Application Note

Application of SSD181X/SSD1815A/SSD1815B to Existing
LCD Modules

Solomon Systech Limited

INTRODUCTION

SSD181X/SSD1815A/SSD1815B series LCD driver IC is a
single-chip CMOS LCD driver with controller for liquid crystal
dot-matrix graphic display system. It is capable of driving various
sizes displays, which are commonly used in mobile phone appli­cations. This application note describes how to apply SSD181X/
SSD1815A/SSD1815B into existing LCD modules.

Dot-matrix Display with separated Icon Line

• SSD1811: 132 x 48 + 1 Icon Line

• SSD1812: 132 x 54 + 1 Icon Line

• SSD1813: 132 x 32 + 1 Icon Line

• SSD1815/SSD1815A/SSD1815B: 132 x 64 + 1 Icon Line

SPECIFICATION OF DRIVER IC

Single Supply Operation, 1.8 V - 3.5V
Minimum -12.0V LCD Driving Output Voltage
Low Current Sleep Mode
On-Chip Voltage Generator or External LCD Driving Power
Supply Selectable
2X / 3X / 4X On-Chip DC-DC Converter
On-Chip Oscillator
Programmable Multiplex ratio in dot-matrix display area

• SSD1811: 1Mux ~ 48Mux

• SSD1812: 1Mux ~ 54Mux

• SSD1813: 1Mux ~ 32Mux

• SSD1815/SSD1815A/SSD1815B: 1Mux ~ 64Mux
On-Chip Bias Divider
Programmable bias ratio

• SSD1811, SSD1815: 1/4, 1/5, 1/6, 1/7, 1/8, 1/9

• SSD1815A, SSD1815B: 1/4, 1/5, 1/6, 1/7, 1/8, 1/9

• SSD1812: 1/4, 1/5, 1/6, 1/7, 1/8.4, 1/9

• SSD1813: 1/4, 1/5, 1/6
8-bit 6800-series Parallel Interface, 8-bit 8080-series Parallel
Interface and Serial Peripheral Interface
On-Chip 132 X 65 Graphic Display Data RAM
Re-mapping of Row and Column Drivers
Vertical Scrolling
Display Offset Control
64 Level Internal Contrast Control
External Contrast Control
Programmable LCD Driving Voltage Temperature Coeffi­cients
Available in Gold Bump Die and TAB (Tape Automated
Bonding) Package

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
2

SOLOMON

APPLICATION NOTE 1: ELECTROSTATIC DISCHARGE (ESD) PROTECTION CIRCUIT

For SSD181X/SSD1815A/SSD1815B series IC, it is recommended to design a protection circuit to prevent from un­expected external interference. This is useful especially the designed product has to go through unexpected elec­trostatic discharge. Figure 1 or 2 are examples of the common circuit used.

Figure 1. ESD Protection Circuit (Recommendation 1)

Figure 2. ESD Protection Circuit (Recommendation 2)

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

3

Figure 1 & 2 show the common connection design of the LCD driver IC and the main Microprocessor (MCU) unit,
the RESET pin of the driver is connected directly to one of the port of the MCU. When external charge is brought
near the device (or electrostatic discharge through the device (a spike)), it will discharge by finding its way to the
shortest path to ground.

This discharge sometimes will affect the normal operation of the device, causing data loss inside RAM or internal
registers, or even re-initialize / reset the device. The IC has a built-in protection circuit to protect the I/O pins from
external charge or spike. It can be strengthened by adding an circuitry across the IC Reset pin and MCU port as
figure 1 or figure 2.

In addition, more protection can be done by adding a resistor in series, directly in between the RESET pin of the
driver IC and the port of the MCU. This will create a filter effect, that will be able to eliminate external noise entering
the RESET pin of the driver IC.

Adoption of protection circuit and value of positive components used largely depends on the application printed cir­cuit board design. It is recommended to test and evaluate to find out the best capacitor value for a particular appli­cation.

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
4

SOLOMON

APPLICATION NOTE 2: CONTRAST CONTROL CALCULATION

In the SSD181X/SSD1815A/SSD1815B series IC revision 2.5 onwards, there has been an update on the data information, when
using VL6 voltage regulator internal resistors and the electronic volume function, software control of the 64 contrast voltage levels
is at each voltage regulator feedback gain can be used (without adding any external resistors). The equation given is as follows:

From the above table, the formula can provide a quick estimation of the voltage generated by the software setting
and the electronic booster circuit in the IC.

