Page 1
Inspiron 15-5578
2-in-1
Service Manual
Reg ula tor y M ode l: P58 F
Reg ula tor y T ype : P 58F 001
Nov emb er 202 0
Rev . A 03
Page 2
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2016-2020 Dell Inc. or its subsidiaries. All rights reserved. Del l, EMC , and other trademarks are trademarks of Dell Inc. or its subsidiar ies .
Other trademarks may be trademarks of their respective owners.
Page 3
Contents
Chapter 1: Before working inside your computer........................................................................... 8
Before you begin .................................................................................................................................................................8
Safety instructions.............................................................................................................................................................. 8
Recommended tools........................................................................................................................................................... 9
Screw list............................................................................................................................................................................... 9
Chapter 2: After working inside your computer............................................................................ 11
Chapter 3: Removing the base cover............................................................................................ 12
Procedure.............................................................................................................................................................................12
Chapter 4: Replacing the base cover............................................................................................ 14
Procedure.............................................................................................................................................................................14
Chapter 5: Removing the battery................................................................................................. 15
Prerequisites....................................................................................................................................................................... 15
Procedure............................................................................................................................................................................ 15
Chapter 6: Replacing the battery................................................................................................. 16
Procedure............................................................................................................................................................................ 16
Post-requisites....................................................................................................................................................................16
Chapter 7: Removing the memory modules...................................................................................17
Prerequisites........................................................................................................................................................................17
Procedure.............................................................................................................................................................................17
Chapter 8: Replacing the memory modules.................................................................................. 19
Procedure............................................................................................................................................................................ 19
Post-requisites...................................................................................................................................................................20
Chapter 9: Removing the hard drive.............................................................................................21
Prerequisites........................................................................................................................................................................21
Procedure.............................................................................................................................................................................21
Chapter 10: Replacing the hard drive........................................................................................... 24
Procedure............................................................................................................................................................................24
Post-requisites...................................................................................................................................................................24
Chapter 11: Removing the coin-cell battery................................................................................. 25
Prerequisites.......................................................................................................................................................................25
Procedure............................................................................................................................................................................25
Chapter 12: Replacing the coin-cell battery................................................................................. 26
Contents 3
Page 4
Procedure............................................................................................................................................................................26
Post-requisites...................................................................................................................................................................26
Chapter 13: Removing the wireless card...................................................................................... 27
Prerequisites....................................................................................................................................................................... 27
Procedure............................................................................................................................................................................27
Chapter 14: Replacing the wireless card...................................................................................... 28
Procedure............................................................................................................................................................................28
Post-requisites...................................................................................................................................................................29
Chapter 15: Removing the keyboard daughter-board................................................................... 30
Prerequisites.......................................................................................................................................................................30
Procedure............................................................................................................................................................................30
Chapter 16: Replacing the keyboard daughter-board................................................................... 32
Procedure............................................................................................................................................................................32
Post-requisites...................................................................................................................................................................32
Chapter 17: Removing the status-light board...............................................................................33
Prerequisites.......................................................................................................................................................................33
Procedure............................................................................................................................................................................33
Chapter 18: Replacing the status-light board...............................................................................35
Procedure............................................................................................................................................................................35
Post-requisites...................................................................................................................................................................35
Chapter 19: Removing the touchpad............................................................................................ 36
Prerequisites.......................................................................................................................................................................36
Procedure............................................................................................................................................................................36
Chapter 20: Replacing the touchpad............................................................................................39
Procedure............................................................................................................................................................................39
Post-requisites...................................................................................................................................................................39
Chapter 21: Removing the speakers............................................................................................. 40
Prerequisites.......................................................................................................................................................................40
Procedure............................................................................................................................................................................40
Chapter 22: Replacing the speakers............................................................................................ 42
Procedure............................................................................................................................................................................42
Post-requisites...................................................................................................................................................................42
Chapter 23: Removing the fan..................................................................................................... 43
Prerequisites.......................................................................................................................................................................43
Procedure............................................................................................................................................................................43
Chapter 24: Replacing the fan..................................................................................................... 44
4
Contents
Page 5
Procedure............................................................................................................................................................................44
Post-requisites...................................................................................................................................................................44
Chapter 25: Removing the heat sink............................................................................................ 45
Prerequisites.......................................................................................................................................................................45
Procedure............................................................................................................................................................................45
Chapter 26: Replacing the heat sink............................................................................................ 46
Procedure............................................................................................................................................................................46
Post-requisites...................................................................................................................................................................46
Chapter 27: Removing the power-adapter port............................................................................ 47
Prerequisites....................................................................................................................................................................... 47
Procedure............................................................................................................................................................................47
Chapter 28: Replacing the power-adapter port............................................................................ 49
Procedure............................................................................................................................................................................49
Post-requisites...................................................................................................................................................................49
Chapter 29: Removing the power and volume-buttons board.......................................................50
Prerequisites.......................................................................................................................................................................50
Procedure............................................................................................................................................................................50
Chapter 30: Replacing the power and volume-buttons board....................................................... 52
Procedure............................................................................................................................................................................52
Post-requisites...................................................................................................................................................................52
Chapter 31: Removing the I/O board............................................................................................53
Prerequisites.......................................................................................................................................................................53
Procedure............................................................................................................................................................................53
Chapter 32: Replacing the I/O board........................................................................................... 55
Procedure............................................................................................................................................................................55
Post-requisites...................................................................................................................................................................55
Chapter 33: Removing the system board..................................................................................... 56
Prerequisites.......................................................................................................................................................................56
Procedure............................................................................................................................................................................56
Chapter 34: Replacing the system board..................................................................................... 60
Procedure............................................................................................................................................................................60
Post-requisites...................................................................................................................................................................60
Entering the Service Tag in the BIOS setup program..............................................................................................60
Chapter 35: Removing the display assembly................................................................................ 61
Prerequisites....................................................................................................................................................................... 61
Procedure............................................................................................................................................................................ 61
Contents
5
Page 6
Chapter 36: Replacing the display assembly................................................................................ 63
Procedure............................................................................................................................................................................63
Post-requisites...................................................................................................................................................................63
Chapter 37: Removing the palm-rest and keyboard assembly...................................................... 64
Prerequisites.......................................................................................................................................................................64
Procedure............................................................................................................................................................................64
Chapter 38: Replacing the palm-rest and keyboard assembly...................................................... 66
Procedure............................................................................................................................................................................66
Post-requisites...................................................................................................................................................................66
Chapter 39: Removing the display panel...................................................................................... 67
Prerequisites....................................................................................................................................................................... 67
Procedure............................................................................................................................................................................67
Chapter 40: Replacing the display panel...................................................................................... 69
Procedure............................................................................................................................................................................69
Post-requisites...................................................................................................................................................................69
Chapter 41: Removing the display cable....................................................................................... 70
Prerequisites.......................................................................................................................................................................70
Procedure............................................................................................................................................................................70
Chapter 42: Replacing the display cable...................................................................................... 72
Procedure............................................................................................................................................................................72
Post-requisites................................................................................................................................................................... 72
Chapter 43: Removing the display back-cover and antenna assembly.......................................... 73
Prerequisites....................................................................................................................................................................... 73
Procedure............................................................................................................................................................................73
Chapter 44: Replacing the display back-cover and antenna assembly.......................................... 74
Procedure............................................................................................................................................................................74
Post-requisites................................................................................................................................................................... 74
Chapter 45: Removing the camera...............................................................................................75
Prerequisites.......................................................................................................................................................................75
Procedure............................................................................................................................................................................75
Chapter 46: Replacing the camera............................................................................................... 77
Procedure............................................................................................................................................................................ 77
Post-requisites................................................................................................................................................................... 77
Chapter 47: Removing the sensor board...................................................................................... 78
Prerequisites....................................................................................................................................................................... 78
Procedure............................................................................................................................................................................78
6
Contents
Page 7
Chapter 48: Replacing the sensor board...................................................................................... 80
Procedure............................................................................................................................................................................80
Post-requisites...................................................................................................................................................................80
Chapter 49: Downloading drivers................................................................................................. 81
Downloading the audio driver..........................................................................................................................................81
Downloading the graphics driver....................................................................................................................................81
Intel USB 3.0 xHCI.............................................................................................................................................................81
Downloading the Wi-Fi driver..........................................................................................................................................81
Downloading the media-card reader driver.................................................................................................................82
Downloading the chipset driver..................................................................................................................................... 82
Downloading the network driver................................................................................................................................... 82
Chapter 50: System setup........................................................................................................... 83
Boot Sequence...................................................................................................................................................................83
Navigation keys..................................................................................................................................................................83
System setup......................................................................................................................................................................83
Entering BIOS setup program........................................................................................................................................ 84
System setup options.......................................................................................................................................................84
System and setup password...........................................................................................................................................88
Assigning a system setup password....................................................................................................................... 88
Deleting or changing an existing system setup password................................................................................. 89
Clearing CMOS settings............................................................................................................................................ 89
Clearing BIOS (System Setup) and System passwords.....................................................................................89
Chapter 51: Troubleshooting....................................................................................................... 90
Flashing the BIOS..............................................................................................................................................................90
Flashing BIOS (USB key)................................................................................................................................................ 90
Dell SupportAssist Pre-boot System Performance Check diagnostics............................................................... 90
Running the ePSA Diagnostics................................................................................................................................. 91
System diagnostic lights...................................................................................................................................................91
Flea power release............................................................................................................................................................ 92
WiFi power cycle............................................................................................................................................................... 92
Chapter 52: Getting help and contacting Dell.............................................................................. 93
