Dell™ Latitude™ XFR D630
FULLY-RUGGED NOTEBOOK
STEP 1:
TURN IT ON.
STEP 2:
BRING IT ON.
Page 2
Dell™ Latitude™ XFR D630 FULLY-RUGGED NOTEBOOK
RUGGED AND READY
Dell has changed the way people look at the rugged industry once again with the introduction
of the Dell™ Latitude™ XFR D630 Fully-Rugged Notebook. With Dell, you get state-of-the-art
technologies, the highest performance, the smartest security and the most robust functionality.
ARMORED PROTECTION
COMMON IT PLATFORM.
UNCOMMON STRENGTH.
Dell™ Latitude™ XFR Notebooks maintain the same
BIOS, Firmware, Drivers, Image, and Utilities as our
standard D-family Latitude platforms. Customers
adopting common D-family platforms now have a
100% compatible, fully-rugged system to address
their most challenging applications.
In addition, IT managers have a single support
model which will help reduce complexity and
improve eciency while supporting deployed
systems.
RUGGED DESIGN.
The XFR is the result of superior design expertise
and a proven Armored Protection System™ (APS),
which is comprised of three powerful elements
– Advanced Construction Materials, Unique
Engineering Designs and Independent MIL-STD810F Testing.
SYSTEM (APS)
CONSTRUCTION MATERIALS
• Dense Magnesium Alloy Housing
• Thermo-Elastomer Composite Overmold
• Reinforced Fiberglass Injected Polycarbonate (FIP)
• Channeled Die Cast Compression Gaskets (CDCG)
• Optically-Clear Seals
• Custom Paint Sealant Mixture
UNIQUE ENGINEERING DESIGNS
• Robust Exoskeleton Structure
• Patent-pending QuadCool™ Thermal Management
System
• Reinforced LCD Assembly
• Overmold Protection System
• Sealed Keyboard and Touchpad Assembly
• Reinforced and Thermally-Enhanced HDD Access Bay
• Secure Battery Protection System
• Dense Magnesium Hinged and Friction Fit Doors
MIL–STD–810F TESTING
• Published specifications, independently tested
• Operating temperature — -20˚F to 140˚ F
(-29˚C to 60˚C)
• Moisture ingress — 4 in/hr rain, 40 psi (IP54)
• Dust, Dirt ingress — 1.5 m/s – 8.7 m/s wind (IP54)
• Drop/Shock — 36” drop, 26X non-yielding surface
• Vibration — random vibration simulation, 1000 miles
transportation
• Humidity — 0 to 95% non-condensing
• Altitude — 15,000 ft operating
• Crash Shock — 40g, 11ms; 75g, 6ms
• Salt Fog
Page 3
BIGGER. BRIGHTER. SHARPER.
Take advantage of the 14.1” wide-aspect LCD with
DirectVue™ technology - one of the largest in the
rugged industry - rated as brighter, sharper and
more vivid for excellent readability. The Latitude
XFR DirectVue™ technology oers optimal sunlight
readability because of its increased brightness,
reduced reflectivity, and proprietary optical
enhancements. An optional Touch screen is
available that supports reliable finger (gloved) and
passive stylus inputs.
IN SHORT, THE XFR TAKES
WHATEVER YOU THROW AT IT
OR THROW IT AT.
LOWER COST OF OWNERSHIP
Because the XFR will continue to operate through
drops, shocks, spills, extreme temperatures,
vibrations and other challenging conditions found
in the harshest environments, you’ll be able to
experience more uptime and less maintenance with
this fully-rugged system. And deployment, support,
and training costs will be lower because the XFR
shares the same architecture as Dell Latitude
D-family notebooks.
CHOOSE YOUR RUGGED LOOK
The XFR D630 is rugged and striking from the inside
out and is available with or without a touch screen
and in two standard exterior color options...Desert
Tan or Black & Charcoal. Choose your rugged look to
blend in or stand out.
Best outdoor-readable screen of any
notebook currently on the market.
Geo Walker, Pen Computing
May 18, 2007 edition
“
NEXT-GENERATION PERFORMANCE.
The Dell™ Latitude™ XFR D630 delivers a superior
computing platform that provides the most
technologically-advanced features available in a rugged
mobile device.
• The latest Intel® Core™ 2 Duo, Dual Core processors
• Integrated graphics with Intel’s GMA X3100
• Hyperconnect™ Wireless technology – providing simple,
reliable and secure productivity for mobile personnel
• Advanced wireless WAN, Broadband, and Bluetooth®
technologies
• The Smart Security Suite – multi-level security providing
maximum protection of the physical system and its data
and prevention of unauthorized access
• Superior battery performance for extended field use
and a quick-charge battery recharge system
”
Desert Tan
WORLD-CLASS QUALITY, RELIABILITY, AND SUPPORT
You can expect superior, world-class quality and reliability
from your XFR based on the combination of awardwinning core system elements and quality programs
from Dell with the proven rugged design and production
expertise from Dell. The XFR from Dell has a global
technical support and warranty service program that
provides:
• Exceptional levels of service and turnaround
• Consistency of parts over the product lifecycle
Black
Page 4
Dell™ Latitude™ XFR D630 FULLY-RUGGED NOTEBOOK
THROUGH RAIN,
DUST OR HEAT.
