INSPIRON

SETUP GUIDE

™

INSPIRON

Model P04S series Regulatory type: P04S001

™

SETUP GUIDE

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your

computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

If you purchased a Dell™ n Series computer, any references in this document to Microsoft® Windows® operating systems are not applicable.

__________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: of Dell Inc.; trademarks and

Vista,

United States and/or other countries.; Dell under license;

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

ATI Radeon

and

Windows Vista

Core

May 2009 P/N G374R Rev. A00

Dell

, the

DELL

logo,

is a trademark of Advanced Micro Devices, Inc;

is a trademark of Intel Corporation in the U.S. and other countries;

start button logo are either trademarks or registered trademarks of Microsoft Corporation in the

Bluetooth

SRS Premium Sound, SRS,

Inspiron, YOURS IS HERE

is a registered trademark owned by Bluetooth SIG, Inc. and is used by

and the symbol are trademarks of SRS Labs, Inc.

, Dell On Call, and

Intel, Celeron,

DellConnect

and

Pentium

Microsoft, Windows, Windows

are trademarks

are registered

Contents

Setting Up Your Inspiron™ Laptop. . . . . . . . .5

Before Setting Up Your Computer . . . . . . . . . 5

Connect the AC Adapter . . . . . . . . . . . . . . . .6

Connect the Network Cable (Optional) . . . . . 7

Press the Power Button . . . . . . . . . . . . . . . . . 8

Set Up Microsoft® Windows Vista®. . . . . . . . 9

Enable or Disable Wireless (Optional). . . . . 10

Connect to the Internet (Optional) . . . . . . . . 12

Using Your Inspiron Laptop. . . . . . . . . . . . .14

Right Side Features . . . . . . . . . . . . . . . . . . . . 14

Left Side Features . . . . . . . . . . . . . . . . . . . . .16

Computer Base Features. . . . . . . . . . . . . . . . 18

Media Controls. . . . . . . . . . . . . . . . . . . . . . . . 21

Display Features . . . . . . . . . . . . . . . . . . . . . .22

Removing and Replacing the Battery . . . . . 24

Software Features . . . . . . . . . . . . . . . . . . . . . 26

Solving Problems . . . . . . . . . . . . . . . . . . . . .29

Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . .29

Network Problems . . . . . . . . . . . . . . . . . . . . . 31

Power Problems. . . . . . . . . . . . . . . . . . . . . . . 32

Memory Problems . . . . . . . . . . . . . . . . . . . . . 34

Lockups and Software Problems . . . . . . . . . 35

Using Support Tools. . . . . . . . . . . . . . . . . . .37

Dell Support Center . . . . . . . . . . . . . . . . . . . . 37

System Messages . . . . . . . . . . . . . . . . . . . . . 38

Hardware Troubleshooter . . . . . . . . . . . . . . . 40

Dell Diagnostics . . . . . . . . . . . . . . . . . . . . . . 40

Restoring Your Operating System . . . . . . .43

System Restore . . . . . . . . . . . . . . . . . . . . . . . 44

Dell Factory Image Restore . . . . . . . . . . . . .45

Operating System Reinstallation . . . . . . . . . 47

Contents

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . .49

Technical Support and Customer

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

DellConnect™ . . . . . . . . . . . . . . . . . . . . . . . . . 50

Online Services . . . . . . . . . . . . . . . . . . . . . . . 51

Automated Order-Status Service. . . . . . . . . 52

Product Information. . . . . . . . . . . . . . . . . . . . 52

Returning Items for Repair Under

Warranty or for Credit . . . . . . . . . . . . . . . . . . 53

Before You Call. . . . . . . . . . . . . . . . . . . . . . . .54

Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . 55

Finding More Information and

Resources . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Specifications . . . . . . . . . . . . . . . . . . . . . . .58

Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Macrovision Product Notice. . . . . . . . . . . . . 67

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Setting Up Your Inspiron™ Laptop

INSPIRON

This section provides information about setting up your Inspiron 1320 laptop.

Before Setting Up Your Computer

When positioning your computer, ensure that you allow easy access to a power source, adequate ventilation, and a level surface to place your computer.

Restricting airflow around your Inspiron laptop may cause it to overheat. To prevent overheating ensure that you leave at least

10.2 cm (4 inches) at the back of the computer and a minimum of 5.1 cm (2 inches) on all other sides. You should never place your computer in an enclosed space, such as a cabinet or drawer when it is powered on.

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell™ computer in a low-airflow environment, such as a closed briefcase, while it is powered on. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.

CAUTION: Placing or stacking heavy or sharp objects on the computer may result in permanent damage to the computer.

Setting Up Your Inspiron™ Laptop

Connect the AC Adapter

Connect the AC adapter to the computer and then plug the other end to an electrical outlet or surge protector.

WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to a power strip or electrical outlet may cause fire or permanent damage to your computer.

NOTE: Use only Dell AC adapter family PA-12, PA-2E, and PA-3E with your computer.

Connect the Network Cable (Optional)

To use a wired network connection, connect the network cable.

Setting Up Your Inspiron™ Laptop

Press the Power Button

Setting Up Your Inspiron™ Laptop

Set Up Microsoft® Windows Vista

Your computer is preconfigured with Windows Vista operating system if you ordered it while purchasing your computer. To set up Windows Vista for the first time, follow the instructions on the screen. These steps are mandatory and may take up to 15 minutes to complete. The Windows Vista setup screen will take you through several procedures including accepting license agreements, setting preferences, and setting up an Internet connection.

CAUTION: Do not interrupt the operating system’s setup process. Doing so may render your computer unusable and you will need to reinstall the operating system.

Setting Up Your Inspiron™ Laptop

Enable or Disable Wireless (Optional)

Setting Up Your Inspiron™ Laptop

Press the <F2> key or press the1. key on the keyboard to enable or disable wireless. The wireless enable or disable dialog box will appear on your screen.

Press the left-arrow key or the right-arrow keys to:2.

Enable Bluetooth –

Enable Wireless LAN –

Enable Bluetooth and Wireless LAN –

Disable Bluetooth and Wireless LAN –

Press <Enter> to apply the change.3.

Setting Up Your Inspiron™ Laptop

Connect to the Internet (Optional)

To connect to the Internet, you need an external modem or network connection and an Internet service provider (ISP).

If an external USB modem or WLAN adapter is not a part of your original order, you can purchase one from the Dell website at www.dell.com.

You can connect to the Internet using either a wired or a wireless connection.

Setting Up a Wired Connection

If you are using a dial-up connection, • connect the telephone line to the external USB modem (optional) and to the telephone wall connector before you set up your Internet connection.

