Delfield N8118B, N8130B, N8156B, N8169B, N8181B Service Manual

™

Delfield

N8000, N8000-R, N8100B, N8100-BR,
N8100-FA, 8100-EF, N8200, N8200G, N8600,
N8700-D, N8700-R, N8800 Drop Ins

Service, Installation and Care Manual

Please read this manual completely before attempting to install or operate this equipment! Notify
carrier of damage! Inspect all components immediately.

®

Hot Food Wells, Cold Pans, Granite Cold Slabs,

Frost Tops and Hot/Cold Food Wells

IMPORTANT INFORMATION

READ BEFORE USE

PLEASE SAVE THESE INSTRUCTIONS!

January 2012

N8000 Series Drop-In Installation and Operation Manual

Delfield

Important Warning And Safety Information

WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing

Maintenance On The Equipment.

WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage,

Injury Or Death.

WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The

Vicinity Of This Or Any Other Appliance.

WARNING Unless All Cover And Access Panels Are In Place And Properly Secured, Do

Not Operate This Equipment.

WARNING Do Not Clean With Water Jet.

CAUTION Observe the following:

• Minimum clearances must be maintained from all walls and combustible
materials.

• Keep the equipment area free and clear of combustible material.

• Adequate clearance for air openings.

• Operate equipment only on the type of electricity indicated on the

specification plate.

• Retain this manual for future reference.

2

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Contents Serial Number Location

Receiving And Inspecting Unit .................................................... 3

Specifications ......................................................................... 4-7

Installation

Curved Drop-In Cutout Details .................................................. 8

N8000, N8000N, N8000-R, N8100B, N8100NB, N8100-BR, N8200,

N8200G, 8100-FA, 8100-EF Series ............................................ 9

N8600 Series ........................................................................... 9

N8700-D, N8700N, N8700-R & N8800 Series ........................... 10

Operation

N8100B, N8100NB, N8100-BR ................................................ 11

N8100-FA .............................................................................. 11

8100-EF ................................................................................ 12

N8200 & N8200G ................................................................... 12

N8600 ................................................................................... 13

N8700-D, N8700N, N8700-R & N8800 Series ........................... 14

Maintenance ............................................................................ 15

Unit Assembly N8100-FA .......................................................... 16

Wiring Diagram

N8100-FA .............................................................................. 16

N8100B, N8100NB & N8100-BR .............................................. 17

8100-EF & 8100-EFN .............................................................. 17

N8200 & N8200G ................................................................... 17

N8600 .............................................................................. 18-19

N8800 ................................................................................... 19

N8700-D, N8700N & N8700-R ................................................ 20

Louver Diagram ....................................................................... 21

Miscellaneous Replacement Parts ............................................. 21

N8100-FA Replacement Parts List ............................................. 22

Condensing Unit Assembly Parts List ................................... 23-26

Food Well Assembly Parts List ............................................. 27-28

Standard Labor Guidelines ........................................................ 29

Standard Warranties ........................................................... 30-31

The serial number on self-contained refrigerated units is on the electrical
specications tag located near the condensing unit.

The serial number on remote refrigerated units is on the outside bottom
of the food well.

On hot food pans and hot/cold combination pans, the serial number tag
is located on the back of the control raceway or remote panel.

The serial number tag also lists the refrigerant used and the amount
of charge.

Always have the serial number of your unit available when calling for
parts or service.

This manual covers only standard 8000 series units. If you have a
custom designed unit, you should contact our parts/service department
at [phone] for questions.

©2012 The Deleld Company. All rights reserved. Reproduction without written
permission is prohibited. “Deleld” is a registered trademark of The Deleld
Company.

Receiving And Inspecting The Equipment

Even though most equipment is shipped crated, care should
be taken during unloading so the equipment is not damaged
while being moved into the building.

1. Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported to
the delivering carrier immediately.

2. If damaged, open and inspect the contents with the carrier.

3. In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment
notify the carrier. Notication should be made verbally as
well as in written form.

4. Request an inspection by the shipping company of the
damaged equipment. This should be done within 10 days
from receipt of the equipment.

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

5. Also open the compressor compartment housing and
visually inspect the refrigeration package. Be sure lines
are secure and base is still intact.

6. Freight carriers can supply the necessary damage forms
upon request.

7. Retain all crating material until an inspection has been
made or waived.

Uncrating The Equipment

First cut and remove the banding from around the crate.
Remove the front of the crate material, use of some tools will
be required.

3

N8000 Series Drop-In Installation and Operation Manual

Delfield

Specifications

N8100B Series Self-Contained Mechanically Cooled Pans - R134A

Model

N8118B

N8130B

N8143B

N8156B

N8169B

N8181B

L D H

18”
(45.7cm)

30.75”
(78.1cm)

43.5”
(110.5cm)

56.25”
(142.9cm)

69”
(175.3cm)

81.75”
(208cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

21.87”
(55.5cm)

21.87”
(55.5cm)

21.87”
(55.5cm)

21.87”
(55.5cm)

21.87”
(55.5cm)

21.87”
(55.5cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P. BTU

17” X 25”
(43.2cm x 63.5cm)

29.75” x 25”
(75.6cm x 63.5cm)

42.50” X 25”
(108.6cm x 63.5cm)

55.25” x 25”
(140.3cm x 63.5cm)

68” X 25”
(172.7cm x 63.5cm)

80.75” x 25”
(205.1cm x 63.5cm)

115/60/1

115/60/1 4.0 1/5 379

115/60/1

115/60/1 7.0 1/4 758

115/60/1 7.0 1/4 948

115/60/1 8.0 1/3 1138

4.0 1/5 204

4.0 1/5 569

N8100NB Series Self-Contained Mechanically Cooled Pans Narrow Style - R134A

N8146NB

N8168NB

46.75”
(118.7cm)

67.5”
(171.5cm)

18”
(45.7cm)

18”
(45.7cm)

21.81”
(55.4cm)

21.81”
(55.4cm)

45.75” x 17”
(113.7cm x 43.2cm)

66.5” x 17”
(168.9cm x 43.2cm)

115/60/1 4.0 1/5 454 17/40º/-5º 680 175lbs

115/60/1 4.0 1/5 676 26/31º/4º 804 240lbs

Evap BTU/
TD/TEMP

19/38º/-3º

26/31º/4°

35/26º/9º

43/32º/3º

51/29º/6º

59/32º/3º

Sys
Cap

708 100lbs

812 140lbs

889 173lbs

1373 205lbs

1469 225lbs

1921 258lbs

Ship
Weight

(45kg)

(64kg)

(78kg)

(93kg)

(102kg)

(117kg)

(80kg)

(109kg)

Refrig.

NEMA

Charge

Plug

5-15P

8.0oz

8.0oz 5-15P 2

5-15P

8.0oz

16.0oz 5-15P 4

16.0oz 5-15P 5

11.5oz 5-15P 6

5-15P

8.0oz

8.0oz 5-15P 3

12”x20”
Pans

1

3

2

N8100BR Series Curved Self-Contained Mechanically Cooled Pans - R134A

Model

N8144-BR

N8159-BR

N8176-BR

N8194-BR

L D H

40.43”
(103cm)

57.22”
(145cm)

73.68”
(187cm)

89.86”
(228cm)

26.05”
(66cm)

26.05”
(66cm)

26.05”
(66cm)

26.05”
(66cm)

21.81”
(55cm)

21.81”
(55cm)

21.81”
(55cm)

21.81”
(55cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P. BTU

see drawing on
page 8

see drawing on
page 8

see drawing on
page 8

see drawing on
page 8

115/60/1 4.0 1/5 379

115/60/1

115/60/1 7.0 1/4 758

115/60/1 7.0 1/4 948

4.0 1/5 569

Evap BTU/
TD/TEMP

26/31º/4°

35/26º/9º

43/32º/3º

51/29º/6º

N8100-FA Series Forced Air Drop-In Mechanically Cooled Cold Pans - R404A

Model L D H

N8131-FA

N8144-FA

N8157-FA

N8169-FA

N8182-FA

31.25”
(79.4cm)

44”
(111.8cm)

56.75”
(144.1cm)

69.5”
(176.5cm)

82.25”
(208.9cm)

26.67”
(67.7cm)

26.67”
(67.7cm)

26.67”
(67.7cm)

26.67”
(67.7cm)

26.67”
(67.7cm)

26.62”
(68cm)

26.62”
(68cm)

26.62”
(68cm)

28.62”
(72.7cm)

28.62”
(72.7cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P. BTU

30.25” x 25.5”
(76.8cm x 64.8cm)

43” x 25.5”

109.2cm x 64.8cm)

55.75” x 25.5”
(141.6cm x 64.8cm)

68.5” x 25.5”

174.0cm x 64.8cm)

81.25” x 25.5”

206.4cm x 64.8cm)

115/60/1 7.8 1/4 1339 140/15º/20

115/60/1 9.2 1/2 2035 140/22º/13

115/60/1 9.2 1/2 2731 280/14º/21° 3806

115/60/1 14.8 3/4

115/60/1 14.8 3/4 4070 280/20º/15° 5545

Evap BTU/
TD/TEMP

º

º

3374 280/20º/15° 5545

Sys

Ship

Cap

Weight

812 161lbs

(72kg)

889 184lbs

(83kg)

1373 233lbs

(105kg)

1469 243lbs

(109kg)

Sys

Ship

Cap

Weight

168lbs

2154

(76kg)

175lbs

3142

(79kg)

225lbs
(102kg)

235lbs
(107kg)

406lbs
(184kg)

Refrig.

