Dell Lifecycle Controller 2 Web Services Interface Guide

Dell Lifecycle Controller Web Services Interface Guide for Windows
A Dell Technical White Paper about the Best Practices to be followed for using the WS-Manbased Remote Services provided by iDRAC and Lifecycle Controller
A Dell Best Practices
Date
Description
August 2013
Initial release
Revisions
Dell, the DELL logo, and the DELL badge are trademarks of Dell Inc. Symantec, NetBackup, and Backup Exec are trademarks of Symantec Corporation in the U.S. and other countries. Microsoft, Windows, and Windows Server are registered trademarks of Microsoft Corporation in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims any proprietary interest in the marks and names of others.
Dell™, the Dell logo, Dell Boomi™, Dell Precision™ ,OptiPlex™, Latitude™, PowerEdge™, PowerVault™, PowerConnect™, OpenManage™, EqualLogic™, Compellent™, KACE™, FlexAddress™, Force10™ and Vostro™ are
trademarks of Dell Inc. Other Dell trademarks may be used in this document. Cisco Nexus®, Cisco MDS®, Cisco NX­0S®, and other Cisco Catalyst® are registered trademarks of Cisco System Inc. EMC VNX®, and EMC Unisphere® are registered trademarks of EMC Corporation. Intel®, Pentium®, Xeon®, Core® and Celeron® are registered trademarks of Intel Corporation in the U.S. and other countries. AMD® is a registered trademark and AMD Opteron™, AMD
Phenom™ and AMD Sempron™ are trademarks of Advanced Micro Devices, Inc. Microsoft®, Windows®, Windows
Server®, Internet Explorer®, MS-DOS®, Windows Vista® and Active Directory® are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat® and Red Hat® Enterprise Linux® are registered trademarks of Red Hat, Inc. in the United States and/or other countries. Novell® and SUSE® are registered trademarks of Novell Inc. in the United States and other countries. Oracle® is a registered trademark of Oracle Corporation and/or its affiliates. Citrix®, Xen®, XenServer® and XenMotion® are either registered trademarks or trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter® and vSphere® are registered trademarks or trademarks of VMware, Inc. in the United States or other countries. IBM® is a registered trademark of International Business Machines Corporation. Broadcom® and NetXtreme® are registered trademarks of Broadcom Corporation. Qlogic is a registered trademark of QLogic Corporation. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and/or names or their products and are the property of their respective owners. Dell disclaims proprietary interest in the marks and names of others.
2 Dell Lifecycle Controller Web Services Interface Guide for Windows
3 Dell Lifecycle Controller Web Services Interface Guide for Windows
Contents
Revisions ............................................................................................................................................................................................. 2
Executive Summary ........................................................................................................................................................................ 14
1 Introduction .............................................................................................................................................................................. 15
2 References ................................................................................................................................................................................ 16
3 Overview.................................................................................................................................................................................... 17
3.1 Format for WinRM CLI Examples in Document....................................................................................................... 17
3.2 WS-Man Security and Time Parameters ................................................................................................................... 18
3.2.1 Encryption Certificate Security ................................................................................................................................... 18
3.2.2 Handling Invalid Responses from WS-Man Commands ........................................................................................ 18
3.2.3 Improving WinRM Enumeration Performance ........................................................................................................ 19
3.2.4 Specifying StartTime, Until Time, and TIME_NOW Parameters ........................................................................... 19
3.2.5 Return Values ................................................................................................................................................................. 20
3.2.6 Glossary .......................................................................................................................................................................... 20
4 Discovery ................................................................................................................................................................................... 22
4.1 Discovering Web Service Capability .......................................................................................................................... 22
4.2 Discovering the Implemented Profiles ...................................................................................................................... 22
4.3 Discovering Implementation Namespace ................................................................................................................ 23
5 Managing iDRAC Local User Accounts ................................................................................................................................ 26
5.1 Description of iDRAC Attributes Versus Standard DMTF Model ........................................................................... 26
5.2 Account Inventory (Using iDRAC Attributes) ............................................................................................................ 26
5.2.1 Account and Capabilities (Using iDRAC Attributes) ................................................................................................ 26
5.2.2 Privilege and Capabilities (Using iDRAC Attributes) ................................................................................................ 28
5.3 Manage Account Settings (Using iDRAC Attributes) ............................................................................................... 29
5.3.1 Modify User Name (Using iDRAC Attributes) ........................................................................................................... 29
5.3.2 Modify Password (Using iDRAC Attributes) .............................................................................................................. 30
5.3.3 Modify Account State (Using iDRAC Attributes) ...................................................................................................... 31
5.3.4 Modify User Privilege (Using iDRAC Attributes) ....................................................................................................... 32
5.4 Account Inventory (Using DMTF Model) ................................................................................................................... 33
5.4.1 Account and Capabilities (Using DMTF Model) ....................................................................................................... 34
5.4.2 Privilege and Capabilities (Using DMTF Model) ....................................................................................................... 37
5.5 Manage Account Settings (Using DMTF Model) ..................................................................................................... 40
4 Dell Lifecycle Controller Web Services Interface Guide for Windows
5.5.1 Modify User Name (Using DMTF Model) ................................................................................................................. 40
5.5.2 Modify Password (Using DMTF Model) ..................................................................................................................... 43
5.5.3 Modify Account State (Using DMTF Model) ............................................................................................................. 44
5.5.4 Modify User Privilege (Using DMTF Model) .............................................................................................................. 45
6 Firmware Inventory ................................................................................................................................................................. 47
6.1 Software Inventory Profile Specification ................................................................................................................... 47
6.2 Remote Inventory Method Invocation Get Software Inventory ...................................................................... 47
7 Firmware Update ..................................................................................................................................................................... 49
7.1 Software Update Profile Specification....................................................................................................................... 49
7.2 ”Rollback” Firmware ...................................................................................................................................................... 49
7.2.1 Request “Rollback” Image ............................................................................................................................................ 49
7.2.2 Create Reboot Job ....................................................................................................................................................... 49
7.2.3 Schedule Update Jobs ................................................................................................................................................. 49
7.2.4 Monitor Update Jobs .................................................................................................................................................... 49
7.3 BIOS Firmware “Rollback” ............................................................................................................................................ 51
7.4 NIC Firmware “Rollback” .............................................................................................................................................. 52
7.5 Update from Network Source .................................................................................................................................... 54
7.5.1 Request Update Download ......................................................................................................................................... 54
7.5.2 Monitor Download Status ............................................................................................................................................ 54
7.5.3 Reboot to Perform Update .......................................................................................................................................... 54
7.5.4 Wait for Job Completion ............................................................................................................................................. 54
7.5.5 Delete Job ...................................................................................................................................................................... 54
7.6 Update NICs from HTTP, CIFS Share, NFS Share, TFTP, or FTP ........................................................................... 54
7.7 Update BIOS from HTTP, CIFS Share, NFS Share, TFTP, or FTP ........................................................................... 57
7.8 CreateRebootJob() ....................................................................................................................................................... 59
7.9 Automatic Updates ....................................................................................................................................................... 61
7.9.1 Enable Automatic Update ............................................................................................................................................ 61
7.9.2 Create a Config Job ..................................................................................................................................................... 61
7.9.3 Set Update Schedule .................................................................................................................................................... 62
7.9.4 Get the Update Schedule ............................................................................................................................................ 63
7.9.5 Clear the Update Schedule ......................................................................................................................................... 63
7.10 Device Update from Repository ................................................................................................................................. 64
5 Dell Lifecycle Controller Web Services Interface Guide for Windows
7.10.1 Install from Repository ................................................................................................................................................. 64
7.10.2 Get Repo-Based Update List ....................................................................................................................................... 65
8 Power State Management ...................................................................................................................................................... 69
8.1 Description of Base Server Versus Power State Management Methods ............................................................. 69
8.2 Get Power State ............................................................................................................................................................ 69
8.2.1 Base Server Method ...................................................................................................................................................... 69
8.2.2 Power State Management Method ............................................................................................................................ 70
8.3 Get Power Control Capabilites ................................................................................................................................... 71
8.3.1 Base Server Method ...................................................................................................................................................... 71
8.3.2 Power State Management Method ............................................................................................................................ 73
8.4 Power Control ............................................................................................................................................................... 75
8.4.1 Base Server Method ...................................................................................................................................................... 75
8.4.2 Power State Management Method ............................................................................................................................ 76
9 Hardware Inventory ................................................................................................................................................................. 77
9.1 Power Supply Inventory ............................................................................................................................................... 77
9.2 Fan Inventory ................................................................................................................................................................. 78
9.3 Memory Inventory ........................................................................................................................................................ 80
9.4 CPU Inventory................................................................................................................................................................ 82
9.5 iDRAC Card Inventory .................................................................................................................................................. 84
9.6 PCI Device Inventory .................................................................................................................................................... 85
9.7 Video Inventory ............................................................................................................................................................. 87
9.8 VFlash SD Card Inventory ............................................................................................................................................ 88
9.9 NIC Inventory and Configuration ............................................................................................................................... 89
9.10 RAID Inventory and Configuration ............................................................................................................................. 91
9.11 BIOS Inventory and Configuration ............................................................................................................................. 93
9.12 System Inventory (Including CSIOR Attribute) ......................................................................................................... 95
10 Job Control Management ...................................................................................................................................................... 98
10.1 Description of Job Management ............................................................................................................................... 98
10.2 Remote Job Control Examples .................................................................................................................................. 98
10.2.1 Setup Job Queue .......................................................................................................................................................... 98
10.2.2 Delete Job Queue ..................................................................................................................................................100
10.2.3 List Jobs in Job Store ............................................................................................................................................ 101
6 Dell Lifecycle Controller Web Services Interface Guide for Windows
11 Operating System Deployment ........................................................................................................................................... 104
11.1 OS Deployment Profile Implementation Conformance ...................................................................................... 104
11.2 Checking OS Deployment Service Availability ....................................................................................................... 104
11.3 OS Deployment Method Invocation Examples ..................................................................................................... 105
11.3.1 Get Driver Pack Information ..................................................................................................................................... 105
11.3.2 Unpack Selected Drivers and Attach to Host OS as USB Device ....................................................................... 106
11.3.3 Detach Emulated USB Device Containing Drivers ................................................................................................ 107
11.3.4 Unpack Selected Drivers and Copy to Network Share ........................................................................................ 107
11.3.5 Check Job Status ........................................................................................................................................................ 109
11.3.6 Boot to Network ISO .................................................................................................................................................. 110
11.3.7 Detach Network ISO USB Device .............................................................................................................................. 111
11.3.8 Boot To PXE ................................................................................................................................................................. 112
11.3.9 Get Host MAC Address Information ........................................................................................................................ 112
11.3.10 Download ISO to VFlash ................................................................................................................................... 113
11.3.11 Boot to ISO from VFlash ................................................................................................................................... 114
11.3.12 Delete ISO from VFlash ..................................................................................................................................... 115
11.3.13 Detach ISO from VFlash ................................................................................................................................... 115
11.3.14 Connect Network ISO Image .......................................................................................................................... 116
11.3.15 Disconnect Network ISO Image ...................................................................................................................... 117
11.3.16 Skip ISO Image Boot .......................................................................................................................................... 118
11.3.17 Get Network ISO Image Connection Information ....................................................................................... 119
11.3.18 Connect RFS ISO Image ................................................................................................................................... 119
11.3.19 Disconnect RFS ISO Image .............................................................................................................................. 120
11.3.20 Get RFS ISO Image Connection Information ............................................................................................... 121
11.3.21 Boot To Hard Disk Drive (HDD) ....................................................................................................................... 122
11.3.22 Configurable Boot to Network ISO ................................................................................................................ 122
12 Lifecycle Controller Management Profile ......................................................................................................................... 124
12.1 Collect System Inventory on Restart (CSIOR) ........................................................................................................ 124
12.2 Part Replacement Configuration and Management ............................................................................................. 126
12.2.1 Create Config Job ...................................................................................................................................................... 126
12.2.2 Get LC Config Job Status .......................................................................................................................................... 127
12.2.3 List All LC Jobs ............................................................................................................................................................. 127
7 Dell Lifecycle Controller Web Services Interface Guide for Windows
12.2.4 Get CSIOR Component Configuration Recovery (CCR) Attribute ..................................................................... 128
12.2.5 Get Part Firmware Update Attribute ........................................................................................................................ 129
12.3 Re-Initiate Auto-Discovery Client ............................................................................................................................ 130
12.4 Clear or Set Provisioning Server ............................................................................................................................... 131
12.5 Check vFlash License Enablement........................................................................................................................... 132
12.6 Download Server Public Key ..................................................................................................................................... 133
12.7 Download Client Certificates .................................................................................................................................... 134
12.8 Delete Auto-Discovery Client Certificates ............................................................................................................. 136
12.9 Set Public Certificates ................................................................................................................................................ 136
12.10 Set iDRAC Certificate and Private Key ..................................................................................................................... 138
12.11 Delete Auto-Discovery Server Public Key .............................................................................................................. 139
12.12 Insert Comment in Lifecycle Controller Log ......................................................................................................... 139
12.13 Export Lifecycle Controller Log ................................................................................................................................ 140
12.14 ExportCompleteLCLog() ............................................................................................................................................ 141
12.15 Export Hardware Inventory from Lifecycle Controller ......................................................................................... 143
12.16 Export Factory Configuration ................................................................................................................................... 144
12.17 System Decommission .............................................................................................................................................. 146
12.18 Get Remote Services API Status ............................................................................................................................... 146
12.19 Export System Configuration .................................................................................................................................... 147
12.20 Import System Configuration ................................................................................................................................... 148
12.21 XML Template Preview ............................................................................................................................................... 149
12.22 Remote Diagnostics ................................................................................................................................................... 151
12.22.1 Run Diagnostics ................................................................................................................................................. 151
12.22.2 Export Diagnostics Results ............................................................................................................................... 151
12.22.3 Verify the Diagnostics Job Status: .................................................................................................................. 152
13 VFlash SD Card Management .............................................................................................................................................. 154
13.1 Listing the SD Card Partitions ................................................................................................................................... 154
13.2 Initialize the Virtual Flash Media ............................................................................................................................... 155
13.2.1 Get vFlash SD Card Inventory ................................................................................................................................... 155
13.2.2 Initialize or Format Media .......................................................................................................................................... 156
13.2.3 Verify Initialization or Formatting ............................................................................................................................. 157
13.3 Enable or Disable vFlash using vFlash State Change ............................................................................................ 158
8 Dell Lifecycle Controller Web Services Interface Guide for Windows
13.4 Create Partition ........................................................................................................................................................... 158