Case sample: When the voltage regulator internal resistance are used:

The liquid crystal power supply voltage VL6 can be set with the VL6 voltage regulator internal resistors (IRS pin is
pulled “H”). When selecting Ta=25°C, with VDD = 2.775V, IRS = 23hex, Contrast setting = 25hex (=37dec), Tem­perature Compensation (TC) = 0;

By using the formula,

V

ref

= 1.176V

Then,

Therefore, calculated VL6 is -8.22V.

)

1

)(

(

)1(6

R

VVRV

V

V

Contrast

GainVV

SSDD

refDDL

BE

ref

+

−∗+

=

∗+∗=−

β

Int. Reg Resistor
Ratio Setting
(IRS)

20Hex 21Hex 22Hex 23Hex 24Hex 25Hex 26Hex 27Hex

Ext. Resistor
Gain -3.36 -3.84 -4.38 -4.93 -5.50 -5.89 -6.54 -7.10 -(1+R2/R1)
β 90.54 89.95 89.32 88.69 88.04 87.59 86.77 86.01 96.68

TC 0

(-0.01%/

°

C)2(-0.10%/

°

C)4(-0.18%/

°

C)7(-0.25%/

°

C)

V

BE

0.025 0.523 0.520 0.517

R 0.72 0.423 0.272 0.121

where

and

)

72.0

1

)0775.2(72.0025.0

(

+

−∗+

=Vref

176.1)

69.88

37

1(93.46 ∗+∗−=− VDDVL

*Note: There may be a calculation error of max. 6% when comparing with measurement values.

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

5

This is a calculated value to give the electronic engineer or designer an indication where the voltage will be generated. This value
will deviate in the actual IC performance. The maximum deviation (due to extreme cases) is 6%.

Please find below is a typical VL6 distribution:

Note: The maximum deviation takes care of the very ex­treme cases (usually less than 1%), it is guaranteed the
driver released from mass production will stay within 6%
range of the calculated VL6 value.

SUGGESTION:

It is strongly suggested in real-life situations, the calculated VL6 value should be used only as a reference information
for initial design. The actual VL6 value of the IC performance should be measured using a number of LCD modules
(normally 50 to 100 pieces) from pre-production stage or even at mass production. This value then will truly reflect
the actual performance of the IC at LCD modular level.

95%

99%

# of IC

V

L6

Figure: Normal distribution of the IC performance

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
6

SOLOMON

APPLICATION NOTE 3: HIGH FREQUENCY MODE

The high frequency mode is an enhanced feature for different applications if a higher oscillation frequency is required.
For the IC used in different countries, there is the possibility with a different mains supply frequency of e.g. 50 and 60 Hz.

Ambient light from 50 Hz system creates ambient light waves with frequencies of multiples of 50Hz, and same situation applies
to 60 Hz mains frequency system.

This multiples of 50Hz/60Hz can interact with the normal operation of the LCD module, thus creating a superimpose interaction
with the LCD module. This phenomenon, if happens, can be picked up as the “flickering” effect.

Solomon Systech Limited add an extra feature to change the oscillation frequency of its SSD181X/SSD1815A/SSD1815B series
IC during initial setup stage. This feature therefore changes the operating frame frequency of the LCD module. It is hoped that
in certain situations and areas, this phenomenon can be reduced.

Modify Oscillation Frequency command:
10101001

X7X6X5.....

For default operation: X7X6X5 = 010 (POR for SSD1811, SSD1812) : Typ. 31 kHz

X7X6X5 = 011 (POR for SSD1813, SSD1815, SSD1815A, SSD1815B) : Typ. 17 kHz

For High Frequency mode: X7X6X5 = 110 (POR for SSD1811, SSD1812) : Typ. 38 kHz

X7X6X5 = 110 (POR for SSD1813, SSD1815, SSD1815A, SSD1815B) : Typ. 19 kHz

Example:
The SSD1813 series driver IC has a typical oscillation frequency of 17kHz. By calculation, the frame frequency is then 64.4 Hz.
It is possible to shift the oscillation frequency up to a typical of 19 kHz. The frame frequency is thus shifted up to 73 Hz.
This shift of oscillation frequency can keep the display system away from the ambient light frequency and its harmonics, reducing
interference caused by these ambient light waves.

