Page 1
XPS 15-7590
Setup and Specications
Computer Model: XPS 15-7590
Regulatory Model: P56F
Regulatory Type: P56F003
Page 2
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2019 - 05
Rev. A00
Page 3
Contents
1 Set up your XPS 15-7590............................................................................................................................... 4
2 Views of XPS 15-7590................................................................................................................................... 6
Front.................................................................................................................................................................................... 6
Right.................................................................................................................................................................................... 6
Left.......................................................................................................................................................................................7
Base..................................................................................................................................................................................... 8
Display..................................................................................................................................................................................9
Bottom.................................................................................................................................................................................9
3 Specications of XPS 15-7590......................................................................................................................11
Dimensions and weight.....................................................................................................................................................11
Processors..........................................................................................................................................................................11
Chipset...............................................................................................................................................................................12
Operating system..............................................................................................................................................................12
Memory..............................................................................................................................................................................12
Ports and connectors.......................................................................................................................................................12
Communications............................................................................................................................................................... 13
Wireless module.......................................................................................................................................................... 13
Audio...................................................................................................................................................................................14
Storage...............................................................................................................................................................................14
Media-card reader............................................................................................................................................................ 14
Keyboard............................................................................................................................................................................15
Camera...............................................................................................................................................................................15
Touchpad........................................................................................................................................................................... 16
Touchpad gestures..................................................................................................................................................... 16
Power adapter...................................................................................................................................................................16
Battery................................................................................................................................................................................17
Display................................................................................................................................................................................ 18
Fingerprint reader (optional)........................................................................................................................................... 19
Video.................................................................................................................................................................................. 19
Computer environment....................................................................................................................................................19
4 Keyboard shortcuts...................................................................................................................................... 21
5 Getting help and contacting Dell..................................................................................................................23
Self-help resources.......................................................................................................................................................... 23
Contacting Dell.................................................................................................................................................................23
Contents
3
Page 4
Set up your XPS 15-7590
NOTE: The images in this document may dier from your computer depending on the conguration you ordered.
1 Connect the power adapter and press the power button.
1
NOTE: To conserve battery power, the computer might enter power saving mode (sleep state). Connect the power
adapter and press the power button to turn on the computer.
2 Finish Windows setup.
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE
: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an oine account.
• On the Support and Protection screen, enter your contact details.
3 Locate and use Dell apps from the Windows Start menu—Recommended
Table 1. Locate Dell apps
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about your
computer. It also noties you about the warranty status, recommended accessories, and software updates if
available.
SupportAssist
Pro-actively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery
tool troubleshoots issues with the operating system. For more information, see the SupportAssist
documentation at www.dell.com/support.
4 Set up your XPS 15-7590
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Page 5
Resources Description
Dell Update
Updates your computer with critical xes and latest device drivers as they become available. For more
information about using Dell Update, see the knowledge base article SLN305843 at www.dell.com/support.
Dell Digital Delivery
Download software applications, which are purchased but not pre-installed on your computer. For more
information about using Dell Digital Delivery, see the knowledge base article 153764 at www.dell.com/
support.
Set up your XPS 15-7590 5
Page 6
Front
1 Left microphone
Provides digital sound input for audio recording and voice calls.
2 Power and battery-status light
Indicates the power state and battery state of the computer.
Solid white—Power adapter is connected and the battery is charging.
Solid amber—Battery charge is low or critical.
2
Views of XPS 15-7590
O—Battery is fully charged.
3 Right microphone
Provides digital sound input for audio recording and voice calls.
Right
1 SD-card slot
Reads from and writes to the SD card.
2 USB 3.1 Gen 1 port with PowerShare
Connect peripherals such as external storage devices and printers.
Provides data transfer speeds up to 5 Gbps. PowerShare enables you to charge your USB devices even when your computer is
turned o.
: If the charge on your computer’s battery is less than 10 percent, you must connect the power adapter to charge
NOTE
your computer, and USB devices connected to the PowerShare port.
6 Views of XPS 15-7590
Page 7
NOTE: If a USB device is connected to the PowerShare port before the computer is turned o or in hibernate state,
you must disconnect and connect it again to enable charging.
NOTE: Certain USB devices may not charge when the computer is turned o or in sleep state. In such cases, turn on
the computer to charge the device.
3 Battery-charge status lights (5)
Turn on when the battery-charge status button is pressed. Each light indicates approximately 20% charge.
