use this broom icon to purge a job.

Use this icon to export a file.

Locating the Software Version

The software version is found on the OpenManage Integration for VMware vCenter Getting Started tab.

1. In VMware vCenter home page, click the OpenManage Integration icon.

2. On the OpenManage Integration for VMware vCenter Getting Started tab, click Version Information.

3. On the Version Information dialog box, view the version information.

4. To close the dialog box, click OK.

Refreshing the Screen Content

Refresh the screen at anytime using the VMware vCenter Refresh icon.

1. Select a page that you want to refresh.

2. In the VMware vCenter title bar, click the Refresh button.

The Refresh icon is left of the Search area and looks like a clockwise arrow.

Viewing the OpenManage Integration for VMware vCenter Licensing Tab

When you install OpenManage Integration for VMware vCenter license, the number of supported hosts and vCenters is displayed on this tab. You can also view the version of the OpenManage Integration for VMware vCenter at the top of the page. This page under License Management has links to:

• Product Licensing Portal (Digital Locker)

• iDRAC Licensing Portal

• Administration Console

In the OpenManage Integration for VMware vCenter, on the Licensing tab, view the following:

Licensing

Host Licenses

vCenter Licenses

• Licenses Available Displays the number of available licenses.

• Licenses In Use Displays the number of licenses in use.

• Licenses Available Displays the number of available licenses.

• Licenses In Use Displays the number of licenses in use.

Opening Online Help

You can open the online help from the Help and Support tab. You can search the document for help on understanding a topic or for a procedure. Online Help contains most of the product User’s Guide.

1. In OpenManage Integration for VMware vCenter. Do one of the following:

• In the Help and Support, under Product Help, click OpenManage Integration for VMware vCenter Online Help.

2. Use the left-pane table of contents or search to find the topic of your choice.

3. When finished with Help, in the upper right-hand corner, click the red X.

Finding Help and Support

To provide you with the information you need about your product, OpenManage Integration for VMware vCenter offers the Help and Support tab. On this tab, you can find the following information:

Product Help

Dell Manuals Provides live links to:

Administration Console

Additional Help and Support

Provides the following links:

• OpenManage Integration for VMware vCenter Help Provides a link to the product help, which is located inside the product. Use the table of

contents or search to find the help you need.

• About This link brings up the Version Information dialog box. You can find the product version

here.

• Server Manuals

• OpenManage Integration for VMware vCenter Manuals

Provides a link to the Administration Console.

Provides live links to:

• iDRAC with Lifecycle Controller Manuals

• Dell VMware Documentation

• OpenManage Integration for VMware vCenter Product Page

• Dell Help and Support Home

• Dell TechCenter

Support Call Tips Offers tips on how to contact Dell Support and route your calls correctly.

Troubleshooting Bundle

Dell Recommends Dell recommends Dell Repository Manager and you can find a link to it here. Use Dell

iDRAC Reset Provides a Reset iDRAC button to use when iDRAC is not responsive. This reset performs a

1. In the OpenManage Integration for VMware vCenter, click the Help and Support tab.

2. View the OpenManage Integration for VMware vCenter support information on this tab.

Download a troubleshooting bundle. Provide or refer to this bundle when you contact technical support. For more information, see Download a Troubleshooting Bundle

Repository Manager to find and download all firmware updates available for your system.

normal iDRAC reboot. See Resetting iDRAC

Downloading a Troubleshooting Bundle

Use this information to assist in troubleshooting issues, or send to Technical Support.

1. In OpenManage Integration for VMware vCenter, click the Help and Support tab.

2. Click Create and Download Troubleshooting Bundle.

3. Click the Create button.

4. To save the file, click Download.

5. On the browser dialog that warns you of a security certificate, click Continue to this website.

6. In the File Download dialog, click Save.

7. In the Save As dialog, browse to where you want to save the file, and click Save.

8. To exit, click Close.

Soft iDRAC Reset

You can find the iDRAC Reset button on the Help and Support tab. Resetting iDRAC performs a normal iDRAC reboot. The iDRAC reboot does not reboot the host. After you perform a reset, it takes up to 2 minutes to return to a usable state. Only use this reset in cases where the iDRAC is not responsive in the OpenManage Integration for VMware vCenter.

NOTE: Dell recommends that you place the host in maintenance mode before resetting iDRAC. You can only apply this reset action on a host that is part of a connection profile that has been inventoried at least once. This reset action may not return the iDRAC to a usable state. In this case, a hard reset is required. Refer to your iDRAC documentation to learn more about a hard reset.

While iDRAC is rebooting, you may see:

• Some delay of communication error while the OpenManage Integration for VMware vCenterobtains its health status.

• All open sessions with iDRAC close.

• The DHCP address for iDRAC may change.

If iDRAC uses DHCP for its IP address, then there is a chance that the IP address will change. If this happens, rerun the host inventory job to capture the new iDRAC IP address in the inventory data.

1. In the OpenManage Integration for VMware vCenter, click the Help and Support tab.

2. Under iDRAC Reset, click Reset iDRAC.

3. On the iDRAC Reset dialog, under iDRAC Reset, type the host IP address/name.

4. To confirm that you understand the iDRAC reset process, select the I understand iDRAC reset. Continue iDRAC reset.

5. Click Reset iDRAC.

Launching the Administration Console

Deploy OpenManage Integration for VMware vCenter OVF, and register using the VMware vCenter Console before you access the Administration Console. See the username "admin" is the only username that is allowed and pre-created after OVF is imported. You are allowed to set the admin's password after the import is done and use it to login to the Admin Console. You can launch OpenManage Integration for VMware vCenter from within the VMware vCenter web client, and open the Administration Console from the Help and Support tab.

1. In the OpenManage Integration for VMware vCenter, on the Help and Support tab, under the Administration Console, click the link to the console.

2. In the Administration Console login, use the same administrator password you used when you registered and set the Admin user name and password for theOpenManage Integration for VMware vCenter Using the Administration console, you can do the following:.

a. You can register / unregister a vCenter and, you can modify credentials, or update the certificate. b. You can upload the license. c. This page provides the summary about the number of vCenters registered and available, and about maximum

host license, in use and available. d. You can Restart the virtual appliance. e. Update (upgrade to latest version). f. Generate troubleshooting bundle. g. Displays the network settings (read only mode) h. You can configure the HTTP Proxy Settings : this will be used to connect to Dell server for appliance upgrade or

for connectivity to ftp.dell.com i. You can configure NTP settings that is, you can enable or disable NTP server, and configure preferred and

secondary NTP server j. For HTTPS Certificates, you can generate CSR (certificate signing request), upload certificate or restore default

certificate. k. Configure global settings on how alerts are stored for all vCenter instances. You can configure maximum

number. of alerts to be stored, number. of days to retain them, and timeout for duplicate alerts. l. You can initiate Backup, or Restore. m. Configure backup location to a network share, and the encryption password for the backed up files (along with

test network connection). n. You can schedule recurring backup.

OpenManage Integration for VMware vCenter Quick Start Guide

. The

Profiles

The Credential Profiles tab lets you manage and configure the connection Profiles and the Chassis Profiles.

The Connection Profiles lets you manage and configure connection profiles required to access the Dell servers. A connection profile stores the credentials that the virtual appliance uses to communicate with Dell servers. Associate each Dell server with only one connection profile for management by the OpenManage Integration for VMware vCenter. You may assign multiple servers to a single connection profile.

The Chassis Profiles lets you manage and configure connection profiles required to access the Dell Chassis. The Chassis profile stores the credentials that the virtual appliance uses to communicate with the Dell Chassis. Associate each discovered Chassis with one chassis profile for management by the OpenManage Integration for VMware vCenter. You may assign multiple chassis to a single chassis profile.

• Viewing Connection Profiles

• Creating a Connection Profile

• Editing a Connection Profile

• Refreshing a Connection Profile

• Deleting a Connection Profile

• Testing a Connection Profile

Viewing Connection Profiles

Create a connection profile before you can view it.

After you create a connection profile, view it here on the connection profile page. The OpenManage Integration for VMware vCenter uses profiles to communicate with Dell hosts.

In OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profile you can view all the connection profiles you have created. The information you can view includes:

Profile Name Displays the name of the connection profile.

Description Displays a description, if provided.

vCenter Displays the IP address of the vCenter.

Associated Hosts Displays the hosts associated with this connection profile. If more than one, use the

expand icon to show all.

iDRAC Certificate Check Shows whether the iDRAC Certificate Check is enabled or disabled.

Host Root Certificate Check

Date Created Displays the create date.

Date Modified Displays the Modify date.

Last Modified By Displays who last modify this profile.

Shows whether the Host Root Certificate Check is enabled or disabled.

Creating A Connection Profile

You may assign multiple servers to a single connection profile. Create a Connection Profile using OpenManage Integration for VMware vCenter sign to proceed.

NOTE: The vCenter hosts that display during this procedure have authenticated using the same Single Sign On (SSO). If you do not see a vCenter host, it may be on a different SSO or you may be using a VMware vCenter version less than version 5.1.

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profile tab, click the Create New icon.

2. In the Connection Profile Description page, click Next.

Manage → Profiles → Credential Profiles → Connection Profile tab and click the Plus

3. In the Name and Credentials page, do the following:

a. Under Profile, type the Profile Name and optional Description. b. Under vCenter, select the host or hosts on which you want to associate with this connection profile. This option

lets you create one connection profile for many vCenter hosts.

c. Under Name and Credentials page, do the following:

• The iDRAC account requires administrative privileges for updating firmware, applying hardware profiles, and deploying hypervisor.

• In the Active Directory User Name text box, type the user name. Type the username in one of these formats: domain\username or username@domain. The user name is limited to 256 characters. Refer to Microsoft Active Directory documentation for user name restrictions.

• In the Active Directory Password text box, type the password. The password is limited to 127 characters.

• In the Verify Password text box, type the password again

• In the Certificate Check box, select one of the following:

• To download and store the iDRAC certificate and validate it during all future connections, select Enabled.

• To perform no check and not store the certificate, do not select the Enable Certificate Check check box.

d. In the Hosts Root page, do the following:.

• In the Active Directory Password text box, type the password. The password is limited to 127 characters.

• In the Verify Password text box, type the password again.

• In the Certificate Check box, select one of the following:

• To download and store the Host certificate and validate it during all future connections, select Enabled.

• To perform no check and not store the Host certificate, select Disabled.

• To configure Host Credentials without Active Directory, do the following:

• In the User Name text box, the user name is root. This is the default username and you cannot change the username

• If the Activate directory is set, you can choose any Active directory user not just root.

• In the Password text box type the password. The password is limited to 127 characters.

NOTE: The OMSA credentials are the same credentials as those used for ESX and ESXi hosts.

• In the Verify Password text box, type the password again.

• In the Certificate Check check box, select one of the following:

• To download and store the Host certificate and validate it during all future connections, select Enabled

• To perform no check and not store the Host certificate, do not select the Enable Certificate Check check box.

4. Click Next.

5. In the Associated Hosts page, select the hosts for the connection profile and click OK.

6. To test the connection profile, select one or more hosts and select the Test Connection button. This step is optional. This is used to check whether the Host and iDRAC credentials are correct or not.

7. To complete the profile, click Next. For servers that do not have either an iDRAC Express or Enterprise card, the iDRAC test connection result states Not Applicable for this system.

Editing a Connection Profile

After you have configured a connection profile, you can edit the profile name, description, associated hosts, and credentials.

NOTE: The vCenters that display during this procedure have authenticated using the same Single Sign On (SSO). If you do not see a vCenter host, it may be on a different SSO or you may be using a VMware vCenter version less than version 5.1.

NOTE: You are allowed to edit the connection profile irrespective of the license limit

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profiles tab, select a connection profile.

2. Click the Edit icon.

3. In the Connection Profile window, on the Welcome tab, read the information and click Next.

4. In the Name and Credentials tab, do the following:

a. Under Profile, type the Profile Name and optional Description. b. Under vCenter, view the associated hosts for this connection profile. See the note above about why you see the

hosts displayed here.

c. Under iDRAC Credentials, do the following:

• The user name is root and this entry cannot be modified if you do not select the Active Directory. If the Active directory is set, you can choose any Active directory user not just root.

• Domain\Username: Type the username in one of these formats: domain\username, or domain@username.

NOTE: The following characters are allowed for the user name: / (forward slash), &, \ (backslash), . (period), " (quotation mark), @, % (percent) (127 character limit).

The domain can contain alphanumeric characters and (dash) and . (period) only (254 character limit). The first and last characters for domain must be alphanumer ic.

• Password: Type your password.

The following characters are not allowed for the password: / (forward slash), &, \ (backslash), . (period), " (quotation mark).

• Verified password: Type your password again.

• Enable Certificate Check: The default is a cleared check box. To download and store the iDRAC certificate and validate it during all future connections, select Check check box to perform no certificate check and not store the certificate.

NOTE: You need to select Enable if you are using Active-Directory.

d. Under Host Root, do the following:

Enable Certificate Check, or clear the Enable Certificate

• Select the Use Active Directory check box to access all the consoles associated with the active directory.