Contents
7
Page 8
Before working inside your computer
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Before you begin
1. Save and close all open files and exit all open applications.
2. Shut down your computer.
The shut-down instruction varies depending on the operating system installed on your computer.
● Windows 10: Click Start >
● Windows 8.1: On the Start screen, Click the power icon
● Windows 7: Click Start > Shut down.
NOTE: If you are using a different operating system, see the documentation of your operating system for shut-down
instructions.
3. Disconnect your computer and all attached devices from their electrical outlets.
4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor, from your computer.
5. Remove any media card and optical disc from your computer, if applicable.
Power > Shut down.
> Shut down.
1
Safety instructions
Use the following safety guidelines to protect your computer from potential damage and to ensure your personal safety. Unless
otherwise noted, each procedure included in this document assumes that you have read the safety information that shipped
with your computer.
NOTE:
Before working inside your computer, read the safety information that shipped with your computer. For more safety
best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
NOTE: Disconnect all power sources before opening the computer cover or panels. After you finish working inside the
computer, replace all covers, panels, and screws before connecting to the electrical outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat and clean.
CAUTION: Handle components and cards with care. Do not touch the components or contacts on a card. Hold a
card by its edges or by its metal mounting bracket. Hold a component such as a processor by its edges, not by
its pins.
CAUTION: You should only perform troubleshooting and repairs as authorized or directed by the Dell technical
assistance team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. See the
safety instructions that shipped with the product or at www.dell.com/regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself by using a wrist grounding strap or
by periodically touching an unpainted metal surface, such as the metal at the back of the computer. While you
work, periodically touch an unpainted metal surface to dissipate static electricity, which could harm internal
components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull tab, not on the cable itself. Some
cables have connectors with locking tabs or thumb-screws that you must disengage before disconnecting
the cable. When disconnecting cables, keep them evenly aligned to avoid bending any connector pins. When
connecting cables, ensure that the ports and connectors are correctly oriented and aligned.
8 Before working inside your computer
Page 9
CAUTION: Press and eject any installed card from the media-card reader.
NOTE: The color of your computer and certain components may appear differently than shown in this document.
Recommended tools
The procedures in this document may require the following tools:
● Philips screwdriver #1
● Plastic scribe
Screw list
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Base cover Palm rest and keyboard assembly M2.5x7 10
Battery Palm rest and keyboard assembly M2x3 2
Display hinge Palm rest and keyboard assembly M2.5x7 2
Display hinge Display back-cover and antenna
assembly
Display hinge Display back-cover and antenna
assembly
Fan Palm rest and keyboard assembly M2x3 2
Hard-drive bracket Palm rest and keyboard assembly M2x3 3
Hard drive Hard-drive bracket M3x3 4
I/O board Palm rest and keyboard assembly M2x3 2
Power-adapter port Palm rest and keyboard assembly M2x3 1
Power and volume-buttons board Palm rest and keyboard assembly M2x3 1
System board Palm rest and keyboard assembly M2x2 Big Head 5
M2.5x2.5 Big
Head
M2x3 2
6
Sensor board Display panel M2.5x2.5 Big
Head
Touchpad Palm rest and keyboard assembly M2x2 4
Before working inside your computer 9
1
Page 10
Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Touchpad bracket Palm rest and keyboard assembly M2x2.5 3
Wireless card Palm rest and keyboard assembly M2x3 1
10 Before working inside your computer
Page 11
After working inside your computer
CAUTION: Leaving stray or loose screws inside your computer may severely damage your computer.
1. Replace all screws and ensure that no stray screws remain inside your computer.
2. Connect any external devices, peripherals, or cables you removed before working on your computer.
3. Replace any media cards, discs, or any other parts that you removed before working on your computer.
4. Connect your computer and all attached devices to their electrical outlets.
5. Turn on your computer.
2
After working inside your computer 11
Page 12
Removing the base cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Close the display and turn the computer over.
2. Remove the ten screws (M2.5x7) that secure the base cover to the palm rest and keyboard assembly.
3
Figure 1. Removing screws from the base cover
a. base cover
b. screws (10)
3. Using a plastic scribe, pry the base cover off the palm rest and keyboard assembly.
12 Removing the base cover
Page 13
Figure 2. Removing the base cover
a. plastic scribe
b. palm rest and keyboard assembly
c. base cover
4. Disconnect the battery cable from the system board.
NOTE: Disconnect the battery cable only when you continue to remove other components from your computer.
Figure 3. Disconnecting the battery cable
a. battery cable
Removing the base cover
13
Page 14
Replacing the base cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Connect the battery to the system board, if applicable.
2. Slide the tabs on the base cover into the slots on the palm rest and keyboard assembly and snap the base cover into place.
3. Replace the ten screws (M2.5x7) that secure the base cover to the palm rest and keyboard assembly.
4
14 Replacing the base cover
Page 15
Removing the battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1. Disconnect the battery cable from the system board, if applicable.
2. Press and hold the power button for 5 seconds to ground the system board.
3. Remove the two screws (M2x3) that secure the battery to the palm rest and keyboard assembly.
4. Lift the battery along with its cable off the palm rest and keyboard assembly.
5
Figure 4. Removing the battery
1.
battery cable 2. battery
3. palm rest and keyboard assembly 4. screws (2)
Removing the battery 15
Page 16
Replacing the battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the battery with the screw holes on the palm rest and keyboard assembly.
2. Replace the two screws (M2x3) that secure the battery to the palm rest and keyboard assembly.
3. Connect the battery cable to the system board.
Post-requisites
Replace the base cover.
6
16 Replacing the battery
Page 17
Removing the memory modules
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1. Lift the Mylar from to access the memory module.
7
Figure 5. Removing the memory modules
a. Mylar
b. memory module
2. Use your fingertips to carefully spread apart the securing-clips on each end of the memory-module slot until the memory
module pops up.
3. Remove the memory module from the memory-module slot.
Removing the memory modules 17
Page 18
Figure 6. Removing the memory modules
a. memory-module slot
b. securing clips (2)
c. memory module
18
Removing the memory modules
Page 19
Replacing the memory modules
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Lift the Mylar to access the memory-module slot.
2. Align the notch on the memory module with the tab on the memory-module slot.
3. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
8
Figure 7. Replacing the memory modules
1.
memory-module slot 2. tab
3. notch 4. memory module
Replacing the memory modules 19
Page 20
Post-requisites
Replace the base cover.
20 Replacing the memory modules
Page 21
Removing the hard drive
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard drive.
CAUTION: To avoid data loss, do not remove the hard drive while the computer is in sleep or on state.
Prerequisites
Remove the base cover.
Procedure
9
1. Using the pull tab, disconnect the hard-drive cable from the system board.
2. Peel off the tape that secures the hard-drive cable to the palm rest and keyboard assembly.
3. Note the hard-drive cable routing and remove the cable from the routing guides.
Figure 8. Removing the hard-drive assembly
1.
system board 2. routing guides
3. tape 4. hard-drive assembly
5. palm rest and keyboard assembly 6. hard-drive cable
7. pull tab
Removing the hard drive 21
Page 22
4. Remove the three screws (M2x3) that secure the hard-drive assembly to the palm rest and keyboard assembly.
5. Lift the hard-drive assembly along with its cable off the palm rest and keyboard assembly.
Figure 9. Removing the hard-drive assembly
a. screws (3)
b. hard-drive assembly
c. palm rest and keyboard assembly
6. Disconnect the interposer from the hard-drive assembly.
Figure 10. Disconnecting the interposer
a. hard-drive assembly
b. interposer
7. Remove the four screws (M3x3) that secure the hard-drive bracket to the hard drive.
8. Lift the hard drive off the hard-drive bracket.
22
Removing the hard drive
Page 23
Figure 11. Removing the hard-drive bracket
a. hard drive
b. hard-drive bracket
c. screws (4)
Removing the hard drive
23
Page 24
Replacing the hard drive
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard drive.
