Definitive Technology C-L-R 2500 User Manual
C/L/R 2500
Center/Left/Right Professional Audio Video Shielded Loudspeaker
with Built-In Powered Subwoofer
Owner's Manual
Congratulations on your purchase of the
Definitive Technology C/L/R 2500 Shielded
Center/Left/Right Audio Video Loudspeaker System.
This revolutionary loudspeaker utilizes state-of-theart components (cast-basket homopolymer-coned
bass/midrange drivers, moving coil ferrofluid-cooled
dome high-frequency radiator, long excursion subwoofer, infinite power source amplifier, uniphase
crossover networks, etc.), a non-resonant monocoque
cabinet and low-diffraction construction in order to
achieve the most lifelike sound possible in your listening room for many years to come.
The Definitive Technology C/L/R 2500 is a compact high-definition loudspeaker system designed for
use in audio/video systems of the highest quality.
Because of its low profile, wide range, high power
handling and articulate clarity, it is ideal for use as a
center channel in conjunction with all surround sound
decoding systems, including Dolby ProLogic*, Dolby
Digital AC-3*, and DTS*. In addition, the C/L/R
2500 is ideal for use as an LCR (left, center right
speaker) as well as a rear surround speaker in all surround sound decoding systems, including Dolby Pro
Logic, Dolby Digital AC-3, and DTS, or as the main
speakers in a high quality stereo system.
* Registered
Trademark
Safety Precautions
CAUTION
RISK OF ELECTRIC SHOCK
O NOT OPEN
D
CAUTION! To reduce the risk of electric shock and fire, do not remove the cover or back plate of
this device. There are no user serviceable parts inside. Please refer all servicing to licensed service
technicians. Avis: Risque de choc electricque, ne pas ouvrir.
CAUTION! The international symbol of a lightning bolt inside a triangle is intended to alert the
user to uninsulated “dangerous voltage” within the device’s enclosure. The international symbol of
an exclamation point inside a triangle is intended to alert the user to the presence of important
operating, maintenance and servicing information in the manual accompanying the device.
CAUTION! To prevent electrical shock, match wide blade of plug to wide slot, fully insert.
Attention: Pour eviter les chocs electriques, introduire la lame la plus large de la fiche dans la
borne correspondante de la prise et pousser jusqu'au fond.
CAUTION! To reduce the risk of electrical shock, do not expose this equipment to rain or moisture.
1. Read Instructions—All safety and operating instructions should be read before operating the device.
2. Retain Instructions—The safety and operating instructions should be retained for future reference.
3. Heed Warnings—All warnings on the device and in the operating instructions should be adhered to.
4. Follow Instructions—All operating and safety instructions should be followed.
5. Water & Moisture—The device should never be used in, on or near water for risk of fatal shock.
6. Carts & Stands—The device should only be used on carts or stands recommended by the manufacturer.
7. Wall & Ceiling Mounting—The device should be mounted on a wall or ceiling only as recommended by
the manufacturer.
8. Ventilation—The device should always be located in such a way that it maintains proper ventilation. It should
never be placed in a built-in installation or anywhere that may impede the flow of air through its heat sink.
9. Heat—Never locate the device near heat sources such as radiators, floor registers, stoves or other heat-generating devices.
10. Power Supply—The device should only be connected to a power supply of the type described in the operating instructions or as marked on the device.
11. Power Cord Protection—Power cables should be routed so they are not likely to be stepped on or crushed
by items placed on them or against them. Special attention should be paid to areas where the plug enters a
socket or fused strip and where the cord exits the device.
12. Cleaning—The device should be cleaned in accordance with manufacturer’s instructions.
13. Periods Of Non-Use—The device should be unplugged when not being used for extended periods.
14. Dangerous Entry—Care should be taken that no foreign objects or liquids fall or are spilled inside the
device.
15. Damage Requiring Service—The device should be serviced by licensed technicians when:
• The plug or power supply cord has been damaged.
• Objects have fallen or liquid spilled inside of the device.
• The device has been exposed to moisture.
• The device does not appear to be operating properly or exhibits a marked change in performance.
• The device has been dropped or the cabinet becomes damaged.
16. Service—The device should always be serviced by licensed technicians. Only replacement parts specified by the manufacturer should be used. The use of unauthorized substitutions may result in fire,
shock, or other hazards.
2
Unpacking Your C/L/R 2500
Please Inspect For Shipping Damage
Each loudspeaker leaves our plant in perfect condition. Any visible or
concealed damage most likely occurred in handling after it left our plant and
should be reported at once to your Definitive dealer or the delivery company
that delivered your loudspeaker.
all cartons and packing materials in case you move or need to ship your system. Record the serial number found on the back of the C/L/R 2500 in the
appropriate place on your warranty card.
Please unpack your system carefully. Save
Speaker Break-in
Your C/L/R 2500s should sound good right out of the box; however, an
extended break-in period of 40-60 hours or more of normal playing is required
to reach full performance capability. Break-in allows the suspensions to work
in and results in fuller bass, a more open “blossoming” midrange and
smoother high frequency reproduction.
3
Rear Panel
High
Mid
Low
®
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACAE FUSE WITH SAME
TYPE 1.2A 250V
AVIS
NE PAS OUVRIR
U
TILISER FUSIBLE DE
R
ECHARGE DE MEME TYPE
1.2A 250V
AC 120V 60HZ
2
50 WATT
LEVEL
FULL RANGE
LOW LEVEL IN
P
ower
Automatic On/Off
B
ALTIMORE MD USA
CLR - 2500 Center Channel
T
M
WITH BUILT-IN POWERED SUBWOOFER
P
ATENT PENDING
SERIAL NUMBER
RISQUE DE CHOC ELECTRIQUE
1
.2A 250V
+ -
+ -
+ -
H
IGH
LEVEL
I
N
1
20 V 60 Hz
High
Mid
Low
LEVEL
FULL RANGE
LOW LEVEL IN
Power
Automatic On/Off
4
*
This section of the rear panel will be
shown on the connection diagrams.
Gold Jumper
Connecting Your Loudspeakers
High
Mid
Low
LEVEL
FULL RANGE
LOW LEVEL IN
Power
Automatic On/Off
Since in most cases the C/L/R 2500 will be used as a center channel, we
will give hook-up instructions as such. If you use C/L/R 2500s across the
front (or a pair in stereo) simply hook-up each C/L/R 2500 by repeating
similar hook ups for the left and right channel C/L/R 2500s to their appropriate channel as for the center.
Connecting Each Speaker with One Pair of Speaker Wires Only
When the C/L/R 2500(s) are hooked up using simply one set of speaker
wire per speaker (with no separate low-level input for the subwoofer section) a special circuit takes an infinitesimally small signal from the speaker
level input and converts it to a low-level signal which then drives the subwoofer power amp.
With all the gold jumpers in place, (see diagram # 1) simply connect any
of the red (+) terminals of the speaker to the red (+) terminal of the center
channel speaker level outputs on your amplifier or receiver, and any of the
black (-) terminals of each speaker to the black (-) terminal of the center
speaker level outputs channel on your amplifier or receiver. It is essential
that all the speakers (center, left, right and rears) be connected in the same
way (in phase) to its own channel of the amplifier. If you experience a great
lack of bass, it is likely that one speaker is out of phase with the other.
+
-
Center
Diagram # 1: Connecting C/L/R 2500 with One Pair of Speaker Wires Only
Amplifier or Receiver
Power
5