Username: The default usertname is root and cannot be modified. If the Use Active Directory is selected, you can use any active directory user name.

• Password: Type your password.

The following characters are not allowed for the password: / (forward slash), &, \ (backslash), . (period), " (quotation mark).

• Verified password: Type your password again.

• Enable Certificate Check: The default is a cleared check box. To download and store the iDRAC certificate and validate it during all future connections, select Enable Certificate Check, or clear the Enable Certificate Check check box to perform no certificate check and not store the certificate.

NOTE: You need to select Enable if you are using Active-Directory.

NOTE: The OMSA credentials are the same credentials as those used for ESX and ESXi hosts.

NOTE: For servers that do not have either an iDRAC Express or Enterprise card, the iDRAC test connection result states

5. Click Next.

6. In the Select Hosts dialog box, select the hosts for this connection profile.

7. Click OK.

Not Applicable for this system

8. The Associated Host tab lets you test the iDRAC and Host Credentials on the selected servers. Do one of the following:

• To begin the test, select the hosts to check and then click the Test Connection icon. The other options are

inactive. When the test is done click Finish.

• To stop the tests click Abort All Tests. In the Abort Tests dialog box, click OK, and then click Finish.

Refreshing A Connection Profile

In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profiles tab, up in the VMware vSphere Web Client title bar, click the Refresh icon.

NOTE: After removing the host from vCenter, when you navigate to connection profile page, you will be prompted to remove the host from connection profile. Upon confirmation, the host will be removed from Connection Profile.

Deleting A Connection Profile

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profiles tab, select the profiles to delete.

2. Click the Delete icon.

3. On the Delete Confirmation message, to remove the profile, click Yes , or click No to cancel the delete action.

Testing a Connection Profile

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Connection Profiles tab, select a connection profile to test. This action may take several minutes to complete.

2. In the Test Connection Profile dialog, select the hosts you want to test and then click the Test Connection icon.

3. To abort all selected tests and cancel the testing, click Abort All Tests. In the Abort Tests dialog box, click OK.

4. To exit, click Cancel.

Viewing Chassis Profiles

To view chassis profiles:

1. In the OpenManage Integration, select Manage → Profiles → Credential Profiles → Chassis Profiles window. The Chassis Profiles are displayed.

2. If multiple chassis are associated with the Chassis Profile, clicking the arrow icon display all the associated chassis.

3. In the Chassis View page, you can view the Profile name, description, Chassis IP, service tag and the date you modified the chassis.

4. You can perform the following actions from the Chassis View Page.

a. Add b. Edit c. Delete d. Test connectivity

Editing a Chassis Profile

After you have configured a chassis profile, you can edit the profile name, description, associated hosts, and credentials.

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Chassis Profiles tab, select a chassis profile.

2. Click the Edit icon on the main menu which is displayed as a tilted Pencil icon.

3. The Edit Chassis Profile window is displayed.

4. In the Chassis Profile area, you can edit the Profile Name and optional Description.

5. Under the Credentials area, you can edit the User Name, Password, and Verify Password The password that you type in the Verify Password must be same as the one you entered in the Password field. The credentials entered must have administrator rights on the chassis.

6. Click Apply. The changes are saved.

7. The Associated Chassis tab lets you test the Chassis and Credentials on the selected chassis. Do one of the following:

• To begin the test, select either one chassis or multiple chassis to check and then click the Test Connection

icon. The Test Result column displays whether the test connection was a success or not.

• You can add or delete either one or multiple chassis to a chassis profile by clicking on the Plus icon.

NOTE: If the chassis are not inventoried, only the IP/host name and Service tag are displayed. The fields Chassis Name and Model are displayed once the chassis is inventoried.

Creating A Chassis Profile

The chassis profile is created using the following steps.

1. In the OpenManage Integration, select Manage → Profiles → Credential Profiles → Chassis Profile.

NOTE: Chassis will be discovered and available to be associated with the Chassis Profile after the host inventory is run.

2. In the Chassis Profiles page, click on the Plus (+) sign to create a New Chassis Profile.

3. In the Chassis Profile Wizard page, do the following:

• In the Profile Name text box, enter the profile name.

• In the Profile Description text box, enter an optional description.

4. Under Credentials do the following:

• In the User Name text box, type the chassis credential which is typically the user name used to log on to the

chassis. This User Name must have administrator rights.

• In the Password text box, type the password you use to log on to the chassis.

• In the Verify Password text box, enter the same password you have entered in the Password text box. The

passwords must match.

NOTE: The credential can be a local or active directory credential.

5. Click Next. The Select Chassis page is displayed which shows all the inventoried chassis for the hosts.

6. To select either an individual chassis or multiple chassis, select the corresponding check boxes next to the IP/Host Name column.

If the selected chassis is already a part of another profile then a warning message is displayed indicating that the selected chassis is associated with a profile.

For example, you have a profile Test associated with Chassis A. If you create another profile Test 1 and try to associate Chassis A to Test 1 , a warning message is displayed.

7. Click OK. The Associated Chassis page is displayed.

8. Select the chassis and click on Test Connection Icon to test the chassis connectivity which verifies the credentials and the result is displayed in the

9. Click Finish to complete the profile. A chassis credential profile is created with single or multiple chassis.

NOTE: You can also add or remove a chassis by clicking on the Plus Icon displayed on the to row of the Associated Chassis page.

Test Result column as Pass or Fail.

Deleting Chassis Profiles

To delete Chassis profiles:

1. In the OpenManage Integration, select Manage → Profiles → Credential Profile → Chassis Profiles window.

2. Select a chassis profile that you want to delete and click the Cross (X) Icon. A warning Message is displayed.

3. Click Yes to proceed with deletion or click No to cancel deletion.

NOTE: If all the chassis associated to a Chassis profile is deleted or moved to different profiles, a delete confirmation message will be displayed mentioning the chassis profile does not have any associated chassis and will be deleted. Click on OK to delete the chassis profile.

Testing a Chassis Profile

1. In the OpenManage Integration for VMware vCenter, on the Manage → Profiles → Credential Profiles → Chassis Profiles tab, select a single or multiple chassis profile to test. This action may take several minutes to complete.

2. In the Test Chassis Profile dialog, select the chassis you want to test and then click the Test Connection icon.

3. To abort all selected tests and cancel the testing, click Abort All Tests. In the Abort Tests dialog box, click OK.

4. To exit, click Cancel.

Job Queue

After the OpenManage Integration for VMware vCenter is configured, you can monitor the inventory, warranty jobs and firmware updates under the Monitor tab. Inventory and warranty are set up with the Configuration Wizard or on the Settings tab.

• Inventory History

• Warranty History

Inventory History

Inventory Jobs are set up using the Settings tab or the Initial Configuration wizard. Use the Inventory History tab to view your inventory jobs. Tasks you can do from this tab include:

• Viewing Inventory History

• Changing Inventory Job Schedules

• Running an Inventory Job Now

Viewing Hosts Inventory

A successful completed inventory is required to gather the data. Once the inventory is complete, you can view the inventory results for the entire datacenter or for an individual host system. See Running an Inventory Job Now. Columns are sortable in ascending and descending order.

If server data cannot be retrieved and displayed, there are several possible causes:

• The server is not associated with a connection profile, and therefore you cannot run an inventory job.

• An inventory job has not been run on the server to collect the data, and therefore there is nothing to display.

• The number of host licenses is exceeded, and you must have additional licenses available for the inventory task to

complete.

• The server does not have the correct iDRAC license required for Dell PowerEdge 12th generation servers and you

must purchase the correct iDRAC licence.

1. In the OpenManage Integration for VMware vCenter, click the Monitor tab.

2. Click Job Queue → Inventory History. → Host Inventory.

3. To view the server information on a selected vCenter, select a vCenter to display all associated host details.

4. Review the Host Inventory information.

vCenter Details

Change Schedule button Click to edit an inventory schedule.

Run Now button Click to run an inventory.

vCenter Displays vCenter Address.

Hosts Passed Displays any hosts, which have passed.

Next Inventory Displays the next inventory schedule that will run.

Last Inventory Displays the last inventory schedule that was run.

Hosts

Host Displays the host address.

Status Displays the status. Options include:

• Successful

• Failed

• In Progress

• Scheduled

Duration (MM:SS) Displays the duration of the job in minutes and seconds.

Start Date and Time Displays the date and time when the inventory schedule

started.

End Date and Time Displays the time the inventory schedule ended.

Changing Inventory Job Schedules

To make sure there is up-to-date server information you must run periodic inventories on Dell servers. Dell recommends running an inventory once a week. Inventories do not impact host performance. You can change a inventory job schedule on the Monitor → Job Queue → Inventory History → Hosts Inventory page or from the Manage → Settings page.

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab, click Inventory History and Hosts Inventory.

2. Select a vCenter and then click the Change Schedule icon.

3. In the Inventory Data Retrieval dialog box, do the following:

a. Under Inventory Data, select the Enable Inventory Data Retrieval check box. b. Under Inventory Data Retrieval Schedule, select the days of the week for your job. c. In the Inventory Data Retrieval Time text boxes, type the local time for this job.

You may need to calculate the time difference required to run this job at the proper time.

4. Click Apply to save the settings, Clear to reset the settings, and Cancel to abort the operation.

Running an Inventory Job Now

Run an inventory job at least once a week.

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab, click Inventory History and Hosts Inventory.

2. Click the Run Now button.

3. In the Success dialog box, click Close.

NOTE: When you run a modular host inventory, corresponding chassis are discovered automatically,

An inventory job is now in queue. Note that you cannot run an inventory for a single host. An inventory job starts it for all hosts

Running a Chassis Inventory job now

You can view and run a chassis inventory job in the Chassis Inventory tab.

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab, click Inventory History and Chassis Inventory.

2. The list of chassis and status that had inventory run in the last inventory execution will be shown.

NOTE: The scheduled inventory will be executed the same time as the scheduled host inventory.

3. Click the Run Now button, the lists of updated inventoried chassis are displayed with the status against each chassis as

Success or Failure.

Warranty History

Warranty jobs are set up using the Configuration Wizard. View your warranty job history on this tab. Tasks you can do on this tab include:

• Viewing Warranty History

• Changing a Warranty Job Schedule

• Running a Warranty Job Now

Viewing Warranty History

A warranty job is a scheduled task to get warranty information from support.dell.com on all systems. Columns are sortable in ascending and descending order.

1. In the OpenManage Integration for VMware vCenter, click the Monitor tab.

2. Click Job Queue → Warranty History.

3. Expand Warranty History to display Hosts Warranty and Chassis Warranty.

4. Select either Hosts Warranty or Chassis Warranty to view your corresponding warranty job history information

Modify Schedule button Click to edit a warranty job schedule.

Run Now button Click to run a warranty job.

vCenter History

vCenters Displays lists of vCenters.

Hosts Passed Displays the number of vCenter Hosts that passed.

Last Warranty Displays the last warranty job that was run.

Next Warranty Displays the next warranty job that will run.

Hosts History

Host Displays the host address.

Status Displays the status. Options include:

• Successful

• Failed

• In Progress

• Scheduled

Duration (MM:SS) Displays the duration of the warranty job in MM:SS.

Start Date and Time Displays the date and time when the warranty job

started.

End Date and Time Displays the time the warranty job ended.

Modifying a Warranty Job Schedule

Hardware warranty information is retrieved from Dell Online and displayed by the OpenManage Integration for VMware vCenter. Server’s Service Tag is used to gather warranty information about the server. Warranty jobs are originally configured in the Initial Configuration Wizard. Later, you can modify a warranty job schedule on the Monitor Tab → Job

→ Warranty History → Hosts Warranty page or from the Manage Tab → Settings page.

Queue

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab, click Warranty History.

2. Click the Change Schedule icon.

3. In the Warranty Data Retrieval dialog box, do the following:

a. Under Warranty Data, select the Enable Warranty Data Retrieval check box. b. Under Warranty Data Retrieval Schedule, select the days of the week for your job. c. In the Warranty Data Retrieval Time text boxes, type the local time for this job.

You may need to calculate the time difference required to run this job at the proper time.

4. Click Apply.

Running a Hosts Warranty Job Now

Run an warranty job at least once a week.

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab.

2. Click on Warranty History and Hosts Warranty to select the warranty job you want to run.

3. Click the Run Now button.

4. In the Success dialog box, click Close.

NOTE: Chassis Warranty is run automatically for all the chassis once the host warranty is run. In a SSO environment having multiple vCenters, the chassis warranty runs automatically with every vCenter when the warranty for any vCenter is run manually.

A warranty job is now in queue.

Running a Chassis Warranty Job Now

Run an warranty job at least once a week.

1. In the OpenManage Integration for VMware vCenter, on the Monitor → Job Queue tab.

2. Click on Warranty History and Chassis Warranty to select the warranty job you want to run.

3. Click the Run Now button.

4. In the Success dialog box, click Close.

A warranty job is now in queue.

About Logs

You can view user actions on the Monitor → Log tab of the OpenManage Integration for VMware vCenter.