Procedure
1. Align the screw holes on the hard-drive bracket with the screw holes on the hard drive.
2. Replace the four screws (M3x3) that secure the hard-drive bracket to the hard drive.
3. Connect the interposer to the hard-drive assembly.
4. Align the screw holes on the hard-drive assembly with the screw holes on the palm rest and keyboard assembly.
5. Replace the screws three (M2x3) that secure the hard-drive assembly to the palm rest and keyboard assembly.
6. Route the hard-drive cable through the routing guides on the palm rest and keyboard assembly.
7. Connect the hard-drive cable to the system board.
8. Adhere the tape that secures the hard-drive cable to the palm rest and keyboard assembly.
10
Post-requisites
Replace the base cover.
24 Replacing the hard drive
Page 25
Removing the coin-cell battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Removing the coin-cell battery resets the BIOS setup program’s settings to default. It is
recommended that you note the BIOS setup program’s settings before removing the coin-cell battery.
Prerequisites
Remove the base cover.
Procedure
1. Disconnect the coin-cell battery cable from the I/O board.
2. Peel the coin-cell battery off the palm rest and keyboard assembly.
11
Figure 12. Removing the coin-cell battery
1.
coin-cell battery cable 2. coin-cell battery
3. I/O board 4. palm rest and keyboard assembly
Removing the coin-cell battery 25
Page 26
Replacing the coin-cell battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Adhere the coin-cell battery to the palm rest and keyboard assembly.
2. Connect the coin-cell battery cable to the I/O board.
Post-requisites
Replace the base cover.
12
26 Replacing the coin-cell battery
Page 27
Removing the wireless card
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1. Remove the screw (M2x3) that secures the wireless-card bracket to the wireless card and the palm rest and keyboard
assembly.
2. Remove the wireless-card bracket and disconnect the antenna cables from the wireless card.
3. Slide and remove the wireless card from the wireless-card slot.
13
Figure 13. Removing the wireless card
1.
wireless-card bracket 2. screw
3. antenna cables (2) 4. wireless-card slot
5. wireless card
Removing the wireless card 27
Page 28
Replacing the wireless card
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
CAUTION: To avoid damage to the wireless card, do not place any cables under it.
1. Align the notch on the wireless card with the tab on the wireless-card slot.
2. Insert the wireless card at an angle into the wireless-card slot.
3. Connect the antenna cables to the wireless card.
The following table provides the antenna-cable color scheme for the wireless card supported by your computer.
Table 2. Antenna-cable color scheme
14
Connectors on the wireless card Antenna-cable color
Main (white triangle) White
Auxiliary (black triangle) Black
4. Align the screw hole on the wireless-card bracket with the screw hole on the wireless card and the palm rest and keyboard
assembly.
5. Replace the screw (M2x3) that secures the wireless-card bracket to the wireless card and the palm rest and keyboard
assembly.
28 Replacing the wireless card
Page 29
Figure 14. Replacing the wireless card
tab 2. notch
1.
3. wireless card 4. wireless-card slot
5. antenna cables (2) 6. screw
7. wireless-card bracket
Post-requisites
Replace the base cover.
Replacing the wireless card
29
Page 30
15
Removing the keyboard daughter-board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Open the latches and disconnect the keyboard cables, keyboard-backlight cable (optional), status-light board cable, and the
touch-pad cable from the keyboard daughter-board.
2. Using a plastic scribe, gently pry out the keyboard daughter-board from the palm rest and keyboard assembly.
Figure 15. Removing the keyboard daughter board
1.
keyboard cable 2. touch-pad cable
3. keyboard cable 4. latches (4)
5. status-light board cable 6. plastic scribe
30 Removing the keyboard daughter-board
Page 31
7. keyboard daughter-board 8. palm rest and keyboard assembly
Removing the keyboard daughter-board 31
Page 32
16
Replacing the keyboard daughter-board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Adhere the keyboard daughter-board to the palm rest and keyboard assembly.
2. Slide the keyboard cables, keyboard-backlight cable (optional), status-light board cable, and the touch-pad cable into their
respective connectors on the keyboard daughter-board, and then close the latches to secure the cables.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
32 Replacing the keyboard daughter-board
Page 33
Removing the status-light board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Open the latch and disconnect the status-light board cable from the keyboard daughter-board.
2. Peel off the tape that secures the speaker cable to the palm rest and keyboard assembly.
3. Note the speaker-cable routing and remove the speaker cable from the routing guides on the palm rest and keyboard
assembly.
17
Figure 16. Removing the status-light board
1.
latch 2. status-light board cable
3. palm rest and keyboard assembly 4. speaker cable
5. tape
4. Peel off the foam that secures the status-light board to the palm rest and keyboard assembly.
5. Peel off the status-light board cable from the palm rest and keyboard assembly.
6. Lift the status-light board along with its cable off the palm rest and keyboard assembly.
Removing the status-light board 33
Page 34
Figure 17. Removing the status-light board
status-light board cable 2. palm rest and keyboard assembly
1.
3. status-light board 4. foam
34 Removing the status-light board
Page 35
Replacing the status-light board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Place the status-light board into the slot on the palm rest and keyboard assembly.
2. Slide the status-light board cable into the connector on the keyboard daughter-board and close the latch to secure the
cable.
3. Adhere the foam that secures the status-light board to the palm rest and keyboard assembly.
4. Adhere the status-light board cable to the palm rest and keyboard assembly.
5. Route the speaker cable through the routing guides on the palm rest and keyboard assembly and adhere the tape that
secures the speaker cable to the palm rest and keyboard assembly.
18
Post-requisites
1. Replace the battery.
2. Replace the base cover.
Replacing the status-light board 35
Page 36
Removing the touchpad
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the status-light board.
Procedure
1. Open the latches, and then disconnect the keyboard cable from the system board and the keyboard daughter-board.
19
Figure 18. Removing the keyboard cable
1.
latches (2) 2. keyboard cable
3. system board 4. keyboard daughter-board
2. Open the latches, and then disconnect the touch-pad cable from the touch pad and the keyboard daughter-board.
3. Peel off the touch-pad cable from the touch pad.
4. Peel off the tape that secures the touch-pad assembly to the palm rest and keyboard assembly.
36 Removing the touchpad
Page 37
Figure 19. Removing the touch-pad cable from the touch pad
1. touch-pad cable 2. latches (2)
3. tape 4. touch pad
5. Remove the screws that secure the touch-pad bracket to the palm rest and keyboard assembly.
Figure 20. Removing the touchpad bracket
a. screws (3)
b. touch-pad bracket
c. palm rest and keyboard assembly
6. Remove the screws that secure the touch pad to the palm rest and keyboard assembly.
7. Lift the touch pad off the palm rest and keyboard assembly.
Removing the touchpad
37
Page 38
Figure 21. Removing the touch pad
a. screws (4)
b. touch pad
c. palm rest and keyboard assembly
38
Removing the touchpad
Page 39
Replacing the touchpad
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the touch pad with the screw holes on the palm rest and keyboard assembly.
2. Replace the screws that secure the touch pad to the palm rest and keyboard assembly.
3. Align the screw holes on the touch-pad bracket with the screw holes on the palm rest and keyboard assembly.
4. Replace the screws that secure the touch-pad bracket to the palm rest and keyboard assembly.
5. Adhere the tape that secures the touch-pad bracket to the palm rest and keyboard assembly.
6. Adhere the touch-pad cable to the touch pad.
7. Slide both ends of the touch-pad cable into their respective connectors and close the latches to secure the cable.
8. Slide both ends of the keyboard cable into their respective connectors and close the latches to secure the cable.
20
Post-requisites
1. Replace the status-light board.
2. Replace the battery.
3. Replace the base cover.
Replacing the touchpad 39
Page 40
21
Removing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Disconnect the speaker cable from the system board.
