F2600 & F2700

Low-Prole Freezer Equipment Stands

Models

F2660 60.25” Self-contained l ow-profile f reezer b as e equipment stand

•

F2694 94.25” Self-contained l ow-profile f reezer b as e equipment stand

•

F2748 48.25” Remote low-profile freezer base equipment stand

•

F2776 76.25” Remote low-profile freezer base equipment stand

Project ___ ____________________ ___________

Item _________________ ___________________

Quantity _________________ _______________

CSI Sec tion 11400

Approved ____________ ___________________

Date ____ _____________________ ___________

F2600 & F2700: Low-Prole Freezer Equipment Stands

F2660

Specifications

Ext eri or t op is 18- gau ge st ain less ste el wi th f ull per ime ter m ari ne

edg e. Corn ers ar e full y weld ed wit h smoo th rad ii cor ners f or eas y clea n

out . Inte rior sub top is 22-g auge sta inle ss s teel . Ov er t wo inche s o f

env iron ment ally f rie ndly, K yoto P roto col Co mpli ant, N on ODP ( Ozon e

Dep leti on Pot enti al), Non G WP (G loba l Warm ing Po tent ial) Polyu reth ane

two -par t fo am p rovi des insu latio n a nd r igid ity.

Ref rige rated base has 22 gaug e stai nles s stee l int erio r back and b ottom

wit h ABS th ermo form ed sid es. Bas e exte rior b ack, b otto m and si des ar e

con struc ted of galv anize d st eel.

Fini shed s tain less st eel en ds are st andar d. Louve r, coil pa nel an d d rawe r

fac es are a ll sta ndard w ith st ainl ess st eel co nstr ucti on. (Un it is su ppli ed

wit h a wal l-mo unte d br acke t a nd threa ded rod to all ow i nsta llat ion of the

uni t ag ains t a soli d su rfa ce.)

Uni ts fo undat ion i s ma de of 14 ga uge 1 .50" x 3.2 5" th ick galva nize d leg rail s

wit h cas ters as stand ard. Uni t co mes stand ard with a st ainl ess steel leg rail

cove r-up sk in. Leg s av ailab le on re ques t.

Full Ext ensi on P lus drawe r sys tem is a comp lete drawe r sy stem , whi ch c an

ope rate ind epen dent of the uni t i t’s insta lled in . D rawer sys tem is size d t o

hol d 12” x 20” x 4“ d eep ho tel pan s and s malle r frac tion al pan s. Draw er

sys tem is al l stain less s teel co nstr ucti on for ma ximu m durab ilit y. D rawer

tra ck roll ers ar e made o f Delr in and do not r equir e grea se for o perat ion.

Int erme diat e track s are re mova ble wit hout t ools a nd hou se Del fiel d’s

“ant i-fr icti on bina ry rol ler sys tem”. Dr awer bo xes are de sign ed with “eas y

Standard Features

Top is heavy duty stainless steel, with full perimeter

• marine ed ge Standard st ainless steel end s

• Exterior drawer fronts are s tainless steel

• High densi ty e nvironment ally frie ndly, Kyoto

• Protocol Compli ant, Non ODP (Ozone Depletion Potential), N on GWP (Global Warming Potential) polyurethane foam insulation throughout unit Snap-in drawer gaskets for easy removal

• 8’ cord and plug supplied

• Base interior cabinet is cooled w ith mull ion styl e

• coated blower co il(s) mount ed between ea ch door/drawer section for even air and temper ature control Digital th ermometer

• Electric condensate evaporator s are standard

• Wall-mounted b racket to prevent tipping

• Full Extension Plus Drawer system is a comple te

• drawer system. Drawer s ystem is sized to hold 12” x 20” x 4” deep hotel pans (by oth ers). The drawer system is all stainless steel construction for maximum du rability F26/270 0 base ca binet w ill mai ntain 0 º to -5º

• temperatures at 100º ambient room temp erature meeting NS F7 requirements When ordering, specify make, model a nd depth

•

pan gr ip flan ges”. Trac ks are des igne d w ith a stay s hut feat ure tha t h olds

the draw er g asket tig ht to the base fro nt on une ven f loor s. E xter ior drawe r

fro nts are made of stai nles s st eel; and an int erior ma de o f AB S p lasti c w ith

for med in cha nnel s to hous e t he sna p-in da rt sty le sant opre ne gask et. A

gal vani zed bra ce is fo amed i n plac e to be an i ntegr al par t of th e drawe r

fro nt ass embl y. Each drawe r fron t is in ject ed wi th 1.8 7” of hi gh den sity

pol yuret hane foam betw een t he ex teri or an d int erio r. Han dles are r ecess ed

bla ck p last ic a nd h eld in w ith a p osit ive lock syst em.