13.5 Create Partition using Image .................................................................................................................................... 160
13.6 Delete Partition ............................................................................................................................................................ 162
13.7 Format Partition ........................................................................................................................................................... 163
13.8 Modify Partition ........................................................................................................................................................... 164
13.9 Attach Partition ............................................................................................................................................................ 165
13.10 Detach Partition........................................................................................................................................................... 166
13.11 Export Data from Partition ........................................................................................................................................ 168
14 Boot Control Configuration Management ......................................................................................................................... 171
14.1 Listing the Boot Inventory-ConfigSetting Class ..................................................................................................... 171
14.2 Getting a Boot ConfigSetting Instance ................................................................................................................... 172
14.3 Listing the Boot Inventory-SourceSetting Class ................................................................................................... 173
14.4 Changing the Boot Order by InstanceID-ChangeBootOrderByInstanceID() .................................................. 174
14.5 Enable or Disable the Boot Source-ChangeBootSourceState() ......................................................................... 175
15 NIC or CNA Card Management .......................................................................................................................................... 177
15.1 Listing the NIC or CNA Inventory-Enumeration Class ......................................................................................... 177
15.2 Listing the NIC or CNA Inventory-String Class ...................................................................................................... 179
15.3 Listing the CNA Inventory-Integer Class ................................................................................................................ 182
15.4 Listing the CNA Inventory-NICView Class ............................................................................................................. 184
15.5 Listing the CNA Inventory-NICCapabilities Class.................................................................................................. 187
15.6 Listing the CNA Inventory- NICStatistics Class ..................................................................................................... 189
15.7 Applying the Pending Values for CNA-CreateTargetedConfigJob() ................................................................. 191
15.8 Deleting the Pending Values for CNA-DeletePendingConfiguration() ............................................................. 192
15.9 Getting the CNA Enumeration Instance ................................................................................................................. 193
15.10 Setting the IscsiOffloadMode Attribute ................................................................................................................... 194
15.11 Setting the MaxBandwidth Attribute ........................................................................................................................ 195
15.12 Setting the VirtMacAddr Attribute ............................................................................................................................ 196
15.13 Setting the LegacyBootProto Attribute ................................................................................................................... 197
15.14 Setting CNA LAN Modes ............................................................................................................................................ 199
15.15 Setting the iSCSI Boot Target................................................................................................................................... 200
15.16 Setting the FCoE Boot Target ................................................................................................................................... 201
16 RAID Storage Management ................................................................................................................................................. 203
9 Dell Lifecycle Controller Web Services Interface Guide for Windows
16.1 Listing the RAID Inventory-Enumeration Class .................................................................................................... 203
16.2 Getting a RAID Enumeration Instance ................................................................................................................... 205
16.3 Listing the RAID Inventory-Integer Class ............................................................................................................... 206
16.4 Getting a RAID Integer Instance .............................................................................................................................. 208
16.5 Listing the RAID Inventory-String Class ................................................................................................................. 208
16.6 Getting a RAID String Instance ................................................................................................................................. 210
16.7 Listing the RAID Inventory-ControllerView Class ................................................................................................. 210
16.8 Getting a RAID ControllerView Instance................................................................................................................. 212
16.9 Listing the RAID Inventory-PhysicalDiskView Class .............................................................................................. 213
16.10 Listing the RAID VirtualDiskView Inventory ............................................................................................................ 216
16.11 Listing the RAID EnclosureView Inventory ............................................................................................................. 219
16.12 Reset Configuration-ResetConfig() ........................................................................................................................ 220
16.13 Clearing the Foreign Configuration-ClearForeignConfig() ................................................................................ 220
16.14 Applying the Pending Values for RAID-CreateTargetedConfigJob() ................................................................. 221
16.15 Deleting the Pending Values for RAID-DeletePendingConfiguration() ............................................................. 223
16.16 Managing Hot Spare .................................................................................................................................................. 224
16.16.1 Determining Potential Disks-GetDHSDisks() ............................................................................................... 224
16.16.2 Assigning the Hot Spare-AssignSpare() .......................................................................................................... 225
16.16.3 Unassigning the Hot Spare-UnassignSpare() ............................................................................................... 226
16.17 Managing Keys for Self Encrypting Drives ............................................................................................................. 226
16.17.1 Setting the Key-SetControllerKey() ................................................................................................................. 227
16.17.2 Locking the Virtual Disk-LockVirtualDisk() ................................................................................................... 228
16.17.3 Locking the Controller with a Key-EnableControllerEncryption() ........................................................... 228
16.17.4 Rekeying the Controller-ReKey() ................................................................................................................... 230
16.17.5 Removing the Key-RemoveControllerKey() .................................................................................................. 231
16.18 Managing Virtual Disk ................................................................................................................................................. 232
16.18.1 Getting the Available RAID levels-GetRAIDLevels() ..................................................................................... 232
16.18.2 Getting the Available Disks-GetAvailableDisks() .......................................................................................... 234
16.18.3 Checking the Create VD Parameters Validity-CheckVDValues() .............................................................. 235
16.18.4 Creating a Single Virtual Disk-CreateVirtualDisk() ...................................................................................... 236
16.18.5 Creating a Sliced Virtual Disk-CreateVirtualDisk() ........................................................................................239
16.18.6 Creating a Cachecade Virtual Disk-CreateVirtualDisk() ............................................................................. 242
10 Dell Lifecycle Controller Web Services Interface Guide for Windows
16.18.7 Deleting a Virtual Disk-DeleteVirtualDisk() ................................................................................................... 243
16.19 Setting Controller Attributes .................................................................................................................................... 244
16.19.1 Changing the Value of a RAID Controller Enumeration Attribute ........................................................... 244
16.19.2 Changing Multiple Values of RAID Controller Enumeration Attributes....................................................245
16.19.3 Changing the Value of a RAID Controller Integer Attribute ...................................................................... 246
16.19.4 Changing Multiple Values of RAID Controller Integer Attributes .............................................................. 247
16.20 Convert Physical Disks to RAID-ConvertToRAID() ............................................................................................... 248
16.21 Convert Physical Disks to Non RAID-ConvertToNonRAID() .............................................................................. 249
17 Managing BIOS Configuration............................................................................................................................................. 251
17.1 Listing the BIOS Inventory-Enumeration Class ..................................................................................................... 251
17.2 Getting a BIOS Enumeration Instance .................................................................................................................... 253
17.3 Changing the BIOS BootMode-SetAttribute()........................................................................................................ 253
17.4 Setting Multiple BIOS BootMode Parameters ........................................................................................................254
17.5 Listing the BIOS Inventory-Integer Class ................................................................................................................ 255
17.6 Listing the BIOS Inventory-String Class ..................................................................................................................256
17.7 Applying the Pending Values for BIOS & Boot-CreateTargetedConfigJob() ................................................... 257
17.8 Deleting the Pending Values for BIOS & Boot-DeletePendingConfiguration() ...............................................259
17.9 Managing BIOS Passwords ....................................................................................................................................... 260
17.9.1 Setting the BIOS Password ....................................................................................................................................... 260
17.9.2 Create Target Configuration Job ............................................................................................................................. 261
17.9.3 Monitor Set BIOS Password Status ......................................................................................................................... 262
17.10 Listing the BIOS Inventory-Password Class .......................................................................................................... 262
18 Exporting and Importing Server Profile .............................................................................................................................265
18.1 Exporting Server Profile .............................................................................................................................................265
18.1.1 Exporting Server Profile to iDRAC vFlash Card-BackupImage() .........................................................................265
18.1.2 Exporting Server Profile to NFS Share-BackupImage() ....................................................................................... 266
18.1.3 Exporting Server Profile to CIFS Share-BackupImage() ...................................................................................... 266
18.1.4 Monitoring Export status ........................................................................................................................................... 267
18.2 Automatic Backup ...................................................................................................................................................... 268
18.2.1 Enable the Automatic Backup ................................................................................................................................. 268
18.2.2 Set Backup Schedule ................................................................................................................................................. 269
18.2.3 Get the Backup Schedule ......................................................................................................................................... 269
11 Dell Lifecycle Controller Web Services Interface Guide for Windows
18.2.4 Clear the Backup Schedule ..................................................................................................................................270
18.3 Importing Server Profile .............................................................................................................................................270
18.3.1 Importing Server Profile from iDRAC vFlash Card-RestoreImage() ...................................................................270
18.3.2 Importing Server Profile from NFS share-RestoreImage() ................................................................................... 271
18.3.3 Importing Server Profile from CIFS share-RestoreImage() .................................................................................. 271
18.3.4 Monitoring Import Status ...................................................................................................................................... 272
19 iDRAC Configuration ............................................................................................................................................................. 274
19.1 Listing the iDRAC Card Inventory-Enumeration Class ......................................................................................... 274
19.2 Getting an iDRAC Card Enumeration Instance ...................................................................................................... 276
19.3 Listing the iDRAC Card Inventory-Enumeration Class using groupID .............................................................. 277
19.4 Applying the Attributes and Polling Job Completion .......................................................................................... 280
19.4.1 Changing iDRAC Values-ApplyAttributes() (Immediate) ..................................................................................... 280
19.4.2 Polling Job Completion ....................................................................................................................................... 282
19.4.3 Set Attribute Verification ...................................................................................................................................... 282
19.5 Listing the iDRAC Card Inventory-Integer Class .................................................................................................. 285
19.6 Listing the iDRAC Card Inventory-Integer Class using groupID........................................................................ 286
19.7 Listing the iDRAC Card Inventory-String Class ..................................................................................................... 288
19.8 Listing the iDRAC Card Inventory-String Class using groupID .......................................................................... 289
19.9 Changing the iDRAC IP Change Notification........................................................................................................ 292
19.9.1 Getting the Current iDRAC IPChange State .......................................................................................................... 292
19.9.2 Setting the iDRAC IPChange Notification-SetAttribute() ............................................................................... 292
20 Remote Service Status ......................................................................................................................................................... 294
20.1 Getting Remote Service Status ................................................................................................................................ 294
20.2 Restarting Remote Service Status ........................................................................................................................... 296
21 System Information .............................................................................................................................................................. 298
21.1 Listing the System Inventory-SystemView Class .................................................................................................. 298
22 Sensor Information ................................................................................................................................................................ 301
22.1 Listing the Sensors Inventory-PSNumericSensor Class ....................................................................................... 301
23 Managing Fiber Channel (FC) Configuration ................................................................................................................... 305
23.1 Listing the FC Inventory-Attribute Class ................................................................................................................ 305
23.2 Listing the FC Inventory-Statistics Class ................................................................................................................ 306
23.3 Listing the FC Inventory-String Class ..................................................................................................................... 308
12 Dell Lifecycle Controller Web Services Interface Guide for Windows
23.4 Listing the FC Inventory-Integer Class ................................................................................................................... 309
23.5 Listing the FC Inventory-Enumeration Class ........................................................................................................ 309
23.6 Changing the FC Attributes-SetAttribute() ............................................................................................................. 310
23.7 Applying the Pending Values for FC-CreateTargetedConfigJob() ..................................................................... 311
23.8 Deleting the Pending Values for FC-DeletePendingConfiguration() ................................................................. 313
23.9 Listing the FC Views .................................................................................................................................................... 314
13 Dell Lifecycle Controller Web Services Interface Guide for Windows
Executive Summary
Dell PowerEdge servers are equipped with the integrated Dell Remote Access Controller and the Lifecycle Controller solution for remote managementiDRAC6 on 11th generation servers and iDRAC7 on 12th generation servers. These servers can be remotely managed by using the WS-Man services for configuration, update, deployment, and maintenance. This whitepaper describes the various WS-Man interfaces with examples about using different interfaces in a Windows environment.
14 Dell Lifecycle Controller Web Services Interface Guide for Windows
1 Introduction
This document serves as a guideline for utilizing the functionality available from embedded Lifecycle Controller Remote Enablement Web Services interfaces. The purpose of this document is to provide information and examples for utilizing the Web services for Management (WS-Man) management protocol using Windows WinRM and open source WSMANCLI command line utilities. Examples and invocation information is provided for the following functionality.
Inventory for BIOS, component firmware and embedded software Update of BIOS, component firmware and embedded software Job Control of update tasks Enhancement of Operating System Deployment using VFlash SD Card Enhancement of Discovery and Handshake from LifeCycle Controller 1.x RAID configuration management iDRAC Inventory and configuration features NIC configuration management Boot configuration management BIOS configuration management
The target audience for this document is application and script writers who want to utilize the remote management capabilities using WS-Man protocol available from Dell Lifecycle Controller.
15 Dell Lifecycle Controller Web Services Interface Guide for Windows
2 References
Dell 12th generation PowerEdge server resources:
http://www.delltechcenter.com/12thGen
Dell CIM Profiles:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Managed Object Format (MOF) files:
http://www.delltechcenter.com/page/DCIM.Library.MOF
WinRM Scripting API, MSDN:
http://msdn.microsoft.com/en-us/library/aa384469(VS.85).aspx
Openwsman CLI:
http://www.openwsman.org/project/wsmancli
DMTF Common Information Model (CIM) Infrastructure Specification (DSP0004):
http://www.dmtf.org/standards/published_documents/DSP0004_2.5.0.pdf
List of PCI IDs:
http://pciids.sourceforge.net/pci.ids
16 Dell Lifecycle Controller Web Services Interface Guide for Windows
3 Overview
The remote interface guidelines provided in this document are illustrated by command line interface (CLI) examples of the WS-Man protocol Web services APIs that expose the remote management capabilities of the Dell Lifecycle Controller. The command line examples are from the Microsoft® Windows® and Linux
environments using WinRM management capabilities are organized by management domain and documented in Dell CIM Profile
specifications capabilities:
Remotely get inventory of the BIOS, component firmware, and embedded software including
version information of both the installed as well as available cached versions
Remote update of BIOS, component firmware, Diagnostic content, DRAC content, driver pack,
power supplies from remotely located Dell Update Packages or cached images located in the Lifecycle Controller
Remotely schedule and track the status of update tasks (jobs) Remotely manage the Part Replacement feature by allowing retrieving and setting auto update and
auto system inventory sync
Enable re-initiation of Lifecycle Controller Auto-Discovery feature Enhancement of Operation System Deployment capabilities by supporting the downloading of an
ISO image to a Dell VFlash SD Card and booting to the ISO image on the VFlash SD Card
NIC configuration enables the ability to get and set NIC attributes that are configurable using NIC
Option ROM or NIC UEFI HII.
Remote RAID configuration allows users to remotely query and configure the Hardware Raid of the
system
Multiple HW Inventory views allows users to remote query the inventory of Hardware
2
.. The remote enablement feature for Lifecycle Controller 2.0 provides the following
4
and WSMANCLI
5
respectively. The Lifecycle Controller remote
3.1 Format for WinRM CLI Examples in Document
The examples of WinRM and WSMANCLI command line invocations in this document are formatted for readability and often span multiple lines in the document. In actual use, scripted or hand-typed invocations are contained on one line. The examples also use substitute values for the target iDRAC IP address, username (with ExecuteServerCommand privilege), password and other site specific information. Actual use of these examples would require using values for IP Address, username and password, etc. that are valid. These values are represented in the examples as follows:
Target iDRAC IP address = [IPADDRESS]
iDRAC Username = [USER]
iDRAC Password = [PASSWORD]
Additional substitute values are used in some of the examples and are described in the specific example. The following example is typical of the formatting used in this document:
17 Dell Lifecycle Controller Web Services Interface Guide for Windows
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_OSDeploymentService
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443
-encoding:utf-8 -a:basic
3.2 WS-Man Security and Time Parameters
3.2.1 Encryption Certificate Security
For the WinRM examples provided in this document, the strict checks of certificates such as matching of CNs (Common Names) and verification with the actual CA (Certificate Authority) of the certificate of the WS-Management protocol HTTPS encryption certificate is assumed to be already configured and enabled. To disable the strict certificate checking, add the following command line options to all WinRM examples: –skipCACheck and -skipCNCHeck.
Additionally, the following error may result if the end point does not support this feature. Use the switch ­skiprevocationcheck to bypass this error.
WSManFault
Message = The server certificate on the destination computer (10.35.0.232:443) has the following errors:
The SSL certificate could not be checked for revocation. The server used to check for revocation might be unreachable.
Refer to the WinRM documentation 4 and related documentation for directions on setting up encryption certificates for WinRM and executing WinRM invocations using full security capabilities. Refer to the Lifecycle Controller User Guide 1 for directions on configuring different encryption certificates for the iDRAC Web server. Dell recommends that the full security and encryption capabilities of the WS­Management protocol is used for production level utilization of the Lifecycle Controller Web services interfaces.
3.2.2 Handling Invalid Responses from WS-Man Commands
Check the network connection to make sure that the system is connected Check the WS-Man syntax to ensure there are no typos in the command line Check if there are other WS-Man commands sending from other systems Wait for a few seconds and re-try the WSMAN command
18 Dell Lifecycle Controller Web Services Interface Guide for Windows
3.2.3 Improving WinRM Enumeration Performance
When an enumeration command is executed, the default WinRM configuration gets only 20 instances at a time and therefore slows down the system drastically. Changing the WinRM configuration to allow a greater number, such as 50, will reduce the time taken by the enumeration operations.
Execute the following command to get instances in groups of up to 50.
winrm set winrm/config @{MaxBatchItems="50"}
Additionally, increasing the allotted maximum envelope size and timeout can also increase performance.
winrm set winrm/config @{MaxEnvelopeSizekb="150"}
winrm set winrm/config @{MaxTimeoutms ="60000"}
Other optional WinRM configuration commands are listed below for convenience. To get the current WinRM configuration settings, execute the following command.
winrm g winrm/config
By default, the client computer requires encrypted network traffic. To allow the client computer to request unencrypted traffic, execute the following command:
winrm s winrm/config/Client @{AllowUnencrypted="true"}
TrustedHosts is an array that specifies the list of remote computers that are trusted. Other computers in a workgroup or computers in a different domain should be added to this list.
Note: The computers in the TrustedHosts list are not authenticated.