Note: Slightly higher current consumption in high frequency mode, should be considered.

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

7

APPLICATION NOTE 4: REFERENCE CIRCUIT EXAMPLE

FOR HIGH LOADING SITUATIONS

When the built-in power circuit is used to drive a liquid crystal display panel which is heavily loaded with AC or DC sig­nals, it is recommended to connect a series of external resistors to stabilize potentials of VL2, VL3, VL4 and VL5 which
are output from the built-in voltage divider (follower). The number of resistors used depends on the situations of the pan­el. SSL recommends customer to try in order to obtain the best result.

When installing the COG, or in special cases when designs that may cause high loading situations for the driver IC. It
is necessary to consider the fact that there exists a resistance of the ITO wiring occurring between the driver chip and
the externally connected parts (such as capacitors and resistors). By the influence of this resistance, non-conformity
may occur with the indications on the liquid crystal display.

Therefore, when installing the COG design the module paying sufficient considerations to the following situations:

- suppress the resistance occurring between the driver chip pin to the externally connected parts as much as possible.

- suppress the resistance connecting to the power supply pin of the driver chip.

- make various COG module samples with different ITO sheet resistance to select the module with the sheet resistance
with sufficient operation margin.

As a rule of thumb, it is more preferred to use lower resistance ITO glass panels. Normally we recommend customers
to use below 15ohm square ITO glass panels.

Example:
Please find the following circuit a recommendation to LCD module designers that in case of large loading situations, it

is possible to maximize the stability of the Voltage booster output.

Remarks: 1. C1 ~ C5 = 0.1 ~ 0.47uF

2. R1 ~ R4 = 100k ohm~ 1M ohm

V

DD

V

L2

V

L3

V

L4

V

L5

V

L6

R3 R1

R2

R4

+

V

DD

C5

+

C4

+

C3

+

C2

+

C1

SSD181X/SSD1815A/SSD1815B Series

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
8

SOLOMON

APPLICATION NOTE 5: VF PROTECTION

FOR POTENTIAL HIGH RF INTERFERENCE SITUATIONS

There are situations when the design of the LCD driver circuits is in close proximity with the RF components/circuits,
and noise generated from the RF circuit, will potentially affect the general performance of the LCD. There are cases
where interference may cause distortion to VF circuit operation, thus it may have an unexpected effect on the LCD dis­play.

Function of the VF circuit: Circuit design which is using external resistor network (IRS pulled low), the VF pin is the volt-

age feedback of the built-in voltage regulator for generating VL6. In order to generate the LCD
driving level, VL6, two external resistors, R1 and R2 should be connected between VDD and
VF, and VF and VL6, respectively.

Further study needs to be done in a very careful manner, but there are a few precautions that can be done during the
PCB design stage:

1) Layout consideration: PCB design should be carefully designed, so that VF circuit can be placed as far as possible
from the RF circuit. The placement of the external components in VF circuit should be avoided to form a close loop an­tenna, so as to reduce the chance of RF interference. Reducing the total length of the external circuit from the VF pin
will help improve the immunity to RF signal.

2) VF circuit: If external resistor network is used, the noise immunity of VF can be further improved by an additional fil­tering capacitor as indicated in the circuit below:

This circuit will act as a feedback path which reduce the RF interference.

3) Selection of R1& R2: It is recommended in some of the designs using the values of R1+R2 - less than 1.5 Mohm.

4) Shielding: Shielding is the most effective way to resist RF noise. By covering up the VF pin and other external com­ponents with a metal foil connected to GND, will provide the best result.

VL6 VDDVF

0.1uF

R2 R1

0.01uF

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

9

APPLICATION NOTE 6: CASCADE OPERATION

FOR SSD181X/SSD1815A/SSD1815B

Two SSD181X/SSD1815A/SSD1815B ICs can be cascaded to form a “master amd slave” system which enlarge the
maximum display size to 264 segment x 64 common. The master device generates all the necessary analog and digital
control signals for the slave device. The following section summarizes some important note of the system.