If you are using a DSL or cable/satellite • modem connection, contact your ISP or cellular telephone service for setup instructions

Setting Up a Wireless Connection

Before you can use your wireless Internet connection, you need to connect to your wireless router.

Ensure that wireless is enabled on your 1. computer (see “Enable or Disable Wireless” on page 10).

Save and close any open files, and exit any 2. open programs.

Click 3. Start → Connect To.

Follow the instructions on the screen to 4. complete the setup.

Setting Up Your Inspiron™ Laptop

Setting Up Your Internet Connection

ISPs and ISP offerings vary by country. Contact your ISP for offerings available in your country.

If you cannot connect to the Internet but have successfully connected in the past, the ISP might have a service outage. Contact your ISP to check the service status, or try connecting again later.

Have your ISP information ready. If you do not have an ISP, the Connect to the Internet wizard can help you get one.

Save and close any open files, and exit any 1. open programs.

NOTE: The following instructions are applicable for the Windows default view, they may not apply if you set your computer to the Windows Classic view.

Click 2. Start → Control Panel.

Click 3. Network and Internet→Network

and Sharing Center→Setup a Connection→Connect to the Internet.

The Connect to the Internet window appears.

NOTE: If you do not know which type of

connection to select, click Help me choose or contact your ISP.

Follow the instructions on the screen and 4. use the setup information provided by your ISP to complete the setup.

Using Your Inspiron Laptop

Your Inspiron 1320 laptop has indicators and buttons that provide information and enable you to

INSPIRON

perform common tasks. The connectors on your computer provide the option of attaching additional devices.

Right Side Features

ExpressCard slot – Supports one ExpressCard. The computer ships with a plastic blank

installed in the slot.

NOTE: Your computer ships with a plastic blank installed in the ExpressCard slot. Blanks protect unused slots from dust and other particles. Save the blank for use when no ExpressCard is installed in the slot; blanks from other computers may not fit your computer.

Using Your Inspiron Laptop

Audio out/Headphone connector – Connects to a pair of headphones, or sends audio to a

powered speaker or sound system.

Audio in/Microphone connector – Connects to a microphone or inputs signal for use

with audio programs.

IEEE 1394 connector – Connects to high-speed serial multimedia devices, such as digital

video cameras.

USB 2.0 connectors (2) – Connects to USB devices, such as a mouse, keyboard, printer,

external drive, or MP3 player.

eSATA/USB combo connector – Connects to eSATA compatible storage devices (such as external hard disk drives or optical drives) or USB devices (such as a mouse, keyboard, printer, external drive, or MP3 player).

Network connector – Connects your computer to a network or a broadband device if you are using a wired network.

Security cable slot – Attaches a commercially available antitheft device to the computer.

NOTE: Before you buy an antitheft device, ensure that it works with the security cable slot on

your computer.

Using Your Inspiron Laptop

1 2 3

Left Side Features

Using Your Inspiron Laptop

AC adapter connector – Connects to the AC adapter to power the computer and charge the battery.

VGA connector – Connects to a monitor or projector.

HDMI connector – Connects to a TV for both 5.1 audio and video signals.

NOTE: When used with a monitor, only the video signal is read.

share digital photos, music, videos, and documents stored on the following digital memory cards:

Secure Digital (SD) memory card• Secure Digital High Capacity •

(SDHC) card Multimedia Card (MMC)• Memory Stick• Memory Stick PRO•

NOTE: Your computer ships with a plastic blank installed in the Media Card Reader slot. Blanks protect unused slots from dust and other particles. Save the blank for use when no Media card is installed in the slot; blanks from other computers may not fit your computer.

5-in-1 Media Card Reader – Provides a fast and convenient way to view and

Using Your Inspiron Laptop

3 4 5

Computer Base Features

Using Your Inspiron Laptop

Power/Battery indicator light – The light indicates the following states when powered

using an AC adapter or a battery.

Indicator light status Computer state(s) Battery charge level

AC Adapter

Battery

NOTE: The battery is charging when the computer is powered using an AC adapter.

Solid white on

off/hibernate

Breathing white standby n/a

off off/hibernate >90%

Solid white on >10%

Breathing white standby >10%

Solid amber on/standby <10%

off off/hibernate n/a

n/a <90%

Using Your Inspiron Laptop

Hard drive activity light – Turns on when the computer reads or writes data. A blinking

light indicates hard drive activity.

NOTE: To avoid loss of data, never turn off the computer while the hard drive activity light is flashing.

Keyboard – The media controls are also located on the keyboard. These keys control CD, DVD,

and media playback. For more information about the keyboard, see the on your hard drive or on the Dell Support website at support.dell.com.

Touch pad – Provides the functionality of a mouse to move the cursor, drag or move selected

items, and left-click by tapping the surface.

Touch pad buttons – Provide left- and right-click functions like those on a mouse.

Dell Technology Guide

Using Your Inspiron Laptop

Media Controls

The media control keys are located on the keyboard.

To use the media controls, press the required key. You can use the Function Key Behavior setting in the System Setup (BIOS) utility to configure the media control keys.

The options in the Function Key Behavior setting are:

Multimedia Key First – This is the default option. Press any multimedia key to perform the associated action. For function key, press <Fn> + the required function key.

Function Key First – Press any function key to perform the associated action. For multimedia key, press <Fn> + the required multimedia key.

Mute the sound

Decrease the volume level

Increase the volume level

Play the previous track or chapter

Play or pause

Play the next track or chapter

Eject the disc from optional USB/eSATA optical drive

Using Your Inspiron Laptop

Display Features

Using Your Inspiron Laptop

Microphone – Provides quality sound for audio chatting and voice recording.

Camera activity light – Indicates if the camera is on or off.

Camera – Built-in camera for video capture, conferencing, and chat.

Display – Your display can vary based on selections you made when purchasing your

computer. For more information about displays, see the drive or on the Dell Support website at support.dell.com.

Dell Technology Guide

on your hard

Using Your Inspiron Laptop

Removing and Replacing the Battery

WARNING: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.

WARNING: Using an incompatible battery may increase the risk of fire or explosion. This computer should only use a battery purchased from Dell. Do not use batteries from other computers.

WARNING: Before removing the battery, shut down the computer, and remove external cables (including the AC adapter).

To remove the battery:

Shut down the computer and turn it over. 1.

Slide the battery release latch to the unlock position.2.

Slide the battery out and lift it.3.

To replace the battery:

Align the battery with the notch on both sides and place it in the battery bay. 1.

Push the battery until it clicks into place.2.

battery

battery bay

battery release latch

Using Your Inspiron Laptop

Software Features

NOTE: For more information about the

features described in this section, see the

Dell Technology Guide

drive or on the Dell Support website at

support.dell.com.

