Data Sheet January 1998

Electronic Protection Array for ESD and
Over-Voltage Protection

The SP720 is an array of SCR/Diode bipolar structures for
ESD and over-voltage protection to sensitive input circuits.
The SP720 has 2 protection SCR/Diode device structures
per input. A total of 14 available inputs can be used to
protect up to 14 external signal or bus lines. Over-voltage
protection is from the IN (pins 1-7 and 9-15) to V+ or V-. The
SCR structures are designed for fast triggering at a
threshold of one +V
a -V

diode threshold below V- (Pin 8). From an IN input, a

BE

clamp to V+ is activated if a transient pulse causes the input
to be increased to a voltage level greater than one V
above V+. A similar clamp to V- is activated if a negative
pulse, one V
Standard ESD Human Body Model (HBM) Capability is:

HBM STANDARD MODE R C ESD (V)

IEC 1000-4-2 Air 330 Ω 150pF >15kV

MIL-STD-3015.7 Direct, In-circuit 1.5k Ω 100pF >15kV

Refer to Figure 1 and Table 1 for further detail. Refer to
Application Note AN9304 and AN9612 for additional
information.

BE

diode threshold above V+ (Pin 16) or

BE

less than V-, is applied to an IN input.

Direct 330 Ω 150pF >4kV

Direct, Dual Pins 330 Ω 150pF >8kV

BE

Ordering Information

TEMP. RANGE

PART NO.

SP720AP -40 to 105 16 Ld PDIP E16.3

SP720AB -40 to 105 16 Ld SOIC M16.15

SP720ABT -40 to 105 16 Ld SOIC

o

(

C) PACKAGE

Tape and Reel

PKG.

NO.

M16.15

Pinout

SP720 (PDIP, SOIC)

TOP VIEW

16

1

IN

2

IN

3

IN

4

IN

5

IN

6

IN

7

IN

8

V-

V+

15

IN

14

IN

13

IN

12

IN

11

IN

10

IN

9

IN

File Number 2791.10

Features

• ESD Interface Capability for HBM Standards

- MIL STD 3015.7 . . . . . . . . . . . . . . . . . . . . . . . . . . .15kV

- IEC 1000-4-2, Direct Discharge,

Single Input. . . . . . . . . . . . . . . . . . . . . . . . 4kV (Level 2)

Two Inputs in Parallel . . . . . . . . . . . . . . . . 8kV (Level 4)

- IEC 1000-4-2, Air Discharge. . . . . . . . . . 15kV (Level 4)

• High Peak Current Capability

- IEC 1000-4-5 (8/20 µ s) . . . . . . . . . . . . . . . . . . . . . . ± 3A

- Single Pulse, 100 µ s Pulse Width . . . . . . . . . . . . . . ± 2A

- Single Pulse, 4 µ s Pulse Width . . . . . . . . . . . . . . . . ± 5A

• Designed to Provide Over-Voltage Protection

- Single-Ended Voltage Range to . . . . . . . . . . . . . . .+30V

- Differential Voltage Range to . . . . . . . . . . . . . . . . ± 15V

• Fast Switching . . . . . . . . . . . . . . . . . . . . . . . 2ns Risetime

• Low Input Leakages . . . . . . . . . . . . . . . 1nA at 25

• Low Input Capacitance. . . . . . . . . . . . . . . . . . . . 3pF (Typ)

• An Array of 14 SCR/Diode Pairs

• Operating Temperature Range . . . . . . . . . -40

o

C (Typ)

o

C to 105

o

Applications

• Microprocessor/Logic Input Protection

• Data Bus Protection

• Analog Device Input Protection

• Voltage Clamp

Functional Block Diagram

V+

16

3 - 7

IN

1

IN

V-

8

2

9 - 15

IN

C

6-3

NOTE: The design of the SP720 SCR/Diode ESD Protection Arrays is covered by Littelfuse patent

1-800-999-9445 or 1-847-824-1188

Copyright

|

Littelfuse, Inc. 1998

©

4567500.

Ω

±

SP720

Absolute Maximum Ratings Thermal Information

Continuous Supply Voltage, (V+) - (V-) . . . . . . . . . . . . . . . . . . +35V

Forward Peak Current, I

(Refer to Figure 6) . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 2A, 100 µ s

IN

to V

CC

, I

to GND

IN

ESD Ratings and Capability (Figure 1, Table 1)
Load Dump and Reverse Battery (Note 2)

Thermal Resistance (Typical, Note 1) . . . . . . . . . . . . .

PDIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

SOIC Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Maximum Storage Temperature Range. . . . . . . . . . -65

Maximum Junction Temperature (Plastic Package) . . . . . . . . .150

Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . .300

(SOIC Lead Tips Only)

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

NOTE:

1. θ

is measured with the component mounted on an evaluation PC board in free air.

JA

(

θ

JA

o

C to 150

o

C/W)

o
o
o

C
C
C

Electrical Specifications

T

= -40

A

o

C to 105

o

C; V

= 0.5V

IN

, Unless Otherwise Specified

CC

PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS

Operating Voltage Range,
V

SUPPLY

= [(V+) - (V-)]

Forward Voltage Drop:

IN to V­IN to V+

Input Leakage Current I

Quiescent Supply Current I

V

SUPPLY

V

FWDL

V

FWDH

IN

QUIESCENT

I

= 1A (Peak Pulse)

IN

- 2 to 30 - V

-

-

2
2

-

-

-20 5 20 nA

- 50 200 nA

V
V

Equivalent SCR ON Threshold Note 3 - 1.1 - V

Equivalent SCR ON Resistance V

Input Capacitance C

Input Switching Speed t

IN

ON

FWD

/I

; Note 3 - 1 -

FWD

-3-pF

-2-ns

NOTES:

2. In automotive and battery operated systems, the power supply lines should be externally protected for load dump and reverse battery. When the
V+ and V- pins are connected to the same supply voltage source as the device or control line under protection, a current limiting resistor should
be connected in series between the external supply and the SP720 supply pins to limit reverse battery current to within the rated maximum
limits. Bypass capacitors of typically 0.01 µ F or larger from the V+ and V- pins to ground are recommended.

3. Refer to the Figure 3 graph for definitions of equivalent “SCR ON Threshold” and “SCR ON Resistance.” These characteristics are given here
for thumb-rule information to determine peak current and dissipation under EOS conditions.

ESD Capability

ESD capability is dependent on the application and defined
test standard. The evaluation results for various test
standards and methods based on Figure 1 are shown in
Table 1.

For the “Modified” MIL-STD-3015.7 condition that is defined
as an “in-circuit” method of ESD testing, the V+ and V- pins
have a return path to ground and the SP720 ESD capability
is typically greater than 15kV from 100pF through 1.5k Ω . By
strict definition of MIL-STD-3015.7 using “pin-to-pin” device
testing, the ESD voltage capability is greater than 6kV. The
MIL-STD-3015.7 results were determined from AT&T ESD
Test Lab measurements.

The HBM capability to the IEC 1000-4-2 standard is greater
than 15kV for air discharge (Level 4) and greater than 4kV
for direct discharge (Level 2). Dual pin capability (2 adjacent
pins in parallel) is well in excess of 8kV (Level 4).

For ESD testing of the SP720 to EIAJ IC121 Machine Model
(MM) standard, the results are typically better than 1kV from

STANDARD TYPE/MODE R

MIL STD 3015.7 Modified HBM 1.5k Ω 100pF 15kV

IEC 1000-4-2 HBM, Air Discharge 330 Ω 150pF 15kV

EIAJ IC121 Machine Model 0k Ω 200pF 1kV

TABLE 1. ESD TEST CONDITIONS

C

D

D

Standard HBM 1.5k Ω 100pF 6kV

HBM, Direct Discharge 330 Ω 150pF 4kV

HBM, Direct Discharge,

330 Ω 150pF 8kV

Two Parallel Input Pins

R

H.V.

SUPPLY

°±V

D

R

1

CHARGE
SWITCH

IEC 1000-4-2: R150 to 100MΩ

MIL STD 3015.7: R11 to 10MΩ

C

D

D

DISCHARGE

SWITCH

IN

DUT

FIGURE 1. ELECTROSTATIC DISCHARGE TEST

200pF with no series resistance.

