Datasheet VNI4140K Datasheet (ST)

Quad high-side smart power solid-state relay

Features

Typ e V

VNI4140K VCC-41 V 0.08 Ω 0.7 A 41 V

1. Per channel.

■ Output current: 0.7 A per channel

■ Shorted load protections

■ Junction overtemperature protection

■ Case overtemperature protection for thermal

demag

(1)

R

independence of the channels

■ Thermal case shutdown restart not

simultaneous for the various channels

■ Protection against loss of ground

■ Current limitation

■ Undervoltage shutdown

■ Open drain diagnostic outputs

■ 3.3 V CMOS/TTL compatible inputs

■ Fast demagnetization of inductive loads

■ Conforms to IEC 61131-2

■ ESD according to IEC 61000-4-2 up to +/-

25 kV

Figure 1. Block diagram

DS(on)

(1)

I

out

(1)

V

CC

VNI4140K

Datasheet − production data

PowerSSO-24

Description

The VNI4140K is a monolithic device made using
STMicroelectronics VIPower technology, intended
for driving four independent resistive or inductive
loads with one side connected to ground. Active
current limitation avoids dropping the system
power supply in case of shorted load. Built-in
thermal shutdown protects the chip from
overtemperature and short-circuit. In overload
condition, channel turns OFF and back ON
automatically so as to maintain junction
temperature between T
condition makes case temperature reach T
overloaded channel is turned OFF and will
restartonly when case temperature has
decreased down to T
channel in overload, re-start of the overloaded
channels will not be simultaneous, in order to
avoid high peak current from the supply. Non
overloaded channels continue to operate
normally. The open drain diagnostics outputs
indicates overtemperature conditions.

and TR. If this

TSD

. In case of more than one

CR

CSD

,

March 2012 Doc ID 14174 Rev 10 1/25

This is information on a product in full production.

www.st.com

25

Contents VNI1440K

Contents

1 Pin connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2 Maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.1 Thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4 Truth table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5 Typical application circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6 Switching waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7 Pin functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

8 Package and PC board thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

8.1 VNI4140K thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

9 Reverse polarity protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

10 Package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

11 Order codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

12 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

2/25 Doc ID 14174 Rev 10

VNI1440K Pin connection

1 Pin connection

Figure 2. Pin connection (top view)

V

CC

IN1

STAT1

IN2

STAT2

GND

STAT3

IN3

STAT4

IN4
NC
NC

Table 1. Pin description

Pin Name Description

Tab TAB Exposed tab internally connected to Vcc

1 Vcc Supply voltage

2 IN1 Channel 1 input 3.3 V CMOS/TTL compatible

OUT1
OUT1
OUT1
OUT2
OUT2
OUT2
OUT3

OUT3
OUT3
OUT4
OUT4
OUT4

3 STAT1 Channel 1 status in open drain configuration

4 IN2 Channel 2 input 3.3 V CMOS/TTL compatible

5 STA2 Channel 2 status in open drain configuration

6 GND Device ground connection

7 STAT3 Channel 3 status in open drain configuration

8 IN3 Channel 3 input 3.3 V CMOS/TTL compatible

9 STAT4 Channel 4 status in open drain configuration

10 IN4 Channel 4 input 3.3 V CMOS/TTL compatible

11 NC

12 NC

13 OUT4 Channel 4 power stage output, internally protected

14 OUT4 Channel 4 power stage output, internally protected

15 OUT4 Channel 4 power stage output, internally protected

16 OUT3 Channel 3 power stage output, internally protected

17 OUT3 Channel 3 power stage output, internally protected

Doc ID 14174 Rev 10 3/25

Pin connection VNI1440K

Table 1. Pin description (continued)