Execute the following command to allow all computers to be included in TrustedHosts.
winrm s winrm/config/Client @{TrustedHosts="*"}
Basic authentication is a scheme in which the user name and password are sent in clear text to the server or proxy. This method is the least secure method of authentication. The default is True.
Execute the following command to set client computer to use Basic authentication.
winrm s winrm/config/Client/Auth @{Basic="true"}
3.2.4 Specifying StartTime, Until Time, and TIME_NOW Parameters
The several methods that attach a virtual USB device to the target system accept a StartTime and Until parameter. The parameter data type is CIM date-time. If the StartTime parameter is null the action will not be started. If the Until parameter is null, the default value will be 17 hours. The date-time data type is defined in the CIM Infrastructure Specification 4 as:
19 Dell Lifecycle Controller Web Services Interface Guide for Windows
Term
Meaning
BIOS
Basic Input / Output System
HW
Hardware
iDRAC
Integrated DELL Remote Access Controller
IPL
Initial Program Load
DUP
Dell Update Package
MOF
Managed Object File
CIM
Common Information Model
NIC
Network Interface Controller
RAID
Redundant Array of Independent Disks
FQDD
Fully Qualified Device Description
ddddddddhhmmss.mmmmmm
Where:
dddddddd is the number of days hh is the remaining number of hours mm is the remaining number of minutes ss is the remaining number of seconds mmmmmm is the remaining number of microseconds
The Lifecycle controller firmware update, and set attribute related methods that require a date time parameter, use the form YYYYMMDDhhmmss (Eg. 20090930112030). The user is expected to enter the date and time in this format for all Lifecycle Controller updates and set attribute tasks. TIME_NOW is a special value that represents “running the tasks immediately”.
3.2.5 Return Values
Many of the methods in this document have the following possible return values. They are summarized here for convenience.
0 = Success
1 = Not Supported
2 = Failed
4096 = Job Created
3.2.6 Glossary
20 Dell Lifecycle Controller Web Services Interface Guide for Windows
UEFI
Unified Extensible Firmware Interface
AMEA
Advanced Management Enablement Adapter
HII
Human Interface Infrastructure
WS-Man
WS-Management is a specification of a SOAP-based protocol for the management of servers, devices, applications and more
21 Dell Lifecycle Controller Web Services Interface Guide for Windows
4 Discovery
4.1 Discovering Web Service Capability
Determine if the target system supports the WinRM interface using the ‘identify’ command.
Profiles: http://www.dmtf.org/sites/default/files/standards/documents/DSP0217_2.0.0.pdf
EXAMPLE:
winrm identify
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman
-SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
IdentifyResponse
ProtocolVersion = http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd
ProductVendor = Openwsman Project
ProductVersion = 2.2.4
4.2 Discovering the Implemented Profiles
Implemented profiles are advertised using the class CIM_RegisteredProfile. Enumerate this class in the “root/interop” CIM namespace.
Profiles: http://www.dmtf.org/sites/default/files/standards/documents/DSP1033_1.0.0.pdf
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/CIM_RegisteredProfile?__cimnamespace=root/interop -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_LCRegisteredProfile
AdvertiseTypeDescriptions = WS-Identify, Interop Namespace AdvertiseTypes = 1, 1
InstanceID = DCIM:Memory:1.0.0
22 Dell Lifecycle Controller Web Services Interface Guide for Windows
OtherRegisteredOrganization = DCIM
RegisteredName = Memory
RegisteredOrganization = 1
RegisteredVersion = 1.0.0
...
DCIM_RegisteredProfile
AdvertiseTypeDescriptions = WS-Identify
AdvertiseTypes = 1
Caption = null
Description = null
ElementName = null
InstanceID = DCIM:CSRegisteredProfile:1 OtherRegisteredOrganization = null
RegisteredName = Base Server
RegisteredOrganization = 2
RegisteredVersion = 1.0.0
.
.
The above example shows that the DMTF Base Server profile version 1.0.0 is implemented.
4.3 Discovering Implementation Namespace
The implementation CIM namespace may be discovered from the interop (root/interop) CIM namespace using the class CIM_ElementConformsToProfile that associates an instance of CIM_RegisteredProfile class with an instance of CIM_ComputerSystem class.
Profiles: n/a
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/* -dialect:association
-associations - filter: {object=DCIM_ComputerSystem?CreationClassName=DCIM_ComputerSystem+Name=srv:syste m+__cimna mespace=root/dcim}
23 Dell Lifecycle Controller Web Services Interface Guide for Windows
-u:[USER] -p:[PASSWORD] -r:https://[IPADDRESS]/wsman -encoding:utf-8 -a:basic ­SkipCNcheck –SkipCAcheck
OUTPUT:
DCIM_CSRoleLimitedToTarget
DefiningRole
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Role
SelectorSet
Selector: CreationClassName = DCIM_Role, Name = DCIM:Role:9, __cimnamespace = root/dcim
TargetElement
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim- schema/2/DCIM_ComputerSystem
SelectorSet
Selector: CreationClassName = DCIM_ComputerSystem, Name = srv:system, __cimnamespace = root/dcim
DCIM_CSRoleLimitedToTarget
DefiningRole
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Role SelectorSet
Selector: CreationClassName = DCIM_Role, Name = DCIM:R ole:10, __cimnamespace = root/dcim TargetElement
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
24 Dell Lifecycle Controller Web Services Interface Guide for Windows
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim- schema/2/DCIM_ComputerSystem
SelectorSet
Selector: CreationClassName = DCIM_ComputerSystem, Name = srv:system, __cimnamespace = root/dcim
25 Dell Lifecycle Controller Web Services Interface Guide for Windows
5 Managing iDRAC Local User Accounts
5.1 Description of iDRAC Attributes Versus Standard DMTF Model
The iDRAC user account management data model is represented by both DMTF and Dell Profiles. Both models are currently offered. The DMTF Profiles for Simple Identity Management and Role Based Authorization represent iDRAC user accounts and privileges. The DMTF data model is complex and typically requires multiple transactions to accomplish simple operations such as specifying a username and password or giving a user account admin privileges. For this reason, LC also offers a Dell data model for managing iDRAC user accounts that is based on an attribute model. The DCIM iDRAC Card Profile specifies the attributes for each user account name, password, and privilege. The iDRAC has 15 local user account that can be managed.
5.2 Account Inventory (Using iDRAC Attributes)
The list of user accounts may be retrieved by enumerating the DCIM_iDRACCard classes. The class provides the user account name and enabled state properties.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
5.2.1 Account and Capabilities (Using iDRAC Attributes)
Enumerating the DCIM_iDRACCardEnumeration class, Section 19.1, and parsing the output for the attribute AttributeDisplayName = User Admin Enable, will display all of the 16 possible user accounts and their respective status.
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_iDRACCardEnumeration -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -SkipCNcheck -SkipCAcheck -encoding:utf-8 ­a:basic
OUTPUT:
DCIM_iDRACCardEnumeration
AttributeDisplayName = User Admin Enable
AttributeName = Enable
CurrentValue = Disabled
DefaultValue = Disabled
26 Dell Lifecycle Controller Web Services Interface Guide for Windows
Dependency = null
DisplayOrder = 0
FQDD = iDRAC.Embedded.1
GroupDisplayName = Users
GroupID = Users.1
InstanceID = iDRAC.Embedded.1#Users.1#Enable
IsReadOnly = true
PossibleValues = Disabled, Enabled
DCIM_iDRACCardEnumeration
AttributeDisplayName = User Admin Enable
AttributeName = Enable
CurrentValue = Enabled
DefaultValue = Enabled
Dependency = null
DisplayOrder = 0
FQDD = iDRAC.Embedded.1
GroupDisplayName = Users
GroupID = Users.2
InstanceID = iDRAC.Embedded.1#Users.2#Enable
IsReadOnly = false
PossibleValues = Disabled, Enabled
.
.
27 Dell Lifecycle Controller Web Services Interface Guide for Windows
5.2.2 Privilege and Capabilities (Using iDRAC Attributes)
Enumerating the DCIM_iDRACCardEnumeration class, Section 19.1, and parsing the output for the attribute AttributeDisplayName = User Admin IPMI LAN(or Serial) Privilege, will display all of the 16 possible user accounts and their respective status.
EXAMPLE:
DCIM_iDRACCardEnumeration
AttributeDisplayName = User Admin IPMI LAN Privilege
AttributeName = IpmiLanPrivilege
CurrentValue = NoAccess
DefaultValue = NoAccess
Dependency = null
DisplayOrder = 0
FQDD = iDRAC.Embedded.1
GroupDisplayName = Users
GroupID = Users.1
InstanceID = iDRAC.Embedded.1#Users.1#IpmiLanPrivilege
IsReadOnly = true
PossibleValues = User, Operator, Administrator, NoAccess
DCIM_iDRACCardEnumeration
AttributeDisplayName = User Admin IPMI Serial Privilege
AttributeName = IpmiSerialPrivilege
CurrentValue = NoAccess
DefaultValue = NoAccess
Dependency = null
DisplayOrder = 0
FQDD = iDRAC.Embedded.1
28 Dell Lifecycle Controller Web Services Interface Guide for Windows
GroupDisplayName = Users
GroupID = Users.1
InstanceID = iDRAC.Embedded.1#Users.1#IpmiSerialPrivilege
IsReadOnly = true
PossibleValues = User, Operator, Administrator, NoAccess.
.
5.3 Manage Account Settings (Using iDRAC Attributes)
When the account setting capability allows, the user name of an account may be modified by invoking the ApplyAttributes() method on the UserName property. Confirmation of successful user name or password verification can be obtained by enumerating the DCIM_iDRACCardString class( Section 19.6).
5.3.1 Modify User Name (Using iDRAC Attributes)
EXAMPLE:
winrm i ApplyAttributes http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_iDRACCardService
?SystemCreationClassName=DCIM_ComputerSystem
+CreationClassName=DCIM_iDRACCardService
+SystemName=DCIM:ComputerSystem
+Name=DCIM:iDRACCardService
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck
-encoding:utf-8 -a:basic -file: DracCard_UserName.xml
The input file, DracCard_UserName.xml, is shown below:
<p:ApplyAttributes_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_iDRACCardService">
<p:Target>iDRAC.Embedded.1</p:Target>
<p:AttributeName>Users.4#UserName</p:AttributeName>
29 Dell Lifecycle Controller Web Services Interface Guide for Windows
<p:AttributeValue>HELLO</p:AttributeValue>
</p:ApplyAttributes_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
ApplyAttributes_OUTPUT
ReturnValue = 4096
Job
EndpointReference
Address = https://127.0.0.1:443/wsman
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-
schema/2/DCIM_LifecycleJob
SelectorSet
Selector: __cimnamespace = root/dcim,
InstanceID = JID_001296571842
5.3.2 Modify Password (Using iDRAC Attributes)
EXAMPLE:
winrm i ApplyAttributes http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_iDRACCardService ?SystemCreationClassName=DCIM_ComputerSystem +CreationClassName=DCIM_iDRACCardService +SystemName=DCIM:ComputerSystem
+Name=DCIM:iDRACCardService -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic ­file:DracCard_Password.xml
The input file, DracCard_Password.xml, is shown below:
<p:ApplyAttributes_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_iDRACCardService">
<p:Target>iDRAC.Embedded.1</p:Target> <p:AttributeName>Users.4#Enable</p:AttributeName> <p:AttributeValue>Enabled</p:AttributeValue> <p:AttributeName>Users.4#Password</p:AttributeName> <p:AttributeValue>PWORDHERE</p:AttributeValue>
30 Dell Lifecycle Controller Web Services Interface Guide for Windows
</p:ApplyAttributes_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
ApplyAttributes_OUTPUT
ReturnValue = 4096
Job
EndpointReference
Address = https://127.0.0.1:443/wsman
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-
schema/2/DCIM_LifecycleJob
SelectorSet
Selector: __cimnamespace = root/dcim,
InstanceID = JID_001296571842
5.3.3 Modify Account State (Using iDRAC Attributes)
When the account setting capability allows, the user account may be enabled or disabled by invoking the method ApplyAttributes() method on the Enable property. Confirmation of the change can be obtained by enumerating the DCIM_iDRACCardString class( Section 19.6).
EXAMPLE:
winrm i ApplyAttributes http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_iDRACCardService
?SystemCreationClassName=DCIM_ComputerSystem +CreationClassName=DCIM_iDRACCardService +SystemName=DCIM:ComputerSystem
+Name=DCIM:iDRACCardService -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
-file: DracCard_AccountChange.xml
The input file, DracCard_ AccountChange.xml, is shown below:
<p:ApplyAttributes_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_iDRACCardService">
31 Dell Lifecycle Controller Web Services Interface Guide for Windows
<p:Target>iDRAC.Embedded.1</p:Target> <p:AttributeName>Users.4#Enable</p:AttributeName> <p:AttributeValue>Enabled</p:AttributeValue> <p:AttributeName>Users.4#Password</p:AttributeName> <p:AttributeValue>PASSWORDHERE</p:AttributeValue>
</p:ApplyAttributes_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
ApplyAttributes_OUTPUT
Job
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-
schema/2/DCIM_LifecycleJob
SelectorSet
Selector: InstanceID = JID_001296744532, __cimnamespace = root/dcim ReturnValue = 4096
The following error may result if the password has not initially been set to a value. The password may be set an initail value at the same time as the account is enabled by adding the Users.4#Password attribute name and corresponding attribute value, as shown above.
ApplyAttributes_OUTPUT
Message = The User Password is not configured so cannot Enable the User or set values for IPMILan IPMISerial or User Admin Privilege
MessageArguments = NULL
MessageID = RAC023
ReturnValue = 2
5.3.4 Modify User Privilege (Using iDRAC Attributes)
When the account setting capability allows, the user privileges may be enabled or disabled by invoking the method ApplyAttributes() method on the Enable property. Confirmation of the change can be obtained by enumerating the DCIM_iDRACCardString class( Section 19.6).
EXAMPLE:
32 Dell Lifecycle Controller Web Services Interface Guide for Windows
winrm i ApplyAttributes http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_iDRACCardService
?SystemCreationClassName=DCIM_ComputerSystem +CreationClassName=DCIM_iDRACCardService +SystemName=DCIM:ComputerSystem
+Name=DCIM:iDRACCardService -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
-file: DracCard_PrivilegeChange.xml
The input file, DracCard_ PrivilegeChange.xml, is shown below:
<p:ApplyAttributes_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_iDRACCardService">
<p:Target>iDRAC.Embedded.1</p:Target> <p:AttributeName>Users.4#IpmiLanPrivilege</p:AttributeName> <p:AttributeValue>Operator</p:AttributeValue>
</p:ApplyAttributes_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
ApplyAttributes_OUTPUT
Job
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim­schema/2/DCIM_LifecycleJob
SelectorSet
Selector: InstanceID = JID_001296745342, __cimnamespace = root/dcim ReturnValue = 4096
5.4 Account Inventory (Using DMTF Model)
The list of user accounts may be retrieved by enumerating the CIM_Account class. The class provides the user account name and EnabledState properties. The user account password is also included but it is a write-only property.
Profiles:
33 Dell Lifecycle Controller Web Services Interface Guide for Windows
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf
http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
5.4.1 Account and Capabilities (Using DMTF Model)
Example-A demonstrates standard ouput. Example-B demonstrates EPR mode
output.
EXAMPLE-A:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Account
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT-A:
DCIM_Account
CreationClassName = DCIM_Account
ElementName = DCIM Account
EnabledDefault = 2
EnabledState = 3
Name = iDRAC.Embedded.1#Users.1
OrganizationName = DCIM
RequestedState = 0
SystemCreationClassName = DCIM_SPComputerSystem
SystemName = systemmc
TransitioningToState = 12
UserID = null
UserPassword = null
DCIM_Account
CreationClassName = DCIM_Account
ElementName = DCIM Account
34 Dell Lifecycle Controller Web Services Interface Guide for Windows
EnabledDefault = 2
EnabledState = 2
Name = iDRAC.Embedded.1#Users.2
OrganizationName = DCIM
RequestedState = 0
SystemCreationClassName = DCIM_SPComputerSystem
SystemName = systemmc
TransitioningToState = 12
UserID = root
UserPassword
.
.
.