You can sort the content on this page using the two drop-down lists. The first drop-down list lets you sort on file category, which includes:

• All Categories

• Info

• Warning

• Error

The second drop-down helps you sort on blocks of time, which include:

• Last Week

• Last Month

• Last Year

• Custom Range

If you select custom range, you can pick the start and end date and click Apply.

You can also sort the datagrid columns in ascending or descending order by clicking the column header.

Use the Filter text box to search within your content.

At the bottom of the page grid, the following information is displayed:

Total items Displays the total count of all log items.

Items per screen Displays the number of log items on the displayed page. Use the drop-down box to set the

number of items per page.

Page Displays the page you are on. Type a page number in the text box or use the Previous and

Next buttons to get you the page you want.

Previous or Next buttons Buttons that guide you to the next or previous pages.

Export icon Use this to export log content to a CSV file.

Viewing the Logs

1. In OpenManage Integration for VMware vCenter, click the Monitor tab.

2. On the Log tab, view the user actions logs for the OpenManage Integration for VMware vCenter. The Log page shows:

Category Displays the category type.

Date and Time Displays the date and time of the user action.

Description Displays a description of the user action.

3. To sort the data in the grid, click a column header.

4. To sort using categories or time blocks use the drop-down lists above the grid.

5. To page between pages of log items, use the Previous and Next buttons.

Exporting Log Files

The OpenManage Integration for VMware vCenter uses a comma-separated values (CSV) file format for exporting information from data tables.

1. In OpenManage Integration for VMware vCenter, click the Monitor tab.

2. On the Log tab, view the user actions for the OpenManage Integration for VMware vCenter.

3. To export a CSV formatted log file, in the lower right-hand corner of the screen, click the Export All button.

4. In the Select location for download dialog box, browse to the location to save the log information.

5. In the File name text box, either accept the default name ExportList.csv or type your own file name.

6. Click Save.

Console Administration

Administration of the OpenManage Integration for VMware vCenter and its virtual environment is achieved by using two additional administration portals:

• Web-based Administration Console

• Console view for an individual server (the appliance virtual machine console).

Through the use of these two portals, global settings for vCenter management, OpenManage Integration for VMware vCenter database backup and restore, and reset/restart actions can be entered and used across all vCenter instances.

Using the Administration Console

From the vCenter Registration window in the Administration Console, you can register a vCenter server, and upload or buy a license. If you are using a demo license, a Buy Software link displays from which you can purchase a full-version license for managing multiple hosts. In this section you can also modify, update, and unregister a server.

Related Tasks:

• Registering a vCenter Server

– Modifying the Administrator vCenter Login

– Updating the SSL Certificates for Registered vCenters

– Uninstalling OpenManage Integration for VMware vCenter from vCenter

• Uploading a OpenManage Integration for VMware vCenter License

Registering a vCenter Server

You can register vCenter servers with the OpenManage Integration for VMware vCenter after the OpenManage Integration for VMware vCenter is installed. OpenManage Integration for VMware vCenter uses the admin user account for vCenter operations. OpenManage Integration for VMware vCenter supports 10 vCenters per appliance.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. To register a new server, in the left pane, click VCENTER REGISTRATION, and then click Register New vCenter Server.

4. In the Register a New vCenter dialog box, under vCenter Name do the following:

a. In the vCenter Server IP or Hostname text box, enter the vCenter IP address or a hostname. b. In the Description text box, enter an optional description.

5. Under Admin User Account, do the following:

a. In the Admin User Name text box, enter the administrator's user name. b. In the Password text box, enter the password. c. In the Verify Password text box, enter the password again.

6. Click Register.

Modifying The vCenter Administrator Login

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click VCENTER REGISTRATION. The registered vCenters are displayed in the right pane. To open the Modify Admin Acct window, under Credentials, click Modify.

4. Enter the vCenter Administrator User Name, Password, and Verify Password; the passwords must match.

5. To change the password, click Apply, or to cancel the change click Cancel.

Updating The SSL Certificates For Registered vCenter Servers

If the SSL certificate is changed on a vCenter server, then use the following steps to import the new certificate for the OpenManage Integration for VMware vCenter. The OpenManage Integration for VMware vCenter uses this certificate to make sure the vCenter server it is talking to is the correct vCenter server and not an impersonator.

OpenManage Integration for VMware vCenter uses the openssl API to create the Certificate Signing Request (CSR) using the RSA encryption standard with a 2048 bit key length. The CSR generated by the OpenManage Integration for VMware vCenter is used to get a digitally signed certificate from a trusted Certification Authority. The OpenManage Integration for VMware vCenter uses the digital certificate to enable SSL on the Web server for secure communication.

1. Launch a web Browser then enter https://<ApplianceIPAdrdress>

2. In the left pane, click VCENTER REGISTRATION. The registered vCenters are displayed in the right pane. To update the certificates, click Update.

Uninstalling the OpenManage Integration for VMware vCenter From VMware vCenter

To remove the OpenManage Integration for VMware vCenter, it must be unregistered from the vCenter server using the Administration Console.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the vCenter Registration page, under the vCenter server table, unregister the OpenManage Integration for VMware vCenter by clicking Unregister.

You may have more than one vCenter, so be sure select the right one.

4. In the Unregister vCenter dialog box that asks if you really want to unregister this server, click Unregister.

Uploading a OpenManage Integration for VMware vCenter License to the Administration Console

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click VCENTER REGISTRATION. The registered vCenters are displayed in a table. To display the upload license dialog box, click

Upload License.

4. To navigate to the license file, click the Browse button, to navigate to the license file, and then click Upload.

NOTE: If the license file is modified or edited in any way, the appliance views it as corrupted and the file will not work. You can add licenses if you need to add more hosts. Follow the process mentioned above to add more licenses.

NOTE: If the number of successfully inventoried 11G and 12G servers equals the number of purchased licenses, you will be blocked from adding 9G or 10G servers to new or existing connection profiles, Edit existing connection profiles by removing few 11G/12G servers and add 10G/9G instead of them. Create a new connection profile for the removed 11G/12G servers.

Virtual Appliance Management

Virtual appliance management contains the OpenManage Integration for VMware vCenter network, version, NTP, and HTTPS information, and lets you:

• Restart the virtual appliance

• Update the virtual appliance and configure an update repository location

• Download a troubleshooting bundle

• Set up NTP servers

• Upload HTTPS certificates

Restarting the Virtual Appliance

Restarting the virtual appliance logs you out from the Administration Console, and the OpenManage Integration for VMware vCenter is unavailable until the virtual appliance and its services are active.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. To restart the OpenManage Integration for VMware vCenter, click Restart the Virtual Appliance.

5. On the Restart Virtual Appliance dialog box, to restart the virtual appliance click Apply or click Cancel to cancel.

Updating a Repository Location and Virtual Appliance

Perform a backup prior to an update of the virtual appliance to make sure all data is protected. See, Managing Backup

and Restore.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. Next to Appliance Update, click Edit.

5. In the Appliance Update window, enter the Repository Location URL, and then click Apply.

NOTE: If the update location is on an external network, such as the Dell FTP site, then a proxy must be entered below in the HTTP Proxy area.

Updating the Virtual Appliance Software Version

To prevent data loss, perform an appliance backup prior to beginning the software update.

1. Launch a web Browser then enter https://<ApplianceIPAddress>.

2. In the left pane, click APPLIANCE MAINTENANCE.

3. To update the virtual appliance to the software version listed under Appliance Update, click Update Virtual Appliance.

4. In the Update Appliance dialog box, the current and available versions are listed. To begin the update, click Update.

5. The system is locked down and put into maintenance mode. When the update is complete, the Appliance page displays showing the newly installed version. You cannot upgrade to version 2.1 using this option.

Downloading the Troubleshooting Bundle

Use this information to assist in troubleshooting issues, or send to Technical Support.

1. Launch a web Browser then enter https://<ApplianceIPAddress>.

2. In the left pane, click APPLIANCE MANAGEMENT.

3. To display the troubleshooting bundle dialog box, click Generate Troubleshooting Bundle.

4. To either open or save a zip file that contains the virtual appliance logging information, click the Download Troubleshooting Bundle link.

5. To exit, click Close.

Setting Up The HTTP Proxy

You can set up the HTTP proxy settings using the Administration Console or the Dell Management Console.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. In the Appliance Management page, scroll down to the HTTP Proxy Settings, and then click Edit.

5. In the Edit page, do the following:

a. To enable the use of HTTP Proxy Settings, next to Use HTTP Proxy Settings, select Enable. b. In the Proxy Server Address text box, enter the proxy server address. c. In the Proxy Server Port text box, enter the proxy server port. d. To use proxy credentials, next to Use Proxy Credentials, select Yes. e. If you are using credentials, in the User Name text box, enter the user name. f. In the Password text box, type the password.

6. Click Apply.

Setting Up the NTP Servers

Use the Network Time Protocol (NTP) to synchronize the virtual appliance clocks to that of a NTP server.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. Click Edit for NTP.

5. Select the Enabled check box. Enter the host name or IP address for a Preferred and Secondary NTP Server and click Apply.

6. To exit, click Cancel.

Generating a Certificate Signing Request

Generating a new Certificate Signing Request prevents certificates that are created with the previously generated CSR from being uploaded to the appliance.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. Click Generate Certificate Signing Request for HTTPS Certificates. A message displays stating that if a new request is generated, then certificates created using the previous CSR can no longer be uploaded to the appliance. To continue with the request, click

5. Enter the Common Name, Organizational Name, Organizational Unit, Locality, State Name, Country and Email for the request. Click Continue.

6. Click Download, and then save the resulting HTTPS certificate to an accessible location.

Uploading an HTTPS Certificate

You can use HTTPS Certificates for secure communication between the virtual appliance and host systems. To set up this type of secure communication, a certificate signing request must be sent to a certificate authority and then the resulting certificate is uploaded using the Administration Console. There is also a default certificate that is self-signed and can be used for secure communication; this certificate is unique to every installation.

NOTE: You can use either Microsoft Internet Explorer or Firefox to upload certificates.

Continue, or Cancel to cancel.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. Click Upload Certificate for HTTPS Certificates.

5. In the Upload Certificates dialog box, click OK.

6. To select the certificate to upload, click Browse, and then click Upload.

7. If you want to abort the upload, click Cancel.

NOTE: The certificate must use PEM format.

Restoring the Default HTTPS Certificate

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click APPLIANCE MANAGEMENT.

4. Click Restore Default Certificate for HTTPS Certificates.

5. In the restore default certificate dialog box, click Apply.

Setting up Global Alerts

Alert management lets you enter global settings for how alerts are stored for all vCenter instances.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click ALERT MANAGEMENT. To enter new vCenter alert settings, click Edit.

4. Enter numeric values for the following items:

• Maximum number of alerts

• Number of days to retain alerts

• Timeout for duplicate alerts (seconds)

5. To save your settings, click Apply, or click Cancel to cancel.

Managing Backup And Restore

Managing backup and restore is accomplished from the Administrative Console. Tasks on this page include:

• Configuring Backup And Restore

• Scheduling Atomatic Backups

• Performing An Immediate Backup

• Restoring The Database From Backup

Configuring Backup And Restore

The backup and restore function backs up the OpenManage Integration for VMware vCenterdatabase to a remote location from which it can be restored at a later date. Profiles, templates, and host information are included in the backup. It is recommended that you schedule automatic backups to guard against data loss. After this procedure, you must configure a backup schedule.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click BACKUP AND RESTORE.

4. To edit the current backup and restore settings, click Edit.

5. In the Settings and Details page, do the following:

a. In the Backup Location text box, type the path to the backup files. b. In the User Name text box, type the user name. c. In the Password text box, type the password. d. Under Enter the password used to encrypt backups, type the encrypted password in the text box.

The encryption password can contain alpha numeric characters and the following special characters: !@#$%*. There is no length restriction.

e. In the Verify Password text box, retype the encrypted password.

6. To save these settings, click Apply.

7. Configure the backup schedule. For more information see, Scheduling Automatic Backups.

Scheduling Automatic Backups

This is the second part of configuring backup and restore. For detailed information on configuring the backup location and credentials, see Configuring Backup And Restore. To schedule an automatic backup:

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click BACKUP AND RESTORE.

4. To edit the backup and restore settings, click Edit Automatic Scheduled Backup (this makes fields active).

5. To enable the backups, click Enabled.

6. Select the check boxes for the days of the week for which you want to run the backup.

7. In the Time for Backup (24 Hour Time Format, HH:mm) text box, enter the time in HH:mm format.

The Next Backup populates with the date and time of the next scheduled backup.

8. Click Apply.

Performing An Immediate Backup

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click BACKUP AND RESTORE.

4. Click Backup Now.

5. To use location and encryption password from the Backup settings, in the Backup Now dialog box, select that check box.

6. Enter a Backup Location, User Name, Password, and Encryption Password.

The encryption password can contain alpha numeric characters and the following special characters: !@#$%*. There is no length restriction.

7. Click Backup.

Restoring the Database from a Backup

NOTE: The restore operation causes the virtual appliance to reboot after it has completed.