Pin Name Description

18 OUT3 Channel 3 power stage output, internally protected

19 OUT2 Channel 2 power stage output, internally protected

20 OUT2 Channel 2 power stage output, internally protected

21 OUT2 Channel 2 power stage output, internally protected

22 OUT1 Channel 1 power stage output, internally protected

23 OUT1 Channel 1 power stage output, internally protected

24 OUT1 Channel 1 power stage output, internally protected

4/25 Doc ID 14174 Rev 10

VNI1440K Maximum ratings

2 Maximum ratings

Table 2. Absolute maximum rating

Symbol Parameter Value Unit

V

-V

I

I

V

I

V

E

P

T

GND

OUT

V

STAT

Power supply voltage 41 V

CC

Reverse supply voltage -0.3 V

CC

DC ground reverse current -250 mA

Output current (continuos) Internally limited A

I

Reverse output current (per channel) -5 A

R

I

Input current (per channel) ± 10 mA

IN

Input voltage +V

IN

Status pin voltage +V

STAT

Status pin current ± 10 mA

Electrostatic discharge (R = 1.5 kΩ; C = 100 pF) 2000 V

ESD

Single pulse avalanche energy per channel not

AS

simultaneously

Power dissipation at Tc = 25 °C Internally limited W

TOT

T

Junction operating temperature Internally limited °C

J

Storage temperature -55 to 150 °C

STG

2.1 Thermal data

CC

CC

V

V

300 mJ

Table 3. Thermal data

Symbol Parameter Value Unit

R

th(JC)

R

th(JA)

1. Per channel

Thermal resistance junction-case

Thermal resistance junction-ambient Max see Figure 11 °C/W

Doc ID 14174 Rev 10 5/25

(1)

Max 2 °C/W

Electrical characteristics VNI1440K

3 Electrical characteristics

10.5 V < VCC < 36 V; -25 °C < TJ < 125 °C; unless otherwise specified

Table 4. Power section

Symbol Parameter Test condition Min Typ Max Unit

Vcc Supply voltage 10.5 36 V

I

R

DS(on)

V

clamp

I

S

I

LGND

V

OUT(OFF)

On-state resistance

Supply current

Output current at turn­off

Off state output
voltage

= 0.5 A at TJ = 25 °C

OUT

I

= 0.5 A

OUT

Is = 20 mA 41 45 52 V

All channel in OFF state
ON state with V

= 125 °C)

(T

J

VCC = V
V

V

STAT

= 24 V, V

GND

= 0 V and I

IN

= 5 V

IN

= VIN =

= 0 V

OUT

= 0 A 1 V

OUT

250

2.4 4

0.080

0.140ΩΩ

µA

mA

1mA

CP

Off state output
current

Charge pump
frequency

V

IN

= V

= 0 V 0 5 µA

OUT

Channel in ON state

(1)

1450 kHz

I

OUT(OFF)

F

1. To cover EN55022 class A and class B normative.

= 24 V; -25 °C < TJ < 125 °C, RL = 48 Ω, input rise time < 0.1 µs

V

CC

Table 5. Switching

Symbol Parameter Min Typ Max Unit

t

d

t

d

(OFF)

dV/dt

dV/dt

(ON)

Turn on delay - 20 - µs

t

Rise time - 10 - µs

r

Turn off - 30 - µs

t

Fall time - 8 - µs

f

Turn on voltage slope - 3 - V/µs

(ON)

(off) Turn off voltage slope - 4 - V/µs

6/25 Doc ID 14174 Rev 10

VNI1440K Electrical characteristics

Table 6. Logical input

Symbol Parameter Test condition Min Typ Max Unit

V

V

V

I(HYST)