2. Disconnect the power and volume-buttons board cable and the coin-cell battery cable from the I/O board.
3. Note the cable routing and remove the power and volume-buttons board cable from the routing guides on the palm rest and
keyboard assembly and the speaker.
4. Note the cable routing and remove the speaker cable from the routing guides on the palm rest and keyboard assembly.
5. Peel off the tape that secures the speaker cable to the palm rest and keyboard assembly.
Figure 22. Removing the speakers
1.
I/O board 2. power and volume-buttons board cable
3. coin-cell battery cable 4. system board
40 Removing the speakers
Page 41
5. speaker cable 6. palm rest and keyboard assembly
7. tape
6. Release the tabs on the speakers from the slots on the palm rest and keyboard assembly and lift the speakers along with the
cable off the palm rest and keyboard assembly.
Figure 23. Removing the speakers
a. system board
b. tabs (4)
c. speakers (2)
Removing the speakers
41
Page 42
22
Replacing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Using the tabs on the speakers, place the speakers in the slots on the palm rest and keyboard assembly and snap the
speakers into place.
2. Route the speaker cable through the routing guides on the palm rest and keyboard assembly.
3. Adhere the tape that secures the speaker cable to the palm rest and keyboard assembly.
4. Connect the speaker cable to the system board.
5. Route the power and volume-buttons board cable through the routing guides on the speaker and the palm rest and keyboard
assembly.
6. Connect the power and volume-buttons board cable and the coin-cell battery cable to the I/O board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
42 Replacing the speakers
Page 43
Removing the fan
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Disconnect the fan cable from the system board.
2. Remove the two screws (M2x3) that secure the fan to the palm rest and keyboard assembly.
3. Lift the fan along with its cable off the palm rest and keyboard assembly.
23
Figure 24. Removing the fan
1.
fan cable 2. system board
3. screws (2) 4. fan
5. palm rest and keyboard assembly
Removing the fan 43
Page 44
Replacing the fan
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the fan with the screw holes on the palm rest and keyboard assembly.
2. Replace the two screws (M2x3) that secure the fan to the palm rest and keyboard assembly.
3. Connect the fan cable to the system board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
24
44 Replacing the fan
Page 45
Removing the heat sink
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
NOTE: The heat sink may become hot during normal operation. Allow sufficient time for the heat sink to cool before you
touch it.
CAUTION: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils
in your skin can reduce the heat transfer capability of the thermal grease.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
25
Procedure
1. In sequential order (as indicated on the heat sink), loosen the captive screws that secure the heat sink to the system board.
2. Lift the heat sink off the system board.
Figure 25. Removing the heat sink
a. captive screws (4)
b. system board
c. heat sink
Removing the heat sink 45
Page 46
26
Replacing the heat sink
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Incorrect alignment of the heat sink can damage the system board and processor.
NOTE: If either the system board or the heat sink is replaced, use the thermal pad/paste provided in the kit to ensure that
thermal conductivity is achieved.
Procedure
1. Align the screw holes on the heat sink with the screw holes on the system board.
2. In sequential order (indicated on the heat sink), tighten the captive screws that secure the heat sink to the system board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
46 Replacing the heat sink
Page 47
Removing the power-adapter port
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Disconnect the power-adapter port cable from the system board.
2. Remove the screw (M2x3) that secures the power-adapter port to the palm rest and keyboard assembly.
3. Lift the power-adapter port along with its cable off the palm rest and keyboard assembly.
27
Figure 26. Removing the power-adapter port
1.
screw 2. power-adapter port
Removing the power-adapter port 47
Page 48
3. palm rest and keyboard assembly 4. power-adapter port cable
5. system board
48 Removing the power-adapter port
Page 49
Replacing the power-adapter port
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Place the power-adapter port into the slot on the palm rest and keyboard assembly.
2. Align the screw hole on the power-adapter port with the screw hole on the palm rest and keyboard assembly.
3. Replace the screw (M2x3) that secures the power-adapter port to the palm rest and keyboard assembly.
4. Connect the power-adapter port cable to the system board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
28
Replacing the power-adapter port 49
Page 50
Removing the power and volume-buttons
board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
29
1. Disconnect the coin-cell battery cable from the I/O board.
2. Disconnect the power and volume-buttons board cable from the I/O board.
3. Remove the power and volume-buttons board cable from the routing guides on the palm rest and keyboard assembly and the
speaker.
4. Remove the screw (M2x3) that secures the power and volume-buttons board to the palm rest and keyboard assembly.
5. Lift the power and volume-buttons board along with its cable off the palm rest and keyboard assembly.
Figure 27. Removing the power and volume-buttons board
1.
coin-cell battery cable 2. power and volume-buttons board cable
50 Removing the power and volume-buttons board
Page 51
3. I/O board 4. routing guides
5. power and volume-buttons board 6. screw
7. palm rest and keyboard assembly
Removing the power and volume-buttons board 51
Page 52
30
Replacing the power and volume-buttons
board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Using the alignment posts, place the power and volume-buttons board on the palm rest and keyboard assembly.
2. Replace the screw (M2x3) that secures the power and volume-buttons board to the palm rest and keyboard assembly.
3. Route the power and volume-buttons board cable through the routing guides on the palm rest and keyboard assembly and
the speaker.
4. Connect the power and volume-buttons board cable to the I/O board.
5. Adhere the tape that secures the power and volume-buttons board to the palm rest and keyboard assembly.
6. Connect the coin-cell battery cable to the I/O board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
52 Replacing the power and volume-buttons board
Page 53
Removing the I/O board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the wireless card.
Procedure
1. Peel off the tape that secures the I/O-board cable to the I/O board.
2. Open the latch and disconnect the I/O-board cable from the I/O board.
3. Disconnect the coin-cell battery cable and the power and volume-buttons board cable from the I/O board.
31
Figure 28. Removing the I/O board
1.
I/O-board cable 2. tape
3. latch 4. I/O board
Removing the I/O board 53
Page 54
5. coin-cell battery cable 6. power and volume-buttons board cable
4. Remove the two screws (M2x3) that secure the I/O board to the palm rest and keyboard assembly.
5. Lift the I/O board off the palm rest and keyboard assembly.
Figure 29. Removing the I/O board
a. screws (2)
b. I/O board
c. palm rest and keyboard assembly
54
Removing the I/O board
Page 55
Replacing the I/O board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Using the alignment posts, place the I/O board on the palm rest and keyboard assembly.
2. Align the screw holes on the I/O board with the screw holes on the palm rest and keyboard assembly.
3. Replace the two screws (M2x3) that secure the I/O board to the palm rest and keyboard assembly.
4. Connect the power and volume-buttons board cable and the coin-cell battery cable to the I/O board.
5. Slide the I/O-board cable into the connector on the I/O board and close the latch to secure the cable.
6. Adhere the tape that secures the I/O-board cable to the I/O board.
32
Post-requisites
1. Replace the wireless card.
2. Replace the battery.
3. Replace the base cover.
Replacing the I/O board 55
Page 56
Removing the system board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You must enter the Service Tag in the BIOS setup
program after you replace the system board.
NOTE: Replacing the system board removes any changes you have made to the BIOS using the BIOS setup program. You
must make the appropriate changes again after you replace the system board.
NOTE: Before disconnecting the cables from the system board, note the location of the connectors so that you can
reconnect the cables correctly after you replace the system board.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the memory modules.
4. Remove the heat sink.
33
Procedure
1. Disconnect the fan cable and the power-adapter port cable from the system board.
2. Peel off the pieces of tape that secure the display cable and touch-screen board cable from their respective connectors.
3. Open the latches and disconnect the display cable and the touch-screen board cable from the system board.
56 Removing the system board
Page 57
Figure 30. Removing the system board cables
fan cable 2. latches (2)
1.
3. tape (2) 4. display cable
5. touch-screen board cable 6. power-adapter port cable
7. system board
4. Disconnect the speaker cable from the system board.
5. Using the pull tab, disconnect the hard-drive cable from the system board.
6. Open the latches and disconnect the keyboard cable and the I/O-board cable from the system board.
Removing the system board
57
Page 58
Figure 31. Removing the system board cables
I/O-board cable 2. latches (2)
1.
3. keyboard cable 4. speaker cable
5. system board 6. hard-drive cable
7. Remove the screws that secure the system board to the palm rest and keyboard assembly.
8. Lift the system board off the palm rest and keyboard assembly.
a. screws (5)
58
Removing the system board
Page 59
b. system board
c. palm rest and keyboard assembly
Removing the system board 59
Page 60
34
Replacing the system board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You must enter the Service Tag in the BIOS setup
program after you replace the system board.
