Dell Express Flash P4510/4610

Technical Specications and Information

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks

may be trademarks of their respective owners.

2019 - 03

Rev. A00

Dell Express Flash P4510/P4610 Specications

and Information

Use these specications and model-specic information to ensure proper application of your P4510/P4610.

Table 1. P4510/P4610 technical specications

Features Description

Media type 3D TLC NAND

P4510 capacities/form factors 1 TB U.2

2 TB U.2, qualied, not shipped (QNS)

4 TB U.2

8 TB U.2 (QNS)

P4610 capacities/form factors 1.6 TB U.2

3.2 TB U.2

6.4 TB U.2

User-addressable 512-byte sectors 1 TB: 1,953,525,168

1.6 TB: 3,125,627,568

2 TB: 3,907,029,168

3.2 TB: 6,251,233,968

4 TB: 7,814,037,168

6.4 TB: 12,502,446,768

8 TB: 15,628,053,168

Host bus interface PCIe Gen 3.0 x4

Device protocol NVM Express 1.2

Bootable device Yes, UEFI mode only

Hot-swap support Yes

P4510 I/O operations per second, 4K random read 1 TB: Up to 465,000 IOPS

2 TB: Up to 637,000 IOPS

4 TB: Up to 636,500 IOPS

8 TB: Up to 641,800 IOPS

Dell Express Flash P4510/P4610 Specications and Information 3

Features Description

P4510 I/O operations per second, 4K random read 1 TB: Up to 70,000 IOPS

2 TB: Up to 81,500 IOPS

4 TB: Up to 111,500 IOPS

8 TB: Up to 134,500 IOPS

P4610 I/O operations per second, 4K random read 1.6 TB: Up to 643,000 IOPS

3.2 TB: Up to 638,000 IOPS

6.4 TB: Up to 654,000 IOPS

P4610 I/O operations per second, 4K random read 1.6 TB: Up to 199,000 IOPS

3.2 TB: Up to 222,000 IOPS

6.4 TB: Up to 210,500 IOPS

P4510 endurance rating (TBW) 1 TB: 1.92 PB, 1 DWPD

2 TB: 2.61 PB, 1 DWPD

4 TB: 6.3 PB, 1 DWPD

8 TB: 13.88 PB, 1 DWPD

P4610 endurance rating (TBW) 1.6 TB: 12.55 PB, 3 DWPD

3.2 TB: 21.85 PB, 3 DWPD

6.4 TB: 36.54 PB, 3 DWPD

Data retention at end of life 3 months at 40°C

Power 12V, 3.3V aux, supply rail

<5 W, idle

21.5 W max

Operating temperature 0°C to 70°C

Physical dimensions 100.45 mm x 70.1 mm x 15.0 mm

Shock 1,000 G/0.5 ms

Vibration, non-operating 3.13 GRMS, 5 ~ 800 Hz

Minimum supported operating systems

: Supported on all operating systems using the included native drivers

NOTE

• Microsoft Windows Server 2016

• Microsoft Windows Server 2019

• VMware ESXi 6.5 U2

• VMware ESXi 6.7 U1

• Red Hat Enterprise Linux 7.6

Dell Express Flash P4510/P4610 Specications and Information

4

• SUSE Linux Enterprise Server 15

• Ubuntu 18.04.2

NOTE: iDRAC support is available with 14th generation of Dell systems onwards.