I

Input low level voltage 0.8 V

IL

Input high level voltage 2.20 V

IH

Input hysteresis
voltage

Input current

IN

V

= 15 V 10

IN

= 36 V 210

V

IN

0.15 V

Table 7. Protection and diagnostic

Symbol Parameter Test condition Min Typ Max Unit

v

STAT

V

USD

V

USDHYS

I

LIM

I

PEAK

Status voltage
output low

Undervoltage
protection

Undervoltage
hysteresis

DC short-circuit
current

Maximum DC output
current

= 1.6 mA 0.6 V

I

STAT

710.5V

0.4 0.5 V

V

CC

= 24 V; R

< 10 mΩ 0.7 1 1.7 A

LOAD

Dynamic load 1.3 A

µΑ

Hyst Tracking limits 0.2 A

I

LSTAT

T

T

T

HIST

T

CSD

T

T

CHYST

V

demag

TSD

Status leakage current VCC = V

Junction shutdown
temperature

Junction reset

R

temperature

Junction thermal
hysteresis

Case shutdown
temperature

Case reset

CR

temperature

Case thermal
hysteresis

Output voltage at
turn-OFF

I

OUT

= 36 V 30 µΑ

STAT

= 0.5 A; L

LOAD

>= 1 mH

150 170 190 °C

135 °C

715 °C

125 130 135 °C

110 °C

715 °C

-41VCC-45VCC-

V

CC

52

V

Doc ID 14174 Rev 10 7/25

Electrical characteristics VNI1440K

Figure 3. Current and voltage conventions

8/25 Doc ID 14174 Rev 10

VNI1440K Truth table

4 Truth table

Table 8 . Tr u th t a ble

Condition INPUTn OUTPUTn STATUSn

Normal operation

Overtemperature

Undervoltage

Shorted load

(Current limitation)

L

H

L

H

L

H

L

H

5 Typical application circuit

Figure 4. Typical application circuit

L

H

L
L

L
L

L

X

H
H

H
L

X
X

H
H

Doc ID 14174 Rev 10 9/25

Typical application circuit VNI1440K

Figure 5. Thermal behavior

Vi n( i ) = H

OUT(i) On

STAT(i) Off (H)

1)

NO

Tj ( i ) > Tt s d

YES

4)

Tc > Tc r

YES

OUT(i) Off

STAT(i) On (L)

Tc > Tc s d

NO

NO

NOYES

2)

YES

Tj(i) > Tjr

10/25 Doc ID 14174 Rev 10

3)

VNI1440K Switching waveforms

6 Switching waveforms

Figure 6. Switching waveforms

Doc ID 14174 Rev 10 11/25

Pin functions VNI1440K

7 Pin functions

Figure 7. Input circuit

Figure 8. Status circuit

12/25 Doc ID 14174 Rev 10

VNI1440K Pin functions

Figure 9. Charge pump switching frequency (typical) vs temperature

Freq_CP

2000

1800

1600

1400

1200

CP_frequency (KHz)

1000

800

-50 0 50 100 150 200

temperature("C)

Freq_CP

Doc ID 14174 Rev 10 13/25

Package and PC board thermal data VNI1440K

8 Package and PC board thermal data

8.1 VNI4140K thermal data

Figure 10. VNI4140K PC board

Note: Layout condition of Rth and Zth measurements (PCB: Double layer, Thermal Vias,

FR4 area = 77 mm x 86 mm, PCB thickness=1.6 mm, Cu thickness = 70 mm (front and back
side), Copper areas: from minimum pad lay-out to 8 cm

Figure 11. R

vs PCB copper area in open box free air condition (one channel ON)

thJA

2

).

14/25 Doc ID 14174 Rev 10

VNI1440K Package and PC board thermal data

Figure 12. VNI4140K thermal impedance junction ambient single pulse

(one channel on)

Doc ID 14174 Rev 10 15/25

Reverse polarity protection VNI1440K

9 Reverse polarity protection

This schematic can be used with any type of load.

The following is an indication on how to dimension the R

R

= (-VCC) / (-I

GND

where -I
maximum rating section of the device datasheet.

Power dissipation in R

PD = (-V

Note: In normal condition (no reverse polarity) due to the diode there will be a voltage drop

between GND of the device and GND of the system.

Figure 13. Reverse polarity protection

is the DC reverse ground pin current and can be found in the absolute

GND

)2/R

CC

GND

GND

)

(when VCC < 0: during reverse polarity situations) is:

GND

+ Vcc

+ Vcc

Input

Input

i

i

Output

Output

Status

Status

i

i

GND

GND

GND

resistor.

i

i

Load

Load

R

R

GND

GND

16/25 Doc ID 14174 Rev 10

Diode

Diode

VNI1440K Package mechanical data

10 Package mechanical data

In order to meet environmental requirements, ST offers these devices in different grades of
ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
ECOPACK

®

packages, depending on their level of environmental compliance. ECOPACK®

®

is an ST trademark.

Doc ID 14174 Rev 10 17/25

Package mechanical data VNI1440K

Table 9. PowerSSO-24 mechanical data

mm

Symbol

Min. Typ. Max.