NOTE: Replacing the system board removes any changes you have made to the BIOS using the BIOS setup program. You
must make the appropriate changes again after you replace the system board.
Procedure
1. Align the screw holes on the system board with the screw holes on the palm rest and keyboard assembly.
2. Replace the screws that secure the system board to the palm rest and keyboard assembly.
3. Connect the fan cable, hard-drive cable, power-adapter port cable, and the speaker cable to the system board.
4. Slide the keyboard cable and the I/O-board cable into their respective connectors on the system board and close the latches
to secure the cables.
5. Slide the display cable and the touch-screen board cable into their respective connectors on the system board and close the
latches to secure the cables.
6. Adhere the pieces of tape that secure the display cable and the touch-screen board cable to their respective connectors on
the system board.
Post-requisites
1. Replace the heat sink.
2. Replace the memory modules.
3. Replace the battery.
4. Replace the base cover.
Entering the Service Tag in the BIOS setup program
1. Turn on or restart your computer.
2. Press F2 when the Dell logo is displayed to enter the BIOS setup program.
3. Navigate to the Main tab and enter the Service Tag in the Service Tag Input field.
NOTE: Service tag is the alphanumeric identifier located at the back side of your computer.
60 Replacing the system board
Page 61
Removing the display assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the wireless card.
4. Remove the memory modules.
5. Remove the heat sink.
6. Remove the system board.
35
Procedure
1. Turn the computer over and open the display to 180-degree angle.
CAUTION: Place the computer on a soft and clean surface to avoid scratching the display.
Figure 32. Removing the display assembly
a. palm rest and keyboard assembly
b. display assembly
2. Place the computer on a flat surface with the display facing down.
3. Remove the two screws (M2.5x7) that secure the display assembly to the palm rest and keyboard assembly.
4. Remove the antenna cables from the routing guide on the palm rest and keyboard assembly.
5. Lift the display assembly off the palm rest and keyboard assembly.
Removing the display assembly 61
Page 62
Figure 33. Removing the display assembly
1. display assembly 2. screws (2)
3. display hinges (2) 4. routing guide
5. antenna cables (2) 6. palm rest and keyboard assembly
62 Removing the display assembly
Page 63
36
Replacing the display assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
CAUTION: Place the computer on a soft and clean surface to avoid scratching the display.
1. With the display facing down, align the screw holes on the display hinges with the screw holes on the palm rest and keyboard
assembly.
2. Replace the two screws (M2.5x7) that secure the display assembly to the palm rest and keyboard assembly.
3. Turn the computer over and close the display.
Post-requisites
1. Replace the system board.
2. Replace the heat sink.
3. Replace the memory modules.
4. Replace the wireless card.
5. Replace the battery.
6. Replace the base cover.
Replacing the display assembly 63
Page 64
Removing the palm-rest and keyboard
assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the memory modules.
4. Remove the wireless card.
5. Remove the coin-cell battery.
6. Follow the procedure from step 1 to step 5 in “Removing the hard drive”.
7. Remove the keyboard daughter-board.
8. Remove the fan.
9. Remove the heat sink.
10. Remove the I/O board.
11. Remove the power and volume-buttons board.
12. Remove the power-adapter port.
13. Remove the status-light board.
14. Remove the speakers.
15. Remove the touchpad.
16. Remove the system board.
17. Remove the display assembly.
37
Procedure
After performing the steps in prerequisites, we are left with the palm rest and keyboard assembly.
64 Removing the palm-rest and keyboard assembly
Page 65
Figure 34. Removing the palm rest and keyboard assembly
1. palm rest and keyboard assembly
Removing the palm-rest and keyboard assembly 65
Page 66
Replacing the palm-rest and keyboard
assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
Place the palm rest and keyboard assembly on a clean and flat surface.
Post-requisites
1. Replace the display assembly.
2. Replace the system board.
3. Replace the touchpad.
4. Replace the status-light board.
5. Replace the speakers.
6. Replace the power-adapter port.
7. Replace the power and volume-buttons board.
8. Replace the I/O board.
9. Replace the heat sink.
10. Replace the fan.
11. Replace the keyboard daughter-board.
12. Follow the procedure from step 4 to step 8 in “Replacing the hard drive”.
13. Replace the coin-cell battery.
14. Replace the wireless card.
15. Replace the memory modules.
16. Replace the battery.
17. Replace the base cover.
38
66 Replacing the palm-rest and keyboard assembly
Page 67
39
Removing the display panel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the display assembly.
Procedure
1. Remove the display cable from inside the hinge covers.
2. Using a plastic scribe, pry up the display-panel assembly to release the tabs that secure display-panel assembly to the display
back-cover and antenna assembly.
Figure 35. Removing the display back cover and antenna assembly
1.
display-panel assembly 2. plastic scribe
3. hinge covers (2) 4. display cable
5. display back-cover and antenna assembly
Removing the display panel 67
Page 68
3. Remove the camera.
4. Remove the sensor board.
5. Remove the display cable.
After performing the preceding steps, we are left with the display panel.
Figure 36. Display panel
a. display panel
68
Removing the display panel
Page 69
Replacing the display panel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
CAUTION: Place the display panel on a soft and clean surface to avoid scratching the display.
1. Place the display panel on a flat surface with the display facing down.
2. Replace the display cable.
3. Replace the sensor board.
4. Replace the camera.
5. Turn over the display-panel assembly.
6. Align the display-panel assembly with the display back-cover and antenna assembly and gently snap the display-panel
assembly into place.
40
Post-requisites
1. Replace the display assembly.
2. Replace the battery.
3. Replace the base cover.
Replacing the display panel 69
Page 70
Removing the display cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the display assembly.
4. Follow the procedure from step 1 to step 2 in “Removing the display panel”.
5. Remove the camera.
Procedure
41
1. Peel off the tape on the sensor-board connector.
2. Open the latch and disconnect the sensor-board cable from the sensor board.
Figure 37. Removing the sensor-board cable
1.
display panel 2. tape
3. latch 4. sensor-board cable
3. Peel off the tape on the display-cable connector.
4. Open the latch and disconnect the display cable from the display panel.
70 Removing the display cable
Page 71
5. Note the display cable routing and remove the display cable from the routing guides on the display-panel assembly.
6. Peel off the tape that secures the display cable from the display-panel assembly.
7. Lift the display cable off the display-panel assembly.
Figure 38. Removing the display cable
tape 2. display-panel assembly
1.
3. latch 4. display cable
5. tape
Removing the display cable 71
Page 72
Replacing the display cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Adhere the tape that secures the display cable to the display-panel assembly.
2. Route the display cable through the routing guides on the display-panel assembly.
3. Slide the display cable into the connector on the display panel and close the latch to secure the cable.
4. Adhere the tape on the display-cable connector.
5. Slide the sensor-board cable into the connector on the sensor board and close the latch to secure the cable.
6. Adhere the tape on the sensor-board connector.
42
Post-requisites
1. Replace the camera.
2. Follow the procedure from step 5 to step 6 in “Replacing the display panel”.
3. Replace the display assembly.
4. Replace the battery.
5. Replace the base cover.
72 Replacing the display cable
Page 73
Removing the display back-cover and
antenna assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the display assembly.
4. Follow the procedure from step 1 to step 2 in “Removing the display panel”.
43
Procedure
After performing the steps in prerequisites, we are left with the display back-cover and antenna assembly.
Figure 39. Display back-cover and antenna assembly
1. display back-cover and antenna assembly
2. antenna cables
Removing the display back-cover and antenna assembly 73
Page 74
Replacing the display back-cover and
antenna assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
Place the display back-cover and antenna assembly on a flat surface.
Post-requisites
1. Follow the procedure from step 5 to step 6 in “Replacing the display panel”.
2. Replace the display assembly.
3. Replace the battery.
4. Replace the base cover.
44
74 Replacing the display back-cover and antenna assembly
Page 75
Removing the camera
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the display assembly.
4. Follow the procedure from step 1 to step 2 in “Removing the display panel”.
Procedure
45
CAUTION: Place the display-panel assembly on a soft and clean surface to avoid scratching the display.
