Series
CROMO 8+
CROMO 10+
CROMO 12Club
CROMO 12+
CROMO 15+
2-Way Active Speakers
Series
2-Way Active
2
-
Way Active
Speakers
Speakers
The Cromo+ Series offers powered loudspeakers with modern digital technology for first
time users, without having to miss out on professional features and outstanding audio
performance.
The Cromo+ Series features the ultra compact digipack digital power amplifiers, based on
the successful digipro® amp technology for maximum efficiency.
The integrated digital sound processor (DSP) caters for perfect sound calibration of the
individual speaker components. All in all, true professional features, unique in its class
and setting new standards in entry level speaker lines.
The compact multifunctional housing of the Cromo+ speaker line, with asymetrical CD
horns, can be used for many different applications, such as live events, a public address
system for a singer, for monitoring purposes on stage, or for fixed installations in Bars
or lounges.
All Cromo+ models have a microphone input on XLR and jack sockets for maximum
flexibility.
C
PACK
r
o
m
o
61
Series
Professional Active Speakers
CROMO 8+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequenc y Response [-10dB]: 68 - 20.00 0 Hz
Frequenc y Response [+/- 3dB]: 80 - 19.000 Hz
Max SPL: 118 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetr ical CD Horn
LF: 8 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 300 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 270 mm (10.8 in)
Height: 435 mm (17.4 in)
Depth: 252 mm (10.08 in)
Weight: 7,8 kg (15.43 lbs)
CROMO 10+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequenc y Response [-10dB]: 65 - 20.000 Hz
Frequenc y Response [+/- 3dB]: 70 - 19.000 Hz
Max SPL: 121 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetr ical CD Horn
LF: 10 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 40 0 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 320 mm (12.8 in)
Height: 508 mm (20.32 in)
Depth: 297 mm (11.8 8 in)
Weight: 12 kg (26.46 lbs)
CROMO 12Club
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequenc y Response [-10dB]: 55 - 20.000 Hz
Frequenc y Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: 124 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetr ical CD Horn
LF: 12 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 40 0 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 402 mm (16.08 in)
Height: 615 mm (24.6 in)
Depth: 356 mm (14.24 in)
Weight: 17,7 kg (39.02 lbs)
62
CR8
CR8
+
+
CR10
CR CR12CR
+
Club
CROMO 8+
More power To Your Power Amp
|
CROMO 10+ | CROMO 12Club | CROMO 12+ | CROMO 15
+
Series
CROMO 12+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequenc y Response [-10dB]: 55 - 20.000 Hz
Frequenc y Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: 126 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetr ical CD Horn
LF: 12 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 60 0 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 402 mm (16.08 in)
Height: 615 mm (24.6 in)
Depth: 356 mm (14.24 in)
Weight: 18,5 kg (39.68 lbs)
CROMO 15+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequenc y Response [-10dB]: 45 - 20.000 Hz
Frequenc y Response [+/- 3dB]: 50 - 19.000 Hz
Max SPL: 128 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetr ical CD Horn
LF: 15 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 60 0 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 470 mm (18.8 in)
Height: 720 mm (28.8 in)
Depth: 405 mm (16.2 in)
Weight: 22.9 kg (50.49 lbs)
CR12
CR CR
+
CR15
+
63