EXAMPLE-B:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Account
-u:[USER] - p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
-returntype:EPR
OUTPUT-B:
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Account
SelectorSet
Selector: __cimnamespace = root/dcim, Name = iDRAC.Embedded.1#Users.1, CreationClassName = DCIM_Account, SystemName = systemmc, SystemCreationClassName = DCIM_SPComputerSystem
35 Dell Lifecycle Controller Web Services Interface Guide for Windows
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Account SelectorSet
Selector: __cimnamespace = root/dcim, Name = iDRAC.Embedded.1#Users.2, CreationClassName = DCIM_Account, Sys
temName = systemmc, SystemCreationClassName = DCIM_SPComputerSystem
.
.
.
Account setting capability is defined in the class CIM_AccountManagementCapabilities associated with the CIM_Account class instance. The ability to enable and disable an account is defined in the capability class CIM_EnabledLogicalElementCapabilities associated with the CIM_Account class.
To determine account setting capabilities:
1. Get the CIM_Account class instance of interest using EnumerateEPR mode.
2. Enumerate the associators of the CIM_Account instance and search for
CIM_AccountManagementService class instance using EnumerateEPR mode.
3. Enumerate the associators of the CIM_AccountManagementService instance and search for
CIM_AccountManagementCapabilities class instance.
4. One exception is account index 0. The first account is static and could not be set.
OUTPUT-C:
DCIM_LocalUserAccountManagementCapabilities
ElementName = Local User Account Management Capabilities
ElementNameEditSupported = false
InstanceID = DCIM:LocalUserAccountManagementCapabilities:1
MaxElementNameLen = 0
OperationsSupported = 3
SupportedAuthenticationMethod = 0, 1, 2
DCIM_IPMICLPAccountManagementCapabilities
ElementName = IPMI/CLP Account Management Capabilities
36 Dell Lifecycle Controller Web Services Interface Guide for Windows
ElementNameEditSupported = false
InstanceID = DCIM:IPMICLPAccountManagementCapabilities:1
MaxElementNameLen = 0
OperationsSupported = 3
To determine account state setting capabilities:
1. Get the CIM_Account class instance of interest using EnumerateEPR mode.
2. Enumerate the associators of the CIM_Account instance and search for
CIM_EnabledLogicalElementCapabilities class instance.
3. The presence of “RequestedStatesSupported” determines which states could be set.
4. One exception is account index 0. The first account is static and could not be set.
OUTPUT-D:
DCIM_EnabledLogicalElementCapabilities
ElementName = Account Capabilities ElementNameEditSupported = false
InstanceID = DCIM_EnabledLogicalElementCapabilities:1 MaxElementNameLen = 0
RequestedStatesSupported = 2, 3
.
.
.
5.4.2 Privilege and Capabilities (Using DMTF Model)
The account privilege assigned to a user is defined in the class CIM_Privilege associated with the CIM_Account class. The class contains a list of privileges granted to the user account.
Profiles:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf
http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
To get the instance of CIM_Privilege for an account:
1. Get the CIM_Account class instance of interest using EnumerateEPR mode.
2. Enumerate the associators of the CIM_Account instance and search for CIM_Identity class
instance using EnumerateEPR mode.
3. Enumerate the associators of the CIM_Identity instance and search for CIM_Role class instance
using EnumerateEPR mode.
37 Dell Lifecycle Controller Web Services Interface Guide for Windows
4. Enumerate the associators of the CIM_Role instance and search for CIM_Privilege class instance.
An alternative to the above method, you can retrieve the specific CIM_Privilege instance by enumerating the class directly with filter. This method is similar to the example used to retrieve CIM_Account.
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/DCIM_LocalRolePrivilege
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]//wsman
-SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_LocalRolePrivilege
Activities = null
ActivityQualifiers = null
ElementName = DCIM Local Privilege 1
InstanceID = DCIM:Privilege:1
PrivilegeGranted = true
QualifierFormats = null
RepresentsAuthorizationRights = false
DCIM_LocalRolePrivilege
Activities = 7, 7, 7, 7, 7, 7, 7, 7, 7
ActivityQualifiers = Login to DRAC, Configure DRAC, Configure Users, Clear Logs, Test Alerts, Execute Server Control Commands, Access Console Redirection, Access Virtual Media, Execute Diagnostic Commands
ElementName = DCIM Local Privilege 2
InstanceID = DCIM:Privilege:2
PrivilegeGranted = true
QualifierFormats = 9, 9, 9, 9, 9, 9, 9, 9, 9
RepresentsAuthorizationRights = true
DCIM_LocalRolePrivilege
38 Dell Lifecycle Controller Web Services Interface Guide for Windows
Activities = null
ActivityQualifiers = null
ElementName = DCIM Local Privilege 3 InstanceID = DCIM:Privilege:3 PrivilegeGranted = true QualifierFormats = null RepresentsAuthorizationRights = false
.
.
.
Privilege setting capability is defined in the class CIM_RoleBasedManagementCapabilities associated with the CIM_Privilege class instance. This class contains the list of possible values used to assign privileges. Look for the property ActivityQualifiersSupported.
To determine privilege setting capabilities:
1. Acquire the class instance of CIM_Privilege of interest.
2. Enumerate the associators of the CIM_Privilege instance and search for
CIM_RoleBasedAuthorizationService class instance using EnumerateEPR mode.
3. Enumerate the associators of the CIM_RoleBasedAuthorizationService instance and search for
CIM_RoleBasedManagementCapabilities class instance using EnumerateEPR mode.
OUTPUT:
DCIM_LocalRoleBasedManagementCapabilities ActivitiesSupported = 7, 7, 7, 7, 7, 7, 7, 7, 7
ActivityQualifiersSupported = Login to DRAC, Configure DRAC, Configure Users, Clear Logs, Execute Server Control Commands, Access Console Redirection, Access Virtual Media, Test Alerts, Execute Di agnostic Commands
ElementName = Local Role Based Management Capabilities
InstanceID = DCIM:LocalRoleBasedManagementCapabilities QualifierFormatsSupported = 9, 9, 9, 9, 9, 9, 9, 9, 9 SharedPrivilegeSupported = false
SupportedMethods = 8
DCIM_CLPRoleBasedManagementCapabilities
ActivitiesSupported = null
ActivityQualifiersSupported = null
ElementName = CLP Role Based Management Capabilities
InstanceID = DCIM:CLPRoleBasedManagementCapabilities
39 Dell Lifecycle Controller Web Services Interface Guide for Windows
QualifierFormatsSupported = null
SharedPrivilegeSupported = false
SupportedMethods = 6
DCIM_IPMIRoleBasedManagementCapabilities
ActivitiesSupported = null
ActivityQualifiersSupported = null
ElementName = IPMI Role Based Management Capabilities
InstanceID = DCIM:IPMIRoleBasedManagementCapabilities
QualifierFormatsSupported = null
SharedPrivilegeSupported = false
SupportedMethods = 6
5.5 Manage Account Settings (Using DMTF Model)
5.5.1 Modify User Name (Using DMTF Model)
When the account setting capability allows, the user name of an account may be modified by issuing a set operation on the UserID property of the CIM_Account class instance. The set operation requires an instance reference. The instance reference may be retrieved by adding EnumerateEPR mode to enumerate or get of the class.
Profiles:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf
http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
The steps below demonstrate how to set the user name and password for local accounts.
A) Enumerate CIM_Account with EPR to identify all possible instance information to be used in a subsequent put or set operations.
EXAMPLE-A:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Account ?__cimnamespace=root/dcim
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -SkipCNcheck
40 Dell Lifecycle Controller Web Services Interface Guide for Windows
-SkipCAcheck -encoding:utf-8 -a:basic
-returntype:EPR
When this command is executed, a list of objects will be returned. Below is a snippet of the output.
OUTPUT-A:
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Account SelectorSet
Selector: __cimnamespace = root/dcim, Name = iDRAC.Embedded.1#Users.1, CreationClassName = DCIM_Account, SystemName = systemmc, SystemCreationClassName = DCIM_SPComputerSystem
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/DCIM_Account SelectorSet
Selector: __cimnamespace = root/dcim, Name = iDRAC.Embedded.1#Users.2, CreationClassName = DCIM_Account, SystemName = systemmc, SystemCreationClassName = DCIM_SPComputerSystem
.
.
.
B) Perform a ‘get’ on any instance from A) to ensure correctness of the URI.
EXAMPLE-B:
winrm g "http://schemas.dell.com/wbem/wscim/1/cim-schema/2/ DCIM_Account?__cimnamespace=root/dcim
+CreationClassName=DCIM_Account +Name= iDRAC.Embedded.1#Users.16
+SystemCreationClassName=DCIM_SPComputerSystem +SystemName=systemmc"
-r:https://[IPADDRESS] -u:[USER] -p:[PASSWORD]
41 Dell Lifecycle Controller Web Services Interface Guide for Windows
-a:basic -encoding:utf-8 –SkipCACheck –SkipCNCheck
When this method is executed, the particular object will be returned. Below is the output.
OUTPUT-B:
DCIM_Account
CreationClassName = DCIM_Account
ElementName = DCIM Account
EnabledDefault = 2
EnabledState = 3
Name = iDRAC.Embedded.1#Users.16
OrganizationName = DCIM
RequestedState = 0
SystemCreationClassName = DCIM_SPComputerSystem
SystemName = systemmc
TransitioningToState = 12
UserID = null
UserPassword = null
C) If B) is successful, set the new values for the specified instance.
EXAMPLE-C:
winrm set "http://schemas.dell.com/wbem/wscim/1/cim-schema/2/ DCIM_Account?__cimnamespace=root/dcim
+CreationClassName= DCIM_Account +Name= iDRAC.Embedded.1#Users.16
+SystemCreationClassName=DCIM_SPComputerSystem +SystemName=systemmc"
-r:https://[IPADDRESS] -u:[USER] -p:[PASSWORD] -a:basic -encoding:utf-8
@{UserID="testuser4";UserPassword="testuser4"} -SkipCACheck -SkipCNCheck –skiprevocationcheck
When this command is executed, the UserID will be displayed in the output. The UserPassword will be displayed as null when the account is disabled. After the account is enabled, it will be displayed as blank. The value of UserPassword will never be displayed.
42 Dell Lifecycle Controller Web Services Interface Guide for Windows
OUTPUT-C:
DCIM_Account
CreationClassName = DCIM_Account
ElementName = DCIM Account
EnabledDefault = 2
EnabledState = 3
Name = iDRAC.Embedded.1#Users.16
OrganizationName = DCIM
RequestedState = 0
SystemCreationClassName = DCIM_SPComputerSystem
SystemName = systemmc
TransitioningToState = 12
UserID = testuser4
UserPassword = null
UserID = testuser4
UserPassword = testuser4
D) If the account specified is new or not yet enabled, it will not be accessible. Login as root in the UI and verify the user name is set correctly and enable it.
E) Logout of the UI. Logging in with new user name and password and be successful.
Possible responses:
1. A fault is returned which suggests a possible error in the request payload.
2. An empty response which suggests an error occurred while processing the request.
3. An instance of the class is returned where the property value is unchanged.
4. An instance of the class is returned where the property value is modified. The set is successful.
5. The property value may be blank as intended by the implementation for security. To determine
success, try logging in with the new password. Make sure the account is enabled.
5.5.2 Modify Password (Using DMTF Model)
When the account setting capability allows, the user password of an account may be modified by issuing a set operation on the UserPassword property of the CIM_Account class instance. The set operation
43 Dell Lifecycle Controller Web Services Interface Guide for Windows
requires an instance reference. The instance reference may be retrieved by adding EnumerateEPR mode to enumerate or get of the class.
Note: The profile defines this property as string array of type octet string. In this implementation, the password is a string of type clear text. The security concern is resolved by transmission of this information only through secure HTTPS communication.
Profiles:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf
http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
See Section 5.5.1 for an implementation example.
5.5.3 Modify Account State (Using DMTF Model)
When the account setting capability allows, the user account may be enabled or disabled by invoking the RequestStateChange() method of the CIM_Account class instance. The invoke operation requires an instance reference. The instance reference may be retrieved by adding EnumerateEPR mode to enumerate or get of the class.
Profiles:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf
http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
Replace “DCIM User 16” with the applicable user name and “2” with the desired request state.
Invoke RequestStateChange() with the following parameters and syntax:
EXAMPLE:
winrm invoke RequestStateChange "http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/DCIM_Account
?__cimnamespace=root/dcim +CreationClassName=DCIM_Account +Name= iDRAC.Embedded.1#Users.16
+SystemCreationClassName=DCIM_SPComputerSystem +SystemName=systemmc"
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -SkipCNcheck -SkipCAcheck -encoding:utf-8 ­a:basic @{RequestedState="2"} -skiprevocationcheck
OUTPUT:
44 Dell Lifecycle Controller Web Services Interface Guide for Windows
RequestStateChange_OUTPUT
ReturnValue = 0
Response status other than zero indicates failure and error message information may be provided.
5.5.4 Modify User Privilege (Using DMTF Model)
When the account setting capability allows, the user account privileges may be modified by issuing a set() operation on the ActivityQualifiers property of the CIM_Privilege class instance associated with the CIM_Account class instance. The set() operation requires an instance reference. The instance reference may be retrieved by adding EnumerateEPR mode to enumerate or get of the class.
The profile defines this property as string array containing all the privileges to be granted for the account. Setting the list of privileges is a complete over-write of the previous setting. This restriction is a limitation where the protocol does not define how to set a particular index in the list. The new list will replace the previous list in its entirety.
Profiles:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1034_1.0.1.pdf http://www.dmtf.org/sites/default/files/standards/documents/DSP1039_1.0.0.pdf
Here is an example list of available privileges from an instance of the class
CIM_RoleBasedManagementCapabilities:
DCIM_LocalRoleBasedManagementCapabilities
ActivitiesSupported = 7, 7, 7, 7, 7, 7, 7, 7, 7
ActivityQualifiersSupported = Login to DRAC, Configure DRAC, Configure Users, Clear Logs, Execute Server Control Commands, Access Console Redirection, Access Virtual Media, Test Alerts, Execute Di agnostic Commands
ElementName = Local Role Based Management Capabilities
InstanceID = DCIM:LocalRoleBasedManagementCapabilities QualifierFormatsSupported = 9, 9, 9, 9, 9, 9, 9, 9, 9 SharedPrivilegeSupported = false
SupportedMethods = 8
The privilege property ActivityQualifiers is an array of type string. To set more than one privilege, you need to provide the same key name more than once. The tool does not allow duplicate keys to be entered through the command line. Instead, you need to perform two operations.
Get an instance of the CIM_Privilege class of interest. Using the class instance, replace the property ActivityQualifiers with the new values. Use the new instance XML as input to the set operation.
45 Dell Lifecycle Controller Web Services Interface Guide for Windows
To determine if the new password has been successfully set, try logging in with the new password. Ensure the account is enabled.
46 Dell Lifecycle Controller Web Services Interface Guide for Windows
6 Firmware Inventory
6.1 Software Inventory Profile Specification
The Dell Common Information Model (CIM) class extensions for supporting remote firmware inventory are defined in the Dell OS Software Update 2 and related MOFs 3. The diagrams representing the classes that are implemented by the Lifecycle Controller firmware can be found in Dell Software Inventory Profile.
6.2 Remote Inventory Method Invocation Get Software Inventory
The SoftwareIdentity class contains information for the BIOS and component firmware installed on the target system as well as available firmware images cached in the Lifecycle Controller. The enumeration of the SoftwareIdentity class returns a list of SoftwareIdentity objects with properties such as firmware type and version.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_SoftwareIdentity
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443
-auth:basic -encoding:utf-8
When this method is executed, a list of software identity objects will be returned, including installed and available firmware. Below is a snippet of the output.
OUTPUT:
DCIM_SoftwareIdentity
BuildNumber = 4846
Classifications = 10
ComponentID = 28897
ComponentType = APAC
DeviceID = null
ElementName = Dell Lifecycle Controller 2, 1.0.0.4846, X79
47 Dell Lifecycle Controller Web Services Interface Guide for Windows
FQDD = USC.Embedded.1:LC.Embedded.1
IdentityInfoType = OrgID:ComponentType:ComponentID
IdentityInfoValue = DCIM:firmware:28897
InstallationDate = 2012-01-15T22:22:32Z
InstanceID = DCIM:INSTALLED#802__USC.Embedded.1:LC.Embedded.1 IsEntity = true
MajorVersion = 1
MinorVersion = 0
RevisionNumber = 0
RevisionString = null
Status = Installed
SubDeviceID = null
SubVendorID = null
Updateable = true
VendorID = null
VersionString = 1.0.0.4846
impactsTPMmeasurements = false
.