1. Place the display-panel assembly face down on a flat surface.
2. Using a plastic scribe, pry the camera module off the display-panel assembly.
3. Turn the camera over and disconnect the display cable from the camera module.
Removing the camera 75
Page 76
Figure 40. Removing the camera
camera module 2. plastic scribe
1.
3. display cable 4. display-panel assembly
76 Removing the camera
Page 77
Replacing the camera
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Connect the display cable to the camera module.
2. Using the alignment posts, place the camera module on the display panel and snap it into place.
Post-requisites
1. Follow the procedure from step 5 to step 6 in “Replacing the display panel”.
2. Replace the display assembly.
3. Replace the battery.
4. Replace the base cover.
46
Replacing the camera 77
Page 78
Removing the sensor board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the display assembly.
4. Follow the procedure from step 1 to step 2 in “Removing the display panel”.
Procedure
47
CAUTION: Place the display-panel assembly on a soft and clean surface to avoid scratching the display.
1. Place the display-panel assembly face down on a flat surface.
2. Remove the screw that secures the sensor board to the display panel.
3. Peel off the tape that secures the sensor-board cable to the sensor board.
4. Open the latch to disconnect the sensor-board cable from the sensor board.
5. Lift the sensor board off the display-panel assembly.
Figure 41. Removing the sensor board
1.
tape 2. latch
78 Removing the sensor board
Page 79
3. sensor-board cable 4. screw
5. sensor board 6. display-panel assembly
Removing the sensor board 79
Page 80
48
Replacing the sensor board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw hole on the sensor board with the screw hole on the display-panel assembly and snap the sensor board in
place.
2. Slide the sensor-board cable into the connector on the sensor board and close the latch to secure the cable.
3. Adhere the tape on the sensor-board connector to secure the cable.
4. Replace the screw that secures the sensor board to the display-panel assembly.
Post-requisites
1. Follow the procedure from step 5 to step 6 in “Replacing the display panel”.
2. Replace the display assembly.
3. Replace the battery.
4. Replace the base cover.
80 Replacing the sensor board
Page 81
Downloading drivers
Downloading the audio driver
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click or tap Product support, enter the Service Tag of your computer, and then click or tap Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click or tap Drivers & downloads > Find it myself.
5. Scroll down the page and expand Audio.
6. Click or tap Download to download the audio driver for your computer.
7. After the download is complete, navigate to the folder where you saved the audio driver file.
8. Double-click or double-tap the audio driver file icon and follow the instructions on the screen.
49
Downloading the graphics driver
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click or tap Product support, enter the Service Tag of your computer, and then click or tap Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click or tap Drivers & downloads > Find it myself.
5. Scroll down the page and expand Video.
6. Click or tap Download to download the graphics driver for your computer.
7. After the download is complete, navigate to the folder where you saved the graphics driver file.
8. Double-click or double-tap the graphics driver file icon and follow the instructions on the screen.
Intel USB 3.0 xHCI
Install the Intel USB 3.0 xHCI driver update from www.dell.com/support.
Figure 42. USB controllers
NOTE: USB 3.0 driver supports USB 3.1 Gen 1 features.
Downloading the Wi-Fi driver
1. Turn on the computer.
Downloading drivers 81
Page 82
2. Go to www.dell.com/support.
3. Click or tap Product support, enter the Service Tag of your computer, and then click or tap Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click or tap Drivers & downloads > Find it myself.
5. Scroll down the page and expand Network.
6. Click or tap Download to download the Wi-Fi driver for your computer.
7. After the download is complete, navigate to the folder where you saved the Wi-Fi driver file.
8. Double-click or double-tap the driver file icon and follow the instructions on the screen.
Downloading the media-card reader driver
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click or tap Product support, enter the Service Tag of your computer, and then click or tap Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click or tap Drivers & downloads > Find it myself.
5. Scroll down the page and expand Chipset.
6. Click or tap Download to download the media-card reader driver for your computer.
7. After the download is complete, navigate to the folder where you saved the card reader driver file.
8. Double-click or double-tap the card reader driver file icon and follow the instructions on the screen.
Downloading the chipset driver
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click or tap Product support, enter the Service Tag of your computer, and then click or tap Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click or tap Drivers & downloads > Find it myself.
5. Scroll down the page and expand Chipset.
6. Click or tap Download to download the chipset driver for your computer.
7. After the download is complete, navigate to the folder where you saved the chipset driver file.
8. Double-click or double-tap the chipset driver file icon and follow the instructions on the screen.
Downloading the network driver
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click Product support enter the Service Tag of your computer and click Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click Drivers & downloads > Find it myself.
5. Scroll down the page and expand Network.
6. Click Download to download the network driver for your computer.
7. Save the file, and after the download is complete, navigate to the folder where you saved the network driver file.
8. Double-click the network driver file icon and follow the instructions on screen.
82
Downloading drivers
Page 83
50
System setup
NOTE: Depending on the computer and its installed devices, the items listed in this section may or may not be displayed.
Boot Sequence
Boot sequence enables you to bypass the System Setup–defined boot device order and boot directly to a specific device (for
example: optical drive or hard drive). During the Power-on Self-Test (POST), when the Dell logo appears, you can:
● Access System Setup by pressing F2 key
● Bring up the one-time boot menu by pressing F12 key.
The one-time boot menu displays the devices that you can boot from including the diagnostic option. The boot menu options
are:
● Removable Drive (if available)
● STXXXX Drive
NOTE: XXXX denotes the SATA drive number.
● Optical Drive (if available)
● SATA Hard Drive (if available)
● Diagnostics
NOTE: Choosing Diagnostics, displays the SupportAssist screen.
The boot sequence screen also displays the option to access the System Setup screen.
Navigation keys
NOTE:
For most of the System Setup options, changes that you make are recorded but do not take effect until you restart
the system.
Keys Navigation
Up arrow Moves to the previous field.
Down arrow Moves to the next field.
Enter Selects a value in the selected field (if applicable) or follow the link in the field.
Spacebar Expands or collapses a drop-down list, if applicable.
Tab Moves to the next focus area.
Esc Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a
message that prompts you to save any unsaved changes and restarts the system.
System setup
CAUTION:
Certain changes can make your computer work incorrectly.
Unless you are an expert computer user, do not change the settings in the BIOS Setup program.
NOTE: Before you change BIOS Setup program, it is recommended that you write down the BIOS Setup program screen
information for future reference.
Use the BIOS Setup program for the following purposes:
System setup 83
Page 84
● Get information about the hardware installed in your computer, such as the amount of RAM and the size of the hard drive.
● Change the system configuration information.
● Set or change a user-selectable option, such as the user password, type of hard drive installed, and enabling or disabling
base devices.
Entering BIOS setup program
1. Turn on (or restart) your computer.
2. During POST, when the DELL logo is displayed, watch for the F2 prompt to appear, and then press F2 immediately.
NOTE: The F2 prompt indicates that the keyboard is initialized. This prompt can appear very quickly, so you must watch
for it, and then press F2. If you press F2 before the F2 prompt, this keystroke is lost. If you wait too long and the
operating system logo appears, continue to wait until you see the desktop. Then, turn off your computer and try again.
System setup options
NOTE: Depending on this computer and its installed devices, the items listed in this section may or may not appear.
Table 3. System setup options—System information menu
General-System Information
System Information
BIOS Version Displays the BIOS version number.
Service Tag Displays the Service Tag of the computer.
Asset Tag Displays the Asset Tag of the computer.
Ownership Tag Displays the ownership tag of the computer.
Manufacture Date Displays the manufacture date of the computer.
Ownership Date Displays the ownership date of the computer.
Express Service Code Displays the express service code of the computer.
Memory Information
Memory Installed Displays the total computer memory installed.
Memory Available Displays the total computer memory available.
Memory Speed Displays the memory speed.
Memory Channel Mode Displays single or dual channel mode.
Memory Technology Displays the technology used for the memory.
DIMM A Size Displays the DIMM A memory size.
DIMM B Size Displays the DIMM B memory size.
Processor Information
Processor Type Displays the processor type.
Core Count Displays the number of cores on the processor.
Processor ID Displays the processor identification code.
Current Clock Speed Displays the current processor clock speed.
Minimum Clock Speed Displays the minimum processor clock speed.
Maximum Clock Speed Displays the maximum processor clock speed.
Processor L2 Cache Displays the processor L2 Cache size.
84 System setup
Page 85
Table 3. System setup options—System information menu (continued)
General-System Information
Processor L3 Cache Displays the processor L3 Cache size.
HT Capable Displays whether the processor is HyperThreading (HT) capable.