Analog control part:
It is obvious that both master and slave devices should have the same LCD driving capability under various operating
conditions. The LCD driving voltage of the whole cascade system is generated by the analog circuitry of the master de­vice. The analog circuitry consists of DC-DC voltage booster, voltage reguator with contrast control, temperature com­pensation circuitry and voltage divider. The divider levels of the master device, which includes VL2 to VL6, are used to
generate the divider levels of the slave device. The implementations are carried out by:

1. Connect all the divider output pins (VL2 to VL6) of master device to the slave device.

2. Disable all the analog circuitry in the slave device by software command (28H).
Digital control part:

The communication between master and slave device is carried out by three signals. These three signals are Frame
signal (M), display blanking signal (DOFF) and the system clock signal (CL). The master device provides the frame,
display blanking and the system clock signals to the slave device. As a result, the slave device is synchronized with the
master device. The data interface of the master and slave devices should be the same, either parallel or serial interface.
The clock selection pins of the master and slave devices should be the same, either external or internal clock mode.

The following digram shows an example of the cascade application. The product features are listed below.

- Maximum display size: 264 segment x 64 common

- Driving scheme: 4-lines serial interface

- Supply Vdd: 2.4 to 3.5V

- VLCD driving voltage: - 9.3V

- Regulator, clock, contrast control: All internal mode

- Boosting configuration: 4X boosting mode

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
10

SOLOMON

Remarks:

1) The following pins should be floated in master device: VFS, Dummy

2) The following pins should be floated in slave device: VFS, VEE, C3N, C1P, C1N,
C2P, C2N, Dummy

3) Recommended value of capacitors:
C1 to C4: 0.47uF - 1uF
C5 to C14: 0.1uF - 0.47uF

4) Software commands
Master Slave Descriptions
2FH 28H Enable all the analog circuit of the master device

Disable all the analog circuit of the slave device

5) Optional capacitors (0.01u to 0.1uF) should be connected across the VL6 and VF

ROW63 ~ ROW 32

COM0 ~ COM31

COM32 ~ COM63

LCD PANEL

+++

+

C1

C2C3

C4

C5C6C7C8C9

/CS1
/RES

D/C

SCK

SDA

VDD

SEG131 ~ SEG0

MASTER

VDD

VDD

VDD

VDD

VDD

M, CL, /DOF, are connected

to slave device

C10C11C12C13C14

CS2

/RES, SCK, SDA, D/C

are connected to Master device

VDD

SEG263 ~ SEG132

SLAVE

VDD

VDD

VDD

M, /DOF, CL

are connected to master device

VDD

VL6 to VL2 from

Master device

VL6 to VL2

connected to Slave

device

SDA, SCK, /RES,D/C are

connected to Slave device

ROW0 ~ ROW 31

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

11

Appendix I Instruction Setup: (For reference)

This section discuss on the initialization, write display data and power off routines of the SSD181X/SSD1815A/SSD1815B.
When the power is applied, the VL5 to VL2 levels are non-selected. The non-selective levels are output through the LCD driv­ing output pins, i.e., Segment and Common. The residual electric charge of the stabilizing capacitors, which is connected

across the VL6 ~ VL2 levels and Vdd, may induce back into the device. As a result, the LCD panel display totally black instan­taneously during the power is turning on. We recommended the following power up sequence in order to prevent the unex­pected flashing on the display.

/RES pin is set to "Low" when the power across VDD-VSS is turned on

/RES pin is set to "High" after the power across VDD-VSS is stable

Initialization routine start

Set LCD bias

Set Segment Re-map

Set COM Output Scan Direction

Set Internal Regulator Resistor Ratio

Set Contrast Control Register

Set Power Control Register

Initialization routine end

LCD Power Levels

are not stable

LCD Power levels are stable

Instruction routine: Normal procedure
Case 1 –The built-in power is used immediately after turning on the power supply

Remarks: Initialization routine lasts for 5 ms. The estimated time 5 ms vary depending on the panel characteristics
and the capacitance of stabilizing capacitors. Please ensure a proper operation check is performed by actual
equipment.

/RES pin is set to "Low" when the power across VDD-VSS is turned on

/RES pin is set to "High" after the power across VDD-VSS is stable

Initialization routine start

Set LCD bias

Set Segment Re-map

Set COM Output Scan Direction

Set Internal Regulator Resistor Ratio

Set Contrast Control Register

Set Power Control Register

Initialization routine end

LCD Power Levels

are not stable

LCD Power levels are stable

Instruction routine:
Case 1 –The built-in power is used immediately after turning on the power supply

Remarks: Initialization routine lasts for 5 ms. The estimated time 5 ms vary depending on the panel characteristics
and the capacitance of stabilizing capacitors. Please ensure a proper operation check is performed by actual
equipment.