NEMA

Charge

Plug

8.0oz 5-15P 2

5-15P

8.0oz

16.0oz 5-15P 4

16.0oz 5-15P 5

Refrig.

NEMA

Charge

Plug

16.0oz 5-15P 2

32.0oz 5-15P 3

32.0oz 5-15P 4

48.0oz 5-20P 5

48.0oz 5-20P 6

12”x20”
Pans

3

12”x20”
Pans

4

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Specifications

8100-EF Series LiquiTec® Eutetic Fluid Refrigerated Cold Pans - R404A

Model L D H

8118-EF

8132-EF

8145-EF

8159-EF

8172-EF

8186-EF

18.20”
(46.2cm)

31.76”
(80.7cm)

45.32”
(115.1cm)

58.88”
(149.6cm)

72.44”
(184cm)

86”
(218.4cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P.

17” x 25”
(43.2cm x 63.5cm)

30.75” x 25”
(78.1cm x 63.5cm)

44.25” x 25”
(112.4cm x 63.5cm)

57.87” x 25”
(147cm x 63.5cm)

71.5” x 25”
(181.6cm x 63.5cm)

85” x 25”
(215.9cm x 63.5cm)

115/60/1 7.5 1/4 204 19/50º/-15° 928 169lbs

115/60/1 7.5 1/4 379 26/42º/-7° 1112 215lbs

115/60/1 7.5 1/4 569 35/36º/-1° 1259 265lbs

115/60/1 7.5 1/4 758 43/32º/3° 1373 285lbs

115/60/1 7.5 1/4 948 51/29º/6° 1469 295lbs

115/60/1 7.5 1/4 1138 59/26º/9° 1529 394lbs

8100-EFN Series LiquiTec® Slim Line Eutetic Fluid Refrigerated Cold Pans - R404A

Model L D H

8148-EFN

8169-EFN

8191-EFN

47.66”
(121.1cm)

69.22”
(175.8cm)

90.78”
(230.6cm)

18”
(45.7cm)

18”
(45.7cm)

18”
(45.7cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

23.25”
(59.1cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P.

46.88” x 17.25”
(119.1cm x 43.8cm)

68.5” x 17.25”
(174cm x 43.8cm)

90” x 17.25”
(228.6cm x 43.8cm)

115/60/1 7.5 1/4 379 26/42º/-7° 1112 235lbs

115/60/1 7.5 1/4 569 35/36º/-1° 1259 285lbs

115/60/1 7.5 1/4 758 43/32º/13° 1373 295lbs

BTU
Load

BTU
Load

Evap BTU/
TD/TEMP

Evap BTU/
TD/TEMP

Sys
Cap

Sys
Cap

Ship
Weight

(77kg)

(98kg)

(120kg)

(130kg)

(134kg)

(179kg)

Ship
Weight

(107kg)

(130kg)

(134kg)

Refrig.

NEMA

Charge

Plug

24.0oz 5-15P 1

24.0oz 5-15P 2

24.0oz 5-15P 3

24.0oz 5-15P 4

24.0oz 5-15P 5

24.0oz 5-15P 6

Refrig.

NEMA

Charge

Plug

24.0oz 5-15P 2

24.0oz 5-15P 3

24.0oz 5-15P 4

12x20
Pans

12x20
Pans

N8000 Series Ice Cooled Cold Pans

Model

N8018

N8030

N8043

N8056

N8069

N8081

L D H

18”
(45.7cm)

30.75”
(78.1cm)

43.5”
(110.5cm)

56.25”
(142.9cm)

69”
(175.3cm)

81.75”
(208cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

Counter Cutout
Dimensions

17” x 25”
(43.2cm x 63.5cm)

29.75” x 25”
(75.6cm x 63.5cm)

42.5” x 25”
(107.9cm x 63.5cm)

55.25” x 25”
(140.3cm x 63.5cm)

68” x 25”
(172.7cm x 63.5cm)

80.75” x 25”
(205.1cm x 63.5cm)

N8000N Series Narrow Ice Cooled Cold Pans

N8046N

N8068N

46.75”
(118.8cm)

67.5”
(171.5cm)

18”
(45.7cm)

18”
(45.7cm)

10.75”
(27.3cm)

10.75”
(27.3cm)

45.75” x 17”
(116.2cm x 43.2cm)

66.50” x 17”
(168.9cm x 43.2cm)

Ship
Weight

38lbs
(17kg)

84lbs
(38kg)

110lbs
(50kg)

139lbs
(63kg)

160lbs
(73kg)

197lbs
(89kg)

100lbs
(45kg)

120lbs
(55kg)

12”x20”
Pans Held

1

2

3

4

5

6

2

3

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

5

N8000 Series Drop-In Installation and Operation Manual

Delfield

Specifications

N8000-R Series Curved Ice Cooled Cold Pans

Model

N8044-R

N8059-R

N8076-R

N8094-R

L D H

40.48”
(103cm)

57.22”
(145cm)

73.68”
(187cm)

89.89”
(228cm)

26.05”
(66cm)

26.05”
(66cm)

26.05”
(66cm)

26.05”
(66cm)

10.77”
(27cm)

10.77”
(27cm)

10.77”
(27cm)

10.77”
(27cm)

Counter Cutout
Dimensions

see drawing on page 8 100lbs

see drawing on page 8 118lbs

see drawing on page 8 145lbs

see drawing on page 8 164lbs

N8200 Series Self-Contained Frost Tops - R404A

Model

N8231

N8245

N8259

N8273

N8287

L D H

31.75"
(80.6cm)

45.63”
(115.9cm)

59.5”
(151.1cm)

73.38"
(186.4cm)

87.25"
(221.6cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

15.75”
(40cm)

15.75”
(40cm)

15.75”
(40cm)

15.75”
(40cm)

15.75”
(40cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P. BTU

30.75” x 25"
(78.1cm x 63.5cm)

44.63” x 25”
(113.3cm x 63.5cm)

58.50” x 25”
(148.6cm x 63.5cm)

72.38” x 25”
(183.8cm x 63.5cm)

86.25" x 25"
(219.1cm x 63.5cm)

Ship
Weight

(45kg)

(53kg)

(65kg)

(74kg)

115/60/1 7.5 1/4

115/60/1 7.5 1/4

115/60/1 7.5 1/4

115/60/1 8.0 1/4

115/60/1 8.0 1/3

12”x20”
Pans Held

2

3

4

5

Evap BTU/
TD/TEMP

379 26/42º/-7° 1112

569 35/36º/-1° 1259

758 43/32º/3° 1373

948 51/29º/6° 1469

1138 59/30º/5° 1787

Sys
Cap Ship Weight

142lbs
(64kg)

168lbs
(76kg)

193lbs
(88kg)

209lbs
(95kg)

239lbs
(108kg)

Refrig.
Charge

24.0oz

24.0oz

24.0oz

24.0oz

24.0oz

NEMA
Plug

5-15P

5-15P

5-15P

5-15P

5-15P

N8200G Series Self-Contained Granite Cold Slabs

Model

N8231G

N8245G

N8259G

N8273G

L D H

31.75”
(80.6cm)

45.63”
(115.9cm)

59.5”
(151.1cm)

73.38”
(186.4cm)

25.87”
(65.7cm)

25.87”
(65.7cm)

25.87”
(65.7cm)

25.87”
(65.7cm)

19”
(48.3cm)

19”
(48.3cm)

19”
(48.3cm)

19”
(48.3cm)

Counter Cutout
Dimensions V/Hz/Ph Amps H.P. BTU

30.75” X 25”
(78.1cm x 63.5cm)

44.63” x 25”
(113.4cm x 63.5cm)

58.5” x 25”
(148.6cm x 63.5cm)

72.38” x 25”
(183.8cm x 63.5cm)

115/60/1 7.5 1/4

115/60/1 7.5 1/4

115/60/1 8.0 1/3

115/60/1 9.0 1/2

Evap BTU/
TD/TEMP

379 26/42º/-7° 1112

569 35/36º/-1° 1259

758 43/37º/-2° 1572

948 51/43º/-8° 2183

N8600 Series Self Contained Combination Hot/Cold Food Wells - R404A

Model

N8630

N8643

N8656

N8669

N8681

L D H

30.75”
(78.1cm)

43.5”
(110.5cm)

56.25”
(142.9cm)

69”
(175.3cm)

81.75”
(207.6cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

23.75”
(60.3cm)

23.75”
(60.3cm)

23.75”
(60.3cm)

23.75”
(60.3cm)

23.75”
(60.3cm)

Counter Cutout
Dimensions

29.75” X 25”
(75.5cm x 63.5cm)

42.50” x 25”
(107.9cm x 63.5cm)

55.25” x 25”
(140.3cm x 63.5cm)

68” x 25”
(172.7cm x 63.5cm)

80.75” x 25”
(205.1cm x 63.5cm)

Control Panel Cutout
Dimensions

12.25” x 4.25” x 7.00”
(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”
(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”
(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”
(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”
(31.1cm x 10.8cm x 17.8cm)

V/Hz/Ph Amps H.P. BTU

120/60/1 24.0 1/4

120/240
/60/1

120/240
/60/1

120/240
/60/1

120/240
/60/1

21.0 1/4

21.0 1/4

42.0 1/4

42.0 1/3

Sys
Cap Ship Weight

219lbs
(99kg)

284lbs
(129kg)

338lbs
(153kg)

425lbs
(193kg)