64-Bit Technology Displays whether 64-bit technology is used.
Device Information
SATA-0 Displays the SATA-0 device information of the computer.
SATA-2 Displays the SATA-2 device information of the computer.
M.2 PCIe SSD-0 Displays the M.2 PCIe SSD information of the computer.
Video Controller Displays the video controller type of the computer.
dGPU Video Controller Displays the discrete graphics information of the computer.
Video BIOS Version Displays the video BIOS version of the computer.
Video Memory Displays the video memory information of the computer.
Panel Type Displays the Panel Type of the computer.
Native Resolution Displays the native resolution of the computer.
Audio Controller Displays the audio controller information of the computer.
Wi-Fi Device Displays the wireless device information of the computer.
Bluetooth Device Displays the bluetooth device information of the computer.
Battery Information Displays the battery health information.
Boot Sequence
Boot Sequence Displays the boot sequence.
Boot List Option Displays the available boot options.
Advanced Boot Options
Enable Legacy Option ROMs Enable or disable the Legacy Option ROMs.
Enable UEFI Network Stack Enable or disable UEFI Network Stack.
UEFI Boot Path Security Enable or disable the system to prompt the user to enter the Admin password
when booting a UEFI boot path from the F12 boot menu.
Date/Time Displays the current date in MM/DD/YY format and current time in HH:MM:SS
AM/PM format.
Table 4. System setup options—System Configuration menu
System Configuration
SATA Operation Configure operating mode of the integrated SATA hard drive controller.
Drives Enable or disable various drives on board.
SMART Reporting Enable or disable SMART Reporting during system startup.
USB Configuration
Enable Boot Support Enable or disable booting from USB mass storage devices such as external
hard drive, optical drive, and USB drive.
Enable External USB Port Enable or disable booting from USB mass storage devices connected to
external USB port.
USB PowerShare Enable or disable charging external devices through the USB PowerShare port.
Audio Enable or disable the integrated audio controller.
Keyboard Illumination Configure the operating mode of the keyboard illumination feature.
System setup 85
Page 86
Table 4. System setup options—System Configuration menu (continued)
System Configuration
Keyboard Backlight with AC Enable or disable the keyboard backlight.
Miscellaneous Devices Enable or disable various onboard devices.
Enable Camera Enable or disable the camera.
Enable Secure Digital (SD) Card Enable or disable the SD card.
Table 5. System setup options—Video menu
Video
LCD Brightness Set the panel brightness independently for Battery and AC power.
Table 6. System setup options—Security menu
Security
Strong Password Enable or disable strong passwords.
Password Configuration Control the minimum and maximum number of characters allowed for Admin
and System passwords.
Password Bypass Bypass the System (Boot) Password and the internal HDD password prompts
during a system restart.
Password Change Enable or disable changes to the System and Hard Disk passwords when an
administrator password is set.
Non-Admin Setup Changes Determines whether changes to the setup option are permitted when an
administrator password is set.
UEFI Capsule Firmware Updates Enable or disable BIOS updates through UEFI capsule update packages.
PTT Security Enable or disable Platform Trust Technology (PTT) visibility to the operating
system.
Computrace(R) Enable or disable the BIOS module interface of the optional Computrace(R)
Service from Absolute Software.
CPU XD Support Enable or disable the Execute Disable mode of the Processor.
Admin Setup Lockout Enable to prevent users from entering Setup when an Admin Password is set.
Table 7. System setup options—Secure Boot menu
Secure Boot
Secure Boot Enable Enable or disable the secure boot feature.
Expert Key Management
Expert Key Management
Custom Mode Key Management
Enable or disable Expert Key Management.
Select the custom values for expert key management.
Table 8. System setup options—Intel Software Guard Extensions menu
Intel Software Guard Extensions
Intel SGX Enable Enable or disable Intel Software Guard Extensions.
Enclave Memory Size Set the Intel Software Guard Extensions Enclave Reserve Memory Size.
Performance
Multi Core Support Enable multiple cores.
Default: Enabled.
Intel SpeedStep Enable or disable Intel Speedstep Technology.
86 System setup
Page 87
Table 8. System setup options—Intel Software Guard Extensions menu (continued)
Intel Software Guard Extensions
Default: Enabled.
NOTE: If enabled, the processor clock speed and core voltage are adjusted
dynamically based on the processor load.
C-States Control Enable or disable additional processor sleep states.
Default: Enabled.
Intel TurboBoost Enable or disable Intel TurboBoost mode of the processor.
Default: Enabled.
HyperThread control Enable or disable HyperThreading in the processor.
Default: Enabled.
Power Management
AC Behavior Enables the system to turn on automatically, when AC is inserted.
Enable Intel Speed Shift Technology Enable or disable Intel Speed Shift Technology.
Auto on Time Enable to set the computer to turn on automatically every day or on a
preselected date and time. This option can be configured only if the Auto On
Time is set to Everyday, Weekdays or Selected Days.
Default: Disabled.
USB Wake Support Enable the USB devices to wake the computer from Standby.
Advanced Battery Charge Configuration Enable Advanced Battery Charge Configuration from the beginning of the day
to a specified work period.
Primary Battery Charge Configuration Set the primary battery charge settings with a preselected custom charge start
and stop.
Default: Adaptive.
POST Behavior
Adapter Warnings Enable adapter warnings.
Default: Enabled.
Numlock Enable Enable or disable Numlock.
Default: Enable Numlock.
Fn Lock Options Enable or disable the Fn lock mode.
Fastboot Enable to set the speed of the boot process.
Default: Thorough.
Extend BIOS POST Time Configure additional pre-boot delay.
Pull Screen Logo Enable or disable to display full screen logo.
Warnings and Errors Select an action on encountering a warning or error.
Table 9. System setup options—Virtualization Support menu
Virtualization Support
Virtualization Specify whether a Virtual Machine Monitor (VMM) can utilize the additional
hardware capabilities provided by Intel Virtualization Technology.
VT for Direct I/O Specify whether a Virtual Machine Monitor (VMM) can utilize the additional
hardware capabilities provided by Intel Virtualization Technology for Direct I/O.
System setup 87
Page 88
Table 10. System setup options—Wireless menu
Wireless
Wireless Switch Determine which wireless devices can be controlled by the Wireless Switch.
Wireless Device Enable Enable or disable internal wireless devices.
Table 11. System setup options—Maintenance menu
Maintenance
Service Tag Display the system’s Service Tag.
Asset Tag Create a system Asset Tag.
BIOS Downgrade Control flashing of the system firmware to previous revisions.
Data Wipe Enable to securely erase data from all internal storage devices.
BIOS Recovery Enable the user to recover from certain corrupted BIOS conditions from a
recovery file on the user primary hard drive or an external USB key.
Table 12. System setup options—System Logs menu
System Logs
BIOS Events Display BIOS events.
Thermal Events Display Thermal events.
Power Events Display Power events.
Table 13. System setup options—SupportAssist System Resolution menu
SupportAssist System Resolution
Auto OS Recovery Threshold Control the automatic boot flow for SupportAssist System Resolution Console
and for Dell OS Recovery tool.
SupportAssist OS Recovery Enable or disable the boot flow for SupportAssist OS Recovery tool in the even
of certain system errors.
System and setup password
Table 14. System and setup password
Password type Description
System password Password that you must enter to log on to your system.
Setup password Password that you must enter to access and make changes to
the BIOS settings of your computer.
You can create a system password and a setup password to secure your computer.
CAUTION: The password features provide a basic level of security for the data on your computer.
CAUTION: Anyone can access the data stored on your computer if it is not locked and left unattended.
NOTE: System and setup password feature is disabled.
Assigning a system setup password
You can assign a new System or Admin Password only when the status is in Not Set.
To enter the system setup, press F2 immediately after a power-on or reboot.
88
System setup
Page 89
1. In the System BIOS or System Setup screen, select Security and press Enter.
The Security screen is displayed.
2. Select System/Admin Password and create a password in the Enter the new password field.
Use the following guidelines to assign the system password:
● A password can have up to 32 characters.
● The password can contain the numbers 0 through 9.
● Only lower case letters are valid, upper case letters are not allowed.
● Only the following special characters are allowed: space, (”), (+), (,), (-), (.), (/), (;), ([), (\), (]), (`).
3. Type the system password that you entered earlier in the Confirm new password field and click OK.
4. Press Esc and a message prompts you to save the changes.
5. Press Y to save the changes.
The computer reboots.