.
.
The key properties in the above output include the following:
InstanceID: Normally identifies the firmware on a particular type of device. The substring right after
DCIM: is the status of a payload or firmware on the system. This can be installed or available.
ComponentID: Uniquely identifies a unique type of device such as BIOS, NIC, Storage and Lifecycle
controller firmware.
InstallationDate: The date when the payload was installed to the system. If the system time was not
set when the firmware installation took place the install date will be 1970-01-01. Factory installed firmware will have the 1970-01-01 date.
VersionString: Shows the version of the firmware represented.
48 Dell Lifecycle Controller Web Services Interface Guide for Windows
7 Firmware Update
7.1 Software Update Profile Specification
The Dell Common Information Model (CIM) class extensions for supporting BIOS, component firmware, and embedded software update are defined in the Dell Software Update Profile 2 and related MOF files 3. The diagrams representing the classes that are implemented by the Lifecycle Controller firmware can be found in Dell Software Update Profile as well.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
7.2 ”Rollback” Firmware
The InstallFromSoftwareIdentity() method is used for installation of a previous version of a component firmware that is available on the Lifecycle Controller (i.e. “rollback” of component firmware). The general
“Rollback” firmware steps are performed in several stages as described in the next sections. Meanwhile, the
steps are demonstrated in examples in Section 7.3 and Section 7.4.
7.2.1 Request “Rollback” Image
The first stage is a request to initiate and download the rollback image from the Lifecycle Controller by invoking the InstallFromSoftwareIdentity() method.
7.2.2 Create Reboot Job
The second stage is to create a reboot job as shown in Section 7.8.
7.2.3 Schedule Update Jobs
The third stage is to invoke the SetupJobQueue() method as shown in Section 10.2.1. Use the jobID(JID) from InstallFromSoftwareIdentity() and rebootID(RID) from the reboot job. The reboot may take several minutes as the UEFI performs the desired operation.
7.2.4 Monitor Update Jobs
The output of getting the job status during various steps, Section 10.2.3, is shown below.
Initial job status after invoking InstallFromSoftwareIdentity
DCIM_LifecycleJob
InstanceID = JID_001276741956
JobStartTime = TIME_NA
49 Dell Lifecycle Controller Web Services Interface Guide for Windows
JobStatus = Downloaded
JobUntilTime = TIME_NA
Message = Package successfully downloaded.
MessageArguments = null
MessageID = RED002
Name = Rollback:DCIM:AVAILABLE:NONPCI:159:2.1.4
Job status after invoking SetupJobQueue
DCIM_LifecycleJob
InstanceID = JID_001276741956
JobStartTime = 00000101000000
JobStatus = Scheduled
JobUntilTime = 20100730121500
Message = Task successfully scheduled
MessageArguments = null
MessageID = JCP001
Name = Rollback:DCIM:AVAILABLE:NONPCI:159:2.1.4
Job status following reboot / install of operation
DCIM_LifecycleJob
InstanceID = JID_001276741956
JobStartTime = 00000101000000
JobStatus = Completed
JobUntilTime = 20100730121500
Message = Job finished successfully
MessageArguments = null
MessageID = USC1
Name = Rollback:DCIM:AVAILABLE:NONPCI:159:2.1.4
50 Dell Lifecycle Controller Web Services Interface Guide for Windows
7.3 BIOS Firmware “Rollback”
The InstallFromSoftwareIdentity() method is used for installation of a previous version of a component firmware that is available on the Lifecycle Controller (i.e. “rollback” of component firmware).
All steps to complete a rollback successfully are listed below.
Invoke InstallFromSoftwareIdentity() with the following parameters and syntax:
[InstanceID]: This is the instanceID of the SoftwareIdentify that is to be used to rollback the firmware to a previous version. The InstanceID can have value such as:
DCIM:AVAILABLE:NONPCI:159:2.1.4
It is available firmware on a NONPCI device. This refers BIOS version 2.1.4
EXAMPLE:
winrm i InstallFromSoftwareIdentity cimv2/root/dcim/ DCIM_SoftwareInstallationService ?CreationClassName=DCIM_SoftwareInstallationService +SystemCreationClassName=DCIM_ComputerSystem +SystemName=IDRAC:ID
+Name=SoftwareUpdate -file:RollInputBIOS.xml -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8
The rollback input file, RollInputBIOS.xml, is shown below:
<p:InstallFromSoftwareIdentity_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_SoftwareInstallationService">
<p:Target xmlns:a="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:w="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <a:Address>http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous</a:Address>
<a:ReferenceParameters> <w:ResourceURI>http://schemas.dell.com/wbem/wscim/1/cim­schema/2/DCIM_SoftwareIdentity</w:ResourceURI> <w:SelectorSet>
<w:Selector Name="InstanceID">[InstanceID]</w:Selector> </w:SelectorSet>
</a:ReferenceParameters>
</p:Target>
</p:InstallFromSoftwareIdentity_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
51 Dell Lifecycle Controller Web Services Interface Guide for Windows
InstallFromSoftwareIdentity_OUTPUT Job
Address = http://schemas.xmlsoap.org/ws /2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1 /cim-
schema/2/DCIM_SoftUpdateConcreteJob
SelectorSet
Selector: InstanceID = JID_001276741956, __cimnamespace = root/dcim
ReturnValue = null
7.4 NIC Firmware “Rollback”
The InstallFromSoftwareIdentity() method is used for installation of a previous version of a component firmware that is available on the Lifecycle Controller (i.e. “rollback” of component firmware).
Invoke InstallFromSoftwareIdentity with the following parameters and syntax:
[InstanceID]: This is the instanceID of the SoftwareIdentify that is to be used to rollback the firmware to a previous version. The InstanceID can have value such as:
DCIM:PREVIOUS:PCI:14E4:1639:0237:1028
It refers to a previous firmware on a PCI device. ID (Vendor ID)= 14E4 DID (Device ID) = 1639 SSID (Subsystem ID) = 0237 SVID (Subvendor ID) = 1028 This refers to a Broadcom NetXtreme II BCM5709 network adaptor 7.
EXAMPLE:
winrm i InstallFromSoftwareIdentity cimv2/root/dcim/ DCIM_SoftwareInstallationService
?CreationClassName=DCIM_SoftwareInstallationService +SystemCreationClassName=DCIM_ComputerSystem +SystemName=IDRAC:ID
+Name=SoftwareUpdate -file:RollInputNIC.xml -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8
The rollback input file, RollInputNIC.xml, is shown below:
<p:InstallFromSoftwareIdentity_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_SoftwareInstallationService">
52 Dell Lifecycle Controller Web Services Interface Guide for Windows
<p:Target xmlns:a="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:w="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <a:Address>http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous</a:Ad dress>
<a:ReferenceParameters>
<w:ResourceURI>http://schemas.dell.com/wbem/wscim/1/cim-
schema/2/DCIM_SoftwareIdentity
</w:ResourceURI>
<w:SelectorSet>
<w:Selector Name="InstanceID">[InstanceID]</w:Selector> </w:SelectorSet>
</a:ReferenceParameters> </p:Target> </p:InstallFromSoftwareIdentity_INPUT>
OUTPUT:
When this method is executed, a jobid or an error message is returned.
InstallFromSoftwareIdentity_OUTPUT
Job
Address = http://schemas.xmlsoap.org/ws
/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1
/cim-schema/2/DCIM_SoftUpdateConcreteJob
SelectorSet
Selector: InstanceID = JID_001265811668,
__cimnamespace = root/dcim
ReturnValue = null
Entering an invalid instanceID may yield the following error message:
InstallFromSoftwareIdentity_OUTPUT
Message = Invalid InstanceID
MessageID = SUP024
53 Dell Lifecycle Controller Web Services Interface Guide for Windows
ReturnValue = null
7.5 Update from Network Source
A Firmware update can be achieved by invoking the InstallFromURI() method in the class DCIM_SoftwareInstallationService. Firmware update is performed in several stages as described in the next sections. The steps are demonstrated in examples in Section 7.6 and Section 7.7.
Note: When using WSMAN command to initiate update jobs, make sure to wait for two seconds before submitting a second job in order to avoiding racing conditions.
7.5.1 Request Update Download
The first stage is a request to initiate and download the update image from a source defined by the user by invoking the InstallFromURI() method.
7.5.2 Monitor Download Status
Downloading the update package may take several minutes. The second stage is to monitor the download. The download status may be monitored by enumerating or getting the instance of the corresponding job.
7.5.3 Reboot to Perform Update
Once downloaded, the request needs to be scheduled. The third stage is to schedule the update. To schedule the update, use the SetupJobQueue() method of the class DCIM_JobService in Section 10.2.1.
7.5.4 Wait for Job Completion
The fourth stage is to wait for the job to be completed, which may take several minutes. The job status can be monitored as shown in Section 10.2.3.
7.5.5 Delete Job
The fifth and final stage is to delete the completed job from the job store. Deleting the job queue is shown in Section 10.2.2.
7.6 Update NICs from HTTP, CIFS Share, NFS Share, TFTP, or FTP
The InstallFromURI() method takes the following input and downloads the Dell Update Package to the Lifecycle Controller in the target system. The method returns a jobid for an instance of DCIM_SoftwareUpdateJob that can be scheduled to execute or queried for status at a later time. The following is the example of the method for updating a NIC firmware.
Invoke InstallFromURI() with the following parameters and syntax:
54 Dell Lifecycle Controller Web Services Interface Guide for Windows
[URI-IP-ADDRESS]: This is the IP address of the location for Dell Update Package. The Dell Update Package will need to be the Windows type update package. The file share can be HTTP, CIFS, NFS, TFTP, or FTP type as shown below:
HTTP Format:
http://[IP ADDRESS]/[PATH TO FILE.exe]
CIFS Format:
cifs://WORKGROUP_NAME\[USERNAME]:[PASSWORD]@[URI-IP-ADDRESS]/ [FILE.exe];mountpoint=[DIRECTORYNAME]
TFTP or FTP Format:
tftp://[IP ADDRESS]/[PATH TO FILE.exe]
ftp://[IP ADDRESS]/[PATH TO FILE.exe]
[InstanceID]: The instanceID is the SoftwareIdentify instanceID that represents the firmware that is to be updated. This instanceID can be retrieved as described in Section 6.2. For example, the instanceID can be:
DCIM:INSTALLED:PCI:14E4:1639:0237:1028
It is installed firmware on a PCI device. VID (Vendor ID)= 14E4 DID (Device ID) = 1636 SSID (Subsystem ID) = 0237 SVID (Subvendor ID) = 1028 This refers to a Broadcom NetXtreme II BCM5709 network adaptor 7.
EXAMPLE:
winrm invoke InstallFromURI cimv2/root/dcim/DCIM_SoftwareInstallationService ?CreationClassName=DCIM_SoftwareInstallationService +SystemCreationClassName=DCIM_ComputerSystem +SystemName=IDRAC:ID+Name=SoftwareUpdate
-file:UpdateInputNIC.xml
-u:[UserName] -p:[Password] -r:https://[IPADDRESS]/wsman:443 -SkipCNCheck ­auth:basic -encoding:utf-8
The above command takes in an input file named UpdateInputNic.xml to supply input parameters required for the InstallFromURI() method.
The syntax for UpdateInputNIC.xml is:
<p:InstallFromURI_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cimschema/
55 Dell Lifecycle Controller Web Services Interface Guide for Windows
2/root/dcim/DCIM_SoftwareInstallationService">
<p:URI>http://[URI-IP-ADDRESS]/[PATH-TO-EXE]/[FILE.exe]</p:URI>
<p:Target xmlns:a="http://schemas.xmlsoap.org/ws/2004/08/addressing"
xmlns:w="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd">
<a:Address>http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous</a:Ad dress>
<a:ReferenceParameters>
<w:ResourceURI>http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_SoftwareIdentity</w:ResourceURI>
<w:SelectorSet>
<w:Selector Name="InstanceID">[INSTANCEID]</w:Selector>
</w:SelectorSet>
</a:ReferenceParameters>
</p:Target>
</p:InstallFromURI_INPUT>
In the above sample, the [URI-IP-ADDRESS] must be replaced with the actual value of the IP address of the server that stores update content, [PATH-TO-EXE] must be replaced with the applicable path to the executable, [FILE.exe] must be replaced with the executable name, and [INSTANCEID] should be replaced with the actual InstanceID of the device to be updated.
OUTPUT:
When this method is executed, a jobid or an error message is returned. This jobid can then be used for subsequent processing with job control provider in Section 10.
InstallFromURI_OUTPUT
Job
Address = http://schemas.xmlsoap.org/ws
ReferenceParameters
ResourceURI =
http://schemas.dell.com/wbem/wscim/1/cim-schema
/2/DCIM_SoftUpdateConcreteJob
56 Dell Lifecycle Controller Web Services Interface Guide for Windows
SelectorSet
Selector: InstanceID = JID_001265810325,
__cimnamespace = root/dcim
ReturnValue = null
Missing XML parameters may yield the following error message:
InstallFromURI_OUTPUT
Message = Insufficient Method Parameters
MessageID = SUP001
ReturnValue = null
7.7 Update BIOS from HTTP, CIFS Share, NFS Share, TFTP, or FTP
The InstallFromURI() method takes the following input and downloads the Dell Update Package to the Lifecycle Controller in the target system. The method returns a jobid for an instance of DCIM_SoftwareUpdateJob that can be scheduled to execute or queried for status at a later time. The following is the example of the method for updating a BIOS firmware.
Invoke InstallFromURI() with the following parameters and syntax:
[URI-IP-ADDRESS]: This is the IP address of the location for Dell Update Package. The Dell Update Package will need to be the Windows type update package. The file share can be HTTP, CIFS, NFS, TFTP, or FTP type as shown below:
HTTP Format:
http://[IP ADDRESS]/[PATH TO FILE.exe]
CIFS Format:
cifs://[USERNAME]:[PASSWORD]@[URI-IP-ADDRESS]/ [FILE.exe];mountpoint=/[DIRECTORYNAME]
TFTP or FTP Format:
tftp://[IP ADDRESS]/[PATH TO FILE.exe]
ftp://[IP ADDRESS]/[PATH TO FILE.exe]
[InstanceID]: The instanceID is the SoftwareIdentify instanceID that represents the firmware that is to be updated. This instanceID can be retrieved as described in Section 6.2. For example, the instanceID can be:
DCIM:AVAILABLE:NONPCI:159:2.1.4
57 Dell Lifecycle Controller Web Services Interface Guide for Windows
It is available firmware on a NONPCI device. This refers BIOS version 2.1.4
EXAMPLE:
winrm invoke InstallFromURI cimv2/root/dcim/DCIM_SoftwareInstallationService ?CreationClassName=DCIM_SoftwareInstallationService +SystemCreationClassName=DCIM_ComputerSystem +SystemName=IDRAC:ID+Name=SoftwareUpdate
-file:UpdateInputBIOS.xml
-u:[UserName] -p:[Password] -r:https://[IPADDRESS]/wsman:443 -SkipCNCheck ­auth:basic -encoding:utf-8
The above command takes in an input file named UpdateInputBIOS.xml to supply input parameters required for the InstallFromURI() method.
The syntax for UpdateInputBIOS.xml is:
<p:InstallFromURI_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_SoftwareInstallationService">
<p:URI>http://[URI-IP-ADDRESS]/[PATH-TO-EXE]/[FILE.exe]</p:URI>
<p:Target xmlns:a="http://schemas.xmlsoap.org/ws/2004/08/addressing"
xmlns:w="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd">
<a:Address>http://schemas.xmlsoap.org/ws/2004/08/addressing/role/ anonymous</a:Address>
<a:ReferenceParameters>
<w:ResourceURI>http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_SoftwareIdentity</w:ResourceURI>
<w:SelectorSet>
<w:Selector Name="InstanceID">[INSTANCEID]</w:Selector>
</w:SelectorSet>
</a:ReferenceParameters>
</p:Target>
</p:InstallFromURI_INPUT>
58 Dell Lifecycle Controller Web Services Interface Guide for Windows
In the above sample, the [URI-IP-ADDRESS] must be replaced with the actual value of the IP address of the server that stores update content, [PATH-TO-EXE] must be replaced with the applicable path to the executable, [FILE.exe] must be replaced with the executable name, and [INSTANCEID] should be replaced with the actual InstanceID of the device to be updated.