Evap BTU/TDSys

Cap

379 26/42º/-7° 1112

569 35/36º/-1° 1259

758 43/32º/3° 1373

948 51/29º/6° 1469

1138 59/30º/5° 1787

Refrig.
Charge

24.0oz

24.0oz

24.0oz

32.0oz

Ship
Weight

164lbs
(74kg)

198lbs
(90kg)

233lbs
(106kg)

266lbs
(121kg)

301lbs
(137kg)

NEMA
Plug

5-15P

5-15P

5-15P

5-15P

Refrig.
Charge

16.0oz 2

16.0oz 3

16.0oz 4

16.0oz 5

24.0oz 6

12”x20”

Pans

6

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Specifications

N8700D Series Individually Controlled Heated Food Wells

Model

N8717-D

N8731-D

N8745-D

N8759-D

N8773-D

N8787-D

L D H

17.88”
(45.4cm)

31.75”
(80.6cm)

45.63”
(115.9cm)

59.5”
(151.1cm)

73.38”
(186.4cm)

87.25”
(221.4cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

Counter Cutout
Dimensions

16.88” X 25”
(42.8cm x 63.5cm)

30.75” x 25”
(78.1cm x 63.5cm)

44.62” x 25”
(113.3cm x 63.5cm)

58.5” x 25”
(148.6cm x 63.5cm)

72.37” x 25”
(183.8cm x 63.5cm)

86.25” x 25”
(219.1cm x 63.5cm)

*14” Overall height including drain connection

N8700-R Series Curved Individually Controlled Heated Food Wells

Model

N8744-R

N8759-R

N8776-R

N8794-R

L D H

40.48”
(103cm)

57.22”
(145cm)

73.68”
(187cm)

89.80”
(228cm)

26.05”
(66cm)

26.05”
(66cm)

26.00”
(66cm)

25.91”
(66cm)

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

9.5”
(24cm)*

*14” Overall height including drain connection

Counter Cutout
Dimensions

see drawing on page 8 10.31” x 4.62” x 7.00”

see drawing on page 8 14.5” x 4.62” x 7.00”

see drawing on page 8 18.69” x 4.62” x 7.00”

see drawing on page 8 22.88” x 4.62” x 7.00”

Control Panel Cutout
Dimensions

7.00” x 4.62” x 7.00”
(17.8cm x 11.7cm x 17.8cm)

10.31” x 4.62” x 7.00”
(26.2cm x 11.7cm x 17.8cm)

14.5” x 4.62” x 7.00”
(36.8cm x 11.7cm x 17.8cm)

18.69” x 4.62” x 7.00”
(47.5cm x 11.7cm x 17.8cm)

22.88” x 4.62” x 7.00”
(58.1cm x 11.7cm x 17.8cm)

27” x 4.62” x 7.00”
(68.6cm x 11.7cm x 17.8cm)

Control Panel Cutout
Dimensions

(26cm x 12cm x 18cm)

(37cm x 12cm x 18cm)

(47cm x 12cm x 18cm)

(58cm x 12cm x 18cm)

V/Hz/Ph Amps

120/60/1 8.3 41lbs

120/60/1 16.6 99lbs

208-230
/60/1

208-230
/60/1

208-230
/60/1

208-230
/60/1

V/Hz/Ph Amps

120/60/1 16.6 99lbs

208-230
/60/1

208-230
/60/1

208-230
/60/1

Ship
Weight

(19kg)

(45kg)

15.0/16.0 134lbs
(61kg)

20.0/22.0 166lbs
(75kg)

24.0/27.0 186lbs
(84kg)

29.0/32.0 236lbs
(107kg)

Ship
Weight

(45kg)

15.0/16.0 134lbs
(61kg)

20.0/22.0 166lbs
(75kg)

24.0/27.0 186lbs
(84kg)

12”x20”
Pans

1

2

3

4

5

6

12”x20”
Pans

2

3

4

5

N8700N Series Individually Controlled Heated Narrow Food Wells

Model

N8746N
N8746ND

N8768N
N8768ND

L D H

45.61”
(116cm)

67.48”
(172cm)

15.87”
(40cm)

15.87”
(40cm)

9.5”
(24cm)

9.5”
(24cm)

*ND Models are standard with drains

Counter Cutout
Dimensions

44.62” x 15.0”
(113.3cm x 38.1cm)

66.50” x 15.0”
(168.9cm x 38.1cm)

Control Panel Cutout Dimen­sions

10.31” x 4.62” x 7.00”
(26.2cm x 11.7cm x 17.8cm)

14.50” x 4.62” x 7.00”
(36.8cm x 11.7cm x 17.8cm)

V/Hz/Ph Amps

120/60/1 17.0 100lbs

208-230
/60/1

N8800 Series Single Tank Electric Hot Food Wells

Model

N8831

N8845

N8859

N8873

N8887

L D H

31.75”
(80.6cm)

45.63”
(115.9cm)

59.5”
(151.1cm)

73.38”
(186.4cm)

87.25”
(221.6cm)

™

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

26”
(66cm)

®

11”
(27.9cm)

11”
(27.9cm)

11”
(27.9cm)

11”
(27.9cm)

11”
(27.9cm)

Counter Cutout
Dimensions

30.75” X 25”
(78.1cm x

63.5

44.63” x 25”
(113.4cm x

63.5

58.5” x 25”
(148.6cm x

63.5

72.38” x 25”
(183.8cm x

63.5

86.25” x 25”
(219.1cm x

63.5

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

Control Panel Cutout Dimen­sions

12.25” x 4.25” x 7.00”

cm)

(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”

cm)

(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”

cm)

(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”

cm)

(31.1cm x 10.8cm x 17.8cm)

12.25” x 4.25” x 7.00”

cm)

(31.1cm x 10.8cm x 17.8cm)

V/Hz/Ph Amps

120/60/1 17.0 100lbs

208-230
/60/1

208-230
/60/1

208-230
/60/1

208-230
/60/1

Ship
Weight

(45kg)

15.0/16.0 130lbs
(59kg)

Ship
Weight

(45kg)

15.0/16.0 136lbs
(62kg)

20.0/22.0 158lbs
(72kg)

24.0/27.0 195lbs
(88kg)

29.0/32.0 224lbs
(102kg)

12”x20”
Pans

2

3

12”x20”
Pans

2

3

4

5

6

7

N8000 Series Drop-In Installation and Operation Manual

Delfield

Curved Drop-In Cutout Details

2 pan standard curved drop-in cutout detail
Models:

• N8044-R

• N8144-BR

• N8744-R

85˚

19.75”
50cm

172.50˚

19.75”
50cm

85˚

25.10”
64cm

95˚

3 pan standard curved drop-in cutout detail
Models:

• N8059-R

• N8159-BR

• N8759-R

25.10”
64cm

85˚

4 pan standard curved drop-in cutout detail
Models:

• N8076-R

• N8176-BR

• N8776-R

25.10”
64cm

85˚

19.56”
50cm

19.56”
50cm

95˚

95˚

25.00”
64cm

15.92”
40cm

25.00”
64cm

15.73”
40cm

25.00”
64cm

15.73”
40cm

172.50˚

172.50˚

172.50˚

25.00”
64cm

15.92”
40cm

17.06”
43cm

13.78”
35cm

17.06”
43cm

25.00”
64cm

25.00”
64cm

13.78”
35cm

95˚

172.50˚

172.50˚

25.10”
64cm

15.73”
40cm

13.78”
35cm

25.00”
64cm

17.06”
43cm

25.00”
64cm

19.56”
50cm

95˚

85˚

172.50˚

25.10”
64cm

15.73”
40cm

25.00”
64cm

19.56”
50cm

95˚

85˚

25.10”
64cm

5 pan standard curved drop-in cutout detail
Models:

• N8094-R

• N8194-BR

• N8794-R

8

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

25.10”
64cm

172.50˚

17.06”
43cm

25.00”
64cm

13.78”
35cm

172.50˚

13.78”
35cm

17.06”
43cm

25.00”
64cm

172.50˚

15.67”
40cm

25.00”
64cm

95˚

19.50”
50cm

85˚

25.10”
64cm

™

®

17.06”

172.50˚

43cm

25.00”
64cm

13.78”
35cm

19.50”
50cm

85˚

25.00”
64cm

95˚

15.67”
40cm

N8000 Series Drop-In Installation and Operation Manual

Delfield

CAUTION

DANGER

DANGER

Installation N8000, N8000N, N8000-R, N8100B, N8100NB, N8100-BR, N8200, N8200G, N8100-FA & 8100-EF

These units are intended for indoor use only. A room
temperature of no more than 86°F (30°C) is recommended.
Be sure the location chosen has a counter strong enough to
support the total weight of the unit and contents. A fully loaded
model may weigh as much as 600 pounds! Reinforce the
counter as necessary to provide maximum loading.

Unit requires that the sides and bottom are not
any closer than 3” (7.6cm) to any combustible
material.

The counter cut-out sizes and power requirements are shown
on the specication pages. A gasket is installed in the ange
of each unit. The weight of the unit on the gasket forms a seal
preventing liquids from seeping into the cut-out opening.

Louvers

Self-contained refrigerated units (N8100, N8100NB, N8100-BR,
N8200 and N8200G Series) require airow to the compressor.
A 13” x 25” (33 cm x 63.5 cm) louver is provided by Deleld and
must be installed in the counter in front of the condenser. The
louver cutout dimension is 11” x 22” (27.9 cm x 55.9 cm). The
rear must have an opening to permit removal of heated air. The
opening must be at least 8” x 11”, a total of 88 square inches
(20.3 cm x 27.9 cm, a total of 566 square centimeters).