Productivity and Communication

You can use your computer to create presentations, brochures, greeting cards, fliers, and spreadsheets. You can also edit and view digital photographs and images. Check your purchase order for software installed on your computer.

After connecting to the Internet, you can access websites, setup an e-mail account, upload and download files, and so on.

on your hard

Entertainment and Multimedia

You can use your computer to watch videos, play games, create your own CDs/DVDs, listen to music and Internet radio stations.

NOTE: Your computer does not have an internal optical drive. Use an external optical drive or any external storage device for the procedures that involve discs.

You can download or copy pictures and video files from portable devices, such as digital cameras and cell phones. Optional software applications enable you to organize and create music and video files that can be recorded to disc, saved on portable products such as MP3 players and handheld entertainment devices, or played and viewed directly on connected TVs, projectors, and home theater equipment.

Using Your Inspiron Laptop

Customizing the Desktop

You can customize your desktop to change the appearance, resolution, wallpaper, screensaver, and so on by accessing the Personalize appearance and sounds window.

To access the Display Properties window:

Right-click an open area of the desktop.1.

Click 2. Personalize, to open the Personalize appearance and sounds window and learn more about your customization options.

Customizing Your Energy Settings

You can use the power options in your operating system to configure the power settings on your computer. Microsoft® Windows Vista® installed on your Dell computer provides three default options:

Dell Recommended• — This power option offers full performance when you need it and saves power during periods of inactivity.

Power saver• — This power option saves power on your computer by reducing system performance to maximize the life of the computer and by reducing the amount of energy consumed by your computer over its lifetime.

High performance• — This power option provides the highest level of system performance on your computer by adapting processor speed to your activity and by maximizing system performance.

Using Your Inspiron Laptop

Transferring Information to a New Computer

Click 1. Start → Control Panel→ System and Maintenance→ Welcome Center→ Transfer files and settings.

If the User Account Control window appears, click Continue.

Follow the instructions in the 2. Windows Easy Transfer wizard.

Backing Up Your Data

It is recommended that you periodically back up files and folders on your computer. To back up files:

Click 1. Start → Control Panel→ System

and Maintenance→ Backup and Restore Center→ Backup Files.

If the User Account Control window appears,

click Continue.

NOTE: Certain editions of Windows

Vista provide an option to back up your computer.

Follow the instructions in the 2. Back Up Files wizard.

Solving Problems

INSPIRON

This section provides troubleshooting information for your computer. If you cannot solve your problem using the following guidelines, see “Using Support Tools” on page 37 or “Contacting Dell” on page 55.

WARNING: Only trained service personnel should remove the computer cover. See the

Service Manual

website at support.dell.com for advanced service instructions.

on the Dell Support

Beep Codes

Your computer might emit a series of beeps during start-up if the monitor cannot display errors or problems. The following repetitive beep codes help you troubleshoot problems with your computer.

NOTE: To replace parts, see the

Manual

on the Dell Support website at

support.dell.com.

One beep —

BIOS ROM checksum failure

Contact Dell (see “Contacting Dell” on page 55).

Possible motherboard failure -

Service

Solving Problems

Two beeps —

Remove the memory modules, reinstall • one module and restart the computer. If the computer starts normally, reinstall an additional module. Continue until you have identified a faulty module or reinstalled all modules without an error.

If available, install memory modules of the • same type in your computer.

If the problem persists, contact Dell (see • “Contacting Dell” on page 55).

Three beeps —

No RAM detected

Possible motherboard failure -

Chipset error

Contact Dell (see “Contacting Dell” on page 55).

Four beeps —

Ensure that no special memory module/• memory connector placement requirements exist (see the Support website at support.dell.com).

RAM read/write failure

Service Manual

on the Dell

Verify that the memory modules that you are • installing are compatible with your computer. For more information about the type of memory supported by your computer, see “Specifications” on page 58.

If the problem persists, contact Dell (see • “Contacting Dell” on page 55).

Five beeps —

Replace the battery.

Six beeps —

Contact Dell (see “Contacting Dell” on page 55).

Seven beeps —

Contact Dell (see “Contacting Dell” on page 55).

Eight beeps —

Contact Dell (see “Contacting Dell” on page 55).

Real Time Clock failure

Video card or chip failure

Processor failure

Display failure

Solving Problems

Network Problems

Wireless Connections

If the wireless network connection is lost —

The wireless router is offline or wireless has been disabled on the computer.

Check your wireless router to ensure it is • powered on and connected to your data source (cable modem or network hub).

Interference may be blocking or interrupting • your wireless connection. Try moving the computer closer to your wireless router.

Re-establish your connection to the wireless • router:

Ensure that wireless is enabled on your a. computer (see “Enabling or Disabling Wireless” on page 10).

Click b. Start → Connect To.

Follow the instructions on the screen c. to complete the setup.

Wired Connections

If the network connection is lost — The cable

is loose or damaged.

Check the cable to ensure it is plugged in • and not damaged.

The link integrity light on the integrated network connector lets you verify that your connection is working and provides information on the status:

Green — A good connection exists between • a 10-Mbps network and the computer.

Orange — A good connection exists between • a 100/1000-Mbps network and the computer.

Off — The computer is not detecting a • physical connection to the network.

NOTE: The link integrity light on the network connector is only for the wired cable connection. The link integrity light does not provide status for wireless connections.

Solving Problems

Power Problems

If the power light is off — The computer is

either turned off, in hibernate state or is not receiving power.

Reseat the power cable into both the • power connector on the computer and the electrical outlet.

If the computer is plugged into a power strip, • ensure that the power strip is plugged into an electrical outlet and that the power strip is turned on. Also bypass power protection devices, power strips, and power extension cables to verify that the computer turns on properly.

Ensure that the electrical outlet is working • by testing it with another device, such as a lamp.

Check the AC adapter cable connections. • If the AC adapter has a light, ensure that the light on the AC adapter is on.

If the power light is solid white and the computer is not responding — The computer

is either turned off, in hibernate state or the display may not be responding.

Press the power button. The computer • resumes normal operation if it is off or in hibernate mode.

If the display is not responding, press the • power button until the computer turns off and then turn it back on.

If the problem persists, contact Dell (see • “Contacting Dell” on page 55 for assistance).

If the power light is solid amber and the computer is not responding — The computer is

in standby mode with low battery or the display may not be responding.

Connect the AC adapter to power the • computer and charge the battery.

Solving Problems

Move the connected mouse or a finger on • the touch pad or press the power button to resume normal operation.

If the display is not responding, press the • power button until the computer turns off and then turn it back on.

