RURD840, RURD860, RURD840S, RURD860S

Data Sheet January 2000

8A, 400V - 600V Ultrafast Diodes

The RURD840, RURD860, RURD840S and RURD860S are
ultrafast dual diodes with soft recovery characteristics
(t

< 60ns). They have low forward voltage drop and are

rr

silicon nitride passivated ion-implanted epitaxial planar
construction.

These devices are intended for use as freewheeling/
clamping diodesandrectifiers in a variety of switching power
supplies and other power switching applications. Their low
stored charge and ultrafast soft recovery minimize ringing
and electrical noise in many power switching circuits
reducing power loss in the switching transistors.

Formerly developmental type TA09616.

Ordering Information

PART NUMBER PACKAGE BRAND

RURD840 TO-251 RUR840
RURD860 TO-251 RUR860
RURD840S TO-252 RUR840
RURD860S TO-252 RUR860

NOTE: Whenordering,usetheentirepart number.Addthesuffix 9A
to obtain the TO-252 variant in tape and reel, e.g. RURD860S9A.

File Number 4033.1

Features

• Ultrafast with Soft Recovery . . . . . . . . . . . . . . . . . . .<60ns

• Operating Temperature. . . . . . . . . . . . . . . . . . . . . . .175

o

• Reverse Voltage Up To. . . . . . . . . . . . . . . . . . . . . . . .600V

• Avalanche Energy Rated

• Planar Construction

Applications

• Switching Power Supplies

• Power Switching Circuits

• General Purpose

Packaging

JEDEC STYLE TO-251

ANODE

CATHODE

CATHODE
(FLANGE)

C

Symbol

K

A

Absolute Maximum Ratings T

Peak Repetitive Reverse Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

Working Peak Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V

DC Blocking Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V

Average Rectified Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

(TC = 155oC)

Repetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

(Square Wave, 20kHz)

Nonrepetitive Peak Surge Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

(Halfwave, 1 Phase, 60Hz)

Maximum Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P

Avalanche Energy (See Figures 10 and 11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E

Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T

Maximum Lead Temperature for Soldering

Leads at 0.063in (1.6mm) from Case for 10s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

Package Body for 10s, See Tech Brief 334 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

= 25oC, Unless Otherwise Specified

C

RRM

RWM

F(AV)

FRM

FSM

STG

PKG

AVL

, T

JEDEC STYLE TO-252

CATHODE

ANODE

RURD840

RURD840S

400 600 V
400 600 V

R

D

J

L

400 600 V

88A

16 16 A

40 40 A

75 75 W
20 20 mJ

-65 to 175 -65 to 175

300 300
260 260

CATHODE
(FLANGE)

RURD860

RURD860S UNITS

o

C

o

C

o

C

1

1-888-INTERSIL or 321-724-7143 | Copyright © Intersil Corporation 2000

RURD840, RURD860, RURD840S, RURD860S

Electrical Specifications T

= 25oC, Unless Otherwise Specified

C

RURD840, RURD840S RURD860, RURD860S

SYMBOL TEST CONDITION

V

F

IF = 8A - - 1.5 - - 1.5 V
IF = 8A, TC = 150oC - - 1.3 - - 1.3 V

I

R

VR = 400V - - 100 - - - µA
VR = 600V - - - - - 100 µA
VR = 400V, TC = 150oC - - 500 - - - µA
VR = 600V, TC = 150oC -----500µA

t

rr

IF = 1A, dIF/dt = 200A/µs - -60- -60ns
IF = 8A, dIF/dt = 200A/µs - -70- -70ns

t

a

t

b

Q

RR

C

J

R

θJC

IF = 8A, dIF/dt = 200A/µs - 32 - - 32 - ns
IF = 8A, dIF/dt = 200A/µs - 21 - - 21 - ns
IF = 8A, dIF/dt = 200A/µs - 195 - - 195 - nC
VR = 10V, IF = 0A - 25 - - 25 - pF

--2--2oC/W

DEFINITIONS

VF = Instantaneous forward voltage (pw = 300µs, D = 2%).