Plumbing

The units drain must have an outlet to an appropriate drainage
area or container. A drain trap must be installed. N8200 series
have 1/2” drain and N8200G series have 3/4” drain located on
end/center. The 1” diameter drain on N8000, N8000-R, N8100,
N8100NB, N8100-BR, N8100-FA and 8100-EF Series units
is shipped loose and must be connected during installation.
N8157-FA, N8169-FA, and N8182-FA have two drains.

Electrical connection

Refer to the amperage data on the specication pages, the
serial tag or your local code to be sure the unit is connected
to the proper power source. A protected circuit of the correct
voltage and amperage must be run for con nec tion of the line
cord.

Some units have an ON/OFF switch located behind the
louvered panel in the machine compartment. Simply turn the
switch to ON to begin operation.

Some units have an OFF position on the thermostat dial which is
located behind the louvered panel in the machine compartment.
Simply turn the dial to begin operation.

Moisture collecting from improper drainage
can create a slippery surface on the oor
and a hazard to employees. It is the owner’s
responsibility to provide a container or outlet
for drainage.

Some N8000, N8000N, N8000-R, N8100B,

N8100NB and N8100-BR may have
polyethylene insulation in the drain hole.
This can easily be cut out without any contact
or damage to the units interior insulation or
refrigeration lines.

The unit must be disconnected from the
power source whenever performing service

or maintenance functions.

Never operate the unit without the louvered

panel in place!

Installation N8600

These units are intended for indoor use only. A room temperature
of no more than 86°F (30°C) is recommended. Be sure the
location chosen has a counter strong enough to support the
total weight of the unit and contents. A fully loaded model
may weigh as much as 600 pounds! Reinforce the counter as
necessary to provide for maximum loading.

Unit requires that the sides and bottom are not
any closer than 3” (7.6cm) to any combustible
material.

The counter cut-out sizes and power requirements are shown
on the specication pages. A gasket is installed in the ange
of each unit. The weight of the unit on the gasket forms a seal
preventing liquids from seeping into the cut-out opening.

The cut-out dimensions for the control box on N8600 Series
units is 4.25” x 12.25” (10.8 cm x 31.1 cm).

Louvers

For proper refrigerated operation, N8600 Series units require
airow to the compressor. A 13” x 25” louver is (33.0 cm x 63.5
cm) is provided by Deleld and must be installed in the counter
in front of the condenser. The louver cutout dimension is 11”

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

x 22” (27.9 cm x 55.9 cm). The rear must have an opening to
permit removal of heated air. The opening must be at least 8” x
11”, a total of 88 square inches (20.3 cm x 27.9 cm, a total of 566
square centimeters).

Plumbing

The units 1” (2.54cm) drain must have an outlet to an appropriate
drainage area or container.

Moisture collecting from improper drainage
can create a slippery surface on the oor
and a hazard to employees. It is the owner’s

CAUTION

responsibility to provide a container or outlet
for drainage.

Electrical connection

Refer to the amperage data on the specication pages, the
serial tag or your local code to be sure the unit is connected to
the proper power source.

The unit must be disconnected from the

power source whenever performing service

or maintenance functions.

Never operate the unit without the louvered

panel in place!

9

N8000 Series Drop-In Installation and Operation Manual

Delfield

CAUTION

DANGER

Installation N8700-D, N8700N, N8700-R & N8800 Series

These units are intended for indoor use only. Be sure the
location chosen has a counter strong enough to support the
total weight of the unit and contents. A fully loaded model
may weigh as much as 600 pounds! Reinforce the counter as
necessary to provide maximum loading.

Plumbing
N8700-D, N8700N-D and N8700-R Plumbing: Unit is equipped

with 1/2” (1.3cm) drains, (one per well located in right rear corner
1/2” (1.3cm) female N.P.T.) manifold and 1/2” (1.3cm) gate valve.

Unit requires that the sides and bottom are not
any closer than 3” (7.6cm) to any combustible
material.

The counter cut-out sizes and power requirements are shown
on the specication pages. A gasket is installed in the ange
of each unit. The weight of the unit on the gasket forms a seal
preventing liquids from seeping into the cut-out opening.

N8700 Series pans should be installed with the
drains at the back, away from the operator’s
sides.

The controls on N8700-D, N8700-R and N8800 series units
are mounted in a control panel, designed to be installed at a
“remote” location. The control panel should be installed so that
the indicator light for each control is to the right of the control.
N8700, N8700N and N8700-R series units have 48” (121.9cm)
of conduit and N8800 Series units have 24” (61.0cm) of conduit
between the pans and the remote control panel to facilitate this
installation.

N8800 Plumbing: Well is sloped to a 1.00” (2.5cm) male N.P.T.
stainless steel drain.

Moisture collecting from improper drainage
can create a slippery surface on the oor
and a hazard to employees. It is the owner’s
responsibility to provide a container or outlet
for drainage.

Electrical connection

Refer to the amperage data on the specication pages, the
serial tag or your local code to be sure the unit is connected to
the proper power source.

The unit must be disconnected from the
power source whenever performing service
or maintenance functions.

Control Panel Installation, N8700-D, N8700N & N8700-R Series

The control panel is designed to be installed on the side
opposite the drains.

If you choose to install the control panel on the same side as the
drains the control panel will either be upside down or the knobs
will control the opposite wells.

10

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

Control panel
installed
opposite drains

Drains

™

®

Delfield

Operation N8100B, N8100NB & N8100-BR

Ruby Tuesday Salad Bar Service and Installation Manual

DEFROST TIMER

18648-BUC

. . . . . . . . . . . . . . . . . . . . . . .

16 oz.

18660-BUC

. . . . . . . . . . . . . . . . . . . . . . .

16 oz.

18672-BUC

16 oz.

18691-BUC

. . . . . . . . . . . . . . . . . . . . . . .

16 oz.

18699-BUC

24 oz.

186114-BUC

24 oz.

55# cut-in and 30# cut-out to maintain

82# cut-in and 57# cut-out to maintain

N8100 Series mechanically cooled cold pans are adjusted
at the factory to provide proper operation without any further
adjustments. However, if it is necessary to adjust the
temperature, the control is located in the machine compartment.
Turn the knob clockwise as indicated on the control. Settings
are from 1 thru 7 (7 being the coldest). Adjustments should
be made gradually. Several small adjustments will be more
effective than one large adjustment. It may take an hour or
longer to realize the temperature change depending on the
application and location of the unit.

These units are not designed to cool warm food products. Items
should be placed in the unit pre-cooled at least to the desired
holding temperature, if not slightly colder. In some applications,
a gradual warming of product may occur, particularly at the
exposed top of the product. Stirring or rotation of the product
may be necessary to maintain overall temperature.

N8000 Series Drop-In Installation and Operation Manual

Warming of food product can occur very quickly outside of the
unit. When loading or rotating product, avoid leaving food items
in a non-refrigerated location for any length of time to prevent
warming or spoilage.

The temperature control is used to turn the unit on and off as
well as control the temperature of the cold pan. The settings
range from 1 through 7 (7 being the coldest). To turn the cold
pan off, turn the knob to the OFF position.

If the cold pan is to be used with ice, it is recommended that
the optional perforated bottoms be used. These will allow ice
to melt properly.

The unit must be turned off when not in use or overnight for
defrosting and cleaning.

Operation N8100-FA

N8100-FA Series forced air mechanically cooled cold pans come
equipped with 115-volt, 60 Hertz, single phase refrigeration
units. The refrigeration valves are open and ready to operate
as soon as the power supply cord is plugged into the standard
115-volt, grounded electrical outlet.

Pressure Control

The temperature is controlled by an adjustable pressure control
located in the machine compartment and adjustable control has
the word COLDER near the knob, with an arrow to indicate the
adjustment direction. This control is eld adjustable and does
not require a service agent. If you have any questions, feel free
to contact the Deleld Service Department at [phone].

In attempting to adjust the pressure control,
you can do damage to the unit by accidentally
adjusting the differential. Deleld is not
responsible for charges incurred while adjusting
the pressure control.

Food in the N8100-FA pans should not be loaded
in such a way as to interfere with the air curtain
owing over the cold pans.

Defrost Timer

Every 2 hours for 15 minutes.

30 psi (207 kPa) dierential
80 psi (552 kPa) cut-in
50 psi (345 kPa) cut-out

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

11

N8000 Series Drop-In Installation and Operation Manual

Delfield

Operation 8100-EF Series

There is a switch on the compressor housing front to turn the
8100-EF units on and off. 8100-EF Series LiquiTec
uid cold pans are adjusted at the factory to provide proper
operation without any further adjustments. However, if it is
necessary to adjust the temperature, the control is located in the
machine compartment. Turn the knob clockwise as indicated
on the control to adjust it colder. Adjustments should be made
gradually. Several small adjustments will be more effective than
one large adjustment. It may take an hour or longer to realize
the temperature change depending on the application and
location of the unit.

These units are not designed to cool warm food products. Items
should be placed in the unit pre-cooled at least to the desired
holding temperature, if not slightly colder. In some applications,
a gradual warming of product may occur, particularly at the
exposed top of the product. Stirring or rotation of the product
may be necessary to maintain overall temperature. Warming
of food product can occur very quickly outside of the unit.
When loading or rotating the product, avoid leaving food items
in a non-refrigerated location for any length of time to prevent
warming or spoilage.

The cold pan is not intended to be used with
ice.