If the problem persists, contact Dell (see • “Contacting Dell” on page 55 for assistance).

If the power light is breathing white and the computer is not responding — The computer

is in standby mode or the display may not be responding.

Move the connected mouse or a finger on • the touch pad or press the power button to resume normal operation.

If the display is not responding, press the • power button until the computer turns off and then turn it back on.

If the problem persists, contact Dell (see • “Contacting Dell” on page 55 for assistance).

If you encounter interference that hinders reception on your computer — An unwanted

signal is creating interference by interrupting or blocking other signals. Some possible causes of interference are:

Power, keyboard, and mouse extension cables.•

Too many devices connected to a power strip.•

Multiple power strips connected to the same • electrical outlet.

Solving Problems

Memory Problems

If you receive an insufficient memory message —

Save and close any open files and exit any • open programs you are not using to see if that resolves the problem.

See the software documentation for • minimum memory requirements. If necessary, install additional memory (see the Service Manual on the Dell Support website at support.dell.com).

Reseat the memory modules (see the • Service Manual on the Dell Support website at support.dell.com) to ensure that your computer is successfully communicating with the memory.

If you experience other memory problems —

Ensure that you are following the memory • installation guidelines (see the Service Manual on the Dell Support website at support.dell.com).

Check if the memory module is compatible • with your computer. Your computer supports DDR2 memory. For more information about the type of memory supported by your computer, see “Specifications” on page 58.

Run the Dell Diagnostics (see “Dell • Diagnostics” on page 40).

Reseat the memory modules (see the • Service Manual on the Dell Support website at support.dell.com) to ensure that your computer is successfully communicating with the memory.

Solving Problems

Lockups and Software Problems

If the computer does not start up — Ensure

that the power cable is firmly connected to the computer and to the electrical outlet.

If a program stops responding — End the program:

Press <Ctrl><Shift><Esc> simultaneously.1.

Click 2. Applications.

Select the program that is no longer 3. responding.

Click 4. End Task.

If a program crashes repeatedly — Check the software documentation. If necessary, uninstall and then reinstall the program.

NOTE: Software usually includes installation instructions in its documentation or on the CD.

NOTE: Your computer does not have an internal optical drive. Use an external optical drive or any external storage device for the procedures that involve discs.

If the computer stops responding or a solid blue screen appears —

WARNING: You might lose data if you are unable to perform an operating system shutdown.

If you are unable to get a response by pressing a key on your keyboard or moving your mouse, press the power button for at least 8 to 10 seconds until the computer turns off and then restart your computer.

Solving Problems

If a program is designed for an earlier Microsoft® Windows® operating system —

Run the Program Compatibility Wizard. The Program Compatibility Wizard configures a program so that it runs in an environment similar to non-Windows Vista operating system environments.

Click 1. Start → Control Panel→

Programs→ Use an older program with this version of Windows.

In the welcome screen, click 2. Next.

Follow the instructions on the screen.3.

If you have other software problems —

Back up your files immediately.•

Use a virus-scanning program to check the • hard drive or CDs.

Save and close any open files or programs • and shut down your computer through the Start menu.

Check the software documentation or • contact the software manufacturer for troubleshooting information:

Ensure that the program is compatible – with the operating system installed on your computer.

Ensure that your computer meets the – minimum hardware requirements needed to run the software. See the software documentation for information.

Ensure that the program is installed and – configured properly.

Verify that the device drivers do not – conflict with the program.

If necessary, uninstall and then reinstall – the program.

Using Support Tools

INSPIRON

Dell Support Center

The Dell Support Center helps you find the service, support, and system-specific information you need.

Click the icon in the taskbar to run the application. The home page provides links to access:

Self Help (Troubleshooting, Security, System • Performance, Network/Internet, Backup/ Recovery, and Windows Vista)

Alerts (technical support alerts relevant to • your computer)

Assistance from Dell (Technical Support with • DellConnect™, Customer Service, Training and Tutorials, How-To Help with Dell on Call, and Online Scan with PC CheckUp)

About Your System (System Documentation, • Warranty Information, System Information, Upgrades & Accessories)

The top of the Dell Support Center home page displays your system’s model number along with its service tag and express service code.

For more information about the Dell Support Center and available support tools, click the Services tab on support.dell.com.

Using Support Tools

System Messages

If your computer has an issue or an error, it may display a System Message that will help you identify the cause and action needed to resolve the issue.

NOTE: If the message you received is not listed in the following examples, see the documentation for either the operating system or the program that was running when the message appeared. Alternatively you could see the Dell Technology Guide on your hard drive or on the Dell Support website at support.dell.com or see “Contacting Dell” on page 55 for assistance.

Alert! Previous attempts at booting this system have failed at checkpoint [nnnn]. For help in resolving this problem, please note this checkpoint and contact Dell Technical Support — The computer failed to complete

the boot routine three consecutive times for the same error (see “Contacting Dell” on page 55 for assistance).

CMOS checksum error — Possible motherboard failure or RTC battery low. Replace the battery (see the Service Manual on the Dell Support website at support.dell.com or see “Contacting Dell” on page 55 for assistance).

CPU fan failure — CPU fan has failed. Replace the CPU fan (see the Service Manual on the Dell Support website at support.dell.com).

Hard-disk drive failure — Possible hard disk drive failure during POST (see “Contacting Dell” on page 55 for assistance).

Hard-disk drive read failure — Possible hard disk drive failure during HDD boot test (see “Contacting Dell” on page 55 for assistance).

Keyboard failure — Keyboard failure or loose cable. Replace the keyboard, see the Service Manual on the Dell Support website at support.dell.com.

Using Support Tools

No boot device available — No bootable partition on hard disk drive, the hard disk drive cable is loose, or no bootable device exists.

If the hard drive is your boot device, ensure • that the cables are connected and that the drive is installed properly and partitioned as a boot device.

Enter system setup and ensure that the boot • sequence information is correct (see the Dell Technology Guide on the Dell Support website at support.dell.com).

No timer tick interrupt — A chip on the system board might be malfunctioning or motherboard failure (see “Contacting Dell” on page 55 for assistance).

USB over current error — Disconnect the USB device. Your USB device needs more power for it to function properly. Use an external power source to connect the USB device, or if your device has two USB cables, connect both of them.

NOTICE- Hard Drive SELF MONITORING SYSTEM has reported that a parameter has exceeded its normal operating range. Dell recommends that you back up your data regularly. A parameter out of range may or may not indicate a potential hard drive problem —

S.M.A.R.T error, possible hard disk drive failure. This feature can be enabled or disabled in the BIOS setup (see “Contacting Dell” on page 55 for assistance).