4 Battery-charge status button
Press to check the charge remaining in the battery.
5 Security-cable slot (wedge-shaped)
Connect a security cable to prevent unauthorized movement of your computer.
Left
1 Power-adapter port
Connect a power adapter to provide power to your computer and charge the battery.
2 USB 3.1 Gen 1 port with PowerShare
Connect peripherals such as external storage devices and printers.
Provides data transfer speeds up to 5 Gbps. PowerShare enables you to charge your USB devices even when your computer is
turned o.
NOTE
: If the charge on your computer’s battery is less than 10 percent, you must connect the power adapter to charge
your computer, and USB devices connected to the PowerShare port.
NOTE: If a USB device is connected to the PowerShare port before the computer is turned o or in hibernate state,
you must disconnect and connect it again to enable charging.
NOTE: Certain USB devices may not charge when the computer is turned o or in sleep state. In such cases, turn on
the computer to charge the device.
3 HDMI port
Connect to a TV or another HDMI-in enabled device. Provides video and audio output.
4 Thunderbolt 3 (USB 3.1 Gen 2 Type-C) port with Power delivery
Supports USB 3.1 Gen 2, DisplayPort 1.2, Thunderbolt 3 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates up to 10 Gbps for USB 3.1 Gen 2 and up to 40 Gbps for Thunderbolt 3. Supports Power Delivery that
enables two-way power supply between devices. Provides up to 5V/3A power output that enables faster charging.
: Adapters (sold separately) are required to connect standard USB and DisplayPort devices.
NOTE
5 Headset port
Connect headphones or a headset (headphone and microphone combo).
Views of XPS 15-7590
7
Page 8
Base
1 Power button with optional ngerprint reader
Press to turn on the computer if it is turned o, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power button for
10 seconds to force shut-down the computer.
If the power button has a ngerprint reader, place your nger on the power button to log in.
NOTE
: You can customize power-button behavior in Windows. For more information, see
www.dell.com/support/manuals.
NOTE: The power-status light on the power button is available only on computers without the ngerprint reader.
Computers shipped with the ngerprint reader integrated on the power button will not have the power-status light on
the power button.
2 Right-click area
Press to right-click.
3 Touchpad
Move your nger on the touchpad to move the mouse pointer. Tap to left-click and two nger tap to right-click.
4 Left-click area
Press to left-click.
Me and My Dell
at
Views of XPS 15-7590
8
Page 9
Display
1 Camera
Enables you to video chat, capture photos, and record videos.
2 Camera-status light
Turns on when the camera is in use.
3 Left speaker
Provides audio output.
4 Right speaker
Provides audio output.
Bottom
1 Service Tag label
The Service Tag is a unique alphanumeric identier that enables Dell service technicians to identify the hardware components in your
computer and access warranty information.
Views of XPS 15-7590
9
Page 10
2 Regulatory label
Contains regulatory information of your computer.
10 Views of XPS 15-7590
Page 11
Specications of XPS 15-7590
Dimensions and weight
Table 2. Dimensions and weight
Description Values
Height:
Front
11.2 mm (0.44 in.)
3
Rear
Width
Depth
Weight
Processors
Table 3. Processors
Description Values
Processors
Wattage
Core count
Thread count
9th generation Intel Core
i5-9300H
45 W 45 W 45 W
4 6 8
8 12 16
17 mm (0.67 in.)
357 mm (14.06 in.)
235 mm (9.25 in.)
1.8 kg (3.97 lb)
NOTE: The weight of your computer depends on the conguration
ordered and the manufacturing variability.