®

Eutetic

The unit must be turned off when not in use or overnight for
defrosting and cleaning.

Temperature Control Settings:
17°F (8ºC) differential
25°F (-4ºC) cut-in
8°F (-13ºC)cut-out

Operation N8200

N8200 Series frost tops are designed to maintain an even layer
of frost to pleasantly display product. Once turned on, the
compressor will run continuously. The unit should be turned off
overnight or when not in use. There is no temperature control
on the N8200 series. The ON/OFF switch is the only means
available to cycle the unit.

Operation N8200G

N8200G Series granite cold slabs are designed to maintain a
low temperature surface for quick turn products such as ice
cream. Frost patterns will vary depending on room conditions
such as temperature, humidity and airow. The “work zone”
of the granite surface is considered to be inside a 2” (5.1cm)
perimeter. Temperatures in the perimeter zone may be higher
and again the frost patterns in this area will vary based on room
conditions.

Since it takes time for the frost to accumulate initially, the unit
should be turned on approximately one hour before it is actually
required. Product should not be placed on the frost top prior to
turning the unit on, because it may freeze to the surface of the
unit.

The unit must be turned off when not in use or overnight for
defrosting and cleaning.

Unit is controlled by an on/off switch. Once turned on, the unit
will run continuously. There is no temperature control in this
unit. Turn the unit on approximately two hours prior to use to
allow for ample cool down time. The unit must be turned off
when not in use or overnight for defrosting and cleaning.

12

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

Delfield

DARNGE

STPE S

Operation N8600 Hot/Cold Series

Hot Operation

N8600 Series hot and cold combination pans must be operated
with water in the well for proper hot operation. Fill well with a
minimum of 4” (10.2cm) of water. Place function switch in HOT
position to begin heating. Turn thermostat dial to the desired
temperature.

Never use anything other than plain water
in the wells or tank. Failure to observe this
warning may result in personal injury or
damage to the unit.

When operated at the highest temperature
setting, the top of the unit will become very
hot. Staff and customers using the equipment
should be informed about this.

To turn unit off, simply move the function switch to OFF position.
Drain water and allow unit to cool before cleaning or switching
to cold operation.

Cold Operation

Simply place the function switch to the COLD position. The
compressor controller has been factory set and no temperature
adjustment should be necessary. If the cold pan is to be used
with ice, it is recommended that the optional perforated bottoms
be used. These will allow ice to melt properly.

N8000 Series Drop-In Installation and Operation Manual

Switching from hot to cold operation

Follow this procedure:

1. Place the function switch in the OFF position
and drain out hot water.

2. Allow the unit to cool until it can be safely
cleaned.

3. When clean up procedures are complete, unit
will be ready for cold operation. This takes
about one hour.

To assure maximum compressor life, do not
switch from “hot” to “cold” operation without
allowing a cool down period. Never switch from
hot to cold operation while hot water remains in
the pans. Failure to observe this warning will
greatly reduce compressor life and eventually
cause premature compressor failure.

Switching from cold to hot operation

No special procedure is required to switch from the cold to hot
operation. Be certain to ll will with a minimum of 4” of water.

The unit is designed so that the compressor
and the heating elements cannot operate at
the same time. Continued operation of the
compressor in the “hot position” should not

be considered normal. Call for service if this
happens.

N8600 Immersion Heater Reset Switch

As a safety feature the N8600 food well immersion heater has a
reset switch. If the heater gets too hot, it will turn off. Low or no
water can be the cause.

The unit must be turned off when you push
the manual reset switch.

Access Hole for N8600 Immersion
Heater Reset Switch

The unit must be turned off when not in use or overnight for
defrosting and cleaning.

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

13

N8000 Series Drop-In Installation and Operation Manual

Delfield

DARNGE

DARNGE

DARNGE

Operation N8700-D, N8700N, N8700-R & N8800 Series

These units are designed to hold warm food product between
140ºF to 160ºF (60ºC to 71ºC).

N8700-D, N8700N and N8700-R series individually heated
hot food units may be operated “wet” (with water in the wells)
or “dry”. However, “wet” operation is recommended for better
performance.

N8800 Series single tank hot food units are designed to be
operated “wet” (with water in the tank) only.

Proper water level (approximately 2” [5.1cm])
must be maintained to prevent damage to the
tank on the N8800 Series units.

After the unit is hard wired to the electrical system, select
desired temperature by rotating temperature control. A knob
and indicator light are provided for each individual heated food
well.

First Time Use

Before the unit is used the rst time for serving, turn the
temperature knob to “HI” and heat the well for 20 to 30 minutes.

Any residue or dust that adhered to the heater element(s) will
be burned off during this initial preheat period.

When serving thick sauces always use the hot food well in
“wet” operation. This provides more uniform temperature for
the sauce.

Never place food directly in well. Always use
pans.

For most efficient operation, keep covered inserts in each well
during preheating or when empty.

Always place covers on pans when not serving to prevent food
from drying out.

Wet Operation

Fill the food well with a minimum of 2” (5.1cm) of water and
cover with lid or empty pan. To preheat water, set temperature
control at “HI”. With pans in place, wells will boil water. Food
temperature will vary depending on type and amount of product.
To minimize steam and water usage, set control at lowest
setting that will maintain proper food temperature. To reduce
preheating time, use hot water to ll the well.

When operating these units “wet,” never use
anything other than plain water in the wells or
tank. Failure to observe this warning may result
in personal injury or damage to the unit.

When operated at the highest temperature
setting, the top of the unit will become very
hot. Staff and customers using the equipment
should be informed about this.

Steam can cause serious burns. Always use
some type of protective covering on your hands
and arms when removing lids from the unit. Lift
the lid in a way that will direct escaping steam
away from your face and body.

Dry Operation N8700 Series only

Wet operation is usually much more efficient and is preferred.
However, these units may be operated without water with no
damage to the unit.

When operated dry, the bottom of the well will discolor. To clean,
use a stainless steel cleaner or mild abrasive.

The dry well should never be preheated longer

than 15 minutes.

When operated dry, the well bottoms become

very hot. Do not allow unprotected skin to

contact any well surface.

14

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

Delfield

Maintenance

N8000 Series Drop-In Installation and Operation Manual

Drain Maintenance - N8100-FA Series

Each unit has a drain located inside the unit that removes
the condensation from the evaporator coil and routes it to an
external condensate evaporator pan. Each drain can become
loose or disconnected during normal use. If you notice water
accumulation on the inside of the unit be sure the drain tube
is connected to the evaporator drain pan. If water is collecting
underneath the unit make sure the end of the drain tube is in
the condensate evaporator in the machine compartment. The
leveling of the unit is important as the units are designed to
drain properly when level. Be sure all drain lines are free of
obstructions.

The power switch must be turned to OFF and

the unit disconnected from the power source
whenever performing service, maintenance

functions or cleaning the refrigerated area.

Stainless Steel Care and Cleaning

To prevent discoloration or rust on stainless steel several
important steps need to be taken. First, we need to understand
the properties of stainless steel. Stainless steel contains 70- 80%
iron, which will rust. It also contains 12-30% chromium, which
forms an invisible passive lm over the steel’s surface, which
acts as a shield against corrosion. As long as the protective
layer is intact, the metal is still stainless. If the lm is broken or
contaminated, outside elements can begin to breakdown the
steel and begin to form discoloration or rust. Proper cleaning
of stainless steel requires soft cloths or plastic scouring pads.

Cleaning the Condenser Coil

In order to maintain proper refrigeration performance, the
condenser ns must be cleaned of dust, dirt and grease
regularly. It is recommended that this be done at least every
three months. If conditions are such that the condenser is totally
blocked in three months, the frequency of cleaning should be
increased. Clean the condenser with a vacuum cleaner or stiff
brush. If extremely dirty, a commercially available condenser
cleaner may be required.

Failure to maintain a clean condenser coil can initially cause high
temperatures and excessive run times. Continuous operation
with a dirty or clogged condenser coil can result in compressor
failure. Neglecting the condenser coil cleaning procedures will
void any warranties associated with the compressor and cost to
replace the compressor.

Never use a high-pressure water wash for this
cleaning procedure as water can damage the
electrical components located near or at the

CAUTION

condenser coil.

NEVER USE STEEL PADS, WIRE BRUSHES OR SCRAPERS!

Cleaning solutions need to be alkaline based or non-chloride
cleaners. Any cleaner containing chlorides will damage
the protective lm of the stainless steel. Chlorides are also
commonly found in hard water, salts, and household and
industrial cleaners. If cleaners containing chlorides are used be
sure to rinse repeatedly and dry thoroughly. Routine cleaning
of stainless steel can be done with soap and water. Extreme
stains or grease should be cleaned with a non-abrasive cleaner
and plastic scrub pad. Always rub with the grain of the steel.
There are stainless steel cleaners available which can restore
and preserve the nish of the steels protective layer. Early signs
of stainless steel breakdown are small pits and cracks. If this
has begun, clean thoroughly and start to apply stainless steel
cleaners in attempt to restore the passivity of the steel.

Never use an acid based cleaning solution!
Many food products have an acidic content,
which can deteriorate the nish. Be sure to clean

CAUTION

the stainless steel surfaces of ALL food
products. Common items include, tomatoes,
peppers and other vegetables.