Using Support Tools

Hardware Troubleshooter

If a device is either not detected during the operating system setup or is detected but incorrectly configured, you can use the Hardware Troubleshooter to resolve the incompatibility.

To start the Hardware Troubleshooter:

Click 1. Start → Help and Support.

Type 2. hardware troubleshooter in the search field and press <Enter> to start the search.

In the search results, select the option that 3. best describes the problem and follow the remaining troubleshooting steps.

Dell Diagnostics

If you experience a problem with your computer, perform the checks in “Lockups and Software Problems” on page 35 and run the Dell Diagnostics before you contact Dell for technical assistance.

NOTE: Dell Diagnostics works only on Dell computers.

NOTE: The

is optional and may not ship with your computer.

See the Dell Technology Guide to review your computer’s configuration information, and ensure that the device that you want to test displays in the system setup program and is active.

Start the Dell Diagnostics from your hard drive or from the

Drivers and Utilities

disc

disc.

Using Support Tools

Starting Dell Diagnostics From Your Hard Drive

The Dell Diagnostics is located on a hidden diagnostic utility partition on your hard drive.

NOTE: If your computer cannot display a screen image, see “Contacting Dell” on page 55.

Ensure that the computer is connected to an 1. electrical outlet that is known to be working properly.

Turn on (or restart) your computer.2.

When the DELL3. immediately. Select Diagnostics from the boot menu and press <Enter>.

™

logo appears, press <F12>

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop; then, shut down your computer and try again.

NOTE: If you see a message stating that no diagnostics utility partition has been found, run the Dell Diagnostics from the

and Utilities

disc.

Drivers

Press any key to start the Dell Diagnostics 4. from the diagnostics utility partition on your hard drive.

When the Dell Diagnostics 5. Main Menu appears, select the test you want to run.

Using Support Tools

Starting Dell Diagnostics From the Drivers and Utilities Disc

NOTE: Your computer does not have an

internal optical drive. Use an external optical drive or any external storage device for the procedures that involve discs

Insert the1.

Shut down and restart the computer. 2. When the DELL logo appears, press <F12> immediately.

Drivers and Utilities

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop; then, shut down your computer and try again.

NOTE: The next steps change the boot sequence for one time only. On the next start-up, the computer boots according to the devices specified in the system setup program.

disc.

When the boot device list appears, highlight 3. CD/DVD/CD-RW and press <Enter>.

Select the 4. Boot from CD-ROM option from the menu that appears and press <Enter>.

Type 1 to start the CD menu and press 5. <Enter> to proceed.

Select 6. Run the 32 Bit Dell Diagnostics from the numbered list. If multiple versions are listed, select the version appropriate for your computer.

When the Dell Diagnostics 7. Main Menu appears, select the test you want to run.

Restoring Your Operating System

INSPIRON

You can restore your operating system in the following ways:

System • Restore returns your computer to an earlier operating state without affecting data files. Use System Restore as the first solution for restoring your operating system and preserving data files.

Dell • Factory Image Restore returns your hard drive to the operating state it was in when you purchased the computer. This procedure permanently deletes all data on the hard drive and removes any programs installed after you received the computer. Use Dell Factory Image Restore only if System Restore did not resolve your operating system problem.

If you received an Operating System disc • with your computer, you can use it to restore your operating system. However, using the Operating System disc also deletes all data on the hard drive. Use the disc only if System Restore did not resolve your operating system problem.

NOTE: Your computer does not have an internal optical drive. Use an external optical drive or any external storage device for the procedures that involve discs.

Restoring Your Operating System

System Restore

The Windows operating systems provide a System Restore option which allows you to return your computer to an earlier operating state (without affecting data files) if changes to the hardware, software, or other system settings have left the computer in an undesirable operating state. Any changes that System Restore makes to your computer are completely reversible.

CAUTION: Make regular backups of your data files. System Restore does not monitor your data files or recover them.

NOTE: The procedures in this document are

applicable for the Windows default view, so they may not apply if you set your Dell™ computer to the Windows Classic view.

Starting System Restore

Click 1. Start .

In the 2. Start Search box, type System Restore and press <Enter>.

NOTE: The User Account Control window may appear. If you are an administrator on the computer, click Continue; otherwise, contact your administrator to continue the desired action.

Click 3. Next and follow the instructions on the screen.

In the event that System Restore did not resolve the issue, you may undo the last system restore.

Restoring Your Operating System

Undoing the Last System Restore

NOTE: Before you undo the last system

restore, save and close all open files and exit any open programs. Do not alter, open, or delete any files or programs until the system restoration is complete.

Click 1. Start .

In the 2. Start Search box, type System Restore and press <Enter>.

Click 3. Undo my last restoration and click

Next.

Dell Factory Image Restore

CAUTION: Using Dell Factory Image Restore permanently deletes all data on the hard drive and removes any programs or drivers installed after you received your computer. If possible, back up the data before using this option. Use Dell Factory Image Restore only if System Restore did not resolve your operating system problem.

NOTE: Dell Factory Image Restore may

not be available in certain countries or on certain computers.

Use Dell Factory Image Restore only as the last method to restore your operating system. This option restores your hard drive to the operating state it was in when you purchased the computer. Any programs or files added since you received your computer—including data files—are permanently deleted from the hard drive. Data files include documents, spreadsheets, e-mail messages, digital photos,

Restoring Your Operating System

music files, and so on. If possible, back up all data before using Dell Factory Image Restore.

Turn on the computer. When the Dell logo 1. appears, press <F8> several times to access the Vista Advanced Boot Options window.

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop; then, shut down your computer and try again.

Select 2. Repair Your Computer.

The 3. System Recovery Options window appears.

Select a keyboard layout and click 4. Next.

To access the recovery options, log on as 5. a local user. To access the command prompt, type administrator in the User name field, then click OK.

Click 6. Dell Factory Image Restore. The Dell Factory Image Restore welcome screen

appears.

NOTE: Depending upon your configuration, you may need to select Dell Factory Tools, then Dell Factory Image Restore.

Click 7. Next. The Confirm Data Deletion screen appears.

NOTE: If you do not want to proceed with Factory Image Restore, click Cancel.

Select the checkbox to confirm that you 8. want to continue reformatting the hard drive and restoring the system software to the factory condition, then click Next.

The restore process begins and may take five or more minutes to complete. A message appears when the operating system and factory-installed applications have been restored to factory condition.

Click 9. Finish to reboot the system.

Restoring Your Operating System

Operating System Reinstallation

Before You Begin

If you are considering reinstalling the Windows operating system to correct a problem with a newly installed driver, first try using Windows Device Driver Rollback. If Device Driver Rollback does not resolve the problem, then use System Restore to return your operating system to the operating state it was in before you installed the new device driver. See “System Restore” on page 44.