A 2.15 2.47

A2 2.15 2.40

a1 0 0.075

b 0.33 0.51

c 0.23 0.32

D 10.10 10.50

E 7.4 7.6

e 0.8

e3 8.8

G 0.1

G1 0.06

H 10.1 10.5

h 0.4

L 0.55 0.85

N 10deg

X 4.1 4.7

Y 6.5 7.1

Figure 14. PowerSSO-24 package dimensions

18/25 Doc ID 14174 Rev 10

VNI1440K Package mechanical data

Figure 15. PowerSSO-24 tube shipment (no suffix)

Table 10. PowerSSO-24 tube shipment

Base quantity 49

Bulk quantity 1225

Tube length (± 0.5) 532

A 3.5

B 13.8

C (± 0.1) 0.6

Note: All dimensions are in mm.

Doc ID 14174 Rev 10 19/25

Package mechanical data VNI1440K

Figure 16. PowerSSO-24 reel shipment (suffix “TR”)

Table 11. PowerSSO-24 reel dimensions

Base quantity 1000

Bulk quantity 1000

A (max) 330

B (min) 1.5

C (± 0.2) 13

F 20.2

G (2 ± 0) 24.4

N (min) 100

T (max) 30.4

20/25 Doc ID 14174 Rev 10

VNI1440K Package mechanical data

Figure 17. PowerSSO-24™ tape dimensions

Table 12. PowerSSO-24™ tape dimensions

Tape width W 24

Tape hole spacing P0 (± 0.1) 4

Component spacing P 12

Hole diameter D (± 0.05) 1.55

Hole diameter D1 (min) 1.5

Hole position F (± 0.1) 11.5

Compartment depth K (max) 2.85

Hole spacing P1 (± 0.1) 2

Note: According to electronic industries association (EIA) Standard 481 rev. A, Feb 1986

Doc ID 14174 Rev 10 21/25

Package mechanical data VNI1440K

Figure 18. VN14140k suggested footprint

  

 n 













2







3OLDER-ASK/PENING

Note: STMicroelectronics is not responsible for any PCB related issues. The footprint shown in the

above figure is a suggestion which might not be in line to the customer PCB supplier design
rules.

All dimensions are in mm.

22/25 Doc ID 14174 Rev 10

VNI1440K Order codes

11 Order codes

Table 13. Order codes

Order codes Package Packaging

VNI4140K PowerSSO-24 Tube

VNI4140KTR PowerSSO-24 Tape and reel

Doc ID 14174 Rev 10 23/25

Revision history VNI1440K

12 Revision history

Table 14. Document revision history

Date Revision Changes

16-Nov-2007 1 Initial release

26-Nov-2007 2 Updated electrical parameters values

08-Jul-2008 3

08-Apr-2008 4 Added I

27-Aug-2009 5 Updated Section 9: Reverse polarity protection

09-Dec-2009 6

15-Apr-2010 7 Updated Table 5 on page 6

06-Feb-2012 8

05-Mar-2012 9

19-Mar-2012 10 Minor text changes.

Inserted: Figure 4 on page 9 and Section 9: Reverse

polarity protection on page 16

parameter in Table 4 on page 6

LGND

Added Section 10: Conformity to IEC 61000-4-2 ESD

immunity test

Inserted feature: Conformity to IEC 61000-4-2 ESD
immunity test in cover page.

Removed chapter: Conformity to IEC 61000-4-2 ESD
immunity test.

Suggested footprint inserted.
In Table 4. parameter I

has been added.

LGND

24/25 Doc ID 14174 Rev 10

VNI1440K

Please Read Carefully:

Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.

All ST products are sold pursuant to ST’s terms and conditions of sale.

Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.

No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.

UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

UNLESS EXPRESSLY APPROVED IN WRITING BY TWO AUTHORIZED ST REPRESENTATIVES, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE
GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.

Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.

ST and the ST logo are trademarks or registered trademarks of ST in various countries.

Information in this document supersedes and replaces all information previously supplied.

The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.

© 2012 STMicroelectronics - All rights reserved

STMicroelectronics group of companies

Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -

Malaysia - Malta - Morocco - Philippines - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America

www.st.com

Doc ID 14174 Rev 10 25/25