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

15

N8000 Series Drop-In Installation and Operation Manual

Delfield

MODELS - NORDIC BREEZE

Unit Assembly N8100-FA

UPRIGHT AIR DIFFUSER
WITH AIR DEFLECTOR

BLACK AIRFLOW EXTRUSIONS

PERFORATED PAN CLIP

ADAPTER BARS

COIL ASSY COVER

PLEXIGLAS END CAPS

Wiring Diagram N8100-FA

L1

1

2

35

DEFROST TIMER

PRESSURE
CONTROL

CONDENSING UNIT

N

G

16

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

COOLING FANS

™

®

Delfield

Wiring Diagram N8100B, N8100NB & N8100-BR

L1

COOLING T'STAT

N

G

Wiring Diagram 8100-EF, 8100-EFN

N8000 Series Drop-In Installation and Operation Manual

CONDENSER FAN

S

C

R

COMPRESSOR

115V

ON/OFF SWITCH

L1

COOLING T'STAT

N

G

Wiring Diagram N8200 & N8200G

ON/OFF SWITCH

L1

N

G

CONDENSER FAN

C

COMPRESSOR

120V

CONDENSER FAN

S

C

R

COMPRESSOR

115V

S

R

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

17

N8000 Series Drop-In Installation and Operation Manual

Delfield

Wiring Diagram N8630

CONDENSING UNIT

COOLING

THERMOSTAT

M

HEATER #1

HEATER #1
CONTACTOR

HEATER #1
LIMIT SWITCH

THERMOSTAT

120V-1PH-3KW HEATER

3-WAY
SWITCH

L1

N

Wiring Diagram N8643 & N8656

CONDENSING UNIT

M

HEATER #1

COOLING

THERMOSTAT

HEATER #1
CONTACTOR

HEATER #1
LIMIT SWITCH

THERMOSTAT

3-WAY
SWITCH

L1

L2

18

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

N

240V-1PH-5KW HEATER

™

®

Delfield

Wiring Diagram N8669 & N8681

LI G

N8000 Series Drop-In Installation and Operation Manual

CONDENSING UNIT

HEATER #1

M

COOLING

THERMOSTAT

HEATER #1
CONTACTOR

3-WAY
SWITCH

L1

L2

THERMOSTAT

HEATER #1
LIMIT SWITCH

HEATER #2
LIMIT SWITCH

N

(2) 240V-1PH-5KW HEATERS

HEATER #2
CONTACTOR

HEATER #2

Wiring Diagram N8800 208/230V

™

THERMOSTAT

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

L2

DOUBLE POLE
THERMOSTAT ON
MODELS N8873 &
N8887 ONLY

19

N8000 Series Drop-In Installation and Operation Manual

Delfield

Wiring Diagram N8700-D, N8700N & N8700-R

PILOT LIGHT
(FURNISHED)

LINE

WIRES

#

OF

WARMERS

1

2

3
4

5

6

L1 G L2

H1

P

L1

L2

H2

INFINITE CONTROL

TO ADDITIONAL

FOOD WARMERS

AMPERES

120V,

PHASE

1

1 PHASE

208V,

WITH “OFF”

IN LINE

230V,

PHASE

1

POSITION

WIRES

8.3 4.8 5.3

16.7 9.6 10.6

25 14.4 15.9 14.4/15.9

33.3 19.2 21.3

24 26.6

28.8 31.3

19.2/21.3

24/26.1

28.8/31.3

1000 W - 120V

OR 1000/1222 W -

208-230 V

HEATING ELEMENT

208-230V, 3 PHASE

L1 L2 L3

14.4/15.9

19.2/21.3

19.2/21.3

28.8/31.3

14.4/15.9

14.4/15.9

19.2/21.3

28.8/31.3

L1 L2 G L3

20

30A SWITCH
(OPTIONAL)

HA–1

HA–2

HA–3

HA–4

HA–5

HA–6

HA = HEATER ASSEMBLY

20A, 3–POLE SWITCH
(OPTIONAL)

HA–1

HA–2

HA–4

HA–5

HA = HEATER ASSEMBLY

Standard Single Phase Optional Three Phase

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

ALL WIRING

MINIMUM 14 AWG

250C

HA–3

HA–6

™

®

Delfield

Drop In Louver Panel

N8000 Series Drop-In Installation and Operation Manual

25”

Louver part #359-411-0003

Cutout dimension is 11” x 22” (27.9 cm x 55.9 cm).

Miscellaneous Parts 8000 SERIES

Deleld Part # Description
265-AXE-0000 Divider bar, 2.00” x 20.93”
243-ALS-0032 Divider bar, 13.00” x .90”
243-AB0-0001 Divider bar, 21.00” x .90”
3234242 Plastic drain
1701273 Trim gasket (sold by foot)

13”

Cap Tube Chart - R134A Refrigerant

Model Number Cap Tube Size/Length
N8118B .036ID x 72”
N8130B .036ID x 72”
N8143B .036ID x 72”
N8144-BR .036ID x 72”
N8146NB .042ID x 120”
N8156B .042ID x 120”
N8159-BR .036ID x 72”
N8168NB .042ID x 120”
N8169B .042ID x 120”
N8176-BR .042ID x 120”
N8181B .054ID x 110”
N8194-BR .042ID x 120”

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

21

N8000 Series Drop-In Installation and Operation Manual

Delfield

Replacement Parts N8100-FA

8

7

6

9

1

2

5

4

3

10

11

12

13

14

15

16

17

N8131-FA N8144-FA N8157-FA N8169-FA N8182-FA
Key Description 2-PAN 3-PAN 4-PAN 5-PAN 6-PAN

1 Upright diffuser 226-0V3-0030 226-0V3-0031 226-0V3-0032 226-0V3-0033 226-0V3-0034
2 Air deector 226-A9L-0030 226-A9L-0031 226-A9L-0032 226-A9L-0033 226-A9L-0034
3 Coil 3510086 3510086 3510086 3510086 3510086
4 Expansion valve 3516273 3516273 3516273 3516273 3516273
5 Coil assembly cover 019-0V0-0030 019-0V0-0038 019-0V0-0032 019-0V0-0033 019-0V0-0034
6 Fan assembly cover 226-0V1-0030 226-0V1-0031 226-0V1-0032 226-0V1-0033 226-0V1-0034
7 Adapter bar 243-AB0-0001 243-AB0-0001 243-AB0-0001 243-AB0-0001 243-AB0-0001
8 Perforated pan clip 270-0V5-0030 270-0V5-0031 270-0V5-0032 270-0V5-0033 270-0V5-0034
9 Black airow extrusion 316-991-0030 316-991-0031 316-991-0032 316-991-0033 316-991-0034
10 Cover support bracket 226-0V2-0030 226-0V2-0030 226-0V2-0030 226-0V2-0030 226-0V2-0030
11 Fan guard 3516173 3516173 3516173 3516173 3516173
12 Fan blade 3516172 3516172 3516172 3516172 3516172
13 Fan motor 2162691 2162691 2162691 2162691 2162691
14 Fan bracket 031-264-0000 031-264-0000 031-264-0000 031-264-0000 031-264-0000
15 Plexiglas end cap 091-0XL-0030 091-0XL-0030 091-0XL-0030 091-0XL-0030 091-0XL-0030
16 S/S thumb screw 9321541 9321541 9321541 9321541 9321541
17 Cond. Unit 000-BN5-0030 000-BN5-0035 000-BN5-0035 000-BN5-0036 000-BN5-0036
— Timer 2194345 2194345 2194345 2194345 2194345
— Pressure Control 2193927 2193927 2193927 2193927 2193927
— Rocker switch 2190154 2190154 2190154 2190154 2190154

™

22

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Condensing Unit 1/4 H.P. R404a Low

8100-EF Series, 8100-EFN Series, N8131-FA, N8231, N8231G, N8245, N8245G, N8259, N8273, N8630, N8643, N8656, N8669

Key Deleld Part # Description

- 000-BN5-0030 Condensing Unit Assembly, 115V

- 000-BN5-003J Condensing Unit Assembly, 220V/50Hz
1 026-C58-0030 Shroud, Condenser Coil
2 3516457 Blade, Fan, 7.25”
3 2162717 Motor, fan, 9W, 115V
3 2162720 Motor, fan, 9W, 230V
4 2160020 Guard, Fan, 7.25”
5 3526999 Compressor, NF5.5CLX, 115V/60Hz, Danfoss
5 3527013 Compressor 220/50Hz, Danfoss
6 2194787 Capacitor, Start 280MFD
7 3516444 Compressor relay and overload, NF5.5CLX
8 3516322 Filter-dryer, (2) inlet .25”
9 075-231-0030 Pan, condensate
10 3516454 Condenser Coil

1

4

2

3

Miscellaneous Parts Not Included in Condensing Unit

- 2194099 15 Amp switch, 120V

- 2194400 15 Amp switch, 220V

- 2183348 Cord/plug assembly

- 3516225 Expansion valve

5

6

7

10

Condensing Unit Assembly 1/3 H.P. R404a, Low, N8259G, N8287, N8681

Key Deleld Part # Description

- 000-BN5-003G Condensing Unit Assembly, 115V

- 000-BN5-003M Condensing Unit Assembly, 220V/50Hz
1 026-C58-0030 Shroud, Condenser Coil
2 3516457 Blade, Fan, 7.25”
3 2162717 Motor, fan, 9W, 115V
3 2162720 Motor, fan, 9W, 230V
4 2160020 Guard, Fan, 7.25”
5 3527000 Compressor, NF7.0. 115V/60Hz, Danfoss
5 3527012 Compressor, 220V/50Hz Danfoss
6 3516324 High pressure switch
7 2194788 Capacitor, Start 320MFD
8 3516438 Compressor relay and overload, NF7CLX
9 3516322 Filter-dryer, (2) inlet .25”
10 3516458 Receiver tank

