TDA7052B

Mono BTL audio amplifier with DC
volume control

1997 Aug 15 2

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

FEA TURES

• DC volume control

• Few external components

• Mute mode

• Thermal protection

• Short-circuit proof

• No switch-on and switch-off clicks

• Good overall stability

• Low power consumption

• Low HF radiation

• ESD protected on all pins.

GENERAL DESCRIPTION

The TDA7052B and TDA7052BT are 1 W and 0.5 W mono
Bridge-Tied Load (BTL) output amplifiers with DC volume
control.
They have been designed for use in TV and monitors, but
are also suitable for use in battery-fed portable recorders
and radios.

A Missing Current Limiter (MCL) is built in. The MCL circuit
is activated when the difference in current between the
output terminal of each amplifier exceeds 100 mA
(300 mA typ.). This level of 100 mA allows for headphone
applications (single-ended).

QUICK REFERENCE DATA

ORDERING INFORMATION

SYMBOL PARAMETERS CONDITIONS MIN. TYP. MAX. UNIT

V

P

supply voltage 4.5 − 18 V

P

O

output power VP=6V

TDA7052B R

L

=8Ω 0.9 1.0 − W

TDA7052BT R

L

=16Ω 0.5 0.55 − W

G

v(max)

maximum total voltage gain 39.5 40.5 41.5 dB
φ gain control 68 73.5 − dB
I

q(tot)

total quiescent current VP=6V; RL=∞−9.2 13 mA
THD total harmonic distortion

TDA7052B P

O

= 0.5 W − 0.3 1 %

TDA7052BT P

O

= 0.25 W − 0.3 1 %

TYPE

NUMBER

PACKAGE

NAME DESCRIPTION VERSION

TDA7052B DIP8

plastic dual in-line package; 8 leads (300 mil)

SOT97-1

TDA7052BT SO8

plastic small outline package; 8 leads; body width 3.9 mm

SOT96-1

1997 Aug 15 3

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

BLOCK DIAGRAM

Fig.1 Block diagram.

handbook, full pagewidth

input

6

MSA705 - 1

1

2

TDA7052B

TDA7052BT

V

P

4

5I + i

8

I – i

TEMPERATURE

PROTECTION

3

signal

ground

DC volume control

7

n.c.

positive output

negative output

power

ground

V

ref

STABILIZER

PINNING

SYMBOL PIN DESCRIPTION

V

P

1 supply voltage
IN+ 2 input
GND1 3 signal ground
VC 4 DC volume control
OUT+ 5 positive output
GND2 6 power ground
n.c. 7 not connected
OUT− 8 negative output

Fig.2 Pin configuration.

handbook, halfpage

1
2
3
4

8
7
6
5

MSA704 - 1

V

P

OUT

GND2
OUT

GND1

IN

VC

n.c.

TDA7052B

TDA7052BT

1997 Aug 15 4

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

FUNCTIONAL DESCRIPTION

The TDA7052B and TDA7052BT are mono BTL output
amplifiers with DC volume control which have been
designed for use in TV and monitors but are also suitable
for use in battery-fed portable recorders and radios.

In conventional DC volume circuits the control or input
stage is AC coupled to the output stage via external
capacitors to keep the offset voltage low. In the TDA7052B
and TDA7052BT the DC volume control stage is
integrated into the input stage so that no coupling
capacitors are required. With this configuration, a low
offset voltage is maintained and the minimum supply
voltage remains low.

The BTL principle offers the following advantages:

• Lower peak value of the supply current

• The frequency of the ripple on the supply voltage is twice

the signal frequency.

Consequently, a reduced power supply with smaller
capacitors can be used which results in cost reductions.
For portable applications there is a trend to decrease the
supply voltage, resulting in a reduction of output power at
conventional output stages. Using the BTL principle
increases the output power.

The maximum gain of the amplifier is fixed at 40.5 dB.
The DC volume control stage has a logarithmic control
characteristic. Therefore, the total gain can be controlled
from 40.5 dB to −33 dB. If the DC volume control voltage
falls below 0.4 V, the device will switch to the mute mode.