9th generation Intel Core
i7-9750H
9th generation Intel Core
i9-9980 HK
Speed
Cache
Integrated graphics
Up to 2.4 GHz Up to 2.6 GHz Up to 2.4 GHz
8 MB 12 MB 16 MB
Intel UHD Graphics 630 Intel UHD Graphics 630 Intel UHD Graphics 630
Specications of XPS 15-7590 11
Page 12
Chipset
Table 4. Chipset
Description Values
Chipset
CM246
Processor
DRAM bus width
Flash EPROM
PCIe bus
9th generation Intel Core i5/i7/i9
64-bit
16 MB
Up to Gen3
Operating system
• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
Memory
Table 5. Memory
Description Values
Slots
Type
specications
Two SODIMM slots
Dual-channel DDR4
Speed
Maximum memory
Minimum memory
Memory size per slot
Congurations supported
Ports and connectors
Table 6. External ports and connectors
External:
USB
2667 MHz
32 GB
4 GB
4 GB, 8 GB, 16 GB, 32 GB
• 4 GB DDR4 at 2667 MHz (1 x 4 GB)
• 8 GB DDR4 at 2667 MHz (2 x 4 GB
• 16 GB DDR4 at 2667 MHz (2 x 8 GB)
• 32 GB DDR4 at 2667 MHz (2 x 16 GB)
• Two USB 3.1 Gen 1 ports with PowerShare
12 Specications of XPS 15-7590
Page 13
External:
• One Thunderbolt 3 (USB 3.1 Gen 2 Type-C) port with Power
delivery
Audio
Video
Media card reader
Docking port
Power adapter port
Security
Table 7. Internal ports and connectors
Internal:
M.2
Communications
One headset (headphone and microphone combo) port
One HDMI 2.0b port
One SD-card slot
Not supported
One 4.5 mm x 2.9 mm DC-in
One security-cable slot (wedge-shaped)
• One M.2 slot for solid-state drive (SATA or PCIe/NVMe)
• One M.2 slot for WiFi and Bluetooth combo card
NOTE: To learn more about the features of dierent types
of M.2 cards, see the knowledge base article SLN301626.
Wireless module
Table 8. Wireless module
Description Values
Model number
Transfer rate
Frequency bands supported
Wireless standards
Encryption
Bluetooth
specications
Killer 1650x
Up to 2400 Mbps
2.4 GHz/5 GHz
• WiFi 802.11a/b/g
• Wi-Fi 4 (WiFi 802.11n)
• Wi-Fi 5 (WiFi 802.11ac)
• WiFi 6 (WiFi 802.11ax)
• 64-bit/128-bit WEP
• AES-CCMP
• TKIP
Bluetooth 5
Specications of XPS 15-7590 13
Page 14
Audio
Table 9. Audio specications
Description Values
Controller
ALC3266-CG with Waves MaxxAudio Pro
Stereo conversion
Internal interface
External interface
Speakers
Internal speaker amplier
External volume controls
Speaker output:
Average
Peak
Subwoofer output
Microphone
Storage
Your computer supports one of the following congurations:
Not supported
High-denition audio interface
HDMI 2.0b port
2
Not supported
Keyboard shortcut controls
2 W
2.5 W
Not supported
Dual-array microphones
• One 2.5-inch hard-drive
• One M.2 2230/2280 solid-state drive (SSD)
Table 10. Storage
Storage type Interface type Capacity
One 2.5-inch hard-disk drive SATA AHCI, up to 6 Gbps Up to 2 TB
One M.2 2230/2280 solid-state drive PCIe Gen3.0x4 NVMe, up to 32 Gbps Up to 2 TB
specications
Media-card reader
Table 11. Media-card reader
Description Values
Type
Cards supported
specications
One SD-card slot
• Secure Digital (SD)
14 Specications of XPS 15-7590
Page 15
Description Values
• Secure Digital High Capacity (SDHC)
• Secure Digital Extended Capacity (SDXC)
Keyboard
Table 12. Keyboard specications
Description Values
Type
Backlit keyboard
Layout
Number of keys
Size
Shortcut keys
Camera
Table 13. Camera
QWERTY
• United States and Canada: 80 keys
• United Kingdom: 81 keys
• Japan: 84 keys
X=19.05 mm key pitch
Y=18.05 mm key pitch
Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
secondary functions. To type the alternate character, press Shift
and the desired key. To perform secondary functions, press Fn and
the desired key.
NOTE: You can dene the primary behavior of the
function keys (F1–F12) changing Function Key Behavior in
BIOS setup program.
Keyboard shortcuts
specications
Description Values
Number of cameras
Type
Location
Sensor type
Resolution
Camera
Still image
Video
Infrared camera
One
RGB HD camera
Front camera on top bezel
Rolling shutter
0.92 megapixel
1280 x 720 (RGB) @ 30 fps
Specications of XPS 15-7590 15
Page 16
Description Values
Still image
0.92 megapixel
Video
Diagonal viewing angle
Camera
Infrared camera
Touchpad
Table 14. Touchpad specications
Description Values
Resolution:
Horizontal
Vertical
Dimensions:
Horizontal
Vertical
1219
919
105 mm (4.13 in.)