1. In OpenManage Integration for VMware vCenter, on the Summary tab, use the link to open the Administration Console.

2. In the Login dialog box, type your password.

3. In the left pane, click BACKUP AND RESTORE and the current backup and restore settings are displayed.

4. Click Restore Now.

5. In the Restore Now dialog box, enter a File Location (CIFS/NFS Format).

6. Enter the User Name, Password, and Encryption Password for the backup file.

The encryption password can contain alpha numeric characters and the following special characters: !@#$%*. There is no length restriction.

7. To save your changes, click Apply.

The appliance reboots or restarts once Apply is clicked.

Understanding the vSphere Client Console

The Console is found within the vSphere Web Client on a virtual machine. The Console works hand and hand with the Administration Console. The Console provides the ability to:

• Configure network settings

• Change the virtual appliance password

• Set the local timezone

• Reboot the virtual appliance

• Reset the virtual appliance to factory settings

• Refresh Console

Use the arrow keys to navigate up or down. Once you have selected the option you want, press <ENTER>. After you access the Console screen, VMware vSphere Client takes control of your cursor. To escape from that control, press <CTRL> + <ALT>.

Configuring Network Settings

Changes to the network settings are done in the vSphere Web Client on the Console.

1. In vSphere Web Client, in the Navigator, select vCenter.

2. In the Navigator, select the Virtual Machine that you want to manage.

3. Do one of the following:

• On the Object tab, select Action → Open Console.

• Right-click the virtual machine that you selected and select Open Console.

4. In the Console window, select Configure Network, then press <ENTER>.

5. Enter the desired network settings under Edit Devices or under Edit DNS configuration, then click Save & Quit. To abort any changes, click Quit.

Changing the Virtual Appliance Password

The virtual appliance password is changed in the vSphere Web Client using the Console.

1. In vSphere Web Client, in the Navigator, select vCenter.

2. In the Navigator, select the Virtual Machine that you want to manage.

3. Do one of the following:

• On the Object tab, select Action → Open Console.

• Right-click the virtual machine that you selected and select Open Console.

4. On the Console, use the arrow keys to select Change Admin Password and press <ENTER>.

5. Enter the Current Admin Password and press <ENTER>.

Admin passwords include one special character, one number, one uppercase, one lowercase, and at least 8 letters.

6. Enter a new password for Enter new Admin Password and press <ENTER>.

7. Type the new password again in Please Confirm Admin Password text box , and then press <ENTER>.

Setting The Local Time Zone

To set the local time zone:

1. Do one of the following:

• In vSphere Web Client, select the OpenManage Integration for VMware vCenter virtual machine, and then click

the Console tab

• Select Set Time Zone and press <ENTER>

2. In the Time zone Selection window, select the desired time zone and click OK. To cancel changes click Cancel. The time zone is updated. You can only edit the time zone and not the current time and date

Rebooting Virtual Appliance

To reboot the virtual appliance:

1. In vSphere Web Client, in the Navigator, select vCenter.

2. In the Navigator, select the Virtual Machine that you want to manage.

3. Do one of the following:

• On the Object tab, select Action → Open Console.

• Right-click the virtual machine that you selected and select Open Console.

4. Use the arrow keys to select Reboot this Virtual Appliance and press <ENTER>.

5. The following message is displayed:

If there are any processes running on this appliance they will be terminated by this action. Are you sure you wish to do this?

6. Enter y to reboot or n to cancel. The appliance is rebooted.

Resetting The Virtual Appliance To Factory Settings

To reset the virtual appliance to factory settings:

1. In vSphere Web Client, in the Navigator, select vCenter.

2. In the Navigator, select the Virtual Machine that you want to manage.

3. Do one of the following:

• On the Object tab, select Action → Open Console.

• Right-click the virtual machine that you selected and select Open Console.

4. Use the arrow keys to select Reset this Virtual Appliance to Factory Settings and press <ENTER>.

5. The following notice is displayed:

This operation is completely Irreversible if you continue you will completely reset *this* appliance to its original settings. All changes you have made to this appliance will be Lost. Are you sure you wish to Reset this Appliance to Factory Settings?

6. Enter y to reset or n to cancel. The appliance is reset to the original factory settings and all the others settings and saved data will be lost.

NOTE: When the virtual appliance is reset to factory settings, any updates made to the Network Configuration are preserved; these settings are not reset.

Refreshing the Console View

To refresh the Console view, select Refresh and press <ENTER>.

Read-only User Role

There is an unprivileged user role called readonly with shell access for diagnostic purposes. The read-only user has limited privileges to run the mount. The read-only user's password is set to the same as the admin.

Migration Path to migrate from 1.6/1.7 to 2.1

OpenManage Integration for VMware vCenter version 2.1 is an OVF release only. There is no RPM update path from the older versions to this version. You can migrate from older version (1.6 or 1.7) to the version 2.1 release using the Backup and Restore path. Also, the migration path is only supported from version 1.6 and 1.7. If you are at a lower version than

1.6, you will have to upgrade your appliance to the supported version before you perform the migration to OpenManage

Integration for VMware vCenter version 2.1.

Do the following to migrate from older version to the OpenManage Integration for VMware vCenter 2.1 version:

1. Take a Backup of the database for the older release. For more information, See the section, Managing Backup and Restore in this guide.

2. Power off the older appliance from the vCenter.

NOTE:

Do not unregister the Plug-in from the vCenter. Unregistering the plug-in from the vCenter will remove all the Alarms registered on the vCenter by the plug-in and remove all the customizing performed on the alarms like actions and so on, on the vCenter. For more information, see the section How to recover if I have unregistered the older plugin after the backup in this guide if you have already unregistered the Plug-ins after the backup.

3. Deploy the new OpenManage Integration version 2.1 OVF. For more information, see the section Deploying the OpenManage Integration for VMware vCenter OVF Using the vSphere Client in this guide to deploy the OVF.

4. Power on the OpenManage Integration version 2.1 appliance.

5. Setup the network, time zone and so on to the appliance. It is recommended that the new OpenManage Integration version 2.1 appliance has the same IP address as the old appliance. To setup the network details, see the section, Registering OpenManage Integration for VMware vCenter And Importing The License File in this guide.

6. Restore the database to the new appliance. For more information, see the section, Restoring The Database From A Backup in this guide.

7. Upload the new license file. For more information, see the section, Registering OpenManage Integration for VMware vCenter And Importing The License File in OpenManage Integration Version 2.1 Quick Install Guide.

8. Verify the appliance. For more information, see the section Installation Verification in this guide to ensure the database migration is successful.

9. Run the Inventory on all the registered vCenters.

NOTE:

It is recommended that you run the inventory on all the hosts managed by the plug-in again after the upgrade. For more information, see the section Running Inventory Jobs for steps to run the inventory on demand.

If the IP address of the new OpenManage Integration version 2.1 appliance has changed from that of the old appliance, the trap destination for the SNMP traps must be configured to point to the new appliance. For 12G servers, this will be fixed by running the Inventory on these hosts. For all 11G or lower generation hosts that were earlier complaint, this IP change will show up as non-complaint and will require configuring OMSA. For more information, see the section, Running the Fix Non-Compliant vSphere hosts Wizard to fix the host compliance in the this guide.

How to recover if I have unregistered the older plugin after the backup

If you have unregistered the plug-ins after taking backup of the database of the older version, perform the following steps before proceeding with the migration.

NOTE: Unregistering the plug-in has removed all the customizing that was done on the registered alarms by the plug-in. The following steps will not be able to restore the customizing, however, it will re-register the alarms in the default state.

1. Perform the steps 3-5 in the section Migration Path to migrate from 1.6/1.7 to 2.1 in this chapter.

2. Register the plug-in to the same vCenters that you had registered earlier in the older plug-in.

3. Proceed with step 6 through step 9 in the section Migration Path to migrate from 1.6/1.7 to 2.1 in this chapter to complete the migration. For more information, see the section OpenManage Integration Version 2.1 Quick Install Guide.

Migration Path to migrate from 1.6/1.7 to 2.1 in

Settings

The Settings tab is used to do the following:

• Editing the OMSA Link

• Viewing Warranty Expiration Notification Settings

• Configuring Warranty Expiration Notification

• Setting Up The Firmware Update Repository

• Viewing the Alarm and Event Settings

• Configuring and Managing Events and Alarms

• Viewing the Data Retrieval Schedules for Inventory and Warranty

Editing the OMSA Link

This procedure assumes that you have already installed an OMSA Web Server and that you have previously configured this link using the Configuration Wizard. See the OMSA in use and for instructions on how to install and configure the Web Server. If you have not provided a link while running the Configuration Wizard, you can edit this link in OpenManage Integration for VMware vCenter Manage → Settings tab.

NOTE: OMSA is only required on Dell PowerEdge 11th generation servers or earlier.

OpenManage Server Administrator Installation Guide

for the version of

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under vCenter Settings and to the right side of the OMSA Web Server URL, click Edit.

2. In the OMSA Web Server URL dialog box, type the URL.

You must include the full URL including the HTTPS.

3. Select Apply these settings to all vCenters check box to apply the OMSA URL to all vCenters. If you do not select this check box, the OMSA URL is applied only to only one vCenter.

4. Verify that the link works by navigating to the host Summary tab for this host. Verify that the OMSA Console link is live within the Dell Host Information.

Understanding Using OMSA with 11th Generation Servers

On servers earlier than Dell PowerEdge 12th generation servers, you must install OMSA to work with the OpenManage Integration for VMware vCenter. You can install OMSA automatically on Dell PowerEdge 11th generation hosts during deployment, or if you want to install it manually, you may still do so.

To configure OMSA on Dell PowerEdge 11th generation hosts, choose from the following:

• Deploying the OMSA Agent onto an ESXi System

• Deploying the OMSA Agent onto an ESX System

• Setting up an OMSA Trap Destination

• Editing the OMSA Link

Deploying the OMSA Agent onto an ESX System

Install the OMSA tar.gz on an ESX system to gather inventory and alert information from the systems.

NOTE: OpenManage agents are required on Dell hosts earlier than Dell PowerEdge 12th generation servers. Install OMSA using the OpenManage Integration for VMware vCenter. Details on manually installing the agents are at http:// en.community.dell.com/techcenter/systems-management/w/wiki/1760.openmanage-server-administratoromsa.aspx.

To deploy the OMSA agent tar.gz on an ESX system with the required remote enablement setting (-c) option:

1. Run the OMSA agent installation script:

srvadmin-install.sh -x -c

2. Start OMSA services:

srvadmin-services.sh start

3. If the OMSA agent is already installed, make sure that it has remote enablement configuration (-c) option or theOpenManage Integration for VMware vCenter installation will not complete successfully. Reinstall it with the -c option and restart the service:

srvadmin-install.sh -c srvadmin-services.sh restart

OpenManage Integration for VMware vCenter or install manually to hosts prior to installing the

Deploying The OMSA Agent Onto An ESXi System

Install the OMSA VIB on an ESXi system to gather inventory and alert information from the systems.

NOTE: OpenManage agents are required on Dell hosts earlier than Dell PowerEdge 12th generation servers. Install OMSA using the OpenManage Integration for VMware vCenter or install manually to hosts prior to installing the OpenManage Integration for VMware vCenter. Details on manually installing the agents are at http:// en.community.dell.com/techcenter/systems-management/w/wiki/1760.openmanage-server-administratoromsa.aspx.

1. If not already installed, install the vSphere command line tool (vSphere CLI) from http://www.vmware.com.

2. Enter the following command:

Vihostupdate.pl -server <IP Address of ESXi host> -i -b OM-SrvAdmin-DellWeb-6.3.0-2075.VIB-ESX41i_A00.8.zip

NOTE: It can take a few minutes for OMSA to install. This command requires a reboot of the host after it completes.

Setting Up An OMSA Trap Destination

This task is only for host systems using OMSA for event generation instead of iDRAC6. There is no additional configuration required for iDRAC6.

NOTE: OMSA is only required on Dell servers earlier than version Dell PowerEdge 12th generation servers.

1. Either use the link to the OMSA user interface found in the OpenManage Integration for VMware vCenter Manage → Settings tab, or navigate to the OMSA agent from a Web browser (https://<HostIP>:1311/).

2. Log in to the interface, and select the Alert Management tab.

3. Select Alert Actions and make sure that any events to be monitored have the Broadcast Message option set, so that the events are sent out.

4. At the top of the tab, select the Platform Events option.

5. Click the grey Configure Destinations button, and click the Destination link.

6. Select the Enable Destination check box.

7. Enter the OpenManage Integration for VMware vCenter appliance IP address in the Destination IP Address field.

8. Click Apply Changes.

9. Repeat step 1 to step 8 to configure additional events.

Viewing Warranty Expiration Notification Settings

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings, click Warranty Expiration Notification.

2. Under Warranty Expiration Notification you can view the following:

• Whether the setting is enabled or disabled

• The number of days for the first Warning setting.

• The number of days for the Critical warning setting.