The amplifier is short-circuit proof to ground, V

P

and
across the load. Also a thermal protection circuit is
implemented. If the crystal temperature rises above
+150 °C the gain will be reduced, thereby reducing the
output power. Special attention is given to switch-on and
switch-off clicks, low HF radiation and a good overall
stability.

Power dissipation

Assume for the TDA7052B that V

P

= 6 V; RL=8Ω.
The maximum sine wave dissipation is 0.9 W.
The R

th j-a

of the package is 100 K/W.

Therefore T

amb(max)

= 150 − 100 × 0.9 = 60 °C.

Assume for the TDA7052BT that VP= 6 V; RL=16Ω.
The maximum sine wave dissipation is 0.46 W.
The R

th j-a

of the package is 155 K/W.

Therefore T

amb(max)

= 150 − 155 × 0.46 = 78 °C.

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

THERMAL CHARACTERISTICS

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

V

P

supply voltage − 18 V

V

2, 4

input voltage pins 2 and 4 − 5V

I

ORM

repetitive peak output current − 1.25 A

I

OSM

non-repetitive peak output current − 1.5 A

P

tot

total power dissipation T

amb

≤ 25 °C
TDA7052B − 1.25 W
TDA7052BT − 0.8 W

T

amb

operating ambient temperature −40 +85 °C

T

stg

storage temperature −55 +150 °C

T

vj

virtual junction temperature − +150 °C

T

sc

short-circuit time − 1h

SYMBOL PARAMETER VALUE UNIT

R

th j-a

thermal resistance from junction to ambient in free air

TDA7052B 100 K/W
TDA7052BT 155 K/W

1997 Aug 15 5

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

CHARACTERISTICS

V

P

=6V; VDC= 1.4 V; f = 1 kHz; RL=8Ω; T

amb

=25°C; unless otherwise specified (see Fig.13).

Notes

1. With a load connected to the outputs the quiescent current will increase, the maximum value of this increase being
equal to the DC output offset voltage divided by R

L

.

2. The noise output voltage (RMS value) at f = 500 kHz is measured with RS=0Ω and B = 5 kHz.

3. The ripple rejection is measured with RS=0Ω and f = 100 Hz to 10 kHz. The ripple voltage VR of 200 mV
(RMS value) is applied to the positive supply rail.

4. The noise output voltage (RMS value) is measured with RS=5kΩ unweighted.

5. The DC volume control can be configured in several ways. Two possible circuits are shown in Figs 14 and 15.
The circuits at the volume control pin will influence the switch-on and switch-off behaviour and the maximum voltage
gain.

SYMBOL P ARAMETER CONDITIONS MIN. TYP. MAX. UNIT

Supply

V

P

supply voltage 4.5 − 18 V

I

q(tot)

total quiescent current note 1; RL= ∞−9.2 13 mA

Maximum gain (V

4

= 1.4 V)

P

O

output power THD = 10%

TDA7052B 0.9 1.0 − W
TDA7052BT 0.5 0.55 − W

THD total harmonic distortion

TDA7052B P

O

= 0.5 W − 0.3 1 %

TDA7052BT P

O

= 0.25 W − 0.3 1 %

G

v(max)

maximum total voltage gain 39.5 40.5 41.5 dB

V

I

input signal handling (RMS value) G

v(max)

= 0 dB; THD < 1% 1.0 −−V

V

no

noise output voltage (RMS value) note 2; f = 500 kHz − 210 −µV
B bandwidth at −1dB − 0.02to 300 − kHz
SVRR supply voltage ripple rejection note 3 48 60 − dB
∆V

O

 DC output offset voltage V8− V5−0 200 mV

Z

I

input impedance (pin 3) 15 20 25 kΩ

Mute position

V

O

output voltage in mute position note 4; V4≤ 0.4 V;

VI= 1.0 V

−− 30 µV

DC volume control; note 5
φ gain control 68 73.5 − dB

I

4

control current V4=0V −20 −25 −30 µA

1997 Aug 15 6

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

Fig.3 Gain control as a function of DC volume

control.

handbook, halfpage

0 2.0

40

−80

−120

0

MBH372

0.4 0.8 1.2 1.6

−40

G

v

(dB)

V (V)

DC

Fig.4 Noise output voltage as a function of DC

volume control.