IR = Instantaneous reverse current.
trr = Reverse recovery time (See Figure 9), summation of ta + tb.

ta = Time to reach peak reverse current (See Figure 9).
tb = Time from peak IRM to projected zero crossing of IRM based on a straight line from peak IRM through 25% of IRM (See Figure 9).

QRR = Reverse recovery charge.

CJ = Junction Capacitance.

R

= Thermal resistance junction to case.

θJC

pw = pulse width.

D = duty cycle.

UNITSMIN TYP MAX MIN TYP MAX

Typical Performance Curves

40

10

100oC

, FORWARD CURRENT (A)

F

I

1

0.5
0 0.5 1 1.5 2 2.5

175oC

25oC

VF, FORWARD VOLTAGE (V)

FIGURE 1. FORWARD CURRENT vs FORWARD VOLTAGE FIGURE 2. REVERSE CURRENT vs REVERSE VOLTAGE

2

500

100

10

1

, REVERSE CURRENT (µA)

0.1

R

I

0.01
0 200 400 600300 500

100

VR, REVERSE VOLTAGE (V)

175oC

100oC

25oC

RURD840, RURD860, RURD840S, RURD860S

Typical Performance Curves (Continued)

60

TC = 25oC, dIF/dt = 200A/µs

50

40

t

30

20

t, RECOVERY TIMES (ns)

10

0

0.5 8

rr

t

a

t

b

1

IF, FORWARD CURRENT (A)

4

100

TC = 100oC, dIF/dt = 200A/µs

80

60

40

t, RECOVERY TIMES (ns)

20

0

0.5

t

rr

t

a

t

b

IF, FORWARD CURRENT (A)

FIGURE 3. trr,taAND tbCURVES vs FORWARD CURRENT FIGURE 4. trr,taAND tbCURVES vs FORWARD CURRENT

125

TC = 175oC, dIF/dt = 200A/µs

100

75

t

rr

8

DC

6

SQ. WAVE

4

814

50

t, RECOVERY TIMES (ns)

25

0

0.5

t

a

t

b

, FORWARD CURRENT (A)

I

F

814

2

, AVERAGE FORWARD CURRENT (A)

F(AV)

I

0

140 145 155 175165

150

, CASE TEMPERATURE (oC)

T

C

160 170

FIGURE 5. trr,taAND tbCURVES vs FORWARD CURRENT FIGURE 6. CURRENT DERATING CURVE

100

80

60

40

20

, JUNCTION CAPACITANCE (pF)

J

C

0

0 50 100 150 200

VR, REVERSE VOLTAGE (V)

FIGURE 7. JUNCTION CAPACITANCE vs REVERSE VOLTAGE

3

RURD840, RURD860, RURD840S, RURD860S

Test Circuits and Waveforms

VGE AMPLITUDE AND
RG CONTROL dIF/dt
t

V

GE

I = 1A
L = 40mH
R < 0.1Ω
E

Q

1 ANDt2

= 1/2LI2 [V

AVL

= IGBT (BV

1

CONTROL I

t

1

R(AVL)

CES

F

R

t

2

FIGURE 8. trr TEST CIRCUIT FIGURE 9. trr WAVEFORMS AND DEFINITIONS

/(V

R(AVL)

> DUT V

R(AVL)

L

DUT

G

IGBT

- VDD)]
)

CURRENT

SENSE

LR

dI

F

I

F

+

V

DD

-

0

dt

t

rr

t

a

V

AVL

t

b

0.25 I

RM

I

RM

CURRENT

Q

1

SENSE

DUT

+
V

DD

V

DD

-

IV

t

0

I

L

I

L

t

1

t

2

FIGURE 10. AVALANCHE ENERGY TEST CIRCUIT FIGURE 11. AVALANCHE CURRENT AND VOLTAGE

WAVEFORMS

t