3. To configure Warranty Expiration Notification, see Configuring Warranty Expiration Notifications.

Configuring Warranty Expiration Notification

You can configure warranty expiration thresholds to warn about warranty expiration.

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings, to the right side of

2. In the Warranty Expiration Notification dialog box, do the following: a. If you want to enable this setting, select the Enable warranty expiration notification for hosts check box.

Selecting the check box enables warranty expiration notification.

b. Under Minimum Days Threshold Alert, do the following:

Warranty Expiration Notification, click the Edit icon.

1. In the Warning drop-down list, select the number of days before you want to be warned of the warranty expiration.

2. In the Critical drop-down list, select the number of days before you want to be warned of the warranty expiration.

3. Click Apply.

About Firmware Updates

The location where servers receive firmware updates is a global setting that is available in the OpenManage Integration for VMware vCenter on the Settings tab.

Firmware repository settings contain the firmware catalog location used to update deployed servers. There are two location types:

Dell (ftp.dell.com) Uses the firmware update repository of Dell (ftp.dell.com). The OpenManage Integration for

VMware vCenter downloads selected firmware updates from Dell.

Shared Network Folder

NOTE: Once the repository is created, save it to a location that the registered hosts can access. Repository passwords cannot exceed 31 characters. Do not use any of the following characters in a password: @, &, %, ', ", , (comma), < >

The Firmware Update Wizard always checks for the minimum firmware levels for iDRAC, BIOS, and Lifecycle Controller, and attempts to update them to required minimum versions. Once iDRAC, Lifecycle Controller, and BIOS firmware versions meet minimum requirements, the Firmware Update wizard allows updates for all firmware including: iDRAC, Lifecycle Controller, RAID, NIC/LOM, Power Supply, BIOS, and so on.

Created with Dell Repository Manager™. These local repositories are located on CIFS or NFS file share.

NOTE: For 9th and 10th generation servers, BIOS/BMC/DRAC firmware versions are viewable only at the Cluster View level in vCenter or on the Overview page of the individual host view. Firmware version information is not active in the individual host view under Firmware, and that page appears grayed out, and remote firmware updates are not available.

Firmware Versions After October 14, 2010

For Firmware updated on or after October 14th, 2010, the Firmware Update Wizard runs.

Firmware Versions Newer Than July 29, 2009 and Prior to October 14th

If your firmware was updated on or after July 29, 2009 and prior to October 14, 2010, you still will not see the Firmware Update Wizard, but you are delivered an ISO bundle to update your firmware. After this update, you may not have the latest firmware. After you run the bundle, it is recommended that you run the update again.

Firmware Versions Older than July 29, 2009

If your firmware is older than July 29, 2009, you may have to download and run the ISO file to update your machines. After you run the ISO, it is recommended that you run the Firmware Update Wizard again.

Related Information:

• Setting Up The Firmware Repository

Setting Up the Firmware Update Repository

You can set up the firmware update repository on the OpenManage Integration for VMware vCenter Settings tab.

1. In OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings and to the right side of Firmware Update Repository, click the Edit icon.

2. In the Firmware Update Repository dialog box, select one of the following:

• Dell Online

Default firmware repository (ftp.dell.com) with a staging folder. The OpenManage Integration for VMware vCenter downloads selected firmware updates and stores them in the staging folder, and then you need to run the firmware wizard to update the firmware.

• Shared Network Folder

These are created with the Dell Repository Manager application. Locate these local repositories on Windowsbased file shares. Use the live link to go to Dell Repository Manager.

3. If you selected Shared Network Folder , do the following:

a. Enter the Catalog File Location using the following format:

• NFS share for xml file: host:/share/filename.xml

• NFS share for gz file: host:/share/filename.gz

• CIFS share for xml file: \\host\share\filename.xml

• CIFS share for gz file: \\host\share\filename.gz

b. If the downloading of the files are in progress in the selected repository path which is displayed in the Select

Update Source screen, an error message is displayed notifying that the download is in progress.

4. When the test is complete, click Apply.

Running The Firmware Update Wizard for a Single Host

This functionality is only available for 11th and 12th generation Dell servers that have either an iDRAC Express or Enterprise card. When your firmware was installed on or after October 14th, 2010, you can automatically update your firmware versions using the Firmware Update Wizard.

NOTE: To safeguard against browser timeout issues, change the default timeout to 30 seconds. For information on changing the default timeout setting, see How Come I see an Error Message Displayed After Clicking the Firmware Update Link in the Troubleshooting section of the

NOTE: Right click on Host > All OpenManage Integration Actions > Firmware Update to access the firmware wizard. Or, Click on firmware wizard. Or, Click on Host > Summary > Dell Host Information > Firmware Update to access the firmware wizard.

NOTE:

To run the Firmware Update Wizard:

1. In the vSphere Web Client click on Hosts. The list of available hosts are displayed.

2. Select a host from the displayed list. If there is only one host then only one host is displayed.

3. In the main menu, click on Monitor and then select the Dell Host Information tab. The inventory information of the Dell Hosts are displayed.

4. Click on Firmware, the available firmwares with the details are displayed.

5. Click on Run Firmware Wizard. The Firmware Update screen is displayed.

6. Click Next, the Select Update Source screen is displayed with the firmware update bundle for the given host is displayed.

a. In the screen, select the firmware update bundle from the Select an Update Bundle drop-down list.

7. Click Next. The Select Components screen is displayed which lists the firmware details for the components.

8. Select the desired firmware updates and click Next. Components that are either a downgrade or currently scheduled for update are not selectable. If you select the Allow Firmware downgrade check box, select the options that are listed as Downgrade. Selecting this option is only recommended to advanced users who understand the implications of downgrading firmware.

9. Click Next. The Schedule Firmware Update screen is displayed.

Host > Actions > All OpenManage Integration Actions > Firmware Update to access the

User’s Guide

• Enter the job name in the Firmware Update Job Name field and description in the Firmware Update Description

field. This field entry is optional.

• Select Update Now will start the firmware update job immediately.

• Schedule Update button , select this radio button to run the firmware update job later and click on Next. You

can schedule the firmware update job after 30 minutes from the current time.

• In the Calendar box, select the month and day.

• In the Time text box, type the time in HH:MM, and then click Next. The time is the local time zone where your

client is physically located. Invalid time values result in a blocked update.

• Apply updates on next reboot.

To avoid a service interruption, it is recommended that the host enters maintenance mode before the reboot.

• Apply updates and force reboot without entering maintenance mode.

-The update is applied, and a reboot occurs even if the host is not in maintenance mode. This method is not recommended.

10. Click Next. The Summary page is displayed that provides details about all components after firmware update.

11. Click Finish.

12. To verify that the update was successful, in Monitor tab, select Job Queue → Firmware Updates, and review the OpenManage Integration Overview page to see the new versions.

Running the Update Firmware Wizard for a Cluster

firmware versions using the Firmware Update Wizard. This wizard only updates hosts that are part of a connection profile and compliant in terms of firmware, CSIOR status, hypervisor, and OMSA status (11th generation servers only). Select a cluster that is listed in the Clusters view and use the Firmware Update Wizard. It typically takes from 30 to 60 minutes to update firmware components for each cluster. Enable DRS on a cluster so that virtual machines can be migrated when a host enters/exits maintenance mode during the firmware update process. You can only schedule or run one firmware update task at a time.

If you want to export from the wizard, use the Export to CSV button. Search is available for locating a specific cluster, datacenter, host, or any topic item from the datagrid except for Date Applied.

NOTE: Always update firmware together as part of the repository bundle: BIOS, iDRAC, and Lifecycle Controller.

NOTE: For information on changing the default timeout setting, see the Troubleshooting section of the

Guide

You can view the status and manage Firmware update jobs from the Job Queue page. See, Viewing Firmware Details for

Datacenters and Clusters.

1. Click on OpenManage Integration icon, click on Clusters hat is displayed in the left pane. The list of clusters are displayed.

2. Click on a cluster from the displayed list. The main menu is displayed with different options.

3. Click on Monitor -->Dell Cluster Information -->Firmware. The Run Firmware Wizard screen is displayed.

4. Click on Run Firmware Wizard link. The Welcome Page is dislayed.

5. Click Next. The Select Update Source screen is displayed where you can select the bundles. The Repository location is also displayed.

6. Select host from the displayed list in the Select Bundles area. You should select at least one bundle for firmware update. Each host has a drop-down list next to the host name from which you can select the required bundle.

7. Click Next. The Select Components screen is displayed. This screen displays the details of components such as model name, host name, service tag, component and so on for the selected host.

8. Select at least one component from the list, and click Next to proceed. You can filter the content of the component data grid using the Filter field or, drag and drop columns within the component data grid. If you select the Allow Firmware downgrade

9. Click Next, the Schedule Firmware Update screen is displayed.

a. Enter the firmware update job name in the Firmware Update Job Name field. This value is mandatory. b. Enter the firmware update description in the Firmware Update Description field. This value is optional.

10. Select an option from the following.

a. Update Now, select this radio button to run the firmware update job now and click on Next. b. Schedule Update button , select this radio button to run the firmware update job later and click on Next. You

can schedule the firmware update job after 30 minutes from the current time. c. In the Calendar box, select the month and day. d. In the Time text box, type the time in HH:MM, and then click Next. The time is the local timezone where your

client is physically located. Invalid time values result in a blocked update.

11. The Summary screen is displayed with all the firmware update details.

12. Click Finish and a message The firmware update job has been created for successful firmware update is displayed.

check box, the existing firmware version will roll back to the previous available version.

User’s

Viewing Firmware Update Status for Clusters and Datacenters

For information to display on this page, run or schedule a firmware update for a cluster or a host. This page only displays relevant job information. On this page you can refresh, purge, or abort your firmware update jobs.

1. From the OpenManage Integration, select Monitor → Job Queue → Firmware Updates.

2. To display the most recent information, click Refresh.

3. View the status in the datagrid. This grid offers the following information about firmware update jobs:

• Status

• Scheduled Time

• Name

• Description

• vCenter

• Collection Size

The collection size is the number of servers on this firmware inventory job.

• Progress Summary

The progress summary lists the progress details of this firmware update.

4. To see more details about a particular job, in the datagrid for a particular job, click on a item of master datagrid. The details are displayed in the details datagrid.

Here you can find the following details:

• Host Name

• Status

• Start Time

• End Time

5. If you want to abort a scheduled firmware update that is not running, in the same line as the job you want to abort,

Abort.

click

6. If you want to modify a scheduled job click on Modify.

7. If you want to purge scheduled firmware updates, click Purge Job Queue.

You can only purge jobs that are completed or scheduled.

8. Select the Older than date and job Status, and click Apply. The selected jobs are then cleared from the queue.

Understanding Events And Alarms for Hosts

You can edit events and alarms settings from the OpenManage Integration for VMware vCenter within Manage → Settings tab. From here you can select the Event Posting Level, enable Alarms for Dell Hosts, or Restore Default Alarms. You can configure events and alarms for each vCenter or all at once for all registered vCenters.

NOTE: To receive Dell events, you must enable both alarms and events.

There are four event posting levels.

Table 2. Event Posting Level Descriptions

Event Description

Do not post any Events Do not have the OpenManage Integration for VMware

vCenter forward any events or alerts into related vCenters.

Post all Events Post all events, including informal events, that the

OpenManage Integration for VMware vCenter receives from managed Dell hosts into related vCenters.

Post only Critical and Warning Events Posts only events with either Critical or Warning criticality

into related vCenters.

Post only Virtualization-Related Critical and Warning Events

When you configure your events and alarms, you can enable them. When enabled, critical hardware alarms can trigger the OpenManage Integration for VMware vCenter to put the host system into a maintenance mode, and in certain cases, migrate the virtual machines to another host system. The OpenManage Integration for VMware vCenter forwards events received from managed Dell hosts, and creates alarms for those events. Use these alarms to trigger actions from vCenter, like a reboot, maintenance mode, or migrate. For example, when a dual power supply fails and an alarm is created, the resulting action is to migrate the virtual machine on that machine to a new one.

A host enters or leaves maintenance mode only as when you request it. If the host is in a cluster when it enters maintenance mode, you are given the option to evacuate powered-off virtual machines. If this option is selected, each powered-off virtual machine is migrated to another host, unless there is no compatible host available for the virtual machine in the cluster. While in maintenance mode, the host does not allow deployment or machine. Virtual machines that are running on a host entering maintenance mode need to be either migrated to another host or shut down, either manually or automatically by VMware Distributed Resource Scheduling (DRS).

Any hosts outside of clusters, or in clusters without VMware Distributed Resource Scheduling (DRS) enabled, could see virtual machines being shut down due to a critical event. DRS continuously monitors usage across a resource pool and intelligently allocates available resources among virtual machines according to business needs. Use clusters with DRS configured in conjunction with Dell Alarms to make sure that virtual machines are automatically migrated on critical hardware events. Listed in the details of the on screen message are any clusters on this vCenter instance that may be impacted. Confirm that the clusters are impacted before enabling Events and Alarms.