Measured with RS=5kΩ unweighted.
Frequency range is 22 Hzto 22 kHz.

handbook, halfpage

2.0

VDC (V)

0

MBH373

1

10

−1

10

−2

0.4

V

no

(mV)

0.8 1.2 1.6

Fig.5 Control current as a function of DC volume

control.

handbook, halfpage

0 2.0

25

−15

−25

15

MBH376

0.4 0.8 1.2 1.6

−5

VDC (V)

5

I

DC

(µA)

Fig.6 Quiescent current versus supply voltage.

Measured with RL= ∞.

handbook, halfpage

020

15

5

MBH367

10

20

4

I

P

(mA)

81216

V

P

(V)

1997 Aug 15 7

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

Fig.7 Total harmonic distortion versus output

power.

(1) VP= 5 V; RL=8Ω.
(2) VP= 6 V; RL=8Ω.
(3) VP=12V;RL=25Ω.

handbook, halfpage

10

6

4

2

0

MBH368

10

−1

1

PO (W)

THD

(%)

10

8

(1)

(2)

(3)

Fig.8 Total harmonic distortion versus frequency.

PO= 0.1 W.
(1) G

v(max)

=40dB.

(2) G

v(max)

=30dB.

handbook, halfpage

0

MBH369

10

2

4

6

8

10

−2

10

2

10

−1

110

f (kHz)

THD

(%)

(1)

(2)

Fig.9 Output power versus supply voltage.

Measured at a THD of 10%. The maximum output power is limited by
the maximum power dissipation and the maximum available output
current.

(1) R

L

=8Ω.
(2) RL=16Ω.
(3) RL=25Ω.

handbook, halfpage

020

2.5

0

0.5

MBH370

1.0

1.5

2.0

4

P

O

(W)

81216

V

P

(V)

(1)

(2)

(3)

Fig.10 Total worst case power dissipation versus

supply voltage.

(1) RL=8Ω.
(2) RL=16Ω.
(3) RL=25Ω.

handbook, halfpage

020

2.5

0

0.5

MBH371

1.0

1.5

2.0

4

P

d

(W)

81216

V

P

(V)

(1) (2)

(3)

1997 Aug 15 8

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

Fig.11 Supply voltage ripple rejection versus

frequency.

Measured with VR= 0.2 V.
(1) VDC= 1.4 V.
(2) VDC= 0.4 V.

handbook, halfpage

−70

−60

−50

−40

−30

−20

MBH374

10

−2

10

−1

11010

2

f (kHz)

SVRR

(dB)

(1)

(2)

Fig.12 Input signal handling.

Measured at a THD of 1% and a voltage gain of 0 dB.

handbook, halfpage

020

2.0

0

0.4

MBH375

0.8

1.2

1.6

4

V

I

(V)

81216

V

P

(V)

QUALITY SPECIFICATION

In accordance with

“SNW-FQ-611E”

, if this type is used as an audio amplifier.

1997 Aug 15 9

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

TEST AND APPLICATION INFORMATION

For single-end application the output peak current may not exceed 100 mA; at higher output currents the short circuit
protection (MCL) will be activated.

Fig.13 Test and application diagram.

To avoid instabilities and too high distortion, the input- and power ground must be separated as long as possible and connected together as close as
possible to the IC.

(1) This capacitor can be omitted if the 220 µF electrolytic capacitor is connected close to pin 1.

handbook, full pagewidth

input

0.47 µF

6

MSA706 - 2

100 nF 220 µF

1

2

TDA7052B

TDA7052BT

VP = 6 V

(1)

4

5 kΩ

R

S

5

8

+

−

STABILIZER

TEMPERATURE

PROTECTION

3

ground

DC

volume

control

RL = 8 Ω

7

n.c.

I + i

I – i

1997 Aug 15 10

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

Fig.14 Application with potentiometer as volume

control; maximum gain = 34 dB.

handbook, halfpage

MCD387

4

volume

control

1 MΩ1 µF

Fig.15 Application with potentiometer as volume

control; maximum gain = 40 dB.

handbook, halfpage

MBH360

4

volume

control

VP = 6 V

22 kΩ

56 kΩ

1 µF

1997 Aug 15 11

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

PACKAGE OUTLINES

REFERENCES

OUTLINE
VERSION

EUROPEAN

PROJECTION

ISSUE DATE

IEC JEDEC EIAJ

SOT97-1

92-11-17
95-02-04

UNIT

A

max.