80 mm (3.15 in.)
340 x 340 @ 30 fps
78 degrees
80 degrees
Touchpad gestures
For more information about touchpad gestures for Windows 10, see the Microsoft knowledge base article 4027871 at
support.microsoft.com.
Power adapter
Table 15. Power adapter
Description Values
Type
Diameter (connector)
Input voltage
Input frequency
Input current (maximum)
Output current (continuous)
Rated output voltage
specications
130 W
4.5 mm x 2.9 mm
100 VAC x 240 VAC
50 Hz x 60 Hz
1.80 A
6.67 A
19.50 VDC
Temperature range:
16 Specications of XPS 15-7590
Page 17
Description Values
Operating
0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F)
Battery
Table 16. Battery specications
Description Values
Type
Voltage
Weight (maximum)
Dimensions:
Height
Width
Depth
Temperature range:
Operating
3-cell lithium ion (56 WHr) 6-cell lithium ion (97 WHr)
11.40 VDC 11.40 VDC
0.24 kg (0.53 lb) 0.34 kg (0.75 lb)
71.80 mm (2.83 in.) 71.80 mm (2.83 in.)
223.20 mm (8.79 in.) 330.50 mm (13.01 in.)
7.20 mm (0.28 in.) 7.20 mm (0.28 in.)
0°C to 35°C (32°F to 95°F) 0°C to 35°C (32°F to 95°F)
Storage
Operating time Varies depending on operating conditions and
Charging time (approximate)
Life span (approximate) 300 discharge/charge cycles 300 discharge/charge cycles
Coin-cell battery
Operating time Varies depending on operating conditions and
-40°C to 65°C (-40°F to 149°F) -40°C to 65°C (-40°F to 149°F)
Varies depending on operating conditions
can signicantly reduce under certain powerintensive conditions.
4 hours (when the computer is o)
NOTE: Control the charging time,
duration, start and end time, and so
on using the Dell Power Manager
application. For more information on
the Dell Power Manager see,
My Dell
on www.dell.com/
ML1220 ML1220
can signicantly reduce under certain powerintensive conditions.
Me and
and can signicantly reduce under certain
power-intensive conditions.
4 hours (when the computer is o)
NOTE: Control the charging time,
duration, start and end time, and so
on using the Dell Power Manager
application. For more information on
the Dell Power Manager see,
and My Dell
Varies depending on operating conditions
and can signicantly reduce under certain
power-intensive conditions.
on www.dell.com/
Me
Specications of XPS 15-7590 17
Page 18
Display
Table 17. Display specications
Decsription Values
Type
15.6-inch UHD touchscreen 15.6-inch WLED FHD nontouchscreen
15.6 inch OLED UHD nontouchscreen
Panel technology
Luminance (typical)
Dimensions (active area):
Height
Width
Diagonal
Native resolution
Megapixels
Color gamut
Pixels per inch (PPI)
Contrast ratio (min)
Response time (max)
Refresh rate
In-Plane Switching (IPS) In-Plane Switching (IPS) OLED
500 nits 500 nits 400 nits
193.62 mm (7.62 in.) 193.59 mm (7.62 in.) 193.62 mm (7.62 in.)
344.21 mm (13.55 in.) 344.16 mm (13.55 in.) 344.22 mm (13.55 in.)
394.9 mm (15.55 in.) 394.9 mm (15.55 in.) 394.9 mm (15.55 in.)