If you ever need to restore the default alarm settings, you can do so with the Reset Default Alarm button. This button is a convenience to restore the default alarm configuration without uninstalling and reinstalling the product. If any Dell alarm configurations have been changed since install, those changes are reverted using this button.

Post Virtualization related events received from hosts into related vCenters. Virtualization related events are those that Dell has selected to be most critical to hosts running virtual machines.

power-on

of a virtual

NOTE: The OpenManage Integration for VMware vCenter pre-selects the virtualization-related events that are the essential to hosts successfully running virtual machines. Dell host alarms are disabled by default. If Dell alarms are enabled, the clusters should use the VMware Distributed Resource Scheduler to make sure that the virtual machines that send critical events are automatically migrated.

Understanding Events And Alarms for Chassis

Events and alarms corresponding to a chassis are shown only at the vCenter level. Events and alarms settings that are done for hosts at every vCenter is also applicable at chassis level.. You can edit events and alarms settings from the OpenManage Integration for VMware vCenter within Manage → Settings tab. From here you can select the Event Posting Level, enable Alarms for Dell Hosts and Chassis, or Restore Default Alarms. You can configure events and alarms for each vCenter or all at once for all registered vCenters.

NOTE: To receive Dell events, you must enable both alarms and events.

Viewing Chassis Events

In the left pane select vCenter, click on vCenter Servers

Click on a specific vCenter.

On the Monitor tab, click Events.

To view more event details, select a specific event.

Viewing Chassis Alarms

In the left pane select vCenter, click on vCenter Servers

Click on a specific vCenter.

The alarms are displayed. Only the first 4 alarms are displayed. Click on Show All and the detailed list are displayed in the Monitor tab as All Issues..

Click on the Alarm in Triggered Alarms to view the Alarm Definition.

Configuring Events And Alarms

For detailed information about events and alarms see Understanding Alarms and Events. Configure events and alarms on the OpenManage Integration for VMware vCenter Management → Settings tab. Under vCenter Settings, expand the Events and Alarms heading to display the current vCenter Alarms for Dell Hosts (Enabled or Disabled), or for all and the Event Posting Level.

NOTE: On hosts prior to Dell PowerEdge 12th generation servers, this feature requires that the virtual appliance is configured as a trap destination in OMSA to display host events in vCenter. For more information on OMSA, see

Setting Up An OMSA Trap Destination.

NOTE: To receive Dell events, you must enable both alarms and events.

1. In the OpenManage Integration for VMware vCenter Manage → Settings tab, next to vCenter Settings use the drop-down list to select the vCenter server or All vCenter Servers to included with this setting.

If you selected All Registered Servers, the options may display blank. This lets you configure the settings for all the registered vCenters at once. If the vCenters had the same settings, they will appear.

2. To the right side of Events and Alarms, click the Edit icon.

3. To enable all hardware alarms and events, select the Enable Alarms for all Dell Hosts check box.

NOTE: Dell hosts that have alarms enabled respond to critical events by entering maintenance mode and you can modify the alarm as needed.

4. To restore the default vCenter alarm settings for all managed Dell servers, click Restore Default Alarms.

It may take up to a minute before the change takes effect.

5. Under Event Posting Level, select one of the following:

• Do not post any events

This options blocks hardware events.

• Post All Events

This option posts all hardware events.

• Post only Critical and Warning Events

This option posts only critical or warning level hardware events.

• Post only Virtualization-Related Critical and Warning Events

This option posts only virtualization-related critical and warning events. This is the default event posting level.

6. If you want to apply these settings to all vCenters, select the Apply these settings to all vCenters check box.

NOTE: Selecting this option overrides the existing settings for all vCenters.

This option is grayed out if you already selected All Registered vCenters from the drop-down list on the Setting page.

7. To save, click Apply.

Viewing the Alarm and Event Settings

Once alarms and events are configured you can view if the vCenter alarms for hosts are enabled and which event posting level is selected on the Settings tab.

1. In the OpenManage Integration for VMware vCenterManage → Settings tab, under vCenter Settings, expand Events and Alarms.

2. Under Events and Alarms you can view the following:

• vCenter Alarms for Dell Hosts: Displays either Enabled or Disabled.

• Event Posting Level

To see the event posting levels that can display, see Understanding Alarms and Events.

3. To configure alarms and events, see Configuring Events and Alarms

Viewing Events

Configure events before you can view them in the Events tab, see Configuring Events and Alarms. View the events for a host, cluster or datacenter on the Events tab.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts, Datacenter or Clusters.

2. On the Objects tab, select the specific host, datacenter or cluster for which you want to view events.

3. On the Monitor tab, click Events.

4. To view more event details, select a specific event.

Viewing the Data Retrieval Schedules for Inventory and Warranty

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under vCenter Settings, click Data Retrieval Schedule.

Clicking Data Retrieval Schedule expands to expose the schedules for inventory and warranty.

2. For either Inventory or Warranty Retrieval, view the settings:

• Shows whether the option is enabled or disabled

• Displays the week days for which it is enabled.

• Displays the time of day it is enabled.

3. If you click Data Retrieval Schedule again, it rolls up the information into a single line and displays whether the option is enabled or disabled.

4. If you want to edit the Data Retrieval Schedule, see Modifying Inventory Job Schedules or Modifying a Warranty

Job Schedule.

Understanding Using OMSA with 11th Generation Servers

To configure OMSA on Dell PowerEdge 11th generation hosts, choose from the following:

• Deploying the OMSA Agent onto an ESXi System

• Deploying the OMSA Agent onto an ESX System

• Setting up an OMSA Trap Destination

• Editing the OMSA Link

Deploying The OMSA Agent Onto An ESXi System

Install the OMSA VIB on an ESXi system to gather inventory and alert information from the systems.

1. If not already installed, install the vSphere command line tool (vSphere CLI) from http://www.vmware.com.

2. Enter the following command:

Vihostupdate.pl -server <IP Address of ESXi host> -i -b OM-SrvAdmin-DellWeb-6.3.0-2075.VIB-ESX41i_A00.8.zip

NOTE: It can take a few minutes for OMSA to install. This command requires a reboot of the host after it completes.

Deploying the OMSA Agent onto an ESX System

Install the OMSA tar.gz on an ESX system to gather inventory and alert information from the systems.

To deploy the OMSA agent tar.gz on an ESX system with the required remote enablement setting (-c) option:

1. Run the OMSA agent installation script:

srvadmin-install.sh -x -c

2. Start OMSA services:

srvadmin-services.sh start

3. If the OMSA agent is already installed, make sure that it has remote enablement configuration (-c) option or

OpenManage Integration for VMware vCenter installation will not complete successfully. Reinstall it with the -c

the option and restart the service:

srvadmin-install.sh -c srvadmin-services.sh restart

Setting Up An OMSA Trap Destination

This task is only for host systems using OMSA for event generation instead of iDRAC6. There is no additional configuration required for iDRAC6.

NOTE: OMSA is only required on Dell servers earlier than version Dell PowerEdge 12th generation servers.

2. Log in to the interface, and select the Alert Management tab.

3. Select Alert Actions and make sure that any events to be monitored have the Broadcast Message option set, so that the events are sent out.

4. At the top of the tab, select the Platform Events option.

5. Click the grey Configure Destinations button, and click the Destination link.

6. Select the Enable Destination check box.

7. Enter the OpenManage Integration for VMware vCenter appliance IP address in the Destination IP Address field.

8. Click Apply Changes.

9. Repeat step 1 to step 8 to configure additional events.

Viewing Warranty Expiration Notification Settings

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings, click Warranty Expiration Notification.

2. Under Warranty Expiration Notification you can view the following:

• Whether the setting is enabled or disabled

• The number of days for the first Warning setting.

• The number of days for the Critical warning setting.

3. To configure Warranty Expiration Notification, see Configuring Warranty Expiration Notifications.

Configuring Warranty Expiration Notification

You can configure warranty expiration thresholds to warn about warranty expiration.

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings, to the right side of Warranty Expiration Notification, click the Edit icon.

2. In the Warranty Expiration Notification dialog box, do the following:

a. If you want to enable this setting, select the Enable warranty expiration notification for hosts check box.

Selecting the check box enables warranty expiration notification.

b. Under Minimum Days Threshold Alert, do the following:

1. In the Warning drop-down list, select the number of days before you want to be warned of the warranty

2. In the Critical drop-down list, select the number of days before you want to be warned of the warranty

3. Click Apply.

expiration.

About Firmware Updates

The location where servers receive firmware updates is a global setting that is available in the OpenManage Integration for VMware vCenter on the Settings tab.

Firmware repository settings contain the firmware catalog location used to update deployed servers. There are two location types:

Dell (ftp.dell.com) Uses the firmware update repository of Dell (ftp.dell.com). The OpenManage Integration for

VMware vCenter downloads selected firmware updates from Dell.

Shared Network Folder

Created with Dell Repository Manager™. These local repositories are located on CIFS or NFS file share.

Firmware Versions After October 14, 2010

For Firmware updated on or after October 14th, 2010, the Firmware Update Wizard runs.

Firmware Versions Newer Than July 29, 2009 and Prior to October 14th

Firmware Versions Older than July 29, 2009

Related Information:

• Setting Up The Firmware Repository

Setting Up the Firmware Update Repository

You can set up the firmware update repository on the OpenManage Integration for VMware vCenter Settings tab.

1. In OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under Appliance Settings and to the right side of Firmware Update Repository, click the

2. In the Firmware Update Repository dialog box, select one of the following:

• Dell Online

• Shared Network Folder

These are created with the Dell Repository Manager application. Locate these local repositories on Windowsbased file shares. Use the live link to go to Dell Repository Manager.

3. If you selected Shared Network Folder , do the following:

a. Enter the Catalog File Location using the following format:

• NFS share for xml file: host:/share/filename.xml

• NFS share for gz file: host:/share/filename.gz

• CIFS share for xml file: \\host\share\filename.xml

• CIFS share for gz file: \\host\share\filename.gz

b. If the downloading of the files are in progress in the selected repository path which is displayed in the Select

Update Source screen, an error message is displayed notifying that the download is in progress.

4. When the test is complete, click Apply.

Edit icon.

Running The Firmware Update Wizard for a Single Host

NOTE: Right click on Host > All OpenManage Integration Actions > Firmware Update to access the firmware wizard. Or, Click on Host > Actions > All OpenManage Integration Actions > Firmware Update to access the firmware wizard. Or, Click on Host > Summary > Dell Host Information > Firmware Update to access the firmware wizard.

NOTE:

To run the Firmware Update Wizard:

1. In the vSphere Web Client click on Hosts. The list of available hosts are displayed.

2. Select a host from the displayed list. If there is only one host then only one host is displayed.

3. In the main menu, click on Monitor and then select the Dell Host Information tab. The inventory information of the Dell Hosts are displayed.

4. Click on Firmware, the available firmwares with the details are displayed.

User’s Guide

5. Click on Run Firmware Wizard. The Firmware Update screen is displayed.

6. Click Next, the Select Update Source screen is displayed with the firmware update bundle for the given host is displayed.

a. In the screen, select the firmware update bundle from the Select an Update Bundle drop-down list.

7. Click Next. The Select Components screen is displayed which lists the firmware details for the components.

9. Click Next. The Schedule Firmware Update screen is displayed.

• Enter the job name in the Firmware Update Job Name field and description in the Firmware Update Description

field. This field entry is optional.

• Select Update Now will start the firmware update job immediately.

• Schedule Update button , select this radio button to run the firmware update job later and click on Next. You

can schedule the firmware update job after 30 minutes from the current time.

• In the Calendar box, select the month and day.

• In the Time text box, type the time in HH:MM, and then click Next. The time is the local time zone where your

client is physically located. Invalid time values result in a blocked update.

• Apply updates on next reboot.

To avoid a service interruption, it is recommended that the host enters maintenance mode before the reboot.

• Apply updates and force reboot without entering maintenance mode.

-The update is applied, and a reboot occurs even if the host is not in maintenance mode. This method is not recommended.

10. Click Next. The Summary page is displayed that provides details about all components after firmware update.

11. Click Finish.

12. To verify that the update was successful, in Monitor tab, select Job Queue → Firmware Updates, and review the OpenManage Integration Overview page to see the new versions.

Running the Update Firmware Wizard for a Cluster

This functionality is only available for 11th and 12th generation Dell servers that have either an iDRAC Express or Enterprise card. If your firmware was installed on or after October 14th, 2010, you can automatically update your firmware versions using the Firmware Update Wizard. This wizard only updates hosts that are part of a connection profile and compliant in terms of firmware, CSIOR status, hypervisor, and OMSA status (11th generation servers only). Select a cluster that is listed in the Clusters view and use the Firmware Update Wizard. It typically takes from 30 to 60 minutes to update firmware components for each cluster. Enable DRS on a cluster so that virtual machines can be migrated when a host enters/exits maintenance mode during the firmware update process. You can only schedule or run one firmware update task at a time.

NOTE: Always update firmware together as part of the repository bundle: BIOS, iDRAC, and Lifecycle Controller.