12

b

1

(1) (1)

(1)

b

2

cD E e M

Z

H

L

mm

DIMENSIONS (inch dimensions are derived from the original mm dimensions)

A

min.

A

max.

b

max.

w

M

E

e

1

1.73

1.14

0.53

0.38

0.36

0.23

9.8

9.2

6.48

6.20

3.60

3.05

0.2542.54 7.62

8.25

7.80

10.0

8.3

1.154.2 0.51 3.2

inches

0.068

0.045

0.021

0.015

0.014

0.009

1.07

0.89

0.042

0.035

0.39

0.36

0.26

0.24

0.14

0.12

0.010.10 0.30

0.32

0.31

0.39

0.33

0.0450.17 0.020 0.13

b

2

050G01 MO-001AN

M

H

c

(e )

1

M

E

A

L

seating plane

A

1

w M

b

1

e

D

A

2

Z

8

1

5

4

b

E

0 5 10 mm

scale

Note

1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

pin 1 index

DIP8: plastic dual in-line package; 8 leads (300 mil)

SOT97-1

1997 Aug 15 12

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

UNIT

A

max.

A

1

A2A

3

b

p

cD

(1)E(2)

(1)

eHELLpQZywv θ

REFERENCES

OUTLINE

VERSION

EUROPEAN

PROJECTION

ISSUE DATE

IEC JEDEC EIAJ

mm

inches

1.75

0.25

0.10

1.45

1.25

0.25

0.49

0.36

0.25

0.19

5.0

4.8

4.0

3.8

1.27

6.2

5.8

1.05

0.7

0.6

0.7

0.3

8
0

o
o

0.25 0.10.25

DIMENSIONS (inch dimensions are derived from the original mm dimensions)

Notes

1. Plastic or metal protrusions of 0.15 mm maximum per side are not included.

2. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

1.0

0.4

SOT96-1

X

w M

θ

A

A

1

A

2

b

p

D

H

E

L

p

Q

detail X

E

Z

e

c

L

v M

A

(A )

3

A

4

5

pin 1 index

1

8

y

076E03S MS-012AA

0.069

0.010

0.004

0.057

0.049

0.01

0.019

0.014

0.0100

0.0075

0.20

0.19

0.16

0.15

0.050

0.244

0.228

0.028

0.024

0.028

0.012

0.010.010.041 0.004

0.039

0.016

0 2.5 5 mm

scale

SO8: plastic small outline package; 8 leads; body width 3.9 mm

SOT96-1

95-02-04
97-05-22

1997 Aug 15 13

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

SOLDERING
Introduction

There is no soldering method that is ideal for all IC
packages. Wave soldering is often preferred when
through-hole and surface mounted components are mixed
on one printed-circuit board. However, wave soldering is
not always suitable for surface mounted ICs, or for
printed-circuits with high population densities. In these
situations reflow soldering is often used.

This text gives a very brief insight to a complex technology.
A more in-depth account of soldering ICs can be found in
our

“IC Package Databook”

(order code 9398 652 90011).

DIP

SOLDERING BY DIPPING OR BY WA VE
The maximum permissible temperature of the solder is

260 °C; solder at this temperature must not be in contact
with the joint for more than 5 seconds. The total contact
time of successive solder waves must not exceed
5 seconds.

The device may be mounted up to the seating plane, but
the temperature of the plastic body must not exceed the
specified maximum storage temperature (T

stg max

). If the
printed-circuit board has been pre-heated, forced cooling
may be necessary immediately after soldering to keep the
temperature within the permissible limit.

R

EPAIRING SOLDERED JOINTS

Apply a low voltage soldering iron (less than 24 V) to the
lead(s) of the package, below the seating plane or not
more than 2 mm above it. If the temperature of the
soldering iron bit is less than 300 °C it may remain in
contact for up to 10 seconds. If the bit temperature is
between 300 and 400 °C, contact may be up to 5 seconds.