3840 x 2160 1920 x 1080 3840 x 2160
8.29 2.07 8.29
100 % (Adobe RGB) NTSC 72 % DCI P3 100%
282.42 141.21 282
1500:1 (typical) 1500:1 (typical) 100000:1 (typical)
35 ms 35 ms 1 ms
60 Hz 60 Hz 60 Hz
Horizontal view angle
Vertical view angle
Pixel pitch
Power consumption
(maximum)
Anti-glare vs glossy nish
Touch options
89/89 (typical), 80/80 (minimum) 89/89 (typical), 80/80
(minimum)
89/89 (typical), 80/80 (minimum) 89/89 (typical), 80/80
(minimum)
0.09 mm 0.18 mm 0.09 mm
10.41 W 4.30 W 14.80 W
Anti-reective Anti-glare Anti-reective
Yes No No
88/88 (typical), 80/80
(minimum)
88/88 (typical), 80/80
(minimum)
18 Specications of XPS 15-7590
Page 19
Fingerprint reader (optional)
Table 18. Fingerprint reader specications
Description Values
Sensor technology
Touch
Sensor resolution
Sensor area
Sensor pixel size
500 dpi
5.5 mm x 4.5 mm
108 x 88
Video
Table 19. Discrete graphics specications
Discrete graphics
Controller External display support Memory size Memory type
NVIDIA GeForce GTX N18P One HDMI 2.0b port 4 GB GDDR5
Table 20. Integrated graphics specications
Integrated graphics
Controller External display support Memory size Processor
Intel UHD 630 Graphics One HDMI 2.0b port Shared system memory 9th generation Intel
Core i5/i7/i9
Computer environment
Airborne contaminant level: G1 as dened by ISA-S71.04-1985
Table 21.
Temperature range
Relative humidity (maximum)
Vibration (maximum)
Shock (maximum)
Altitude (maximum)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
Computer environment
*
0°C to 35°C (32°F to 95°F) -40°C to 65°C (-40°F to 149°F)
10% to 90% (non-condensing) 0% to 95% (non-condensing)
0.66 GRMS 1.3 GRMS
110 G† 160 G†
-15.2 m to 3,048 m (-50 ft to 10,000 ft) -15.2 m to 10,668 m (-50 ft to 35,000 ft)
Operating Storage
Specications
of XPS 15-7590 19
Page 20
‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
20 Specications of XPS 15-7590
Page 21
4
Keyboard shortcuts
NOTE: Keyboard characters may dier depending on the keyboard language conguration. Keys used for shortcuts remain the
same across all language congurations.
Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary
functions. The symbol shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press
shift and the key, the symbol shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press Shift
+ 2, @ is typed out.
The keys F1-F12 at the top row of the keyboard are function keys for multi-media control, as indicated by the icon at the bottom of the key.
Press the function key to invoke the task represented by the icon. For example, pressing F1 mutes the audio (refer to the table below).
However, if the function keys F1-F12 are needed for specic software applications, multi-media functionality can be disabled by pressing Fn
+ Esc. Subsequently, multi-media control can be invoked by pressing Fn and the respective function key. For example, mute audio by
pressing Fn + F1.
NOTE: You can also dene the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in BIOS setup
program.
Table 22. List of keyboard shortcuts
Function key Re-dened key (for multi-media control) Behavior
Mute audio
Decrease volume
Increase volume
Play previous track/chapter
Play/Pause
Play next track/chapter
Task view
Switch to external display
Search
Toggle keyboard backlight (optional)
Keyboard shortcuts 21
Page 22
Function key Re-dened key (for multi-media control) Behavior
Print screen
Insert
The Fn key is also used with selected keys on the keyboard to invoke other secondary functions.
Table 23. List of keyboard shortcuts
Function key Behavior
Pause/Break
Toggle scroll lock
Toggle between power and battery-status light/hard-drive activity
light
System request
Open application menu
Toggle Fn-key lock
Page up/increase brightness
Page down/decrease brightness
22 Keyboard shortcuts
Page 23
Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 24. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell app
Tips
Contact Support In Windows search, type Contact Support, and press Enter.
5
Online help for operating system www.dell.com/support/windows
Troubleshooting information, user manuals, setup instructions,
product specications, technical help blogs, drivers, software
updates, and so on.
Dell knowledge base articles for a variety of computer concerns.
Learn and know the following information about your product:
• Product specications
• Operating system
• Setting up and using your product
• Data backup
• Troubleshooting and diagnostics
• Factory and system restore
• BIOS information
www.dell.com/support
1 Go to www.dell.com/support.
2 Type the subject or keyword in the Search box.
3 Click Search to retrieve the related articles.
See Me and My Dell at www.dell.com/support/manuals.
To locate the Me and My Dell relevant to your product, identify your
product through one of the following:
• Select Detect Product.
• Locate your product through the drop-down menu under View
Products.
• Enter the Service Tag number or Product ID in the search bar.
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
: Availability varies by country/region and product, and some services may not be available in your country/region.
NOTE
NOTE: If you do not have an active internet connection, you can nd contact information on your purchase invoice, packing slip,
bill, or Dell product catalog.
Getting help and contacting Dell 23
Loading...