1

11 075-231-0030 Pan, condensate
12 3516454 Condenser Coil

4

3

2

5

8

9

6

7

8

Miscellaneous Parts Not Included in Condensing Unit

- 3516225 Expansion valve

- 2194099 15 Amp switch, 120V

- 2194400 15 Amp switch, 220V

- 2183348 Cord/plug assembly

™

®

11

12

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

9

10

23

N8000 Series Drop-In Installation and Operation Manual

Delfield

Condensing Unit Assembly 1/2 H.P. R404a, Low, N8273G

Key Deleld Part # Description

- 000-BN5-0033 Condensing Unit Assembly, 115V

- 000-BN5-003N Condensing Unit Assembly, 220V/50Hz
1 026-C58-0031 Shroud, 1/2 HP Condenser Coil
2 3516554 Blade, Fan, 9.00”, 5-pedal
3 2160019 Guard, Fan, Condenser, Upright
4 2162716 Motor, Fan, 16W, 115V
4 2162721 Motor, Fan 16W, 230V
5 3516324 High Pressure Switch
6 3527001 Compressor, SC12CLX.2,115V/60Hz, Danfoss
6 3527011 Compressor, 220V/50Hz, Danfoss
7 3516322 Filter-dryer, (2) inlet .25”
8 2194789 Capacitor, Start 240MFD
9 3516441 Compressor relay, SC12CLX.2
10 3516459 Receiver
11 3516455 Condenser Coil

Miscellaneous Parts Not Included in Condensing Unit

- 3516225 Expansion valve

- 2194099 15 Amp switch, 120V

- 2194400 15 Amp switch, 220V

- 2183348 Cord/plug assembly

2

1

6

5

4

3

7

8

9

10

11

24

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

9

7 6

5

8

2

3

4

1

Narrow Base Condensing Unit Assembly 1/5 H.P. R134A, Low

N8118B, N8130B, N8143B, N8144-BR, N8146NB, N8159-BR, N8168NB

Key Deleld Part # Description
1 2183300 Harness, wire, power cord, 8100
2 3526694 Compressor, 1/5 h.p.,115v/60hz
2 3526718 Compressor, 1/5 h.p., 220v/50hz
3 3516047 Cold Control
4 024-ADB-0040 Compressor stand
5 031-264-0000 Bracket, fan motor, blower coil
6 3516172 Blade, fan, 5.56, CCW, Lexan, clear
7 2162691 Motor, fan, 115v, 50/60, UPPCO/bay
7 2162692 Motor, fan, 230V, 50/60, UPPCO/bay
8 026-ANM-0030 Fan baffle
9 3516067 Coil, condenser, 9 x 10, R-134a, 8100

- 3516191 Filter dryer

- 2194400 15 Amp switch, 220V

Narrow Base Condensing Unit Assembly N8156B, N8169B, N8176-BR, N8181B, N8194-BR

Key Deleld Part # Description
1 2183300 Harness, wire, power cord
2 3526703 Compressor, 1/3HP, 115/60, R134A, N8181B
2 3526695 Compressor, 1/4 h.p.,115v/60hz, N8156B,
N8169B, N8176-BR, N8194-BR
2 3526719 Compressor, 1/4 h.p., 220v/50hz
3 3516047 Cold control
4 024-ADB-0041 Stand, compressor
5 2194013 Fan assembly, condenser, 8” blade, 115V
5 2162689 Fan assembly, condenser, 8” blade, 220V
6 026-ANM-0033 Baffle, fan
7 3516067 Coil, condenser, 9x10, R134A

- 3516191 Filter dryer

- 2194400 15 Amp switch, 220V

1

4

5

6

2

3

™

7

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

25

N8000 Series Drop-In Installation and Operation Manual

Delfield

Condensing Unit Assembly 1/2 H.P. N8144-FA, N8157-FA

Key Deleld Part # Description

- 000-BN5-0035 Condensing Unit Assembly
1 026-C58-0031 Shroud, 1/2 HP condenser coil
2 3516554 Blade, fan 9.00”, 5 pedal
3 2160019 Guard, fan, condenser, upright
4 2162716 Motor, fan, 16W, 115V
5 3516462 Capacitor, start, assembly
6 3527026 Compressor, SC12MLX, 115V/60Hz, Danfoss
7 3516331 High pressure switch
8 3516322 Filter dryer, (2) inlet, .25”
9 3516459 Receiver
10 075-231-0031 Pan, condensate
11 3516455 Coil, 1/2 HP condensing

2

1

4

3

6

5

7

8

8

11

Condensing Unit Assembly 3/4 H.P. N8169-FA, N8182-FA

Key Deleld Part # Description

- 000-BN5-0036 Condensing Unit Assembly
1 026-C58-0032 Shroud, 3/4 HP condenser coil
2 2160019 Guard, fan, condenser, upright
3 3516442 Capacitor, start, run, assembly
4 3527021 Compressor, SC18MLX, 115V/60Hz, Danfoss
5 3516322 Filter dryer, (2) inlet, .25”
6 3516360 Tank, receiver
7 3516456 Coil, condenser, 3/4 HP

- 075-231-0031 Pan, condensate

- 3516433 Blade, fan 25º, 10”, CW, upright

- 2162716 Motor, fan, 16W, 115V

3

2

1

10

4

5

6

26

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

7

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Food Well Assembly With Thermostat control N8600

10

For models N8600

1

2

9

8

7

6

5

4

3

Key Deleld Part # Description
1 2194940 Immersion heater 120V, 1Ph 3KW
1 2194942 Immersion heater 240V 1Ph 5KW
2 026-AO6-0041 Box, control, galv, 8600 series
3 372-ANQ-003D Front, collar, mounting, 8600
4 2193979 Switch, 3 position, 30Amp
5 372-ANS-0001 Cover, control box, 8700 series
6 2194190 Light, pilot, 125V, red
7 2194202 Thermostat, electric (heated)
8 3234556 Knob, thermostat control (heated)
9 2194185 Contactor, relay 30 Amp 120V
10 3516047 Temperature control (cold)

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

27

N8000 Series Drop-In Installation and Operation Manual

Delfield

Food Well Assembly With Innite Control N8700

For models N8700D, N8700N, N8700ND, N8700R

Key Deleld Part # Description
1 3434703 Insulation, berglass, 9” x 48”
2 2194335 Thermostat, non-adjustable, 480˚F
3 026-103-0002 Bottom cover
4 3434663 Insulation, blanket, 24” wide
5 026-061-0001 Plate, deector, DFW, with or without drain
6 2194007 Element, heating, 208/230v, 1000/1222w
6 2194006 Element, heating, 120v
7 000-BQ9-Z0000 Well, hot food, with drain
7 000-BQ9-Z0001 Well, hot food, without drain

- 3234557 Knob, innite control

- 2194110 Control, innite, 240v, 14a

- 2194107 Control, innite, 120v

1

2

4

3

5

1

Food Well Assembly With Thermostat Control N8800

For models N8831, N8859, N8873, N8887

Key Deleld Part # Description
1 3234556 Knob, thermostat control
2 2193984 Thermostat 30A, N8873. N8887
2 2194012 Thermostat, 25A, N8831, N8845, N8859
3 2194007 Element, heating, 208/230v, 1000/1222w
3 2194006 Element, heating, 120v, 1000w
4 026-061-0001 Plate, deector, DFW, with drain

- 3434704 Insulation, berglass, 1” thick

- 3434664 Insulation, berfrax, 1” thick

6

7

4

28

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

1

2

3

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Standard Labor Guidelines To Repair Or Replace Parts On Deleld Equipment

Advice and recommendations given by Deleld Service Technicians do not constitute or guarantee any special
coverage.

•Amaximumof1-hourisallowedtodiagnose a defective component.

•Amaximumof1-hourisallowedforretrieval of parts not in stock.

•Amaximumtravel distance of 100 miles round trip and 2-hours will be reimbursed.

•Overtime,installation/start-up,normalcontroladjustments,generalmaintenance,glassbreakage,freight

damage, and/or correcting and end-user installation error will not be reimbursed under warranty unless pre­approved with a Service Work Authorization from Deleld. You must submit the number with the service claim.

Labor Of 1-Hour Is Allowed To Replace:

•CompressorStartComponentsandOverloadProtector • CondensateElement

•CondenserFanMotorandBlade • Contactor/Relay

•Hi-limit/ThermalProtectorSwitch • InniteSwitch

•SolenoidCoil • Thermostat

Labor Of 2 Hours To Replace:

•HeatingElement • Locate/RepairLeak

•SolenoidValve

Labor Of 3 Hours To Replace:

•CapillaryTubing • Condenser

•ExpansionValve

Labor Of 4 Hours To Replace:

•Compressor

This includes recovery of refrigerant and leak check.
$55.00 maximum reimbursement for refrigerant recovery (includes recovery machine, pump, torch, oil, ux, minor

ttings, solder, brazing rod, nitrogen, or similar fees.)

Refrigerants:

•R134AAmaximumof$5.00/lb.or31/oz.willbereimbursed.

•R404AAmaximumof$15.00/lb.or$1.00/oz.willbereimbursed.