CAUTION: Before performing the installation, back up all data files on your primary hard drive. For conventional hard drive configurations, the primary hard drive is the first drive detected by the computer.

To reinstall Windows, you need the following:

Dell•

Operating System

Dell•

Drivers and Utilities

NOTE: The contains drivers that were installed during the assembly of the computer. Use the Dell Drivers and Utilities disc to load any required drivers. Depending on the region from which you ordered your computer, or whether you requested the disc, the Dell

Drivers and Utilities System

computer.

Drivers and Utilities

disc may not ship with your

disc

disc and

disc

Operating

Restoring Your Operating System

Reinstalling Windows Vista

NOTE: Your computer does not have an

internal optical drive. Use an external optical drive or any external storage device for the procedures that involve discs.

The reinstallation process can take 1 to 2 hours to complete. After you reinstall the operating system, you must also reinstall the device drivers, virus protection program, and other software.

Save and close any open files and exit any 1. open programs.

Insert the 2.

Click 3. Exit if the Install Windows message appears.

Restart the computer.4.

When the DELL logo appears, press <F12> 5. immediately.

Operating System

disc.

NOTE: If you wait too long and the operating system logo appears, continue to wait until you see the Microsoft® Windows® desktop; then, shut down your computer and try again.

NOTE: The next steps change the boot sequence for one time only. On the next start-up, the computer boots according to the devices specified in the system setup program.

When the boot device list appears, highlight 6. CD/DVD/CD-RW Drive and press <Enter>.

Press any key to 7. Boot from CD-ROM. Follow the instructions on the screen to complete the installation.

Getting Help

INSPIRON

If you experience a problem with your computer, you can complete the following steps to diagnose and troubleshoot the problem:

See “Solving Problems” on page 1. 29 for information and procedures that pertain to the problem your computer is experiencing.

See the 2.

Dell Technology Guide

troubleshooting information.

See “Dell Diagnostics” on page 3. 40 for procedures on how to run Dell Diagnostics.

Fill out the “Diagnostic Checklist” on 4. page 54.

Use Dell’s extensive suite of online services 5. available at Dell Support (support.dell.com) for help with installation and troubleshooting procedures. See “Online Services” on page 51 for a more extensive list of Dell Support online.

for more

If the preceding steps have not resolved the 6. problem, see “Before You Call” on page 54.

NOTE: Call Dell Support from a telephone near or at the computer so that the support staff can assist you with any necessary procedures.

NOTE: Dell’s Express Service Code system may not be available in all countries.

When prompted by Dell’s automated telephone system, enter your Express Service Code to route the call directly to the proper support personnel. If you do not have an Express Service Code, open the Dell Accessories folder, double-click the Express Service Code icon, and follow the directions.

NOTE: Some of the services are not always available in all locations outside the continental U.S. Call your local Dell representative for information on

availability.

Getting Help

Technical Support and Customer Service

Dell’s support service is available to answer your questions about Dell hardware. Our support staff use computer-based diagnostics to provide fast, accurate answers.

To contact Dell’s support service, see “Before You Call” on page 54 and then see the contact information for your region or go to support.dell.com.

DellConnect™

DellConnect is a simple online access tool that allows a Dell service and support associate to access your computer through a broadband connection, diagnose your problem and repair it all under your supervision. For more information, go to www.dell.com/DellConnect.

Getting Help

Online Services

You can learn about Dell products and services on the following websites:

www.dell.com•

www.dell.com/ap• (Asian/Pacific countries

only)

www.dell.com/jp• (Japan only)

www.euro.dell.com• (Europe only)

www.dell.com/la• (Latin American and

Caribbean countries)

www.dell.ca• (Canada only)

You can access Dell Support through the following websites and e-mail addresses:

Dell Support websites

support.dell.com•

support.jp.dell.com• (Japan only)

support.euro.dell.com• (Europe only)

Dell Support e-mail addresses

mobile_support@us.dell.com•

support@us.dell.com•

la-techsupport@dell.com• (Latin America and

Caribbean countries only)

apsupport@dell.com• (Asian/Pacific countries only)

Dell Marketing and Sales e-mail addresses

apmarketing@dell.com• (Asian/Pacific

countries only)

sales_canada@dell.com• (Canada only)

Anonymous file transfer protocol (FTP)

ftp.dell.com•

Getting Help

Automated Order-Status Service

To check on the status of any Dell products that you have ordered, you can go to support.dell.com, or you can call the automated order-status service. A recording prompts you for the information needed to locate and report on your order. For the telephone number to call your region, see “Contacting Dell” on page 55.

If you have a problem with your order, such as missing parts, wrong parts, or incorrect billing, contact Dell for customer assistance. Have your invoice or packing slip handy when you call. For the telephone number to call for your region, see “Contacting Dell” on page 55.

Product Information

If you need information about additional products available from Dell, or if you would like to place an order, visit the Dell website at www.dell.com. For the telephone number to call for your region or to speak to a sales specialist, see “Contacting Dell” on page 55.

Getting Help

Returning Items for Repair Under Warranty or for Credit

Prepare all items being returned, whether for repair or credit, as follows:

NOTE: Before you return the product to Dell, make sure to back up any data on the hard drive and on any other storage device in the product. Remove any and all confidential, proprietary and personal information, as well as removable media, such as CDs, and PC Cards. Dell is not responsible for any of your confidential, proprietary or personal information; lost or corrupted data; or damaged or lost removable media that may be included with your return.

Call Dell to obtain a Return Material 1. Authorization Number, and write it clearly and prominently on the outside of the box.

For the telephone number to call for your 2. region, see “Contacting Dell” on page 55.

Include a copy of the invoice and a letter 3. describing the reason for the return.

Include a copy of the Diagnostics Checklist (see 4. “Diagnostic Checklist” on page 54), indicating the tests that you have run and any error messages reported by the Dell Diagnostics (see “Dell Diagnostics” on page 40).

Include any accessories that belong with 5. the item(s) being returned (power cables, software, guides, and so on) if the return is for credit.

Pack the equipment to be returned in the 6. original (or equivalent) packing materials.

NOTE: You are responsible for paying shipping expenses. You are also responsible for insuring any product returned, and you assume the risk of loss during shipment to Dell. Collect On Delivery (C.O.D.) packages are not accepted.

NOTE: Returns that are missing any of the preceding requirements will be refused at Dell’s receiving dock and returned to you.