OUTPUT:
When this method is executed, a jobid or an error message is returned. This jobid can then be used for subsequent processing with job control provider in section 10.
InstallFromURI_OUTPUT
Job
Address = http://schemas.xmlsoap.org/ws
ReferenceParameters
ResourceURI =
http://schemas.dell.com/wbem/wscim/1/cim-schema
/2/DCIM_SoftUpdateConcreteJob
SelectorSet
Selector: InstanceID = JID_001276741475,
__cimnamespace = root/dcim
ReturnValue = null
7.8 CreateRebootJob()
The CreateRebootJob() method creates a reboot job that can be scheduled to reboot immediately or at a later time. When the reboot job is scheduled and then executed, via SetupJobQueue() (Section 10.2.1), the reboot will take several minutes depending on the system setup, including whether collecting system inventory (CSIOR) is enabled.
Invoke CreateRebootJob with the following parameters and syntax:
RebootJobType: There are three options for rebooting the system.
1 = PowerCycle
2 = Graceful Reboot without forced shutdown
3 = Graceful reboot with forced shutdown
EXAMPLE:
59 Dell Lifecycle Controller Web Services Interface Guide for Windows
winrm invoke CreateRebootJob cimv2/root/dcim/DCIM_SoftwareInstallationService ?CreationClassName=DCIM_SoftwareInstallationService +SystemCreationClassName=DCIM_ComputerSystem +SystemName=IDRAC:ID+Name=SoftwareUpdate
-file:reboot.xml -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -SkipCNCheck -auth:basic -encoding:utf-8
The syntax for reboot.xml is:
<p:CreateRebootJob_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_SoftwareInstallationService">
<p:RebootJobType>2</p:RebootJobType>
</p:CreateRebootJob_INPUT>
OUTPUT:
This method will return a reboot jobid that can be set to reboot the system immediately or at a later time.
CreateRebootJob_OUTPUT
RebootJobID
Address = http://schemas.xmlsoap.org/ws/2004
/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem
/wscim/1/cim-schema/2/DCIM_SoftUpdateConcreteJob
SelectorSet
Selector: InstanceID = RID_001265648530, __cimnamespace = root/dcim
ReturnValue = null
The jobid in the above output is the instanceID:
Jobid = InstanceID = RID_001265648530
60 Dell Lifecycle Controller Web Services Interface Guide for Windows
7.9 Automatic Updates
Automatic Updates feature allows for periodic firmware updates at regular intervals as configured by the user.
7.9.1 Enable Automatic Update
This method enables/disables the “Automatic Update Feature ” attribute.
Example:
winrm i SetAttribute http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_LCService?SystemCreationClassName=DCIM_ComputerSystem+Cr eationClassName=DCIM_LCService+SystemName=DCIM:ComputerSystem+Name=DCIM:LCServic e -u:root -p:calvin -r:https://<<ip>>/wsman -SkipCNcheck -SkipCAcheck ­encoding:utf-8 -a:basic @{AttributeName="Automatic Update Feature";AttributeValue="Enabled"}
OUTPUT:
Message = The command was successful
MessageID = LC001
RebootRequired = No
ReturnValue = 0
SetResult = Set PendingValue
7.9.2 Create a Config Job
CreateConfigJob sets the pending value set by SetAttribute() method.
Example:
winrm i CreateConfigJob http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_LCService?SystemCreationClassName=DCIM_ComputerSystem+CreationCla ssName=DCIM_LCService+SystemName=DCIM:ComputerSystem+Name=DCIM:LCService -u:root ­p:calvin -r:https://<<ip>>/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
CreateConfigJob_OUTPUT
Job
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
61 Dell Lifecycle Controller Web Services Interface Guide for Windows
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cim-schema/2/
DCIM_LifecycleJob
SelectorSet
Selector: InstanceID = JID_859945354433, cimnamespace = root/dcim
ReturnValue = 4096
Verify the value of “Automatic Update Feature” attribute from DCIM_iDRACCardEnumeration. It has to be “Enabled” to set Automatic update schedule.
7.9.3 Set Update Schedule
SetUpdateSchedule() method sets the schedule for the automatic updates and the source repository from where the updates are to be applied from.
Example:
winrm i SetUpdateSchedule cimv2/root/dcim/DCIM_SoftwareInstallationService?SystemCreationClassName=DCIM_So ftwareInstallationService+SystemName=IDRAC:ID+CreationClassName=DCIM_SoftwareIns tallationService+Name=SoftwareUpdate -u:root -p:calvin -r:https://<<ip>>/wsman ­SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic -file:SetSchedule.xml
SetSchedule.xml
<p:SetUpdateSchedule_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/root/dcim/DCIM_SoftwareInstallationService">
<p:IPAddress>IPADDR</p:IPAddress>
<p:ShareName>Sharename/Repository</p:SharePath>
<p:ShareType>0</p:ShareType>
<p:Username>USER</p:Username>
<p:Password>PASS</p:Password>
<p:Time>15:00</p:Time>
<p:DayofWeek>mon,Tue,wed</p:DayofWeek>
<p:WeekofMonth>2</p:WeekofMonth>
<p:Repeat>5</p:Repeat>
62 Dell Lifecycle Controller Web Services Interface Guide for Windows
</p:SetUpdateSchedule_INPUT>
7.9.4 Get the Update Schedule
GetUpdateSchedule() lists the patameter set by SetUpdateSchedule()
Example:
winrm i GetUpdateSchedule cimv2/root/dcim/DCIM_SoftwareInstallationService?SystemCreationClassName=DCIM_So ftwareInstallationService+SystemName=IDRAC:ID+CreationClassName=DCIM_SoftwareIns tallationService+Name=SoftwareUpdate -u:root -p:calvin -r:https://<<ip>>/wsman ­SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
GetUpdateSchedule_OUTPUT
ApplyReboot = 0
CatalogName = Sample.xml
DayofMonth = *
IPAddress = 10.94.192.100
Repeat = 5
ReturnValue = 4096
ShareName = Somepath
ShareType = nfs
Time = 16:00
7.9.5 Clear the Update Schedule
Clears the schedule for the automatic updates, that has been set by SetUpdateSchedule() method.
Example:
winrm i ClearUpdateSchedule cimv2/root/dcim/DCIM_SoftwareInstallationService?SystemCreationClassName=DCIM_So ftwareInstallationService+SystemName=IDRAC:ID+CreationClassName=DCIM_SoftwareIns tallationService+Name=SoftwareUpdate -u:root -p:calvin -r:https://[IPADDR]/wsman
-SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
63 Dell Lifecycle Controller Web Services Interface Guide for Windows
ApplyUpdate
ReboootNeeded
Actions
0 X Only comparison report is generated
1
TRUE
All updates are applied immediately. Note: If the update requires a restart, the system is automatically restarted immediately.
1
FALSE
Currently, only updates that do not require a system restart will be applied. For example, Driver Pack DUPs. For those that require a restart, a separate reboot job will have to be created by the user with CreateRebootJob. These updates will go to a scheduled state and are run after a restart.
7.10 Device Update from Repository
This feature allows multiple firmware updates by specifying a network repository which contains a catalog of available updates. All applicable updates contained in the repository are applied to the system.
Following two methods introduced as a part of DCIM_SoftwareUpdate profile
InstallFromRepository: Initiate a job for device updates and creates a comparison report. GetRepoBasedUpdateList: Get the comparison report generated with InstallFromRepository
7.10.1 Install from Repository
The InstallFromRepository method applies the updates
Options available for user to update devices from repositories using WS-Man.
Example:
winrm i InstallFromRepository cimv2/root/dcim/DCIM_SoftwareInstallationService?CreationClassName=DCIM_Software
InstallationService+SystemCreationClassName=DCIM_ComputerSystem+SystemName=IDRAC
:ID+Name=SoftwareUpdate -u:root -p:calvin -r:https://[iDRAc ip]/wsman: -
SkipCNCheck -SkipCACheck -encoding:utf-8 -a:basic @{ipAddress="[Share ip
address] ";ShareName="[] ";ShareType="[]";UserName="[] ";Password="
";RebootNeeded="TRUE";CatalogFile="Catalog.xml";ApplyUpdate="1"}
OUTPUT:
64 Dell Lifecycle Controller Web Services Interface Guide for Windows
InstallFromRepository_OUTPUT
Job
EndpointReference
Address =
http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_LifecycleJob
SelectorSet
Selector: InstanceID = JID_776094296053, __cimnamespace =
root/dcim
ReturnValue = 4096
7.10.2 Get Repo-Based Update List
A comparison XML between the inventory present on the system and the updates present on the repository can be obtained using the GetRepoBasedUpdateList() method.
Example:
winrm i GetRepoBasedUpdateList http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_SoftwareInstallationService?CreationClassName=DCIM_Softw
areInstallationService+Name=SoftwareUpdate+SystemCreationClassName=DCIM_Computer
System+SystemName=IDRAC:ID -u:root -p:calvin -r:https://[IDRAC_IP_ADDR]/wsman
-SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
GetRepoBasedUpdateList_OUTPUT
PackageList = <?xml version="1.0"?>
<CIM xmlns:fo="http://www.w3.org/1999/XSL/Format" CIMVERSION="2.0"
DTDVERSION="2.0">
<MESSAGE ID="4711" PROTOCOLVERSION="1.0">
65 Dell Lifecycle Controller Web Services Interface Guide for Windows
<SIMPLEREQ>
<VALUE.NAMEDINSTANCE>
<INSTANCENAME CLASSNAME="DCIM_RepoUpdateSWID">
<PROPERTY NAME="Criticality" TYPE="string">
<VALUE>1</VALUE>
</PROPERTY>
<PROPERTY NAME="DisplayName" TYPE="string">
<VALUE>Intel(R) Ethernet 10G 4P X540/I350 rNDC -
BC:30:5B:ED:50:38</VALUE>
</PROPERTY>
<PROPERTY NAME="BaseLocation" TYPE="string">
<VALUE/>
</PROPERTY>
<PROPERTY NAME="PackagePath" TYPE="string">
<VALUE>Network_Firmware_KTT4W_WN64_14.5.5_X03.EXE</VALUE>
</PROPERTY>
<PROPERTY NAME="PackageName" TYPE="string">
<VALUE>Network_Firmware_KTT4W_WN64_14.5.5_X03.EXE</VALUE>
</PROPERTY>
<PROPERTY NAME="PackageVersion" TYPE="string">
<VALUE>14.5.5</VALUE>
</PROPERTY>
<PROPERTY NAME="RebootType" TYPE="string">
<VALUE>HOST</VALUE>
</PROPERTY>
<PROPERTY NAME="JobID" TYPE="string">
<VALUE/>
66 Dell Lifecycle Controller Web Services Interface Guide for Windows
</PROPERTY>
<PROPERTY NAME="Target" TYPE="string">
<VALUE>DCIM:INSTALLED#701__NIC.Integrated.1-1-1</VALUE>
</PROPERTY>
<PROPERTY NAME="ComponentID" TYPE="string">
<VALUE/>
</PROPERTY>
<PROPERTY NAME="ComponentType" TYPE="string">
<VALUE>FRMW</VALUE>
</PROPERTY>
<PROPERTY.ARRAY NAME="ComponentInfoValue" TYPE="string">
<VALUE.ARRAY>
<VALUE>8086:1528:1028:1F61</VALUE>
<VALUE>8086:1521:1028:1F62</VALUE>
</VALUE.ARRAY>
</PROPERTY.ARRAY>
<PROPERTY.ARRAY NAME="ComponentInfoName" TYPE="string">
<VALUE.ARRAY>
<VALUE>VendorID:DeviceID:SubVendorID:SubDeviceID</VALUE>
<VALUE>VendorID:DeviceID:SubVendorID:SubDeviceID</VALUE>
</VALUE.ARRAY>
</PROPERTY.ARRAY>
<PROPERTY.ARRAY NAME="ComponentInfoTarget" TYPE="string">
<VALUE.ARRAY>
<VALUE>DCIM:INSTALLED#701__NIC.Integrated.1-1-1</VALUE>
<VALUE>DCIM:INSTALLED#701__NIC.Integrated.1-3-1</VALUE>
</VALUE.ARRAY>
67 Dell Lifecycle Controller Web Services Interface Guide for Windows
</PROPERTY.ARRAY>
<PROPERTY.ARRAY NAME="ComponentInstalledVersion" TYPE="string">
<VALUE.ARRAY>
<VALUE>13.1.10</VALUE>
<VALUE>13.1.10</VALUE>
</VALUE.ARRAY>
</PROPERTY.ARRAY>
</INSTANCENAME>
</VALUE.NAMEDINSTANCE>
</SIMPLEREQ>
</MESSAGE>
</CIM>
ReturnValue = 0
68 Dell Lifecycle Controller Web Services Interface Guide for Windows
8 Power State Management
8.1 Description of Base Server Versus Power State Management
Methods
The remote control of a server power state (On, Off) and methodology for cycling power is available through data models specified in both the DMTF Base Server Profile and the DMTF Power State Management Profile. The Base Server Profile offers the RequestStateChange() method on the instance of the CIM_ComputerSystem class representing the server platform. The Power State Management Profile offers the RequestPowerStateChange() method available on the instance of the PowerStateManagmentService associated with the instance of CIM_ComputerSystem representing the server platform.
Base Server Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1004_1.0.1.pdf
Power State Management Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1027_2.0.0.pdf
8.2 Get Power State
8.2.1 Base Server Method
The power state of the system is reported by the EnabledState property of the DCIM_ComputerSystem class.
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/DCIM_ComputerSystem
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_ComputerSystem
CreationClassName = DCIM_ComputerSystem
Dedicated = 0
ElementName
EnabledState = 2
69 Dell Lifecycle Controller Web Services Interface Guide for Windows
HealthState = 25
IdentifyingDescriptions = CIM:GUID, CIM:Tag, DCIM:ServiceTag
Name = srv:system
OperationalStatus = 6
OtherIdentifyingInfo = 4c4c4544-0036-3510-8034-b7c04f333231, mainsystemchassis, 7654321
PrimaryStatus = 3
RequestedState = 0
8.2.2 Power State Management Method
The power state of the system is also reported by the PowerState property of the DCIM_CSAssociatedPowerManagementService class.
Power State Management Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1027_2.0.0.pdf
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/DCIM_CSAssociatedPowerManagementService -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
PowerState:
2 (On): System is fully on
13 (Off): System is powered off
DCIM_CSAssociatedPowerManagementService
PowerOnTime = null
PowerState = 2
RequestedPowerState = 0
ServiceProvided
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
70 Dell Lifecycle Controller Web Services Interface Guide for Windows
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_CSPowerManageme
ntService
SelectorSet
Selector: SystemCreationClassName = DCIM_SPComputerSystem, CreationClassName = D
CIM_CSPowerManagementService, SystemName = systemmc, Name = pwrmgtsvc:1, __cimnamespace = root/dcim
UserOfService
EndpointReference
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_ComputerSystem
SelectorSet
Selector: Name = srv:system, CreationClassName = DCIM_ComputerSystem, __cimnamespace = root/dcim
8.3 Get Power Control Capabilites
8.3.1 Base Server Method
The power control capabilities are reported by the RequestedStatesSupported property of the
CIM_EnabledLogicalElementCapabilities class associated with the main system CIM_ComputerSystem class.
Base Server Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1004_1.0.1.pdf
In “Part A” enumerate the CIM_ElementCapabilities class and search for the DCIM_CSElementCapabilities reference. Use the resulting InstanceID in “Part B” to obtain the RequestedStatesSupported property.
EXAMPLE (Part A):
71 Dell Lifecycle Controller Web Services Interface Guide for Windows
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/CIM_ElementCapabilities -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT (Part A):
.
.
.
DCIM_CSElementCapabilities
Capabilities
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_CSEnabledLogicalElementCapabilities
SelectorSet
Selector: InstanceID = DCIM:ComputerCap:1, __cimnamespace = root/dcim
Characteristics = null
ManagedElement
Address = http://schemas.xmlsoap.org/ws/2004/08/addressing/role/anonymous
ReferenceParameters
ResourceURI = http://schemas.dell.com/wbem/wscim/1/cimschema/
2/DCIM_ComputerSystem
SelectorSet
Selector: Name = srv:system, CreationClassName = DCIM_ComputerSystem, __cimnamespace
= root/dcim
.