V

D

6-4

SP720

100

TA = 25oC
SINGLE PULSE

80

60

40

FORWARD SCR CURRENT (mA)

20

0

600 800 1000 1200

FORWARD SCR VOLTAGE DROP (mV)

FIGURE 2. LOW CURRENT SCR FORWARD VOLTAGE DROP

CURVE

+V

CC

2.5
TA = 25oC

SINGLE PULSE

2

1.5

1

FORWARD SCR CURRENT (A)

0.5

0

EQUIV. SAT. ON
THRESHOLD ~ 1.1V

01 23

FORWARD SCR VOLTAGE DROP (V)

V

FWD

I

FWD

FIGURE 3. HIGH CURRENT SCR FORWARD VOLTAGE DROP

CURVE

+V

CC

INPUT

DRIVERS

OR

SIGNAL

SOURCES

SP720

SP720 INPUT
PROTECTION CIRCUIT
(1 OF 14 ON CHIP)

LINEAR OR
DIGITAL IC
INTERFACE

V+

V-

TO +V

CC

IN 9-15IN 1-7

FIGURE 4. TYPICAL APPLICATION OF THE SP720 AS AN INPUT CLAMP FOR OVER-VOLTAGE, GREATER THAN 1V

LESS THAN -1V

BELOW V-

BE

6-5

ABOVE V+ OR

BE

SP720

Peak Transient Current Capability of the SP720

The peak transient current capability rises sharply as the
width of the current pulse narrows. Destructive testing was
done to fully evaluate the SP720’s ability to withstand a wide
range of transient current pulses. The circuit used to
generate current pulses is shown in Figure 5.

The test circuit of Figure 5 is shown with a positive pulse
input. For a negative pulse input, the (-) current pulse input
goes to an SP720 ‘IN’ input pin and the (+) current pulse
input goes to the SP720 V- pin. The V+ to V- supply of the
SP720 must be allowed to float. (i.e., It is not tied to the
ground reference of the current pulse generator.) Figure 6
shows the point of overstress as defined by increased
leakage in excess of the data sheet published limits.

The maximum peak input current capability is dependent on
the V+ to V- voltage supply level, improving as the supply
voltage is reduced. Values of 0, 5, 15 and 30 voltages are
shown. The safe operating range of the transient peak
current should be limited to no more than 75% of the
measured overstress level for any given pulse width as
shown in Figure 6.

When adjacent input pins are paralleled, the sustained peak
current capability is increased to nearly twice that of a single
pin. For comparison, tests were run using dual pin
combinations 1+2, 3+4, 5+6, 7+9, 10+11, 12+13 and 14+15.

The overstress curve is shown in Figure 6 for a 15V supply
condition. The dual pins are capable of 10A peak current for
a 10 µ s pulse and 4A peak current for a 1ms pulse. The
complete for single pulse peak current vs. pulse width time
ranging up to 1 second are shown in Figure 6.

VARIABLE TIME DURATION

+

V

G

-

R1 ~ 10Ω TYPICAL
VG ADJ. 10V/A TYPICAL
C1 ~ 100µF

R

1

VOLTAGE

PROBE

FIGURE 5. TYPICAL SP720 PEAK CURRENT TEST CIRCUIT

WITH A VARIABLE PULSE WIDTH INPUT

CURRENT PULSE GENERATOR

CURRENT

SENSE

(+)

1

IN

2

IN

IN

3

4

IN

5

IN

6

IN

7

IN

8

V-

SP720

V+

IN

IN

IN

IN

IN

IN

IN

(-)

16

15

14

13

12

11

10

9

C1

+

-

10

9

8

7

6

5

4

PEAK CURRENT (A)

3

2

1

0

0.001 0.01 0.1 1

CAUTION: SAFE OPERATING CONDITIONS LIMIT

THE MAXIMUM PEAK CURRENT FOR A GIVEN
PULSE WIDTH TO BE NO GREATER THAN 75%
OF THE VALUES SHOWN ON EACH CURVE.

SINGLE PIN STRESS CURVES
DUAL PIN STRESS CURVE

0V
5V

30V

V+ TO V- SUPPLY

PULSE WIDTH TIME (ms)

10

15V

15V

100 1000

FIGURE 6. SP720 TYPICAL SINGLE PULSE PEAK CURRENT CURVES SHOWING THE MEASURED POINT OF OVER-STRESS IN

AMPERES vs PULSE TIME IN MILLISECONDS (TA = 25oC)

6-6

Dual-In-Line Plastic Packages (PDIP)

SP720

N

D1

-C-

E1

-B-

A1

A2

E

A

L

e

C

C

L

e

A

C

e

B

INDEX

AREA

BASE

PLANE

SEATING

PLANE

D1

B1

1 2 3 N/2

-A­D

e

B

0.010 (0.25) C AM BS

NOTES:

1. Controlling Dimensions: INCH. In case of conflict between English and
Metric dimensions, the inch dimensions control.

2. Dimensioning and tolerancing per ANSI Y14.5M-1982.

3. Symbols are defined in the “MO Series Symbol List” in Section 2.2 of
Publication No. 95.

4. Dimensions A, A1 and L are measured with the package seated in JE­DEC seating plane gauge GS-3.

5. D, D1, and E1 dimensions do not include mold flash or protrusions.
Mold flash or protrusions shall not exceed 0.010 inch (0.25mm).