AND THAT’S JUST
FOR STARTERS.
TESTING AND CERTIFICATION SUMMARY
Shock/Drop
• 36”, 26 Drops on each face onto non-yielding surface
• MIL-STD-810F, Modified Method 516.5, Procedure IV
Dust Ingress
• MIL-STD-810F, Method 510.4, Procedure I (Blowing Dust)
• IP Rating of IP54 - water and dust ingress
Operating/Non-Operating Temperature and Thermal Shock
• -20˚F to 140˚F (-29˚ to 60˚C) Operating
• MIL-STD-810F, Methods 501.4 and 502.4, Procedures I + II
and Method 503.4
Rain/Moisture Ingress
• 4 in/hr, 40 psi all 6 axes
• MIL-STD-810F, Modified Method 506.4, Procedure II
• Test done with I/O doors in place
• IP Rating of IP54-water and dust ingress
Salt Fog Protection
• Cycle 48-hour exposure cycles
• MIL-STD-810F, Modified Method 509.4
TECHNICAL SPECIFICATIONS
CPU/PERFORMANCE
• Intel® Core™ 2 Duo (Dual Core) Processors (up to 2.2
GHz)
• 800MHz Front Side Bus, up to 4MB L2 Smart Cache
SYSTEM MEMORY
• Supports 512MB to 4056MB of 667MHz
• Advanced DDR2 Dual Channel Memory
RUGGED STORAGE CAPABILITIES
• HDD Shock Isolation and Protection Cage based on
proprietary design
• User Accessible HDD Cage supports “lock down” and
“expedited access”
• 1.8” 80GB3 shock-resistant, isolated and protected
HDD; 32GB-64GB Solid State Storage Options
VIDEO AND GRAPHICS CHARACTERISTICS
• Intel® GMA X3100 integrated graphics
• Optimized performance supports Windows® Vista®
Software and Aero graphics feature
1
DISPLAY AND READABILITY
• Rugged, protected 14.1” Wide-Aspect WXGA
DirectVue™ display
• DirectVue™ display enhancements and augmentations
support superior outdoor readability.
• 14.1” WXGA resolution (1280 x 800)
• Shock isolated, impact protected and sealed from
moisture and dust
• Optional integrated Touch Screen option.
INTEGRATED MULTI-MODAL WIRELESS
• State-of-the-Art Broadband4, Wireless LAN, Bluetooth
and GPS Capabilities
MODULAR MEDIA BAY OPTIONS
• 24X CD-ROM, 8X DVD-ROM, 24X CDRW/DVD, 8X
DVD+/-RW, Floppy Disk Drive
• 6-cell “Smart” Li-Polymer battery, Second 80GB2 NonRugged Hard Disk Drive or TravelLite™ Module
EXPANSION SLOTS
• Secured and Protected within rugged sealed door
construction
• 1 x PC card slot Type I/II with ExpressCard 34 mm
support
Crash Shock
• 40g, 11 m/s & 75g, 6ms terminal saw-tooth
• MIL-STD-810F, Method 516.5
Hazardous Material Certifications
• XFR operated under intended use is incapable of causing
ignition of specific flammable gas or vapor-air mix
• Optional UL 1604 Class 1, Division II for Zones A, B, C, D
Humidity: MIL-STD-810F Method 507.4
• 0% to 95% non-condensing
Altitude: MIL-STD-810F Method 500.4
• Operating 15,000 ft.
Vibration: MIL-STD-810F Method 514.5C-17
• Categories 20 & 24
POWER ELEMENTS AND MANAGEMENT
• All Battery options are secured by a dense gasketed
magnesium door to help ensure maximum protection
• Primary 6-cell / 56 WHr “Smart” Lithium Ion battery
featuring ExpressCharge™
SOFTWARE
• Microsoft® Windows® XP Professional SP2
• Dell Quickset™ Software suite
• Microsoft® Windows® Vista™ (option)
PHYSICAL CHARACTERISTICS
• Dimensions: 2.6” (H) x 13.9” (W) x 10.2” (D)
• Weight: Starting at 8.98 lbs.
WARRANTY & SUPPORT
• 3-Year Standard Limited Warranty3, 24x7/365
Technical Support
5
1. Significant system memory may be allocated to support graphics, depending on system memory size and other factors. 2. For hard drives, GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with
preloaded material and operating environment and will be less. 3. For a copy of limited warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or visit www.dell.com/warranty. 4. Subject to wireless
provider’s broadband subscription and coverage area; additional charges apply. 5. Weights vary depending on configurations and manufacturing variability.
Dell, the Dell logo, Latitude and Quickset are trademarks of Dell Inc. Intel, the Intel Logo, and Core are trademarks or registered trademarks of Intel Corporation. Microsoft, Windows and Vista are trademarks or registered
trademarks of Microsoft Corporation. Augmentix, Armored Protection System (APS), QuadCool, and DirectVue are registered trademarks or trademarks of Augmentix Corporation. Other trademarks and trade names may be
used in this document to refer to either entities claiming the marks and names of their products. February 2008. A2G.