.
72 Dell Lifecycle Controller Web Services Interface Guide for Windows
EXAMPLE (Part B):
winrm g http://schemas.dell.com/wbem/wscim/1/cim­schema/2/DCIM_CSEnabledLogicalElementCapabilities ?__cimnamespace=root/dcim +InstanceID=DCIM:ComputerCap:1
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT (Part B):
RequestedStatesSupported:
A Enabled
B Disabled
11: Reset
DCIM_CSEnabledLogicalElementCapabilities
Caption = null
Description = null
ElementName = Computer System Capabilities
ElementNameEditSupported = false
ElementNameMask = null
InstanceID = DCIM:ComputerCap:1
MaxElementNameLen = null
RequestedStatesSupported = 2, 3, 11
StateAwareness = null
8.3.2 Power State Management Method
The power control capabilities are also reported by the PowerStatesSupported property of the
CIM_PowerManagementCapabilities (PMC) class associated with the CIM_PowerManagementService (PMS) class. Getting the instance of PMC is a two step process. First, enumerate the instance of PMS with EPR. Second, enumerate the associated PMC class. When there is only one instance of PMC class as in the case of iDRAC, the first step may be skipped and the PMC class may be enumerated directly.
Power State Management Profile:
73 Dell Lifecycle Controller Web Services Interface Guide for Windows
PowerStatesSupported Value
PowerChangeCapabilites Value
1. 2
(Power On)
2. 3
(Sleep - Light)
3. 4
(Sleep - Deep)
(Power State Settable)
4. 5
(Power Cycle (Off Soft))
(Power Cycling Supported)
5. 6
(Power Off - Hard)
6. 7
(Hibernate)
7. 8
(Power Off - Soft)
8. 9
(Power Cycle (Off Hard))
(Off Hard Power Cycling Supported)
9. 1
0
(Master Bus Reset)
(HW Reset Supported)
10. 1
1
(Diagnostic Interrupt (NMI))
(HW Reset Supported)
11. 1
2
(Power Off - Soft Graceful)
(Graceful Shutdown Supported)
12. 1
3
(Power Off - Hard Graceful)
(Graceful Shutdown Supported)
13. 1
4
(Master Bus Reset Graceful)
(HW Reset Supported) and
14.
15.
16.
http://www.dmtf.org/sites/default/files/standards/documents/DSP1027_2.0.0.pdf
EXAMPLE (iDRAC case):
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim­schema/2/CIM_PowerManagementCapabilities?__cimnamespace=root/dcim
-u:[USER] -p:[PASSWORD]-r:https://[IPADDRESS]/wsman
-SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
When the PowerStatesSupported property contains the value in the “PowerStatesSupported Value”
column, the PowerChangeCapabilities property shall contain the value specified in the “PowerChangeCapabilities Value” column.
74 Dell Lifecycle Controller Web Services Interface Guide for Windows
17.
18.
(Graceful Shutdown Supported)
19. 1
5
(Power Cycle (Off - Soft Graceful))
(Power Cycling Supported) and
20.
21.
22.
23.
24.
(Graceful Shutdown Supported)
25. 1
6
(Power Cycle (Off - Hard Graceful))
(Off Hard Power Cycling Supported) and
26.
27.
28.
(Graceful Shutdown Supported)
DCIM_CSPowerManagementCapabilities
Caption = null
Description = null
ElementName = Power Management Capabilities
InstanceID = DCIM:pwrmgtcap1
OtherPowerCapabilitiesDescriptions = null
OtherPowerChangeCapabilities = null
PowerCapabilities = null
PowerChangeCapabilities = 3, 4, 8
PowerStatesSupported = 2, 5, 8, 11, 12
8.4 Power Control
8.4.1 Base Server Method
Changing the power state, such as cycling the power, is performed by invoking the RequestStateChange() method of the CIM_ComputerSystem class instance. For iDRAC, there is one instance for the main system and another for iDRAC. Use the main system instance. The method requires you to specify the RequestedState argument. Refer to Section 8.3 to get the possible values for this argument.
Base Server Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1004_1.0.1.pdf
EXAMPLE:
winrm invoke RequestStateChange "http://schemas.dell.com/wbem/wscim/1/cim­schema/2/DCIM_ComputerSystem
75 Dell Lifecycle Controller Web Services Interface Guide for Windows
?CreationClassName=DCIM_ComputerSystem +Name=srv:system"
-u:[USER] -p:[PASSWORD] -r:https://[IPADDRESS]/wsman:443 -SkipCNcheck ­SkipCAcheck -encoding:utf-8 -a:basic @{RequestedState="2"} -skiprevocationcheck
OUTPUT:
RequestStateChange_OUTPUT
ReturnValue = 0
Return values of zero indicate success, while others indicate failure and may include a corresponding error message.
8.4.2 Power State Management Method
Changing the power state is performed by invoking the RequestPowerStateChange() method of the DCIM_PowerManagementService (PMS) class instance. It is a three step process shown below:
1. Enumerate the DCIM_PowerManagementService with EPR
2. Enumerate the DCIM_ComputerSystem class and search for the Host instance
3. Use the EPR on steps 1) and 2) to invoke RequestPowerStateChange()
Power State Management Profile:
http://www.dmtf.org/sites/default/files/standards/documents/DSP1027_2.0.0.pdf
EXAMPLE:
winrm invoke RequestPowerStateChange http://schemas.dell.com/wbem/wscim/1/cim-
schema/2/DCIM_CSPowerManagementService?__cimnamespace=root/dcim+SystemCreationCl assName= DCIM_SPComputerSystem+SystemName=systemmc+CreationClassName=DCIM_CSPowerManageme ntServi ce+Name= pwrmgtsvc:1
-u:[USER] -p:[PASSWORD] -r:https://[IPADDRESS]/wsman -SkipCNcheck
-SkipCAcheck -encoding:utf-8 -auth:basic @{PowerState=”5”}
76 Dell Lifecycle Controller Web Services Interface Guide for Windows
9 Hardware Inventory
The Dell Common Information Model (CIM) class extensions for supporting remote hardware inventories are defined in the various Dell profiles and related MOFs 3. The Hardware Inventory allows users to remote query the inventory of hardware.
Each of the hardware inventory classes return the attribute LastSystemInventoryTime, which is when the
last time ‘collect system inventory on restart’ or CSIOR was run. See Section 12.1 for more details on
CSIOR. It is an important attribute as it shows how recently the inventory was updated.
9.1 Power Supply Inventory
This section describes the implementation for the DCIM_PowerSupplyView class. The Dell Power Supply
Profile describes platform’s power supply information. Each platform power supply is represented by an
instance of DCIM_PowerSupplyView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_PowerSupplyView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_PowerSupplyView -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8 -SkipCACheck – SkipCNCheck
OUTPUT:
DCIM_PowerSupplyView
DetailedState = Presence Detected
FQDD = PSU.Slot.1
FirmwareVersion = 00.01.31
InputVoltage = 120
InstanceID = PSU.Slot.1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100401130928
Manufacturer = Dell
Model = PWR SPLY,502W,RDNT
77 Dell Lifecycle Controller Web Services Interface Guide for Windows
PartNumber = 0MU791A00
PrimaryStatus = 1
RedundancyStatus = 2
SerialNumber = CN7324597O0411
TotalOutputPower = 502
Type = 0
DCIM_PowerSupplyView
DetailedState = Presence Detected
FQDD = PSU.Slot.2
FirmwareVersion = 00.01.31
InputVoltage = 118
InstanceID = PSU.Slot.2
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100401130929
Manufacturer = Dell
Model = PWR SPLY,502W,RDNT
PartNumber = 0MU791A00
PrimaryStatus = 1
RedundancyStatus = 2
SerialNumber = CN7324597O0446
TotalOutputPower = 502
Type = 0
9.2 Fan Inventory
This section describes the requirements and guidelines for implementing Dell Fan Profile. The Dell Fan Profile describes platform’s fans including the fan speed sensor information. Each platform fan is represented by an instance of DCIM_FanView class.
Profile and Associated MOFs:
78 Dell Lifecycle Controller Web Services Interface Guide for Windows
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_FanView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_FanView -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8 -SkipCACheck – SkipCNCheck
OUTPUT:
DCIM_FanView
ActiveCooling = true
BaseUnits = 19
CurrentReading = 4200
FQDD = Fan.Embedded.1A
InstanceID = Fan.Embedded.1A
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100408115623
PrimaryStatus = 1
RateUnits = 4
RedundancyStatus = 2
UnitModifier = 0
VariableSpeed = true
DCIM_FanView
ActiveCooling = true
BaseUnits = 19
CurrentReading = 4440
FQDD = Fan.Embedded.2A
InstanceID = Fan.Embedded.2A
LastSystemInventoryTime = 20100331101859 LastUpdateTime = 20100408115623
79 Dell Lifecycle Controller Web Services Interface Guide for Windows
PrimaryStatus = 1
RateUnits = 4
RedundancyStatus = 2
UnitModifier = 0
VariableSpeed = true
.
.
.
9.3 Memory Inventory
This section describes the implementation for the DCIM_MemoryView class. The Dell Memory Profile
describes platform’s physical memory. Each DIMM’s information is represented by an instance
ofDCIM_MemoryView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_MemoryView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_MemoryView
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443
-auth:basic -encoding:utf-8 -SkipCACheck
SkipCNCheck
OUTPUT:
DCIM_MemoryView
BankLabel = B
CurrentOperatingSpeed = 1067
FQDD = DIMM.Socket.B1
InstanceID = DIMM.Socket.B1
80 Dell Lifecycle Controller Web Services Interface Guide for Windows
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
ManufactureDate = Mon Jun 29 12:00:00 2009 UTC
Manufacturer = Samsung
MemoryType = 24
Model = DDR3 DIMM
PartNumber = M391B2873DZ1-CH9
PrimaryStatus = 1
Rank = 1
SerialNumber = 85C6DF30
Size = 1024
Speed = 1333
DCIM_MemoryView
BankLabel = A
CurrentOperatingSpeed = 1067
FQDD = DIMM.Socket.A3
InstanceID = DIMM.Socket.A3
LastSystemInventoryTime = 20100331101859 LastUpdateTime = 20100325134947
ManufactureDate = Mon Jun 29 12:00:00 2009 UTC Manufacturer = Samsung
MemoryType = 24
Model = DDR3 DIMM
PartNumber = M391B2873DZ1-CH9 PrimaryStatus = 1
Rank = 1
SerialNumber = 85C6DE0A
Size = 1024
Speed = 1333
.
81 Dell Lifecycle Controller Web Services Interface Guide for Windows
.
.
9.4 CPU Inventory
This section describes the implementation for the DCIM_CPUView class. The Dell CPU Profile describes platform’s CPUs. Each CPU’s information is represented by an instance of DCIM_CPUView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_CPUView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_CPUView -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8 -SkipCACheck – SkipCNCheck
OUTPUT:
DCIM_CPUView
CPUFamily = B3
CPUStatus = 1
Cache1Associativity = 7
Cache1ErrorMethodology = 5
Cache1Level = 0
Cache1PrimaryStatus = 1
Cache1SRAMType = 2
Cache1Size = 256
Cache1Type = 4
Cache1WritePolicy = 0
Cache2Associativity = 7
Cache2ErrorMethodology = 5
Cache2Level = 1
82 Dell Lifecycle Controller Web Services Interface Guide for Windows
Cache2PrimaryStatus = 1
Cache2SRAMType = 2
Cache2Size = 2048
Cache2Type = 5
Cache2WritePolicy = 0
Cache3Associativity = 14
Cache3ErrorMethodology = 5
Cache3Level = 2
Cache3PrimaryStatus = 1
Cache3SRAMType = 2
Cache3Size = 20480
Cache3Type = 5
Cache3WritePolicy = 0
Characteristics = 4
CurrentClockSpeed = 2266
ExternalBusClockSpeed = 5860
FQDD = CPU.Socket.2
InstanceID = CPU.Socket.2
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
Manufacturer = Intel
MaxClockSpeed = 3600
Model = Intel(R) Xeon(R) CPU E5520 @ 2.27GHz
NumberOfEnabledCores = 4
NumberOfEnabledThreads = 8
NumberOfProcessorCores = 4
PrimaryStatus = 1
83 Dell Lifecycle Controller Web Services Interface Guide for Windows
Voltage = 1.20
DCIM_CPUView CPUFamily = B3 CPUStatus = 1 Cache1Associativity = 7
Cache1ErrorMethodology = 5
.
.
.
9.5 iDRAC Card Inventory
This section describes the implementation for the DCIM_iDRACCardView class. The Dell iDrac Profile describes the platform’s iDrac remote access card. Each remote access card’s information is represented by an instance of DCIM_iDRACCARDView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_iDRACCardView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_iDRACCARDView -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman:443 -auth:basic
-encoding:utf-8 -SkipCACheck –SkipCNCheck
OUTPUT:
DCIM_iDRACCardView
FQDD = iDRAC.Embedded.1
FirmwareVersion = 1.00.00
GUID = 314b544f-c0b5-5180-5210-00484c4c454 IPMIVersion = 2.0
InstanceID = iDRAC.Embedded.1-1#IDRACinfo LANEnabledState = 1 LastSystemInventoryTime = 20100331101859 LastUpdateTime = 19700101000000
Model = Enterprise
PermanentMACAddress = 0:21:9b:92:70:5f
ProductDescription = This system component provides a complete set of remote management functions for Dell PowerEdge server
84 Dell Lifecycle Controller Web Services Interface Guide for Windows
SOLEnabledState = 1
URLString = https://192.35.10.1:443
9.6 PCI Device Inventory
This section describes the implementation for the DCIM_PCIDeviceView class. The Dell PCI Profile
describes platform’s PCI devices. Each PCI device’s information is represented by an instance of
DCIM_PCIDeviceView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_PCIDeviceView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_PCIDeviceView -u:[USER] -p:[PASSWORD] ­r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8 -SkipCACheck – SkipCNCheck
OUTPUT:
DCIM_PCIDeviceView
BusNumber = 0
DataBusWidth = 0002
Description = 82801I (ICH9 Family) USB UHCI Controller #4
DeviceNumber = 26
FQDD = USBUHCI.Embedded.4-1
FunctionNumber = 0
InstanceID = USBUHCI.Embedded.4-1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
Manufacturer = Intel Corporation
PCIDeviceID = 2937
PCISubDeviceID = 0236
PCISubVendorID = 1028
85 Dell Lifecycle Controller Web Services Interface Guide for Windows
PCIVendorID = 8086
SlotLength = 0002
SlotType = 0002
DCIM_PCIDeviceView
BusNumber = 0
DataBusWidth = 0002
Description = 5520/5500/X58 I/O Hub PCI Express Root Port 3
DeviceNumber = 3
FQDD = P2PBridge.Embedded.4-1
FunctionNumber = 0
InstanceID = P2PBridge.Embedded.4-1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
Manufacturer = Intel Corporation
PCIDeviceID = 340A
PCISubDeviceID = 0000
PCISubVendorID = 0000
PCIVendorID = 8086
SlotLength = 0002
SlotType = 0002
DCIM_PCIDeviceView
.
.
.
86 Dell Lifecycle Controller Web Services Interface Guide for Windows
9.7 Video Inventory
This section describes the implementation for the DCIM_VideoView class. The Dell Video Profile describes platform’s videos. Each video controller’s information is represented by an instance of DCIM_VideoView class.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate DCIM_VideoView with the following parameters and syntax:
EXAMPLE:
winrm e cimv2/root/dcim/DCIM_VideoView
-u:[USER] -p:[PASSWORD] -r:https://[IPADDRESS]/wsman:443
-auth:basic -encoding:utf-8 -SkipCACheck –SkipCNCheck
OUTPUT:
DCIM_VideoView
BusNumber = 6
DataBusWidth = 0002
Description = PowerEdge R610 MGA G200eW WPCM450
DeviceNumber = 3
FQDD = Video.Embedded.1-1
FunctionNumber = 0
InstanceID = Video.Embedded.1-1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
Manufacturer = Matrox Graphics, Inc.