6. E and are measured with the leads constrained to be perpendic-

e

A

ular to datum .

-C-

7. eB and eC are measured at the lead tips with the leads unconstrained.
eC must be zero or greater.

8. B1 maximum dimensions do not include dambar protrusions. Dambar
protrusions shall not exceed 0.010 inch (0.25mm).

9. N is the maximum number of terminal positions.

10. Corner leads (1, N, N/2 and N/2 + 1) for E8.3, E16.3, E18.3, E28.3,
E42.6 will have a B1 dimension of 0.030 - 0.045 inch (0.76 - 1.14mm).

E16.3

(JEDEC MS-001-BB ISSUE D)

16 LEAD DUAL-IN-LINE PLASTIC PACKAGE

INCHES MILLIMETERS

SYMBOL

NOTESMIN MAX MIN MAX

A - 0.210 - 5.33 4

A1 0.015 - 0.39 - 4

A2 0.115 0.195 2.93 4.95 -

B 0.014 0.022 0.356 0.558 -

B1 0.045 0.070 1.15 1.77 8, 10

C 0.008 0.014 0.204 0.355 -

D 0.735 0.775 18.66 19.68 5

D1 0.005 - 0.13 - 5

E 0.300 0.325 7.62 8.25 6

E1 0.240 0.280 6.10 7.11 5

e 0.100 BSC 2.54 BSC -

e

A

e

B

0.300 BSC 7.62 BSC 6

- 0.430 - 10.92 7

L 0.115 0.150 2.93 3.81 4

N16 169

Rev. 0 12/93

6-7

Small Outline Plastic Packages (SOIC)

SP720

N

INDEX
AREA

123

SEATING PLANE

-A­D

e

B

0.25(0.010) C AM BS

M

E

-B-

A

-C-

0.25(0.010) BM M

H

α

µ

A1

0.10(0.004)

L

h x 45

o

C

NOTES:

1. Symbols are defined in the “MO Series Symbol List” in Section 2.2 of
Publication Number 95.

2. Dimensioning and tolerancing per ANSI Y14.5M-1982.

3. Dimension “D” does not include mold flash, protrusions or gate burrs.
Mold flash, protrusion and gate burrs shall not exceed 0.15mm (0.006
inch) per side.

4. Dimension “E” does not include interlead flash or protrusions. Interlead
flash and protrusions shall not exceed 0.25mm (0.010 inch) per side.

5. The chamfer on the body is optional. If it is not present, a visual index
feature must be located within the crosshatched area.

6. “L” is the length of terminal for soldering to a substrate.

7. “N” is the number of terminal positions.

8. Terminal numbers are shown for reference only.

9. The lead width “B”, as measured 0.36mm (0.014 inch) or greater above
the seating plane, shall not exceed a maximum value of 0.61mm
(0.024 inch).

10. Controlling dimension: MILLIMETER. Converted inch dimensions are
not necessarily exact.

M16.15 (JEDEC MS-012-AC ISSUE C)

16 LEAD NARROW BODY SMALL OUTLINE PLASTIC
PACKAGE

INCHES MILLIMETERS

SYMBOL

A 0.0532 0.0688 1.35 1.75 -

A1 0.0040 0.0098 0.10 0.25 -

B 0.013 0.020 0.33 0.51 9

C 0.0075 0.0098 0.19 0.25 -

D 0.3859 0.3937 9.80 10.00 3

E 0.1497 0.1574 3.80 4.00 4

e 0.050 BSC 1.27 BSC -

H 0.2284 0.2440 5.80 6.20 -

h 0.0099 0.0196 0.25 0.50 5

L 0.016 0.050 0.40 1.27 6

N16 167

o

α

0

o

8

o

0

o

8

Rev. 0 12/93

NOTESMIN MAX MIN MAX

-

6-8