SO

REFLOW SOLDERING
Reflow soldering techniques are suitable for all SO

packages.
Reflow soldering requires solder paste (a suspension of

fine solder particles, flux and binding agent) to be applied
to the printed-circuit board by screen printing, stencilling or
pressure-syringe dispensing before package placement.

Several techniques exist for reflowing; for example,
thermal conduction by heated belt. Dwell times vary
between 50 and 300 seconds depending on heating
method. Typical reflow temperatures range from
215 to 250 °C.

Preheating is necessary to dry the paste and evaporate
the binding agent. Preheating duration: 45 minutes at
45 °C.

W

AVE SOLDERING

Wave soldering techniques can be used for all SO
packages if the following conditions are observed:

• A double-wave (a turbulent wave with high upward
pressure followed by a smooth laminar wave) soldering
technique should be used.

• The longitudinal axis of the package footprint must be
parallel to the solder flow.

• The package footprint must incorporate solder thieves at
the downstream end.

During placement and before soldering, the package must
be fixed with a droplet of adhesive. The adhesive can be
applied by screen printing, pin transfer or syringe
dispensing. The package can be soldered after the
adhesive is cured.

Maximum permissible solder temperature is 260 °C, and
maximum duration of package immersion in solder is
10 seconds, if cooled to less than 150 °C within
6 seconds. Typical dwell time is 4 seconds at 250 °C.

A mildly-activated flux will eliminate the need for removal
of corrosive residues in most applications.

R

EPAIRING SOLDERED JOINTS

Fix the component by first soldering two diagonally­opposite end leads. Use only a low voltage soldering iron
(less than 24 V) applied to the flat part of the lead. Contact
time must be limited to 10 seconds at up to 300 °C. When
using a dedicated tool, all other leads can be soldered in
one operation within 2 to 5 seconds between
270 and 320 °C.

1997 Aug 15 14

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

DEFINITIONS

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

1997 Aug 15 15

Philips Semiconductors Product specification

Mono BTL audio amplifier with DC volume
control

TDA7052B

NOTES

Internet: http://www.semiconductors.philips.com

Philips Semiconductors – a worldwide company

© Philips Electronics N.V. 1997 SCA55
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner.

The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed
without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license
under patent- or other industrial or intellectual property rights.

Netherlands: Postbus 90050, 5600 PB EINDHOVEN, Bldg. VB,
Tel. [phone], Fax. [phone]

New Zealand: 2 Wagener Place, C.P.O. Box 1041, AUCKLAND,
Tel. [phone], Fax. [phone]

Norway: Box 1, Manglerud 0612, OSLO,
Tel. [phone], Fax. [phone]

Philippines: Philips Semiconductors Philippines Inc.,
106 Valero St. Salcedo Village, P.O. Box 2108 MCC,MAKATI,
Metro MANILA, Tel. [phone], Fax. [phone]

Poland: Ul. Lukiska 10, PL 04-123 WARSZAWA,
Tel. [phone], Fax.[phone]

Portugal: see Spain
Romania: see Italy
Russia: Philips Russia, Ul. Usatcheva 35A, 119048 MOSCOW,

Tel. [phone], Fax.[phone]
Singapore: Lorong 1, Toa Payoh, SINGAPORE 1231,

Tel. [phone], Fax. [phone]

Slovakia: see Austria
Slovenia: see Italy
South Africa: S.A. PHILIPS Pty Ltd., 195-215 Main Road Martindale,

2092 JOHANNESBURG, P.O. Box 7430 Johannesburg 2000,
Tel. [phone], Fax.[phone]

South America: Rua do Rocio 220, 5th floor, Suite 51,
04552-903 São Paulo, SÃO PAULO - SP, Brazil,
Tel. [phone], Fax.[phone]

Spain: Balmes 22, 08007 BARCELONA,
Tel. [phone], Fax. [phone]

Sweden: Kottbygatan 7, Akalla, S-16485 STOCKHOLM,
Tel. [phone], Fax. [phone]

Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH,
Tel. [phone], Fax. [phone]

Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1,
TAIPEI, Taiwan Tel. [phone], Fax. [phone]

Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd.,
209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260,
Tel. [phone], Fax. [phone]

Turkey: Talatpasa Cad. No. 5, 80640 GÜLTEPE/ISTANBUL,
Tel. [phone], Fax. [phone]

Ukraine: PHILIPS UKRAINE, 4 Patrice Lumumba str., Building B, Floor 7,
252042 KIEV, Tel. [phone], Fax. [phone]

United Kingdom: Philips Semiconductors Ltd., 276 Bath Road, Hayes,
MIDDLESEX UB3 5BX, Tel. [phone], Fax.[phone]

United States: 811 East Arques Avenue, SUNNYVALE, CA 94088-3409,
Tel. [phone]

Uruguay: see South America
Vietnam: see Singapore
Yugoslavia: PHILIPS, Trg N. Pasica 5/v, 11000 BEOGRAD,

Tel. [phone], Fax.[phone]

For all other countries apply to: Philips Semiconductors, Marketing & Sales Communications,
Building BE-p, P.O. Box 218, 5600 MD EINDHOVEN, The Netherlands, Fax. [phone]

Argentina: see South America
Australia: 34 Waterloo Road, NORTH RYDE, NSW 2113,

Tel. [phone], Fax. [phone]
Austria: Computerstr. 6, A-1101 WIEN, P.O. Box 213, Tel. [phone],

Fax. [phone]
Belarus: Hotel Minsk Business Center, Bld. 3, r. 1211, Volodarski Str. 6,

220050 MINSK, Tel. [phone], Fax. [phone]

Belgium: see The Netherlands
Brazil: seeSouth America
Bulgaria: Philips Bulgaria Ltd., Energoproject, 15thfloor,

51 James Bourchier Blvd., 1407 SOFIA,
Tel. [phone], Fax. [phone]

Canada: PHILIPS SEMICONDUCTORS/COMPONENTS,
Tel. [phone]

China/Hong Kong: 501 Hong Kong Industrial Technology Centre,
72 Tat Chee Avenue, Kowloon Tong, HONG KONG,
Tel. [phone], Fax. [phone]

Colombia: see South America
Czech Republic: see Austria
Denmark: Prags Boulevard 80, PB 1919, DK-2300 COPENHAGEN S,

Tel. [phone], Fax. [phone]
Finland: Sinikalliontie 3, FIN-02630 ESPOO,

Tel. [phone], Fax. [phone]
France: 4 Rue du Port-aux-Vins, BP317, 92156 SURESNES Cedex,

Tel. [phone], Fax. [phone]
Germany: Hammerbrookstraße 69, D-20097 HAMBURG,

Tel. [phone], Fax. [phone]
Greece: No. 15, 25th March Street, GR 17778 TAVROS/ATHENS,

Tel. [phone], Fax. [phone]

Hungary: seeAustria
India: Philips INDIA Ltd, Band Box Building, 2nd floor,

254-D, Dr. Annie BesantRoad, Worli, MUMBAI 400 025,
Tel. [phone], Fax.[phone]

Indonesia: see Singapore
Ireland: Newstead, Clonskeagh, DUBLIN 14,

Tel. [phone], Fax.[phone]
Israel: RAPAC Electronics, 7 Kehilat Saloniki St, PO Box 18053,

TEL AVIV 61180, Tel. [phone], Fax.[phone]
Italy: PHILIPS SEMICONDUCTORS, Piazza IV Novembre 3,

20124 MILANO, Tel. [phone], Fax. [phone]
Japan: Philips Bldg 13-37, Kohnan 2-chome, Minato-ku, TOKYO 108,

Tel. [phone], Fax. [phone]
Korea: Philips House, 260-199 Itaewon-dong, Yongsan-ku, SEOUL,

Tel. [phone], Fax. [phone]
Malaysia: No. 76 Jalan Universiti, 46200 PETALING JAYA, SELANGOR,

Tel. [phone], Fax. [phone]
Mexico: 5900 Gateway East, Suite 200, EL PASO, TEXAS 79905,

Tel. [phone]
Middle East: see Italy

Printed in The Netherlands 547027/1200/03/pp16 Date of release: 1997 Aug15 Document order number: 9397 750 02729
