Definitive technology W Adapt Owner’s Manual
Wireless Collection
Wireless Music Adapter
Owner’s Manual
Audiophile Grade Wireless Speaker
Denitive Technology’s W Adapt is an easy, simple upgrade that transforms
virtually any audio system into a streaming music system. The W Adapt
connects easily with nearly any home theater receiver using the latest digital
and analog connections. Hookups include an auxiliary input to connect to
Blu-ray, DVD or cable/satellite box, digital outputs for connecting to a
receiver, an optical input to connect from a TV and much more.
Contents
What’s in the Box 3
Getting Started with Wireless Streaming 3
Apps 4
Playing Music 5
Adding Multiple Devices 5
Specications 6
Technical Assistance & Contact 6
The Denitive Technology Wireless Collection
The W Adapt is part of Denitive Technology’s Wireless Collection, which is
an all-encompassing solution for distributing audiophile-grade music anywhere
or everywhere in your home. The W Adapt can be used as a stand-alone
wireless product or as part of a family of wireless products. Stream your
favorite music services, internet radio and your personal digital music library
all from your smartphone, tablet or computer. What’s more, the streamlined
setup process allows you to be up and running in a matter of minutes.
And because you can Mix-and-match speakers with the open DTS Play-Fi®
technology standard, future-proong your technology has never been easier.
www.definitivetech.com
2
Adapt
3
2
3
5
6
42
1
1
4
NetAmp
NetAdapt
owner’s manual
What’s in the Box
1. W Adapt
2. RCA cable (3’)
3. Toslink cable (6’)
4. 12V power adapter
5. Setup Guide
6. Optional mounting brackets for custom-installed audio/video racks
(Screws for securing brackets to adapt included.)
Getting Started
Home Network Basics
In general, Wi-Fi is the wireless streaming of data over a network. Here,
Wi-Fi audio is the streaming of music throughout a home by connecting multiple
speakers and/or devices to a wireless network. The controller for the Denitive
Technology Wireless Collection is the Denitive Technology App, which sends
music information to each DTS Play-Fi enabled speaker or device.
For The Best Music Streaming Experience
To ensure your system is operating under the best environment possible, here
are a few additional tips:
• For the fastest streaming performance, especially when connecting
to multiple speakers simultaneously, an 802.11N router or better is
recommended.
• Ensure the Play-Fi device is within wireless reach of your router,
or that the signal is not blocked by concrete, brick, or other walls. The
quality of your connection can be observed in the Denitive App by
the Wireless Strength icon.
W Adapt Back Panel
• DC IN 12V—power cable connects here
• ETHERNET—wired connection to your router
• 3 AUX IN—(Source 3) 1/8” mini jack connection from a
smartphone, tablet or computer
• USB—for firmware updates only
• 2 AUX IN—(Source 2) RCA connection from Blu-ray, cable/satellite
• AUDIO OUT—line level connection to audio/video receiver
• 1 OPT IN—(Source 1) connection from TV
• SPEAKER—Right and Left channel hookups
• Wi-Fi SETUP Button—to connect wirelessly to your Wi-Fi network
Network and System Requirements
It all begins by building a wireless home network, preferably one with a
high-speed Internet connection. Here’s what you’ll need to connect your
W Adapt to your network:
• A Wireless Network connected to the internet with an 802.11g router
or better.*
• An Android device with version 2.2 operating system or newer OR
an iOS device with version 6.0 operating system or newer.
• The password for your wireless network (if required).
*Router type is usually listed on the router, itself. Please call the dedicated
Denitive Technology Acionado hotline at 1-800-223-5246 for further
questions related to router type.
Connecting the W Adapt To Your Receiver
There are two ways to connect your W Adapt to your receiver:
1. Digital Out- this is a coaxial or optical connection to the receiver.
(Recommended)
2. Audio Out – make an analog RCA connection to the receiver.
www.definitivetech.com
3