PCIDeviceID = 0532
PCISubDeviceID = 0236
PCISubVendorID = 1028
PCIVendorID = 102B
87 Dell Lifecycle Controller Web Services Interface Guide for Windows
SlotLength = 0002
SlotType = 0002
9.8 VFlash SD Card Inventory
Each SD card partition is represented by an instance of DCIM_VFlashView that is used to represent the physical attributes of the virtual flash media, such as total size, available size, category etc. on which the partitions will reside. See Section 13 for more information.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate the DCIM_VFlashView with the following parameters and syntax:
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_VFlashView -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_VFlashView
AvailableSize = 970
Capacity = 976
ComponentName = vFlash SD Card
FQDD = Disk.vFlashCard.1
HealthStatus = OK
InitializedState = Initialized
InstanceID = Disk.vFlashCard.1
LastSystemInventoryTime = 20100408123517
LastUpdateTime = 20100408123517
Licensed = true
VFlashEnabledState = true
WriteProtected = false
88 Dell Lifecycle Controller Web Services Interface Guide for Windows
9.9 NIC Inventory and Configuration
The NIC Profile describes NIC controller’s representation and configuration. The profile also describes the relationship of the NIC classes to the DMTF/Dell profile version information. See Section 15 for more information, including inventories for NICString, NICInteger, and NICEnumeration.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate NICView with the following parameters and syntax:
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_NICView -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_NICView
AutoNegotiation = 0
BusNumber = 1
ControllerBIOSVersion = 1.3
CurrentMACAddress = 0:21:9B:92:70:57 DataBusWidth = 0002
DeviceNumber = 0
EFIVersion = null
FCoEOffloadMode = 3
FCoEWWNN = null
FQDD = NIC.Embedded.1-1 FamilyVersion = null FunctionNumber = 0
InstanceID = NIC.Embedded.1-1 LastSystemInventoryTime = 20100413135024
LastUpdateTime = 20100413134727
LinkDuplex = 0
LinkSpeed = 0
MaxBandwidth = 0
MediaType = 4
89 Dell Lifecycle Controller Web Services Interface Guide for Windows
MinBandwidth = 0
NicMode = 3
PCIDeviceID = 1639 PCISubDeviceID = 236 PCISubVendorID = 1028 PCIVendorID = 14E4
PermanentFCOEMACAddress
PermanentMACAddress = 00:21:9B:92:70:57 PermanentiSCSIMACAddress = 00:21:9B:92:70:58
ProductName = Broadcom NetXtreme Gigabit Ethernet - 00:21:9B:92:70:57
ReceiveFlowControl = 0
SlotLength = 0002
SlotType = 0002 TransmitFlowControl = 0
VendorName = null WWPN = null iScsiOffloadMode = 3
DCIM_NICView
AutoNegotiation = 0
BusNumber = 1
ControllerBIOSVersion = 1.3
CurrentMACAddress = 00:21:9B:92:70:59 DataBusWidth = 000 2
DeviceNumber = 0
EFIVersion = null FCoEOffloadMode = 3 FCoEWWNN = null
FQDD = NIC.Embedded.2-1 FamilyVersion = null FunctionNumber = 1
InstanceID = NIC.Embedded.2-1 LastSystemInventoryTime = 20100413135024 LastUpdateTime = 20100413134727
LinkDuplex = 0
LinkSpeed = 0
MaxBandwidth = 0
MediaType = 4
MinBandwidth = 0
NicMode = 3
90 Dell Lifecycle Controller Web Services Interface Guide for Windows
PCIDeviceID = 1639 PCISubDeviceID = 236 PCISubVendorID = 1028 PCIVendorID = 14E4
PermanentFCOEMACAddress
PermanentMACAddress = 00:21:9B:92:70:59 PermanentiSCSIMACAddress = 00:21:9B:92:70:5A
ProductName = Broadcom NetXtreme Gigabit Ethernet - 00:21:9B:92:70:59
ReceiveFlowControl = 0
SlotLength = 0002
SlotType = 0002 TransmitFlowControl = 0 VendorName = null
WWPN = null iScsiOffloadMode = 3
.
.
.
9.10 RAID Inventory and Configuration
The RAID profile extends the management capabilities of referencing profiles by adding the capability to represent the configuration of RAID storage. The RAID storage is modeled as collections of attributes where there are collections for the storage adaptors, physical disks, logical disks, end enclosures and parent-child relationships between the collections. Additionally, there is a configuration service that contains all the methods used to configure the RAID storage. See Section 16 for more information, including inventories for PhysicalDiskView, VirtualDiskView, and EnclosureView.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate ControllerView with the following parameters and syntax:
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_ControllerView -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNCheck -SkipCACheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_ControllerView
Bus = 3
91 Dell Lifecycle Controller Web Services Interface Guide for Windows
CacheSizeInMB = 1024
CachecadeCapability = 1
ControllerFirmwareVersion = 20.10.1-0049
Device = 0
DeviceCardDataBusWidth = 1
DeviceCardManufacturer = DELL
DeviceCardSlotLength = 3
DeviceCardSlotType = PCI Express x8
DriverVersion = null
EncryptionCapability = 0
EncryptionMode = 0
FQDD = RAID.Integrated.1-1
Function = 0
InstanceID = RAID.Integrated.1-1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100330124133
PCIDeviceID = 73
PCISlot = 1
PCISubDeviceID = 1F51
PCISubVendorID = 1028
PCIVendorID = 1000
PatrolReadState = 1
PrimaryStatus = 0
ProductName = PERC H310 Mini
RollupStatus = 0
SASAddress = 50026B902A8B6E00
SecurityStatus = 0
92 Dell Lifecycle Controller Web Services Interface Guide for Windows
SlicedVDCapability = 1
9.11 BIOS Inventory and Configuration
The BIOS Management Profile extends the management capabilities of referencing profiles by adding the capability to represent and configure BIOS attributes, such as a Network Controller or IDE Controller. The
individual BIOS attribute’s relationship with a respective device is also described. Additionally, the profile’s
registration for the schema implementation version information is described. See Section 17 for more information, including inventories for BIOSString, and BIOSInteger.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate BIOSEnumeration with the following parameters and syntax:
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-
schema/2/root/dcim/DCIM_BIOSEnumeration -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman -SkipCNcheck -SkipCAcheck -encoding:utf-8 -a:basic
OUTPUT:
DCIM_BIOSEnumeration
AttributeDisplayName = Memory Operating Voltage AttributeName = MemVolt
CurrentValue = AutoVolt
Dependency = <Dep><AttrLev Op="OR"><ROIf Op="NOT" Name="SysProfile">Custom</ROIf></AttrLev><ValLev Val="AutoVolt" Op="OR"><ForceIf Name="SysProfile">PerfPerWattOptimizedDapc</ForceIf><ForceIf Name="SysProfile">PerfPerWattOptimizedOs</ForceIf><ForceIf Name="SysProfile">PerfOptimized</ForceIf><SupIf Name="SysProfile">DenseCfgOptimized</SupIf></ValLev><ValLev Val="Volt15V" Op="OR"><ForceIf Name="SysProfile">DenseCfgOptimized</ForceIf><SupIf Name="SysProfile">PerfPerWattOptimizedDapc</SupIf><SupIf Name="SysProfile">PerfPerWattOptimizedOs</SupIf><SupIf Name="SysProfile">PerfOptimized</SupIf></ValLev></Dep>
DisplayOrder = 1322
FQDD = BIOS.Setup.1-1
GroupDisplayName = System Profile Settings
GroupID = SysProfileSettings
93 Dell Lifecycle Controller Web Services Interface Guide for Windows
InstanceID = BIOS.Setup.1-1:MemVolt
IsReadOnly = true
PendingValue = null
PossibleValues = AutoVolt, Volt15V
PossibleValuesDescription = Auto, 1.5V
DCIM_BIOSEnumeration
AttributeDisplayName = Serial Debug Output
AttributeName = SerialDbgOut
CurrentValue = Disabled
Dependency = null
DisplayOrder = 319
FQDD = BIOS.Setup.1-1
GroupDisplayName = Memory Settings
GroupID = MemSettings
InstanceID = BIOS.Setup.1-1:SerialDbgOut
IsReadOnly = false
PendingValue = null
PossibleValues = Enabled, Disabled
PossibleValuesDescription = Enabled, Disabled
DCIM_BIOSEnumeration
AttributeDisplayName = Password Status AttributeName = PasswordStatus
CurrentValue = Unlocked
Dependency = null
DisplayOrder = 1405
FQDD = BIOS.Setup.1-1
GroupDisplayName = System Security
GroupID = SysSecurity
94 Dell Lifecycle Controller Web Services Interface Guide for Windows
InstanceID = BIOS.Setup.1-1:PasswordStatus
IsReadOnly = false
PendingValue = null
PossibleValues = Unlocked, Locked
PossibleValuesDescription = Unlocked, Locked
.
.
.
9.12 System Inventory (Including CSIOR Attribute)
This section describes the implementation for the DCIM_SystemView class which is used to represent the higher level attributes of the system, such as asset tag, model, server manufacturer, etc.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
Enumerate SystemView with the following parameters and syntax:
EXAMPLE:
winrm e http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/root/dcim/
DCIM_SystemView -u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman
-SkipCNcheck -SkipCAcheck
-encoding:utf-8 -a:basic
OUTPUT:
DCIM_SystemView
AssetTag = Testtg
BIOSReleaseDate = 09/12/2011
BIOSVersionString = 0.3.22
BaseBoardChassisSlot = NA
BatteryRollupStatus = 1
95 Dell Lifecycle Controller Web Services Interface Guide for Windows
BladeGeometry = 4
BoardPartNumber = 0N051FX02
BoardSerialNumber = CN1374092O003M
CMCIP = null
CPLDVersion = 0.4.7
CPURollupStatus = 1
ChassisName = Main System Chassis
ChassisServiceTag = 7654321
ChassisSystemHeight = 2
ExpressServiceCode = 61387326761
FQDD = System.Embedded.1
FanRollupStatus = 3
HostName
InstanceID = System.Embedded.1
LastSystemInventoryTime = 20100331101859
LastUpdateTime = 20100325134947
LicensingRollupStatus = 1
LifecycleControllerVersion = 2.0.0
Manufacturer = Dell Inc.
MaxCPUSockets = 2
MaxDIMMSlots = 24
MaxPCIeSlots = 3
MemoryOperationMode = OptimizerMode
Model = PowerEdge R620
PSRollupStatus = 1
PlatformGUID = 3548474f-c0d3-4680-3810-00374c4c4544
PopulatedCPUSockets = 1
96 Dell Lifecycle Controller Web Services Interface Guide for Windows
PopulatedDIMMSlots = 1
PopulatedPCIeSlots = 1
PowerCap = 0
PowerCapEnabledState = 3
PowerState = 2
PrimaryStatus = 3
RollupStatus = 3
ServerAllocation = null
ServiceTag = S78FGH5
StorageRollupStatus = 1
SysMemErrorMethodology = 6
SysMemFailOverState = NotInUse
SysMemLocation = 3
SysMemPrimaryStatus = 1
SysMemTotalSize = 2048
SystemGeneration = 12G Monolithic
SystemID = 1230
SystemRevision = 0
TempRollupStatus = 1
UUID = 4c4c4544-0037-3810-8046-d3c04f474835
VoltRollupStatus = 1
smbiosGUID = 44454c4c-3700-1038-8046-d3c04f474835
97 Dell Lifecycle Controller Web Services Interface Guide for Windows
10 Job Control Management
10.1 Description of Job Management
The Dell Common Information Model (CIM) class extensions for supporting update and attribute configuration job control are defined in the Dell Job Control Profile 2 and related MOF files 3. The diagrams representing the classes that are implemented by the Lifecycle Controller firmware can be found in Dell Job Control Profile as well.
Profile and Associated MOFs:
http://www.delltechcenter.com/page/DCIM.Library.Profile
10.2 Remote Job Control Examples
10.2.1 Setup Job Queue
The SetupJobQueue() method takes in an array of jobids and schedules them to run immediately or at a later time. The jobids are acquired via enumerating DCIM_LifecycleJob as described in Section 10.2.3. When there is a Reboot Job, in a job array that contains multiple jobs, the system will reboot the UEFI (Unified Extensible Firmware Interface) at the scheduled time.
Invoke SetupJobQueue() with the following parameters and syntax:
JobArray: The jobids are listed in the JobArray element. Multiple jobs are listed in the order of job execution sequence. If a system is to reboot at the scheduled start time, a reboot job will need to be added to the list. This reboot job has a prefix of RID_ for its jobid.
Note, scheduling a job that is already scheduled will result in an error message.
If there is no reboot job in the job array, the system will schedule the jobs for execution at the specified start time. The jobs will not be executed until the system is rebooted by something other than Lifecycle Controller. At the specified UntilTime, any jobs that have not been executed are failed with an error indicating that the job was not executed in the specified maintenance window. For some component updates such as Diagnostics, USC, and iDRAC firmware, a system reboot is not needed.
EXAMPLE:
winrm invoke SetupJobQueue cimv2/root/dcim/DCIM_JobService
?CreationClassName=DCIM_JobService
+Name=JobService+SystemName=Idrac
+SystemCreationClassName=DCIM_ComputerSystem
98 Dell Lifecycle Controller Web Services Interface Guide for Windows
-file:SetupJobQueue.xml
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8
The syntax for SetupJobQueue.xml is:
<p:SetupJobQueue_INPUT xmlns:p="http://schemas.dmtf.org/wbem/wscim/1/cimschema/
2/root/dcim/DCIM_JobService">
<p:JobArray>JID_001249463339</p:JobArray>
<p:JobArray>RID_001265817718</p:JobArray>
<p:StartTimeInterval>TIME_NOW</p:StartTimeInterval>
<p:UntilTime>20100730121500</p:UntilTime>
</p:SetupJobQueue_INPUT>
Here the JobArray element shows a list of Jobids that are to be scheduled to run. TIME_NOW is a special value that represents “running the tasks immediately”. The UntilTime value specifies the “maintenance windows”. Once a task is not run after passing UntilTime, it should not be run again.
Upon successfully invocation of the SetupJobQueue() method, the aforementioned times will be listed when enumerated in Section 10.2.3.
OUTPUT:
Returns 0 for success or non-zero for error with messageID and message description.
SetupJobQueue_OUTPUT
ReturnValue = null
Entering an invalid jobid or XML syntax error can yield one of the following error messages:
SetupJobQueue_OUTPUT
Message = Job Cannot be Scheduled
MessageID = SUP016
ReturnValue = null
SetupJobQueue_OUTPUT
Message = Duplicated/Invalid JOBID Entries
MessageID = SUP023
99 Dell Lifecycle Controller Web Services Interface Guide for Windows
ReturnValue = null
10.2.2 Delete Job Queue
The DeleteJobQueue() method takes in a jobID and then deletes it from the job store.
Note: When clearing all jobs and pending data using the keyword JID_CLEARALL, as shown in example 2 below, the remote services instrumention is restarted to clear the cache [LC 1.x ONLY]. Users should allow two minutes for this process to complete.
Invoke DeleteJobQueue() with the following parameters and syntax:
[JobID]: The jobID of a particular job instance to be deleted from a jobqueue
EXAMPLE 1:
winrm invoke DeleteJobQueue cimv2/root/dcim/DCIM_JobService ?CreationClassName=DCIM_JobService +Name=JobService+SystemName=Idrac +SystemCreationClassName=DCIM_ComputerSystem @{JobID=”[jobID]” }-u:[USER] ­p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8
The example below uses JID_CLEARALL for the jobID, which is a predefined value that represents
“deleting all jobs in the jobstore”.
EXAMPLE 2:
winrm invoke DeleteJobQueue cimv2/root/dcim/DCIM_JobService ?CreationClassName=DCIM_JobService+Name=JobService +SystemName=Idrac +SystemCreationClassName=DCIM_ComputerSystem @{JobID="JID_CLEARALL" }
-u:[USER] -p:[PASSWORD]
-r:https://[IPADDRESS]/wsman:443 -auth:basic -encoding:utf-8 -SkipCACheck – SkipCNCheck
OUTPUT:
Return 0 for success or non-zero for error with messageID and message description.
DeleteJobQueue_OUTPUT
Message = The specified job was deleted
MessageID = SUP020
ReturnValue = null
100 Dell Lifecycle Controller Web Services Interface Guide for Windows