Getting Help

Before You Call

NOTE: Have your Express Service Code

ready when you call. The code helps Dell’s automated-support telephone system direct your call more efficiently. You may also be asked for your Service Tag (located on the back or bottom of your computer).

Remember to fill out the following Diagnostics Checklist. If possible, turn on your computer before you call Dell for assistance and call from a telephone at or near the computer. You may be asked to type some commands at the keyboard, relay detailed information during operations, or try other troubleshooting steps possible only at the computer itself. Ensure that the computer documentation is available.

Diagnostic Checklist

Name:•

Date:•

Address:•

Phone number:•

Service Tag (bar code on the back or bottom • of the computer):

Express Service Code:•

Return Material Authorization Number (if • provided by Dell support technician):

Operating system and version:•

Devices:•

Expansion cards:•

Are you connected to a network? Yes /No•

Network, version, and network adapter:•

Programs and versions:•

Getting Help

See your operating system documentation to determine the contents of the computer’s start-up files. If the computer is connected to a printer, print each file. Otherwise, record the contents of each file before calling Dell.

Error message, beep code, or diagnostic • code:

Description of problem and troubleshooting • procedures you performed:

Contacting Dell

For customers in the United States, call 800-WWW-DELL (800-999-3355).

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product catalog.

Dell provides several online and telephonebased support and service options. Availability varies by country and product, and some services may not be available in your area.

To contact Dell for sales, technical support, or customer service issues:

Visit 1. support.dell.com.

Verify your country or region in the 2. Choose A Country/Region drop-down menu at the bottom of the page.

Click 3. Contact Us on the left side of the page.

Select the appropriate service or support link 4. based on your need.

Choose the method of contacting Dell that is 5. convenient for you.

Finding More Information and Resources

If you need to: See:

INSPIRON

reinstall your operating system the Operating System disc

run a diagnostic program for your computer, reinstall notebook system software, or update drivers for your computer, and readme files

learn more about your operating system, maintaining peripherals, Internet, Bluetooth®, networking, and e-mail

upgrade your computer with new or additional memory, or a new hard drive

reinstall or replace a worn or defective part

the

Drivers and Utilities

NOTE: Drivers and documentation updates can be found on the Dell™ Support website at support.dell.com.

the

Dell Technology Guide

hard drive

the Service Manual on the Dell Support website at support.dell.com

NOTE: In some countries, opening and replacing parts of your computer may void your warranty. Check your warranty and return policies before working inside your computer.

disc

installed on your

If you need to: See:

find safety best practices information for your computer review Warranty information, Terms and Conditions (U.S. only), Safety instructions, Regulatory information, Ergonomics information, and End User License Agreement

find your Service tag/Express Service Code— You must use the service tag to identify your computer on support.dell.com or to contact technical support

find drivers and downloads

access technical support and product help

check on your order status for new purchases

find solutions and answers to common questions

locate information for last-minute updates about technical changes to your computer or advanced technical-reference material for technicians or experienced users

the safety and regulatory documents that shipped with your computer and also see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance

the back or bottom of your computer

the Dell Support website at

support.dell.com

Finding More Information and Resources

Specifications

System Model

INSPIRON

Inspiron 1320

This section provides information that you may need when setting up, updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start→ Help and Support and select the option to view information about your computer.

Processor

Type L2 cache

Intel® Core™2 Duo

Intel Pentium® Dual-Core

Intel Celeron® Dual-Core

L1 cache 128 KB (Intel-

External bus frequency:

Intel Core2 Duo

Intel Pentium Dual-Core

Intel Celeron Dual-Core

2 MB/3 MB

1 MB

64 KB per core)

800 MHz/1066 MHz

800 MHz

Specications

Memory

Connectors two user-accessible

SODIMM connectors

Capacities 1 GB, 2 GB, and

4 GB

Type 800 MHz SODIMM

DDR2

Memory configuration possible

Minimum 1 GB (single

Maximum 8 GB (dual channel)

NOTE: Memory specification of greater than 4 GB is not well supported by 32-bit operating systems.

1 GB, 2 GB, 3 GB, 4 GB, 6 GB, and 8 GB

channel)

Computer Information

System Chipset Intel GM45 (UMA)

Intel GM45 (Discrete)

Data bus width 64 bits

DRAM bus width dual channel (2)

64-bit buses

Processor address bus width

Flash EPROM 2 MB

Graphics bus PCI-E X16

32 bits

Specications

ExpressCard

Controller Mobile Intel Express

(ICH9m)

Cards supported ExpressCard/34 (34 mm)

1.5 V and 3.3 V

Connector size 26 pins

Communications

Network adapter 10/100/1000 Ethernet LAN

on system board

Wireless WPAN with Bluetooth®

wireless technology, wireless internal WLAN with WiFi bg and WiFi agn

Video

UMA

Video type integrated on system

board

Video controller Intel GM45

Video memory Up to 1292 MB of system

shared memory

LCD interface Low Voltage Differential

Signaling (LVDS)

Discrete

Video type discrete video card

Video controller ATI Mobility Radeon™ HD

4330

Video memory 512 MB

(64M x 16 x 4 DDR2)

LCD interface Low Voltage Differential

Signaling (LVDS)

Specications

Audio

Audio type IDT 92HD81B High

Definition Audio codec with SRS Premium Sound

Audio controller IDT 92HD81B

Stereo conversion

Internal Interface

External Interface

Speaker two 4-ohm speakers

Internal speaker amplifier

Volume controls software program menus

24-bit (analog-to-digital and digital-to-analog)

Intel High Definition Audio

microphone-in connector, stereo headphone/ speaker connector

1 watt per channel into 4 ohms

or media control buttons

Ports and Connectors

Audio one microphone

™

IEEE 1394a 4-pin serial connector

Mini-Card one half size Mini-Card

Network adapter RJ45 connector

eS ATA one seven-pin/four-pin

USB two 4-pin USB

HDMI 19-pin connector

VGA 15-hole connector

connector, one stereo headphone/speaker connector

slot

eSATA/USB combo connector with 5V/1.5A output

2.0-compliant connectors

Specications

Display

Type 13.3 inch High Definition

TrueLife

Dimensions:

Height 308.1 mm (12.1 inches)

Width 183.6 mm (7.23 inches)

Diagonal 336.6mm (13.3 inches)

Maximum resolution

Refresh rate 60 Hz

Luminance 200 min. 220 typ. cd/m²

Viewing Angles:

Horizontal ±45° (WLED) typ.

Vertical +15°/–35° (WLED) typ.