Deleting or changing an existing system setup password
Ensure that the Password Status is Unlocked (in the System Setup) before attempting to delete or change the existing
System and Setup password. You cannot delete or change an existing System or Setup password, if the Password Status is
Locked.
To enter the System Setup, press F2 immediately after a power-on or reboot.
1. In the System BIOS or System Setup screen, select System Security and press Enter.
The System Security screen is displayed.
2. In the System Security screen, verify that Password Status is Unlocked.
3. Select System Password, alter or delete the existing system password and press Enter or Tab.
4. Select Setup Password, alter or delete the existing setup password and press Enter or Tab.
NOTE:
If you change the System and/or Setup password, re enter the new password when prompted. If you delete the
System and Setup password, confirm the deletion when prompted.
5. Press Esc and a message prompts you to save the changes.
6. Press Y to save the changes and exit from System Setup.
The computer restarts.
Clearing CMOS settings
CAUTION: Clearing CMOS settings resets the BIOS settings on your computer.
1. Remove the base cover.
2. Remove the battery.
3. Disconnect the coin-cell battery.
4. Wait for one minute.
5. Connect the coin-cell battery.
6. Replace the battery.
7. Replace the base cover.
Clearing BIOS (System Setup) and System passwords
Contact Dell technical support to clear the forgotten passwords. For more information, see www.dell.com/contactdell.
System setup
89
Page 90
Troubleshooting
Flashing the BIOS
You may need to flash (update) the BIOS when an update is available or when you replace the system board.
Follow these steps to flash the BIOS:
1. Turn on your computer.
2. Go to www.dell.com/support.
3. Click Product support, enter the Service Tag of your computer, and then click Submit.
NOTE: If you do not have the Service Tag, use the auto-detect feature or manually browse for your computer model.
4. Click Drivers & downloads > Find it myself.
5. Select the operating system installed on your computer.
6. Scroll down the page and expand BIOS.
7. Click Download to download the latest version of the BIOS for your computer.
8. After the download is complete, navigate to the folder where you saved the BIOS update file.
9. Double-click the BIOS update file icon and follow the instructions on the screen.
51
Flashing BIOS (USB key)
1. Follow the procedure from step 1 to step 7 in "Flashing the BIOS" to download the latest BIOS setup program file.
2. Create a bootable USB drive. For more information see the knowledge base article SLN143196 at www.dell.com/support.
3. Copy the BIOS setup program file to the bootable USB drive.
4. Connect the bootable USB drive to the computer that needs the BIOS update.
5. Restart the computer and press F12 when the Dell logo is displayed on the screen.
6. Boot to the USB drive from the One Time Boot Menu.
7. Type the BIOS setup program filename and press Enter.
8. The BIOS Update Utility appears. Follow the instructions on the screen to complete the BIOS update.
Dell SupportAssist Pre-boot System Performance Check diagnostics
SupportAssist diagnostics (also known as system diagnostics) performs a complete check of your hardware. The Dell
SupportAssist Pre-boot System Performance Check diagnostics is embedded with the BIOS and is launched by the BIOS
internally. The embedded system diagnostics provides a set of options for particular devices or device groups allowing you to:
● Run tests automatically or in an interactive mode
● Repeat tests
● Display or save test results
● Run thorough tests to introduce additional test options to provide extra information about the failed device(s)
● View status messages that inform you if tests are completed successfully
● View error messages that inform you of problems encountered during testing
Some tests for specific devices require user interaction. Always ensure that you are present at the computer
NOTE:
terminal when the diagnostic tests are performed.
90 Troubleshooting
Page 91
For more information, see Resolve Hardware Issues With Built-in and Online Diagnostics (SupportAssist ePSA, ePSA or PSA
Error Codes) .
Running the ePSA Diagnostics
Invoke diagnostics boot by either of the methods that are suggested below:
1. Power on the computer.
2. As the computer boots, press the F12 key when the Dell logo is displayed.
3. In the boot menu screen, use Up/Down arrow key to select the Diagnostics option and then press Enter.
NOTE: The Enhanced Pre-boot System Assessment window displays, listing all devices detected in the computer.
The diagnostics starts running the tests on all the detected devices.
4. Press the arrow in the lower-right corner to go to the page listing.
The detected items are listed and tested.
5. To run a diagnostic test on a specific device, press Esc and click Yes to stop the diagnostic test.
6. Select the device from the left pane and click Run Tests.
7. If there are any issues, error codes are displayed.
Note the error code and contact Dell.
System diagnostic lights
Power and battery-status light/hard-drive activity light
Indicates the battery-charge status or the hard-drive activity.
NOTE: Press Fn+H to toggle this light between power and battery-status light and hard-drive activity light.
Hard-drive activity light
Turns on when the computer reads from or writes to the hard drive.
NOTE: Hard-drive activity light is supported only on computers shipped with hard drive.
Power and battery-status light
Indicates the power and battery-charge status
Solid white — Power adapter is connected and the battery has more than 5 percent charge.
Amber — Computer is running on battery and the battery has less than 5 percent charge.
Off
● Power adapter is connected and the battery is fully charged.
● Computer is running on battery and the battery has more than 5 percent charge.
● Computer is in sleep state, hibernation, or turned off
NOTE: Hard-drive activity light is supported only on computers shipped with hard drive.
The power and battery-status light blinks amber along with beep codes indicating failures.
For example, the power and battery-status light blinks amber two times followed by a pause, and then blinks white three times
followed by a pause. This 2,3 pattern continues until the computer is turned off indicating no memory or RAM is detected.
The following table shows different light patterns and describes what they indicate.
Table 15. Diagnostics
Light pattern Problem description
2,1 CPU failure
2,2 System board: BIOS and ROM failure
2,3 No memory or RAM detected
Troubleshooting 91
Page 92
Table 15. Diagnostics (continued)
Light pattern Problem description
2,4 Memory or RAM failure
2,5 Invalid memory installed
2,6 System board or chipset error
2,7 LCD failure
3,1 CMOS battery failure
3,2 PCI or video card or chip failure
3,3 Recovery image not found
3,4 Recovery image found but invalid
Camera status light: Indicates whether the camera is in use.
● Solid white — Camera is in use.
● Off — Camera is not in use.
Caps Lock status light: Indicates whether Caps Lock is enabled or disabled.
● Solid white — Caps Lock enabled.
● Off — Caps Lock disabled.
Flea power release
Flea power is the residual static electricity that remains on the computer even after it has been powered off and the battery has
been removed. The following procedure list the steps to conduct a flea power release for the computer.
1. Turn off your computer.
2. Remove the base cover.
3. Disconnect the battery cable from the system board.
4. Press and hold down the power button for 15 seconds to drain the flea power.
5. Connect the battery cable to the system board.
6. Replace the base cover.
7. Turn on your computer.
WiFi power cycle
If your computer is unable to access the Internet due to WiFi connectivity issues, a WiFi power cycle procedure may be
performed. The following procedure provides the instructions on how to conduct a WiFi power cycle:
NOTE: Some ISPs (Internet Service Providers) provide a modem/router combo device.
1. Turn off your computer.
2. Turn off the modem.
3. Turn off the wireless router.
4. Wait for 30 seconds.
5. Turn on the wireless router.
6. Turn on the modem.
7. Turn on your computer.
92
Troubleshooting
Page 93
Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 16. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell
Tips
Contact Support In Windows search, type Contact Support, and press
Enter.
52
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
Troubleshooting information, user manuals, setup instructions,
product specifications, technical help blogs, drivers, software
updates, and so on.
Dell knowledge base articles for a variety of computer
concerns.
Learn and know the following information about your product:
● Product specifications
● Operating system
● Setting up and using your product
● Data backup
● Troubleshooting and diagnostics
● Factory and system restore
● BIOS information
www.dell.com/support
1. Go to https://www.dell.com/support/home/?
app=knowledgebase.
2. Type the subject or keyword in the Search box.
3. Click Search to retrieve the related articles.
See Me and My Dell at www.dell.com/support/manuals.
To locate the Me and My Dell relevant to your product,
identify your product through one of the following:
● Select Detect Product.
● Locate your product through the drop-down menu under
View Products.
● Enter the Service Tag number or Product ID in the
search bar.
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
NOTE: Availability varies by country and product, and some services may not be available in your country.
NOTE: If you do not have an active internet connection, you can find contact information on your purchase invoice, packing
slip, bill, or Dell product catalog.
Getting help and contacting Dell 93