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

29

N8000 Series Drop-In Installation and Operation Manual

Delfield

Standard One Year Limited Warranty (One year parts, 90 days labor)

The Deleld Company (“Deleld”) warrants to the Original
Purchaser of the Deleld product (herein called the “Unit”) that
such Unit, and all parts thereof, will be free from defects in
material and workmanship under normal use and service for a
period of one (1) year from the date of shipment of the Unit to
the Original Purchaser or, if the Original Purchaser returns

the warranty card completely lled out including the date of
installation within thirty (30) days of receipt of the Unit, one
(1) year from the date of installation. During this one year

warranty period, Deleld will repair or replace any defective part
or portion there of returned to Deleld by the Original Purchaser
which Deleld determines was defective due to faulty material
or workmanship. The Original purchaser will pay all labor,
crating, freight and related costs incurred in the removal of the
Unit of defective component and shipment to Deleld, except
that during a period of either ninety (90) days from the date of
shipment of the Unit to the Original Purchaser or, if the Original
Purchaser returns the warranty card completely lled out
including the date of installation within thirty (30) days of receipt
of the Unit, ninety (90) days from the date of installation Deleld
will pay all related labor costs. Deleld will pay the return costs
if the Unit or part thereof was defective.

The term “Original Purchaser” as used herein means that
person, rm, association, or corporation for whom the Unit was
originally installed.

This warranty does not apply to any Unit or part thereof that has
been subjected to misuse, neglect, alteration, or accident, such
as accidental damage to the exterior nish, operated contrary
to the recommendations specied by Deleld; or repaired or
altered by anyone other than Deleld in any way so as to, in
Deleld’s sole judgement, affect its quality or efficiency. This
warranty does not apply to any Unit that has been moved from
the location where it was originally installed. This warranty
also does not cover the refrigerator drier or the light bulbs
used in the Unit. The warranty is subject to the user’s

normal maintenance and care responsibility as set forth
in the Service and Installation Manual, such as cleaning
the condenser coil, and is in lieu of all other obligations
of Deleld. Deleld neither assumes, nor authorizes any
other person to assume for Deleld, any other liability in
connection with Deleld’s products.

Removal or defacement of the original Serial Number or Model
Number from any Unit shall be deemed to release Deleld from
all obligations hereunder or any other obligations, express or
implied.

Parts furnished by suppliers to Deleld are guaranteed by
Deleld only to the extent of the original manufacturer’s express
warranty to Deleld. Failure of the Original Purchaser to
receive such manufacturers warranty shall in no way create
any warranty, expressed or implied, or any other obligation or
liability on Deleld’s part in respect thereof.

If shipment of a replacement part is requested prior to the
arrival in the Deleld factory of the part claimed to be defective,
the Original Purchaser must accept delivery of the replacement
part on a C.O.D. basis, with credit being issued after the part has
been received and inspected at Deleld’s plant and determined
by Deleld to be within this warranty.

Under no condition does this warranty give the Original
Purchaser the right to replace the defective Unit with a complete
Unit of the same manufacturer or of another make. Unless
authorized by Deleld in writing, this warranty does not permit
the replacement of any part, including the motor-compressor, to
be made with the part of another make or manufacturer.

No claims can be made under this warranty for spoilage of any
products for any reason, including system failure.

The installation contractor shall be responsible for building
access, entrance and eld conditions to insure sufficient
clearance to allow any hood(s), vent(s), or Unit(s) if necessary,
to be brought into the building. Deleld will not be responsible
for structural changes or damages incurred during installation
of the Unit or any exhaust system.

Deleld shall not be liable in any manner for any default or delay
in performance hereunder caused by or resulting from any
contingency beyond Deleld’s control, including, but not limited
to, war, governmental restrictions or restraints, strike, lockouts,
injunctions, re, ood, acts of nature, short or reduced supply
of raw materials, or discontinuance of the parts by the original
part manufacturer.

Except as provided in any Additional Four Year Protection
Plan, if applicable, and the Service Labor Contract, if
applicable, the foregoing is exclusive and in lieu of all other
warranties, whether written or oral, express or implied. This
warranty supersedes and excludes any prior oral or written
representations or warranties. Deleld expressly disclaims
any implied warranties of merchantability, tness for a
particular purpose or compliance with any law, treaty, rule
or regulation relating to the discharge of substances into
the environment. The sole and exclusive remedies of any
person relating to the Unit, and the full liability of Deleld
for any breach of this warranty, will be as provided in this
warranty.

Other than this Deleld Standard One Year Limited Warranty,
any applicable Deleld Additional Four Year Protection Plan
or applicable Deleld Service Labor Contract, the Original
Purchaser agrees and acknowledges that no other warranties
are offered or provided in connection with or for the Unit or any
other part thereof.

In no event will Deleld be liable for special, incidental or
consequential damages, or for damages in the nature of
penalties.

30

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

™

®

N8000 Series Drop-In Installation and Operation Manual

Delfield

Additional Four Year Protection Plan (for Motor-Compressor only)

Installation
Deleld Model# Serial # Date

In addition to the Standard One Year Warranty on the Motor­Compressor contained in the above listed Deleld product
(the “Unit”), The Deleld Company (“Deleld”) also agrees to
repair, or exchange with similar or interchangeable parts in
design and capacity at Deleld’s option, the defective Motor­Compressor contained in the Unit (the “Motor-Compressor),
or any part thereof, for the Original Purchaser only, at any
time during the four (4) years following the initial one (1) year
period commencing on the date of installation for the Original
Purchaser. Failure of the Original Purchaser to register

the registration card containing the Original Purchasers
name, address, date of installation, model number and
serial number of the Unit containing the Motor-Compressor
within 30 days from the date of installation shall void this
warranty. This additional warranty is only available if the Motor-

Compressor is inoperative due to defects in material or factory
workmanship, as determined by Deleld in its sole judgement
and discretion. The Original Purchaser shall be responsible for
returning the defective Motor-Compressor to Deleld prepaid,
F.O.B. at the address shown on the back cover of this manual.

The term “Original Purchaser” as used herein means that
person, rm, association, or corporation for whom the Unit was
originally installed.

The term “Motor-Compressor” as used herein does not include
unit base, air or water cooled condenser, receiver, electrical
accessories such as relay, capacitors, refrigerant controls, or
condenser fan/motor assembly. This warranty does not cover
labor charges incidental to the replacement of parts. This
warranty further does not include any equipment to which said
condensing unit is connected, such as cooling coils, temperature
controls or refrigerant metering devices. This warranty shall
be void if the Motor-Compressor, in Deleld’s sole judgement,
has been subjected to misuse, neglect, alteration or accident,
operated contrary to the recommendations specied by the Unit
manufacturer, repaired or altered by anyone other than Deleld
in any way so as, in Deleld’s sole judgment, to affect its quality
or efficiency or if the serial number has been altered, defaced or
removed. This Warranty does not apply to a Motor-Compressor
in any Unit that has been moved from the location where it
was originally installed. The addition of methyl chloride to the
condensing unit or refrigeration system shall void this warranty.

General Conditions

Deleld shall not be liable in any manner for any default or delay
in performance hereunder caused by or resulting from any
contingency beyond Deleld’s control, including, but not limited
to, war, governmental restrictions or restraints, strike, lockouts,
injunctions, re, ood, acts of nature, short or reduced supply
of raw materials, or discontinuance of any part or the Motor­Compressor by the unit manufacturer.

Replacement of a defective Motor-Compressor is limited to one
(1) Motor-Compressor by us during the four (4) year period.
Deleld shall replace the Motor-Compressor at no charge.

This warranty does not give the Original Purchaser of the Motor­Compressor the right to purchase a complete replacement
Motor-Compressor of the same make or of another make. It
further does not permit the replacement to be made with
a Motor-Compressor of another kind unless authorized by
Deleld. In the event Deleld authorizes the Original Purchaser
to purchase a replacement Motor-Compressor locally, only the
wholesale cost of the Motor-Compressor is refundable.

Expressly excluded from this warranty are damages resulting
from spoilage of goods.

Except as provided in any applicable Standard One Year
Limited Warranty or applicable Service Labor Contract, the
foregoing is exclusive and in lieu of all other warranties,
whether written or oral, express or implied. This Warranty
supersedes and excludes any prior oral or written
representations or warranties. Deleld expressly disclaims
any implied warranties of merchantability, tness for a
particular purpose or compliance with any law, treaty, rule
or regulation relating to the Motor-Compressor, and the full
liability of Deleld for any breach of this warranty, will be as
provided in this warranty.

Other than any applicable Deleld Standard One year Limited
Warranty, this Deleld Additional Four Year Protection Plan and
any applicable Deleld Service Labor Contract, the Original
Purchaser agrees and acknowledges that no other warranties
are offered or provided in connection with or for the Motor­Compressor or any part thereof.

In no event will Deleld be liable for special, incidental or
consequential damages, or for damages in the nature of
penalties.

™

®

For customer service, call [phone], [phone], Fax [phone], www.deleld.com

31

™

Delfield

®

Mt. Pleasant, MI

Covington, TN

Thank you for choosing Delfield!

Help is a phone call away. Help our team of professional, courteous

customer service reps by having your model number and serial number

available at the time of your call [phone].

Model: ____________________ S/N: ___________________

Installation Date: ____________

For a list of Deleld’s authorized parts depots,

visit our website at www.deleld.com.

™

®

Delfield

980S.IsabellaRd.,Mt.Pleasant,MI48858,U.S.A.•(989)773-7981or(800)733-8829•Fax(989)773-3210•www.deleld.com

Deleld reserves the right to make changes in design or specications without prior notice. ©2012 The Deleld Company. All rights reserved. Printed in the U.S.A.

DM8000 01/12