NOTE: For information on changing the default timeout setting, see the Troubleshooting section of the

Guide

User’s

You can view the status and manage Firmware update jobs from the Job Queue page. See, Viewing Firmware Details for

Datacenters and Clusters.

1. Click on OpenManage Integration icon, click on Clusters hat is displayed in the left pane. The list of clusters are displayed.

2. Click on a cluster from the displayed list. The main menu is displayed with different options.

3. Click on Monitor -->Dell Cluster Information -->Firmware. The Run Firmware Wizard screen is displayed.

4. Click on Run Firmware Wizard link. The Welcome Page is dislayed.

5. Click Next. The Select Update Source screen is displayed where you can select the bundles. The Repository location is also displayed.

7. Click Next. The Select Components screen is displayed. This screen displays the details of components such as model name, host name, service tag, component and so on for the selected host.

9. Click Next, the Schedule Firmware Update screen is displayed.

10. Select an option from the following.

client is physically located. Invalid time values result in a blocked update.

11. The Summary screen is displayed with all the firmware update details.

12. Click Finish and a message The firmware update job has been created for successful firmware update is displayed.

Understanding Events And Alarms for Hosts

NOTE: To receive Dell events, you must enable both alarms and events.

There are four event posting levels.

Table 3. Event Posting Level Descriptions

Event Description

Do not post any Events Do not have the OpenManage Integration for VMware

vCenter forward any events or alerts into related vCenters.

Post all Events Post all events, including informal events, that the

OpenManage Integration for VMware vCenter receives from managed Dell hosts into related vCenters.

Post only Critical and Warning Events Posts only events with either Critical or Warning criticality

into related vCenters.

Post only Virtualization-Related Critical and Warning Events

Post Virtualization related events received from hosts into related vCenters. Virtualization related events are those that Dell has selected to be most critical to hosts running virtual machines.

power-on

of a virtual

Understanding Events And Alarms for Chassis

NOTE: To receive Dell events, you must enable both alarms and events.

Viewing Chassis Events

In the left pane select vCenter, click on vCenter Servers

Click on a specific vCenter.

On the Monitor tab, click Events.

To view more event details, select a specific event.

Viewing Chassis Alarms

In the left pane select vCenter, click on vCenter Servers

Click on a specific vCenter.

The alarms are displayed. Only the first 4 alarms are displayed. Click on Show All and the detailed list are displayed in the Monitor tab as All Issues..

Click on the Alarm in Triggered Alarms to view the Alarm Definition.

Configuring Events And Alarms

Setting Up An OMSA Trap Destination.

NOTE: To receive Dell events, you must enable both alarms and events.

2. To the right side of Events and Alarms, click the Edit icon.

3. To enable all hardware alarms and events, select the Enable Alarms for all Dell Hosts check box.

NOTE: Dell hosts that have alarms enabled respond to critical events by entering maintenance mode and you can modify the alarm as needed.

4. To restore the default vCenter alarm settings for all managed Dell servers, click Restore Default Alarms.

It may take up to a minute before the change takes effect.

5. Under Event Posting Level, select one of the following:

• Do not post any events

This options blocks hardware events.

• Post All Events

This option posts all hardware events.

• Post only Critical and Warning Events

This option posts only critical or warning level hardware events.

• Post only Virtualization-Related Critical and Warning Events

This option posts only virtualization-related critical and warning events. This is the default event posting level.

6. If you want to apply these settings to all vCenters, select the Apply these settings to all vCenters check box.

NOTE: Selecting this option overrides the existing settings for all vCenters.

This option is grayed out if you already selected All Registered vCenters from the drop-down list on the Setting page.

7. To save, click Apply.

Viewing Events

Configure events before you can view them in the Events tab, see Configuring Events and Alarms. View the events for a host, cluster or datacenter on the Events tab.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts, Datacenter or Clusters.

2. On the Objects tab, select the specific host, datacenter or cluster for which you want to view events.

3. On the Monitor tab, click Events.

4. To view more event details, select a specific event.

Viewing the Alarm and Event Settings

Once alarms and events are configured you can view if the vCenter alarms for hosts are enabled and which event posting level is selected on the Settings tab.

1. In the OpenManage Integration for VMware vCenterManage → Settings tab, under vCenter Settings, expand Events and Alarms.

2. Under Events and Alarms you can view the following:

• vCenter Alarms for Dell Hosts: Displays either Enabled or Disabled.

• Event Posting Level

To see the event posting levels that can display, see Understanding Alarms and Events.

3. To configure alarms and events, see Configuring Events and Alarms

Viewing the Data Retrieval Schedules for Inventory and Warranty

1. In the OpenManage Integration for VMware vCenter, on the Manage → Settings tab, under vCenter Settings, click Data Retrieval Schedule.

Clicking Data Retrieval Schedule expands to expose the schedules for inventory and warranty.

2. For either Inventory or Warranty Retrieval, view the settings:

• Shows whether the option is enabled or disabled

• Displays the week days for which it is enabled.

• Displays the time of day it is enabled.

3. If you click Data Retrieval Schedule again, it rolls up the information into a single line and displays whether the option is enabled or disabled.

4. If you want to edit the Data Retrieval Schedule, see Modifying Inventory Job Schedules or Modifying a Warranty

Job Schedule.

Viewing Associated Host for a Chassis

You can view information about the associated host for the selected chassis on the Manage page.

To view information about the associated host:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Manage tab.

The following information about the associated host is displayed:

• Host Name (If you click on the selected host IP, the details about the host is displayed.)

• Service Tag

• Model

• iDRAC IP

• Slot Location

Chassis Management

The OpenManage Integration for VMware vCenter allows you to view additional information for a selected Chassis. In the Chassis Information tab, you can view the chassis overview details for an individual chassis, information about hardware inventory, firmware and management controller. The following three tabs are displayed for each chassis and varies for some chassis based on the models.

Summary tab

Monitor tab

Manage tab

Viewing Chassis Summary Details

You can view the Chassis summary details for an individual chassis on the ChassisSummary page.

To view the Chassis summary details:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Summary tab.

The following information about the selected Chassis is displayed:

• Model

• Firmware Version

• Service Tag

• CMC (If you click the CMC link, the Chassis Management Controller page is displayed.)

NOTE: If you do not inventory chassis, you can see only Service Tag and CMC IP address.

5. You can view the health status of the devices associated with the selected chassis. The main pane displays the overall health of a chassis. The valid health indicators are Healthy, Warning, Critical, Not Present. In the Chassis Health grid view, the health of each component is displayed. The chassis health parameters are applicable for models VRTX version 1.0 and later, M1000e version 4.4 and later. For versions less than 4.3 only two health indicators are displayed, namely Healthy and Warning or Critical (Inverted triangle with an exclamatory mark in orange color).

NOTE: The overall health indicates the health based on the chassis with the least health parameter. For example, if there are 5 healthy signs and 1 warning sign, the overall health is shown as warning.

6. You can view the CMC Enterprise or Express with the license type and expiry date for a chassis. This is not applicable for M1000e chassis.

7. In the Warranty Icon the number of remaining days and the days used for a server. If you have more than one warranty, then the last day of the last warranty is considered to calculate the number of days left for warranty.

8. The Active Errors table lists and displays the errors for a chassis which are displayed in the Chassis Health page. For M1000e version 4.3 and below, the active errors are not displayed.

Viewing Hardware Inventory: Fans

You can view information about the fans within the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of Fans information.

To view information about fans:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the fans, perform one of the following:

a. In the Overview tab, click Fans.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click Fans.

The following information is displayed:

• Name

• Present

• Power State

• Reading

• Critical Threshold

– Minimum

– Maximum

Viewing Hardware Inventory: I/O Modules

You can view information about the I/O Modules for the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of I/O Modules information.

To view information about I/O Modules:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the I/O Modules, perform one of the following:

a. In the Overview tab, click I/O Modules.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click I/O Modules.

The following information is displayed:

• Slot/Location

• Present

• Name

• Fabric

• Service Tag

• Power Status

To view additional information, select the corresponding I/O module and following information is displayed:

• Role

• Firmware Version

• Hardware Version

• IP Address

• Subnet Mask

• Gateway

• Mac Address

• DHCP Enabled

Viewing Hardware Inventory: iKVM

You can view information about the iKVM for the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of iKVM information.

NOTE: You can view information about the iKVM only for PowerEdge M1000e Chassis.

To view information about iKVM:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the iKVM, perform one of the following:

a. In the Overview tab, click iKVM.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click iKVM.

The following information is displayed:

• iKVM Name

• Present

• Firmware Version

• Front Panel USB/Video Enabled

• Allow access to CMC CLI

NOTE: The iKVM tab will be displayed only if the chassis contains iKVM module.

Viewing Hardware Inventory: PCIe

You can view information about the PCIe for the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of PCIe information.

To view information about PCIe:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the PCIe, perform one of the following:

NOTE: PCIe information is not applicable for M1000e chassis.

a. In the Overview tab, click PCIe.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click PCIe.

The following information is displayed:

• PCIe Slot

– Slot

– Name

– Power Status

– Fabric

• Server Slot

– Name

– Number

To view additional information, select the corresponding PCIe and following information is displayed:

• Slot Type

• Server Mapping

• Assignment Status

• Allocated Slot Power

• PCI ID

• Vendor ID

Viewing Hardware Inventory: Power Supplies

You can view information about the Power Supply Units for the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of Power Supply Unit information.

To view information about the Power Supply Unit:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the Power Supply Units, perform one of the following:

a. In the Overview tab, click Power Supplies.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click Power Supplies.

The following information is displayed:

• Name

• Capacity

• Present

• Power State

Viewing Hardware Inventory: Temperature Sensors

You can view information about temperature sensors for the selected chassis. To view the information on this page, you must run an inventory job. You can export a CSV file of temperature sensors information.

To view information about the temperature sensors:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. To view information about the temperature sensors, perform one of the following:

a. In the Overview tab, click Temperature Sensors.

b. In the Monitor tab, expand the left pane, click Hardware Inventory, and then click Temperature Sensors.

The following information is displayed:

• Location

• Reading

• Warning Threshold

– Minimum

– Maximum

• Critical Threshold

– Minimum

– Maximum

NOTE: For PowerEdge M1000e chassis, information about temperature sensors is displayed only for chassis. For other chassis, information about temperature sensors is displayed for chassis and associated modular servers..

Viewing Warranty Details

Warranty window stores the warranty details.

To view information about warranty:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. The Warranty tab contains the following:

a. Provider

b. Description

c. Status

d. Start Date

e. End Date

f. Days Left

g. Lat Updated

Viewing Storage

Storage window stores the information for the chassis.

To view information about storage:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. The Storage tab contains the following:

a. Virtual Disks

b. Controllers

c. Enclosures

d. Physical Disks

e. Hot Spares

When you click on each highlighted link under storage the View table displays the details for each highlighted item. In the View table, if you click on each line item additional information is displayed for each highlighted item.

6. For M1000e chassis, if you have a storage module, the following storage details are displayed in a grid view without any additional information.

a. Name b. Model c. Service Tag d. IP Address (Link to storage) e. Fabric f. Group Name g. Group IP Address (link to storage group)

Viewing Firmware Details for a Chassis

You can view information about the firmware details for the selected chassis. You can export a CSV file of firmware information.

To view information about firmware:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. Click the double arrow mark and expand the left pane, and then click Firmware.

The following information is displayed:

• Component

• Current Version

6. If you click Launch CMC, the Chassis Management Controller page is displayed.

Viewing Management Controller Details for a Chassis

You can view information about the management controller details for the selected chassis.

To view information about the management controller:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Monitor tab.

5. Click the double arrow mark and expand the left pane, and then click Management Controller.

6. On the Management Controller page, to view additional information, click the arrow mark and expand the left column.

The following information is displayed:

• General

– Name

– Firmware Version

– Last Update Time

– CMC Location

– Hardware Version

• Common Network

– DNS Domain Name

– Use DHCP for DNS

– MAC Address

– Redudancy Mode

• CMC IPv4 Information

– IPv4 Enabled

– DHCP Enabled

– IP Address

– Subnet Mask

– Gateway

– Preferred DNS Server

– Alternate DNS Server

Viewing Associated Host for a Chassis

You can view information about the associated host for the selected chassis on the Manage page.

To view information about the associated host:

1. On the Home page, click vCenter Server.

2. In the left pane, under OpenManage Integration, click Dell Chassis.

3. In the left pane, select the corresponding chassis IP.

4. Click the Manage tab.

The following information about the associated host is displayed:

• Host Name (If you click on the selected host IP, the details about the host is displayed.)

• Service Tag

• Model

• iDRAC IP

• Slot Location

Monitoring a Single Host

The OpenManage Integration for VMware vCenter lets you view detailed information for a single host. You can access hosts in VMware vCenter from the left side Navigator. This displays all hosts for all vendors. Click on a specific Dell host to find more detailed information. To quickly view a list of Dell Hosts, from withinOpenManage Integration for VMware vCenter, in the left Navigator, click Dell Hosts.

