High voltage fast-switching NPN power transistor
Obsolete Product(s) - Obsolete Product(s)
Features
■ NPN transistor
■ Low spread of dynamic parameters
■ Minimum lot-to-lot spread for reliable operation
■ Very high switching speed
Applications
■ Compact fluorescent lamps at 110V A.C. mains
■ Flyback and forward single transistor low power
converters at 110V A.C. mains
Description
The device is manufactured using multi-epitaxial
Planar technology for high switching speeds and
medium voltage capability. It uses a Cellular
Emitter structure with planar edge termination to
enhance switching speeds while maintaining the
wide RBSOA. The device is designed for use in
lighting applications and low cost switch-mode
power supplies.
STL106D
TO-92
Figure 1. Internal schematic diagram
Table 1. Device summary
Order code Marking Package Packaging
STL106D L106D TO-92 Bulk
March 2008 Rev 1 1/8
www.st.com
8
Page 2
Obsolete Product(s) - Obsolete Product(s)
STL106D
Contents
1 Electrical ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2/8
Page 3
Obsolete Product(s) - Obsolete Product(s)
STL106D Electrical ratings
1 Electrical ratings
Table 2. Absolute maximum rating
Symbol Parameter Value Unit
V
V
V
I
I
P
T
Collector-emitter voltage (VBE = 0) 400 V
CES
Collector-emitter voltage (IB = 0) 230 V
CEO
Emitter-base voltage (IC = 0)
EBO
I
Collector current 1.5 A
C
Collector peak current (tP < 5 ms) 3 A
CM
I
Base current 0.4 A
B
Base peak current (tP < 5 ms) 0.8 A
BM
Total dissipation at Tc = 25 °C 1.5 W
tot
Storage temperature -65 to 150 °C
stg
T
Max. operating junction temperature 150 °C
J
9
Table 3. Thermal data
Symbol Parameter Value Unit
R
thj-case
Thermal resistance junction-case __ max 83.3 °C/W
V
3/8
Page 4
Obsolete Product(s) - Obsolete Product(s)
Electrical characteristics STL106D
2 Electrical characteristics
(T
= 25 °C unless otherwise specified)
case
Table 4. Electrical characteristics
Symbol Parameter Test conditions Min. Typ. Max. Unit
I
CES
I
CEO
V
V
CEO(sus)
V
CE(sat)
EBO
Collector cut-off current
= 0)
(V
BE
Collector cut-off current
= 0)
(I
B
Emitter-Base Voltage
= 0)
(I
C
Collector-emitter
(1)
sustaining voltage
(I
= 0)
B
(1)
Collector-emitter
saturation voltage
Base-emitter saturation
BE(sat)
h
FE
V
F
(1)
voltage
DC current gain
Diode forward voltage
V
1. Pulsed duration = 300 µs, duty cycle ≥ 1.5%.
= 400 V
V
CE
= 230 V
V
CE
= 10 mA
I
E
= 10 mA 230
I
C
I
= 0.5 A _ IB = 0.1 A
C
I
= 1 A _ IB = 0.2 A
C
= 2 A _ _ IB = 0.4 A
I
C
I
= 2 A _ IB = 0.4 A
C
I
= 10 mA V
C
= 1 A V
I
C
I
= 3 A V
C
= 2 A
I
C
CE
CE
CE
= 5 V
= 5 V
= 10 V
100 µA
250 µA
9V
V
0.4
0.8
1.2
V
V
V
1.5 V
10
10
20 30
4
2V
4/8
Page 5
Obsolete Product(s) - Obsolete Product(s)
STL106D Package mechanical data
3 Package mechanical data
In order to meet environmental requirements, ST offers these devices in ECOPACK®
packages. These packages have a Lead-free second level interconnect. The category of
second level interconnect is marked on the package and on the inner box label, in
compliance with JEDEC Standard JESD97. The maximum ratings related to soldering
conditions are also marked on the inner box label. ECOPACK is an ST trademark.
ECOPACK specifications are available at: www.st.com
5/8
Page 6
Obsolete Product(s) - Obsolete Product(s)
Package mechanical data STL106D
TO-92 BULK SHIPMENT MECHANICAL DATA
DIM.
MIN. TYP MAX.
A 4.32 4.95
b 0.36 0.51
D 4.45 4.95
E 3.30 3.94
e 2.41 2.67
e1 1.14 1.40
L 12.70 15.49
R 2.16 2.41
S1 0.92 1.52
W 0.41 0.56
V5
mm.
O
0102782 C
6/8
Page 7
Obsolete Product(s) - Obsolete Product(s)
STL106D Revision history
4 Revision history
Table 5. Document revision history
Date Revision Changes
10-Mar-2008 1 Initial release.
7/8
Page 8
Obsolete Product(s) - Obsolete Product(s)
STL106D