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules
12

SOLOMON

Hardware /RES pin is set to "Low" when the power across VDD-VSS is turned on

Hardware /RES pin is set to "High" after the power across VDD-VSS is stable

Initialization routine start

Set LCD bias

Set Segment Re-map

Set COM Output Scan Direction

Set Internal Regulator Resistor Ratio

Set Contrast Control Register

Set Power Control Register

Initialization routine end

Set Power Save Mode

Exit Power Save Mode by pulling harware /RES pin to "Low"

Exit Power Save Mode by issue of a new software command

LCD Power Levels are not unstable

LCD Power levels are stable

Instruction routine: Escape from power save mode procedure
Case 2 –The built-in power is not used immediately after turning on the power supply

Remarks: Initialization routine lasts for 5 ms. The estimated time 5 ms vary depending on the panel
characteristics and the capacitance of stabilizing capacitors. Please ensure a proper operation check is
performed by actual equipment.

Hardware /RES pin is set to "Low" when the power across VDD-VSS is turned on

Hardware /RES pin is set to "High" after the power across VDD-VSS is stable

Initialization routine start

Set LCD bias

Set Segment Re-map

Set COM Output Scan Direction

Set Internal Regulator Resistor Ratio

Set Contrast Control Register

Set Power Control Register

Initialization routine end

Set Power Save Mode

Exit Power Save Mode by pulling harware /RES pin to "Low"

Exit Power Save Mode by issue of a new software command

LCD Power Levels are not unstable

LCD Power levels are stable

Instruction routine:
Case 2 –The built-in power is not used immediately after turning on the power supply

Remarks: Initialization routine lasts for 5 ms. The estimated time 5 ms vary depending on the panel
characteristics and the capacitance of stabilizing capacitors. Please ensure a proper operation check is
performed by actual equipment.

SOLOMON

Application of SSD181X/SSD1815A/SSD1815B to Existing LCD Modules

13

Initialization routine end

Write display data end

Set Display On/Off

Set Display Start Line

Set Page Address
Set Higher Column Address
Set Lower Column Address

Write Display Data

Write Display Data

Write Display

Data

For any status (Optional)

Power off routine end

Set Power Save Mode

Hardware /RES pin is set to "Low"

Power across VDD-VSS is turned off

Display data routine:

Power Off routine:

Remarks: Set the time from “hardware reset active” to “power across VDD-VSS is turned-off” (t

OFF

)to be longer than

The time when the potential of VL6 to VL2 becomes lower than the threshold voltage of the LCD panel(tTH)
(Approximate 1V). If tTHis too long, resistor should be connected between VL2 and VDD such that t

TH

Will be reduced.

Initialization routine end

Write display data end

Set Display On/Off

Set Display Start Line

Set Page Address
Set Higher Column Address
Set Lower Column Address

Write Display Data

Write Display Data

Write Display

Data

For any status (Optional)

Power off routine end

Set Power Save Mode

Hardware /RES pin is set to "Low"

Power across VDD-VSS is turned off

Display data routine:

Power Off routine:

Remarks: Set the time from “hardware reset active” to “power across VDD-VSS is turned-off” (t

OFF

)to be longer than

The time when the potential of VL6 to VL2 becomes lower than the threshold voltage of the LCD panel(tTH)
(Approximate 1V). If tTHis too long, resistor should be connected between VL2 and VDD such that t

TH

Will be reduced.

Solomon reserves the right to make changes without further notice to any products herein. Solomon makes no warranty, representation or guarantee regarding
the suitability of its products for any particular purpose, nor does Solomon assume any liability arising out of the application or use of any product or circuit, and
specifically disclaims any and all liability, including without limitation consequential or incidental damages. “Typical” parameters can and do vary in different appli­cations. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. Solomon does not con­vey any license under its patent rights nor the rights of others.Solomon products are not designed, intended, or authorized for use as components in systems
intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the Solomon
product could create a situation where personal injury or death may occur. Should Buyer purchase or use Solomon products for any such unintended or unau­thorized application, Buyer shall indemnify and hold Solomon and its offices, employees, subsidiaries, affiliates, and distributors harmless against all claims,
costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unin­tended or unauthorized use, even if such claim alleges that Solomon was negligent regarding the design or manufacture of the part.

SSD181XAN01