• Viewing Host Summary Details

• Viewing Hardware: FRU Details for a Single Host

• Viewing Hardware: Processor Details for a Single Host

• Viewing Hardware: Power Supply Details for a Single Host

• Viewing Hardware: Memory Details for a Single Host

• Viewing Hardware: NICs Details for a Single Host

• Viewing Hardware: PCI Slot Details for a Single Host

• Viewing Hardware: Remote Access Card Details for a Single Host

• Viewing Storage Details for a Single Host

– Viewing Storage: Virtual Disk Details for a Single Host

– Viewing Storage: Physical Disk Details for a Single Host

– Viewing Storage: Controller Details for a Single Host

– Viewing Storage: Enclosure Details for a Single Host

• Viewing Firmware Details for a Single Host

• Viewing Power Monitoring for a Single Host

• Viewing Warranty Status for a Single Host

• Quickly Viewing Only Dell Hosts

Viewing Host Summary Details

View the host summary details for an individual host on the Host Summary page. This page displays various portlets. Two apply to the OpenManage Integration for VMware vCenter specially and you can drag and drop the portlets to the position you want.

1. In the OpenManage Integration for VMware vCenter, in the Navigator, click Hosts.

2. In the Objects tab, select the specific host you want to review.

3. Click the Summary tab.

4. View the host summary details:

Summary Information

Alerting system If there are alerts for the OpenManage Integration for VMware vCenter, they display in a

Notification area Dell products integrate information in this right side-panel area. You can find information

At the top of this page, in the upper left corner is a summary list of information for this host.

yellow box below the status area and above the portlets.

about:

• Recent Tasks

• Work In Progress

• Alarms Dell alarm information displays in this notification area portlet.

5. Scroll down to view the Dell Server Management portlet.

Service Tag The Service Tag for your Dell PowerEdge server. Use this number when you call for

support.

Model Name Displays the .servers model name.

Fault Resilient Memory

Identification

This is a BIOS attribute and is enabled in the BIOS during initial setup of the sever and displays the memory operational mode of the server. You need to restart your system when you change memory operational mode value. This is applicable for R620, R720, T620, M620 servers with ESXi 5.5 or later version. The four different values are:

• Enabled and Protected: This value indicates that the system is supported and operating system version is ESXi 5.5 or later and the memory operational mode in BIOS is set to FRM.

• Enabled and Not Protected: This value indicates that it supports the system with operating system version lesser than ESXi 5.5.

• Disabled: This value indicates that it supports valid systems with any operating system version and here memory operational mode in BIOS is not set to FRM.

• Blank: If memory operational mode in BIOS is not supported the FRM attribute is not displayed.

• Host name The name of your Dell host.

• Power State Displays if your power is ON or OFF.

• iDRAC IP Displays the iDRAC IP address.

• Management IP Displays the management IP address.

• Connection Profile Displays the connection profile name for this host.

• Model Displays the Dell server model.

• Service Tag Displays the Service Tag for the server.

• Asset Tag Displays the asset tag.

• Warranty Days Left Displays the days left for the warranty.

• Last Inventory Scan Displays the date and time of the last inventory scan.

Hypervisor & Firmware

• Hypervisor Displays the Hypervisor version.

• BIOS Version Displays the BIOS version.

• Remote Access Card Version

Displays the remote access card version.

Management Consoles

Host Actions Blink Indicator Light lets you set up your physical server to blink at various time intervals.

6. View the Dell Host Health portlet:

Dell Host Health Component health is a graphical representation of the status of all major host server

The management consoles are used to launch external system management consoles, such as:

• Remote Access Console (iDRAC) Launches the Integrated Dell Remote Access Controller (iDRAC) web user interface.

To configure the OMSA link, see Editing the OMSA Link. Launches the OpenManage Server Administrator (OMSA) user interface if it has been

configured.

components: Server Global status, Server, Power supply, Temperature, Voltages, Processors, Batteries, Intrusion, Hardware log, Power management, Power and Memory. The chassis health parameters are applicable for models VRTX version 1.0 and later, M1000e version 4.4 and later. For versions less than 4.3 only two health indicators are displayed, namely Healthy and Warning or Critical (Inverted triangle with an exclamatory mark in orange color). The overall health indicates the health based on the chassis with the least health parameter. For example, if there are 5 healthy signs and 1 warning sign, the overall health is shown as warning. Options include:

• Healthy (green check mark) - component operating normally

• Warning (yellow triangle with exclamation point) - component has a non-critical error

• Critical (red X) - component has a critical failure

• Unknown (question mark) - status is unknown for the component

Launching Management Consoles

There are two management consoles you can launch from the Dell Server Management Portlet. These include:

• Remote Access Console (iDRAC Console) Launch the Remote Access Console to access the iDRAC user interface.

• OMSA Console. Launch the OMSA Console to launch the OpenManage Server Administrator user interface URL that was entered

into the Configuration Wizard. You must install the URL for the server administrator Web server on a Windows-based management station.

Launching the Remote Access Console (iDRAC)

You can launch the iDRAC user interface from the Dell Server Management Portlet.

1. In the OpenManage Integration for VMware vCenter, in the Navigator area, under Inventory Lists, click Hosts.

2. On the Object tab, double-click the host you want.

3. On the Summary tab, scroll down to the Dell Server Management portlet.

4. Click Management Consoles → Remote Access Console (iDRAC).

Launching the OMSA Console

Before you can launch the OMSA Console, you must set up the OMSA URL and install and configure the OMSA Web Server. Set up the OMSA URL from the Settings Tab.

NOTE: You must install OMSA to monitor and manage Dell PowerEdge 11th generation servers usingOpenManage Integration for VMware vCenter.

1. In the OpenManage Integration for VMware vCenter, in the Navigator area, under Inventory Lists, click Hosts.

2. On the Object tab, double-click the host you want.

3. On the Summary tab, scroll down to the Dell Server Management portlet.

4. To open the OMSA Console, click Management Consoles → OMSA Console.

Launching the Remote Access Console (iDRAC)

You can launch the iDRAC user interface from the Dell Server Management Portlet.

1. In the OpenManage Integration for VMware vCenter, in the Navigator area, under Inventory Lists, click Hosts.

2. On the Object tab, double-click the host you want.

3. On the Summary tab, scroll down to the Dell Server Management portlet.

4. Click Management Consoles → Remote Access Console (iDRAC).

Setting Up Physical Server Blink Indicator Light

To assist in locating a physical server in a large datacenter environment, you can set the front indicator light to blink for a set time period.

1. In the OpenManage Integration for VMware vCenter, in the Navigator area, under Inventory Lists, click Hosts.

2. On the Object tab, double-click the host you want.

3. On the Summary tab, scroll down to the Dell Server Management portlet.

4. Under Host Actions, select Blink Indicator Light.

5. Choose one of the following:

• To turn the blink on and set the time period, in the Indicator Light dialog box, click Blink On, and use the Timeout drop-down list to select the timeout increment, and then click OK.

• To turn the blink off, in the Indicator Light dialog box, click Blink Off, and then click OK.

Setting Up Physical Server Blink Indicator Light

To assist in locating a physical server in a large datacenter environment, you can set the front indicator light to blink for a set time period.

1. In the OpenManage Integration for VMware vCenter, in the Navigator area, under Inventory Lists, click Hosts.

2. On the Object tab, double-click the host you want.

3. On the Summary tab, scroll down to the Dell Server Management portlet.

4. Under Host Actions, select Blink Indicator Light.

5. Choose one of the following:

• To turn the blink on and set the time period, in the Indicator Light dialog box, click Blink On, and use the Timeout drop-down list to select the timeout increment, and then click OK.

• To turn the blink off, in the Indicator Light dialog box, click Blink Off, and then click OK.

Buying and Uploading a Software License

You are running a trial license until you upgrade to a full product version. Use a navigate to the Dell website and buy a license. Once you buy it, upload it using the Administration Console. This option only appears if you are using a trial license.

1. In the OpenManage Integration for VMware vCenter. Do one of the following:

• On the Licensing tab, next to Software License, click Buy License.

• On the Getting Started tab, under Basic Tasks, click Buy License.

NOTE: The license will be sent by e-mail as an XML file. For licensing quires send an e-mail with original order number to download_software@dell.com.

2. In the Dell web page, purchase your license and save the file to a known location.

3. In a web browser, type the Administration Console URL.

Use the format: https://<ApplianceIPAddress>

4. In the Administration Console login window, type the password and click Login.

5. Click Upload license.

6. In the Upload License window, to navigate to the license file, click Browse.

7. Select the license file and then click Upload.

Buy License

link from the product to

About OpenManage Integration for VMware vCenter Licensing

The OpenManage Integration for VMware vCenterhas two types of licenses:

Evaluation license

The trial version contains a evaluation license for five hosts (servers) that are managed by the OpenManage Integration for VMware vCenter.This is applicable only for 11G and later generations. This is a default license and is for a 90 days trial period only.

Standard license The full product version contains a standard license for up to ten vCenters and you can

purchase any number of host connections that are managed by the OpenManage Integration for VMware vCenter.

When you upgrade from a evaluation license to a full standard license, a new license XML file is sent to you by e-mail. Save the file to your local system and upload the new license file using the Administration Console. Licensing presents the following information:

• Maximum vCenter Connection Licenses - up to ten registered and in use vCenter connections are allowed.

• Maximum Host Connection Licenses - the number of host connections that were purchased.

• In Use - the number of vCenter connection or host connection licenses in use. For host connection, this number represents the number of hosts (or servers) that have been discovered and inventoried.

• Available - the number of vCenter connection or host connection licenses available for future use.

• Unlicensed Hosts - The number of host connections that exceeded the licensed amount. The OpenManage Integration for VMware vCenter continues to function normally, but a new license must be purchased and installed to resolve this warning

NOTE: The standard license period is for 3 years only and the additional licenses will be appended to the existing license and not over written. You cannot add 9g\10g to a new or existing connection profile if total number of 11g \12g hosts for which inventory ran successfully has reached the blocking number.

Viewing Hardware: FRU Details for a Single Host

View the Field Replaceable Unit (FRU) details for a single host on the Dell Host Information tab. For information to appear on this page, you must run an inventory job. Hardware views are directly reporting the data from OMSA and iDRAC. See

Running an Inventory Job Now.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts.

2. On the Host tab, select the specific host for which you want to view Hardware: FRU details.

3. On the Monitor tab, select the Dell Host Information tab, and on the Hardware: FRU sub-tab, view the following:

Part Name Displays the FRU part name.

Part Number Displays the FRU part number.

Manufacturer Displays the manufacturer’s name.

Serial Number Displays the Manufacturer’s serial number.

Manufacture Date Displays the manufacture date.

Viewing Hardware: Processor Details for a Single Host

View the processor details for a single host on the Dell Host Information tab. For information to appear on this page, you must run an inventory job. Hardware views are directly reporting the data from OMSA and iDRAC. See Running an

Inventory Job Now.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts.

2. On the Object tab, select the specific host for which you want to view processor details.

3. On the Monitor tab, select the Dell Host Information tab, and on the Hardware: Processor sub-tab, view the

following:

Socket Displays the slot number.

Speed Displays the current speed.

Brand Displays the processor brand.

Version Displays the processor version.

Cores Displays the number of cores in this processor.

Viewing Hardware: Power Supply Details for a Single Host

View the virtual power supply details for a single host on the Dell Host Information tab. For information to appear on this page, you must run an inventory job. Hardware views are directly reporting the data from OMSA and iDRAC. See

Running an Inventory Job Now.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts.

2. On the Objects tab, select the specific host for which you want to view Hardware: Power Supply details.

3. On the Monitor tab, select the Dell Host Information tab, and on the Hardware: Power Supply sub-tab, view the

following:

Type Displays the type of power supply. Power supply types include:

• UNKNOWN

• LINEAR

• SWITCHING

• BATTERY

• UPS

• CONVERTER

• REGULATOR

• AC

• DC

• VRM

Location Displays the location of the power supply, such as Slot 1.

Output (Watts) Displays the power in Watts.

Viewing Hardware: Memory Details for a Single Host

View the memory details for a single host on the Dell Host Information tab. For information to appear on this page, you must run an inventory job. Hardware views are directly reporting the data from OMSA and iDRAC. See Running an

Inventory Job Now.

1. In OpenManage Integration for VMware vCenter, in the Navigator, click Hosts.

2. On the Objects tab, select the specific host for which you want to view Hardware: Memory details.

3. On the Monitor tab, select the Dell Host Information tab, and on the Hardware: Memory sub-tab, view the following:

Memory Slots Displays the Used, Total, and Available memory count.

Memory Capacity Displays the Installed Memory, Total Memory Capacity, and Available Memory.

Slot Displays the DIMM slot.

Size Displays the memory size.

Type Displays the memory type.

100

Dell OpenManage Integration for VMware vCenter 2.1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

OpenManage Integration for VMware vCenter Features

Understanding How to Configure or Edit the OpenManage Integration for VMware vCenter

Configuration Wizard Welcome Page

vCenter Selection

Creating A New Connection Profile using the Initial Configuration Wizard

Scheduling Inventory Jobs [Wizard]

Running A Warranty Retrieval Job [Wizard]