Mul lio n Co il Re frig era tion sy ste m u ses HF C-4 04A re fri gera nt, an d

mai ntai ns 0˚F (-1 8˚C) to - 5˚F (-2 1˚C) in teri or cabi net tem perat ure at 100 ˚F

(38 ˚C) ambie nt r oom t empe ratur e. B oth remot e an d sel f-co ntai ned m odel s

are stan dard with ext erio r di gital the rmom eter and elec tric cond ensa te

eva porat ors. Ele ctri cal con nect ions sh all be 11 5 v olt, 60 h ertz a nd sing le

pha se.

The Foll owin g Ap plie s To F270 0 Se ries (R emote ) O nly:

Rem ote mode ls h ave a d igita l t herm omete r i nstal led in the remo vabl e

acc ess p anel , de frost tim er, t herm osta t an d sol enoi d va lve. Remo te m odel s

mus t be har d-wi red at t he i nsta llati on site.

The Foll owin g Ap plie s To F260 0 Se ries (S elf- Conta ined ) O nly:

Sel f-c ont aine d m odel s h ave a p re- wir ed c onde nsi ng u nit , a di gita l

the rmom eter inst alle d in the remo vabl e lo uver and is s uppl ied with an 8.0'

(2. 4m) cord and plu g.

•

Options & Accessories

•

of co oking eq uipment s itting on the equipment stand Height of surface for setti ng e quipment is 25.50” Self-conta ined freezers are standard with a defrost timer Envi ronmen tally fri endly HFC- 404A refrigerant One year parts and 90 day labor stan dard warranty

Drawer locks 230V, 50Hz e lectrical system Stainless steel back Mechanical housing left side Set of 4 casters (F26 Ser ies) Set of 6 casters (F26 Ser ies) Doors in lieu of drawers (except 32”) Plastic laminate end Plastic laminate back Plastic laminate front

980 S. I sabella Rd. Mt. Pleasa nt, Michigan 4885 8

Phone: 800 -733-8948 or 989 -773-7981 Fax: 800-669-0 619

www.delfield.co m

60.25"

153 cm

18.00"

45.6 cm

10.00"

20.5 cm

32" (81.3 cm) FRZR

10.00” Mullion To

Accommodate Freezer

Mullion Coil

S/S End

94.25"

239.4 cm

24.00"

61.0cm

6.00” Mullion To Accommodate Freezer Mullion Coil

S/S Emd

6.00"

15.2 cm

Varies

30.93"

Marine Edge Top

78.6cm

48.25"

122.6 cm

10.00” Mullion To Accommodate Freezer

S/S End

Mullion Coil

10.00"

20.5 cm

76.25"

193.7 cm

6.00” Mullion To Accommodate Freezer

S/S End

Mullion Coil

6.00"

15.2 cm

6.00"

15.2 cm

6.00"

15.2 cm

Mech.

Section

Elevation View

F2748

Elevation View

F2776

Elevation View

F2660

Plan View

F2600 & F2700 Series

Elevation View

F2694

J=Junction Box

R=1/4" Liquid, 3/8" Suction Refrigeration Lines

Mechanical Access

Plan View

F2700 Series (Remote)

C=Condensing Unit J=Junction Box With 8'(2.4m) Cord & Plug

Mechanical Access Behind Louver

Mechanical Access Behind Panel

Plan View

F2600 Series (Self Contained)

NOTE: Remote Unit Must Be Hard Wired

32" (81.3 cm) FRZR

Low-Profile Freezer Equipment Stands

F2600 & F2700

Deleld reserves the right to make changes to the design or specications without prior notice.

25.08" (63.7cm)

7.63"

(19.4cm)

6.13”

(15.6cm)

F2600 & F2700 Series

32" (81.3cm) drawers hold (2) 12" x 20"

(30.5cm x 50.8cm) pans, front to back

Warning

To assure proper operation a 2” airspace must be maintained between the bottom of any cooking equipment and the top of this unit. Cooking equipment must have a barrier (i.e. bottom, drip pan) between its heat source and the top of the equipment stand. Failure to comply with this could severely damage the equipment stand and void all warranties.

Specifications

Model # Of 12x20 Pans V/Hz/Ph Amps Ship Weight BTU Load System BTU H.P. Nema Plug

F2660

F2694

F2748

F2776

NOTE: Add a “C” to the model number when ordering with casters (example - F2660C).

980 S. I sabella Rd. Mt. Pleasa nt, Michigan 4885 8

Self-contained

Remote

4 115/60/1 11.0 418lbs/190kg 925 1776 1/2 5-15P

8 115/60/1 16.0 505lbs/229kg 1558 2713 3/4 5-20P

4 115/60/1 10.0 295lbs/134kg 1032 160 NA NA

8 115/60/1 15.0 375lbs/170kg 1770 160 NA NA

Phone: 800 -733-8948 or 989 -773-7981 Fax: 800-669-0 619 www.delfield.co m

31.00"

(78.7cm)

Right Section View

Drawer Detail

26.00"

(66.0cm)

25.50"

(64.8cm)

Printed in the U.S.A. DSF2600_F270 0 02/10
