Delfield 18650VDR, 18682VDL, 18682VDR Part Manual

ILLUSTRATED

1

Drawer

2

Drawer

Drawer

Drawer

3

4

1

Drawer

2

Drawer

1

Drawer

2

Drawer

PARTS LIST

Versa Drawer

Refrigeration Units

Delfield 980 S. Isabella Rd., Mt. Pleasant, MI 48858
[phone] or [phone] • Fax [phone]
www.delfield.com

February 2007

Delfield

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

2

CONTENTS

FIGURE 1: VERSA DRAWER ASSEMBLIES 4

TABLE 1: VERSA DRAWER ASSEMBLIES 5

FIGURE 2: 4-DRAWER MACHINE COMPARTMENT ASSEMBLY 6

TABLE 2: 4-DRAWER MACHINE COMPARTMENT ASSEMBLY 7

FIGURE 3: 2-DRAWER MACHINE COMPARTMENT ASSEMBLY 8

TABLE 3: 2-DRAWER MACHINE COMPARTMENT ASSEMBLY 9

FIGURE 4: LO-PROFILE MACHINE COMPARTMENT ASSEMBLY 10

TABLE 4: LO-PROFILE MACHINE COMPARTMENT ASSEMBLY 11

FIGURE 5: EVAPORATOR ASSEMBLY 12

TABLE 5: EVAPORATOR ASSEMBLY 13

FIGURE 6: DRAWER ASSEMBLY 14

TABLE 6: DRAWER ASSEMBLY 15

Versa Drawer Refrigeration Units

TABLE 7: CONTROL PARTS 15

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

3

Delfield

FIGURE 1: VERSA DRAWER ASSEMBLIES

296

4-Drawer

15

529 6

1

87

2-Drawer

7

29 6

Lo-Profile

8

5

1

4 3

7

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

4

Versa Drawer Refrigeration Units

TABLE 1: VERSA DRAWER ASSEMBLIES

QTY

REF. PART DESCRIPTION

NO. NO. F/S* MK7 F/S* MK7 F/S* MK7

1 223-BET-0034 LOUVERED ACCESS PANEL (F18VD50 & F18VD82) 1 1

223-BET-0040 LOUVERED ACCESS PANEL(F17VD84) 1

272-AW8-0031 LOUVERED ACCESS PANEL(18650VDL & 18682VDL) 1 1

272-AW7-0032 LOUVERED ACCESS PANEL(18650VDR & 18682VDR) 1 1

221-AM9-0030 LOUVERED ACCESS PANEL (F2982VDL) 1

221-AMA-0031 LOUVERED ACCESS PANEL (F2982FDR) 1

2 356-478-003H FRONT LOUVERED PANEL 1 1

356-478-003F FRONT LOUVERED PANEL 1 1

272-478-003G FRONT LOUVERED PANEL 11

3 3234160 CASTER 5" 3 2** 3**

4 3534161 CASTER 5" W/BRAKE 3 2** 3**

5 3517334 CONTROL BOARD, ELECTRIC I/O 1 1 1 1 1 1

6 3516407 CONTROL BOARD, DISPLAY 1 1 1 1 1 1

7 9292172 CONTROL OVERLAY 1 1 1 1

9292173 CONTROL OVERLY 11

8 3234645 6" LEGS 6** 4*** 6**

9 221-BET-0035 DISPLAY BOARD S/S COVER 1 1 1 1 1 1

LO-PROFILE 2-DRAWER 4-DRAWER

* F/S = FREE STANDING

** OPTIONAL ON F18VD SERIES

*** OPTIONAL ON 18600VD SERIES

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

5

Delfield

FIGURE 2: 4-DRAWER MACHINE COMPARTMENT ASSEMBLY

1

15

10

11

10

14

9

4

17

16

6

2

8

7

5

3

12

13

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

6

Versa Drawer Refrigeration Units

TABLE 2: 4-DRAWER MACHINE COMPARTMENT ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY

1 3516401 CONDENSER COIL 2

2 2162717 CONDENSER FAN MOTOR 2

3 3523995 COMPRESSOR 2

4 3516397 ACCUMULATOR 2

5 3547639 ACCESS VALVE 2

6 022-A9Y-0030 CONDENSER FAN BRACKET 2

7 3516398 RECEIVER TANK 2

8 3516405 CONDENSER FAN BLADE 2

9 3516101 FILTER DRYER 2

10 3516417 SOLENOID COIL 8

11 3516415 SOLENOID VALVE 8

12 019-261-0031 CONDENSATE EVAP WICK HOLDER 1

13 3516138 CONDENSATE WICK 5

14 3516404 PRESSURE TRANSDUCER 2

15 026-C20-0031 CONDENSER COVER 1

16 3516403 TEMPERATURE SENSOR 1

17 024-136-003H CONDENSER CLIP 2

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

7

Delfield

FIGURE 3: 2-DRAWER MACHINE COMPARTMENT ASSEMBLY

1

6

2

15

10

11

14

9

16

8

3

7

5

4

12

13

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

8

Versa Drawer Refrigeration Units

TABLE 3: 2-DRAWER MACHINE COMPARTMENT ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY

1 3516401 CONDENSER COIL 1

2 2162717 CONDENSER FAN MOTOR 1

3 3523995 COMPRESSOR 1

4 3516397 ACCUMULATOR 1

5 3547639 ACCESS VALVE 1

6 022-A9Y-0030 CONDENSER FAN BRACKET 1

7 3516398 RECEIVER TANK 1

8 3516405 CONDENSER FAN BLADE 1

9 3516101 FILTER DRYER 1

10 3516417 SOLENOID COIL 4

11 3516415 SOLENOID VALVE 4

12 019-261-0030 CONDENSATE EVAP WICK HOLDER 1

13 3516138 CONDENSATE WICK 5

14 3516404 PRESSURE TRANSDUCER 1

15 026-C20-0030 CONDENSER COVER 1

16 3516403 TEMPERATURE SENSOR 1

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

9

Delfield

FIGURE 4: LO-PROFILE MACHINE COMPARTMENT ASSEMBLY

1

6

2

15

9

7

5

14

10

11

16

8

3

10

11

12

13

4

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

10

Versa Drawer Refrigeration Units

TABLE 4:

REF. PART

NO. NO. DESCRIPTION QTY

1 3516401 CONDENSER COIL 1

2 2162717 CONDENSER FAN MOTOR 1

3 3523995 COMPRESSOR 1

4 3516397 ACCUMULATOR 1

5 3547639 ACCESS VALVE 1

6 022-A9Y-0030 CONDENSER FAN BRACKET 1

7 3516398 RECEIVER TANK 1

8 3516405 CONDENSER FAN BLADE 1

9 3516101 FILTER DRYER 1

10 3516417 SOLENOID COIL 4

11 3516415 SOLENOID VALVE 4

12 019-261-0030 CONDENSATE EVAP WICK HOLDER 1

13 3516138 CONDENSATE WICK 5

14 3516404 PRESSURE TRANSDUCER 1

15 026-C20-0030 CONDENSER COVER 1

16 3516403 TEMPERATURE SENSOR 1

LO-PROFILE

MACHINE COMPARTMENT ASSEMBLY

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

11

Delfield

FIGURE 5: EVAPORATOR ASSEMBLY

1

53

2

6

4

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

12

Versa Drawer Refrigeration Units

TABLE 5: EVAPORATOR ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY

1 000-ClX-0030 COMPLETE EVAPORATOR ASSY 1

2 3516400 EVAPORATOR COIL 1

3 2193993 EVAPORATOR FAN MOTOR/BLADE ASSY 2

4 3516396 EXPANSION VALVE 1

5 226-C1Y-0030 COIL ASSEMBLY COVER 1

6 3516403 TEMPERATURE SENSOR 1

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

13

Delfield

FIGURE 6: DRAWER ASSEMBLY

10

8

6

9

3

4

2

1

7

5

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

14

Versa Drawer Refrigeration Units

TABLE 6: DRAWER ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY

1 2194550 DRAWER SWITCH FOR FAN 1

2 000-328-003U DRAWER FRONT ASSEMBLY 1

3 000-333-0040 DRAWER BOX ASSEMBLY 1

4 1702812 DRAWER GASKET 1

5 3234492 INTERMEDIATE PROFILE - REG EXTENSION - RH 1

6 3234504 INTERMEDIATE PROFILE - REG EXTENSION - LH 1

7 3234903 OUTER PROFILE - RH 1

8 3234904 OUTER PROFILE - LH 1

9 264-018-0030 DIVIDER BAR 1

10 3516403 TEMPERATURE SENSOR 1

TABLE 7: CONTROL PARTS

Note: The following parts are not illustrated

REF. PART QTY

NO. NO. DESCRIPTION LO-PROFILE 2-DRAWER 4-DRAWER

2183842 HARNESS, BRD-CTR, VS 1 1 1

2183838 HARNESS, LOW VOLTAGE 1

2183839 HARNESS, LOW VOLTAGE 1 1

2183840 HARNESS, MACHINE COMPARTMENT 1

2183841 HARNESS, MACHINE COMPARTMENT 1 1

Delfield • 980 S. Isabella Road, Mt. Pleasant, MI 48858 • [phone] or [phone] • Fax [phone]

15

Mt. Pleasant, MI Covington, TN

Thank you for choosing Delfield!

Help is a phone call away. Help our team of professional, courteous

customer service reps by having your model number and serial number

available at the time of your call to [phone].

Model: ______________________ S/N: _____________________

Installation Date: ______________

For a list of Delfield’s authorized parts depots,

visit our website at www.delfield.com.

Delfield reserves the right to make changes in design or specifications without prior notice. ©2006 The Delfield Company. All rights reserved. Printed in the U.S.A.

980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] or [phone] • Fax [phone] • www.delfield.com

DMVERSAPARTS 2/07