Pixel pitch 0.2148 mm

1366 x 768

(WLED 5 point avg)

Display

Controls brightness can be

controlled through keyboard shortcuts (see the

Dell Technology Guide

for more information)

Keyboard

Number of keys 86/103 (English-U.S.,

Simplified Chinese, Traditional Chinese, and Thai)

Layout QWERTY

Specications

Camera

Pixel 1.3 megapixel

Video resolution 320 x 240 ~1280 x 1024

(640 x 480 at 30 fps)

Diagonal viewing angle

60° ± 1°

Touch Pad

Resolution:

X coordinate 1701 DPI

Y coordinate 2540 DPI

Size:

Width 79.62 mm (3.13 inches)

sensor-active area

Height 39.51 mm (1.56 inches)

rectangle

Battery

Type 4-cell/6-cell smart

lithium ion

Depth 51.6 mm (2.03 inches)

(4/6 cell)

Height 21.0 mm (0.83 inches)

(4/6 cell)

Width 207.7 mm (8.18 inches)

(4/6 cell)

Weight 0.26 kg (0.57 lb) (4 cell)

0.34 kg (0.75 lb) (6 cell)

Voltage 14.8 VDC (4 cell)

11.1 VDC (6 cell)

Charge time (approximate):

4 hours (when the computer is turned off)

Specications

Battery

Operating time Battery operating time

varies depending on operating conditions and can be significantly reduced under certain power-intensive conditions.

See the

Dell Technology

Guide

on your hard drive or on the Dell Support website at support.dell. com for more information.

Life span (approximate)

Temperature range:

Operating 0° to 50°C (32° to 122°F)

Storage –20° to 60°C (–4° to 140°F)

Coin-cell battery CR-2032

300 discharge/charge cycles

AC Adapter

Input voltage 100–240 VAC

Input current (maximum)

Input frequency 50–60 Hz

Output power 65 W or 90 W

Rated Output current (90 W)

Rated Output current (65 W)

Rated output voltage

Dimensions:

65 W

Height 28.0 mm (1.10 inches)/

Width 58.0 mm (2.28 inches)/

1.5 A

4.62 A

3.34 A

19.5 VDC

16 mm (0.63 inches)

66 mm (5.6 inches)

Specications

AC Adapter

Depth 137.0 mm (5.39 inches)/

127 mm (5.0 inches)

Weight (with cables)

90 W

Height 21 mm (0.83 inches)/

Width 70 mm (2.76 inches)/

Depth 147 mm (5.79 inches)/

Weight (with cables)

Operating 0° to 40°C (32° to 104°F)

Storage –40° to 70°C (–104° to

0.56 kg (1.23 lb)/0.25 kg (0.55 lb)

16 mm (0.63 inches)

65 mm (2.56 inches)

90 mm (3.54 inches)

0.46 kg (1.01 lb)/0.26 kg (0.57 lb)

158°F)

Physical

Height 27.0 mm to 31.0 mm

(1.06 inches to 1.22 inches)

Width 322.0 mm (12.7 inches)

Depth 218.0 mm (8.58 inches)

Weight (with 4-cell battery):

Configurable to less than

1.68 kg (3.74 lb)

Computer Environment

Relative humidity (maximum):

Operating 10% to 90%

(noncondensing)

Storage 5% to 95%

(noncondensing)

Specications

Computer Environment

Altitude (maximum):

Operating –15.2 to 3048 m

(–50 to 10,000 ft)

Storage –15.2 to 10,668 m

(–50 to 35,000 ft)

Airborne contaminant level

Temperature range:

Operating 0° to 35°C (32° to 95°F)

Storage –40° to 65°C (–40° to

G2 or lower as defined by ISA-S71.04-1985

149°F)

Computer Environment

Maximum vibration (using a random-vibration spectrum that simulates user environment)

Operating 0.66 GRMS

Non-Operating 1.3 GRMS

Maximum shock (for operating - measured with Dell Diagnostics running on the hard drive and a 2-ms half-sine pulse; for nonoperating - measured with hard drive in head-parked position and a 2-ms half-sine pulse ):

Operating 110 GRMS

Non-Operating 160 GRMS

Appendix

Macrovision Product Notice

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

INSPIRON

Index

INSPIRON

AC adapter

size and weight 64, 65

airflow, allowing 5

backups

creating 28

calling Dell 54

CDs, playing and creating 26

chipset 59

computer capabilities 26

computer, setting up 5

conserving energy 27

Contacting Dell online 55

customer service 50

customizing

your desktop 26

your energy settings 27

damage, avoiding 5

data, backing up 28

Dell Diagnostics 40

Dell Factory Image Restore 43

Dell Support Center 37

Dell support website 57

Dell Technology Guide

for further information 56

Index

Diagnostic Checklist 54

drivers and downloads 57

DVDs, playing and creating 26

email addresses

for technical support 51

energy

conserving 27

expansion bus 60

finding more information 56

FTP login, anonymous 51

hardware problems

diagnosing 40

Hardware Troubleshooter 40

help

getting assistance and support 49

Internet connection 12

ISP

Internet Service Provider 12

memory problems

solving 34

memory support 59

network connection

fixing 31

network speed

testing 31

Index

power problems, solving 32

power strips, using 6

processor 58

products

information and purchasing 52

reinstalling Windows 43

resources, finding more 56

restoring factory image 45

setup, before you begin 5

shipping products

for return or repair 53

software features 26

software problems 35

specifications 56, 58

support email addresses 51

System Messages 38

System Restore 43

USB PowerShare 15

ventilation, ensuring 5

warranty returns 53

Windows, reinstalling 43

Windows Vista® 9

Program Compatibility Wizard 36

reinstalling 48

wired network connection 7

wireless network connection 31

0G374RA00

Printed in the U.S.A.

www.dell.com | support.dell.com

Dell G374R, P04S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Setting Up Your Inspiron™ Laptop

Before Setting Up Your Computer

Connect the AC Adapter

Connect the Network Cable (Optional)

Press the Power Button

Enable or Disable Wireless (Optional)

Connect to the Internet (Optional)

Using Your Inspiron Laptop

Right Side Features

Left Side Features

Computer Base Features

Media Controls

Display Features

Removing and Replacing the Battery

Software Features

Solving Problems

Beep Codes

Network Problems

Power Problems

Memory Problems

Lockups and Software Problems

Using Support Tools

Dell Support Center

System Messages

Hardware Troubleshooter

Dell Diagnostics

Restoring Your Operating System

System Restore

Dell Factory Image Restore

Operating System Reinstallation

Getting Help

Technical Support and Customer Service

DellConnect™

Online Services

Automated Order-Status Service

Product Information

Returning Items for Repair Under Warranty or for Credit

Before You Call

Contacting Dell

Finding More Information and Resources

Specifications

Appendix

Macrovision Product Notice

Index
